Page 1
FIRST EDITION 03-2012
2012 Products
Page 2
SamSung
ToTal
SecuriTy
SoluTionS
2012 Products
FIRST EDITION 03-2012
Page 3
Your Source for
Professional Security Solutions
Samsung Techwin was founded in 1977 as Part of Samsung's Machinery
and Heavy Industries Group. This group has specialized in a wide range of
high technology products such as semiconductor manufacturing systems,
turbine engines, and defense systems. The need for advanced optical and
image processing technologies came from the company's activities in these
areas. After years of successful development of advanced optics and digital
processing technology, the Security Solutions division was created to provide
commercial security products from these technologies. What you see in this
catalog is not just another version of video security products produced from
off the shelf components. Samsung Techwin's security solution products are
based upon cutting edge technologies that are unique in the security
industry. When you try our products you will experience the difference that
these technologies provide.
02
Page 4
Quality & Reliability
“Quality and Reliability” is the key concern for physical security products and every user is concerned about the
potential failure of their products. Warranty or no warranty, additional cost or not, the most important point is that users
may not be able to use the products at the moment of greatest need. The best way to alleviate this worry and
inconvenience would be to minimize product failure by conducting vigorous quality test.
Understanding the importance of product quality and reliability, Samsung Techwin is committed to adhering to high
standards of tests throughout the product development stages. Samsung Techwin has dedicated teams of people for
the Quality Assurance and use cutting edge testing equipments to prove the reliability of the products. The Quality
Assurance team publishes the reliability reports and MTBF figures (Mean Time Between Failures) to provide a guide for
product lifetime expectations.
Image Quality Evaluation :
To guarantee the image quality of our products, we conduct tests in a dedicated
image quality evaluation lab. The resolutions/chrominance/phase under various
light/environment conditions for various objects, color reproducibility and other
operational functions are tested here, to ensure reliable image quality.
ALT (Accelerated Life Test) / HALT (Highly Accelerated Life Test) :
We ensure product reliability by eliminating potential quality defects in advance,
through the use of a variety of high-level stress tests relating to temperature,
vibration and power.
Temperature & Humidity Profile Test :
(Environmental tests for high-temperature/low-temperature/high-humidity) :
We ensure that our products operate normally under any environmental conditions
by conducting a variety of environmental tests.
Power Environment Test :
To secure the electronic reliability of our products, we perform an electro-static
test, which verifies the electrical tolerances against unstable voltage supply,
voltage drop and thunder stroke.
Distribution Environment Test :
To minimize the possibility of damage occurring during shipping, we perform tests
including vibration, drop, and cold proof drop according to international standards,
which simulate the types of situations that can occur during product distribution.
03
Page 5
Product Numbering Rule
Network Camera
SNP
Samsung Network Camera Appearance
Analogue Camera
B : Box
Z : Zoom
V : Dome(Vandal)
D : Dome(Interior)
P : PTZ
U : P/T United
O : One body box
M : Module
SCP
Samsung Transmission (Video)
C : Camera
U : UTP Camera
Appearance
B : Box
D : Dome (Interior)
M : Module
O : One body box
P : PTZ
U : P/T United
V : Dome (Vandal)
Z : Zoom
-
3371TH
Sensor (Pixel No.)
9 : Special, EMCCD
8 : 5 Mega
7 : 3 Mega
6 : 2 Mega
5 : 1.3 Mega
4 : SVGA
3 : WDR CCD
2 : BLC CCD
1 : VGA CMOS
-
3120VH
Sensor (Pixel No.)
9 : Special
8 : 5 Mega
7 : 3 Mega
6 : 2 Mega
5 : 1.3 Mega
4 : 1/2"
3 : WDR CCD
2 : BLC CCD
1 : VGA / 270K
Lens (Zoom Ratio)
00 : No Lens
01 : 3 mm Fixed
02 : 3 ~ 4mm Fixed
03 : 4 ~ 6mm Fixed
04 : 6 ~ 10mm Fixed
05 : 10mm Fixed
06 : 2x V/F
08 : 2 ~ 9x V/F
09 : 10x V/F
xx : Zoom (PTZ, Zoom)
36 : 360° Fisheye
Lens (Zoom Ratio)
00 : No Lens
01 : 3mm
02 : 4mm
03 : 6mm
04 : 8mm
05 : 10mm
06 : 2x V/F
07 : 3x V/F
08 : 4 ~ 9x V/F
09 : 10x V/F
xx : Zoom (PTZ, Zoom)
Version No : 0 ~ 9 Etc. Feature
Version No : 0 ~ 9 Etc. Feature
B : Black
R : IR
RF : IR + Flush
F : Flush
H : Housing
C : Counting
CF : Counting + Flush
T : Tracking
TH : Tracking + Housing
VH : Vandal + Housing
B : Black
C : Counting
F : Flush
H : Housing
R : IR
T : Tracking
V : Vandal
HE : Heater
Lens
SLA
Samsung Lens Lens Type
A : Auto Iris
M : Manual Iris
Z : Motorized Zoom
-
M3180DN
Resolution
Null : 410K pixel
M : Megapixel
Focal Length (Wide) Focal Length (Tele)
/ Zoom Ratio
Others
DN : Day & Night
D : DC Iris
04
Page 6
Product Numbering Rule
DVR / NVR
Monitor
SRD
Samsung Recorder Back up Type
D : DVR
P : PC
H : Hybrid
N : NVR
M : Mobile
S : S/W
SMT
-
1670DC
Version No : 0 ~ 9 Back up
-
Channel
1 : 1CH
4 : 4CH
8 : 8CH
16 : 16CH
32 : 32CH
64 : 64CH
Encode Rate (NTSC)
1 : CIF 7.5fps
3 : CIF 15fps
5 : CIF 30fps
7 : 4CIF 30fps
Encode Rate (PAL)
1 : CIF 6.25fps
3 : CIF 12.5fps
5 : CIF 25fps
7 : 4CIF 25fps
1722
D : DVD
Option
C : Coaxial
Samsung Monitor Appearance
Access Control System
SSA
Samsung System Access Control
T : TFT-LCD
C : CRT
V : PVM
E : AMOLED
Panel Size
17" ~ 40"
-
S2000V
S : Standalone
P : Panel
R : Reader
C : Card
X : Accessory
M : Management S/W
Panel/Reader
1 : one way recognition
2 : two way recognition
3 : Three way recognition
4 : Four way recognition
0 : BNC
1 : VGA
2 : VGA+BNC
3 : etc.
Version No : 0 ~ 9
Version
1 : 13.56MHz Mifare
2 : 0 & 1
3 : 125KHz EM
N : N/W
Null : Normal
V : Vandal-resistant0 : 125KHz Samsung
05
Page 7
Product Line-up
Network
Network Camera
Box
SNB-7000 16
SNB-5000 17
SNB-3002 18
SNB-1001 19
Zoom Box
SNZ-5200 20
IR Bullet
SNO-7080R 21
SNO-5080R 22
SNO-1080R 23
Network
IR Vandal-Resistant
SNV-7080R 35
SNV-5080R 36
New
SNV-1080R 37
PTZ Dome
SNP-5200/5200H 38
SNP-3371TH/3371H 39
SNP-3371 40
SNP-3302H/3302 41
SNP-3120 42
SNP-3120VH 43
Network Video Recorder
Dome
SND-7080/7080F 24
SND-5080/5080F 25
SND-3082/3082F 26
SND-1080 27
SND-1011 28
Vandal-Resistant
SNV-7080 29
SNV-5080 30
SNV-5010 31
SNV-3120 32
SNV-3082 33
SNV-1080 34
SRN-6450/3250 45
SRN-1670D 46
SRN-470D 47
Encoder
SPE-400B/1600R 48
SPE-400 49
SPE-101/100 50
Decoder
SPD-400 51
Management Software
NET-i viewer 52
NET-i ware 53
Network Controller
SPC-2000 54
06
Page 8
Product Line-up
Analogue Camera
Box
SCB-4000 60
SCB-3001 61
SCB-3000 62
New
SCB-2002 63
SCB-2001 64
SCB-2000 65
SCB-1000 66
SCB-3021/3020 67
SCB-2010 68
Zoom Box
SCZ-3430 69
Analogue Camera
Flat Dome
SCD-2010F 81
IR Dome
SCD-2080R 82
SCD-2020R 83
SCD-1020R 84
Vandal-Resistant
SCV-3120 85
SCV-2120 86
SCV-3081/2081 87
SCV-3080/2080 88
SCV-2060 89
SCZ-3370/2370 70
SCZ-2250 71
Bullet
SCO-2080 72
IR Bullet
SCO-2120R 73
SCO-2080R/2080RH 74
Dome
SCD-3081 75
New
SCD-2081 76
SCD-3080/2080 77
SCD-2080E/2060E 78
SCD-2020/2040 79
SCV-2010F 90
IR Vandal-Resistant
SCV-2081R 91
SCV-2080R 92
PTZ Dome
SCP-3430H/2430H 93
SCP-3370TH/3370H/3370 94
SCP-2370TH/2370H/2370 95
SCP-2330H/2330 96
SCP-2270H/2270 97
SCP-2250H/2250 98
SCP-3120/3120VH 99
SCP-2120 100
SCD-2010 80
SCU-2370 101
07
Page 9
Product Line-up
Analogue Camera
HD CCTV
SCB-6000 102
SCD-6080 103
UTP
SUB-2000 104
SUD-3080/3080F 105
SUD-2080/2080F 106
Thermal
SCB-9051/9050 108
DVR
Stand-Alone
SRD-1670D/1670DC 113
Lens / Peripheral
Zoom
SLA-12240/880 128
Varifocal
SLA-3580DN/2810D/550DA/612DN 129
SLA-M2882/M3180DN 130
PTZ Housings / Mounts
SHP-3700H/3700F 131
SBP-300WM1/300WM/300B
PTZ/Dome Mounts
SBP-300LM/300PM/300KM
Fixed Housings
SBP-300CM/300HM1/300HM2/300HM3
132
SRD-1650D/1650DC 114
SRD-1630D 115
SRD-1652D/852D 116
SRD-870DC 117
SRD-850D/850DC 118
SRD-470D 119
SRD-442 120
SRD-440 121
HD CCTV
SRD-480D 122
Management Software
SmartViewer 123
HDD
STH-500/200
Fixed Mounts
SBU-500WM/220PM 134
STB-400/4150V
HD CCTV Converter
SPH-110C 135
UTP
SPU-100TR 136
SPU-400/400R
Positioning
SCU-VAC/VAC1 137
SHB-4300H/4300H1/4300H2/4200/4200H
133
SVS-5R/5E 124
08
Page 10
Product Line-up
Monitor
LCD
SMT-4023 142
SMT-3223 143
SMT-2231 144
LED
SMT-1930 145
LCD
SMT-1922/1722 146
SMT-1912/1712 147
Controller
SPC-6000 149
Access Control System
Stand-Alone Controller
SSA-S3010/S3020/S3040 161
SSA-S3011/S3021/S3041
SSA-S2100/S2101 162
SSA-S2000/S2000V 163
SSA-S1000/S1000V
Control Panel
SSA-R2010/R2020/R2040 164
SSA-R2011/R2021/R2041
SSA-R2000/R2001/R2003 165
SSA-R2000V/R2001V
SPC-1010 150
SPC-300/200 151
Security Robot
SGR-1 154
SGR-2
SGR-3
SSA-R1000/R1001/R1003 166
SSA-R1100/R1101/R1103
SSA-R1000V/R1001V/R1100V/R1101V 167
SSA-PE1202 168
SSA-P420(T)/P421(T)/P400(T)/P401(T) 169
SSA-P112(T)/P102(T) 170
SSA-X100 171
Card & Key Tag
SSA-C100/C200/C110 172
SSA-C120/X500
Software
SSA-M1000/M1100 173
SSA-M2000/M2100 174
09
Page 11
Page 12
Network Solution
at a Glance
Samsung provides one-stop IP video surveillance solution ; Network Cameras, Encoders, NVRs, Monitoring Software, Hardware
NVRs, and Software NVRs (Recording Software). Based on its cutting edge technology earned from long history in video surveillance
industry, iPOLiS supports users with convenient & easy management and outstanding functions.
Monitoring Software
Network Cameras
NETWORK
CAMERA
ANALOGUE
Analogue Cameras
Network Cameras
Network cameras communicate with monitoring/recording tools via
IP network. Samsung is expanding its line ups for network cameras,
based on its excellent technological background. Various types of
network cameras which are equipped with useful functions.
NET-i viewer
Hardware NVR
IP Network
Software NVR
(Recording Software)
Network Video Encoder
Hardware NVRs
Unlik e DV R that digitize the analogue vi de o feeds, NVR re ce iv e
digitized video images from IP network. While the DVR has to be
located near the analogue feeds, the NVR can be located anywhere
on a network and users can simply access the recorded video.
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
Network Video Encoders
To comprise surveillance system in network does not mean having to
change analogue cameras were already installed. The encoder
digitize the analogue video signal into network so that the video from
analogue cameras can be transmitted via IP network.
Monitoring Software
A common PC can be used as a monitoring device by installing NET-i,
Samsung network monitoring software. Familiar operation and easyto-use GUI will benefit users.
Software NVRs (Recording Software)
NET-i ware, network recording software of Samsung, provides video
streaming, recording and event management functions. Users can
record video continuously, on schedule, on alarm and/or on motion
detection.
SYSTEM
ACCESS CONTROL
11
Page 13
Core Network DSP Technology
The WiseNet series of Digital Signal Processor (DSP) chipsets have been developed in house at Samsung Techwin specifically for use
in Samsung network video surveillance cameras. With three WiseNet DSP chipsets to choose from, users are able to pick the set of
advanced features and functionality that best matches the requirement for their application.
Network cameras featuring the WiseNetII DSP
benefit from 3 megapixel and Full HD (1080p)
resolution image output. The most advanced
DSP in the WiseNet series, WiseNetII includes
technologies such as Smart Codec, remote
focus control and HD W ide Dynamic Range
(WDR).
SSDR
(Samsung Super
Dynamic Range)
1 7
3Megapixel
16 : 9 HD (720p)
Full HD (1080p)
Resolution
4
Full HD WDR
5
Samsung
Smart Codec -
ROI
(Regions of Interest)
6
Remote
Focus Control
Network cameras featuring the W iseNet DSP
are able to display images at 1.3 megapixel
and HD (720p) resolutions. Available in a broad
range of camera styles, including pan / tilt /
zoom models, the WiseNet D SP brin gs the
benefits of Intelligent Video Analytics to your
applications.
98 10
SSNRIII
(Samsung
Super Noise
ReductionIII)
2 3
1.3Megapixel
16 : 9 HD (720p)
Resolution
11
Intelligent Video Analytics
(Appear / Disappear / Virtual Line /
Enter / Exit)
WiseNetS network cameras offer a costeffective solution for small to medium sized
applications, such as retail outlets and schools.
Supporting VGA resolution image capture, they
contain all the features needed to create a
professional network video solution.
Multiple Codec &
Multiple Streaming
VGA (640 x 480)
Resolution
11
Intelligent Video Analytics
(Motion Detection / Face Detection)
Polygonal Mask
32ea
11
Intelligent Video Analytics
(Appear / Disappear / Virtual Line /
Enter / Exit / Scene Change /
Motion Detection / Face Detection)
12
Page 14
(VGA 640 x 480)
1
Max. 3 Megapixel, 16 : 9 HD (720p) Full HD (1080p) support
(1.3MP 1280 x 1024)
(3MP 2048 x 1536)
The WiseNetII cameras support 3MP (2048 x 1536) resolution and Full HD display
which is an established production standard guaranteed to provide a resolution of
1920 x 1080p pixels, a 16 : 9 aspect ra tio and real-time image capture. It can
capture a much wider area which is useful for surveillance systems, as the width of
image is usually more helpful than height of image.
2
Max. 1.3 Megapixel , 16 : 9 HD (720p) Resolution
The W iseNet supports 1.3MP resolution and HD display; the images look much
larger, wider, and clearer than at lower resolutions. It can be used to monitor the
critical places in small to medium applications or larger projects to a view wide range
of areas.
3
VGA Resolution Support
The WiseNetS cameras provide VGA (640 x 480) resolution. Although megapixel
and HD cameras have many advantages, there are applications that VGA cameras
are best-suited. It is important to consider the whole system and environment when
choosing the most suitable network camera.
4
Full HD WDR
The WiseNetII DSP’s WD R te ch nology compen sa te s fo r ba ck light pro bl em s
effectively, by applying an optimum fusion ratio when combining the long exposure
(low shu tter speed exposure )
met hod use d in br ight areas
and the short exposu re (high
sh u t t er sp ee d e x p o s ur e )
method used in dark areas.
WDR Off WDR On
5
Samsung Smart Codec - ROI (Regions of Interest)
In the majority of scenes viewed by a surveillance camera, only a proportion of the
image is of interest to the operator. With the continued increase in resolution and
the ref ore d ata s izes there is a n inc rease d amo unt of “Waste d Data” created .
Samsung’s smart codec technology allow the network cameras to be programmed
to capture in greater detail the real ROI, such as moving objects, human faces, doors
or windows than the remainder
of the scene. This smart codec
fea ture pro duces l ower da ta
Low Quality
sizes while clearly highlighting
the ROI.
Region of interest High Quality
Normal Compressed Image
(Higher Data Size)
Smart Compressed Image
(Effectively Saved Data Size)
7
Polygonal Mask 32
The W is eN etS suppo rt s up to 3 2 polygon al s haped p ri vacy ma sk s so that i t
efficiently prevents invasion of privacy under various surveillance environments.
8
SSDR (Samsung Super Dynamic Range)
Useful in high contrast or backlight scene. Automatically lighten of the dark areas
within a scene whilst maintaining the brighter areas at the same level. This ensures
that the dark areas become
more visible al l o w i n g th e
operator to view objects in the
shadows.
SSDR Off SSDR On
9
SSNRIII (Samsung Super Noise ReductionIII)
Useful in low ligh t condition. This technology eliminates image noise in l ow light
co nd ition s w ith ou t c re ati ng
image blur or ghosting.
SSNRIII Off SSNRIII On
10
Multiple Codec & Multiple Streaming
The WiseNet network cameras support simultaneous streaming of multiple video
comp ress ion tec hnologies such as H.264 and MJPEG. This faci litates mu ltiple
purposes monitorin g such as real-tim e, highquality or high-efficiency re cording,
mobile monitoring, E-mail notification and SD memory recording.
NVR
H.264
MPEG-4
640 x 480 H.264 5fps
SD Memory Recording
MJPEG
1280 x 720 H.264 10fps
800 x 600 MPEG-4 30fps
320 x 240 MJPEG 5fps
1280 x 1024 JPEG Snapshot
Recording /
Back up
Monitoring /
Control
Monitoring on
Smartphone
E-mail Notification
* Some camera models support dual streaming.
11
Intelligent Video Analytics
Intelligent Video Analytics can be used for efficient monitoring. WiseNetS cameras
provide Motion Detection which detects any change occurring in predefined fields of
view, and Face Detection to detect up to 32 faces in the scene. Built-in Intelligent
Vid eo Anal ytics o f Wi seNet i nclud e Appea r/ Disap pe ar/Vi rt ual L in e/Ent er/Exit
fun ct io ns. App ea r/ Disappe ar f un ction can d et ect the m ov em ent of ob je ct i n
predefined area; Virtual Line/Enter/Exit functions detect the invasion of the line or
areas in predefined areas.
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
6
Remote Focus Control
The WiseNetII dome and bullet cameras incorporated motorized varifocal lenses so
that users can adjust the focus and viewing angle of camera very easily through the
network from a remote site without having to vis it the installation and open the
camera’s housing.
Built-in 3 ~ 8.5mm
Motorized Varifocal Lens
Network
Remote Control of Focus and
View Angle via Network
Motion Detection
Object Counting
(SND-3080C)
3
Virtual Line Detection
Scene Change Detection
(Tampering)
Enter / Exit Detection
Appear / Disappear Detection
* The Intelligent Video Analytics functions supported by each camera can vary by model.
