6. Electrical Parts Lists
6-1. MAIN PBA
6-1-1. SF3000 MAIN PBA
Ref. No. Description SEC. Code Remark
ASSEMBLY, MAIN PBA, SF3000 JG92-01035A
- Capacitors -
C1 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C2 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C3 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C4 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C5 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C6 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C7 C-CERMIC, CHIP, 68 pF, 5 %, 50 V 2003-001158
C8 C-CERMIC, CHIP, 15 pF, 5 %, 50 V 2003-001517
C9 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C10 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C11 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C12 C-CERMIC, CHIP, 120 pF, 5 %, 50 V 2003-000316
C13 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C14 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C16 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C17 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C18 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C19 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C20 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C21 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
C22 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C23 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C25 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C26 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C27 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C28 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C29 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C30 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C31 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C32 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C33 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C34 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
Samsung Electronics 6-1
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
C35 C-CERMIC, CHIP, 68 nF, 10 %, 25 V 2003-001142
C37 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C38 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C39 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C40 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C41 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C42 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C43 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C44 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C45 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C46 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C47 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C49 C-CERMIC, CHIP, 4.7 nF, 10 %, 50 V 2003-000891
C50 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C54 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C55 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C56 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C57 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C58 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C59 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C60 C-CERMIC, CHIP, 18 pF, 5 %, 50 V 2003-000429
C61 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C63 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C64 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C65 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C67 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C68 C-CERMIC, CHIP, 10 nF, 10 %, 50 V 2003-000260
C73 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C74 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C75 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C76 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C77 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C78 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C79 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C80 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C81 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C82 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C83 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C85 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
6-2 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
C86 C-CERMIC, CHIP, 27 pF, 5 %, 50 V 2003-000683
C87 C-CERMIC, CHIP, 27 pF, 5 %, 50 V 2003-000683
C96 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C97 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C99 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C98 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C100 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C102 C-AL, 47 µF, 20 %, 16 V 2401-000031
C103 C-TA, CHIP, 1 µF, 20 %, 10 V 2404-000291
C104 C-AL, 100 µF, 20 %, 16 V 2401-000042
C105 C-AL, 22 µF, 20 %, 16 V 2401-000913
C106 C-TA, CHIP, 10 µF, 20 %, 6.3 V 2404-000141
C107 C-AL, 47 µF, 20 %, 16 V 2401-000031
C108 C-AL, 47 µF, 20 %, 16 V 2401-000031
C109 C-AL, 1000 µF, 20 %, 35 V 2401-000172
C110 C-AL, 10 µF, 20 %, 16 V 2401-000414
C111 C-AL, 22 µF, 20 %, 16 V 2401-000913
C113 C-TA, CHIP, 470 nF, 20 %, 16 V 2404-000312
C116 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C117 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C118 C-AL, 100 µF, 20 %, 16 V 2401-000042
