Thank you for purchasing this Samsung mobile device.
This device will provide you with high quality mobile
communication and entertainment based on Samsung’s
exceptional technology and high standards.
This user manual has been specially designed to guide you
through the functions and features of your device.
Read me first
●
Please read all safety precautions and this manual carefully
before using your device to ensure safe and proper use.
●
The descriptions in this manual are based on the default
settings of your device.
●
Images and screenshots used in this user manual may differ
in appearance from the actual product.
●
Content in this user manual may differ from the product,
or from software provided by service providers or carriers,
and is subject to change without prior notice. Refer to
www.samsung.com/hk for the latest version of the user
manual.
●
Available features and additional services may vary by
device, software, or service provider.
●
Formatting and delivery of this user manual is based on
Bada operating systems and may vary depending on the
user’s operating system.
●
Applications and their functions may vary by country,
region, or hardware specifications. Samsung is not liable for
performance issues caused by third-party applications.
●
Samsung is not liable for performance issues or
incompatibilities caused by edited registry settings or
modified operating system software. Attempting to
customise the operating system may cause your device or
applications to work improperly.
Using this manual
3
●
You may upgrade your mobile device’s software by
accessing www.samsung.com/hk.
●
Software, sound sources, wallpapers, images, and other
contents provided in this device are licenced for limited use
between Samsung and their respective owners. Extracting
and using these materials for commercial or other purposes
is an infringement of copyright laws. Samsung is not liable
for such copyright infringement by the user.
●
Please keep this manual for future reference.
Instructional icons
Before you start, familiarise yourself with the icons you will
see in this manual:
Warning—situations that could cause injury to
yourself or others
Caution—situations that could cause damage to
your device or other equipment
►
→
[]
Note—notes, usage tips, or additional information
Refer to—pages with related information; for
example:
► p. 12 (represents “see page 12”)
Followed by—the order of options or menus you
must select to perform a step; for example: In Menu
laws.
No part of this user manual may be reproduced, distributed,
translated, or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording,
or storing in any information storage and retrieval system,
without the prior written permission of Samsung Electronics.
Trademarks
●
SAMSUNG and the SAMSUNG logo are registered
trademarks of Samsung Electronics.
●
Headphone and WOW HD technologies are incorporated
under licence from SRS Labs, Inc.
●
Bluetooth
Inc. worldwide.
●
Oracle and Java are registered trademarks of Oracle and/
or its affiliates. Other names may be trademarks of their
respective owners.
●
Windows Media Player
Microsoft Corporation.
●
Wi-Fi
Wi-Fi logo are registered trademarks of the Wi-Fi Alliance.
●
All other trademarks and copyrights are the property of
their respective owners.
and are trademarks of SRS Labs, Inc. CS
is a registered trademark of the Bluetooth SIG,
®
is a registered trademark of
®
, Wi-Fi Protected Setup™, Wi-Fi CERTIFIED™, and the
Use only Samsung-approved software. Pirated or illegal
software may cause damage or malfunctions that are
not covered by your manufacturer's warranty.
●
The items supplied with your device and available
accessories may vary depending on your region or
service provider.
●
You can purchase additional accessories from your
local Samsung dealer.
●
The supplied accessories perform best for your device.
●
Accessories other than the supplied ones may not be
compatible with your device.
Assembling
9
Install the SIM or USIM card and battery
When you subscribe to a cellular service, you will receive
a Subscriber Identity Module (SIM) card, with subscription
details, such as your personal identification number (PIN) and
optional services. To use UMTS or HSDPA services, you can
purchase a Universal Subscriber Identity Module (USIM) card.
To install the SIM or USIM card and battery,
If the device is on, press and hold the Power key and select
1
Ye s to turn it off.
Remove the back cover.
2
Be careful not to damage your fingernails when you
remove the back cover.
Assembling
10
Insert the SIM or USIM card with the gold-coloured
3
contacts facing up.
●
If you do not insert a SIM or USIM card, you can only
use your device’s non-network services and some
menus.
●
Do not insert a memory card into the SIM or USIM
card slot.
Insert the battery.
4
Replace the back cover.
5
Assembling
11
Charge the battery
Before using the device for the first time, you must charge the
battery.
You can charge the device with a travel adapter or by
connecting the device to a PC with a USB cable.
Use only Samsung-approved chargers and cables.
Unauthorised chargers or cables can cause batteries to
explode or damage your device.
●
When your battery is low, the device will emit a
warning tone and display a low battery message. The
battery icon
becomes too low, the device will automatically power
off. Recharge your battery to continue using your
device.
●
If the battery is completely discharged, you cannot
turn on the device, even with the travel adapter
connected. Allow a depleted battery to charge for a
few minutes before you try to turn on the device.
will also be empty. If the battery level
Assembling
12
Charge with a travel adapter
›
Open the cover of the multifunction jack.
