Samsung SGH-A717 User Manual

SGH-A717

PORTABLE Quad-BAND

MOBILE PHONE

User Guide

Please read this manual before operating your

phone, and keep it for future reference.

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the
property of Samsung or its respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or software relating there to (the
“Phone System”), is proprietary to Samsung and protected under federal laws, state
laws, and international treaty provisions. Intellectual Property includes, but is not
limited to, inventions (patentable or unpatentable), patents, trade secrets,
copyrights, software, computer programs, and related documentation and other
works of authorship. You may not infringe or otherwise violate the rights secured by
the Intellectual Property. Moreover, you agree that you will not (and will not attempt
to) modify, prepare derivative works of, reverse engineer, decompile, disassemble,
or otherwise attempt to create source code from the software. No title to or
ownership in the Intellectual Property is transferred to you. All applicable rights of
the Intellectual Property shall remain with SAMSUNG and its suppliers.

Samsung Telecommunications America (STA), LLC

Headquarters: Customer Care Center:

1301 E. Lookout Drive 1000 Klein St.

Richardson, TX 75082 Plano, TX 75074

Toll Free Tel: [phone].HELP (4357)

Internet Address: http://www.samsungusa.com

©

2007 Samsung Telecommunications America, LLC is a registered trademark of

Samsung Electronics America, Inc. and its related entities.

Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS System
(Automated Response System) at:

www.samsungwireless.com/support

GH68-14413A

Printed in Korea

Openwave® is a registered Trademark of Openwave, Inc.

RSA® is a registered Trademark RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE
WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE
PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF
ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT
LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE
PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE
PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE
PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR
CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY
OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION,
SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

A717_UCGD7_ATT_WB_050207_F5

Table of Contents

Section 1: Getting Started ..........................................................................5

SIM Card Information ................................................................................................ 5

Charging a Battery .................................................................................................... 7

Installing the microSD Card .......................................................................................8

Turning the Phone On or Off ......................................................................................9

Setting Up Your Voice Mail ........................................................................................ 9

Section 2: Understanding Your Phone .....................................................12

Features of Your Phone ...........................................................................................12

Open View of Your Phone ........................................................................................13

Closed View of Your Phone .....................................................................................15

Internal Display Layout ...........................................................................................16

Selecting Functions and Options .............................................................................19

Command Keys ......................................................................................................20

Section 3: Call Functions .........................................................................23

Making a Call ..........................................................................................................23

Answering a Call .....................................................................................................25

Video Share ............................................................................................................25

Play a Video Share Recording .................................................................................26

Recent Calls ...........................................................................................................26

Call Time ................................................................................................................28

Data Volume ...........................................................................................................29

Data Call Time ........................................................................................................29

Silent Mode ............................................................................................................ 30

Options During a Call ..............................................................................................30

Section 4: Menu Navigation ....................................................................35

Menu Navigation .....................................................................................................35

Menu Outline ..........................................................................................................36

Section 5: Entering Text ..........................................................................48

Changing the Text Input Method ............................................................................. 48

Using the T9 Input Method ...................................................................................... 49

Using the Alphabet Input Method ............................................................................ 50

Using the Symbols Input Method .............................................................................51

Using the Numeric Input Method .............................................................................52

Section 6: Understanding Your Address Book ........................................53

Using Contacts List .................................................................................................53

Address Book Entry Options .................................................................................... 54

Adding a New Contact ............................................................................................55

Dialing a Number from the SIM Card using the Location Number ............................58

Speed Dial ..............................................................................................................58

Finding My Own Phone Number .............................................................................. 60

FDN Mode ..............................................................................................................60

1

Group Settings ........................................................................................................60

Managing Address Book Entries ..............................................................................61

Section 7: Messaging ............................................................................. 63

Types of Messages .................................................................................................63

Creating and Sending New Messages .....................................................................63

Text Messages ........................................................................................................63

Using Message Options ...........................................................................................70

Using Instant Messenger (IM) ..................................................................................71

Signing into your IM Account ...................................................................................72

Signing into your Mobile Email ................................................................................72

Using Message Templates ......................................................................................72

Deleting Messages .................................................................................................73

Messaging Settings ................................................................................................74

Memory Status .......................................................................................................77

Section 8: Changing Your Settings ......................................................... 78

Sound Settings .......................................................................................................78

Display Settings ......................................................................................................81

Time & Date ............................................................................................................82

Phone Settings ........................................................................................................83

Call Settings ...........................................................................................................84

Connectivity ............................................................................................................88

Configuring your Phone’s Connections ....................................................................91

Configuring your Phone’s USB Connection ..............................................................92

Software Update .....................................................................................................93

Application Settings ................................................................................................93

Reset Settings .........................................................................................................96

Memory Settings .....................................................................................................97

Video Share Settings ...............................................................................................98

Section 9: AT&T Mall ............................................................................. 100

Shopping for Audio ...............................................................................................100

Shopping for Games .............................................................................................101

Shopping for Graphics ...........................................................................................101

Shopping for Multimedia Content ..........................................................................102

Shopping for Applications .....................................................................................102

Accessing the MEdia Net Home .............................................................................103

Section 10: AT&T Music ........................................................................ 104

Accessing AT&T Music ..........................................................................................104

Adding Music to your Handset ...............................................................................104

Using the Music Player ..........................................................................................107

Multitasking ..........................................................................................................108

Using Playlists .......................................................................................................109

Using MusicID .......................................................................................................112

Streaming Music ...................................................................................................113

Music Video ..........................................................................................................114

Table of Contents 2

The Buzz ..............................................................................................................115

Music Community ................................................................................................. 116

Music Apps ...........................................................................................................117

Section 11: Cellular Video ......................................................................118

Cellular Video Options ........................................................................................... 119

Media Clip Options ................................................................................................120

Using the Video Categories ...................................................................................121

Customizing Cellular Video ....................................................................................122

My Purchases ....................................................................................................... 123

Parental Controls .................................................................................................. 123

Section 12: Using the Applications ........................................................125

Shop Applications .................................................................................................126

Using the Camera .................................................................................................126

Using the Camcorder ............................................................................................ 130

Media Player .........................................................................................................134

Record Audio ........................................................................................................134

Alarms ..................................................................................................................135

Calendar ...............................................................................................................137

Tasks ...................................................................................................................140

Note .....................................................................................................................141

Calculator .............................................................................................................141

Tip Calculator .......................................................................................................141

Converter ..............................................................................................................142

World Time ...........................................................................................................142

Timer ....................................................................................................................142

Stopwatch ............................................................................................................143

Section 13: MEdia Net and WAP .............................................................144

Accessing the MEdia Net Homepage ..................................................................... 144

Accessing the MEdia Net Site ...............................................................................147

Navigating with the WAP Browser .........................................................................147

Using Favorites .....................................................................................................149

Downloading Multimedia Files .............................................................................. 150

Using your History .................................................................................................151

Clearing the Cache ...............................................................................................151

Clearing the Cookies ............................................................................................. 151

Changing the WAP Profiles ....................................................................................152

Section 14: Section 14: Accessibility .....................................................154

Section 15: Health and Safety Information ............................................155

Health and Safety Information ............................................................................... 155

Samsung Mobile Products and Recycling ..............................................................157

UL Certified Travel Adapter ................................................................................... 157

Consumer Information on Wireless Phones ........................................................... 158

Road Safety ..........................................................................................................164

Responsible Listening ........................................................................................... 166

3

Operating Environment .........................................................................................168

Using Your Phone Near Other Electronic Devices ...................................................168

Potentially Explosive Environments .......................................................................169

Emergency Calls ...................................................................................................170

FCC Notice and Cautions .......................................................................................171

Other Important Safety Information .......................................................................171

Product Performance ............................................................................................172

Availability of Various Features/Ring Tones ...........................................................173

Battery Standby and Talk Time .............................................................................173

Battery Precautions ...............................................................................................173

Care and Maintenance ..........................................................................................174

Section 16: Warranty Information ......................................................... 176

Standard Limited Warranty ...................................................................................176

Index ........................................................................................................ 181

Table of Contents 4

Section 1: Getting Started

Topics Covered

• SIM Card Information

• Charging a Battery

• Installing the microSD Card

• Turning the Phone On or Off

• Setting Up Your Voice Mail

This section describes the first steps to operating your phone.

SIM Card Information

When you subscribe for 3G cellular network services, you receive a plug-in USIM
(Universal Subscriber Identity Module) card loaded with your subscription details,
such as your PIN, and available optional services.

Install and charge the phone

1. If necessary, power-off the phone by holding down the key until the

power-off image displays.

2. Remove the battery by pressing the battery lock down and slide the battery

cover away, as shown.

5

SIM Card Information

Inserting and Removing the SIM card

Important!: The plug-in SIM card and its contacts can be easi ly damaged by scratches or bending. Use

caution when inserting or removing the card and keep all SIM cards out of reach of childre n.

Make sure the gold contacts of the card are face down, then slide the SIM card into
the socket.

Installing the Battery

1. Align the battery tabs with the slots at the bottom of the phone.

2. Press the battery down until it clicks into place. Make sure that the battery

is properly installed before switching on the phone.

3. With the battery in position on the phone, place the cover back on the

handset and slide it in until it clicks.

Getting Started 6

Charging a Battery

Your phone is powered by a rechargeable Li-ion battery. Use the travel adaptor to
charge the battery, and use only Samsung approved batteries and chargers.

Note: You must fully charge the battery before using your phone for the first time. A fully discharged battery

requires up to 4 hours of charge time.

Note: For connection to an electrical supply not located in the U.S., you must use an adaptor of the proper

configuration for the power outlet. Use of the wr ong adaptor could damage your phone and void your
warranty.

1. Plug the connector of the travel adaptor into the jack on the side of the

phone.

2. Plug the adaptor into a standard AC wall outlet.

Note: The following illustration is the correct and inco rrect method for connecting the charger. If attempted,

damage to the accessory port will occur therefore voiding the phone’s warranty.

3. When the phone is completely charged (the battery icon becomes still),

unplug the adapter from the power outlet.

7

Installing the microSD Card

4. Remove the adapter from the phone by gently pulling the connector out.

Note: You must unplug the ada ptor before removing the battery from the phone during charging to avoid

damage.

Installing the microSD Card

To add additional memory to your phone you can insert a microSD card into the side
of the phone. Use the following instructions and illustrations for proper insertion and
removal.

1. Open the side slot to insert the card. Place the microSD card into the slot.

2. Push the microSD card into the slot until it clicks into place.

Warning!: Please note the proper side is facing down wh en inserting the card.

3. To remove the card, a quick press to release the card from the slot.

Getting Started 8

Low Battery Indicator

When the battery is weak and only a few minutes of talk time remain, a warning tone
sounds, the “Battery Low” message repeats at regular intervals on the display, and
the empty battery icon blinks. The backlight turns off to conserve the
remaining battery power.

If the battery level becomes too low, the phone automatically turns off. Recharge
your battery.

Turning the Phone On or Off

1. Open the phone.

2. Press and hold the key until the phone power-on screen displays.

Note: Do not turn on the phone when mobile phone use is pro hibited.

3. If the phone asks you to enter a password, enter a password and press the

Confirm soft key or the key. For further details, see "Change Phone

Password" on page 95.

The phone searches for your network and after finding it, the Idle screen
displays. Now, you can make or receive calls.

Note: The display language is preset to Automatic at the factory. To change the language, use the

Language menu. For more information, refer to "Phone Settings" on page 83.

4. When you wish to switch off the phone, press and hold the key until

the power-off image is displayed.

Note: You must store the voicemail server number before accessing the ser ver. Your service provider can

give you the number.

Setting Up Your Voice Mail

To access you voice mail from your keypad, use the following steps:

9

Setting Up Your Voice Mail

1. Open the phone to access your keypad.

2. From an Idle screen, press and hold the key.

3. Follow the voice mail prompts to access messages.

Accessing Your Voice Mail

1. In Idle mode, press the Menu soft key to access Menu mode.

2. Highlight Recent Calls and press the key.

3. Highlight Voice Mail.

4. Highlight Connect to Voice Mail and press the Select soft key or

the key.

5. When connected, follow the voice prompts from the voice mail center.

Changing the Voice Mail Name and Number

Your SIM card gives you default service number of the voice mail center. However,
you may need to change the number. Use the following procedures to change your
voice mail number.

1. In Idle mode, press the Menu soft key to access Menu mode.

2. Highlight Recent Calls and press Select soft key or the key.

3. Highlight Voice Mail and press Select soft key or the key.

4. Highlight Voice Server Number and press the Select soft key or the

key.

5. Press the Edit softkey.

6. To edit the Voice Server Name, highlight Name and press and press

to delete the current name and then use your keypad to enter a
replacement name.

- or -

7. To edit the Voice Mail Number, highlight Center Address and press to

delete the current number.

Getting Started 10

8.

Enter your new Voice Server number and press the Save soft key or the

key to save this new number.

9. Press the key to return to Idle mode.

11

Features of Your Phone

Section 2: Understanding Your Phone

Topics Covered

• Features of Your Phone

• Open View of Your Phone

• Closed View of Your Phone

• Internal Display Layout

• Selecting Functions and Options

• Command Keys

This section outlines some key features of your phone. It also displays the screen
and the icons that are displayed when the phone is in use.

Features of Your Phone

Your phone is lightweight, easy-to-use and offers many significant features. The
following list outlines a few of the features included in your phone.

User friendly, menu driven access to features and options.

• Bluetooth

• Camera and camcorder

• Video Sharing

• Multi-tasking

• Instant Messaging capability

• E-mail

• Featured applications provide alarms, calendar, calculator, record audio, converter,

timer, stopwatch, and world time.

• File viewer

• Name card

• Multimedia Message Service (MMS)

• Multimedia capability (with included Media player)

• Photo caller ID

• Speakerphone capability

• Web browser

Understanding Your Phone 12

Open View of Your Phone

The following illustrations show the main elements of your phone:

Keys

The following list correlates to the open and front view illustrations.

1. Display: This screen displays all the information needed to operate your

phone.

2. Navigation keys: This key allows you to scroll through phone menu

options and provides a shortcut to phone functions from standby mode.

3. Soft keys: Perform the functions indicated by the screen text on the

bottom of the display.

4. Music key: Allows you to access both local and web-based Music

applications.

5. Send key: Allows you to place or receive a call. In standby mode, press the

key once to access the Recent Call log. If you press and hold the key down,
you will initiate the most recent call from the Recent Call log.

6. Microphone: The Microphone allows the other callers to hear you clearly

when you are speaking to them.

13

Open View of Your Phone

7. Voice Mail key: Press and hold the key to automatically dial your

voicemail.

[

8. Special Function keys: Asterisk/Shift key-enters the

calling features. In text mode, press to change the character input type.
Pound/Space key-enters the pound

[#] character for calling features. In

] character for

*

text entry mode, press to enter a space between characters.
Press and hold the to activate/deactivate the Silent profile. Press and
hold

to enter a pause between numbers.