C119 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C120 C-CERMIC, CHIP, 15 pF, 5 %, 50 V 2003-001517
C122 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C123 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C124 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C125 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C126 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C127 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C128 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C129 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C130 C-CERMIC, CHIP, 220 nF, +80-20 %, 25 V 2003-000563
C131 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C133 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C134 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
- Diodes -
D1 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D3 DIODE-RECTIFIER, 1N4002, 100 V, 1 A 0402-000371
D4 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
Samsung Electronics 6-3
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
D5 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
D6 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
D8 DIODE-ARRAY, DAP202K, 80 V, 100mA 0407-000116
D9 DIODE-ARRAY, DAP202K, 80 V, 100mA 0407-000116
ZD4 DIODE-ZENER, PTZ5.1B, 5.1B, 5.1 V 0403-000464
ZD5 DIODE-ZENER, MMBZ5249BL, 5 %, 225 mW 0403-000286
- ICs -
U1 IC ASIC-JUPITER 2, MJ-715S, KS32C6500, 160 P JB13-10503B
U2 IC-ASIC-IMAGE CHIP, STOA7110, QFP, 238 P JG13-10062A
U3 IC-MODEM, KS16117Q, QFP, 100 P 1205-001134
U4 IC-OP AMP, 82, SOP, 8 P 1201-000178
U5 IC-DRAM, 416C256, 256K x 16BIT, 40 P 1105-001029
U6 IC-DRAM, 416C256, 256K x 16BIT, 40 P 1105-001029
U9 IC-SRAM, 68257, 32K x 8BIT, 28 P 1106-001012
U11 IC-DECODER, A5817SEP, QFP, 44 P 1204-000359
U12 IC-DECODER, A5817SEP, QFP, 44 P 1204-000359
U13 IC-OP AMP, 358, SOP, 8 P 1201-000167
U14 IC-MOTOR DRIVER, PBL3717A, DIP, 16 P 1003-000243
U15 IC-MOTOR DRIVER, PBL3717A, DIP, 16 P 1003-000243
U19 FREQ-ATTENUATOR, 5-8 MHz, 15dB, 0.03 W 4701-001020
U20 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U21 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U22 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U23 IC-AUDIO AMP, 386, SOP, 8 P 1201-000114
U24 IC-ANALOG SWITCH, MC14053BD, 16 P 1001-000171
U26 IC-ANALOG SWITCH, MC14051BD, 16 P 1001-000170
U27 TR-ARRAY, ULN2003L, NPN, 1 W 0506-000182
U28 IC-EPROM. 27C240, 256K x 16 BIT, DIP, 40 P 1102-001051
U28 SOCKET-IC, 40 P, DIP 3704-000275 SOCKET
U30 IC-SRAM, 62256B, 32K x 8BIT, 28 P 1106-000197
U31 PHOTO-INTERRUPTER, TR, 150 mW 0604-001033
U32 IC-CMOS LOGIC, 74HC00, NAND GATE, 14 P 0801-000379
U33 IC-RESET, 7045, T0-92, 3 P 1203-000495
U128 TR-ARRA, STA471A, NPN, 4 W 0506-001019
- Resistors -
R2 R-CHIP, 1.5 Kohm, 5 %, 1/10 W 2007-000241
R4 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R5 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R6 R-CHIP, 86.6 Kohm, 1 %, 1/10 W 2007-001220
6-4 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R7 R-CHIP, 150 Kohm, 5 %, 1/10 W 2007-000395
R8 R-CHIP, 118 Kohm, 1 %, 1/10 W 2007-000325
R10 R-CHIP, 620 ohm, 5 %, 1/10 W 2007-001092
R11 R-CHIP, 82 Kohm, 5 %, 1/10 W 2007-001208
R12 R-CHIP, 150 Kohm, 5 %, 1/10 W 2007-000395
R13 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R14 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R15 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R16 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R20 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R21 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R22 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R23 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
R24 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R25 R-CHIP, 330 ohm, 5 %, 1/10 W 2007-000766
R26 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R27 R-CHIP, 47.5 Kohm, 1 %, 1/10 W 2007-000920
R28 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R29 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R30 R-CHIP, 17.4 Kohm, 1 %, 1/10 W 2007-000435
R31 R-CHIP, 86.6 Kohm, 1 %, 1/10 W 2007-001220
R32 R-CHIP, 51 Kohm, 5 %, 1/10 W 2007-001009
R33 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R34 R-CHIP, 24 Kohm, 5 %, 1/10 W 2007-000615
R35 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R36 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R40 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R41 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R42 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R43 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R45 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R46 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R47 R-CHIP, 2 Kohm, 5 %, 1/10 W 2007-000671
R48 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R50 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R51 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R52 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R53 R-CHIP, 7.5 Kohm, 5 %, 1/10 W 2007-001141
R54 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
Samsung Electronics 6-5
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R55 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R56 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R59 R-CHIP, 10 ohm, 5 %, 1/10 W 2007-000308
R68 R-CHIP, 820 ohm, 5 %, 1/10 W 2007-001201
