Page 1
Some of the contents in this manual may differ from your phone
depending on the software of the phone or your service provider.
Printed in Korea
Code No.:GH68-28861A
www.samsung.com
English (MEA). 07/2011. Rev. 1.2
Page 2
GT-C5010
user manual
Page 3
Using this manual
This user manual has been specially designed to
guide you through the functions and features of
your mobile phone. To get started quickly, refer to
"Introducing your mobile phone," "Assembling and
preparing your mobile phone," and "Using basic
functions."
Instructional icons
Note: notes, usage tips, or additional
information
Followed by: the order of options or menus
you must select to perform a step; for example:
In Menu mode, select Messages → Create
→
message (represents Messages, followed by
Create message)
Square brackets: phone keys; for example:
[ ]
< >
2
] (represents the Power/End key)
[
Angled brackets: softkeys that control different
functions at each screen; for example: <OK>
(represents the OK softkey)
Refer to: pages with related information; for
►
example: ► p. 12 (represents "see page 12")
Page 4
Copyright information
Rights to all technologies and products that
comprise this phone are the property of their
respective owners:
®
Bluetooth•
is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Java™ is a trademark of Sun Microsystems, •
Inc.
3
Page 5
Contents
Using this manual .....................................................2
Introducing your mobile phone ...............................6
Phone layout ...............................................................6
Icons ............................................................................ 8
Assembling and preparing your mobile phone .....9
Install the SIM or USIM card and battery ....................9
Charge the battery ....................................................10
Insert a memory card (optional) ................................ 11
Using basic functions.............................................12
Turn your phone on or off ..........................................12
Access menus ...........................................................12
Use the smart home screen ......................................13
Customise your phone .............................................. 15
Use basic call functions ............................................16
Send and view messages ......................................... 18
Send and view emails ............................................... 19
Enter text ................................................................... 20
Add and nd contacts ...............................................21
Use basic camera functions ......................................22
Listen to music ..........................................................24
Browse the web.........................................................26
Use the Google services ...........................................27
Using advanced functions ..................................... 28
Use advanced call functions .....................................28
4
Page 6
Use advanced phonebook functions ........................31
Use advanced messaging functions .........................32
Use advanced camera functions ..............................34
Use advanced music functions ................................. 37
Using tools and applications .................................41
Use the Bluetooth wireless feature ........................... 41
Activate and send an SOS message ........................43
Make fake calls .........................................................44
Activate the mobile tracker ........................................44
Record and play voice memos .................................45
Edit images ...............................................................46
Use Java-powered games and applications .............46
Synchronise data ......................................................47
Create a world clock .................................................47
Set and use alarms ...................................................48
Use the calculator .....................................................49
Convert currencies or measurements ......................49
Set a countdown timer ..............................................49
Use the stopwatch ....................................................50
Create new tasks ......................................................50
Create a text memo ..................................................50
Manage your calendar ..............................................51
Troubleshooting ......................................................52
Safety and usage information ...............................58
5
Page 7
Introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, and icons.
Phone layout
1
5
2
3
4
6
6
7
8
9
Page 8
1
4-way navigation key
In ldle mode, access user-
dened menus; In Menu
mode, scroll through menu
options
Depending on your service
provider, pre-dened menus
may differ
2
Dial key
Make or answer a call; In Idle
mode, retrieve logs of your
calls and messages
3
Voice mail service key
In ldle mode, access voice
mails (press and hold)
4
Keypad lock key
In Idle mode, lock or unlock
the keypad (press and hold)
5
Softkeys
Perform actions indicated at
the bottom of the display
6
Conrm key
In Idle mode, access Menu
mode; Launch the web
browser (press and hold);
In Menu mode, select the
highlighted menu option or
conrm an input
Depending on your service
provider or region, the key may
perform differently
7
Power/End key
Turn the phone on or off
(press and hold); End a call; In
Menu mode, cancel input and
return to Idle mode
8
Alphanumeric keys
9
Silent prole key
In ldle mode, activate or
deactivate the silent prole
(press and hold)
7
Page 9
Icons
Your phone displays the following status indicators
on the top of the screen:
Icon Denition
Signal strength
Call in progress
Call diverting activate
SOS message feature activated
Roaming (outside of normal area)
Connecting to secured web page
FM radio on
Bluetooth activated
Alarm activated
Memory card inserted
New text message (SMS)
New multimedia message (MMS)
New email message
New voice mail message
Normal prole activated
Silent prole activated
Battery power level
8
Page 10
Assembling and
preparing your mobile
phone
Get started by assembling and setting up your
mobile phone for its rst use.
Install the SIM or USIM card and
battery
1. Remove the back cover and insert the SIM or
USIM card.
SIM cardBack cover
2. Insert the battery and replace the back cover.
Battery
9
Page 11
Charge the battery
1. Plug the small end of the supplied travel
adapter into the multifunction jack.
2. Plug the large end of the travel adapter into a
power outlet.
3. When charging is nished, unplug the travel
adapter.
Do not remove the battery from the phone before
unplugging the travel adapter rst. Otherwise, the
phone may be damaged.
10
Page 12
Insert a memory card (optional)
Your phone accepts microSD™ or microSDHC™
memory cards up to 8 GB (depending on memory
card manufacturer and type).
Formatting the memory card on a PC may cause •
incompatibility with your phone. Format the
memory card only on the phone.
Frequent writing and erasing will shorten the life •
span of memory cards.
1. Remove the back cover.
2. Insert a memory card with the label side facing
up.
Memory card
3. Push the memory card in the memory card slot
until it locks in place.
4. Replace the battery and back cover.
11
Page 13
Using basic functions
Learn how to perform basic operations and use the
main features of your mobile phone.
