- SF-650 / 650P
1. Print Speed (Only SF-650P)
• 19 ppm in Letter
2. Copy Speed
• 19 ppm in Letter
3. Processor
• Chorus2 66 Mhz
4. Interfaces
• One USB port
6. Toner cartridge
• Initial: 1K, starter cartridge
• Sales : 1.5K / 2.5K two types
7. Machine Life : 50,000 pages
Page 2
This Parts Catalog is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of this manual can be punished under
applicable International and/or domestic law.
Page 3
ExplodedView and Parts List
Contents
Samsung Electronics Service Manual
Samsung Electronics Service Manual
Power Cord ……………………………………………………………… 4
Thumbnail ………………………………………………………………… 5
1. MAIN …………………………………………………………………… 7
2. COVER ………………………………………………………………… 9
Parts Catalog - SF-650/650P
3. COVER FRONT ……………………………………………………… 11
4. COVER REAR ………………………………………………………… 13
5. ADF FRAME-MAIN_650P …………………………………………… 15
6. ADF FRAME-MAIN_650 ……………………………………………… 17
7. COVER-TOP ………………………………………………………… 19
8. ADF STACKER-TX …………………………………………………… 21
Parts Catalog - SF-650/650P
9. HANDSET ……………………………………………………………… 23
10. ADF FRAME-LOWER ……………………………………………… 25
11. DRIVE-ADF …………………………………………………………… 27
12. ADF FRAME-UPPER_650P ……………………………………… 29
13. ADF FRAME-UPPER_650 ………………………………………… 31
14. FRAME-LOWER …………………………………………………… 33
15. FRAME BASE-PICK UP …………………………………………… 37
16. DRIVE MAIN-BRACKET …………………………………………… 39
17. FUSER ……………………………………………………………… 41
18. CASSETTE …………………………………………………………… 43
3
Page 4
4
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
5
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Power Cord
3903-000042
3903-000085
3903-000067
3903-000050
3903-000133
3903-000082
3903-000227
3903-000146
3903-000020
3903-000182
XAZ
SEE / STS / XSA / XSG
XSS / XEV / XEG
XFA / XIP
XEU / XSS
XIL
XAA / XAX
KOR
XBH
ETS
TED
To p View
Side View
Part Code
Usable Country Code
To p View
Side View
Part Code
Usable Country Code
Power Cord differs by countries. Please check your country code.
Page 5
5
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Thumbnail 1
1. MAIN
2. COVER
3. COVER FRONT
4. COVER REAR
5. ADF FRAME-MAIN_650P
7. COVER-TOP
9. ELA UNIT-HANDSET
10. ADF FRAME-LOWER
8. ADF STACKER-TX
(SF-650P)
(SF-650)
6. ADF FRAME-MAIN_650
11. DRIVE-ADF
12. ADF FRAME-UPPER_650P 13. ADF FRAME-UPPER_650 14. FRAME-LOWER
Page 6
6
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
7
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Thumbnail 2
16. DRIVE MAIN-BRACKET
17. FUSER
18. CASSETTE
15. FRAME BASE-PICK UP
Page 7
7
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
1. MAIN
0
7
13
12
1
2
3
4
5
8
9
6
10
11
(SF-650P) (SF-650)
Page 8
8
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
9
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
MAIN Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 SF-650P SET 1
0 SF-650 SET 1
1 JC44-00178A SMPS/HVPS-V1 1 SA 110V
1 JC44-00179A SMPS/HVPS-V2 1 SA 220V
2 JC92-02203B PBA-MAIN 1 SA 650/SEE
2 JC92-02203J PBA-MAIN 1 SA 650/Others