R69 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R70 R-CHIP, 15 Kohm, 5 %, 1/10 W 2007-000409
R71 R-CHIP, 24 Kohm, 5 %, 1/10 W 2007-000615
R72 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R73 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R74 R-CHIP, 10 Mohm, 5 %, 1/10 W 2007-000304
R78 R-CHIP, 3.6 Kohm, 5 %, 1/10 W 2007-000703
R79 R-CHIP, 3.6 Kohm, 5 %, 1/10 W 2007-000703
R83 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R84 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R85 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R86 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R87 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R88 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R89 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R90 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R91 R-CHIP, 10 Mohm, 5 %, 1/10 W 2007-000304
R92 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R94 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R95 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R96 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R97 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R98 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R99 R-CHIP, 56 Kohm, 5 %, 1/10 W 2007-001039
R100 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R101 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R105 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R106 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R107 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R108 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R109 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R110 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R111 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R112 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R114 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
6-6 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R121 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R122 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R123 R-CHIP, 1.2 Kohm, 5 %, 1/10 W 2007-000221
R124 R-CHIP, 56 Kohm, 5 %, 1/10 W 2007-001039
R125 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R126 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R127 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R128 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R129 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R131 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R132 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R135 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
R136 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R138 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R145 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R146 R-CHIP, 39 ohm, 5 %, 1/10 W 2007-000028
R147 R-CHIP, 39 ohm, 5 %, 1/10 W 2007-000028
R148 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R149 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R152 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R153 R-CHIP, 2 Kohm, 5 %, 1/10 W 2007-000671
R155 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R156 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R157 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R158 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R159 R-CHIP, 20 ohm, 5 %, 1/4 W 2007-001289
R160 R-CARBON, 0.5 ohm, 5 %, 1/2 W 2001-000202
R161 R-CHIP, 100 Kohm, 5 %, 1/10 W 2007-000282
R162 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R163 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R166 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R167 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R168 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R169 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R172 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
- Transistors -
Q2 TR-SMALL SIGNAL, KSC5019-MTA, NPN, 750 mW 0501-000342
Q3 TR-SMALL SIGNAL, KSC1623-Y, NPN, 200 mW 0501-000342
Q6 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
Samsung Electronics 6-7
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
Q7 TR-DARLINGTON, TIP127, PNP, 2 W 0503-000134
Q8 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
Q9 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
- Micellanceous -
BT1 BATTERY-LI, 3 V, 220 mAH 4301-000108
L1 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L3 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L5 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L6 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L7 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L8 INDUCTOR-SMD, 10 µH, 10 %, 1.25 x 2 x 1.25 mm 2703-000125
L9 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
P1 CONNECTOR-HEADER, 3 WALL, 13 P 3711-000417
P2 CONNECTOR-HEADER, 3 WALL, 3 P 3711-000452
P3 CONNECTOR-HEADER, 1 WALL, 6 P 3711-000280
P4 CONNECTOR-HEADER, 3 WALL, 5 P 3711-000484
P5 CONNECTOR-HEADER, 3 WALL, 10 P 3711-000398
P6 CONNECTOR-FPC/FC/PIC, 30 P, 1.0 mm 3708-001058
P7 CONNECTOR-HEADER, 3 WALL, 6 P 3711-000496
P8 CONNECTOR-HEADER, BOX, 3 P 3711-000907 WHITE
P9 CONNECTOR-HEADER, BOX, 6 P 3711-001062 WHITE
P10 CONNECTOR-HEADER, 3 WALL, 2 P 3711-000443
P11 CONNECTOR-FPC/FC/PIC, 30 P, 1.0 mm 3708-001058
P12 CONNECTOR-HEADER, 1 WALL, 4 P 3711-000225
