2_ safety information
SAFETY INFORMATION
• Before operating the appliance, please read this
manual thoroughly and retain it at a safe place
near the appliance for your future reference.
• Use this appliance only for its intended purpose
as described in this instruction manual. This
appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Warnings and Important Safety Instructions in
this manual do not cover all possible conditions
and situations that may occur. It is your
responsibility to use common sense, caution,
and care when installing, maintaining, and
operating your appliance.
• Because these following operating instructions
cover various models, the characteristics of
your refrigerator may differ slightly from those
described in this manual and not all warning
signs may be applicable. If you have any
questions or concerns, contact your nearest
service center or fi nd help and information online
at www.samsung.com.
Important safety symbols and
precautions :
WARNING
Hazards or unsafe practices that
may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that
may result in minor personal
injury or property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the
wall socket.
Make sure the machine is grounded
to prevent electric shock.
Call the contact center for help.
Note.
These warning signs are here to prevent
injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe
place for future reference.
CE Notice
This product has been determined to be in
compliance with the Low Voltage Directive
(2006/95/EC), the Electromagnetic Compatibility
Directive (2004/108/EC) and the Eco-Design
Directive(2009/125/EC) implemented by Regulation
(EC) No 643/2009 of the European Union.
SEVERE WARNING SIGNS
FOR TRANSPORTATION
AND SITE
• When transporting and installing the
appliance, care should be taken to ensure
that no parts of the refrigerating circuit are
damaged.
- Refrigerant squirting out of the pipes could ignite
or cause an eye injury.
If a leak is detected, avoid any naked fl ames or
potential sources of ignition and air the room
in which the appliance is standing for several
minutes.
• In order to avoid the creation of a fl ammable
gas-air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the
appliance may be sited depends on the amount
of refrigerant used.
• Never start up an appliance showing any signs
of damage. If in doubt, consult your dealer. The
room where the refrigerator will be sited must
be 1 m³ in size for every 8 g of R600a refrigerant
inside the appliance. The amount of refrigerant
in your particular appliance is shown on the
identifi cation plate inside the appliance.
WARNING
safety information
DA99-03236N(EN)-09.indd Sec2:2DA99-03236N(EN)-09.indd Sec2:2 2012.6.5 10:38:15 AM2012.6.5 10:38:15 AM
safety information _3
SEVERE WARNING SIGNS
FOR INSTALLATION
• Do not install the refrigerator in a damp
place or place where it may come in
contact with water.
- Deteriorated insulation of electrical parts may
cause an electric shock or fi re.
• Do not place this refrigerator in direct sunlight or
expose to the heat from stoves, room heaters or
other appliance.
• Do not plug several appliances into the same
multiple power board.
The refrigerator should always be plugged into
its own individual electrical which has a voltage
rating that matched the rating plate.
- This provides the best performance and also
prevents overloading house wiring circuits,
which could cause a fi re hazard from overheated
wires.
• If the wall socket is loose, do not insert the
power plug.
- There is a risk of electric shock or fi re.
• Do not use a cord that shows cracks or
abrasion damage along its length or at either
end.
• Do not use aerosols near the refrigerator.
- Aerosols used near the refrigerator may cause
an explosion or fi re.
• This refrigerator must be properly installed
and located in accordance with the
manual before it is used.
• Connect the power plug in proper position with
the cord hanging down.
- If you connect the power plug upside down, wire
can get cut off and cause fi re or electric shock.
• Make sure that the power plug is not squashed
or damaged by the back of the refrigerator.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
- This constitutes a fi re hazard.
• The appliance must be positioned so that the
plug is accessible after installation.
• The refrigerator must be grounded.
- You must ground the refrigerator to prevent
any power leakages or electric shocks caused by
current leakage from the refrigerator.
• Never use gas pipes, telephone lines or other
potential lightening rods as ground.
- Improper use of the ground plug can result in
electric shock.
• If the power cord is damaged, have it
replaced immediately by the manufacturer
or its service agent.
• The fuse on the refrigerator must be changed by
a qualifi ed technician or service company.
- Failing to do so may result in electric shock or
personal injury.
CAUTION SIGNS FOR
INSTALLATION
• Keep ventilation opening in the appliance
enclosure or mounting structure clear of
obstruction.
• Allow the appliance to stand for 2 hours after
installation.
