the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
KEY FEATURES OF YOUR NEW REFRIGERATOR
Your Samsung French Door Refrigerator comes equipped with various innovative storage and energy-efficient
features.
Twin Cooling System
The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system,
the Freezer and Refrigerator cool more efficiently.
Additionally, this separate air flow system prevents food odor of one compartment from seeping into
other compartments.
Bigger & Wider Space
The wide shelf area and pantry provide enough space for larger items like a pizza box, etc.
The wide freezer drawer also provides enough space for 2-3 turkeys.
Secure Auto Close
The Secure Auto Close feature will automatically close a door that is slightly open.
Compact Ice Maker
The Ice maker can dispense cubed or crushed ice.
®
Digital Display and Temperature Control
®
Water Filtration System
O
Door Alarm
A helpful beeper alerts you if a door is ajar.
,, Tilting Pocket
The Tilting pocket can be used to store up to a 16" pizza.
,, Auto Pull Out Drawer
The upper drawer in the freezer comes out automatically as you just open the freezer door.
,, Super Extended Drawer
The upper drawer can be pulled out to the Tilting Pocket.
,, Easy Handle
Freezer door can be opened with less effort.
o Energy Star
This Energy star labeled product may save you money on your energy costs.
For easy future reference, write the model and
serial number down which can be found on the left
side of the refrigerator.
Model #
Serial #
2 Features
SAFETY INFORMATION
Before using your new Samsung French Door Refrigerator,please read this manual thoroughly to
ensurethat you know how to safely and efficiently operate the features and functions that your
new appliance offers.
Because the following instruction covers various models, the characteristics of your Refrigerator
may differ slightlyfrom the Refrigeratordescribed inthis manual. If you have any question, contact
us at 1-800-SAMSUNG or find help and information online at www.samsung.com.
What the icons and signs in this user manual mean '
WARNING
A Hazards or unsafe practices that may result in minor personal injury or property
CAUTION damage.
CAUTION refrigerator, follow these basic safety precautions:
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
Keep this manual in a safe place for future reference.
Hazards or unsafe practices that may result in severe personal injury or death.
To reduce the risk of fire, explosion, electric shock, or personal injury when using your
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
SEVEREWARNING SIGNS
Do not plug several appliances into the same power receptacle.
• Large appliancesdraw a lot of power. Powering more than one appliance or machine from a single power source
could cause overheatingand cause afire.
Make sure that the power plug is not kinked or damaged by the back of the Refrigerator.
• A damaged power plug may overheat and cause a fire.
Do not spray water directly into or on the outside of the Refrigerator/Freezer drawer.
• Water could get into the interior machine parts and cause electric shock.
Do not use aerosols near the Refrigerator.
• Aerosols used nearthe Refrigerator may cause an explosion or fire.
Safety Info_rration 3
Do not put undue stress on the power cord or place heavy articles on it.
• Placing heavy articles on the power cord may create the risk of explosion or fire.
Do not insert the power plug with wet hands.
It may cause electric shock.
Do not put a container filled with water on the Refrigerator.
If it spills, it may cause fire or electric shock.
Do not install the Refrigerator in a damp place or water closed places.
Wet and/or deteriorated insulation of the internal electrical parts may cause electric shock or fire.
Do not store volatile or flammable substances in the Refrigerator.
Storing benzene, thinner, alcohol, ether, LP gas and other such products may cause explosions.
Do not disassemble or repair the Refrigerator by yourself.
You may run the risk of fire, appliance malfunctions and/or personal injury. Call your nearest service center
for help from a qualified service technician.
When the interior or exterior LED lamp has gone out, please contact your service agents.
Unplug the Refrigerator before changing the interior light.
Changing the light while the Refrigerator is plugged in may cause electric shock.
If you wish to dispose the Refrigerator, remove the doors and seals before throwing it
away.
The doors(and their seals) can entrap a child if they climb into the Refrigerator.
Make sure that the doors are off, and ensure that no one is suffocated by being locked inside.
The Refrigerator must be safely grounded
@
Always make sure that you have grounded the Refrigerator before attempting to investigate or repair any
part of the appliance. Power leakages can cause severe electric shock.
Never use gas pipes, telephone lines or other potential lightning attractors as an
electrical ground.
Improper use of the grounding plug can result in arisk of electric shock. If it is necessary to use an
extension cord to power the Refrigerator, use only a 3-wire extension cord that has a 3-blade ground plug
and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension
cord should be AC 115V-120V, 10A, or more. Additionally, if a grounding adapter is used, make sure the
receptacle box is also fully grounded.
4 Safe,ty info_rr_tion
CAUTION SIGNS
Use good judgment when filling the Refrigerator with food and drinks.
• In an overfull Refrigerator, heavy, fragile, bulky or breakable items may fall out and cause personal injury
and/or damage to surrounding objects.
Do not put bottles or glass containers in the Freezer drawer.
When the contents freeze and then expand, the glass may break and cause personal injury or leave
dangerous glass shards in the Freezer.
If the electrical wall socket is loose, do not insert the power plug.
There is a risk of electric shock or fire. Have the plug looked at by a licensed electrician.
Never unplug your Refrigerator by pulling on the power cord.
Always grip the power cord firmly and pull straight out from the outlet. Yanking or pulling on the power
cord may cause a short-circuit, fire and/or electric shock.
A damaged power cord must be replaced by the manufacturer, a certified service agent or qualified service
personnel.
Do not store articles on the top of the appliance.
When you open or close the door, the articles may fall and cause personal injury and/or damage to
surrounding objects.
A
CAUTION
®
Do not store pharmaceutical products, scientific materials and temperature-sensitive
products in the refrigerator.
Products that require exact temperature controls should not be stored inthe Refrigerator.
Do not allow children to climb, stand or hang on shelves and handles of the
Refrigerator. They could damage the Refrigerator and seriously injure themselves.
Do not sit on the freezer door. The door may break.
Do not allow children to climb into the freezer basket.
If you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator
immediately and contact your Samsung Electronics Service Center.
After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer
compartment. Particularly when hands are damp or wet, skin may adhere to these
extremely cold surfaces.
Skin may stick to the surface and you may get frostbite.
Do not put your hands under the appliance.
Anysharp edgesmaycausepersonalinjury.
Safety Inforrr_ation5
form t
Never put fingers or other objects into the water dispenser hole or ice chute.
• It may cause personal injury and/or material damage.
@
If the Refrigerator will not be used for a long period of time (for example, over several
months), unplug the power from the wall.
Over time, deterioration in the power cord insulation may cause fire.
[_ Do not use a wet or damp cloth when cleaning the plug.
Remove any dust or foreign matter from the power plug pins.
• A dirty power plug can increase the risk of fire.
If the Refrigerator is disconnected from the power supply, you should wait for at least
five minutes before plugging it back in.
Do not place the refrigerator directly in sunlight.
The appliance must be positioned for easy access to power source.
If the power cord is damaged, it must be replaced by the manufacturer, a certified
service agent or qualified service personnel.
If you have a long vacation planned, empty the Refrigerator and turn it off.
Wipe excess moisture from the inside and leave the doors open to keep odor and mold from developing.
Service Warranty and Modification
Any changes or modifications performed by a 3rd party on this finished appliance is not covered under
Samsung warranty service, nor can Samsung be responsible for safety issues that result from 3rd party
modifications.
Children can get trapped inside Refrigerators.
