Samsung SC5115, SC5100 User Manual
EN
Operating Instructions
For household use only
VACUUM CLEANER
❈ Before operating this unit, please read the instructions carefully.
Register your product at www.samsung.com/global/register
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be fol-lowed,
including the following :
READ ALL INSTRUCTIONS BEFORE USING
THIS VACUUM CLEANER.
WARNING
To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.
4. Use only as described in this manual. Use only manufacturer’s recommended attachments.
5. Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, take it to a service center.
6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around
sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any opening blocked: keep free of dust,
lint, hair and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all other parts of the body away from openings and
moving parts.
11. Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot
ashes.
12. Do not use without dust bag and filters in place.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs.
15. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas
where they may be present.
16. Store your vacuum cleaner indoors in a cool, dry area.
17. Do not use extension cords or an outlet with inadequate current carrying capacity.
18. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.
19. Unplug electrical appliances before vacuuming them.
20. The hose contains electrical wires. Do not use if damaged, cut, or punctured.
Avoid picking up sharp objects.
21. Always turn off this appliance before connecting or disconnecting either hose, wand or
motorized nozzle.
EN-1
SAVE THESE INSTRUCTIONS
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider
than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a qualified electri-cian
to install the proper outlet. Do not change the plug in any way.
EN-2
ASSEMBLING THE CLEANER
1
OPTION
OPTION
Features may vary according to model.
▼
Parking floor nozzle for easier storage.
EN-3
OPERATING THE CLEANER
2
2-1 POWER CORD
2-3 POWER CONTROL
1) HANDLE CONTROL TYPE
• SLIDE TO THE STOP POSITION
Vacuum cleaner switches off(stand by mode)
• SLIDE FORWARD TO MAX
Suction capacity increase smoothly up to maximum.
2) BODY CONTROL TYPE
MIN =
For delicate surface e.g. net curtains.
MAX =
For hard floors and heavily soiled carpets.
2-2 ON/OFF SWITCH
(BODY CONTROL TYPE ONLY)
NOTE
Grasp the plug to
disconnect cord from
the electrical outlet.
HANDLE CONTROL TYPE ONLY
EN-4
BODY CONTROL TYPE ONLY
2-4 AIR CONTROL
To reduce suction for cleaning draperies,
small rugs, and other light fabrics, pull
the tap air until the hole is open.
2-5 USING CYCLONE FILTER (OPTIONAL)
BODY CONTROL TYPE ONLY
EN-5
2-6 USING FLOOR TOOLS
Carpets
Bare floors
CREVICE
OPTION
Features may vary according to model.
▼
Transparent tube (optional)
EN-6
DUSTING
DUST FULL INDICATOR
3
If the "Filter Check" indicator turns to red color while you
are cleaning, the dust bag requires replacement
NOTE : If the "Filter Check" indicator continues to dis-
CHANGING THE DUST BAG
4
1
45
23
play red color even after having changed bag
into new one, turn the cleaner off and check if
there is any clogging in the hose,tube,floor
nozzle,or on the inlet/outlet filter.
OPTIONAL
●
FOR TEXTILE FILTER BAG
If the textile filter bag gets full after using,
clean the textile filter bag and use it again.
EN-7
VP-95B TYPE