SYSTEM
ACCESS CONTROL
13
Page 15
Network Camera Selection
SNB-7000 SNB-5000 SNB-3002 SNB-1001
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
1/2.8" 3M PS CMOS 1/3" 1.3M PS CMOS
Color : 1Lux (50 IRE)
B/W : 0.08Lux (50 IRE)
Yes (ICR) Yes (ICR) Yes (ICR) Yes (S/W)
Yes N/A Yes N/A
CVBS 1.0Vp-p CVBS 1.0Vp-p CVBS 1.0Vp-p DIP connector type
N/A N/A N/A N/A
N/A N/A N/A N/A
H.264, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming
2048 x 1536 1280 x 1024 NTSC : 704 x 480, PAL : 704 x 576 640 x 480
20fps at 3M 30fps NTSC : 30fps, PAL : 25fps 30fps
Mic / Line in, Line out
(Bi-directional audio)
G.711 u-law G.711 u-law G.711 u-law G. 711 u-law
Yes (SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC) Yes (Micro SD/SDHC)
1 / 1 1 / 1 1 / 1 Input 1
Yes Yes Tampering Face detection
24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af)
SNZ-5200 SNO-7080R SNO-5080R SNO-1080R
1/3" 1.3M PS CMOS 1/2.8" 3M PS CMOS 1/3" 1.3M PS CMOS 1/4" PS CMOS
Color : 0.7Lux (50 IRE)
B/W : 0.08Lux (50 IRE)
Yes (ICR) Yes (ICR) Yes (ICR) Yes (ICR)
N/A Yes N/A N/A
CVBS 1.0Vp-p CVBS 1.0Vp-p DIP connector type DIP connector type
4.45 ~ 89mm 3 ~ 8.5mm (Motorized V/F lens) 2.8 ~ 10mm 2.3 ~ 7.9mm
20x 2.8x 3.6x 3.4x
H.264, MPEG-4, MJPEG H.264, MJPEG H.264, MPEG-4, MJPEG H.264, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming
1280 x 1024 2048 x 1536 1280 x 1024 640 x 480
30fps 20fps at 3M 30fps at HD (720p) 30fps at all resolutions
Mic / Line in, Line out
(Bi-directional audio)
G. 711 u-law G.711 u-law N/A G. 711 u-law
Yes (SD/SDHC) Yes (SD/SDHC, 4GB included) N/A N/A
1 / 1 1 / 1 1 / 1 Input 1
Yes N/A Yes Face detection
12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af)
Color : 0.3Lux (50 IRE)
B/W : 0.01Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
Color : 1Lux (50 IRE)
B/W : 0Lux (50 IRE, IR LED on)
Mic / Line in, Line out
(Bi-directional audio)
1/3" Super HAD PS CCD
Color : 0.4Lux (50 IRE)
B/W : 0.04Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
Color : 0.3Lux (50 IRE)
B/W : 0Lux (50 IRE, IR LED on)
N/A Mic / Line in, Line out (2-Way)
1/4" PS CMOS
0.7Lux
Mic / Line in, Line out
(Bi-directional audio)
0.7Lux
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
SND-7080/7080F SND-5080/5080F SND-3082/3082F SND-1080 SND-1011
1/2.8" 3M PS CMOS 1/3" 1.3M PS CMOS
Color : 1Lux (50 IRE)
B/W : 0.08Lux (50 IRE)
Yes (ICR) Yes (ICR) Yes (S/W) Yes (S/W) Yes (S/W)
Yes N/A Yes N/A N/A
CVBS 1.0Vp-p CVBS 1.0Vp-p CVBS 1.0Vp-p DIP connector type DIP connector type
3 ~ 8.5mm (Motorized V/F lens) 2.8 ~ 10mm 2.8 ~ 11mm 2.2 ~ 7.7mm 3mm
2.8x 3.6x 3.9x 3.5x N/A
H.264, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MJPEG H.264, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming Multiple streaming
2048 x 1536 1280 x 1024 NTSC : 704 x 480, PAL : 704 x 576 640 x 480 640 x 480
20fps at 3M 30fps NTSC : 30fps, PAL : 25fps 30fps at all resolutions 30fps at all resolutions
Mic / Line in, Line out
(Bi-directional audio)
G.711 u-law G.711 u-law G.711 u-law G. 711 u-law N/A
Yes (SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC) Yes (Micro SD/SDHC) Yes (Micro SD/SDHC)
1 / 1 1 / 1 2 / 2 Input 1 Input 1
Yes Yes Tampering Face detection Face detection
24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af)
Color : 0.3Lux (50 IRE)
B/W : 0.01Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
1/3" Super HAD PS CCD
Color : 0.4Lux (50 IRE)
B/W : 0.04Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
1/4" PS CMOS 1/4" PS CMOS
0.7Lux 0.7Lux
Mic / Line in, Line out
(Bi-directional audio)
N/A
14
Page 16
Network Camera Selection
SNV-7080 SNV-5080 SNV-5010 SNV-3120
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
1/2.8" 3M PS CMOS 1/3" 1.3M PS CMOS 1/3" 1.3M PS CMOS
Color : 1Lux (50 IRE)
B/W : 0.08Lux (50 IRE)
Yes (ICR) Yes (ICR) N/A Yes (ICR)
Yes N/A N/A Yes
CVBS 1.0Vp-p CVBS 1.0Vp-p DIP connector type CVBS 1.0Vp-p
3 ~ 8.5mm (Motorized V/F lens) 2.8 ~ 10mm 3mm 3.69 ~ 44.32mm
2.8x 3.6x N/A 12x
H.264, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming
2048 x 1536 1280 x 1024 1280 x 1024 NTSC : 704 x 480, PAL : 704 x 576
20fps at 3M 30fps 30fps NTSC : 30fps, PAL : 25fps
Mic / Line in, Line out
(Bi-directional audio)
G.711 u-law G.711 u-law N/A G.711 u-law
Yes (SD/SDHC) Yes (SD/SDHC) N/A Yes (SD/SDHC)
1 / 1 1 / 1 N/A 1 / 1
Yes Yes Yes Yes
24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af)
SNV-3082 SNV-1080 SNV-7080R SNV-5080R SNV-1080R
1/3" Super HAD PS CCD
Color : 0.4Lux (50 IRE)
B/W : 0.04Lux (50 IRE)
Yes (ICR) Yes (S/W) Yes (ICR) Yes (ICR) Yes (S/W)
Yes N/A Yes N/A N/A
CVBS 1.0Vp-p DIP connector type CVBS 1.0Vp-p CVBS 1.0Vp-p DIP connector type
2.8 ~ 11mm 2.2 ~ 7.7mm 3 ~ 8.5mm (Motorized V/F lens) 3 ~ 8.5mm (Motorized V/F lens) 2.2 ~ 7.7mm
3.9x 3.5x 2.8x 2.8x 3.5x
H.264, MPEG-4, MJPEG H.264, MJPEG H.264, MJPEG H.264, MPEG-4, MJPEG H.264, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming Multiple streaming
NTSC : 704 x 480, PAL : 704 x 576 640 x 480 2048 x 1536 1280 x 1024 640 x 480
NTSC : 30fps, PAL : 25fps 30fps at all resolutions 20fps at 3M 30fps at HD (720p) 30fps at all resolutions
Mic / Line in, Line out
(Bi-directional audio)
G.711 u-law G. 711 u-law G.711 u-law G.711 u-law G. 711 u-law
Yes (SD/SDHC) Yes (Micro SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC) Yes (Micro SD/SDHC)
1 / 1 Input 1 1 / 1 1 / 1 Input 1
Tampering Face detection Yes Yes Face detection
24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 24V AC,12V DC, PoE (IEEE802.3af) 12V DC, PoE (IEEE802.3af)
Color : 0.3Lux (50 IRE)
B/W : 0.01Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
1/4" PS CMOS 1/2.8" 3M PS CMOS 1/3" 1.3M PS CMOS 1/4" PS CMOS
0.7Lux
Mic / Line in, Line out
(Bi-directional audio)
Color : 1Lux (50 IRE)
B/W : 0Lux (50 IRE, IR LED on)
Mic / Line in, Line out
(Bi-directional audio)
Color : 1Lux (50 IRE)
N/A
Color : 0.3Lux (50 IRE)
B/W : 0Lux (50 IRE, IR LED on)
Mic / Line in, Line out
(Bi-directional audio)
1/4" Ex-view HAD PS CCD
Color : 0.7Lux (50 IRE)
B/W : 0.07Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
0.7Lux
Mic / Line in, Line out
(Bi-directional audio)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
Image Sensor
Min. Illumination
Day & Night
Wide Dynamic Range
Analogue Out
Focal Length
Zoom Ratio
Video Compression
Streaming
Max. Resolution
Max. Frame Rate
Audio I/O
Audio Compression
Memory Slot
Alarm I/O
Intelligent Video Analytics
Power Requirement
SNP-5200/5200H SNP-3371TH/3371H SNP-3371 SNP-3302H/3302 SNP-3120/3120VH
1/3" 1.3M PS CMOS
Color : 0.7Lux (50 IRE)
B/W : 0.08Lux (50 IRE)
Yes (ICR) Yes (ICR) Yes (ICR) Yes (ICR) Yes (ICR)
N/A Yes Yes Yes Yes
CVBS 1.0Vp-p CVBS 1.0Vp-p CVBS 1.0Vp-p CVBS 1.0Vp-p CVBS 1.0Vp-p
4.45 ~ 89mm 3.5 ~ 129.5mm 3.5 ~ 129.5mm 3.5 ~ 105.3mm 3.69 ~ 44.32mm
20x
H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG
Multiple streaming Multiple streaming Multiple streaming Multiple streaming Multiple streaming
1280 x 1024
30fps at all resolutions NTSC : 30fps, PAL : 25fps NTSC : 30fps, PAL : 25fps NTSC : 30fps, PAL : 25fps NTSC : 30fps, PAL : 25fps
Mic / Line in, Line out
(Bi-directional audio)
G.711 u-law G.711 u-law G.711 u-law G.711 u-law G.711 u-law
Yes (SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC) Yes (SD/SDHC)
4 / 2 4 / 2 4 / 2 4 / 2 2 / 2
Yes Auto tracking : SNP-3371TH Yes Yes Moved / Fixed
24V AC, PoE+ (IEEE802.3at) 24V AC, PoE+ (IEEE802.3at) 24V AC, PoE+ (IEEE802.3at) 24V AC, PoE+ (IEEE802.3at) 24V AC, PoE+ (IEEE802.3at)
1/4" Vertical double density interline CCD 1/4" Vertical double density interline CCD 1/4" Vertical double density interline CCD
Color : 0.7Lux (50 IRE)
B/W : 0.07Lux (50 IRE)
37x 37x 30x
NTSC : 704 x 480, PAL : 704 x 576 NTSC : 704 x 480, PAL : 704 x 576 NTSC : 704 x 480, PAL : 704 x 576 NTSC : 704 x 480, PAL : 704 x 576
Mic / Line in, Line out
(Bi-directional audio)
Color : 0.7Lux (50 IRE)
B/W : 0.07Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
Color : 0.7Lux (50 IRE)
B/W : 0.07Lux (50 IRE)
Mic / Line in, Line out
(Bi-directional audio)
1/4" Ex-view HAD PS CCD
Color : 0.7Lux (50 IRE)
B/W : 0.07Lux (50 IRE)
12x
Mic / Line in, Line out
(Bi-directional audio)
SYSTEM
ACCESS CONTROL
15
Page 17
SNB-7000
SYSTEM
AUDIO OUT AUDIO IN
SD
RESET
ACT LINK
GND
AC 24V
DC 12V
NETWORK
POWER
VIDEO
SD CARD
1 2 3 4 5
72.0 (2.83") 136.8 (5.39")
60.0 (2.36")
3 Megapixel Full HD Network Camera
3M
Key Features
• Max. 3M (2048 x 1536) resolution
• 16 : 9 Full HD (1080p) resolution support
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
128x
160x
D&N ICR
60.0 (2.36")
PoE
Technical Specifications
SNB-7000N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Unit : mm (inch)
136.8 (5.39")72.0 (2.83")
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/2.8" 3M PS CMOS
2,144(H) x 1,588(V)
2,096(H) x 1,561(V)
Progressive
Color : 1Lux (F1.2, 50IRE), 0.017Lux (Sens-up 60x)
B/W : 0.08Lux (F1.2, 50IRE), 0.001Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
Manual / DC auto iris
C / CS
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
Off / On (Full HD WDR)
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On (4 programmable zones)
Off / On (1ea 4 point polygonal + 16ea rectangular zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RS-485
Samsung-T/E, Pelco-P/D, Sungjin
RJ-45 (10/100BASE-T)
H.264, MJPEG
2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960,
3M mode -
1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360,
320 x 240, 320 x 180
2M mode -
1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
3M mode -
H.264 : Max. 20fps at all resolutions
MJPEG : 800 x 600 ~ 320 x 180 - 20fps, 1280 x 1024 ~1920 x 1080 - 15fps
2048 x 1536 - 10f ps
2M mode -
H.264 : Max. 30fps at all resolutions (When WDR on, Max. framerate is Max. 15fps.)
MJPEG : 800 x 600 ~ 320 x 180 - 30fps, 1280 x 1024 ~ 1920 x 1080 - 15fps
Yes (Area based method, Face detection method)
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 6 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W (12V DC), Max. 7W (24V AC, PoE)
Dark gray / Metal
72.0 x 60.0 x 136.8mm (2.83" x 2.36" x 5.39")
440g (0.97 Ib)
REVISED 03-2012
16
Page 18
SNB-5000
SYSTEM
AUDIO OUT AUDIO IN
SD
RESET
ACT LINK
GND
1,2 : ALARM IN 1,2
3 : GND
4,5 : ALARM OUT 1,2
AC 24V
DC 12V
NETWORK
POWER
VIDEO
SD CARD
1 2 3 4 5
72.0 (2.83") 136.8 (5.39")
60.0 (2.36")
1.3 Megapixel HD Network Camera
1.3M
D&N ICR
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
60.0 (2.36")
PoE
Technical Specifications
SNB-5000N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
LENS
Lens Type
Mount Type
Manual / DC auto iris
C / CS
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
NETWORK
Unit : mm (inch)
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
ENVIRONMENTAL
Operating Temperature / Humidity
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
ELECTRICAL
Input Voltage / Current
Power Consumption
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W
MECHANICAL
Color / Material
136.8 (5.39")72.0 (2.83")
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
Dark gray / Metal
72.0 x 60.0 x 136.8mm (2.83" x 2.36" x 5.39")
440g (0.97 Ib)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
17
Page 19
SNB-3002
SYSTEM
AUDIO OUT AUDIO IN
SD
RESET
ACT LINK
GND
1,2 : ALARM IN 1,2
3 : GND
4,5 : ALARM OUT 1,2
AC 24V
DC 12V
NETWORK
POWER
VIDEO
SD CARD
1 2 3 4 5
72.0 (2.83") 136.8 (5.39")
60.0 (2.36")
4CIF WDR Network Camera
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Tampering detection
Dimensions
128x
160x
D&N ICR
60.0 (2.36")
PoE
Unit : mm (inch)
Technical Specifications
SNB-3002N SNB-3002P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Profile
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Storage Temperature / Humidit
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.4Lux (F1.2, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.04Lux (F1.2, 50IRE), 0.0001Lux (Sens-up 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite
Manual / DC auto iris
C / CS
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / WDR
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
Motion adaptive 2D+3D noise filter (Off / Low / Middle / High / User)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones, 4 point polygonal method)
Off / Auto (2x ~ 512x)
AGC (Low / Middle / High)
ATW1 / ATW2 / AWC / 3200K / 5600K
Off / Auto (1/100 ~ 1/10Ksec) Off / Auto (1/120 ~ 1/10Ksec)
Off / On
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Tampering detection
Input 1ea / Output 1ea (Relay)
RS-485
Samsung-T/E, Pelco-P/D, Sungjin
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240 704 x 576, 640 x 480, 352 x 288
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W
Silver / Metal
72.0 x 60.0 x 136.8mm (2.83" x 2.36" x 5.39")
440g (0.97 Ib)
REVISED 03-2012
136.8 (5.39")72.0 (2.83")
18
Page 20
SNB-1001
74.3 (2.93") 114.4 (4.50")
54.5 (2.15")
VGA Network Camera
VGA
E-D&N
Key Features
• Max. 30fps at VGA resolution
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Face detection
Dimensions
PoE
Unit : mm (inch)
Technical Specifications
SNB-1001N SNB-1001P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Lens Type
Mount Type
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
0.7Lux (F1.2, 50IRE)
50dB
DIP connector type, for installation
Manual / DC auto iris
C / CS
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W / External
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic/Line in , Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Micro SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC / PoE (IEEE802.3af)
Max. 3.4W (12V DC), Max. 4W (PoE)
Black, Silver / Aluminium, Plastic
74.3 x 54.5 x 114.4mm (2.93" x 2.15" x 4.50") excluding projections
190g (0.42 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
54.5 (2.15")
74.3 (2.93") 114.4 (4.50")
REVISED 03-2012
SYSTEM
ACCESS CONTROL
19
Page 21
SNZ-5200
72.0 (2.83") 136.0 (5.35")
60.0 (2.36")
1.3 Megapixel HD 20x Network Zoom Camera
1.3M
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 4.45 ~ 89mm (20x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
20x
PoE
D&N ICR
Unit : mm (inch)
60.0 (2.36")
136.0 (5.35")72.0 (2.83")
Technical Specifications
SNZ-5200N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Preset
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.7Lux (F1.2, 50IRE), 0.01Lux (Sens-up 60x, 50IRE)
B/W : 0.08Lux (F1.6, 50IRE), 0.001Lux (Sens-up 60x, 50IRE)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
4.45 ~ 89mm (20x)
F1.6(Wide) / F2.9(Tele)
H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
1m (3.28ft)
AF / One-shot AF / Manual (Remote control via Network)
DC auto iris
Board-in type
128ea
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On
Off / On (4 programmable zones)
Off / On (8 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
16x
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RS-485
Samsung-T/E, Pelco-P/D, Sungjin
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
30fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0 Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20 ~ 80% RH
12V DC, PoE (IEEE802.3af)
12V DC : Max. 8W, PoE : Max. 7.5W
Dark gray / Metal
72.0 x 60.0 x 136.0mm (2.83" x 2.36" x 5.35")
540g (1.19 lb)
REVISED 03-2012
20
Page 22
SNO-7080R
388.0 (15.28")
Ø114.0 (4.49")
103.0 (4.06")
359.0 (14.13")
220.0 (8.66")
3 Megapixel Full HD Weatherproof Network IR Camera
3M
Key Features
• Max. 3M (2048 x 1536) resolution
• 16 : 9 Full HD (1080p) resolution support
• 3 ~ 8.5mm (2.8x) motorized varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, Bi-directional audio support
• Intelligent video analytics
Dimensions
Ø103.0 (4.06") 359.0 (14.13")
Ø114.0 (4.49")
2.8x
Motorized V/F Lens
128x
160x
220.0 (8.66")
PoE
D&N ICR
Unit : mm (inch)
388.0 (15.28")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination (TBD)
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Focus Control
Lens Type
Mount Type
OPERATIONAL
IR LED
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/2.8" 3M PS CMOS
2,144(H) x 1,588(V)
2,096(H) x 1,561(V)
Progressive
Color : 1Lux (F1.2, 50IRE), 0.017Lux (Sens-up 60x)
B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3 ~ 8.5mm (2.8x) Motorized varifocal
F1.2
H : 94°(Wide) ~ 32.9°(Tele), V : 69.86°(Wide) ~ 24.92°(Tele)
Remote control via network (Manual, One-shot AF)
DC auto iris
Board-in type
32ea
30m (98.43ft)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC / WDR
Off / On (Full HD WDR)
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (1ea 4 point polygonal + 16ea rectangular zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30~30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MJPEG
3M mode -
2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360,
320 x 240, 320 x 180
2M mode -
1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
3M mode -
H.264 : Max. 20fps at all resolutions
MJPEG : 800 x 600 ~ 320 x 180 - 20fps, 1280 x 1024 ~1920 x 1080 - 15fps
2048 x 1536 - 10f ps
2M mode -
H.264 : Max 30fps at all resolutions (When WDR on, Max. framerate is Max. 15fps.)
MJPEG : 800 x 600 ~ 320 x 180 - 30fps, 1280 x 1024 ~ 1920 x 1080 - 15fps
Yes (Area based method, Face detection method)
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 6 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot (4GB included)
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
16.5W (Heater on), 11.3W (Heater off)
Dark gray / Metal
Ø114.0 x 388.0mm (Ø4.49" x 15.28")
1.8Kg (3.97 lb)
SNO-7080RN/P
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
21
Page 23
SNO-5080R
334.8 (13.18")
216.0 (8.50")
86.0 (3.38")
86.3 (3.40")
318.8 (12.55")
1.3 Megapixel HD Weatherproof Network IR Camera
1.3M
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 2.8 ~ 10mm (3.6x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• IR LED (31ea), PoE
• Intelligent video analytics
Dimensions
86.0 (3.39")
3.6x
V/F Lens
86.3 (3.40")
PoE
D&N ICR
Unit : mm (inch)
216.0 (8.50")
318.8 (12.55")
332.8 (13.10")
Technical Specifications
SNO-5080RN/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Focus Control
Lens Type
Mount Type
OPERATIONAL
IR LED
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
IP
Protocol
Security
Streaming Method
Max. User Access
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
DIP connector type, 704 x 480(N), 704 x 576(P), for installation
2.8 ~ 10mm (3.6x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
Manual
DC auto iris
Board-in type
31ea
30m (98.43ft)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
22fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 11W
Dark gray / Metal
86.0 x 86.3 x 332.8mm (3.39" x 3.40" x 13.10")
1.3Kg (2.87 lb)
REVISED 03-2012
22
Page 24
SNO-1080R
Ø84.8 (3.42") 304.6 (11.99")
VGA Weatherproof Network IR Camera
VGA
Key Features
• Max. 30fps at VGA resolution
• 2.2 ~ 7.7mm (3.5x) varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• IR LED (15ea), PoE
• Face detection
Dimensions
3.5x
V/F Lens
Ø86.8 (3.42")
D&N ICR
304.6 (11.99")
PoE
Unit : mm (inch)
Technical Specifications
SNO-1080RN SNO-1080RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
OPERATIONAL
IR LED
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
IP
Protocol
Security
Streaming Method
Max. User Access
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
Color : 0.7Lux (F1.2, 50IRE)
B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
SMD connector type, for installation
2.2 ~ 7.7mm (3.5x) varifocal
F1.2
H : 94°(Wide) ~ 26.5°(Tele), V : 70°(Wide) ~ 20°(Tele)
500mm (1.64ft)
DC auto iris
Board type (Ø14)
15ea
15m (49.21ft)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
4 : 3 Mode - 640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
IP66 Grade (Waterproof)
12V DC / 480mA, PoE (IEEE802.3af)
Max. 5.6W
Dark gray / Aluminum
Ø86.8 x 304.6mm (Ø3.42" x 11.99")
1Kg (2.2 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
23
Page 25
SND-7080/7080F
Ø159.9 (6.3")
125.0 (4.92")
Ø133.0 (5.24")
129.4 (5.09")
3 Megapixel Full HD Network Dome Camera
SND-7080 SND-7080F
3M
Key Features
• Max. 3M (2048 x 1536) resolution
• 16 : 9 Full HD (1080p) resolution support
• 3 ~ 8.5mm (2.8x) motorized varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
SND-7080
SND-7080F
2.8x
Motorized V/F Lens
128x
160x
Ø133.0 (5.24")
Ø159.9 (6.3")
PoE
D&N ICR
Unit : mm (inch)
129.4 (5.09")
125.0 (4.92")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/2.8" 3M PS CMOS
2,144(H) x 1,588(V)
2,096(H) x 1,561(V)
Progressive
Color : 1Lux (F1.2, 50IRE), 0.017Lux (Sens-up 60x)
B/W : 0.08Lux (F1.2, 50IRE), 0.001Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3 ~ 8.5mm (2.8x) Motorized varifocal
F1.2
H : 100°(Wide) ~ 35.3°(Tele), V : 74.6°(Wide) ~ 26°(Tele)
0.5m (1.64ft)
Remote control via network (Manual, One-shot AF)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
Off / On (Full HD WDR)
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (1ea 4 point polygonal + 16ea rectangular zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MJPEG
3M mode -
2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360,
320 x 240, 320 x 180
2M mode -
1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
3M mode -
H.264 : Max. 20fps at all resolutions
MJPEG : 800 x 600 ~ 320 x 180 - 20fps, 1280 x 1024 ~1920 x 1080 - 15fps
2048 x 1536 - 10f ps
2M mode -
H.264 : Max. 30fps at all resolutions (When WDR on, Max. framerate is Max. 15fps.)
MJPEG : 800 x 600 ~ 320 x 180 - 30fps, 1280 x 1024 ~ 1920 x 1080 - 15fps
Yes (Area based method, Face detection method)
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 6 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W (DC 12V), Max. 7W (24V AC, PoE (48V DC))
Ivory / Plastic
SND-7080 : Ø133.0 x 129.4mm (Ø5.24" x 5.09")
SND-7080F : Ø159.9 x 125.0mm (Ø6.3" x 4.92") (Flush mounting type)
SND-7080 : 700g (1.54 lb), SND-7080F : 800g (1.76 lb)
SND-7080(F)N/P
REVISED 03-2012
24
Page 26
SND-5080/5080F
Ø159.9 (6.3")
125.0 (4.92")
Ø133.0 (5.24")
129.4 (5.09")
1.3 Megapixel HD Network Dome Camera
SND-5080 SND-5080F
1.3M
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 2.8 ~ 10mm (3.6x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
SND-5080
SND-5080F
3.6x
V/F Lens
PoE
D&N ICR
Unit : mm (inch)
129.4 (5.09")
Ø133.0 (5.24")
Ø159.9 (6.3")
125.0 (4.92")
Technical Specifications
SND-5080(F)N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
2.8 ~ 10mm (3.6x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access logg, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 7W
White / Plastic
SND-5080 : Ø133.0 x 129.4mm (Ø5.24" x 5.09")
SND-5080F : Ø159.9 x 125.0mm (Ø6.3" x 4.92") (Flush mounting type)
SND-5080 : 550g (1.21 lb) SND-5080F : 650g (1.43 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
25
Page 27
SND-3082/3082F
Ø159.9 (6.3")
125.0 (4.92")
Ø133.0 (5.24")
129.4 (5.09")
4CIF WDR Network Dome Camera
SND-3082 SND-3082F
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 2.8 ~ 11mm (3.9x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Tampering detection
Dimensions
SND-3082
SND-3082F
3.9x
V/F Lens
128x
160x
Ø133.0 (5.24")
Ø159.9 (6.3")
PoE
E-D&N
Unit : mm (inch)
129.4 (5.09")
125.0 (4.92")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Storage Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.4Lux (F1.2, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.04Lux (F1.2, 50IRE), 0.0001Lux (Sens-up 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W / External
Off / BLC / WDR
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
Motion adaptive 2D+3D noise filter (Off / Low / Middle / High / User)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones, 4 point polygonal method)
Off / Auto (2x ~ 512x)
AGC (Low / Middle / High)
ATW1 / ATW2 / AWC / 3200K / 5600K
Off / Auto (1/100 ~ 1/10Ksec) Off / Auto (1/120 ~ 1/10Ksec)
Off / On
Tampering detection
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240 704 x 576, 640 x 480, 352 x 288
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W
Ivory / Plastic
SND-3082 : Ø133.0 x 129.4mm (Ø5.24" x 5.09")
SND-3082F : Ø159.9 x 125.0mm (Ø6.3" x 4.92") (Flush mounting type)
SND-3082 : 580g (1.27 lb), SND-3082F : 755g (1.66 lb)
SND-3082(F)N SND-3082(F)P
REVISED 03-2012
26
Page 28
SND-1080
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
VGA Network Dome Camera
VGA
Key Features
• Max. 30fps at VGA resolution
• 2.2 ~ 7.7mm (3.5x) varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, Bi-directional audio support
• Face detection
Dimensions
REVISED 03-2012
3.5x
V/F Lens
E-D&N
92.7 (3.65")
PoE
Ø115.8 (4.56")
Unit : mm (inch)
Technical Specifications
SND-1080N SND-1080P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
0.7Lux (F1.2, 50IRE)
50dB
DIP connector type, for installation
2.2 ~ 7.7mm (3.5x) varifocal
F1.2
H : 94°(Wide) ~ 26.5°(Tele), V : 70°(Wide) ~ 20°(Tele)
500mm (1.64ft)
DC auto iris
Board type (Ø14)
0° ~ 352°
17° ~ 90°
0° ~ 351°
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W / External
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic/Line in , Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Micro SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC / PoE (IEEE802.3af)
Max.3.4W (12V DC), Max.4W (PoE)
Ivory / Plastic
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
380g (0.84lb)
27
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
Page 29
SND-1011
83.7 (3.3")
83.7 (3.3")
Ø107.6 (4.24")
VGA Network Dome Camera
VGA
Key Features
• Max. 30fps at VGA resolution
• Built-in 3mm fixed lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory
• Face detection
Dimensions
3mm
E-D&N
83.7 (3.3")
PoE
Ø107.6 (4.24")
Unit : mm (inch)
Technical Specifications
SND-1011N SND-1011P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
0.7Lux (F1.2, 50IRE)
50dB
DIP connector type, for installation
3mm fixed
F2.0
H : 70˚, V : 50˚
40cm (1.31ft)
Board type
0° ~ 352°
17° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Micro SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC / PoE (IEEE802.3af)
Max.3.4W (12V DC), Max.4W (PoE)
Ivory / Plastic
Ø107.6 x 83.7mm (Ø4.24" x 3.3")
280g (0.62 lb)
REVISED 03-2012
28
Page 30
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
SNV-7080
3 Megapixel Full HD Vandal-Resistant Network Dome Camera
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination (TBD)
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
3M
2.8x
Motorized V/F Lens
128x
160x
PoE
D&N ICR
Key Features
• Max. 3M (2048 x 1536) resolution
• 16 : 9 Full HD (1080p) resolution support
• 3 ~ 8.5mm (2.8x) motorized varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
• Vandal-resistant IK10 rated
Dimensions
Ø160.0 (6.3")
Ø160.0 (6.3")
Flush Type
125.0 (4.92") 134.5 (5.3")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
Unit : mm (inch)
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SNV-7080N/P
1/2.8" 3M PS CMOS
2,144(H) x 1,588(V)
2,096(H) x 1,561(V)
Progressive
Color : 1Lux (F1.2, 50IRE), 0.017Lux (Sens-up 60x)
B/W : 0.08Lux (F1.2, 50IRE), 0.001Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3 ~ 8.5mm (2.8x) Motorized varifocal
F1.2
H : 100°(Wide) ~ 35.3°(Tele), V : 74.6°(Wide) ~ 26°(Tele)
0.5m (1.64ft)
Remote control via network (Manual, One-shot AF)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
Off / On (Full HD WDR)
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (1ea 4 point polygonal + 16ea rectangular zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MJPEG
3M mode -
2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360,
320 x 240, 320 x 180
2M mode -
1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
3M mode -
H.264 : Max. 20fps at all resolutions
MJPEG : 800 x 600 ~ 320 x 180 - 20fps, 1280 x 1024 ~1920 x 1080 - 15fps
2048 x 1536 - 10f ps
2M mode -
H.264 : Max 30fps at all resolutions (When WDR on, Max. framerate is Max. 15fps.)
