Samsung RL55VQBRS, RL52VEBTB, RL52VPBTS, RL55VTEBG, RL52VEBTS1 User Manual
Refrigerator
user manual
English
imagine the possibilities
Thank you for purchasing this Samsung product. To receive more complete service, please register your product at
www.samsung.com/register
Free Standing Appliance
features of your new refrigerator
KEY FEATURES OF YOUR NEW REFRIGERATOR
Your Samsung Refrigerator comes equipped with various innovative storage and energy-efficient features. Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual.
• COOL SELECT ZONE™
You can store specific foods at various temperature conditions.
• LCD TOUCH SCREEN
Simply touch the screen and all the functions make your life easier at your finger tips. From checking personal schedules, enjoying on-screen photos, getting nutrition facts, unit conversion, to controlling refrigerator temperature through the screen.
• POWER FREEZE
Store food in fresh conditions by cooling it quickly via the “Power Freeze” function.
• VACATION
Save on energy consumption when you take a long vacation or are away for any reason.
CE Notice
This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), the Electromagnetic Compatibility Directive (2004/108/EC) and Energy efficiency Directive (96/57/EC) of the European Union.
For easy future reference, write the model and serial number down. You will find your model number on the left bottom side of the refrigerator.
2_ features
Model #
Serial #
safety information
safety information
•Before operating the appliance, please read this manual thoroughly and retain it at a safe place near the appliance for your future reference.
•Use this appliance only for its intended purpose as described in this instruction manual. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
•Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your appliance.
•Because these following operating instructions cover various models,
the characteristics of your refrigerator may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com.
Important safety symbols and precautions:
|
Hazards or unsafe practices that may result in severe personal |
WARNING |
injury or death. |
Hazards or unsafe practices that may result in minor personal
CAUTION injury or property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the contact center for help.
Note.
These warning signs are here to prevent injury to you and others. Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
safety information _3
safety information
WARNING SEVERE WARNING SIGNS FOR TRANSPORTATION AND SITE
•When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-Refrigerant squirting out of the pipes could ignite or cause an eye injury.
If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
•In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used.
•Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room where the refrigerator will be sited must be 1m³ in size for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance.
WARNING SEVERE WARNING SIGNS FOR INSTALLATION
•Do not install the refrigerator in a damp place or place where it may come in contact with water.
-Deteriorated insulation of electrical parts may cause an electric shock or fire.
•Do not place this refrigerator in direct sunlight or expose to the heat from stoves, room heaters or other appliance.
•Do not plug several appliances into the same multiple power board.
The refrigerator should always be plugged into its own individual electrical which has a voltage rating that matched the rating plate.
-This provides the best performance and also prevents overloading house wiring circuits, which could cause a fire hazard from overheated wires.
•If the wall socket is loose, do not insert the power plug.
-There is a risk of electric shock of fire.
•Do not use a cord that shows cracks or abrasion damage along its length or at either end.
•Do not bend the power cord excessively or place heavy articles on it.
•Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.
-Damage to the cord may cause short-circuit, fire and/or electric shock.
•Do not use aerosols near the refrigerator.
-Aerosols used near the refrigerator may cause an explosion or fire.
4_ safety information
•This refrigerator must be properly installed and located in accordance with the manual before it is used.
•After unpacking, keep the packing materials out of reach of children.
-There is a risk of death from suffocation if children put them over their head.
•Connect the power plug in proper position with the cord hanging down.
-If you connect the power plug upside down, wire can get cut off and cause fire or electric shock.
•Make sure that the power plug is not squashed or damaged by the back of the refrigerator.
•When moving the refrigerator, be careful not to roll over or damage the power cord.
-This constitutes a fire hazard.
•The appliance must be positioned so that the plug is accessible after installation.
• The refrigerator must be grounded.
-You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator.
•Never use gas pipes, telephone lines or other potential lightening rods as ground.
-Improper use of the ground plug can result in electric shock.
•If the power cord is damaged, have it replaced immediately by the manufacturer or its service agent.
•The fuse on the refrigerator must be changed by a qualified technician or service company.
-Failing to do so may result in electric shock or personal injury.
CAUTION CAUTION SIGNS FOR INSTALLATION
• Allow sufficient space to install the refrigerator on a flat surface.
-If your refrigerator is not level, the internal cooling system may not work correctly.
•Keep ventilation opening in the appliance enclosure or mounting structure clear of obstruction.
•Allow the appliance to stand for 2 hours after installation.
WARNING SEVERE WARNING SIGNS FOR USING
•Do not insert the power plug with wet hands.
•Do not store articles on the top of the appliance.
-When you open or close the door, the articles may fall and cause personal injury and/or material damage.
safety information _5
safety information
WARNING SEVERE WARNING SIGNS FOR USING (cont’d)
•Do not put items filled with water on the refrigerator.
-If spilled, there is a risk of fire or electric shock.