PCB PCB-MAIN JG41-10124A
RA1 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA2 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA3 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA4 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA5 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA6 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA7 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA8 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA9 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA10 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA11 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA12 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
X1 CRYSTAL-UNIT, 30 MHz, 50 ppm 2801-003582
X2 CRYSTAL-UNIT, 38.00053 MHz, 15 ppm 2801-003330
6-8 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
X4 CRYSTAL-UNIT, 32.768 KHz, 5 ppm 2801-001498
6-1-2. SF3000T MAIN PBA
Ref. No. Description SEC. Code Remark
ASSEMBLY, MAIN PBA, SF3000T JG92-01035B
- Capacitors -
C1 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C2 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C3 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C4 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C5 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C6 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C7 C-CERMIC, CHIP, 68 pF, 5 %, 50 V 2003-001158
C8 C-CERMIC, CHIP, 15 pF, 5 %, 50 V 2003-001517
C9 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C10 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C11 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C12 C-CERMIC, CHIP, 120 pF, 5 %, 50 V 2003-000316
C13 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C14 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C15 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C16 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C17 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C18 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C19 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C20 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C21 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
C22 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C23 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C24 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C25 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C26 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C27 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C28 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C29 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C30 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C31 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C32 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
Samsung Electronics 6-9
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
C33 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C34 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C35 C-CERMIC, CHIP, 68 nF, 10 %, 25 V 2003-001142
C36 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C37 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C38 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C39 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C40 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C41 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C42 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C43 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C44 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C45 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C46 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C47 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C48 C-CERMIC, CHIP, 470 pF, 5 %, 50 V 2003-000953
C49 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C50 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C51 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C52 C-CERMIC, CHIP, 10 nF, 10 %, 50 V 2003-000260
C53 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C54 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C55 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C56 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C57 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C58 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C59 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C60 C-CERMIC, CHIP, 18 pF, 5 %, 50 V 2003-000429
C61 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C62 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C63 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C64 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C65 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C66 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C67 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C68 C-CERMIC, CHIP, 10 nF, 10 %, 50 V 2003-000260
C69 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C70 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C71 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
6-10 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