9. Alphanumeric keypad: Use these keys to enter numbers, letters and

some special characters. When in Idle mode, press and hold the key to
access your voicemail server or press and hold to enter an
International call prefix.

10. Clear key: Deletes characters from the display when you are in text entry

mode. Deletes items when in an application. When in a main menu, press
to return to the previous menu.

11. Power on/off/Menu Exit key: Ends a call. Press and hold this key for a

few seconds to power your phone On or Off. While in the main menu, it
returns the phone to standby mode and cancels you input. When you
receive an incoming call, press to reject call.

12. Swap key: Opens the application switch window which allows you to

select from a group of different applications without having to exit from the
currently active application.

13. Menu access/Confirm key (WAP browser): When navigating through a

menu accepts the highlighted choice in the menu. If you press once in Idle
mode, the WAP browser will launch.

14. Earpiece/Speaker: Used to listen to audio and music from your phone.

Understanding Your Phone 14

Closed View of Your Phone

Keys

The following list correlates to the open and front view illustrations.

1. Camera lens: The camera lens is used for taking photos.

2. Front LCD: Your phone has an external display on the front of the phone. It

indicates when you have an incoming call or message. It also displays
date, time, reception, battery power, and any icons associated with alerts,
such as messages, or a set alarm.

3. Volume key: Allows you to adjust the ringer volume in standby mode or

adjust the voice volume during a call. The volume key can also be used to
scroll up or down to navigate through the different menu options. To mute
the ringer during an incoming call, press the volume key up or down.
When the phone is closed, press and hold these keys to toggle the display
on or off. This key is also used when the Music Player is active.

• If you are playing music and the backlight goes out, you will need to press and

hold this key to gain access to the music player keys when the flip is closed. If
the backlight is out, the keys themselves will not wake up the phone or control
the music player.

4. Headset jack/Adapter jack: Allows you to plug in the travel adapter

(power), PC connection cable (data transfer), and optional headset for safe,
convenient, hands-free conversations.

5. Memory Card slot: Used to install an optional microSD™ card for

additional data storage.

15

Internal Display Layout

Back Light

A back light illuminates the display and the keypad when you press any key or open
the phone. It turns off when no keys are pressed within a given period of time,
and/or dims the light, depending on the settings in the Backlight Time menu.

Internal Display Layout

The display has 3 areas:

Icons

Shows the received signal strength. The greater the number of
bars, the stronger the signal.

Appears when the phone is accessing services in a GPRS
network. When data is being transferred, this icon animates.

Appears when the phone is accessing services in an EDGE
network. When data is being transferred, this icon animates.

Appears when the phone is accessing services in a 3G (UMTS)
network. When data is being transferred, this icon animates.

Appears when the phone is accessing services in a 3G+
(HSDPA) network. When data is being transferred, this

icon animates.

Appears when a call is in progress.

Understanding Your Phone 16

Appears when there is no network coverage available. When
you are out of the service area, you cannot make or receive
voice calls.

Appears when an alarm is set on your phone.

Appears when your incoming phone calls are being forwarded
to another number.

Appears when a new voice mail has been received.

Appears when a new text message has been received.

Appears when a new multimedia message has been received.

Appears when a new E-mail message has been received.

Appears when a push-messages has been received from the
WAP server.

Appears when a new Over the Air (OTA) software update file has
been received.

Appears after your memory card has been inserted.

Appears when Bluetooth wireless technology is active. When
transferring data, this icon blinks red and blue.

Appears when a Bluetooth wireless headset is active and in use.

Appears when you are connected to a PC via a USB port.

Appears when you are browsing the Internet while using the
phone as a modem.

Appears when you are connected to a secured web page.

Note: The default phone profile is Normal, the profile is editable and the displayed icons may var y

according to the setting.

17

Internal Display Layout

Appears when the phone’s profile is set to either Normal,
Driving or Meeting profile or Driving. This indicates that the

phone’s incoming Alert Type is set to melody. This audio icon is

accompanied on screen by the Driving or Meeting icon.

Appears when the phone’s profile is set to Silent. In this case,
the speaker is muted and the phone only vibrates and displays
information on its front panel LCD. This Vibrate off icon is

accompanied on screen by the Vibrate icon.

Appears when the phone’s profile is set to Silent. This indicates
that the phone’s incoming Alert Type is set to vibrate only. This
icon is accompanied on screen by the Vibrate off icon.

Appears when the phone’s profile is set to Meeting. In this
case, both the speaker and vibration features are disabled and
only the front panel LCD displays information. This icon is

accompanied on screen by the Melody Alert icon.

Appears when the phone’s profile is set to Airplane. This
indicates that the phone’s incoming Alert Type is set to mute the

speakers and deactivate the vibration feature.
This Vibrate Off icon is accompanied on screen by either
the Airplane icon.

Appears when the phone’s profile is set to Driving. In this case,

the speaker is active. In this case, the speaker is active and will

launch the currently selected ringtone or melody when the
associated notification is activated. This icon is accompanied
on screen by the Audio icon.

Appears when the phone’s profile is set to Outdoor. In this case,

the speaker is active, the volume settings are raised to their

highest levels, any currently active ringtones or melodies
are activated, and the phone’s vibrate feature is activated.
This icon is accompanied on screen by the Vibrate/Audio icon.

Understanding Your Phone 18

Appears when the phone’s profile is set to Outdoor. This
indicates that the phone’s incoming Alert Type is set to melody
and vibrate. This vibrate/audio icon is accompanied on screen

by the Outdoor icon.

Appears when a phone’s profile is set to Airplane. This
indicates that the phone’s incoming Alert Type allows you to use

many of your phone’s features, such as Games, Music,
Voice Memos, etc., but you cannot send or receive any calls or
access online information. This icon is accompanied on screen
by the Vibrate Off icon.

Appears when the speakerphone feature is being used during

an active call.

Shows the level of your battery. The more bars you see, the

more power you have remaining.

Selecting Functions and Options

Your phone offers a set of functions that can be customized for your ease and
specific needs. These functions are arranged in menus and sub-menus, accessed
using the two soft keys. Each menu and sub-menu allows you to view and alter the
settings of a particular function.

In some functions, you may be asked for a password or PIN. Enter the code and
press the Select soft key or the key.

When you access a list of options, your phone highlights the currently active option.
If, however, there are only two options, such as On/Off or Enable/Disable, your
phone highlights the option that is not currently active, so that you can select it
directly.

Selecting Options

To view the various functions and options available and to select the one you want:

• Press the appropriate soft key.

• To select the function displayed or the option highlighted, press the Select soft key

or the key.

• To view the next function or highlight the next option on a list, press the Down

Navigation key or the key on the left side of the phone.

19

Command Keys

• To move back to the previous function or option on a list, press the Up Navigation

key or the key on the left side of the phone.

• To move back up one level in the menu structure, press the Back soft key.

• To exit the menu structure without changing the settings, press the key.

Command Keys

Functions for the soft keys are defined by what appears above each in the display.
There are two soft keys, the left soft key and the right soft key .

Soft Keys

The roles of the soft keys vary depending on the function you are currently using; the
labels on the bottom line of the display just above each key indicate their current
role.

Left Soft Key

Some functions of the left soft key are as follows.

• In the Idle screen, press the Menu (left) soft key to open the Menu screen.

• When in a menu mode the left soft key function is Select.

Right Soft Key

Some functions of the right soft key are as follows.

• In the Idle screen, press the Options (right) soft key to open the My Menu

screen. This menu contains the following:

• 1: Camera

• 2: Profiles

• 3: Bluetooth

• 4: Alarms

• 5~12: Empty

• When in a menu mode the right soft key function is Back.

Understanding Your Phone 20

Clear Key

The CLR key is used to erase or clear numbers, text, or symbols from the
display. You can also use to return to a previous menu or to return to standby
mode from any menu.

• If you enter an incorrect character, briefly press to backspace (and delete) the

character.

• To erase the entire sentence, press and hold .

• To back up one menu level, briefly press .

End Key

The End key is used to turn on/off your phone, disconnect calls, and return to
the standby mode.

• Press and hold the End key to turn on/off your phone.

• Briefly press once to disconnect a call.

• Press to return to standby mode from any menu.

Send Key

The Send key is used to answer calls, dial calls, and to recall the last number(s)
dialed, received, or missed.

• Press once to answer calls.

• Enter a number and briefly press to make a call.

• Briefly press in standby mode to display a list of recent calls to and from your

phone.

• Press twice in standby mode to call the most recent number.

• Press to pick up a waiting call.

21

Command Keys

Navigation Key

Use the directional keys on the Navigation key to browse menus, sub menus, and
lists. Press the up or down navigation when jumping to highlighted links on the web.

Each key also acts as a shortcut to launch applications.

Understanding Your Phone 22

Section 3: Call Functions

Topics Covered

• Making a Call

• Answering a Call

• Video Share

• Recent Calls

• Call Time

•Data Volume

• Data Call Time

• Silent Mode

• Options During a Call

This section describes how to make or answer a call. It also includes the features
and functionality associated with making or answering a call.

Making a Call

When the Idle screen displays, enter the area code and phone number, and press the

key.

Note: When you activate the Auto Redial option in the Voice Call menu, the phone will automatically redial

up to 10 times when the person does not answer the call or is already on the phone.

Making an International Call

1. Press and hold the key. The + character appears.

2. Enter the country code, area code, and phone number, then press the

key.

Correcting an Entered Number

Use the following steps to correct a mis-typed entry when dialing.

1. After entering a number

• To clear the last digit displayed, press the key.

23

Making a Call

• To clear another digit in the number, press the Left or Right Navigation key until

the cursor is immediately to the right of the digit to be cleared. Press the
key.

• To enter a missing digit press the Left or Right Navigation key until the cursor is

in position and enter the digit.

• To clear the whole display, press and hold the key.

2. Press the key to return to the Idle screen.

Ending a Call

When you want to finish your call, briefly press the key.

Redialing the Last Number

All incoming, outgoing and missed calls are listed in the Recent Calls Menu. If the
number or caller is listed in your Address Book, the name associated displays.

To access the Recent Calls menu:

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Use the Up and Down Navigation keys to scroll through the Recent Calls

options. Choose from All Calls, Missed Calls, Calls Made, Calls

Received, or Voice Mail.

3. From the Idle Screen, press the key to display a list of the most recent

numbers used in the order you dialed or received them.

4. Use the Up and Down Navigation keys to scroll through the numbers until

the number you want highlights.

5. To dial the number, highlight the number and press the key.

Making a Call from the Address Book

You can store phone numbers that you use regularly on the SIM card or in the
phone’s memory. These entries are collectively called the Address Book.

Once you have stored a number in the Address Book, you can dial it by pressing a
few keys using the Speed Dial feature.

For further details about the Address Book feature, see "Finding an Address Book
Entry" on page 54.

Call Functions 24

Answering a Call

When a call is received the phone rings and displays the caller’s phone number, or
name if stored in the Address Book.

1. From the Idle Screen press the key.

If the Any key option in the Call Settings menu is activated, you can press
any key to answer a call except for the key and the Reject soft key.

If the Active Flip option in the Call Settings menu is activated, you can
answer the call simply by opening the phone.

Note: To reject an incoming call, press and hold the Volume keys on the left side of the phone before

opening the phone. A quick press of side volume ke y silences the ringer on an incoming call.

2. End the call by closing the phone or by pressing the key.

Note: You can answer a call while using the Address Book or menu features. After ending the call, the

phone returns to the function screen you were using.

Video Share

The Video Share features allows you to place a call and share live or recorded video
while on the call. You can initiate or receive video by using the following steps. To
enable or disable Video Share, see "Video Share Settings" on page 98.

Initiating and Receiving a Video Share Session

To initiate and receive a Video Share session use the following steps:

1. Dial the number and press the key.

2. Once the call is answered, if you're both capable of Video Share, a "Video

Share Ready" icon will appear on the screen and the Right Soft Key

will change to Video Share. Press the Right soft key to invite the
other party to see video shot from your phone.

3. "Establishing a Video Connection" displays. A message is sent to the

recipient "###-###-#### Wants to Share Video With You."

4. The recipient will receive a Video Share pop-up to Accept or Decline the

Video Share call. Press the Left soft key Accept to continue or
Right soft key to Decline.

5. A Recording Started pop-up displays showing the memory available for the

video.

25

Play a Video Share Recording

6. During a Video Share session, the following are displayed above the soft

key options:

Stop: press this key to stop the video share feature.

Brightness: press this key to adjust the brightness for the video.

Mute: Press this key to turn the audio off.

Spkr Off: press this key to turn off the speaker.

Lscape: press this key to change the image orientation from Normal

to Landscape.

Tip: To stop the video share call press the Options soft key and press the Select the “Video Share End”

soft key.

A pop-up message displays “Do you want to save the video share call?” The
recorded videos are stored in the My Stuff > Video folder.

Video Share (In-Call)

You can begin a Video Share call during an existing call by pressing Video
Share, or by pressing the Options and selecting Video Share > Live.

Play a Video Share Recording

During a call (while not in a Live Video Share session) you can share a recorded
video for the recipient. Press the Options key and select Video Share>Recorded>
and then select from the available files in your "My Stuff," folder. To make the
connection, the recipient should press Accept and the Video begins to play on both
phones.

Recent Calls

The phone stores the numbers of the calls you’ve dialed, received, or missed in the
Recent Calls menu. If the number or caller is listed in your Address Book, the
associated name is displayed.

Call Functions 26

Viewing Missed Calls

The number of calls you have missed is displayed on both the Idle screen and the
front panel LCD. To view the number details, use the following steps:

1. If the phone is closed, open the phone.

2. Press the View soft key. The most recently missed call is displayed.

Note: If there is a voicemail sent by the same number, associated icons display and can be selected.

3. To scroll through the list of missed calls, press the Up or Down Navigation

key.

4. To move to another call type, press the Left or Right Navigation key.

Viewing the Details of a Missed Calls

To view the details of a selected missed call, use the following steps:

1. Press the View soft key. The most recently missed call is displayed.

2. To scroll through the list of missed calls, press the Up or Down Navigation

key.

3. With the missed call selected and press the Options soft key.

4. Use the Navigation keys to highlight Details and press the key.

Calling Back a Missed Call

To call back a missed call number, use the following steps:

1. Press the View soft key. The most recently missed call is displayed.

2. To scroll through the list of missed calls, press the Up or Down Navigation

key.

3. Highlight the number and press either Call or press the Send to Call Back.

Saving a Missed Call to your Address Book

To save the missed call entry to your address book, use the following steps:

1. Press the View soft key. The most recently missed call is displayed.

2. With the missed call selected and press the Options soft key.

3. Use the navigation keys to highlight Save to Address book and press the

key.

27

Call Time

4. Select the location of your Address Book:

• Phone: This option allows you to save the missed number to your Address Book

stored on the phone.

•SIM: This option allows you to save the missed number to your Address Book

stored on the optional SIM card.

For further details about the Address Book feature, see "Adding a New Contact" on
page 55.