SEVERE WARNING SIGNS
FOR USING
• Do not insert the power plug with wet
hands.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles
may fall and cause personal injury and/or
material damage.
• Do not insert your hands into the bottom area
under the appliance.
- Any sharp edges may cause personal injury.
• Do not let children step on drawer’s cover.
- It may break and cause slip hazard.
• Do not overfi ll the refrigerator with food.
- When you open the door, an item may fall out
and cause personal injury or material damage.
• Do not store volatile or fl ammable substances
such as benzene, thinner, alcohol, ether or LP
gas in the refrigerator.
- The storage of any of such products may cause
explosions.
SEVERE WARNING SIGNS
FOR USING (CONT’D)
• Do not put items fi lled with water on the
refrigerator.
- If spilled, there is a risk of fi re or electric shock.
WARNING
CAUTION
WARNING
WARNING
DA99-03236N(EN)-09.indd Sec2:3DA99-03236N(EN)-09.indd Sec2:3 2012.6.5 10:38:15 AM2012.6.5 10:38:15 AM
4_ safety information
• Do not let children hang on the door.
- Failure to do so may cause serious personal
injury.
• Do not leave the doors of the refrigerator open
while the refrigerator is unattended and do not
let children enter inside of the refrigerator.
- There is a risk of children entrapment and
serious personal injury because of low
temperature.
• Do not store low temperature-sensitive
pharmaceuticals products, scientifi c materials or
other low temperature-sensitive products in the
refrigerator.
- Products that require strict temperature controls
must not be stored in the refrigerator.
• Do not place or use electrical appliance inside
the refrigerator, unless they are of a type
recommended by the manufacturer.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odors.
- This may result in electric shock or fi re.
• Do not touch the inside walls of the freezer or
products stored in the freezer with wet hands.
- This may cause frostbite.
• Do not use mechanical devices or any other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
• Do not damage the refrigerant circuit.
• This product is intended only for the
storage of food in a domestic environment.
• Bottles should be stored tightly together so that
they do not fall out.
• If a gas leak is detected, avoid any naked fl ames
or potential sources of ignition and air the room
in which the appliance is standing for several
minutes.
• Use only the LED Lamps provided by
manufacturer or service agents.
• Children should be supervised to ensure that
they do not play with and/or climb into the
appliance.
• Do not disassemble or repair the
refrigerator by yourself.
- You run risk of causing a fi re, malfunction and/
or personal injury. In case of malfunction, please
contact your service agents.
• If the appliance generates a strange noise,
a burning or smell or smoke,
unplug the power plug immediately and
contact your nearest service center.
- Failing to do so may result in electric or fi re
hazards. Keep ventilation opening in the
appliance enclosure or mounting structure clear
of obstruction.
• If any dust or water is in refrigerator, pull
out power plug and contact your Samsung
Electronics service center.
- There is a risk of fi re.
• Replacing the LED Lamp
When the interior or exterior LED lamp has gone
out, please contact your service agents.
• Do not install this appliance in a humid, oily or
dusty location, in a location exposed to direct
sunlight and water (rain drops).
• Do not install this appliance in a location where
gas may leak.
- This may result in electric shock or fi re.
• Plug the power plug into the wall socket in the
right direction so that the cord runs towards the
fl oor.
- If you plug the power plug into the socket in the
opposite direction, the electric wires within the
cable may be damaged and this may result in
electric shock or fi re.
• Install your appliance on a level and hard fl oor
that can support its weight.
- Failing to do so may result in abnormal
vibrations, noise, or problems with the product.
CAUTION SIGNS FOR
USING
• To get best performance of product,
- Do not place foods too closely in front of
the vents at the rear of the appliance as it can
obstruct free air circulation in the refrigerator
compartment.
- Wrap the food up properly or place it in airtight
containers before put it into the refrigerator.
• Do not place carbonated or fi zzy drinks in the
freezer compartment. Do not put bottles or
glass containers in the freezer.
- When the contents freeze, the glass may break
and cause personal injury and property damage.
• Do not change the functionality of or modify the
refrigerator.
- Changes or modifi cations may result in personal
CAUTION
DA99-03236N(EN)-09.indd Sec2:4DA99-03236N(EN)-09.indd Sec2:4 2012.6.5 10:38:16 AM2012.6.5 10:38:16 AM
safety information _5
injury and/or property damage. Any changes or
modifi cations performed by a 3rd party on this
completed appliance is neither covered under
Samsung warranty service, nor is Samsung
responsible for safety issues and damages that
result from 3rd party modifi cations.
