Samsung RF220NCTASG User Manual

imagine the possibilities

RF22**

English

Refrigerator

user manual

Thank you for purchasing this Samsung product.

DA68-02657A-12.indb 1 2018. 10. 8. 오후 5:45

safety information

SAFETY INFORMATION

• Before using your new Samsung Refrigerator,
please read this manual thoroughly to ensure
that you know how to operate the features and
functions that your new appliance oers safely
and eciently.

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with
the appliance.

• Because the following instructions cover
various models, the characteristics of your
refrigerator may dier slightly from the
refrigerator described in this manual.

• If you have any question, contact us at
1-800-SAMSUNG or find help and information
online at www.samsung.com.

• R-600a or R-134a is used as a refrigerant.
Check the compressor label on the rear of
the appliance or the rating label inside the
fridge to see which refrigerant is used for your
refrigerator. If this product contains flammable
gas (Refrigerant R-600a), contact your local
authority in regard to safe disposal of this
product.

• It is hazardous for anyone other than an
Authorized Service Person to service this
appliance.

Warning :
Risk of fire
/ flammable
materials

Important safety symbols and
precautions:

Hazards or unsafe practices that may result in

WARNING

severe personal injury or death.
Hazards or unsafe practices that may result in

CAUTION

minor personal injury or property damage.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions carefully.

Unplug the power plug from the wall socket.
Make sure the refrigerator is grounded

to prevent electric shock.
Call the contact center for help.

Note.

These warning signs are here to prevent
injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe
place for future reference.

STATE OF CALIFORNIA

WARNING

PROPOSITION 65
WARNING

• Cancer and Reproductive Harm - www.
P65Warnings.ca.gov.

SEVERE WARNING SIGNS

WARNING

FOR INSTALLATION

• Do not install the refrigerator in a damp
place or place where it may come in

- Deteriorated insulation of electrical parts may

• Do not place this refrigerator in direct sunlight

• Do not plug several appliances into the same

- This provides the best performance and

contact with water.

cause an electric shock or fire.

or expose to the heat from stoves, room
heaters or other appliance.

multiple power strip. The refrigerator should
always be plugged into its own individual
electrical outlet which has a voltage rating that
matches the voltage listed on the refrigerator’s
rating plate.

also prevents overloading house wiring
circuits, which could cause a fire hazard from
overheated wires.

02_ Safety information

DA68-02657A-12.indb 2 2018. 10. 8. 오후 5:45

• If the wall socket is loose, do not insert the
power plug.

- There is a risk of electric shock of fire.

• Do not use a cord that shows cracks or
abrasion damage along its length or at either
end.

• Do not bend the power cord excessively or
place heavy articles on it.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal
object, place a heavy object on the power
cord, insert the power cord between objects,
or push the power cord into the space behind
the appliance.

- When moving the refrigerator, be careful not to
roll over or damage the power cord

- This may result in an electric shock or fire.

• Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull
straight out from the outlet.

- Damage to the cord may cause a short-circuit,
fire and/or electric shock.

• Do not use aerosols near the refrigerator.

- Aerosols used near the refrigerator may cause
an explosion or fire.

• Do not install this appliance near a heater,
inflammable material.

• Do not install this appliance in a humid, oily or
dusty location, in a location exposed to direct
sunlight and water (rain drops).

• Do not install this appliance in a location where
gas may leak.

- This may result in an electric shock or fire.

• This appliance must be properly grounded.
Do not ground the appliance to a gas pipe,
plastic water pipe, or telephone line.

- You must ground the refrigerator to prevent
any power leakages or electric shocks caused
by current leakage from the refrigerator.

- This may result in an electric shock, fire,
explosion, or problems with the product.

- Never plug the power cord into a socket that
is not grounded correctly and make sure that it
is in accordance with local and national codes.
This appliance should be positioned in such a
way that it is accessible to the power plug.

- Failing to do so may result in an electric shock
or fire due to electric leakage.

• This refrigerator must be properly
installed and located in accordance
with the manual before it is used.

• Connect the power plug in the proper position
with the cord hanging down.

- If you connect the power plug upside down,
the wire can get cut o and cause a fire or
electric shock.

• When moving the refrigerator, be careful not to
roll over or damage the power cord.

- This constitutes a fire hazard.

• Make sure that the power plug is not
squashed or damaged by the back of the
refrigerator.

• Keep the packing materials out of reach of
children.

- There is a risk of death from suocation if a child
puts the packing materials on his or her head.

• The appliance must be positioned so that the
plug is accessible after installation.

• You need to remove all the protective plastic
film before you initially plug the product in.