C72 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C73 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C74 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C75 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C76 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C77 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C78 C-CERMIC, CHIP, 560 pF, 5 %, 50 V 2003-001058
C79 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C80 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C81 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C82 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C83 C-CERMIC, CHIP, 820 pF, 10 %, 50 V 2003-000009
C84 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C85 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C86 C-CERMIC, CHIP, 27 pF, 5 %, 50 V 2003-000683
C87 C-CERMIC, CHIP, 27 pF, 5 %, 50 V 2003-000683
C88 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C89 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C90 C-CERMIC, CHIP, 47 nF, 10 %, 50 V 2003-000979
C91 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C92 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C93 C-CERMIC, CHIP, 10 pF, 5 %, 50 V 2003-000295
C94 C-CERMIC, CHIP, 1 nF, 10 %, 50 V 2003-000444
C95 C-CERMIC, CHIP, 10 pF, 5 %, 50 V 2003-000295
C96 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C97 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C98 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C99 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C100 C-CERMIC, CHIP, 22 pF, 5 %, 50 V 2003-000634
C102 C-AL, 47 µF, 20 %, 16 V 2401-000031
C103 C-TA, CHIP, 1 µF, 20 %, 10 V 2404-000291
C104 C-AL, 100 µF, 20 %, 16 V 2401-000042
C105 C-AL, 22 µF, 20 %, 16 V 2401-000913
C106 C-TA, CHIP, 10 µF, 20 %, 6.3 V 2404-000141
C107 C-AL, 47 µF, 20 %, 16 V 2401-000031
C108 C-AL, 47 µF, 20 %, 16 V 2401-000031
C109 C-AL, 1000 µF, 20 %, 35 V 2401-000172
C110 C-AL, 10 µF, 20 %, 16 V 2401-000414
C111 C-AL, 22 µF, 20 %, 16 V 2401-000913
Samsung Electronics 6-11
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
C112 C-TA, CHIP, 1 µF, 20 %, 10 V 2404-000291
C113 C-TA, CHIP, 470 nF, 20 %, 16 V 2404-000312
C114 C-TA, CHIP, 10 µF, 20 %, 6.3 V 2404-000141
C115 C-TA, CHIP, 10 µF, 20 %, 6.3 V 2404-000141
C116 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C117 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C118 C-AL, 100 µF, 20 %, 16 V 2401-000042
C119 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C120 C-CERMIC, CHIP, 15 pF, 5 %, 50 V 2003-001517
C122 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C123 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C124 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C125 C-CERMIC, CHIP, 100 nF, 79.8, 50 V 2003-000192
C126 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C127 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C128 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C129 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C130 C-CERMIC, CHIP, 220 nF, +80-20 %, 25 V 2003-000563
C131 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C133 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
C134 C-CERMIC, CHIP, 100 pF, 5 %, 50 V 2003-000239
- Diodes -
D1 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D2 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D3 DIODE-RECTIFIER, 1N4002, 100 V, 1 A 0402-000371
D4 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
D5 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
D6 DIODE-SCHOTTKY, RB420D, 25 V, 100 mA 0404-000112
D7 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D8 DIODE-ARRAY, DAP202K, 80 V, 100mA 0407-000116
D9 DIODE-ARRAY, DAP202K, 80 V, 100mA 0407-000116
D10 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
ZD1 DIODE-ZENER, PTZ5.1B, 5.1B, 5.1 V 0403-000464
ZD2 DIODE-ZENER, PTZ12B, 120-135 V 0403-001142
ZD3 DIODE-ZENER, PTZ12B, 120-135 V 0403-001142
ZD4 DIODE-ZENER, PTZ5.1B, 5.1B, 5.1 V 0403-000464
ZD5 DIODE-ZENER, MMBZ5249BL, 5 %, 225 mW 0403-000286
- ICs -
U2 IC-ASIC-IMAGE CHIP, STOA7110, QFP, 238 P JG13-10062A
6-12 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
U3 IC-MODEM, KS16117Q, QFP, 100 P 1205-001134
U4 IC-OP AMP, 82, SOP, 8 P 1201-000178
U5 IC-DRAM, 416C256, 256K x 16BIT, 40 P 1105-001029
U6 IC-DRAM, 416C256, 256K x 16BIT, 40 P 1105-001029
U7 IC-DSP, 6305, 16BIT, 80 P 0904-001068
U8 IC-CMOS LOGIC, 74HC245, 20 P 0801-000696
U9 IC-SRAM, 68257, 32K x 8BIT, 28 P 1106-001012
U10 IC-DRAM, 44C1000, 1M x 4BIT, 20 P 1105-000133
U11 IC-DECODER, A5817SEP, QFP, 44 P 1204-000359
U12 IC-DECODER, A5817SEP, QFP, 44 P 1204-000359
U13 IC-OP AMP, 358, SOP, 8 P 1201-000167
U14 IC-MOTOR DRIVER, PBL3717A, DIP, 16 P 1003-000243
U15 IC-MOTOR DRIVER, PBL3717A, DIP, 16 P 1003-000243
U16 IC-VOLTAGE COMP, 393, 8 P 1202-000164
U17 IC-CMOS LOGIC, 7S32, 5 P 0801-000795
U18 IC-VOLTAGE REGULATOR, 78L05, 3 P 1203-001037
U19 FREQ-ATTENUATOR, 5-8 MHz, 15dB, 0.03 W 4701-001020
U20 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U21 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U22 IC-OP AMP, 4558, SOP, 8 P 1201-000189
U23 IC-AUDIO AMP, 386, SOP, 8 P 1201-000114
U24 IC-ANALOG SWITCH, MC14053BD, 16 P 1001-000171
U25 IC-ANALOG SWITCH, MC14053BD, 16 P 1001-000171
U26 IC-ANALOG SWITCH, MC14051BD, 16 P 1001-000170
U27 TR-ARRAY, ULN2003L, NPN, 1 W 0506-000182
U28 IC-EPROM. 27C240, 256K x 16 BIT, DIP, 40 P 1102-001051
U28 SOCKET-IC, 40 P, DIP 3704-000275 SOCKET
U29 IC-CODEC, TP3054J, 16 P 1205-000120