Sending a Message to a Missed Call

To send a text message or attachment to a missed call entry, use the following
steps:

1. Immediately after missing a call, press the View soft key.

2. Press the Options soft key and select Send Message. Press the Select

soft key, or the key.

3. At the “Create New Message” screen, press Down Navigation key.

4. Use the Alphanumeric keys to type in a message or press the Options soft

key to also Add Items such as an: Image, Sound, or Video.

5. When you are done with your message, press the Options soft key. Use the

navigation keys to highlight Send and press the key.

Note: When you "Add items" in the options, the setting automatically changes to "Multimedia Message".

Deleting a Missed Call

To delete a missed call entry, use the following steps:

1. Immediately after missing a call, press the View soft key.

2. Press the Options soft key and select Delete. Press the Select soft key, or

the key.

3. At the “Delete?” prompt, press either the Ye s soft key to confirm deletion

or No to cancel.

You can press the key at any time to exit the Missed Call feature.

Call Time

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select or the key.

2. Highlight Call Time from the Recent Calls menu and press the Select soft

key or the key.

Call Functions 28

3.

The following options are available.

• Last Call Time: shows the length of time for the last call.

• Total Sent: shows the total length of time for the calls made.

• Total Received: shows the total length of time for the calls received.

4. Select the desired option, press the Reset soft key.

5. Enter the password and press the Confirm soft key to reset the selected

option.

6. Press the Back soft key or the key to end.

Data Volume

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Highlight Data Volume and press the Select soft key or the key. Data

Volume refers to the amount of data (volume) to and from the phone.

3. Use the Up and Down Navigation keys to view the following information:

• Last Sent Data: shows the size of the last data packet (measured in KB -

kilobytes) sent by the phone since the last time this counter was reset.

• Last Received Data: shows the size of the last data packet (measured in KB -

kilobytes) received by the phone since the last time this counter was reset.

• Total Sent Data: shows the size of the total data packet (measured in KB -

kilobytes) which have been sent by the phone since the last time this counter
was reset.

• Total Received Data: shows the size of the total data packet (measured in KB -

kilobytes) which have been received by the phone since the last time this counter
was reset.

4. Press the Back soft key or the key to end.

Data Call Time

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Highlight Data Call Time and press the Select soft key or the key.

3. The following options are available:

• Last Data Call: shows the time used for the last data call sent or received since

the last time this counter was reset.

• Total Data Call: shows the total time used to send or receive data since the last

time this counter was reset.

4. Press the Back soft key or the key to end.

29

Silent Mode

Silent Mode

Silent mode is convenient when you wish to stop the phone from making noise, in a
theater for example.

In Idle mode, press and hold the key until the phone vibrates, the “Silent Profile
on” message appears on screen. Both the Silent mode and Vibrate icons
are displayed on screen.

In Silent mode, your phone’s speakers are muted. The phone will vibrate and light up
the external LCD display or just light the external LCD display depending on the
settings of the Silent Phone Settings feature.

To exit and reactivate the previous sound settings, press and hold the key again
until “Normal Profile on” displays. The Silent mode and Vibrate icons are no longer
displayed.

Options During a Call

Your phone provides a number of control functions that you can use during a call.

Adjusting the Call Volume

During a call, if you want to adjust the earpiece volume, use the Volume keys on the
left side of the phone.

Press the key to increase the volume level and the key to decrease the level.

In Idle mode, you can also adjust the ringer volume using these same keys.

Putting a Call on Hold

You can place the current call on hold whenever you want. You can also make
another call while you have a call in progress if your network supports this service.

To put a call on hold:

1. While on a call, press the left Options soft key.

2. Highlight Hold and press the Select soft key. The call is on hold.

3. You can reactivate the call whenever you want, by pressing the Resume

soft key.

Call Functions 30

To make a call while you have a call in progress:

1. Place the current call on hold using the previous procedures.

2. Enter the new phone number that you wish to dial or look it up in the

Address Book.

3. Press the key to dial the second call. Once connected, both calls are

displayed on the screen.

When you have an active call and a call on hold, you may switch between the two
calls, changing the one on hold to active and placing the other on hold.

To switch between the two calls:

1. Press the left soft key Options.

2. Highlight Swap and press the Select soft key. The current call (#2) is

placed on hold and the previous call on hold (#1) is reactivated so that you
can continue conversing with that person.

3. Press the key to end the currently selected call.

To end a call:

1. Press the left soft key Options.

2. Highlight End and press the Select soft key.

3. Highlight the call you wish to end (Active Call, Held Call, or All Calls) and

press the Select soft key.

4. Press the key to end the remaining call.

Using the Speakerphone Key

1. During a call, press the speakerphone key .

2. Use the volume keys (located on the left side of your phone) to adjust the

volume.

Important!: For more information, see "Responsible Listening" on page 166.

In Call Options

During a call, press the Options soft key to access the following:

• Mute: Mutes the onboard microphone.

• Video Share: Initiates a video conferencing session.

• Whisper Mode ON/OFF: Increases the microphone sensitivity level so that you do

not have to speak louder to be heard by the other party.

• Hold: Places the current call on hold.

31

Options During a Call

• Mute Keypad Tone: Silences/mutes the key tones when on the call. To turn this

feature off (unmute the keypad), return to this option and select Send Keypad
Ton e.

• New Call: Places the current call on hold and then allows you to enter and dial

another number.

• Send DTMF: Sends DTMF (Dual Tone Multi-Frequency) tones to the contacts you

have selected. These DTMF tones are sent as a group. The DTMF tones are the
tones used in phones for tone dialling, sounding when you press the number keys.
This option is helpful for entering a password or an account number when you call
an automated system, like a banking service.

• Address Book: Allows you to access your Address Book information.

• Save to Address Book: Allows you to add the currently phone number to your

Contacts list on either your Phone or SIM card.

• View Address Book Details: Displays the Address Book entry information for this

caller.

• Send Message: Allows you to create and send a new Text message or Multimedia

Message.

• Calendar: Allows you to temporarily access your calendar while still maintaining

the current call active.

• Note: Allows you to associate a note with the current phone number.

• End Call: Allows you to end the current call.

If you have are in a multi-party call, the following options also display.

• Join: Joins all of the calls you have established with your phone (both active and

on hold).

• Swap: Places the current call on hold and then activates the previous call.

When you want to finish, end each call normally by pressing the key.

Muting or Sending Key Tones

These options allow you to turn the key tones off or on. If the Mute Key Tone option
is selected, tones of the keys, which allows you to press keys without hearing
annoying key tones during a call.

Note: To communicate with answering machines or computerized telephone systems, the Send Keypad

Tone option must be selected.

Call Functions 32

Switching off the Microphone (Mute)

You can temporarily switch your phone’s microphone off, so that the other person
cannot hear you.

Example: You wish to say something to person in the room, but do not want the person on the phone to

hear you.

During a call, to switch the microphone off temporarily:

1. Press the Mute. Unmute displays.

2. Press the Unmute to deactivate the Mute function.

Searching for a Number in Address Book

You can search for a number in Address Book during a call.

1. Press the Options soft key.

2. Press the Down key to highlight the Address Book option.

3. Press the Select soft key or the key.

4. Highlight the Address Book entry by using the Up or Down Navigation key.

- or -

5. Enter the first few letters of the contact into the Search field which then

highlights the closest match in the Address Book list.

6. To view the highlighted entry, press the Options soft key.

For further details about the Address Book feature, see "Finding an Address Book
Entry" on page 54.

Call Waiting

The Call Waiting feature allows you to answer an incoming call while you have a call
in progress, if this service is supported by the network, and you have set the Call
Settings > Call Waiting > Voice Waiting Menu to Activated. You are notified of an
incoming call by a call waiting tone.

To answer a call while you have a call in progress:

1. Press the key to answer the incoming call. The first call is

automatically put on hold.

2. To switch between the two calls, press the left Options soft key and

highlight Swap.

33

Options During a Call

To end a call on hold:

1. Press the Options soft key.

2. Select the End Held Call option or press the key.

To end the current call, press the key.

Note: Join: Joins all of the calls you have established with your phone (both active and on hold).

Swap: Places the current call on hold and then activates the previous call.

3-Way Calling (Party Line)

The 3-Way or Multi-Line feature allows you to answer a series of incoming calls,
place them on hold, and if this service is supported by the network, and join all of the
calls together. You are notified of an incoming call by a call waiting tone.

To answer a call while you have a call in progress:

1. Press the key to answer the first incoming call.

2. Press the key to answer the consecutive incoming calls. The previous

call is then automatically put on hold.

3. To Join the first two calls, press the left Options soft key and highlight

Join.

4. To end the current call, press the key.

Call Functions 34

Section 4: Menu Navigation

Topics Covered

• Menu Navigation

• Menu Outline

This section explains the menu navigation for your phone. It also includes an outline
of all the available menus associated with your phone.

Menu Navigation

Menus and sub-menus can be accessed by scrolling through them using the
Navigation keys or by using the shortcut keys.

Accessing a Menu Function by Scrolling

1. In Idle mode, press the Menu soft key to access Menu mode.

2. Scroll using the Navigation keys to reach a main menu, Settings for

example. Press the Select soft key or the key to enter the menu.

3. If the menu contains sub-menus, Phone Settings for example, you can

access them by first highlighting the option and then by pressing the
Select soft key or the key. If the menu you have selected contains
further options, repeat this step.

4. To scroll through these menus, press either the Up or Down Navigation key

or the Volume key (located on the left side of your phone). Press the

Select soft key, or the key to make your selection.

5. To return to the previous menu level, press the Back soft key, the key.

6. To exit the menu without changing the settings, press the key.

35

Using Shortcuts

Numbered menu items, such as menus, sub-menus, and options can be quickly
accessed by using their shortcut numbers. In Menu mode, Main Menus can be
accessed by pressing the number keys (1 to 0) corresponding to their location on the
screen.

Example: Accessing the Language menu.

1. Press the Menu soft key.

2. Press the key for Settings.

3. Press the key for Phone Settings

4. Press the key for Language.

5. Press the key to display the list of available languages.

Menu Outline

The following list shows the menu structure and indicates the number assigned to
each option.

1: AT&T Music

1: Music Player

1: Last played
2: All
3: Recently played
4: Most played
5: Artists
6: Genres
7: Albums
8: Composers

9: Playlists
2: Shop Music
3: MusicID
4: Streaming Music
5: Music Video

1: Go to

2: Reload

3: Desktop View

4: Page Size

5: Go to Homepage

6: Add to Favorites

Menu Navigation 36

7: View Favorites
8: Send URL
9: Enter URL
10: Copy URL via Message
11: Save
12: Saved Pages
13: History
14: Advanced

6: The Buzz
7: Community

1: Go to
2: Go
3: Reload
4: Desktop View
5: Page Size
6: Go to Homepage
7: Add to Favorites
8: View Favorites
9: Send URL
10: Enter URL
11: Copy URL via Message
12: Save
13: Saved Pages
14: History
15: Advanced

8: Music Apps

1: Go to
2: Go
3: Reload
4: Desktop View
5: Page Size
6: Go to Homepage
7: Add to Favorites
8: View Favorites
9: Send URL
10: Enter URL
11: Copy URL via Message
12: Save
13: Saved Pages

37

14: History

15: Advanced

2: Messaging

1: Create New Message

1: Add Recipients

2: Add Attachment

3: Back
2: Inbox

1: View

2: Reply

3: Forward

4: Call Back

5: Delete

6: Move to Phone

7: Sort by

8: Add to Address Book
3: Mobile Email

1: Yahoo! Mail

2: AOL

3: AIM

4: Windows Live Mail

5: AT&T Yahoo!

6: BellSouth

7: Other Providers
4: IM

1: AIM

2: Windows Live

3: Yahoo!
5: Sent

1: View

2: Forward

3: Delete

4: Move to SIM

5: Move to My Folder

6: Sort by
6: Outbox

1: Edit

2: Send Again

3: Delete

Menu Navigation 38

4: Sort by

7: Drafts

1: Edit
2: Send
3: Delete
4: Move to My Folder
5: Sort by

8: My Folder

1: My Folder 1
2: My Folder 2
3: My Folder 3

9: Templates

1: Text Templ ates
2: Multimedia Message Templates

10: Delete All

1: All
2: Inbox
3: Sent
4: Outbox
5: Drafts
6: My Folder

11: Messaging Settings

1: Text Message
2: Multimedia Message
3: Voice Mail
4: Push Message

12: Memory Status

3: Recent Calls

1: All Calls

1: Details
2: Call Back
3: Video Share ***
4: Save to Address Book
5: Send Message
6: Delete
7: Add to Reject List

2: Missed Calls

1: Details
2: Call Back

39

3: Video Share***

4: Save to Address Book

5: Send Message

6: Delete

7: Add to Reject List
3: Calls Made

1: Details

2: Call Back

3: Video Share***

4: Save to Address Book

5: Send Message

6: Delete

7: Add to Reject List
4: Calls Received

1: Details

2: Call Back

3: Video Share***

4: Save to Address Book

5: Send Message

6: Delete

7: Add to Reject List
5: Voice Mail

1: Connect to Voice Mail

2: Voice Server Number
6: Speed Dial

1: Add

2: View

3: Change

4: Remove

5: Voice Call
7: Delete All

1: All Calls

2: Missed Calls

3: Calls Made

4: Calls Received
8: Call Time

1: Last Call Time

2: Total Sent

3: Total Received

Menu Navigation 40

9: Data Volume

1: Last Sent Data
2: Last Received Data
3: Total Sent Data
4: Total Received Data

10: Data Call Time

1: Last Data Call
2: Total Data Call

4: MEdia Net

1: MEdia Net

1: Go

1: Forward

2: Backward
2: Reload
3: Desktop View
4: Page Size

1: Large

2: Normal

3: Small
5: Go to Homepage
6: Add to Favorites
7: View Favorites
8: Send URL
9: Enter URL
10: Copy URL via Message
11: Save
12: Saved Pages
13: History
14: Advanced

2: Enter URL
3: Favorites

1: Cellular Video
2: Chat
3: News
4: Sports
5: Weather
6: MEdia Net

4: Saved Pages
5: History

41

1: Go to

2: Delete

3: Details
6: Advanced

1: Clear Cache

2: Empty Cookies

3: Cookie Options

4: Preferences

5: About Browser
7: Browser Settings

1: MEdia Net wap1.x

2: MEdia Net wap2.x

3: AT&T MMS

4: AT&T IMS

5: AT&T Mall

1: Shop Tones
2: Shop Games
3: Shop Graphics
4: Shop Multimedia
5: Shop Applications
6: MEdia Net Home

6: Cellular Video

1: Go to
2: Go

1: Forward

2: Backward
3: Reload
4: Desktop View
5: Page Size

1: Large

2: Normal

3: Small
6: Go to Homepage
7: Add to Favorites
8: View Favorites
9: Send URL

1: via Message

2: via Bluetooth
10: Enter URL

Menu Navigation 42

11: Copy URL via Message
12: Save

1: Image
2: Web page

13: Saved Pages
14: History
15: Advanced

1: Clear Cache
2: Empty Cookies
3: Cookie Options
4: Preferences
5: Certificates
6: Page Details
7: Browser Settings
8: About Browser