Turn your phone on or off
To turn your phone on,
1. Press and hold [
2. Enter your PIN and press <OK> (if necessary).
3. When the prole wizard opens, customise your
phone as desired by following the screen.
To turn your phone off, repeat step 1 above.
Access menus
To access your phone's menus,
1. In Idle mode, press <Menu> to access Menu
mode.
You may need to press the Conrm key to access
Menu mode depending on your region or service
provider.
2. Use the Navigation key to scroll to a menu or
option.
3. Press <Select>, <OK> or the Conrm key to
conrm the highlighted option.
12
].
Page 14
4. Press <Back> to move up one level; Press
[
] to return to Idle mode.
When you access a menu requiring the PIN2, •
you must enter the PIN2 supplied with the SIM
or USIM card. For details, contact your service
provider.
Samsung is not responsible for any loss of •
passwords or private information or other
damages caused by illegal software.
Use the smart home screen
The smart home screen allows you to access
your favourite applications and contacts and view
upcoming events or tasks. You can customise the
smart home screen to t your preferences and
needs.
When you are using the smart home screen, the
Navigation key does not access shortcuts.
To customise the smart home screen
1. In Menu mode, select Settings → Display →
Smart home.
2. Press <Edit>.
3. Select the items to display on the smart home
screen.
4. Press <Save>, or press <Options> → Save.
13
Page 15
You can change the idle screen to another style.
In Menu mode, select Settings → Display →
Smart home and scroll left or right to a style you
want.
To access the smart home idle items
Press the Navigation key to scroll through the
items on the smart home screen and press the
Conrm key to select an item. The following items
are available.
Available items may vary depending on your
service provider.
Shortcuts toolbar• : access your favourite
applications. You can customise the shortcut
toolbar as desired.
My buddies• : access contacts that are saved in
the favourite number list.
PIMs ticker• : access upcoming calendar events
and tasks.
Dual clock• : view your home clock and a world
clock.
Monthly calendar• : view the monthly calendar.
Single clock• : view the current time and date.
Facebook/Twitter• : access recently updated
feeds.
14
Page 16
To customise the shortcut toolbar
1. In Menu mode, select Settings → Display →
Smart home.
2. Press <Edit>.
3. Scroll to Shortcuts toolbar and press
<Options> → Edit shortcuts.
4. Select a menu to change or an empty location.
5. Select <Options> → Edit.
6. Select the menus you want.
Press <Options> → Open to select submenus
(if necessary).
7. Press <Save>, or press <Options> → Save.
Customise your phone
To switch to or from the silent prole
In Idle mode, press and hold [ ] to silence or
unsilence your phone.
To set the sound prole
To switch to another sound prole,
1. In Menu mode, select Settings → Sound
proles.
2. Select a prole you want.
15
Page 17
To edit a sound prole,
1. In Menu mode, select Settings → Sound
proles.
2. Scroll to a prole and press <Edit>.
3. Customise the sound settings as desired.
To set menu shortcuts
1. In Menu mode, select Settings → Phone →
Shortcuts.
2. Select a key to use as a shortcut.
3. Select a menu to assign to the shortcut key.
Use basic call functions
To make a call
1. In Idle mode, enter an area code and a phone
number.
2. Press [
3. To end the call, press [
16
] to dial the number.
For a video call, press <Options> → Video
call.
].
Page 18
To answer a call
1. When a call comes in, press [ ].
2. For a video call, press <Show me> to allow the
caller to see you via the front camera lens.
3. To end the call, press [
].
To adjust the volume of voice during a call
While a call is in progress, press the Navigation
key up or down to adjust the volume.
To use the speakerphone feature
1. During a call, press the Conrm key to activate
the speaker.
2. To switch back to the earpiece, press the
Conrm key again.
In noisy environments, you may have difculty
hearing the calls while using the speakerphone
feature. For better audio performance, use the
normal phone mode.
17
Page 19
To use the headset
By plugging the supplied headset into the
multifunction jack, you can make and answer calls:
To redial the last call, press and hold the •
headset button.
To answer a call, press the headset button.•
To end a call, press and hold the headset button.•
Send and view messages
When you set the PC connection settings to mass
storage and connect your phone to a PC, the PC
will recognise your phone as a removable disk.
If you format the removable disk, all multimedia
messages and emails saved in your phone will be
deleted. Back up important data before formatting
your phone on a PC.
To send a text or multimedia message
1. In Menu mode, select Messages → Create
message.
2. Enter a recipient number and scroll down.
3. Enter your message text. ► p. 20
For sending as a text message, skip to step 5.
For attaching multimedia, continue with step 4.
18
Page 20
4. Press <Options> → Add multimedia and add
an item.
5. Press the Conrm key to send the message.
To view a text or multimedia message
1. In Menu mode, select Messages → Inbox.
2. Select a text or multimedia message.
Send and view emails
To send an email
1. In Menu mode, select Messages → Create
email.
2. Enter an email address and scroll down.
3. Enter a subject and scroll down.
4. Enter your message text.
5. Press <Options> → Attach items and add an
item (if necessary).
6. Press the Conrm key to send the message.
To view an email
1. In Menu mode, select Messages → Email
inbox.
2. Press <Download>.
19
Page 21
3. Select an email or a header.
4. If you selected a header, press <Options> →
Retrieve to view the body of the email.
Enter text
To change the text input mode
Press and hold [• ] to switch between T9 and
ABC modes.
Press [•
] to change case or switch to Number
mode.
Press [•
] to switch to Symbol mode.
Press and hold [•
change the input language, or access your
word list.
T9 mode
1. Press appropriate alphanumeric keys to enter
an entire word.
2. When the word displays correctly, press [0]
to insert a space. If the correct word does not
display, press the Navigation key up or down to
select an alternate word.