U30 IC-SRAM, 62256B, 32K x 8BIT, 28 P 1106-000197
U31 PHOTO-INTERRUPTER, TR, 150 mW 0604-001033
U32 IC-CMOS LOGIC, 74HC00, NAND GATE, 14 P 0801-000379
U33 IC-RESET, 7045, T0-92, 3 P 1203-000495
U34 IC-CMOS LOGIC, 7S32, 5 P 0801-000795
U128 TR-ARRA, STA471A, NPN, 4 W 0506-001019
- Resistors -
R2 R-CHIP, 1.5 Kohm, 5 %, 1/10 W 2007-000241
R3 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R4 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R5 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
Samsung Electronics 6-13
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R6 R-CHIP, 86.6 Kohm, 1 %, 1/10 W 2007-001220
R7 R-CHIP, 150 Kohm, 5 %, 1/10 W 2007-000395
R8 R-CHIP, 118 Kohm, 1 %, 1/10 W 2007-000325
R9 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R10 R-CHIP, 620 ohm, 5 %, 1/10 W 2007-001092
R11 R-CHIP, 82 Kohm, 5 %, 1/10 W 2007-001208
R12 R-CHIP, 150 Kohm, 5 %, 1/10 W 2007-000395
R13 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R14 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R15 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R16 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R20 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R21 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R22 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R23 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
R24 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R25 R-CHIP, 330 ohm, 5 %, 1/10 W 2007-000766
R26 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R27 R-CHIP, 47.5 Kohm, 1 %, 1/10 W 2007-000920
R28 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R29 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R30 R-CHIP, 17.4 Kohm, 1 %, 1/10 W 2007-000435
R31 R-CHIP, 86.6 Kohm, 1 %, 1/10 W 2007-001220
R32 R-CHIP, 51 Kohm, 5 %, 1/10 W 2007-001009
R33 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R34 R-CHIP, 24 Kohm, 5 %, 1/10 W 2007-000615
R35 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R36 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R40 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R41 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R42 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R43 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R45 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R46 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R47 R-CHIP, 2 Kohm, 5 %, 1/10 W 2007-000671
R48 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R50 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R51 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R52 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
6-14 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R53 R-CHIP, 7.5 Kohm, 5 %, 1/10 W 2007-001141
R54 R-CHIP, 3 Kohm, 5 %, 1/10 W 2007-000844
R55 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R56 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R57 R-CHIP, 68 Kohm, 5 %, 1/10 W 2007-000001
R58 R-CHIP, 100 Kohm, 5 %, 1/10 W 2007-000282
R59 R-CHIP, 10 ohm, 5 %, 1/10 W 2007-000308
R60 R-CHIP, 3.9 Kohm, 5 %, 1/10 W 2007-000710
R61 R-CHIP, 33 Kohm, 5 %, 1/10 W 2007-000774
R62 R-CHIP, 2.2 Kohm, 5 %, 1/10 W 2007-000493
R63 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R64 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R65 R-CHIP, 15 Kohm, 5 %, 1/10 W 2007-000409
R66 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R67 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R68 R-CHIP, 820 ohm, 5 %, 1/10 W 2007-001201
R69 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R70 R-CHIP, 15 Kohm, 5 %, 1/10 W 2007-000409
R71 R-CHIP, 30 Kohm, 5 %, 1/10 W 2007-000738
R72 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R73 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R74 R-CHIP, 10 Mohm, 5 %, 1/10 W 2007-000304
R75 R-CHIP, 12 Kohm, 5 %, 1/10 W 2007-000355
R76 R-CHIP, 12 Kohm, 5 %, 1/10 W 2007-000355
R77 R-CHIP, 2.2 Kohm, 5 %, 1/10 W 2007-000493
R78 R-CHIP, 3.6 Kohm, 5 %, 1/10 W 2007-000703
R79 R-CHIP, 3.6 Kohm, 5 %, 1/10 W 2007-000703
R80 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R81 R-CHIP, 100 Kohm, 5 %, 1/10 W 2007-000282
R82 R-CHIP, 100 Kohm, 5 %, 1/10 W 2007-000282
R83 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R84 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R85 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R86 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R87 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R88 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R89 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R90 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R91 R-CHIP, 10 Mohm, 5 %, 1/10 W 2007-000304
Samsung Electronics 6-15
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R92 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R93 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R94 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R95 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R96 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R97 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R98 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R99 R-CHIP, 56 Kohm, 5 %, 1/10 W 2007-001039
R100 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R101 R-CHIP, 300 ohm, 5 %, 1/10 W 2007-000728