7: My Stuff

1: Audio

1: Open
2: Record Audio
3: Create Folder
4: Copy Folder
5: Sort by
6: Bluetooth Visibility
7: Memory Card Settings**
8: Properties

2: Graphics

1: Open
2: Take Photo
3: Create Folder
4: Copy Folder
5: Sort by
6: Bluetooth Visibility
7: Memory Card Settings**
8: Properties

3: Video

1: Open
2: Record Video
3: Create Folder
4: Copy Folder

43

5: Sort by

6: Bluetooth Visibility

7: Memory Card Settings**

8: Properties
4: Music

1: Open

2: Create Folder

3: Copy Folder

4: Sort by

5: Bluetooth Visibility

6: Memory Card Settings**

7: Properties
5: Games and Apps

1: Open

2: Create Folder

3: Sort by

4: Memory Card Settings**

5: Properties
6: Applications

1: Open

2: Create Folder

3: Sort by
7: Other Files

1: Open

2: Create Folder

3: Copy Folder

4: Sort by

5: Bluetooth Visibility

6: Memory Card Settings**

7: Properties
8: Memory Status

1: Open

2: Create Folder

3: Sort by

8: Address Book

1: View
2: Add New Contact

1: Phone

2: SIM

Menu Navigation 44

3: Voice Call
4: Video Share***
5: Send Message
6: Edit
7: Duplicate
8: Delete

1: Selected
2: Multiple

9: Save to My Stuff
10: Send Business Card

1: As Message
2: via Bluetooth

11: My Business Card

1: Input method
2: Input language
3: Add More Fields

12: Assign Speed Dial
13: Copy to SIM

1: Selected
2: Multiple

14: Move to SIM

1: Selected
2: Multiple

15: Service Number
16: FDN Contacts

1: Create FDN Contact

17: Copy to FDN Contacts
18: Print via Bluetooth
19: Address Book Settings

1: Speed Dial
2: Save New Contacts to Always Ask
3: View Contacts from
4: Own Number

20: Memory Status

9: Settings

1: Profiles

1: Normal
2: Silent
3: Driving

45

4: Meeting

5: Outdoor

6: Airplane
2: Display Settings

1: Display Settings

2: Light Settings
3: Time & Date

1: Time zone updating

2: Home Zone

3: Time

4: Date

5: Time Format

6: Date Format
4: Phone Settings

1: Language

2: Shortcuts

3: Own Number
5: Call Settings

1: All Calls

2: Voice Call

3: Data Call
6: Connectivity

1: Bluetooth

2: Connections

3: Select USB Mode

4: IMS Settings
7: Software Update
8: Application Settings

1: Messaging Settings

2: Browser Settings

3: Camera Settings

4: Camcorder Settings

5: Player Settings

6: Cellular Video Settings

7: Record Audio Settings

8: Calendar Settings

9: Address Book Settings

10: Video Share Settings***
9: Security

Menu Navigation 46

1: Phone Lock
2: SIM Lock
3: PIN Check
4: Lock Applications
5: FDN Mode
6: Change Phone Password
7: Change PIN Code
8: Change PIN2 Code

10: Reset Settings

1: All
2: Phone Settings
3: Display Settings
4: Profiles
5: Alarms

11: Memory Settings

1: Clear Memory
2: Memory Status

12: Phone Information

1: My Number
2: Manufacturer
3: Model
4: Device ID
5: Hardware Version
6: Software Version
7: Language
8: Client Version

* Shows only if supported by your SIM card.
** Shows when a memory card is inserted.
*** Shows only if you have Video Share service.

47

Changing the Text Input Method

Section 5: Entering Text

Topics Covered

• Changing the Text Input Method

• Using the T9 Input Method

• Using the Alphabet Input Method

• Using the Symbols Input Method

• Using the Numeric Input Method

This section outlines how to select the desired text input mode when entering
characters into your phone. This section also describes how to use the T9 predictive
text entry system to reduce the amount of key strokes associated with entering text.

Changing the Text Input Method

The Tex t Inp u t option switches the key entry functions from an T9 Alphabet,
ABC (Alphabet), Numeric Mode, and Symbols Mode.

T9 Input Method (T9 abc, T9 Abc, and T9 ABC)

This input method allows you to enter words with only one keystroke per letter. Each
key on the keypad has more than one letter; for example, pressing the 5 key can
enter J, K, or L. However, the T9 method automatically compares the series of
keystrokes you make with an internal linguistic dictionary to determine the most
likely word, thus requiring far fewer keystrokes than the traditional Alphabet mode.
The T9 abc method makes all characters lowercase. The T9 Abc method makes the
initial character an uppercase while the remaining characters are left as lowercase.
The T9 ABC method all characters uppercase.

ABC (Alphabet) Input Method (abc and ABC)

This input method allows you to enter letters by pressing the key labeled with the
letter you want. Press the key once, twice, three, or four times until it displays.
The abc method makes all characters of the word lowercase. The ABC method
makes all characters of the word uppercase.

Entering Text 48

Numeric

This mode allows you to enter numbers.

Symbols

This mode allows you to enter symbols, such as punctuation marks.

Add word

This mode allows you to add new words to the phone’s current dictionary.
When you are in a field that allows characters to be entered (such as in a
text message), you will notice the text input mode indicator on the display.

1. To change the text input mode, press the key.

2. Highlight Input Method and press the key. The default mode is Abc.

3. Choose from the following options:

ABC: abc (all lowercase), Abc (initial capitalization) and ABC (all

uppercase).
T9: T9 abc (completed words are all lowercase), T9 Abc (completed words

are initial uppercase) and T9 ABC (completed words are all uppercase).
Numeric: configures the keypad to be used only to enter numbers into a

text message.
Symbols: provides an on screen table which allows you to select from the

list of available symbols associated to each keypad.

Note: Press and hold the key to access Symbol mode. Press the number key corresponding to the

symbol you want to enter. Use the Up and Down Navigation keys to scroll th rough the available
symbols. Press the Cancel soft key to exit.

Using the T9 Input Method

T9 Predictive Text input method is based on a built-in dictionary.

Enter a Word in T9 Mode

1. In T9 method, begin entering a word by pressing the 2 to 9 keys. Press

each key only once for each letter. The built-in dictionary lists words that
match the keystrokes you have entered.

2. Example: To enter “Hello”, press

, , , ,

The word that you are typing appears in the display. It may change with
each key that you press.

49

Using the Alphabet Input Method

3. Enter the whole word before editing or deleting the keystrokes.

4. When the word displays correctly, go to step 5.

If the word doesn’t display correctly, press the key to display
alternative word choices for the keys that you have pressed.

Example: Both “Of” and “Me” have the and keys. The phone displays the most commonly used

choice first.

5. Insert a space by pressing the key and start entering the next word.

Add a New Word into the T9 Dictionary

1. After pressing the keys corresponding to the word you want to add, press

the key to display the alternative words.

2. When the last alternative word is displayed, Spell displays. Press the Spell

soft key.

3. Enter the word you want to add using the ABC mode.

4. Press the Add soft key or the key.

The word is added to the T9 dictionary and becomes the first word for the
associated keypress series.

Note: This feature may not be available for some languages.

• To enter periods, hyphens, colons, or parenthesis, press and hold the key.

T9 mode applies grammar rules to ensure that correct punctuation is used.

• To shift case in T9 mode, use the key. There are 4 cases: Initial capital, Capital

lock, Lower case, and Numeric.

• You can move the cursor by using the Left and Right keys. To delete letters, press

the key. Press and hold the key to clear the display.

Using the Alphabet Input Method

To use the ABC Alphabet input method use the to keys to enter your text.

1. Press the key labeled with the letter you want:

• Once for the first letter

• Twice for the second letter

• And so on

2. Select the other letters in the same way.

Entering Text 50

Note: The cursor moves to the right when you press a different key. When entering the same letter twice or

a different letter on the same key, just wait for a few seconds for the cursor to move to the right
automatically, and then select the next letter.

Keys

Using the Symbols Input Method

The Symbol input method enables you to insert symbols and punctuation marks into
text.

1. To enter symbol mode press and hold the key.

2. Use the Navigation keys to select an on screen symbol group.

3. To select a symbol from that group, press the corresponding number key.

4. To clear the symbol(s), press the key. When the input field is empty,

this key returns the display to the previous mode.

5. To return to your message, press the OK soft key or the key.

51

Using the Numeric Input Method

Using the Numeric Input Method

The Numeric mode enables you to enter numbers into a text message. Press the
keys corresponding to the digits you want to enter.

Entering Text 52

Section 6: Understanding Your Address Book

Topics Covered

• Using Contacts List

• Address Book Entry Options

• Adding a New Contact

• Dialing a Number from the SIM Card using the Location Number

• Speed Dial

• Finding My Own Phone Number

•FDN Mode

• Group Settings

• Managing Address Book Entries

This section allows you to manage your daily contacts by storing their name and
number in your Address Book. Address Book entries can be sorted by name, entry, or
group.

Note: When storing an Address Book entry into your SIM card, note that only the Name, Address, and slot

location are saved. To save additional information for a particular contact, such as notes, e-mail,
dates, etc.., it is important to save that Contact into your phone’s onboard memory.

Using Contacts List

Dialing a Number from Address Book

Once you have stored phone numbers in the Address Book, you can dial them easily
and quickly by either using their SIM card location number or by using the Search
field to locate the entry.

Note: The default Address Book entries are: Check Bill Balance - *225#, Directory Assistance - 411,

Music ID - #43, Pay My Bill - *729, View My Minutes - *646#, Voice Connect - *08, *Now - *669.

53

Address Book Entry Options

Finding an Address Book Entr y

You can store phone numbers and their corresponding names onto your SIM card
and phone’s onboard memory. They are physically separate but are used as a single
entity, called the Address Book.

Depending on your particular SIM card, the maximum number of phone numbers the
SIM card can store may differ.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, and press the Select soft key or the key.

3. Enter the first few letters of the name.

The Address Book entries are then listed, starting with the first entry
matching your input.

4. To select a different entry, press the Up or Down Navigation key until the

entry you want is highlighted.

5. Once you have found the entry, press the key to dial the number, or

press the Options soft key to access the Address Book entry options.

Address Book Entry Options

While accessing any Address Book entry, press the Options soft key to use the
options for the entry.

The following options are available:

• View: provides you with details about that contact entry. Press the Back soft key to

return to the Address Book listing.

• Add New Contact: allows you to add a new entry to either your Phone or SIM card.

• Voice Call: allows you to call a currently selected entry.

• Video Share: innitiates a Video Share Call with this contact.

• Send Message: allows you to send a text message or a multimedia message to

the selected entry.

• Edit: allows you to edit the properties of an entry such as: Name, Category, Group,

or location. Press the key to save your changes.

• Duplicate: allows you to duplicate a selected entry. Press the key to save your

duplicate entry.

• Delete: allows you to delete either a selected address book entry or multiple

entries from a target location such as the Phone and/or SIM card.

• Save to My Stuff: allows you to copy the contact information from its current

location to your My Stuff folder.

Understanding Your Address Book 54

•

Send Business Card: allows you to send a message to the selected entry which
contains the information from their Address Book entry which you have on file.
This can be sent as either a message or via Bluetooth.

• My Business Card: allows you to send a name card message to the selected

entry. This name card contains your name cards with your number and profile.

• Assign Speed Dial: allows you to set the speed dial key for this entry.

• Copy to Phone/SIM: allows you to copy the contact information from the SIM to

the phone or from your phone to your SIM.

• Move to Phone/SIM: allows you to move the contact information from the SIM to

the phone or from your phone to your SIM.

• Service Number: allows you to search through your address book listings of saved

service numbers.

• FDN Contacts: Fixed Dialling Number mode restricts your outgoing calls to a

limited set of phone numbers. When this feature is enabled, you can make calls
only to phone numbers stored on the SIM FDN list.

• Copy to FDN Contacts: allows you to copy the list of restricted phone numbers

from your phone to the FDN section of the SIM card.

• Print via Bluetooth: allows you send the selected contact entry information to a

Bluetooth compatible printer.

• Address Book Settings: allows you to access the address book settings menu list.

• Memory Status: allows you to view the amount of memory allocation for the

following categories: Phone, USIM, Additional No.1 (SIM card), Additional No.2,
Email, and FDN.

Adding a New Contact

Use the following procedures to store a new contact to your Phone or SIM Card.

Storing a Number in the Phone’s Memor y

1. When the Idle screen displays, enter the phone number.

2. Press the Options soft key.

3. Scroll to Save to Address Book by pressing the Up or Down key and

press the Select soft key or the key.

4. Choose the target location for the entry (Phone or SIM), press the Select

soft key or the key.

5. Press the Select soft key or the key to assign this number as a New

entry.

6. From the Select Type screen, select from the following category types:

55

Adding a New Contact

• Mobile - Private: assigns the number entered as a Private Mobile entry.

• Mobile - Business: assigns the number entered as a Business Mobile entry.

•Landline - Private: assigns the number entered as a Private Landline entry.

• Landline - Business: assigns the number entered as a Business Landline

entry.

•FAX: assigns the number entered as a Fax entry.

•Etc.: allows you to classify the entry as a miscellaneous type.

7. Enter alphanumeric characters into each of the available fields:

• First Name: allows you enter a first name for this entry.

•Last Name: allows you enter a Last name for this entry.

• Display Name: allows you enter a display name for this entry which then

appears when you receive a call from this contact.

• Phone Number: allows you keep or alter the currently entered phone number.

• Number Type: allows you to enter an additional landline-private number to this

entry.

• Contact E-mail: allows you to enter a contact E-mail address for this entry.

•Group: allows you to assign this contact to group. Press the Options soft key to

display available groups. Use the Up or Down Navigation keys to select a group.
Press the Select soft key or the key to save your selection.

• Caller ID: allows you to set a graphic to the Caller ID for this contact. Press the
Options soft key or the key to access the My Stuff menu.

• Ringtone: allows you to choose a ringtone for this contact information. Press the
Options soft key or the key to access the My Stuff menu.

• Instant Messaging: allows you to assign an Instant Message profile to this

entry. Press the key to access the IM menu.

• Note: allows you enter notes associated with this contact.

8. Press the Options soft key or the key to save the information for this

entry.

Understanding Your Address Book 56

Storing a Number in the SIM Card

Note: When storing an Address Book entry into your SIM card, note that only the Name, Address, and slot

location are saved. To save additional information for a particular contact, such as notes, e-mail,
dates, etc.., it is important to save that Contact into your phone’s onboard memory.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, and press the Select soft key or the key.

3. Select the Address Book entry you wish to add and press the Options soft

key.

4. Scroll to Add New Contact by pressing the Up or Down key and press the

Select soft key or the key.

5. Select SIM and press the Select soft key or the key.

6. Enter the following information for the New Contact.

•Name: allows you to enter a name for the number entered.