2 JC92-02203K PBA-MAIN 1 SA 650P
3 JC90-00939B CASSETTE 1 SA
4 JC61-00601A BRACKET-P-INLET 1 SA
5 JC63-02410A SHIELD-ENGINE 1 SNA
6 JC39-00240B HARNESS-ENGINE 1 SA
7 JC91-00946A FUSER_110V 1 SA 650_650P/XAA
7 JC91-00946B FUSER_110V 1 SA
7 JC91-00945A FUSER_220V 1 SA Others
7 JC91-00945B FUSER_220V 1 SA 650P/XSS
650_650P/TED
Drawer# SEC_Code Description QT’y Service Remark
8 JC66-01218A ROLLER-TRANSFER 1 SA
9 JC93-00114B FRAME-LOWER 1 SNA
10 JC97-03702A ADF FRAME-MAIN 1 SNA 650P/Others
10 JC97-03702D ADF FRAME-MAIN 1 SNA 650P/TED
10 JC97-03702E ADF FRAME-MAIN 1 SNA 650P/ETS
10 JC97-03702F ADF FRAME-MAIN 1 SNA 650P/STS
10 JC97-03705A ADF FRAME-MAIN 1 SNA 650/Others
10 JC97-03705D ADF FRAME-MAIN 1 SNA 650/TED
10 JC97-03705G ADF FRAME-MAIN 1 SNA 650/SEE
11 JC95-01131A COVER 1 SNA 650P
11 JC95-01132A COVER 1 SNA 650
12 - CARTRIDGE-TONER 1 SNA CRU
13 - CBF-POWER CORD 1 SA
Refer to power cord
Page 9
9
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
1
2
3
4
0
(SF-650P) (SF-650)
(SF-650P)
(SF-650)
2. COVER
Page 10
10
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
11
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
COVER Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC95-01131A COVER 1 SNA 650P
0 JC95-01132A COVER 1 SNA 650
1 JC95-01153A COVER-REAR 1 SA
2 JC95-01019H COVER-FRONT(650P) 1 SA 650P
Drawer# SEC_Code Description QT’y Service Remark
2 JC63-02480A COVER-FRONT(650) 1 SA 650
3 JC63-02392A COVER-LEFT 1 SNA
4 JC63-02393A COVER-RIGHT 1 SNA
5 JC63-02477A COVER-HARNESS 1 SNA
Page 11
11
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
0
2
3
1
4
5
4
6
5
5
(SF-650P)
(SF-650)
3. COVER FRONT
Page 12
12
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
13
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
COVER FRONT Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC95-01019H COVER-FRONT(650P) 1 SA 650P
0 JC63-02480A COVER-FRONT(650) 1 SA 650
1 JC95-01019H COVER-FRONT(650P) 1 SA Only_650P
2 JC70-00477G ADJUST-MENUAL_R 1 SA Only_650P
Drawer# SEC_Code Description QT’y Service Remark
3 JC70-00476G ADJUST-MENUAL_L 1 SA Only_650P
4 JC70-00304A ADJUST RACK-M-MANUAL 2 SA Only_650P
5 6003-000264 SCREW-TAPTYPE 3 SNA
6 JC66-00387A GEAR-RACK_PINION 1 SA Only_650P
Page 13
13
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
0
1
2
4. COVER REAR
Page 14
14
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
15
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
COVER REAR Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC95-01153A COVER-REAR 1 SA
1 JC63-02394A COVER-REAR 1 SNA
Drawer# SEC_Code Description QT’y Service Remark
2 JC63-02469A COVER-REAR DOWN 1 SA
Page 15
15
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
5. ADF FRAME-MAIN_650P
0
4
3
2
5
1
6
7
7
(SF-650P)
Page 16
16
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
17
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF FRAME-MAIN_650P Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03702A ADF FRAME-MAIN 1 SA 650P/Others
