Figures and illustrations in this UserManual are provided forreference Transportation to and from the Service Center is the responsibility of
onlyand may differ from actual product appearance. Product design and the purchaser. Conditions covered are limited only to manufacturing
specifications maybe changed withoat notice, defects in material or workmanship, and only those encountered
Important Warranty Information Regarding
Television Format Viewing
=_ See the warranty card for more informationon warranty
terms.
Wide screen format LED Displays (16:9, the aspect ratio of the
screen width to height) are primarily designed to vies!wide screen
format full-motion video. The images displayed on them should
primarily be inthe wide screen 16:9ratio format, or expanded to
fillthe screen if your model offers this feature and the images are
constantly moving. Displaying stationary graphics and images on
screen, such as the dark sidebars on non- expanded standard
format television video and programming, should be limitedto no
more than 5% of the total televisionviewing perweek. Additionally,
viewing other stationary images and text such as stock market
reports, video game displays, station Iogos,web sites or computer
graphics and patterns, should be limited asdescribed above for
all televisions. Displaying stationary images that exceed the above
guidelines can cause uneven aging of LED Displays that leave
subtle, but permanent burnedqn ghost images in the LED picture.
To avoidthis, vary the programming and images, and primarily
display full screen moving images, not stationary patterns or dark
bars. On LED models that offer picture sizingfeatures, use these
controls to vies! different formats as afull screen picture. Becareful
in the selection and duration of televisionformats you usefor
viewing. Uneven LED aging as aresult of format selection and use,
aswell as burnedqn images, are notcovered byyour Samsung
limited warranty.
• SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED
WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations
of the original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
and limitations contained herein, SAMSUNG will additionally
provide Warranty Repair Service in the United States on SAMSUNG
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the UnitedStates, forthe warranty period
originally specified, and to the Original Purchaser only.
The above described warranty repairs must beperformed by a
SAMSUNG Authorized Service (}enter. Along withthis Statement,
the Original Limited Warranty Statement and a dated Bill ofSale
as Proofof Purchase must be presented to the Service (}enter.
IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
BN68 04214B 01
innormal use of the product. Excluded, but not limited to, are
any originally specified provisions for, in-home or on-site services,
minimum or maximum repair times, exchanges or replacements,
accessories, options, upgrades, or consumables.
Forthe location of a SAMSUNG Authorized Service Center,please
call toll-free:
-- Inthe United States :1-800-SAMSUNG (1-800-726-7864)
-- InCanada :1-800-SAMSUNG
Still image warning
Avoid displaying still images (such as jpeg picture files)or still
imageelements (such asTV channel Iogos, TV shows or movies
inpanorama or 4:3 format, stock or news scroll bars, etc.) onthe
screen. The constant display of still pictures can cause ghosting or
image burnqn (image retention) on the LEDscreen, which will affect
imagequality. To reduce the risk of thiseffect, pleasefollow the
recommendations below:
- Avoid displaying the same TV channelfor long periods.
- Always try to display anyimage in full screen mode. Use the TV's
Picture Options menu to select the optimal screen size.
- Reduce brightness and contrast values tothe minimum required
to achieve thedesired picture quality. Values that exceed the
minimum may speed up the burnqn process.
- Frequently use all TVfeatures designed to reduce image retention
and screen burnqn. Refer to proper user manual section for
details.
Contact SAMSUNG WORLDWIDE u
Ifyo_ have any questions or comments re!ating toSamsung products, n
please Pontact the SAMSUNG oustomer carecenter,
Samsung Electronics
Canada hc, Customer
Service 55Standish Court
Mississauga, Ontario LSR
4B2 Canada
Samsung Electlonics
America, Dc.
85Chalbnger Road
Ridgefield Park, NJ
07660 2112
1800 SAMSUNG(726 7864)
www samsung corn
=............................................ =
@2012 Samsung Ebctronics Co., Ltd. All rights reserved.
To add channels to the Added Channels list, follow thesesteps:
1. Select one or more channels in the All Channels list using the
A/V buttons and the YellowSelect button on your remote.
2. Press the TOOLS button onyour remote. The Tools menu
appears.
3. Select Add inthe Tools menu, and then press the ENTER_
button.
_' All deleted channels will be shown onthe All Channels list.
You add channels back to the Added Channels list on the
All Channels list.
'_' A gray-colored channel indicates the channel has been
deleted from theAdded Channels list.
'_ The Add menu option only appears for deleted channels.
m Add to Favorite/Delete from Favorite: Lets you add channels
to and delete channels from your Favorites list.
To add channels to the Favorites list, follow these steps:
1. Select one or more channels in the All Channels list using the
A/V buttons and the YellowSelect button on your remote.
2. Press the TOOLS button onyour remote. The Tools menu
appears.
3. Select Add to Favorite inthe Tools menu, and then press the
ENTER_ button.
To delete channels from the Favorites list, follow these steps:
1. Select one or more channels in the Favorite Channels list
usingthe A/T buttons and the Yellow Select button on your
remote.
2. Press the TOOLS button onyour remote. The Tools menu
appears.
3. Select Delete from Favorite in the Toolsmenu, and then
press the ENTER _ button.
m Timer Viewing: You can schedule a channel to be displayed
automatically ata set time, even when you are watching another
channel. You must set the current time first in the Time > Clock
function to use Time Viewing.
To schedule a channel, follow these steps:
1. Select a channel in the Added Channels list using the A/_'
buttons and the Yellow Select button on your remote.
2. Press the TOOLS button onyour remote. The Tools menu
appears.
3. Select Time Viewing in the Tools menu, and then press the
ENTER_ button. The Time Viewing screen appears.
4. Use the _/1_ buttons to move from entryfield to entry field
and the A/T buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly usingthe
number keypad on your remote.
'_' Ifyou select Everyday or Every Week, the date you
select in the Date field becomes the start date for your
scheduled viewing. For Everyday, the TV will turn on
every day, atthe time you selected, starting from that
date. For Everyweek, the TV willturn on every week,
on the same day of the week as the start date you
selected, at the time you selected, from that day on. If
you select Once, theTV will turn on once, on the date
and time you selected.
5. Press the ENTER _ button on your remote when done.
_' Only Added Channels can be scheduled.
_' Scheduled programs and channels are displayed in the
Programmed List.
'_' When you select a digital channel, press the !_button to
view the digital program list. If you highlight a program in
the list, and then press the ENTERS(Schedule) button,
you set Timer Viewing for that program directly.
m Select All: Selectall the channels inthe displayed channel list.
m Deselect All: Deselect all the selected displayed channels.
'_' You can only select Deselect All when one or more
channels are selected.
m Channel Name Edit: Analog channels only. Lets youassign a
name of up tofive characters to ananalog channel. For example,
Hist, Food, Golf, etc. This makes it easierto find and select a
channel.
m Auto Program: See Auto Program under Memorizing Channels.
(_ Programmed List (on the Channel List Screen)
The Programmed listdisplays the channels and programs you
have scheduled for viewing using the Time Viewing function. You
can vies!, modify, or delete ashow you have scheduled using the
functions on the Programmed List screen Tools menu.
Programmed List Screen Tools Menu
m Change Info: Change the sctqeduling informationfor a show or
ctqannelyou havesctqeduled.
To ctqangettqe information,follow these steps:
1. Select the Programmed List icon on the left side ofthe
Channel Listscreen, and then press the ENTER_ button.
2. On the Programmed List screen, select the show or channel
entryyou want to change, and then press the TOOLS button.
The Tools Menu appears.
3. Select Change Info, and then press ttqe ENTER _ button.
The Time Viewing screen appears.
4. Use ttqe _1/!_ buttons to move from entry field to entry field
and the A/_' buttons to change the entries. Wtqerenumbers
aredisplayed, you can also enter numbers directly using the
number keypad on your remote.
5. Press the ENTER _ button wtqen done.
m Cancel Schedules: Cancel ashow or ctqannelyou have
scheduled.
To cancel a scheduled show or channel, follow these steps:
1. Select the Programmed List icon on the left side ofthe
Channel List screen, and then press the ENTER_ button.
2. On the Programmed List screen, select the show or channel
entryyou want to cancel, and ttqen pressttqe TOOLS button.
The Tools Menu appears.
3. Select Cancel Schedules, and ttqen pressttqe ENTER
button. The Cancel Schedule screen appears.
4. Select OK, and then pressthe ENTER _ button.
-5-
' Advanced Settings
_ Available in Standard and Movie mode only.
Your TVhas two kinds ofmenus, the Main menu and the various Compared to previous models, new Samsung TVs offer a more
Tools menus. The Main menu gives you access to most or all of precise picture with moreprecise controls.
the menu options available on your TV. The Toolsmenus display
aselected number of frequently used menu options that change =z When your TV is connected to a PC,you can only make
depending on the screen you are viewing. A Tools menu symbol changes toGamma and White Balance.