CAUTION
Before you throw away your old Refrigerator or Freezer,make sure that you;
Take off the doors.
Leave all shelves in places so that children may not easily climb inside and shut the door while they are
inside.
This appliance is not intended for use by small children or infirm persons without capable, adult
supervision. Small children should be supervised when using the appliance.
Do not block air holes
If the air holes are blocked, especially with a plastic bag, the refrigerator can be over cooled.
Ifthis cooling period lasts too long, the water filter may break and cause water leakage.
6 Safe,ty Inforrration
SETTING UP YOUR
FRENCH DOOR REFRIGERATOR
08 Getting ready to install the refrigerator
09 Removing the refrigerator doors
11 Disassemble the freezer drawer
12 Reattaching the refrigerator doors
13 Using the doors
14 Assemble the freezer drawer
15 Adjusting the doors
16 Making minor adjustments between doors
17 Adjusting the freezer drawer level
18 Checking the water dispenser line
19 Installing the water line
OPERATING YOUR SAMSUNG
FRENCH DOOR REFRIGERATOR
_f
TROUBLESHOOTING
ii !!i
21 Using the control panel
22 Using the digital display
24 Using the cold water dispenser
25 Parts and Features
26 Storing Food in the Refrigerator
26 Storing Food in the Freezer Drawer
26 Using the tilting pocket
27 Removing the refrigerator accessories
28 Removing the freezer accessories
29 Cleaning the refrigerator
30 Changing the interior lights
30 Changing the water filter
32 Water Filter Chart
33 Water Filter Certification
34 Food Storage Tips
36 Troubleshooting
/
WARRANTY 37 Warranty
Contents _7
GETTING READY TO INSTALL THE REFRIGERATOR
Congratulations on your purchase of the Samsung French Door Refrigerator. We
hope you enjoy the state-of-art features and efficiencies that this new appliance
offers.
Selecting the best location for the Refrigerator
• A location with easy access to the water supply.
• A location without direct exposure to sunlight.
A location with level (or nearly level) flooring.
A location with enough space for the Refrigerator doors to open easily.
• Allow sufficient space to the right, left, back and top for air circulation. If
the Refrigerator does not have enough space, the internal cooling system
may not work properly.
Please ensure that appliance can be moved freely in the event of maintenance & service.
If your refrigerator has an ice maker, allow extra space at the back for the water line connections. When you
install the refrigerator next to a fixed wall, minimum
clearance is 3 sA" (95mm) between the refrigerator and wall to allow the door to swing open.
First thing! Make sure that you can easily move your Refrigerator to its final location by measuring doorways
(both width and height), thresholds, ceilings, stairways, etc.
The following chart details the exact height and depth of Samsung French Door Refrigerator.
Dimension
(inches/mm)
MODEL
Width (A)
with Hinge (B)
Case Height
without Hinge (C)
with Door (D)
Depth
without Door (E)
RFG295**
35 5/s (912mm)
69 7/8 (1775mm)
68 1/8 (1730mm)
35 7/8 (912mm)
28 7/s) (734mm)
Allow clearance to the right, left, back and top when installing. This will help reduce power consumption
and keep your energy bills lower.
Do not install the Refrigerator where the temperature will go below 50°F (10°C).
When moving your refrigerator
CAUTION
To prevent floor damage be sure the front leveling legs are in
the up position(above the floor).
Refer to 'Leveling the refrigerator' in the manual(at page 15)
FLOORING
Screwdriver(-) Control Lever
For proper installation, this refrigerator must be placed on a level
surface of hard material that is the same height as the rest of the
flooring. This surface should be strong enough to support a fully loaded
refrigerator, or approximately
6601bs(299kg). To protect the finish of the flooring, cut a large section
of the cardboard carton and place under the refrigerator where you are
working. When moving, be sure to pull the unit straight out and push
back in straight.
8 Sett qg Up
SETTING UP THE REFRIGERATOR
Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and functions of
the appliance. By completing the following steps, your Refrigerator should be fully operational.
1. Place the Refrigerator inan appropriate location with reasonable clearance between the wall and the
Refrigerator. Refer to installation instructions in this manual.
2. Once the Refrigerator is plugged in, make sure the interior light comes on when you open the doors.
3. Set the Temperature control to the coldest temperature and wait for an hour. The Freezer will get slightly chilled
and the motor will run smoothly.
4. After powering the Refrigerator, it will take a few hours to reach the appropriate temperature. You can store
food and drinks in the Refrigerator after the temperature is sufficiently cool.
® Check the accessory list below.
Water filter
(DA29-00003G)
Hex wrench Fastener Compression nut
(DA80-00002C) (DA60-00143B) (DA74-00070B)
Compression fitting
(DA62-00305A)
REMOVING THE REFRIGERATOR DOORS
If the Refrigerator is too large to pass through your doorway easily, you can remove the refrigerator doors.
Tools you will need
Philips screwdriver Flat-blade screwdriver Wrench Pliers Allen wrench(3/16")
(Smm)
Disassemble the Refrigerator doors
1. With the door opened, remove the Hinge Cover cap
({_}) with a Flat head screwdriver, and close the
door.
Remove the 3 screws holding down the Hinge
Coverand remove the Hinge Cover (_}).
?
Setting Up 9
.
Disconnect two connectors ({_)
at each side of the top cap and the
one connector ({_}) on left side door.
Remove the tube (_) with pressing the
dark gray color part ((_}) of the water
line coupler.
Z_ If a red clip is on the coupler, it must
....... be removed before removing the tube.
.
Remove the 3 hex head bolts ((_;}) attached
to the upper left and right door hinges with a
wrench(13/32").
With a Philips head screwdriver, remove the ground
screw (_) attached to the upper left and right door
hinges.
Remove the upper left and right door hinges (_).
%
8S
, ( ,
4. Lift the door straight up to remove.
.
With a Philips head screwdriver, remove the screw (_)
attached to the lower left and right door hinges.
With a wrench(3/16"), remove the two hex head bolts (_})
attached to the lower left and right door hinges.
Remove the lower left and right door hinges (@).
10 sett_g up
, o o
DISASSEMBLE THE FREEZER DRAWER
1. Take out the upper drawer by lifting it up.
2. Remove the tilting pocket(l_}) by pulling on both brackets(G )
upward at the same time.
3. Take out the lower basket(_}) by lifting the basket up from
the rail system.
\
\
\
4. Remove four 10mm hex-head bolts from the both sides.
5. Lift the freezer door up from the rails.
settng up 11
REATTACHING THE REFRIGERATOR DOORS
Assemble the Refrigerator doors
,
Reattach the lower left and right door hinges(@).
With a Philips head screwdriver, insert and tighten the
screw (1_) into the lower left and right door hinges.
With a wrench(13/16"), insert and tighten the 2 hex head
bolts ((_) into the lower left and right door hinges.
2. Place the hole in the bottom of the door over the lower
hinge(@).
Be careful not to miss the hinge cap because it can
be easily taken off.
@
.
Insert the upper hinges (_) into the holes at the
top of the doors.
With a wrench(13/32"), insert and tighten the 3 hex
head bolts (_) into the upper left and right door
hinges.
With a philips head screwdriver, insert and tighten
the ground screw (_) into the upper left and right
door hinges.
12 Setting Up
%
REATTACHING THE REFRIGERATOR DOORS
4. Connect the water line ((_) and then insert a clip
on the coupler with pulling tube. Connect the one
connector(@) on left side door and two connectors
(1_) at each side of the top cap.
