Page 1

SPEED DOME CAMERA

User Manual

SCP-2370RH

Page 2

SPEED DOME CAMERA

User Manual

Tradem a rk

is the registered logo of Samsung Techwin Co., Ltd. The name of this product is the registered trademark of Samsung Techwin Co., Ltd. Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Samsung Techwin shall have the right to change the contents of this manual without prior notice for the purpose of enhanced performance.

Warranty

If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve the problem for free of charge. The warranty period is 3 years. However, the followings are excluded:

If the system behaves abnormally because you run a program irrelevant to the system operation.

•

Deteriorated performance or natural worn-out in process of time

•

Design and specifications are subject to change without prior notice.

Page 3

safety information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

WARNING

To reduce the risk of ﬁ re or electric shock, do not expose this appliance to rain or moisture.

•

To prevent injury, this apparatus must be securely attached to the ﬂ oor/wall in accordance with the installation

•

instructions.

- REPLACE WITH SAME TYPE 250V T4AL FUSE (F101,F201,F1)

WARNING

Be sure to use only the standard adapter that is speciﬁ ed in the speciﬁ cation sheet.

Using any other adapter could cause ﬁ re, electrical shock, or damage to the product. Incorrectly connecting the power supply or replacing battery may cause explosion, ﬁ re, electric shock, or

damage to the product. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat

generation or ﬁ re. Securely plug the power cord into the power receptacle. Insecure connection may cause ﬁ re.

When installing the camera, fasten it securely and ﬁ rmly. The fall of camera may cause personal injury.

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers ﬁ lled with water

on top of the camera. Doing so may cause personal injury due to ﬁ re, electric shock, or falling objects. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause ﬁ re or electric shock.

If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately

disconnect the power source and contact the service center. Continued use in such a condition may cause ﬁ re or electric shock.

If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product

in any way. (SAMSUNG is not liable for problems caused by unauthorized modiﬁ cations or attempted repair.)

When cleaning, do not spray water directly onto parts of the product. Doing so may cause ﬁ re or electric shock.

10.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit.

● SAFETY INFORMATION

CAUTION - Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

CAUTION

Do not drop objects on the product or apply strong blows to it. Keep away from a location subject to

excessive vibration or magnetic interference. Do not install in a location subject to high temperature (over 55°C), low temperature (below -50°C), or high

humidity. Doing so may cause ﬁ re or electric shock. If you want to relocate the already installed product, be sure to turn off the power and then move or reinstall it.

Remove the power plug from the outlet when there is a lighting storm. Neglecting to do so may cause ﬁ re

or damage to the product.

English - 3

Page 4

safety information

Keep out of direct sunlight and heat radiation sources. It may cause ﬁ re.

Install it in a place with good ventilation.

Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the

CCD image sensor. Apparatus shall not be exposed to dripping or splashing and no objects ﬁ lled with liquids, such as vases,

shall be placed on the apparatus. Do not expose the camera to radioactivity. Radioactivity exposure may damage the CCD.

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :

This device may not cause harmful interference, and

This device must accept any interference received including interference that may cause undesired operation.

CAUTION

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

IC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian Interference.-Causing Equipment Regulations of ICES-003.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.) This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, please separate batteries from other types of

waste and recycle them through your local, free battery return system.

4_ safety information

Page 5

important safety instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, or other apparatus (including

ampliﬁ ers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

Only use attachments/accessories speciﬁ ed by the manufacturer.

10.

Use only with the cart, stand, tripod, bracket, or table speciﬁ ed by the manufacturer, or

11.

sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

● IMPORTANT SAFETY INSTRUCTIONS

Unplug this apparatus during lightning storms or when unused for long periods of time.

12.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the apparatus has been

13.

damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Apparatus shall not be exposed to dripping or splashing and no objects ﬁ lled with liquids, such as vases, shall be placed on the apparatus

WARNING

To prevent injury, this apparatus must be securely attached to the ﬂ oor/wall in accordance with the installation instructions.

English - 5

Page 6

CAUTION

These servicing instructions are for use by qualiﬁ ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualiﬁ ed to do so.

DETAILED WARNINGS AND CAUTIONS

Avoid operating the camera for long durations under high temperatures and in high humidity. Excessive heat can shorten the lifespan of the camera components.

Do not install or place the camera near any heat sources.

Do not expose the camera to a direct light. If a strong light such as spot light reﬂ ects on the display, this may cause blooming or smear on the display that will result in discoloration due to a deteriorated ﬁ lter.

Do not drop the camera or subject it to physical shock or vibration; this can cause serious damage to the camera.

When installing the camera near a power line, make sure to keep at least 1 meter distance from the power line, or earth an additional metal pipe to separate the camera from the power source.

Install this camera on the ceiling. Installing it on the ground or a unleveled location may cause product malfunctions and shorten its lifespan.

Avoid installing and operating the camera in the following places.

Places whose temperature exceed the camera’s recommended range. ( -50º ~ 55º)

Places where drastic temperature changes occur: e.g. Near an air conditioner.

Places that are exposed to steam, oil, and inﬂ ammable substances: e.g. Inside a kitchen.

Places that are exposed to radioactivity, X-rays, strong electric waves, and electro-magnetic waves.

Places that are exposed to outdoor air contaminants: e.g. Dust and car exhaust.

Places in high humidity.

Places that are exposed to corrosive gas: e.g. Next to the sea.

This camera is not equipped with a power switch. Plug in the camera only after the installation is complete.

The pan/tilt position may be reverse momentarily when it blows a strong wind such as typhoon.

CAUTIONS FOR OPERATING TEMPERATURE

The camera cannot operate properly at temperatures lower than -50°.

Even if the surrounding temperature is -50° or higher, the camera may not thaw itself and operate

properly depending on the installation environment.

Always keep the power on, so the camera can maintain its internal temperature at -10° or higher.

If the product is kept at a low temperature, it may take a max of 3 hours to warm up for normal

operation.

6_ important safety instructions

Page 7

The video signal will be not played with a message of “Wait to warm up (xx Left)” on the dark screen, which will cause a system failure.

Ú For maximum 2 hours

The zooming speed of the IR light projector will be deteriorated in a temperature of less than -40

The “Wait to warm up(xx Left)” message disappears. And the product will be reset to operate normally.

Both Sequence and Turbo functions will be restricted; only the manual P/T operations will be enabled.

Ú For maximum 1 hour

Any of the Sequence and Turbo

functions will be enabled.

degrees (Celsius).

● IMPORTANT SAFETY INSTRUCTIONS

Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents Samsung Techwin’s will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive.

English - 7

Page 8

contents

INTRODUCTION

CONNECTION &

INSTALLATION

SETUP

9 Features 10 What’s included 11 Component Names and Functions

12 Camera Wiring Interface Board 13 Camera and Appliances Wiring Diagram 15 How to Set Up Protocols and ID DIP

Switches

16 Communication Protocol DIP Switch

Settings (SW2)

19 Camera ID DIP Switch Settings (SW1) 27 Preparing Adapter and Cables 28 Product Conﬁ gurations 29 Preparing & Installing Camera Bracket 30 Optional Accessories for Installation 33 Installation

35 Interface Symbols 36 Using and setting the menus 37 OSD Menu Chart 38 Camera Setup 48 Sequence Setting 58 P/T Setting 65 OSD Setting 66 Alarm Setting 69 IR Illuminator 71 Initialize 72 Password setting 72 Status

TROUBLESHOOTING

PRODUCT SPECIFICATIONS

8_ contents

73 Troubleshooting

76 Product Speciﬁ cations) 78 D

imensions

Page 9

introduction

FEATURES

A/F 37x Optical Zoom

The built-in 37x optical zoom lens with auto-focus is combined with a 16x digital zoom, providing a maximum of 592 zoom.

Versatile protocols and coaxial communication

RS-422/485, Coaxial communication methods are supported.

RS-422/485 (10 Protocol) : Auto Detected, SAMSUNG-T, SAMSUNG-E, Pelco (D/P), Panasonic, Vicon,

Honeywell, AD, GE, BOSCH

Coaxial communication: Pelco Coaxitron (Camera ID DIP switches (SW1) are all positioned to OFF)

Wide Range Auto Security Functions

Multiple Preset Function Saving : Up to 12 camera image properities can be saved individually to provide high quality pictures.

Image Holding : When moving between presets in Group and Tour functions, using this Preset Freeze function holds the image status and helps the screen observer relieve visual fatigue.

PTZ Trace : Patterns operated with the joystick can be saved and replayed by users.

Swing : Using the Swing function commands the camera to move between 2 selected locations, monitoring the route.

Group Search : Maximum 128 Preset positions are toured in order.

Tour Search : Maximum 6 Group Search functions are toured in order.

● INTRODUCTION

Digital Flip

The Digital Flip function is useful to monitor moving objects or people passing directly under the camera. When an object or a person passes directly under the camera, its tilt motor follows the object or person over 90 degrees to the other side of the tilt area without panning. The screen inversion starts to occur at 90 degrees or higher is digitally adjusted.

Smart P/T

The Smart P/T function automatically adjusts the control speed of the Pan and Tilt functions according to the current zoom ratio. It is useful to adjust the functions manually for detailed controls when monitoring at high zoom ratios.

Day & Night

With its daytime & nighttime switch and Sens-Up functions based on the ICR (Infrared Cut ﬁ lter Removal) method, the camera provides high quality pictures regardless of whether it is day or night.

Sens-Up increases the CCD sensitivity by electrically extending the camera’s exposure time.

Day & Night enables you to select between color and B/W modes depending on the lighting conditions.

Highly durable built-in housing

This IP66-rated built-in housing is easy to install, and protects the product from a full range of harsh outside conditions. The high performance built-in fan/heater enables the product to operate under extreme temperatures between -50° ~ 50° .

English - 9

Page 10

introduction

Preset Position Saving and Loading

Up to 255 preset positions can be set.

Camera Backup

The configuration file of the camera can be saved for later use. This is useful when the camera or its install base are damaged or malfunctions occur.

Area Masking

If a monitoring location includes a highly private area, the area can be selectively masked on the screen.

IR Illuminator

You can use the IR Illuminator to configure the surveillance settings against a low contrast scene. The illuminator can be controlled in various ways within up to 100 meters in distance.

WHAT’S INCLUDED

Check if the following items are included in the product package.

Appearance Item Name Quantity Description

10_ introduction

Main Body 1 -

CD Manual 1 Multilingual User Manual

User Manual 1 English User Manual

Hexagon screw 3

L Wrench 1

Used for attaching the installation base

to the camera

Used for fixing the installation base after

attaching it to the camera

Page 11

COMPONENT NAMES AND FUNCTIONS

Front Back

● INTRODUCTION

➊

Bottom

➋

➌

➊ Safety Wire Holder

➋ SW2: Communication DIP Switch

➌ SW1: ID DIP Switch

Ú For the DIP switch settings, please refer to the

“Installing Your Camera” on Page 15~19.

English - 11

Page 12

connection & installation

CAMERA WIRING INTERFACE BOARD

For the camera wiring, please refer to the picture below.

(When using coaxial communication, a separate control signal connection is not required.)