MJPEG : 800 x 600 ~ 320 x 180 - 30fps, 1280 x 1024 ~ 1920 x 1080 - 15fps
Yes (Area based method, Face detection method)
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 6 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W (12V DC), Max. 7W (24V AC, PoE (48V DC))
Max. 11W (24V AC - Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.4Kg (3.09 lb)
29
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
Page 31
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
SNV-5080
1.3 Megapixel HD Vandal-Resistant Network Dome Camera
1.3M
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 2.8 ~ 10mm (3.6x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
• Vandal-resistant IK10 rated
Dimensions
Flush Type
Accessories (Optional)
3.6x
V/F Lens
PoE
D&N ICR
Unit : mm (inch)
Ø160.0 (6.3")
Ø160.0 (6.3")
125.0 (4.92") 134.5 (5.3")
Technical Specifications
SNV-5080N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
2.8 ~ 10mm (3.6x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 8W (Heater off), Max. 11W (Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.3Kg (2.87 lb)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
30
Page 32
125.2 (4.93")
52.0 (2.05")
115.2 (4.54")
SNV-5010
1.3 Megapixel HD Vandal-Resistant Network Flat Camera
1.3M
3mm
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• Built-in 3mm fixed lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, IP66
• Intelligent video analytics
• Vandal-resistant IK10 rated
Dimensions
125.2 (4.93") 52.0 (2.05")
PoE
Unit : mm (inch)
115.2 (4.54")
Technical Specifications
SNV-5010N/P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
OPERATIONAL
Camera Title
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
IP
Protocol
Security
Streaming Method
Max. User Access
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 1Lux (F1.8, 50IRE), 0.016Lux (Sens-up 60x)
50dB
DIP connector type, 704 x 480(N), 704 x 576(P), for installation
3mm
F1.8
H : 91.2°, V : 72.3°
Fixed iris
Board-in type
-10° ~ 10°
0° ~ 90°
Off / On (Displayed up to 15 characters)
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (-14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, PoE (IEEE802.3af)
Max. 6W
Ivory / Aluminum
125.2 x 52.0 x 115.2mm (4.93" x 2.05" x 4.54")
435g (0.96 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
31
Page 33
SNV-3120
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
4CIF 12x Vandal-Resistant Network Dome Camera
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.69 ~ 44.32mm (12x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
Dimensions
Flush Type
Accessories (Optional)
12x
Ø160.0 (6.3")
Ø160.0 (6.3")
128x
160x
PoE
D&N ICR
Unit : mm (inch)
125.0 (4.92") 134.5 (5.3")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
VPS
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.7Lux (F1.65, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.07Lux (F1.65, 50IRE), 0.0001Lux (Sens-up 512x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite
3.69 ~ 44.32mm (12x)
F1.65(Wide) / F2.01(Tele)
H : 54.44˚(Wide) ~ 4.64˚(Tele), V : 41.42˚(Wide) ~ 3.52˚(Tele)
0.2m (Wide) / 0.8m (Tele)
AF / One-shot AF / Manual
DC auto iris
0° ~ 355°
0° ~ 90°
0° ~ 355°
12ea
±0.1˚
Off / On (Displayed up to 54 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR
128x, 52dB 160x, 52dB
XDR (eXtended Dynamic Range) - Off / Low / Middle / High
Motion adaptive 2D+3D noise filter (Off / Low / Middle / High / User)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones)
Off / Auto (2x ~ 512x)
Off / Very Low / Low / Medium / High / Very High
ATW1 / ATW2 / AWC / Manual
Off / Manual (1/100 ~ 1/10Ksec)
16x
Digital flip
Off / On
Moved / Fixed
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 8W (Heater off), Max. 11W (Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.5Kg (3.31 lb)
SNV-3120N SNV-3120P
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
32
Page 34
SNV-3082
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
4CIF WDR Vandal-Resistant Network Dome Camera
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 2.8 ~ 11mm (3.9x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Tampering detection
Dimensions
Flush Type
Accessories (Optional)
3.9x
V/F Lens
Ø160.0 (6.3")
Ø160.0 (6.3")
128x
160x
PoE
D&N ICR
Unit : mm (inch)
125.0 (4.92") 134.5 (5.3")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Storage Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.4Lux (F1.2, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.04Lux (F1.2, 50IRE), 0.0001Lux (Sens-up 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / WDR
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
Motion adaptive 2D+3D noise filter (Off / Low / Middle / High / User)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones, 4 point polygonal method)
Off / Auto (2x ~ 512x)
AGC (Low / Middle / High)
ATW1 / ATW2 / AWC / 3200K / 5600K
Off / Auto (1/100 ~ 1/10Ksec) Off / Auto (1/120 ~ 1/10Ksec)
Off / On
Tampering detection
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240 704 x 576, 640 x 480, 352 x 288
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W (Heater off), Max. 11W (Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.39Kg (3.06 lb)
SNV-3082N SNV-3082P
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
33
Page 35
SNV-1080
Ø100.0 (3.93”)
Ø137.0 (5.39")
Ø137.0 (5.39")
106 (4.17")
Ø137.0 (5.39")
VGA Vandal-Resistant Network Dome Camera
VGA
Key Features
• Max. 30fps at VGA resolution
• 2.2 ~ 7.7mm (3.5x) varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Face detection
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM2 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
3.5x
V/F Lens
Ø100.0 (3.93")
Ø137.0 (5.39")
PoE
E-D&N
Unit : mm (inch)
106.0 (4.17")
Ø137.0 (5.39")
Technical Specifications
SNV-1080N SNV-1080P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
0.7Lux (F1.2, 50IRE)
50dB
DIP connector type, for installation
2.2 ~ 7.7mm (3.5x) varifocal
F1.2
H : 94°(Wide) ~ 26.5°(Tele), V : 70°(Wide) ~ 20°(Tele)
500mm (1.64ft)
DC auto iris
Board type (Ø14)
0° ~ 355°
17° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic/Line in , Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Micro SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
IP66 Grade (Waterproof)
12V DC / PoE (IEEE802.3af)
Max.3.4W (12V DC), Max.4W (PoE)
Ivory / Aluminum
Ø137.0 x 106.0mm (Ø5.39" x 4.17")
770g (1.7 lb)
34
Page 36
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
SNV-7080R
3 Megapixel Full HD Vandal-Resistant Network IR Dome Camera
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
IR LED
3M
2.8x
Motorized V/F Lens
128x
160x
PoE
D&N ICR
Key Features
• Max. 3M (2048 x 1536) resolution
• 16 : 9 Full HD (1080p) resolution support
• 3 ~ 8.5mm (2.8x) motorized varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
Dimensions
Ø160.0 (6.3")
Ø160.0 (6.3")
Flush Type
125.0 (4.92") 134.5 (5.3")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
Unit : mm (inch)
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SNV-7080RN/P
1/2.8" 3M PS CMOS
2,144(H) x 1,588(V)
2,096(H) x 1,561(V)
Progressive
Color : 1Lux (F1.2, 50IRE), 0.017Lux (Sens-up 60x)
B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3 ~ 8.5mm (2.8x) Motorized varifocal
F1.2
H : 100°(Wide) ~ 35.3°(Tele), V : 74.6°(Wide) ~ 26°(Tele)
Remote control via network (Manual, One-shot AF)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
15ea
25m (82.02ft)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
Off / On (Full HD WDR)
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (1ea 4 point polygonal + 16ea rectangular zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MJPEG
3M mode -
2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360,
320 x 240, 320 x 180
2M mode -
1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
3M mode -
H.264 : Max. 20fps at all resolutions
MJPEG : 800 x 600 ~ 320 x 180 - 20fps, 1280 x 1024 ~1920 x 1080 - 15fps
2048 x 1536 - 10f ps
2M mode -
H.264 : Max 30fps at all resolutions (When WDR on, Max. framerate is Max. 15fps.)
MJPEG : 800 x 600 ~ 320 x 180 - 30fps, 1280 x 1024 ~ 1920 x 1080 - 15fps
Yes (Area based method, Face detection method)
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 6 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 9W (Heater off), Max. 13W (Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.4Kg (3.09 lb)
35
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
Page 37
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
SNV-5080R
1.3 Megapixel HD Vandal-Resistant Network IR Dome Camera
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
1.3M
2.8x
Motorized V/F Lens
PoE
D&N ICR
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 3 ~ 8.5mm (2.8x) motorized varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE, SD memory, IP66, IR LED (15ea)
• Intelligent video analytics
• Vandal-resistant IK10 rated
Dimensions
Ø160.0 (6.3")
Ø160.0 (6.3")
Flush Type
125.0 (4.92") 134.5 (5.3")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
Unit : mm (inch)
Rotate Range
OPERATIONAL
IR LED
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SNV-5080RN/P
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3 ~ 8.5mm (2.8x) Motorized varifocal
F1.2
H : 91.0°(Wide) ~ 32.1°(Tele), V : 72.2°(Wide) ~ 25.7°(Tele)
Remote control via network (Manual, One-shot AF)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
15ea
15m (49.21ft)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
III
(2D+3D noise filter) (Off / On)
SSNR
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
22fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
2-Way
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
24V AC : -40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
12V DC, PoE : -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 9W or 650mA (Heater off), Max. 13W or 800mA (Heater on)
Ivory / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.4Kg (3.09 lb)
36
Page 38
SNV-1080R
Ø100.0 (3.93”)
Ø137.0 (5.39")
Ø137.0 (5.39")
106 (4.17")
Ø137.0 (5.39")
VGA Vandal-Resistant Network IR Dome Camera
VGA
Key Features
• Max. 30fps at VGA resolution
• 2.2 ~ 7.7mm (3.5x) varifocal lens
• H.264, MJPEG dual codec
• Multiple streaming
• PoE, SD memory, IP66, Bi-directional audio support, IR LED (12ea)
• Face detection
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM2 SBP-300LM SBP-300PM SBP-300KM
FIRST EDITION 03-2012
3.5x
V/F Lens
Ø100.0 (3.93")
Ø137.0 (5.39")
PoE
E-D&N
Unit : mm (inch)
106.0 (4.17")
Ø137.0 (5.39")
Technical Specifications
SNV-1080RN SNV-1080RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Out
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Mount Type
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
IR LED
Viewable Length
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" PS CMOS
680(H) x 512(V)
640(H) x 480(V)
Progressive
Color : 0.7Lux (F1.2, 50IRE), B/W : 0Lux (F1.2, 50IRE, IR LED on)
50dB
DIP connector type, for installation
2.2 ~ 7.7mm (3.5x) varifocal
F1.2
H : 94°(Wide) ~ 26.5°(Tele), V : 70°(Wide) ~ 20°(Tele)
500mm (1.64ft)
Board type (Ø14)
0° ~ 355°
17° ~ 90°
0° ~ 355°
12ea
15m (49.21ft)
Off / On (Displayed up to 15 characters)
Auto (S/W) / Color / B/W / External
Off / BLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (32ea 4 points polygonal)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (60x ~ 1/12000sec)
Off / On
Face detection
Input 1ea
RJ-45 (10/100BASE-T)
H.264, MJPEG
640 x 480 / 320 x 240 / 160 x 120
Max. 30fps at all resolutions
H.264 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic/Line in , Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication
Unicast / Multicast
10 users at unicast mode
Micro SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
IP66 Grade (Waterproof)
12V DC / PoE (IEEE802.3af)
Max.3.4W (12V DC), Max.4W (PoE)
Ivory / Aluminum
Ø137.0 x 106.0mm (Ø5.39" x 4.17")
786g (1.73 lb)
37
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
Page 39
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
SNP-5200/5200H
1.3 Megapixel HD 20x Network PTZ Dome Camera
SNP-5200 SNP-5200H
1.3M
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 4.45 ~ 89mm (20x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE plus, SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
Dimensions
SNP-5200
SNP-5200H
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
20x
243.4 (9.58")
215.7 (8.49")
20.0 (0.79")
316.5 (12.46")
Ø155.0 (6.1")
Ø162.0 (6.38")
Ø248.0 (9.76")
PoE+
D&N ICR
Ø155.0 (6.1")
Ø248.0 (9.76")
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.7Lux (F1.6, 50IRE), 0.01Lux (Sens-up 60x, 50IRE)
B/W : 0.08Lux (F1.6, 50IRE), 0.001Lux (Sens-up 60x, 50IRE)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
4.45 ~ 89mm (20x)
F1.6(Wide) / F2.9(Tele)
H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
1m (3.28ft)
AF / One-shot AF / Manual
DC auto iris
Board-in type
360˚ Endless
Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
190˚(-5˚ ~185˚ )
Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
255ea
±0.1˚
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
Off / On
Off / On (4 programmable zones)
Off / On (8 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
16x
Off / On
Scene Change, Virtual Line, Enter / Exit, Appear / Disappear
Input 4ea / Output 2ea (Relay)
RS-485/422
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
30fps at all resolutions
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
N/A IP66 Grade (Waterproof)
24V AC, PoE+ (IEEE802.3at)
Max. 21W
Ivory / Plastic Ivory / Aluminum / Plastic sun-shield
Ø155.0 x 243.4mm (Ø6.1" x 9.58") Ø248.0 x 316.5mm (9.76" x 12.46")
2.1Kg (4.63 lb) 4.6Kg (10.14 lb)
SNP-5200N/P SNP-5200HN/HP
III
(2D+3D noise filter) (Off / On)
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
Max. 25W (Heater off), Max. 52W (Heater on)
* Heater works at AC input only.
REVISED 03-2012
38
Page 40
SNP-3371TH/3371H
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
4CIF 37x Network PTZ Dome Camera
20.0 (0.79")
316.5 (12.46")
37x
Ø162.0 (6.38")
Ø248.0 (9.76")
128x
160x
PoE+
D&N ICR
Unit : mm (inch)
Ø248.0 (9.76")
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.5 ~ 129.5mm (37x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
•
Auto tracking (SNP-3371TH), SD memory, IP66, Bi-directional audio support
• Intelligent video analytics
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300LM SBP-300PM SBP-300KM
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
Auto Tracking
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SNP-3371THN/3371HN SNP-3371THP/3371HP
1/4" Vertical double density interline transfer CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
Color : 0.7Lux (F1.6, 50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux (F1.6, 50IRE), 0.0001Lux (Sens-up, 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3.5 ~ 129.5mm (37x)
F1.6(Wide) / F3.9(Tele)
H : 55.5˚(Wide) ~ 1.59˚(Tele) / V : 42.5˚(Wide) ~ 1.19˚(Tele)
1.8m (5.91ft)
AF / One-shot AF / Manual
DC auto iris
Board-in type
360˚ Endless
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
190˚ (-5˚ ~ 185˚)
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
255ea
±0.1˚
Yes (SNP-3371TH only)
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR / HLC
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On
Yes
Off / On (8 programmable zones)
Off / Auto (2x ~ 512x)
Off / Low / Medium / High / Manual
AWC / Manual / Indoor / Outdoor / ATW (1,700°K ~ 11,000°K)
ESC / FLK / Manual (1/60 ~ 1/120,000) ESC / FLK / Manual (1/50 ~ 1/120,000)
16x
Off / On
Virtual Line, Enter / Exit, Appear / Disappear
Input 4ea / Output 2ea
RS-485/422
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or 8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
SNP-3371TH/H : -50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
SNP-3371 : -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
IP66 Grade
24V AC, PoE+ (IEEE 802.3at)
Max. 25W (Heater off), Max. 60W (Heater on)
* Heater works at AC input only
Ivory / Aluminum / Plastic sun-shield
Ø248.0 x 316.5mm (Ø9.76" x 12.46")
4.6Kg (10.14 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
39
Page 41
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
SNP-3371
4CIF 37x Network PTZ Dome Camera
243.4 (9.58")
37x
215.7 (8.49")
128x
160x
Ø155.0 (6.1")
PoE+
D&N ICR
Ø155.0 (6.1")
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.5 ~ 129.5mm (37x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE plus, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Vertical double density interline transfer CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
Color : 0.7Lux (F1.6, 50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux (F1.6, 50IRE), 0.0001Lux (Sens-up, 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3.5 ~ 129.5mm (37x)
F1.6(Wide) / F3.9(Tele)
H : 55.5˚(Wide) ~ 1.59˚(Tele) / V : 42.5˚(Wide) ~ 1.19˚(Tele)
1.8m (5.91ft)
AF / One-shot AF / Manual
DC auto iris
Board-in type
360˚ Endless
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
190˚ (-5˚ ~ 185˚)
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
255ea
±0.1˚
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR / HLC
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
Off / On
Yes
Off / On (8 programmable zones)
Off / Auto (2x ~ 512x)
Off / Low / Medium / High / Manual
AWC / Manual / Indoor / Outdoor / ATW (1,700°K ~ 11,000°K)
ESC / FLK / Manual (1/60 ~ 1/120,000) ESC / FLK / Manual (1/50 ~ 1/120,000)
16x
Off / On
Virtual Line, Enter / Exit, Appear / Disappear
Input 4ea / Output 2ea
RS-485/422
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or 8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
24V AC, PoE+ (IEEE 802.3at)
Max. 21W
Ivory / Plastic
Ø155.0 x 243.4mm (Ø6.1" x 9.58")
2.2Kg (4.85 lb)
SNP-3371N SNP-3371P
III
(2D+3D noise filter) (Off / On)
REVISED 03-2012
40
Page 42
SNP-3302H/3302
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
4CIF 30x Network PTZ Dome Camera
SNP-3302SNP-3302H
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.5 ~ 105.3mm (30x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE plus, SD memory, IP66
• Intelligent video analytics
Dimensions
SNP-3302H
SNP-3302
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
30x
20.0 (0.79")
316.5 (12.46")
243.4 (9.58")
215.7 (8.49")
128x
160x
Ø162.0 (6.38")
Ø248.0 (9.76")
Ø155.0 (6.1")
PoE+
D&N ICR
Ø248.0 (9.76")
Ø155.0 (6.1")
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SNP-3302HN/3302N SNP-3302HP/3302P
1/4" Vertical double density interline transfer CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
Color : 0.7Lux (F1.6, 50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux (F1.6, 50IRE), 0.0001Lux (Sens-up, 512x)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
3.5 ~ 105.3mm (30x)
F1.6(Wide) / F3.6(Tele)
H : 55.5˚(Wide) ~ 1.92˚(Tele) / V : 42.5˚(Wide) ~ 1.43˚(Tele)
1.8m (5.91ft)
AF / One-shot AF / Manual
DC auto iris
Board-in type
360˚ Endless
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
190˚ (-5˚ ~ 185˚)
Preset : 500˚/sec, Manual : 0.024˚/sec ~120˚/sec
255ea
±0.1˚
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR / HLC
128x, 52dB 160x, 52dB
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNR
III
(2D+3D noise filter) (Off / On)
Off / On
Yes
Off / On (8 programmable zones)
Off / Auto (2x ~ 512x)
Off / Low / Medium / High / Manual
AWC / Manual / Indoor / Outdoor / ATW (1,700°K ~ 11,000°K)
ESC / FLK / Manual (1/60 ~ 1/120,000) ESC / FLK / Manual (1/50 ~ 1/120,000)
16x
Off / On
Virtual Line, Enter / Exit, Appear / Disappear
Input 4ea / Output 2ea
RS-485/422
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
2-Way
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes (1.02)
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or 8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
SNP-3302H : -50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
SNP-3302 : -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
IP66 Grade (SNP-3302H only)
24V AC, PoE+ (IEEE 802.3at)
SNP-3302H : Max. 25W (Heater off), Max. 60W (Heater on), * Heater works at AC input only
SNP-3302 : Max. 21W
SNP-3302H : Ivory / Aluminum / Plastic sun-shield, SNP-3302 : Ivory / Plastic
SNP-3302H : Ø248.0 x 316.5mm (9.76" x 12.46")
SNP-3302 : Ø155.0 x 243.4mm (Ø6.1" x 9.58")
SNP-3302H : 4.6Kg (10.14 lb), SNP-3302 : 2.2Kg (4.85 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
41
Page 43
168.0 (6.61")
108.0 (4.25")
Ø174.0 (6.85") Ø174.0 (6.85")
SNP-3120
4CIF 12x Network PTZ Dome Camera
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.69 ~ 44.32mm (12x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE plus, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
12x
Ø174.0 (6.85") Ø174.0 (6.85")
128x
160x
D&N ICR
108.0 (4.25")
168.0 (6.61")
PoE+
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
VPS
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.7Lux (F1.65, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.07Lux (F1.65, 50IRE), 0.0001Lux (Sens-up 512x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite
3.69 ~ 44.32mm (12x)
F1.65(Wide) / F2.01(Tele)
H : 54.44˚(Wide) ~ 4.62˚(Tele), V : 42.32˚(Wide) ~ 3.58˚(Tele)
0.2m(Wide) / 0.8m(Tele)
AF / One-shot AF / Manual
DC auto iris
360˚ Endless
Preset : 650˚/sec, Manual : 0.05˚/sec ~120˚/sec (Turbo : 200˚/sec)
-5˚~185˚
Preset : 650˚/sec, Manual : 0.05˚/sec ~120˚/sec
255ea
±0.1˚
Off / On (Displayed up to 12 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR
128x, 52dB 160x, 52dB
XDR (eXtended Dynamic Range) (Off / Low / Medium / High)
Motion adaptive 2D+3D noise filter (Off / Low / Medium / High)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones)
Off / Auto (2x ~ 512x)
Off / Low / Medium / High / Manual
ATW (In) / ATW (Out) / AWC / Manual
Off / A.FLK / Manual (1/120 ~ 1/10Ksec)
16x
Digital flip
Off / On
Moved / Fixed
Input 2ea / Output 2ea (Relay)
RS-485
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, GE, Bosch
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) Login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
24V AC, PoE+ (IEEE802.3at)
Max. 15W
Ivory / Plastic
Ø174.0 x 168.0mm (Ø6.85" x 6.61")
1.2Kg (2.65 Ib)
SNP-3120N SNP-3120P
REVISED 03-2012
42
Page 44
SNP-3120VH
Ø115.0 (4.53")
Ø200.0 (7.87")
203.0 (7.99")
120.0 (4.72") 19.0 (0.75")
4CIF 12x Network PTZ Dome Camera
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• 3.69 ~ 44.32mm (12x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming
• PoE plus, SD memory, Bi-directional audio support
• Intelligent video analytics
Dimensions
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300LM SBP-300PM SBP-300KM
12x
128x
160x
D&N ICR
120.0 (4.72") 19.0 (0.75")
203.0 (7.99")
PoE+
Unit : mm (inch)
Ø200.0 (7.87")Ø115.0 (4.53")
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
PAN / TILT / ROTATE
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror
VPS
Intelligent Video Analytics
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD PS CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
Progressive (VPS on) (If WDR on, Interlaced scan)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.7Lux (F1.65, 50IRE), 0.001Lux (Sens-up 512x)
B/W : 0.07Lux (F1.65, 50IRE), 0.0001Lux (Sens-up 512x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite
3.69 ~ 44.32mm (12x)
F1.65(Wide) / F2.01(Tele)
H : 54.44˚(Wide) ~ 4.62˚(Tele), V : 42.32˚(Wide) ~ 3.58˚(Tele)
0.2m(Wide) / 0.8m(Tele)
AF / One-shot AF / Manual
DC auto iris
360˚ Endless
Preset : 650˚/sec, Manual : 0.05˚/sec ~120˚/sec (Turbo : 200˚/sec)
-5˚~185˚
Preset : 650˚/sec, Manual : 0.05˚/sec ~120˚/sec
255ea
±0.1˚
Off / On (Displayed up to 12 characters)
Auto (ICR) / Color / B/W
Off / BLC / WDR
128x, 52dB 160x, 52dB
XDR (eXtended Dynamic Range) (Off / Low / Medium / High)
Motion adaptive 2D+3D noise filter (Off / Low / Medium / High)
Off / On
Off / On (4 programmable zones)
