OWNER’S MANUAL

REFRIGERATOR

ENGLISH

Before operating the unit, please read this manual thoroughly,

and retain it for future reference.

•

If you disconnect from the power supply, plug in again after five minutes.

•

How to install and disassemble the door handle.(reference 12page)

DA99-00849F REV(0.0)

FEATURES

Digital temperature control display (option)

• The display shows all functions of the appliance which can be easily controlled.

Vacation (option)

•

If you are going on a long vacation or business trip or you do not need to use the refrigerator, adjust the temperature control to the “VACATION” position.

QUICK freezing function (option)

• The Quick Freeze function allows you to freeze food quickly.Ice can be produced faster .

Surround Cooling System

• Freshness depends on cooling speed.The surround cooling system blows cold air to every corner for even cooling.

• Because this operating instruction book covers various models, the characteristics of your refrigerator may differ slightly from those described in this manual.

Warning

• This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsilble person to ensure that they can use the appliance safely.

• Children should be supervised to ensure that they do not interfere with the appliance.

• The appliance must be positioned so that the plug is accessible after installation.

Quick opening and closing system!

• Vegetables and fruits can be rapidly accessible to prevent loss of cold temp using a rail system design in high-humidity vegetable bin and special fresh bin which operates smoothly only by pulling and pushing the handle.

A slightly opened door is closed automatically.

• In case of a slight opening of the refrigerator door, it will close automatically by using an energy saving automatic closing function.

CONTENTS

FEATURES................................................................................. 2

WARNINGS / SAFETY PRECAUTIONS ................................. 3

INSTALLING THE FRIDGE/FREEZER .................................... 5

USING THE CONTROL FEATURES USING THE CONTROL FEATURES

MAKING ICE............................................................................... 8

GENERAL CLEANING ............................................................. 9

HOW TO DISASSEMBLE THE ACCESSORIES ................... 10

REPLACING THE INTERIOR LIGHT.......................................11

HOW TO INSTALL AND DISASSEMBLE THE DOOR HANDLE

PROBLEMS AND SOLUTIONS...............................................13

USAGE PRECAUTIONS...........................................................14

VIEW OF YOUR FRIDGE / FREEZER.....................................15

(ELECTRONIC CONTROL TYPE) (DIAL CONTROL TYPE)

..... 6

................ 7

....12

WARNINGS / SAFETY PRECAUTIONS

To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to observe the following safety precautions. (After reading these owner’s instructions, please keep them in a safe place for reference). Remember to hand them over to any subsequent owner.

Indicates that a danger of death or

Warning

Do not plug several appliances into the same sockets.

• This could cause overheating and the r isk of fire.

Keep the power plug away from the rear of the fridge/freezer.

• A damaged power plug may cause fire due to overheating.

Do not directly spray water inside or outside the fridge/freezer.

• There is a risk of fire or electric shock.

Do not spray inflammable gas near the fridge/freezer.

• There is a risk of explosion or fire.

Do not bend the power cord excessively or place heavy articles on it. This constitutes a fire hazard.

serious injury exists.

Warning

If the power cord is damaged, have it replaced immediately by the manufacturer,its service agent or a similarly qualified person.

Do not insert the power plug with wet hands.

• You may receive an electric shock.

Do not put a container filled with water on top of the appliance.

• If the water spills on to any electrical parts, it may

lead to fire or electric shock.

Do not install the fridge/freezer in a damp place, where it could be splashed with water.

• Incorrect insulation of the electrical par ts may

cause an electric shock or fire.

• Do not place the equipment directly under the

sunlight.

Indicates that a risk of personal injury or material damage exists.

Caution

Do not store volatile and inflammable substances in the refrigerator.

• The storage of benzene, thinner, alcohol, ether, LP gas or other such substances may cause an explosion.

Do not disassemble, repair or alter the appliance.

• It may cause fire or abnormal operations, which may lead to injury.

Pull the power plug out of the socket before replacing the interior light in the refrigerator.

• Otherwise, there is a risk of electric shock.

