Samsung SCB-3003 User Manual

Supreme Resolution
WDR Camera

User Manual

SCB-3003

B

■

■

h

Supreme Resolution WDR Camera

User Manual

Copyright
©2013 Sam sung Techwi n Co., Ltd . All rig hts res erved .

Tra dem ark

The name of t his product is the re gistered tradem ark of Samsung Techwin C o., Ltd.
Other tr ademarks mentio ned in this manual are t he registered tr ademark of their res pective compan y.

Restriction

Samsung Tech win Co., Ltd shall rese rve the copyrig ht of this document . Under no circumst ances, this docum ent
shall be rep roduced, distr ibuted or changed, p artially or who lly, without formal a uthorization o f Samsung Techwin.

Disclaimer

Samsung Tech win makes the best to v erify the integr ity and correc tness of the conte nts in this documen t, but
no formal gu arantee shall be pr ovided. Use of this d ocument and the sub sequent results s hall be entirely on
the user’s ow n responsibilit y. Samsung Techwin rese rves the right to c hange the content s of this document
without p rior notice.

Warra nty

If the pro duct does not oper ate properly in no rmal conditions , please let us know. S amsung Techwin will res olve
the probl em for free of charge. T he warranty pe riod is 3 years. How ever, the followings ar e excluded:

•

If the sys tem behaves abnorm ally because you r un a program irrelev ant to the system ope ration.

•

Deterio rated perform ance or natural wor n-out in proces s of time

 Design and s pecifi cation s are subject to cha nge without prio r notice.

is the regis tered logo of Sams ung Techwin Co., Ltd.

Before operating the camera, confirm the camera model and correct input power voltage. To
help you understand this manual thoroughly, we'll introduce our model description.

■ SCB-2002 SERIES

• NTSC MODEL • PAL MODEL
SCB-3003N SCB-3003P

■ MODEL DESCRIPTION

• SCB-3003X

_

SIGNAL SYSTEM

• SIGNAL SYSTEM
N → NTSC MODEL
P → PAL MODEL

safety information

C

6

7

8

9

2

3

4

5

6

7

8

9

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

WARNING

To prevent damage which may result in fi re or electric shock hazard, do not expose this

•
appliance to rain or moisture.

To prevent injury, this apparatus must be securely attached to the fl oor/wall in accordance with

•
the installation instructions.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric
shock is present within this unit.

This exclamation point symbol is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

WARNING

1.

Be sure to use only the standard adapter that is specifi ed in the specifi cation sheet.
Using any other adapter could cause fi re, electrical shock, or damage to the product.

2.

Incorrectly connecting the power supply or replacing battery may cause explosion, fi re,
electric shock, or damage to the product.

3.

Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause
abnormal heat generation or fi re.

4.

Securely plug the power cord into the power receptacle. insecure connection may cause
fi re.

5.

When installing the camera, fasten it securely and fi rmly. The fall of camera may cause
personal injury.

4_ safety information

1

1

1

t

6.

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers
fi lled with water on top of the camera. doing so may cause personal injury due to fi re, electric
shock, or falling objects.

7.

Do not install the unit in humid, dusty, or sooty locations. doing so may cause fi re or electric
shock.

8.

If any unusual smells or smoke come from the unit, stop using the product. in such case,
immediately disconnect the power source and contact the service center. continued use in
such a condition may cause fi re or electric shock.

9.

c

e
e

If this product fails to operate normally, contact the nearest service center. never disassemble
or modify this product in any way. (samsung is not liable for problems caused by unauthorized
modifi cations or attempted repair.)

10.

When cleaning, do not spray water directly onto parts of the product. doing so may cause

fi re or electric shock.

● SAFETY INFORMATION

CAUTION

Do not drop objects on the product or apply strong shock to it. Keep away from a location

s

h

.

,

e

e

e

1.

subject to excessive vibrationor magnetic interference.

Do not install in a location subject to high temperature (over 55°C), low temperature (below

2.

-10°C), or high humidity. Doing so may cause fi re or electric shock.

If you want to relocate the already installed product, be sure to turn off the power and then

3.

move or reinstall it.

Remove the power plug from the outlet when then there is a lightning. Neglecting to do so

4.

may cause fi re or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause fi re.

5.

Install it in a place with good ventilation.

6.

Avoid aiming the camera directly towards extremely bright objects such as sun, as this may

7.

damage the CCD image sensor.

Apparatus shall not be exposed to dripping or splashing and no objects fi lled with liquids,

8.

such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at any time.

9.

Do not expose the camera to radioactivity. Radioactivity exposure may damage the CCD.

10.

English_5

safety information

m

2
3
4
5
6
7

8

9

i

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions :

This device may not cause harmful interference, and

1)
This device must accept any interference received including interference that may cause

2)
undesired operation.

CAUTION

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.

IC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian
Interference.-Causing Equipment Regulations of ICES-003.

Correct Disposal of This Product

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC
Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health
or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste
and recycle them through your local, free battery return system.

(Waste Electrical & Electronic Equipment)

6_ safety information

1

1

1
1

1

1

o

important safety instructions

Read these instructions.

e

1.

Keep these instructions.

2.

Heed all warnings.

3.

Follow all instructions.

4.

Do not use this apparatus near water.

5.

Clean only with dry cloth.

6.

Do not block any ventilation openings. Install in accordance with the manufacturer’s

7.

instructions.
Do not install near any heat sources such as radiators, heat registers, or other apparatus

8.

(including amplifi ers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

9.

has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not fi t into your outlet, consult an electrician for replacement of the
obsolete outlet.

10.

Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11.

Only use attachments/accessories specifi ed by the manufacturer.

12.

Use only with cart, stand, tripod, bracket, or table specifi ed by the

manufacturer, or sold with the apparatus.

13.

Unplug this apparatus when a card is used. Use caution when moving the

cart/ apparatus combination to avoid injury from tip-over.

14.

Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus

has been damaged in any way, such as powersupply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.

Apparatus shall not be exposed to dripping or splashing and no objects
fi lled with liquids, such as vases, shall be placed on the apparatus

Samsung Techwin cares for the environment at all product manufacturing
stages to preserve the environment, and is taking a number of steps to provide
customers with more environment-friendly products.The Eco mark represents
Samsung Techwin’s will to create environment-friendly products, and indicates
that the product satisfi es the EU RoHS Directive.

● SAFETY INFORMATION

English_7

contents

n

F

y

y

y

y

y

y

y

y

y

i

INTRODUCTION

9

CONNECTION

18

CAMERA OPERATION

21

TROUBLESHOOTING

39

SPECIFICATIONS

40

9

Features

11

Components and Accessories

11

Overview

15

Lens

18

Connecting to Monitor

18

Connecting to Power

19

Control via RS-485 Interface

20

Using Coaxial Communications

21

Menu Confi guration

21

Menu Setup

39

Troubleshooting

40

Specifi cations

42

Dimension

8_ contents

introduction

Features

y

High Resolution

By adopting a diagonal 6mm (1/3”) 520,000 pixel (NTSC), 610,000 pixel (PAL) Super HAD
CCD II, the camera produces clear picture quality with a horizontal resolution of Max 700TVL
in ER mode and

Excellent Sensitivity

y

The built-in high sensitivity COLOR CCD produces a clear image.

