REFRIGERATOR
RT23_26_31_34
OWNER’S INSTRUCTIONS
Before operating the unit, please read t his manual thoroughly, and
retain for future reference.
DA99-01149A REV(0.0)
MAIN FEATURES
Large Freezer Storage Area
- Stores large quantities of food in the freezer.
Jumbo Storage Guard
- Holds large bottles securely.
Two Type Storage Guard
- Position them for your convenience
and efficient storage.
Vegetable Box
- Keep vegetables fresh separately for
longer periods.
BASIC PREPARATION
Read Instructions.
Please read all safety and operating instructions before
operating this appliance.
Retain Instructions.
Please keep this Owner's Manual for future reference.
Heed Warnings.
All warnigns, Cautions and Notes on this refrigerator are
important; please pay attention to them.
Follow Instructions.
For best results, follow all instructions given in this manual.
Model and Serial Numbers.
Include both the model number and the serial number when
corresponding with your Dealer concerning this product.
This manual is made on the basis of
RT25/ RT28 model.
Date of Purchase :
Model No. :
Serial No. :
Sliding Drawer (Select model)
- Extra storage space for vegetables and fruits.
ICooling
- Advanced air circulation for faster surround cooling.
Super Freeze Zone (Select model)
-Freezes stored items quickly.
Twist Ice-Tray (Select model)
-Spring mechanism for automatic release of ice
cubes.
Contents
MAIN FEATURES ................................
BASIC PREPARATION ........................
- Getting Started ...................................
INSTALLATION ....................................
CAUTIONS WHILE USING .................
PARTS ..................................................
REPLACING THE LAMP ......................
STORING FOOD .................................
HOW TO USE ......................................
- Temperature control ...........................
- Ice cube maker ..................................
- Chiller Compartment .........................
- Twin-Vegetable Box ...........................
LEVELING THE APPLIANCE ..............
REMOVING ACCESSORIES ...............
BEFORE CALLING SERVICE ..............
1
1
2
2
3,4
5
6
7
8
8
9
10
10
11
12,13
14,15
1
Getting Started
Before plugging in for the first time, allow the
refrigerator to stabilize for at least one hour.
Allow the freezer compartment to cool for 2 to 3
hours before storing food.
INSTALLATION
???
??
??
The appliance must be positioned so that the
electrical supply and plug
is easily accessible.
Avoid locations affected
by draughts
or dampness.
For optimum operation, normal room
temperature is recommended. Avoid
locations in direct sunlight, near heaters,
radiators, stoves or ovens.
? ????
??
Allow a 100mm space between the refrigeratgor and the
wall.If your refrigerator is going into a recessed area,
allow at least 300mm clearance above the refrigerator.
For personal safety, properly ground this appliance.Do
not ground this refrigerator with a telephone line,
gas pipe, etc.
2
Above 300mm
Above 100mm
Above 100mm
CAUTIONS WHILE USING
-Do not allow water to splash onto
the refrigerator.
-Water impairs the insulation of
electric parts and may cause an
electrical shock or a fire hazard.
-Do not use flammable sprays such
as lacquer and paint near the
refrigerator.
-Heat from the refrigeration unit may
ignite flammable aerosols.
-Do not allow unattended children to
play in or around refrigerators and
other large appliances. The child may
get hurt or they could damage the
appliance.
-Do not allow children to hang on to
the refrigerator door.
-The gases in the insulation material required special
disposal procedure.
-Please dispose of the packaging for this product in an
environmentally friendly manner.
-Please contact your local authorities in regards to the
Environmentally safe disposal of this product.
This product contains flammable insulation blowing gas.
Contact your local authority in regards to safe disposal of this product.
3
-For optimum operation, do not leave the door open
for any longer than necessary.
-Leaving the door open allows warmer air to enter
the refrigerator and causes the refrigeration unit to
use more energy to maintain the temperature.
-Do not store volatile chemicals such as
ether and benzene in the refrigerator.
-The fumes, besides damaging food, can
build up and cause an explosion.
-Do not use the refrigerator if it is not operating
correctly or has been damaged. Disconnect it from
the power supply and call your local service center.
-If the power cord is damaged, avoid a hazard by
replacing it through the manufacturer or its service
agent or a similarly qualified person
-Always be careful of not banging your head on the
bracket lock while storing or taking out food.
-Frequent opening of door can cause excessive
frost in the unit that will reduce the cooling
momentarily, this is a general phenomenon
especially in coastal or high humidity area. It is
not a malfunction. Opening of door should be avoided
while defrosting.
4
PARTS (TYPE - II)
Twist Ice Cube Tray (Select model)
Ice Storage Bin (Select model)
Freezer Compartment Temperature
Control
Super-Freeze Zone (Select model)
Chiller Compartment (Select model)
Refrigerator Compartment
Temperature Control
i-Cooling
Refrigerator Shelf (Glass or Steel)
Lamp
Guard Variety
Dairy Guard (Select model)
Bottle Guide (Select model)
Jumbo Guard
Bottle Storage Guard
Bio-Fresh Zone (Select model)
Sliding Drawer (Select model)
It is recommended to store fruits & vegetables in Bio-fresh Zone/Case vegetable.