1
Plug the small end of the travel adapter into the
2
multifunction jack.
Connecting the travel adapter improperly may cause
serious damage to the device. Any damage caused by
misuse is not covered by the warranty.
Plug the large end of the travel adapter into a power
3
outlet.
●
You can use the device while it is charging, but it may
take longer to fully charge the battery.
●
While the device is charging, the touch screen may
not function due to an unstable power supply. If this
happens, unplug the travel adapter from the device.
●
While charging, the device may heat up. This is
normal and should not affect your device’s lifespan or
performance.
●
If your device is not charging properly, bring your
device and the charger to a Samsung Service Centre.
Assembling
13
When the battery is fully charged, first unplug the travel
4
adapter from the device and then from the power outlet.
Do not remove the battery before removing the travel
adapter. Doing this may cause damage to the device.
To save energy, unplug the travel adapter when not in
use. The travel adapter does not have a power switch,
so you must unplug the travel adapter from the outlet
when not in use to avoid wasting power. The travel
adapter should remain close to the socket when in use.
Charge with a USB cable
›
Before charging, ensure that your PC is turned on.
Open the cover of the multifunction jack.
1
Plug one end (micro-USB) of the USB cable into the
2
multifunction jack.
Plug the other end of the USB cable into a USB port on a
3
PC.
Depending on the type of USB cable you are using, it
may take some time before charging begins.
When the battery is fully charged, first unplug the USB
4
cable from the device and then from the PC.
Assembling
14
Insert a memory card (optional)
To store additional multimedia files, you must insert
a memory card. Your device accepts microSD
microSDHC
16 GB (depending on memory card manufacturer and type).
Samsung uses approved industry standards for memory
cards, but some brands may not be fully compatible
with your device. Using an incompatible memory card
may damage your device or the memory card and can
corrupt data stored on the card.
●
●
Remove the back cover.
1
Insert a memory card with the gold-coloured contacts
2
facing up.
memory cards with maximum capacities of
™
Your device supports only the FAT file structure for
memory cards. If you insert a card formatted with
a different file structure, your device will ask you to
reformat the memory card.
Frequent writing and erasing of data will shorten the
lifespan of memory cards.
™
or
Assembling
15
Push the memory card in the memory card slot until it
3
locks in place.
Replace the back cover.
4
Remove the memory card
›
Ensure that the device is not currently using the memory
1
card.
Remove the back cover.
2
Push the memory card gently until it disengages from the
3
device.
Remove the memory card.
4
Replace the back cover.
5
Do not remove a memory card while the device is
transferring or accessing information, as this could
result in loss of data or damage to the memory card or
device.
Format the memory card
›
Formatting your memory card on a PC may cause
incompatibilities with your device. Format the memory card
only on the device.
→
In Menu mode, select Settings
→
Format memory card
Ye s .
General → Memory →
Before formatting the memory card, remember to make
backup copies of all important data stored on your
device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
Attach a hand strap (optional)
Remove the back cover.
1
Slide a hand strap through the hand strap hole and hook
2
it over the small projection.
Replace the back cover.
3
Assembling
16
Getting started
Turn your device on and off
To turn on your device, press and hold the Power key. If you
turn on your device for the first time, follow the on-screen
instructions to set up your device.
To turn off your device, press and hold the Power key and
select Ye s .
●
Follow all posted warnings and directions from
authorised personnel in areas where the use of
wireless devices is restricted, such as aeroplanes and
hospitals.
●
To use your device's non-network services only,
switch to Flight mode. In Menu mode, select Settings
and drag the slider next to Flight mode.
Getting started
17
Getting started
18
Get to know your device
Device layout
›
Earpiece
Volume key
Home key
Touch screen
Dial key
Mouthpiece
Multifunction jack
Camera lens
Power/Reset/Lock
key
Camera key
Internal antenna
End key
Headset jack
Back cover
Speaker
Getting started
19
Keys
›
KeyFunction
Turn the device on or off (press and
Power/
1
Reset
Lock
hold); Reset the device (press and hold
/
for 8-10 seconds until the SAMSUNG
logo appears; Lock the touch screen
and keys.
Make or answer a call; In Idle mode,
Dial
retrieve logs of your calls and
messages.
In Idle mode, switch between the
widget panel and the idle screen;
Home
Return to the idle screen; Launch
the task manager to view all active
applications (press and hold).
End a call; While using an application,
End
return to the idle screen or the main
menu.
VolumeAdjust the device’s volume.
In Idle mode, turn on the camera; In
Camera
Camera mode, take a photo or record
a video.
1. If your device has fatal errors or hang-ups, or freezes, you may
need to reset the device to regain functionality.