(_'3) inthe lower rightside of the screen indicates thata Tools menu m Color Space (Auto / Native): Auto automatically matches the
isavailable, rangeof colors available to create pictures to the color range of
The Main menu has seven primary categories:
" Picture o Input
" Sound o Application
" Channel o Support
- Setup
Toview the Main menu, press the MENU button on your remote. To
vies! aTools menu, pressthe TOOLS button on your remote.
'_' The menu options that appear in the Main menu depend
on the Source you have selected. For example, ifyou have
selected the HDMI source, the Channel category will not
appear. To see the Channel category, you must first select TV
inthe Source List.
The Menu options are presented below, arranged by Main menu
categories. A Tools button symbol (J_l_l) next to an option
name indicates the option isalso available in one of the Tools
menus.
Mode
Select your preferred picture mode.
'_' When your TV is connected to a PC,you can only select
Entertain and Standard.
m Dynamic: Brightens the screen. Suitable for a bright room.
m Standard: Suitable for a normal normal.
m Movie: Darkens the screen, making it lessglary. Suitable for
watching movbs in a darkened room.
m Entertain: Sharpens the picture. Suitable for games.
_ Only available when the TV is connected to a PC.
Backlight / Contrast / Brightness / Sharpness /
Color / Tint
Backlight: Adjusts the brightness of the screen by adjusting the
brightness of the individual pixeIs.
Contrast: Increases or decreases the contrast between dark and
light areas ofthe picture.
Brightness: Adjusts the brightness of the screen. Not as
effective as Backlight.
Sharpness: Sharpens ordulls the edges ofobjects.
Color: Adjusts the color saturation. The higher the Color setting,
the more intense the color. Los! settings remove color and the
picture becomes black, white and gray.
Tint: Adjusts theamount of green and red inthe picture. As you
increase the amount of green, the amount of reddecreases and
vice versa.
'_' When the TV is connected to a PC,you can only make
changes to ight, Contrast, Brightness, and Sharpness.
the video source. Native provides a color rangewider thanthe
color range of the video source.
[] White Balance: Adjusts the color temperature of the picture so
that white objects lookwhite (instead of, forexample, slightly
pink or slightly yellow)and the overall color of the picture looks
natural.
R-Offset /G-Offset / B-Offset: Adjusts each color's (red,
green, blue) darkness.
R-Gain / G-Gain / B-Gain: Adjusts each color's (red, green,
blue) brightness.
Reset: Resets the White Balance to it'sdefault settings.
[] Gamma: Adjusts the primary color intensity.
[] Dynamic Contrast (Off / Low / Medium / High): Adjusts the
screen contrast.
[] Black Tone (Off/Dark/Darker/Darkest): Selects the black
levelto adjust the screen depth. Darker settings make blacks
look darker.
[] Flesh Tone: Adjusts the amount ofred in skin tones.
[] Motion Lighting (Off / On): When on, the TV automatically
adjusts the brightness ofthe screen inresponse to the
brightness of the room. In bright light, the screen brightens. In
dim light, the screen dims.
'_' Available in Standard mode only.
Picture Options
'_' When the TV is connected to aPC, you can only make
changes to the Color Tone, Size and HDMI Black Level.
[] Color Tone (Cool / Standard / Warm1 / Warm2): Cool makes
the picture bluer (cooler). Warm 1 and Warm 2 make the picture
redder (warmer).
'_' Warmt andWarm2 are deactivated when the picture
mode is set to Dynamic.
[] Size: Setthe size and aspect ratioof the picture on the screen.
Your cable box or satellite receiver may have itsown set of
screen sizes aswell. However, we highly recommend you use
the TVs 16:9 mode most of the time.
16:9: Sets the picture to the 16:9 wide screen format.
Zoomt : Provides moderate magnification ofthe picture. Sides,
top, and bottom arecut off.
Zoom2: Provides larger magnification ofthe picture. Sides, top,
and bottom arecut off.
Wide Fit: Enlarges the aspect ratio of the picture so the picture
fits the entire screen.
4:8: Sets the picture to the old, 4:3 format and puts black or gray
borders on the right and leftof the picture.
'_' Do not watch your TV in the 4:3 format for a long time.
Traces of borders displayed on the left, rightand center of
the screen may cause image retention (screen burn)which
isnot covered by the warranty.
Screen Fit: Displays thefull image without anycut-off when
your TV is inputting HDMI (720p / 1080i / 1080p) or Component
(1080i/1080p) HD signals.
_' HD (High Definition) has a 16:9aspect ratio and 1080i/1080p
(1920x1080) or 720p (1280x720) resolution.
_' You can adjust and store settings for each external device you
have connected to an input on the TV. Picture Sizes available
by Input Source are listed below:
-2-
[] Information: Display the information fora show orchannel you
have scheduled. You can also change the schedule Information.
1. Select the Programmed List icon on the left side ofthe
Channel List screen, and then pressthe ENTER _ button.
2. On the Programmed List screen, select the show or channel
entry you want information for,and then press the TOOLS
button. The Tools Menu appears.
3. Select Information, and then press the ENTER_ button.
The Time Viewing Information screen appears.
4. Select Change Info and press the ENTER _ button
to change information, or select Close and press the
ENTER_ button to close the information screen.
[] Select All / Deselect All: You can select or deselect all
channels in the channel list.
_3 Other Channel Menu Functions
Channel Mode (Added Channels/Favorite
Channels)
Lets you select the channel list displayed when you press the
ACHV (Channel) button on yourremote. For example, ifyou
select Favorite Channels, you will only see Favorite channels when
you press the ACHV button.
Fine Tune
Analog channels only.
Ifthe reception is clear,you do not haveto fine tune the channel,
as this isdone automatically during the search and store
operation. If the signal is weak or distorted, fine tune the channel
manually.
'_' Select the channel, and then select Fine Tune.
'_' Fine tuned channels that have been saved are marked with
an asterisk "*" on the right-hand side of the channel number
inthe channel banner.
'_'To reset fine-tuning, select the channel, select Fine Tune, and
then select Reset on the Fine Tune screen.
Plug & Play
Lets you re-run the Plug & Play initial setup procedure. For
instructions, seeyour Quick Start Guide.
Language
Set the menu language.
_' Choose between English, Espa_ol, and Francais.
_3Setting the Time
Time
'_' The time you set will appear when you press the INFO
button.
[] Clock: Set the clock so you can use the various timer features
of the TV.
'_' Ifyou disconnect the power cord, you have to set the
clock again.
To set the clock, follow these steps:
1. Select Setup >Time > Clock.
2. Press ENTER _ and select Auto or Manual, andthen press
ENTER_ again.
Ifyou selected Auto:
The TV willautomatically download the correct time from a
digital channel.
- Select Time Zone, and then press the ENTER_ button.
Use the_,/_!' buttons to select your Time Zone, and then
press ENTER _.
- Select DST (Daylight Savings Time), and then press
ENTER_. Select On if youwant toturn the DST
adjustment onand offmanually. Select Off to turn off the
DST adjustment. Select Auto ifyou want the TVto adjust
to DST automatically. Press ENTER_ when done.
'_' DST and Time Zone function are only available when
the Clock Mode isset to Auto.
Ifyou selected Manual:
The Clock Set screen appears. Use the _/_ buttons to
change the values in each fieldor use the number buttons to
enter the values directly. Usethe _1/1_buttons to move from
field to field. When done with all the fields, press ENTER _.
'_ Available onlywhen Clock Mode isset to Manual.
[] Sleep Timer
Automatically shuts off the TV after a preset period of time. (30,
60, 90, 120, 150 and 180 minutes).
'_' To cancel the Sleep Timer, select Off.
Timer 1/ Timer 2 / Timer 3
Turns the TVon andoff automatically attimes and days you
select. You can setthree differenton/off timer settings.
'_' You must set the clock first.
[] On Time / Off Time: Set the hour, minute, am/pm, and
Activate/Inactivate fields for the On Time and Off Time. Usethe
_1i/1_buttons to move from field to field. Use the A/_ buttons
to change the values in each field. Toactivate the timer with
the setting you have chosen, setthe Activate/Inactivate field to
Activate.
[] Volume: Setthe desired loudness.
[] Contents: To select what will be turned on when the timer
setting is activated. You can set theTV to turn on a specific
channel or play back contents such as photo or audiofiles.
Usethe _1/_ buttons to move to move to the Contents field,
and then press the ENTER _ button. The Contents screen
appears. Use the _1/1_ buttons to move from field to field. Use
the &/_' buttons to change the values ineach field.
- TV/USB: Select TV or USB. The USB device must be
connected to yourTV before you can select USB.
- Antenna: Displays the current antenna source, Air or Cable.
- Channel: If you have selected TV, select the desired channel.