20
] to select an input mode,
Page 22
ABC mode
Press an appropriate alphanumeric key until the
character you want appears on the display.
Number mode
Press an appropriate alphanumeric key to enter a
number.
Symbol mode
Press an appropriate alphanumeric key to enter
a symbol.
To move the cursor, press the Navigation key.•
To delete characters one by one, press <• Clear>.
To quickly delete characters, press and hold •
<Clear>.
To insert a space between characters, press [• 0].
To enter punctuation marks, press [• 1].
Add and nd contacts
The memory location to save new contacts may
be preset depending on your service provider.
To change the memory location, in Menu mode,
select Contacts → <Options> → Settings
Save new contacts to → a memory location.
→
21
Page 23
To add a new contact
1. In Idle mode, enter a phone number and press
<Options>.
2. Select Add to Contacts → a memory location
(if necessary).
3. Select Create contact.
4. Select a number type (if necessary).
5. Enter contact information.
6. Press the Conrm key or press <Options> →
Save to add the contact to memory.
To nd a contact
1. In Menu mode, select Contacts.
2. Enter the rst few letters of the name you want
to nd.
3. Select the contact’s name from the contact list.
Use basic camera functions
To capture photos
1. In Menu mode, select Camera to turn on the
camera.
2. Aim the lens at the subject and make any
adjustments.
22
Page 24
3. Press the Conrm key to take a photo. The
photo is saved automatically.
4. Repeat steps 2 and 3 to take another picture.
After capturing photos, select <View> to view
photos.
To view photos
In Menu mode, select My les → Images → a
photo le.
To capture videos
1. In Menu mode, select Camera to turn on the
camera.
2. Press [1] to switch to Recording mode.
3. Aim the lens at the subject and make any
adjustments.
4. Press the Conrm key to start recording.
5. Press the Conrm key or <Stop> to stop
recording. The video is saved automatically.
After capturing videos, select <View> to view
videos.
To view videos
In Menu mode, select My les → Videos → a
video le.
23
Page 25
Listen to music
To listen to the FM radio
1. Plug the supplied headset into the phone.
2. In Menu mode, select Applications → FM
radio.
3. Press the Conrm key to start the FM radio.
4. Press <Yes> to start automatic tuning.
The radio scans and saves available stations
automatically.
The rst time you turn on the FM radio, you will be
prompted to start automatic tuning.
5. Control the FM radio using the following keys:
Key Function
Conrm Turn the FM radio on or off
Navigation
24
Left/Right: Select a saved radio station •
Up/Down: Adjust the volume•
Page 26
To listen to music les
Start by transferring les to your phone or memory
card:
Download from the wireless web. ► p. 27 •
Download from a PC with the optional Samsung •
PC Studio. ► p. 37
Receive via Bluetooth. ► p. 42•
Copy to your memory card. ► p. 38•
After transferring music les to your phone or
memory card,
1. In Menu mode, select Music → Library.
2. Select a music category → a music le.
3. Control playback using the following keys:
Key Function
Conrm Pause or resume playback
Left: Skip backward (press within 3 •
seconds); Scan backward in a le
Navigation
(press and hold)
Right: Skip forward; Scan forward in a •
le (press and hold)
Up/Down: Adjust the volume•
25
Page 27
Browse the web
To browse web pages
1. In Menu mode, select Internet and press
<Yes> to launch your service provider’s
homepage.
2. Navigate web pages using the following keys:
Key Function
Navigation Scroll up or down on a web page
Conrm Select an item
<Back> Return to the previous page
<Options> Access a list of browser options
To bookmark your favourite web pages
1. In Menu mode, select Internet and press
<Yes>.
2. Press <Options> → Bookmarks → <Add>.
3. Enter a page title and a web address (URL)
and press the Conrm key.
26
Page 28
To download contents from the web
1. In Menu mode, select Downloads.
2. Select a menu according to the content type to
download.
3. Search for a ringtone or picture and download it
to the phone.
Use the Google services
1. In Menu mode, select Applications → Google.
2. Select a Google service you want.
27
Page 29
Using advanced
functions
Learn how to perform advanced operations and
use additional features of your mobile phone.
Use advanced call functions
To view and dial missed calls
Your phone will display calls you have missed on
the display. To dial the number of a missed call,
1. Press <Open>.
2. Scroll to the missed call you want to dial.
3. Press [
To call a recently dialled number
1. In Idle mode, press [ ] to display a list of
2. Scroll to the number you want and press [
To hold a call or retrieve a held call
Press <Hold> to place a call on hold or press
<Retrve.> to retrieve a held call.
28
] to dial.
recent numbers.
to dial.
]
Page 30
To dial a second call
If your network supports this function, you can dial
another number during a call:
1. Press <Hold> to place the rst call on hold.
2. Enter the second number to dial and press
[
].
3. Press <Swap> to switch between the two calls.
To answer a second call
If your network supports this function, you can
answer a second incoming call:
1. Press [
The rst call is automatically placed on hold.
2. Press <Swap> to switch between the two calls.
To make a multiparty call (conference call)
1. Call the rst party you want to add to the
multiparty call.
2. While connected to the rst party, call the
second party.
The rst party is automatically placed on hold.
3. When connected to the second party, press
<Options> → Conference call.
] to answer the second call.
29
Page 31
To call an international number
1. In Idle mode, press and hold [0] to insert the +
character.
2. Enter the complete number you want to dial
(country code, area code, and phone number),
and then press [
To call a contact from the phonebook
1. In Menu mode, select Contacts.
2. Scroll to the number you want to dial and press
[
] to dial.
To reject a call
To reject an incoming call, press [ ]. The caller
will hear a busy tone.