• Please observe maximum storage times and
expiry dates of frozen goods.
• If the refrigerator is disconnected from the
power supply, you should wait for at least fi ve
minutes before plugging it back in.
• If you will be away for more than three weeks
or the refrigerator will not be used for a long
period of time, you must empty and clean the
refrigerator and pull out the power plug. Wipe
excess moisture from the inside and leave the
doors open.
- Otherwise, odor and mold may develop.
- Deterioration in the insulation may cause fi re.
• There is no need to disconnect the refrigerator
from the power supply if you will be away for
less than three weeks. But, Remove all the food
if you are going away for the three weeks or
more. Unplug the refrigerator and clean it, rinse
and dry.
• This refrigerator contains fl uorinated greenhouse
gases covered by the Kyoto Protocol. Foam
blown with fl uorinated greenhouse gases.
• If the appliance is fl ooded, cut the power
immediately and contact your nearest
service center.
CAUTION SIGNS FOR
CLEANING AND MAINTENANCE
• Do not directly spray water inside or
outside the refrigerator.
- There is a risk of fi re or electric shock.
• Do not spray infl ammable gas near the
refrigerator.
- There is a risk of explosion or fi re.
• Do not spray cleaning products directly on the
display.
- Printed letters on the display may come off.
• Remove any foreign matter or dust from
the power plug pins. But do not use a wet
or damp cloth when cleaning the plug,
remove any foreign material or dust from
the power plug pins.
- Otherwise there is a risk of fi re or electric shock.
• Unplug the refrigerator before cleaning and
performing maintenance.
Defrosting
- Refrigerator compartment
Defrosting is actuated automatically.
- Freezer compartment
The freezer compartment does not defrost
automatically, otherwise the frozen food would
start thawing. A layer of frost in the freezer
compartment impairs refrigeration of the frozen
food and increases power consumption. Remove
the layer of hoarfrost regularly.
Do not scrape off hoarfrost or ice with
pointed object. You could damage the
refrigerant tubes. Leaking refrigerant
may ignite or cause eye injuries.
1. Pull out mains plug.
2. Place the freezer drawers containing the
food in a cool location.
3. Open condensation outlet.
4. Place the empty container under the open
condensation outlet.
5. When the freezer compartment has defrosted,
pour the water out of the freezer drawer. Wipe
any remaining water off the bottom of the
freezer compartment with a sponge.
6. Close condensation outlet.
7. When defrosting is complete, connect and
switch on the appliance again.
SEVERE WARNING SIGNS
FOR DISPOSAL
• Ensure that none of the pipes on the
back of the appliance are damaged prior
to disposal.
•
R600a or R134a is used as a refrigerant.
Check the compressor label on the rear of
the appliance or the rating label inside the
refrigerator to see which refrigerant is used for
your refrigerator. When this product contains
fl ammable gas (Refrigerant R600a), contact your
local authority in regard to safe disposal of this
product. Cyclopentane is used as an insulation
blowing gas. The gases in insulation material
require special disposal procedure. Please
contact your local authorities in regard to the
environmentally safe disposal of this product.
Ensure that none of the pipes on the back of the
appliances are damaged prior to disposal. The
pipes shall be broken in the open space.
CAUTION
WARNING
CAUTION
DA99-03236N(EN)-09.indd Sec2:5DA99-03236N(EN)-09.indd Sec2:5 2012.6.5 10:38:16 AM2012.6.5 10:38:16 AM
6_ safety information
contents
SETTING UP YOUR REFRIGERATOR ········································································· 7
OPERATING YOUR REFRIGERATOR ········································································· 9
TROUBLESHOOTING ·································································································· 10
FIGURE ························································································································ 12
•
If the appliance contains iso-butane refrigerant
(R600a), a natural gas with high environmental
compatibility that is, however, also combustible.
When transporting and installing the appliance,
care should be taken to ensure that no parts of
the refrigerating circuit are damaged.
• When disposing of this product or other
refrigerators, remove the door/door seals,
door latch so that small children or animals
cannot become trapped inside. Leave the
shelves in place so that children may not
easily climb inside. Children should be
supervised to ensure that they do not play
with the old appliance.