- Music/Photo: If youhave selected USB, follow these steps to
select a folder containing MP3 (Music)or JPEG (Photo) files on
the USB device:
'_' The maximum displayed number of files, including sub
folders, in one folder ofUSB storage device is 2000.
'_' The media may not be playing smoothly when using the
device lower than USB 2.0.
1. Use the _1/_ buttons tomove tothe field under Music
or thefield under Photo, and then press the ENTER
button. The TV displays a single folder (the Root folder)
and the type or name of thedevice.
-6-
16:9, Zoom1, Zoom2,
ATV,AV,Component (480i,480p) 4:3
DTV(1080i, 1080p),Component (1080i, 16:9, Wide Fit, 4:3,
1080p),HDMI (720p, 1080i,1080p) Screen Fit
[] Digital Noise Filter (Off / Low / Medium / High / Auto) : Ifthe
broadcast signalreceived byyour TVis weak, you can activate
the Digital Noise Filter featureto reduce anystatic and ghosting
that may appear on ttqescreen.
'z Wtqen the signal isweak, tryall the Digital Noise Filter
options until the TV displays the best picture.
[] HDMI Black Level (Normal / Low) : For HDMI signals, select
the black level to adjust the screen depth. Low make blacks look
darker.
'_ Available only in HDMI mode (RGB signals).
[] Film Mode (Off / Auto) :Sets the TV to automatically sense and
process film signals from all sources and adjusts the picture for
optimum quality.
'z Available in ATV,DTV (interlace), AV, COMPONENT (480i /
1080i) and HDMI (480i/1080i).
[] Auto Motion Plus (Off / Clear / Standard / Smooth / Custom /
Demo): Enhances motion infast moving scenes.
'z The info screen on your TV displays ttqe resolution and
frequency of the incoming video signal (60Hz). This
displayed frequency isnot what the TVis displaying by
usingthe Auto Motion Plus function.
[] LED Motion Plus (Off / On): Removes drag from fast scenes
wittqa lot of movement to provide aclear picture.
Picture Reset
[] Picture Reset (Reset Picture Mode/Cancel): Resets the
picture settings to ttqeir factory defaults.
Mode
[] Standard: Selects the normal sound mode.
[] Music: Emphasizes musicover voices.
[] Movie: Provides the best sound for movies.
[] Clear Voice: Emphasizes voices overother sounds.
[] Amplify: increase the intensity ofhigh-frequency sounds to allow
a better listening experience for the hearing impaired.
Equalizer
Available in Standard sound mode only.
[] Balance L/R: Adjusts the balance bets!een the right and left
speaker.
[] 100Hz /300Hz / 1KHz / 3KHz / 10KHz (Bandwidth
Adjustment): Adjusts the loudness of specific bandwidth
frequencies.
[] Reset: Resets the equalizer to its default settings.
SRS TruSurround HD (On/Off)
Available in Standard sound mode only.
SRS TruSurround HD is a patented SRS technology that solves
the problem of playing 5.1 multichannel content through two
speakers. TruSurround deliversa compelling, virtual surround
sound experience through anytwo-speaker playback system,
including internal television speakers. It isfully compatible with all
multichannel formats.
2. Press the ENTER _ button. A listof folders on the device
appears.
'_' Ifthere are nofolders on your device, press the
Yellow select button toselect the Root folder, and
then press the RETURN button. The Timer screen
re-appears.
3. Use the A/_' buttons to highlight a bider that contains
music or photos, and then press the Yellow select button
to select thefolder.
4. Press the RETURN button. The Timer screen re-appears.
[] Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun
or Manual. Ifyou select Manual, you can select the days you
want to activate the timer by using the _1/i_ buttons to highlight
the day,and then pressing the ENTER _ button. To unsebct a
day, highlight it, and then press the ENTER_ button.
When you finished making all your selections on the Timer screen,
press either the ENTER _ or RETURN button.
_3 Other Features
Program Rating Lock
The Program Rating Lock feature letsyou block programs
you've determined are inappropriate for your children based on
the program's ratings. To accessthe Program Rating Lock
feature and make any changes, you must enter a PIN (personal
identification number). Towatch ablocked program, you must also
enter the same PIN.
'_' Program Rating Lock is not available in HDMI or
Component mode.
'_' The default PIN number of a newTV set is "0-0-0-0". You can
set your own PIN using the Change PIN function.
How It Works
When you access the Program Rating Lock Menu functions for
the first time, the PiN input screen appears. Enter 0-0-0-0. The PiN
screen closes and the Program Rating Lock Menu appears. Every
time you access the Program Rating Lock functions, the PIN
screen will appear and you must enter a PiN.
When the Rating Lock screen appears, select Program Rating
Lock, andthen press ENTER_. Select On, and then press the
ENTER _ key again. Depending on what type of programs or
movies you want to block, select one of the options onthe screen,
and then press the ENTER _ button. The options arelisted below:
[] TV Parental Guidelines: You can block TV programs based
on their ratings. This function allows you to control what your
children are watching.
[] MPAA Rating: You can block movbs based on their MPAA
ratings. The Motion Picture Association of America (MPAA) has
implemented a ratingsystem that provides parents or guardians
with advanced information on which films are appropriate for
children.
[] Canadian English: You can block TV programs based on their
Anglophone Canadian ratings.
[] Canadian French: You can block TV programs based on their
French Canadian ratings.
[] Downloadable U.S. Rating: Parental restriction information can
be used while watching DW channels.
Preferred Language
Digital channels only.
DigitaI-TV broadcasts can transmit many audio tracks
simultaneously (for example, simultaneous translations ofa program
intoforeign languages).
'_' You can only select a language from among the ones being
broadcast.
Multi=Track Sound (MTS)
Analog channels only.
[] Mono: Select for channels that are broadcasting in mono or if
you are having difficulty receiving a stereo signal.
[] Stereo: Select for channels that are broadcasting in stereo.
[] SAP: Select tolisten tothe Separate Audio Program, which is
usuallya foreignqanguage translation.
'_' Depending on the program being broadcast, you can listen to
Mono, Stereo or SAR
Auto Volume
Because each station hasits own broadcasting conditions, the
volume may fluctuate each time you change the channel. This
feature automatically adjusts the volume of achannel by lowering
the sound output when the modulation signal is high or by raising
the sound output when the modulation signal is los!.
SPDIF Output
The SPDIF (Sony PhilipsDigital InterFace)outputs an
uncompressed digital audio signal when you connect the digital
audio jack on the back of the TVto a digital audio injack on a
receiver or home theater.
[] Audio Format (POM/Dolby Digital): Youcan select the Digital
Audio output (SPDIF) format. The available Digital Audio output
format may differ depending on the input source.
'_' By connecting the TV toa receiver or home theater with
Dolby Digital and 5.1ch speakers and selecting Dolby
Digital, you can maximize your interactive 3D sound
experience.
[] Audio Delay: Lets you correct timing mismatches between the
audio track and the video when you are watching theTV and
listening to digital audio output from the TV through an external
device such as an AVreceiver. When you select Audio Delay, a
slider appears. Use the left and right arrow buttons to adjust the
slider. Press ENTER_ when done (0ms _ 250ms).
Speaker Settings
[] Speaker Select (External Speaker / TV Speaker)
Ifyou are listening to the sound track of a broadcast ormovb
through an external receiver, you may hear asound echo caused
bythe difference indecoding speed between theTV's speakers
and the speakers attached to youraudio receiver. Ifthis occurs,
set the TVto External Speaker.
'_' When you set Speaker Select to External Speaker, the
TV's speakers are turned off. You will hear sound through
the external speakers only. When you set Speaker Select
to TVSpeaker both the TV's speakers and the external
speakers are on. You will hear sound through both.
'_' When Speaker Select is set to External Speaker, the
VOLUME and MUTE buttons will not operate and the
sound settings will be limited.
'_' Ifthere isno video signal, both the TV's speakers and the
external speakers will be mute.
Sound Reset
[] Reset All: Resets all sound settings to the factory defaults.
-3-
Locking/Blocking Programs or Movies
You lock or block programs and/or movies in essentially the same
way for each option. Each option displays a gridor table. All the
tables have ratings listed on the left. The TV Parental Guidelines
option also has kinds of content listed across the top: ALL: Lock all
TV ratings. / FV: Fantasyviolence /V: Violence / S:Sexual situation
/ L: Adult Language / D: Sexually Suggestive Dialog.
To lock/block movies or shows with certain ratings and/or kindsof
content, clickthe square nextto the rating and/or under the kind of
content. A lock appears. Tounlock/unblock, click the square again.
When you click a low rating, all the ratings above itwill also display
locks. You can also Allow All or LockAll. When done, press the
RETURN button onyour remote.
[] Change PIN: The Change PIN screen will appear. Choose any
4 digits for your PIN andenter them in Enter New PiN fields.
Re-enter the same 4 digits in Confirm New PIN fields. When the
Change PIN screen disappears, press the OK button. The TV
has memorized your new PIN.