- Color : 0.1Lux @ F1.2, 0.0002 Lux (Sens-up, 512x)
B/W : 0.01 Lux @ F1.2, 0.00002 Lux ( Sens-up, 512x )

Intelligence

y

Without assistance from an external sensor, this camera independently detects and
traces objects while examining stillness and movement to activate the alarm.

SSNR3 (Samsung Super Noise Reduction) Function

y

High performance SV-V DSP Chip removes noises of GAIN resulting from the low light
level and shows a vivid, high defi nition video even in the dark place.

Day&Night (ICR)

y

This camera has a function that automatically selects the mode that is appropriate
for daytime or night-time conditions. The COLOR mode operates in daytime condi­tions to provide optimum colors, and B/W mode operates in night-time conditions to
enhance the defi nition of the image.

y

SSDR (Samsung Super Dynamic Range)

For images with high contrast between bright and dark areas from diffi cult lighting
conditions such as backlighting, this camera selectively illuminates darker areas while
retaining the same light level for brighter areas to even out the overall brightness.

y

PROFILE

You can set a mode according to the camera installation conditions.

- BASIC, DAYNIGHT, BACKLIGHT, ITS, INDOOR, USER,

y

PIP

Displays a full-size image along with the thumbnail.

WDR

y

By adopting a proprietary SV-V DSP chip, the camera delivers clear, high quality
pictures even in backlight, by increasing exposure in dark areas while decreasing it in
bright areas; a corrected image with clear details results.

700TVL

for BW .

● INTRODUCTION

English_9

introduction

C

C

O

VPS(Virtual Progressive Scan)

y

By adopting a proprietary SV-V DSP chip, the camera delivers clear, high quality
pictures even in backlight, by increasing exposure in dark areas while decreasing it in
bright areas; a corrected image with clear details results.

y

Video/DC Drive Lens Support

You can select Video or DC Drive Lens from the menu.

y

DIS (Digital Image Stabilizer)

The DIS function compensates for any camera movement, to produce more stable
pictures.

y

SIMPLE FOCUS

Using SIMPLE FOCUS, you can easily adjust the focus.

y

Miscellaneous Functions

HLC(High Light Compensation), SENS-UP, REVERSE , D-ZOOM, SHARPNESS and
PRIVACY functions are provided.

y

Communication

Coaxial and RS-485 communication methods are supported.

- Coaxial Communications : Pelco Coaxitron

- RS-485 Communications : Samsung-T, Samsung-E, PELCO-D, PELCO-P,

y

OSD

The camera’s OSD is complimented by 19 languages.

- NTSC : English, Korean, Japanese, Spanish, French, Portuguese

- PAL : English, Chinese, German, Italian, French, Spanish, Russian, Czech, Polish,
Romanian, Serbian, Swedish, Danish, Turkish, Portuguese

BOSCH, HONEYWELL, VICON, PANASONIC, GE, AD

10_ introduction

Components and Accessories

Check if the following items are included in the product package.

● INTRODUCTION

SCB-3003

Supreme Resolution
WDR Camera

Quick Guide

SCB-3003

Auto Iris Lens

Connector Plug

C-Mount Adapter

Quick Manual 10 level terminal block

Overview

Front View

➊

➋

❶

Tripod Mounting Bracket Screw Hole :

Used to fi x the Tripod Mounting Bracket to the top of the camera.

➋

C-Mount Lens Adapter : Install this adapter to use a C-Mount Lens.

English_11

introduction

Side View

➌

Auto Iris Lens Connector :

Used to connect Auto Iris Lens plug.

Bottom View



➍

➍

Tripod Mounting Bracket Screw Hole :

Used to fi x the camera on a bracket or tripod.
The screw sizes for this hole are as follows.



Tripod is not supplied with the camera. Please check the installed documentation of tripod for

M

the installation of cameras.

12_ introduction

1/4"-20 UNC (20 THREAD)
L:4.5mm±0.2mm (ISO standard),
or 0.197" (ASA standard)

L

Rear View

⓫

❿

⓬

● INTRODUCTION

➎

➏

➐
➑
➒

➎

Function Setup Button

SET button : (Short press) The SIMPLE FOCUS operates.

y

⓭

⓮

⓯

⓰

(Long press) The menu screen is displayed.

y

Up & Down button : Used to move the cursor up or down in the menu screen.
Left x right button : Move the cursor left and right on the menu screen.

y

➏

RS-485 Control Port : You can control SETUP MENU through this port by using

external controllers like a Remote controller that RS-485 Communication is supported.

➐

FREEZE Mode Setting Terminal : Turns on or off FREEZE function.

➑

V-SYNC Input Terminal : Enables External Sync.

➒

Shutter Speed Select Terminal : Selects external sync shutter speed.

Use it to go the lower menu on the menu screen.

If the menu screen is not desired, move the focus to Near or Far.

1/60 OFF OFF OFF
1/120 ON OFF OFF
1/250 OFF ON OFF
1/500 ON ON OFF
1/700 OFF OFF ON

1/1000 ON OFF ON

1/1600 OFF ON ON

1/2500 ON ON ON

SHUTTER 1 SHUTTER 2 SHUTTER 3

[Interlace mode]

English_13

introduction

L

T
T

❿

D & N Input Port : You can switch to Day & Night Mode by connecting an external

signal to this port.

⓫

MD Output Port : Motion detection signals are output through this port.

⓬

GND

⓭

Video OUT Terminal : Sends video signal and connects to the video input terminal of the monitor.

⓮

Power LED : This lamp is lit when the camera is receiving power normally.

⓯

Power input terminal : Connects to the power appropriate to each model.

⓰

Ground terminal

ö

External I / O port configuration

Num Name I/O Direction

1 RS-485+ I/O
2 RS-485- I/O
3 Freeze I
4 V-SYNC I

5-7 Shutter I

8DN I
9MD O

10 GND -

When using the FREEZE Mode Setting Terminal, the Shutter Speed Select Terminal and the D & N



M

Input Port, Connect each of the terminals to the Ground Terminal.

14_ introduction

Lens

The lens is not supplied with this camera. Purchase a lens suitable for your environment.
This camera accepts the auto iris lens and both C-and CS-mount lens.

.

To use the functions of this camera effectively it is recommended that a DC type Auto Iris lens is used.



M

Keep the lens surface clean, if it becomes contaminated with dirt or fi ngerprints the picture quality suffers.



When Using Auto Iris Lens

Strip the insulation of the auto iris lens cable 8mm from the end.

1.

approx. 8mm

Strip the insulation of the core of the auto iris lens cable to expose a 2mm

2.

length.

approx. 2mm

Remove the cover of the auto iris lens connector plug and solder the lens cable

3.

to the connector pin of the plug.

Pin No. DC VIDEO

LENS

No.1 Pin Damping - Red (power)

No.2 Pin Damping + NC

No.3 Pin Drive + White (video signal)

No.4 Pin Drive - Black (GND)

No.3 Pin

No.1 Pin

Connector

No.4 Pin

No.2 Pin

Lens cable

● INTRODUCTION

English_15

introduction

Fit the cover of the auto iris lens connector plug, remove the protective glass

4.

cover from the front of the camera, and fasten the auto iris lens by turning it
clockwise.

Combine the lens and adjust the focus manually fi rst. Then use SIMPLE FOCUS to

5.

easily adjust the focus.