To reject calls from certain numbers automatically,
use the auto rejection. To activate the auto
rejection and set up the reject list,
1. In Menu mode, select Settings → Call → All
calls → Auto reject.
2. Press <Change> to select On (if necessary).
3. Scroll down and press <Change>.
4. Press <Options> → Create.
5. Enter a number to reject.
30
] to dial.
Page 32
6. Select Match criteria → an option (if
necessary).
7. Press <Save>.
8. To add more numbers, repeat steps 4-7 above.
9. Select numbers to reject.
10. Press <Options> → Save.
Use advanced phonebook
functions
To create your namecard
1. In Menu mode, select Contacts.
2. Press <Options> → Settings → My
namecard.
3. Enter your personal details and press the
Conrm key.
To create a group of contacts
1. In Menu mode, select Contacts.
2. Scroll right to Groups.
3. Press <Options> → Create group.
4. Select a memory location (if necessary).
5. Enter a group name and press the Conrm key.
31
Page 33
6. To set a group ringtone, scroll to the group you
want and press <Options> → Group ringtone
→ the Conrm key.
7. Select a ringtone category → a ringtone.
8. Press <Options> → Save.
Use advanced messaging
functions
To create a text template
1. In Menu mode, select Messages → My
folders → Templates.
2. Press <Create> to open a new template
window.
3. Enter your text and press the Conrm key to
save the template.
To insert text templates in new messages
1. In Menu mode, select Messages → Create
message.
2. In the text input eld, press <Options> → Add
text → Template → a template.
32
Page 34
To use the instant messenger
1. In Menu mode, select Communications →
Instant messenger.
2. Select <OK> from the intro window.
3. Enter your user name and password, and press
<Sign In>.
4. Chat with your family or friends instantly.
To use the Bluetooth messenger
1. In Menu mode, select Communications →
Bluetooth messenger.
2. Press the Conrm key.
3. Press <Yes> to turn on the Bluetooth wireless
feature (if necessary).
4. Select a device.
5. Enter your message and press the Conrm key.
6. Enter a PIN for the Bluetooth wireless feature
or the other device's Bluetooth PIN, or press
<Yes> to send the message.
33
Page 35
Use advanced camera functions
To capture a series of photos
1. In Menu mode, select Camera to turn on the
camera.
2. Press <Options> → Shooting mode →
Continuous.
3. Make any necessary adjustments.
4. Press and hold the Conrm key to take a series
of photos.
To capture divided photos
1. In Menu mode, select Camera to turn on the
camera.
2. Press <Options> → Shooting mode →
Mosaic.
3. Select an image layout and press <Select>.
4. Make any necessary adjustments.
5. Press the Conrm key to take photos for each
segment.
34
Page 36
To capture photos with decorative frames
1. In Menu mode, select Camera to turn on the
camera.
2. Press <Options> → Shooting mode →
Frame.
3. Select a frame and press <Select>.
4. Make any necessary adjustments.
5. Press the Conrm key to take a photo with the
frame.
To use camera options
Before capturing a photo, press <Options> to
access the following options:
Option Function
Shooting mode Change the shooting mode
Resolution Change the resolution option
White balance Adjust the colour balance
Exposure
metering
Effects Apply a special effect
Select a type of exposure metre
35
Page 37
Before capturing a video, press <Options> to
access the following options:
Option Function
Recording mode Change the recording mode
Resolution Change the resolution option
White balance Adjust the colour balance
Effects Apply a special effect
To customise camera settings
Before capturing a photo, press <Options> →
Settings to access the following settings:
Option Function
Timer Select the time delay
Quality
Night mode Set whether to use Night shot mode
Viewnder mode Change the preview screen
Review
Shutter sound
Storage
Shortcut info View the shortcut information
Adjust the quality level for your
photos
Set the camera to display the
captured image
Select a sound to accompany the
shutter action
Select a memory location for storing
captured photos
36
Page 38
Before capturing a video, press <Options> →
Settings to access the following settings:
Option Function
Timer Select the time delay
Quality Adjust the quality level for your videos
Viewnder mode Change the preview screen
Recording sound Turn the recording sound on or off
Audio recording Turn the audio on or off
Storage
Shortcut info View the shortcut information
Select a memory location for storing
captured videos
Use advanced music functions
To copy music les via Samsung PC Studio
1. In Menu mode, select Settings → PC
connections → Samsung PC studio or Mass
storage.
2. Using an optional PC data cable, connect the
multifunction jack on your phone to a PC.
37
Page 39
3. Run Samsung PC Studio and copy les from
the PC to the phone.
Refer to the Samsung PC Studio help for more
information.
To transfer data from a PC to your phone, you
need Windows XP Service Pack 2.
To copy music les to a memory card
1. Insert a memory card.
2. In Menu mode, select Settings → PC
connections → Mass storage.
3. Using an optional PC data cable, connect the
multifunction jack on your phone to a PC.
When connected, a pop-up window will appear
on the PC.
4. Open a folder to view les.
5. Copy les from the PC to the memory card.
38
Page 40
To create a playlist
1. In Menu mode, select Music → Library →
Playlists.
2. Press <Create>.
3. Enter a title for your new playlist and press the
Conrm key.
4. Select the new playlist.
5. Press <Add> → Tracks.
6. Select the les you want to include and press
<Add>.
To customise your music player settings
1. In Menu mode, select Music → Settings →
Music player.
2. Adjust the settings to customise your music
player.
3. Press <Save>.
39
Page 41
To record songs from the FM radio
1. In Menu mode, select Applications → FM
radio.
2. Press the Conrm key to start the FM radio.
3. Select a radio station you want.
4. Press <Options> → Record to start recording.
5. When you are nished recording, press
<Stop>.