'_' Ifyou forget the PIN, press the remote-control buttons in
the following sequence, which resets the pin to "0-0-0-0" :
POWER (off) _ MUTE _ 8_ 2 _ 4 _ POWER (on)
Game Mode (On/Off)
When you connect a game console such as aPlayStation TM
or XboxTM toyour TV, you can enjoy a more realistic gaming
experience by turning onthe Game Mode function.
'_' Precautions and limitations forgame mode:
* Before youdisconnect thegame console and connect another
external device, setGame Mode to Offin the setup menu.
* Ifyou display theTV menu in Game Mode, the screen shakes
slightly.
'_' Game Mode is not available when the input source is set to
TV.
'_' After connecting the game console, set Game Mode to On.
You may notice slightly reduced picture quality.
(On-Screen Text Dialogue)
[] Caption: You can switctq the caption function onor off. If
captions are not available, they will not be displayed on the
screen.
'_' The Caption feature does not work in Component or
HDMI mode.
[] Caption Mode: You can select the desired caption mode.
Default / OO1 ~O04 / Text1 ~Text4: (analog channels only) The
Analog Caption function operates in either analog TVchannel
mode or when a signal issupplied from anexternal device to the
TV.(Depending onthe broadcasting signal, the Analog Caption
function may or may not work with digital channels.)
Default / Service1 ~Service6 / OO1~004 / Text1 ~Text4:
(Digital channels only) The DigitalCaptions function works with
digital channels.
'_' Service1~6 may not be available indigital caption mode
depending on the broadcast.
[] Digital Caption Options: (Digital channels only)
Size: Options include Default, Small, Standard and Large. The
default is Standard.
Font Style: Options include Default and Styles 0 to 7. The
default is Style 0.
Foreground Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
color of the letters. The default is White.
-7-
_3 Memorizing Channels
When you first set up your TV using Plug & Play, the TV memorized
the channels that were available over the air or through your cable
system and added them tothe Channel List. The Antenna and
Auto program functions described below let youre-run the channel
memorization function without having to re-run the Plug &Play
procedure.
_3 Managing Channels
Channel List
See your list ofAdded channels, Favorite channels, or channels
you've scheduled forviewing. Add or delete Favorite channels, add
or delete channels from the Added Channels list, schedule channels
or programs for viewing. Watch achannel by selecting the channel
in theAll Channels, Added Channels, or Favorite screen, pressing
the A / _ buttons, and then pressing the ENTER _ button.
Antenna (Air / Cable)
Before your televbion can memorize ttqe available channeB, you
must select your TV's signal source, Air (using an antenna) or Cable.
Select Menu >Channel > Antenna > Air or Cable. After you have
selected ttqe signalsource, go on to the Auto Program function.
Selecting the signal source using the Antenna function also
determines ttqe signal source the TVis tuned to. For example,
ifyou receive your TV signal over the air, andyou select Cable,
you will see only snow. You must select Air to see a picture.
The Auto Program function memorizes allchanneb that are
available over the airor througtq your cable system andadds them to
the Channel List.
To startAuto Program, follow these steps:
1. Pustq MENUITR _ Channel _ ENTER_ on your remote. The
Antenna Source screen appears.
2. On the Antenna Source screen, select the source of your TV
signal.
Air
Ifyour TV is connected to an antenna choose Air, and ttqenpress
ENTER_. TheTV will automatically start memorizing channeb.
Cable
Ifyour TV is connected to a cable outlet, choose Cable, and then
press ENTER _. Go to Step 3.
Auto
Ifyou choose Auto, and then press ENTERS, the TV will
automatically select the correct Antenna source. Go to
Step 3.
3. On the (}able Type screen, use the _1/!_/_/_' buttons to select
the type of digital and analog cable systems you have: STD, HRC,
or IRC. Most systems are STD (Standard). When done, select
Start, and then pressENTER _. The TV will start memorizing
channeb.
Channel List Screens icons are listed on the left side. Select an
icon using the _/_' buttons to view each list.
[] _ All Channels: Shows all currently available channels includng
those you deleted from the Added Channels
list.
[] _ Added Channels: Shows all Added channels. These arethe
channels that appear when you pressthe CH button.
[] _ Favorite: Shows allfavorite channels.
[] (_ Programmed: Shows allchannels and programs currently
scheduled using Timer Viewing.
Remote control buttons active on the Channel List screen.
° Green (Zoom):Enlarges or shrinks achannel number.
° Yellow(Select): Movethe cursor toa channel. Press theYellow
button to select thechannel. A ,7 mark appears. Repeat to select
additional channels. Then, openthe Tools menuand apply a
function to thechannels you selected.
o r_ (Tools): Displays the Channel List Tools menu. (TheTools
menus maydiffer depending on the situation.)
Display icons Used in the Channel List Screens
!_
-7 A selected ctqannel.
A Favorite ct_annel.
(_) A reserved program.
I_ A program currently beingbroadcast.
Channel memorization can take up to45 minutes, depending _ The Channel List Tools Menu
on your cable system.
'_' Memorized channels are added to the Added Channels
list. These are the channels you will see when you usethe
Channel buttons on your remote.
Clear Scrambled Channel
This function filters out scrambled channels after Auto Program is
completed. This process may take up to 20_30 minutes.
'_' Press the ENTER_ button tostop the Clear Scrambled
Channel.
_' This function isonly available in Cable mode.
The Channel List '[bob menu contains most ofthe functions you
can use on the AllChannel, Added Channels, and Favorite List
screens. To view, select a list screen, select a channel, and then
press the TOOLS button,
[] Add / Delete: Deletea channel from or add a channel to the
Added Channels list.
To delete channels from the Added Channels list,follow these steps:
1. Select one or more channels in the Added Channels list using
the _/_' buttons andthe Yellow Select button on your remote.
2. Press the TOOLS button onyour remote. The Tools menu
appears.
3. Select Delete inthe Tools menu, andthen pressthe ENTER
button.
-4-
Background Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
background color of thecaptions. The default is Black.
Foreground Opacity: This adjusts the opacity of text. Options
include Default,Transparent, Translucent, Solid and Flashing.
Background Opacity: This adjusts the opacity ofthe caption
background. Options include Default, Transparent, Translucent,
Solid and Flashing.
Return to Default: This option sets each Size, Font Style,
Foreground Color, Background Color, Foreground Opacity and
Background Opacity to its default.
'_' Digital Caption Options are available only when you can
select Default and Service1 ~ Service6 in Caption Mode.
'_' The Foreground and Background cannot be set to the
same color.
Melody
Lets you control whether amelody playswhen theTV is turned on
or off.
_' The Melody does not play:
° When no sound isoutput from the TV because the MUTE
button has been pressed.
° When no sound isoutput from the TV because the volume
has been reduced to minimum with the VOL - button.
° When the TV is turned off by the Sleep Timer function.
[] Reset: Reset all settings to the factory defaults.
'_ The PIN input screen appears before the setup screen.
'_' Enter your 4-digit PIN. Change the PIN using the Change
PiN option.
Software Upgrade
Software Upgrade can be performed by downloading the latest
firmware from samsung.com to a USB memory device.
HD Connection Guide
Refer to this information when connecting external devices to the
TV.
Contact Samsung
Vies!this information when your TV does not work properlyor
when you want to upgrade the softs!are. Youcan find information
regarding our call centers and how to download products and
software.
Enjoy photos, music and/or movie files saved on a
USB Mass Storage Class (MSC) device.
Auto Protection Time
_3 Connecting a USB Device
[] Auto Protection Time (Off / 10 rain / 20 min / 40 rain / 1hour):
Ifthe screen remains idlewith a still imagefor a certain period 1. Turn on your TV.
of time you define, the screen saver is activated to prevent the
formation of ghost images on ttqescreen.
Eco Solution
[] Energy Saving (Off /Low / Medium / High / Picture Off) :
This adjust the brightness of the TV in orderto reduce power
consumption. Ifyou select Picture Off,the screen isturned
off, but the sound remains on. Press any button except volume
button to turn on the screen.
[] Eco Sensor (Off / On): To enhance your power savings; the
picture settings will automatically adapt to the light in the room.
'_' Ifyou adjust the Backlight, the Eco Sensor will be set to
Off.
Min. Backlight: When Eco Sensor isOn, the minimum screen
brightness can be adjusted manually.
'_' If Eco Sensor is On, the display brightness may change
(become slightly darker in most cases) depending on the
surrounding light intensity.
[] NoSignal Power Off (Off / 15 rain. / 30 rain. / 60 rain.): Sets
how quickly the TV switches to standby mode, if no picture is
being received.
'_ Disabled when the PC isin power saving mode.
[] Auto Power Off (Off/ On):The TV will be automatically turned
off when no user operation is received for 4 hours.