0 JC97-03702D ADF FRAME-MAIN 1 SA 650P/TED
0 JC97-03702E ADF FRAME-MAIN 1 SA 650P/ETS
0 JC97-03702F ADF FRAME-MAIN 1 SA 650P/STS
1 JC97-03703A ADF FRAME-LOWER 1 SNA
2 JC95-01130A COVER-TOP 1 SA
3 JB97-01207A MEA ETC-ROLLER WHITE 1 SA
Drawer# SEC_Code Description QT’y Service Remark
4 JC97-03704A ADF FRAME-UPPER 1 SA 650P/Others
4 JC97-03704D ADF FRAME-UPPER 1 SA 650P/TED
4 JC97-03704E ADF FRAME-UPPER 1 SA 650P/ETS
4 JC97-03704F ADF FRAME-UPPER 1 SA 650P/STS
5 4302-001183 BATTERY-NIH(2ND) 1 SA
6 JC63-02474A COVER-BACK 1 SA
7 6003-000196 SCREW-TAPTYPE 6 SA
Page 17
17
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
6. ADF FRAME-MAIN_650
0
4
3
2
5
1
6
7
7
(SF-650)
Page 18
18
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
19
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF FRAME-MAIN_650 Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03705A ADF FRAME-MAIN 1 SNA 650/Others
0 JC97-03705D ADF FRAME-MAIN 1 SNA 650/TED
0 JC97-03705G ADF FRAME-MAIN 1 SNA 650/SEE
1 JC97-03703A ADF FRAME-LOWER 1 SNA
2 JC95-01130A COVER-TOP 1 SA
3 JB97-01207A MEA ETC-ROLLER WHITE 1 SA
Drawer# SEC_Code Description QT’y Service Remark
4 JC97-03706A ADF FRAME-UPPER 1 SA 650/Others
4 JC97-03706D ADF FRAME-UPPER 1 SA 650/TED
4 JC97-03706G ADF FRAME-UPPER 1 SA 650/SEE
5 4302-001183 BATTERY-NIH(2ND) 1 SA
6 JC63-02474A COVER-BACK 1 SA
7 6003-000196 SCREW-TAPTYPE 6 SA
Page 19
19
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
7. COVER-TOP
0
(Top View)
(Bottom View)
1
1
2
4
3
5
6
7
Page 20
20
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
21
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
COVER-TOP Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC95-01130A COVER-TOP 1 SA
1 JC63-02471A COVER-TOP 1 SA
2 JC61-03501A GUIDE-DOC R 1 SA
3 JC61-03502A GUIDE-DOC L 1 SA
Drawer# SEC_Code Description QT’y Service Remark
4 JG66-40003A GEAR-PINION 1 SA
5 JC63-02472A TRAY-INPUT ADF 1 1 SA
6 JC63-02473A TRAY-INPUT ADF 2 1 SA
7 JC63-00944D COVER-M_STACKER_RX 1 SA
Page 21
21
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
8. ADF STACKER-TX
0
2
1
Page 22
22
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
23
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF STACKER-TX Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03707A ADF STACKER-TX 1 SA
1 JC63-02478A TRAY-OUTPUT ADF 1 1 SA
Drawer# SEC_Code Description QT’y Service Remark
2 JC63-02479A TRAY-OUTPUT ADF 2 1 SA
Page 23
23
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
9. HANDSET
0
4
2
1
3
5
Page 24
24
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
25
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
HANDSET Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC96-05367A ELA UNIT-HANDSET 1 SA
1 3009-001028 AUDIO-RECEIVER 1 SNA
2 6044-000138 RING-OP 1 SNA
Drawer# SEC_Code Description QT’y Service Remark
3 JB63-00145Q COVER-HANDSET LOWER 1 SNA
4 JB63-00189J COVER-HANDSET UPPER 1 SNA