The clip is enveloped inside of the top cap.
_, Red Clip
Door Tube
Z_ The water line ([_}) must be fully inserted to the marked line to prevent
....... water leakage from the dispenser.
Line
5. Position the Hinge Cover (1_}) in place.
With a philips head screwdriver, insert and tighten the
3 screws into the Hinge Cover. With the door opened,
reinsert the Top Table cap((_) and close the doors.
When reattaching the hinge cover, make sure that the
wires are not pressed or damaged by the top table.
USING THE DOORS
The Refrigerator doors ensure that the doors close all the way and are securely sealed.
When the Refrigerator door is only partially open, it will automatically close. The door will stay open
when opened more than 3 Inches.
Sett qg Up 13
ASSEMBLE THE FREEZER DRAWER
1. Pull out the rails fully on each side of the cabinet.
2. Attach the freezer door front onto the open slots on the sides.
3. Tighten 4 hex head bolts completely with a socket wrench(7/16inch).
4. Insert the lower basket (_) into the rail system.
5. Hook the ends of the tilting pocket (_) onto the support guard
and push down until they lock into place.
6. Insert the upper drawer.
Remove 2 pieces of tape ((_) attached to the side of the drawer bin.
Reattach the tape in the same position when moving the refrigerator to
prevent scratching the drawer bin.
\\
\
14 Settng Up //
ADJUSTING THE DOORS
Now that the doors are back on the Refrigerator, you want to make sure the Refrigerator is level so that you can
make final adjustments. If the Refrigerator is not level, it will not be possible to get the doors perfectly even.
When the Left door is lower than the Right door.
Insert a flat-blade screwdriver into a notch on the left control lever, turn it clockwise or counter-clockwise
to level the left door.
Control Lever
Screwdriver
When the Left door is higher than the Right door.
Insert a flat-blade screwdriver into a notch on the right control lever, turn it clockwise or counter-clockwise
to level the right door.
Control Lever
Screwdriver
We do not recommend making small adjustments with the control lever. Instead, refer to the next page for the
best way to make minor adjustments to the doors.
Settisg Up 15
MAKING MINOR ADJUSTMENTS BETWEEN DOORS
Remember a level Refrigerator is necessary for getting the doors perfectly even. If you need help, review the
previous section on leveling the Refrigerator.
When the left _m
door is lower 8
than the right
door.
m
When the left
door is higher
than the right
door.
part
l E_=_.........................................................................._ Adjustment
Adjustment
part
1. If you open the drawer ([_), you can see the lower hinge (1_).
2. Insert the supplied hex wrench (1_) into the shaft (@) of the lower hinge.
3. Please adjust the height by turning the hex wrench ([_)) clockwise( ) or counter-clockwise( ).
When you turn the hex wrench counter-clockwise( ), the door will move up.
1. After adjusting the doors, please insert the supplied fastener-ring ([_}) using a pair of pliers ([_) in the
gap between the hinge-grommet ((_) and the lower hinge((_). The number of fastener-rings you'll need
to insert depends on the gap.
Two fastener-rinqs are enclosed with the refrigerator.
The thickness ofeach fastener-ring is 0.04 inch.
16 Setting Up
ADJUSTING THE FREEZER DRAWER LEVEL
Adjustment part
1. Locate the height-adjuster (1_) in the freezer drawer.
Unscrew the four Phillips screws (_) slightly to loosen the door.
Freezer Drawer
2. Loosen the controller screw(I]_) with a Phillips
screwdriver.
3. Find the best level to align the door slope.
f
£i
Example) The slope is about 2ram (0.08inch) as shown below.
Slope __________________
Reference @)
plane
- Rotate the Height Adjuster to -2.0 to reduce the door slope.
After adjustment, first tighten screw(_}) and then screw(l_}).
Setti-_g Up 17
CHECKING THE WATER DISPENSER LiNE
A water dispenser is one of the helpful features on your new Samsung Refrigerator. To help promote better
health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or
destroy microorganisms. You may need to purchase a water purifying system to do that.
In order for the ice maker to operate properly, a water pressure of 20-125 psi (pound per square inch) is
required.
Under normal conditions, a 170 cc (5.75 oz.) cup can be filled in 10 seconds.
If the Refrigerator is installed in an area with low water pressure (below 20psi), you can install a booster pump to
compensate for the low pressure.
Make sure the water storage tank inside the Refrigerator is properly filled. To do this, oress the water dispenser
lever until the water runs from the water outlet.
[_ Water line installation kits are available at extra cost from your dealer. We recommend using a water supply kit that
contains copper tubing.
Connecting to the water supply line
1. First, shut off the main water supply line and turn the ice-maker off.
2. Locate the nearest cold water drinking line.
3. After connecting the water supply with water filter, turn on water supply and Flush 3 gallons through filter
before use (flush approximately 6 minutes).
Shut off valve
Cold water line
Pipe damp
Water line installation kit
18 Setting Up
INSTALLING THE WATER LINE
Connecting the water line to the Refrigerator.
There are several items that you need to purchase to complete this connection.
You may find these items sold as a kit at your local hardware store.
• 1/4" compression nut • copper tubing
Refrigerator
• plastic tubing * ferrule
Compression nut ®
l Plas_tictubing ®
(Supplied)
(Not supplied)
Ferrule -- Bulb
Copper tubing or Plastic tubing@ ,_
t
_} Compression fitting
(Not supplied) (Not supplied)
(1/4") (Supplied)
(Supplied)
Compression nut @
(1/4") (Not supplied)
........ Household water line ....
1. Slip the compression nut ® through the supplied plastic tubing ®.
2. Tighten the compression nut ® onto the 1/4" compression fitting.
- If you are using copper tubing, slip the compression nut ® (not included) and ferrule (not included) on
copper tubing (not included) as shown.
- If you are using plastic tubing ®, insert the molded end(Bulb) of the plastic tubing ® into the
compression fitting.
/_, Do not use without the molded end(Bulb) of the plastic tubing ®
CAUTION
3. Tighten the compression nut ® onto the compression fitting. Do not over-tighten the compression nut ®.
4. Turn water on and check for any leakage.
Only connect the water line to a drinkable water source.
Ifyou have to repair or disassemble the water line, cut off 1/4" of the plastic tubing to make sure you get a snug,
leak-free connection.
Installing the water filter.
1. Remove the water filter cover({_)
2. Remove the fixed cap by turning it counter clockwise. Keep
the cap in a safe place for later use if you don't use the filter.
3. Remove the water filter from the box and put a replacement
indicator sticker on the filter as shown. Place the sticker on
the filter that dates six months in the future. For example, if
@ ®
you install the water filter in March, put the "SEP" sticker on
the filter to remind you to replace it in September. That way
you'll know when it is time to replace the filter. Normally, a filter
life is about 6 months.
Sticker
(month indicator
Setti_g Up_ 9
4. Remove the filter cap and insert the filter into the filter
housing.
5. Slowly turn the water filter 90° clockwise to align with the
printing mark on the cover, locking the filter in position.
Make sure to align the water filter label mark with center of
cover filter printing as illustrated. Remember, do not over-
tighten.
i /j
J" Separation
' of red cap,
_You should remove the right side upper glass shelf before installing the water filter.
Removing any residual matter inside the water supply line after
installing the water filter.