Off / On (12 polygonal programmable zones)
Off / Auto (2x ~ 512x)
Off / Low / Medium / High / Manual
ATW (In) / ATW (Out) / AWC / Manual
Off / A.FLK / Manual (1/120 ~ 1/10Ksec)
16x
Digital flip
Off / On
Moved / Fixed
Input 2ea / Output 2ea (Relay)
RS-485
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, GE, Bosch
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) Login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0/7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
IP66 Grade
24V AC, PoE+ (IEEE802.3at)
Max. 15W (Heater off), Max. 45W (Heater on)
* Heater works at AC power input only
Ivory / Aluminum (Vandal-resistance), Sun-shield built-in
Ø200.0 x 203.0mm (Ø7.87" x 7.99")
2.4Kg (5.29 Ib)
SNP-3120VHN SNP-3120VHP
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
43
Page 45
Network Video Recorder Selection
SRN-6450 SRN-3250 SRN-1670D SRN-470D
VIDEO
Number of Cameras
Resolution
Protocols
Local Display
PERFORMANCE
Operating System
Video Compression
Recording Bit Rate
Record Rate
Search & Playback
Internal HDD
External HDD
DVD Writer
Max. Remote Users
Network Protocol Support
Network Monitoring
INTERFACE
VGA
HDMI
Audio Inputs
Audio Output
Audio Compression Format
Alarm Inputs
Alarm Outputs
Ethernet
USB
e-SATA
Controller
GENERAL
Input Voltage / Current
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxHxD)
Weight (With Hard Disks)
Up to 64CH (CIF 1,920/1,600fps) Up to 32CH (CIF 960/800fps) Up to 16CH (4CIF 480fps) Up to 4CH (4CIF 120fps)
CIF ~ 3M CIF ~ 3M CIF ~ 3M CIF ~ 3M
Samsung, Axis Samsung, Axis Samsung Samsung
N/A N/A Yes Yes
Linux Linux Linux Linux
H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG H.264, MPEG-4, MJPEG
48Mbps 36Mbps 64Mbps 64Mbps
Up to 160fps@3M (15Mbps) Up to 60fps@3M (15Mbps) Up to 90fps@3MP (15Mbps) Up to 90fps@3MP (15Mbps)
Webviewer or NET-i viewer Webviewer or NET-i viewer Yes (Local display) / Webviewer / NET-i viewer Yes (Local display) / Webviewer / NET-i viewer
Up to 4 SATA HDDs Up to 4 SATA HDDs Up to 5 SATA HDDs Up to 1 SATA HDD
4 e-SATA Interface 4 e-SATA Interface 2 e-SATA Interface 2 e-SATA Interface
N/A N/A Yes Yes
Search 5 / Live unicast 5 Search 5 / Live unicast 5 Search 3 / Live unicast 10 / Live multicast 20 Search 3 / Live unicast 10 / Live multicast 20
TCP/IP, DHCP, DDNS, HTTP, ARP, ICMP,
NTP, RTP/RTCP, RTSP
NET-i viewer, Webviewer NET-i viewer, Webviewer NET-i viewer, Webviewer NET-i viewer, Webviewer
N/A N/A Analogue RGB 1280 x 1024(60Hz) resolution Analogue RGB 1280 x 1024(60Hz) resolution
N/A N/A 720p/1080p(60Hz) resolution 720p/1080p(60Hz) resolution
N/A (Network audio support, up to 64CH) N/A (Network audio support, up to 32CH) N/A (Network audio support, up to 16CH) N/A (Network audio support, up to 4CH)
N/A N/A RCA x 1 RCA x 1
N/A N/A G.711, G.723.1, G.726 G.711, G.723.1, G.726
Terminal 2 inputs, NO/NC Terminal 2 inputs, NO/NC Terminal 16 inputs, NO/NC Terminal 4 inputs, NO/NC
Terminal 2 relay outputs, NO/NC Terminal 2 relay outputs, NO/NC Terminal 4 relay outputs, NO/NC Terminal 2 relay outputs, NO/NC
3 (RJ-45 10/100/1000 Base-T),
1 (RJ-45 100 Base-T)
2 USB 2.0 ports (Firmware upgrade) 2 USB 2.0 ports (Firmware upgrade) USB 2.0, 3 ports USB 2.0, 2 ports
4 ports 4 ports 2 ports 2 ports
N/A N/A Mouse, IR remote controller Mouse, IR remote controller
100 ~ 240V AC ±10%, 50/60 Hz,
Auto ranging
Max. 110W (With 1x HDD) Max. 110W (With 1x HDD) Max. 65W (With 1x HDD) Max. 36W (With 1x HDD)
+5°C ~ +40°C (+41°F ~ +104°F) +5°C ~ +40°C (+41°F ~ +104°F) +0°C ~ +40°C (+32°F ~ +104°F) +0°C ~ +40°C (+32°F ~ +104°F)
0% ~ 60% RH 0% ~ 60% RH 20% ~ 85% RH 20% ~ 85% RH
430.0 x 88.0 x 501.0mm (16.92" x 3.46" x 19.73") 430.0 x 88.0 x 501.0mm (16.92" x 3.46" x 19.73")
Approx. 11Kg (24.25 lb) Approx. 11Kg (24.25 lb) Approx. 7.1Kg (15.65 lb) Approx. 3.7Kg (8.16 lb)
TCP/IP, DHCP, DDNS, HTTP, ARP, ICMP,
NTP, RTP/RTCP, RTSP
3 (RJ-45 10/100/1000 Base-T),
1 (RJ-45 100 Base-T)
100 ~ 240V AC ±10%, 50/60 Hz,
Auto ranging
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP,
DDNS, RTP, RTSP
2 (RJ-45 10/100/1000 Base-T) 2 (RJ-45 10/100/1000 Base-T)
100 ~ 240V AC ±10%, 50/60 Hz,
Auto ranging
440.0 x 88.0 x 430.0mm (17.32" x 3.46" x 16.93") 215.0 x 88.0 x 352.0mm (8.46" x 3.46" x 13.86")
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP,
DDNS, RTP, RTSP
12V DC adaptor,4A,100 ~ 250V AC,
50 ~ 60Hz, 55watt
44
Page 46
430.0 (16.92")
501.0 (19.73")
88.0 (3.46")
SRN-6450/3250
64CH/32CH Network Video Recorder
64CH/32CH
Key Features
• Up to 1.3MP resolution support
• H.264, MPEG-4, MJPEG multiple codec
• 48Mbps recording bit rate (SRN-6450)
36Mbps recording bit rate (SRN-3250)
• Up to 20TB using external storage option
Dimensions
H.264
48bps 36bps
Unit : mm (inch)
88.0 (3.46")
430.0 (16.92")
Technical Specifications
SRN-6450 SRN-3250
DISPLAY
N/W
Camera
Web
Support
PERFORMANCE
Recording
Search &
Playback
Network
Storage
Security
INTERFACE
Monitors DOT Matrix LCD
Alarm
Connections
IP Camera
Protocols
GENERAL
Electrical
Environmental
Mechanical
Language (LCD)
Certifications
(*1) VAPIX MPEG-4 Model, Some functions are limited
* The latest product information / specification can be found at www.samsungsecurity.com
501.0 (17.73")
Inputs
Resolution
Live
Search
Compression
Recording Bit Rate
Record Rate
(NTSC / PAL)
Mode
Overwrite Modes
Pre-alarm
Post-alarm
Search Mode
Playback Function
Bandwidth Control
Max. Remote Users
Protocol Support
Monitoring
Maximum Capacity
RAID
Internal HDD
External HDD
NAS
Password Protection
Inputs
Outputs
Remote Notification
Ethernet
Serial Interface
USB
eSATA
Supported
IP Cameras
Input Voltage / Current
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxHxD)
Weight (4x Hard Disks)
Rack Mount Kit
Up to 64CH (CIF 1920/1600fps) Up to 32CH (CIF 960/800fps)
VGA, 4CIF, 1.3M
1 / 4 / 9 / 16 / 36 / 64, Sequence 1 / 4 / 9 / 16 / 32, Sequence
1CH
H.264, MPEG-4, MJPEG
48Mbps 36Mbps
Up to 320fps@1.3M
Up to 1280/1152fps@4CIF
Up to 1920/1600fps@2CIF, CIF
Manual, Schedule (Normal / Event)
Continuous
Up to 5sec
Up to 60sec
Time, Event, Calendar
REW, FWD (Depend on CMS)
Automatic (Automatic transmission control)
5 Users simultaneously
TCP/IP, DHCP, DNS, DDNS, HTTP, ARP, ICMP, NTP, RTP/RTCP, RTSP
NET-i viewer, Built-in web server
Up to 20TB using external storage option
Normal, RAID1, 5 Normal, RAID1
Up to 4 SATA HDDs
Up to 4 expansion bay (Up to 4 HDD each)
Up to 4 NAS connection (CIFS / Samba)
2 User level
20 x 2 Status display
Screw terminal 2 inputs, NO/NC
Screw terminal 2 relay outputs, NO/NC
Notification via e-mail
3 (RJ-45 100/1000 Base-T), 1 (RJ-45 100Base-T)
RS-232C
2 USB 2.0 ports (Firmware upgrade)
4 External SATA ports
Samsung, AXIS (*1)
100 ~ 240V AC ±10%, 50/60Hz, Auto ranging
Max. 110W (With 1x HDD)
Max. 130W (With 4x HDD)
+5°C ~ +40°C (+41°F ~ +104°F)
0% ~ 60% RH
430.0 x 88.0 x 501.0mm (16.92" x 3.46" x 19.73")
Approx. 11Kg (24.25 lb)
For mounting one unit in an EIA 19 inch rack
English
FCC (Class A), cUL/UL listed, CE (Class A)
Up to 120fps@1.3M
Up to 480/400fps@4CIF
Up to 960/800fps@2CIF, CIF
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
45
Page 47
430.0 (16.93")
440.0 (17.32")
7.9 (0.3")
426.8(168.03)
437.7(172.32)
440(173.23)
7.9(3.11)
88.0 (3.46")7.5 (0.3")
430.0 (16.93")
440.0 (17.32")
7.9 (0.3")
426.8(168.03)
437.7(172.32)
440(173.23)
7.9(3.11)
88(34.65)
95.5(37.6)
7.5(2.95)
SRN-1670D
16CH Network Video Recorder
16CH
Key Features
• Full HD resolution support
• H.264, MPEG-4, MJPEG multiple codec
• 64Mbps recording bit rate
• Local monitor output : HDMI & VGA
• Built-in 1TB HDD
• DVD writer support
Dimensions
H.264
64bps
7.5 (0.3") 88.0 (3.46")
440.0 (17.32")
HDMI
1080p
Unit : mm (inch)
Technical Specifications
DISPLAY
N/W
Camera
Live
PERFORMANCE
Operating System
Recording
Search &
Playback
Network
Storage
Security
INTERFACE
Monitors
Audio
Alarm
Connections
Dome
Protocols
7.9 (0.3")
GENERAL
Electrical
Environmental
Mechanical
430.0 (16.93")
Language
* The latest product information / specification can be found at www.samsungsecurity.com
Inputs
Resolution
Protocols
Multi Screen Display
Embedded
Compression
Recording Bit Rate
Resolution
Mode
Overwrite Modes
Pre-alarm
Post-alarm
Playback Speed
Resolution
Search Mode
Playback Function
Ethernet
Transmission Speed
Bandwidth Control
Max. Remote Users
Protocol Support
Monitoring
Internal HDD
External (e-SATA Interface)
DVD Writer (Back up)
USB (Back up)
File Format (Back up)
Password Protection
Data Authentication
VGA
HDMI
Inputs
Output
Compression
Inputs
Outputs
Remote Notification
Ethernet
USB
eSATA
Application Support
Supported
PTZ Cameras
Input Voltage / Current
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxHxD)
Weight (1x Hard Disks)
Rack Mount Kit
Up to 16CH
VGA (640 x 480) / SVGA (800 x 600) / 4CIF (704 x 480) /
1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Samsung
1 / 4 / 6 / 8 / 9 / 13 / 16, Sequence
Linux
H.264, MPEG-4, MJPEG
64Mbps
4CIF (704 x 480) / 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Manual, Schedule (Continuous / Event), Event (Pre / Post)
Selectable (Stop / Continuous)
Up to 15sec (5,10,15sec) * 4CIF standard resolution
Up to 6hour (5, 10, 20, 30sec,1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
120fps (Up to 4CH)
4CIF (704 x 480) / 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Date/time, Event, Back up (*All search included preview function)
Fast forward / backward, Slow forward / backward, Step forward / backward
Gigabit Ethernet x 2
Up to 48Mbps, Unlimited (48M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Automatic
Search 3 / Live unicast 10 / Live multicast 20
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP
NET-i viewer, Webviewer
Up to 5 SATA HDDs
Up to 2 expansion bay (*Model : SVS-5R)
Yes
3 USB ports
BU (NVR player), EXE (Include player)
1Admin, 10 Group, 20 User per 1 group, User can be assigned authority for function
Watermark
Analogue RGB 1024 x 768 / 1280 x 1024(60Hz) resolution
720p/1080p(60Hz) resolution
N/A (Network audio support, up to 16CH)
RCA x 1
G.711, G.723.1, G.726
Terminal 16 inputs, NO/NC
Terminal 4 relay outputs, NO/NC
Notification via e-mail
2 RJ-45 10/100/1000 Base-T
USB 2.0, 3 ports
2 ports
Mouse, Remote controller
Samsung network products (Network PTZ)
100 ~ 240V AC ±10%, 50/60Hz, 4 ~ 1.5A
Max. 56W (With 1x HDD)
+0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 85% RH
440.0 x 88.0 x 430.0mm (17.32" x 3.46" x 16.93")
Approx. 7.1Kg (15.65 lb)
2ea
Korean, Japanese, Chinese, English, French, German, Spanish, Italian, Russian,
Polish, Czech, Turkish, Netherlands, Portuguese,Swedish,Danish, Thai, Rumania,
Serbia, Croatia, Hungarian, Greek (22 Language)
SRN-1670D
REVISED 03-2012
46
Page 48
SRN-470D
215.0 (8.46")
352.0 (13.86")
9.4 (0.37")
eSATA1
eSATA2
88.0 (3.46")10.0 (0.39")
215.0 (8.46")
352.0 (13.86")
9.4 (0.37")
4CH Network Video Recorder
4CH
Key Features
• Full HD resolution support
• H.264, MPEG-4, MJPEG multiple codec
• 64Mbps recording bit rate
• Local monitor output : HDMI & VGA
• Built-in 1TB HDD
• DVD writer support
Dimensions
H.264
64bps
88.0 (3.46")
10.0 (0.39")
215.0 (8.46")
HDMI
1080p
Unit : mm (inch)
9.4 (0.37")
352.0 (13.86")
Technical Specifications
SRN-470D
DISPLAY
N/W
Camera
Live
PERFORMANCE
Operating System
Recording
Search &
Playback
Network
Storage
Security
INTERFACE
Monitors
Audio
Alarm
Connections
Dome
Protocols
GENERAL
Electrical
Environmental
Mechanical
Language
* The latest product information / specification can be found at www.samsungsecurity.com
Inputs
Resolution
Protocols
Multi Screen Display
Embedded
Compression
Recording Bit Rate
Resolution
Mode
Overwrite Modes
Pre-alarm
Post-alarm
Playback Speed
Resolution
Search Mode
Playback Function
Ethernet
Transmission Speed
Bandwidth Control
Max. Remote Users
Protocol Support
Monitoring
Internal HDD
External (e-SATA Interface)
DVD Writer (Back up)
USB (Back up)
File Format (Back up)
Password Protection
Data Authentication
VGA
HDMI
Inputs
Output
Compression
Inputs
Outputs
Remote Notification
Ethernet
USB
eSATA
Application Support
Supported
PTZ Cameras
Input Voltage / Current
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxHxD)
Weight (1x Hard Disks)
Up to 4CH
VGA (640 x 480) / SVGA (800 x 600) / 4CIF (704 x 480) /
1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Samsung
1 / 4, Sequence
Linux
H.264, MPEG-4, MJPEG
64Mbps
4CIF (704 x 480) / 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Manual, Schedule (Continuous / Event), Event (Pre / Post)
Selectable (Stop / Continuous)
Up to 15sec (5,10,15sec) * 4CIF standard resolution
Up to 6hour (5, 10, 20, 30sec,1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
120fps (Up to 4CH)
4CIF (704 x 480) / 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Date/time, Event, Back up (*All search included preview function)
Fast forward / backward, Slow forward / backward, Step forward / backward
Gigabit Ethernet x 2
Up to 48Mbps, Unlimited (48M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Automatic
Search 3 / Live unicast 10 / Live multicast 20
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP
NET-i viewer, Webviewer
Up to 1 SATA HDD
Up to 2 expansion bay (*Model : SVS-5R)
Yes
2 USB ports
BU (NVR player), EXE (Include player)
1Admin, 10 Group, 20 User per 1 group, User can be assigned authority for function
Watermark
Analogue RGB 1280 x 1024(60Hz) resolution
720p/1080p(60Hz) resolution
N/A (Network audio support, up to 4CH)
RCA x 1
G.711, G.723.1, G.726
Terminal 4 inputs, NO/NC
Terminal 2 relay outputs, NO/NC
Notification via e-mail
2 RJ-45 10/100/1000 Base-T
USB 2.0, 2 ports
2 ports
Mouse, Remote controller
Samsung network products (Network PTZ)
12V DC adaptor, 4A,100 ~ 250V AC, 50/60Hz, 1.2A
Max. 36W (With 1x HDD)
+0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 85% RH
215.0 x 88.0 x 352.0mm (8.46" x 3.46" x 13.86")
Approx. 3.7Kg (8.16 lb)
Korean, Japanese, Chinese, English, French, German, Spanish, Italian, Russian,
Polish, Czech, Turkish, Netherlands, Portuguese,Swedish,Danish, Thai, Rumania,
Serbia, Croatia, Hungarian, Greek (22 Language)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
47
Page 49
310.5 (12.22")
440.0 (17.32")
44.0 (1.73")
310.5 (12.22")
440.0 (17.32")
236.7 (9.32")
35.0 (1.37")
82.0 (3.23")
SPE-400B/1600R
4CH Blades / 16CH Network Video Encoder Rack
SPE-400B
SPE-1600R
4CH 16CH
Key Features
• Max. 30(25)fps at 4CIF resolution
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming simultaneously
• 1000BASE-T
• SPE-1600R : extension rack, 4 slots for SPE-400B
Dimensions
4CIF
Unit : mm (inch)
Technical Specifications
SPE-400BN SPE-400BP
OPERATIONAL
Video In
De-interlacing Filter
Event Trigger
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
IP
Protocol
Security
Streaming Method
Max. User Access
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
4 CVBS : 1.0 Vp-p / 75Ω composite, NTSC/PAL auto detection
Built-in
Motion detection, Alarm input, Video loss
Input 4ea / Output 4ea (Relay)
4ea RS-485 (Half duplex)
Samsung-T/E, Pelco-P/D
RJ-45 (1000BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps per channel 25fps per channel
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPOE
FTP, SMTP, ICMP, IGMP, SNMPV1/V2C/V3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
NET-i viewer
0°C ~ +40°C (+32°F ~ +104°F) / 20% ~ 80% RH
5V DC
Max. 11W
Black / Metal
236.7 x 82.0 x 35.0mm (9.32" x 3.23" x 1.38")
165g (0.36 lb)
REVISED 03-2012
SPE-400B
SPE-1600R
82.0 (3.23")
35.0 (1.37")
44.0 (1.73")
236.7 (9.32")
440.0 (17.32")
CONNECTION
Expansion Slots
Connector
ENVIRONMENTAL
Operating Temperature
Operating Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
310.5 (12.22")
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
4 Slots for SPE-400B
RJ-45 (10/100/1000BASE-T)
0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 80% RH
100 ~ 240V AC ±10%, 50/60Hz / 0.5A
Max. 50W (with SPE-400B x 4)
Black / Metal
440.0 x 310.5 x 44.0mm (17.32" x 12.22" x 1.73")
3.17Kg (1.44 lb)
SPE-1600R
48
Page 50
178.0 (7")
128.0 (5.04")
34.0 (1.34")
SPE-400
4CH Network Video Encoder
4CH
H.264
4CIF
Key Features
• Max. 30(25)fps at 4CIF resolution
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming simultaneously
• 10/100/1000BASE-T
• SD memory, Bi-directional audio support
Dimensions
Bi-directional
178.0 (7")
Unit : mm (inch)
Technical Specifications
SPE-400N SPE-400P
OPERATIONAL
Video In
De-interlacing Filter
Event Trigger
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
4 CVBS : 1.0 Vp-p / 75Ω composite, NTSC/PAL auto detection
Built-in
Motion detection, Alarm input, Video loss
Input 4ea / Output 4ea (Relay)
4ea RS-485 (Half duplex)
Samsung-T/E, Pelco-P/D, Panasonic, Vicon, Honeywell, AD, GE, Bosch, Sungjin
RJ-45 (10/100/1000BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps per channel 25fps per channel
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
1ea line in / 1ea line out (CH1 only)
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPOE
FTP, SMTP, ICMP, IGMP, SNMPV1/V2C/V3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot (CH1 only)
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari
NET-i viewer
0°C ~ +40°C (+32°F ~ +104°F) / 20% ~ 80% RH
12V DC
Max. 15W
Silver / Metal
128.0 x 34.0 x 178.0mm (5.04" x 1.34" x 7")
562g (1.29 lb)
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
REVISED 03-2012
128.0 (5.04") 34.0 (1.34")
SYSTEM
ACCESS CONTROL
49
Page 51
SPE-101/100
29.0 (1.41")
83.0 (3.26")
95.5 (3.76")43.0 (1.69")
87.14 (3.43")
43.8 (1.72")
128.0 (5.04")
AUDIO IN AUDIO OUT
VIDEO IN LOOP OUT
SD CARD
ETHERNET / PoE
RESET
SD
POWER
DC12V
D+ D- S1 G NC CM NO
RS-485 SENSOR RELAY OUT
+
1CH Network Video Encoder
SPE-101
1CH
Key Features
• Max. 30(25)fps at 4CIF resolution
• H.264, MPEG-4, MJPEG multiple codec
• Multiple streaming simultaneously
• 10/100BASE-T, PoE
• SD memory, Bi-directional audio support (SPE-100)
Dimensions
43.0 (1.69")
H.264
29.0 (1.41")
4CIF
PoE
83.0 (3.26")
95.5 (3.76")
SPE-101
SPE-100
Unit : mm (inch)
Technical Specifications
SPE-101N/100N SPE-101P/100P
OPERATIONAL
Video In
Video Out
De-interlacing Filter
Event Trigger
Alarm I/O
Remote Control Interface
RS-485 Protocol
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Web Viewer
Central Management Software
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
CVBS : 1.0 Vp-p / 75Ω composite, NTSC/PAL auto detection
CVBS : 1.0 Vp-p / 75Ω composite, Loop-out : SPE-100
Built-in
Motion detection, Video loss : SPE-101
Motion detection, Alarm input, Video loss : SPE-100
Input 1ea / Output 1ea (Relay) : SPE-100
RS-422/485 : SPE-101, 1ea RS-485 (Half duplex) : SPE-100
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, GE, Bosch, Sungjin : SPE-101
Samsung-T/E, Pelco-P/D : SPE-100
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
704 x 480, 640 x 480, 352 x 240, 320 x 240 704 x 576, 640 x 480, 352 x 288, 320 x 240
30fps 25fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
1ea line in / 1ea line out : SPE-100
G.711 u-law : SPE-100
Bi-directional audio : SPE-100
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPOE
FTP, SMTP, ICMP, IGMP, SNMPV1/V2C/V3(MIB-2), ARP, DNS, DDNS
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log
802.1x authentication : SPE-101
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot : SPE-100
Yes
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, PoE (IEEE802.3af)
Max. 3.2W : SPE-101, Max. 4W : SPE-100
White / Mold, Silver / Press : SPE-101, Silver / Metal : SPE-100
43.0 x 29.0 x 95.5mm (1.69" x 1.41" x 3.76"), Connector included : SPE-101
128.0 x 43.8 x 87.14mm (5.04" x 1.72" x 3.43") : SPE-100
115g (0.25 lb) : SPE-101, 391g (0.86 lb) : SPE-100
REVISED 03-2012
43.8 (1.72")
128.0 (5.04")
SPE-100
87.14 (3.43")
50
Page 52
SPD-400
178.0 (7")
128.0 (5.04")
34.0 (1.34")
4CH Network Video Decoder
4CH
H.264
Key Features
• H.264, MPEG-4, MJPEG decoding
• Full HD (1080p) video output
• Single and quad view
• Sequence mode for multiple video sources
Dimensions
2M
Unit : mm (inch)
178.0 (7")
Technical Specifications
SPD-400N SPD-400P
OPERATIONAL
HDMI / VGA : Max. 1920 x 1080p
1920 x 1080p, 1680 x 1050, 1600 x 900, 1440 x 900, 1280 x 1024, 1280 x 720p, 1024 x 768
Video Out
Event Trigger
Alarm I/O
NETWORK
Ethernet
Video Compression Format
Resolution
Max. Framerate
Display
Audio I/O
Audio Compression Format
IP
Protocol
Security
Camera Registration
Support Device
Web Viewer
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
CVBS : 1.0 Vp-p / 75Ω composite
704 x 480
HDMI / VGA, CVBS selectable
Alarm Input, IP camera event input
Input 1ea / Output 2ea (Relay)
RJ-45 (10/100/1000BASE-T)
H.264, MPEG-4, MJPEG
H.264 : Single view - up to 2M pixel / Quad view - up to 720p
MPEG-4 : Single view - up to 4CIF / Quad view - Quad up to 4CIF
MJPEG : Single vIew - up to 720p (800 x 600) / Quad vIew - up to 720p (800 x 600)
1920 x 1080p, 1280 x 1024, 1280 x 720p, 704 x 576, 704 x 480, 640 x 480,
352 x 288, 352 x 240, 320 x 240
Max. 30fps at single view, Max. 120fps at 4 x 4CIF, Max. 60fps at 4 x 720p (No audio)
Single view, Quad view
Line out 1ea
G.711
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), NTP, HTTP, DHCP, ICMP, IGMP, ARP, SSL, DNS
HTTPS(SSL) login authentication, User access log
20 camera, 8 layout, 10 sequence
Samsung : SNB-7000/5000, SNV-3120/5080/5010, SND-5080(F)
SNP-3430H/3120/3120V/3120VH, SPE-400/100, SPE-1600R/400B
Axis : P3301, P3343, P3344, P1311, P1343, P1344, P1346, PTZ215, Q6032, Q7401,
Q7404 (F/W ver : 5.x)
Stream (Live video / audio) : SVNP1.2 (AXIS : RTP/RTSP)
Control / Network alarm : SNVP1.2 (AXIS : Not supported)
Supported OS : Windows XP
Supported Browser : Internet Explorer 7.0 or 8.0, Firefox 2.x, 3.x, Chrome, Safari
0°C ~ +40°C (+32°F ~ +104°F) / 0% ~ 90% RH
12V DC
Max.10W
Silver / Metal
128.0 x 34.0 x 178.0mm (5.04" x 1.34" x 7")
530g (1.17 lb)
CVBS : 1.0 Vp-p / 75Ω composite
704 x 576
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
REVISED 03-2012
128.0 (5.04")
SYSTEM
ACCESS CONTROL
34.0 (1.34")
51
Page 53
NET-i viewer
Central Management Software
Live MapSearch
Key Features
• Monitoring software for Samsung video surveillance products
• Up to 64 channels real-time live monitoring simultaneously in single PC
• Support for various video format : H.264, MPEG-4, MJPEG
• Support for various audio format : G.726, G.711, G.723
• Support for various video resolution
: megapixel (1M, 2M, 3M), Full HD, 4CIF, Half D1, VGA, CIF
• Powerful E-map based monitoring
• Bi-directional audio communication
• Remote PTZ control and power area zoom (click and go control)
• Support for various search and playback options
: date and time based search
: event (alarm, motion, intelligent video) based search
:
normal playback, backward playback, fast/slow playback, step playback
• Notification in case of event occurring
: highlighting in the border of video window
: display event log message in real time
• Back up capability
: manual back up
: AVI, REC1, SEC format
• Manual recording (up to 1CH) during 24 hours
• Multi-level user access and authority management
• Support for multi-language user interface
• Automatic search of network cameras for quick and easy configuration
• Easy device management (configuration, firmware upgrade)
• Automatic self upgrade (connection to Samsung upgrade server)
Technical Specifications
NET-i viewer (Version : 1.37)
DEVICE
Supported Device
Max. Register Device
PERFORMANCE
Supported Format
Video
Supported Resolution
Supported Format
Audio
Functions
Multi-monitor
Screen-split Mode
Live
Monitoring
PTZ Control
Functions
Local (Remote) Playback
Search
Search &
Playback
Playback Mode
Functions
Local (Remote) Back up
Back up
Back up
Display
Event
Monitoring
Logs
Display
Number of Map
MAP
Viewer
Supports Image
Monitoring
User
Update
GENERAL
Language
System Requirement
(Recommended)
* The entire items are not supported in every device. Some items are not supported in certain devices.