R102 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R103 R-CHIP, 3.3 Kohm, 5 %, 1/10 W 2007-000686
R104 R-CHIP, 1.5 Kohm, 5 %, 1/10 W 2007-000241
R105 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R106 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R107 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R108 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R109 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R110 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R111 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R112 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R114 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R115 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R116 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R117 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R118 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R119 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R120 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R121 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R122 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R123 R-CHIP, 1.2 Kohm, 5 %, 1/10 W 2007-000221
R124 R-CHIP, 56 Kohm, 5 %, 1/10 W 2007-001039
R125 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R126 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R127 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R128 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R129 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R131 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R132 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
6-16 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R135 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
R136 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R138 R-CHIP, 47 Kohm, 5 %, 1/10 W 2007-000941
R139 R-CHIP, 680 Kohm, 5 %, 1/10 W 2007-001113
R140 R-CHIP, 680 Kohm, 5 %, 1/10 W 2007-001113
R141 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R142 R-CHIP, 82 Kohm, 5 %, 1/10 W 2007-001208
R143 R-CHIP, 1 Mohm, 5 %, 1/10 W 2007-000477
R144 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R145 R-CHIP, 5.1 Kohm, 5 %, 1/10 W 2007-000964
R146 R-CHIP, 39 ohm, 5 %, 1/10 W 2007-000028
R147 R-CHIP, 39 ohm, 5 %, 1/10 W 2007-000028
R148 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R149 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R150 R-CHIP, 100 ohm, 5 %, 1/10 W 2007-000290
R152 R-CHIP, 150 ohm, 5 %, 1/10 W 2007-000401
R153 R-CHIP, 2 Kohm, 5 %, 1/10 W 2007-000671
R154 R-CARBON, 0.5 ohm, 5 %, 1/2 W 2001-000202
R155 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R156 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R157 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R158 R-CHIP, 22.1 ohm, 1 %, 1/2 W 2008-000177
R159 R-CHIP, 20 ohm, 5 %, 1/4 W 2007-001289
R160 R-CARBON, 0.5 ohm, 5 %, 1/2 W 2001-000202
R161 R-CHIP, 100 Kohm, 5 %, 1/10 W 2007-000282
R162 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R163 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R164 R-CHIP, 300 Kohm, 5 %, 1/10 W 2007-000027
R165 R-CHIP, 300 Kohm, 5 %, 1/10 W 2007-000027
R166 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R167 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R168 R-CHIP, 1 Kohm, 5 %, 1/10 W 2007-000468
R169 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R170 R-CHIP, 12 Kohm, 5 %, 1/10 W 2007-000355
R171 R-CHIP, 12 Kohm, 5 %, 1/10 W 2007-000355
- Transistors -
Q1 TR-SMALL SIGNAL, KSA1182-Y, PNP, 150 mW 0501-000279
Q2 TR-SMALL SIGNAL, KSC5019-MTA, NPN, 750 mW 0501-000385
Q3 TR-SMALL SIGNAL, KSC1623-Y, NPN, 200 mW 0501-000342
Samsung Electronics 6-17
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
Q4 TR-SMALL SIGNAL, KSC1623-Y, NPN, 200 mW 0501-000342
Q5 TR-SMALL SIGNAL, KSA1182-Y, PNP, 150 mW 0501-000279
Q6 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
Q7 TR-DARLINGTON, TIP127, PNP, 2 W 0503-000134
Q8 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
Q9 TR-SMALL SIGNAL, MMTB2222A, NPN, 225 mW 0501-000457
- Micellanceous -
BT1 BATTERY-LI, 3 V, 220 mAH 4301-000108
L1 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L2 INDUCTOR-SMD, 3.3 µH, 10 %, 1.25 x 2 x 1.25 mm 2703-000185
L3 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L5 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L6 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L7 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
L8 INDUCTOR-SMD, 10 µH, 10 %, 1.25 x 2 x 1.25 mm 2703-000125
L9 CORE-FERRITE BEAD, AB, 3.2 x 2.5 x 1.3 mm 3301-000325
P1 CONNECTOR-HEADER, 3 WALL, 13 P 3711-000417
P2 CONNECTOR-HEADER, 3 WALL, 3 P 3711-000452
P3 CONNECTOR-HEADER, 1 WALL, 6 P 3711-000280
P4 CONNECTOR-HEADER, 3 WALL, 7 P 3711-000502
P5 CONNECTOR-HEADER, 3 WALL, 10 P 3711-000398
P6 CONNECTOR-FPC/FC/PIC, 30 P, 1.0 mm 3708-001058
P7 CONNECTOR-HEADER, 3 WALL, 6 P 3711-000496
P8 CONNECTOR-HEADER, BOX, 3 P 3711-000907 WHITE
P9 CONNECTOR-HEADER, BOX, 6 P 3711-001062 WHITE
P10 CONNECTOR-HEADER, 3 WALL, 2 P 3711-000443
P11 CONNECTOR-FPC/FC/PIC, 30 P, 1.0 mm 3708-001058
P12 CONNECTOR-HEADER, 1 WALL, 4 P 3711-000225
P13 CONNECTOR-HEADER, 3 WALL, 2 P 3711-000443
PCB PCB-MAIN JG41-10124A