5 JF73-40501A RMO-RUBBER MIC 1 SNA
Page 25
25
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
10. ADF FRAME-LOWER
8-1
8-2
0
(Top View)
(Bottom View)
6
2
3
5
5
4
22
7
1
1
9
16
12
13
15
17
11
14
10
8
14
19
20
21
18
Page 26
26
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
27
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF FRAME-LOWER Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03703A ADF FRAME-LOWER 1 SNA
1 6003-000196 SCREW-TAPTYPE 6 SA
2 0609-001360 CONTACT IMAGE SENSOR 1 SA
3 JB61-00137A GUIDE-M_CIS R 1 SA
4 JB61-00138A GUIDE-M_CIS L 1 SA
5 JB61-70938A SPRING ETC-CIS(ATLAS) 2 SA
6 JC39-01242A HARNESS-CIS_MAIN 1 SNA
7 JC93-00115A DRIVE ADF 1 SA
8 JB97-01620A MEA UNIT-ROLLER ADF 1 SA
9 JC66-00681A LINK-M_SCAN OPEN 1 SNA
10 JB66-00166A SHAFT-M_DRIVER ADF 1 SA
11 3001-002262 SPEAKER 1 SA
Drawer# SEC_Code Description QT’y Service Remark
12 JC92-02100A PBA-HOOK 1 SA
13 JC39-01245A HARNESS-HOOK_MAIN 1 SNA
14 JC61-03500A FRAME-SCAN LOWER 1 SA
15 JB61-00462A BUSH-M_WHITE L 1 SNA
16 JC64-00522A BUTTON-HOOK 1 SA
17 JC61-00022A SPRING ETC-HOOK 1 SNA
18 JC63-02470A COVER-EXIT 1 SA
19 JC61-03517A STACKER-BIN_FULL 1 SNA
20 JC72-01343A PMO-SUB_M_STACKER 1 SC
21 JC72-00387A PMO-BUSHING_F/DOWN 1 SA
22 JC39-01244A HARNESS-SCAN MOTOR_MAIN 1 SNA
Page 27
27
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
11. DRIVE-ADF
0
2
1
3
7
7
7
8
4
5
6
9
5
6
Page 28
28
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
29
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
DRIVE-ADF Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC93-00115A DRIVE ADF 1 SA
1 JC61-03505A BRACKET-TX 1 SA
2 JC31-00110D MOTOR STEP 1 SA
3 6003-000269 SCREW-TAPTYPE 1 SA
4 JB61-00140A GUIDE-M_SWING 1 SNA
Drawer# SEC_Code Description QT’y Service Remark
5 JB61-70922A SPRING ETC-CLUTCH 2 SA
6 JF72-41293A PMO-GEAR CLUTCH 2 SNA
7 JB66-00006A GEAR-IDLE 3 SNA
8 JB66-00005A GEAR-TRANS 1 SNA
9 JC66-02430A GEAR-DOUBLE(38/14) 1 SA
Page 29
29
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
12. ADF FRAME-UPPER_650P
0
(SF-650P)
6
1
2
3
5
4
20
7
17
8
16
17
14
15
11
13
13
10
12
9
18
19
Page 30
30
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
31
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF FRAME-UPPER_650P Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03704A ADF FRAME-UPPER 1 SA 650P/Others
0 JC97-03704D ADF FRAME-UPPER 1 SA 650P/TED
0 JC97-03704E ADF FRAME-UPPER 1 SA 650P/ETS
0 JC97-03704F ADF FRAME-UPPER 1 SA 650P/STS
1 JC63-02476A COVER-OPE 1 SA 650P/Others
1 JC63-02476D COVER-OPE 1 SA 650P/TED
1 JC63-02476E COVER-OPE 1 SA 650P/ETS
1 JC63-02476F COVER-OPE 1 SA 650P/STS
2 JC63-02508A SHEET-ONETOUCH 1 SA
3 JC68-02355A LABEL-ONE TOUCH 1 SA
4 JC67-00420A LENS-STATUS 1 SA
5 JC64-00526A KEY-RUBBER_CONTACT(650P) 1 SA
6 JC63-02475A COVER-LCD 1 SA
7 JC92-02202B PBA-OPE 1 SA
Drawer# SEC_Code Description QT’y Service Remark
8 JC61-03503A FRAME-UPPER 1 SA
9 JB61-00352A SUPPORT-M-ADF RIB 1 SNA