* The latest product information / specification can be found at www.samsungsecurity.com
Network Camera, Encoder, DVR, NVR
250
H.264, MPEG-4, MJPEG
QXGA, UXGA, SXGA, HD, SVGA, 4CIF, Half D1, VGA, CIF, QVGA
G.711, G.726, G.723
Bi-directional audio, listen, transmit client microphone input to remote speakers
Up to 4 monitors
(Follow the recommended system requirement)
1, 4, 6, 7, 8, 9, 10, 11, 12, 16, 25, 36, 49, 64 (Full-screen)
PTZ control (Pan, Tilt, Zoom, Focus, Preset) using mouse
Digital zoom in/out on the image, click and go control
Automatic device search of network cameras for quick and easy configuration,
Device management (Configuration & firmware update), Snapshot / Prints image
Supported
Search for recordings based on DVR, NVR, Date/time based search,
Event (Alarm, Motion, Intelligent video) based search, POS search
Normal, Forward/Backward, Fast/Slow, Step
Snapshot / Prints image
Supported
Local storage, back up format (AVI, REC1, SEC)
Highlighting in the border of video window,
Display event log message in real time, Launches instant player
Event (Alarm, Motion, Intelligent video, video loss),
Stores user actions by time and cameras and full system operation
Camera / Alarm / Sensor on the map
50maps
JPEG / BMP / GIF / PNG
Launches instant player/viewer up to 16CH
Admin, Operator, User
Automatic self upgrade (Connection to Samsung upgrade server)
Total 24 languages support.
English, French, German, Spanish, Italian, Russian, Chinese, Japanese, Korean,
Turkish, Polish, Czech, Serbian, Romanian, Portuguese, Dutch, Croatian,
Hungarian, Greek,Taiwanese, Swedish, Danish, Finnish, Norwegian
CPU Intel i7 above, RAM 3GB above, Video memory 1GB above,
HDD 200GB above, DirectX 8.1 above. Display resolution : 1,280 x 1,024 above,
OpenGL compatible,
OS : Window XP Professional, Windows 2000 Professional,
Windows Vista Home Basic/Premium/Ultimate, Windows 7 (64bit / 32bit)
Supported Models
NET-i viewer (The latest release version : 1.37)
SNB-7000/5000/3002/3000/2000/1000/1001, SNZ-5200, SNO-7080R/5080R/1080R
Box
SNC-B2335/B2331/M300/1300/550/570
Network
Camera
Encoder
DVR
NVR (H/W)
NVR (S/W)
N/W Controller
SND-7080/5080(F)/3082/3080(F)/3080C(F)/1010/1080/1011
Dome
SNV-7080/5080/3080/5010/3120/5080R/3082/1080/1080R
SND-560/460V, SNC-B5368/B5399
SNP-5200(H)/3430H/3370(TH)/3301(H)/3120(V/VH)/3302(H)/SNP-6200(H)
PTZ
SNC-C6225/C7225/C7478, SNP-3300A/1000A/3750/3350
SNS-400/100/101, SPE-400/100, SPE-1600R
SRD-1670(D/DC)/1650(D/DC)/870(D/DC)/850(D/DC)/470(D)/440
SRD-1630(D)/1610(D)/830(D), SRD-1652D/852D, SRD-480D/442
SRD-1640/840/1641/841
SVR-1670/3200/1680(C)/1660(C)/1645/960(C)/945/480
SHR-2000/5000/6000/7000/8000 series
SVR-1650E/1640A/950E
SRN-6450/3250, SNR-6400/3200, SRN-1670D/470D
NET-i ware : SNS-SF064/032/016/008/004
SPC-2000
REVISED 03-2012
52
Page 54
NET-i ware
Recording Software
Key Features
• Recording software for Samsung network cameras
: 16 / 32 / 64 cameras recording package are available now
:
live video monitoring and search/playback of recorded video by CMS software
• High performance recording : up to 250Mbps
• Triplex operation performance
: recording, live video transmission, recorded video transmission
• Support for various recording options
: continuous recording
: event based recording (including pre/post alarm recording)
(motion detection, intelligent video detection, video loss, alarm signal input)
: scheduled recording (including holiday setup)
• Notification in case of event occurring
: user defined alert sound output
: e-mail to pre-assigned receiver
: notification to monitoring software (CMS software)
•
Event log : system, user access, back up, recording, motion, alarm, video loss, I/V
• Multiple disk allocation and distribution for stable recording
• Multi-level user access and authority management
• Support for multi-language user interface
• Automatic search of network cameras for quick and easy configuration
• Automatic self upgrade (connection to Samsung upgrade server)
Technical Specifications
SNS-SF064 SNS-SF032 SNS-SF016
DEVICE
Supported Device
Max. Register Device
PERFORMANCE
Supported Format
Video
Supported Resolution
Supported Format
Audio
Functions
Performance
Record Mode
Quality
Record
Pre/Post Record Time
LOG
Playback
Search &
Playback
Mode
Manual
Back up
Schedule
E-mail
Event
Monitoring
Preset
Maximum Controller of HDD
Supported Device Format
Storage
Functions
NIC Support
SW Status
Data Security
System
Configuration Value
Functions
Time Synchronization
User Level
User
Local(Remote) User
IP Filtering for Remote User
Live
Search
Webviewer
Setup
Update
GENERAL
Language
System Requirement
(Recommended)
* Recording channel extension is available by channel addition function.
* Two or more HDDs (SATA2 7200rpm) should be used for 250Mbps recording performance.
* The latest product information / specification can be found at www.samsungsecurity.com
Samsung's Network Camera, Encoder
64 32 16
H.264, MPEG-4, MJPEG
QXGA, UXGA, SXGA, HD, SVGA, 4CIF, Half D1, VGA, CIF, QVGA
G.711, G.726, G.723
Bi-directional audio, listen, transmit client microphone input to remote speakers
250Mbps
Continuous, Event (Pre/Post alarm recording), Scheduled recording
10 levels
Pre : 1 ~ 16CH 60sec, 17~ 32CH 30sec, 33 ~ 64CH 15sec, Post : 1200sec
System, User access, Back up, Recording, Motion, Alarm, Video loss, Intelligent video
4 user x 4CH
Time, Event, Timeline
DVD/CD, USB HDD, USB flash memory, Back up format : REC1, SEC
NAS (Network Attached Storage), USB HDD, Back up format : REC1
E-mail transfer at event occurrence
Preset move at alarm occurrence
24HDDs
e-SATA
Storage space assigning by each disk, Warning against lower disk space
NIC is selectable by device connection and client connection type
Device connection, Manual / Schedule recording status
Login packet encryption
Initialization / Export / Import
Auto power-on record
NTP Server, Client
User authority setting by each camera or functions
Group : 32, User : 32
Supported
Monitoring up to 9channels
Time, Timeline (4channels simultaneously)
NET-i ware remote setting
Automatic self upgrade (Connection to Samsung upgrade server)
English, French, German, Spanish, Italian, Turkish, Russian, Chinese, Japanese,
Korean, Polish, Czech, Serbian, Romanian, Portuguese, Dutch, Croatian,
Hungarian, Greek, Taiwanese, Danish, Norwegian, Finnish
CPU : Intel Core i7, RAM : 4GB
Video memory : 256MB, 2HDDs (SATA
Microsoft .NET Framework 4.0
OS : Windows 2003 Server SP2, Windows 2008 Server
II
Supported Models
NET-i ware (The latest release version : 1.37)
SNB-7000/5000/3002/3000/2000/1000/1001, SNZ-5200, SNO-7080R/5080R/1080R
Box
SNC-B2335/B2331/M300/1300/550/570
Network
Camera
Encoder
SND-7080/5080(F)/3082/3080(F)/3080C(F)/1010/1080/1011
Dome
SNV-7080/5080/3080/5010/3120/5080R/3082/1080/1080R
SND-560/460V, SNC-B5368/B5399
SNP-5200(H)/3430H/3370(TH)/3301(H)/3120(V/VH)/3302(H)/SNP-6200(H)
PTZ
SNC-C6225/C7225/C7478, SNP-3300A/1000A/3750/3350
SNS-400/100/101, SPE-400/100, SPE-1600R
) above
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
53
Page 55
157.0 (6.18”) 168.0 (6.61”)
168.0 (6.61”)
35.0 (1.38”)
127.0 (5”)
79.0 (3.11”)48.0 (1.89”)
Network Video Recorder
SRN-6450/3250/1670D/470D
Network Camera
Network
PC
Network Controller
SPC-2000
CMS Program
SPC-2000
Network Controller
• Superior system compatibility
• 3D joystick control
• Quick and easy installation
• NET-i viewer support
Dimensions
35.0 (1.38")
Unit : mm (inch)
Technical SpecificationsKey Features
PTZ Control
Interface
Voltage
Operating Temperature
Operating Humidity
Dimensions (WxHxD)
Weight
SPC-2000
Joystick (3-axis twist zoom)
USB 2.0, DirectX
5V DC, 32mA (USB)
-25°C ~ +70°C (-13°F ~ +158°F)
10% ~ 70%
157.0 x 127.0 x 168.0mm (6.18" x 5" x 6.61")
440g (0.97 lb)
157.0 (6.18") 168.0 (6.61")
System Configuration
REVISED 09-2011
168.0 (6.61")
127.0 (5")
48.0 (1.89") 79.0 (3.31")
54
Page 56
Page 57
Core Analogue DSP Technology
CCTV systems requirements depend upon the application where they will be installed. Samsung has provided their CCTV Cameras
with a useful set of functions integrated into the DSPs. There are three types of DSPs, SV-V, A1, and W-V, which Samsung have
equipped with these core features.
The SV-V DSP chipset feature state-of-the-art
technologies to provide the maximum benefit
for video surveillance. Providing a powerful tool
to en sure that u sers achieve the ma ximum
benefit from surveillance systems deployed in
a wide range of applicati on s in cl ud in g; c ar
par ks , industrial esta te s, petrol f orecourts ,
schools, hospitals, retail parks, airports and
ports.
1
600TV lines
7
VPS (Virtual
Progressive Scan)
(Samsung Super Dynamic Range)
8 9
Polygonal Mask
The A1 DSP chipset features state-of-the-art
technologies similar to the SV-V DSP to provide
the maximum benefit for video surveillance. It
provides a powerful tool to ensure that users
achieve maximum benefit from surveillance
systems deployed for a wide range of
applications including car parks, industrial
estates, petrol forecourts, schools, hospitals,
retail parks, airports and ports.
SSDR
XDR
(eXtended Dynamic Range)
(Samsung Super Noise ReductionIII)
Motion Adaptive DNR
(Motion Adaptive
Digital Noise Reduction)
Camera Control
via
Coaxial Cable
Samsung's 5th generation DSP is the engine
that brings out the best from the basic
performing CCTV camera. This unique DSP
provides such advanced features as 2D/3D
noise filtering and digital image stabilization to
enhance the image quality and other essential
functions for effective video surveillance.
62 43 5
SSNRIII
DIS
(Digital Image
Stabilization)
10 10
Intelligent Video
Analytics
(Fixed/Moved/Area/
Fence/Tracking/
Detection/Counting)
Intelligent Video
Analytics
(Fixed/Moved/Area/
Fence/Tracking/
Detection)
56
Page 58
1 7
600TV lines
The cameras equipped with A1, SV-V, and W-V DSP chipset all deliver superb
image clarity and detail for all applications.
Conventional Camera 600TV lines Interlace Transmission (Delayed edge) VPS Transmission (Clear edge)
Virtual Progressive Scan
Virtual progressive scan provides a flawless clean frame every time, thus preventing
motion artifacts spoiling the quality of video from fast moving objects.
NETWORK
2
SSDR (Samsung Super Dynamic Range)
The SSDR function is useful in high contrast or backlight scene. Automatically lighten
the dark areas within a scene whilst maintaining the brighter areas at the same level.
This ensures that the dark areas become more visible allowing the operator to view
objects in the shadows.
SSDR Off SSDR On
3
XDR (eXtended Dynamic Range)
The XDR function is useful in high contrast or backlight scene. Automatically lighten
the dark areas within a scene whilst maintaining the brighter areas at the same level.
This ensures that the dark areas become more visible allowing the operator to view
objects in the shadows.
XDR Off XDR On
4
SSNRIII (Samsung Super Noise ReductionIII)
The 3rd generation of SSNR can be used in low light condition to enhance the image
quality. Thi s technolog y e liminates imag e n oise in low li ght conditions wi tho ut
creating image blur or ghosting.
8
Polygonal Mask
The SV-V/A1 cameras support polygonal shaped privacy masks so that it efficiently
prev ents inv asi on of pr iva cy under va rious su rve illance env iro nme nts, wit hou t
masking too much of the scene.
Polygonal Masking Off Polygonal Masking On
9
Camera Control via Coaxial Cable
This function enables access to the camera menu settings without connecting any
other control cables to the camera. This technology allows for camera set up (with
the exception of lens focus) to be performed remotely, thus simplifying the installation
process.
SV-V/A1 Cameras
Video Signal /
Control Signal
Control Signal
Video Signal
DVR (SRD series)
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
CAMERA
SSNRIII Off SSNRIII On
5
Motion Adaptive DNR
(Motion Adaptive Digital Noise Reduction)
The Motion Adaptive DNR function can be used in low light condition to enhance the
image quality. This technology eliminates image noise in low light conditions without
creating image blur or ghosting.
DNR Off DNR On
6
DIS (Digital Image Stabilization)
The DIS function helps to negate the effects of a camera shaking due to high winds
or building vibration.
DIS Off DIS On
Controller (SPC-300)
10
Intelligent Video Analytics
The Samsung SV-V/A1 s eries o f camer as , als o pro vi de buil t- in ca pa bility for
intelligent video analytics. Operational modes include :
• Fixed/Moved : The Fixed senses objects that appear and remain in a scene for
longer than a pre-determined period of time and the Moved detects objects removed
from a scene.
• Fence : Two modes can be set on the Fence function. Area mode provides a virtual
electronic area and the Line mode provides a virtual directional line on the scene
then generates an alarm in the event of a breach of that area or a crossing of the
directional line.
• Tracking : Tracks an object through a scene and generates an alarm in the event of
abnormal directional changes.
• Motion Detection : The Motion detection analyzes successive frames of video and
detects movement in the scene. Users can set the level of thresholds to prevent or
reduce false alarms and the camera can generate alert if the type or level of motion
crosses these thresholds.
• Counting : Provides a count of the objects passing in a pre-determined direction.
(SV-V)
SYSTEM
ACCESS CONTROL
57
Page 59
Analogue Camera Selection
Type Model Image
SCB-4000
SCB-3001
SCB-3000
SCB-2002
SCB-2001
SCB-2000
SCB-1000
SCB-3021
SCB-3020
Box
SCB-2010
SCZ-3430
SCZ-3370
SCZ-2370
SCZ-2250
SCO-2080
SCO-2120R
SCO-2080R
SCO-2080RH
SCD-3081
SCD-2081
SCD-3080
SCD-2080
SCD-2080E
SCD-2060E
SCD-2020
Dome
SCD-2040
SCD-2010
SCD-2010F
SCD-2080R
SCD-2020R
SCD-1020R
SCV-3120
Sensor
Min. Illumination Lens
0.1Lux@F1.2 (Color)
1/2"
0.01Lux@F1.2 (B/W)
0.1Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.3Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.1Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.05Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
1/3" 0.05Lux@F1.2 (Color) N/A N/A 600TVL (Color)
1/3" 0.05Lux@F1.2 (Color) N/A N/A 540TVL (Color)
4.3mm
1/3" 0.45Lux@F2.0
1/3" 0.45Lux@F2.0
1/3" 0.04Lux@F2.0
0.7Lux@F1.65 (Color)
1/4"
0.07Lux@F1.65 (B/W)
0.7Lux@F1.6 (Color)
1/4"
0.07Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.65 (Color)
1/4"
0.02Lux@F1.65 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
0.2Lux@F1.67 (Color)
1/4"
0Lux@F1.67 (LED on)
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
0.1Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.1Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.3Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
1/3" 0.15Lux@F1.2 (Color)
1/3" 0.15Lux@F1.2 (Color)
1/3" 0.04Lux@F1.2 (Color)
1/3" 0.04Lux@F1.2
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
1/4" 0Lux@F2.0 (LED on)
0.7Lux@F1.65 (Color)
1/4"
0.07Lux@F1.65 (B/W)
(Sens-up)
(Sens-up)
(Sens-up)
(Sens-up)
(Fixed)
3.7mm
(Fixed)
3mm
(Fixed)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
3.7mm
(Fixed)
8mm
(Fixed)
3mm
(Fixed)
3mm
(Fixed)
3.6mm
(Fixed)
3.6mm
(Fixed)
(Zoom)
Angular Field
of View
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
64.6°(H) / 46.6°(V) 600TVL (Color)
64.65°(H) / 48.49°(V) 600TVL (Color)
95°(H) / 71°(V) 600TVL (Color)
43x
61.22° ~ 1.47°(H)
47.16° ~ 1.1°(V)
37x
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
37x
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
25x
54.95° ~ 2.24°(H)
41.83° ~ 1.68°(V)
3.6x
94.4° ~ 28°(H)
(V/F)
69.2° ~ 21°(V)
12x
51.54° ~ 4.5°(H)
39.24° ~ 3.38°(V)
3.6x
94.4° ~ 28°(H)
(V/F)
69.2° ~ 21°(V)
3.6x
94.4° ~ 28°(H)
(V/F)
69.2° ~ 21°(V)
3.9x
(V/F)
3.9x
(V/F)
3.9x
(V/F)
3.6x
(V/F)
3.6x
(V/F)
2.4x
(V/F)
3.6x
(V/F)
94° ~ 26°(H)
67° ~ 20°(V)
94° ~ 26°(H)
67° ~ 20°(V)
94° ~ 26°(H)
67° ~ 20°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
103.4˚~ 46.6˚(H)
77.6˚ ~ 35.1˚(V)
71°(H) / 52°(V)
33°(H) / 25°(V)
71°(H) / 52°(V)
33°(H) / 25°(V)
95°(H) / 71°(V)
46°(H) / 34°(V)
89.5°(H) / 67.2°(V) 600TVL (Color)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
66°(H) / 49°(V)
56°(H) / 42°(V) 520TVL (Color) Auto N/A 46dB N/A N/A N/A 12V DC
12x
54.44° ~ 4.64°(H)
41.42° ~ 3.52°(V)
Resolution D&N WDR / BLC
600TVL (Color)
700TVL (B/W)
650TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
650TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
650TVL (Color)
700TVL (B/W)
650TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
600TVL (Color)
600TVL (Color)
600TVL (Color)
600TVL (Color)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
S/N
OSD MD
Ratio
ICR XDR / BLC 52dB Yes Yes Yes
WDR / SSDR
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
ICR XDR / BLC 52dB Yes Yes Yes
Electrical
HLC / BLC
Electrical
Electrical
WDR / BLC 52dB Yes Yes Yes 12V DC
Electrical
WDR / BLC 52dB Yes Yes Yes 12V DC
Electrical
HLC / BLC
WDR / XDR
ICR
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
ICR XDR / BLC 52dB Yes Yes Yes
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
Electrical
HLC / BLC
Electrical
HLC / BLC
Electrical
Electrical
Electrical
HLC / BLC
Electrical
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
WDR / XDR
ICR
52dB Yes Yes Yes
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
BLC 50dB Yes Yes Yes
SSDR
52dB Yes Yes Yes 12V DC
52dB Yes Yes Yes
BLC
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR 52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR 52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes 12V DC
SSDR
52dB Yes Yes Yes 12V DC
SSDR
52dB Yes Yes Yes 12V DC
SSDR
52dB Yes Yes Yes 12V DC
52dB Yes Yes Yes Dual (24V AC / 12V DC)
BLC
Privacy
Masking
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
12V DC, 230V AC
24V AC, 12V DC
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Power
230V AC
230V AC
230V AC
230V AC
230V AC
230V AC
12V DC
12V DC
12V DC
12V DC
58
Page 60
Analogue Camera Selection
Type Model Image
SCV-2120
SCV-3081
SCV-2081
SCV-3080
Dome
SCV-2080
SCV-2060
SCV-2010F
SCV-2081R
SCV-2080R
SCP-3430H
SCP-2430H
SCP-3370TH/
3370H
SCP-3370
SCP-2370TH/
2370H
SCP-2370
SCP-2330H
SCP-2330
PTZ
SCP-2270H
SCP-2270
SCP-2250H
SCP-2250
SCP-3120
SCP-3120VH
SCP-2120
SCU-2370
SCB-6000
HD
CCTV
SCD-6080
SUB-2000
SUD-3080/
UTP
3080F
SUD-2080/
2080F
SCB-9051
Thermal
SCB-9050
Sensor
Min. Illumination Lens
0.2Lux@F1.67 (Color)
1/4"
0.02Lux@F1.67 (B/W)
0.3Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
0.3Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
1/3" 0.04Lux@F1.2
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
0.15Lux@F1.2 (Color)
1/3"
0Lux@F1.2 (LED on)
0.7Lux@F1.65 (Color)
1/4"
0.07Lux@F1.65 (B/W)
0.2Lux@F1.65 (Color)
1/4"
0.02Lux@F1.65 (B/W)
0.7Lux@F1.6 (Color)
1/4"
0.07Lux@F1.6 (B/W)
0.7Lux@F1.6 (Color)
1/4"
0.07Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.6 (Color)
1/4"
0.02Lux@F1.6 (B/W)
0.2Lux@F1.65 (Color)
1/4"
0.02Lux@F1.65 (B/W)
0.2Lux@F1.65 (Color)
1/4"
0.02Lux@F1.65 (B/W)
0.7Lux@F1.65 (Color)
1/4"
0.07Lux@F1.65 (B/W)
0.7Lux@F1.65 (Color)
1/4"
0.07Lux@F1.65 (B/W)
0.2Lux@F1.67 (Color)
1/4"
0.004Lux@F1.67 (B/W)
0.2Lux@F1.65 (Color)
1/4"
0.02Lux@F1.65 (B/W)
1Lux@F1.2 (Color)
1/3"
0.1Lux@F1.2 (B/W)
1Lux@F1.2 (Color)
1/3"
0.1Lux@F1.2 (B/W)
1/3" 0.05Lux@F1.2 (Color) N/A N/A 600TVL (Color)
0.3Lux@F1.2 (Color)
1/3"
0.01Lux@F1.2 (B/W)
0.15Lux@F1.2 (Color)
1/3"
0.001Lux@F1.2 (B/W)
QVGA 0Lux
QVGA 0Lux
(Sens-up)
(Zoom)
3mm
(Fixed)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
(Zoom)
50mm
(Fixed)
14mm
(Fixed)
Angular Field
12x
3.9x
(V/F)
3.6x
(V/F)
3.9x
(V/F)
3.6x
(V/F)
2.4x
(V/F)
3.6x
(V/F)
3.6x
(V/F)
43x
43x
37x
37x
37x
37x
33x
33x
27x
27x
25x
25x
12x
12x
12x
37x
N/A N/A 1920 x 1080 ICR
2.8x
(V/F)
3.9x
(V/F)
3.6x
(V/F)
of View
51.54° ~ 4.5°(H)
39.24° ~ 3.38°(V)
94° ~ 26°(H)
67° ~ 20°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
102° ~ 28°(H)
73° ~ 21°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
103.4˚~ 46.6˚(H)
77.6˚ ~ 35.1˚(V)
89.5°(H) / 67.2°(V) 600TVL (Color)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
61.22° ~ 1.47°(H)
47.16° ~ 1.1°(V)
61.22° ~ 1.47°(H)
47.16° ~ 1.1°(V)
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
55.5° ~ 1.77°(H)
42.5° ~ 1.33°(V)
55.5° ~ 1.77°(H)
42.5° ~ 1.33°(V)
55.5° ~ 2.24°(H)
42.5° ~ 1.79°(V)
55.5° ~ 2.24°(H)
42.5° ~ 1.79°(V)
54.95° ~ 2.24°(H)
41.83° ~ 1.68°(V)
54.95° ~ 2.24°(H)
41.83° ~ 1.68°(V)
54.44° ~ 4.64°(H)
41.42° ~ 3.52°(V)
54.44° ~ 4.64°(H)
41.42° ~ 3.52°(V)
51.54° ~ 4.49°(H)
39.28° ~ 3.39°(V)
55.5° ~ 1.59°(H)
42.5° ~ 1.19°(V)
105° ~ 36.9°(H)
58° ~ 20.8°(V)
102° ~ 28°(H)
73° ~ 21°(V)
94.4° ~ 28°(H)
69.2° ~ 21°(V)
8.6° ~ 6.5° 320 x 240 N/A N/A N/A Yes N/A N/A 24V AC
30.1° ~ 22.8° 320 x 240 N/A N/A N/A Yes N/A N/A 24V AC
Resolution D&N WDR / BLC
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
1920 x 1080 ICR
600TVL (Color)
700TVL (B/W)
600TVL (Color)
700TVL (B/W)
S/N
Ratio
SSDR
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
Electrical
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
WDR /XDR
ICR
ICR XDR / BLC 52dB Yes Yes Yes 24V AC
WDR / SSDR
ICR
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR
HLC / BLC
ICR XDR / BLC 52dB Yes Yes Yes 24V AC
ICR XDR / BLC 52dB Yes Yes Yes 24V AC
WDR / XDR
ICR
WDR / XDR
ICR
ICR
HLC / BLC
ICR
HLC / BLC
HLC / BLC
HLC / BLC
Electrical
HLC / BLC
WDR / SSDR
ICR
HLC / BLC
ICR
HLC / BLC
52dB Yes Yes Yes Dual (24V AC / 12V DC)
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes 12V DC
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes Dual (24V AC / 12V DC)
52dB Yes Yes Yes 24V AC
BLC
52dB Yes Yes Yes 24V AC
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
52dB Yes Yes Yes 24V AC
BLC
52dB Yes Yes Yes 24V AC
BLC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
52dB Yes Yes Yes 24V AC
SSDR
50dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
50dB Yes Yes Yes Dual (24V AC / 12V DC)
SSDR
52dB Yes Yes Yes
52dB Yes Yes Yes
SSDR
52dB Yes Yes Yes
OSD MD
Privacy
Masking
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
Dual (24V AC / 12V DC)
24V AC, 12V DC
24V AC, 12V DC
Power
24V AC
24V AC
24V AC
24V AC
28V AC
28V AC
28V AC
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
59
Page 61
64.0 (2.52")
100.0 (3.94") 9.2 (0.36")
58.0 (2.28")
SCB-4000
High Resolution Low Light Camera
600TVL
0.1Lux