Alarm/AUX

2.NC

2.NO

2.COM

IN4

Alarm Input 5~8

IN5

IN6

GND

IN7

IN8

7*%&0

+

*/

*/

(/%

*/

*/

39 39 59 59

%

2.NC

1.COM

2.NO

2.COM

1.NC

1.NO

GND

IN4

IN3







(/%$0./0









Alarm/ AUX Output 2

Alarm/ AUX Output 1

Alarm Input 1~4

Control Signal Connection

• RS485 Communications Camera

RX+ RX-

• RS422 Communications Camera

RX+ RX-

TX+

TX-

The max capacity of the Alarm OUT/AUX OUT ports are 30VDC/2A, 125VAC/0.5A, and 250VAC/0.25A, respectively.



Connecting the power connector and GND incorrectly to the NC/NO and COM ports may cause a short circuit and ﬁ re, damaging the camera.

Communications and Alarm/AUX

3.COM

39 39

3.NO

Refer to the below Control Signal Connection chart

Controller or DVR

TXD+ TXD-

Controller or DVR

TXD+

TXD-

RXD+ RXD-

Power Supply

AC24V 2.5A

Power Input

Ground

Alarm/AUX Output 3



Never use installation base for previous models (for SCP-2370/3370 and SPU-3750T/3700 models) with this product, it is not compatible with this product. Otherwise, applying power may lead to short circuit and result in ﬁ re or damage to the product.

12_

connection & installation

Page 13

CAMERA AND APPLIANCES WIRING DIAGRAM

Connecting to the Samsung Techwin’s “Stand Alone DVR”

RS-485 :

Camera

RX+

RX-

Stand Alone DVR

T(TXD)+

T(TXD)-

RS-422 :

Camera

RX+

RX-

TX+

TX-

● CONNECTION & INSTALLATION

Stand Alone DVR

T(TXD)+

T(TXD)-

R(RXD)+

R(TXD)-

English - 13

Page 14

connection & installation

Connecting to the Samsung Techwin Controller SPC-6000

RS-485 :

RS-422 :

Camera

RX+

RX-

TX RX TX RX

+- +- +- + -

Camera

TXD+ TXD-

TX+

TX-

RX+

RX-

TX RX TX RX

+- +- +- + -

S E

A R

C H

M U

L T I

A M

M O

PTZ

S E

T UP

F UN

E N

S C

C L

N E

A R

F A

WID

E L

RXD+ RXD-

TXD+ TXD-

M E

N U

P R E

S ET

O UP

T R

O PEN

14_

connection & installation

Page 15

HOW TO SET UP PROTOCOLS AND ID DIP SWITCHES

You can control various settings of the camera system using the Communication and ID DIP switches. Before installing the product, please set up the DIP switches according to the installation environment.

Detach the camera frame from the install base, and place the bottom of the frame toward you as shown in the

picture below.

Set the switches according to your installation environment. For more detailed setup information, please refer

to the chart on the next page.

The camera may malfunction if the switches are not fully turned On/Off; please double check the switches

before ﬁ nishing setup.

Communication Protocol DIP Switch(SW2)

● CONNECTION & INSTALLATION

Camera ID DIP Switch(SW1)

English - 15

Page 16

connection & installation

COMMUNICATION PROTOCOL DIP SWITCH SETTINGS (SW2)

SW2

SW2 Pin No. Purpose

1 ~ 4 Protocol Settings

5~6 Baud Rate Settings

7 Transfer Method (RS-485/422) Settings

8 Response Mode Settings

9~10 Backup Mode Settings

11~12 Termination Settings

OFF

Protocol Settings

Select a communication protocol for the camera.

No Protocol SW2-#1 SW2-#2 SW2-#3 SW2-#4

1 Auto Detected OFF OFF OFF OFF

2 Samsung-T OFF OFF OFF ON

3 Samsung-E OFF OFF ON OFF

4 Pelco-D OFF OFF ON ON

5 Pelco-P OFF ON OFF OFF

6 Panasonic OFF ON OFF ON

7 Vicon OFF ON ON OFF

8 Honeywell OFF ON ON ON

9 AD ON OFF OFF OFF

10 GE ON OFF OFF ON

11 Bosch ON OFF ON OFF

16_

connection & installation

Page 17

Baud Rate Settings

Select the transfer speed of a selected communication protocol.

No Baud Rate (BPS) SW2-#5 SW2-#6

1 2,400 ON ON

2 4,800 ON OFF

3 9,600 OFF OFF

4 19,200 OFF ON

Communication Method Settings

Select a communication method for the camera.

Function ON OFF

SW2- #7 Transfer Mode Switch RS-422 (4Wire) RS-485 (2Wire)

Communication Response Settings

Select a communication response method for the camera and controller: Response or No Response.

Function ON OFF

SW2- #8 Response Mode Switch Response No Response

● CONNECTION & INSTALLATION

Termination Settings

To prevent the attenuation of communication signals between the camera and controller, the items at the end of line must be set up with the termination settings.

Camera Input Position

Termination of Longest Path (RS-422)

Termination of Longest Path (RS-485)

On the Path OFF OFF

Example of terminal setting

SW2- #11 SW2- #12

ON ON

ON OFF

If using RS-422, SW2-#11: ON /SW2-#12: ON for camera 16

If using RS-485, SW2-#11: ON / SW2-#12: OFF for camera 16

English - 17

Page 18

connection & installation

Camera Backup Settings

These settings are useful when the camera or its install base are damaged or a malfunction has occurred.

When replacing the camera or its install base, you can transfer existing presets and sequence information to the replacement using these settings.

Backup Function

Backup(IBD) OFF OFF

Backup(DIB) ON OFF

Backup Disable - ON

Backup(IBD) : Enables transferring the current camera's sequence information to a new camera.

Backup(D

IB: Install base, D: Dome Camera

■



IB) : Enables transferring the current camera's sequence information to a new install base.

[Current Time] is not backed up from install base to camera.

For this model, all DIP switches are set to OFF by factory default. Each of the default settings will be grayed out in the



applicable menu. If you want to use a third-party controller for controlling the camera, contact us at the call center or visit our website for



details. AD Protocol Control Method



Camera OSD On: 3+Auxiliary On

1. Camera OSD Off: 3+Auxiliary Off

2. Enter: IRIS Open

3. ESC: IRIS Close

For more information about the protocols, refer to our ofﬁ cial website.



http://www.samsungtechwin.com/

SW2- #9 SW2- #10

18_

connection & installation

Page 19

CAMERA ID DIP SWITCH SETTINGS (SW1)

Assign a unique number to each camera to identify itself from the others.

In coaxial communication systems, the camera will work normally only if the Camera ID DIP switches (SW1) are all positioned to OFF.

OFF

SW1

● CONNECTION & INSTALLATION

The switch is set to “ID: 1” by default, and 7 switches other than

switch 1 are all set to OFF.

Each switch has a unique value, and the board ID is the sum of

the values of the switches.



Refer to the example below for the board ID.





Example 1













Example 2 Example 3

















OFF

































1+2 = 3 (Board ID = 3) 4+32 = 36 (Board ID = 36)

Use a unique ID for each Camera.



1+2+4+8+16+32+64+128

= 255 (Board ID = 255 )

English - 19

Page 20

connection & installation

Camera ID Chart

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

1 ON OFF OFF OFF OFF OFF OFF OFF 2 OFF ON OFF OFF OFF OFF OFF OFF 3 ON ON OFF OFF OFF OFF OFF OFF 4 OFF OFF ON OFF OFF OFF OFF OFF 5 ON OFF ON OFF OFF OFF OFF OFF 6 OFF ON ON OFF OFF OFF OFF OFF 7 ON ON ON OFF OFF OFF OFF OFF 8 OFF OFF OFF ON OFF OFF OFF OFF

9 ON OFF OFF ON OFF OFF OFF OFF 10 OFF ON OFF ON OFF OFF OFF OFF 11 ON ON OFF ON OFF OFF OFF OFF 12 OFF OFF ON ON OFF OFF OFF OFF 13 ON OFF ON ON OFF OFF OFF OFF 14 OFF ON ON ON OFF OFF OFF OFF 15 ON ON ON ON OFF OFF OFF OFF 16 OFF OFF OFF OFF ON OFF OFF OFF 17 ON OFF OFF OFF ON OFF OFF OFF 18 OFF ON OFF OFF ON OFF OFF OFF 19 ON ON OFF OFF ON OFF OFF OFF 20 OFF OFF ON OFF ON OFF OFF OFF 21 ON OFF ON OFF ON OFF OFF OFF 22 OFF ON ON OFF ON OFF OFF OFF 23 ON ON ON OFF ON OFF OFF OFF 24 OFF OFF OFF ON ON OFF OFF OFF 25 ON OFF OFF ON ON OFF OFF OFF 26 OFF ON OFF ON ON OFF OFF OFF 27 ON ON OFF ON ON OFF OFF OFF 28 OFF OFF ON ON ON OFF OFF OFF 29 ON OFF ON ON ON OFF OFF OFF 30 OFF ON ON ON ON OFF OFF OFF 31 ON ON ON ON ON OFF OFF OFF 32 OFF OFF OFF OFF OFF ON OFF OFF 33 ON OFF OFF OFF OFF ON OFF OFF 34 OFF ON OFF OFF OFF ON OFF OFF 35 ON ON OFF OFF OFF ON OFF OFF 36 OFF OFF ON OFF OFF ON OFF OFF 37 ON OFF ON OFF OFF ON OFF OFF 38 OFF ON ON OFF OFF ON OFF OFF

20_

connection & installation

Page 21

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

39 ON ON ON OFF OFF ON OFF OFF

40 OFF OFF OFF ON OFF ON OFF OFF

41 ON OFF OFF ON OFF ON OFF OFF

42 OFF ON OFF ON OFF ON OFF OFF

43 ON ON OFF ON OFF ON OFF OFF

44 OFF OFF ON ON OFF ON OFF OFF

45 ON OFF ON ON OFF ON OFF OFF

46 OFF ON ON ON OFF ON OFF OFF

47 ON ON ON ON OFF ON OFF OFF

48 OFF OFF OFF OFF ON ON OFF OFF

49 ON OFF OFF OFF ON ON OFF OFF

50 OFF ON OFF OFF ON ON OFF OFF

51 ON ON OFF OFF ON ON OFF OFF

52 OFF OFF ON OFF ON ON OFF OFF

53 ON OFF ON OFF ON ON OFF OFF

54 OFF ON ON OFF ON ON OFF OFF

55 ON ON ON OFF ON ON OFF OFF

56 OFF OFF OFF ON ON ON OFF OFF

57 ON OFF OFF ON ON ON OFF OFF

58 OFF ON OFF ON ON ON OFF OFF

59 ON ON OFF ON ON ON OFF OFF

60 OFF OFF ON ON ON ON OFF OFF

61 ON OFF ON ON ON ON OFF OFF

62 OFF ON ON ON ON ON OFF OFF

63 ON ON ON ON ON ON OFF OFF

64 OFF OFF OFF OFF OFF OFF ON OFF

65 ON OFF OFF OFF OFF OFF ON OFF

66 OFF ON OFF OFF OFF OFF ON OFF

67 ON ON OFF OFF OFF OFF ON OFF

68 OFF OFF ON OFF OFF OFF ON OFF

69 ON OFF ON OFF OFF OFF ON OFF

70 OFF ON ON OFF OFF OFF ON OFF

71 ON ON ON OFF OFF OFF ON OFF

72 OFF OFF OFF ON OFF OFF ON OFF

73 ON OFF OFF ON OFF OFF ON OFF

74 OFF ON OFF ON OFF OFF ON OFF

75 ON ON OFF ON OFF OFF ON OFF

76 OFF OFF ON ON OFF OFF ON OFF

77 ON OFF ON ON OFF OFF ON OFF

● CONNECTION & INSTALLATION

English - 21

Page 22

connection & installation

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

78 OFF ON ON ON OFF OFF ON OFF 79 ON ON ON ON OFF OFF ON OFF 80 OFF OFF OFF OFF ON OFF ON OFF 81 ON OFF OFF OFF ON OFF ON OFF 82 OFF ON OFF OFF ON OFF ON OFF 83 ON ON OFF OFF ON OFF ON OFF 84 OFF OFF ON OFF ON OFF ON OFF 85 ON OFF ON OFF ON OFF ON OFF 86 OFF ON ON OFF ON OFF ON OFF 87 ON ON ON OFF ON OFF ON OFF 88 OFF OFF OFF ON ON OFF ON OFF 89 ON OFF OFF ON ON OFF ON OFF 90 OFF ON OFF ON ON OFF ON OFF 91 ON ON OFF ON ON OFF ON OFF 92 OFF OFF ON ON ON OFF ON OFF 93 ON OFF ON ON ON OFF ON OFF 94 OFF ON ON ON ON OFF ON OFF 95 ON ON ON ON ON OFF ON OFF 96 OFF OFF OFF OFF OFF ON ON OFF 97 ON OFF OFF OFF OFF ON ON OFF 98 OFF ON OFF OFF OFF ON ON OFF