_nosis
[] Picture Test: Use to ctqeckfor picture problems. If the problem
appears in the test picture, select Yes and follow the directions
on the screen.
[] Sound Test: Use the builtqn melody sound to check for sound
problems. Ifttqe problem occurs during the test, select Yesand
follow the directions on the screen.
[] Signal Strength: (Digital channels only) An HD channel's
reception quality is either perfect or the channels are unavailable.
Adjust your antenna to increase signal strength.
-8-
2. Connect aUSB device containing photo, music, and/or movie
files to tt_eUSB jack on the back of the TV. Apop up window
appears.
3. Press the MED_A,P button onyour remote. The Media Play
menu appears.
_3 Using the Media Play Menu
To open Media Playin the Menu, follow thesesteps:
1. Press the MENU button. Then, press ttqe A or • button to
select Application on the left, and then pressttqe ENTER
button.
2. Press the • or _' button to select Media Play (USB), and then
press the ENTER _ button.
3. Press the _1 or !_ button to select an icon (Videos, Music,
Photos, Settings), and then press the ENTER _ button.
_' Media Play might not work properly with unlicensed
multimedia files.
_' Need-to-Know List before using Media Play (USB)
° The file system supports FAT16, FAT32 and NTFS.
° Certain types of USB Digital camera and audio devices may not
be compatible with this TV.
° Media Play only supports USB Mass Storage Class (MSC)
devices. MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV's USB
port. USB HDD is not supported.
°BeforeconnectingyourdevicetotheTV,pleasebackupyour
filestopreventthemfromdamageorlossofdata.SAMSUNGis
notresponsibleforanydatafiledamageordataloss.
°AUSBdevicethatrequireshighpower(morethan0.5A)maynot
besupported.
°DonotdisconnecttheUSBdevicewhileitisloading.
°Thehighertheresolutionoftheimage,thelongerittakesto
displayonthescreen.
°ThemaximumsupportedJPEGresolutionis15360x8640pixels.
°IfafileiscorruptedortheTVdoesnotsupportthefiletype,the
"NotSupportedFileFormat"messageappears.
°TheTVcannotplayMP3fileswithDRMthathavebeen
downloadedfromafor-paysite.DigitalRightsManagement
(DRM)isatechnologythatsupportsthecreation,distribution,
andmanagementofdigitalcontentinanintegratedand
comprehensiveway,includingprotectingtherightsandinterests
ofcontentproviders,preventingillegalcopyingofcontents,and
managingbillingandsettlements.
°PTPdevicesarenotsupported.
°Ifanover-powerwarningmessageisdisplayedwhileyouare
connectingorusingaUSBdevice,thedevicemaynotbe
recognizedormaymalfunction.
°IftheTVhasnoinputduringthetimeperiodsetinAuto
ProtectionTime,theScreensaverwillrun.
°Thepower-savingmodeofsomeexternalharddiskdrivesmay
bereleasedautomaticallywhenyourconnectthemtotheTV.
°IfyouuseaUSBextensioncable,theTVmaynotrecognizethe
USBdeviceormaynotbeabletoreadthefilesonthedevice.
°IfaUSBdeviceconnectedtotheTVisnotrecognized,thelistof
filesonthedeviceiscorrupted,orafileinthelistisnotplayed,
connecttheUSBdevicetoaPC,formatthedevice,andcheck
theconnection.
°IfafileyoudeletedfromthePCisstillfoundwhenyourunMedia
Play,usethe"EmptytheRecycleBin"functiononthePCto
permanentlydeletethefile.
°Photosonlysupportsthesequentialjpegformat.
°TheVideosoptiondoesnotsupportthescenesearchand
thumbnailfunctions.
°IfthenumberoffilesandfolderssavedonaUSBstoragedeviceis
overapproximately4000,thefilesandfoldersmaynotappearand
somefoldersmaynotopen.
°Themaximumdisplayednumberoffiles,includingsubfolders,in
onefolderofUSBstoragedeviceis2000.
°Themediamaynotbeplayingsmoothlywhenusingthedevice
lowerthanUSB2.0.
Videos
1. In the Media Play menu, press the _ or !_ button to select
Videos, and then press the ENTER_ button.
2. Press the _/I_/A/T buttons to select a video klthe file list.
3. Press the ENTER _ button or [_ (Play) button.
The fib name isdisplayed on the top of the screen with the
playing time.
Ifvideo time information isunknown, playing time and the
progress barare not displayed.
During video playback, you can search using the -ql and
_. buttons.
'_' In this mode, you can play movie clips contained ina game,
but you cannot playthe game itself.
-9-
'_Supported Subtitle Formats
External
MPEG4timed text
SAMI
SubRip
SubViewer
MicroDVD
SubStationAlpha
AdvancedSubStationAlpha
Internal
Xsub
SubStationAlpha
AdvancedSubStationAlpha
SubRip
MPEG4Timedtext
'_Supported Video Formats
ttxt
sml
srt
sub
.subor txt
ssa
ass
i!iiiiiiiiiiiiiiiii!_!_ii_i!!i!!i!!i!!i!!i!!iii!ii!ii!!il
AVI
MKV
MKV
MKV
MP4
PictureFormat
TextFormat
TextFormat
TextFormat
TextFormat
DivX
311/4x/5 1 1920x1080 6-30 30Mbps
/60
*rap4 MP4 H264 1920x1080 6-_30 30Mbps
AVC 1920x1080 6-_30 30Mbps
MJPEG 640x480 6-_30 10Mbps
DivX
311/4x/5 1 1920x1080 6-30 30Mbps
/60
*avi AVl, MPEG4 SP
1920x1080 6-_30 30Mbps
*mkv MKV /ASP
H264 1920x1080 6-_30 30Mbps
MJPEG 640x480 6-_30 10Mbps
DivX3 11
/4x/5.1 1920x1080 6-_30 30Mbps
/60
ASF
MPEG4 SP
1920x1080 6-_30 30Mbps
/ASP
H.264 1920x1080 6-_30 30Mbps
*ts MPEG2 1920x1080 6-_30 30Mbps
TS H 264 BP
1920x1080 6-_30 30Mbps
*m2ts / MP/ HP
MPEG1 1920x1080 24/25/30 30Mbps
*dat
MPEG2 1920x1080 24/25/30 30Mbps
PS
H 264 BP
*rob / MP /HP 1920x1080 6-_30 30Mbps
MPEG4 SP
1920x1080 6-_30 30Mbps
*3gp 3GPP /ASP
H.264 1920x1080 6-_30 30Mbps
H.264 1920x1080 6-_30 30Mbps
*fly flash
*swf formats Sorenson
1920x1080 6-_30 30Mbps
H.263
MP3 /
ADPCM /
AAC
MP3 /
AC3 /
LPCM /
ADPCM
/ DTS
Core
MP3 /
AC3 /
LPCM /
ADPCM
/ WMA
/ WMA
Pro
AC3 /
AAC/
MP3 /
DD+ /
HE AAC
AC3 /
MPEG /
LPCM /
AAC
MP3
MP3
Trouble Powering On Before you turn the TV on, find the red light on the right or left bottom ofyour TV.Press the power on button
on the TVor remote and the light should blink about 5 times before the TV turns on.
Ifyou find that you are havingtrouble powering on your Samsung television, there are a number ofthings to check it
before making a callto the service department.
,, Ifyou happen to beusing the TV as amonitor and thestand-by light only blinks for a fewseconds when you
pressthe power button, your PC is insleep mode. Totake your PC out of sleep mode, press a keyon your
keyboard or move the mouse. Then try turning your TV on.
Ifyou're sureyour power cord, remote control, and PC arefunctioning properly, you maybe having a cable issue. If
you havea cable or satellite box, your TVmay appear to be off because the cable or satellite boxis not outputting a
signal. Totest the signal output of your cable or satellitebox, pressthe guideor info button on the cable orsatellite
box remote control. If thescreen displays theguide or info data, the problem is caused by the box.
Stand Assembly • If you haveany trouble assembling the stand, refer to"Install the Stand" in the Start Up orStand Intallation Guide.
Cannot find achannel • Re-run Plug & Play orrun Auto Program. (goto MENU - Channel - Auto Program)
Poor Picture First, perform the Picture Test and tQsee ifyour TV is disp!aying thetest image prqperly.
Go toMENU :Suppert ;Self Diagnosis =Picture Test
Ifthe test image is properly displayed, the poor picture may be caused by the source or signal.
TheTV image does not look as good as Ifyou have an analog cable/satellite box, upgrade toa digital set top box. Use HDMIor Component cables to
itdid in the store, deliverHD (high definition) picture quality.
Cable/Satellite subscribers: TryHD channels from the channel line up.
Air/Cable Antenna connection: Try HDchannels after runningAuto Program.
=& Many HD channels broadcast up scaled SD (Standard Definition) content. The picture quality of up
scaled SD content is low.