•
Please dispose of the packaging material for this
product in an environmentally friendly manner.
ADDITIONAL TIPS FOR
PROPER USAGE
• In the event of a power failure, call the
local offi ce of your Electricity Company
and ask how long it is going to last.
- Most power failures that are corrected within
an hour or two will not affect your refrigerator
temperatures. However, you should minimize
the number of door openings while the power
is off.
- Should the power failure last more than 24
hours, remove all frozen foods.
• If keys are provided with the refrigerator,
the keys should be kept out of the reach of
children and not in vicinity of the appliance.
• The appliance might not operate consistently
(possibility of temperature becoming too warm
in refrigerator) when sited for an extended
period of time below the cold end of the range
of temperature for which the refrigerating
appliance is designed.
• Do not store food which spoils easily at low
temperature, such as bananas, melons.
• Temperature rising during the defrost can
comply with ISO requirement.
But if you want to prevent an undue rise in
the temperature of the frozen food while
defrosting the appliance, please wrap the
frozen food in several layers of newspaper.
• Any increase in temperature of frozen food
during defrosting can shorten its storage life.
Saving Energy Tips
- Install the appliance in a cool, dry room with
adequate ventilation.
Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat
(radiator, for example).
- Never block any vents or grilles on the
appliance.
- Allow warm food to cool down before placing it
in the appliance.
- Put frozen food in the refrigerator to thaw.
You can then use the low temperatures of the
frozen products to cool food in the refrigerator.
- Do not keep the door of the appliance open for
too long when putting food in or taking food out.
The shorter time for which the door is open, the
less ice will form in the freezer.
- Clean the rear of the refrigerator regularly.
Dust increases energy consumption.
- Do not set temperature colder than necessary.
- Ensure suffi cient air exhaust at the refrigerator
base and at the back wall of the refrigerator.
Do not cover air vent openings.
- Allow clearance to the right, left, back and top
when installing.
This will help reduce power consumption and
keep your energy bills lower.
DA99-03236N(EN)-09.indd Sec2:6DA99-03236N(EN)-09.indd Sec2:6 2012.6.5 10:38:16 AM2012.6.5 10:38:16 AM
setting up _7
01 SETTING UP
GETTING READY TO INSTALL
THE REFRIGERATOR
Congratulations on your purchase of this Samsung
Refrigerator.
We hope you enjoy state-of-the-art features and
effi ciencies that this new appliance offers.
• This refrigerator must be properly installed and
located in accordance with the manual before it is
used.
• Use this appliance only for its intended purpose as
described in this instruction manual.
• We strongly recommend that any servicing be
performed by a qualifi ed individual.
• Please dispose of the packaging material for this
product in an environmentally friendly manner.
Selecting the best location for the
refrigerator (Figure
1
)
• A location without direct exposure to sunlight.
• A location with fl at fl oor surface.
• A location with enough space for the refrigerator
door to open easily.
• Allow suffi cient space to the right, left, back and top
for air circulation.
If the refrigerator does not have enough space, the
internal cooling system may not work properly.
• Please ensure that appliance can be moved freely
in the event of maintenance & service.
• Height of the product may be different
depending on the models.
• Allow clearance to the right, left, back and top
when installing.
This will help reduce power consumption and keep
your energy bills lower.
• Do not install the refrigerator in a place with the
temperature lower than 10 °C.
Pull the unit straight out when installing,
servicing or cleaning behind the
refrigerator and push it straight back after
work is complete. Make sure your fl oor
can support fully loaded refrigerator.
REVERSING THE
REFRIGERATOR DOOR
Before you reverse the refrigerator door,
make sure to unplug the refrigerator.
Samsung recommends that reversing of
the door opening is only completed by Samsung
approved Service providers. This will be on a
chargeable basis and at the customers expense.
Any damage caused while attempting to
reverse the door opening is not covered under
the appliance manufactures warranty. Any
repairs requested due to this circumstance will be
completed on a chargeable basis at the customers
expense.
Required Tools
Not provided
Phillips
Head Driver
(+)
Flat Head
Driver (-)
11 mm
Wrench
(for hinge
shaft)
3/16”
Allen
Wrench
(for middle
hinge)
1. Remove the Hinge cover on the top of the
Fridge door with fl at head driver. (Figure 2)
2.