•Do not let children hang on the door.
-Failure to do so may cause serious personal injury.
•Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside of the refrigerator.
-There is a risk of children entrapment and serious personal injury because of low temperature.
•Do not insert your hands into the bottom area under the appliance.
-Any sharp edges may cause personal injury.
•Do not let children step on drawer’s cover.
-It may break and cause slip hazard.
•Do not overfill the refrigerator with food.
-When you open the door, an item may fall out and cause personal injury or material damage.
•Never put fingers or other objects into the dispenser hole.
-Failure to do so may cause personal injury or material damage.
•Do not store volatile or flammable substances such as benzene, thinner, alcohol, ether or LP gas in the refrigerator.
-The storage of any of such products may cause explosions.
•Do not store low temperature-sensitive pharmaceuticals products, scientific materials or other low temperature-sensitive products in the refrigerator.
-Products that require strict temperature controls must not be stored in the refrigerator.
•Do not place or use electrical appliance inside the refrigerator, unless they are of a type recommended by the manufacturer.
•Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odors.
-This may result in electric shock or fire.
•Do not touch the inside walls of the freezer or products stored in the freezer with wet hands.
-This may cause frostbite.
•Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.
•Do not damage the refrigerant circuit.
6_ safety information
• This product is intended only for the storage of food in a domestic environment.
•Bottles should be stored tightly together so that they do not fall out.
•If a gas leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
•Use only the LED Lamps provided by manufacturer or service agents.
•Children should be supervised to ensure that they do not play with and/or climb into the appliance.
• Do not disassemble or repair the refrigerator by yourself.
-You run risk of causing a fire, malfunction and/or personal injury. In case of malfunction, please contact your service agents.
• Pull the power plug out of the socket before changing the interior lamps of the refrigerator.
-Otherwise, there is a risk of electric shock.
•If the appliance generates a strange noise, a burning or smell or smoke, unplug the power plug immediately and contact your nearest service center.
-Failing to do so may result in electric or fire hazards. Keep ventilation opening in the appliance enclosure or mounting structure clear of obstruction.
•If you experience difficulty when changing the light, contact service agents.
•If the products equipped with LED Lamp, do not disassemble Lamp Cover and
LED Lamp by yourself.
-Please contact your service agents.
•If any dust or water is in refrigerator, pull out power plug and contact your
Samsung Electronics service center.
-There is a risk of fire.
CAUTION CAUTION SIGNS FOR USING
•If the refrigerator is disconnected from the power supply, you should wait for at least five minutes before plugging it back in.
•If you will be away for more than three weeks or the refrigerator will not be used for a long period of time, you must empty and clean the refrigerator and pull out the power plug. Wipe excess moisture from the inside and leave the doors open.
-Otherwise, odor and mold may develop.
-Deterioration in the insulation may cause fire.
•To get best performance of product,
-Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the refrigerator compartment.
-Wrap the food up properly or place it in airtight containers before put it into the refrigerator.
safety information _7
safety information
CAUTION CAUTION SIGNS FOR USING (cont’d)
• Do not re-freeze frozen foods that have thawed completely.
•Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer.
-When the contents freeze, the glass may break and cause personal injury and property damage.
•Do not change the functionality of or modify the refrigerator.
-Changes or modifications may result in personal injury and/or property damage. Any changes or modifications performed by a 3rd party on this completed appliance is neither covered under Samsung warranty service, nor is Samsung responsible for safety issues and damages that result from 3rd party modifications.
•Do not block air holes.
-If the air holes are blocked, especially with a plastic bag, the refrigerator can be over cooled. If this cooling period lasts too long, the water filter may break and cause water leakage.
-Do not put any newly introduced food for freezing near to already frozen food.
•Please observe maximum storage times and expiry dates of frozen goods.
•Fill water tank, ice tray, water cubes only with potable water.
•Do not place food inside the refrigerator in a haphazard way.
-The food will not cool properly.
•If the appliance is flooded, cut the power immediately and contact your nearest service center.
CAUTION CAUTION SIGNS FOR CLEANING AND MAINTENANCE
•Do not directly spray water inside or outside the refrigerator.
-There is a risk of fire or electric shock.
•Do not spray inflammable gas near the refrigerator.
-There is a risk of explosion or fire.
•Do not spray cleaning products directly on the display.
-Printed letters on the display may come off.
•Remove any foreign matter or dust from the power plug pins. But do not use a wet or damp cloth when cleaning the plug, remove any foreign material or dust from the power plug pins.
-Otherwise there is a risk of fire or electric shock.
• Unplug the refrigerator before cleaning and performing maintenance.
8_ safety information
WARNING SEVERE WARNING SIGNS FOR DISPOSAL
•Ensure that none of the pipes on the back of the appliance are damaged prior to disposal.
