Samsung RT 58 ZATG, RT 58 ZANB, RT 62 VATG, RT 62 VANB, RT 58 ZAMT User Manual
OWNER’S MANUAL
REFRIGERATOR
ENGLISH
Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
•
If you disconnect from the power supply, plug in again after five minutes.
•
How to install and disassemble the door handle. (reference 15page)
Register your product at www.samsung.com/global/register
DA99-00743F REV(0.8)
FEATURES
Digital temperature control display
(option)
• The display shows all functions of the
appliance which can be easily controlled.
Vacation (option)
• Save on energy consumption by switching
off the fridge and maintaining only the
freezer.
SUPER fast freezing function (option)
• The Super Freeze function allows you to
freeze food quickly. Ice can be produced
faster.
Surround Cooling System
• Freshness depends on cooling speed. The
surround cooling system blows cold air to
every corner for even cooling.
Quick opening and closing system!
• Vegetables and fruits can be rapidly
accessible to prevent loss of cold temp
using a rail system design in high-humidity
vegetable bin and special fresh bin which
operates smoothly only by pulling and
pushing the handle.
A slightly opened door is closed
automatically.
• In case of a slight opening of the
refrigerator door, it will close automatically
by using an energy saving automatic
closing function.
• Because this operating instruction book covers
various models, the characteristics of your
refrigerator may differ slightly from those
described in this manual.
Warning
• This appliance is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsilble person to
ensure that they can use the appliance safely.
• Children should be supervised to ensure that they
do not interfere with the appliance.
• The appliance must be positioned so that the plug
is accessible after installation.
CONTENTS
FEATURES ................................................................................. 2
WARNINGS / SAFETY PRECAUTIONS ................................. 3
INSTALLING THE FRIDGE/FREEZER .................................... 5
USING THE CONTROL FEATURES
USING THE CONTROL FEATURES
MAKING ICE............................................................................... 8
FUNCTIONS OF WATER DISPENSER (OPTION).................. 9
HOW TO CLEAN ..................................................................... 10
GENERAL CLEANING ........................................................... 11
HOW TO DISASSEMBLE THE ACCESSORIES ................... 12
REPLACING THE INTERIOR LIGHT .......................................13
HOW TO INSTALL AND DISASSEMBLE THE DOOR HANDLE
PROBLEMS AND SOLUTIONS ...............................................15
USAGE PRECAUTIONS...........................................................16
VIEW OF YOUR FRIDGE / FREEZER.....................................17
(ELECTRONIC CONTROL TYPE)
(DIAL CONTROL TYPE)
..... 6
................ 7
....14
2
WARNINGS / SAFETY PRECAUTIONS
To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to
observe the following safety precautions. (After reading these owner’s instructions, please keep them in
a safe place for reference). Remember to hand them over to any subsequent owner.
Indicates that a danger of death or
Warning
Do not plug several appliances into the same
sockets.
• This could cause overheating and the risk of fire.
Keep the power plug away from the rear of the
fridge/freezer.
• A damaged power plug may cause fire due to
overheating.
Do not directly spray water inside or outside
the fridge/freezer.
• There is a risk of fire or electric shock.
Do not spray inflammable gas near the
fridge/freezer.
• There is a risk of explosion or fire.
Do not bend the power cord excessively or
place heavy articles on it.
This constitutes a fire hazard.
serious injury exists.
Warning
If the power cord
is damaged, have it replaced immediately by the
manufacturer, its service agent or a similarly
qualified person.
Do not insert the power plug with wet hands.
• You may receive an electric shock.
Do not put a container filled with water on top
of the appliance.
• If the water spills on to any electrical parts, it may
lead to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
• Incorrect insulation of the electrical parts may
cause an electric shock or fire.
• Do not place the equipment directly under the
sunlight.
Indicates that a risk of personal
injury or material damage exists.
Caution
Do not store volatile and inflammable
substances in the refrigerator.
• The storage of benzene, thinner, alcohol, ether,
LP gas or other such substances may cause an
explosion.
Do not disassemble, repair or alter the
appliance.
• It may cause fire or abnormal operations, which
may lead to injury.
Pull the power plug out of the socket before
replacing the interior light in the refrigerator.
• Otherwise, there is a risk of electric shock.
Make sure that appliance is correctly earthed.
• Otherwise, it may cause material damage and
electric shock.
If you wish to dispose of the fridge/freezer,
throw it away after removing the door or its
seals.
• In this way, it is not possible for a child to remain
trapped inside it.
• The gases in the insulation material required
special disposal procedure.
• Please dispose of the packaging material for this
product in an environmentally friendly manner.
• Please contact your local authorities in regard to
the enviromentally safe disposal of this product.
• This product is intended only for the storage of
food in a domestic environment.
3
Warning
• Keep ventilation openings in the appliance
enclosure or mounting structure clear of
obstruction.
• Do not use mechanical devices or any other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the
fridge/freezer, unless they are a type
recommended by the manufacturer.
Caution
Do not store too much food in the appliance.
• When you open the door, an item may fall out and
cause personal injury or material damage.
Do not put bottles or any kinds of glass in the
freezer.
• The container may break and cause personal
injury.
If the wall socket outlet is loose, do not insert
the power plug.
• It May cause electric shock or fire.
Do not disconnect the power cord by pulling
on it.
• You may disconnect a wire and cause a short
circuit.