Make sure that the appliance is correctly earthed.

• Otherwise, it may cause material damage and electric shock.

If you wish to dispose of the fridge/freezer, throw it away after removing the door or its seals.

• In this way, it is not possible for a child to remain trapped inside it.

• The gases in the insulation material required

special disposal procedure.

• Please dispose of the packaging material for this

product in an environmentally friendly manner.

• Please contact your local authorities in regard to

the enviromentally safe disposal of this product.

• This product is intended only for the storage of

food in a domestic environment.

Warning

• Keep ventilation openings in the appliance enclosure or mounting structure clear of obstruction.

• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the fridge/freezer, unless they are a type recommended by the manufacturer.

Caution

Do not store too much food in the appliance.

• When you open the door, an item may fall out and cause personal injury or material damage.

Do not put bottles or any kinds of glass in the freezer.

• The container may break and cause personal injury.

If the wall socket is loose, do not insert the power plug.

• It May cause electric shock or fire.

Do not disconnect the power cord by pulling on it.

• You may disconnect a wire and cause a short circuit.

Do not store articles on top of the appliance.

• When you open or close the door, the ar ticles may fall and cause personal injury or material damage.

Do not store pharmaceutical products, scientific materials or other temperature-sensitive products in the refrigerator.

• Products that require strict temperature controls must not be stored in the refrigerator.

Do not let a child hang from the door.

Do not touch any containers and food in the freezer with wet hands.

• It may cause frostbite.

Remove any foreign matter from the power plug pins.

• Otherwise, there is a risk of fire.

Do not insert your hand into the bottom area of the appliance.

• Any sharp edges may cause personal injury.

After unplugging the appliance, wait for at least five minutes before plugging it in again to the wall socket.

• Abnormal operation of the freezer may cause material damage.

If the appliance is not to be used for a long period of time, pull out the power plug.

• Any deterioration in the wire insulation may cause fire.

Do not let children touch or play with the controller of the appliance.

• Do not allow children to interfere with the appliance.

• Repairs and maintenance of the appliance should only be performed by a qualified technician. Incorrect repairs by an unqualified person are a potential source of danger that may have critical consequences for the user of the appliance.

• Never put ice cubes or ice lollies straight from the freezer into your mouth.(The low temperature may cause “freezer bur ns”.)

INST ALLING THE FRIDGE/FREEZER

Allow an adequate space and install the fridge/freezer on a firm, level floor.

• If the appliance is not level, there may be unusual noises and poor cooling.

• Wait for at least five minutes before plugging the appliance in.

Clean the fridge/freezer.

• Wipe and clean the appliance inside and outside with a damp cloth.

Plug the fridge/freezer into a wall socket used exclusively by this appliance.

• This appliance must be properly earthed.

Place the food in the fridge/freezer.

• Set the temperature control to the colder temperature and let the refrigerator operate for one hour.The freezer should get slightly chilled and the motor should run smoothly with a soft hum and no noise.Your fridge/freezer is operated by a compressor which switches “on and off” to maintain the internal temperature. When the compressor is new, it requires running in for a period of up to five months.During this period, it may be slightly noisy. This is quite normal and does not represent a fault.

Warning

Use of an grounded socket exclusively for the appliance:

• If you are using a socket with an earthing terminal, you do not require a separate earthing connection.

Use of a no grounded wire socket:

• Connect the “grounding wire” to the copper plate and bury it at a depth of at least 25 cm2in the ground.

LEVELLING

If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily.

The appliance tilts down to the left.

Turn the left adjusting leg in the direction of the arrow until the appliance is level.

The appliance tilts down to the right.

Turn the right adjusting leg in the direction of the arrow until the appliance is level.

• When the level adjustment legs are not fixed on the

Caution

❊ What if they do not make the ground circuit correctly.

floor, the refrigerator could move.

• Please tie up the extra length of the power cord at the back of the refrigerator so as not to be touched on the floor preventing the power cord from being crushed by the rollers upon relocation.