1. Turn ON the main water supply & turn OFF the valve to the water supply line.
2. Run water through the dispenser until the water runs clear (approx. 6-7 minutes).
This will clean the water supply system and remove air from the lines.
3. Additional flushing may be required in some households.
4. Open the Refrigerator door and make sure there are no water leaks coming from
the water filter.
Cover filter,
®
Turn until the label
is aligned,
}i;
Be sure to flush the dispenser thoroughly or water may drip from it.
This means that there is still air in the line.
Reverse Osmosis Water Supply
IMPORTANT • The pressure of the water supply coming out of a reverse osmosis system going to the water
inlet valve of the refrigerator needs to be between 35 and 120 psi (241 and 827 kPa).
If a reverse osmosis water filtration system is connected to your cold water supply, the water pressure to the
reverse osmosis system needs to be a minimum of 40 to 60 psi (276 to 414 kPa.)
If the water pressure to the reverse osmosis system is less than 40 to 60 psi (276 to 414 kPa):
,, Check to see whether the sediment filter in the reverse osmosis system is blocked. Replace the filter if
necessary.
,, Allow the storage tank on the reverse osmosis system to refill after heavy usage.
,, If your refrigerator has a water filter, it may further reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter.
If you have questions about your water pressure, call a licensed, qualified plumber.
20 Sett-_g Up
Op r tng r,
Door fq fr or tor
USING THE CONTROL PANEL
For better energy efficiency,press the Energy Saver button. Ifcondensation occurs on the doors,turn the Energy Saver function off.
U
Pressthe Freezer/Hold 3 sec for Power Freeze buttonto set the Freezerto your desiredtemperature.
You can setthe temperature between 8°F and -8°R
Pressand hold the FreezedHold 3 sec for Power Freeze button for 3 seconds, to speed up thetime needed to freeze products
in the Freezer. It canbe helpful ifyou need to quickly freezeeasilyspoiled itemsor ifthe temperature inthe Freezerhaswarmed
dramatically (For example, ifthe door was left open).
Pressthe Alarm buttonto turn off the door openalarm. After removing the old water filter and installinga new one, reset the
Indicator by pressing and holingthe "Alarm" button for 3seconds.
The indicatorwill lightagain inabout 6months to letyou know itis Time to change your water filter.
Pressthe Lightingbutton toturn on the DispenserLEDlamp.
iiiiii PresstheFr, 0e ,o, 3sec,orPowerCoo,buttontosetthefr,dgetoyourdes,redtemperature.
(!5_i _ _ _ fo Youcan set the temperature between34°F and 46°R
i: Refrigerator.Itcan be helpfulifyouneed to quickly cool easily spoiled itemsor if the temperature in the fridge haswarmed dramatically
mm,,
ii Ifyou press and hold the Ice Off button for 3 seconds, the Displayand Dispenserwill be locked.
Pressand hold the Fridge/Hold 3 sec for Power Cool button for 3 seconds, to speed upthe time needed to cool products inthe
(Forexample, ifthe door was leftopen).
Pressthe Ice Off button to turn the ice makingfunction off.
Pressthe IceType button to selectyour desiredicetype. Cubed and crushed ice modes will be alternativelychanged whenever you
press the button. Afterselecting, push the Dispenser Levergentlywith your glass.
This mode cannot be used with the Water modesimultaneously.
Pressthe Waterbutton to dispensewater. There isnoOffmode additionally.Afterselecting, push the DispenserLever gently with your
glass. This button can not be used with the Ice Type buttonsimultaneously.Water modewill be offifyou pressthe IceTypebutton.
Cooling offstops cooling in the freezerand refrigeratorcompartments, but does not shut off electrical power to the refrigerator.Touse
this feature, press Energy Saver Button and Freezer/Hold 3 sec for Power Freeze Button simultaneouslyfor 3 seconds until an
alarm sound is heard. Tocancel this mode, press the same buttons again for 3 seconds. Eventhough power isturned off andthen
back on, itremain in Coolingoff mode.
Operat -_g21
USING THE DIGITAL DISPLAY
"FreezerTemp" indicatesthe current Freezertemperature.
"Fridge Temp" indicatesthe current Refrigerator temperature.
When not in use the Displaywill turn off not in use, this is normal.
f
Ice Type Water
Power Freeze @
This icon will light up when you activate the "Power Freeze" feature. "Power Freeze" is great when you need a lot of ice.
When you have enough ice, just press the button again to cancel the "Power Freeze" mode.
If you select "Power Freeze", the inside temperature of the Freezer will decrease for about two and a half hours.
Cubed ice _, Crushed ice _, Water
Enjoy cubed or crushed ice by selecting your preference from the digital control panel. If you don't
need ice, turn the feature off to save on water and energy consumption. Each Ice type icon will light up
depending on what is currently chosen.
Power Cool _)
This icon will light up when you activate the "Power Cool" button. For a quick fridge cool down, use
"Power Cool".
If you select "Power Cool", the inside temperature of the Fridge will decrease for about two and a half hours.
L.-"9
Filter Indicator o
When the filter indicator light is on, it is time to change the filter. Typically this happens about every 6 months.
The filter Indicator will be Blue when you initially insert the water filter.
The filter Indicator will be Light Pink when you have used your water filter for 5 months.
The filter Indicator will be Red when you have used your water filter for 6 months.
After removing the old water filter and installing a new one (see page 31 for instructions on how to do this),
reset the indicator by pressing and holding the "Alarm/Hold 3 sec for Filter Reset" button for 3 seconds.
Cooling off Mode ("OF & OF" code on the display)
This function is for store display refrigerators. It is not for customer use.
In Cooling Off Mode, the refrigerator works but doesn't make cool air.To cancel this mode, press the Energy Saver and
CAUTIONFreezer buttons at the same time for 3 seconds until a "Ding-dong" sound is heard and the unit will now cool.
22 Operating
Energy saver :D-£
This icon will light up when you activate the "Energy Saver" function. The EnergySaver function is automatically set to
"ON" when power issupplied to the Refrigerator. Ifcondensation occurs on the doors, turn the Energy Saver function off.
Lighting _8_
This icon will light up when you activate the "Lighting" feature. In this case, the dispenser light(under the
display) will be on constantly. If you would like the dispenser light to come on only when using the dispenser,
turn the "Lighting" feature off.
Alarm @)
This icon will light up when you activate the "Alarm" feature. The door alarm will sound if any door is open for
more than 3 minutes. The beeping stops when you close the door. Initially the Alarm is set to on.
ice off
This icon will light up when you activate the "Ice Off" feature. In this case, the ice will not be produced.
Lock _
This icon will light up when you activate the "Lock" feature. Inthis case, you won't be able to use the control panel.
If you press and hold the Ice Off/Hold button for 3 sec to unlock Child Lock, you will be able to use the control
panel again.
USING THE CONTROL PANEL
Basic temperature of Freezer and Refrigerator Compartments
The basic temperature and/or recommended temperature of Freezer and Refrigerator Compartments are -2°F
and 38°F respectively.
If the temperature of Freezer and Refrigerator Compartments are too high or low, adjust the temperature manually.
Controlling the Freezer temperature
The Freezer temperature can be set between 8°F and -8°F to suit your particular needs. Press the Freezer
button repeatedly until the desired temperature is shown in the temperature display. Keep in mind that foods like
ice cream may melt at 4°R The temperature display will move sequentially from -8°F to 8°R When the display
reaches 8°F, the temperature display goes back to -8°R
Five seconds after the new temperature is set, the display will again show the actual current freezer temperature
until the new temperature is reached.
