Samsung SC01J Users Manual
User Manual
DRAFT
DRAFT, Not FINAL
SC-01J
English (EU). 01/2015. Rev.1.0
a ana ana na and a dd a n aa and a
n na d a and a a ad dn
www.samsung.com
Table of Contents
DRAFT
DRAFT, Not FINAL
Basics
4 Read me first
5 Package contents
6 Device layout
8 SIM or USIM card
11 Battery
15 Turning the device on and off
16 Touchscreen
19 Home screen
25 Lock screen
27 Notification panel
30 Entering text
33 Screen capture
33 Opening apps
34 Multi window
38 Device and data management
44 Connecting to a TV
46 Emergency mode
53 More
58 Sound and notification
58 Display
59 Motions & gestures
59 Applications
60 Wallpaper
60 Themes
60 Lock screen & security
65 Privacy & safety
68 Easy mode
68 Accessibility
69 Accounts
70 Backup and reset
70 Language and input
71 Battery
71 Storage
72 Date and time
72 User manual
72 About device
Settings
47 Introduction
47 Wi-Fi
49 Bluetooth
51 Tethering and Mobile hotspot
52 Flight mode
52 Data usage
53 Mobile networks
Applications
73 Installing or uninstalling apps
74 Phone
77 Contacts
79 Messages
80 Internet
81 Email
2
Table of Contents
DRAFT
DRAFT, Not FINAL
82 Camera
98 Gallery
99 Smart Manager
100 S Planner
102 S Health
105 S Voice
106 Music
107 Video
107 Voice Recorder
110 My Files
110 Memo
111 Clock
112 Calculator
113 Google apps
115 Microsoft apps
Appendix
116 Accessibility
131 Troubleshooting
136 Removing the battery (non-removable
type)
3
Basics
DRAFT
DRAFT, Not FINAL
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
•
•
Depending on the region or model, some devices are required to receive approval from
the Federal Communications Commission (FCC). If your device is approved by the FCC,
you can view the FCC ID of the device. To view the FCC ID, tap Settings→ About
device→ Battery Info.
Supprted features may differ or labelled differently depending on whether your
device is a single or dual SIM Model.
4
Basics
DRAFT
DRAFT, Not FINAL
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
Package contents
Check the product box for the following items:
•
Device
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
5
Basics
SIM card tray
Microphone
DRAFT
DRAFT, Not FINAL
Device layout
Speaker
LED indicator
Proximity/Light sensor
Touchscreen
Recents key
Headset jack
Microphone
Multipurpose jack
Front camera
Power key
Home key (Fingerprint
recognition sensor)
Back key
Loud speaker
Microphone
GPS antenna
Infrared port
Volume key
Rear camera
Flash
NFC antenna/Wireless
charging coil
Main antenna
6
Basics
DRAFT
DRAFT, Not FINAL
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touchscreen. The touchscreen may malfunction
in humid conditions or when exposed to water.
Keys
Key Function
•
Press and hold to turn the device on or off.
Power
•
Press to turn on or lock the screen.
•
Tap to open the list of recent apps.
Recents
•
Tap and hold to launch the split screen view.
Home
Back
Volume
•
Press to turn on the screen while the screen is locked.
•
Press to return to the Home screen.
•
Press and hold to launch
•
Tap to return to the previous screen.
•
Press to adjust the device volume.
Google
.
7
Basics
DRAFT
DRAFT, Not FINAL
SIM or USIM card
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
•
Only nano-SIM cards work with the device.
•
Some LTE services may not be available depending on the service provider. For
more information about service availability, contact your service provider.
Insert the ejection pin into the hole on the SIM card tray to loosen the tray.
1
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may
be damaged.
Pull out the SIM card tray gently from the SIM card tray slot.
2
8
Basics
DRAFT
DRAFT, Not FINAL
Place the SIM or USIM card on the SIM card tray with the gold-coloured contacts facing
3
downwards.
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
Insert the SIM card tray back into the SIM card tray slot.
4
9
Basics
DRAFT
DRAFT, Not FINAL
Removing the SIM or USIM card
Insert the ejection pin into the hole on the SIM card tray to loosen the tray.
1
Pull out the SIM card tray gently from the SIM card tray slot.
2
Remove the SIM or USIM card.
3
Insert the SIM card tray back into the SIM card tray slot.
4
10
Basics
DRAFT
DRAFT, Not FINAL
Battery
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
•
If you use multiple apps at once, network apps, or apps that need a connection
to another device, the battery will drain quickly. To avoid disconnecting from the
network or losing power during a data transfer, always use these apps after fully
charging the battery.
•
Using a power source other than the USB power adaptor, such as a computer, may
result in a slower charging speed due to a lower electric current.
Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable
into the multipurpose jack.
11
Basics
DRAFT
DRAFT, Not FINAL
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
•
If the device receives an unstable power supply while charging, the touchscreen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device and the charger may heat up. This is normal and should
not affect the device’s lifespan or performance. If the battery gets hotter than usual,
the charger may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
After fully charging, disconnect the device from the charger. First unplug the charger from the
device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•
Optimise the device using the Smart manager.
•
When you are not using the device, switch to sleep mode by pressing the Power key.
•
Activate power saving mode.
•
Close unnecessary apps.
•
Deactivate the Bluetooth feature when not in use.
•
Deactivate the Wi-Fi feature when not in use.
•
•
•
Deactivate auto-syncing of apps.
Decrease the backlight time.
Decrease the screen brightness.
12
Basics
DRAFT
DRAFT, Not FINAL
Fast charging
The device has a built-in fast charging feature. You can use this feature to charge the battery
more quickly while the device or its screen is turned off.
About Fast charging
•
Fast charging uses battery charging technology that charges the battery faster by
increasing the charging power. The device supports Samsung’s Adaptive fast charging
feature and Qualcomm Quick Charge 2.0.
•
To use Fast charging on your device, connect it to a battery charger that supports
Adaptive fast charging or Quick Charge 2.0.
Increasing the charging speed
To increase the charging speed, turn the device or its screen off when you charge the battery.
•
While charging the battery when the device is turned off, the icon appears on the
screen.
•
You cannot use the fast charging feature when the screen is turned on. Turn off the
screen to increase the charging speed.
•
You cannot use the built-in fast charging feature when you charge the battery
using a standard battery charger.
•
If the device heats up or the ambient air temperature rises, the charging speed may
decrease automatically. This is a normal operating condition to prevent damage to
the device.
13
Basics
DRAFT
DRAFT, Not FINAL
Wireless charging
The device has a built-in wireless charging coil. You can charge the battery using a wireless
charging pad (sold separately).
Place the centre of the device’s back on the centre of the charging pad.
1
You can check the remaining charge time on the screen. The actual remaining time may
vary depending on the charging conditions.
After fully charging, disconnect the device from the charging pad.
2
•
You can check the battery’s charging status from the battery icon on the screen.
•
When there are foreign materials between the device and the wireless charging
pad, the device may not charge properly.
•
If you use the wireless charging pad in areas with weak signals, you may lose
reception.
Power saving mode
Save the battery power by limiting the device’s functions.
On the Home screen, tap
the switch to activate it.
To automatically activate power saving mode when the remaining battery power reaches the
preset level, tap
To set the device to disable sync in the background while using a mobile network, tap the
Enable Power saving mode when
Apps
→
Settings
→
Battery
→
Power saving mode
and select an option.
, and then tap
Restrict background data
switch to activate it.
14
Basics
DRAFT
DRAFT, Not FINAL
Ultra power saving mode
Use this mode to extend the device’s battery power. In ultra power saving mode, the device
performs the following:
•
Displays colours on the screen as grey tones.
•
Restricts the available apps to essential and selected apps only.
•
Deactivates the mobile data connection when the screen turns off.
•
Deactivates the Wi-Fi and Bluetooth features.
On the Home screen, tap
then tap the switch to activate it.
To deactivate ultra power saving mode, tap
The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.
Apps
→
Settings
→
Battery
MORE
→
Ultra power saving mode
→
Disable ultra power saving mode
, and
.
Turning the device on and off
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow the on-
screen instructions to set up your device.
To turn off the device, press and hold the Power key, and then tap
•
If your device is frozen and unresponsive, press and hold the Power key and the
Power off
.
Volume key down simultaneously for more than 7 seconds to restart it.
•
Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
15
Basics
DRAFT
DRAFT, Not FINAL
Touchscreen
•
Do not allow the touchscreen to come into contact with other electrical devices.
Electrostatic discharges can cause the touchscreen to malfunction.
•
To avoid damaging the touchscreen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touchscreen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touchscreen when you do not use the
device.
•
It is recommended to use fingers when you use the touchscreen.
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen, tap it with your finger.
16
Basics
DRAFT
DRAFT, Not FINAL
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.
Dragging
To move an item, tap and hold it and drag it to the target position.
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
17
Basics
DRAFT
DRAFT, Not FINAL
Swiping
Swipe to the left or right on the Home screen or the Apps screen to view other panels. Swipe
upwards or downwards to scroll through a webpage or a list of items, such as contacts.
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
18
Basics
DRAFT
DRAFT, Not FINAL
Home screen
Home screen
The Home screen is the starting point for accessing all of the device’s features. It displays
widgets, shortcuts to apps, and more.