When Using a C/CS-Mount lens

Before installing a lens, identify whether the lens to be installed is a C-Mount or CS-Mount.
This camera is set for a CS-Mount Lens by default. To install a C-Mount Lens, a simple
modification is required.

y

When Using a CS-Mount Lens

Remove the protective glass cover at
the front of this product and turn the
CS-Mount Lens clockwise to install it.
Combine the lens and adjust the focus
manually fi rst. Then use SIMPLE FOCUS
to easily adjust the focus.

16_ introduction

Use the lens connector shown in the following fi gure. If the



M

dimensions of the connector are not correct, it may damage
the camera, or the lens may not be installed fi rmly.

If the lens is too heavy, the camera becomes unbalanced and



there may be problems. Use a lens that weighs less than 450g.



When adjusting the Automatic Level Control (ALC) of an auto
iris lens, use Av mode if available. If you use the Pk mode, the
picture brightness may change continuously.

y

When Using a C-Mount Lens

Remove the protective glass cover at the

1.

front of this product and turn the C-Mount
Adapter clockwise to install it.

Turn the C-Mount lens clockwise to install it.

2.

3.

Combine the lens and adjust the focus
manually fi rst. Then use SIMPLE FOCUS to
easily adjust the focus.

C-Mount Lens: 10mm or less

CS-Mount Lens: 5mm or less

● INTRODUCTION

English_17

connection

W

ö

ö

C

T
C

1

2

y

Connecting to Monitor

Connect the Video OUT port on the rear panel of the camera to a monitor.

CCD Camera

CCD 카메라

y

As the connecting method varies with the instruments, refer to the manual supplied
with the instrument.

y

Only connect the cable when the power is turned off.

Monitor

모니터

Connecting to Power

Since power specifications differ depending on the model, make sure to check your model
name and specifications before connecting power.

You can connect power as shown in the following figure.

For AC / DC power

Since the power specification supports
both AC and DC, connect AC 24V, 500mA
Adaptor or DC 12V, 500mA Adaptor.

(

(

18_ installation

When the resistance value of copper wire is at [20°C(68°F)]

Copper wire size (AWG) #24 (0.22mm2) #22 (0.33mm2) #20 (0.52mm2) #18 (0.83mm2)

Resistance value(/m) 0.078 0.050 0.030 0.018

Voltage Drop (V/m) 0.028 0.018 0.011 0.006

As shown in the table above, voltage decreases as the wire gets longer.

y

Therefore use of an excessively long adaptor output line for connection to the camera
may affect the performance of the camera.

ö

Standard voltage for camera operation : DC 12V±10%, AC 24V±10%

ö

There may be some deviation in voltage drop depending on the type of wire and the

manufacturer.

Be sure to connect power only after all the installation is complete.



M

● INSTALLATION

Control via RS-485 Interface

The camera can be controlled by using external controllers like a Remote controller. (RS-485
Communication)

(1) To control by PC

Connect the RS-485 control port of the camera and the serial cable through an RS-485
converter.
Example) PC Serial Port (COM1)  Serial Cable RS-485 Converter  Camera RS-485Control Port.

(2) To control using a DVR or System Controller

Connect the RS-485 cable (TRX+, TRX-) to the connection port of the 485 control board
that is connected to the DVR or System Controller.

485 Control Board Connection Port RS-485 Control Port

(+) CONNECTION TERMINAL (TRX+) 485+

(- ) CONNECTION TERMINAL (TRX-) 485-

* RS-485 Communication establishment initial value

Item

Initial value

Camera ID BAUD RATE UART MODE RET PKT

1 19200 8-NONE-1 ENABLE

To control the camera by constructing an additional controller, use the SAMSUNG-T, SAMSUNG-E,



M

PELCO-D, PELCO-P, BOSCH, HONEYWELL, VICON and PANASONIC, GE, AD protocol.

English_19

connection

M

L

E

W

B

S

D

P

S

E

M

U

c

Using Coaxial Communications

y

Coaxial Communications System

y

OSD Control method

y

If you set the sensitivity level of the sub menu item (of COAX) to “Low”, you have to

press the MENU/ENTER (OSD KEY) button twice in a row to access the OSD menu.
(To prevent an error by noise from the DVR)

CAMERA DVR CONTROLLER

SET MENU/ENTER OSD KEY

UP UP KEY JOYSTICK UP

DOWN DOWN KEY JOYSTICK DOWN

LEFT LEFT KEY JOYSTICK LEFT

RIGHT RIGHT KEY JOYSTICK RIGHT

DVR

ALARM HDD NETWORK BACKUP REC

REC

1234

ZOOM

FREEZE

BACKUP

SEARCH

5678

9101112

TELE WIDE VIEWPRESET

MODE

AUDIO

ALRAM

MENU

DVD RECORDER

Video Cable

­The camera's video output port is connected to the monitor with a BNC coaxial
cable, shown below. If the distance between the camera and the monitor
exceeds the recommended maximum, please use an auxiliary video amp.

13 14 15 16

OPEN/CLOSE

M
E
N
U

S
E
AR
C
H

M
U
L
T
I

R
E
C

C
A
M

MO
N

P
T
Z

DV

1

R

M

2

T

3

6

4

7

5

8

9

0

Distance

USB

RETURN

M
E

N
U

P
R
E
S
E
T

G
R
O
UP

T
R
A
C

X

K
S
E
T
U
P

F
U
N

C
EN

T
E

E

R
S
C

C
LO
S
E

O

P
E

N
N
E
A
R

F
A
R

W
I
DE

T
ELE

: BNC

•

---- : RS-485

•

Recommended Cable

Specification

300m 3C2V(RG-59/U)

450m 5C2V(RG-6/U)

600m 7C2V(RG-11/U)



M

20_ installation

It is recommended that pure copper coax cable is used and not copper coated steel, as this will
cause issues with the communication over the coaxial cable.

camera operation

Menu Configuration

MAIN SETUP

LENS

.

EXPOSURE

WHITE BAL

BACKLIGHT

SSNR3

DAY/NIGHT

PROFILE

SPECIAL

EXIT

Menu Setup

Use the Function Setup button within the camera.

Press the SET button for more than three seconds.

l
r

1.

UP button

SET button

LEFT button

DOWN button

RIGHT button

●

DC

●

BRIGHTNESS ● SHUTTER

●

SENS-UP

●

ATW

●

MANUAL

●

OFF

●

SSDR

●

ON

●

AUTO

●

B/W

●

BASIC

●

ITS

● IMAGE ADJ ● CAM TITLE ● SYNC

● INTELLIGENCE ● PRIVACY ● DIS

● COMM ADJ ● LANGUAGE ● RETURN

● SAVE ● NOT SAVE ● RESET

●

VIDEO ● MANUAL

●

●

RETURN

●

OUTDOOR ● INDOOR

●

AWC→SET

●

USER BLC ● HLC

●

WDR

●

OFF

●

EXTERN

●

DAY/NIGHT

●

INDOOR

AGC

●

COLOR

●

BACKLIGHT

●

USER

● CAMERA OPERATION

English_21

camera operation

y

Main SETUP menu is displayed on the monitor screen.

Select the

function using

the Function

Setup button

2.

Select a desired function using the Function Setup button.

y

Place the cursor over a desired item.

3.

Set up a selected item by using The Function Setup button.

4.

To fi nish the setting, select ‘EXIT’ and press The set button .

An item with the icon also has sub menus. To select a sub menu, select an item with the icon



M

and press the set button.

An item with the --- icon is unavailable due to function settings.



