Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
VIDEO AMP MERGED OSD PROCESSOR
The S1D2502B01 is a very high frequency video amplifier
& wide range OSD processor 1 chip system with I2C Bus
control used in monitors. It contains 3 matched R/G/B video
amplifiers with OSD processor and provides flexible
interfacing to I2C Bus controlled adjustment systems.
FUNCTIONS
ORDERING INFORMATION
• R/G/B video amplifier
• OSD processor
• I2C bus control
• Cut-off brightness control
• R/G/B sub contrast/cut-off control
• Half tone
S1D2502B01-D0B0 32-DIP-600A -20 °C — +75 °C
FEATURES
VIDEO AMP PART
32-DIP-600A
Device Package Operating Temperature
• 3-channel R/G/B video amplifier, 175MHz @f-3dB
• I2C bus control items
— Contrast control: -38dB
— Sub contrast control for each channel: -12dB
— Brightness control
— OSD contrast control: -38dB
— Cut-off brightness control (AC coupling)
— Cut-off control for each channel (AC coupling)
— Switch registers for SBLK and video half tone and
CLP/BLK polarity selection and INT/EXT CLP selection
and generated CLP width control
• Built in ABL (automatic beam limitation)
• Built in video input clamp, BRT clamp
• Built in video half tone (3mode) function on OSD
pictures
• Capable of 8.0Vp-p output swing
• Improvement of rise & fall time (2.2ns)
• Cut-off brightness control
• Built in blank gate with spot killer
• Clamp pulse generator
• OSD intensity
• BLK, CLP polarity selection
• Clamp gate with anti OSD sagging
• Built in 1K-byte SRAM
• 448 ROM fonts (each font consists of 12 × 18
dots.)
• Full screen memory architecture
• Wide range PLL available (15kHz — 90kHz,
Reference 800 X 600)
• Programmable vertical height of character
• Programmable vertical and horizontal
positioning
• Character color selection up to 16 different
colors
• Programmable background color (up to 16
colors)
• Character blinking, bordering and shadowing
• Color blinking
• Character scrolling
• Fade-in and fade-out
• Box drawing
• Character sizing up to four times
• 72MHz pixel frequency from on-chip PLL
(Reference 800 X 600)
0
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
BLOCK DIAGRAM
6
VDDA
VDD
VSS
VCC3
GND3
VREF1
VREF
ABL
CONT_CAP
RIN
GND1
VCC1
31
ROM
(448 x 18 x 12)
28
Font Data
11
12
Output Stage
9
R/G/B OSD
FBLK
4
Intensity
9 16
ROM
Address
Display Ctrl
H/V/CLK Ctrl
Timing Controller
Band
Gap.Ref
Multi (3 mode)
5
8
7
12
ABL
Video
Input
Clamp
15
CLP
OSD
R OSD
13
Input
Cilp.
HT DET.
Half Tone
Video
Half Tone
SW
I2CFBLK
OSD
Half Tone
SW
FBLK I2C
(480 x 16)
Ctrl Font
Controller
Sub
Cont.
Control
OSD
Cont.
Control
ROM
Display
H/V/CLK Ctrl
RGB OSD
FBL
INTE
HT DET.
I2C
I2C
RAM Data
Frame Ctrl
ROM Ctrl
Frame Ctrl
ROM Ctrl
BLK
CLP
Video
Contrast
Control
Register
BLK
Clamp
Pulse
Gen.
+
I2C Cont. Cntl
Data Receiver
16Ctrl Data
CLK
H_Pulse
V_Pulse
I2C bus
decoder
D/A
R cut off
Int
G cut off
HFLB
B cut off
Sub
Cont.
Control
OSD
PLL
Latches
Amp
Birght
Control
CLPI2C
Out
V/I
V/I
V/I
BLK
2
VSSA
32
HFLB
1
VFLB
3
VCO_IN_P
30
SDA
SCL
29
27
RCT
26
GCT
25
BCT
10
CLP_IN
24
R OUT
22
VCC2
23
R CLP
GND2
19
GIN
BIN
14
16
G OSD
B OSD
G-CHANNEL
CLP HT DET. FBLK CLP BLKI2C
B-CHANNEL
CLP HT DET. FBLK CLP BLKI2C
Figure 1. Functional Block Diagram
20
21
17
18
G CLP
G OUT
B CLP
B OUT
1
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
PIN CONFIGURATION
1
VFLB
VSSA
2
VCO_IN_P
3
4
VREF1
5
VREF
6
VDDA
CONT_CAP
7
ABL_IN
8
9
GND3
CLP_IN
10
VCC3
11
S1D2502B01
HFLB
VDD
SDA
SCL
VSS
RCT
GCT
BCT
ROUT
RCLP
VCC2
32
31
30
29
28
27
26
25
24
23
22
12
13
14
15
16
RIN
VCC1
GIN
GND1
BIN
GOUT
GCLP
GND2
BOUT
BCLP
21
20
19
18
17
Figure 2. Pin Configuration
2
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 1. Pin Configuration
Pin No. Symbol I/O Configuration
1 VFLB I Vertical flyback signal
2 VSSA - Ground (PLL part)
3 VCO_IN_P I
4 VREF1 O Charge pump output
5 VREF O PLL regulator filter
6 VDDA - +5V supply voltage for PLL part
7 CONT_CAP - Contrast control for AMP part
8 ABL - Auto beam limit.
9 GND3 - Ground for video AMP part(for AMP control)
10 CLP_IN - Video clamp pulse input
11 VCC3 - +12V supply voltage for video AMP part(for AMP control)
12 RIN I Video signal input (red)
13 VCC1 - +12V supply voltage for video AMP(for main video signal process)
14 GIN I Video signal input (green)
15 GND1 - Ground for video AMP part(for main video signal process)
16 BIN I Video signal input (blue)
17 BCLP - B output clamp cap
18 BOUT O Video signal output (blue)
This voltage is generated at the external loop filter and goes into the
input stage of the VCO.
19 GND2 - Ground for video AMP part(for video output drive)
20 GCLP - G output clamp cap
21 GOUT O Video signal output (green)
22 VCC2 - +12V supply voltage for video AMP part(for video output drive)
23 RCLP - R output clamp cap
24 ROUT O Video signal output (red)
25 BCT - B cut-off output
26 GCT - G cut-off output
27 RCT - R cut-off output
28 VSS - Ground for digital part
29 SCL I
30 SDA I/O
31 VDD - +5V supply voltage for digital part
32 HFLB I Horizontal flyback signal
Serial clock (I2C)
Serial data (I2C)
3
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
PIN DESCRIPTION
Table 2. Pin Description
Pin No Pin Name Schematic Description
1
32
3
4
5
VFLB
HFLB
VCO_IN_P
VPEF/
VREF
7 Contrast cap
(CONT_CAP)
VFLB
HFLB
4.0K
FLB signal is in TTL level
Multi polarity input
PLL loop filter output
BandGap ref. output
Contrast cap range
(0.1uF — 5uF)
VrefI2C Data
100µA
8 ABL_IN
4
100K
2K
VCC
ABL input DC range
(1 — 4.5V)
VrefVref
250µA
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 2. Pin Description (Continued)
Pin No Pin Name Schematic Description
10 CLP_IN Multi polarity input
VCC
50K
Clamp gate pulse TTL level
input
10K
12
14
Red video input
(RIN)
Green video input
VCC
Max input video signal is 0.7
Vpp
VCC
(GIN)
16
Blue video input
(BIN)
Video_In
0.2K
17
20
23
Blue (B clamp cap)
Green (G clamp cap)
Red (R clamp)
0.2K
0.2K
12K
Brightness controlling actives by
charging and discharging of the
external cap. (0.1µF)
(During clamp gate)
CLP
Iclamp
5
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Table 2. Pin Description (Continued)
Pin No Pin Name Schematic Description
18
21
24
27
26
25
Blue video output
(BOUT)
Green video output
(GOUT)
Red video output
(ROUT)
Red cut-off control
(RCT)
Green cut-off control
(GCT)
Blue cut-off control
(BCT)
VCC
0.05K
0.5K
0.04K
Isink
0-600uA 0-200uA 50uA 100uA
Video_Out
0.2K
Video signal output
Cut-off control output
CTX
29 SCL
30 SDA
Serial clock input port of I2C bus
SCL
Serial data input port of I2C bus
SCL
ACK
6
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
ABSOLUTE MAXIMUM RATINGS
(see 1)
(Ta = 25 °C)
Table 3. Absolute Maximum Ratings
Value
No Item Symbol
Min Typ Max
1 Maximum supply voltage
2
Operating temperature
(see 2)
V
CC
V
DD
Topr -20 - 75 °C
- - 13.2
- - 6.5
3 Storage temperature Tstg -65 150 °C
4 Operating supply voltage
V
V
5 Power dissipation P
CCop
DDop
D
11.4 12.0 12.6
4.75 5.00 5.25
- - W
THERMAL & ESD PARAMETER
Table 4. Thermal & ESD Parameter
Unit
V
V
(see 3)
No Item Symbol
Value
Min Typ Max
Thermal resistance
1
(junction-ambient)
θja - 48 - °C/W
2 Junction temperature Tj - 150 - °C
Human body model
3
(C = 100p, R = 1.5k)
Machine model
4
(C = 200p, R = 0)
HBM 2 - - KV
MM 300 - - V
5 Charge device model CDM 800 - - V
Unit
7
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
ELECTRICAL CHARACTERISTICS
DC ELECTRICAL CHARACTERISTICS
(Tamb = 25 °C, VCC = 12V, VDD = V
= 5V, ABL input voltage = 5V, HFLB input signal = S3, load resistors =
DDA
470Ω, except OSD part current 35mA, unless otherwise stated)
Table 5. DC Electrical Characteristics
Parameter Symbol Conditions
Supply current ICC
Minimum supply current ICC min VCC = 11.4V 95 110 120 mA
Maximum supply current ICC max VCC = 12.6V 105 130 140 mA
ABS supply current ICC abs VCC = 13.2V - - 175 mA