10 JG70-40514A ICT-SPRING COIL 1 SA
11 JB66-00168A LEVER-M_SENSOR DOC 1 SA
12 JB66-00169A LEVER-M_SENSOR SCAN 1 SA
13 JB61-00107A SPRING ETC-LEVER SENSOR 2 SA
14 JB73-00100A RUBBER-ADF 1 SA
15 JB61-00143A HOLDER-M_RUBBER 1 SA
16 JC67-00055A BRUSH-ANTISTATIC 531P 1 SA
17 6003-000196 SCREW-TAPTYPE 4 SA
18 6003-000282 SCREW-TAPTYPE 1 SNA
19 JC39-01246A HARNESS-GROUND 1 SNA
20 JC39-01243A HARNESS-OPE-MAIN 1 SNA
21 JC63-02483A SHEET-GUIDE_PAPER 2 SNA
Page 31
31
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
13. ADF FRAME-UPPER_650
0
(SF-650)
6
1
2
3
5
4
20
7
17
8
16
17
14
15
11
13
13
10
12
9
18
19
Page 32
32
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
33
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
ADF FRAME-UPPER_650 Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC97-03706A ADF FRAME-UPPER 1 SNA 650/Others
0 JC97-03706D ADF FRAME-UPPER 1 SNA 650/TED
JC97-03706G ADF FRAME-UPPER 1 SNA 650/SEE
1 JC63-02481A COVER-OPE(650) 1 SA 650/Others
1 JC63-02481D COVER-OPE 1 SA 650/TED
JC63-02481G COVER-OPE 1 SA 650/SEE
2 JC63-02508A SHEET-ONETOUCH 1 SA
3 JC68-02355A LABEL-ONE TOUCH 1 SA
4 JC67-00420A LENS-STATUS 1 SA
5 JC64-00527A KEY-RUBBER_CONTACT(650) 1 SNA
6 JC63-02475A COVER-LCD 1 SA
7 JC92-02202A PBA-OPE 1 SA
8 JC61-03503A FRAME-UPPER 1 SA
Drawer# SEC_Code Description QT’y Service Remark
9 JB61-00352A SUPPORT-M-ADF RIB 1 SNA
10 JG70-40514A ICT-SPRING COIL 1 SA
11 JB66-00168A LEVER-M_SENSOR DOC 1 SA
12 JB66-00169A LEVER-M_SENSOR SCAN 1 SA
13 JB61-00107A SPRING ETC-LEVER SENSOR 2 SA
14 JB73-00100A RUBBER-ADF 1 SA
15 JB61-00143A HOLDER-M_RUBBER 1 SA
16 JC67-00055A BRUSH-ANTISTATIC 531P 1 SA
17 6003-000196 SCREW-TAPTYPE 4 SA
18 6003-000282 SCREW-TAPTYPE 1 SNA
19 JC39-01246A HARNESS-GROUND 1 SNA
20 JC39-01243A HARNESS-OPE-MAIN 1 SNA
21 JC63-02483A SHEET-GUIDE_PAPER 2 SNA
Page 33
33
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
14. FRAME-LOWER 1
0
1
26
31
55
50
5
6
33
48
45
20
11
10
39
38
40
67
6
61
54
49
24
31
56
9
57
46
37
47
36
35
28
52
30
54
53
66
65
51
63-1
63-2
63-3
63-4
63
60
27
2
34
6
29
30
67-2
67-4
67-1
67-5
67-3
68-1
68-2
68-3
68
61-1
61-2
66-2
66-1
65-2
65-1
62-1
62-2
62-3
62-4
62
63
62
3
Page 34
34
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
35
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
FRAME-LOWER 2
64-1
64-2
0
58
24
22
19
4
3
13
69
16
32
42
Transfer Roller
23
7
8
18
51
41
64
21
25
15
44
59
17
43
51
Page 35
35
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
FRAME-LOWER Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC93-00114B FRAME-LOWER 1 SNA
1 0604-001393 PHOTO-INTERRUPTER 1 SA
2 6002-000308 SCREW-TAPTYPE 4 SNA
3 6003-000196 SCREW-TAPTYPE 29 SA
4 6003-000282 SCREW-TAPTYPE 2 SNA
5 6031-001051 WASHER-PLAIN 2 SNA
6 6044-000001 RING-CS 4 SA
7 6107-001162 SPRING-ETC 1 SA
8 6107-001370 SPRING-CS 1 SA
9 JC31-00087A FAN-DC 1 SA
10 JC33-00025B SOLENOID-MANUAL 1 SA
11 JC33-00026A SOLENOID-PICK UP 1 SA
12 JC39-01066A HARNESS-BINFULL 1 SA
