Samsung SCD-3081 User Manual

Super High Resolution WDR Dome Camera

User Manual

SCD-3081

High Resolution WDR Dome Camera

User Manual

Copyright
©2011 Samsung Techwin Co., Ltd. All rights reser ved.

Trademark

The name of this product is the registered trademar k of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document
shall be reproduced, distribu ted or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaim er

Samsung Techwin makes the best to verify the integrit y and correctness of the contents in this document, but
no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on
the user’s own responsibility. Samsung Techwin reser ves the right to change the contents of this document
without prior notice.

Warranty

If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve
the problem for free of charge. The warrant y period is 3 years. However, the followings are excluded:

If the system behaves abnormally because you run a program irrelevant to the system operation.

•
Deteriorated per formance or natural worn-out in process of time

•

is the registered logo of Samsung Techwin Co., Ltd.

Before operating the camera, confirm the camera model and correct input power voltage.
To help you understand this manual thoroughly, we’ll introduce our model description.

■ SCD-3081 SERIES

 • NTSC MODEL • PAL MODEL
SCD-3081N

  SCD-3081P

■ MODEL DESCRIPTION

• SCD-3081X

 

_



SIGNALSYSTEMSIGNALSYSTEM

 •SIGNAL SYSTEM
  N→NTSC MODEL
  P→PAL MODEL

safety information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric
shock is present within this unit.

This exclamation point symbol is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

WARNING

To prevent damage which may result in fire or electric shock hazard, do not expose this

•
appliance to rain or moisture.

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance

•
with the installation instructions.

WARNING

Be sure to use only the standard adapter that is specified in the specification sheet.

1.

Using any other adapter could cause fire, electrical shock, or damage to the product.

Incorrectly connecting the power supply or replacing battery may cause explosion, fire,

2.

electric shock, or damage to the product.

Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause

3.

abnormal heat generation or fire.

Securely plug the power cord into the power receptacle. insecure connection may cause

4.

fire.

When installing the camera, fasten it securely and firmly. The fall of camera may cause

5.

personal injury.

4_ safety information

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers

6.

filled with water on top of the camera. doing so may cause personal injury due to fire,
electric shock, or falling objects.

Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or

7.

electric shock.

If any unusual smells or smoke come from the unit, stop using the product. in such case,

8.

immediately disconnect the power source and contact the service center. continued use in
such a condition may cause fire or electric shock.

If this product fails to operate normally, contact the nearest service center. never

9.

disassemble or modify this product in any way. (samsung is not liable for problems caused
by unauthorized modifications or attempted repair.)

10.

When cleaning, do not spray water directly onto parts of the product. doing so may cause

fire or electric shock.

CAUTION

Do not drop objects on the product or apply strong shock to it. Keep away from a location

1.

subject to excessive vibrationor magnetic interference.

Do not install in a location subject to high temperature (over 50°C), low temperature (below

2.

-10°C), or high humidity. Doing so may cause fire or electric shock.

If you want to relocate the already installed product, be sure to turn off the power and then

3.

move or reinstall it.

Remove the power plug from the outlet when then there is a lightning. Neglecting to do so

4.

may cause fire or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause fire.

5.

Install it in a place with good ventilation.

6.

Avoid aiming the camera directly towards extremely bright objects such as sun, as this

7.

may damage the CCD image sensor.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

8.

such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at any time.

9.

10.

Do not expose the camera to radioactivity. Radioactivity exposure may damage the CCD.

● SAFETY INFORMATION

English_5

safety information

FCC STATEMENT

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions :

This device may not cause harmful interference, and

1)
This device must accept any interference received including interference that may cause

2)
undesired operation.

CAUTION

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.

IC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian
Interference.-Causing Equipment Regulations of ICES-003.

Correct Disposal of This Product

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC
Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health
or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste
and recycle them through your local, free battery return system.

6_ safety information

(Waste Electrical & Electronic Equipment)

important safety instructions

Read these instructions.

1.

Keep these instructions.

2.

Heed all warnings.

3.

Follow all instructions.

4.

Do not use this apparatus near water.

5.

Clean only with dry cloth.

6.

Do not block any ventilation openings. Install in accordance with the manufacturer’s

7.

instructions.

Do not install near any heat sources such as radiators, heat registers, or other apparatus

8.

(including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

9.

has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10.

Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11.

Only use attachments/accessories specified by the manufacturer.

12.

Use only with cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus.

13.

Unplug this apparatus when a card is used. Use caution when moving

the cart/ apparatus combination to avoid injury from tip-over.

14.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as powersupply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.

● SAFETY INFORMATION

Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus

English_7

contents

INTRODUCTION

9

INSTALLATION

13

CONNECTION

17

9

Features

11

What’s included

12

Component names and

Functions

13

Installation

16

Adjust the panning and tilting

while watching the monitor

17

Connecting to Monitor

17

Connecting to Power

18

Using Coaxial Communications

TROUBLESHOOTING

SPECIFICATIONS

8_ contents

SETUP

19

36

37

19

Menu Configratio

19

Menu Setu

36

Troubleshootin

37

Specification

39

Dimensio

n

p

g

s

n

introduction

FEATURES



Ultra High Resolution

By adopting a diagonal 6mm (1/3”) 520K pixel (NTSC), 610K pixel (PAL) Color Double
Density CCD, the camera produces clear picture quality with a horizontal resolution of
650 TV lines for color and 700 TV lines for BW.



Excellent Sensitivity

The Built-in high sensitivity COLOR CCD produces a clear image.

- Color : 0.1 Lux (50IRE, @F1.2), 0.0002LUX (SENS-UP, x512)

- B/W : 0.01 Lux (50IRE, @F1.2), 0.00002 LUX (SENS-UP, x512)



Intelligence
Without assistance from an external sensor, this camera independently detects and
traces objects while examining stillness and movement to activate the alarm.



SSNR3 (Samsung Super Noise Reduction) Function

The high-performance SV-V DSP chip effectively removes low-light gain noise and
afterimage to provide clear images even in dark environments.



Day & Night(ICR)

The camera identifies whether it is day or night and automatically switches to the
appropriate mode, depending on its environment. By day, the camera switches to color
mode in order to maintain optimal color. At night, it switches to B/W mode so as to obtain
better picture definition.



PROFILE

You can set a mode according to the camera installation conditions.

- BASIC, DAY/NIGHT, BACKLIGHT, ITS, INDOOR, USER



PIP

Displays a full-size image along with the thumbnail.



SSDR(Samsung Super Dynamic Range)

For images with high contrast between bright and dark areas from difficult lighting
conditions such as backlighting, this camera selectively illuminates darker areas while
retaining the same light level for brighter areas to even out the overall brightness.