Video input bias voltage V bias 1.8 2.1 2.4 V
Video black level voltage (POR) V blackpor 1.20 1.50 1.80 V
Black level voltage channel difference (POR) ∆ V blackpor
Video black level voltage (FFH) V blackff
Black level voltage channel difference (FFH) ∆ V blackff ∆ 10 - - %
Video black level voltage (00H) V black00 04 = 00H - 0.2 0.5 V
Black level voltage channel difference (00H) ∆ V black00 ∆ 10 - - %
Spot killer voltage Vspot VCC = Var. 9.20 10.4 11.2 V
(see 4)
(see 5)
04 = FFH
(see 13)
Min Typ Max
100 125 130 mA
∆ 10 - - %
2.2 2.7 3.2 V
Value
Unit
Cut-off current (FFH) ICTff Pin25, 26, 27 = 12V
09 — 0B: FFH
0C: 00H
Cut-off current (00H) ICT00 Pin25, 26, 27 = 12V
09 — 0C: 00H
Cut-off brightness current (FFH) ICTBRTff Pin25, 26, 27 = 12V
09 — 0B: 00H
0C: FFH
Cut-off brightness current (80H) ICTBRT80 Pin25, 26, 27 = 12V
09 — 0B: 00H
0C: 80H
Cut-off offset current 1 ICS1 Pin25, 26, 27 = 12V
09 — 0C: 00H
0E: 11H
500 625 750 µA
- 2.0 5.0 µA
100 180 260 µA
50 90 130 µA
25 50 75 µA
8
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 5. DC Electrical Characteristics (Continued)
Parameter Symbol Conditions
Value
Min Typ Max
Cut-off offset current 2 ICS2 Pin25, 26, 27 = 12V
50 100 130 µA
09 — 0C: 00H
0E: 12H
Soft BLK output voltage Vsblk 0D: 80H
- 0.2 0.5 V
0E: 14H
Clamp cap voltage (POR) Vcap 6.0 7.0 8.0 V
Total external cut-off current range
Red
cut-off
Creen
cut-off
Blue
cut-off
600uA
Unit
Cut-Off Brightness
Cut-Off Offset
Switch
CS2
CS1
200uA
100uA
50uA
150uA
9
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
AC ELECTRICAL CHARACTERISTICS
(Tamb = 25 °C, VCC = 12V, VDD = V
470Ω, Vin = 0.7Vpp manually adjust video output pins 18, 21 and 24 to 4V DC for the AC test
otherwise stated
(see 12)
)
= 5V, ABL input voltage = 5V, HFLB input signal = S3, load resistors =
DDA
(see 11)
unless
Table 6. AC Electrical Characteristics
Parameter Symbol Conditions
Min Typ Max
Contrast max. output voltage Vcff 03, 05, 06, 07 = FFH
Contrast max. output channel difference ∆ Vcff ∆ 10 - - %
04, 08 — 0C = 80H
RGB input = S1
Contrast center output voltage Vc80 03, 04, 08 ~ 0C = 80H
Contrast center output channel difference ∆ Vc80 ∆ 10 - - %
05, 06, 07 = FFH
RGB input = S1
5.0 5.7 6.4 Vpp
2.5 2.85 3.2 Vpp
Contrast max. - Center attenuation C C = 20log (Vc80/Vcff) -8 -6 -4 dB
Sub contrast center output voltage Vd80 03 = FFH
Sub contrast center output channel
∆ Vd80 ∆ 10 - - %
difference
Sub contrast min. output voltage Vd00
Sub contrast min. output channel difference ∆ Vd00 ∆ 10 - - %
04 — 0C = 80H
RGB input = S1
03 = FFH, 05—07: 00H
04, 08 — 0C = 80H
2.3 2.6 2.9 Vpp
1.3 1.6 1.9 Vpp
RGB input = S1
Sub contrast max. - min. attenuation D D = 20log (Vd00/Vcff) -14 -12 -10 dB
ABL control range ABL
R/G/B video rising time
R/G/B video falling time
(see 7)
(see 7)
R/G/B blank output rising time
R/G/B blank output falling time
R/G/B video band width
(see 7, 8)
(see 7)
(see 7)
tr (video) 03, 05 ~ 07: FFH
tf (video) - 2.2 2.8 ns
tr (blank) POR
tf (blank) - 8.0 15.0 ns
f (-3dB)
Video AMP 50MHz cross talk CT_50M
(see7, 9)
(see 15)
04, 08 ~ 0C: 80H
RGB input = S2
HFLB: S4
(see 16)
(see 17)
-12 -10 -8 dB
175 - - MHz
Value
- 2.2 2.8 ns
- 6.0 12.0 ns
- -25 -20 dB
Unit
Video AMP 130MHz cross talk CT_130M
(see7, 9)
Absolute gain match Avmatch
Gain change between amplifier Avtrack
(see 7)
10
(see 6)
(see 18)
- -15 -10 dB
-1 - 1 dB
-1 - 1 dB
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
OSD ELECTRICAL CHARCTERISTICS
(Tamb = 25 °C, VCC = 12V, VDD = V
= 5V, HFLB input voltage = S3, load rosistors = 470Ω, V-AMP test
DDA
registor’s FBLK, OSD input conditions unless otherwise stated)
Table 7. OSD Electrical Chaacteristics
Parameter Symbol Conditions
OSD contrast max. output voltage Vocff 08 = FFH
OSD contrast max. output channel
difference
OSD contrast center output voltage Voc80 08 = 80H
OSD contrast center output channel
difference
R/G/B OSD rising time tr (OSD) 08: FFH - 4.0 5.0 ns
R/G/B OSD falling time tf (OSD) - 4.0 5.0 ns
HT video level HTvideo ABL = 6V
HT video output channel difference ∆ HTvideo ∆ 15 - - %
HT OSD level HTosd ABL = 6V
HT OSD output channel difference ∆ HTosd ∆ 15 - - %
∆ Vocff ∆ 10 - - %
∆ Voc80 ∆ 10 - - %
OSD RGB output conditions
OSD RGB output conditions
RGB input = S1
03, 05 — 08: FFH
0D: 01H
OSD black conditions input
HTvideo = 20log(V
05 — 08: FFH
0D: 0FH
OSD white condition input
HTosd = 20log (V
htvideo/Vcff
htosd/Vocff
Min Typ Max
-6.0 -4.5 -3.0 dB
)
-7.0 -5.5 -4.0 dB
)
Value
5.4 6.4 7.4 Vpp
2.7 3.2 3.7 Vpp
Unit
11
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
OPERATION TIMINGS
Table 8. Operation Timings
Parameter Symbol Min Typ Max Unit
Input Signal HFLB, VFLB
Horizontal flyback signal frequency f
Vertical flyback signal frequency f
I2C Interface SDA, SCL (Refer to Figure 3)
SCL clock frequency f
Hold time for start condition t
Set up time for stop condition t
Low duration of clock t
High duration of clock t
Hold time for data t
Set up time for data t
Time between 2 access t
Fall time of SDA t
Rise time of both SCL and SDA t
HFLB
VFLB
SCL
hs
sus
low
high
hd
sud
ss
fSDA
rSDA
- - 120 kHz
- - 200 Hz
- - 300 kHz
500 - - ns
500 - - ns
400 - - ns
400 - - ns
0 - - ns
500 - - ns
500 - - ns
- - 20 ns
- - - ns
SDA
SCL
ths
tsud
thigh
tss
tlow
Figure 3. I2C Bus Timing Diagram
thd
tsus
12
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
OSD PART ELECTRICAL CHARACTERISTICS
OSD PART DC ELECTRICAL CHARACTERISTICS
(Ta = 25 °C, V
= VDD = 5V)
DDA
Table 9. OSD Part DC Electrical Characteristics
Parameter Symbol Min Typ Max Unit
Supply voltage V
Supply current
(no load on any output)
Input voltage V
Output voltage
(lout = ±1mA)
Input leakage current I
VCO input voltage V
I
DD
V
V
V
VCO
DD
IH
IL
OH
OL
IL
4.75 5.00 5.25 V
- - 25 mA
0.8V
DD
- - V
- - VSS + 0.4 V
0.8V
DD
- - V
- - VSS + 0.4 V
-10 - 10 µA
2.5 V
13
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
NOTES:
1. Absolute maximum rating indicates the limit beyond which damage to the device may occur.
2. Operating ratings indicate conditions for which the device is functional but do not guarantee specific performance limits.
For guaranteed specifications and test conditions, see the electrical characteristics. The guaranteed specifications apply
only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under
the listed test conditions.
3. VCC supply pins 11, 13, and 22 must be externally wired together to prevent internal damage during VCC power on/off
cycles.
4. The supply current specified is the quiescent current for VCC1/VCC2 and VCC3 with RL = ∞, The supply current
for VCC2 (pin 22) also depends on the output load.
5. Output voltage is dependent on load resistor. Test circuit uses RL = 470Ω
6. Measure gain difference between any two amplifiers Vin = 700mVpp.
7. When measuring video amplifier bandwidth or pulse rise and fall times, a double sided full ground plane printed circuit
board without socket is recommended. Video amplifier 50MHz cross talk test also requires this printed circuit board. The
reason for a double sided full ground plane PCB is that large measurement variations occur in single sided PCBs.
8. Adjust input frequency from 10MHz (AV max reference level) to the -3dB frequency (f -3dB).
9. Measure output levels of the other two undriven amplifiers relative to the driven amplifier to determine channel separation.
Terminate the undriven amplifier inputs to simulate generator loading. Repeat test at fin = 50MHz for cross talk 50MHz.
10. A minimum pulse width of 200 ns is guaranteed for a horizontal line of 15kHz. This limit is guaranteed by design. if a lower
line rate is used a longer clamp pulse may be required.
11. During the AC test the 4V DC level is the center voltage of the AC output signal. For example. If the output is 4Vpp the
signal will swing between 2V DC and 6V DC.