99 ON ON OFF OFF OFF ON ON OFF 100 OFF OFF ON OFF OFF ON ON OFF 101 ON OFF ON OFF OFF ON ON OFF 102 OFF ON ON OFF OFF ON ON OFF 103 ON ON ON OFF OFF ON ON OFF 104 OFF OFF OFF ON OFF ON ON OFF 105 ON OFF OFF ON OFF ON ON OFF 106 OFF ON OFF ON OFF ON ON OFF 107 ON ON OFF ON OFF ON ON OFF 108 OFF OFF ON ON OFF ON ON OFF 109 ON OFF ON ON OFF ON ON OFF 110 OFF ON ON ON OFF ON ON OFF 111 ON ON ON ON OFF ON ON OFF 112 OFF OFF OFF OFF ON ON ON OFF 113 ON OFF OFF OFF ON ON ON OFF 114 OFF ON OFF OFF ON ON ON OFF 115 ON ON OFF OFF ON ON ON OFF 116 OFF OFF ON OFF ON ON ON OFF

22_

connection & installation

Page 23

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

117 ON OFF ON OFF ON ON ON OFF 118 OFF ON ON OFF ON ON ON OFF 119 ON ON ON OFF ON ON ON OFF 120 OFF OFF OFF ON ON ON ON OFF 121 ON OFF OFF ON ON ON ON OFF 122 OFF ON OFF ON ON ON ON OFF 123 ON ON OFF ON ON ON ON OFF 124 OFF OFF ON ON ON ON ON OFF 125 ON OFF ON ON ON ON ON OFF 126 OFF ON ON ON ON ON ON OFF 127 ON ON ON ON ON ON ON OFF 128 OFF OFF OFF OFF OFF OFF OFF ON 129 ON OFF OFF OFF OFF OFF OFF ON 130 OFF ON OFF OFF OFF OFF OFF ON 131 ON ON OFF OFF OFF OFF OFF ON 132 OFF OFF ON OFF OFF OFF OFF ON 133 ON OFF ON OFF OFF OFF OFF ON 134 OFF ON ON OFF OFF OFF OFF ON 135 ON ON ON OFF OFF OFF OFF ON 136 OFF OFF OFF ON OFF OFF OFF ON 137 ON OFF OFF ON OFF OFF OFF ON 138 OFF ON OFF ON OFF OFF OFF ON 139 ON ON OFF ON OFF OFF OFF ON 140 OFF OFF ON ON OFF OFF OFF ON 141 ON OFF ON ON OFF OFF OFF ON 142 OFF ON ON ON OFF OFF OFF ON 143 ON ON ON ON OFF OFF OFF ON 144 OFF OFF OFF OFF ON OFF OFF ON 145 ON OFF OFF OFF ON OFF OFF ON 146 OFF ON OFF OFF ON OFF OFF ON 147 ON ON OFF OFF ON OFF OFF ON 148 OFF OFF ON OFF ON OFF OFF ON 149 ON OFF ON OFF ON OFF OFF ON 150 OFF ON ON OFF ON OFF OFF ON 151 ON ON ON OFF ON OFF OFF ON 152 OFF OFF OFF ON ON OFF OFF ON 153 ON OFF OFF ON ON OFF OFF ON 154 OFF ON OFF ON ON OFF OFF ON 155 ON ON OFF ON ON OFF OFF ON

● CONNECTION & INSTALLATION

English - 23

Page 24

connection & installation

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

156 OFF OFF ON ON ON OFF OFF ON 157 ON OFF ON ON ON OFF OFF ON 158 OFF ON ON ON ON OFF OFF ON 159 ON ON ON ON ON OFF OFF ON 160 OFF OFF OFF OFF OFF ON OFF ON 161 ON OFF OFF OFF OFF ON OFF ON 162 OFF ON OFF OFF OFF ON OFF ON 163 ON ON OFF OFF OFF ON OFF ON 164 OFF OFF ON OFF OFF ON OFF ON 165 ON OFF ON OFF OFF ON OFF ON 166 OFF ON ON OFF OFF ON OFF ON 167 ON ON ON OFF OFF ON OFF ON 168 OFF OFF OFF ON OFF ON OFF ON 169 ON OFF OFF ON OFF ON OFF ON 170 OFF ON OFF ON OFF ON OFF ON 171 ON ON OFF ON OFF ON OFF ON 172 OFF OFF ON ON OFF ON OFF ON 173 ON OFF ON ON OFF ON OFF ON 174 OFF ON ON ON OFF ON OFF ON 175 ON ON ON ON OFF ON OFF ON 176 OFF OFF OFF OFF ON ON OFF ON 177 ON OFF OFF OFF ON ON OFF ON 178 OFF ON OFF OFF ON ON OFF ON 179 ON ON OFF OFF ON ON OFF ON 180 OFF OFF ON OFF ON ON OFF ON 181 ON OFF ON OFF ON ON OFF ON 182 OFF ON ON OFF ON ON OFF ON 183 ON ON ON OFF ON ON OFF ON 184 OFF OFF OFF ON ON ON OFF ON 185 ON OFF OFF ON ON ON OFF ON 186 OFF ON OFF ON ON ON OFF ON 187 ON ON OFF ON ON ON OFF ON 188 OFF OFF ON ON ON ON OFF ON 189 ON OFF ON ON ON ON OFF ON 190 OFF ON ON ON ON ON OFF ON 191 ON ON ON ON ON ON OFF ON 192 OFF OFF OFF OFF OFF OFF ON ON 193 ON OFF OFF OFF OFF OFF ON ON 194 OFF ON OFF OFF OFF OFF ON ON

24_

connection & installation

Page 25

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

195 ON ON OFF OFF OFF OFF ON ON 196 OFF OFF ON OFF OFF OFF ON ON 197 ON OFF ON OFF OFF OFF ON ON 198 OFF ON ON OFF OFF OFF ON ON 199 ON ON ON OFF OFF OFF ON ON 200 OFF OFF OFF ON OFF OFF ON ON 201 ON OFF OFF ON OFF OFF ON ON 202 OFF ON OFF ON OFF OFF ON ON 203 ON ON OFF ON OFF OFF ON ON 204 OFF OFF ON ON OFF OFF ON ON 205 ON OFF ON ON OFF OFF ON ON 206 OFF ON ON ON OFF OFF ON ON 207 ON ON ON ON OFF OFF ON ON 208 OFF OFF OFF OFF ON OFF ON ON 209 ON OFF OFF OFF ON OFF ON ON 210 OFF ON OFF OFF ON OFF ON ON 211 ON ON OFF OFF ON OFF ON ON 212 OFF OFF ON OFF ON OFF ON ON 213 ON OFF ON OFF ON OFF ON ON 214 OFF ON ON OFF ON OFF ON ON 215 ON ON ON OFF ON OFF ON ON 216 OFF OFF OFF ON ON OFF ON ON 217 ON OFF OFF ON ON OFF ON ON 218 OFF ON OFF ON ON OFF ON ON 219 ON ON OFF ON ON OFF ON ON 220 OFF OFF ON ON ON OFF ON ON 221 ON OFF ON ON ON OFF ON ON 222 OFF ON ON ON ON OFF ON ON 223 ON ON ON ON ON OFF ON ON 224 OFF OFF OFF OFF OFF ON ON ON 225 ON OFF OFF OFF OFF ON ON ON 226 OFF ON OFF OFF OFF ON ON ON 227 ON ON OFF OFF OFF ON ON ON 228 OFF OFF ON OFF OFF ON ON ON 229 ON OFF ON OFF OFF ON ON ON 230 OFF ON ON OFF OFF ON ON ON 231 ON ON ON OFF OFF ON ON ON 232 OFF OFF OFF ON OFF ON ON ON 233 ON OFF OFF ON OFF ON ON ON

● CONNECTION & INSTALLATION

English - 25

Page 26

connection & installation

ID SW1-#1 SW1-#2 SW1-#3 SW1-#4 SW1-#5 SW1-#6 SW1-#7 SW1-#8

234 OFF ON OFF ON OFF ON ON ON 235 ON ON OFF ON OFF ON ON ON 236 OFF OFF ON ON OFF ON ON ON 237 ON OFF ON ON OFF ON ON ON 238 OFF ON ON ON OFF ON ON ON 239 ON ON ON ON OFF ON ON ON 240 OFF OFF OFF OFF ON ON ON ON 241 ON OFF OFF OFF ON ON ON ON 242 OFF ON OFF OFF ON ON ON ON 243 ON ON OFF OFF ON ON ON ON 244 OFF OFF ON OFF ON ON ON ON 245 ON OFF ON OFF ON ON ON ON 246 OFF ON ON OFF ON ON ON ON 247 ON ON ON OFF ON ON ON ON 248 OFF OFF OFF ON ON ON ON ON 249 ON OFF OFF ON ON ON ON ON 250 OFF ON OFF ON ON ON ON ON 251 ON ON OFF ON ON ON ON ON 252 OFF OFF ON ON ON ON ON ON 253 ON OFF ON ON ON ON ON ON 254 OFF ON ON ON ON ON ON ON

255 ON ON ON ON ON ON ON ON

26_

connection & installation

Page 27

PREPARING ADAPTER AND CABLES

Power Adapter

Power adapter has the capacity of AC24V 6A.

Video Cable

The camera’s video output port is connected to the monitor with a BNC coaxial cable, shown below :

If the distance between the camera and the monitor exceeds the recommended maximum, please use

an auxiliary video amp.

● CONNECTION & INSTALLATION

Distance

300m 4C2V(RG-59/U)

450m 5C2V(RG-6/U)

600m 7C2V(RG-11/U)

If the camera is controlled through coaxial communication, please use a video amp intended for coaxial communications.



Communications Cable

For the camera to communicate with the controller, a

RS-485/422 communications line is required. To ensure the

quality of long distance communication and the accuracy of the

overall communication it is recommended using a twisted pair

cable such as UTP.