To view other panels, swipe to the left or right, or tap one of the screen indicators at the
bottom of the screen.
A widget
An app
Favourite apps
A folder
Screen indicators
Apps screen icon
19
Basics
DRAFT
DRAFT, Not FINAL
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to access
the available options. Customise the Home screen by adding, deleting, or rearranging Home
screen panels. You can also set the Home screen wallpaper, add widgets to the Home screen,
and more.
•
Wallpapers
•
Widgets
app functions to provide information and convenient access on your Home screen.
•
Themes
and wallpapers, will change depending on the selected theme.
•
Screen grid
screen.
: Change the wallpaper settings for the Home screen and the locked screen.
: Add widgets to the Home screen. Widgets are small apps that launch specific
: Change the device’s theme. Visual elements of interface, such as colours, icons,
: Change the size of the grid to display more or less items on the Home
20
Basics
DRAFT
DRAFT, Not FINAL
Flipboard Briefing
View the latest articles in various categories. You can get up to date on news that interests
you using this feature.
On the Home screen, tap
or downwards to browse articles in each news category.
To deactivate Flipboard Briefing, tap and hold an empty area on the Home screen. Then,
swipe to the right and deselect the tick box at the top of the Flipboard Briefing panel.
or swipe to the right to open Flipboard Briefing. Swipe upwards
Adding items
Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.
To add widgets, tap and hold an empty area on the Home screen, tap
widget, and then drag it to the Home screen.
Widgets
, tap and hold a
Moving and removing an item
Tap and hold an item on the Home screen, and then drag it to a new location.
To move the item to another panel, drag it to the side of the screen.
You can also move frequently used apps to the shortcuts area at the bottom of the Home
screen.
To remove an item, tap and hold the item. Then, drag it to
Remove
at the top of the screen.
21
Basics
DRAFT
DRAFT, Not FINAL
Creating folders
On the Home screen, tap and hold an app, and then drag it over another app.
1
Drop the app when a folder frame appears around the apps.
2
A new folder containing the selected apps will be created.
Tap the area above the horizontal line and enter a folder name.
3
To change the folder colour, tap
To add more apps to the folder, tap and hold another app, and then drag it to the folder.
.
Managing panels
On the Home screen, tap and hold an empty area to add, move, or remove a panel.
To add a panel, swipe to the left, and then tap
To move a panel, tap and hold a panel preview, and then drag it to a new location.
To remove a panel, tap and hold a panel preview, and then drag it to
the screen.
To set a panel as the main Home screen, tap
.
Remove
.
at the top of
22
Basics
DRAFT
DRAFT, Not FINAL
Apps screen
The Apps screen displays icons for all apps, including newly installed apps.
On the Home screen, tap
left or right, or select a screen indicator at the bottom of the screen.
Moving items
On the Apps screen, tap
To move the item to another panel, drag it to the side of the screen.
Creating folders
On the Apps screen, tap
1
Tap and hold an app, and then drag it over another app.
2
Drop the app when a folder frame appears around the apps.
3
A new folder containing the selected apps will be created.
Apps
to open the Apps screen. To view other panels, swipe to the
EDIT
. Tap and hold an item and drag it to a new location.
EDIT
.
23
Basics
DRAFT
DRAFT, Not FINAL
Tap the area above the horizontal line and enter a folder name.
4
To change the folder colour, tap
To add more apps to the folder, tap and hold another app, and then drag it to the folder.
.
Indicator icons
Indicator icons appear on the status bar at the top of the screen. The icons listed in the table
below are most common.
The status bar may not appear at the top of the screen in some apps. To display the
status bar, drag down from the top of the screen.
Icon Meaning
No signal
Signal strength
Roaming (outside of normal service area)
/
GPRS network connected
EDGE network connected
UMTS network connected
HSDPA network connected
HSPA+ network connected
LTE network connected (LTE-enabled models)
Wi-Fi connected
Bluetooth feature activated
GPS activated
Call in progress
Missed call
New text or multimedia message
Alarm activated
Mute mode activated
Vibration mode activated
24
Basics
DRAFT
DRAFT, Not FINAL
Icon Meaning
Flight mode activated
Error occurred or caution required
Battery power level
Lock screen
Locking and unlocking the screen
Pressing the Power key turns off the screen and locks it. Also, the screen turns off and
automatically locks if the device is not used for a specified period.
To unlock the screen, press the Power key or the Home key and swipe in any direction.
You can change the way that you lock the screen to prevent others from accessing your
personal information.
On the Apps screen, tap
select a screen lock method. The device requires an unlock code whenever unlocking it.
If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.