12. These parameters are not tested on each product which is controlled by an internal qualification procedure.
13. The conditions block’s 03, 04, 05... etc. signify sub address’ 0F03, 0F04, 0F05... etc.
14. Sub address 0F03, 0F05 ~ 0F07: FFH
0F04, 0F08 ~ 0F0C: 80H
RGB input = S1,
When the ABL input voltage is 0V, the R/G/B’s output voltage is VR/VG/VB and uses the formula ABLR = 20log (VR/V
15. OSD TST mode = High, CLP operation off,
RGB input = S5 (frequency sweep),
RGB input clamp cap = 2.1V DC,
RGB clamp cap (pin 23/20/17) = Vcap voltage (7.0V),
S5’s frequency 1MHz → 130MHz sweep, -3dB point = 20log (V
130MHz/V1MHz
)
03, 05 ~ 07: FFH
04, 08 ~ 0C: 80H
0F: 80H
16. OSD TST mode = High, CLP operation off,
RGB input clamp cap = 2.1V DC,
RGB clamp cap (pin 23/20/17) = Vcap voltage (7.0V),
03, 05 ~ 07: FFH
04, 08 ~ 0C: 80H
0F: 80H
R input = S5 (50MHz)
CT_50M = 20log (V
outG/VoutR
) or 20log (V
outB/VoutR
)
17. OSD TST mode = High, CLP operation off,
RGB input clamp cap = 2.1V DC,
RGB clamp cap (pin 23/20/17) = Vcap voltage (7.0V),
03, 05 ~ 07: FFH
04, 08 ~ 0C: 80H
0F: 80H
R input = S5 (130MHz)
CT_150M = 20log (V
outG/VoutR
) or 20log (V
outB/VoutR
)
cffR
)
14
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
TEST SIGNAL FORMAT
Table 10. Test Signal Format
Signal
Name
S1 Video gain measurement
[V]
S2 Video Tr/Tf measurement
[V]
S3 HFLB (posi & nega.) input
[V]
Video
4uS
f = 200kHz
Input Signal Formal Signal Description
Video = 1MHz/0.7Vpp
Sync = 50kHz
Sync
[t]
f = 200kHz
V = 0.7Vpp
Duty = 50%
Duty = 50%
t = 2uS
0.7
Vpp
[t]
f = 50kHz
t = 2uS
V = 0V/5V
f = 50kHz
S4 OSD level measurement
[V]
[V]
f = 200kHz
S5 Crosstalk test
[V]
Duty = 50%
[t]
5V
0V
[t]
Vi
[t]
Blank Tr/Tf measurement
f = 50kHz
V = 0V/5V
Bandwidth measurement
1MHz/10MHz/50MHz/
Vref
130MHz
Vref = input clamp voltage
Vi = 0.7Vpp
• S1, S2 signal’s low level must be synchronized with the S3 signal’s sync. term.
• The input signal level uses the IC pin as reference.
15
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
TEST CIRCUIT
VDD = 5.0V
BNC2
BNC7
BNC8
ABL
BNC1
5.6K
BNC6
562
30M
100u
33
100u
75
75
33
33
1
2
0.1u
0.1u
0.1u75
27K
4.7u
103
1u
100
1u
100u
1M
SW1
VFLB
1
VSSA
2
VCO_IN_P
3
VREF1
4
VREF
5
VDDA
6
CONT_CAP
7
ABL_IN
8
GND3
9
CLP_IN
10
VCC3
11
RIN
12
VCC1
13
GIN
14
GND1
15
BIN
16
S1D2502B01
KB2502
HFLB
VDD
SDA
SCL
VSS
RCT
GCT
BCT
ROUT
RCLP
VCC2
GOUT
GCLP
GND2
BOUT
BCLP
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
0.1u
0.1u
0.1u
33
33
2K
2K
2K
33
100u
470
470
470
BNC3
4.7K
BNC4
4.7K
BNC5
16
BNC9
VCC = 12.0V
Magnetic Core
Figure 4. Test Circuit
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
FUNCTIONAL DESCRIPTIONS
DATA TRANSMISSION
The interface between S1D2502B01 and MCU follows the I2C protocol. After the starting pulse, the transmission
takes place in the following order: Slave address with R/W bit, 2-byte register address, 2-byte data, and stop
condition. an acknowledge signal is received for each byte, excluding only the start/stop condition. The 2-byte
register address is composed of an 8-bit row address, and an 8-bit column address. The order of transmission for
a 2-byte register address is 'Row address → Column address'. The 2 bytes of data is because S1D2502B01 has a
16-bit base register configuration. S1D2502B01's slave address is BAh. It is BBh in read mode, and BAh in write
mode.
• Address Bit Pattern for Display Registers Data
(a) row address bit pattern
R3 - R0: Valid data for row address
A15 A14 A13 A12 A11 A10 A9 A8
X X X X R3 R2 R1 R0
(b) Column address bit pattern
C4 - C0: Valid data for column address
A7 A6 A5 A4 A3 A2 A1 A0
X X X C4 C3 C2 C1 C0
X:Don't care bit
• Data Transmission Format
Start → Slave address → ACK → Row address → ACK → Column address → ACK
Data byte N → ACK → Data byte N+1 → ACK → Stop
Figure 5. Data Transmission Format at Writing Operation
Start → Slave address → ACK → Row address → ACK → Column address → ACK → Stop
Start → Slave address → ACK → Data byte N → ACK → Data byte N+1 → ACK → Stop
Figure 6. Data Transmission Format at Reading Operation
17
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• SDA / SCL Signal At Communication
SCL
SDA
START IIC SLAVE ADDRESS ACK MSB ADDRESS ACK LSB ADDRESS ACK
R/W
A5 A4 A3 A2 A1 A0A6A7A9 A8A10A11A12A13A14A15
SCL
SDA
DATA BYTE N(MSB DATA)
D1 D0D2D3D4D5D6D7
D1 D0D2D3D4D5D6D7
ACK DATA BYTE N(MSB DATA) ACK STOPACK DATA BYTE N(LSB DATA)
D1 D0D2D3D4D5D6D7
Figure 7. SDA line and SCL line (Write Operation)
SCL
R/W
R/W
D15
D9
D8D10D11D12D13D14
ACK DATA BYTE N(LSB) ACK STOPACK DATA BYTE N(MSB)
SDA
START IIC SLAVE ADDRESS ACK MSB ADDRESS ACK LSB ADDRESS ACK
SCL
SDA
START IIC SLAVE ADDRESS
A5 A4 A3 A2 A1 A0A6A7A9 A8A10A11A12A13A14A15
D5D6D7
Figure 8. SDA line and SCL line (Read Operation)
...
...
STOP
D1 D0D2D3D4
18
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
MEMORY MAP
00 01
Row
00
Row
01
Row
12
13
Row
14
Row
Row
15
00 01 02 03 06
Frame Control
Registers
02
Character & Attribute Registers
(30 x15 Character Display)
04 05 0807 0910 11 12 13 1415 16
V-AMP Control Registers
V-AMP Test Registers
2728 29
Row Attribute
Registers
30
31
Test Registers
Figure 9. Memory Map of Display Registers
The display RAM's address of the row and column number are assigned in order. The display RAM is composed of
4 register groups (character & attribute register, row attribute register, frame control register, and V-AMP control
register).
The display area in the monitor screen is 30 column × 15 row, so the related character & attribute registers are also
30 column × 15 row. Each register has a character address and characteristics corresponding to the display
location on the screen, and one register is composed of 16 bits. The lower 9 bits select the font from the 448 ROM
fonts, and the upper 7 bits give font characteristics to the selected font.
The row attribute register takes up the display RAM's 31st column. It provides raster color, raster color intensity,
character color intensity, horizontal & vertical character size, box, border, and shadow features in units of row.
The frame control registers are in the 16th row. It controls OSD's display location, character height, scroll, and
fade-in/out in units of frame.
The V-AMP control registers are also located in the 16th row.
19
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
REGISTER DESCRIPTION
♦
Character & Attribute Register: Row00 ~ 14, Column00 ~ 29
F E D C B A 9 8 7 6 5 4 3 2 1 0
BINV BOX1 BOX0 B G R Blink/Fint C8 C7 C6 C5 C4 C3 C2 C1 C0
Character Attribute Character Code (448 fonts)
♦
Row Attribute Register: Row00 ~ 14, Column30
F E D C B A 9 8 7 6 5 4 3 2 1 0
- BREN INTE CBil BOXE BORD SHA
♦
Frame Control Register 0: Row15, Column00
F E D C B A 9 8 7 6 5 4 3 2 1 0
- Fde FdeT VPOL HPOL - -
RB RG RR RINT CINT HZ2 HZ0 VZ1 VZ0
Raster Color Intensity Character Size
- - Erase EN Scrl ScrT Bli1 Bli0 BliT
♦
Frame Control Register 1: Row15, Column01
F E D C B A 9 8 7 6 5 4 3 2 1 0
CP1 CP0 Fpll HF2 HF1 HF0 dot1
dot0 - FBLK CH5 CH4 CH3 CH2 CH1 CH0
PLL Control Character Height Control
♦
Frame Control Register 2: Row15, Column02
F E D C B A 9 8 7 6 5 4 3 2 1 0
HP7 HP6 HP5 HP4 HP3 HP2 HP1
HP0 VP7 VP6 VP5 VP4 VP3 VP2 VP1 VP0
Horizontal Start Position Vertical Start Position
♦
V-AMP Control Register: Row15, Column03 ~ 15
Column03
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - -- - -
Column04
- VC7 VC6 VC5 VC4 VC3 VC2 VC1 VC0
Contrast Control
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - -- - -
Column05
- BRT7 BRT6 BRT5 BRT4 BRT3 BRT2 BRT1 BRT0
Brightness Control
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - -- - -
- RSB7 RSB6 RSB5 RSB4 RSB3 RSB2 RSB1 RSB0
R SUB Contrast Control
Column06
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - -- - -
- GSB7 GSB6 GSB5 GSB4 GSB3 GSB2 GSB1 GSB0
G SUB Contrast Control
20
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
♦
V-AMP Control Register: Row15, Column03 ~ 15
Column07
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column08
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column09
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column10
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column11
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column12
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column13
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column14
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
Column15
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - -
- BSB7 BSB6 BSB5 BSB4 BSB3 BSB2 BSB1 BSB0
B SUB Control
- OSD7 OSD6 OSD5 OSD4 OSD3 OSD2 OSD1 OSD0
OSD Contrast Control
- RWB7RWB6RWB5RWB4RWB3RWB2RWB1RWB0
R Cut-off Control
- GWB7GWB6GWB5GWB4GWB3GWB2GWB1GWB0
G Cut-off Control
- BWB7 BWB6BWB5BWB4BWB3 BWB2 BWB1 BWB0
B Cut-off Control
- CUT7 CUT6 CUT5 CUT4 CUT3 CUT2 CUT1 CUT
Cut-off Brightness Control
- SB HS6 HS5 HS4 HS3 HS2 HS1 HT
Half Tone & Soft Blank Control
- CLPS CLPP BLKP BPW2BPW1 - CS2 CS1
Clamp, Polarity & Offset Control
- - - - - TST HS9 HS8 HS7
’ - ’ ; Don’t care bit
Half Tone Control
Figure 10. Register Description
21
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Table 11. Register Description
Registers Bits Description
Character &
Attribute Registers
(Row 00 — 14,
Column 00 — 29)
C8 — C0
(Bit 8 — 0)
Blink/FINT
(Bit 9)
Character code address
This is the address of 448 ROM fonts.