WDR

By adopting a proprietary SV-V DSP chip, the camera delivers clear, high quality pictures
even when the scene is backlight, by increasing exposure in dark areas while decreasing
it in bright areas; a corrected image with clear details results.



VPS(Virtual Progressive Scan)

Adopting Samsung's unique development, the VPS(Virtual Progressive Scan) enhances
the sharpness of moving subject's outline. The VPS enables elective output in progressive
mode using the existing interlaced input and effectively enhances the sharpness of
captured pictures from video and still images. The function effectively removes blurred
outline problems resulting in excellent road monitoring and improved license plate
recognition.

English_9

● INTRODUCTION

10_ introduction

introduction



DIS (Digital Image Stabilizer)

The DIS function compensates for any camera movement, to produce more stable
pictures.



Miscellaneous Functions

HLC (High Light Compensation), SENS-UP, REVERSE, D-ZOOM, SHARPNESS and
PRIVACY functions are provided.



Communication

Coaxial communication methods are supported.

- Protocol: Pelco Coaxitron



OSD

The camera’s OSD is complimented by 17 languages.

- NTSC: English, Korean, Japanese, Spanish, French, Portuguese

- PAL: English, Chinese, German, Italian, French, Spanish, Russian, Czech, Polish,
Romanian, Serbian, Swedish, Danish, Turkish, Portuguese.

English_11

● INTRODUCTION

WHAT’S INCLUDED

Super High Resolution WDR Dome Camera

User Manual

SCD-3081

ESPAÑOL

Guía Rápida para la Configuración del SCD-3081

SCD-3081 Anleitung zur Schnelleinrichtung

DEUTSCH

❶

Domekuppel ❷ Abschirmkappe

❸

Supporto Pan : Für die Steuerung des Schwenkwinkels der Kamera.

➍

x3.9 Objektiv mit variabler Brennweite : 2.8 ~ 11mm (F1.2).

➎

Funktion-Setup-Schalter : Anzeigen des Bildschirmmenüs und Bewegen des Cursors in vier
Richtungen zur Statusbestä oder nach Änderung eines Elements.

➏

Videoausgang für Anschluss von Monitor

➐

Drehbasis : Für die Steuerung des Drehwinkels der Kamera

➑

Netzeingang : Schließen Sie die für das jeweilige Modell angegebene Stromversorgung hier an.

❾

Erdungsanschluss

❿

D & N Eingang Anschlussterminal : Sie können zwischen Tag- und Nachtmodi umschalten, indem Sie ein
externes Signal an diesen Anschlussterminal anschließen.

⓫

MD Output Anschlussterminal :

Bewegungserkennungssignale werden durch diesen Anschluss ausgegeben.

⓬

Video-Out-Anschlussbuchse : Über diesen Port werden Videosignale ausgegeben. Diesen Port mit
dem Port “Video IN” an einem Monitor verbinden.

❶

Cubierta del Domo ❷ Tapa Protectora

❸

Base de Paneo : Controla el ángulo de paneo de la cámara.

➍

Módulo del Lente Varifocal x3,9 : 2.8 ~ 11mm (F1.2).

➎

Botón de Configuración de Funciones : Muestra el menú en la pantalla y desplaza el cursor en las
cuatro direcciones para confirma estado o el cambio de un elemento seleccionado.

➏

Terminal de Salida de Video al Monitor

➐

Base de rotación : Commande de l’angle de rotation de la caméra.

➑

Terminal de entrada de alimentación : Conecte aquí la alimentación apropiada para cada modelo.

❾

Terminal de toma de tierra

❿

Terminal de entrada D y N :

Puede cambiar al modo Día y Noche conectando una señal externa a este terminal.

⓫

Terminal de salida MD : La salida de las señales de detección de movimiento se realizan a través de
este terminal.

⓬

Puerto de Salida de Video : Permite la salida de las señales de video. Conecte este puerto al puerto
de entrada de un monitor.

EINST HAUPTMENÜ

1.LENS DC

2.BELICHTUNG

3.WEIβAB ATW

4.GEGENLICHT AUS

5.SSNR3 EIN

6.TAG/NACHT AUTO

7.PROFIL GRUND

8.SPEZIAL

9.BEENDEN SAVE

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ
Ķ

ATW / AUßEN / INNEN / MANUELL / AWCĄSET

DC
HELLIGKEIT / SHUTTER / AGC / SENS-UP / ZURÜCK

AUS / BEN BLC / HLC / SSDR / WDR
EIN / AUS

SAVE / NOT SAVE / RÜCKS

GRUND / TAG/NACHT / GEGENLIGHT / ITS / INNEN / BEN

AUTO / EXTERN / COLOR / S/W

BILDEINST / TITEL KAM / SYNC / INTELLIGENCE / PRIVAT
/ DIS / SPRACHE / ZURÜCK

SAVE / NOT SAVE / RESET

CONFIG PRINCIPAL

1.LENTE DC

2.EXPOSIC

3.BAL BLAN ATW

4.CONTRALUZ OFF

5.SSNR3 ON

6.DIA/NOCHE AUTO

7.PROFIL BÁSICO

8.ESPEC

9.SALIR SAVE

DC
BRILLO / SHUTTER / AGC / SENS-UP / VOLVER
ATW / EXTER / INTER / MANUAL / AWCĄSET
OFF / USUA BLC / HLC / SSDR / WDR
ON / OFF

BÁSICO / DIA/NOCHE / CONTRALUZ / ITS / INTER / USUA

AUTO / EXTERNO / COLOR / N/B

AJUST IMAG / TITULO CAM / SYNC / INTELIG. /
PRIVACIDAD / DIS / IDIOMA / VOLVER

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Ķ

Super High Resolution WDR Dome Camera

Quick Set-up Guide

SCD-3081

R
E
D
(
M
D
_
O
U

T

W
H
I
T
E
(
E
X
T
_D
N

)

B
L
A
C
K
(
G
N
D
)

➑

➏➐

➌

⓬

❶

➍

➎

➋

⓫
❿
➒

R
E
D
(
M
D
_O
U
T

W
H
I
T
E
(
E
X
T
_
D
N
)

B
L
A
C
K
(
G
N
D
)

➑

➏➐

➌

⓬

❶

➍

➎

➋

⓫

❿

➒

Check if the following items are included in the product package.

SCD-3081 User Manual Quick Set-up Guide

M4 Tapping Screw 3EA Video Output Cable

12_ introduction

introduction

RED (MD_OUT

WHITE (EXT_DN)

BLACK (GND)

COMPONENT NAMES AND FUNCTIONS

OVERVIEW

➌

2

❶

⓬

⓫
❿
➒
➑

➏➐

❶ Dome Cover
❷ Shield Case

❸

Pan Base : control panning angle of camera

❹

3.9 Vari-focal Lens Module 2.8 ~ 11.0mm (F1.2)

❺

Function Setup Switch : Display the OSD menu and move the cursor up, down,

❻

Video Output Terminal to Monitor

➐

Rotate Base : control rotating angle of camera.