Getting started
20
Idle screen
›
When the device is in Idle mode, you will see the idle screen.
From the idle screen, you can view your device’s status and
access applications.
The idle screen has multiple panels, and you can add new
panels to the idle screen.
Scroll left or right to a panel of the idle screen to move
directly to the corresponding screen.
Indicator icons
›
Icons shown on the display may vary depending on
your region or service provider.
IconDefinition
No signal
Signal strength
Flight mode activated
Network searching
► p. 28
GPRS network connected
EDGE network connected
UMTS network connected
HSDPA network connected
Wi-Fi AP connected
Call missed
Getting started
21
IconDefinition
Synchronised with a web server
Bluetooth activated
Bluetooth hands-free car kit or headset
connected
Virtual Private Network (VPN) connected
Voice call in progress
Video call in progress
Call diverting activated
Synchronising with PC
Wi-Fi tethering activated
Memory card inserted
New text or multimedia message
New email message
New voice mail message
Alarm activated
Roaming (outside of normal service area)
Music playback in progress
Music playback paused
Getting started
22
IconDefinition
Silent & vibration mode activated
Silent mode activated
Vibration mode activated
FM radio turned on in the background
Current time
Battery power level
Notifications panel
›
In Idle mode or while using an application, tap the indicator
icons area at the top of the screen and drag your finger down
to open the notifications panel.
Select icons to activate or deactivate the Wi-Fi and Bluetooth
features. You can also turn on or off the device’s volume and
check new messages and alerts.
Use the touch screen
Your device’s touch screen lets you easily select items or
perform functions. Learn basic actions to use the touch
screen.
●
To avoid scratching the touch screen, do not use
sharp tools.
●
Do not allow the touch screen to come into contact
with other electrical devices. Electrostatic discharges
can cause the touch screen to malfunction.
●
Do not allow the touch screen to come into contact
with water. The touch screen may malfunction in
humid conditions or when exposed to water.
Getting started
23
●
For optimal use of the touch screen, remove the
screen protection film before using your device.
●
Your touch screen has a layer that detects small
electrical charges emitted by the human body. For
best performance, tap the touch screen with your
fingertip. The touch screen will not react to touches of
sharp tools, such as a stylus or pen.
Control your touch screen with the following actions:
●
Tap: Tap once with your finger to select or launch a menu,
option, or application.
●
Tap and hold: Tap an item and hold it for more than
2 seconds to open a pop-up option list.
●
Drag: Tap and drag your finger up, down, left, or right to
move to items on lists.
●
Double-tap: Tap twice quickly with your finger to zoom in
or out while viewing photos or web pages.
●
Drag and drop: Tap and hold your finger on an item, and
then drag your finger to move the item.
●
Flick: Flick the screen quickly to activate an application.
●
Area zoom: Place two fingers on the screen and pull them
apart to zoom in or squeeze them together to zoom out.
●
Your device turns off the touch screen when you do
not use the device for a specified period. To turn on
the screen, press the Power key or the Home key.
●
You can also adjust the backlight time. In Menu mode,
select Settings → Display → Backlight time.
●
Some lists have an index along the right side. Tap a
letter to jump to items starting with that letter. Drag
your finger along the index to quickly scroll through
the list.
Getting started
24
Lock or unlock the touch screen and keys
You can lock the touch screen and keys to prevent any
unwanted device operations.
To lock, press the Power key. To unlock, press the Power key or
the Home key and flick the window with your finger.
You can also set the device to automatically lock the touch
screen and keys when you do not use the device for a
→
specified period. In Menu mode, select Settings
→
Lock screen and drag the slider next to Touch panel
auto-lock.
You can activate the device lock feature to prevent
others from using or accessing your personal data and
information saved in your device.
► p. 30
Display
Access menus
To access your device’s menus,
In Idle mode, select
1
When the help screen for adding shortcuts to the idle
2
screen appears, select OK.
If you do not want to see the screen again, select the
check box next to Do not show again.
Scroll left or right to a screen.
3
Select a menu or application.
4
Select 5 to return to the previous screen (if available);
press the Home key to return to idle screen.
When you return to the first idle screen, the help screen
for editing the idle screen panels appears. If you do not
want to see the screen again, select the check box next to
Do not show again.
Menu to access Menu mode.
Getting started
25
●
Your device has a built-in motion sensor that detects
its orientation. If you rotate the device while using
some features, the interface will automatically switch
to landscape view. To set the interface to keep the
orientation when you rotate the device, open the
notifications panel and select Auto rotation.
●
While using the device, you can capture an image of a
screen by pressing the Power key and the Home key
simultaneously. The image will be saved in My files
→
Images
Organise applications
›
You can reorganise the applications by changing their order
or grouping them into categories to suit your preferences and
needs.