Character blinking/font intensity
If row attribute register's INTE bit is set to '1', this bit carries out the font
intensity feature, and if not, the character blinking feature instead. In other
words, to carry out character blinking, set the INTE bit to '0'. Select frame
control register-0's BliT bit as blinking time, and select Bli1, Bli0 Bit as
blinking duty. When giving intensity in units of font, refer to the table below.
Blink/FINT INTE RINT CINT Function
0 0 - - Normal
0 1 - - Normal
1 0 - - Blink
1 1 0 1 Character intensity
1 1 1 0 Raster intensity
B, G, R
(Bit C — A)
BOX1, BOX0
(Bit E, D)
BINV
(Bit F)
1 1 1 1 Character & raster intensity
Character color
The character color is chosen from 16 colors using these 3 bits and the row
attribute register's CINT bit.
Character box drawing
You can make 4 box drawing modes using these 2 bits in combination. The
box drawings possible with font 'A' are shown below.
BOX0
BOX1
0
1
Refer to row attribute register's 'BOXE' bit.
Box inversion
The white box turns black and black box turns white in the box drawing
using BOX1, BOX0.
o 1
BOX OFF
A
AA
22
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 11. Register Description (Continued)
Registers Bits Description
Row Attribute
Registers
(Row00—14,
Column30)
VZ1, VZ0
(Bit 1, 0)
HZ1, HZ0
(Bit 3, 2)
Vertical character size control
VZ1 VZ0 Vertical Character Size
0 0 1X (1 time)
0 1 2X (2 times)
1 0 3X (3 times)
1 1 4X (4 times)
As shown above, the vertical character size is decided by using these two
bits in combination.
Horizontal character size control
HZ1 HZ0 Horizontal Character Size
0 0 1X (1 time)
CINT
(Bit 4)
RINT
(Bit 5)
0 1 2X (2 times)
1 0 3X (3 times)
1 1 4X (4 times)
As shown above, the horizontal character size is decided by using these
two bits in combination. However, unlike VZ, the surrounding area (row) is
taken over in the amount of the HZ increase, so you must keep that in mind
when changing font size. Refer to Character Size.
Character color intensity
When this bit is set to '1', the color intensity of the character on the same
row becomes high. Refer to BLINK/FINT, INTE, RINT, and CINT's
combination chart in the previous page. (Even if you change this bit, you
can't check the intensity feature on the demo board. This is because the
OSD IC's output INT is applied as the video Pre Amp's input, and the demo
board doesn't apply the OSD IC's INT output to the Pre Amp.)
Raster color intensity
When this bit is set to '1', the color intensity of the raster on the same row
becomes high. Refer to BLINK/FINT, INTE, RINT, and CINT's combination
chart in the previous page. (Like CINT given above, you can't check RINT's
feature on the demo board.)
23
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Table 11. Register Description (Continued)
Registers Bits Description
Row Attribute
Registers
(Row00 — 14,
Column30)
RB, RG, RR
(Bit 8 — 6)
SHA Character shadowing
BORD Character bordering
BOXE
(Bit B)
CBli
(Bit C)
INTE
(Bit D)
BREN
(Bit E)
Bit F Reserved
Raster color is determined by these bits
The raster color is chosen from out of 16 colors using these 3 bits and the
row attribute register's 'RINT' bit. If 'BOXE' Bit is not '1', the setting of these
three bits have no meaning. Refer to 'BOXE' bit shown below.
Character shadowing feature is carried out if you set this bit to '1'.
Character bordering feature is carried out if you set this bit to '1'.
BOX enable
If you set this bit to '1', it uses the character & attribute register's 'BINV',
'BOX1', and 'BOX0' bits to carry out box drawing, and if you set it to '0', the
character & attribute register's bits F~D (BINV, BOX1, BOX0) act as each
raster color's B, G, and R. This has higher priority than selection by setting
RB, RG, and RR bits. In other words, if the BOXE bit is set to '0', the
character & attribute register's BINV, BOX1, and BOX0 each do the
function of RB, RG, and RR to decide the raster color, and the original row
attribute register's RB, RG, and RR don't do anything.
Color blink enable
If this bit is '1', the color blinking effect is applied. Color blinking is instead
of normal blinking, 8 colors appear in order in the font's character part. Its
time and duty is controlled by 'BliT', 'Bli1', and 'Bli0', like in character
blinking.
Intensity enable
Refer to the table on the combination of BLINK/FINT, INTE, RINT, and
CINT bits in the explanation of the character & attribute register's BLINK/
FINT bit.
Back raster enable
If the BREN bit is '1' and the raster color is black, the raster is transparent.
That is, the video back raster is shown. If not, the OSD raster covers the
video's back raster. Refer to other color effect.
24
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 11. Register Description (Continued)
Registers Bits Description
Frame Control
Registers — 0
(Row 15,
Column 00)
BliT
(Bit 0)
Bli1, Bli0
(Bit 2 — 1)
Blink time control
If this bit is '1', blink time is 0.5sec, and if not, 1sec.
Blinking duty control
As the font blinks, there is a time when it is visible and invisible on screen.
Blinking duty is the ratio of the invisible time to the visible time, and is
decided by the combination of these two bits. In other words, blinking duty
is the length of time the font is shown on screen.
Bli1 Bli0 Blinking Duty
0 0 Blink Off
0 1 Duty 25%
1 0 Duty 50%
1 1 Duty 75%
ScrT
(Bit 3)
Scrl
(Bit 4)
EN
(Bit 5)
Erase
(Bit 6)
Scroll time control
If this bit is '1', scroll time is 0.5sec, and if not, 1sec.
Scroll enable
Scrolling effect is controlled by this bit. If this bit is ‘1’, scrolling effect is
enabled. You must remember that scrolling can be turned on/off only when
OSD is enabled/disabled.
OSD enable
OSD is enabled when this bit is '1'. In other words, if this bit isn't '1'OSD is
not output inspite of writing control data. We recommend that you enable
the OSD after setting the control registers (such as the character & attribute
register) because of video and OSD output timing.
RAM erasing
If this bit is '1', the RAM data (character & attribute registers and row
attribute registers) is erased. The time spent in carrying out this operation is
called erasing time, which can be calculated as follows.
Erasing time = RAM clock × 480 (RAM cell no.)
RAM clock = 12 dot clock
Dot clock = 1/(dot frequency)
Dot frequency = Horizontal frequency × resolution (mode)
Therefore, the maximum erasing time value is:
(Erasing Time)
= (12 × 480) / (15k × 320) = 1.2ms
MAX
25
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Table 11. Register Description (Continued)
Registers Bits Description
Frame Control
Registers — 0
(Row 15,
Column 00)
HPOL
(Bit B)
VPOL
(Bit C)
FdeT
(Bit D)
Fde
(Bit E)
Bit F Reserved.
Polarity of horizontal fly back signal
If this bit is '1', HFLB's polarity is positive, and if '0', it is negative. In other
words, this bit is set to '1' if active high, and '0' if active low.
Polarity of vertical fly back signal
If this bit is '1', VFLB's polarity is positive, and if '0', it is negative. In other
words, this bit is set to '1' if active high, and '0' if active low.
Fade-in and fade-out time control
If this bit is '1', fade-in/fade-out time is 0.5sec. If not, it is 1sec.
Fade-in and fade-out enable
This feature is enabled when this bit is '1'. The effect where the display
goes from the center to the outside, or from the outside to the center in
units of font, is called fade-in/fade-out. Refer to fade-in/fade-out. You must
remember that fade-in/fade-out, like scrolling on/off, only occurs when OSD
enabled/disabled.
The purpose of bits 'HPOL', and 'VPOL' is to provide flexibility when using the S1D2502B01 IC. No matter which
polarity you choose for the input signal, the IC will handle them identically, so you can select active high or active
low according to your convenience.
26
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Tabel 4. Register Description (Continued)
Registers Bits Description
Frame Control
Registers — 1
(Row 15,
Column 01)
CH5 — CH0
(bit 5 — 0)
FBLK
(bit 6)
dot1, dot0
(bit 9, 8)
Character height control
While the purpose of VZ[1:0] (vertical character height) is to control the
absolute size of the character, the purpose of CH[5:0] (Character Height) is
to output OSD of a uniform size even if the resolution changes. If you adjust
the value in the range of CH = 18 — CH = 63, each line's repeating number
is decided (standard height CH = 18 is the reference value), by which the
line is repeated. For more information on repeating number selection, refer
to character height.
Selection of the FBLK output pin's configuration
Unlike pin description's FBLK, if this bit is '0', the FBLK pin output is high
while the character and raster are being displayed and the character and
raster are output as they are. If this bit is '1', the FBLK pin output becomes
high only when character is being displayed, so only the character is
output. Refer to 'Figure 11. Character/raster signal part.
Resolution control (dots/line)
Dot1 Dot0 No. of Dots
HF2—HF0
(bit C — A)
FPLL
(bit D)
0 0 320 dots/line
0 1 480 dots/line
1 0 640 dots/line
1 1 800 dots/line
As shown above, the number of dots per horizontal line is decided by a
combination of these two bits.
Horizontal frequency
PLL's horizontal frequency is decided by the combination of these 3 bits.
This is related to the selection of DOT[1:0], so you can't numerically
express the frequency range with only the HF[2:0] selection. For more
information, please refer to HF Bits Selection.
Full range PLL
If this bit is '1', the OSD_PLL block's VCO operates at full range (4.8MHz -
96MHz). If it is ’0', it operates within the region decided by the HF bit [C:A]
explained above. if you can’t optimize OSD screen decided by the HF bit in
the high region, you may set the FPLL bit to ‘1’.