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.1Lux@F1.2 (Color), 0.01Lux (B/W)
• True Day & Night (ICR), Intelligent video analytics, MD, DNR
• Coax : CCVC, RS-485, Dual power, 230V AC (High voltage type)
Dimensions
64.0 (2.52") 100.0 (3.94") 9.2 (0.36")
DUAL
POWER
230V AC
Unit : mm (inch)
Technical Specifications
SCB-4000N SCB-4000P SCB-4000PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/2" Ex-view HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
Manual / Auto iris (Video / DC)
C / CS
English, Japanese, Spanish,
French, Portuguese,
Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC / 3200K / 5600K
1/60 ~ 1/200,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Fixed / Moved, Fence (Line, Area)
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%) 230V AC ±10%
Max. 3.0W Max. 4.1W
Silver / Aluminum, Steel
64.0 x 58.0 x 100.0mm
(2.52" x 2.28" x 3.94")
305g (0.67 lb) 395g (0.87 lb)
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
64.0 x 58.0 x 129.2mm
(2.52" x 2.28" x 5.09")
REVISED 03-2012
58.0 (2.28")
60
Page 62
61.0 (2.4")
66.0 (2.6")
113.0 (4.45")
102.0 (4.02")
SCB-3001
Premium Resolution WDR Camera
650TVL
0.1Lux
128x
160x
D&N ICR
Key Features
• High resolution of 650TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.1Lux@F1.2 (Color), 0.01Lux (B/W)
• WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD
• SSNR
III
, Coax : Pelco-C (Coaxitron),
RS-485, Dual power, 230V AC (High voltage type)
Dimensions
DUAL
POWER
230V AC
Unit : mm (inch)
Technical Specifications
SCB-3001N SCB-3001P SCB-3001PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
Intelligent Video Analytics
VPS
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
1,028(H) x 508(V) 1,028(H) x 596(V)
976(H) x 494(V) 976(H) x 582(V)
2 : 1 Interlace
Internal / Line lock / Extern
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 650TV lines, B/W : 700TV lines
Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
Manual / Auto iris (Video / DC)
C / CS
English, Japanese, Spanish,
French, Portuguese,
Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / User BLC / HLC / SSDR / WDR
128x 160x
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev
Basic / Day & Night / Backlight / ITS / Indoor / User
Fixed / Moved / Fence / Tracking / Detection / Counting
Off / On
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%) 230V AC ±10%
Max. 4.0W Max. 4.2W
Black, Silver / Aluminum, Steel
66.0 x 61.0 x 102.0mm (2.6" x 2.4" x 4.02")
310g (0.68 lb) 540g (1.19 lb)
II
(Double scan)
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
66.0 x 61.0 x 115.0mm (2.6" x 2.4" x 4.53")
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
REVISED 03-2012
66.0 (2.6")
102.0 (4.02")
113.0 (4.45")
61.0 (2.4")
SYSTEM
ACCESS CONTROL
61
Page 63
SCB-3000
61.0 (2.4")
66.0 (2.6")
113.0 (4.45")
102.0 (4.02")
High Resolution WDR Camera
600TVL
0.3Lux
128x
160x
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.3Lux@F1.2 (Color), 0.01Lux (B/W)
• WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD
• SSNR
III
, Coax : Pelco-C (Coaxitron),
RS-485, Dual power, 230V AC (High voltage type)
Dimensions
DUAL
POWER
230V AC
Unit : mm (inch)
Technical Specifications
SCB-3000N SCB-3000P SCB-3000PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
Intelligent Video Analytics
VPS
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD (Double scan)
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock / Extern
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.3Lux@F1.2 (50IRE), 0.0006Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
Manual / Auto iris (Video / DC)
C / CS
English, Japanese, Spanish,
French, Portuguese,
Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / User BLC / HLC / SSDR / WDR
128x 160x
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev
Basic / Day & Night / Backlight / ITS / Indoor / User
Fixed / Moved / Fence / Tracking / Detection / Counting
Off / On
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%) 230V AC ±10%
Max. 4.0W Max. 4.2W
Black, Silver / Aluminum, Steel
66.0 x 61.0 x 102.0mm (2.6" x 2.4" x 4.02")
310g (0.68 lb) 540g (1.19 lb)
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
66.0 x 61.0 x 115.0mm (2.6" x 2.4" x 4.53")
REVISED 03-2012
66.0 (2.6")
61.0 (2.4")
102.0 (4.02")
113.0 (4.45")
62
Page 64
61.0 (2.4")
66.0 (2.6")
113.0 (4.45")
102.0 (4.02")
SCB-2002
Premium Resolution Camera
650TVL
0.1Lux
D&N ICR
Key Features
• High resolution of 650TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.1Lux@F1.2 (Color), 0.01Lux (B/W)
• True Day & Night (ICR), MD
• SSNR
III
, Coax : Pelco-C (Coaxitron),
RS-485, Dual power, 230V AC (High voltage type)
Dimensions
DUAL
POWER
230V AC
Unit : mm (inch)
Technical Specifications
SCB-2002N SCB-2002P SCB-2002PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
1,028(H) x 508(V) 1,028(H) x 596(V)
976(H) x 494(V) 976(H) x 582(V)
2 : 1 Interlace
Internal / Line lock / Extern
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 650TV lines, B/W : 700TV lines
Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
Manual / Auto iris (Video / DC)
C / CS
English, Japanese, Spanish,
French, Portuguese,
Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / User BLC / HLC / SSDR
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev
Basic / Day & Night / Backlight / ITS / Indoor / User
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE, AD
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%) 230V AC ±10%
Max. 4.2W Max. 4.5W
Black, Silver / Aluminum, Steel
66.0 x 61.0 x 102.0mm (2.6" x 2.4" x 4.02")
310g (0.68 lb) 540g (1.19 lb)
II
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
66.0 x 61.0 x 115.0mm (2.6" x 2.4" x 4.53")
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
FIRST EDITION 03-2012
66.0 (2.6")
102.0 (4.02")
113.0 (4.45")
61.0 (2.4")
SYSTEM
ACCESS CONTROL
63
Page 65
SCB-2001
64.0 (2.52")
100.0 (3.94") 9.2 (0.36")
58.0 (2.28")
High Resolution Camera
600TVL
0.05Lux
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.05Lux@F1.2 (Color), 0.01Lux (B/W)
• True Day & Night (ICR), Intelligent video analytics, MD, DNR
• Coax : CCVC, RS-485, Dual power, 230V AC (High voltage type)
Dimensions
DUAL
POWER
230V AC
Unit : mm (inch)
Technical Specifications
SCB-2001N SCB-2001P SCB-2001PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Lens Type
Mount Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.05Lux@F1.2 (50IRE), 0.0001Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
Manual / Auto iris (Video / DC)
C / CS
English, Japanese, Spanish,
French, Portuguese,
Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/200,000sec 1/50 ~ 1/200,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Fixed / Moved, Fence (Line, Area)
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%) 230V AC ±10%
Max. 3.0W Max. 4.1W
Silver / Aluminum, Steel
64.0 x 58.0 x 100.0mm
(2.52" x 2.28" x 3.94")
305g (0.67 lb) 395g (0.87 lb)
II
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
64.0 x 58.0 x 129.2mm
(2.52" x 2.28" x 5.09")
REVISED 03-2012
64.0 (2.52") 100.0 (3.94") 9.2 (0.36")
58.0 (2.28")
* The latest product information / specification can be found at www.samsungsecurity.com
64
Page 66
121.0 (4.76")58.0 (2.28")
52.0 (2.05")
POWER
VIDEO
SET
CLASS 2 ONLY
1 --- 2 AC24V
+ --- -- DC12V
POWER
VIDEO
SET
POWER INLET
SCB-2000
High Resolution Camera
600TVL
0.05Lux
Key Features
• High resolution of 600TV lines
• Min. illumination 0.05Lux@F1.2 (Color)
• MD, SSNR
III
, Coax : Pelco-C (Coaxitron)
• Dual power, 12V DC, 230V AC (High voltage type)
Dimensions
58.0 (2.28")
DUAL
POWER
12V DC
230V AC
121.0 (4.76")
Unit : mm (inch)
52.0 (2.05")
Technical Specifications
SCB-2000N SCB-2000ND SCB-2000P SCB-2000PD SCB-2000PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
0.05Lux / 0.0001Lux (F1.2, Sens-up 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
LENS
Lens Type
Mount Type
Manual / Auto iris (Video / DC)
C / CS
OPERATIONAL
English, Japanese, Spanish,
On Screen Display
French, Portuguese, Taiwanese,
Korean
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
On / Off (Displayed 15 characters)
Auto (Electrical) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
III
(Off / On)
SSNR
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On), V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
ENVIRONMENTAL
Operating Temperature / Humidity
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
ELECTRICAL
Input Voltage / Current
Power Consumption
Dual (24V AC &
12V DC ±10%)
Max. 3.5W Max. 2.5W Max. 3.5W Max. 2.5W Max. 4.0W
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
Black & Dark gray / Aluminum, Steel
58.0 x 52.0 x 121.0mm (2.28" x 2.05" x 4.76")
340g (0.75 lb) 310g (0.68 lb) 340g (0.75 lb) 310g (0.68 lb) 510g (1.12 lb)
II
Internal
12V DC ±10%
Internal / Line lock
English, French, German, Spanish, Italian, Chinese,
Russian, Polish, Czech, Romanian, Serbian, Swedish,
Danish, Turkish, Portuguese
Dual (24V AC &
12V DC ±10%)
Internal
Internal / Line lock
12V DC ±10% 230V AC ±10%
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
FIRST EDITION 03-2011
65
Page 67
POWER
LENS
DC VIDEO
VIDEO
SET UP
POWER INLET
POWER
LENS
DC VIDEO
VIDEO
SET UP
AC 24V GND
POWER
LENS
DC VIDEO
VIDEO
SET UP
DC 12V GND
+
-
121.0 (4.76")58.0 (2.28")
52.0 (2.05")
SCB-1000
High Resolution Camera
540TVL
0.05Lux
Key Features
• High resolution of 540TV lines
• Min. illumination 0.05Lux@F1.2 (Color)
• MD, SSNR, 24V AC, 12V DC, 230V AC (High voltage type)
Dimensions
24V AC
12V DC
230V AC
Unit : mm (inch)
52.0 (2.05")
Technical Specifications
SCB-1000NA SCB-1000ND SCB-1000PA SCB-1000PD SCB-1000PH
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 540TV lines
0.05Lux / 0.0004Lux (F1.2, Sens-up, 128x)
50dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
LENS
Lens Type
Mount Type
Manual / Auto iris (Video / DC)
C / CS
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
SSNR (Digital Noise Reduction)
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Mirror
Built-in
Off / On (Displayed 15 characters)
Auto (Electrical) / On
Low / Middle / High / Off
Low / Middle / High / Off
Off / On (4 programmable zones)
Off / On (4 programmable zones)
2x ~ 128x
Low / Middle / High / Off
ATW / Manual / AWC (1,800K° ~ 10,500K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On
ENVIRONMENTAL
Operating Temperature / Humidity
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
ELECTRICAL
Input Voltage / Current
Power Consumption
24V AC ±10% 12V DC ±10% 24V AC ±10% 12V DC ±10% 230V AC ±10%
Max. 3.5W Max. 2.5W Max. 3.5W Max. 2.5W Max. 4.0W
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
Light silver / Aluminum, Steel
58.0 x 52.0 x 121.0mm (2.28" x 2.05" x 4.76")
340g (0.75 lb) 310g (0.68 lb) 340g (0.75 lb) 310g (0.68 lb) 510g (1.12 lb)
II
Internal
Internal / Line lock
Internal
Internal / Line lock
REVISED 08-2011
58.0 (2.28")
121.0 (4.76")
66
Page 68
48.5 (1.91")
44.5 (1.75")
20.1 (0.79")
27.6 (1.09")
40.2 (1.58")
50.2 (1.98")
53.3 (2.1")
44.5 (1.75")
SCB-3021/3020
High Resolution WDR ATM Camera
600TVL
0.45
Lux
4.3/3.7mm
Key Features
• High resolution of 600TV lines
• Min. illumination 0.45Lux@F2.0 (Color) : SCB-3021/3020
• Built-in 4.3mm fixed lens : SCB-3021
3.7mm fixed lens : SCB-3020
• WDR, VPS, Intelligent video analytics, MD, DNR
• Coax : CCVC, 12V DC
Dimensions
50.2 (1.98")
44.5 (1.75")
53.3 (2.1")
44.5 (1.75")
128x
160x
12VDC
20.1 (0.79")
Unit : mm (inch)
Technical Specifications
SCB-3021N/3020N SCB-3021P/3020P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD (Double scan)
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock (L-Pulse input)
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.45Lux@F2.0 (50IRE, Sens-up 2x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
4.3mm : SCB-3021, 3.7mm : SCB-3020
F2.0
D : 70.9° / H : 55.3° / V : 40.9° : SCB-3021
D : 80.81° / H : 64.65° / V : 48.49° : SCB-3020
0.4m (1.31ft)
Multi-language support
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto
Off / On
128x 160x
Off / Low / Mid / High
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones, polygonal type)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/200,000sec 1/50 ~ 1/200,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Off / On
Fixed / Moved, Fence (Line, Area)
Off / On
1 Output
Coaxial control (SPC-300 compatible)
Coax : CCVC
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 2.0W
Black / Aluminum
50.2 x 53.3 x 40.2mm (1.98" x 2.1" x 1.58")
105g (0.23 lb)
Multi-language support
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
48.5 (1.91")
27.6 (1.09")
40.2 (1.58")
67
Page 69
52.0 (2.05")
52.0 (2.05")
81.4 (3.2")
SCB-2010
High Resolution Small Box Camera
600TVL
Key Features
• High resolution of 600TV lines
• Min. illumination 0.04Lux@F2.0 (Color)
• Built-in 3mm fixed lens
• MD, SSNR
• Coax : Pelco-C (Coaxitron), 12V DC
Dimensions
0.04Lux
III
3mm
12VDC
Unit : mm (inch)
Technical Specifications
SCB-2010N SCB-2010P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Dynamic Range
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.04Lux (50IRE@F1.2, Sens-up 2x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3mm
F2.0
H : 95° / V : 71°
0.4m (1.31ft)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
On / Off (Displayed 15 characters)
Auto (Electric) / Color / B/W
Off / User BLC / HLC / SSDR
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On), V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 1.8W
Ivory / Plastic
52.0 x 52.0 x 40.4 mm (2.05" x 2.05" x 1.59") (Without Bracket)
52.0x 52.0 x 81.4 mm (2.05" x 2.05" x 3.2") (With Bracket)
95g (0.21 lb) (With Bracket)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
FIRST EDITION 03-2011
52.0 (2.05")
52.0 (2.05") 81.4 (3.2")
68
Page 70
144.2 (5.68")
154.5 (6.08")
59.0 (2.32")
59.0 (2.32")
SCZ-3430
High Resolution 43x Zoom Camera
600TVL
0.7Lux
43x
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines(B/W)
• Min. illumination 0.7Lux@F1.65 (Color), 0.07Lux (B/W)
• Powerful 43x zoom (3.2 ~ 138.5mm), Digital 16x
•
WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD, DNR
• Coax : CCVC, RS-485, Dual power, 12V DC
Dimensions
59.0 (2.32")
144.2 (5.68")
154.5 (6.08")
59.0 (2.32")
DUAL
POWER
12V DC
Unit : mm (inch)
Technical Specifications
SCZ-3430N SCZ-3430ND SCZ-3430P SCZ-3430PD
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD CCD (Double scan)
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock Internal Internal / Line lock Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.7Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.65 (50IRE), 0.0002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.2 ~ 138.5mm (Optical 43x)
1: 1.65(Wide) ~ 3.7(Tele)
H : 61.22°(Wide) ~ 1.47°(Tele) / V : 47.16°(Wide) ~ 1.1°(Tele)
1m (3.28ft)
Auto / Manual / One AF
3.2sec (Wide to tele)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
128x 160x
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Off / On : SCZ-3430
Fixed / Moved
Off / On
Day / Time
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC &
12V DC ±10%)
Max. 5.6W Max. 4.2W Max. 5.6W Max. 4.2W
Silver / Aluminum, Steel
59.0 x 59.0 x 144.2mm
(2.32" x 2.32" x 5.68")
564g (1.24 lb) 421g (0.93 lb) 564g (1.24 lb) 421g (0.93 lb)
12V DC ±10%
59.0 x 59.0 x 113.9mm
(2.32" x 2.32" x 4.48")
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
Dual (24V AC &
12V DC ±10%)
59.0 x 59.0 x 144.2mm
(2.32" x 2.32" x 5.68")
: SCZ-3430
: SCZ-3430
12V DC ±10%
59.0 x 59.0 x 113.9mm
(2.32" x 2.32" x 4.48")
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
69
Page 71
67.6 (2.66")
118.5 (4.67")
67.6 (2.66")
142.5 (5.61")
67.6 (2.66")
118.5 (4.67")
67.6 (2.66")
67.6 (2.66")
67.6 (2.66")
67.6 (2.66")
144.3 (5.68")
67.6 (2.66")
67.6 (2.66")
122.2 (4.81")
67.6 (2.66")
SCZ-3370/2370
High Resolution 37x Zoom Camera
SCZ-3370
SCZ-2370
600TVL
0.7Lux
0.2Lux
37x
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.7Lux@F1.6 (Color), 0.07Lux (B/W) : SCZ-3370
0.2Lux@F1.6 (Color), 0.02Lux (B/W) : SCZ-2370
• Powerful 37x zoom (3.5 ~ 129.5mm), Digital 16x
• WDR, VPS, Intelligent video analytics : SCZ-3370
•True Day & Night (ICR), SSNRIII
• Coax : Pelco-C (Coaxitron), RS-485, Dual power, 12V DC
Dimensions
SCZ-3370
67.6 (2.66")
SCZ-2370
67.6 (2.66")
67.6 (2.66")
POWER
12V DC
142.5 (5.61")
144.3 (5.68")
DUAL
Unit : mm (inch)
Technical Specifications
SCZ-3370N/2370N
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Flip / Mirror (Reverse)
Profile
VPS
Intelligent Video Analytics
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD CCD (Double scan) : SCZ-3370, 1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace, Progressive
Internal / Line lock Internal Internal / Line lock Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.7Lux@F1.6 (50IRE), 0.001Lux (Sens-up, 512x)
0.2Lux@F1.6 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.6 (50IRE), 0.0001Lux (Sens-up, 512x)
0.02Lux@F1.6 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.5 ~ 129.5mm (Optical 37x)
1 : 1.72(Wide) ~ 3.94(Tele)
H : 55.5°(Wide) ~ 1.59°(Tele) / V : 42.5°(Wide) ~ 1.19°(Tele)
1.5m (4.92ft)
Auto / Manual / One shot
2.8sec (Wide to tele)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / HLC / BLC / WDR : SCZ-3370, Off / HLC / BLC : SCZ-2370
128x : SCZ-3370 160x : SCZ-3370
SSDR (Off / On)
III
(Off/ Low / Medium / High)
SSNR
Off / On
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev : SCZ-3370, H-Rev (Off / On) / V-Rev (Off / On) : SCZ-2370
Basic / Day & Night / Backlight / ITS / Indoor / User : SCZ-3370
Off / On : SCZ-3370
Fixed / Moved / Motion Detection / Tracking / Fence / Counting : SCZ-3370
1 Out : SCZ-3370
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC &
12V DC ±10%)
Max. 6.1W : SCZ-3370
Max. 4.8W : SCZ-2370
Black, Silver / Aluminum : SCZ -3370, Black, Silver / Plastic, Steel : SCZ-2370
67.6 x 67.6 x 142.5mm
(2.66" x 2.66" x 5.61")
: SCZ-3370N
67.6 x 67.6 x 144.3mm
(2.66" x 2.66" x 5.68")
: SCZ-2370N
500g (1.1 lb)
: SCZ-3370N
520g (1.15 lb)
: SCZ-2370N
SCZ-3370ND/2370ND
12V DC ±10%
Max. 4.7W : SCZ-3370
Max. 4.8W : SCZ-2370
67.6 x 67.6 x 118.5mm
(2.66" x 2.66" x 4.67")
: SCZ-3370ND
67.6 x 67.6 x 122.3mm
(2.66" x 2.66" x 4.81")
: SCZ-2370ND
410g (0.9 lb)
: SCZ-3370ND
415g (0.91 lb)
: SCZ-2370ND
SCZ-3370P/2370P
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
Dual (24V AC &
12V DC ±10%)
Max. 6.1W : SCZ-3370
Max. 4.8W : SCZ-2370
67.6 x 67.6 x 142.5mm
(2.66" x 2.66" x 5.61")
: SCZ-3370P
67.6 x 67.6 x 144.3mm
(2.66" x 2.66" x 5.68")
: SCZ-2370P
500g (1.1 lb)
: SCZ-3370P
520g (1.15 lb)
: SCZ-2370P
SCZ-3370PD/2370PD
: SCZ-3370
: SCZ-2370
: SCZ-3370
: SCZ-2370
12V DC ±10%
Max. 4.7W : SCZ-3370
Max. 4.8W : SCZ-2370
67.6 x 67.6 x 118.5mm
(2.66" x 2.66" x 4.67")
: SCZ-3370PD
67.6 x 67.6 x 122.3mm
(2.66" x 2.66" x 4.81")
: SCZ-2370PD
410g (0.9 lb)
: SCZ-3370PD
415g (0.91 lb)
: SCZ-2370PD
II
: SCZ-2370
REVISED 03-2012
67.6 (2.66")
70
Page 72
SCZ-2250
59.0 (2.32")
59.0 (2.32")
144.2 (5.68")
154.5 (6.08")
High Resolution 25x Zoom Camera
600TVL
0.2Lux
25x
D&N ICR
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.65 (Color), 0.02Lux (B/W)
• Powerful 25x zoom (3.66 ~ 91.36mm), Digital 16x
• True Day & Night (ICR), Intelligent video analytics, MD, DNR
• Coax : CCVC, RS-485, Dual power, 12V DC
Dimensions
59.0 (2.32")
59.0 (2.32")
144.2 (5.68")
154.5 (6.08")
DUAL
POWER
12V DC
Unit : mm (inch)
Technical Specifications
SCZ-2250N SCZ-2250ND SCZ-2250P SCZ-2250PD
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
Intelligent Video Analytics
PIP
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock Internal Internal / Line lock Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.2Lux@F1.65 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.65 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.66 ~ 91.36mm (Optical 25x)
1 : 1.65(Wide) ~ 3.0(Tele)
H : 54.95°(Wide) ~ 2.24°(Tele) / V : 41.83°(Wide) ~ 1.68°(Tele)
1m (3.28ft)
Auto / Manual / One AF
2.9sec (Wide to tele)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Fixed / Moved
Off / On
Day / Time
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC &
12V DC ±10%)
Max. 5.6W Max. 4.2W Max. 5.6W Max. 4.2W
Silver / Aluminum, Steel
59.0 x 59.0 x 144.2mm
(2.32" x 2.32" x 5.68")
564g (1.24 lb) 421g (0.93 lb) 564g (1.24 lb) 421g (0.93 lb)
II
12V DC ±10%
59.0 x 59.0 x 113.9mm
(2.32" x 2.32" x 4.48")
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
Dual (24V AC &
12V DC ±10%)
59.0 x 59.0 x 144.2mm
(2.32" x 2.32" x 5.68")
12V DC ±10%
59.0 x 59.0 x 113.9mm
(2.32" x 2.32" x 4.48")
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
REVISED 03-2012
SYSTEM
ACCESS CONTROL
71
Page 73
Ø77.0 (3.03") 284.0 (11.18")
SCO-2080
High Resolution Weatherproof Camera
600TVL
0.15
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.15Lux@ F1.2 (Color), 0.001Lux (B/W)
• Built-in V/F lens (2.8 ~ 10mm)
• True Day & Night (ICR), MD, SSNR
• IP66, Coax : Pelco-C (Coaxitron), RS-485, Dual power
Dimensions
Lux
3.6x
V/F Lens
D&N ICR
III
Unit : mm (inch)
Technical Specifications
SCO-2080N SCO-2080P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Dynamic Range
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0.001Lux@F1.2 (50IRE), 0.000002Lux (Sens-up 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4°(Wide) ~ 28°(Tele) / V : 69.2°(Wide) ~ 21°(Tele)
0.2m (0.66ft)
Manual
DC auto iris
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
On / Off (Displayed 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On), V-Rev (Off / On)
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 3.8W
Dark gray / ALDC
Ø77.0 x 216.0mm (Ø3.03" x 8.5") (Bracket angle 90°), 284.0mm (11.18") (Bracket angle 180°)
955g (2.11 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
Ø77.0 (3.03") 284.0 (11.18")
FIRST EDITION 03-2011
72
Page 74
Ø77.0 (3.03") 314.1 (12.37")
SCO-2120R
High Resolution 12x Weatherproof IR Camera
600TVL
0Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0Lux (IR LED On), IR distance 70m
• Powerful 12x zoom (3.94 ~ 46.05mm), Digital 16x
• True Day & Night (ICR), MD, SSNR
• IP66, Coax : Pelco-C (Coaxitron), RS-485, Dual power
Dimensions
12x
D&N ICR
III
Unit : mm (inch)
Technical Specifications
SCO-2120RN SCO-2120RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Dynamic Range