LENS

Using this function, you can control the screen brightness.

When the SETUP menu screen is displayed, select‘LENS’by using the Function

1.

Setup button so that the arrow indicates‘LENS’.

Select the connected lens type by using the Function Setup button.

2.

y

DC/Video : Select Auto Iris Lens.

y

Manual : Select Manual Lens.

Each Lens mode has sub menu site as listed below.

3.

You can adjust the minimum
shutter and maximum value of
ESC shutter mode when DC
Lens mode is selected.

MAIN SETUP

䯝 1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

4. BACKLIGHT OFF

5. SSNR3 ON

6. DAY/NIGHT AUTO

7. PROFILE BASIC

8. SPECIAL

9. EXIT SAVE

Change the status by
moving the setup
switch left or right.

MAIN SETUP

䯝 1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

22_ camera operation

-

Brightness (DC, Manual) : Adjusts the video brightness.

-

Level (VIDEO) : Adjusts the level of video iris signals; the higher the level, the brighter
the video looks.

-

FOCUS ADJ (DC, VIDEO) :
To correctly adjust the focus of LENS, activate the focus setup mode located at
the bottom of each lens menu.
Go to the focus setup menu to adjust the focus of the lens. Then exit from the
mode exit. (The VIDEO lens requires an extra step: go to the sub menu of the
Focus Settings mode and change the shutter speed to adjust the lens brightness.)

1)

Set your focus to the next sequence.

y

FOCUS initialization : Move the focus to the default (BFL).

y

Lens adjustment : Manually adjusts the lens focus and make an image

y

AFTER D/N : Automatically adjust the focus of the video.

2)

ER D/N : After D or N is switched, select whether to use the focus

IRIS SPEED (DC) : Adjusts the Iris control speed of the DC lens. If the control speed is

-

n

When using VIDEO lens, adjust the lens VR explained below first and set the focus using 'FOCUS



M

ADJ' menu.

If color rolling occurs when using a DC lens, set Shutter to ---.





Some lenses may not work properly, depending on the setting of the BRIGHTNESS LEVEL.



When Using a Video-Type Auto Iris Lens

1)

Adjust the ALC adjustment terminal on the lens appropriately. In general, set it to AV
(Average).

2)

Adjust the ALC adjustment terminal on the lens appropriately. In general, set it to AV

(Average).

3)

Set AGC to OFF and adjust the Lens VR to an appropriate brightness.

4)

Adjust the Lens VR, adjust the BRIGHTNESS, and then check if the screen brightness

changes properly. Otherwise, adjust the Lens VR again.

※

Lens’ level VR may not operate depending on the type of lens.

look clearer.

readjustment function.

too slow or fast, please use this menu to adjust the speed.

● CAMERA OPERATION

English_23

camera operation

EXPOSURE

When the SETUP menu screen is displayed,

1.

select ‘EXPOSURE’ by using the Function
Setup button so that the arrow indicates
‘EXPOSURE’.

Select a desired mode using the Function

2.

Setup button.

y

BRIGHTNESS :

y

SHUTTER : You can select the shutter.

ESC : Select this to control the shutter

­speed automatically. If ESC is selected,
the shutter speed is automatically
controlled depending on the ambient
illumination of the subject.

-

MANUAL : You can control shutter speed manually.
(NTSC MODEL - 1/60sec~1/120,000sec, PAL MODEL - 1/50sec~1/120,000sec)

-

A.FLK : Select this when you experience picture flicker, this happen when there is

-

EXTERN : Use the Shutter Speed Select Terminal on the back of the camera to

-

--- : Shutter speed is fixed at 1/60 sec (1/50 sec).

Adjusts the video brightness.

a clash with the installed lighting frequency.

control the shutter speed via an external input. You can control the
desired speed as shown in the table below by connecting the terminal
to the Ground Terminal.

1/60(1/50) OFF OFF OFF

1/120(1/100) ON OFF OFF

1/250 OFF ON OFF

1/500 ON ON OFF

1/700 OFF OFF ON

1/1000 ON OFF ON

1/1600 OFF ON ON

1/2500 ON ON ON

SHUTTER 1 SHUTTER 2 SHUTTER 3

[Interlace Mode]

MAIN SETUP

1. LENS DC
䯝 2. EXPOSURE

3. WHITE BAL ATW

EXPOSURE SETUP

BRIGHTNESS

䯝 1.

2.SHUTTER ESC

3.AGC HIGH

4.SENS-UP OFF

5.RETURN

IIIIIÂIIIIIIIIIIIIIIII

25

24_ camera operation

When you use a DC lens, set the shutter mode to --- if color rolling occurs.



M

When the SHUTTER is set to ESC after selecting the Internal Synchronization Type, the picture



may become unstable if the camera faces a bright fl uorescent light. Therefore, take care when
choosing the installation position.

When the SHUTTER is set to MANUAL or A.FLK mode, SENS-UP will be disabled.




When using an external input, Connect the Shutter Speed Select Terminal to the Ground
Terminal.

y

AGC(AUTO GAIN CONTROL) : The higher the gain level, the brighter the screen - but

-

HIGH : Allows automatic gain control from 5.3dB to 42dB.

-

OFF : Deactivates the AGC function.

-

LOW : Allows automatic gain control from 5.3dB to 32dB.

y

SENS-UP : When it is night or dark, the camera automatically detects the light level and

maintains a clear picture if this mode is activated.

-

OFF : Deactivates the SENS-UP function.

-

AUTO : Activates the SENS-UP function.

If you set the Function Setup button to ‘AUTO’ mode, You can adjust the brightness by



M

increasing or decreasing the shutter speed. (x2 ~ x512)
Note that the higher the zoom level, the brighter the screen, but the more likely it is that an



after-image will appear.
Although Noise, Spots, and Whitish symptoms may occur in SENS-UP operation when the zoom



level is increased, this is normal.
If GAIN of EXPOSURE is not in use, the SENS-UP (Sensitivity-Up) is set to “---“.



y

RETURN : Return to the SETUP menu.

the greater the noise.

● CAMERA OPERATION

English_25

camera operation

White Bal (White Balance)

Use the White Balance function to adjust the screen color.

When the SETUP menu screen is displayed,

1.

select ‘White Bal’ by using the Function
Setup button so that the arrow indicates
‘White Bal’ .

2.

Select a desired mode using the Function
Setup button.

ö

Select one of the following 5 modes, as appropriate for your purpose.

y

ATW : Select this when the color temperature is between 2,400˚K and 10,500˚K.

y

y

y

y

M

OUTDOOR :

INDOOR :

MANUAL :

AWC⳨SET :

Select this when the color temperature is between 1,700˚K and 11,000˚K.
(sodium light inclusion) Select this When the color temperature of environment
surrounding the subject is out of the control range (e.g. clear sky, or sunset)

Select this when the color temperature is between 4,500˚K and 8,500˚K.

Select this to fi ne-tune White Balance manually. Set White Balance fi rst by using
the ATW or AWC mode. After that button to MANUAL mode, fi ne-tune the
White Balance and the Function Setup button.

To fi nd the optimal luminance level for the current environment, point the
camera towards a sheet of white paper and press the set button. If the
environment changes, readjust it.

White Balance may not work properly under the following conditions. In this case select the



OUTDOOR mode.

When the ambient illumination of the subject is dim.