27
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Tabel 4. Register Description (Continued)
Registers Bits Description
Frame Control
Registers — 1
(Row 15,
Column 01)
FBLK bit setting is explained at the figure below.
CP1, CP0 Charge pump output current control
This is the PLL block's internal phase detector output status, converted into
current. Refer to PLL control.
CP1 CP0 Charge Pump Current
0 0 0.50 mA
0 1 0.75 mA
1 0 1.00 mA
1 1 1.25 mA
The output is decided by the combination of these two bits.
Blue
Character
Red
Raster
Blue
Bordering
Red
Character
Green
Figure 11. Character/Raster Signal Part
Raster
28
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Tabel 4. Register Description (Continued)
Registers Bits Description
Frame Control
Registers — 2
(Row 15,
Column 02)
V-AMP Control
Registers — 0
(Row 15,
Column 03)
V-AMP Control
Registers — 1
(Row 15,
Column 04)
V-AMP Control
Registers — 2
(Row 15,
Column 05)
V-AMP Control
Registers - 3
(Row 15,
Column 06)
V-AMP Control
Registers - 4
(Row 15,
Column 07)
V-AMP Control
Registers - 5
(Row 15,
Column 08)
V-AMP Control
Registers - 6
(Row 15,
Column 09)
V-AMP Control
Registers - 7
(Row 15,
Column 10)
VP7 — VP0 Vertical start position control ( = VP[7:0] × 4)
Signifies top margin height from the V-Sync reference edge.
HP7 — HP0 Horizontal start position control ( = HP[7:0] × 6)
Signifies delay of the horizontal display from the H-Sync reference edge
to the character's 1st pixel location.
VC7 — VC0
(bit7 — 0)
BRT7 — BRT0
(bit7 — 0)
RSB7 — RSB0
(bit7 — 0)
GSB7 — GSB0
(bit7 — 0)
BSB7 — BSB0
(bit7 — 0)
OSD7 — OSD0
(bit7 — 0)
RWB7 — RWB0
(bit7 — 0)
GWB7 — GWB0
(bit7 — 0)
The contrast adjustment is made by contrdling simultaneously the gain
of three internal variable gain amplifiers.
The contrast adjustment allows to cover a typical range of 38dB.
The brightness adjustment controls to add the same black level
(pedestal) to the 3-channel R/G/B signals after contrast amplifier.
R channel SUB contrast control.
The SUB contrast adjustment is used to adjust the white balance, and
the gain of each channel is controlled.
The SUB contrast adjustment allows you to cover a typical tange of
12dB.
G channel SUB contrast control.
The SUB contrast adjustment is used to adjust the white balance, and
the gain of each channel is controlled.
The SUB contrast adjustment allows you to cover a typical tange of
12dB.
B channel SUB contrast control.
The SUB contrast adjustment is used to adjust the white balance, and
the gain of each channel is controlled.
The SUB contrast adjustment allows you to cover a typical tange of
12dB.
The OSD contrast adjustment is made by contrdling simultaneously the
gain of three internal variable gain amplifiers.
The OSD contrast adjustment allows to cover a typical range of 38dB.
R channel cut-off control.
The cut-off adjustment is used to adjust the raster white balance.
G channel cut-off control.
The cut-off adjustment is used to adjust the raster white balance.
29
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Tabel 4. Register Description (Continued)
Registers Bits Description
V-AMP Control
Registers - 8
(Row 15,
Column 11)
V-AMP Control
Registers - 9
(Row 15,
Column 12)
V-AMP Control
Registers - 10
(Row 15,
Column 13)
BWB7 — BWB0
(bit7 — 0)
CUT7 — CUT0
(bit7 — 0)
HT
(bit 0)
HS3 — HS1
(bit3 — 1)
B channel cut-off control.
The cut-off adjustment B used to adjust the raster white balance.
The cut-off brightness adjustment is made by simultaneously controlling
the external cut-off current.
Video & OSD half tone enable.
If you set this bit to ’1’, the half tone function is on.
Then you can see the video signal & OSD raster.
HS3 — HS1 bits select OSD raster color 1 to be half tone.
To carry out half tone function, set the HT bit to ’1’.
HS6 — HS4
(bit6 — 4)
HS3 HS2 HS1
0 0 0 0 0 0 Black O
0 0 1 0 0 1 Blue
0 1 0 0 1 0 Red
0 1 1 0 1 1 Magenta
1 0 0 1 0 0 Green
1 0 1 1 0 1 Cyan
1 1 0 1 1 0 Yellow
1 1 1 1 1 1 White
HS6 — HS4 bits select OSD raster color 2 to be half tone.
To carry out half tone function, set the HT bit to ’1’.
HS6 HS5 HS4
0 0 0 0 0 0 Black O
0 0 1 0 0 1 Blue
0 1 0 0 1 0 Red
0 1 1 0 1 1 Magenta
1 0 0 1 0 0 Green
1 0 1 1 0 1 Cyan
1 1 0 1 1 0 Yellow
1 1 1 1 1 1 White
G R B
G R B
OSD
OSD
Raster
Color 1
Raster
Color 2
POR
POR
30
SB
(bit 7)
Soft blanking enable
If you set this bit ’1’, the R/G/B outputs go to GND.
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Tabel 4. Register Description (Continued)
Registers Bits Description
V-AMP Control
Registers - 11
(Row 15,
Column 14)
CS2 — CS1
(bit1 — bit0)
Cut-off offset current control
CS2 CS1 Cut-off Offset Current POR
0 0 0 O
0 1 50µA
1 0 100µA
1 1 150µA
V-AMP Control
Registers - 12
(Row 15,
Column 15)
BPW2 — BPW1
(bit4 — bit3)
BLKP
(bit 5)
CLPP
(bit 6)
CLPS
(bit 7)
HS9 — HS7
(bit2 — bit 0)
Generated clamp pulse width control
BPW2 BPW1 Width POR
0 0 0.33µs
0 1 0.66µs
1 0 1.00µs O
1 1 1.33µs
To carry out this function, set the CLPS bit to " 0 "
Polarity of horizontral fly back signal
If this bit is ’0’, HFLB’s polarity is negative, and if ’1’, it is positive.
Polarity of clamp pulse signal
If this bit is ’0’, CLP’s polarity is positive, and if ’1’, it is negative.
This bit has meaning only if the CLPS bit is set to ’1’.
Clamp pulse generation enable
If this bit is ’0’, clamp signal is made using the HFLB signal, so there is
no need to supply the clamp signal.
and if ’1’ you must supply external clamp signal.
HS9 — HS7 bits select OSD raster color 3 to be half tone.
To carry out half tone function, set the HT bit to " 1 ".
HS9 HS8 HS7
0 0 0 0 0 0 Black O
0 0 1 0 0 1 Blue
0 1 0 0 1 0 Red
0 1 1 0 1 1 Magenta
1 0 0 1 0 0 Green
1 0 1 1 0 1 Cyan
1 1 0 1 1 0 Yellow
1 1 1 1 1 1 White
OSD
G R B
Raster
Color 3
POR
31
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
VIDEO AMP PART ADDRESS MAP
Register sub address (use limited to 1byte out of 2bytes)
Table 12. Video AMP Part Address Map
SUB Address
[Hex]
0F03 Contrast control 80H
0F04 Brightness control 80H
0F05 SUB contrast control (R) 80H
0F06 SUB contrast control (G) 80H
0F07 SUB contrast control (B) 80H
0F08 OSD contrast control 80H
0F09 Cut-off control (R) 80H
0F0A Cut-off control (G) 80H
0F0B Cut-off control (B) 80H
0F0C Cut-off brightness control 80H
0F0D SB HS6 HS5 HS4 HS3 HS2 HS1 HT 00H
0F0E CLPS CLPP BLKP BPW2 BPW1 - CS2 CS1 10H
0F0F - - - - TST HS9 HS8 HS7 00H
In normal status, you must set TST bit to ’0’.
D7 D6 D5 D4 D3 D2 D1 D0
Function POR Value
[Hex]
32
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Contrast Register (SUB ADRS: 03H) (Vin = 0.7Vpp, bright: 80H, subcont: FFH)
Hex
Brightness Register (3-ch) (SUB ADRS: 04H) (cont: 80H, subcont: 80H)
Hex B7 B6 B5 B4 B3 B2 B1 B0 Brightness (Vpp) Int. Value (Hex)
SUB Contrast Register (R/G/B-ch) (SUB ADRS: 05/06/07H)
(Vin = 0.7Vpp, bright: 40H, cont: FFH)
Hex B7 B6 B5 B4 B3 B2 B1 B0 SUB Contrast
B7 B6 B5 B4 B3 B2 B1 B0
00 0 0 0 0 0 0 0 0 0 80 1 0 0 0 0 0 0 0 2.85 - O
FF 1 1 1 1 1 1 1 1 5.2 -
Increment/bit 0.0223
00 0 0 0 0 0 0 0 0 0.2
80 1 0 0 0 0 0 0 0 1.5 O
FF 1 1 1 1 1 1 1 1 2.7
Increment/bit 0.01055
00 0 0 0 0 0 0 0 0 80 1 0 0 0 0 0 0 0 - O
FF 1 1 1 1 1 1 1 1 -
Increment/bit
Contrast (Vpp) Gain (dB) int. Value (Hex)
(Vpp)
Gain
(dB)
Int. Value
(Hex)
OSD Contrast Register (SUB ADRS: 08H) (VOSD = TTL, bright: 80H, subcont: 80H)
Hex B7 B6 B5 B4 B3 B2 B1 B0 OSD Contrast
(Vpp)
00 0 0 0 0 0 0 0 0 0 80 1 0 0 0 0 0 0 0 3.2 - O
FF 1 1 1 1 1 1 1 1 6.4 -
Increment/bit 0.025
Gain
(dB)
Int. Value
(Hex)
33
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Cut-Off Brightness Register (3-ch) (SUB ADRS: 0CH)
Hex B7 B6 B5 B4 B3 B2 B1 B0 Cut-Off Brightness (µA) Int. Value (Hex)
00 0 0 0 0 0 0 0 0 0
80 1 0 0 0 0 0 0 0 100 O
FF 1 1 1 1 1 1 1 1 200
Increment/bit 0.781
Cut-Off Register (R/G/B-ch) (SUB ADRS: 09/0A/0BH)
(cont = 80H, subcont: 80H)
Hex B7 B6 B5 B4 B3 B2 B1 B0 Cut-Off EXT (µA) Int. Value (Hex)
00 0 0 0 0 0 0 0 0 0
80 1 0 0 0 0 0 0 0 300 O
FF 1 1 1 1 1 1 1 1 600
Increment/bit 2.344
34
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
ADDRESSING
• Display RAM Structure
Row Attribute Register
Virtual Register
Row
0
1
2
3
.