Controlling the Refrigerator temperature
The Refrigerator temperature can be set between 46°F and 34°F to suit your particular needs. Press the Fridge
button repeatedly until the desired temperature is shown in the temperature display.
The temperature control process for the Fridge works just like the Freezer process.
Press the Fridge button to set your desired temperature. After a few seconds, the Fridge will begin adjusting
towards the newly set temperature. This will be reflected in the digital display.
The temperature of the Freezer, Refrigerator or Pantry Room may rise when you open the doors too frequently,
or if a large amount of warm or hot food is placed inside.
This may cause the digital display to blink. Once the Freezer and Refrigerator temperature return to their normal
set temperatures, the blinking will stop.
If the blinking continues, you may need to "reset" the Refrigerator. Try unplugging the appliance, wait for around
10 minutes and then plug the power cord back in.
The temperature of the Pantry Room may be a little different according to the location inside.
If communication between Display and Main Controller errors, Pantry Display light may blink.
Once the communication return to their normal set temperatures, the blinking will stop.
If the blinking continues for a long period of time, please contact to Samsung Electronics Service Center.
Operating 23
USING THE COLD WATER DISPENSER
Press the Ice / Water button to select the type of you want
f
Using the ice Dispenser
Place a glass underneath the ice dispenser and push gently against the dispenser lever with your glass.
Make sure the glass is in line with the dispenser to prevent the ice from bouncing out.
Please wait 2 seconds before removing the glass under the dispenser to prevent spills.
CAUTION
CAUTION
If the Refrigerator door opens, the Dispenser does not work.
o When Cubed Ice is selected after using the Crushed Ice feature, a small amount of
A
residual crushed ice might be produced.
Water Dispenser installation
After installation, press the dispenser arm for at least 2 minutes to remove trapped air
from the water line and to fill the water system.
French
PUSH
zL
CAUTION
/,'x/_ When you dump the ice from the ice bucket, you should press the (-__!il/"'--_ c_ --_-'_
CAUTIONON to get new ice faster after replacing the ice bucket in the refrigerator' __t_
In case ice doesn't come out, pull out the ice bucket and press test button
located on the right side of ice maker.
Do not press the test button continuously when the tray is filled with ice or water
as illustration. Water may overflow or ice jamming may occur.
Normal Use
Tofill ice bucket to maximum capacity after installation, makesure to do the following steps.
1. Allow your refrigerator to operate and cool down for 24 hours (or 1full day).
2. Waiting 24 hours will allow your ice maker to cool properly.
3. Dispense 4 to 6 ice cubes into the glass.
4. After 8 and 16 hours, dispense a full glass of ice at each time.
dispenser lever once with 'ICE CUBED' or 'CRUSHED' function _-
Whenever all ice is used at one time, the above step 3 and4 must be
repeated (before dispense the first 4 to 6 ice cubes, it needs waiting 8 hours).
This will replenish the ice cubes and ensure maximum ice production.
Test button
Check the
water level
Using the water dispenser
Place a glass underneath the water outlet and push gently against the water dispenser lever with your glass.
Make sure the glass is in line with the dispenser to prevent the water from splashing out.
If you have just installed the refrigerator or installed a new water filter, Flush 3 gallons through filter before use (flush
approximately 6 minutes). Make sure that water flows clearly again before drinking.
CAUTIONmay have a funny smell or taste. If this occurs, we recommend that you discard the first 1-2 glasses for better
When you do not use the water dispenser for 2-3 days (especially during the summer), the dispensed water
tasting water.
Using the ice off Function
When selecting the Ice Off mode, remove all ice cubes from the bucket. If you are not
using the ice dispenser, the ice cubes may clump together. Pull the lock lever
forward to throw away ice cubes or remove clumped ice from the bucket.
Push the bucket back until you hear a click.
24 Operati qg
PARTSAND FEATURES
Use this page to become more familiar with the parts and features of the Refrigerator.
Ice-Maker
SU FrenchI}
Light
DairyCompartment I?]
Water Filter
Extension-Shelf El
Vertical Hinged
Section m
Dell Drawer
@Vegetable &
Fruit Drawers
Door Bins _i
H/h Light
l_)Tilting Pocket Auto PullOut Drawer @
Freezer DrawerBin _}
@When closing the door, make sure the Vertical Hinged Section is in the correct position to avoid scratching
the other door.
Ifthe Vertical Hinged Section is reversed, put it back to the right position and close the door.
Moisture may occur at times on the Vertical Hinged Section.
The door handle may become loose over time.
Ifthis happens, tighten the bolts found on the inside of the door.
If you close one door with a lot of force, the other door may open.
Ope_ating 25
r nch
STORING FOOD IN THE REFRIGERATOR
Can be used to store small dairy items like butter or margarine,
yogurt or cream cheese bricks
Designed to handle large, bulky items such as gallons of milk or
other large bottles and containers.
Designed to be crack-resistant, the shelves can be used to store all types
of food and drinks. Circular marks on the glass surface are a normal
phenomenon and can usually be wiped clean with a damp cloth.
Used to preserve the freshness of your stored vegetables and fruits. This
drawer has been specifically designed to control the level of humidity within
the compartment. Keep vegetables and fruits separate when possible.
_Do not place any large articles of food under the lamp in the Refrigerator. An air sensor is located near the
lamp and if the sensor is blocked, your Refrigerator may become too cold. Please place Vegetable and Fruits in
the Vegetable and Fruits drawers to avoid freezing them. If the food in your Refrigerator becomes
frozen, please set the temperature higher.
STORING FOOD IN THE FREEZER DRAWER
Best use to store meats or dry foods. Stored food should be placed in a
container or wrapped securely using foil or other suitable wrapping materials.
Can be used for small packages of frozen food.
You can store a 16" pizza.
Can be used to store meat and dry foods. Stored food should be
placed in a container or wrapped securely using foil or other suitable
wrapping materials.
_ Bottles should bestored tightlytogether so that they do not tip andfall out whenthe Refrigeratordooris opened.
lf you plan to go away for a long time, empty the Refrigerator and turn it off. Wipe the excess moisture from the
inside of the appliance and leave the doors open. This helps keep odor and mold from developing.
USING THE TILTING POCKET
The Tilting Pocket can be used to store up to a 16" pizza if you place it as shown
in the illustration.
26 Operating
REMOVING THE REFRIGERATORACCESSORIES
1. Door Bins & Dairy Compartment
To remove - Simply lift the bin up and pull straight out.
To relocate - Slide it in above the desired location and push down
until it stops.
/k
Injury may occur if the door bins are not firmly assembled.
CAUTION
Do not allow children to play with bins. Sharp corners of the bins
may cause injury.
®
Do not adjust a bin full of foods.
Dust removal method -Remove the guard and wash in the water which flows.
Dispenser Bin Compartment - First fix the right side 0, then engage the left side O in the Molded
supports and push down until it stop. The bin will lock in place.
2. Tempered Glass Shelves
To remove -
To relocate -
The Tempered Glass shelves are heavy.
CAUTIONUse special care when removing them.
Tilt up the front of the shelf in the direction shown
((_) and lift it up vertically (_).
Pull the shelf out.
Tilt the front of the shelf up and guide the shelf
hooks into the slots at a desired height.
Then lower the front of the shelf so that the
hooks can drop into the slots.