• Phone Number: assigns the number entered to the Mobile entry.

• Location: allows you to assign a location number on your SIM for the number

being entered.

7. Press the key to save your new entry and return to a screen which then

lists the details of your new entry onto the SIM.

8. To view available options for this entry, press the Options soft key:

•Edit: allows you to edit the properties of an entry such as: Name, Number, or

Location. Press the key to save your changes.

• Voice Call: allows you to call a currently selected entry.

• Video Share: innitiates a Video Share Call with this contact.

• Send Message: allows you to send a text message or a multimedia message to

the selected entry.

• Duplicate: allows you to duplicate a selected entry. Press the key to save

your duplicate entry.

• Delete: allows you to delete the currently selected address book entry from a

target location.

• Save to My Stuff: allows you to copy the contact information from its current

location to your My Stuff folder.

• Send Business Card: allows you to send a message to the selected entry

which contains the information from their Address Book entry which you have on
file. This can be sent as either a message or via Bluetooth.

• Copy to Phone: allows you to copy the contact information from the SIM to the

phone or from your phone to your SIM.

57

Dialing a Number from the SIM Card using the Location Number

• Move to Phone: allows you to move the contact information from the SIM to the
phone or from your phone to your SIM.

• Copy to FDN Contacts: allows you to copy the restricted phone number list to
the FDN section of the SIM card.

• Print via Bluetooth: allows you send the selected contact entry information to a
Bluetooth compatible printer.

9. To return to the Idle screen, press the key.

Dialing a Number from the SIM Card using the Location
Number

1. In Idle mode, enter the location number for the phone number you want to

dial and press the key.

The contact entry information is displayed.

2. Press the Up or Down Navigation key to find other numbers on the list.

3. Press the Call soft key, the key, or the key when you have

selected the number you want to call.

Speed Dial

Once you have stored phone numbers from your Address book list, you can set up to
8-speed dial entries and then dial them easily whenever you want, simply by
pressing the associated numeric key.

In Idle mode, to speed dial the numbers assigned to keys (2 to 9), press and hold the
appropriate key.

Setting Up Speed Dial Entries

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Highlight Speed Dial by pressing the Up or Down Navigation key, and

press the Select soft key or the key.

3. Select the key in which you wish to assign the speed-dialing number (from

the 2 to 9 keys), and press the Options soft key or the key.

Note: Memory location 1 is reserved for your Voice mail server number.

4. Highlight Add and press the Select soft key or the key. You can choose

to assign a number from your Address Book or FDN contacts.

5. Highlight Address Book and press the Select soft key or the key.

Understanding Your Address Book 58

• Select the Address Book entry you would like to add by pressing the Up or
Down key and press the Select soft key or the key to save the entry.

6. Highlight FDN Contacts and press the Select soft key or the key.

• Select the FDN entry you would like to add by pressing the Up or Down key and
press the Select soft key or the key to save the entry.

Changing a Number Assigned to a Key

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Highlight Speed Dial by pressing the Up or Down Navigation key, and

press the Select soft key or the key.

3. Select the key you wish to change and press the Options soft key.

4. Press Change, select the location of the new entry (Address Book or FDN

Contacts), and press the Select soft key or the key.

5. Use either steps 5 or 6 from the previous section to add the Address Book

or FDN Contacts entry.

6. Once you’ve selected your entry (by name or number), press the Select

soft key or the key to confirm the change.

7. After the “Change Speed Dial?” screen appears, press the Yes soft key to

save the new speed dial entry and overwrite the previous information.

8. When you are finished, press the key to return to Idle mode.

Deleting Speed Dial Entries

1. From the Idle Screen, press Menu. Use the navigation keys to highlight

Recent Calls and press Select.

2. Highlight Speed Dial by pressing the Up or Down Navigation key, and

press the Select soft key or the key.

3. Select the key you wish to clear and press the Options soft key.

4. Select Remove and press the Ye s soft key to confirm your deletion.

5. When you are finished, press the key to return to Idle mode.

59

Finding My Own Phone Number

Finding My Own Phone Number

This function is a memory aid, which you can use to check your own phone number
if you need to do so.

You can assign a name to each of your own phone numbers registered on your SIM
card. You can also edit the names and numbers. Any changes made here do not in
any way affect the actual subscriber numbers on your SIM card.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Settings, press the Select soft key or the key.

3. Select Phone Information by pressing the Up or Down key and press the

Select soft key or the key.

FDN Mode

FDN (Fixed Dialing Number) mode, if supported by your SIM card, restricts your
outgoing calls to a limited set of phone numbers. When this feature is enabled, you
can make calls only to phone numbers stored in the FDN list on the SIM card.

The following options are available:

• Disable: you can call any number.

• Enable: you can only call the phone numbers stored in the SIM FDN list.

You must enter your PIN2 password.

Group Settings

Editing a Caller Group

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, press the Select soft key or the key.

3. Scroll to Groups by pressing the Right Navigation key.

4. Scroll through the list of groups by pressing the Up or Down Navigation

key.

5. Highlight the target group entry and press the Options soft key.

6. Highlight Group Settings, press the Select soft key or the key.

The following options are then available:

• Picture: allows you to view the assigned group image.

• Ringtone: allows you to set the ringtone associated with this group. Choose

from the Default Ringtones or from the Downloaded Ringtones.

Understanding Your Address Book 60

7.

Once you’ve made your changes, press the Options soft key, select Save
and press the Select soft key or the key.

8. When you are finished, press the key to return to Idle mode.

Managing Address Book Entries

You can copy, delete, and view the memory status for the Phone and SIM entries on
your phone.

Copying an Entry to the Phone

You can copy a SIM entry to the Phone by using the Duplicate option. When you copy
entries to the phone, duplicate entries are created.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, press the Select soft key or the key.

3. Select an entry which currently resides on the phone.

• If the entry’s associated Group graphic has a SIM location icon on it, then the

entry already exists on the SIM card. This is the type you can duplicate.

• If the entry’s associated Group image does not have a SIM location icon, then
this entry currently also exists on the phone.

4. Press the Options soft key, highlight Copy to Phone, and press the Select

soft key or the key.

5. When you are finished, press the key to return to Idle mode.

Note: Options are available for phone entries tha t are not available when stored to the SIM card. For details

see "Storing a Number in the Phone’s Memory" on page 55.

Deleting All of the Address Book Entries

You can delete All, Phone, SIM, and SIM (FDN) entries from your phone’s memory.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, press the Select soft key or the key.

3. Press the Options soft key, highlight Delete, and press the Select soft key

or the key.

4. Highlight Multiple, press the Select soft key or the key.

5. Choose the location of the Address Book entries you wish to delete (Phone,

SIM, or Phone & SIM), press the Select soft key or the key.

6. Highlight All and press the key.

You can remove the check mark by pressing the key again. Selecting
All places a checkmark adjacent to every entry in the list.

61

Managing Address Book Entries

7. Press the Delete soft key to delete the entries from the selected memory

location.

8. At the Delete? confirm screen, press the Yes soft key to continue, or the

No soft key to cancel.

9. Enter the password and press the Confirm soft key or the key.

10. When you are finished, press the key to return to Idle mode.

Checking the Memory Status

You can check how many names and numbers are stored in the Address book, in
both SIM card and the phone memory. You can also see the capacity of both
memories.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, press the Select soft key or the key.

3. Press the Options soft key.

4. Select Memory Status by pressing the Up or Down Navigation key and

press the Select soft key or the key.

5. When you are finished viewing your phone’s Memory Status, press the

key to return to Idle mode.

Using the Service Dialing Numbers

You can view the list of Service Dialing Numbers (SDN) assigned by your service
provider. These numbers include emergency numbers, customer service numbers
and directory inquiries.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Address Book, press the Select soft key or the key.

3. Press the Options soft key.

4. Select Service Number, by pressing the Up or Down Navigation key and

press the Select soft key or the key.

5. Scroll through the numbers by using the Up or Down Navigation key.

6. To dial the number displayed, press the key.

Note: This menu is available only when your SIM card supports Se rvice Dialing Numbers.

Understanding Your Address Book 62

Section 7: Messaging

Topics Covered

• Types of Messages

• Creating and Sending New Messages

• Text Messages

• Using Message Options

• Using Instant Messenger (IM)

• Signing into your IM Account

• Signing into your Mobile Email

• Using Message Templates

• Deleting Messages

• Messaging Settings

• Memory Status

This section describes how to send or receive different types of messages. It also
includes the features and functionality associated with messaging.

Types of Messages

Your phone provides the following message types:

• IM Messages

• Text Messages

• Multimedia Messages

Creating and Sending New Messages

Text Messages

The Short Message Service (SMS) allows you to send and receive short text
messages to and from other mobile phones. To use this feature, you must subscribe
to your service provider’s message service.

The Message icon ( ) displays when you have received new text messages. When
the memory is full, an error message displays and you cannot receive any new
messages. Use the Delete option in each message box to delete obsolete messages.

63

Text Messages

1. When the Idle screen displays, press the Menu soft key.

2. Select Messaging and press the Select soft key or the key.

3. Using the Up or Down Navigation key, highlight Create New Message and

press the Select soft key or the key.

4. Enter either a phone number or contact name (from your Address Book) by

pressing the key to access both a list of recent calls and your Address
Book Contacts and Groups.

• Recent Log: allows you to choose from a brief list of recently dialed phone

numbers. Press the key to add a selected number to your message’s
recipients list field. This entry can later be appended prior to sending the
message.

•Contacts: allows you to insert additional recipients from your Address Book by

using your Up and Down Navigation keys to select those entries you wish to add.

- Press the key to place a checkmark next to those entries.

- Once you have selected the desired entries, press the Add softkey to return to

the message.

•Group: allows you to insert additional Group members from your Address Book

by using your Up and Down Navigation keys to select those entries you wish to
add.

• FDN Contacts: allows you to insert numbers assigned to your Fixed Dial

Network (FDN) group.

5. Use the Down Navigation key to access the text field and begin creating

your text message.

6. When you have finished writing your message, press the Options soft key.

Choose from the following options:

•Send: allows you to send the message.

• Text: allows you to set the Text Selection on or off, Cut previously entered
text, Copy text, or Remove text before sending.

• Add Item: allows you to add an image, sound or video clip to your message.

• Create Item: allows you to temporarily exit from the current text message and

create either a new photo, video clip, or audio clip for your current text message.

- Take Photo: allows you to temporarily exit the message, take a photo with

phone’s camera, and then add it to your message.

- Record Audio: allows you to temporarily exit the message, record an audio clip

using the phone’s microphone, and then add it to your message.

- Record Video: allows you to temporarily exit the message, record a video clip

using the phone’s camera, and then add it to your message.

Messaging 64

•Insert: allows you to insert a predefined Text template, Text emoticon, Business

card, or favorite web address into the message.

- Text Template: allows you to insert one of the preset message templates to the

text, such as (Out of Office, I’m in a meeting..).

- Text Emoticon: allows you to add an a emotion (created by phone characters) to

your message. An example would be: which creates a :-) “happy face”.

- Business Card: allows you to add the contact information for an entry from

Address Book directly to your message.

- Favorite s: allows you to add a web address from your Favorites list of Internet

sites to the message.

• Add Recipients: allows you to update the recipient list by appending it with

information form either your Recent Log, Contacts, or Group FDN Contacts
entries.

• Change to Multimedia Message: allows you to convert the current message

to/from either a text or multimedia message prior to being sent.

Note: A multimedia message should only be sent to a phone which can support the receipt and disp lay of

this message type.

• Input Language: allows you to temporarily change the input language used to

create your message.

• Input Method: allows you to change the method used to input data into your

message, such as text, numbers, and symbols. For more information, refer to
"Entering Text" on page 48.

• Add Attachment: allows you to add either a file, card, or other information such

as a calendar entry, task, or note.

- File: allows you to insert an audio, graphic, or video clip to your message as an

attached file.

- Business Card: allows you to insert the contact information for an entry from

Address Book directly to your message as an attached file.

- Appointment: allows you to insert an Appointment entry from your calendar

directly to your message as an attached file.

- Anniversary: allows you to insert an Anniversary entry from your calendar

directly to your message as an attached file.

- Private: allows you to insert a Private entry from your calendar directly to your

message as an attached file.

- Holiday: allows you to insert a Holiday entry from your calendar directly to your

message as an attached file.

- Important: allows you to insert an entry from your calendar tagged as Important

directly to your message as an attached file.

- Tas k: allows you to insert an entry from your calendar tagged as a Task directly

to your message as an attached file.

65

Text Messages

- Note: allows you to insert a presaved Note (text) directly to your message as an

attached file.

- Favorites: allows you to add a web address from your Favorites list of Internet

sites as an attachment to the message.

•Back: allows you to return to the active message.

7. Press the Send To soft key, confirm the recipient(s). You can add additional

recipients from you Address Book by selecting one of the Empty fields and
pressing the key.

• Add the additional recipients from your Address Book by then using your Up and
Down Navigation keys to select those entries you wish to add.

• Press the key to place a checkmark next to those entries.

• Once you have selected the desired entries, press the Add softkey to return to

the previous list of Recipients.

8. Send the message to the selected recipients by either pressing the Send

soft key or the key.

Multimedia

The Multimedia Message icon ( ) displays when you have received new
multimedia messages. When the memory is full, an error message displays and you
cannot receive any new messages. Use the Delete option in each message box to
delete obsolete messages.

1. When the Idle screen displays, press the Menu soft key.

2. Select Messaging and press the Select soft key or the key.

3. Using the Up or Down Navigation key, highlight Create New Message and

press the Select soft key or the key.

4. Enter either a phone number or contact a contact name (from your Address

Book) by pressing the key to access both a list of recent calls and your
Address Book Contacts and Groups.

• Recent Log: allows you to choose from a brief list of recently dialed phone
numbers. Press the key to add a selected number to your message’s
recipients list field. This entry can later be appended prior to sending the
message.

•Contacts: allows you to insert additional recipients from your Address Book by
using your Up and Down Navigation keys to select those entries you wish to add.

- Press the key to place a checkmark next to those entries.

- Once you have selected the desired entries, press the Add softkey to return to

the message.

Messaging 66

•Groups: allows you to insert additional Group members from your Address Book

by using your Up and Down Navigation keys to select those entries you wish to
add.

• FDN Contacts: allows you to enter a contact from the FDN Contact list.

5. Use the Down Navigation key to access the text field and begin creating

your message.

6. Press the Options soft key, highlight the Change to Multimedia Message

and press the Select soft key or the key.

Note: A multimedia message should only be sent to a phone which can support the receipt and disp lay of

this message type.

7. Add an Image, Sound, or Video clip directly into your message by pressing

the Options soft key and selecting from one of the following options:

•Send: allows you to send the message.

•Preview: allows you to preview your message prior to being sent.

•Text: allows you to enter, cut, copy, and remove text from your message prior to

being sent.

• Add Item: allows you to add an image, sound or video clip to your message.

•Create Item: allows you to temporarily exit from the current text message and

create either a new photo, video clip, or audio clip for your current text message.