Regular video amps do not transfer coaxial signals.

Depending on the camera’s environment, the communications distance may vary.



Neither the video nor communications cable is enclosed with the camera.

Recommended Cable

Specification

English - 27

Page 28

connection & installation

PRODUCT CONFIGURATIONS

ALARM HDD NETWORK BACKUP REC

REC

1234

PSRCH

5678

9101112

TELE WIDE VIEW P ET

DVD RECORDER

....

DVD RECORDER

....

DVD RECORDER

13 14 15 16

OPEN/CLOSE

RS-485

SRD Series

ALARM HDD NETWORK BACKUP REC

1234

5678

9101112

13 14 15 16

OPEN/CLOSE

RS-485

SRD Series

ALARM HDD NETWORK BACKUP REC

1234

5678

9101112

13 14 15 16

OPEN/CLOSE

USB

RETURN

REC

ZOOM

FREEZE

BACKUP

TELE WIDE VIEW ET

MODE

AUDIO

ALRAM

USB

RETURN

REC

PSRCH

TELE WIDE VIEW P ET

USB

RETURN

....

1216

CONTROLLER (SUB)

CAM

DVD RECORDER

....

CONTROLLER (MAIN)

N U

ARCH

L T I

PRE

S ET

O U

D V

MTX

ACK S E

FUNC

E N TER

ESC

C LO

S E

O PEN

NEA

FAR

W ID

L E

Coaxial Communication

SRD Series

ALARM HDD NETWORK BACKUP REC

REC

1234

MEBA PASRCH

5678

9101112

TELE WIDE VIEW P ET

13 14 15 16

OPEN/CLOSE

USB

RETURN

Coaxial Communication

SRD Series

E N

LT I

CA M

GRO

D V R

TRACK

MTX

T UP

E N

TER ES C

CLO

PEN

NEA

IDE

TEL

CONTROL LINE VIDEO LINE

E NU

PRE

S ET

CONTROL/VIDEO LINE

28_

connection & installation

Page 29

PREPARING & INSTALLING CAMERA BRACKET

For installation guidelines for brackets and housings, refer to the installation manual that is enclosed with the bracket or housing.

❖

Available Bracket Models

Model Item

● CONNECTION & INSTALLATION

SBP-300WM1

SBP-300WM

SBP-300CM Ceiling Mount

SBP-300LM Parapet Mount

SBP-300KM Corner Mount

SBP-300PM Pole Mount

See “Optional Accessories for Installation” on the next page for the appearance of each bracket (unbundled).



Wall Mount

English - 29

Page 30

connection & installation

OPTIONAL ACCESSORIES FOR INSTALLATION

For your easier installation, you can purchase appropriate optional accessories available.

If installing the camera on the wall

Wall mount (SBP-300WM1)

Wall mount (SBP-300WM)

If installing the camera on the ceiling

Ceiling Mount (SBP-300CM)

30_

connection & installation

Page 31

If installing the wall mount (SBP-300WM/SBP-300WM1) on a pole with a

diameter of at least 80mm

Pole Mount (SBP-300PM)

If installing the wall mount (SBP-300WM/SBP-300WM1) on a corner of the wall

Corner Mount (SBP-300KM)

● CONNECTION & INSTALLATION

If installing on a building rooftop

Parapet Mount (SBP-300LM)

English - 31

Page 32

connection & installation

Bracket Mounting

Wall mount

Ceiling Mount

(SBP-300WM1)

(SBP-300CM)

Wall mount

Parapet Mount

(SBP-300WM)

(SBP-300LM)

32_

connection & installation

Page 33

INSTALLATION

❖

Fixing the installation base to the bracket

Fix the base with the bracket by turning it clockwise.

Hold the bottom latch of the installation base and gently press it down as shown.

Please refer to the “Camera Wiring Interface Board” on page 12, connect the wires.

Do not connect the camera to a power outlet until the installation is complete.



Supplying power while the installation is in progress may cause ﬁ re or damage the product.



● CONNECTION & INSTALLATION

Knob

Connect the camera safety wire to the installation

base.

Safety Cable

English - 33

Page 34

connection & installation

Assembling the Camera and Installation Base

Assemble the installation base and camera by matching the installation direction guides.

Attach Camera

Turn the camera frame counterclockwise until the protrusions on the camera frame and installation base become matched perfectly.

Secure Camera and Installation Base

As shown in the picture below, secure the installation base and camera using 3 hexagon screws.

34_

connection & installation

Page 35

setup

INTERFACE SYMBOLS

Motion Detection Standby/Operation Display :

When in standby mode, the “

if motion is detected.

Alarm Input Port Status Display :

"①", "②", "③", "④", "⑤", "⑥", "⑦", and "⑧" in the upper right of the screen blink.

Current Alarm Port Display According to Input Alarm Ports(Priority) :

Only one of "

Preset Number Display Settings :

‘*’ : If a preset number is already available 'H' : If a preset location is the camera’s home position

PTZ Function Screen :

➊

", "➋", "➌", "➍", "➎", "➏", "➐", "➑" in the upper right of the screen blinks.

Area Display

” in the upper right of the screen blinks and then changes to “ ”

Camera Name

Motion Detect

Alarm Input

ID=001

Area1 Area Name

1234

5678

● SETUP

Sequence Status

Preset Info

G-SEQ1 PRESET : 001 Preset Name P:300 T:040 010X

Preset Number Setting Screen :

Preset Setting

Preset=011* (1~255)

English - 35

Page 36

setup

USING AND SETTING THE MENUS

OSD (On-screen Display) Indicators

Camera Setting

Has a submenu

Has no submenu

For a mode with “ ” next to it, you can press “Enter” to move to a sub menu.

Operating Your Camera

Panning and Tilting :

Use the joystick of the controller or its direction buttons.

Controlling Zoom :

Move the joystick clockwise (Tele) or counterclockwise (Wide), or use the zoom buttons.

偓Zoom/Focus

White Balance ATW

------  ------ 

Accessing Screen Menus:

Press the Menu or OSD button on the controller.

For more detailed information about controls when using a third party controller or a DVR, refer to the user’s manual of



that product

OSD Commands, Function Chart, and Menu Controls (Applied to Samsung T/Samsung E protocol)

This camera can be operated by using two methods: Using hot keys on its dedicated controller, or accessing the OSD (On Screen Display) on the video output. The OSD menu commands are as follows:

Command Function

Move the joystick up/down/left/right Moves the OSD menus up/down/left/right, respectively.

Enter/Focus Far Selects a menu and allows access to the sub menus.

ESC/Focus Near Cancels a command and moves back to an upper-level menu.

36_

setup

Page 37

OSD Menu Chart

You can have an overall view of the menu structure. For more information, refer to the applicable page or section in the manual.

Zoom/Focus

White Balance

Exposure

Back Light

Camera Setting

Sequence Setting

P/T Setting

OSD Setting

Alarm Setting

IR Illuminator

Initialize

Password Setting

AGC

SSNR

SSDR

Day & Night

Others

Pan/Tilt Limit

Area Setting

Area Masking

Prop.P/T

Digital Flip

Image Hold

Jog Speed

Alarm Enable

Alarm Input

Alarm/AUX Output

MD Dwell Time

ALM Dwell Time

Power On Reset

Factory Default Set

Camera Default Set

Auto Refresh

Fan Life

Preset

Swing SEQ

Group SEQ

Tour SEQ

PTZ Trace

Auto Run

Power On Resume

Camera ID

Camera Name

Preset Number

Preset Name

Seq. Status

Area Name

PTZ Position

Language

Others

IR Mode

LED Max.Power

LED Pwr.CtrlLED Pwr.Ctrl

Focus Limit

On/Off

Edit Password

● SETUP

Status

English - 37

Page 38

setup

CAMERA SETUP

Zoom and Focus Settings

Focus Mode

AUTO : Performs continuous auto-focus.

MANUAL : Changes the camera mode to Manual Focus.

ONE SHOT : Auto-focuses the camera once after the Pan,

Tilt, or Zoom function is used.

Zoom Tracking

Through this menu you can set up the camera’s focus mode when zooming.

Mode

Auto : Auto-focuses when zooming.

Tracking : Focuses manually when zooming.

Off : Disable the focus modes when zooming. (Full manual

mode)

Speed

Slow/Medium/Fast : Adjusts the zooming speed.

Fast Medium Slow

37x 2.5 sec 3.1 sec 5.6 sec

Digital Zoom

Enables the maximum digital zoom. Setting the digital zoom to 2x~16x provides a total zoom of 592x.

Unlike the optical zoom, the graphics quality of the digital zoom decreases



as its zoom ratio increases.

The auto-focus function may not operate normally under the following



conditions :

When background illumination is low

While Slow-Shutter is in operation

If the zoom level is set too high

When background illumination is too high

If a long distance object and a close distance object appear together within a monitoring area

If there is no contrast, e.g. the sky or a wall

If the camera is facing a thin horizontal line

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

Zoom/Focus

Focus Mode ONE SHOT Zoom Tracking Digital Zoom OFF

38_

Auto Focus focuses on an object in the center of the screen; objects around the screen edges may not be properly in focus.



If the IR indicator turns on and the zoom factor is at least x21, the focus mode will be set to Manual regardless of the focus



mode settings.

setup

Page 39

White Balance

The White Balance menu adjusts the balance of the screen colors under different lighting conditions.

ATW : Adjusts the screen color automatically.

(Color Temperature:1800~10500°K)

ATW(IN) : Adjusts the screen color to be optimal in an indoor

environment. (Color Temperature:4500~8500°K)

ATW(OUT) :

AWC : To obtain the optimal condition for the current lighting, put

MANUAL :

Adjusts the screen color to be optimal in an outdoor environment. (Color Temperature:1700~11000°K)

the focus of the camera onto to a white paper and press the SET button. If the lighting environment changes, you should readjust the settings accordingly.

Enables customization of the Red and Blue gains.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

● SETUP



White Balance may not work properly under the following conditions.

➊ When the color temperature of the environment surrounding the subject is out of the control range.(e.g. Clear sky or sunset)

➋ When the ambient illumination of the subject is dim.

➌ If the camera is directed towards a ﬂ uorescent light or is installed in a place where illumination changes dramatically, White

Balance adjustments may not deliver consistent results.

English - 39

Page 40

setup

Exposure

The Exposure settings control the camera’s exposure level.

Brightness :

Iris

AUTO : Automatically adjusts the exposure level.

MANUAL : Enables manual adjustment of the exposure level.

Shutter : Controls the camera’s electronic shutter.

--- : The shutter speed is ﬁ xed at 1/60 for NTSC and 1/50 for

ESC : Adjusts the shutter speed automatically according

A.FLK : Select this setting when you experience picture

MANUAL : Enables manual adjustment of the shutter speed.

Sens-Up

AUTO : Automatically detects light levels and maintains a

Sens-Up Limit

Adjusts the screen brightness.

(Over 50: Brighter, Under 50: Darker)

(F1.6~Close: 18 levels)

PAL. Operates when Iris is on the Auto Mode.

to the screen brightness. Operates when the Iris is in Manual Mode.

ﬂ ickering. Flickering can happen when artiﬁ cial lighting frequencies clash with camera frame rates.

clear picture at night or under low-light conditions.