• When disposing of this or other refrigerator/s,
remove the door/door seals, door latch so that
children or animals cannot become trapped
inside. Children should be supervised to
ensure that they do not enter and play with the
appliance.

- If trapped inside, the child may become injury
and suocate to death.

• The refrigerator must be safely
grounded.

- Always make sure that you have grounded the
refrigerator before attempting to investigate
or repair any part of the appliance. Power
leakages can cause severe electric shock.

• Never use gas pipes, telephone lines or other
potential lightning attractors as an electrical
ground.

- Improper use of the grounding plug can result
in a risk of electric shock. If it is necessary
to use an extension cord, use only a 3-wire
extension cord that has a 3-blade grounding
plug and a 3-slot receptacle that will accept
the plug on the appliance. The marked rating
of the extension cord should be AC115-120
V, 10 A, or more. If a grounding adapter is
used, make sure the receptacle box is fully
grounded.

• If the products is equipped with the LED
Lamp, do not disassemble Lamp Cover and
LED Lamp by yourself.

- Please contact your service agent.

• Use only the LED Lamps provided by
manufacturer or service agent.

• If the power cord is damaged,
have it replaced immediately by the

Safety information _03

DA68-02657A-12.indb 3 2018. 10. 8. 오후 5:45

• The wall socket must be easily accessible so

• It must be outside the area of the rear of the

• When positioning the appliance, ensure the

• Do not locate multiple portable socket-outlets

• Do not store explosive substances such as

CAUTION

manufacturer or its service agent.

that the appliance can be quickly disconnected
from the wall socket in an emergency.

appliance.

power cord is not trapped or damaged.

or portable power supplies at the rear of the
appliance.

aerosol cans with a flammable propellant in
this appliance.

INSTALLATION
CAUTIONS

• Allow sucient space to install the

- If your refrigerator is not level, the internal

• Keep the ventilation space in the appliance

• Allow the appliance to stand for 2 hours after

• We recommend you have installed this

- Failing to do so may result in an electric shock,

• “WARNING - Improper use of the grounding

• If it is necessary to use an extension cord, use

• Plug the power plug into the wall socket firmly.

- This may result in an electric shock or fire.

• Do not plug several appliances into the same

- This provides the best performance and

refrigerator on a flat surface.

cooling system may not work correctly.

enclosure or mounting structure clear of
obstruction.

installation.

refrigerator by a qualified technician or service
company.

fire, explosion, problems with the product, or
injury.

plug can result in a risk of an electric shock.

only a 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will
accept the plug on the appliance. The marked
rating of the extension cord should be AC115­120 V, 10 A, or more. If a grounding adapter
is used, make sure the receptacle box is fully
grounded.

Do not use a damaged power plug, damaged
power cord or loose wall socket.

multiple power board. The refrigerator should
always be plugged into its own individual
electrical outlet which has a voltage rating that
matched the rating plate.

also prevents overloading house wiring
circuits, which could cause a fire hazard from

overheated wires.

• Connect the power plug in proper position with
the cord hanging down.

- If you connect the power plug upside down,
wire can get cut o and cause fire or electric
shock.

• Do not pull or excessively bend the power
cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal
object, place a heavy object on the power
cord, insert the power cord between objects,
or push the power cord into the space behind
the appliance.

- When moving the refrigerator, be careful not to
roll over or damage the power cord

- This may result in an electric shock or fire.

• Do not install this appliance near a heater,
inflammable material.

• Do not install this appliance in a humid, oily or
dusty location, in a location exposed to direct
sunlight and water (rain drops).

• Do not install this appliance in a location where
gas may leak.

- This may result in an electric shock or fire.

• Do not attempt to repair, disassemble, or
modify the appliance yourself.

- Do not use any fuse(such as cooper, steel
wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is
required, contact your nearest service center.

- Failing to do so may result in an electric shock,
fire, problems with the product, or injury.

• If any dust or water is in Refrigerator, pull
out power plug and contact your Samsung
Electronics service center.

- Otherwise there is a risk of fire.

- If gas leak is detected, avoid any naked flames
or potential sources of ignition and air the
room in which the appliance is standing for
several minutes.

CRITICAL USAGE

WARNING

WARNINGS

• Do not insert the power plug with wet

• Do not store articles on the top of the

- When you open or close the door, the articles

• Do not put a container filled with water on the

- If spilled, there is a risk of fire or electric shock.

hands.

appliance.

may fall and cause personal injury and/or
material damage.

refrigerator.

04_ Safety information

DA68-02657A-12.indb 4 2018. 10. 8. 오후 5:45

• Children should be supervised to ensure that
they do not play with the appliance.

- Keep fingers out of “pinch point” areas;
clearances between the doors and cabinet are
necessarily small. Be careful when you open
the doors when children are in the area.