- Take P hot o: allows you to temporarily exit the message, take a photo with

phone’s camera, and then add it to your message.

- Record Audio: allows you to temporarily exit the message, record an audio clip

using the phone’s microphone, and then add it to your message.

- Record Video: allows you to temporarily exit the message, record a video clip

using the phone’s camera, and then add it to your message.

•Insert: allows you to insert a predefined Text template, Text emoticon, Business

card, or favorite web address into the message.

- Text Template: allows you to insert one of the preset message templates to the

text, such as (Out of Office, I’m in a meeting..).

- Text Emoticon: allows you to add an a emotion (created by phone characters) to

your message. An example would be: which creates a :-) “happy face”.

- Business Card: allows you to add the contact information for an entry from

Address Book directly to your message.

- Favorite s: allows you to add a web address from your Favorites list of Internet

sites to the message.

• Add Recipients: allows you to update the recipient list by appending it with

information form either your Recent Call Log, Contacts, Group entries , or FDN
Contacts .

67

Text Messages

• Change to Text Message: allows you to convert the multimedia message back
to a text-based message which can contain multimedia files as attachment and
not as part of the main body of the message.

• Add Page: allows you to add a text page to your multimedia message.

• Input Language: allows you to change the language used for the message text.

• Input Method: allows you to change the method used to input data into your

message, such as text, numbers, and symbols. For more information, refer to
"Entering Text" on page 48.

•Edit Style: allows you to edit the style of your outgoing message with option
such as: Select page, Background Color, Page Duration (for embedded media),
Font Color, and Font Style.

• Add Subject: allows you to add a subject header to your multimedia message.

• Add Attachment: allows you to add either a file, card, or other information such

as a calendar entry, task, or note.

- File: allows you to insert an audio, graphic, or video clip to your message as an

attached file.

- Business Card: allows you to insert the contact information for an entry from

Address Book directly to your message as an attached file.

- Appointment: allows you to insert an Appointment entry from your calendar

directly to your message as an attached file.

- Anniversary: allows you to insert an Anniversary entry from your calendar

directly to your message as an attached file.

- Private: allows you to insert a Private entry from your calendar directly to your

message as an attached file.

- Holiday: allows you to insert a Holiday entry from your calendar directly to your

message as an attached file.

- Important: allows you to insert an entry from your calendar tagged as Important

directly to your message as an attached file.

- Tas k: allows you to insert a Task directly to your message as an attached file.

- Note: allows you to insert a presaved Note (text) directly to your message as an

attached file.

- Favorites: allows you to add a web address from your Favorites list of Internet

sites as an attachment to the message.

• Sending Options: allows you to configure the options associated with sending
the message.

• Save to Drafts: saves the current message to the Drafts folder.

• Save as Template: allows you to save the current text message or multimedia

message to the current list of preset message templates, such as (Out of Office,
I’m in a meeting..).

•Back: allows you to return to the active message.

Messaging 68

8.

Press the Send To soft key, confirm the recipient(s). You can add additional
recipients from you Address Book by selecting one of the Empty fields and
pressing the key.

• Add the additional recipients from your Address Book by then using your Up and
Down Navigation keys to select those entries you wish to add.

• Press the key to place a checkmark next to those entries.

• Once you have selected the desired entries, press the Add softkey to return to

the previous list of Recipients.

9. Send the message to the selected recipients by either pressing the Send

soft key or the key.

Locating a Message

1. In Idle mode, press the Menu soft key and highlight Messaging. Press the

Select soft key or the key.

2. Highlight Inbox and press the Select soft key. The message list opens.

The following icons indicate the message type.

• : indicates a new Voice message (This is an icon not identifiable in the
Inbox but rather under "Idle Pop up" or the Icons in the Icon area.)

• : indicates a new Text message

• : indicates a new Multimedia message

• : indicates a new E-mail message (This is an icon not identifiable in the

Inbox but rather under "Idle Pop up" or the Icons in the Icon area.)

Retrieving a Text Message

When a new Text message comes in, the display (in Idle mode) shows a new
Message notification icon ( ) along with the available sender’s information.

1. Press the View soft key to launch the Inbox list of message.

2. Use the Up or Down Navigation keys to select the message.

3. Press the key to open the message.

4. When you have finished, press the key.

Retrieving an Multimedia Message

When a new Multimedia message comes in, the display shows the Multimedia
Message icon ( ) and a text notification along with the sender’s number.

1. Use the Up or Down Navigation keys to select a message from the list.

69

Using Message Options

2. Press the Options soft key, highlight Properties, and press the Select

soft key or the key to view brief information about the message, such
as the sender’s number, the message size, and the subject.
If you want to view the message later in the Inbox, press the Back soft key.

3. To view the message, highlight View, and press the Select soft key or the

key.

4. To play the multimedia message, press the key.

• To pause the audio/video clip, press the key.

• To stop the audio/video clip press the Stop soft key.

5. To scroll through the message (if additional text page have been added),

press the Up or Down key.

6. When you have finished, press the key.

Note: Messages can also be accessed by navigating to your In box (Menu > Messaging).

Using Message Options

While viewing the content of a message, press the Options soft key to access the
following message options:

Options for SMS Messages

• Reply: allows you to reply to the message via Text message.

• Forward: allows you to forward the message.

• Call Back: allows you to dial the originating message number.

• Delete: deletes the message.

• Move to Phone/Move to SIM: If a message is stored in the SIM card, it is saved to

the phone’s memory. If a message is stored in the phone’s memory it is then saved
to the SIM card.

• Add to Address Book: allows you to save the recipient or sender’s information

from the message to your Address Book on either the Phone or SIM.

Note: When storing an Address Book entry into your SIM card, note that onl y the Name, Address, and slot

location are saved. To save additional information for a particular contact, such as notes, e-mail,
dates, etc.., it is important to save that Contact into your phone’s onboard memory.

• Print via Bluetooth: allows you to print the content of the text message wirelessly

to a target Bluetooth-compatible printer.

Messaging 70

Options for Multimedia Messages

• View/Play: allows you to view or play the multimedia message.

• Reply: allows you to reply to the message.

• Reply to All: allows you to reply to the all recipients of the message.

• Forward: allows you to forward the message to another person.

• Delete: allows you to delete the selected or all messages.

• Move to My Folder: moves the message to the phone’s My Folder location.

• Save as Template: saves to the message as a template for this message type.

This template can be used to save time during the creation of the next similar
message.

• Save Items: saves the multimedia content to the My Stuff folder.

• Add to Address Book: allows you to save the recipient or sender’s information

from the message to your Address Book on either the Phone or SIM.

• Print via Bluetooth: allows you print the contents of the message on a Bluetooth

compatible printer.

• Lock: locks the message.

• Properties: displays some of the file properties for the message such as: sender,

date/time, file size, priority, etc..

Using Instant Messenger (IM)

The Instant Messaging function allows you to send and receive instant messages
using AIM, Windows Live, and Yahoo communities. You must first create a default
community account before accessing it on your phone. To access your default
community session settings, use the following steps:

Default Community Settings

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Select IM and press the Select soft key or the key.

4. Select Settings and press the Select soft key or the key.

5. Select Choose Your Community and press the Select soft key or the

key. This is the service that will load when you press the IM soft key.

6. Use the Navigation keys to highlight your option, and press the Select soft

key or the key to save your selection.

71

Signing into your IM Account

Signing into your IM Account

Although each account type differs, the initial sign in procedure is common to all
supported types. Before beginning the sign in procedure, you must complete the
previous procedures for selecting your default IM Community.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Select IM and press the Select soft key or the key.

4. Select Sign In/On and press the Select soft key or the key.

5. Use the Navigation keys to select each log in field and then use the keypad

to enter the appropriate information.

6. Press the Options soft key. Highlight Sign In and press the Select soft key

or the key.

Signing into your Mobile Email

Take your email with you! With Mobile Email you can check your Yahoo!® Mail, AOL®,
Windows Live Hotmail, AT&T Yahoo!

®

, BellSouth, and AIM quickly and easily from the

SYNCTM.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Select Mobile Email and press the Select soft key or the key.

4. Use the Navigation keys to select an e-mail carrier of your choice and

press the Select soft key or the key.

5. Use the Navigation keys to select which domain your personal account

uses (e.g., "@hotmail.com") and press the Select soft key or the key.

6. Type in your personal Email address (e.g., "silverfox2"), then enter your

account's Password and press the Sign In soft key. You will be connected
to your account's Inbox and contacts, where you can send and receive
emails.

Using Message Templates

Your phone has message templates (both SMS and MMS) which allows you to
retrieve them when creating a message. You can change the templates as your
preferences or send a message immediately.

1. When the Idle screen displays, press the Menu soft key.

Messaging 72

2.

Select Messaging and press the Select soft key or the key. Highlight
Templates and press the Select soft key or the key.

3. Highlight a template type (Text or Multimedia) and press the Select soft

key or the key.

4. Use the Up or Down Navigation Keys to select a current template message

and press the Options soft key to access the following options:

•Send: allows you to send an SMS and MMS message using the template.

•Add New: allows you to add a new the template.

•Edit: allows you to change the currently selected template.

• Delete: deletes the currently selected template.

5. When you have finished, press the key.

Deleting Messages

You can delete the messages in each message folder(s) individually or all at one
time. You can also delete all of your messages at one time.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Highlight Delete All and press the Select soft key or the key.

4. Using the Up or Down Navigation key to select the message folder(s) you

want to empty.

5. Press the key to mark the folder you want to delete.

•All: allows you select all of the list items and mark each one for content deletion.

•Inbox: allows you select the your Inbox folder and mark its files for deletion.

•Sent: allows you select the your Sent folder and mark its files for deletion.

• Outbox: allows you select the your Outbox folder and mark its files for deletion.

•Drafts: allows you select the your Drafts folder and mark its files for deletion.

• My Folder: allows you select the your My Folder and mark its files for deletion.

To view the contents in each folder, use the Right key to display the
folder’s contents or use the Left key to close the folder’s contents.

To delete all of the messages in all folders, select All.

6. Press the Delete soft key. At the “Delete?” pop-up, press the Yes soft key

or the key to delete.

7. When you have finished, press the key.

73

Messaging Settings

Messaging Settings

You can set up various options for using messaging services.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Highlight Messaging Settings and press the Select soft key or the

key.

4. Select the type of messages for which you want to change.

• Text Message

• Multimedia Message

• Voice Mail

• Push Message

5. Press the Select soft key or the key.

Text Message

The following options are available:

• Sending Options: allows you to set the following options:

• Keep a Copy: allows you to keep a copy of your sent messages.

• Text Message Center Settings: allows you to set the default method of text

message transmission used by the Text Message Center. The options are:

• SMS Settings: allows you to configure the text delivery parameters used when

sending this type of message.

• Email Settings: allows you to configure the Email parameters used when

sending this type of message.

•Empty: allows you to configure a new Text Message Center profile for use when

sending this type of message.

Multimedia Message

The following options are available:

• Sending Options:

•Priority: you can select the priority level of your messages.

• Expiration: select the length of time you wish the message you sent to remain

on the MMS server.

•Delivery: you can set a time delay before the phone sends your messages.

• Message Size: you can set the maximum allowed size for a multimedia

message.

• Request Delivery Report: when this option is enabled, the network informs

you whether or not your message has been delivered.

Messaging 74

• Request Read Report: when this option is enabled, your phone sends a
request for a reply along with your message to the recipient.

• Keep a Copy: you specify whether you want to keep a copy of the sent
messages on your phone.

• Add My Business Card: you send your content information along with your
sent messages.

• Receiving Options: you can specify the category of messages you want to

receive. Allows you to set the following:

• Download Type: allows you to set the message receipt options. Choose from
Auto Download, Manual, or Reject.

• Send Delivery Report: when this option is enabled, the phone allow the
network report to the sender whether or not the message has been received.

• Send Read Report: when this option is enabled, your phone sends a
notification back to the recipient indicating that your message has been received.

• Reject Anonymous: allows you to automatically reject messages with a
category of anonymous.

• Reject Advertisement: allows you to automatically reject messages with a
category of advertisement.

• Multimedia Message Profiles: you can select a connection profile which is then

used for sending and receiving Multimedia messages.

• MMS Profiles: allows you to select an option for sending a multimedia message.

Choose from the following options:

• MEdia Net wap1.x

• MEdia Net wap2.x

• AT& T M MS

• AT&T IMS

• Profile Settings (accessed by pressing the Options softkey)

• Set Name

• Access Name

• Auth Type

• User ID

• Password

• Protocol

• Home URL

• Proxy address

• Port

• Linger Time (Sec.)

• Advanced Settings (Static IP, Static DNS, and Traffic Class)

75

Messaging Settings

• Auto Resize Image: you can specify that the received image by be resized up/

down:

• No Resize

• 100 KB

• 300 KB

• 600 KB

• Creation: you can specify that the users creating new media content be given the

following options:

• Warning

• Free

• Restricted

• Default Style: you can specify the default visual parameters used by this type of

message:

• Font Color

• Font Style

• Background Color

• Page Duration

Voice Mail Message

The following options are available:

• Voicemail: you can specify the default phone number used for access of phone’s

remote voicemail:

•Name: allows you to create a new descriptive name for this access number.

• Center Address: allows you edit the existing number and create a new number

for use when accessing the remote voicemail.

Push Message

The following options are available:

• Receiving Option: you can specify whether to turn push message reception On or

Off.

• Service Loading: you can specify whether to load this service:

• Always

• Prompt

• Never

Messaging 76

Memory Status

You can check the amount of the memory being used and the memory remaining for
Multimedia, Text, Push, and Configuration Messages. The display shows the total
space including the used and free space. You can also view how much space is
currently occupied by each message box.

1. When the Idle screen displays, press the Menu soft key.

2. Highlight Messaging, and press the Select soft key or the key.

3. Highlight Memory Status and press the Select soft key or the key.

4. Use your Up, Down, Left or Right Navigation keys to select a particular

folder for review.

5. Press the Select soft key or the key. The contents of that folder are

then listed.

6. When you have finished, press the key.

77

Sound Settings

Section 8: Changing Your Settings

Topics Covered

• Sound Settings

• Display Settings

• Time & Date

• Phone Settings

• Call Settings

• Connectivity

• Configuring your Phone’s Connections

• Configuring your Phone’s USB Connection

• Software Update

• Application Settings

• Reset Settings

• Memory Settings

• Video Share Settings

This section explains the sound and phone settings for your phone. It includes
display settings, security settings, and extra settings associated with your phone.

Sound Settings

You can customize various sound settings.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Profiles and press the Select soft key or the key. Use the Down

Navigation key to scroll through the following list of available options:

Normal Profile

To access the available options for this calling profile, press the Options soft key.
Highlight Edit and press the Select soft key or the key. Use the Left and Right
Navigation keys to move between the various tabs. This menu allows you to alter the
audio settings for the following categories:

Changing Your Settings 78

•

Incoming Call: allows you to edit the properties for audio alert used for incoming
phone calls.