: Adjusts to the maximum-powered zoom

per frame.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

40_

setup

Exposure

For optimal performance of the A.FLK mode, avoid using the mode in conjunction



with Backlight. While the Internal Sync mode is in effect, setting the shutter to ‘---’ and facing



the camera directly to a bright light source may cause poor camera performance. Sens-Up is disabled when the shutter is in Manual or A. FLK mode.



If the gain mode is set to “Off” or “Manual”, the Sens-Up function will not be activated.



Brightness 050

Iris

AUTO Shutter -- Sens-Up AUTO

Page 41

Back Light

The Backlight function is incorporated in the W-V DSP chip, developed by Samsung Techwin, which, unlike the old models, provides a sharp image of both object and background against a severe counter-light condition.

Back Light Mode

OFF : Disables the Backlight mode.

HLC : Activates the High Light Compensation mode.

(See “HLC Setting” on the next page for details.)

BLC : Activates a user deﬁ ned backlight compensation mode.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

● SETUP

English - 41

Page 42

setup



HLC Setting

The HLC settings selectively eliminates high lights in a limited environment such as the entrance to an apartment parking lot or gas station, and is useful to detect a small objects like car license plates.

HLC is disabled during the daytime. While monitoring nigh time car traffic, if car headlights reflects too much bright light on the screen, the camera automatically eliminates the headlamp lights and adjusts the color of the license plate accordingly.

Level : Adjusts the HLC sensitivity level.

Mask Tone : Adjusts the mask color on the high lighted area.

Even if HLC is on, car license plates may not be detectable depending on the location and angle of the camera as well as



the lighting condition.

The HLC function will be disabled while using Digital Zoom, Freeze or Stabilizer.





BLC Setting

You can selectively choose a screen area to see objects within the area more clearly than others.

Four-direction Joystick Controls :

Moving the joystick in all four directions—upward, downward, left, and right—adjusts the location and size of a selected area.

Zoom Control :

Zoom Tele : Enlarges the size of a selected area.

Zoom Wide : Reduces the size of a selected area.

HLC Setting

Level Mask Tone 07

BLC MEDIUM

1 + PST : Level Change

m: Up n: Down k: Left l: Right

W: Decrease T: Increase

MEDIUM

42_

setup

Page 43

AGC(Auto Gain Control)

AGC (Automatic Gain Control) adjusts the camera’s gain control and the screen brightness if the camera has captured an object under low-light conditions.

OFF:

AGC does not function.

LOW/MEDIUM/HIGH:

As the level increases to HIGH, brighter the captured screen in a dark lighting.

MANUAL:

AGC can be ﬁ ne tuned by adjusting the level (5dB ~ 41dB).

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

● SETUP

If the IR mode is set to “DAY/NIGHT”, you can set the gain mode only to one of “LOW/MEDIUM/HIGH”.



English - 43

Page 44

setup

SSNR(Samsung Super Noise Reduction)

SSNR significantly reduces the amount of low luminance noise.

OFF : Disables the noise reduction function.

LOW : Reduces only a small amount of noise, but generates

almost no afterimage.

MEDIUM : The most commonly used mode. Reduces a suitable

amount of noise while generating a subtle afterimage.

HIGH : Reduces noise signiﬁ cantly, but generates obvious

afterimages.

SSNR is not available if AGC is set to OFF or MANUAL.



Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

44_

setup

Page 45

SSDR(Samsung Super Dynamic Range)

SSDR illuminates darker spots of an image while retaining the same light level for brighter spots to even out the overall brightness of the image with high contrast between bright and dark spots.

SSDR ON

Mode : Enables or disables SSDR.

Range : Deﬁ nes a range of SSDR.

Level : Changes the contrast between bright and dark spots by

the level.

SSDR OFF

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

● SETUP

SSDR

Mode ON Range NARROW Level 08

English - 45

Page 46

setup

Day & Night

The Day & Night function allows the camera to switch between the Color and B/W modes.

MODE

AUTO : Operates in Color mode most times, and switches

to B/W mode if a low light level is detected during nighttime.

COLOR : Operates in Color mode at all times.

B/W : Operates in B/W mode at all times. By using the Burst

On/Off sub menu, burst signals can be retained or disabled.

If the camera is in B/W mode and connected to equipment

that requires external sync through burst signals, set the Burst On/Off option to “On”.

Duration :

The camera’s light sensitivity is adjustable as in the chart below. The camera’s ambient light diversion performance may vary depending on its environment.

Color p B/W B/W p Color

FAST 2.6Lux 4.2Lux

SLOW 1.2Lux 6.0Lux

Dwell Time :

The duration of both the lighting conditions can be customized to

let the camera divert between the daytime and nighttime settings.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

46_

setup

Day/Night

Mode AUTO Duration SLOW

Auto mode is not available if AGC is set to OFF or MANUAL.



Using B/W mode under sunlight or a halogen lamp may decrease the focusing performance.



As long as the indicator of the IR light turns on, the camera will be set to B/W mode automatically.



If the IR light is set to Day/Night mode, the mode will switch to Auto automatically.



If the IR illuminator is set to SENSOR or TIMED, it will switch to Day or Night mode depending on the sensor or time.

Dwell Time 05 SEC

Page 47

Others

Sync :

Image Adj :

Freeze : Stops or reanimates an image.

Stabilizer : The Stabilizer compensates for any small

Select Internal or Line Lock.

INTERNAL : Synchronizes the camera’s output timing to the

internal crystal.

LINE LOCK : Synchronizes the camera’s output timing to

the AC adapter power to synchronize multiple cameras. This option is useful when using a switch such as Matrix Switcher.

LINE LOCK PHASE

Sharpness : Sharpens outlines of an image.

Color : Adjusts the color density of an image.

movements of the camera caused by the wind and other such events

The Stabilizer uses the digital zoom and may cause low picture quality.



The Stabilizer is disabled if the ambient light is too low.



The Stabilizer is disabled if the ﬁ eld of view has very low or no contrast,



e.g. The sky or a white wall.



If you are using the Freeze function, the stabilizer function will be disabled.

Enables setting the adapter’s synchronization phase between 0 and 359°.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Setting

Zoom/Focus White Balance ATW Exposure Back Light OFF AGC HIGH SSNR MEDIUM SSDR Day & Night Others

Others

● SETUP

Sync INTERNAL Image Adj Freeze OFF Stabilizer OFF

English - 47

Page 48

setup

Sequence Setting

Preset

This function enables the memorization of a selected location and activates the Pan, Tilt, and Zoom functions at that location. Saved locations can be recalled using the Preset Execute command.

Setting Up Preset Numbers :

Selecting the Preset Setting menu brings up a screen as shown below. Move the joystick in all four directions to select the desired number.

Preset Setting

Preset = 001 (1~255)

001 :

ююююю



ююююю



ююююю



ююююю

021 :

ююююю



ююююю



ююююю



ююююю



041 :

ююююю



ююююю



ююююю



ююююю



061 :

ююююю



ююююю



ююююю



ююююю



081 :

ююююю



ююююю



ююююю



ююююю



101 :

ююююю



ююююю



ююююю



ююююю



121 :

ююююю



ююююю



ююююю



ююююю

Saving Preset Locations :

Selecting a preset number and pressing the Enter key redirects the menu to the screen shown below.

Using the joystick, adjust the location of the Pan and Tilt functions and then set the Zoom and Focus command.

In Preset mode, the zooming focus can be controlled only by the zoom command.

Preset Setting

1+PST:ZOOM 2+PST:FOCUS

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

Preset

Setting Edit Home Position OFF Execute Clear Status

48_

setup

Page 49

PTZF Setting



If you open the PTZF setup menu, you will see the following

window. You can use the joystick to select a desired number.

Select a preset number and press ENTER. You will move to

the setup screen. Using the joystick, adjust the location of the Pan and Tilt functions and then set the Zoom and Focus command. In Preset mode, the zooming focus can be controlled only by the zoom command. For switching modes, refer to the menu bar in the bottom.



Edit

With this feature, you can edit or save the video-related settings for each preset of the camera.

PTZ : Recalls saved locations using the Preset Settings command.

Focus : Refer to the section entitled Setting Up Your Camera.

Brightness : Refer to the section entitled Setting Up Your Camera.

Iris :

Refer to the section entitled Setting Up Your Camera.

Back Light : Refer to the section entitled Setting Up Your Camera.

Day & Night : Refer to the section entitled Setting Up Your Camera.

Preset Setting

Preset = 001 (1~255)

001 :

ююююю



ююююю



ююююю



ююююю

021 :

ююююю



ююююю



ююююю



ююююю

Preset Setting

1+PST:ZOOM 2+PST:FOCUS

Preset

Setting Edit Home Position OFF Execute Clear Status

● SETUP

After Action : Enables setting up an automatic action after the

camera arrives at a selected preset location.

MD :

Commands the camera to perform the Motion Detection function. If Focus mode is set to Auto, the MD function may not work properly in a challenging environment.

OFF : Select this when no action is desired.

Others : You can set AGC, Stabilizer, SSNR, SSDR, Shutter,

Sens-Up and White Balance functions. For terms related to settings, refer to the camera settings commands.

Preset Edit

Preset = 001

001 :

ююююю

021 :

ююююю

(1~255)



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю

Preset Edit [001]

PTZ 180/025/1X Focus ONE SHOT Brightness 050

Iris

AUTO Back Light OFF Day & Night AUTO After Action OFF Scene Adj

English - 49

Page 50

setup



Preset Name Setting

Using this function, you can add names to preset locations up to 12 characters.

Once a name is entered, use the joystick and the Enter key to perform the Set command and save the name.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

OSD Setting

Camera ID ON Camera Name Preset Number ON Preset Name

....

50_

setup

Preset Name

On/Off OFF Edit



Preset Name

Preset = 001

001 :

ююююю

021 :

ююююю

(1~255)



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю

Preset Name [ ]

"#$%&'()*+,-. /0123456789:;

BCDEFGHIJKLMN OPQRSTUVWXYZ[   

 <>Â 

BACK SPACE CLR SET

Page 51



Home Position

Sets one of the currently configured preset positions as the home position.



Execute

Recalls a saved preset location. While in the Sequence mode of operation, the actual movement can be slower than specified when moving the camera in the direction of Pan and Tilt at the same time.



Clear

Deletes the selected preset location.



Status

Opens a map of saved preset locations. An area saved as a preset location is displayed with the ‘

Preset Status



001 :

ююююю

021 :

ююююю



041 :

ююююю



061 :

ююююю



081 :

ююююю



101 :

ююююю



121 :

ююююю



141 :

ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю



ююююю

Preset Status



ююююю

161 :



ююююю

181 :



ююююю

201 :



ююююю



ююююю



ююююю



ююююю



ююююю

ююююю ююююю ююююю

221 :

ююююю

241 :

ююююю



ююююю



ююююю



ююююю



ююююю ююююю



ююююю



ююююю ююююю



ююююю



ююююю ююююю



ююююю



ююююю

’ icon.



ююююю

Preset

Setting Edit Home Position OFF Execute Clear Status

Preset

Setting Edit Home Position OFF Execute Clear Status

Preset

Setting Edit Home Position OFF Execute Clear Status

Preset

Setting Edit Home Position OFF Execute Clear Status

● SETUP

English - 51

Page 52

setup

Swing SEQ

The Swing function commands the camera to move between 2 selected locations, monitoring the route.