To set up your favourite station list
1. In Menu mode, select Applications → FM
radio.
2. Select a radio station to add to the favourite
station list.
3. Press <Options> → Add to Favourites.
4. Select an empty location you want to set.
You can access your favourite stations by pressing
the location number on the FM radio screen.
40
Page 42
Using tools and
applications
Learn how to work with your mobile phone’s tools
and additional applications
Use the Bluetooth wireless feature
To turn on the Bluetooth wireless feature
1. In Menu mode, select Applications →
Bluetooth.
2. Press <Options> → Settings.
3. Press <Change> to select On (if necessary).
4. To allow other devices to locate your phone,
scroll down to My phone’s visibility and press
<Change> → Always on (if necessary).
To nd and pair with other Bluetooth-enabled
devices
1. In Menu mode, select Applications →
Bluetooth.
2. Press the Conrm key.
3. Select a device.
4. Enter a PIN for the Bluetooth wireless feature
or the other device’s Bluetooth PIN, if it has
one, and press <OK>.
41
Page 43
When the owner of the other device enters the
same code or accepts the connection, pairing is
complete.
You may not need to enter a PIN depending on
the device.
To send data using the Bluetooth wireless
feature
1. Select a le or item from one of your phone’s
applications that you want to send.
2. Press <Options> → Send via or Send
namecard via → Bluetooth (when sending
contact data, specify which data to send).
To receive data using the Bluetooth wireless
feature
1. Enter the PIN for the Bluetooth wireless feature
and press <OK> (if necessary).
2. Press <Yes> to conrm that you are willing to
receive data from the device (if necessary).
42
Page 44
Activate and send an SOS
message
In an emergency, you can send SOS messages to
your family or friends for help.
To activate the SOS message
1. In Menu mode, select Messages → Settings
→ SOS messages → Sending options.
2. Press <Change> to select On.
3. Scroll down and press the Conrm key to open
the recipient list.
4. Press <Search> to open your contact list.
5. Select a contact.
6. Select a number (if necessary).
7. Press the Conrm key to save the recipients.
8. Scroll down and set the number of times to
repeat the SOS message.
9. Press <Back> → <Yes>.
To send an SOS message
1. With the keys locked, press [ ] four times to
send an SOS message to preset numbers.
The phone switches to SOS mode and sends
the preset SOS message.
2. To exit SOS mode, press [
].
43
Page 45
Make fake calls
You can simulate an incoming call when you want
to get out of meetings or unwanted conversations.
To make a fake call
In Idle mode, press and hold the Navigation key •
down.
When the keys are locked, press the Navigation •
key down four times.
Activate the mobile tracker
When someone inserts a new SIM card in your
phone, the mobile tracker feature will automatically
send the contact number to two recipients to help
you locate and recover your phone. To activate the
mobile tracker,
1. In Menu mode, select Settings → Security →
Mobile tracker.
2. Enter your password and press <OK>.
The rst time you access Mobile tracker, you will
be prompted to create and conrm a password.
3. Press the conrm key to select On.
4. Scroll down and press the Conrm key to open
the recipient list.
5. Press <Search> to open your contact list.
44
Page 46
6. Select a contact.
7. Select a number (if necessary).
8. Press the Conrm key twice to save the
recipients.
9. Scroll down and enter the sender's name.
10. Press the Conrm key → <Accept>.
Record and play voice memos
To record a voice memo
1. In Menu mode, select Applications → Voice
recorder.
2. Press the Conrm key to start recording.
3. Speak your memo into the microphone.
4. When you are nished speaking, press
<Stop>.
To play a voice memo
1. From the voice recorder screen, press
<Options> → Go to Sounds.
2. Select a le.
45
Page 47
Edit images
1. In Menu mode, select Applications → Image
editor.
2. Select the image you want to edit.
3. Press the Conrm key.
4. Scroll to an editing tool and press the Conrm
key.
5. Select an option or set the area you want, and
press <Apply>.
For resizing the image, press <Yes> and skip
to step 7.
6. Press <Options> → Save as.
7. Enter a new le name for the image and press
the Conrm key.
Use Java-powered games and
applications
1. In Menu mode, select Applications → Games
and more.
2. Select a game or application from the list and
follow the on-screen instructions.
Available games may vary, depending on your
service provider or region. Game controls and
options may vary.
46
Page 48
Synchronise data
To create a synchronisation prole
1. In Menu mode, select Applications →
Synchronise.
2. Press <Add> and specify prole parameters.
3. When you are nished, press the Conrm key
or press <Options> → Save.
To start synchronisation
1. In Menu mode, select Applications →
Synchronise.
2. Select a synchronisation prole.
3. Press <OK> to start synchronisation with the
web server you have specied.
Create a world clock
1. In Menu mode, select Organiser → World
clock.
2. Press <Add>.
3. Scroll left or right to a time zone and press
<Add>.
4. To add more world clocks, repeat steps 2 and 3
above.
47
Page 49
Set and use alarms
Learn to set and control alarms for important
events.
To set a new alarm
1. In Menu mode, select Organiser → Alarms.
2. Press <Create>.
3. Set the details of the alarm.
4. Press <Save> or the Conrm key.
To stop an alarm
When the alarm sounds,
Press <• Conrm> or the Conrm key to stop
the alarm.
Press <• Snooze> to silence the alarm for the
snooze period.
To deactivate an alarm
1. In Menu mode, select Organiser → Alarms.
2. Scroll to the alarm you want to deactivate.
3. Press <Options> → Deactivate alarm.
48
Page 50
Use the calculator
1. In Menu mode, select Organiser →
Calculator.
2. Use the keys that corresponds to the calculator
display to perform basic mathematical
operations.