➑

Power Input Connector

➒

Ground Terminal

❿ D & N Input Terminal : You can switch to Day & Night Mode by connecting

⓫

MD Output Terminal: Motion detection signals are output through this terminal.

⓬

Video Output Jack

Be sure to connect the Day & Night input terminal to GND when using an external input.



M

left,and right amend or confi rm changes.

an external signal to this terminal.

4

5

installation

INSTALLATION

1) Separate the dome cover by turning anti-clockwise.

2) Separate the shield case by pulling from the camera body.

* To install the dome cover on the camera

Latch

Locking direction

[Figure-1]

body, turn the latches in locking
direction as shown in the figure-1.

Main Body
(Camera)

Shield Case

● INSTALLATION

Unlocking direction
(Anti-clockwise)

The installation should be done by qualifi ed



M

service personnel or system installers.
If the ceiling material is not strong enough to



hold the installation screws, the camera may
fall off. Reinforce the ceiling as needed.

To change the position of the cable, take away



the Hole Cover and pass the cable through.

Locking direction
(Clockwise)

Dome cover

Original position of
the cable

Hole Cover

English_13

installation

14_ installation

An arrow for installing

directions

M4 tapping
screw (provided)

Ceiling bracket

Lock Lever

Unlocking

direction

Dome cover

Locking
direction

CAMERA

WHEN USING THE CEILING BRACKET

1) Hold down the lock lever on the bottom of the
camera in the UNLOCK position and turn it
counter clockwise with the other hand to
remove the ceiling bracket from the main body.

2) Place the separated ceiling bracket so that
the “Front” side faces the area to be
monitored and install it with the M4 tapping
screws.

3) To combine the main body with the ceiling

bracket, make sure that the pan base fixation
screw face the opposite side of the “Front”
side of the ceiling bracket and rotate it
clockwise.

4) Adjust the camera lens to face the area to be

monitored and fix the main body and the
dome cover by aligning the grooves and
rotating the body clockwise.

If you want to install the camera with the ceiling bracket combined, fix it using two M4 tapping



M

screws at the side of the main body. (refer to the [Figure-2])

M4 tapping
screw

[Figure-2]

Pan Base
fixation
screw

English_15

● INSTALLATION

Ceiling bracket

Locking
direction

Shield Case

Unlocking
direction

Main Body
(Camera)

Dome cover

Lock Lever

IF DETACHING THE CAMERA FROM THE INSTALLATION POSITION

1) Remove the dome cover as well as the shield
case.

2) Hold down the lock lever on the bottom of
the camera in the UNLOCK position and turn
it counter clockwise with the other hand to

remove the ceiling bracket from the main
body.

installation

ADJUST THE PANNING, TILTING & ROTATION WHILE WATCHING THE MONITOR

174˚

176˚

Pan Base

176˚

You can adjust camera to any direction by using Pan, Tilt, Rotate mechanism.

1.



Pan Base moves by 176˚ to each side direction and 352˚ on the whole.



Tilt Base covers total 73˚ angle(0˚ ~ 73˚).



Rotate Base moves by 174° to each side direction and 348° on the whole.

Methods of adjustment

2.



The case of wall installation

1

After mounting the camera on a wall, adjust the panning angle so that the
correct viewing angle is attained and the titling is correctly orientated.

2

And then adjust the tilting angle by rotating the tilt base.

➌

Loosen the rotate base hold screw and adjust rotate base for the best view

4

Tighten rotate base securing screw.



The case of ceiling installation

1

After mounting the camera on a ceiling, adjusting the panning angle to the
correct viewing position by rotating the pan base.

2

And then adjust the tilting angle by rotating the tilt base.

➌

Loosen the rotate base hold screw and adjust rotate base for the best view

4

Tighten pan and tilt securing screw.

When you want to adjust the Pan/Tilt/Rotate Base, loosen, adjust and then tighten the Pan/Tilt/



M

Rotate Base screws.

174˚

73˚

Rotate Base

Tilt Base

16_ installation

connection

CONNECTING TO MONITOR

Connect the VIDEO-OUT jack to the VIDEO-IN jack of monitor.

● CONNECTION

CCTV Camera



As the connecting method varies with the instruments, refer to the manual supplied
with the instrument.



Only connect the cable when the power is turned off.



If necessary, you can connect the monitor to the REMOTE jack on the back of your
camera.

Monitor

CONNECTING TO POWER

Connect the adaptor to the power input connector as shown in the figure below.
The recommended adaptor specification for SCD-3081N/3081P is DC 12V / 500mA or AC 24V /
300mA.

---- Power Input
Terminal

When the resistance value of copper wire is at [20°C(68°F)]

Copper wire size

(AWG)

Resistance (Ω/m) 0.078 0.050 0.030 0.018

Voltage Drop (V/m) 0.028 0.018 0.011 0.006



As shown in the table above, voltage decreases as the wire gets longer. Therefore use of
an excessively long adaptor output line for connection to the camera may
affect the performance of the camera.

#24 (0.22mm2) #22 (0.33mm2) #20 (0.52mm2) #18 (0.83mm2)

English_17

18_ connection

connection

M
E
N
U

SEAR
CH

MUL

T
I

REC

M
E
N
U

PRESET

G
R
O
UP

TRACK

CAM

1

2

3

4

5

6

7

8

9

0

MON

CLO
SE

OPEN

N
EAR

F
AR

WIDE

TELE

P
T
Z

DVR

MTX

SE
TU
P

ESC

FUNC

ENT
ER

1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

ALARM HDD NETWORK BACKUP REC

DVD RECORDER

REC

ZOOM

MODE

FREEZE

AUDIO

BACKUP

ALRAM

SEARCH

TELE WIDE VIEWPRESET

MENU

RETURN

USB

OPEN/CLOSE

* Standard voltage for camera operation : DC 12V ±10%, AC 24V ± 10%
* There may be some deviation in voltage drop depending on the type of wire and the

manufacturer.

Be sure to connect power only after all the installation is complete.



M

Note that AC/DC adaptor is not supplied with camera.



Ground should be connected to the GND terminal.



USING COAXIAL COMMUNICATIONS



Coaxial Communications System



OSD Control method

CAMERA DVR CONTROLLER

SET MENU/ENTER OSD KEY

UP UP KEY JOYSTICK UP

DOWN DOWN KEY JOYSTICK DOWN

LEFT LEFT KEY JOYSTICK LEFT

RIGHT RIGHT KEY JOYSTICK RIGHT

DVR

•

---- : RS-485

•

- Video Cable
The camera’s video output port is connected to the monitor with a BNC coaxial

cable, shown below : If the distance between the camera and the monitor exceeds
the recommended maximum, please use an auxiliary video amp.