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.2Lux@F1.67 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0Lux (IR LED on)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.94 ~ 46.05mm (Optical 12x)
1 : 1.67(Wide) ~ 1.88(Tele)
H : 51.54°(Wide) ~ 4.5°(Tele) / V : 39.24°(Wide) ~ 3.38°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
1.9sec (Wide to tele)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
On / Off (Displayed 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / On
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD
70m (850nm IR LED : 31ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 6.8W / 6.5W (IR LED on)
Dark gray / ALDC
Ø77.0 x 274.7mm (Ø3.03" x 10.81") (Bracket angle 90°), 314.1mm (12.37") (Bracket angle 180°)
1.2Kg (2.65 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
Ø77.0 (3.03") 314.1 (12.37")
FIRST EDITION 03-2011
SYSTEM
ACCESS CONTROL
73
Page 75
Ø77.0 (3.03") 284.0 (11.18")
SCO-2080R/2080RH
220.0 (8.66")
353.0 (13.90")
383.0 (15.08")
103.0 (4.06")
Ø92.0 (3.62")
Ø103.0 (4.06")
114.0 (4.49")
High Resolution Weatherproof IR Camera
SCO-2080R
SCO-2080RH
Ø103.0 (4.06")
V/F Lens
114.0 (4.49")
3.6x
D&N ICR
III
284.0 (11.18")
220.0 (8.66")
353.0 (13.90")
383.0 (15.08")
Unit : mm (inch)
600TVL
0Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0Lux (IR LED On), IR distance 50m
• Built-in V/F lens (2.8 ~ 10mm)
• True Day & Night (ICR), MD, SSNR
• IP66, Coax : Pelco-C (Coaxitron), RS-485, Dual power
Dimensions
SCO-2080R
Ø77.0 (3.03")
SCO-2080RH
Ø92.0 (3.62")
Ø103.0 (4.06")
FIRST EDITION 08-2011
Technical Specifications
SCO-2080RN/2080RHN SCO-2080RP/2080RHP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Dynamic Range
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature /
Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0Lux (IR LED 0n)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4°(Wide) ~ 28°(Tele) / V : 69.2°(Wide) ~ 21°(Tele)
0.2m (0.66ft)
Manual
DC auto iris
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
On / Off (Displayed 15 characters)
Auto (ICR) / Color / B/W
Off / BLC / HLC
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On), V-Rev (Off / On)
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
50m (850nm IR LED : 32ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH : SCO-2080R
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCO-2080RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 6.8W / 6.5W (IR LED on) : SCO-2080R
Max. 15W (Heater on), Max. 7.2W (Heater off) : SCO-2080RH
Dark gray / ALDC
Ø77.0 x 216.0mm (Ø3.03" x 8.5") (Bracket angle 90°), 284.0mm (11.18") (Bracket angle 180°) : SCO-2080R
Ø114.0 x 383.0 (Ø4.49" x 15.08") (Bracket angle 180°) : SCO-2080RH
1Kg (2.2 lb) : SCO-2080R, 1.7Kg (3.75 lb) : SCO-2080RH
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
74
Page 76
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
SCD-3081
Premium Resolution WDR Varifocal Dome Camera
SCD-3081 SCD-3081B
3.9x
V/F Lens
D&N ICR
III
Unit : mm (inch)
92.7 (3.65")
Ø115.8 (4.56")
650TVL
0.1Lux
Key Features
• High resolution of 650TV lines, 700TV lines (B/W)
• Min. illumination 0.1Lux@F1.2 (Color), 0.01Lux (B/W)
• 3.9x V/F lens (2.8 ~ 11mm), WDR, VPS, Intelligent video analytics
• True Day & Night (ICR), MD, SSNR
• Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Technical Specifications
SCD-3081N SCD-3081P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-3081B
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
1,028(H) x 508(V) 1,028(H) x 596(V)
976(H) x 494(V) 976(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 650TV lines, B/W : 700TV lines
Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94°(Wide) ~ 26°(Tele) / V : 67°(Wide) ~ 20°(Tele)
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / User BLC / HLC / SSDR / WDR
128x 160x
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev
Basic / Day & Night / Backlight / ITS / Indoor / User
Off / On
Fixed / Moved / Area / Fence / Tracking / Detection / Counting
Off / On
1 Out
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Plastic (Dome cover : Clear)
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
365g (0.8 lb)
II
(Double scan)
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
75
Page 77
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
SCD-2081
Premium Resolution Varifocal Dome Camera
SCD-2081 SCD-2081B
3.9x
V/F Lens
D&N ICR
III
Unit : mm (inch)
92.7 (3.65")
650TVL
0.1Lux
Key Features
• High resolution of 650TV lines, 700TV lines (B/W)
• Min. illumination 0.1Lux@F1.2 (Color), 0.01Lux (B/W)
• 3.9x V/F lens (2.8 ~ 11mm)
• True Day & Night (ICR), MD, SSNR
• Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Technical Specifications
SCD-2081N SCD-2081P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-2081B
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
1,028(H) x 508(V) 1,028(H) x 596(V)
976(H) x 494(V) 976(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 650TV lines, B/W : 700TV lines
Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94°(Wide) ~ 26°(Tele) / V : 67°(Wide) ~ 20°(Tele)
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 340°
0° ~ 73°
0° ~ 340°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Off / User BLC / HLC / SSDR
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev
Basic / Day & Night / Backlight / ITS / Indoor / User
Off / On
1 Out
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Plastic (Dome cover : Clear)
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
365g (0.8 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
FIRST EDITION 03-2012
Ø115.8 (4.56")
76
Page 78
SCD-3080/2080
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
High Resolution Varifocal Dome Camera
SCD-3080/2080 SCD-3080B/2080B
600TVL
0.3Lux
0.15
Key Features
• High resolution of 600TV lines, 700TV lines (B/W)
• Min. illumination 0.3Lux@F1.2 (Color), 0.01Lux (B/W) : SCD-3080
• 3.9x V/F lens (2.8 ~ 11mm) : SCD-3080
3.6x V/F lens (2.8 ~ 10mm) : SCD-2080
• WDR, VPS, Intelligent video analytics : SCD-3080
• True Day & Night (ICR) : SCD-3080/2080, MD, SSNR
• Coax : Pelco-C (Coaxitron), Dual power
Dimensions
3.9x
3.6x
Lux
V/F Lens
D&N ICR
0.15Lux@F1.2 (Color), 0.001Lux (B/W) : SCD-2080
III
Unit : mm (inch)
92.7 (3.65")
Ø115.8 (4.56")
Technical Specifications
SCD-3080N/2080N SCD-3080P/2080P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-3080B/2080B
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD (Double scan) : SCB-3080, 1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.3Lux@F1.2 (50IRE), 0.0006Lux (Sens-up, 512x) : SCD-3080
0.15Lux@F1.2 (50IRE) : 0.0003Lux (Sens-up, 512x) : SCD-2080
B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x) : SCD-3080
0.001Lux@F1.2 (50IRE), 0.000002Lux (Sens-up, 512x) : SCD-2080
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x) : SCD-3080, 2.8 ~ 10mm (3.6x) : SCD-2080
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94°(Wide) ~ 26°(Tele) / V : 67°(Wide) ~ 20°(Tele) : SCD-3080
H : 94.4°(Wide) ~ 28°(Tele) / V : 69.2°(Wide) ~ 21°(Tele) : SCD-2080
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W
Auto (ICR) / Color / B/W
Off / User BLC / HLC / SSDR / WDR : SCD-3080, BLC / HLC / Off : SCD-2080
128x : SCD-3080 160x : SCD-3080
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev : SCD-3080, H-Rev (Off / On) / V-Rev (Off / On) : SCD-2080
Basic / Day & Night / Backlight / ITS / Indoor / User : SCD-3080
Off / On : SCD-3080
Fixed / Moved / Area / Fence / Tracking / Detection / Counting : SCD-3080
Off / On : SCD-3080
1 Out : SCD-3080
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Plastic (Dome cover : Clear)
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
365g (0.8 lb) : SCD-3080, 345g (0.76 lb) : SCD-2080
: SCD-2080
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
: SCD-3080
II
: SCB-2080
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
77
Page 79
SCD-2080E/2060E
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
High Resolution Varifocal Dome Camera
SCD-2080E/2060E SCD-2080EB/2060EB
600TVL
0.15
Key Features
• High resolution of 600TV lines, 700TV lines (B/W)
• Min. illumination 0.15Lux@F1.2 (Color)
• 3.6x V/F lens (2.8 ~ 10mm) : SCD-2080E
2.4x V/F lens (2.5 ~ 6mm) : SCD-2060E
• MD, SSNR
III
• Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Lux
3.6x
2.4x
V/F Lens
Unit : mm (inch)
92.7 (3.65")
Technical Specifications
SCD-2080EN/2060EN SCD-2080EP/2060EP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-2080EB/2060EB
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x) : SCD-2080E, 2.5 ~ 6mm (2.4x) : SCD-2060E
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4°(Wide) ~ 28°(Tele) / V : 69.2°(Wide) ~ 21°(Tele) : SCD-2080E
H : 103.4˚(Wide) ~ 46.6˚(Tele) / V : 77.6˚(Wide) ~ 35.1˚(Tele) : SCD-2060E
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (Electrical ) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Plastic (Dome cover : Clear)
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
345g (0.76 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
REVISED 03-2012
Ø115.8 (4.56")
78
Page 80
83.7 (3.3")
83.7 (3.3")
Ø107.6 (4.24")
SCD-2020/2040
High Resolution Small Dome Camera
SCD-2020/2040 SCD-2020B
600TVL
Key Features
• High resolution of 600TV lines
• Min. illumination 0.15Lux@F1.2
• Built-in fixed lens (3.7mm : SCD-2020, 8mm : SCD-2040)
• SSNRIII, Coax : Pelco-C (Coaxitron), Dual power
Dimensions
0.15Lux
3.7mm/8mm
Unit : mm (inch)
83.7 (3.3")
Ø107.6 (4.24")
Technical Specifications
SCD-2020N/2040N SCD-2020P/2040P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-2020B
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0006Lux (Sens-up, 256x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.7mm (Fixed) : SCD-2020, 8mm (Fixed) : SCD-2040
F2.0
H : 71˚ / V : 52˚ (3.7mm), H : 33˚ / V : 25˚ (8mm)
0.4m (1.31ft)
Fixed
Board type
0° ~ 352°
0° ~ 75°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (Electrical ) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Plastic (Dome cover : Smoked)
Ø107.6 x 83.7mm (Ø4.24" x 3.3")
285g (0.63 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
FIRST EDITION 03-2011
79
Page 81
67.0 (2.64")
104.0 (4.09")
104.0 (4.09")
SCD-2010
High Resolution Mini Dome Camera
SCD-2010
600TVL
Key Features
• High resolution of 600TV lines
• Min. illumination 0.04Lux@F1.2
• Built-in fixed lens (3mm)
• Coax : Pelco-C (Coaxitron), 12V DC
Dimensions
0.04Lux
3mm
67.0 (2.64")
SCD-2010B
12VDC
Unit : mm (inch)
Technical Specifications
SCD-2010N SCD-2010P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* Derivative products : SCD-2010B
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.04Lux@F1.2
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3mm
F2.0
H : 95˚ / V : 71˚
0.4m (1.31ft)
Fixed
Board type
0° ~ 352°
0° ~ 75°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (Electrical ) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 1.8W
Ivory / Plastic (Dome cover : clear)
Ø104.0 x 67.0mm (Ø4.09" x 2.64")
180g (0.4 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
FIRST EDITION 03-2011
Ø104.0 (4.09")
80
Page 82
SCD-2010F
100.5 (3.96")
115.3 (4.54") 41.9 (1.65")
High Resolution Compact Flat Camera
600TVL
Key Features
• High resolution of 600TV lines
• Min. Illumination 0.04Lux@F1.2
• Built-in fixed lens (3mm)
• Coax : Pelco-C (Coaxitron), 12V DC
Dimensions
0.04Lux
3mm
100.5 (3.96")
12VDC
Unit : mm (inch)
Technical Specifications
SCD-2010FN SCD-2010FP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.04Lux (Sens-up, 2x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3mm
F2.0
H : 89.5° / V : 67.2°
0.4m (1.31ft)
Fixed
Board type
±10°
0° ~ 90°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (Electrical) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 1.8W
Ivory / Plastic (Dome cover : Clear)
115.3 x 100.5 x 41.9mm (4.54" x 3.96" x 1.65")
140g (0.31 Ib)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
115.3 (4.54")
FIRST EDITION 03-2011
41.9 (1.65")
SYSTEM
ACCESS CONTROL
81
Page 83
SCD-2080R
92.7 (3.65")
92.7 (3.65")
Ø115.8 (4.56")
High Resolution IR Dome Camera
3.6x
V/F Lens
D&N ICR
III
92.7 (3.65")
12VDC
Unit : mm (inch)
Ø115.8 (4.56")
600TVL
0Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0Lux (IR LED on), IR distance 20m
• 3.6x V/F lens (2.8 ~ 10mm)
• True Day & Night (ICR), MD, SSNR
• Coax : Pelco-C (Coaxitron), 12V DC
Dimensions
Technical Specifications
SCD-2080RN SCD-2080RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0Lux (IR LED on)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4˚(Wide) ~ 28˚(Tele) / V : 69.2˚(Wide) ~ 21˚(Tele)
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
20m (IR LED 12ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 3.5W
Ivory / Plastic (Dome cover : Smoked)
Ø115.8 x 92.7mm (Ø4.56" x 3.65")
310g (0.68 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
FIRST EDITION 03-2011
82
Page 84
SCD-2020R
83.7 (3.3")
83.7 (3.3")
Ø107.6 (4.24")
High Resolution Small IR Dome Camera
600TVL
0Lux
3.6mm
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0Lux (IR LED on), IR distance 7m
• Built-in fixed lens (3.6mm), SSNRIII
• Coax : Pelco-C (Coaxitron), 12V DC
Dimensions
83.7 (3.3")
12VDC
Unit : mm (inch)
Technical Specifications
SCD-2020RN SCD-2020RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), B/W : 0Lux (IR LED on)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.6mm
F2.0
H : 66˚ / V : 49˚
0.4m (1.31ft)
Fixed
Board type
0° ~ 352°
0° ~ 75°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
7m (IR LED 8ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
12V DC ±10%
Max. 2.5W
Ivory / Plastic (Dome cover : clear)
Ø107.6 x 83.7mm (Ø4.24" x 3.3")
280g (0.62 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
FIRST EDITION 03-2011
Ø107.6 (4.24")
SYSTEM
ACCESS CONTROL
83
Page 85
SCD-1020R
71.7 (2.82")
Ø102.0 (Ø4.02")
Small IR Dome Camera
520TVL
0Lux
3.6mm
Key Features
• High resolution of 520TV lines
• Min. illumination 0Lux (IR LED on), IR distance 10m
• Built-in fixed lens (3.6mm)
• 12V DC
Dimensions
12VDC
Unit : mm (inch)
Technical Specifications
SCD-1020RN SCD-1020RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
OPERATIONAL
Day & Night
Digital Noise
Reduction
Gain Control
White Balance
Shutter Mode
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" CMOS
680(H) x 512(V)
640(H) x 480(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 520TV lines
0Lux (IR LED on)
46dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.6mm
F2.0
H : 56˚ / V : 42˚
0.2m (0.66ft)
Fixed
Board type
0° ~ 355°
0° ~ 60°
Auto
Auto
Auto
Auto (3200°K ~ 6500°K)
Auto (Rolling Shutter)
10m (IR LED 12ea)
0°C ~ +40°C (+32°F ~ +104°F) / 20% ~ 85% RH
12V DC
Max. 2.2W
Ivory / Plastic (Dome cover : clear)
Ø102.0 x 71.7mm (Ø4.02" x 2.82")
180g (0.40 lb)
REVISED 03-2012
71.7 (2.82")
Ø102.0 (4.02")
84
Page 86
SCV-3120
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
High Resolution 12x WDR Vandal-Resistant Dome Camera
600TVL
0.7Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.7Lux@F1.65 (Color), 0.07Lux (B/W)
• Powerful 12x zoom (3.69 ~ 44.32mm), digital 16x
• WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD
• IP66, Coax : CCVC, RS-485, Dual power
Dimensions
Flush Type
Accessories (Optional)
12x
D&N ICR
Unit : mm (inch)
Ø160.0 (6.3")
Ø160.0 (6.3")
125.0 (4.92") 134.5 (5.3")
Technical Specifications
SCV-3120N SCV-3120P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Double scan CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.7Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.65 (50IRE), 0.0001Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.69 ~ 44.32mm (12x)
1 : 1.65(Wide) ~ 3.7(Tele)
H : 54.44°(Wide) ~ 4.64°(Tele) / V : 41.42°(Wide) ~ 3.52°(Tele)
1m (3.28ft)
Auto / Manual / One-AF
1.9sec (Wide to tele)
0° ~ 355°
0° ~ 90°
0° ~ 355°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
128x 160x
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H / V / H/V
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Off / On
Fixed / Moved
Off / On
1 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 6W
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.28Kg (2.82 lb)
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
85
Page 87
85.0 (3.35")Ø148.0 (5.83")
126.0 (4.96")
Ø148.0 (5.83")
85.0 (3.35")Ø148.0 (5.83")
72.5 (2.85")Ø148.0 (5.83")
126.0 (4.96")
114.0 (4.49")
27.0 (1.06")
Ø148.0 (5.83")
Ø148.0 (5.83")
SCV-2120
High Resolution 12x Vandal-Resistant Dome Camera
600TVL
0.2Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.67 (Color), 0.02Lux (B/W)
• Powerful 12x zoom (3.94 ~ 46.05mm), Digital 16x
• MD, SSNR
III
• IP66, Coax : Pelco-C (Coaxitron), RS-485, Dual power
• Vandal-resistant IK10 rated
Dimensions
Flush Type
Accessories (Optional)
12x
D&N ICR
126.0 (4.96")
Ø148.0 (5.83") 85.0 (3.35")
27.0 (1.06")
114.0 (4.49")
Ø148.0 (5.83")
72.5 (2.85")
Unit : mm (inch)
Technical Specifications
SCV-2120N SCV-2120P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.2Lux@F1.67 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.67 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.94 ~ 46.05mm (Optical 12x)
1 : 1.67(Wide) ~ 3.7(Tele)
H : 51.54°(Wide) ~ 4.5°(Tele) / V : 39.24°(Wide) ~ 3.38°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
1.9sec (Wide to tele)
0° ~ 340°
0° ~ 146°
0° ~ 340°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / On
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Vicon, Honeywell, Panasonic, Bosch, AD
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 3.5W
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø148.0 x 126.0mm (Ø5.83" x 4.96")
1.38Kg (3.04 lb)
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
FIRST EDITION 03-2011
86
Page 88
SCV-3081/2081
Ø100.0 (3.93”)
Ø137.0 (5.39")
Ø137.0 (5.39")
106 (4.17")
Ø137.0 (5.39")
High Resolution Vandal-Resistant Dome Camera
600TVL
0.3Lux
0.15
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.3Lux@F1.2 (Color), 0.01Lux (B/W) : SCV-3081
•
3.9x V/F lens (2.8 ~ 11mm), WDR, VPS, Day & Night (ICR), Intelligent video analytics : SCV-3081
3.6x V/F lens (2.8 ~ 10mm), True Day & Night (ICR), MD, SSNRIII : SCV-2081
• IP66, Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Ø100.0 (3.93")
Ø137.0 (5.39")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM2 SBP-300LM SBP-300PM SBP-300KM
3.9x
3.6x
Lux
V/F Lens
D&N ICR
0.15Lux@F1.2 (Color), 0.001Lux (B/W) : SCV-2081
Unit : mm (inch)
106.0 (4.17")
Ø137.0 (5.39")
Technical Specifications
SCV-3081N/2081N SCV-3081P/2081P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD (Double scan) : SCV-3081, 1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.3Lux@ F1.2 (50IRE), 0.0006Lux (Sens-up, 512x) : SCV-3081
0.15Lux@ F1.2 (50IRE), 0.0003Lux (Sens-up, 512x) : SCV-2081
B/W : 0.01Lux@ F1.2 (50IRE), 0.00002Lux (Sens-up, 512x) : SCV-3081
0.001Lux@ F1.2 (50IRE), 0.000002Lux (Sens-up, 512x) : SCV-2081
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x) : SCV-3081, 2.8 ~ 10mm (3.6x) : SCV-2081
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94˚(Wide) ~ 26˚(Tele) / V : 67˚(Wide) ~ 20˚(Tele) : SCV-3081
H : 94.4˚(Wide) ~ 28˚(Tele) / V : 69.2˚(Wide) ~ 21˚(Tele) : SCV-2081
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W : SCV-3081, Auto (ICR) / Color / B/W : SCV-2081
Off / User BLC / HLC / SSDR / WDR : SCV-3081, BLC / HLC / Off : SCV-2081
128x (52dB) : SCV-3081 160x (54dB) : SCV-3081
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in : SCV-3081, Off / On (8 programmable zones) : SCV-2081
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev : SCV-3081, H-Rev (Off / On) / V-Rev (Off / On) : SCV-2081
Basic / Day & Night / Backlight / ITS / Indoor / User : SCV-3081
Off / On : SCV-3081
Fixed / Moved / Area / Fence / Tracking / Detection / Counting : SCV-3081
Off / On : SCV-3081
1 Out : SCV-3081
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%), Built-in fan & heater (24V AC±10%)
Max. 3.5W
Ivory / Aluminum, Plastic (Dome cover : Clear) : SCV-3081
Ivory / Aluminum, Plastic (Dome cover : Smoked) : SCV-2081
Ø137.0 x 106.0mm (Ø5.39" x 4.17")
340g (0.75 lb) : SCV-3081, 710g (1.57 lb) : SCV-2081
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
II
: SCV-2081
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
87
Page 89
SCV-3080/2080
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
High Resolution Vandal-Resistant Dome Camera
600TVL
0.3Lux
0.15
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.3Lux@F1.2 (Color), 0.01Lux (B/W) : SCV-3080
•
3.9x V/F lens (2.8 ~ 11mm), WDR, VPS, Day & Night (ICR), Intelligent video analytics : SCV-3080
3.6x V/F lens (2.8 ~ 10mm), True Day & Night (ICR), MD, SSNRIII : SCV-2080
• IP66, Coax : Pelco-C (Coaxitron), Dual power
• Vandal-resistant IK10 rated : SCV-3080
Dimensions
Flush Type
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
3.9x
3.6x
Lux
V/F Lens
D&N ICR
0.15Lux@F1.2 (Color), 0.001Lux (B/W) : SCV-2080
Unit : mm (inch)
Ø160.0 (6.3")
Ø160.0 (6.3")
125.0 (4.92") 134.5 (5.3")
Technical Specifications
SCV-3080N/2080N SCV-3080P/2080P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Profile
VPS
Intelligent Video Analytics
PIP
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD (Double scan) : SCV-3080, 1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.3Lux@ F1.2 (50IRE), 0.0006Lux (Sens-up, 512x) : SCV-3080
0.15Lux@ F1.2 (50IRE), 0.0003Lux (Sens-up, 512x) : SCV-2080
B/W : 0.01Lux@ F1.2 (50IRE), 0.00002Lux (Sens-up, 512x) : SCV-3080
0.001Lux@ F1.2 (50IRE), 0.000002Lux (Sens-up, 512x) : SCV-2080
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 11mm (3.9x) : SCV-3080, 2.8 ~ 10mm (3.6x) : SCV-2080
1 : 1.2(Wide) ~ 2.8(Tele)
H : 102˚(Wide) ~ 28˚(Tele) / V : 73˚(Wide) ~ 21˚(Tele) : SCV-3080
H : 94.4˚(Wide) ~ 28˚(Tele) / V : 69.2˚(Wide) ~ 21˚(Tele) : SCV-2080
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 355°
0° ~ 90°
0° ~ 355°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / External / Color / B/W : SCV-3080, Auto (ICR) / Color / B/W : SCV-2080
Off / User BLC / HLC / SSDR / WDR : SCV-3080, BLC / HLC / Off : SCV-2080
128x (52dB) : SCV-3080 160x (54dB) : SCV-3080
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in : SCV-3080, Off / On (8 programmable zones) : SCV-2080
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / H-Rev / V-Rev / HV-Rev : SCV-3080, H-Rev (Off / On) / V-Rev (Off / On) : SCV-2080
Basic / Day & Night / Backlight / ITS / Indoor / User : SCV-3080