Remove 2 screws on the Top front cover of the
refrigerator. (Figure 3)
3. Remove the Fridge door from the Middle hinge(A)
by carefully lifting the door straight up.
(Figure 4)
Fridge door is heavy, be careful not to
injure yourself when removing the Fridge
door.
4. Disassemble the Middle hinge(A) by removing 2
bolts. (Figure
5
)
5. Remove the Freezer door from the Bottom
hinge(A) by carefully lifting the door straight up.
(Figure
6
)
Freezer door is heavy, be careful not
to injure yourself when removing the
Freezer door.
CAUTION
CAUTION
CAUTION
WARNING
120º
960 mm
595 mm
515 mm
1,084 mm
at least
50 mm
at least
50 mm
setting up your refrigerator
DA99-03236N(EN)-09.indd Sec4:7DA99-03236N(EN)-09.indd Sec4:7 2012.6.5 10:38:16 AM2012.6.5 10:38:16 AM
8_ setting up
6. Unscrew the leg front and 2 screws at the
Bottom hinge. (Figure
7
)
Before removing the Bottom hinge,
remove the leg.
7. Switch the position of the Bottom hinge shaft.
Remove the screw on the Auto guide(A) and
remove the Bottom hinge shaft with 11 mm
wrench. Attach the Bottom hinge shaft(B) on the
left and put the reversed Auto Guide back.
(Figure
8
)
8. Attach the Bottom hinge on the bottom left side
of the refrigerator where 2 screws was previously
removed in step 8. Screw remaining bolt on the
bottom right side of the refrigerator for the future
usage. (Figure
9
)
9. Switch the position of the Middle hinge cap(A),
from left to the right side. (Figure
10
)
10. Remove the screw on the bottom right side of
the Freezer door.
Switch the position of the Door stopper(A) and
the Hinge grommet(B) and Bracket Stopper
door from the right to the left. (Figure
11
)
11. Switch the Hinge grommet(A) and the Grommet
cap(B) on the top of the Freezer door.
(Figure 12)
12. Carefully put the Freezer door back on.
(Figure
13
)
13. Assemble the Middle hinge with 2 bolts on the
left side. (Figure
14
)
14. Remove the screw on the bottom right side of
the Fridge door.
Switch the Door stopper(A) and the Hinge
grommet(B) and Bracket Stopper door from the
left. (Figure
15
)
15. Use 11mm wrench to separate the Top hinge
shaft. Flip the Top hinge and reattach the Top
hinge shaft. (Figure
16
)
16. Assemble a Top hinge to left side of the Fridge
Door. (Figure
17
)
17. Carefully put the Fridge door back on.
Then tighten 3 bolts to assemble the Top hinge.
(Figure
18
)
• You must reverse the Type B door handle
before putting the Fridge door back.
• For Door handle Type A, make sure to
switch the door handle after reversing the
door.
18. Assembly the Fridge Door to the top of the Ref.
(Figure
19
)
19. Switch the side of the Door cap on the top of
the Fridge door. (Figure
20
)
Make sure that red tape on the wire is
positioned on the end of the Top left hinge
cover.
20. Switch the side of the Display cover Cap.
(Figure
21
)
• After reversing the doors, make sure
the Fridge and Freezer door gaskets are
properly arranged. If not, there might
be a noise or dew formed which affects
perfomance of the refrigerator.
21. Take off the handle cover and remove the
screws, make sure to attach the caps and the
handle at the right side of the door.(Make sure
to cover the right side with detached caps.)
caps and the handle from the right to left side of
the door. (Figure
22
)
LEVELLING THE REFRIGERATOR
If the front of the appliance is slightly higher than
the rear, the door can be opened and closed
more easily.
Turn the adjusting legs clockwise to raise and
counter-clockwise to lower the height. (Figure 23)
Case 1) The appliance tilts down to the left.
• Turn the left adjusting leg in the direction of the
arrow until the appliance is level.
Case 2) The appliance tilts down to the right.
• Turn the right adjusting leg in the direction of the
arrow until the appliance is level.
CAUTION
DA99-03236N(EN)-09.indd Sec4:8DA99-03236N(EN)-09.indd Sec4:8 2012.6.5 10:38:20 AM2012.6.5 10:38:20 AM
02 OPERATING
operating _9
CHECKING THE CONTROL PANEL
<TYPE A> (Figure 24)
1
Fridge
You can set the desired temperature
of the fridge from 1 °C to 6 °C.