13 JC39-01067A HARNESS-LSU 1 SA
14 JC39-01081A HARNESS-CRUM 1 SA
15 JC39-01083A HARNESS-STEP_MOTOR_CLUTCH 1 SA
16 JC61-00585A BUSH-M-FEED IDLE 2 SA
17 JC61-00587A BUSH-M-PICK_UP R 1 SA
18 JC61-00588A BUSH-M-TR L 1 SA
19 JC61-00594A GUIDE-M-TR RIB 1 SA
20 JC61-00602A BRACKET-P-FEED 1 SA
21 JC61-00604A PLATE-P-SAW 1 SA
22 JC61-00607A GUIDE-P-TR 1 SA
23 JC61-02468A BUSH-TR_L 1 SA
24 JC61-03322A FRAME-BASE 1 SNA
25 JC61-03440A BRACKET-BUSH_TR L 1 SA
26 JC61-03447A FRAME-HOLDER_LSU_L 1 SNA
27 JC61-03448A FRAME-HOLDER_LSU_R 1 SNA
28 JC61-03467A HOUSING-TERMINAL 1 SNA
29 JC61-03524A STOPPER-LEVER_DR 1 SA
30 JC61-40001A FOOT-ML80 2 SA
Drawer# SEC_Code Description QT’y Service Remark
31 JC61-70932A SPRING ETC-GUIDE DEVE 2 SA
32 JC61-70958A SPRING ETC-TR 2 SA
33 JC63-02411A GROUND-FUSER 1 SNA
34 JC65-00019A TERMINAL-CRUM 4 SA
35 JC65-00041A TERMINAL-SUPPLY 1 SA
36 JC65-00042A TERMINAL-CON 1 SA
37 JC65-00043A TERMINAL-CR 1 SA
38 JC66-00394A GEAR-FEED 2 1 SA
39 JC66-00396A GEAR-IDLE 23 1 SA
40 JC66-00398A SHAFT-FEED 1 SA
41 JC66-00526B ROLLER-REGI 1 SA
42 JC66-00527A SHAFT-FEED IDLE 1 SA
43 JC66-00598B ROLLER-FEED 1 SA
44 JC66-00720A SHAFT-P-CORE 2 SA
45 JC70-00308A IPR-P-GROUND_DRIVE 1 SNA
46 JC70-00311A IPR-P-GROUND_TR 1 SNA
47 JC70-00312A IPR-P-TERMINAL CON 1 SA
48 JC70-00335A IPR-P_GROUND_DRIVE2 1 SNA
49 JC70-00458A IPR-P-GROUND_GUIDE PAPER 1 SNA
50 JC72-00143A PMO-GEAR_EXIT_DRV16 2 SNA
51 JC72-00382B PMO-BUSHING FEED 7 SA
52 JC72-00974A PMO-ACTUATOR CVR OPEN 1 SA
53 JC72-00975A PMO-ACTUATOR EMPTY 1 SA
54 JC72-00983A PMO-LOCKER CST 2 SA
55 JC72-00984A PMO-PLATE GUIDE DEVE_L 1 SA
56 JC72-00985A PMO-PLATE GUIDE DEVE_R 1 SA
57 JC75-00049A MEC-TERMINAL 4 SA
58 JC93-00083B DRIVE MAIN-BRACKET 1 SA
59 JC93-00085A FRAME BASE-PICK UP 1 SA
60 JC93-00097B FRAME-ROLLER EXIT FACE DOWN 1 SA
61 JC93-00106A FRAME-LEFT STOPPER PICK UP 1 SA
Page 36
36
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
37
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
FRAME-LOWER Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
61-1 6107-001170 SPRING-TS 1 SA
61-2 JC66-00377A CAM-M-PICK_UP 1 SA
62 JC93-00107C FRAME-ROLLER DECURL 2 SA
62-1 JC61-01172A HOLDER-M-EXIT F/DOWN 1 SNA
62-2 JC66-02551A ROLLER-M-EXIT FR 1 SNA
62-3 JC66-00824A ROLLER-M-EXIT MAIN 1 SA
62-4 6107-002519 SPRING-CS 1 SA
63 JC93-00107D FRAME-ROLLER DECURL 2 SA
63-1 JC61-02702B HOLDER-EXIT ROLLER 1 SA
63-2 JC66-02551A ROLLER-M-EXIT FR 1 SNA
63-3 JC66-00824A ROLLER-M-EXIT MAIN 1 SA
63-4 6107-002519 SPRING-CS 1 SA
64 JC93-00108A FRAME-FRONT GUIDE PAPER 1 SA
64-1 JC61-00718A GUIDE-P-PAPER 1 SA
64-2 JC63-02483A SHEET-GUIDE_PAPER 1 SA
65 JC93-00109A FRAME-LOWER ACTUATOR MANUAL 1 SA
65-1 6107-001165 SPRING-TS 1 SA
Drawer# SEC_Code Description QT’y Service Remark
65-2 JC72-00977A PMO-ACTUATOR MANUAL 1 SA
66 JC93-00110A FRAME-LOWER ACTUATOR FEED 1 SA
66-1 6107-001164 SPRING-TS 1 SA
66-2 JC72-00976A PMO-ACTUATOR FEED 1 SA
67 JC97-01788A MEA UNIT-CLUTCH 1 SA