3. Vegetable & Fruit Drawers
To remove - Pull the drawer out to full extension.
Tilt up the front of the drawer and pull straight out.
To relocate - Insert the drawer into the frame rails and push back into
place.
The drawers need to be removed before the glass shelf above them
CAUTIONcan be lifted out.
Do not open the drawers while the pantry is open.
It may cause a scratch or breakage tothe drawer covers.
@
[
4. Deli Drawer
To remove - Pull the Dell Drawer out to the stop position
Lift the Dell Drawer up and past the stop.
Operating 27
REMOVING THE FREEZERACCESSORIES
1. Tilting Pocket
To remove - Pull the brackets((_) upward until you hear a
clicking sound and remove the pocket
To replace - Hook the ends of the pocket into both brackets
({_}) and push down until it locks into place.
2. Auto Pull out Drawer
To remove - Pull the drawer out to full extension.
Tilt up rear of drawer and lift straight out.
To relocate - Place the drawer onto the rails by tilting it up.
Lower the drawer into place until it is horizontal
and slide the drawer in.
O French
\
//_ Please do not lose the side knobs during disassembly
WARNINGas they may present a choking hazard to children.
3. Freezer Drawer
To remove the freezer drawer - Pull the freezer drawer out fully.
Tilt up the rear of the bin and lift it
out to remove.
To relocate the freezer drawer - Place the bin into the rail
assembly.
To remove the divider - Pull the divider straight up.
To relocate the divider - Hook the top corners of divider(i_)over
a hole in the bin ({_).
Do not allow babies or children go inside the freezer drawer.
CAUTION
WARNINGto replace the divider. It is for the safety of babes or children.
They could damage the refrigerator and seriously injure
themselves. Do not sit on the freezer door. The door may
break. Do not allow children to climb into the freezer drawer.
If you remove the divider to clean the freezer drawer, be sure
\
28 Operati qg
CAUTION
,, Children can become trapped inside and suffocate.
CLEANING THE REFRIGERATOR
Caring for your Samsung French Door Refrigerator prolongs the life of your appliance and helps
keep the refrigerator free of odor and germs.
Cleaning the interior
Clean the inside walls and accessories with a mild detergent and then
wipe dry with a soft cloth. You can remove the drawers and shelves for a
more thorough cleaning. Just make sure to dry drawers and shelves before
putting them back into place.
Cleaning the Exterior
Wipe the control panel and digital display with a damp, clean, soft cloth. Do
not spray water directly on the surface of the refrigerator.
The doors, handles and cabinet surfaces should be cleaned with a mild
detergent and then wiped dry with a soft cloth. To keep your appliance
looking its best, polish the exterior once or twice a year.
CAUTION
CAUTION
CAUTIONdirectly to the area where the letters are printed.
Cleaning the ice / Water Dispenser
Push down one end of the tray dispenser and remove it. Wipe the Ice / Water
Dispenser with a clean and soft cloth.
CAUTIONchips may start to collect in the ice chute. In order to prevent that residual ice
Do not spray water directly or not use a wet or damp cloth.
Do not use benzene, thinner, or CIorox for cleaning. They may damage the
surface of the appliance and may cause a fire.
Printed letters on the display be erased if the stainless cleaner is applied
When using the crushed ice selection from the dispenser some residual ice
from melting and running out of the chute you should clean out the residual ice
when you see it start to collect in the ice chute.
may
Cleaning the Rubber door seals
If the rubber door seals are dirty, the doors may not close properly, and
the refrigerator will not operate efficiently. Keep the door seals free of dust
or stain by cleaning the doors with a mild detergent and damp cloth. Wipe
dry with a clean, soft cloth.
Do not clean the with
CAUTIONdue to risk of fire.
refrigerator benzene, thinner, or car detergent
Cleaning the rear side of the refrigerator
To keep cords and exposed parts free of dust and dirt accumulation.
Vacuum the rear side of the appliance once or twice a year.
CAUTION shock.
Do not remove the back cover(l_). You could suffer an electric
Ope_ating 29
REPLACING THE INTERIOR LIGHT
For LED lamp, please contact service engineer to replace it.
CHANGING THE WATER FILTER
To reduce risk of water damage to your property DO NOT use generic brands of water filters in your
WARNING
The "Filter Indicator" light lets you know when it is time to change your water filter cartridge. To give
you preparation time to get a new filter, the red light will come on just before the capacity of the current
filter runs out. Changing the filter on time provides you with the freshest, cleanest water from your
fridge.
SAMSUNG Refrigerator. USE ONLY SAMSUNG BRAND WATER FILTERS.
SAMSUNG will not be legally responsible for any damage, including, but not limited to property damage
caused by water leakage from use of a generic water filter. SAMSUNG Refrigerators are designed to work
ONLY WITH SAMSUNG WATER Filter.
O French
1. Take a new water filter and put a month indicator sticker on the filter as shown.
The date on the sticker must be six months from the current date. For example, if you are
replacing the water filter in March, put the "SEP" (September) sticker on the filter to remind you
to replace in September. Normal filter life is about every 6 months.
2. Remove the new filter's protective cap and remove the old filter.
3. Position and insert the new filter into the filter housing.
Slowly turn the water filter clockwise to align with the printing mark on the cover, locking the filter
in position. Make sure to align the water filter label mark with the center of cover filter printing as
illustrated. Remember, do not over-tighten.
Cover filter
@ ®
Sticker_ { Turn until the
...... labels are aligned.
(month
indicator)
30 Operati_g
f
4. Once you have completed this process, press and hold the Ice / Water button for 3 seconds to reset
the filter schedule.
IceType Water
5. Lastly, Flush 3 gallons through filter before use (flush approximately 6 minutes) Make sure that water
flows clearly again before drinking.
[_Be sure to flush the dispenser thoroughly otherwise water may drip from the dispenser.
This means that there is still air in the line.
Do NOT use the water or ice dispenser without a water filter cartridge because the water line may
become blocked.
U
Ordering replacement Water Filter
For replacement waster filter you can visit your local service center or contact the Samsung Parts distributor.
Be sure the replacement water filter has the SAMSUNG logo on the box and the water filter.
Link: http://www.samsungparts.com
Operating 31
r nch Door
WATER FILTER CHART
Performance Data Sheet For Samsung Model DA97=06317A
Using Replacement Cartridge DA29-00003G
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed
below. The concentration of the indicated substances in water entering the system was reduced to a concentration less
than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42 and 53.
System tested and certified by NSF International against NSF/ANSI Standard 42 for
the reduction of Chlorine Taste and Odor, Particulate Class I, and against NSF/ANSI
Standard 53 for the reduction of Cysts, Turbidity, Lead, Asbestos, Benzene, Carbofuran,
p-Dichlorobenzene and Mercury.
To a capacity of 300 gallons (1,136 liters).