2
Power on
When the unit is turned on, this
lamp will be lit.
3
Power
Cool
When this function be working
on, this lamp will be lit.
4
Temp.
Alarm
If the temp. inside refrigerator
be strange, This lamp will be lit.
5
Power
Cool
The unit will be activated for 150
minutes in the Power cool mode.
<TYPE B> (Figure 31)
1
POWER
ON/OFF
Press and hold 3 seconds this
button to turn on or off the
compressor.
2
Temp.
Alarm
If the temperature inside the
freezer cabinet is warmer than
normal, this lamp will be lit.
3
Led Lamp
There are fi ve temperature
settings, represented by fi ve
indicator lights.
When all lights are on, the
temperature is at its coldest.
4
Power
Cool
The unit will be activated for 120
minutes in the Power cool mode.
5
TEMP
You can set the desired
temperature of the fridge from
Cold(5 °C) to Colder(1 °C).
Initially, the mid-point
temperature setting is selected.
When starting the unit at fi rst, the unit will
be activated for 180 minutes in the power
cool mode.
If you need to freeze large amount of food
stuff, turn on the Power Cool mode.
To get the best energy effi ciency of this
product, please leave all shelves, drawers
and baskets on their original position like as
above illustration.
(Figure 30)
The door guard(s) in the freezer of this model
is the two star section, so the temperature in
two star section is slightly higher than other
freezer compartment.
STORING FOOD
To get more space, you can remove drawers
except the lowest drawer as following picture.
It does not affect thermal and mechanical
characteristics.
A declared storage volume of frozen food
storage compartment is calculated with
these drawers removed.
(Figure 25)
Do not touch the Evaporator with
wet hands.
- Stacking of products on the freezer shelves
is acceptable.
(Figure 26)
REMOVING THE INTERIOR PAR
TS
Shelves
Gently lift up the shelves with both hands and pull it
toward you. (Glass shelf/Foldable shelf)
(Figure 27)
Door guards
Firmly grab the door guards with both hands and lift
it up gently to remove the door guards.
(Figure 28)
Drawers
Pull the drawers out fully then slightly lift it up
to remove the drawers. (Fresh safe drawer / Cool
select zone drawer / Cooler zone drawer / Freezer
Drawers )
(Figure 29)
Do not use Benzene, Thinner or
Clorox™ for cleaning.
They may damage the surface of
the appliance and can create a risk of fi re.
You may remove the rubber door
seal from the door to clean it. Make
sure that you put the rubber door
seal back correctly or the refrigerator will not
operate effi ciently.
Do not spray the refrigerator with
water while it is plugged in, as it
may cause an electric shock.
Do not clean the refrigerator with benzene,
thinner or car detergent for risk of fi re.
Clean by using a soft cloth with
neutral detergent.
operating your refrigerator
WARNING
WARNING
CAUTION
CAUTION
CAUTION
DA99-03236N(EN)-09.indd 섹션4:9DA99-03236N(EN)-09.indd 섹션4:9 2012.6.5 10:38:20 AM2012.6.5 10:38:20 AM
10_ troubleshooting
troubleshooting
PROBLEM SOLUTION
The appliance is not
operating at all or the
temperature is too high.
• Check if the power plug is correctly connected.
•
Is the temperature control on the front panel correctly set?
• Does sun shine on the appliance or are there any heat
sources nearby?
• Is the back of the appliance too close to the wall?
• If you select the OFF on the control Panel, Compressor
does not work.
The food in the
refrigerator is frozen.
• Is the temperature control on the front panel set to the
coldest temperature?
• Is the surrounding temperature too low?
There are unusual noises.
•
Check if the appliance is installed on a stable and even fl oor.
• Is the back of the appliance too close to the wall?
•
Have any foreign objects fallen behind or under the appliance?
• Is the noise coming from the compressor in the appliance?
• A ticking sound occurs when the various accessories
contract or expand.
The front corners of the
appliance are warm and
condensation starts to
form.
• Heat-proof pipes are installed in the front corners of the
appliance to prevent condensation from forming.
When the surrounding temperature rises, this may not
always be effective. However, this is not abnormal.
• In very humid weather, condensation may form on the
outer surface of the appliance when the moisture in the air
comes into contact with the cool surface of the appliance.