To add a shortcut to the idle screen,
In Menu mode, tap and hold the screen.
1
Drag the application icon to an idle screen panel at the
2
bottom of the screen.
Screen capture.
→
To change the order of applications,
In Menu mode, tap and hold an application.
1
Drag an application icon to the location you want.
2
You can move an application icon to another screen.
To add a folder,
In Menu mode, tap and hold the screen.
1
Select 2 at the top left of the screen.
Drag an application icon to the folder.
3
Repeat this step to add more applications.
Getting started
26
Select the new folder.
4
Select the name field, enter a name for the folder, and
5
then select Save.
Before you delete a folder, you need to move the
applications in the folder to the screen. Then, select
To change the order of the screens,
In Menu mode, place your two fingers on the screen and
1
pinch.
Tap and hold the thumbnail of a screen and drag it to the
2
location you want.
Add new screens
›
In Menu mode, tap and hold the screen.
1
Tap and hold an application icon.
2
Drag the application icon to an empty screen.
3
The new screen is added.
.
Launch and manage applications
Launch multiple applications
›
Your device allows you to multi-task by running multiple
applications at the same time.
To launch multiple applications, press the Home key while
using an application to return to Idle mode, and then select
an application to launch.
Getting started
27
Use the task manager
›
You can manage multiple applications with the task manager.
To launch the task manager,
Press and hold the Home key. The icons of active
1
applications appear.
Control active applications as follows:
2
●
To switch between applications, select one from the
icons of active applications.
●
To close an application, select
●
To close all active applications, select
→
applications
Ye s .
.
End all
Use widgets
Widgets are small applications that provide convenient
functions and information.
●
Some of your widgets connect to web services. Using
a web-based widget may incur additional charges.
●
Available widgets may vary depending on your
region or service provider.
Open the widget panel
›
To open the widget toolbar and access widgets,
In Idle mode, press the Home key to open the widget
1
panel.
When the help screen for customising the widget panel,
2
select OK.
If you do not want to see the screen again, select the
check box next to Do not show again.
Getting started
28
Scroll up or down on the widget panel to find the widget
3
you want to use.
Select the widget to launch.
4
Organise the widget panel
›
You can reorganise the widgets by changing their order and
activating or deactivating them.
In Idle mode, press the Home key to open the widget
1
panel and tap and hold the screen.
To activate or deactivate a widget, drag the slider next to
2
the widget.
To change the order of the widgets, tap and hold a widget
and drag it to the location you want.
Customise your device
Get more from your device by customising it to match your
preferences.
Add new panels to the idle screen
›
You can add new panels to the idle screen to organise
widgets according to your preferences and needs.
In Idle mode, place your two fingers on the screen and
1
pinch.
Select
2
Select to remove a panel from the idle screen.
to add new panels to the idle screen.
Getting started
29
Set the current time and date
›
In Menu mode, select 1 Settings → General → Date and
time.
Drag the slider next to
2
auto time updates.
Select
3
Enter the current time and date, and set the time and date
4
format.
Adjust the volume of the ringtones
›
Press the Volume key to adjust the ringtone volume.
Change your ringtone
›
In Menu mode, select 1 Settings → Sound → Ringtone.
Select a ringtone from the list.
2
Switch to Silent mode
›
To mute or unmute your device, do one of the following:
●
In Menu mode, select
●
Open the notifications panel from the top of the screen and
select Sound & vibration.
●
In Menu mode, select
slider next to Sound.
Time zone → your time zone.
Automatic update to deactivate
Keypad, and then tap and hold #.
Settings → Sound and drag the
Select a wallpaper for the idle screen
›
In Menu mode, select 1 Settings → Display → Wallpaper.
→
Select an image folder
2
3
Select
Set.
Samsung is not responsible for any use of default
images or wallpapers provided on your device.
an image.
Getting started
30
Adjust the brightness of the display
›
In Menu mode, select 1 Settings → Display.
Drag the slider to adjust the level of brightness under
2
Brightness.
The brightness level of the display will affect how
quickly the device consumes battery power.
Lock your device
›
You can lock your device by activating the device password.
In Menu mode, select
1
Drag the slider next to
2
Enter a new 4- to 8-digit password and select
3
Enter the new password again and select
4
The first time you access a menu that requires a
password, you will be prompted to create and confirm a
password.
Once the device lock is enabled, you must enter the password
each time you turn on the device or unlock the touch screen
and keys.
●
If you forget your password, bring your device to a
Samsung Service Centre to reset it.
●
Samsung is not responsible for any loss of passwords
or private information or other damages caused by
illegal software.
Settings → General → Security.
Phone lock → Ye s .
OK.
OK.
Loading...
+ 98 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