Pan Swing :

Activates the Pan function for the Swing operation.

Tilt Swing :

Activates the Tilt function for the Swing operation.

P/T Swing :

Activates both the Pan and Tilt functions for the Swing operation.

Swing Setting/Execute/Clear

Each of the Swing menus have sub menus with the settings.

Pan Swing Set

Setting Execute Clear

Pan Swing

[

ÂÂÂ

][

ÂÂÂ

]

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

Speed =64 (1~64) Dwell Time =005(1~120) (s)

Select 2 preset locations by using the joystick.

Speed indicates the camera’s movement speed. DWELL TIME indicates the camera’s duration of stay at a preset location.

- Execute: Executes the Swing operation.

- Clear: Deletes data in the Swing memory.

While in the Sequence mode of operation, the actual movement can be slower than speciﬁ ed when moving the camera in



52_

the direction of Pan and Tilt at the same time.

setup

Swing SEQ

Pan Swing Tilt Swing P/T Swing

Page 53

Group SEQ

Selecting Group SEQ recalls a group of multiple preset locations in a consecutive manner. Up to 6 groups can be defined and up to 128 presets can be memorized for each group.

During the group operation, the camera settings for each preset will be retrieved accordingly.

Setting :

Using the joystick, enter the desired preset numbers into the PSET section. DWT indicates the camera’s duration of stay at a preset location. The speed is adjusted in 64 levels.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Group SEQ 1

NO PSET DWT(s) SPD 001: *** : 003 : 64 002: *** : 003 : 64 003: *** : 003 : 64 004: *** : 003 : 64 005: *** : 003 : 64 006: *** : 003 : 64 007: *** : 003 : 64

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace

Execute :

Executes the group operation.

Auto Run Power On Resume ON

● SETUP

Clear :

Deletes the selected group.

About 8 seconds of recognition time is required if [Intelligence] of the preset



is activated from the Group menu.

For a proper operation of [Intelligence], set [Time (sec)] of the Group menu



to more than 8 seconds.

Group SEQ

Group 1 Group 2 Group 3 Group 4

....

Group SEQ 1

Setting Execute

Clear

English - 53

Page 54

setup

Tour SEQ

Selecting Tour SEQ recalls groups of preset locations in a consecutive manner. Up to 6 groups can be listed for this function.

Setting :

Selecting the Settings menu brings up the following screen. Using the joystick, you can enter desired group numbers to the Group section. DWT indicates the camera’s standby time before a new group is recalled.

Tour SEQ

NO Group DWT(s) 01: * 003 02: * 003 03: * 003 04: * 003 05: * 003 06: * 003

Execute :

Executes the group operation.

Clear :

Deletes the selected group.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

54_

setup

Tour SEQ

Setting Execute Clear

Page 55

PTZ Trace

Maximum 4 patterns of the manual operation paths (for Pan, Tilt, Zoom and Focus) are memorized and replayed.

Replay :

Replays a route saved by the Trace function.

Replay Once :

Replays a saved Trace route once.

Memorize :

The time for storing the event differs depending on the complexity of PTZ operations of your choice. When the memory is full, any further storing will be stopped. You can use the Menu button (OSD access key) to stop the

memorize function during its process.

Using other protocols

Protocol

PELCO-D/P KDB300A Ack, Iris Open

SAMSUNG-E SSC-5000

PANASONIC WV-CU161C

VICON V1300X-DVC Iris Open

HONEYWELL HTX-3000 Iris Open

GE KTD-405

Bosch

Clear : Deletes a saved Trace route.

Representative

Model

Stop saving the

trace

OSD ON, Iris Open

OSD ON

OSD ON, Iris Open

Iris Open

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

PTZ Trace

Trace 1 Trace 2 Trace 3 Trace 4

● SETUP

PTZ Trace

Replay Replay Once Memorize Clear

English - 55

Page 56

setup

Auto Run

If an operator is not controlling the dome at a specific time, the sequence operation scheduled by the user will be executed.

Mode :

HOME : Auto run Home Position (Refer to the Preset Menu.)

PRESET : Auto run a selected preset number.

SWING : Auto run a selected Swing mode.

GROUP : Auto run a selected Group mode.

TOUR : Auto run a selected Tour mode.

TRACE : Auto run a selected trace mode.

A.PAN : Auto run a 360-degree pan. To activate the

panning command, you need to set up the camera’s tilt angle and auto pan speed manually.

SCHEDULE : Execute Auto Run on the selected day of the

week.

Time :

Enables setting up an Auto Run duration. (The duration can be 5~30 seconds, or 1~5 minutes.)

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

56_

Auto Run

Mode OFF Time 30 SEC

setup

Page 57



Schedule

Schedule enables you to set a sequencing action by day and time.

Select Day : At Auto Run, select SCHEDULE to set up each day of the week,

as shown on the side picture. Select a day, change to ON, and then press Enter.

Select Time :

When turning ON a day, a timetable appears as shown on the side picture. (Up to 6 timelines can be selected for a day.) Select the beginning time and sequencing action to schedule the action.

Power On Resume

Auto Run Mode

SCHEDULE

Time 30SEC

Schedule Set

Sunday ON Monday OFF Tuesday OFF Wednesday OFF Thursday OFF Friday OFF Saturday OFF

Schedule Set

No START SEQ No 1 09:00 HOME

2 00:00 OFF 3 00:00 OFF 4 00:00 OFF 5 00:00 OFF 6 00:00 OFF

Clear

● SETUP

Power On Resume :

This is useful when the power is disconnected and reconnected due to power failures or other power interruptions.

If the camera was performing a sequence action prior to a power disconnection, the camera automatically resumes the action when the power is reconnected.

Main Menu

Camera Setting Sequence Setting P/T Setting

Sequence Setting

Preset Swing SEQ Group SEQ Tour SEQ PTZ Trace Auto Run Power On Resume ON

English - 57

Page 58

setup

P/T Setting

Pan/Tilt Limit

The moving ranges in the Pan/Tilt directions can be limited.

Position :

Selecting the Position menu brings up the following screen if it is for the Pan Limit setting. Move the joystick left and right to select a movement range from the starting point to the end.

START LIMIT

Enter: Set ESC: Exit

The following picture shows the Tilt Limit setting.

Move the joystick left and right to select a movement range from the starting point to the end.

START LIMIT

Enter: Set ESC: Exit

END LIMIT

Enter: Set ESC: Exit

END LIMIT

Enter: Set ESC: Exit

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

Activation :

Sets the configured Pan/Tilt Limit function to use or not.

58_

setup

Pan/Tilt Limit

Pan Limit Tilt Limit

Pan Limit

Position Activation OFF

Page 59

Area Setting

The Area Setting menu enables the selection of certain locations in the course of the Pan and Tilt operation, and then display the areas with the OSD (On Screen Display) texts when the camera passes through them. Up to 8 areas can be selected.

Main Menu

Camera Setting Sequence Setting

Area Name :

You can add names to selected areas. Names can be up to 12 characters and can be entered via the joystick and the Enter key. Once a name is entered, use the joystick and the Enter key to perform the Set command and save the name.

Area Name [ ]

"#$%&'()*+,-. /0123456789:;

BCDEFGHIJKLMN OPQRSTUVWXYZ[   

 < >    Â 

BACK SPACE CLR SET

Position :

As shown in the picture below, move the joystick to select the upper left corner and lower right corner of an area.

Area Setting

P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

● SETUP

MANUAL

Enter: Set ESC: Exit

The effective positioning range is between -45° and 40° in the tilting angle at the zoom factor of 1x.

Activation :

Cancels or activates the display function of selected areas.

Enter: Set ESC: Exit

Area Setting

Area 1 Area 2 Area 3 Area 4

....

Area Setting

Area Name Position Activation OFF

English - 59

Page 60

setup

Area Masking

If a monitoring location includes a highly private area, the area can be selectively excluded from monitoring.

Main Menu

Camera Setting

Position :

As shown in the picture below, move the joystick to select the upper

left corner and lower right corner of an area.

Sequence Setting P/T Setting OSD Setting

Area Masking

Alarm Setting IR Illuminator Initialize Password Setting Status

Enter: Set ESC: Exit

P/T Setting

Activation :

Activate or deactivate the display of speciﬁ ed masks.

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

60_

Area Masking

Mask 1 Mask 2 Mask 3 Mask 4

....

Area Masking

Position Activation OFF

setup

Page 61

Prop. P/T

This commands the camera to change the Pan and Tilt speed automatically according to the current zoom ratio. Moving the joystick clockwise (Tele) slows down and counterclockwise (Wide) accelerates the Pan and Tilt speed, allowing detailed adjustments. Turning this “Off” executes the function the optical 1x zoom speed regardless of how far the lens is zoomed in.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

● SETUP

English - 61

Page 62

setup

Digital Flip

Digital Flip is useful to monitor a moving object or a person passing directly under the camera. When the object passes straight under the camera, tilting can be traced up to the opposite tilting area without the need of the pan operation. The reverse screen that occurs when the object gets through the 90-degree point will be corrected in digital processing.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting

0° → 180° : Image flip at the 93-degree point

180° → 0° : Image flip at the 87-degree point

Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

62_

setup

Page 63

Image Holding

This will display the preset video in still images until the orientation of the camera reaches the preset position at a group or tour movement. This is useful if you want to monitor the video while preventing a possible visual distraction of the observer.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

● SETUP

English - 63

Page 64

setup

Jog Speed

The pan/tilt speed changes according to the tilt of the joystick, or you can control the operation in a fixed speed.

Main Menu

Camera Setting

MANUAL :

The pan/tilt speed depends on how much the joystick of the controller is tilted. The more the joystick is tilted, the faster the operation is performed.

30/35/40/45/50/55/60 :

The pan/tilt operation will be performed at the selected speed; the greater the number is, the faster the operation is performed.

However, the speed at each level may differ according to the zooming status, and depending on the use of synchronized zooming.

Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

P/T Setting

Pan/Tilt Limit Area Setting Area Masking Prop. P/T ON Digital Flip ON Image Hold OFF Jog Speed

MANUAL

64_

setup

Page 65

OSD SETTING

In this menu, you can configure the OSD (On Screen Display) settings.

Camera ID :

Displays or hides Camera ID in the upper left of the screen.

Camera Name :

Add a name to the camera. (see the top note on page 66 for more information.)

Preset Number :

Displays or hides Preset Numbers on the screen.

Preset Name :

Add names to preset locations. (see the top note on page 66 for more information.)

Seq. Status :

Displays or hides the status of a sequence action that is in progress.

Area Name :

Displays or hides the Area Name for the Area Settings on the screen.

PTZ Position :

Displays or hides the status of the Pan, Tilt, and Zoom operation that is in progress.

Language :

Enables the system language to be changed. This camera supports ENGLISH, CHINESE, FRENCH, GERMAN, SPANISH, ITALIAN, PORTUGUES, POLISH, RUSIAN, CZECH, TURKISH, KOREAN, JAPANESE, TAIWANESE.

Others

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

OSD Setting

Camera ID ON Camera Name Preset Number ON Preset Name Seq. Status ON Area Name OFF PTZ Position ON Language

Others

OSD Setting

Direction Clock Setting

ENGLISH

● SETUP

Direction : Indicates the current angle of the camera:

East, West, South, North, Southeast, Southwest, Northeast, or Northwest.