Distance Recommended Cable Specifi cation

300m 3C2V(RG-59/U)

450m 5C2V(RG-6/U)

600m 7C2V(RG-11/U)

It is recommended that pure copper coax cable is used and not copper coated steel, as this will



M

cause issues with the communication over the coaxial cable.
To ensure image quality, please connect only one-way video output from camera to other video



display devices.

: BNC

setup

MENU CONFIGRATION

Setup Menu

●

LENS

EXPOSURE

WHITE BAL

BACKLIGHT

SSNR3

DAY/NIGHT

PROFILE

SPECIAL

EXIT

MENU SETUP

Use the Function Setup switch beside of the lens.

DC

●

BRIGHTNESS

●

SENS-UP

●

ATW

●

MANUAL

●

OFF

●

SSDR ● WDR

●

ON

●

AUTO

●

B/W

●

BASIC

●

ITS

●

IMAGE ADJ

●

INTELLIGENCE

●

LANGUAGE

●

SAVE

●

SHUTTER

●

RETURN

●

OUTDOOR

●

AWC→SET

●

USER BLC

●

OFF

●

EXTERN

●

DAY/NIGHT

●

INDOOR

●

CAM TITLE

●

PRIVACY

●

RETURN

●

NOT SAVE

●

AGC

●

INDOOR

●

HLC

●

COLOR

●

BACKLIGHT

●

USER

●

SYNC

●

DIS

●

RESET

● SETUP

Function Setup switch

English_19

20_ setup

setup

Press the Function Setup switch.

1.



Main setup menu is displayed on the monitor screen.

Select the function
by moving up or
down direction of
function setup switch.

▶ 1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW

4.

5.

6.

7.PROFILE BASIC

8.SPECIAL

9.EXIT SAVE

Select a desired function using the Function Setup switch.

2.



Place the cursor over a desired item.

Set up a selected item by using the Function Setup switch.

3.

To finish the setting, select ‘EXIT’ and press the Function Setup switch.

4.

An item with the icon also has sub menus. To select a sub menu, select an item with the icon



M

and press the Function Setup switch.
An item with the - - - icon is unavailable due to function settings.



LENS

Using this function, you can control the screen brightness.

When the SETUP menu screen is displayed,

1.

select‘LENS’by using the Function Setup
switch so that the arrow indicates‘LENS’.

The Lens mode has sub menu site as listed

2.

below.

- BRIGHTNESS : Adjusts the video brightness.

- FOCUS ADJ : To adjust the lens focus correctly, you must activate the Focus
Settings mode. To activate the Focus Settings mode, adjust the lens focus,
and then deactivate the settings mode.

- You can adjust the shutter value of ESC shutter mode.

MAIN SETUP

BACKLIGHT OFF
SSNR3 ON
DAY/NIGHT AUTO

▶ 1.LENS DC

2.EXPOSURE

MAIN SETUP

Change the status
by moving the
setup switch left or
right.

English_21

● SETUP

EXPOSURE

When the SETUP menu screen is displayed,

1.

select EXPOSURE by using the Function
Setup switch so that the arrow indicates
'EXPOSURE'.

Select a desired mode using the Function

2.

1.LENS DC
▶ 2.EXPOSURE

3.WHITE BAL ATW

Setup switch.

BRIGHTNESS : Adjusts the video brightness.



SHUTTER : You can select shutter mode.



ESC : Select this to control the shutter

-

speed automatically. If ESC is
selected, the shutter speed is
automatically controlled depend-

▶ 1.

2.SHUTTER ---

3.AGC HIGH

4.SENS-UP OFF

5.RETURN

ing on the ambient illumination of the subject.

MANUAL : You can control shutter speed manually.

-

(NTSC MODEL : 1/60~1/120,000, PAL MODEL : 1/50~1/120,000)

A.FLK : Select this when you experience picture flicker, this happens when

-

there is a clash with the installed lighting frequency.

---: Shutter speed is fixed at 1/60sec(1/50sec).

-

When the SHUTTER is set to ESC after selecting the Internal Synchronization Type, the picture may



M

become unstable if the camera faces a bright fluorescent light. Therefore, take care when choosing
the installation position.
When the SHUTTER is set to MANUAL or A.FLK mode, SENS-UP will be disabled.



Set the shutter mode to --- if color rolling occurs.



MAIN SETUP

EXPOSURE SETUP

BRIGHTNESS

IIIIIIIIIIIIIIIIIIIII

25

AGC (AUTO GAIN CONTROL)



: The higher the gain level, the brighter the screen

but the higher the noise.

OFF : Deactivates the AGC function.

-

LOW : Allows automatic gain control from 5.3dB to 32dB.

-

HIGH : Allows automatic gain control from 5.3dB to 37dB.

-

SENS-UP



: When it is night or dark, the

camera automatically detects the
light level and maintains a clear

▶ AUTO x2

picture if this mode is activated.

OFF : Deactivates the SENS-UP function.

-

AUTO : Activates the SENS-UP function.

-

LIMIT

Press SET to Return

22_ setup

setup

RETURN



M

WHITE BAL (WHITE BALANCE)

Use the White Balance function to adjust the screen color.

When the SETUP menu screen is displayed, select ‘White Bal.’ by using the

1.

Function Setup switch so that the arrow
indicates ‘White Bal.’.

Select a desired mode using the Function

2.

Setup switch.

※ Select one of the following 5 modes, as

appropriate for your purpose.











: Select this to save the changes in the EXPOSURE menu and return to

the SETUP menu.

If you set the Function Setup switch to 'AUTO' mode, You can adjust the brightness by increasing



or decreasing the limit value. (x2~x512)
Note that the higher the SENS-UP level, the brighter the screen, but the more likely it is that an



after-image will appear.
Although Noise, Spots, and Whitish symptoms may occur in SENS-UP operation when the



sens-up level is increased, this is normal.

1.LENS DC

2.EXPOSURE
▶ 3.WHITE BAL ATW

4.BACKLIGHT OFF

ATW

: Select this when the color temperature is between 1,700°K and 11,000°K.

OUTDOOR

INDOOR

MANUAL : Select this to fine-tune White

AWC→SET

: Select this when the color temperature is between 1,700°K and

11,000°K.(sodium light inclusion)
Select this When the color temperature of environment surrounding
the subject is out of the control range (e.g. clear sky, or sunset)

:

Select this when the color temperature is between 4,500°K and 8,500°K.