1)

If the camera is directed towards a fl uorescent light or is installed in a place where illumination

2)

changes dramatically, the White Balance operation may become unstable.

MAIN SETUP

1. LENS DC

2. EXPOSURE
䯝 3. WHITE BAL ATW

4. BACKLIGHT OFF

5. SSNR3 ON

26_ camera operation

BACKLIGHT

The SCB-3003 is designed so that it delivers a distinctive subject and background at
the same time, even when the subject is in backlight, by adopting a function of the
proprietary SV-V DSP chip.

When the SETUP menu screen is displayed,

1.

select ‘BACKLIGHT’ by using the Function
Setup button. so that the arrow indicates
‘BACKLIGHT’.

Select a desired mode using the Function

2.

Setup button depending on the camera
purpose.

y

OFF :

t

e

n

Not being used

y

BLC :

Enables a user to select a desired area on a
picture and view that area more clearly.

-

LEVEL : Adjusts the brightness level of a

monitoring area.

-

TOP/BOTTOM/LEFT/RIGHT :
Adjust the area to be enhanced.

y

HLC (High Light Compensation) :

This function masks the strong light to minimize
white out due to over exposure and preserve much
of the on-screen details when the camera aims a
strong light source.

LEVEL : Adjusts the brightness level of a

­monitoring area.
LIMIT : Enable to change the operating condition.

­ MASK COLOR/TONE : Change the

­color / brightness of the masking area.
(Black, Red, Blue, Cyan, Magenta)
TOP/BOTTOM/LEFT/RIGHT : Adjust the area to be enhanced.

-

MAIN SETUP

1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW
䯝 4. BACKLIGHT OFF

5. SSNR3 ON

BLC SETUP

䯝 1. LEVEL

2. TOP

3. BOTTOM

4. LEFT

5. RIGHT

6. RETURN

䯝 1. LEVEL

2. LIMIT

3.

4. MASK TONE

5. TOP

6. BOTTOM

7. LEFT

8. RIGHT

9. RETURN

MIDDLE

IIIÂIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIÂIIIII

IIIÂIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIÂIIIII

HLC SETUP

MIDDLE

MASK COLOR BLACK

NIGHT ONLY

Â

IIIIIIIIIIIIIIIIIIIII

IÂIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIÂIII

IÂIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIÂII

25
90
70

150

5

10

105

10

210

● CAMERA OPERATION

English_27

camera operation

y

SSDR (Samsung Super Dynamic Range) :

SSDR illuminates darker areas of an image while
retaining the same light level for brighter areas
to even out the overall brightness of images with
high contrast between bright and dark areas.
Use the Function Setup button to change the
SSDR level in the sub menu according to the
contrast between bright and dark areas.

䯝 1. LEVEL

SSDR SETUP

IIIIIIIIIIIÂIIIIIIIIII

Press SET to Return

8

SSDR ON

y

WDR : When there are both bright and dark areas at the same time, this mode makes

both areas distinctive.

-

LIMIT : Adjust the WDR Sensitivity by
selecting LOW, MIDDLE, or HIGH.

-

LEVEL : Adjust the WDR Brightness by
controlling the bar from 1 to 10.

-

MODE : Indoor and outdoor backlight
conditions are appropriately selected.

-

ANTI ROLLING : Rolling caused around a
fluorescent lamp is improved.

3.

Select a desired mode using the Function Setup button.

SSDR OFF

WDR SETUP

䯝 1. LIMIT MIDDLE

2. LEVEL

3. MODE INDOOR

4. ANTI ROLLING OFF

5. RETURN

IIIIIIIIIÂIIIIIIIIIIII

28_ camera operation

5

Because there can be a difference in the effectiveness of HLC according to the amount of light



M

area in the screen, optimize the installation angle for the best HLC performance.
When dark, the HLC is only activated when a bright light exceeding a specifi c size. (In NIGHT



ONLY mode).
The HLC is not activated in day light or when bright light is not present at night. (In NIGHT ONLY



mode).
Using the WDR function, select the shutter mode can be either fi xed or A.FLK in the DC and Video



lens. And in the manual lens, select the shutter mode can be only ESC.

If you select the WDR, the following problems may occur depending on the lighting condition. So,



deactivate it if not necessary.

1)

In the case colors are unnaturally changed and the screen is unnaturally displayed.

2)

In the case a noise in the bright part of the screen occurs.



If you increase LIMIT, the screen display may be distorted.



If you use the VPS (Virtual Progressive Scan) function, the CCD reads differently so you can not use
WDR simultaneously. If you set VPS to ON, WDR will be automatically set to FIXED Mode.



The use of a DC lens than the manual lens is recommended to WDR optimal performance.



The D-ZOOM (Digital Zoom) and DIS (Digital Image Stabilization) functions are disabled if HLC
(Highlight Compensation) is enabled. (Set to “---“.)

SSNR3

This function reduces the background noise in a low luminance environment.

When the SETUP menu screen is displayed,

1.

select ‘SSNR3’ by using the Function Setup
button so that the arrow indicates ‘SSNR3’.

Select a desired mode using the Function

2.

Setup button.

y

ON : Activates SSNR3 so that noise is reduced.

y

OFF : Deactivates SSNR3. Noise is not reduced.

3.

Set the SSNR3 mode to ‘ON’ and press the
set button. Then you can adjust the noise
reduction level.

You cannot set the SSNR3 to ‘ON’ or ‘OFF’ when the AGC mode of the 'EXPOSURE' menu is ‘OFF’.



M

When adjusting the noise reduction level in the SSNR3 mode, remember that the higher the level set,



the more the noise level will be reduced, as will the brightness of the image.

MAIN SETUP

1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

4. BACKLIGHT OFF
䯝 5. SSNR3 ON

6. DAY/NIGHT AUTO

7. PROFILE BASIC

8. SPECIAL

9. EXIT SAVE

● CAMERA OPERATION

English_29

camera operation

DAY/NIGHT

You can display pictures in color or in black and white.

1.

When the SETUP menu screen is displayed,

select ‘DAY/NIGHT’ by using the Function
Setup button so that the arrow indicates
‘DAY/NIGHT’.

2.

Select a desired mode using the Function

Setup button according to the picture
display you want.

y

AUTO : The mode is switched to ’Color‘ in a
normal environment, but switches to ’B/W‘ mode
when ambient illumination is low. To set up the
switching time for AUTO mode, press the set
button. You can turn on or off the burst signal on
B/W mode.

-

DURATION : You can select the day/night

-

DWELL TIME : You can select day/night

※

y

EXTERN : Ground to the grounding terminal to allow automatic switching between

y

COLOR : The picture is always displayed in color.

y

B/W : The picture is always displayed in black and white.



M




switching point.

switching delay time from.

→

3s, 5s, 7s, 10s, 15s,
20s, 30s, 40, 60s

Fast 2.5 lux 5 lux

Slow 1 lux 7 lux

The day/night switching point of the camera can be adjusted.

COLOR and B/W (Black/White).

You can turn on or off the burst signal on B/W mode.

When using a Video Auto Iris Lens, if you set the lens level to low, automatic switching between
Color and Black & White may not occur.
If the GAIN of EXPOSURE menu is set to OFF, AUTO mode is not available to select.
When using an external input, Connect the D & N Input Port to the Ground Terminal.