Set North Dir. : Specify the azimuth of the north manually.

Clock Setting: You can specify the time information manually that will be displayed on the

screen. This will synchronize with Sequence so that you can set it to activate on a speciﬁ c time and date.



Display: Specify the use of time display on the screen.



Date Format: Specify the date format. (DD/MM/YYYY, MM/DD/YYYY)



Set Date: Enter a desired date manually.



Time Format: Specify the time format. (24hr / 12hr)



Set Time: Specify the time manually.

English - 65

Page 66

setup

XXX Name [ ]

"#$%&'()*+,-. /0123456789:;

BCDEFGHIJKLMN OPQRSTUVWXYZ[   

 < >    Â 

BACK SPACE CLR SET

ALARM SETTING

Alarm Enable

ON/OFF :

Enables or disables the Alarm function.

Alarm Input

MOD

Enables selecting an Alarm Input method.

- NO (Normally Open)

IN 1.2.3.....8 IN 1.2.3.....8

When selecting the Camera Name and Preset Name, the screen displays the Left



keypad.

Names can be up to 12 characters and can be entered via the joystick and the Enter



key. Once a name is entered, use the joystick and the Enter key to perform the Set command and save the name.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

ALM GND

ALARM OFF

- NC (Normally Closed)

ALM GND

ALARM OFF

As shown in the picture above, the Alarm Input must be entered with the Open or Closed switch signals. Supplying power without entering



66_

the signals may damage the product.

setup

ALM GND

ALARM ON

< Alarm input when N.O. is enabled >

IN 1.2.3.....8IN 1.2.3.....8

ALM GND

ALARM ON

< Alarm input when N.C. is enabled >

Alarm Setting

Alarm Enable OFF Alarm Input Alarm/AUX Output MD Dwell Time OFF ALM Dwell Time

HOLD

ALM MOD P SEQ. NO

IN1 OFF 1 OFF IN2 OFF 2 OFF IN3 OFF 3 OFF

.....

Page 67

P(Priority) :

Set the priority of Alarm Inputs. If more than one alarm is simultaneously activated, the alarm with the highest priority activates before the others.

SEQ. :

Enables setting up a sequence action for the camera in response to an alarm. You can configure the settings of: HOME/PRESET/SWING/GROUP/TOUR/TRACE/A.PAN/OFF

Alarm/AUX Output

● SETUP

Setting 1, 2, 3 :

Enables selecting an Alarm Output method.

DETECT MODE : Displays the alarm input ports (1~8) and the

motion detection input. If you set MD Input, you can select one from: OFF/MD.

AUX MODE : Both Alarm OUT/AUX OUT 1 and 2 are NC/NO

while Alarm OUT/AUX OUT 3 performs NO only.

Timer 1, 2, 3 :

On : If an alarm event occurs, the alarm will stay active for

the time speciﬁ ed. You can specify the time from at least one second to a max of 60 minutes.

MOMENT : The output operation will last until an alarm/AUX event

is released since its occurrence.

The Alarm/AUX output system is equipped with a relay circuit,

whose output port operates as below: (based on “NO”)

/0/0

$0.

Alarm Out OFF

OUT Off 1, 2, 3 :

Output of an alarm/AUX event can be forcibly terminated

when it occurred.

Alarm Out ON

$0.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Alarm Setting

Alarm Enable OFF Alarm Input Alarm/AUX Output MD Dwell Time OFF ALM Dwell Time

HOLD

Alarm/AUX Output

Setting 1 Setting 2 Setting 3 Timer 1 OFF Timer 2 OFF Timer 3 OFF Out Off 1 Out Off 2 Out Off 3

DETECT MODE DETECT MODE DETECT MODE

English - 67

Page 68

setup

Connecting the power connector and GND incorrectly to the NC/NO and COM ports may cause a short circuit and ﬁ re,



MD Dwell Time

damaging the camera. The maximum power capacity of the built-in relay is 30VDC/2A, 125VAC/0.5A, and 250VAC/0.25A. Operating the



camera beyond the capacity may decrease the camera’s lifespan and damage it.

When Motion Detection under the Preset Edit menu is selected, MD Dwell Time performs the Tour or Group function.

While the camera is performing a sequence action, if motion is detected from a selected preset location, the camera pauses the sequence action operation and starts monitoring the location instead for a duration that is set under the MD Dwell Time menu.

If the motion is no longer detectable or the duration expires, the camera aborts the monitoring operation and then resumes the sequence action.

ALM Dwell Time

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Alarm Setting

Alarm Enable OFF Alarm Input Alarm/AUX Output MD Dwell Time OFF ALM Dwell Time

HOLD

You can specify the time of sequence operation that will be activated if an event occurs from the alarm input.

SET:

The sequence operation will proceed for a speciﬁ ed time.

HOLD:

The sequence operation will be maintained until the user deactivates it.

The alarm dwell time will be activated while the “Sequence Setting > Auto Run” option is active.



68_

setup

Page 69

IR ILLUMINATOR

In this menu, you can configure the IR Illuminator settings against a low contrast scene.

IR Mode: Specify the use conditions for the IR Illuminator.

Off: Does not use the IR Illuminator.

On: Activates the IR Illuminator.

DAY/NIGHT: Synchronizes the IR Illuminator with Day/Night

mode of the camera. Set the Day/Night mode so that the product uses the IR Illuminator in the night but does not use the illuminator during the day.

SENSOR: It will be in sync with the built-in brightness sensor of

the camera. See the next page for details.

TIMED: Set the IR Illuminator to activate/deactivate at a speciﬁ ed

time. See the next page for details.

If the IR mode is set to ON and the LED turns on, the screen will be



displayed in black and white mode. If the LED turns off, the screen will return to the previous screen mode.

If you set the IR mode to “DAY/NIGHT”, “Camera Setting>Day/Night>Mode”



will be set to “Auto”, which you cannot change the setting. If you set the IR mode to Sensor or Time mode, you cannot change “Camera



Setting> Day & Night > Mode” as you want. When used with IR illuminator, changing the zoom ratio automatically



synchronizes the IR illuminator. Note that synchronizing IR illuminator to zooming may slow down in low temperatures.

If the ambient temperature increases too high, the IR LED can turn off to



prevent overheat of the product.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

IR Illuminator

IR Mode LED Max.Power MEDIUM LED Pwr.Ctrl Focus Limit

DAY/NIGHT

● SETUP

AUTO

LED Max. Power: Specify the maximum output of the IR Illuminator.

LOW/MEDIUM/HIGH: The higher the level is, the brighter the indicator of the IR Illuminator becomes.

LED Pwr.Ctrl : Set to control the indicator’s output of the IR Illuminator.

AUTO : If the light from the IR indicator reﬂ ects on a short-distant object (causing saturation), this

will lower the max power of the IR indicator.

MANUAL :Limit the output of the indicator to the value speciﬁ ed in “LED Max. Power”.

Focus Limit: This is to restrict the auto focusing in a high zoom factor of the IR illuminator in order to

On:

If the IR indicator turns on and the zoom factor is at least x21, the focus mode will be set to Manual

Off: The user focus settings and LED output settings will be applied.

prevent unnecessarily extended duration of the auto focusing.

regardless of the focus mode settings. In Sequence mode, the focus will return to the preset value regardless of the focus mode settings. To guarantee exact operation at night, you must make the preset settings in advance. If you use the joystick to control the Pan/Tilt/Zoom operations, the focus mode will switch to “Manual”. However, if you still want to enable the auto focusing, press the A/F button on the controller to activate the auto focus mode. For optimal IR performance, the intensity of the IR LED will be set to High regardless of the user settings.

English - 69

Page 70

setup



SENSOR:

In this mode, the IR mode will be controlled according to the illumination. The “level” on the top right corner indicates the current illumination.

LED On Level : Specify the illumination level that activates the IR mode.

If the illumination is below the speciﬁ ed level, the indicator will turn on.

LED Off Level : Specify the illumination level that deactivates the IR mode.

If the illumination is above the speciﬁ ed level, the indicator will turn off.

IR Illuminator

IR Mode

SENSOR LED Max.Power MEDIUM LED Pwr.Ctrl Focus Limit

AUTO

Sensor Mode

Level

=100

LED ON Level cannot be higher than LED Off Level; LED Off Level cannot be lower than LED On Level.



The sensor mode will be triggered if the lighting stays at a certain illumination for more than 5 seconds.



Level difference between “LED ON Level” and “LED OFF Level” cannot be less than or equal to 10.



If the Sensor mode is set to ON and the LED turns on, the screen will be displayed in black and white mode. If the LED turns off, the screen will be displayed in color mode.



TIMED:

You can use this option to set the IR Illuminator to On/Off at your specified time.

LED On Time: Specify the time to activate the IR mode.

LED Off Time: Specify the time to deactivate the IR mode.

LED On Level LED Off Level

040 060

IR Illuminator

IR Mode

TIMED LED Max.Power MEDIUM LED Pwr.Ctrl Focus Limit

AUTO

70_

setup

TIMED Mode

Led On Time Led Off Time

If the Time mode is set to ON and the LED turns on, the screen will be displayed in black and white mode. If the LED



turns off, the screen will be displayed in color mode.

19:00 05:00

Page 71

INITIALIZE

Power On Reset :

Restarts the camera.

Factory Default Set :

Enables resetting the camera to its factory default settings. When the mode is selected, all custom data such as preset locations are deleted from the camera.

Use this function if it is necessary to reset the settings of the camera.

Camera Default Set :

Reset the zoom module of the camera to the factory default. Use this if you want to return the camera settings of such as Exposure or Backlight to the factory default.

Auto Refresh :

Optimizes the settings of the electric circuits and component parts of the camera on a regular basis.

This is useful for maintenance purpose, especially when the camera faces a specific light source, or if the camera settings are not maintained properly due to an extended time of recording while rotating the camera in four directions.

Off, 1~7 Days : Selecting Off disables Auto Refresh and selecting 1~7 Days automatically executes it after 1~7 days has passed.

Auto Refresh takes about 10 seconds or less. Any sequence operation that is being performed will be stopped and resume after Auto refresh is completed.

Fan Life :Enables setting the Fan Life.

Message Display: The following warning message will appear 2 months before the expiry of the fan

life. “Fan Life Expired. Replace the Fans”

ON: Display the warning message. (Default)

OFF: Do not display the warning message.

[OFF] is to hide the message, rather than to delete it. Set it back to [ON]. Then, the warning message will appear. (Only if you didn’t clear the message [Message Clear])

Message Clear: Use this if you want to delete the warning message when it pops up.

If you set [Message clear] to [On]after performing the command, no warning message will appear on the screen.

Time Reset: Set to count the fan life again after replacing the fan. (However, this is available only

after you see a warning message that the fan life has expired.)

The fan life is counted only for an actual operation so the fan can be used longer than the displayed time.

Time Remain.(hour):

49000 : Remaining life of fan (unit: hour)

The fan life will be updated when you access the [Fan Life] menu and if you press [ENTER] on the

[Time Remain.(hour)] item.

Main Menu

Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Initialize

Power On Reset Factory Default Set Camera Default Set Auto Refresh OFF Fan Life

● SETUP

English - 71

Page 72

setup

PASSWORD SETTING

The Password feature enables you to conﬁ gure a password for rebooting the camera and accessing the OSD and preventing unauthorized modiﬁ cation of existing camera settings.