Balance manually. Set White
Balance first by using the ATW
or AWC mode. After that switch
to MANUAL mode, fine-tune the
White Balance and then press the
Function Setup switch.

: To find the optimal luminance level for the current environment,

point the camera towards a sheet of white paper and press the
Function Setup switch. If the environment changes, readjust it.

▶ RED GAIN
BLUE GAIN

Press SET to Return

MAIN SETUP

WB MANUAL

IIIIIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIIIIIIII

529
532

English_23

● SETUP

White Balance may not work properly under the following conditions. In this case select the AWC



M

mode.

1

When the color temperature of the environment surrounding the subject is out of

the control range (e.g. clear sky or sunset).

2 When the ambient illumination of the subject is dim.

➌

If the camera is directed towards a fluorescent light or is installed in a
place where illumination changes dramatically, the White Balance
operation may become unstable.

BACKLIGHT

This camera is designed so that it delivers a distinctive subject and background at
the same time, even when the subject is in backlight, unlike conventional cameras, by
adopting a proprietary SV-V DSP chip.

When the SETUP menu screen is displayed,

1.

select ‘BACKLIGHT’ by using the Function
Setup switch so that the arrow indicates
BACKLIGHT .

Select a desired mode using the Function Setup

2.

switch depending on the camera purpose.

USER BLC



: Enables a user to directly

select a desired area from a
picture, and to view the area
more clearly.

LEVEL : Adjust level of the BLC function.

-

TOP/BOTTOM/LEFT/RIGHT :

­Adjust the area to be enhanced.



HLC (High Light Compensation) :

This function masks the strong light to
minimize white out due to over exposure and
preserve much of the on-screen details when
the camera aims a strong light source.

LEVEL : Adjusts the brightness level of a

-

monitoring area.

LIMIT : Enable to change the operating

-

condition.

1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW
▶ 4.BACKLIGHT OFF

5.SSNR3 ON

▶ 1.LEVEL

2.TOP

3.BOTTOM

4.LEFT

5. RIGHT

6. RETURN

▶ 1. LEVEL

2. LIMIT

3. MASK COLOR BLACK

4. MASK TONE

5.TOP

6.BOTTOM

7.LEFT

8.RIGHT

9. RETURN

MAIN SETUP

BLC SETUP

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

Press SET to Return

HLC SETUP

IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

Press SET to Return

MIDDLE

150

MIDDLE

NIGHT ONLY



105



210

25
90
70

5

10

10

24_ setup

setup





MASK COLOR/TONE :

-

Change the color / brightness of the masking area. (Black, Red, Blue, Cyan, Magenta)
TOP/BOTTOM/LEFT/RIGHT :

-

Adjust the area to be enhanced.

OFF

: Not being used

SSDR

(Samsung Super Dynamic Range) :

SSDR illuminates darker areas of an
image while retaining the same light level
for brighter areas to even out the overall
brightness of images with high contrast
between bright and dark areas.
Use the Function Setup switch to
change the SSDR level in the sub menu

▶ LEVEL

Press SET to Return

SSDR SETUP

IIIIIIIIIIIIIIIIIIIII

according to the contrast between bright
and dark areas.

8

SSDR ON

WDR

: When there are both bright and dark areas at the same time, this

mode makes both areas distinctive.
Select 'WDR' to adjust the WDR
LIMIT and LEVEL.

- LIMIT : Adjust the WDR Sensitivity by
selecting LOW, MIDDLE or
HIGH.

- LEVEL : Adjust the WDR Brightness by

SSDR OFF

WDR SETUP

▶ 1.LIMIT

2.LEVEL

3.MODE INDOOR

4.ANTI ROLLING OFF

5. RETURN

IIIIIIIIIIIIIIIIIIIII

controlling the bar from 1 to 10.

- MODE : Indoor and outdoor backlight

conditions are appropriately selected.

- ANTI ROLLING : Rolling caused around a fluorescent lamp is improved.

MIDDLE

5

English_25

● SETUP

< WDR ON >

Because there can be a difference in the effectiveness of HLC according to the amount of light



M

area in the screen, optimize the installation angle for the best HLC performance.
In a dark environment, the HLC is only activated when a high light that is larger than a certain area



is present.
The HLC is not activated in day light or when bright light is not present at night. (In NIGHT ONLY



mode).
When using the WDR function, the shutter is only available with the fixed (---) mode.



Since the performance of the WDR function may be affected by the area of the bright part of the



screen, optimize the installation angle for the best WDR performance.
If you increase LIMIT, the screen display may be distorted.



If you use the VPS (Virtual Progressive Scan) function, the CCD reads differently so you can not use



WDR simultaneously. If you set VPS to ON, WDR will be automatically set to FIXED Mode.

< WDR OFF >

26_ setup

setup

SSNR3

This function reduces the background noise in a low luminance environments.

When the SETUP menu screen is displayed,

1.

select 'SSNR3' by using the Function Setup
switch so that the arrow indicates 'SSNR3' .

Select a desired mode using the Function

2.

Setup switch.

: Deactivates SSNR3 so that noise is



OFF

not reduced.

ON

: Activates SSNR3 so that noise is reduced.



Set the SSNR3 mode to 'ON' and press the

3.

Function Setup switch. Then you can adjust
the noise reduction level.

You cannot set the SSNR3 to 'ON' or 'OFF' when the AGC mode of the EXPOSURE menu is 'OFF'.



M

When adjusting the noise reduction level of the SSNR3 mode, remember that the higher the level



set, the more the noise level will be reduced but that after image may also occur.

1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW

4.BACKLIGHT OFF
▶ 5.SSNR3 ON

6.DAY/NIGHT AUTO

▶ LEVEL

DAY/NIGHT

You can display pictures in color or black and white.

When the SETUP menu screen is displayed,

1.

select ‘DAY/NIGHT’ by using the Up and
Down buttons so that the arrow indicates
‘DAY/NIGHT’.

Select a desired mode using the Left and

2.

Right buttons according to the picture
display you want.

AUTO

: The mode is switched to ’Color‘ in a normal environment, but switches to



’B/W‘ mode when ambient illumination is low. To set up the switching time
for AUTO mode, press the Function Setup
the burst signal on B/W mode.

1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW

4.BACKLIGHT OFF

5.SSNR3 ON
▶ 6.DAY/NIGHT AUTO

MAIN SETUP

IIIIIIIIIIIIIIIIIIIII

Press SET to Return

MAIN SETUP

switch

. You can turn on or off

SSNR3

15

English_27

● SETUP

▶1.BURST MODE ON

2.COLORB/W
DURATION FAST
DWELL TIME 5 SEC

3.B/WCOLOR
DURATION FAST
DWELL TIME 10 SEC

4.RETURN

-

BURST MODE : You can turn on or off the burst signal on B/W mode.