.
.
.
Display RAM Address Area
. . . . . . .
0
32
64
96
.
.
.
.
29 30 31
61 62 63
93 94 95
125 126 127
.
.
.
.
.
.
.
.
.
.
.
.
14
15
. . . . . . .
448
481 482 483 484 511
480
Frame/V-AMP Control Registers
...
477 478 479
496495
Figure 12. Display RAM Structure & Monitor Display Position
Whereas ‘Figure 9. Memory Map of Display Registers’ showed a logical configuration, the Figure above shows a
1KByte SRAM (512 × 16 bit)'s practical and physical configuration. For facilitating internal calculations, addressing
is done using exponents of 2, and the rows to the right of the 'Row Attribute Registers', excepting only IFF(255),
are 'Virtual Registers' that are not used.
If you set 'Frame Control Register 0's 'Erase' bit to '1', 480 areas are erased (excepting only the 16th line) in the
Figure above, and the 'Erasing Time' is measured with 480 areas as the standard.
35
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• ROM Fonts
S1D2502B01 provides 448 Rom fonts for displaying OSD Icons, which allows the use of multi-language OSD
Icons. Font $000 is reserved for blank data.
0 1
$000 $001
00
$010 $011
01
$1A0 $1A1
1A
$1B0 $1B1
1B
E F
$00E $00F
$01E $01F
$1AE $1AF
$1BE $1BF
Figure 13. Composition of the ROM Fonts
Standard
Fonts
36
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
COLORING
If you have an Intensity feature, the number of possible colors you can express becomes doubled. In other words,
the number of colors you can represent with three colors blue, green, and red is 8 ( = 23), but with the intensity
feature, it is 16 ( = 24).
• Character Color
Character color is assinged for each font, and the 4 components for expressing a color are listed below.
Blue Character & attribute register's B bit[C]
Green Character & attribute register's G bit[B]
Red Character & attribute register's R bit[A]
Intensity Character & attribute register's BLINK/FINT bit[9]
Row attribute register's INTE bit[D]
Row attribute register's CINT bit[4]
If all 3 bits are set to '1', the character intensity feature is enabled.
• Raster Color
Blue
Green
Red
Intensity
According to the 'BOXE' bit setting, raster color can be assigned in units of font or row. There is a trade-off in either
case. If 'BOXE' Bit is set to '1', the box drawing feature can be carried out in units of font, but the raster color can
only be assigned in units of row. On the other hand, if 'BOXE' bit is set to '0', the box drawing feature can't be
carried out, but you can assign raster color in units of font.
Address 000h is appointed as blank data. RAM's initial values are all 0, and all bits are written as 0 when you
erase the RAM, so blank data means the initial value. In other words, blank data means 'do nothing'. You don't
need to write any data for the space font, except for 000h. It just needs to be an undotted area.
Row attribute register's RB bit[8] if the row attribute register's 'BOXE' bit is '1', and character
& attribute register's 'BINV' bit[F] if BOXE' bit is '0'.
Row attribute register's RG bit[7] if row attribute register's 'BOXE' Bit is '1', and character &
attribute register's 'BOX1' bit[E] if 'BOXE' bit is '0'.
Row attribute register's RR bit[6] if row attribute register's 'BOXE' bit is '1', and character &
attribute register's 'BOX0' bit[D] if 'BOXE' bit is '0'.
Character & attribute register's BLINK/FINT bit[9]
Row attribute register's INTE bit[D]
Row attribute register's RINT bit[5]
If all 3 bits are set to '1', the raster intensity feature is enabled.
Notes for When Making S1D2502B01 Fonts
37
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• Other Color Effet
The row attribute register's 'BREN' bit's function is shown in the Figure below. If you set the 'BREN' bit of the
row with the letter A as '0' after selecting A and B's raster color as black, the raster color black will be
displayed. But if you set the 'BREN' bit of the row with the letter B as '1', the raster color black becomes
invisible, so the back raster color (gray) is displayed as if it is the raster color.
BREN bit = 0 & Rastor Color = Black
BREN bit = 1 & Rastor Color = Black
BREN bit = 1 & Rastor Color = Light Blue
Gray
Figure 14. Color Effect by BREN Bit
Color blinking is using a selective control bit in blink mode to replace normal blinking with 8 different colors
appearing in order on the font's character. Color blinking only replaces normal blinking, and blink time and blink
duty are still applied at the same time. Therefore, if the blink duty is not set to off, only 3 ~ 4 colors may appear
according to the blink duty, instead of all 8.
SIZING/POSITIONING
• Character Size
Row attribute register's HZ bit[3:2] and VZ bit[1:0] control the character's vertical and horizontal size by factors
of 1/2/3/4 in units of row. VZ is correctly expressed without regard to size since the next line is just pushed
down in order, but HZ decides the column that the font occupies according to the size. For example, if HZ [1:0]
= 0, 1, the font doubles in the horizontal direction, and one font takes up 2 columns. Therefore, the column
address must move in the same amount as the HZ for the next font to be expressed correctly. in other words, if
the horizontal size is doubled and takes up 2 columns, the next font must be put 2 columns back.
Original
VZ × 2
HZ × 2
Figure 15. Character Size by VZ, HZ Bits
38
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
• Character Height
Whereas the purpose of VZ[1:0] (Vertical Character Height) is to adjust the character's absolute size, the
purpose of CH[5:0] (Character Height) is to output a uniformly sized OSD even if the resolution changes. To
express a Character Height of CH = 18 ~ CH = 63 after receiving CH[5:0]'s input from the frame control
register-1, decide on each line's repeating number (Standard Height CH = 18) and repeat the lines.
The following Figure shows two examples of a height-controlled character. height control is carried out by
repeating some of the lines.
1
2
3
4
5
6
Standard Font(12*18)
7
8
9
10
11
12
13
14
15
16
17
18
Standard font
in high vertical resolution
Height-controlled font
: added
line
Standard Font(12*18)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Standard font
in more higher vertical resolution
Figure 16. Character Height
: added
line
Height-controlled font
39
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
Repeating line-number can be found by the following formula.
[# of the repeating lines = 2 + N × M],
where N = 1, 2, 3, ... and M = round{14 ÷ (CH[5:0]-18)}.
1. If CH[5:0] is greater than 32 and less than or equal to 46 (32 < CH[5:0] ≤ 46), all lines are repeated once or
twice. The lines that are repeated twice are chosen by the following formula.
[# of the repeating lines = 2 + N × M],
where N = 1, 2, 3, ... and M = round {14 ≤ (CH[5:0]-32)}.
2. If CH[5:0] is greater than 46 and less than or equal to 60 (46 < CH[5:0] ≤ 60), all lines are repeated two or three
times. The lines that are repeated three times are chosen by the following formula.
[# of the repeating lines = 2 + N × M],
where N = 1, 2, 3, ... and M = round {14 ≤ (CH[5:0]-46)}.
3. If CH[5:0] is greater than 60 and less than or equal to 64 (60 < CH[5:0] ≤ 64), all Lines are repeated three or four
times. The lines that are repeated four times are chosen by the following formula.
[# of the repeating lines = 2 + N x M],
where N = 1, 2, 3, ... and M = round {14 ≤ (CH[5:0]-60)}.
CH's reference value is 18, and even if you input 0, it operates in the same way as when CH = 18. The repeating
line-number is limited to 16. If the M value is less than or equal to 1, all lines of the standard font are repeated more
than once.
Table 13. Repeating Line as Controlling by CH bits
Character Height Repeating Line
CH = 18 CH = 19 9
CH = 20, 21 6, 13
CH = 22 5, 11, 17
CH = 23 4, 9, 14, 19
CH = 24 3, 7, 11, 15, 19, 21
CH = 25, 26, 27 3, 7, 11, 13, 15, 19, 22
CH = 28 3, 6, 9, 12, 14, 18, 20, 23, 25
CH = 29 3, 6, 9, 11, 13, 15, 18, 21, 23, 25, 26
CH = 30 3, 6, 8, 10, 12, 14, 16, 18, 20, 22, 25, 27
CH = 31 2, 5, 7, 9, 11, 13, 15, 17, 21, 23, 25, 27, 28
CH = 32, 33, 34, 35 2, 5, 7, 9, 11, 13, 15, 18, 21, 23, 25, 27, 28, 29
CH = 36 CH = 37 18
40
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
Table 13. Repeating Line as Controlling by CH bits
Character Height Repeating Line (Continued)
CH = 38, 39 12, 25
CH = 40 10, 20, 30
CH = 41 8, 16, 24, 32
CH = 42 6, 12, 18, 24, 30, 36
CH = 43, 44, 45 6, 12, 18, 24, 30, 36, 41
CH = 46 4, 8, 12, 17, 21, 25, 29, 33, 37, 41
CH = 47 4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44
CH = 48 4, 8, 12, 16, 20, 23, 26, 29, 33, 37, 41, 45
CH = 49 4, 8, 12, 16, 19, 22, 25, 28, 31, 35, 39, 43, 47
CH = 50, 51, 52, 53 4, 8, 12, 15, 18, 21, 24, 27, 30, 33, 36, 40, 44, 48
CH = 54 CH = 55 27
CH = 56, 57 18, 36
CH = 58 14, 28, 42
CH = 59 12, 23, 34, 45
CH = 60 9, 18, 26, 34, 43, 52
CH = 61, 62, 63 8, 16, 23, 30, 37, 44, 51
41
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• Positioning
The frame control register-2's HP Bit [F:8] signifies delay of the horizontal display from the H-Sync reference
edge to the character's 1st pixel location, and is controlled by multiplying HP [F:8]'s range value by 6. Also, VP
bit[7:0] signifies the top margin height from the V-Sync reference edge, and is controlled by multiplying 4 to the
VP [7:0]'s range value. Refer to the Figure shown below.