Do not store articles on top of the appliance.
• When you open or close the door, the articles may
fall and cause personal injury or material damage.
Do not store pharmaceutical products, scientific
materials or other temperature-sensitive
products in the refrigerator.
• Products that require strict temperature controls
must not be stored in the refrigerator.
Do not let a child hang from the door.
Do not touch any containers and food in the
freezer with wet hands.
• It may cause frostbite.
Remove any foreign matter from the power plug
pins.
• Otherwise, there is a risk of fire.
Do not insert your hand into the bottom area of
the appliance.
• Any sharp edges may cause personal injury.
After unplugging the appliance, wait for at least
five minutes before plugging it in again to the
wall socket outlet.
• Abnormal operation of the freezer may cause
material damage.
If the appliance is not to be used for a long
period of time, pull out the power plug.
• Any deterioration in the wire insulation may cause
fire.
Do not let children touch or play with the
controller of the appliance.
• Do not allow children to interfere with the
appliance.
• Repairs and maintenance of the appliance should
only be performed by a qualified technician.
Incorrect repairs by an unqualified person are a
potential source of danger that may have critical
consequences for the user of the appliance.
• Never put ice cubes or ice lollies straight from the
freezer into your mouth. (The low temperature
may cause “freezer burns”.)
• Contains fluorinated greenhouse gases covered
by the Kyoto Protocol.
• Hermetically sealed system.
• Do not vent gases into the atmosphere.
• Refrigerant type: R-134a
• Quantity: 0.16 Kg
• Global Warming Potential (GWP) = 1300
4
INSTALLING THE FRIDGE/FREEZER
Allow an adequate space and install the fridge/freezer on a firm, level floor.
• If the appliance is not level, there may be unusual noises and poor cooling.
• Wait for at least five minutes before plugging the appliance in.
Clean the fridge/freezer.
• Wipe and clean the appliance inside and outside with a damp cloth.
Plug the fridge/freezer into a wall socket outlet used exclusively by this appliance.
• This appliance must be properly earthed.
Place the food in the fridge/freezer.
• Set the temperature control to the colder temperature and let the refrigerator operate for one
hour. The freezer should get slightly chilled and the motor should run smoothly with a soft hum
and no noise. Your fridge/freezer is operated by a compressor which switches “on and off” to
maintain the internal temperature. When the compressor is new, it requires running in for a period
of up to five months. During this period, it may be slightly noisy. This is quite normal and does not
represent a fault.
Warning
Use of an grounded socket exclusively for the appliance:
• If you are using a socket with an earthing terminal, you
do not require a separate earthing connection.
Use of a no grounded wire socket:
• Connect the “grounding wire” to the copper plate and bury
it at a depth of at least 25 cm in the ground.
LEVELLING
If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily.
The appliance tilts down to the left.
Turn the left adjusting leg in the direction of the arrow until
the appliance is level.
The appliance tilts down to the right.
Turn the right adjusting leg in the direction of the arrow until the
appliance is level.
• When the level adjustment legs are not fixed on the
Caution
❊ What if they do not make the ground circuit correctly.
floor, the refrigerator could move.
• Please tie up the extra length of the power cord at the
back of the refrigerator so as not to be touched on the
floor preventing the power cord from being crushed by the
rollers upon relocation.
They acted on samsung advice.
5
USING THE CONTROL FEATURES (ELECTRONIC CONTROL TYPE)
Super Freeze
●
You can push this button, when you
want to make ice or cool food quickly.
●
If you push Super Freeze button the
indicator will work for 2.5hrs nonstop.
●
To stop Super Freeze, simply press
the Super Freeze button once more.
Vacation
●
If you are going on a long vacation or
business trip or you do not need to
use the refrigerator, press the
vacation button.
●
The refrigerator is switched off but the
freezer remains on.
●
The vacation indicator remains on
while in vacation mode.
• You must empty the
Caution
refrigerator before pressing
the vacation button.
1. Freezer Temp Setting
1) With the initial power is on, Freezer will be set at -19°C and Fridge will be set at 3°C
automatically. At this time, the temp on the display panel means the temp in the
fridge/freezer and as the temp decreases the displayed temp also decreases down to
the set temp. Afterward, the displayed temp is the set temp.
2) Freezer Temp can be set from -14°C to -25°C with Freezer temp setting button.
2. Fridge Temp Setting
1) Fridge Temp can be set from 7°C to 1°C with Fridge temp setting button.
2) Fridge set temp varies slightly from actual temperature according to the user’s way of
storing food and Ambient temp.
3. Door Alarm
1) you can check the airtight of door with the alarm.
2) If the door of refrigerator is left opened over the angle 5°, the alarm will operate for
10 second every 2 minute repeatedly.
As soon as you plug in a refrigerator, this function will operate.If you don’t want to
use this function,push this button and then you will see the lamp off.
4. TriCool Zone Temp Setting(Option)
Specially designed bin with temperature control function for costomized life styles.
Chilled room : To store dairy products or
thawed-out meat /fish before cooking.
Do not adjust this position when
storing fruits or vegetables.
Caution
Fridge Drawer : When there is a large quantity
of food products to store,it can be used as the
same as the fridge compartment.
Crisper Drawer : When additional room for fruits
or vegetables is needed, it can be used to store a
large quantity of them in fresh conditions.
6
Loading...