-

DWELL TIME : You can select the duration time about changing the

-

DURATION : You can select the brightness level at which the camera

※ Light levels are often site dependant.

EXTERN:



COLOR: The picture is always displayed in color.



B/W: The picture is always displayed in black and white.



You can turn on or off the burst signal on B/W mode.

When AGC in the EXPOSURE menu is ‘OFF’, ‘---’ mode operates as selecting ‘COLOR’ mode and



M

‘AUTO’ mode cannot be selected.



Be sure to connect the Day & Night input terminal to GND when using an external input.

The OSD key does not work for 3 seconds when switching to Color or B/W, to ensure stable



camera operation.

day/night mode.
→3s, 5s, 7s, 10s, 15s, 20s, 30s, 40s, 60s

switches from day to night mode.

Fast 2.5 lux 5 lux

Slow 1 lux 7 lux

This mode allows you to apply a desired filter to external signals.

AUTO SETUP

Color → B/W B/W → Color

28_ setup

setup

PROFILE

When the SETUP menu screen is

1.
displayed, select ‘PROFILE’ by using the
Function Setup switch so that the arrow
indicates ‘PROFILE’.

Select a desired mode using the Function

2.
Setup switch according to the picture
display you want.



BASIC : The most common environment is
set to meet.



DAY/NIGHT : It will be set automatically so it optimizes to the day or night



BACKLIGHT : It will be set automatically so you can distinguish the object from



ITS : It will be set automatically so you can easily check the traffic conditions.



INDOOR : It will be set automatically to help you take a picture in a regular



USER : Automatically configures the camera to your custom settings.

1)

Select Custom for Simple Setup mode.

Configure the menu options to your custom settings.

2)

3)

The settings are automatically saved as Custom mode.
Profile user mode don't initialize when menu resets.

4)

In the PROFILE menu, you can configure the following camera settings at

3.
once.

conditions, respectively.

the background in a severe backlighting scene.

indoor lighting condition.

1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW

4.BACKLIGHT OFF

5.SSNR3 ON

6.DAY/NIGHT AUTO
▶ 7.PROFILE BASIC

MAIN SETUP

SHUTTER --- --- ---

BASIC DAY/NIGHT

GAIN HIGH HIGH HIGH HIGH HIGH ­ WHITE BAL ATW ATW ATW OUTDOOR INDOOR ­ BACKLIGHT OFF OFF USER BLC OFF OFF -

SSNR3 ON ON ON ON ON -

DAY/NIGHT AUTO AUTO AUTO AUTO AUTO -

BACKLIGHT

ITS INDOOR USER

MANUAL(1/250)

A.FLK -

English_29

● SETUP

SPECIAL

When the SETUP menu screen is displayed,

1.

select ‘SPECIAL’ by using the Function Setup
switch so that the arrow indicates ‘SPECIAL’.

Select a desired mode using the Function

2.

Setup switch.

IMAGE ADJ :



1) When the SPECIAL menu screen is

2



Monitor

of video appropriate to your monitor.

-

-

-



VPS(Virtual Progressive Scan)

an advanced technology that reproduces a
sharp progressive image. This is appropriate
to high quality recording and file transfer via
the Internet.

-

-

displayed, select ‘IMAGE ADJ’ by using
the Function Setup switch so that the
arrow indicates ’IMAGE ADJ‘.

) Select a desired mode using the Function

Setup switch.

: Please change the settings value

LCD : Please select this menu item when

using an LCD monitor.
You can change the gamma, PED
level and color gain in the sub
menus.

CRT : Please select this menu item when

using a CRT monitor. You can
change the PED level, color gain in
the sub menus.

USER : Please use this menu item when

using a monitor other than stan­dard ones. You can change the
gamma, PED level and color gain
in the sub menus.

OFF : Selects 2:1 Interlaced Scan as the Imaging Method.
ON : Selects Progressive Scan as the Imaging Method.

: This is

▶8.SPECIAL

Press SET to Return

MAIN SETUP

SPECIAL

IMAGE SETUP

LCD MONITOR

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

1.LENS DC

2.EXPOSURE

3.WHITE BAL ATW

4.BACKLIGHT OFF

5.SSNR3 ON

6.DAY/NIGHT AUTO

7.PROFILE BASIC

▶ 1.IMAGE ADJ

2.CAM TITLE OFF

3.SYNC INT

4.INTELLIGENCE OFF

5.PRIVACY OFF

6.DIS OFF

7.LANGUAGE ENGLISH

8.RETURN

▶ 1. MONITOR LCD

2.VPS OFF

3.REVERSE OFF

4.PIP OFF

5.D-ZOOM OFF

6.FONT COLOR BLUE

7.SHARPNESS ON

8.RETURN

▶ GAMMA 0.55
PED LEVEL
COLOR GAIN
RESET

14

5

30_ setup

setup



REVERSE : You can reverse the picture.

OFF : You don’t reverse the picture.

­H-REV : You can flip the picture horizontally on the screen.

­V-REV : You can flip the picture vertically on the screen.

-



-

HV-REV : You can flip the picture horizontally and vertically on the screen.



PIP(Picture in Picture) : Displays a full-
size image along with the thumbnail to
provide more detailed information. The
position of the thumbnail is adjustable.



D-ZOOM : You can use a digital zoom of
x1 ~ x16.



FONT COLOR: You can change the OSD
font color. (White, Yellow, Green, Red, Blue)

:



SHARPNESS

RETURN: Select this to save the settings



When the V-REV or H-REV mode is enabled, the text on the screen does not flip.



M

If you increase the SHARPNESS level too high, the picture may become distorted or noise may



appear.

As you increase this value,

the picture outline becomes
stronger and clearer. Adjust
this value appropriately
depending on the sharpness
of the picture.

for the IMAGE ADJ menu and to
return to the SPECIAL menu.

1.XPOS

2.YPOS

3. RETURN

▶LEVEL

Press SET to Return

PIP SETUP

SHARPNESS

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

17
17

15

CAM TITLE



:

If you enter a title, the title will appear on the monitor.

1 If the SPECIAL menu screen is

displayed, use the Function Setup
switch so that the arrow indicates
‘CAM TITLE’.

2 Set it to ‘ON’ by using the Function

Setup switch.

➌ Press the Function Setup switch.

CAMERA TITLE SETUP

A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
a b c d e f g h i j k l m
n o p q r s t u v w x y z

- . 0 1 2 3 4 5 6 7 8 9
← → C L R P O S E N D

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _

English_31

● SETUP

4 Use the Function Setup switch to move to a desired letter and select the letter

by pressing the switch. Repeat this to enter multiple letters. You can enter
up to 15 letters.