•R600a or R134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the refrigerator to see which refrigerant is used for your refrigerator. When this product contains flammable gas (Refrigerant R600a), contact your local authority in regard to safe disposal of this product. Cyclopentane is used as an insulation blowing gas. The gases in insulation material require special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product. Ensure that none of the pipes on the back of the appliances are damaged prior to disposal. The pipes shall be broke in the open space.
•If the appliance contains iso-butane refrigerant (R600a), a natural gas with high environmental compatibility that is, however, also combustible.
When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
•When disposing of this product or other refrigerators, remove the door/door seals, door latch so that small children or animals cannot become trapped inside. Leave the shelves in place so that children may not easily climb inside. Children should be supervised to ensure that they do not play with the old appliance.
•Please dispose of the packaging material for this product in an environmentally friendly manner.
ADDITIONAL TIPS FOR PROPER USAGE
• In the event of a power failure, call the local office of your Electricity Company and ask how long it is going to last.
- Most power failures that are corrected within an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off.
- Should the power failure last more than 24 hours, remove all frozen foods.
• If keys are provided with the refrigerator, the keys should be kept out of the reach of children and not in vicinity of the appliance.
• The appliance might not operate consistently (possibility of temperature becoming too warm in refrigerator) when sited for an extended period of time below the cold end of the range of temperature for which the refrigerating appliance is designed.
• Do not store food which spoils easily at low temperature, such as bananas, melons.
• Your appliance is frost free, which means there is no need to manually defrost your appliance, as this will be carried out automatically.
• Temperature rising during the defrost can comply with ISO requirement.
But if you want to prevent an undue rise in the temperature of the frozen food while defrosting the appliance, please wrap the frozen food in several layers of newspaper.
• Any increase in temperature of frozen food during defrosting can shorten its
storage life.
safety information _9
contents
SETTING UP YOUR
Refrigerator
11
OPERATING YOUR
Refrigerator
24
CLEANING and maintaining
YOUR Refrigerator
36
APPENDIX
39
11Getting ready to install the refrigerator
12Reversing the refrigerator door
20 Reversing the door handle
22Leveling the refrigerator
23Setting up the refrigerator
24Checking the control panel
27Using the control panel
30Storing food
32Using Cool Select Zone™
32Making ice
33Using the foldable shelf
33Using the water dispenser
35Using the photosynthetic fresh
36Removing the interior parts
37Cleaning the refrigerator
38Cleaning the water dispenser
38Replacing the led lamp
39Troubleshooting
10_ contents
setting up your refrigerator
GETTING READY TO INSTALL THE Refrigerator
Congratulations on your purchase of this Samsung Refrigerator. We hope you enjoy state- of-the-art features and efficiencies that this new appliance offers.
•This refrigerator must be properly installed and located in accordance with the manual before it is used.
•Use this appliance only for its intended purpose as described in this instruction manual.
•We strongly recommend that any servicing be performed by a qualified individual.
•Please dispose of the packaging material for this product in an environmentally friendly manner.
Pull the power plug out of the socket before changing the interior light of the WARNING refrigerator.
- Otherwise, there is a risk of electric shock.
Selecting the best location for the Refrigerator
•A location without direct exposure to sunlight.
•A location with flat floor surface.
•A location with enough space for the refrigerator door to open easily.
•Allow sufficient space to the right, left, back and top for air circulation.
If the refrigerator does not have enough space, the internal cooling system may not work properly.
•Please ensure that appliance can be moved freely in the event of maintenance
& service.
100mm
2000mm or 1920mm
50mm
UP SETTING 01
•Height of the product may be different depending on the models.
•Allow clearance to the right, left, back and top when installing.
This will help reduce power consumption and keep your energy bills lower.
•Do not install the refrigerator in a place with the temperature lower than 10°C.
Pull the unit straight out when installing, servicing or cleaning behind the
CAUTION refrigerator and push it straight back after work is complete.
Make sure your floor can support fully loaded refrigerator.
setting up _11
setting up your refrigerator
REVERSING THE Refrigerator DOOR
Before you reverse the refrigerator door, make sure to unplug the refrigerator.
WARNING If this operation is not performed by After sales service, it is not covered by the warranty.
Required Tools
Not provided |
Additional part |
|
|
|
|
|
|
|
|
10mm |
11mm |
3/16” |
Top Left |
Phillips Head |
Flat Head |
Socket |
Wrench |
Allen Wrench |
Hinge Cover |
Driver (+) |
Driver (-) |
Wrench |
(for hinge |
(for middle |
(Underneath the |
|
|
(for bolts) |
shaft) |
hinge) |
Top Cover) |
|
|
|
|
|
|
1. Remove 4 screws on the Top cover of the refrigerator.
WARNING Make sure your refrigerator is unplugged before handling electrical wires.
2.Remove the Top cover. Make sure to disconnect the wire underneath the Top cover.
CAUTION Be careful not to damage the electrical wires when removing the Top cover.
12_ setting up
Loading...