Adjust the Cable/Set top box video output resolution to 1080i or720p.
The picture isdistorted: macroblock • Compression of video contents may cause picture distortion, especially on fastmoving pictures such as those in
error, smallblock, dots, pixelization, sports and action movies.
• A weak signal can cause picture distortion. This is not aTV problem.
• Mobile phones usedclose tothe TV (within 3.3ft) may cause noisein the picture on analog and digital channels.
Color iswrong ormissing. • If you're using acomponent connection, make surethe component cables are connected tothe correct jacks.
Incorrect or loose connections maycause color problems or ablank screen.
There ispoor color or brightness. • Adjust the Picture options inthe TV menu. (goto Picture Mode / Color /Brightness / Sharpness)
• Adjust the Energy Saving option in the TVmenu. (goto MENU - Setup - Eco Solution - Energy Saving )
• Try resetting the picture to thedefault picture settings. (go to MENU - Picture - Picture Reset)
There isa dotted line on the edge of • If the picture sizeis set to Screen Fit, change it to 16:9.
the screen. • Change the cable/satellite box resolution.
The picture isblack andwhite. • If you areusing an AV composite input, connect the videocable (yellow) to the Green jack ofComponent Input 1
onthe TV.
When changing channels, the picture • If connected to a cable box, please try toreset it.(Reconnect theAC cord and wait until the cable boxreboots. It
freezes oris distorted or delayed, maytake up to 20 minutes)
Setthe output resolution of thecable boxto 1080i or 720p.
Sound Problems Peflorm the Sound Test to Confirm that yourR/audio is properly operating.
(goto MENU :Supp0rt : Self Diagngsis _Sound Test)
Ifthe audio is OK, the sound problem may be caused by thesource orsignal.
There isno sound or the sound istoo • Check the volume of the device (Cable/Sat Box, DVD, Blu-ray, etc.) connected toyour TV.
low atmaximum volume.
The picture isgood, butthere is no • Ifyou are using anexternal device, check the device's audio output option Ex.you may need to change your
sound, cable box's audio option to HDMI ifthe box is connected to your TV using anHDMI cable.
• Reboot the connected device by reconnecting the device's power cable.
The speakers are making an • Check the cable connections. Make sure avideo cable isnot connected toan audio input.
inappropriate noise. • For Antenna or Cable connections, check the signalinformation. Aweak signal maycause sound distortion.
• Perform the Sound Test asexplained above.
No Picture, NoVideo
TheTV will not turn on. • Make sure the AC power cord issecurely plugged intothe wall outlet and the TV.
• Make sure the wall outlet isworking.
Trypressing the POWER button on the TVto make sure the problem is not the remote.
Ifthe TV turns on, referto 'Remote control does not work' below.
TheTV turns off automatically. • Ensurethe Sleep Timer is setto Off in the Time menu.
• If your PCis connected to theTV, check your PC power settings.
• Make sure the AC power cord is plugged securely into thewall outlet and the TV.
• When you are watching TV connected to an antenna or cable connection, theTV willturn offafter 10 - 15 minutes
ifthere is nosignal.
Other Restrictions Photos
,*Video content will not play,or not play correctly, if ttqere isan error
inthe content or the container.
,* Sound or video may not work if the contents have a standard
bit rate,/frame rate above the compatible Frame/sec listedin the
Supported Video Formats table.
,_If the Index Tableerroneous, the Seek (Jump)function is not
supported.
,*The menu maytake longer toappear ifthe video's bit rate
exceeds 10Mbps.
,*Video content can not be played if there are many contents in 1. Inthe Media Play menu, press the _lior _. button to select
one file. Photos, then press the ENTER _ button.
2. Press the _i/_/_,/_ buttons to select a photo in the filelist.
Supports up to H.264, Level 4.1
H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are
not supported.
MPEG4 SP, ASP :
- Below 1280 x 720:60 frame max
- Above 1280 x 720:30 frame max
H.263 is not supported.
GMC is not support.
Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO
WMA 9 PRO and WMA 10 PRO support 5.1 channel. (LBR
mode of WMA Pro is not supported)
WMA Lossless is not supported.
Music
1. In the Media Play menu, press the _ or !_ button to select
Music, andthen pressthe ENTER_ button.
2. Press the _li/l_/A/_' buttons to select the desired Music in the
file list.
3. Press the ENTER _ button or _ (Play)button.
'_' During music playback, you can search using the _ and
button.
'_' [_ (REW) and [_ (FF) buttons do notfunction during
play.
'_' Media Playonly displays flies with MP3 and PCM file
extension. Other file extensions arenot displayed, even if they
are saved on the same USB device.
'_' If the sound is abnormal when playing MP3files, adjust the
Equalizer in the Sound menu. (An ovePmodulated MP3 file
may cause a sound problem.)
3. Press the ENTER _ button or [_ (Play) button.
'_' NOTE
* While aphoto list isdisplayed, press the _ (Play) / ENTERS4 _
button on the remote control to start a slide show.
* All files in the file list section will be displayed in the slide show.
* During the slide show, files are displayed in order.
* During the slide show, you can adjust the slide show speed
using (_) (REW) or ([_) (FF) button.
* You can move to other files using *_ or _ button.
_' Media Play can play Music files automatically during a Slide
Show if Background Music is set to On.
'_, You cannot change the Mode in Background Music until the
Background Music file has finished loading.
Supported Photo Formats
JPEG Base-line 15360 x 8704
' I Progressive I 1024 x 768
Other Restrictions
" CMYK, YCCK Color space JPEG are not supported.
Playing Multiple Files
[] Playing selected video/music/photo files
1. On the File List screen, highlight a file, and then press the Yellow
button on your remote.
2. Repeat Step 1 to select multiple files.
_' NOTE
* A _ mark appears to the left ofthe selected files.
* To cancel a selection, press the Yellow button again.
* To deselect all selected files, press the TOOLS button, select
Deselect All, and then the ENTER _4_ button.
3. Press the TOOLS button, select Play Selected Contents, and
then press the ENTER _ button.
[] Playing a video/music/photo folder
1. With the folders on your USB device displayed, use the
_i/_-/A/_' buttons to highlight a folder.
2. Press the TOOLS button, select Play Folder, and then press the
ENTER _ button.
-10-
There isno picture/video. Check the cable connections. (Remove and reconnect all cables connected to the TV andexternal devices).
Set your external device's (Cable/Sat Box, DVD, BIu-ray etc) video outputs to match the connections tothe TV
input. Forexample, ifan external device's output is HDMI, it should be connected to an HDMI input on the TV.
Makesure your connected devices are powered on.
Be sureto select the correct input source by pressing the SOURCE button on theremote control.
Reboot the connected device by reconnecting the device's power cable.
RF (Cable/Antenna) Connection
TheTV is not receMng all channels. Make sure the coaxial cable is connected securely.
RunAuto Program to add availablechannels tothe channel list.
go to _,4ENU- Channel -Auto program then select Auto andmake sure the correct Cable TV signal type isset
inthe menu. There are 3options. (STD, HRC and IRC)
Verify theantenna ispositioned correctly.
No Caption on digital channels. Check the Caption Setup menu. Try changing Caption Mode Service f to CCf.
Some channels may not have caption data.
The picture isdistorted: macroblock, Compression of video contents may cause picture distortion, especially on fast moving pictures such as those in
error, smallblock, dots, pixelization, sports and action movies.
Aweak signal can cause picture distortion. This isnot aTV problem.
Others
Purple/green rolling horizontal bars and Remove the left and right audio connections from the set-top-box. If thebuzzing stops, this indicates that the set-
buzzing noise from the TVspeakers with top-box hasa grounding issue. Replace theComponent video cables with an HDMI connection.
Component cable connection.
The picturewill notdisplay in full screen. HD channels willhave black barson either side of thescreen when displaying up scaled SD(4:3) contents.
Black bars onthe top and bottom appearwhen movies that have aspect ratios different from your TVplay on the
TV.
Adjust the picture size option on your external device orchange the TVto fullscreen.
The remote control does not work. Replace the remote control's batteries. Make sure youinsert them withthe polarity (+/-) correct.
Clean the transmission window located on the topof the remote control.
Trypointing the remote directly atthe TV from 5.-6 feet away.
The cable/set top box remote control Program the Cable/Set top boxremote control tooperate theTV. Refer to theCable/Set top box user manual for
does not turn theTV on or off,or adjust the SAMSUNG TV code.
the volume.
A"Mode Not Supported" message Check the supported resolution of the TV and adjust the externaldevice's output resolution accordingly. Referto
appears, resolution settings in this manual.
Caption on theTV menu is greyed out. You cannot select Caption in theTV menu when watching content from adevice connected via HDMI or
Component.
Caption must be activated on the external device.
There isa plastic smell fromthe TV. This smell isnormal and will dissipate in a few days.