5 Enter a title, move the cursor to ’POS’

and press the Function Setup switch. The
entered title appears on the screen. Select
the position to display the title on the screen
by using the Function Setup switch and
press. When the position is determined,
select ’END’ and press the Function Setup
switch to return to the SPECIAL menu.

When the CAM TITLE menu is ‘OFF’, no title will be displayed on the monitor screen even if you



M

enter one.

Only English is available in the mode.



If you move the cursor to CLR and press the Function Setup switch, all the letters are deleted.



To edit a letter, change the cursor to the bottom left arrow and press the Function Setup switch.
Move the cursor over the letter to be edited, move the cursor to the letter to be inserted and then
press the Function Setup switch.



SYNC :

In areas where the supply is
at 60Hz(NTSC), 50Hz(PAL), you can
synchronize the output phase of multiple
cameras using the power synchronization
function (Line-Lock) without using a
synchronization signal generator.

INT : Internal Synchronization Type

-

LL : Power Synchronization Type, Line-lock

-

Press the Function Setup switch.





You can select a desired phase from 0 to 359 when select ‘phase’.

When using AC power at 60Hz(NTSC), 50Hz(PAL) frequency, you can use the LL type



M

synchronization.

When the power is DC 12V, the SYNC menu is fixed to the ‘INT’ mode.



If the VPS is set to ON, synchronization is fixed to INT.



FRONT DOOR

▶ PHASE

Press SET to Return

SYNC



IIIIIIIIIIIIIIIIIIIII

0

32_ setup

setup



INTELLIGENCE:

MOTION : Select motion types to

­detect.

OFF : Not being used.

-

-

DETECTION : Since the camera

-

TRACKING : Commands the camera to

▶FENCE :
You can select up to 4 FENCE.
▶MODE : Determines whether to use

▶TYPE : Two types, line and area, of

▶COUNT : Displays the number of times that an object enters or leaves a

▶FILL : Fill or remove color from the FENCE.
▶POSITION : Defines the position and detection direction of a line or

1) LINE FENCE

-

-

- DIRECTION

·DIR2 :

·DIR1/2 : Detects all objects moving crosswise on the fence line.

-

2) AREA FENCE

- SEL POS :

-

- DIRECTION

·

·

Commands the camera to motion-detect and trace an object.

INTELLIGENCE

▶ 1.MOTION OFF

2.DETECT BOX ON

3.ALARM OUT OFF

detects motion without
any additional external
sensor, you can monitor
activity more efficient.

detect and trace a moving
object.

the fence selected in the
FENCE.

fences are available.

4.DETECT AREA

5.MASK AREA

6.SENSITIVITY

7.DET.SIZE

8.RETURN

▶ 1.FENCE FENCE1

2.MODE OFF

3.TYPE LINE

4.COUNT OFF

5.FILL OFF

6.POSITION

7.RETURN

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

TRACKING

fenced area.

fenced area.

SEL POS : Selects a position from POS1,POS2.
X POS / Y POS : Adjust the size and position of the selected line fence.

·

DIR1 : Detects objects moving left to right on the fence line.

Detects objects moving right to left on the fence line.

RETURN : Select this to save the POSITION menu settings and

return to the TRACKING menu.

Selects a position from POS1 ~ POS4.

X POS / Y POS : Adjust the size and position of the selected area fence.

IN : Detects objects entering the fenced area.
OUT : Detects objects exiting the fenced area

3
3

English_33

● SETUP

·IN/OUT : Detects all objects entering and exiting the fenced area.

- RETURN : Select this to save the POSITION menu settings and return to
the TRACKING menu.

▶

RETURN : Select this to save the TRACKING menu settings and return to

the INTELLIGENCE menu.

1. SEL POS POS1

2. X POS

3. Y POS

4. DIRECTION DIR1

5. RETURN

-

LINE FENCE

IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIIIIIII

FIXED/MOVED : Detects an object that emerges or disappears from the

screen, or stays onscreen without movement

A detection (FIXED/MOVED) error may occur if :



M

· multiple motions occur continuously in random directions

· a fixed object moves in one position continuously

· a second object screens the first moving object

DETECT BOX : Outlines an object on the screen in a box when its

-

1. SEL POS POS1

12

2. X POS

1

3. Y POS

4. DIRECTION IN

5. RETURN

AREA FENCE

IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIIIIIII

12

1

.

movement matches a custom Motion Type.

ALARM OUT : Releases a signal from the MD Output Terminal of the

-

DETECT AREA : Defines the Motion

­Detection area.

MASK AREA : Specify a detection

-

▶AREA : You can select up to 4 areas.
▶MODE : Determines whether to use the

▶ TOP / BOTTOM / LEFT / RIGHT :

Adjust the size and position of the
selected area.

camera when an object’s movement matches a custom
Motion Type.

1. TOP

DETECT AREA

2. BOTTOM

exception area to mask.
Select a mask area
number and specify the
size and position.

area selected in the AREA.

3. LEFT

4. RIGHT

5. RETURN

▶1. AREA AREA1

2. MODE OFF

3. TOP

MASK AREA

4. BOTTOM

5. LEFT

6. RIGHT



IIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIIII

1



50

1



50

30

110

25

110

7. RETURN

34_ setup

setup

▶ RETURN : Select this to save the MASK AREA menu settings and return to

the INTELLIGENCE menu.

SENSITIVITY : Set the sensitivity of the motion detection. When adjusting

­the sensitivity, note that the lower the level means the higher
sensitivity.

DET. SIZE :

-

Selects an object size to detect on the screen. When adjusting
the detection size, note that the higher the level means the bigger
detection size.

RETURN : Select this to save the INTELLIGENCE menu settings and return to

-

the SPECIAL menu.

PRIVACY



: Mask an area you want to hide on the screen,

1 When the SPECIAL menu screen is

displayed, press the Function Setup
switch so that the arrow indicates
‘PRIVACY’.

2 Set up the mode using the Function

Setup switch.

AREA: You can select up to 12 PRI-

-

VACY areas.

MODE : Determines whether to use

-

PRIVACY AREA SETUP

▶ 1.AREA AREA1

2.MODE OFF

3.MASK COLOR GREEN

4.TRANSPARENCY OFF

5.SEL POS L_TOP

6.XPOS

7.YPOS

8.RETURN



IIIIIIIIIIIIIIIIIIIII



IIIIIIIIIIIIIIIIIIIII

10
10

the area selected in the AREA
SEL.

MASK COLOR : Determine area color. You can select GREEN, RED, BLUE,

-

BLACK, WHITE and GRAY.

-

TRANSPARENCY : Adds or removes transparency from the masking

area.

SEL POS/XPOS/YPOS : Adjust the size and position of the selected

-

area.
RETURN : Select this to save the PRIVACY menu settings and return to the

-

SPECIAL menu.