On/Off :

Enables or disables Password protection.

Edit Password

Change the password; enter the current password and then a new one, consisting of 4 hexadecimal characters (0~F).

The default password is "0000".

STATUS

Displays the settings and version of the camera.

CAM MODEL :

Indicates the model name of the camera.

CAM VER. :

Indicates the software version of the camera.

DOME VER. :

Indicates the version of the camera control board.

COAX VER. :

Indicates the software version of the Coax communication

PROTOCOL :

Indicates the status of the current protocol.

DOME ID :

Dome Camera ID

CONTROLLER :

Indicates the settings of the current communications mode.

MODEL NAME :

Shows the model name of the product.

72_

setup

Main Menu Camera Setting Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Password Setting

On/Off OFF Edit Password

Main Menu Camera Setting

Sequence Setting P/T Setting OSD Setting Alarm Setting IR Illuminator Initialize Password Setting Status

Camera Status

CAM MODEL = SCM2370/PAL CAM VER. = V2. 06_ 111101 DOME VER. = V0. 50_111220 COAX VER. = V1. 00_110126 PROTOCOL = AUTO DET DOME ID = 001 CONTROLLER = Simplex MODEL NAME = SCP-2370RH

Page 73

troubleshooting

TROUBLESHOOTING

If the product does not function properly, please see the below for trouble shooting.

Problem Cause and Solution Page

Controller does not work.

No picture is displayed on monitor.

The picture is too dark/bright.

The monitor displays a white image.

Picture is out of focus.

► Check if the camera and peripheral devices are properly connected. 12~14

► Verify the setups of ID, protocol, and baud rates. 15~26

► Check if power cable is securely connected to the camera and the monitor.

Check if the video cable is properly connected. Consult the operation manual of the system controller connected to the camera.

► Check if the iris of the lens is closed.

Adjust the menu for the iris of the lens.

► Check the camera’s fixed shutter speed.

Adjust the camera’s shutter menu.

► Check the camera’s Brightness menu.

Adjust the camera’s Brightness menu.

► Check if the iris of the lens is open.

Adjust the menu for the iris of the lens.

► Verify the distance between the camera and the subject, as well as the

subject’s surroundings. Camera may have difficulty focusing on a subject against a white background.

► If Auto Focusing is having difficulty focusing on a particular subject, set

Focus Mode to Manual and adjust the focus by yourself.

► Use the camera’s reset menu to restore the camera settings in order to

default.

12~14

● TROUBLESHOOTING

Digital noise appears in picture.

Picture’s colors are not good.

The picture is flickering.

► Adjust Sharpness level. 47

►

This can happen if the IR LED turns on with the zoom factor set to at least x21.

► Check if the video cable is properly connected. -

► Make sure that the power cable and video cable do not exceed the

recommended maximum lengths.

► Adjust Sharpness level. 47

► Check the White Balance. 39

► Adjust Color Menu in Image Adj. 47

► Check if the camera is pointing directly at a fluorescent light or sunlight. If

so, change the camera’s direction to remove the flickering.

English - 73

Page 74

troubleshooting

Problem Cause and Solution Page

Afterimages appear in picture. ► Check Sens-Up settings. 40

Camera switches between color and B&W modes frequently.

Pan, tilt, zoom, and/or focus do not work.

The camera’s position differs from the position defined in a preset.

Sequence configuration of the camera does not work.

The upper side of the picture is dark when the camera is on the horizontal reference point.

Camera suddenly turns on or moves to a preset position by itself.

► Adjust Duration and Dwell Time in Day & Night menu. 46

► Check if power cable is securely connected to the camera and the monitor.

Check if the video cable is properly connected. Consult the operation manual of the system controller connected to the camera.

► Check if Pan Limit and/or Tilt Limit are set.

If so, remove the limit(s).

► A motor or the lens may be overheated.

If so, contact your service personnel or system provider for assistance.

►

This phenomenon may happen, since the motors have a margin error of ±0.1˚.

► Check if Preset or another operation mode has been set. ► Check the Auto Refresh settings.

►

You are seeing the camera's internal cover. The camera is functioning normally.

► Check the Auto Run settings.

Auto Run puts a camera through a predefined action sequence if the user does not use the Controller to operate the camera for a certain period of time.

► Check the Auto Refresh settings.

Auto Refresh optimizes the camera's circuitry and components according to a predefined schedule.

12~14

48~49

Coxial communication does not work.

I turned on the power, but the camera didn't start running.

74_

troubleshooting

► Check the distance between the camera and the monitor. 27

► If the distance between the camera and the monitor exceeds the

recommended maximum, please use an auxiliary video amp.

► Ensure that the Camera ID DIP switches (SW1) are all positioned to OFF. 19

► Please check the environment temperature; the camera may not operate

properly if it has been left at temperatures lower than -50º for a prolonged duration.

► The motor may malfunction at temperatures lower than -20º; please turn

on the camera in Standby mode instead of [Initialize].

► Keep in Standby mode for at least 120 minutes. Once the internal

temperature reaches -20º or higher, the camera automatically resets itself and activates the [Initialize] mode for normal operation.

6~7

Page 75

Problem Cause and Solution Page

I can’t see the screen. (The screen is black.)

The camera stops in the Initialize mode and won’t proceed to the next mode.

I can use the controller, but I can’t activate the Sequence command.

I can't get rid of this message from the screen: “ Fan life Expired. Replace the Fans.”

The camera suddenly resets

itself while displaying the black

screen.

"Auto Refresh(Wait)" appears and the camera reboots.

► When the camera’s internal temperature drops down to -20º or lower, it

becomes unable to transmit video signals and may cause a black screen.

► A black screen does not indicate camera breakage; it resets itself and

starts displaying video again once its internal temperature reaches -20º or higher.

► The motor may malfunction at temperatures lower than -20º ; please turn

on the camera in Standby mode instead of [Initialize].

► When the camera's internal temperature is between -10º to -20º, the

motor may malfunction, limiting the use of the Sequence and Turbo commands.

► Once the internal temperature reaches -10º or higher, all Sequence modes

become reactivated normally.

► Please make sure to "Clear" the message from the screen. 6~7

► Such symptoms may occur if the camera's temperature increases from

-20º or lower to -20º or higher.

► Such symptoms may occur if the camera's temperature increases from

-10º or lower to -10º or higher to prevent the malfunction of motor.

6~7

● TROUBLESHOOTING

“Please Check Heater System” appears.

► The heater may malfunction.

Turn off the camera and call where you bought.

Check the Power cord’s by periods

The Power cord’s coating has been damaged.

The power cord is hot to touch when the product is in operation.

The power cord gets hot after being folded or pulled on.

Continuing to use the product when its power cord is damaged constitutes an electrical and fire hazard. The power plug must be removed from the outlet immediately, and a qualified service personnel or your system provider should be contacted for assistance.

6~7

English - 75

Page 76

product specifications

PRODUCT SPECIFICATIONS)

Model SCP-2370RH

Image Device 1/4” Super HAD CCD

Total Pixels

Effective Pixels

Scanning System 2:1 Interlace

Synchronization Internal / Line Lock

Frequency

Horizontal Resolution

<Use IR Illuminator> 0 Lux

Min. Illumination

S / N Ratio 52 dB (AGC off, Weight On)

Video Output CVBS : 1.0 Vp-p / 75Ω composite

Focal Length (Zoom Ratio)

Max. Aperture Ratio 1:1.6 (Wide) ~ 3.9 (Tele)

Angular Field of View H : 55.5°(Wide) ~ 1.59°(Tele) / V : 42.5°(Wide) ~ 1.19°(Tele)

Min. Object Distance 1500mm

Focus Control AUTO / MANUAL / ONE SHOT

Zoom Movement Speed

Pan Range 360° Endless

Pan Speed Preset : 250°/sec, Manual : 0.024°/sec ~ 120°/sec

Tilt Range -5° ~ 185°

Tilt Speed Preset : 250°/sec, Manual : 0.024°/sec ~ 120°/sec

Preset 255

Preset Accuracy ±0.1°

OSD

Camera Title Off / On (Displayed 12 Characters)

<Do not use IR Illuminator> COLOR : 0.2 Lux (50 IRE @ F1.6 ), 0.0004 Lux (50IRE, Color, Sens-up 512x )

B/W : 0.02 Lux (50 IRE @ F1.6 ), 0.00004 Lux (50IRE, B/W, Sens-up 512x )

NTSC: ENGLISH, FRENCH, SPANISH, PORTUGUES, KOREAN, JAPANESE, TAIWANESE PAL: ENGLISH, CHINESE, FRENCH, GERMAN, SPANISH, ITALIAN, PORTUGUES, POLISH, RUSIAN, CZECH,

TURKISH

NTSC : 811(H) x 508(V)

PAL : 795(H) x 596(V)

NTSC : 768(H) x 494(V)

PAL :752(H) x 582(V)

NTSC : H : 15.734kHz / V : 59.94Hz

PAL : H : 15.625KHz / V : 50Hz

Color : 600TV lines / BW : 700TV lines

3.5~129.5mm

2.8sec

76_

product specifications

Page 77

Model SCP-2370RH

Day & Night Auto (ICR) / Color / B/W

Back Light BLC / HLC / Off

Contrast Enhancement

Digital Noise Reduction

Digital Image Stabilization

SSDR (Off/On)

III

SSNR

(Off/On)

Off/On

Motion Detection Off/On

Privacy Masking Off/On (8 programmable zones)

Sens-up 2x ~ 512x

Gain Control Off/Low/Medium/High/Manual

White Balance ATW / ATW (IN) / ATW (OUT) / Manual / AWC

Electronic Shutter Speed

NTSC :1/60~1/120,000sec

PAL : 1/50~1/120,000sec

Digital Zoom Off/On (2x ~ 16x)

Digital Flip Off/On

Schedule Day/Time

Alarm 8 In 3 Out

Communication RS-485/422, Coaxial Control

Protocol

Operating Temperature / Humidity

Coax : Pelco-C ( Coaxitron ) RS-485: Auto Detected, SAMSUNG-T, SAMSUNG-E, Pelco(D/P), Panasonic, Vicon,Honeywell,AD,GE,BOSCH

-50°C ~ +55°C / Less than 100% RH

Ingress Protection IP66

Input Voltage

24V AC ±10%, 50/60Hz

Power Consumption 15W / Max. 90W (Fan & Heater)

Color / Material Ivory, Aluminum

Dimension (Φ×H) Φ248 x 399.5mm

Weight 6 Kg

● PRODUCT SPECIFICATIONS

The specification for this product may change without prior notice for product improvement.

English - 77

Page 78

product specifications

DIMENSIONS

Unit : mm (inch)

78_

product specifications

Page 79

MEMO

Page 80

SALES NETWORK

SAMSUNG TECHWIN CO., LTD.

Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400 TEL : +82-70-7147-8740~60, FAX : +82-31-8018-3745

SAMSUNG TECHWIN AMERICA Inc.

100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Toll Free : +1-877-213-1222 Direct : +1-201-325-6920 Fax : +1-201-373-0124 www.samsungcctvusa.com

www.samsungtechwin.com www.samsungsecurity.com

SAMSUNG TECHWIN EUROPE LTD.

Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS

TEL : +44-1932-45-5300, FAX : +44-1932-45-5325

PT01-000759A

Samsung SCP-2370RH User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