Color → B/W B/W → Color

30_ camera operation

MAIN SETUP

1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

4. BACKLIGHT OFF

5. SSNR3 ON
䯝 6. DAY/NIGHT AUTO

7. PROFILE BASIC

8. SPECIAL

9. EXIT SAVE

AUTO SETUP

▶ 1.BURST MODE ON

2.COLOR→B/W
DURATION FAST
DWELL TIME 5 SEC

3.B/W→COLOR
DURATION FAST
DWELL TIME 10 SEC

4.RETURN

PROFILE

When the SETUP menu screen is displayed,

1.

select ‘PROFILE’ by using the Function
Setup button so that the arrow indicates
‘PROFILE’.

2.

Sel

ect a desired mode using the Function Setup button according to the picture

display you want.

y

BASIC : The most common environment is set to meet.

y

DAY/NIGHT : It will be set automatically so it optimizes to the day or night conditions,

y

BACKLIGHT : It will be set automatically so you can distinguish the object from the

y

ITS : It will be set automatically so you can easily check the traffi c conditions.

y

INDOOR : It will be set automatically to help you take a picture in a regular indoor lighting

y

USER : Automatically confi gures the camera to your custom settings.

1)

2)

3)

4)

In the PROFILE menu, you can confi gure the following camera settings at once.

.

3

respectively.

background in a severe backlighting scene.

condition.

Select Custom for Simple Setup mode.
Configure the menu options to your custom settings.
The settings are automatically saved as Custom mode.
Profile user mode don't initialize when menu resets.

BASIC DAYNIGHT

BACKLIGHT

SHUTTER ESC ESC ESC
GAIN HIGH HIGH HIGH HIGH HIGH -

n

WHITE BAL ATW ATW ATW OUTDOOR INDOOR -
BACKLIGHT OFF OFF USER BLC OFF OFF -
SSNR3 ON ON ON ON ON -

MAIN SETUP

1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

4. BACKLIGHT OFF

5. SSNR3 ON

6. DAY/NIGHT AUTO
䯝 7. PROFILE BASIC

8. SPECIAL

9. EXIT SAVE

ITS INDOOR USER

MANUAL(1/250)

A.FLK -

● CAMERA OPERATION

DAY/NIGHT AUTO AUTO AUTO AUTO AUTO -

English_31

SPECIAL

When the SETUP menu screen is displayed,

1.

select ‘SPECIAL’ by using the Function
Setup button so that the arrow indicates
‘SPECIAL’.

Select a desired mode using the Function

2.

Setup button.

y

IMAGE ADJ :

When the SPECIAL menu screen is

1)
displayed, select ‘IMAGE ADJ’ by using
the Function Setup button so that the
arrow indicates ‘IMAGE ADJ’.

Select a desired mode using the Function

2)
Setup button.

Monitor : Please change the settings value

­of video appropriate to your monitor.

LCD: Please select this menu item

•

when using an LCD monitor. You can
change the gamma, PED level and
color gain in the sub menus.

•

CRT: Please select this menu item

when using a CRT monitor. You can
change the PED level, color gain in
the sub menus.

•

USER : Please use this menu item

when using a monitor other than
standard ones. You can change the
gamma, PED level and color gain in
the sub menus.

MAIN SETUP

1. LENS DC

2. EXPOSURE

3. WHITE BAL ATW

4. BACKLIGHT OFF

5. SSNR3 ON

6. DAY/NIGHT AUTO

7. PROFILE BASIC
䯝 8. SPECIAL

9. EXIT SAVE

䯝 1. IMAGE ADJ

2. CAM TITLE OFF

3. SYNC INT

4. INTELLIGENCE OFF

5. PRIVACY OFF

6. DIS OFF

7. COMM ADJ

8. LANGUAGE ENGLISH

9. RETURN

䯝 1.MONITOR LCD

2.VPS OFF

3.REVERSE OFF

4.PIP OFF

5.D-ZOOM OFF

6.FONT COLOR

7.SHARPNESS ON

8.RETURN

䯝 GAMMA 0.55

# PED LEVEL

# COLOR GAIN

RESET

SPECIAL

IMAGE SETUP

LCD MONITOR

IIÂIIIIIIIIIIIIIIIIIII

IIIIIIIIIIÂIIIIIIIIIII

Press SET to Return

BLUE

14

5

32_ troubleshooting

VPS(Virtual Progressive Scan) :

-

This is an advanced technology that reproduces a sharp progressive image. This is
appropriate to high quality recording and file transfer via the Internet.

OFF : Selects 2:1 Interlaced Scan as the Imaging Method.

•
ON : Selects Progressive Scan as the Imaging Method.

•

REVERSE : You can reverse the picture.

-

OFF : You don’t reverse the picture.

•
H-REV : You can flip the picture horizontally on the screen.

•
V-REV : You can flip the picture vertically on the screen.

•
HV-REV : You can flip the picture horizontally and vertically on the screen.

•

PIP(Picture in Picture) : Displays a full-size

-

image along with the thumbnail to provide
more detailed information. The position of
the thumbnail is adjustable.

D-ZOOM : You can use a digital zoom

-

of x1 ~ x16.

FONT COLOR : You can change the OSD

-

font color. (White, Yellow, Green, Red, Blue)

SHARPNESS : As you increase this value,

-

the picture outline becomes stronger and
clearer. Adjust this value appropriately
depending on the sharpness of the picture.
ER mode is resolution priority. Using the
mode may cause deterioration (Thermalization)the video quality.

-

RETURN : Return to the SPECIAL menu.

When the V-REV or H-REV mode is enabled, the text on the screen does not fl ip.



M

If you increase the SHARPNESS level too high, the picture may become distorted or noise may



appear.

y

CAM TITLE : If you enter a title, the title will appear on

1)

2)

the monitor.

If the SPECIAL menu screen is displayed, use
the Function Setup button so that the arrow
indicates ‘CAM TITLE’.

Set it to ‘ON’ by using the Function Setup
button.

䯝 1. X POS

2. Y POS

3. RETURN

䯝 Level

PIP SETUP

IIIIIIIIIIIIIIIIIIIIIIIIIIÂIII

I

IIIIIIIIIIIIIIIIIIIIIIIIIIÂIII

I

SHARPNESS

IIIIIIIIIIIIIIIÂIIIIIIIIIIIIII

I

Press SET to Return

CAMERA TITLE SETUP

ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcdefghijklm
nopqrstuvwxyz

-.0123456789
←→ CLR POS END

_______________

English_33

● CAMERA OPERATION

I

17

I

17

I

15

camera operation

Press the set button.

3)

Use the Function Setup button to move to a desired letter and select the letter

4)
by pressing the set button. Repeat this to enter multiple letters. You can enter
up to 15 letters.

Enter a title, move the cursor to ‘POS’ and press

5)
the set button. The entered title appears on the
screen. Select the position to display the title on
the screen by using the Function Setup button
and press the set button. When the position
is determined, select ‘END’ and press the set
button to return to the SPECIAL menu.

When the CAM TITLE menu is ‘OFF’, no title will be displayed on the monitor screen even if you enter one.



M

and Numbers are available in this mode.



If you move the cursor to CLR and press the set button, all the letters are deleted. To edit a letter,



change the cursor to the bottom left arrow and press the set button. Move the cursor over the
letter to be edited, move the cursor to the letter to be inserted and then press the set button.

y

SYNC : In areas where the supply is at

60Hz(NTSC), 50Hz(PAL) frequency,
you can synchronize the output
phase of multiple cameras using
the power synchronization func­tion (Line-Lock) without using a
synchronization signal generator.

