Samsung SC4127 User Manual

VACUUM CLEANER

❈ Before operating this unit, please read the instructions carefully. ❈ For indoor use only.

Operating instructions

For household use only

EN-1

When using an electrical appliance, basic precautions should always be followed, including the following:

To reduce the risk of fire, electric shock, or injury.

1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.

2. Do not use outdoors or on wet surfaces.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

4. Use only as described in this manual. Use only manufacturer’s recommended attachments.

5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a service center.

6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.

7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

8. Do not handle plug or appliance with wet hands.

9. Do not put any object into openings. Do not use with any opening blocked: keep free of dust, lint, hair, and anything that may reduce air flow.

10. Keep hair, loose clothing, fingers, and all other parts of the body away from

openings and moving parts.

11. Do not vacuum anything that is burning or smoking, such as cigarettes,

matches, or hot ashes.

12. Do not use without dust bag and filters in place.

13. Turn off all controls before unplugging.

14. Use extra care when cleaning on stairs.

15. Do not use to vacuum flammable or combustible liquids such as gasoline or

use in areas where they may be present.

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER

IMPORTANT SAFETY INSTRUCTIONS

WARNING

EN-2

To reduce the risk of electric shock, this appliance has a polarized plug(one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

16. Store your vacuum cleaner indoors in a cool, dry area.

17. Do not use extension cords or an outlet with inadequate current carrying

capacity.

18. Unplug electrical appliances before vacuuming them.

19. Hold plug when rewinding onto cord reel. Do not allow plug to whip when

rewinding.

SAVE THESE INSTRUCTIONS

EN-3

1. ASSEMBLING THE CLEANER

▲

Features may vary according to model.

▲

For storage, park the floor nozzle.

▲

Tool storage

OPTION

2. OPERATING YOUR CLEANER

MIN = For delicate fabrics, e.g. net

curtains.

MAX = For hard floors and heavily

soiled carpets.

2-1 POWER CORD 2-2 ON/OFF SWITCH

2-3 POWER CONTROL(VOLUME TYPE ONLY)

MIN

MAX

To reduce suction for cleaning draperies, small rugs and other light fabrics, slide the air vent until the hole is open.

2-4 SUCTION CONTROL

Located on the left rear side of the cleaner.

1) Disconnect the hose from the body of the cleaner.

2) Connect the hose clamper to the blow hole.

2-5 USING THE BLOWER

NOTE :

When removing the plug from the socket, please take care to grasp the plug, not the cord in order to avoid

undue stress.

EN-4

- Dusting brush for furniture. shelves, books, etc.

- Crevice tool for radiators, crevices, corners, between cushions.

- For efficiency. clean Floor Nozzle with Crevice Tool.

DUSTING BRUSH CREVICE TOOL

EN-5

▲

Features may vary according to model.

Floor Nozzle

OPTION OPTION

OPTION

Crevice

Dusting

2-6 USING FLOOR TOOLS