(HFLB)
HP[7:0]
VP[7:0]
(VFLB)
OSD characters
30 columns (= 30 x 12 dots)
15 rows
(=15 x 18 lines)
Background Screen
Figure 17. Frame Composition with the OSD Characters
42
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
VISUAL EFFECTS
• Box Drawing
Set the row attribute register's boxe bit to '1' and enable the box feature. Then set the character & attribute
register's BOX bit to select one of 4 modes. Or, use the character & attribute register's BINV bit to inverse the
white and black areas of the box mode selected by the BOX bit.
BOX0
BOX1
o 1
0
1
BOX OFF
Figure 18. Box Drawing
The principle behind the boxing feature is shown below.
HDOT0
DOTLINE_
17
H
DOTLINE_
DOTLINE_
17
H
0
H
A
AA
DOTLINE_
0
H
DOTLINE_
17
H
HDOT11
DOTLINE_
0
H
BOX<1:0> 01 BOX<1:0> 10 BOX<1:0> 11
Out of the 12 horizontal dots and 18 vertical lines that make 1 character, make the first and 12th horizontal dots to
HDOT0/HDOT11, and the first and 18th vertical lines to DOTLINE-0H/DOTLINE-17H in order to carry out box
drawing for 1 dot outside the character.
43
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• Bordering/Shadowing
The character border and shadow can only be black. Character border is the effect where you make 1 pixel
around the character, and character shadow is making 1 pixel to the right and below the character.
Bordering Shadowing
Figure 19. Character Bordering/Shdowing
• Scrolling
Scrolling is slowly displaying or erasing a character from the top line to the bottom. This effect makes it look as
if 1 character line is scrolling up or down.
Figure 20. Scrolling
44
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
• Fade-In/Fade-Out
Fade-in/fade-out is displaying from the center to the outside in units of font when OSD display is on/off. Each
font's display is turned on/of without regard to size, in units of (12 × 18) dot.
Also, to control the fade in/out time, the V_PULSE's 1/4, 1/8 clocks are used for counting. In other words, as
control data, it takes 0.5sec if the frame control register - 0's 'FdeT' bit is 1, and 1sec if 0. If it is difficult to
visualize the fade-in / fade-out feature with the explanation and diagrams in this document, write the control
data to the OSD IC and verify the IC's operations. Like the scrolling feature, fade in/out can only be verified
when OSD is enabled/disabled.
Fade in/out
Unit: Font 6CK_Time
6CK_Time + 3CK_Time
row Space
Display at 9CK_Time
Figure 21. Fade-In/Fade-Out
45
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
PLL CONTROL
• Introduction
PLL (Phase Lock Loop) is feedback controlled circuit that maintains a constant phase difference between a
reference signal and an oscillator output signal.
Generally, PLL is composed as follow Figure.
Reference Signal
PFD
(Phase Frequency Detector)
(Frequency Detector)
LF
(Loop Filter)
FD
VCO (Voltage
Controlled Oscillator)
Figure 22. Block Diagram of General PLL
- PFD (Phase Frequency Detector)
PFD compares the phase of the VCO output frequency, with the phase of a reference signal frequency output
pulse is generated in proportion to that phase difference.
- LF (Loop Filter)
LF smooths the output pulse of the phase detector and the resulting DC component is the VCO input.
- VCO (Voltage Controlled Oscillator)
VCO is controlled by loop filter output. The output of the VCO is fed back to the phase frequency detector
input for comparison which in turn controls the VCO oscillating frequency to minimize the phase difference.
- FD (Frequency Divider)
FD divides too much different frequency that is oscillated from the VCO to compare it with reference signal
frequency.
46
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
• PLL of the S1D2502B01
PLL is composed of the phase detector, charge pump, VCO, and N-divider as 4 sub-blocks.
HFLB (Pin32)
Detector
Div_out
Phase
Loop
Filter
CP_out
(Pin4)
Charge
Pump
N-Divider
CP0 CP1 DOT0 DOT1 HF0 HF1 HF2
# Composed of External Components
VCO_in
(Pin3)
VCO
Figure 23. Block Diagram of the PLL Built in S1D2502B01
VCO_out
The following is the description of the input/output signals.
- HFLB (Input)
Horizontal flyback signal is refrence signal of the PLL built in S1D2502B01.
The HFLB signal's frequency range is 15 ~ 90kHz, so the PLL block must be a wide range PLL that can cover
HFLB's entire frequency range.
> 4.2V
fHFLB
~2us
< 0.4V
- VCO (Input)
Error signal that passes through an external loop filter is input into VCO.
Operation voltage range is 1-4V. You can raise immunity towards external noise by lowering VCO
sensitivity. You can do this by making it have the maximum operation voltage range possible in the 5V power
voltage.
47
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
- DOT0, 1 (Input)
Mode control signal that controls the number of dots per line in the frame control register. There are 4 modes:
320, 480, 640, and 800 dots/line.
According to your choice of mode, the OSD_PLL block's N-Divider is controlled by one of ÷320, ÷480, ÷640, or
÷800 Divider.
- HF0, 1, 2 (Input)
The horizontal Sync frequency information is received from the micro controller through the frame control
registers-1's bit C-A.
- CP0, 1 (Input)
Charge Pump's output sourcing (or sinking) current control pin.
This control data is received through frame control registers-1's bits E-D.
- VCO_OUT (Output)
VCO output that becomes a system clock. It is the OSD R, G, B output signal's dot frequency, and the standard
signal for OSD's various timings.
Also, it is input into the N-Divider and makes a PLL loop
> 4.2V
< 0.4V
fclk
Rise Time : < 4nS
Fall Time : < 4nS
- CP_OUT (Output)
Charge Pump circuit's output. input into external loop filter. It becomes one of 3 states according to the standard
signal input into the phase detector (HFLB) and the divider output (Div_Out).
- HFLB Div_Out is lead: Current sink
- HFLB Lag: Current source
- HFLB In-Phase: High impedence
48
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
TUNNING FACTORS OF THE S1D2502B01 PLL
• PLL External Circuit
You may follow the recommendations for PCB art work and input/output signal characteristic improvement in
recommendation.
The external circuit that has the most influence on S1D2502B01 PLL block operation is pin 3 (VCO_IN) and pin
4 (CP_OUT)'s surrounding circuit. Refer to OSD PLL block.
3 4
C1
R1 R2
R3
(option)
Figure 24. PLL External Circuit
Because the PLL circuit is basically a feedback circuit, there are many components that influence the
characteristics. C1, R1, R2, and R3 do not have a localized effect.
As you can see, they are connected to the PLL control bits and influence the characteristics through their
complicated relationships. The main functions of the time canstant and their reference values are as follows.
Table 14. Main Function of Time Constant in PLL External Circuit
Time Canstant Recommended Value Main Function
C1 562 (or 103, 223) Influences the damping ratio and controls the PLL
response time
R1 5.6KΩ(7.5KΩ) Same as C1
R2 27KΩ (or 33KΩ) Charge pump current adjustment
R3 (Option) 30MΩ (or 20MΩ) Extend frequency range
49
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
• PLL Control Bit
After configuring an external circuit using the recommended values, carry out programming using the
recommended values for frequency range and control bits given in the Table below.
Table 15. Recommend Values of PLL Control Bit
Register Set PLL Control Bit
Freq. Range CP1 CP0 FPLL HF2 HF1 HF0 DOT1 DOT0 Hex
Below 40kHz 0 0 0 0 1 0 1 1 0B
40 - 50kHz 1 0 0 1 0 0 1 1 93
50 - 70kHz 1 0 0 1 0 1 1 1 97
Above 70kHz 1 0 0 1 1 1 1 1 9F
(Ref: 800 × 600, C1: 562, R1: 5.6K, R2: 27K, R3: 30M)
• Locking Range
As you can see the figure below, it is 2.35V that measured voltage at pin-3 to optimize OSD quality. The proper
voltage range is 1.5 ~ 3.25V.
Locking Range
1.625V
Ve (min)
4V
3.25V
2.37V
1.5V
-2
0.75V
¥ð
fC
fL
f0
fmax
¥ð
2
Ve (max)
1.625V
Figure 25. Locking Range
50
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
• HF Bits Selection
HF bits is not selecting from out of 8 (23) steps uniformly, but selecting the step shown in figure below. In
example, at 800 mode, there are 5 steps that the frequency range is controlled by HF bits.
Table 16. HF Bits Selection
DIV DOT1 DOT0 HF2 HF1 HF0
320 0 0
480 0 1
640 1 0
800 1 1
After fixing time constants of the external circuit and PLL control bits except HF bits, if HF bits are stepped up, the
voltage measured at pin-3 drops. On the contrary, if HF bits are stepped down, the voltage rises.
The voltage measured at pin-3 don't change by changing CP bits.
• External Register at pin-4
The external register at pin-4 is the factor that changes greatly at PLL tunning. The initial value of this external
register value is decided as follows.
At first, the external register is replaced variable-register (about 50KΩ range).
and then, set the lowest PLL control bits at the lowest frequency allowed by set.
and then, change variable-register to be 2.35V that optimum voltage is locking.
and then, measure register value at this time.
also, set the highest PLL control bits at the highest frequency allowed by set.
and then, change variable-register to be 2.35V that optimum voltage is locking.
and then, measure register value at this time.
You may decide the average of these two registers' value to initial value.
51
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
The table below shows that other factors change as changing external register's value.
Fixing Factor Variable Factor Change Voltage Current Lock Range
Time constants of the external circuit
and PLL control bits except
Rext
↑ ↑ ↓ ↓ (shift)
↓ ↓ ↑ ↑ (shift)
52
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
RECOMMENDATION
5V Power Routing
S1D2502B01's OSD part power is composed of analog VDD and digital VDD. To eliminate clock noise influence in
the digital block, you need to separate the analog VDDA and digital VDD.
(BD102 use: Refer to Application Circuit )
12V Power Routing
Because S1D2502B01 is a wideband AMP of above 150MHz, 12V power significantly affects the video
characteristics. The effects from the inductance and capacitance are different for each board, and , therefore,
some tuning is required to obtain the optimum performance. The output power, VCC2, must be separated from
VCC1 and VCC3 using a coil, which is parallel-connected to the damping resistor.The appropriate coil value is
between 20uH - 200uH. Parallel-connected a variable resistor to the coil and control its resistance to obtain the
optimum video waveform.