You can hear a liquid
bubbling in the appliance.
• This is the refrigerant, which cools the inside of the
appliance.
There is a bad smell
inside the appliance.
• Is there any spoiled food inside of the refrigerator?
• Make sure that strong smelling food (for example, fi sh) is
wrapped so that it is airtight.
• Clean out your refrigerator periodically and throw away any
spoiled or suspect food.
There is a layer of frost
on the appliances walls.
• Are the air outlet vents blocked by food stored inside the
refrigerator?
•
Space the food out as much as possible to improve ventilation.
• Is the door fully closed?
• Defrost the freezer compartment (see chapter Defrosting).
Condensation forms on
the inside wall of the
appliance and around
vegetables.
• Food with a high water content is stored uncovered with a
high humidity level or the door has been left open for a
long time.
• Store the food with a cover or in sealed containers.
DA99-03236N(EN)-09.indd 섹션2:10DA99-03236N(EN)-09.indd 섹션2:10 2012.6.5 10:38:20 AM2012.6.5 10:38:20 AM
circuit diagram
DA99-03236N(EN)-09.indd 섹션2:11DA99-03236N(EN)-09.indd 섹션2:11 2012.6.5 10:38:20 AM2012.6.5 10:38:20 AM
12_ fi gure
1
2
3
4
5
6
7
8
fi gure
100 mm
50 mm
2005 mm
or
1855 mm
or
1671 mm
or
1475 mm
A
A
A
A
B
9
DA99-03236N(EN)-09.indd 섹션3:12DA99-03236N(EN)-09.indd 섹션3:12 2012.6.5 10:38:22 AM2012.6.5 10:38:22 AM
fi gure _13
10
11
12
13
14
15
16
17
18
19
A
B
A
B
A
A
B
DA99-03236N(EN)-09.indd 섹션3:13DA99-03236N(EN)-09.indd 섹션3:13 2012.6.5 10:38:24 AM2012.6.5 10:38:24 AM
14_ fi gure
20 25
21
22
23
24
26
27
28
29
2 3 4 1 5
DA99-03236N(EN)-09.indd 섹션3:14DA99-03236N(EN)-09.indd 섹션3:14 2012.6.5 10:38:26 AM2012.6.5 10:38:26 AM
fi gure _15
30
31
RL43
RL29
RL39
RL23
2 41 53
DA99-03236N(EN)-09.indd 섹션3:15DA99-03236N(EN)-09.indd 섹션3:15 2012.6.5 10:38:45 AM2012.6.5 10:38:45 AM
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
COUNTRY CALL Web site
AUSTRALIA 1300 362 603 www.samsung.com/au
COLOMBIA 01-8000112112 www.samsung.com.co
EIRE 0818 717 100 www.samsung.com/ie
HONG KONG (852) 3698-4698 www.samsung.com/hk
INDIA 3030 8282, 1-800-3000-8282 www.samsung.com/in
MALAYSIA 1800-88-9999 www.samsung.com/my
NEW ZEALAND 0800 SAMSUNG (726-7864) www.samsung.com/nz
PANAMA 800-7267 www.samsung.com/latin
PHILIPPINES 1800-10-SAMSUNG (726-7864) www.samsung.com/ph
SINGAPORE 1800-SAMSUNG (726-7864) www.samsung.com
SOUTH AFRICA 0860-SAMSUNG (726-7864 ) www.samsung.com
U.K 0845 SAMSUNG (7267864) www.samsung.com
VIETNAM 1 800 588 889 www.samsung.com
Ambient Room Temperature Limits
This refrigerator is designed to operate in ambient temperatures specifi ed by its temperature class
marked on the rating plate.
Class Symbol Ambient Temperature range (°C)
Extended Temperate SN +10 to +32
Temperate N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
Internal temperatures may be affected by such factors as the location of the refrigerator,
ambient temperature and the frequency with which you open the door.
Adjust the temperature as required to compensate for these factors.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and
its electronic accessories (e.g. charger, headset, USB cable) should not be disposed
of with other household waste at the end of their working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please
separate these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government offi ce, for details of where and how they can take
these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
English
Code No. DA99-03236N REV(0.9)
DA99-03236N(EN)-09.indd 섹션3:16DA99-03236N(EN)-09.indd 섹션3:16 2012.6.5 10:38:47 AM2012.6.5 10:38:47 AM
Loading...