67-1 6107-001171 SPRING-TS 1 SA
67-2 JC66-00393A GEAR-FEED 1 1 SA
67-3 JC66-00398A SHAFT-FEED 1 SA
67-4 JC72-00978A PMO-COLLAR_SPRING 1 SA
67-5 JC72-00981A PMO-HUB CLUTCH 1 SNA
68 JC97-03141A MEA UNIT-GEAR_PICKUP 1 SA
68-1 6107-001167 SPRING-CS 1 SA
68-2 JC72-00979A PMO-GEAR PICK_UP A 1 SC
68-3 JC72-00980A PMO-GEAR PICK_UP B 1 SC
69 JC97-03585A LSU 1 SA
70 JC66-01218A ROLLER-TRANSFER 1 SA
Page 37
37
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
15. FRAME BASE-PICK UP
3-3
3-2
3-1
3
1
2
6
4
5
2
1
7
0
Page 38
38
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
39
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
FRAME BASE-PICK UP Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC93-00085A FRAME BASE-PICK UP 1 SA
1 JC61-03477A STOPPER-PICK_UP 2 SA
2 JC72-00982A PMO-IDLE PICK_UP 2 SA
3 JC93-00087A FRAME BASE-PICK UP RUBBER 1 SA
3-1 JC73-00315A RUBBER-PICK_UP 1 SA
3-2 JC61-03514A HOUSING-PICKUP_RUB 1 SA
Drawer# SEC_Code Description QT’y Service Remark
3-3 JC61-03435A HOUSING-PICKUP 1 SA
4 JC61-03485A HOLDER-PICKUP 1 SA
5 6003-000264 SCREW-TAPTYPE 1 SNA
6 JC66-00399A SHAFT-P-PICK_UP 1 SA
7 JC61-00586A BUSH-M-PICK_UP L 1 SNA
Page 39
39
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
16. DRIVE MAIN-BRACKET
0
12
1
6
13
6
13
5
8
7
9
10
11
13
4
12
2
3
Page 40
40
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
41
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
DRIVE MAIN-BRACKET Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC93-00083B DRIVE MAIN-BRACKET 1 SA
1 JC61-00598B BRACKET-P-GEAR 1400 1 SC
2 JC31-00028D MOTOR STEP 1 SA
3 JC72-00825A PMO-IMPELLER_DRV 1 SA
4 JC61-03395A BRACKET-MOTOR_STEP 1 SA
5 JC66-02316A GEAR-RDCN_OPC 1 SA
6 JC66-00389A GEAR-RDCN 57/18 2 SA
Drawer# SEC_Code Description QT’y Service Remark
7 JC66-00392A GEAR-RDCN 90/31 1 SA
8 JC66-00390A GEAR-RDCN 103/41 1 SA
9 JC66-01203A GEAR-DRV FUSER OUT 1 SA
10 JC66-00340A GEAR-HUB CLUTCH 1 SA
11 JC66-01202A GEAR-DRV FUSER IN 1 SA
12 6003-000269 SCREW-TAPTYPE 5 SA
13 6031-000023 WASHER-PLAIN 3 SA
Page 41
41
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
17. FUSER
0
23
20
14
19
24
25
12
4
11
6
31
40
3
10
7
45
5
44
43
4
41
4
13
35
28
36
27
17
33
18
32
15
34
22
21
16
37
26
29
39
30
3
3
38
8
9
42
Page 42
42
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog -SF-650/650P
Samsung Electronics Service Manual
43
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
FUSER Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Drawer# SEC_Code Description QT’y Service Remark
0 JC91-00946A FUSER_110V 1 SA 650_650P/XAA
0 JC91-00946B FUSER_110V 1 SA 650_650P/TED
0 JC91-00945A FUSER_220V 1 SA Others
0 JC91-00945B FUSER_220V 1 SA 650P/XSS
3 6003-000269 SCREW-TAPTYPE 5 SA
4 6003-000282 SCREW-TAPTYPE 2 SNA
5 6006-001078 SCREW-TAPTYPE 1 SNA
6 6003-000196 SCREW-TAPTYPE 1 SA
7 6031-001051 WASHER-PLAIN 1 SNA
8 6031-001584 WASHER-PLAIN 2 SA
9 6044-000159 RING-C 2 SA
10 6044-000001 RING-CS 1 SA