TVSignal Strength isunavailable inthe This function isonly available for digitalchannels received through an Antenna / RF/Coax connection.
Self Diagnosis Testmenu.
TVis tilted to the right or leftside. Remove the stand base from the TV and reassemble it.
The Channel menu is grey out The Channel menu is only available when you select the TVsource.
(unavailable).
Yoursettings arelost after 30 minutes or IfTV isin the Store Demo mode, itwill reset audio and picture settings every 30 minutes. Please change from
everytime the TV is turned off. Store Demo mode to Home Use mode using the Plug & Play procedure. Press theSOURCE button to select
TV mode, go to MENU _ Setup _ Plug & Play _ ENTER C_.
You haveintermittent lossof audio or Check the cable connections and reconnect them.
video. Loss of audio or video can becaused by usingoverly rigid or thick cables. Make sure the cables areflexible
enough for long term use. Ifmounting the TV tothe wall, we recommend using cables with 90 degree
connectors.
You seesmall particles when you look This ispart of the product's design and is not adefect.
closely at theedge of the frame of
the TV.
POP (TV'sinternal banner ad) appears Select Home Uee under Plug &Play mode. Fordetails, refer to Plug & Play (Initial Setup).
on thescreen.
'_' This TFT LED panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may
be afew bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.
'_' Watch these troubleshooting on video at www.samsung.com/spsn.
'_' Some functions and pictures shown in this manual are available on specific models only.
'_' Typical power consumption is measured according to Energy Star Program requirements for Televisions.
'_' You can keep your TV in optimum condition byupgrading it with the latest firmware from the Samsung web site (samsung.com
Support _ Downloads). To upgrade, download the firmware to your computer, copy thefirmware file to a USB memory stick,
insert the USB memory stick into the TV's USB slot, and then select Support > Software Upgrade in the TV's menu.
-14-
Media Play - Additional Functions
[] Videos/Music/Photos Play Option menus
When playing a file, press the TOOLS button.
Title
Repeat Mode
Picture Size
Picture Mode
Auto Motion
Plus
Sound Mode
Subtitle
Setting
Audio Format
Audio
Language
Stop Slide
Show /
Start Slide
Show
Slide Show
Speed
Background
Music
Zoom
Rotate
_nformation
You canselect another videofile
to play directly. ,7
You canplay movie and music
files repeatedly. ,7 ,7
You canadjust the picture sizeto
your preference. ,7
You canadjust the picture setting. ,7
You canenhance motion infast
moving scenes. ,7
You canadjust the sound setting. ,7 ,7
You canplay the video with
Subtitles. This function only works
ifthe subtitles havethe same file ,7
name as thevideo.
You canselect the digital audio
output format. ,7
You canchange theaudio
language if thevideo hasmore ,7
than one language.
You canstart orstop a Slide
Show.
You canselect the slide show
speed during the slide show.
You canset and select
background music when
watching a Slide Show.
You canzoom into images infull
screen mode.
You canrotate images infull
screen mode.
You cansee detailed information
about the played file. ,7 ,7
,7
,7
,7
,7
,7
,7
,7
,7
Using the Setup Menu
[] DivX@ Video On Demand :Shows the registration code
authorized for the TV. If you connect to the DNX web site and
register with the lO-digit registration code, you can download
the VOD activation file. Once you play it using Media Play, the
registration is completed.
'_' For more information on DivX@ VOD, visit "http://vod.divx.
corn".
[] Information: Select to vies! information about the connected
USB device.
'_' NOTE
" Standard dimensions for wall mount kits are shown in the table
below.
* When purchasing our wall mount kit, a detailed installation
manual and all parts necessary for assembly are provided.
* Do not use screws that do not comply with the VESA standard
screw specifications.
* Do not use screws that are longer than the standard dimension
or do not comply with the VESA standard screw specifications.
Screws that are too long may cause damage to the inside of the
TV set.
* For wall mounts that do not comply with the VESA standard
screw specifications, the length of the screws may differ
depending on the wall mount specifications.
* Do not fasten the screws too firmly. This may damage the
product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
* Samsung is not liable for product damage or personal injury
when a nomVESA or non-specified wall mount is used or the
consumer fails to follow the product installation instructions.
* Do not mount the TV at more than a 15 degree tilt.
* Always have two people mount the TV on a wall.
LED-TV
19_22
26
32._40
46_60
l 75 X 75 M4
100 X100
200 X200 M6
400 X400 M8
Do not installyour Wall Mount Kitwhile
//_ TVis turned It result in
your
on,
may
personal injury due to electric shock.
Securing the "IV to the Wall
Caution: Pulling, pushing, or climbing onto the TV
may cause the TV to fall. In particular, ensure that your
children do not hang over or destabilize the TV; doing
so may cause the TV to tip over, resulting in serious
injuries or death. Follow all safety precautions provided
on the included Safety Flyer. For added ,stability, instal!
the anti-fall device for safety purposes, as follows.
To prevent the IV from falling
=_ Since ttqenecessary brackets, screws, and string or cable are
not supplied, please purchase these separately.
1. Insert the screws into the wall brackets and firmly fasten them to
ttqewall. Make sure the screws are firmly fixed to ttqewall.
We strongly recommend you drive ttqescrews into astud.
Installing the Wall Mount Kit
The wall mount kit (sold separately) allows you to mount the TV on
the wall.
For detailed information about installing the wall mount, see
the instructions provided with the wall mount items. Contact a
technician for assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the
product or injury to yourself or others ifyou elect to install the wall
mount on your own.
Wail Mount Kit Specifications (VESA)
'_' The wall mount kit is not supplied, but sold separately.
Install your wall mount on a solid wall perpendicular to the floor.
When attaching to other building materials, please contact your
2. Using screws, insert the screws through the TV brackets, and
then fasten the screws to the top VESA screw holes on the back
of the TV.
3. Connect the brackets on the TV andthe brackets on the wall
with astrong string or cable, and then tie the string or cable
tightly to the brackets.
_' Verify all connections are properly secured. Periodically check
the connections for any sign of fatigue or failure. Ifyou have
any doubt about the security of your connections, contact a
professional installer.
'_ Install the TV close to the wall so that it does notfall.
'_' Connect the string orcable so that the brackets on the wall
are atthe same height or lower than the brackets on the TV.
Untie the string or cable before moving the TV.
'_' To purcase a TVHolder kit, contact Samsung customer care.
nearest dealer. Ifyou install the TV on aceiling or slanted wall, it - 11-
may falland result insevere personal injury.
Storage and Maintenance
'_' Ifa sticker was attached to the TV screen, some debris can remain after you remove the sticker. Please clean it before watching
the TV.
'_' The exterior and screen of the product can get scratched during cleaning. Be sure towipe the exterior and screen carefully using
a soft cloth to prevent scratches.
Do not spray water directly onto the
product. Any liquid tha tgoes into th e
produc t may cause a failure, fire, or
electric shock.
Clean the product with a soft cloth
dampened with in a small amount of
water. Do not use aflammable liquid
(e.g. benzene, thinners)or a cleaning
agent.
License
rM
TheaterSound, SRS and the _ symbol are i SRS TbeaterSound provides the most immersive
SrS_ trademarks of SRS Labs, h_c. i surround sound experience from the l_/'s built-in
TheaterSo_nd TheaterSound technology isincorporated under i speakers, while maintaining steady volume and delivering
licence from SRS Labs, hqc. i rich bass and clear dialog.
_| _- DNX Certified@ to play DNX@ video up to HD 1080p, including premium content.
HD
ABOUT DIVXVIDEO: DNX@ isa digital video format created by DNX, LLC, a subsidiary ofRovi Corporation. This isan official DNX
Certified@device that playsDNX video. Visit dNx. corn for more information and software tools to convert your files into DNXvideos.
ABOUT DIVXVIDEO_ON_DEMAND: This DNX Certified@ device must be registered inorder toplay purchased DNXVideo_om
Demand (VOD)movies. To obtain your registration code, locate the DNXVOD section in your device setup menu. Go to vod. dNx.
corn for more information on how to complete your registration. Covered by oneor more of the following U.S. patents : 7,295,673;
7,460,668; 7,515,710; 7,519,274 DivX@,DNX Certified@ andassociated Iogos aretrademarks of Rovi Corporation or its subsidiaries
and areused under license.
[_ DOLB¥
DIGITAL PLUS I
PULSE I
Manufactured under license from Dolby Laboratories. Dolby andttqe double_D symbol are trademarks of Dolby
Laboratories.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and
worldwide patents issued & pending. DTS, ttqe Symbol, & DTS and the Symbol together are registered trademarks
2.0+Diaital Out & DTS 2.0+Digital Out isa trademark of DTS, Inc. Product includes software. @ DTS, Inc. All Rights Reserved.
Open Source License Notice
Open Source used in this product can be found on the following webpage. (http://opensoume.samsung.com) Open Source License
Notice is written only English.