Convert currencies or
measurements
1. In Menu mode, select Organiser → Convertor
→ a conversion type.
2. Enter the currencies or measurements and
units in the appropriate elds.
Set a countdown timer
1. In Menu mode, select Applications → Timer.
2. Enter the time to count down and press
<Start>.
3. When the timer expires, press <OK> to stop
the alert.
49
Page 51
Use the stopwatch
1. In Menu mode, select Applications →
Stopwatch.
2. Press <Start> to begin the stopwatch.
3. Press the Conrm key to record lap times.
4. When you are nished, press <Stop>.
5. Press <Reset> to clear recorded times.
Create new tasks
1. In Menu mode, select Organiser → Task.
2. Press <Create>.
3. Enter the details of the task.
4. Press <Save> or the Conrm key.
Create a text memo
1. In Menu mode, select Organiser → Memo.
2. Press <Create>.
3. Enter your memo text and press the Conrm
key.
50
Page 52
Manage your calendar
To change the calendar view
1. In Menu mode, select Organiser → Calendar.
2. Press <Options> → View by week or View by
month.
To create an event
1. In Menu mode, select Organiser → Calendar.
2. Press <Options> → Create → an event type.
3. Enter the details of the event.
4. Press <Save> or the Conrm key.
To view events
1. In Menu mode, select Organiser → Calendar.
2. Select a date on the calendar.
3. Select an event to view its details.
51
Page 53
Troubleshooting
When you turn on your phone or while you are using
the phone, it prompts you to enter one of the following
codes:
Code Try this to solve the problem:
Password
PIN
PUK
PIN2
52
When the phone lock feature is enabled,
you must enter the password you set for
the phone.
When using the phone for the rst time or
when the PIN requirement is enabled, you
must enter the PIN supplied with the SIM or
USIM card. You can disable this feature by
using the PIN lock menu.
Your SIM or USIM card is blocked, usually
as a result of entering your PIN incorrectly
several times. You must enter the PUK
supplied by your service provider.
When you access a menu requiring the
PIN2, you must enter the PIN2 supplied
with the SIM or USIM card. For details,
contact your service provider.
Page 54
Your phone displays "No networks found" or
"Network error"
When you are in areas with weak signals or poor •
reception, you may lose reception. Move to another
area and try again.
•
You cannot access some options without a
subscription. Contact your service provider for more
details.
Calls are being dropped
When you are in areas with weak signals or poor
reception, you may lose your connection to the
network. Move to another area and try again.
Outgoing calls are not connected
Ensure that you have pressed the Dial key.•
Ensure that you have accessed the right cellular •
network.
•
Ensure that you have not set call barring for the
phone number you are dialling.
Incoming calls are not connected
Ensure that your phone is turned on.•
Ensure that you have accessed the right cellular •
network.
•
Ensure that you have not set call barring for the
incoming phone number.
53
Page 55
Others cannot hear you speaking on a call
Ensure that you are not covering the built-in •
microphone.
•
Ensure that the microphone is close to your mouth.
If using a headset, ensure that it is properly •
connected.
Audio quality is poor
Ensure that you are not blocking the phone's internal •
antenna.
•
When you are in areas with weak signals or poor
reception, you may lose reception. Move to another
area and try again.
When dialling from contacts, the call is not
connected
Ensure that the correct number is stored in the •
contact list.
•
Re-enter and save the number, if necessary.
Ensure that you have not set call barring for the •
contact's phone number.
The phone beeps and the battery icon ashes
Your battery is low. Recharge or replace the battery to
continue using the phone.
54
Page 56
The battery does not charge properly or the
phone turns off
The battery terminals may be dirty. Wipe both gold-•
coloured contacts with a clean, soft cloth and try
charging the battery again.
•
If the battery will no longer charge completely,
dispose of the old battery properly and replace it
with a new battery (refer to your local ordinances for
proper disposal instructions).
Your phone is hot to the touch
When you use applications that require more power or
use applications on your phone for an extended period
of time, your phone may feel hot to the touch. This is
normal and should not affect your phone's lifespan or
performance.
Error messages appear when launching the
camera
Your Samsung mobile phone must have sufcient
available memory and battery power to operate the
camera application. If you receive error messages
when launching the camera, try the following:
•
Charge the battery or replace it with a battery that is
fully charged.
•
Free some memory by transferring les to a PC or
deleting les from your phone.
•
Restart the phone. If you are still having trouble with
the camera application after trying these tips, contact
a Samsung Service Centre.
55
Page 57
Error messages appear when launching the
FM radio
The FM radio application on your Samsung mobile
phone uses the headset cable as an antenna. Without
a headset connected, the FM radio will be unable to
receive radio stations. To use the FM radio, rst ensure
that the headset is properly connected. Next, scan for
and save the available radio stations.
If you still cannot use the FM radio after performing
these steps, try accessing your desired station with
another radio receiver. If you can hear the station with
another receiver, your phone may require service.
Contact a Samsung Service Centre.
Error messages appear when opening music
les
Some music les may not play on your Samsung
mobile phone for a variety of reasons. If you receive
error messages when opening music les on your
phone, try the following:
•
Free some memory by transferring les to a PC or
deleting les from your phone.
•
Ensure that the music le is not Digital Rights
Management (DRM)-protected. If the le is DRM-
protected, ensure that you have the appropriate
license or key to play the le.
•
Ensure that your phone supports the le type.
56
Page 58
Another Bluetooth device is not located
Ensure that the Bluetooth wireless feature is •
activated on your phone.
•
Ensure that the Bluetooth wireless featurs is
activated on the device you wish to connect to, if
necessary.
•
Ensure that your phone and the other Bluetooth
device are within the maximum Bluetooth range (10
metres/30 feet).