11 1404-001447 THERMISTOR-NTC ASSY 1 SA
12 4712-001031 THERMOSTAT 1 SA
13 4713-001211 LAMP-HALOGEN 1 SA 110V
13 4713-001212 LAMP-HALOGEN 1 SA 220V
14 6107-001800 SPRING-TS 4 SA
15 6107-001802 SPRING-ES 2 SA
16 6107-001165 SPRING-TS 1 SA
17 JC73-00017A RMO-RUBBER_EXIT 4 SA
18 JC72-00382A PMO-BUSHING TX 3 SNA
19 JC61-03685A GUIDE-CLAW 4 SA
20 JC61-70976A SPRING ETC-FUSER EXIT 4 SA
21 JC61-00056A SPRING ETC-PR(7300) 2 SA
22 JC61-03473A BUSH-PR HIGH 2 SNA
Drawer# SEC_Code Description QT’y Service Remark
23 JC72-40361A PMO-ROLLER_EXIT 4 SA
24 JC39-01160A HARNESS-FUSER JOINT 1 SA
25 JC39-01082A HARNESS-FUSER AC 1 SA
26 JC61-00581A HOLDER-ACTUATOR 1 SA
27 JC61-00887A BUSH-M-HR R_R2 1 SA
28 JC61-00888A BUSH-M-HR L_R2 1 SA
29 JC61-03449A FRAME-FUSER 1 SNA
30 JC61-03450A GUIDE-INPUT 1 SA
31 JC63-02412A COVER-FUSER 1 SNA
32 JC63-02413A COVER-FUSER DUMMY 1 SNA
33 JC66-00380A ROLLER-M-EXIT F/UP 1 SA
34 JC66-00600A ROLLER-PRESSURE 1 SA 650_650P/Others
34 JC66-00600B ROLLER-PRESSURE 1 SA
35 JC66-01254A GEAR-FUSER 1 SA
36 JC66-01256A ROLLER-HEAT 1 SA 650_650P/Others
36 JC66-01256B ROLLER-HEAT 1 SA
37 JC66-02364A ACTUATOR-EXIT 1 SA
38 JC66-02365A LEVER-LINK JAM L 1 SA
39 JC66-02366A LEVER-LINK JAM R 1 SA
40 JC67-00414A CAP-FUSER LAMP R 1 SA
41 JC67-00415A CAP-FUSER LAMP L 1 SA
42 - LABEL-CAUTION 1 SNA
43 JC72-00143A PMO-GEAR_EXIT_DRV16 1 SNA
44 JC66-02317A GEAR-RDCN_EXIT 1 SA
45 JC66-00396A GEAR-IDLE 23 1 SA
650_650P/TED/XSS
650_650P/TED/XSS
Page 43
43
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
Parts Catalog - SF-650/650P
Samsung Electronics Service Manual
18. CASSETTE
0
5
4
6
7
8
9
10
10
11
11-1
11-2
11-3
12
13
14
15
2
3
1
16
17
18
19
20
21
22
Page 44
CASSETTE Parts List
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Samsung Electronics Service Manual
Samsung Electronics Service Manual
Drawer# SEC_Code Description QT’y Service Remark
0 JC90-00939B CASSETTE 1 SA
1 JC61-03343A FRAME-CASSETTE 1 SNA
2 JC61-03341B GUIDE-EXTENSION CST 1 SNA
3 JC72-00971A PMO-EXTENSION SMALL 1 SA
4 JC70-00300A ADJUST-M-CASSETTE_L 1 SA
5 JC70-00301A ADJUST-M-CASSETTE_R 1 SA
6 JC73-00141A RPR-PAD CASSETTE 1 SA
Parts Catalog -SF-650/650P
7 JC61-00603A PLATE-P-KNOCK_UP 1 SNA
8 JC66-00719A CAM-M-KNOCK UP 1 SA
9 6003-000261 SCREW-TAPTYPE 1 SNA
10 6107-001166 SPRING-CS 2 SA
11 JC90-00941A CASSETTE-HOLDER PAD 1 SA
11-1 JC63-02592A SHEET-HOLDER PAD 1 SA
Drawer# SEC_Code Description QT’y Service Remark
11-2 JC73-00140A RPR-FRICTION PAD 1 SA
11-3 JC61-03344A HOLDER-PAD 1 SA
12 JC61-01978A HOUSING-HOLDER PAD 1 SA
13 JC61-70911A SPRING ETC-EXIT ROLL FD 1 SA
14 JC66-00529A ROLLER-M-IDLE FEED 2 SA
15 6107-001047 SPRING-ES 2 SA
16 JC63-02341B COVER-CASSETTE 1 SNA
17 6003-000196 SCREW-TAPTYPE 2 SA
18 JG66-40003A GEAR-PINION 1 SA
19 6003-000264 SCREW-TAPTYPE 1 SNA
20 JC72-00972A PMO-PLATE_LOCKER 1 SA
21 JG61-70531A SPRING ETC-LOCKER,PLATE 1 SA
22 JC72-40981A PMO-ROLLER UPPER DP 2 SA
Parts Catalog - SF-650/650P
44
Loading...