Tosend inquiries andrequests for questions regardingopen sources, contact Samsung viaEmail (oss.request@samsung.com).
I_ This product uses some eoftware programs which aredistributed under the Independent JPEG Group.
ICULicense - ICU1.8.1 and later
COPYRIGHTAND PERMISSION NOTICE
Copyright (c)1995-2008 International Business Machines eorperation and othersAll rights reserved.
Permission ishereby granted,free of charge, toany person obtaining acopy ofthis sofb_vareandassociated documentationfiles (the "Software"),to deal inthe Software
without restriction, includingwitheut limitation the rightsto use, copy,modify, merge, publish, distribute, and/or sellcopies ofthe Seftware, and topermit persons to
whom the Softwareis furnishedto do se, provided thatthe above copyright netice(s)and thispermissien notice appear inall copies ofthe Software andthat both the
above cepyright notice(s)and thispermission netice appear in suppertingdocumentation.
THE SOFTWAREISPROVIDED "AS IS",WITHOUT WARRANTYOF ANYKIND, EXPRESSOR IMPLIED, INCLUDINGBUT NOTLIMITED TOTHE WARRANTIES
OF MERCHANTABUT_, FITNESSFORA PARTICULAR PURPOSEAND NONINFRINGEMENT OFTHIRD PARTYRIGHTS.IN NO EVENTSHALL THECOPYRIGHT
HOLDER ORHOLDERS INCLUDEDIN THISNOTICE BE LIABLEFOR ANYCLAIM, ORANY SPECIAL INDIRECTOR CONSEQUENTIALDAMAGES, OR ANY
DAMAGES WHATSOEVERRESULTINGFROM LOSS OFUSE, DATAORPROFITS, WHETHERIN AN ACTIONOF CONTRACT,NEGLIGENCE OROTHER TORTIOUS
ACTION,ARISING OUT OFOR INCONNECTION WITH THEUSE ORPERFORMANCE OFTHIS SOFTWARE.
Except ascontained in thisnotice, the nameof a copyright holdershall not beused in advertisingor otherwise topromote the sale, useor other dealingsin thisSoftware
without priorwritten authorization ef thecepyright holder.
Alltrademarks and registered trademarks mentioned hereinare theproperty of their respectiveowners.
Kensington Lock
The Kensington Lock is not supplied by Samsung. It is a device
used to physically fix the system when using it in a public place.
Refer to the manual provided with the Kensington Lock for additional
information on proper use. IBM
_' Please find a "i_" icon on the rear of the TV. The Kensington
slot is beside the "i_" icon. MAC
The position and color may differ depending on ttqe model.
Assembling the Wire Holder stand
VESA DMT
Display Modes (HDMI/DVl Input)
Optimal resolution is 1920 x 1080@60Hz.
640 x350 31 469 70086 25175
720 x400 31 469 70087 28322
640 x480 35000 66667 30240 /
832x 624 49726 74551 57284
1152x 870 68681 75062 100000
640 x480 31 469 59940 25175 /
640 x480 37861 72809 81500 /
640 x480 37500 75000 31500 /
800 x600 37879 60317 40000 +/+
800x 600 48 077 72188 50000
800x 600 46 875 75000 49500
1024x 768 48363 60004 65000 /
1024x 768 56476 70069 75000
1024x 768 60023 75029 78750
1152x 864 67500 75000 108000 +/+
1280x 720 45000 60000 74250 +/+
1280x 800 49702 59810 83500 /+
1280x 1024 63 981 60020 108000
1280x 1024 79 976 75025 135000
1366x 768 47712 59790 85500 +/+
1440x 900 55935 59887 106500 /+
1600x 900RB 60000 60000 108000 +/+
1680x 1050 65 290 59954 146250
1920x 1080 67 500 60000 148500
Troubleshooting
If the TV seems to have a problem, first review this listof possible )roblems and solution. If none of these troubleshooting tips apply, visit
samsung.com, ttqen click on Support, or call Samsung customer service at 1_800_SAMSUNG.
Flickering and Dimming Ifyour Samsung Television is flickering or dimming sporadically, you may need to disable some of its energy efficient
features likethe Eco Sensor or the Energy Saving feature. Follow the steps below with your remote to turn these
features offor on.
_,Energy saving :Menu _ Setup _ Eco Solution _ Energy Saving _Select Settings
_,Eco Sensor : Menu _ Setup _ Eco Solution _ Eco Sensor _Select Settings
Component Connections / Ifyou find that the color on your Samsung television's screen is notcorrect or black and white, first runa Self
Screen Color Diagnosis Teston the TV to makesure there are no device issues.
_,Self Diagnosis : User Menu _ Support _ Self Diagnosis _ Picture Test
_,If the test isok, try making sure ;
_,Your connections are allconsistent. For example, if you've used theAV In jack on your TV,make sure you have
used the AV Outjack on your video source.
_,Try making sure you have connected tothe correct jacks. For example, ifyou use the Component jacks, labeled
Pb, Pr,and Y,to connect your TVand video source, make sure youhave connected the blue Pb jack on the
video source to the blue Pb jack onthe TV, the red Prjack on the source to the red Prjack on the TV.
Screen Brightness Ifyou find thatthe colors on your Samsung TV are correct but just alittle too dark or bright, there are some settings
/ou should check before calling for arepair.
_,Backlight, Contrast, Brightness, Sharpness, Color, Tint and so on. Go to "Picture" inthe Menu, and then try
adjusting these options.
Unwanted Powering off IfyourSamsung TV appears toturn offby itself, there may bean issue with either yourTimer settings or your Eco
friendly No Signal PowerOff feature.
First makesure the Sleep Timer is not accidentally set. The Sleep Timerlets you fall asleepwith theTV still on
knowing that it willturn off after a certain period of timeand not waste energy.
_,Sleep Timer : User Menu _ Setup _ Time _ Sleep Timer
Ifthe Sleep Timer is not activated, you may have engaged the No Signal Power Off or Auto Power Off feature.
_,No Signal Power Off : User Menu _ Setup _ Eco Solution _ No Signal Power
_,Auto Power Off : User Menu _ Setup _ Eco Solution _ Auto Power Off
-12-
Environmental I
Considerations I
Operating Temperature
Operating Humidity I
Storage Temperature
Storage Humidity
50°F to 104°F (t0°C to 40°C)
10% to 80%, non-condensing
-4°F to 113°F (-20°C to 45°C )
5% to 95%, non-condensing
Display Resolution
1920x 1080
46" Class 55" Class
_5.9" measured diagonally) (54.6" measured diagonally)
40" Class 60" Class
(Diagonal) (40.0" measured diagonally) (60.0" measured diagonally)
Sound
Output 10W x2
Dimensions (W XD x H)
38.2 X3.6 X 21.8 inches 41.7 X3.7 X 24.7inches 49.2 X 3.7 X28.9 inches 54.0 X 3.7X 31.7 inches
(927.6X 93.3 X 555.5 (ram)) (1059.8 X 94.3 X 629.4 (ram)) (1250.6X 94.3 X 735.7 (ram)) (1374.1 X94.3 X 807.0 (mm))
With stand 38.2 X 8.9 X23.8 inches 41.7 X 8.9X 26.7 inches 49.2 X8.9 X 31.0 inches 54.0 X 12.9 X 33.8 inches
(927.6X227.6X606.5(mm)) (1059.8X227.6X680.3(mm)) (1250.6X227.6X789.2(mm)) (1374.1X329.8X859.0(mm))
Without Stand 20.2 Ibs (9.2 kg) 26.4Ibs (12.0 kg) 45.6 Ibs (20.7 kg) 54.6 Ibs (24.8 kg)
With Stand 24.6 Ibs (11.2 kg) 30.8 Ibs (14.0 kg) 51.3 Ibs(23.3 kg) 60.4 Ibs (27.4 kg)
,L, Design andspecifications are subject to change without prior notice.
,L, This device is a Class B digital apparatus.
,L, For information about power supply, and more about power consumption, refer to the label attached to the
product.
,L, Typical power consumption is measured according to Energy Star Program requirements forTelevisions.
,L, Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our
website: www.samsung.com/recyclingdirect or call, (877)278-0799.
[] JACK PANEL DETAIL / REAR VIEW
(Unit: inches)
UN40EH6000 / UN40EH6050 9.6 5.8 5.8 24.1 7.8 7.8
UN46EH6000 / UN46EH6050 11.6 5.2 7.3 29.8 15.7 15.7
UN55EH6000 / UN55EH6050 15.5 6.1 7.6 36.4 15.7 15.7
UN60EH6000 / UN60EH6050 16.7 8.6 8.8 38.5 15.7 15.7
NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions
prior to performing installation of your TV. Not responsible for typographical or printed errors.
@ 2012 Samsung Electronics America, Inc
-13- -15- -16-
Loading...