If the tips above do not solve the problem, contact a
Samsung Service Centre.
A connection is not established when you
connect the phone to a PC
Ensure that the PC data cable you are using is •
compatible with your phone.
•
Ensure that you have the proper drivers installed and
updated on your PC.
57
Page 59
Safety and usage
information
Comply with the following precautions to avoid
dangerous or illegal situations and ensure peak
performance of your mobile phone
Safety warnings
Keep your phone away from small children
and pets
Keep your phone and all accessories out of the reach
of small children or animals. Small parts may cause
choking or serious injury if swallowed.
Excessive exposure to sound at high
volumes can cause hearing damage.
Always turn the volume down before
plugging the earphones into an audio
source and use only the minimum
volume setting necessary to hear your
conversation or music.
58
Page 60
Install mobile phones and equipment with
caution
Ensure that any mobile phones or related equipment
installed in your vehicle are securely mounted. Avoid
placing your phone and accessories near or in an air
bag deployment area. Improperly installed wireless
equipment can cause serious injury when air bags
inate rapidly.
Handle and dispose of batteries and chargers
with care
Use only Samsung-approved batteries and chargers •
specically designed for your phone. Incompatible
batteries and chargers can cause serious injuries or
damage to your phone.
•
Never dispose of batteries or phones in a re. Follow
all local regulations when disposing of used batteries
or phones.
•
Never place batteries or phones on or in heating
devices, such as microwave ovens, stoves, or
radiators. Batteries may explode when overheated.
•
Never crush or puncture the battery. Avoid exposing
the battery to high external pressure, which can lead
to an internal short circuit and overheating.
59
Page 61
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between
mobile phones and pacemakers to avoid potential
interference, as recommended by manufacturers and
the independent research group, Wireless Technology
Research. If you have any reason to suspect that your
phone is interfering with a pacemaker or other medical
device, turn off the phone immediately and contact the
manufacturer of the pacemaker or medical device for
guidance.
Turn off the phone in potentially explosive
environments
Do not use your phone at refuelling points (service
stations) or near fuels or chemicals. Turn off your
phone whenever directed by warning signs or
instructions. Your phone could cause explosions
or re in and around fuel or chemical storage and
transfer areas or blasting areas. Do not store or carry
ammable liquids, gases, or explosive materials in
the same compartment as the phone, its parts, or
accessories.
Reduce the risk of repetitive motion injuries
While using your phone, hold the phone with a relaxed
grip, press the keys lightly, use special features that
reduce the number of keys you have to press (such
as templates and predictive text), and take frequent
breaks.
60
Page 62
Do not use the device if the screen is cracked
or broken
Broken glass or acrylic could cause injury to your hand
and face. Bring the phone to a Samsung service centre
to replace the screen. Damage caused by careless
handling will void your manufacturer’s warranty.
Safety precautions
Drive safely at all times
Avoid using your phone while driving and obey all
regulations that restrict the use of mobile phones while
driving. Use hands-free accessories to increase your
safety when possible.
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a
mobile phone in a certain area.
Use only Samsung-approved accessories
Using incompatible accessories may damage your
phone or cause injury.
61
Page 63
Turn off the phone near medical equipment
Your phone can interfere with medical equipment in
hospitals or health care facilities. Follow all regulations,
posted warnings, and directions from medical
personnel.
Turn off the phone or disable the wireless
functions when in an aircraft
Your phone can cause interference with aircraft
equipment. Follow all airline regulations and turn off
your phone or switch to a mode that disables the
wireless functions when directed by airline personnel.
Protect the phone and batteries from damage
Avoid exposing your phone and batteries to very •
cold or very hot temperatures (below 0° C or above
45° C).
•
Extreme temperatures can cause the deformation of
the phone and reduce the charging capacity and life
of your phone and batteries.
•
Prevent batteries from contacting metal objects,
as this can create a connection between the + and
– terminals of your batteries and lead to temporary
or permanent battery damage.
•
Never use a damaged charger or battery.
62
Page 64
Handle your phone carefully and sensibly
Do not disassemble your phone due to a risk of •
electric shock.
•
Do not allow your phone to get wet—liquids can
cause serious damage and will change the colour
of the label that indicates water damage inside
the phone. Do not handle your phone with wet
hands. Water damage to your phone can void your
manufacturer's warranty.
•
Avoid using or storing your phone in dusty, dirty
areas to prevent damage to moving parts.
•
Your phone is a complex electronic device—protect
it from impacts and rough handling to avoid serious
damage.
•
Do not paint your phone, as paint can clog moving
parts and prevent proper operation.
•
If your phone has a camera ash or light, avoid using
it close to the eyes of children or animals.
•
Your phone may be damaged by exposure to
magnetic elds. Do not use carrying cases or
accessories with magnetic closures or allow your
phone to come in contact with magnetic elds for
extended periods of time.
63
Page 65
Avoid interference with other electronic
devices
Your phone emits radio frequency (RF) signals that
may interfere with unshielded or improperly shielded
electronic equipment, such as pacemakers, hearing
aids, medical devices, and other electronic devices in
homes or vehicles. Consult the manufacturers of your
electronic devices to solve any interference problems
you experience.
Important usage information
Use your phone in the normal position
Avoid contact with your phone's internal antenna.
Internal antenna
64
Page 66
Allow only qualied personnel to service your
phone
Allowing unqualied personnel to service your phone
may result in damage to your phone and will void your
manufacturer’s warranty.
Ensure maximum battery and charger life
Avoid charging batteries for more than a week, as •
overcharging may shorten battery life.
•
Over time, unused batteries will discharge and must
be recharged before use.
•
Disconnect chargers from power sources when not
in use.
•
Use batteries only for their intended purpose.