Note that while the testing was
Contaminant
Reduction
Chlorinetaste
and odor
Particulate
ClassIParticlesize: pt/mL particles/mL 98.4 171,833pts/mL NA > 85% J-00029739
<0.5to< 1um
Cysts* 127,500cysts/L cysts/L
Turbidity 10.5 11+1NTU 98.6 0.15 NTU 0.5 NTU > 0.5 NTU J-00033223
Lead@pH6.5 153 ug/L 0.15+10% 99.3 <lug/L 0.010 mg/L 10ug/L J-00039590
Lead@pH8.5 155 ug/L 0.15+10% >99.4 <lug/L 0.010 mg/L 10ug/L J-00039591
Mercury@pH6.5 5.97 ug/L 0.006+10% 96.6 <0.2 ug/L 0.002 mg/L 2 ug/L J-00039589
Mercury@pH8.5 6.29 ug/L 0.006+10% 88.9 0.7 ug/L 0.002 mg/L 2 ug/L J-00039586
Asbestos 140MFL > 99 <0.17 MFL NA 99% J-00029743
Benzene 13.88ug/L 0.015+10% 96.4 <0.5 ug/L 0.005 mg/L < 5ug/L J-0029751
Average
Influent
Concentration
2.1 mg/L 2.0 mg/L + 10% 97.6 0.05 mg/L NA > 50% J-00029741
10,566,666 At least 10,000
)erformed under standard laboratory conditions, actual performance may vary.
NSF Specified
Influent
Challenge
Concentration
Units apply
to each row
Minimum50,000 99.99 <1cyst/L NA > 99.95% J-00031000
107 to 108fibers
>um in length
Average
%
Reduction
Average
Product
Water
Concentration
Max.
Permissible
Product
Water
Concentration
NSF
Reduction
Requirements
NSF
Test
Carbofuran 79.6 ug/L 0.190 mg/L 98.7 1 ug/L 0.001 mg/L <40 ug/L J-00029750
p-Dichlorobenzene237.5ug/L 0.225+10% 99.8 0.525 ug/L 0.075 mg/L < 75 ug/L J-00029749
* Based on the use of Cryptosporidium parvurn oocysts
32 Ope_ating
WATER FILTER CERTIFICATION
Department of Public Health
Water Treatment Device
Trademark/Model Designation
Samsung DA61-00159A-B
Samsung DA97-06317A
Manufacturer: Cuno Incorporated
O French
State of California
Certificate Number
04 - 1660
Date Issued: July 7, 2004
Date Revised: June 2, 2008
The water treatment devic_ listed On this certificate have met the testing require_nts pursuant to Section
116830 of the Health and Safety Code for the following health related contaminan[s! ,
Microbiological Contaminants and
Cysts
Turbidity
Organic Contamihants
Rated Service Capacity: 300 gal Rated Service Flow: 0.5 gpm
Conditions of Certification:
Do not use where water is microbiologically unsafe or with water of unknown quality, except that systems certified for
cyst reduction may be used on disinfected waters that may contain filterable cysts.
Operating _33
FOOD STORAGE TIPS
Foods Refrigerator Freezer I Storage Tips
DAIRY PRODUCTS ...................................
Butter
Milk
Cream Cheese,
cheese food, and
cheese spread
HardCheese(unopened)
Hard Cheese(opened)
Cottage Cheese
Cream
Sour Cream
Cream Dips (opened)
Yogurt
Frozen Yogurt
2-3 Weeks
1-2 Weeks
2-4 Weeks
3-4 Months
2 Months
10-15 Days
7-10 Days
2 Weeks
1 week
10-14 Days
na
6-9 Months
Not recommended
Not recommended
6 Months
Not recommended
Not recommended
2 Months
Not recommended
Not recommended
Not recommended
2 Months
r nch Door
Wrap or cover tightly.
Check date code. Most milk and similar
products are sold in date-coded cartons that
indicate a product's peak freshness. Re-seal
with cap or wrap tightly. Do not return unused
portions to original container.
Check date code. Keep all cheese tightly
packed in moisture proof wrap.
Check date code. Most yogurt, creams, and
similar products are sold in date-coded car-
tons that indicate a product's peak freshness.
Re-seal or cover tightly. Do not return unused
portions to original container.
Check date code. Keep covered.
Eggs (uncooked) 3-4 Weeks Not recommended Check date code. Store eggs in coldest part
of refrigerator and in their original container.
Eggs (cooked) 1 week Not recommended Store in covered container.
Leftover egg dishes 3-4 Days Not recommended Store in covered container.
FRESH FRUITS
Apples
Bananas
Peaches, Melons,
Pears,Avocados
Berries and Cherries
Apricots
Grapes
Pineapple (un-cut)
Pineapple (cut)
Citrus
Juice
Frozen Juice Thawing only 12 Months Check date code. Do not re-freeze.
34 Ope_ating
I Month Not recommended
2-4 Days Not recommended
3-5 Days Not recommended
2-3 Days
3-5 Days
3-5 Days
2-3 Days
5-7 Days
1-2 Weeks
6 Days
12 Months
Not recommended
na
Not recommended
6-12 Months
Not recommended
Not recommended
If storing in refrigerator, do not wash fruit be-
fore storing. Store in moisture resistant bags
or containers. Wrap cut fruits. Some fruits
darken when refrigerated.
Store uncovered.
Checkdatecodeandre-sealin originalcontainer.Don
notreturnunusedportionsto originalcontainer.
SU FrenchD
FOOD STORAGE TIPS
Foods Refrigerator Freezer Storage Tips
FISHAND SHELl_FISH ................................................................................. .........................
Fish
Fatty Fish (mackerel,
trout,salmon)
Lean Fish (cod,
flounder, etc)
Frozen or Breaded
Shellfish
Shrimp (uncooked)
Crab
Cooked Fish or
Shellfish
1-2 Days
1-2 Days
na
1-2 Days
3-5 Days
2-3 Days
2-3 Months
6 Months
3 Months
12 Months
10 Months
3 Months
Keep in original wrapper and store in coldest
part of refrigerator. Package in vapor-proof
and moisture proof wrap for freezer. Freeze
at 0°R Thaw in refrigerator or under cold run-
ning water.
Check date code. Freeze in original packag-
ing.
To freeze package invapor-proof and mois-
ture-proof container.
Fresh, Uncooked
Chops
Ground
Roast
Bacon
Sausage
Steak
Poultry
Lunch meat
Cooked
Meat
Poultry
Ham
2-4 Days
1 day
2-4 Days
1-2 weeks
1-2 Days
2-4 Days
1 day
3-5 Days
2-3 Days
2-3 Days
1-2 weeks
6-12 Months
3-4 months
6-12 Months
1-2 Months
1-2 Months
6-9 Months
12 Months
1 month
2-3 Months
4-5 months
1-2 Months
Check date code for use. Store in coldest part
of refrigerator in original packaging. Add more
packaging in moisture-proof and vapor-proof
container for freezing. Recommended refrig-
erator temperature 33°F to 36°F and freezer
temperature 0°F to 2°R
Check date code for use. Store in coldest part
of refrigerator in original packaging. Package
in moistureproof and vapor-proof container for
freezing.
Sources,
American MeatInstitute Foundation.1994.Yellowpages:answersto predictablequestionsconsumersaskabout meatand poultry.
American MeatInstitute
FoodMarketingInstitute. 1999.The food keeper.Food MarketingInstitute,Washington,D.C.
Freeland-Graves,J.H.and G.C. Peckham. 1996. Foundationsof food preparation,6th ed. Prentice-Hall,Inc.Englewood Cliffs,NJ.
Hillers,V.N.1993. Storingfoods at home. WashingtonState UniversityCooperativeExtension,Pullman,WA. Publ.EB 1205.
NationalRestaurantAssociation.2001. Be cool-chillout! Refrigeratepromptly.NationalRestaurantAssociationEducation
FoundationlAsInternationalFoodSafetyCouncil, Washington,D.C.
USDA.1997.Basics for handlingfood safely.U.S. DepartmentofAgriculture,FoodSafety and InspectionService,Washington,D.C.