-

INT : Internal Synchronization Type

-

L/L : Power Synchronization Type, Line-lock

Press the set button.

1)
You can select a desired phase from 0 to 359 when select 'phase'.

2)

EXTERN : The camera can use the external power source frequency for

­the synchronization. Regardless of the input voltage the EXTERN MODE is
available only when an external trigger signal input into camera.

When using AC power at 60Hz(NTSC), 50Hz(PAL) frequency, you can use the L/L type



M

synchronization.
When the power is DC 12V, the SYNC menu is fi xed to the ‘INT’ mode.



When using an external input, the signal level must be +3 V (60 Hz ± 0.2). Otherwise, the



camera may malfunction and/or become damaged.

FRONT DOOR

䯝 PHASE

Press SET to Return

SYNC

IIIIIIIIIIIIIIIIIIIIIIIIIIIIII

Â

I

0

34_ camera operation

y

INTELLIGENCE :

Commands the camera to motion-detect and

.

r,

trace an object.

-

MOTION : Select motion types to detect.

OFF : Not being used.

•

DETECTION : Since the camera

•
detects motion without any additional
external sensor, you can monitor
activity more efficient.

•

TRACKING : Commands the camera
to detect and trace a moving object.

-

FENCE : You can select up to 4
FENCE.

-

MODE : Determines whether to use
the fence selected in the FENCE.

-

TYPE : Two types, line and area,
of fences are available.

-

COUNT : Displays how many times
a subject passes over the fence on the screen.

-

FILL : Fill or remove color from the FENCE.

POSITION :Defines the position and detection direction of a line or

-

fenced area.

INTELLIGENCE

䯝 1. MOTION OFF

2. DETECT BOX ON

3. ALARM OUT OFF

4. DETECT AREA

5. MASK AREA

# 6. SENSITIVITY

# 7. DETECT SIZE

8. RETURN

䯝 1. FENCE FENCE1

2. MODE OFF

3. TYPE LINE

4. COUNT OFF

5. FILL OFF
# 6. POSITION

7. RETURN

TRACKING

IIIIIIIIÂIIIIIIII

IIIIIIIIÂIIIIIIIII

● CAMERA OPERATION

3

3

1) LINE FENCE

-

SEL POS : Selects a position from
POS1,POS2.

-

X POS / Y POS : Adjust the size and
position of the selected line fence.

-

DIRECTION

y

DIR1 : Detects objects moving left

to right on the fence line.

y

DIR2 : Detects objects moving right to left on the fence line.

y

DIR1/2 : Detects all objects moving crosswise on the fence line.

-

RETURN : Return to the TRACKING menu.

LINE FENCE

䯝 1. SEL POS POS1

# 2. X POS

# 3. Y POS

4. DIRECTION DER1

5. RETURN

IIÂIIIIIIIIIIIIIIII

Â

IIIIIIIIIIIIIIIIII

12

1

English_35

camera operation

2) AREA FENCE
SEL POS : Selects a position from

-

-

-

fenced area.

-

FENCE:

-

FIXED/MOVED : Detects an object that emerges or disappears from the

•

A detection (FIXED/MOVED) error may occur if :



M

multiple motions occur continuously in random directions

-

a fixed object moves in one position continuously

-

-

a second object screens the fi rst moving object

DETECT BOX : Outlines an object on the screen in a box when its movement

­matches a custom Motion Type.

-

ALARM OUT : Releases a signal from the MD Output Port on the back of the
camera when an object’s movement matches a custom Motion Type.

-

DETECT AREA : Motion Detection and
tracking will only occur within this defined
area. (Full Screen is defined as factory
default).

-

MASK AREA : Specify a detection
exception area to mask.

number and specify the size and position.

•

AREA : You can select up to 4 areas.

•

MODE : Determines whether to use

•

TOP / BOTTOM / LEFT / RIGHT :
Adjust the size and position of the
selected area.

36_ camera operation

POS1 ~ POS4.

X POS / Y POS : Adjust the size
and position of the selected area
fence.

DIRECTION

IN : Detects objects entering the

y

OUT : Detects objects exiting the fenced area

y

IN/OUT : Detects all objects entering and exiting the fenced area.

y

Return to the TRACKING menu.

RETURN :

Return to the INTELLIGENCE menu.

screen, or stays onscreen without movement.

Select a mask area

the area selected in the
AREA.

AREA FENCE

䯝 1. SEL POS POS1

# 2. X POS

# 3. Y POS

4. DIRECTION IN

5. RETURN

䯝 1.TOP

2.BOTTOM

3.LEFT

4.RIGHT

5.RETURN

䯝 1.AREA

2.MODE

3.TOP

4.BOTTOM

5.LEFT

6.RIGHT

7.RETURN

IIÂIIIIIIIIIIIIIIII

Â

IIIIIIIIIIIIIIIIII

DETECT AREA

Â

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

Â

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIII

MASK AREA

IIIIIÂIIIIIIIIIIIIIIII

IIIIIIIIIIIIÂIIIIIIIII

Â

IIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIÂIIIIIIIII

Â

Â

12

AREA1

OFF

110

110

1

1

50

1

50

30

25

RETURN : Select this to save the MASK AREA menu settings and return

•

SENSITIVITY : Set the sensitivity of the motion detection. When you adjust the

­lower level, the more sensitive.

DETECT SIZE : Selects an object size to detect on the screen. When you

­adjust higher levels, the more larger size.

RETURN : Return to the SPECIAL menu.

-

y

PRIVACY :

Mask an area you want to hide on the screen.

1)

When the SPECIAL menu screen is
displayed, press the set button so that
the arrow indicates ‘PRIVACY’.

2)

Set up the mode using the Function
Setup button.

-

AREA : You can select up to 12 PRIVACY areas.

-

MODE : Determines whether to use the
area selected in the AREA.

-

MASK COLOR : Determine area color.
You can select Green, Red, Blue, Black,
White, Gray.

-

TRANSPARENCY : Adds or removes transparency from the masking area.

-

SEL POS/ XPOS/ YPOS : Adjust the size and position of the selected area.

-

RETURN :



M

y

DIS (Digital Image Stabilizer) :



M




to the INTELLIGENCE menu.

PRIVACY AREA SETUP

䯝 1. AREA AREA1

2. MODE OFF

3. MASK COLOR GREEN

4. TRANSPARENCY OFF

5. SEL POS

6. X POS

7. Y POS

8. RETURN

Â

IIIIIIIIIIIIIIIIIIIII

Â

IIIIIIIIIIIIIIIIIIIII

Return to the SPECIAL menu.

In case two functions, PRIVACY and FENCE of intelligence video are simultaneously set up to
be overlapped, PRIVACY masking is exposed partially due to the transparency trait of the
FENCE.

This function mitigates any picture movement due to
external factors such as wind.

As the DIS function uses the digital zoom, the camera's resolution will decrease.
DIS doesn’t operate when background illumination is too low.
DIS doesn’t operate when object pattern is monotonic as like sky or white wall.

L_TOP

10
10

● CAMERA OPERATION

English_37

camera operation

t

T

T

T

T

c

T
w

T

C

T

W
a

y

COMM ADJ (Communication Adjustment) :
This function sets up the camera communication status when controlling the camera
through an external control device.