Handle SIM or USIM cards or memory cards
with care
Do not remove a card while the phone is transferring •
or accessing information, as this could result in loss
of data and/or damage to the card or phone.
•
Protect cards from strong shocks, static electricity,
and electrical noise from other devices.
•
Do not touch gold-coloured contacts or terminals
with your ngers or metal objects. If dirty, wipe the
card with a soft cloth.
65
Page 67
Ensure access to emergency services
Emergency calls from your phone may not be possible
in some areas or circumstances. Before travelling
in remote or undeveloped areas, plan an alternate
method of contacting emergency services personnel.
Specic Absorption Rate (SAR) certication
information
Your phone conforms to European Union (EU)
standards that limit human exposure to radio frequency
(RF) energy emitted by radio and telecommunications
equipment. These standards prevent the sale of
mobile phones that exceed a maximum exposure level
(known as the Specic Absorption Rate, or SAR) of
2.0 W/kg.
During testing, the maximum SAR recorded for this
model was 0.71 W/kg. In normal use, the actual SAR
is likely to be much lower, as the phone has been
designed to emit only the RF energy necessary to
transmit a signal to the nearest base station. By
automatically emitting lower levels when possible, your
phone reduces your overall exposure to RF energy.
The Declaration of Conformity of this manual
demonstrates your phones compliance with the
European Radio & Terminal Telecommunications
Equipment (R&TTE) directive. For more information
about the SAR and related EU standards, visit the
Samsung mobile phone website.
66
Page 68
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and
other European countries with separate
collection systems)
This marking on the product, accessories
or literature indicates that the product and
its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household
waste at the end of their working life.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate these items from other types of waste and
recycle them responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government ofce, for details of where and how
they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check
the terms and conditions of the purchase contract. This
product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
This EEE is compliant with RoHS.
67
Page 69
Correct disposal of batteries in this product
(Applicable in the European Union and
other European countries with separate
battery return systems)
packaging indicates that the batteries in this product
should not be disposed of with other household waste
at the end of their working life. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the
reference levels in EC Directive 2006/66. If batteries
are not properly disposed of, these substances can
cause harm to human health or the environment.
To protect natural resources and to promote material
reuse, please separate batteries from other types of
waste and recycle them through your local, free battery
return system.
This marking on the battery, manual or
Disclaimer
Some content and services accessible through this
device belong to third parties and are protected by
copyright, patent, trademark and/or other intellectual
property laws. Such content and services are provided
solely for your personal noncommercial use. You
may not use any content or services in a manner
that has not been authorised by the content owner
or service provider. Without limiting the foregoing,
unless expressly authorised by the applicable content
68
Page 70
owner or service provider, you may not modify, copy,
republish, upload, post, transmit, translate, sell, create
derivative works, exploit, or distribute in any manner
or medium any content or services displayed through
this device.
"THIRD PARTY CONTENT AND SERVICES
ARE PROVIDED "AS IS." SAMSUNG DOES
NOT WARRANT CONTENT OR SERVICES SO
PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY,
FOR ANY PURPOSE. SAMSUNG EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO, WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. SAMSUNG DOES
NOT GUARANTEE THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS
OF ANY CONTENT OR SERVICE MADE
AVAILABLE THROUGH THIS DEVICE AND
UNDER NO CIRCUMSTANCES, INCLUDING
NEGLIGENCE, SHALL SAMSUNG BE LIABLE,
WHETHER IN CONTRACT OR TORT, FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES, ATTORNEY
FEES, EXPENSES, OR ANY OTHER DAMAGES
ARISING OUT OF, OR IN CONNECTION WITH, ANY
INFORMATION CONTAINED IN, OR AS A RESULT
OF THE USE OF ANY CONTENT OR SERVICE BY
YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES."
69
Page 71
Third party services may be terminated or interrupted
at any time, and Samsung makes no representation
or warranty that any content or service will remain
available for any period of time. Content and services
are transmitted by third parties by means of networks
and transmission facilities over which Samsung
has no control. Without limiting the generality of
this disclaimer, Samsung expressly disclaims
any responsibility or liability for any interruption or
suspension of any content or service made available
through this device.
Samsung is neither responsible nor liable for customer
service related to the content and services. Any
question or request for service relating to the content
or services should be made directly to the respective
content and service providers.
70
Page 72
Declaration of Conformity (R&TTE)
We,
Samsung Electronics
declare under our sole responsibility that the product
GSM Mobile Phone : GT-C5010
to which this declaration relates, is in conformity with the following standards and/or
other normative documents.
SAFETY EN 60950- 1 : 2006 +A11:2009
EMC EN 301 489- 01 V1.6.1 (09-2005)
EN 301 489- 01 V1.8.1 (04-2008)
EN 301 489- 07 V1.3.1 (11-2005)
EN 301 489- 17 V2.1.1 (05-2009)
EN 301 489- 24 V1.4.1 (09-2007)
SAR EN 50360 : 2001
EN 62209- 1 : 2006
RADIO EN 301 511 V9.0.2 (03-2003)
EN 300 328 V1.7.1 (10-2006)
EN 301 908- 1 V3.2.1 (05-2007)
EN 301 908- 2 V3.2.1 (05-2007)
We hereby declare that [all essential radio test suites have been carried out and
that] the above named product is in conformity to all the essential requirements of
Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in
Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the
following Notied Body(ies):
BABT, Forsyth House,
Churcheld Road,
Walton-on-Thames,
Surrey, KT12 2TD, UK*
Identication mark: 0168
The technical documentation kept at :
Samsung Electronics QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK*
2011.05.07 Joong-Hoon Choi / Lab Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone
number of Samsung Service Centre, see the warranty card or contact the retailer
where you purchased your product.
Loading...