Opera.ring 35
oLAb , hoot ncj
• Check that the power plug is properly connected.
Is the temperature control on the display panel set to the correct temperature?
Try setting it to a lower temperature.
Is the Refrigerator in direct sunlight or located near a heat source?
Is the back of the Refrigerator too close to the wall and therefore keeping airfrom
circulating?
Is the temperature control on the display set to the correct temperature?
Try setting it to a warmer temperature.
Is the temperature in the room too low?
Did you store the food with high water content inthe coldest part of the
Refrigerator? Try moving those items into the body of the Refrigerator instead of
keeping them in the Cool Select PantryTM.
Check that the Refrigerator is leveland stable.
Is the back of the Refrigerator too close to the wall and therefore keeping airfrom
circulating?
Was anything dropped behind or under the Refrigerator?
A "ticking" sound is heard from inside the Refrigerator. It is normal and occurs
because various accessories are contracting or expanding according to the
temperature of the Refrigerator interior.
Some heat is normal as anti-condensators are installedin the vertical hinged section
of the Refrigerator to prevent condensation.
Is the Refrigerator door ajar? Condensation can occur when you leavethe door open
for a long time.
Did you wait for 12 hours after installation of the water supply line before making ice?
Is the water line connected and the shut-off valve opened?
Did you manually stop the ice making function?
Is the Freezertemperature too warm? Trysetting the Freezertemperature lower.
This is normal. The bubbling comes from the Refrigerator coolant liquid circulating
through the Refrigerator.
Check for spoiled food.
Foods with strong odors(for example, fish) should be tightly covered.
Clean out your Freezer periodically and throw away anyspoiled or suspicious food.
Is the airvent blocked? Remove any obstructions so air can circulate freely.
Allow sufficient space between the foods stored for efficient air circulation.
Is the Freezerdrawer closed properly?
Is the water line connected and the shut-off valve opened?
Has the water supply line tubing been crushed or kinked?
Make sure the tubing isfree and clear of any obstruction.
Is the water tank frozen because the Refrigerator temperature is too low?
Try selecting awarmer setting on the main display panel.
36 _oubleshooting
\
SAMSUNG REFRIGERATOR
LIMITED WARRANTY TO ORIGINAL PURCHASER
This Samsung brand product, as supplied and distributed by Samsung ElectronicsAmerica, Inc. (Samsung) and delivered new, in
the original carton to the originalconsumer purchaser, iswarranted by Samsung against manufacturing defects in materialsand
workmanship for a limited warranty period of:
One (1) Year Parts and Labor on Refrigerator
Five (5) Years Parts and Labor on Sealed Refrigeration System Only*
(*Compressor, evaporator, condenser, drier, connecting tubing)
This limitedwarranty begins on the original date of purchase, and isvalid only on products purchased and used in the United
States. To receivewarranty service,the purchaser must contact Samsung for problem determination and service procedures.
Warranty service can only be performed by a Samsung authorized service center.The originaldated bill of sale must be presented
upon request as proof of purchase to Samsung or Samsung authorized service center.
Samsung will repairor replace any part found to be defective, at our option and at no charge as stipulated herein,with new or
reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of
Samsung and must be returned to Samsung. Replacement parts and products assume the remainingoriginal warranty, or ninety
(90)days, whichever is longer.
In-home servicewill be provided during the warranty labor period subject to availability within the contiguous United States. In-
home service is not availablein allareas. Toreceive in-home service, the product must be unobstructed and accessible from floor
levelto service personnel. If during in-home service repair cannot be completed, it may be necessary to remove, repair and return
the product. If in-home service is unavailable,Samsung may elect, at our option, to providefor transportation of our choice to and
from a Samsung authorized service center.Otherwise, transportation to and from the Samsung authorized service center isthe
responsibility of the purchaser.
This limitedwarranty covers manufacturing defects in materialsand workmanship encountered in normal, noncommercial use
of this product, and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery
and installation;applications and uses for which this product was not intended; altered product or serial numbers; cosmetic
damage or exteriorfinish; accidents, abuse, neglect, fire,water, lightning or other acts of nature; use of products, equipment,
systems, utilities,services, parts, supplies, accessories, applications, installations, repairs, externalplumbing and leaks, external
wiring, circuit breakers, fuses or connectors not supplied and authorized by Samsung, or which damage this product or result in
service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating
instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; loss of
food due to spoilage; consumable items includingfilters and light.
THEREARE NO EXPRESSWARRANTIESOTHERTHAN THOSE LISTEDAND DESCRIBEDABOVE,AND NO WARRANTIES
WHETHER EXPRESSOR IMPLIED, INCLUDING,BUT NOT LIMITEDTO, ANY IMPLIEDWARRANTIESOF MERCHANTABILITY
OR FITNESSFORA PARTICULARPURPOSE,SHALL APPLYAFTERTHE EXPRESSWARRANTY PERIODSSTATED
ABOVE, AND NO OTHER EXPRESSWARRANTY OR GUARANTYGIVENBY ANY PERSON, FIRMOR CORPORATIONWITH
RESPECTTO THIS PRODUCTSHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FORLOSS OF
REVENUEOR PROFITS,FAILURETO REALIZESAVINGSOR OTHER BENEFITS,OR ANY OTHER SPECIAL, INCIDENTALOR
CONSEQUENTIAL DAMAGESCAUSED BY THE USE, MISUSEOR INABILITYTO USETHIS PRODUCT,REGARDLESSOF
THE LEGALTHEORY ON WHICH THE CLAIM ISBASED, AND EVEN IFSAMSUNG HAS BEENADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. NOR SHALL RECOVERYOF ANY KINDAGAINST SAMSUNG BE GREATERIN AMOUNT THAN THE
PURCHASE PRICEOFTHE PRODUCTSOLD BY SAMSUNG AND CAUSINGTHE ALLEGED DAMAGE. WITHOUTLIMITING
THE FOREGOING,PURCHASERASSUMES ALL RISKAND LIABILITYFORLOSS, DAMAGEOR INJURYTO PURCHASER
AND PURCHASER'S PROPERTYAND TO OTHERS AND THEIR PROPERTYARISING OUT OFTHE USE,MISUSE OR
INABILITYTO USETHIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLYBY THE NEGLIGENCEOF SAMSUNG. THIS
LIMITEDWARRANTY SHALL NOT EXTENDTO ANYONE OTHERTHAN THE ORIGINAL PURCHASEROFTHIS PRODUCT,IS
NONTRANSFERABLEAND STATESYOUR EXCLUSIVEREMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidentalor
consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights,
and you may also haveother rights, which varyfrom state to state.
To obtain warranty service, please contact Samsung at:
SAMSUNG CUSTOMER CARE CENTER
Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660
1-800-SAMSUNG (1-800-726-7864) and www.samsung.com
QUESTIONS OR COMMENTS?
COUNTRY I CALL OR VISIT US ONLINE AT WRITE
U.S www.samsung.com
CANADA (800-726-7864) www.samsung.com/ca Service, 55 Standish Court Mississauga, Ontario
800-SAMSUNG Samsung Electronics America, Inc. 85 Challenger
(800-726-7864) Road Ridgefield Park, NJ 07660
800-SAMSUNG Samsung Electronics Canada Inc. Customer
L5R 4B2 Canada
in an effort to promote recycling this user manual is printed on recycled paper,
Loading...