When the SPECIAL menu screen is

1)
displayed, press the set button so that the
arrow indicates ‘COMM ADJ’.

Set up the mode using the Function

2)
Setup button.

-

CAM ID : Determines the camera's identification

number (between 0 and 255).

-

BAUD RATE : You can select 2400/4800/9600/

-

UART MODE : You can select NONE, EVEN or ODD for the parity bits.

-

RET PKT : Determines whether to send a command back to the controller device when a

-

DISP ID : Display camera title on top left corner of the screen.
PROTOCOL : Select the communication PROTOCOL. (SAMSUNG-T, SAMSUNG-E , PELCO-D,

-

COAX :

-

RETURN : Rreturn to the SPECIAL menu.

-

y

LANGUAGE :

y

RETURN :

19200/38400/57600 bps.

communication control command is sent to the camera.

PELCO-P, BOSCH, HONEYWELL, VICON, PANASONIC, GE and AD)

You can select whether to use COAX communication.
If you use the COAX communication, you prevent malfunctions by selecting
low sensitivity levels against noise.

You can select the menu language according to your requirements.

Return to the MAIN SETUP menu.

COMM SETUP

Â

IIIIIIIIIIIIIIIIIIIII

1

OFF

SAMSUNG-T

ON

䯝 1. CAM ID

2. BAUD RATE 19200

3. UART MODE 8-N-1

4. RET PKT ENABLE

5. DISP ID

6. PROTOCOL

7. COAX

8. RETURN

EXIT

Select a desired EXIT mode using the Function Setup button depending on the
camera purpose.

y

SAVE : Save the current settings and exit the MAIN SETUP menu.

y

NOT SAVE : Do not save the current settings and exit the MAIN SETUP menu.

y

RESET : Resets the camera settings to the factory defaults. Communication,

Language and Monitor settings are not initialized.

If
If

38_ camera operation

troubleshooting

,

If you have trouble operating your camera, refer to the following table.
If the guidelines do not enable you to solve the problem, contact an authorized technician.

Problems Troubleshooting

Nothing appears on the screen. Check that the power cord and line connection between the

The image on the screen is dim. Is lens stained with dirt? Clean your lens with soft, clean cloth.

The image on the screen is dark. Adjust the contrast feature of the monitor or DVR.

The camera is not working
properly, and the surface of the
camera is hot.

he DAY/NIGHT menu does not work. Check that AGC of EXPOSURE SETUP menu is ‘OFF’.

The SENS-UP function does not
work.

The INTELLIGENCE function does
not work.

Color is not correct. Check the setting of WHITE BAL SETUP menu

The screen flickers continually. Ensure the camera is not pointing towards the sun.

When coaxial communication is not
available

y

camera and monitor are properly connected.

Check that you have properly connected BNC cable to the camera.

y

y

Check the type of lens.

y

Set the monitor or DVR to the proper condition.

y

If the camera is exposed to very strong light, change the camera

y

position.

y

If you have an intermediate device, set the 75Ω / Hi-z properly.

y

Check that you have properly connected the camera to an

y

appropriate power source.

y

Check that AGC of EXPOSURE SETUP menu is ‘OFF’.

y

Check that SHUTTER of EXPOSURE SETUP menu is ‘A.FLK’ or
‘MANUAL’.

Check that INTELLIGENCE of menu is ‘OFF’.

y

y

y

Make sure that the camera and monitor are installed within the

y

recommended distance.

Use the video amplifi er equivalent to coaxitron if the recommended

y

installation distance is exceeded.

● TROUBLESHOOTING

Troubleshooting

English_39

specifications

M

P

S
(

G

W

E
S

D

R

P

V

I

P

A

C

P

E

O
/

E

P

M

C

D

W

※

Specifications

SCB-3003N SCB-3003P

Video
Imaging Device 1/3 Super HAD CCD II (Double Scan)
Total Pixels 1,028(H) x 508(V) 1,028(H) x 596(V)
Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
Scanning System 2:1 Interlace
Synchronization Internal / Line-Lock / Extern
Frequency H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz

Horizontal Resolution

Min. Illumination

S / N Ratio 52dB (AGC off, Weight on)
Video Output CVBS : 1.0 Vp-p / 75 composite

Lens Type
Focus Control Simple Focus / Manual / After DN
Lens Type Manual / Auto Iris (Video/DC)
Mount Type C/CS

Operational

On Screen Display

Camera Title Off / On (Displayed 15 characters)
Day & Night Auto (ICR) / External / Color / B/W

Backlight Compensation

Wide Dynamic Range

Contrast Enhancement

Digital Noise Reduction

Digital Image Stabilization

Color : 700 TV lines(ER mode).
B/W : 700 TV lines

Color : 0.1Lux @ F1.2, 0.0002 Lux (Sens-up, 512x)
B/W : 0.01 Lux @ F1.2, 0.00002 Lux ( Sens-up, 512x )

Multi-language Support
Multi-language Support
English, Japanese, Spanish,
French, Portuguese,Korean

Off / User BLC / HLC / SSDR / WDR
52dB (AGC off, Weight on)
SSDR
SSNRII ( Off / On )
Off / On

English, French, German, Spanish,

Italian, Chinese, Russian, Polish,

Czech, Romanian, Serbian, Swedish,

Danish, Turkish, Portuguese

40_ specifi cations

I

SCB-3003N SCB-3003P

Motion Detection Built-in
Privacy Masking Off / On (12 programmable zones with polygonal masking)

Sens-up
(Frame Integration)

2x ~ 512x

● SPECIFICATIONS

Gain Control Off / Low / High

White Balance

Electronic Shutter
Speed

Digital Zoom

ATW / Outdoor / Indoor / Manual / AWC (1,700K° ~ 11,000K°)

1/60 ~ 1/120,000 sec 1/50 ~ 1/120,000 sec

Off / On (1x ~ 16x)

Reverse Off / H-Rev / V-Rev / HV-Rev
Profi le Basic, Day & Night, Backlight, ITS, Indoor, User
VPS Off / On
Intelligent Video Fixed_Moved, Fence, Tracking, Detection, Counting
PIP Off / On
Alarm 1 Out
Communication Coaxial Control, RS-485

Protocol

Coax : Pelco-C (Coaxitron)
RS-485: Samsung-T, Samsung-E, Pelco-D, Pelco-P, Panasonic,

Bosch, Honeywell, Vicon, GE, AD

Environmental

Operating Temperature
/ Humidity

Electrical

Input Voltage

Power Consumption

-10°C ~ +55°C / Less than 90% RH

Dual ( 24VAC±10% & 12VDC±10% )
Max. 5.4W

Mechanical

Color / Material

Dimension (WxHxD)

Weight

※

The specifi cation for this product may change without prior notice for product improvement.

Black, Silver / Aluminum, Plastic

73.1 x 67.2 x 123.9 mm (2.88” x 2.65” x 4.88”) excluding projections
285g

English_41

Dimension

Unit: mm

42_ specifi cations

MEMO

SALES NETWORK

SAMSUNG TECHWIN CO., LTD.

Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400
TEL : [phone]~60, FAX : [phone]

SAMSUNG TECHWIN AMERICA Inc.

100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : [phone] Direct : [phone]
Fax : [phone]
www.samsungcctvusa.com

www.samsungtechwin.com
www.samsungsecurity.com

SAMSUNG TECHWIN EUROPE LTD.

Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS

TEL : [phone], FAX : [phone]