DIS (Digital Image Stabilizer)

:

This function mitigates any picture movement due to external factors such as wind.

As the DIS function uses the digital zoom the camera's resolution will decrease.



M

DIS doesn’t operate when background illumination is too low.



DIS doesn’t operate when object pattern is monotonic as like sky or white wall.



English_35

● SETUP

LANGUAGE



-

-



RETURN

: You can select the menu language according to your requirements.

NTSC : Korean, English, French, Spanish, Japanese, Portuguese
PAL : English, Chinese, German, Italian, French, Spanish, Russian, Czech,

Polish, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese

: Select this to save the SPECIAL menu settings and return to the MAIN

SETUP menu.

EXIT

Select a desired EXIT mode using the Function Setup switch depending on the camera
purpose.

SAVE : Save the current settings and exit the MAIN SETUP menu.





NOT SAVE : Do not save the current settings and exit the MAIN SETUP menu.



RESET: Resets the camera settings to the factory defaults.

Language and Monitor settings are not initialized.

troubleshooting

TROUBLESHOOTING

If you have trouble operating your camera, refer to the following table. If the guidelines do
not enable you to solve the problem, contact an authorized technician.

PROBLEM SOLUTION

Nothing appears on the screen.

The image on the screen is dim.

The image on the screen is dark.

The camera is not working
properly, and the surface of the
camera is hot.

The DAY/NIGHT menu does not
work.

The SENS-UP function does not
work.

The INTELLIGENCE function does
not work.

Color is not correct.

The screen flickers continually.

When coaxial communication is
not available:

The camera is out of focus.

▶ Check that the power cord and line connection between the camera

and monitor are fixed properly.

▶ Check that you have properly connected BNC cable to the camera.

▶

Is the lens stained with dirt? Clean your lens with a soft, clean cloth.

▶

Check the monitor and DVR settings.

▶

If the camera is exposed to very strong light, change the camera position.

▶

Adjust the contrast feature of the monitor .
If you have an intermediate device, set the 75Ω / Hi-z properly.

▶

▶

Check that you have properly connected the camera to an appropriate
power source.

▶

Check that AGC of EXPOSURE SETUP menu is ‘OFF’.

▶ Check that AGC of EXPOSURE SETUP menu is ‘OFF’.

Check that SHUTTER of EXPOSURE SETUP menu is ‘A.FLK’ or

▶

‘MANUAL’.

▶

Check that INTELLIGENCE of menu is ‘OFF’.

▶ Check the setting of WHITE BAL SETUP menu .

▶ Check that the camera is not pointing at the sun.

▶Make sure that the camera and monitor are installed within the

recommended distance.

Use the video amplifier equivalent to coaxitron if the

▶

recommended installation distance is exceeded.

▶Check that you have properly adjusted the zoom/focus
adjustment lever of lens.

36_ troubleshooting

English_37

● TROUBLESHOOTING

specifications

SPECIFICATIONS

VIDEO

Imaging Device

Total Pixels

Effective Pixels

Scanning System

Synchronization

Frequency

Horizontal Resolution

Min. Illumination

S / N Ratio

Video Output

Lens Type

Focal Length(Zoom Ratio)

Max. Aperture Ratio

Angular Field of View

Lens Type

Mount Type

Pan / Tilt /Rotate

Pan/Tilt/Rotate Range

OPERATIONAL

On Screen Display

Camera Title

1/3 inch, 520K pixel(NTSC), 610K pixel(PAL) Double Density CCD

1028(H) x 508(V) 1028(H) x 596(V)

976(H) x 494(V) 976(H) x 582(V)

2 : 1 Interlace / Progressive

Internal / Line Lock

H:15.734KHz / V:59.94Hz H:15.625KHz / V:50Hz

Color : 650 TV lines, B/W : 700 TV lines

COLOR : 0.1 Lux (50IRE, @F1.2), 0.0002Lux (SENS-UP, x512)

B/W : 0.01Lux (50IRE, @F1.2), 0.00002Lux (SENS-UP, x512)

52dB (AGC off, Weight on)

CVBS : 1.0 Vp-p / 75Ω composite

2.8 ~ 11mm (3.9x)

1:1.2(Wide) ~ 2.8(Tele)

94.0°(Wide) ~ 26.0°(Tele) / V: 67.0°(Wide) ~ 20.0°(Tele)

DC Auto Iris

Board Type

0°~352° / 0°~73° / 0°~348°

Multi-language Support by
Coaxial Cable
English, Japanese, Spanish, French,
Portuguese, Korean

Off / On (Displayed 15 characters)

SCD-3081N SCD-3081P

Multi-language Support by
Coaxial Cable
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese

●      ● SPECIFICATIONS

38_ specifications

specifications

Day & Night

Backlight Compensation

Wide Dynamic Range

Dynamic Range (SSDR)

Digital Noise Reduction (SSNR

Digital Image Stabilization

Privacy Masking

Sens-up
(Frame Integration)

Gain Control

White Balance

Electronic Shutter Speed

Digital Zoom

Flip / Mirror

Profile

VPS

Communication

Environmental

Operating Temperature / Humidity

Electrical

Input Voltage

Power Consumption

Mechanical

Color / Material

Dimension

Weight

※

This specification can be changed without notice for performance improvement of product.

Ⅲ )

SCD-3081N SCD-3081P

Auto (ICR) / EXTERNAL/ Color / B/W

Off/ USER BLC / HLC / SSDR /WDR

128x 160x

Off / On

Off / On

Off / On

Off / On (12 Programmable zones, Polygonal type)

2x ~ 512x

Off/ Low / High

ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)

1/60 ~ 1/120,000 sec 1/50 ~ 1/120,000 sec

Off / On (1x ~ 16x)

Off / H-Rev / V-Rev / HV-Rev

Basic, Day & Night, Backlight, ITS, Indoor, User

Off / On

Coaxial Control ( SPC-300 Compatible )

-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH

AC 24V ± 10% , DC 12V±10%

Max. 3.5W

Ivory / Plastic (Dome Cover : Clear)

Ø115.8 x 92.7mm

365g

English_39

● TROUBLESHOOTING●      ● SPECIFICATIONS

DIMENSION

Ø115.8

Ø97

92.7

MEMO

SALES NETWORK

SAMSUNG TECHWIN CO., LTD.

Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400
TEL : [phone]~60, FAX : [phone]

SAMSUNG TECHWIN AMERICA Inc.

100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : [phone] Direct : [phone]
Fax : [phone]
www.samsungcctvusa.com

www.samsungtechwin.com
www.samsungsecurity.com

SAMSUNG TECHWIN EUROPE LTD.

Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS

TEL : [phone], FAX : [phone]

P/NO. : PT01-000073A (01)