(Moreover, BD103 can tune using a coil and variable resistor to obtain the optimum video waveform.
L103, R124, BD103: Refer to application circuit)
VCC1, VCC3 12V Power
Use a 104 capacitor and large capacitor greater than 470uH for the power filter capacitor.
12V Output Stage Power VCC2
Do not use the power filter capacitor.
5V Digital Power VDD
Don't use a coil or magnetic core to the VDD input. Make the power filter capacitor, an electric capacitor of greater
than 50uF, single and connect it to VSS, the digital GND.
Output Stage GND2
Care must be taken during routing because it ,as an AMP output stage GND, is an important factor of video
oscillation. R/G/B clamp cap and R/G/B load resistor must be placed as close as possible to the GND2 pin. GND2
must be arranged so that it has the minimum GND loop, which at one point must be connected to the main GND.
Digital GND VSS
When this is to be connected directly to the GND2, it can cause the OSD clock noise, so the loop connection
should be routed as far away as possible. If the OSD clock noise affects the screen, separate VSS GND from all
GND and connect it to the main board using a bead. Again, the bead connection point should be placed as far
away as possible to the GND2.
Analog Block
The PLL built in to S1D2502B01 is sensitive to noise due to the wide range PLL characteristics. Therefore, you
need to isolate the analog block in the following manner. First make a separate land for the analog block (pin2 pin6)'s ground, and connect it to the main ground through a 1MΩ resistor. The analog GND of both sides of a
double faced PCB must be separated from the main ground. (Separate pin 2's 5V analog GND, which is the GND
for OSD PLL, from the main and digital GNDs and connect it to the main GND using about 1MΩ resistor. GND for
pins 2 - 6 is the No. 2 VSSA GND.)
53
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
I2C Control Line (SCL, SDA Line)
I2C communication noise (noise generated in the OSD display pattern when data is transmitted in the I2C line) may
be generated because of an I2C control line that passes near the analog block. The I2C control lines near
S1D2502B01 must be separated from the analog block as much as possible.
Furthermore, the I2C bus interference can be prevented by inserting a series resistor in the line.
Horizontal Flyback Signal
Display jittering can be generated if the horizontal signal (HFLB) input to S1D2502B01 is not a clean signal.
We recommend a short path and shielded cable for obtaining a clean signal.
Generally, the input horizontal signal (HFLB) is generated by using a high voltage horizontal flyback signal. The
effect from the high voltage flyback signal can be reduced by separating the R115 and R117 GND, which
determines the flyback signal slice level, from the transistor GND, which generates the actual S1D2502B01 input
horizontal signal. Furthermore, the flyback signal sharpness must be maintained by minimizing the values of R115,
R116 and R117 resistors, which set the horizontal signal slice level. values.
(R115, R116, R117: Refer to application circuit )
HFLB Input Signal Generator
You can correct the circuit by reducing the resistors that sets the slice level of the horizontal signal in the HFLBgenerating circuit.
54
Preliminary
12_1V
12V
BD103
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
APPLICATION BOARD CIRCUIT
C117
R117
150
D102
R115
2K
1 3
Q102
2N3904
CN2
1N4148
1N4148
1N4148
6
RG01
RB01
75
75
RB02
75
CB02
104
16
BCLP
BOUT
17
18
CB02
104
RB03
470
RB15
47
RB04
CB08
100
270pF
14
C119
102
5V
SK101
WSP-401M
C126
C116
1nF
C118
330pF
R116
1N4148
1.8nF
1nF
G1
10K
12345678910111213
C123
103
C124
103
L101
100uH
R103
390
R118
R119
DR02
70V
DG02
6.3V
DB02
12V
R107
1K
R101
4.7K
R102
100
560
560
2
CN1
12345
1N4148
DR01
DG01
DB01
RR01
75
RR02
RG02
75
75
CG02
CR01
104
104
13
GIN14GND115BIN
GND2
19
VCC311RIN12VCC1
GOUT
GCLP
VCC222RCLP
20
21
CG02
104
RG03
470
RG15
47
RG04
CG08
100
270pF
12V
C109
1N4148
1N4148
C102
C112
+
+
1uF
1uF
10
7
8
ABL_IN
GND9CLP_IN
KB2502
ROUT
BCT25GCT
23
24
26
CR02
104
RR03
470
RR15
47
RR04
CR08
100
270pF
R123
5
VREF1
VREF
VDDA6CONT_CAP
VSS
SCL29SDA
RCT
27
28
C160
103
1M
C114
103
C110
C111
+
+
100uF
4.7uF
R109
27K
4
VCO_IN
+
47uF
R124
L103
BD102
5V
R108
5.6K
C113
R120
562
30M
2
3
VFLB1VSSA
C152
104
+
470uF
C103
HFLB
VDD
30
31
220
27uH
C151
32
104
C128
104
R114
5V
470
RR04
CR08
100
270pF
2N5401C-Y
6
7
9
8
BIN
GIN
RIN
12V
C106
104
C107
+
220uF
RR08
CR07
56
37pF
RR14
75
LR01
0.15uH
1SS244
1SS244
VDD
1SS244
DB04
DG04
DR04
+
2N5401C-Y
RG11
100
RG20
4.7K
1 3
QG01
2
2N5551C-Y
CG05
104
CG05
104
RG12
2.2K
2
QG02
2N5401C-Y
13
RG13
82K
DG05
1N4148
RB11
100
RB20
4.7K
1 3
QB01
2
2N5551C-Y
CB05
104
CB05
104
RB12
2.2K
2
QB02
13
RB13
82K
DB05
1N4148
RR11
100
RR20
4.7K
1 3
QR01
2
2N5551C-Y
CR05
104
CR05
104
RR12
2.2K
2
QR02
13
RR13
82K
DR05
1N4148
G2
R104
DMS-200D
SK102
390
C120
1nF
G2
DMS-200D
DMS-200D
DMS-200D
SKB01
SKG01
SKR01
R_OUT
RR10
39
VBB
LG01
0.15uH
DRIVER IC
GOUT
ROUT
BOUT
GND
VCC
1
2
5
3
4
RB08
RG08
56
CB07
CG07
56
37pF
37pF
RB14
RG14
75
75
LB01
0.15uH
C121
104
C108
+
47uF
70V
DB03
DG03
1SS244
DR03
1SS244
1SS244
+
+
CB04
CG04
CR04
1uF
G_OUT
1uF
1uF
RB09
75K
RB10
RG10
39
39
RR09
75K
RG09
75K
B_OUT
Figure 26. Application Board Circuit
55
Preliminary
12_1V
12V
470uF
BD103
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
TYPICAL APPLICATION CIRCUIT
C117
R117
150
D102
R115
2K
1 3
Q102
2N3904
GND2
CN1
12345
1N4148
DR01
DG01
DB01
RR01
75
RG02
RR02
75
75
CR01
CG02
104
104
VCC3
RIN12VCC113GIN14GND115BIN
GOUT
GCLP
VCC222RCLP
19
20
21
CG02
104
RG03
470
RG15
47
12V
C109
1N4148
1N4148
C102
C112
+
+
1uF
1uF
10
11
7
8
ABL_IN
GND9CLP_IN
KB2502
ROUT
BCT25GCT
23
24
26
CR02
104
RR03
470
RR15
47
R123
VREF1
VREF5VDDA6CONT_CAP
VSS
SCL29SDA
RCT
27
28
C160
103
1M
C114
103
C110
C111
+
4.7uF
R109
27K
4
+
100uF
BD102
5V
R108
5.6K
C113
R120
562
30M
3
VFLB1VSSA2VCO_IN
C152
104
+
C103
HFLB
VDD
30
31
+
47uF
R124
220
L103
27uH
C151
32
104
C128
104
5V
R114
470
CN2
1N4148
1N4148
1N4148
6
RB01
RG01
75
75
RB02
75
CB02
104
16
BCLP
BOUT
17
18
CB02
104
RB03
470
RB15
47
14
C119
102
5V
SK101
WSP-401M
C126
C116
1nF
C118
330pF
R116
1N4148
1.8nF
1nF
10K
G1
12345678910111213
C123
103
C124
103
L101
100uH
R103
390
R118
R119
DR02
70V
DG02
6.3V
DB02
12V
R107
1K
R101
4.7K
R102
100
560
560
2
CB05
RB12
2.2K
2N5401C-Y
6
7
9
8
BIN
GIN
RIN
G_OUT
VBB
DRIVER IC
GOUT
ROUT
BOUT
GND
VCC
1
2
5
3
4
RB14
RG14
75
75
C121
104
C108
+
47uF
70V
DB03
DG03
1SS244
1SS244
RR09
75K
RG09
75K
DR03
1SS244
+
+
CB04
CG04
1uF
1uF
RB09
75K
LB01
LG01
0.15uH
0.15uH
RB10
RG10
39
39
B_OUT
C106
C107
VDD
DMS-200D
DMS-200D
DMS-200D
220uF
104
+
1SS244
1SS244
1SS244
12V
RR14
75
DB04
DG04
DR04
+
CR04
1uF
LR01
0.15uH
RR10
SKB01
39
SKG01
SKR01
R_OUT
CG05
104
RG12
2.2K
QG02
DMS-200D
RG11
100
RG20
4.7K
1 3
QG01
2
2N5551C-Y
CG05
104
2
13
RG13
82K
DG05
1N4148
SK102
C120
CR05
RR12
2.2K
2N5401C-Y
1nF
RR11
100
RR20
4.7K
1 3
QR01
2
2N5551C-Y
CR05
104
104
2
QR02
13
RR13
82K
DR05
1N4148
R104
390
RB11
100
RB20
4.7K
1 3
QB01
2
2N5551C-Y
CB05
104
104
2
QB02
2N5401C-Y
13
RB13
82K
DB05
1N4148
G2G2
Figure 27. Typical Application Circuit
56
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
ROM FONTS
Figure 28. ROM Fonts
57
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
58
Preliminary
VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS S1D2502B01
59
Preliminary
S1D2502B01 VIDEO AMP MERGED OSD PROCESSOR FOR MONITORS
60
Loading...