Settings
→
Lock screen & security
→
Screen lock type
, and then
25
Basics
DRAFT
DRAFT, Not FINAL
Pattern
Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.
Set a backup PIN to unlock the screen when you forget the pattern.
PIN
A PIN consists of numbers only. Enter at least four numbers, and then enter the password
again to verify it.
Password
A password consists of characters and numbers. Enter at least four characters including
numbers and symbols, and then enter the password again to verify it.
Fingerprint
Register your fingerprints to unlock the screen. Refer to
information.
Fingerprint recognition for more
Dynamic lock screen
Set the locked screen’s wallpaper to change automatically based on your settings, your
location and weather, and your interests.
On the Home screen, tap and hold an empty area, and then tap
1
Alternatively, on the Apps screen, tap
Tap →
2
Select a wallpaper option.
3
•
From Gallery
Lock screen
: Select images from
.
Settings
Gallery
→
Wallpaper
. The device will display the images on the
Wallpapers
.
.
locked screen at the interval you set.
•
Live weather
on the time, weather, and your location information.
•
My interests
images on the locked screen based on your interests.
•
You may incur additional charges when using this feature.
•
This feature may not work properly depending on your region.
: The device will display high quality images on the locked screen based
: Select categories that interest you. The device will display high quality
26
Basics
Rearrange quick setting buttons.
DRAFT
DRAFT, Not FINAL
Notification panel
Using the notification panel
When you receive new notifications, such as messages or missed calls, indicator icons appear
on the status bar. To see more information about the icons, open the notification panel and
view the details.
To open the notification panel, drag the status bar downwards. To close the notification panel,
swipe upwards on the screen.
You can use the following functions on the notification panel.
Activate or deactivate options.
Tap and hold a button to view
more detailed settings.
Launch S Finder.
Tap a notification and perform
various actions.
Launch Settings.
Adjust the brightness.
Launch Quick Connect.
Clear all notifications.
Rearranging quick setting buttons
To rearrange quick setting buttons on the notification panel, tap
EDIT
, tap and hold an item,
and then drag the item to another location.
27
Basics
DRAFT
DRAFT, Not FINAL
S Finder
Search for a wide variety of content with a keyword.
Searching for content on the device
Open the notification panel and tap
Enter a keyword in the search field or tap
To get more refined results, tap the filter buttons under the search field, and then select filter
details.
S Finder
and say a keyword.
.
Setting search categories
You can set search categories to search for content in specific search fields.
Tap
MORE
→
Select search locations
and select categories.
Quick Connect
Automatically search for nearby devices and quickly connect to them.
•
When connecting to a device that does not support the Quick connect feature,
ensure that Wi-Fi Direct or the Bluetooth feature is activated.
•
Connection methods may vary depending on the type of connected devices or the
shared content.
Connecting to other devices
Open the notification panel and tap
1
When the panel opens, the Wi-Fi and the Bluetooth features are activated automatically
and the device searches for nearby devices.
The list of devices registered to your Samsung account appears at the top of the
screen.
Quick Connect
.
28
Basics
DRAFT
DRAFT, Not FINAL
Select a device from the list and connect to it by following the on-screen instructions.
2
The next steps may vary depending on the connected device.
To allow nearby devices to search for your device and connect to it, tap
→
device visibility
Device visibility
, and then select an option.
Re-searching for devices
If the desired device does not appear in the list, search for the device.
Tap
REFRESH
and select the device from the list of detected devices.
Deactivating the Quick connect feature
To deactivate the Quick connect feature, tap
.
Sharing content
Share content with the connected devices.
Open the notification panel and tap
1
Quick Connect
.
MORE
→
Set
Select a device from the list of detected devices.
2
Tap
3
4
Send content
Follow the on-screen instructions to send content to the connected device.
The next steps may vary depending on the selected media category.
and select a media category.
29
Basics
DRAFT
DRAFT, Not FINAL
Entering text
Keyboard layout
A keyboard appears automatically when you enter text to send messages, create memos, and
more.
Text entry is not supported in some languages. To enter text, you must change the
input language to one of the supported languages.
Enter uppercase. For all caps, tap
it twice.
Enter punctuation marks.
Change the keyboard settings.
Delete a preceding character.
Break to the next line.
Enter a space.
Changing the input language
Tap
two or more languages, you can switch between the input languages by swiping to the left or
right on the space key.
→
Select input languages
, and then select the languages to use. When you select
Changing the keyboard layout
Tap
, select a language under
On
3x4 keyboard
, a key has three or four characters. To enter a character, tap the
Input languages
, and then select a keyboard layout to use.
corresponding key repeatedly until the desired character appears.
30
Loading...