Off / On : SCV-3080
Fixed / Moved / Area / Fence / Tracking / Detection / Counting : SCV-3080
Off / On : SCV-3080
1 Out : SCV-3080
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%), Built-in fan & heater (24V AC±10%)
Max. 3.8W / Max. 8W (Fan & heater on) : SCV-3080, Max. 4.0W / Max. 8.3W (Fan & heater on) : SCV-2080
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.26Kg (2.78 lb)
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
II
: SCV-2080
88
Page 90
SCV-2060
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
134.5 (5.3")
Ø160.0 (6.3")
125.0 (4.92")
High Resolution Vandal-Resistant Dome Camera
600TVL
0.15
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.15Lux@F1.2 (Color), 0.001Lux (B/W)
• 2.4x V/F lens (2.5 ~ 6mm), True Day & Night (ICR), MD, SSNR
• IP66, Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Flush Type
Accessories (Optional)
2.4x
Lux
V/F Lens
Ø160.0 (6.3")
Ø160.0 (6.3")
D&N ICR
Unit : mm (inch)
125.0 (4.92") 134.5 (5.3")
III
Technical Specifications
SCV-2060N SCV-2060P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0.001Lux@F1.2 (50IRE), 0.000002Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.5 ~ 6mm (2.4x)
1 : 1.2(Wide) ~ 1.7(Tele)
H : 103.4˚(Wide) ~ 46.6˚(Tele) / V : 77.6˚(Wide) ~ 35.1˚(Tele)
DC auto iris
Board type
0° ~ 355°
0° ~ 90°
0° ~ 355°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%), Built-in fan & heater (24V AC ±10%)
Max. 3.8W / Max. 7.8W (Fan & heater on)
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.28Kg (2.82 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
REVISED 09-2011
89
Page 91
SCV-2010F
125.2 (4.93")
52.0 (2.05")
115.2 (4.54")
High Resolution Compact Vandal-Resistant Flat Camera
600TVL
0.04Lux
3mm
Key Features
• High resolution of 600TV lines
• Min. illumination 0.04Lux@F1.2
• Built-in fixed lens (3mm)
• IP66, Coax : Pelco-C (Coaxitron), 12V DC
• Vandal-resistant IK10 rated
Dimensions
12VDC
Unit : mm (inch)
Technical Specifications
SCV-2010FN SCV-2010FP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
PAN / TILT
Pan Range
Tilt Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxHxD)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.04Lux (Sens-up, 2x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3mm
F2.0
H : 89.5° / V : 67.2°
±10°
0° ~ 90°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (Electrical) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Low / High / Off
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
12V DC ±10%
Max. 1.8W
Ivory / Aluminum, Plastic (Dome cover : Clear)
125.2 x 52.0 x 115.2mm (4.93" x 2.05" x 4.54")
410g (0.9 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
FIRST EDITION 03-2011
115.2 (4.54")
125.2 (4.93") 52.0 (2.05")
90
Page 92
SCV-2081R
Ø100.0 (3.93”)
Ø137.0 (5.39")
Ø137.0 (5.39")
106 (4.17")
Ø137.0 (5.39")
High Resolution Vandal-Resistant IR Dome Camera
600TVL
0Lux
Key Features
• High resolution of 600TV lines, 700TV lines (B/W)
•
Min. illumination 0Lux (IR LED on), IR distance 20m
• 3.6x V/F lens (2.8 ~ 10mm), True Day & Night (ICR), MD, SSNR
• IP66, Coax : Pelco-C (Coaxitron), Dual power
Dimensions
Ø100.0 (3.93")
Ø137.0 (5.39")
Accessories (Optional)
3.6x
V/F Lens
D&N ICR
III
Unit : mm (inch)
106.0 (4.17")
Ø137.0 (5.39")
Technical Specifications
SCV-2081RN SCV-2081RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0Lux (IR LED on)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4˚(Wide) ~ 28˚(Tele) / V : 69.2˚(Wide) ~ 21˚(Tele)
DC auto iris
Board type
0° ~ 352°
0° ~ 73°
0° ~ 348°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible)
Coax : Pelco-C (Coaxitron)
20m (IR LED 20ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 3W / Max. 4W (IR LED on)
Ivory / Aluminum, Plastic (Dome cover : Smoked)
Ø137.0 x 106.0mm (Ø5.39" x 4.17")
710g (1.57 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM2 SBP-300LM SBP-300PM SBP-300KM
REVISED 09-2011
91
Page 93
SCV-2080R
85.0 (3.35")Ø148.0 (5.83")
126.0 (4.96")
Ø148.0 (5.83")
85.0 (3.35")Ø148.0 (5.83")
72.5 (2.85")Ø148.0 (5.83")
126.0 (4.96")
114.0 (4.49")
27.0 (1.06")
Ø148.0 (5.83")
Ø148.0 (5.83")
High Resolution Vandal-Resistant IR Dome Camera
600TVL
0Lux
Key Features
• High resolution of 600TV lines, 700TV lines (B/W)
•
Min. illumination 0Lux (IR LED on), IR distance 30m
•
3.6x V/F lens (2.8 ~ 10mm), True Day & Night (ICR),
• IP66, Coax : Pelco-C (Coaxitron), RS-485, Dual power
Dimensions
Flush Type
Accessories (Optional)
3.6x
V/F Lens
D&N ICR
MD, SSNR
126.0 (4.96")
Ø148.0 (5.83") 85.0 (3.35")
27.0 (1.06")
114.0 (4.49")
Ø148.0 (5.83")
72.5 (2.85")
Unit : mm (inch)
III
Technical Specifications
SCV-2080RN SCV-2080RP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Lens Type
Mount Type
PAN / TILT
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Reverse
Communication
Protocol
IR Distance
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.15Lux@F1.2 (50IRE), 0.0003Lux (Sens-up, 512x)
B/W : 0Lux (IR LED on)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
2.8 ~ 10mm (3.6x)
1 : 1.2(Wide) ~ 2.8(Tele)
H : 94.4˚(Wide) ~ 28˚(Tele) / V : 69.2˚(Wide) ~ 21˚(Tele)
0.2m (0.66ft)
DC auto iris
Board type
0° ~ 340°
0° ~ 146°
0° ~ 340°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 15 characters)
Auto (ICR) / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On (8 programmable zones)
Off / On (12 programmable zones)
2x ~ 512x
Off / Low / High
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
H-Rev (Off / On) / V-Rev (Off / On)
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
30m (IR LED 10ea)
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
Dual (24V AC & 12V DC ±10%)
Max. 5W
Ivory / Aluminum, Plastic (Dome cover : Smoked)
Ø148.0 x 126.0mm (Ø5.83" x 4.96")
1.3Kg (2.87 lb)
II
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM3 SBP-300LM SBP-300PM SBP-300KM
FIRST EDITION 03-2011
92
Page 94
Ø228.0 (8.98") Ø228.0 (8.98")
256.0 (10.08")
240.0 (9.45")
SCP-3430H/2430H
High Resolution 43x Weatherproof PTZ Dome Camera
600TVL
0.7Lux
0.2Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.7Lux@F1.65 (Color), 0.07Lux (B/W) : SCP-3430H
0.2Lux@F1.65 (Color), 0.02Lux (B/W) : SCP-2430H
• Powerful 43x zoom (3.2 ~ 138.5mm), Digital 16x
•
WDR, VPS
: SCP-3430H, True Day & Night (ICR)
Intelligent video analytics, MD, DNR
• IP66, Coax : CCVC, RS-485/422, 24V AC
• Vandal-resistant IK10 rated
Dimensions
240.0 (9.45")
256.0 (10.08")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300LM SBP-300PM SBP-300KM
43x
D&N ICR
24VAC
Unit : mm (inch)
Ø228.0 (8.98")Ø228.0 (8.98")
Technical Specifications
SCP-3430HN/2430HN SCP-3430HP/2430HP
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
Profile
VPS
Intelligent Video Analytics
PIP
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD CCD (Double scan)
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.7Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
0.2Lux@F1.65 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.65 (50IRE), 0.0002Lux (Sens-up, 512x)
0.02Lux@F1.65 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.2 ~ 138.5mm (Optical 43x)
1 : 1.65(Wide) ~ 3.7(Tele)
H : 61.22°(Wide) ~ 1.47°(Tele) / V : 47.16°(Wide) ~ 1.1°(Tele)
1m (3.28ft)
Auto / Manual / One AF
3.2sec (Wide to tele)
360° Endless
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
-6° ~ 186°
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
512
±0.1°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
: SCP-3430H
128x
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
Off / On (1x ~ 16x)
Off / On
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Off / On
Fixed / Moved
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : CCVC
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH
IP66 Grade
24V AC ±10%
Max. 16.3W / 47W (Fan & heater on)
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø228.0 x 256.0mm (Ø8.98" x 10.08")
5.6Kg (12.35 lb)
: SCP-3430H, 1/4"
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
160x
Super HAD CCD II : SCP-2430H
: SCP-3430H
: SCP-3430H
: SCP-2430H
: SCP-3430H
: SCP-2430H
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 03-2012
93
Page 95
SCP-3370TH/3370H/3370
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
High Resolution 37x WDR PTZ Dome Camera
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
SCP-3370TH/3370H SCP-3370
600TVL
0.7Lux
37x
D&N ICR
24VAC
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.7Lux@F1.6 (Color), 0.07Lux (B/W)
• Powerful 37x zoom (3.5 ~ 129.5mm), Digital 16x
•
WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD, SSNRIII
• Coax : Pelco-C (Coaxitron), RS-485/422, 24V AC
Dimensions
SCP-3370TH/3370H
SCP-3370
20.0 (0.79")
316.5 (12.46")
243.4 (9.58")
215.7 (8.49")
Ø162.0 (6.38")
Ø248.0 (9.76")
Ø155.0 (6.1")
Ø248.0 (9.76")
Ø155.0 (6.1")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Unit : mm (inch)
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
Auto Tracking
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
VPS
Intelligent Video Analytics
PIP
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SCP-3370THN/3370HN/3370N SCP-3370THP/3370HP/3370P
1/4" Ex-view HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.7Lux@F1.6 (50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.6 (50IRE), 0.0001Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.5 ~ 129.5mm (Optical 37x)
1 : 1.6(Wide) ~ 3.9(Tele)
H : 55.5°(Wide) ~ 1.59°(Tele) / V : 42.5°(Wide) ~ 1.19°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
2.8sec
360° Endless
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
255
±0.1°
Yes (SCP-3370TH only)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 12 characters)
Auto (ICR) / External / Color / B/W
BLC / HLC / Off / WDR
128x
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Built-in
Off / On (8 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / On
Off / On
Off / Detection / Tracking / Fixed_Moved
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCP-3370TH/3370H
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH : SCP-3370
IP66 Grade (SCP-3370TH/3370H only)
24V AC ±10%
Max. 15W / 60W (Fan & heater on) : SCP-3370TH/3370H, Max. 15W : SCP-3370
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø248.0 x 316.5mm (Ø9.76" x 12.46") : SCP-3370TH/3370H
Ø155.0 x 243.4mm (Ø6.1" x 9.58") : SCP-3370
4.5Kg (9.92 lb) : SCP-3370TH/3370H, 2Kg (4.41 lb) : SCP-3370
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
160x
REVISED 03-2012
94
Page 96
SCP-2370TH/2370H/2370
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
High Resolution 37x PTZ Dome Camera
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
SCP-2370TH/2370H SCP-2370
600TVL
0.2Lux
37x
D&N ICR
24VAC
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.6 (Color), 0.02Lux (B/W)
• Powerful 37x zoom (3.5 ~ 129.5mm), Digital 16x
• True Day & Night (ICR), MD, SSNR
III
• Coax : Pelco-C (Coaxitron), RS-485/422, 24V AC
Dimensions
SCP-2370TH/2370H
SCP-2370
20.0 (0.79")
316.5 (12.46")
243.4 (9.58")
215.7 (8.49")
Ø162.0 (6.38")
Ø248.0 (9.76")
Ø155.0 (6.1")
Ø248.0 (9.76")
Ø155.0 (6.1")
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Unit : mm (inch)
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
Auto Tracking
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SCP-2370THN/2370HN/2370N SCP-2370THP/2370HP/2370P
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.2Lux@F1.6 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.6 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.5 ~ 129.5mm (Optical 37x)
1 : 1.6(Wide) ~ 3.9(Tele)
H : 55.5°(Wide) ~ 1.59°(Tele) / V : 42.5°(Wide) ~ 1.19°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
2.8sec
360° Endless
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
255
±0.1°
Yes (SCP-2370TH only)
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 12 characters)
Auto (ICR) / External / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On
Off / On (8 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCP-2370TH/2370H
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH : SCP-2370
IP66 Grade (SCP-2370TH/2370H only)
24V AC ±10%
Max. 15W / 60W (Fan & heater on) : SCP-2370TH/2370H, Max. 15W : SCP-2370
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø248.0 x 316.5mm (Ø9.76" x 12.46") : SCP-2370TH/2370H
Ø155.0 x 243.4mm (Ø6.1" x 9.58") : SCP-2370
4.5Kg (9.92 lb) : SCP-2370TH/2370H, 2Kg (4.41 lb) : SCP-2370
II
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 09-2011
95
Page 97
SCP-2330H/2330
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
High Resolution 33x PTZ Dome Camera
SCP-2330H SCP-2330
20.0 (0.79")
316.5 (12.46")
243.4 (9.58")
215.7 (8.49")
33x
Ø162.0 (6.38")
Ø248.0 (9.76")
Ø155.0 (6.1")
D&N ICR
III
24VAC
Ø248.0 (9.76")
Ø155.0 (6.1")
600TVL
0.2Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.6 (Color), 0.02Lux (B/W)
• Powerful 33x zoom (3.5 ~ 115.5mm), Digital 16x
• True Day & Night (ICR), MD, SSNR
• Coax : Pelco-C (Coaxitron), RS-485/422, 24V AC
Dimensions
SCP-2330H
SCP-2330
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SCP-2330HN/2330N SCP-2330HP/2330P
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.2Lux@F1.6 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.6 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.5 ~ 115.5mm (Optical 33x)
1 : 1.6(Wide) ~ 3.6(Tele)
H : 55.5°(Wide) ~ 1.77°(Tele) / V : 42.5°(Wide) ~ 1.33°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
2.8sec
360° Endless
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
255
±0.1°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 12 characters)
Auto (ICR) / External / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On
Off / On (8 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCP-2330H
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH : SCP-2330
IP66 Grade (SCP-2330H only)
24V AC ±10%
Max. 15W / 58W (Fan & heater on) : SCP-2330H, Max. 15W : SCP-2330
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø248.0 x 316.5mm (Ø9.76" x 12.46") : SCP-2330H
Ø155.0 x 243.4mm (Ø6.1" x 9.58") : SCP-2330
4.5Kg (9.92 lb) : SCP-2330H, 2Kg (4.41 lb) : SCP-2330
II
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
REVISED 09-2011
96
Page 98
SCP-2270H/2270
215.7 (8.49")
243.4 (9.58")
155.0 (6.1")
155.0 (6.1")
316.5 (12.46")
20.0 (0.79")
248.0 (9.76")
162.0 (6.38")
248.0 (9.76")
High Resolution 27x PTZ Dome Camera
SCP-2270H SCP-2270
20.0 (0.79")
316.5 (12.46")
243.4 (9.58")
215.7 (8.49")
27x
Ø162.0 (6.38")
Ø248.0 (9.76")
Ø155.0 (6.1")
D&N ICR
III
24VAC
Ø248.0 (9.76")
Ø155.0 (6.1")
600TVL
0.2Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.6 (Color), 0.02Lux (B/W)
• Powerful 27x zoom (3.5 ~ 94.5mm), Digital 16x
• True Day & Night (ICR), MD, SSNR
• Coax : Pelco-C (Coaxitron), RS-485/422, 24V AC
Dimensions
SCP-2270H
SCP-2270
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Unit : mm (inch)
Technical Specifications
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
SCP-2270HN/2270N SCP-2270HP/2270P
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines
Color : 0.2Lux@F1.6 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.6 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.5 ~ 94.5mm (Optical 27x)
1 : 1.6(Wide) ~ 3.6(Tele)
H : 55.5°(Wide) ~ 2.24°(Tele) / V : 42.5°(Wide) ~ 1.79°(Tele)
1.8m (5.91ft)
Auto / Manual / One shot
2.8sec
360° Endless
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Preset : 600°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
255
±0.1°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 12 characters)
Auto (ICR) / External / Color / B/W
BLC / HLC / Off
SSDR (Off / On)
SSNR
III
(Off / On)
Off / On
Off / On
Off / On (8 programmable zones)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Off / On (1x ~ 16x)
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCP-2270H
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH : SCP-2270
IP66 Grade (SCP-2270H only)
24V AC ±10%
Max. 15W / 58W (Fan & heater on) : SCP-2270H, Max. 15W : SCP-2270
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ø248.0 x 316.5mm (Ø9.76" x 12.46") : SCP-2270H
Ø155.0 x 243.4mm (Ø6.1" x 9.58") : SCP-2270
4.5Kg (9.92 lb) : SCP-2270H, 2Kg (4.41 lb) : SCP-2270
II
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
REVISED 09-2011
97
Page 99
SCP-2250H/2250
Ø171.0 (6.73")
Ø178.0 (7.01")
219.0 (8.62")
140.0 (5.51")
Ø178.0 (7.01")
Ø228.0 (8.98") Ø228.0 (8.98")
256.0 (10.08")
240.0 (9.45")
High Resolution 25x PTZ Dome Camera
SCP-2250H SCP-2250
240.0 (9.45")
256.0 (10.08")
219.0 (8.62")
25x
D&N ICR
Ø178.0 (7.01")
140.0 (5.51")
Ø171.0 (6.73") Ø178.0 (7.01")
24VAC
Unit : mm (inch)
Ø228.0 (8.98")Ø228.0 (8.98")
600TVL
0.2Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.2Lux@F1.65 (Color), 0.02Lux (B/W)
• Powerful 25x zoom (3.66 ~ 91.36mm), Digital 16x
• True Day & Night (ICR), Intelligent video analytics, MD, DNR
• Coax : CCVC, RS-485/422, 24V AC
• Vandal-resistant IK10 rated : SCP-2250H
Dimensions
SCP-2250H
SCP-2250
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
Technical Specifications
SCP-2250HN/2250N SCP-2250HP/2250P
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
Profile
VPS
Intelligent Video Analytics
PIP
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.2Lux@F1.65 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.02Lux@F1.65 (50IRE), 0.00004Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.66 ~ 91.36mm (Optical 25x)
1 : 1.65(Wide) ~ 3.0(Tele)
H : 54.95°(Wide) ~ 2.24°(Tele) / V : 41.83°(Wide) ~ 1.68°(Tele)
1m (3.28ft)
Auto / Manual / One AF
2.9sec (Wide to
360° Endless
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
-6° ~ 186°
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
512
±0.1°
English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
Off / On (Displayed 54 characters)
Day / Night / Auto / Ext
Off / On (Area setting)
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / On
ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
Off / On (1x ~ 16x)
Off / On
Standard / ITS / Backlight / Day & Night / Gaming / Custom
Off / On
Fixed / Moved
Off / On
Day / Time
8 In 3 Out
Coaxial control (SPC-300 compatible), RS-485/422
Coax : CCVC
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
IP66 Grade
24V AC ±10%
Max. 16.3W / 47W (Fan & heater on)
Ivory / Aluminum, Plastic (Dome cover : Clear)
Ivory / Plastic (Dome cover : Clear)
Ø228.0 x 256.0mm (Ø8.98" x 10.08")
Ø178.0 x 219.0mm (Ø7.01" x 8.62")
5.6Kg (12.35 lb)
tele
)
: SCP-2250H
: SCP-2250H
II
: SCP-2250H,
: SCP-2250
: SCP-2250H
: SCP-2250
, 1.9Kg (4.19 lb)
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
: SCP-2250H
: SCP-2250
Max. 11.5W
: SCP-2250
REVISED 03-2012
98
Page 100
150.0 (5.91")
108.0 (4.25")
Ø154.0 (6.06") Ø154.0 (6.06")
Ø115.0 (4.53")
Ø200.0 (7.87")
203.0 (7.99")
120.0 (4.72") 19.0 (0.75")
SCP-3120/3120VH
High Resolution 12x WDR PTZ Dome Camera
SCP-3120 SCP-3120VH
600TVL
0.7Lux
Key Features
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination 0.7Lux@F1.65 (Color), 0.07Lux (B/W)
• Powerful 12x zoom (3.6 ~ 44.3mm), digital 16x
• WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD, DNR
•
IP66 : SCP-3120V/3120VH, Coax : Pelco-C (Coaxitron), RS-485, 24V AC
Dimensions
SCP-3120
SCP-3120VH
Accessories (Optional)
12x
D&N ICR
Ø154.0 (6.06") Ø154.0 (6.06")
Ø115.0 (4.53")
24VAC
108.0 (4.25")
150.0 (5.91")
120.0 (4.72") 19.0 (0.75")
203.0 (7.99")
Ø200.0 (7.87")
Unit : mm (inch)
Technical Specifications
SCP-3120N/3120VN/3120VHN
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N Ratio
Video Output
LENS
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Zoom Movement Speed
PAN / TILT
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Preset
Preset Accuracy
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Backlight Compensation
Wide Dynamic Range
Contrast Enhancement
Digital Noise
Reduction
Digital Image
Stabilization
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Digital Flip
VPS
Intelligent Video Analytics
Schedule
Alarm
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
Ingress Protection
ELECTRICAL
Input Voltage / Current
Power Consumption
MECHANICAL
Color / Material
Dimensions (WxH)
Weight
* The latest product information / specification can be found at www.samsungsecurity.com
1/4" Ex-view HAD CCD (Double scan)
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines, B/W : 700TV lines
Color : 0.7Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.65 (50IRE), 0.0001Lux (Sens-up, 512x)
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
3.6 ~ 44.3mm (Optical 12x)
1 : 1.65(Wide) ~ 2.01(Tele)
H : 54.44°(Wide) ~ 4.64°(Tele) / V : 41.42°(Wide) ~ 3.52°(Tele)
1m (3.28ft)
Auto / Manual / One shot
1.9sec
360° Endless
Preset : 650°/sec, Manual : 0.05°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Preset : 650°/sec, Manual : 0.05°/sec ~ 120°/sec (Proportional zoom ratio)
255
±0.1°
English, French, Spanish, Italian,
German, Portuguese, Korean
Off / On (Displayed 12 characters)
Off / Auto / B/W
BLC / WDR / Off
128x 160x
XDR (Off / Low / Mid / High)
Adaptive 3D+2D (Off / Low / Mid / High / User)
Off / On
Off / Tracking / Detection
Off / On (12 programmable zones with polygonal masking)
2x ~ 512x
Off / Low / Medium / High / Manual
ATW (In) / ATW (Out) / AWC / Manual
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
Off / On (1x ~ 16x)
Off / On
Off / On
Fixed / Moved
Day / Time
2 In 2 Out
Coaxial control (SPC-300 compatible), RS-485
Coax : Pelco-C (Coaxitron)
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
-10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH : SCP-3120
-50°C ~ +50°C (-58°F ~ +122°F) / Less than 90% RH : SCP-3120V/3120VH
IP66 Grade (SCP-3120V/3120VH only)
24V AC ±10%
Max. 12W : SCP-3120, Max. 12W / 45W (Fan & heater on) : SCP-3120V/3120VH
Ivory / Plastic (Dome cover : Clear ) : SCP-3120
Ivory / Aluminum, Plastic (Dome cover : Clear) : SCP-3120V/3120VH
Ø154.0 x 150.0mm (Ø6.06" x 5.91") : SCP-3120, Ø165.0 x 165.0mm (Ø6.5" x 6.5") : SCP-3120V
Ø200.0 x 203.0mm (Ø7.87" x 7.99") : SCP-3120VH
1Kg (2.2 lb) : SCP-3120, 1.8Kg (3.97 lb) : SCP-3120V, 2.4Kg (5.29 lb) : SCP-3120VH
English, French, Spanish, German,
Italian, Chinese, Portuguese
SCP-3120P/3120VP/3120VHP
NETWORK
CAMERA
ANALOGUE
DVRLENSPERIPHERALMONITORCONTROLLERSECURITY ROBOT
SYSTEM
ACCESS CONTROL
SBP-300WM1 SBP-300WM SBP-300CM SBP-300HM1 SBP-300LM SBP-300PM SBP-300KM
REVISED 03-2012
99
Loading...