RA1 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA2 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA3 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA4 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA5 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA6 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA7 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA8 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA9 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
6-18 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
RA10 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA11 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
RA12 R-NETWORK, 39 ohm, +-5 %, 1/16 W 2011-001094
X1 CRYSTAL-UNIT, 30 MHz, 50 ppm 2801-003582
X2 CRYSTAL-UNIT, 38.00053 MHz, 15 ppm 2801-003330
X3 CRYSTAL-UNIT, 29.4912 KHz, 50 ppm 2801-001530
X4 CRYSTAL-UNIT, 32.768 KHz, 5 ppm 2801-001498
Samsung Electronics 6-19
Electrical Parts Lists
6-2. OPE PBA
Ref. No. Description SEC. Code Remark
ASSEMBLY, OPE PBA JG92-01036A
- Capacitors -
C301 C-AL, 10 µF, 20 %, 16 V 2401-000414
C302 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C303 C-CERAMIC, CHIP, 47 pF, 5 %, 50 V 2203-001002
C304 C-CERAMIC, CHIP, 47 pF, 5 %, 50 V 2203-001002
C305 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C306 C-CERAMIC, CHIP, 100 pF, 5 %, 50 V 2203-000239
C307 C-CERAMIC, CHIP, 22 pF, 5 %, 50 V 2203-000634
C308 C-CERAMIC, CHIP, 22 pF, 5 %, 50 V 2203-000634
C309 C-CERAMIC, CHIP, 22 pF, 5 %, 50 V 2203-000634
C311 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C312 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C313 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C314 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C315 C-CERAMIC, CHIP, 100 nF, 79.8, 50 V 2203-000192
C310 C-CERAMIC, CHIP, 100 pF, 5 %, 50 V 2203-000239
- Diodes -
D301 DIODE-ARRAY, KDS226, 80 V, 300 mA 0407-000122
D302 DIODE-ARRAY, KDS226, 80 V, 300 mA 0407-000122
D303 DIODE-ARRAY, KDS226, 80 V, 300 mA 0407-000122
D304 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D305 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D306 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D307 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
D308 DIODE-SWITCHING, MMSD914T1, 100 V, 200 mA 0401-000116
- ICs -
U300 IC MICRO COMPUTER JF09-10052A
U301 PHOTO-INTERRUPTER, TR 0604-000231
U302 PHOTO-INTERRUPTER, TR, 150 mW 0604-001033
- Resistors -
R301 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R302 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R303 R-CHIP, 200 ohm, 5 %, 1/10 W 2007-000026
R304 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R305 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
R306 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
6-20 Samsung Electronics
Electrical Parts Lists
Ref. No. Description SEC. Code Remark
R307 R-CHIP, 680 ohm, 5 %, 1/10 W 2007-001118
R308 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R311 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R312 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R313 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R314 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R315 R-CHIP, 470 ohm, 5 %, 1/10 W 2007-000931
R316 R-CHIP, 10 Kohm, 5 %, 1/10 W 2007-000300
R317 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R318 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R319 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R320 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R321 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R322 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R323 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R324 R-CHIP, 22 Kohm, 5 %, 1/10 W 2007-000586
R326 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
R327 R-CHIP, 4.7 Kohm, 5 %, 1/10 W 2007-000872
- Micellanceous -
J300 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J301 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J302 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J303 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J304 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J305 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J306 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J307 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J308 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J309 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J310 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J311 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
J312 R-CHIP, 0 ohm, 5 %, 1/10 W 2007-000029
P301 CBF HARNESS-OPE JB39-40521A OPE-MAIN
P302 CBF HARNESS-OPE JB39-40525A OPE-LIU
PCB PCB-OPE JG41-10121A
X300 RESONATOR-CERAMIC, 7.37 MHz, 0.5 % 2802-000185
Samsung Electronics 6-21
Electrical Parts Lists
6-3. HOOK PBA
Ref. No. Description SEC. Code Remark
ASSEMBLY, HOOK PBA JG92-01037A
SWITCH SWITCH-HOOK, 48 V, 200mA 3409-000118
LIU CBF HARNESS-HOOK JB39-40526A
PCB PCB-HOOK JF41-10692A
6-4. MIC PBA
Ref. No. Description SEC. Code Remark
ASSEMBLY, HOOK PBA JF92-00625A
MIC MIC-CONDENSOR, 1.5 V, 0.3 mA 3003-000103
PCB PCB-H/S MIC JF41-10589A
ZD1 DIODE-ZENER, IN4736A, 6.8 A, 5 %, 1 W 0403-000142
6-5. HOME SENSOR
Ref. No. Description SEC. Code Remark
ASSEMBLY, HOME SENSOR JB96-00930A
HARNESS CBF HARNESS, HOME JB39-40524A MAIN-HOME
PCB PCB-SUB JB41-10050G
SENSOR PHOTO-INTERRUPTER 0604-000156
6-22 Samsung Electronics
Loading...