• Call Alert Type: allows you to select the way in which the selected ringtone is
played to notify you of an incoming call. Options include:

- Melody: the phone sounds the selected melody.

- Increasing Melody: the phone sounds the selected melody at continually

increasing volume until the incoming call is answered.

- Vibration then Melody: the phone vibrates then plays the melody.

- Vibration & Melody: the phone vibrates and also plays the melody.

- Vibration & Increasing Melody: the phone vibrates and also plays the

melody at increasing volume levels during each consecutive ring.

• Voice Call Ringtone: allows you to select a ringtone from your My Stuff
(Phone) folder which contains not only the default phone ringtones, but also any
new ringtones which have been downloaded from the Internet.

• Ringtone Volume: allows you to select the volume at which the ringtone is
played. This range is from 1 - 7.

• Auto Reply: allows you to setup an automatic text reply for missed calls.

• New Messages: allows you to edit the properties for audio alert used for newly

received messages.

• Message Alert Type: allows you to select the way in which the selected
ringtone is played to notify you of an incoming message. Options include the use
of either the Mute, Melody, Vibration, or a combination of the latter two.

- Melody: the phone sounds the selected melody.

- Vibration: the phone vibrates.

- Vibration & Melody: the phone vibrates and also plays the melody.

- Mute: the alert is muted.

• Message Alert Tone: allows you to select either an Effect Tone (Beep, Pure,
Clean, or Fun) or a personalized My Alert Tone from your My Stuff (Phone) folder
which contains not only the default phone tones, but also any new tones which
have been downloaded from the Internet.

• Message Alert Repetition: allows you to select whether the message alert
tone is used to notify you of a new message only once or periodically until you
open the message.

• Alert Tone Volume: allows you to select the volume at which the tone is
played. This range is from 1 - 7.

• Phone Sounds: allows you to edit the properties for phone’s audio properties while

it is set to this mode

• Keypad Tones: allows you to select what tone is played when the keypad keys
are pressed. Options include the Beep, Clean and Mute.

• Power On Type: allows you to select what tone is played when the phone is
powered On. Options include a Melody, Vibration, Vibration & Melody, or Mute.

79

Sound Settings

• Power Off Type: allows you to select what tone is played when the phone is

powerd Off. Options include a Melody, Vibration, Vibration & Melody, or Mute.

• Folder Open/Close Tone: allows you to select what tone is played when a

folder is Opened (accessed) or Closed. Options include a Melody, 1 - 3, or Mute.

• Volume, Phone Sounds: allows you to select the volume at which the keypad

tone is played. This range is from 0 - 7.

Note: To save any changes made to this profile’s parameters, press the Options soft key. Highlight Save and

press the Select soft key.

Other Available Profiles

The phone can be set to additional audio profiles which are available via the Profiles
menu. Although each profiles has similarities, they have each been preset to use
different audio parameters for incoming phone call alerts, message alerts, and
phone usage. For more information, refer to "Icons" on page 16.

• The Silent profile causes the speaker to be muted and the phone only

vibrates and displays information on its front panel LCD. This icon is
accompanied on screen by the Vibrate icon.

Note: The Silent profile can also be activated by pressing and holding the key. An on screen message

notifies you that the new Silent profile is no w active. To deactivate this profile, press an d hold the

key again.

• The Driving profile keeps the speaker is active. In this case, the speaker

is active and will launch the currently selected ringtone or melody
when the associated notification is activated. This icon is accompanied

on screen by the Audio icon.

• The Meeting profile causes both the speaker audio and vibration

features to be disabled and only the front panel LCD displays
information. This icon is accompanied on screen by the Audio icon.

• The Outdoor profile keeps the speaker active, the volume settings are

raised to their highest levels, any currently active ringtones or melodies
are activated, and the phone’s vibrate feature is activated. This icon is

accompanied on screen by the Vibrate/Audio icon.

• The Airplane profile allows you to use many of your phone’s features,

such as Games, Music, Notepad, Voice Memos, etc., but you cannot
send or receive any calls or access online information. This icon is

accompanied on screen by the Mute icon.

Changing Your Settings 80

Display Settings

In this menu, you can change various settings for the display or backlight.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Display Settings and press the Select soft key or the key.

The following options are available. Use the Down Navigation key to scroll
to and set options:

Main Display

• Wallpaper: allows you to select from either the preloaded wallpapers found in the

My Stuff (Phone) folder or photographs which have been either taken with the
camera or downloaded from the Internet. The None option

blank. Press the Up or Down Navigation keys to make your selection. Press the Set soft
key or the key to make your selection.

Greeting Message: allows you to enter the text which appears on the screen then the

•
phone powers on

• Menu Style: allows you to select the whether the phone’s menus are presented in either
a Grid Menu style of List Menu style. Press the Up or Down Navigation keys to make your
selection. Press the Select soft key or the key to make your selection.

Pop Up List Menu: allows you to select the whether the to activate pop up menus.

•
Press the Up or Down Navigation keys to make your selection. Choose from On or Off.
Press the Save soft key or the key to make your selection.

Idle Screen Setting: allows you to select what is displayed when the phone is in Idle

•

. Press the Left or Right Navigation keys to make your selection. Choose from Text

mode
Clock, Clock 1, Clock 2, or Calendar. Press the Save soft key or the key to make your
selection.

Dialing Display: allows you to select the properties of those items which are part of the

•
display such as Font and Color:

Font Type: allows you to select what font is used. Press the Left or Right Navigation

•

keys to make your selection. Choose from Normal, Quill Pen, or Sticky Note. Press the

Save soft key or the key to make your selection.

Font Size: allows you to select a size for the selected font. Press the Left or Right

•

Navigation keys to make your selection. Choose from Large, Medium, or Small. Press
the Save soft key or the key to make your selection.

Font Color: allows you to select a color for the selected font. Press the Left or Right

•

Navigation keys to make your selection. Choose from Monochrome, Rainbow,
Gradation, or Basic. Press the Save soft key or the key to make your selection.

.

leaves the wallpaper

81

Time & Date

• Background Color: allows you to select a color for the background screen. Press

the Left or Right Navigation keys to make your selection. Choose from the available
colors. Press the Save soft key or the key to make your selection.

Light Settings

• Brightness: allows you to adjust the display brightness for the LCD to see it better

in different lighting conditions. Press the Left or Right Navigation keys to adjust the
brightness. Press the Save soft key or the key to make your selection.

• Backlight Time: allows you to select the amount of time for the backlight to

remain on and the length of time for the actual dimming to occur. Press the Up or
Down Navigation keys to make your selection. For On choose from either 15
Seconds, 30 Seconds, or 1 Minute. For Dim choose from either Off, 5 Seconds, 15
Seconds, 30 Seconds, or 1 Minute. Press the Save soft key or the key to make
your selection. Choose On or Off for the Front LCD Indicator.

• Keypad Light: allows you to determine when to use the keypad light. Press the Up

or Down Navigation keys to make your selection. Choose from either Use at Any
Time, or Use at Custom Time. Press the Save soft key or the key to make
your selection.

Time & Date

This menu allows you to change the current time and date displayed. You can also
find out what time it is in another part of the world.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Time & Date and press the Select soft key or the key. The

following options are available. Use the Down Navigation key to scroll to
and set options:

• Time Zone Updating: allows you to select whether the time zone information is

updated: Automatic (which greys-out all other options), Manual Only, or Prompt
first.

• Home Zone: allows you to enter the assign your current time zone based upon

Greenwich Mean Time. Major cities in each zone are displayed upon selection. Use
the Left or Right Navigation key to select a new zone. Press the OK soft key or the

key to save the new selection.

Tip: You can also choose to activate Daylight Savings Time within the Home Zone menu option.

Changing Your Settings 82

•

Time: allows you to enter the current time using your keypad. Press the Right
Navigation key to select AM or PM. Press the Save soft key or the key to save
the new selection.

• Date: allows you to enter the current date using your keypad. Press the Left or

Right Navigation key to navigate between the month, day, or year fields. Press the
Save soft key or the key to save the new selection.

• Time Format: allows you to change the time format to 12 hours or 24 hours. Use

the Left or Right Navigation key to select between the two options. Press the Save
soft key to save the new selection.

• Date Format: allows you to change the date format. Press the key to activate

the option. Use the Up or Down Navigation key to select between the different
options. Press the OK soft key to change the format. Press the Save soft key to
save the new selection.

Note: Automatic updates of time and date do not change the time you have set for alarm settings or

calendar memos.

Phone Settings

To customize the settings of your phone use the following steps:

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Phone Settings and press the Select soft key or the key.

The following options are available. Use the Down Navigation key to scroll
to and set options:

• Language: allows you to select a display language. You can set the Text Language

or the Input Mode.

• Screen Text: allows you to select the phone text. Use the Up or Down Navigation

key to highlight your selection. Press the OK softkey or the key to make your selection.
Press the Save soft key to save your new selection. Options include:

-

Automatic: the language is automatically selected according to the language

of the SIM card used.

- English: the selected phone language is changed to English.

- Français: the selected phone language is changed to French.

- Español: the selected phone language is changed to Spanish.

• Input T9: sets the language used when entering text into the phone. Use the Up or

Down Navigation key to highlight your selection. Press the OK softkey or the
to make your selection. Press the Save soft key to save your new selection. Options
include:

-

English: the selected phone language is changed to English.

83

key

Call Settings

- Français: the selected phone language is changed to French.

- Español: the selected phone language is changed to Spanish.

• Shortcuts: allows you to change the applications assigned to your Navigation keys.

• Press a particular Navigation key and press the Options softkey.

• Highlight Change and press the . Use the Up or Down Navigation key to

select a new application to assign to the previously pressed key.

• Press the Save soft key or the key to save the new application to the

assigned Navigation key.

• Own Number: allows you to enter a name and number into your phone for easy

referral.

Call Settings

This menu allows you to change the actions taken by the phone when dialing and
receiving calls. These settings extend to not only voice calls but also Data calls as
well.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Call Settings and press the Select soft key or the key. The

following options are available. Use the Down Navigation key to scroll to
and set options:

All Calls

This allows you to configure some common high level parameters used by the phone
for most types of calls.

• Show My Number: allows you to select how your ID is handled when an outgoing

call is initiated. Use the Up or Down Navigation key to highlight your selection. Press

key to make your selection. Press the Save soft key to save your new

the
selection. Options include:

• By Network: you are identified to the other party using the default network

information.

•Send: your phone number and name are sent to the other party.

• Hide: your identifying information is hidden from the other party.

• Auto Reject: allows you to enable a phone feature which allows you to automatically

reject calls from a list of contacts. Use the Left or Right Navigation key to toggle the
activation of this feature. Select Auto Reject List and press the
list of rejected numbers. Press the
Create soft key to create a new phone entry. Press the OK softkey or the key to make
your selection. Press the Save soft key to save your new selection.

key to select an entry from the list of press the

key to access the

Changing Your Settings 84

Answering Mode: allows you to select how your phone answers incoming calls. Use

•

the Up or Down Navigation key to highlight your selection. Press the
your selection. Press the Save soft key to save your new selection. Options include:

key to make

• Normal: allows you to answer an incoming call by pressing either the Accept

soft key or the key.

•Any key: allows you to answer an incoming call by pressing any key on your

phone.

• Active Flip: allows you to answer an incoming call by just opening the phone.

• Show Caller ID: allows you to select whether your phone displays the caller ID

information for the incoming call. Use the Left or Right Navigation key to toggle the
activation of this feature. Press the
soft key to save your new selection. Options include:

key to make your selection. Press the Save

• Activation On/Off: allows you to set whether your phone displays the caller ID

for the incoming call.

• With Front Display: allows you to also display the caller ID on the front LCD.

• Call Status Tones: allows you to activate an alert tone for one of three available

status categories. Use the Up or Down Navigation key to highlight your selection.
Press the
selection. Options include:

key to make your selection. Press the Save soft key to save your new

• Call Connect Tone: allows you to activate an alert tone when the a connection

has been made.

• Minute Minder: allows you to activate an alert tone which sounds every

minute the call is active.

• Call End Tone: allows you to activate an alert tone when the a connection has

been terminated.

• Alerts On Call: allows you to activate an alert tone for new messages being received

during an active call. Use the Up or Down Navigation key to highlight your selection.
Press the
selection. Options include:

key to make your selection. Press the Save soft key to save your new

• Off/On: allows you to toggle the activation of this feature. Selecting Off prevents

a new message alert from sounding while you are on an active call. Selecting On
allows an alert tone to sound if you receive a new message during an active call.

85

Call Settings

Voice Call

This allows you to configure those phone parameters associated to voice calls.

• Call Forwarding: enables incoming calls to be rerouted to a number that you specify.

Use the Up or Down Navigation key to highlight your selection. Press the
make your selection. Press the Select soft key to save your new selection. Options
include:

• Always: allows you to forward Voice Calls. Press the Select soft key and either
enter the phone number or press the Options soft key to select a number from
your Address Book. Once you have selected a number, press the Options soft
key and select to either Activate/Deactivate this feature.

• If Busy: allows you to forward Voice Calls to a designated number instead of
your voice mail number if you are on another phone call. Press the Select soft
key and either enter the phone number or press the Options soft key to select a
number from your Address Book. Once you have selected a number, press the

Options soft key and select to either Activate/Deactivate this feature.

• If No Reply: allows you to forward Voice Calls to a designated number instead

of your voicemail number when there is no answer on your phone. Press the
Select soft key and either enter the phone number or press the Options soft
key to select a number from your Address Book. Once you have selected a
number, press the Options soft key and select to either Activate/Deactivate
this feature.

• If Out Of Reach: allows you to forward Voice Calls to a designated number
instead of your voicemail number when you are not in an area covered by your
service provider or when your phone is switched off. Press the Select soft key
and either enter the phone number or press the Options soft key to select a
number from your Address Book. Once you have selected a number, press the

Options soft key and select to either Activate/Deactivate this feature.

• Cancel All: allows you to cancel all Call Forwarding features. Press the Select

soft key to activate this feature.

• Call Waiting: informs you when someone is trying to reach you during another call.

Press the
selection. Options include:

key to make your selection. Press the Select soft key to save your new

• Activate: allows you to activate this feature for all Voice Calls. Press the
Options soft key to select this option.

• Deactivate: allows you to deactivate this feature for all Voice Calls. Press the
Options soft key to select this option.

• Check Status: allows you to check the status of this feature for all Voice Calls.
Press the Options soft key to select this option.

• Auto Redial: allows to you automatically redial the last number if the call was either

cut off or you were unable to connect. Press the
Press the Save soft key to save your new selection. Options include:

key to make your selection.

Changing Your Settings 86

key to

•Off: keeps the phone from automatically redialing the last number if the call was

disconnected or the call was cut off.

•On: causes the phone to automatically redial the last number if the call was

disconnected or the call was cut off.

Data Call

This allows you to configure those phone parameters associated to data calls.

• Call Forwarding: enables incoming data calls to be rerouted to a number that you

specify. Use the Up or Down Navigation key to highlight your selection. Press the
key to make your selection. Press the Select soft key to save your new selection.
Options include:

• Always: allows you to forward Data Calls. Press the Select soft key and either
enter the phone number or press the Options soft key to select a number from
your Address Book. Once you have selected a number, press the Options soft
key and select to either Activate/Deactivate this feature.

• If Busy: allows you to forward Data Calls to a designated number instead of
your voice mail number if you are on another phone call. Press the Select soft
key and either enter the phone number or press the Options soft key to select a
number from your Address Book. Once you have selected a number, press the

Options soft key and select to either Activate/Deactivate this feature.

• If No Reply: allows you to forward and Data Calls to a designated number

instead of your voicemail number when there is no answer on your phone. Press
the Select soft key and either enter the phone number or press the Options
soft key to select a number from your Address Book. Once you have selected a
number, press the Options soft key and select to either Activate/Deactivate
this feature.

• If Out Of Reach: allows you to forward Data Calls to a designated number
instead of your voicemail number when you are not in an area covered by your
service provider or when your phone is switched off. Press the Select soft key
and either enter the phone number or press the Options soft key to select a
number from your Address Book. Once you have selected a number, press the

Options soft key and select to either Activate/Deactivate this feature.

• Cancel All: allows you to cancel all Call Forwarding features. Press the Select

soft key to activate this feature.

87

Connectivity

• Call Waiting: informs you when someone is trying to reach you during another call.

Press the
selection. Options include:

key to make your selection. Press the Select soft key to save your new

• Activate: allows you to activate this feature for all Data Calls. Press the
Options soft key to select this option.

• Deactivate: allows you to deactivate this feature for all Data Calls. Press the
Options soft key to select this option.

• Check Status: allows you to check the status of this feature for all Data Calls.
Press the Options soft key to select this option.

Connectivity

The Connectivity Settings allow you to manage the settings associated with the
connection types available to your phone, including, Bluetooth, Network, Wireless
connectivity, and USB.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Connectivity and press the Select soft key or the key. Use the

Down Navigation key to scroll to and set these options.

Bluetooth

Bluetooth is a short-range wireless communications technology capable of
exchanging information over a distance of about 30 feet without requiring a physical
connection. Unlike infrared, you don't need to line up the devices to beam
information with Bluetooth. If the devices are within a range of one another, you can
exchange information between them, even if they are located in different rooms.

The Bluetooth wireless technology settings menu provides the ability to view and
change the device name, show the visibility, and set the security for the device.

Activation of Bluetooth

When the Bluetooth is turned on, you can use the Bluetooth features available. When
the Bluetooth is turned off, you cannot send or receive information via Bluetooth. To
save battery life or in situations where Bluetooth use is prohibited, you can turn off
the Bluetooth wireless technology headset.

Changing Your Settings 88

My Devices

This menu provides a list of Bluetooth wireless technology devices discovered by
your handset.

1. From the Bluetooth menu items, highlight My Devices and press the

Select soft key or the key.

2. To search for the Bluetooth device(s), highlight Search For New Devices

and press the Select soft key or the key.

Connecting to a Bluetooth Device

From the Device list,

1. Highlight the device and press the Select soft key or the key.

2. Enter the PIN for the device.

If connecting to a Bluetooth wireless device consult your Bluetooth device
user manual for your assigned PIN.
If connecting to another handset, enter the same user-defined PIN on both
handsets.

Note: The first time you try to pair with a handset, you and the o wner of the other handset must enter the

same PIN. Once the handsets are paired, you will not need to use the PIN again.

3. Press the OK soft key or the key.

4. If you are unable to pair with the device a popup appears in the display.

Press the Yes soft key to retry.

Configuring your Phone’s Bluetooth Visibility

When the Bluetooth Visibility is turned on, your phone is wirelessly transmitting its
phone name and status. This can be useful if you are attempting to connect
additional Bluetooth devices. Allowing your phone to promote its visibility can pose a
security risk and incite unauthorized connection. This feature should be paired with a
Bluetooth security option.

1. Highlight the option (On/Off) and press the Select soft key or the key.

Configuring your Phone’s Bluetooth Name

89

Connectivity

When your phone’s Bluetooth visibility is turned On, it identifies itself using the name
entered into this text field. This name can be altered by selecting the pre-existing
text and selecting a new text string in its place. This feature should be paired with a
Bluetooth security option.

1. Press the key to erase the previous name.

2. Use the phone’s keypads to enter a new name. The default input entry

method is Abc, where the initial character is Uppercase and each
consecutive character in that same word is left as lowercase text.

3. Press the Save soft key or the key to save the new name.

Configuring your Phone’s Bluetooth Security

When the Bluetooth Visibility is turned on, your phone is wirelessly transmitting its
phone name and status. This transmission can pose a security risk and incite
unauthorized connection to your phone. It is recommended that you active your
phone’s Bluetooth security.

1. Highlight the option (On/Off) and press the Select soft key or the key.

Bluetooth Ser vices

Actually, the Bluetooth specification is a protocol that describes how the short-range
wireless technology works, whereas individual profiles describe the services
supported by individual devices. Profiles reduce the chance that different devices
will not work together.

Your phone supports the following profile services:

• Headset: enables outgoing and incoming calls.

• Handsfree: the remote carkit enables outgoing and incoming calls.

• Bluetooth Stereo Headset: enables outgoing and incoming calls via a headset

equipped with stereo headsets.

• Serial Port: data communication can be established via a Serial Port connection.

• Dial Up: The phone is configured as a dial up modem for access to the Internet.

• Basic printing: The phone is configured to use bluetooth technology to enable basic

printing from the phone. This is useful to print received text message or contact
information.

• File Transfer: The phone is configured to transfer data wirelessly to a target device.

• Object Push: The phone is configured to wirelessly transfer information about

Pushes.

Changing Your Settings 90

Configuring your Phone’s Connections

Your phone is wirelessly connecting to the Internet via a built in WAP browser.
Connection can be made via either one of three available WAP browsers: MEdia Net
wap1.x, MEdia Net wap2.x, AT&T MMS (MultiMedia Server), AT&T IMS. Use this
menu to create and customize the profiles containing the settings for connecting
your phone to the network. You need these settings to use the web browser or send
MMS messages or e-mails. Although the active connection can be changed by the
user, it is recommended that this choice be made with the assistance of either the
retailer or customer service representative.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Connectivity. Highlight Connections and press the Select soft key

or the key. Use the Up or Down Navigation key to highlight one of
these options:

• MEdia Net wap1.x

• MEdia Net wap2.x

• AT&T MMS

• AT&T IMS

4. Press the Options soft key.

Note: The MEdia Net WAPs are pre-configured and can not be altered on this screen. The AT&T MMS

connection option can be edited, renamed, or deleted on this screen. Your phone is set up by default
for connecting to the network. If you change the settings without first checking with your service
provider, the web browser, MMS, and e-mail features may not work properly.

5. To create a new connection, press the Options soft key, select New, and

press the Select soft key or the key.

- or -

6. To edit the existing AT&T MMS, highlight this entry, press the Options soft

key, select Edit, and press the Select soft key or the key.

7. Select the parameter you want to edit:

•Set Name: enter a profile name.

• Access Name: edit the access point name.

• Auth Type: select the type of authentication used for this WAP connection:

None, Normal, or Secure.

•User ID: enter the User ID required to connect to the network.

• Password: enter the user password required to connect to the network.

91

Configuring your Phone’s USB Connection

• Protocol: set the connection protocol used by the WAP browser: WAP, HTTP, or
Other.

•Home URL: enter the URL address of the page to be used as your homepage.

• Gateway address: (wap1.x only) enter the gateway address of the proxy server.

•Proxy address: (wap2.x and AT&T MMS) set the proxy server address and port.

• Linger Time (Sec.): set a time period (in seconds) after which the network is

disconnected if there has been no new data traffic in that time.

• Advanced Settings: allows you to configure some of the IP-specific
information: Static IP, Static DNS, Server information, and Traffic Class.

- Static IP: specify if you want to manually enter an IP address. If you want the IP

address to be automatically assigned by the server, remove the check mark.

- Local phone IP: enter the IP address obtained from the network operator, if you

checked the Static IP option.

- Static DNS: specify if you want to manually enter the Domain Name Server

(DNS) address. If you want the address to be automatically assigned by the
server, remove the check mark.

- Server 1/Server 2: enter the Domain Name Server (DNS) addresses.

- Traff ic c las s: select the traffic class.

Note: The WAP settings may vary depending on the service provider.

Configuring your Phone’s USB Connection

Your phone can connect to a PC via the USB cable (sold separately). The phone can
be configured to open launch a default application when an active USB connection is
detected.

1. Use the USB adapter cable to connect the handset to the target PC. When

an active connection has been established, a USB icon ( ) appears on
the phone.

2. When the Idle screen displays, press the Menu soft key.

3. Select Settings and press the Select soft key or the key.

Select Connectivity. Highlight Select USB Mode and press the Select soft
key or the key. Use the Up or Down Navigation key to highlight one of
these options:

• Media Player: sets the Media Player to launch as the default application when
a USB connection is detected. This is the default application.

•PC Studio: sets PC Studio to launch as the default application when a USB
connection is detected.

• Ask on Connection: requires the phone to present a “Select USB Mode”
pop-up which requires you to assign a default USB application.

Changing Your Settings 92

4.

With the application highlighted, press the Save soft key or the key.

Software Update

The Software Update feature enables you to use your phone to connect to the
network and upload any new phone software directly to your phone.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Software Update and press the Select soft key or the key.

4. Press the key to continue the update process and follow the on screen

instructions.

Application Settings

The Application Settings feature allows you to configure the functional parameters
for most of the on board applications. These applications are described in more
detail within other sections of this manual.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Application Settings and press the Select soft key or the key.

4. Select the type of application which you want to change.

• Messaging Settings (page 74)

• Browser Settings (page 152)

• Camera Settings (page 126)

• Camcorder Settings (page 130)

• Media Player Settings (page 120)

• Cellular Video Settings (page 118)

• Record Audio Settings (page 134)

• Calendar Settings (page 137)

• Address Book Settings (page 54)

• Video Share Settings (page 98)

5. Press the Select soft key or the key.

93

Application Settings

Security

The Security feature enables you to restrict the use of your phone by the others and
to restrict the types of calls.

Various codes and passwords are used to protect the features of your phone.

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Security and press the Select soft key or the key.

The following options are available. Use the Up or Down Navigation key to
scroll to and set options.

Phone Lock

When the Phone lock feature is enabled, the phone is locked and you must enter the
4- to 8-digit phone password each time the phone is switched on. To change the
phone password, see "Change Phone Password" on page 95. Once the correct
password has been entered, you can use the phone until you switch it off. The
following options are available:

• Off: you are not asked to enter the phone password when you switch on the phone.

• On: you are required to enter the phone password when you switch on the phone.

SIM Lock

When the SIM Lock feature is enabled, your phone only works with the current SIM.
You must enter the lock code to unlock the SIM so you can use a different SIM card.

• Once you have entered the lock code, you are asked to confirm your password.

Reenter your password and press the OK soft key.

PIN Check

When the PIN Check feature is enabled, you must enter your PIN each time you
switch on the phone. Consequently, any person who does not have your PIN cannot
use your phone without your approval.

Note: Before disabling the PIN Check feature, you must enter your PIN.

The following options are available:

• Off the phone connects directly to the network when you switch it on.

• On: you must enter the PIN each time the phone is switched on.

Changing Your Settings 94

Lock Applications

Using this menu, you can lock the following categories:

• Lock All

• Messaging

• My Stuff

• Recent Calls

• Address Book

• Calendar

• Note

• IM

• Tas ks

Once you have locked the contents, you must enter the phone’s password to access
the associated menus.

FDN Mode

FDN (Fixed Dial Number) mode, if supported by your SIM card, allows you to restrict
your outgoing calls to a limited set of phone numbers.

The following options are available:

• Off: you can call any number.

• On: you can only call phone numbers stored in Phone book. You must enter your

PIN2. The following options are available:

• Full length entries or wild cards can be entered in to the FDN list.

• A full length number with a specific contact name can be entered into the FDN

list.

• Wildcard entries allow a range of numbers to be dialed with a single entry: ex.

555 – All dialed numbers that begin with 555 will be allowed. Numbers that do
not match the conditions in the FDN list will be restricted. Note: Entering an
asterisk (*) is not required for wild card entries.

Note: Not all SIM cards have a PIN2. If your SIM card doe s not, this menu does not display.

Change Phone Password

The Change Phone Password feature allows you to change your current phone
password to a new one. You must enter the current password before you can specify
a new one.

Once you have entered a new password, you are asked to confirm it by entering it
again.

95

Reset Settings

Change PIN Code

This feature allows you to change your current PIN, provided that the PIN Check
feature is enabled. You must enter the current PIN before you can specify a new one.

Once you have entered a new PIN, you are asked to confirm it by entering it again.

Change PIN2 Code

The Change PIN2 feature allows you to change your current PIN2 to a new one. You
must enter the current PIN2 before you can specify a new one. Once you have
entered a new PIN2, you are asked to confirm it by entering it again.

Note: Not all SIM cards have a PIN2. If your SIM card does not, this menu does not di splay.

Reset Settings

You can easily reset your phone to its default settings. To reset your phone:

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Reset Settings and press the Select soft key or the key.

4. The following options are available. Use the Up or Down Navigation key to

scroll to and set options. Choose from the following:

• All

• Phone Settings

• Display Settings

• Profiles

• Alarms

5. Press the key to make your selection and press the OK soft key.

6. Enter your phone password, if prompted.

7. At the “Reset Settings?” prompt, press the Yes soft key to reset, or the

No soft key to cancel. Once your phone has been reset to its default

settings for those selected options, it will restart itself in order to
incorporate the new settings.

Changing Your Settings 96

Memory Settings

You can easily check the amount of memory being used for storing data, such as
messages, media, calendar data, or contacts entries. You can also delete any
selected information from your phone:

1. When the Idle screen displays, press the Menu soft key.

2. Select Settings and press the Select soft key or the key.

3. Select Memory Settings and press the Select soft key or the key.

4. The following options are available. Use the Up or Down Navigation key to

scroll to and set options. Choose from the following:

• Clear Memory

• Memory Status

Clearing Memory

Note: To completely remove any personal information stored on y our device, see "Precautions for Transfer

and Disposal" on page 179.

1. Highlight Clear Memory and press the Select soft key or the key.

2. Highlight All and press the key to select all available categories.

You can remove the check mark by pressing the key again. Selecting
All places a checkmark adjacent to every entry in the list.

- or -

3. Highlight a specific category and press the key to select it.

4. Press the OK soft key.

5. Enter your password (if applicable) and press the Confirm soft key.

Depending on your phone’s security settings, you may be asked to enter
your password a second time.

6. At the Clear all memories? confirm screen, press the Yes soft key to

continue, or the No soft key to cancel.

7. When you are finished, press the key to return to Idle mode.

97