• Do not let children hang on the door. A serious
injury may occur.

• There is a Risk of children entrapment. Do not
let children enter inside the refrigerator.

• Never put fingers or other objects into the
dispenser hole, ice chute and ice maker
bucket.

- It may cause a personal injury or material
damage.

• Do not use or place any substances sensitive
to temperature such as inflammable sprays,
inflammable objects, dry ice, medicine, or
chemicals near or inside of the refrigerator.

• Do not keep volatile or inflammable objects or
substances (benzene, thinner, propane gas,
alcohol, ether, LP gas and other such products
etc.) in the refrigerator.

- This refrigerator is for storing food only.

- This may result in fire or explosion.

• Do not store pharmaceuticals products,
scientific materials or temperature-sensitive
products in the refrigerator.

• Products that require strict temperature
controls must not be stored in the refrigerator

• Do not place or use electrical appliance inside
the refrigerator/freezer, unless they are of a
type recommended by the manufacturer.

• If you smell pharmaceutical or smoke, pull
out power plug immediately and contact your
Samsung Electronics service center

• Do not let children go inside the refrigerator.
Children could become trapped.

• Do not insert your hands into the bottom area
under the appliance.

- Any sharp edges may cause personal injury.

• Do not let children step on a drawer’s cover.

- The drawer may break and cause them to slip.

• Do not overfill the refrigerator with food.

- When you open the door, an item may fall out
and cause personal injury or material damage.

• Do not touch the inside walls of the freezer or
products stored in the freezer with wet hands.

- This may cause frostbite.

• Never put fingers or other objects into the
water dispenser hole, ice chute, or ice maker
bucket.

- It may cause personal injury or material
damage.

• Do not spray flammable gas near the
refrigerator.

- There is a risk of explosion or fire.

• Do not store volatile or flammable substances
in the refrigerator.

- The storage of benzene, thinner, alcohol, ether,
LP gas and other such products may cause
explosions.

• Do not store pharmaceuticals products,
scientific materials, or temperature sensitive
products in the refrigerator.

- Products that require strict temperature
controls must not be stored in the refrigerator.

• Do not place or use an electrical appliance
inside the refrigerator, unless it is of a type
recommended by the manufacturer.

• Do not stand on top of the appliance or place
objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance. This may result
in an electric shock, fire, problems with the
product, or injury. Do not put a container filled
with water on the appliance.

- If spilled, there is a risk of fire or electric shock.

• Do not use mechanical devices or any other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.

• Do not damage the refrigerant circuit.

• Do not spray volatile material such as
insecticide onto the surface of the appliance.

- As well as being harmful to humans, it may
also result in an electric shock, fire or problems
with the product.

• Never stare directly at the UV LED lamp for
long periods of time.

- This may result in eye strain due to the
ultraviolet rays.

• Keep ventilation opening in the appliance
enclosure or mounting structure clear of
obstruction.

• The installation or any service of this appliance
is recommended by a qualified technician or
service company.

- Failing to do so may result in an electric shock,
fire, explosion, problems with the product, or
injury.

• Do not touch the power plug with wet hands.

- This may result in an electric shock.

• Do not disassemble or repair the
refrigerator by yourself.

- You run risk of causing a fire, malfunction and/
or personal injury.

Safety information _05

DA68-02657A-12.indb 5 2018. 10. 8. 오후 5:45

- When the interior or exterior LED lamp has
gone out, please contact your service agents.

• Children should be supervised to
ensure that they do not play with the
appliance.

- Keep fingers out of “pinch point” areas :
clearances between the doors and cabinet are
necessarily small. Be careful when you open
the doors when children are in the area. Do not
let children hang on the door. If not, a serious
injury may occur. Risk of children entrapment.
Do not let children enter inside the refrigerator.

• Bottles should be stored tightly together so
that they do not fall out.

• This product is intended only for the storage of
food in a domestic environment.

• If a gas leak is detected, avoid any naked
flames or potential sources of ignition and air
the room in which the appliance is standing for
several minutes.

- Do not touch the appliance or power cord.

- Do not use a ventilating fan.

- A spark may result in explosion or fire.

• Use only the LED Lamps provided by
manufacturer or service agents.

• If there are burning smells or smoke,
pull out power plug immediately and
contact your Samsung Electronics
service center.

• If you experience diculty when changing the
light, contact a service agent.

• If the product is equipped with LED Lamps,
do not disassemble the Lamp Cover and LED
Lamp by yourself.

- Please contact your service agents.

• If any dust or water is in refrigerator, pull out
the power plug and contact your Samsung
Electronics service center.

- Otherwise there is a risk of fire.

a) Allow the appliance to stand for 2 hours after

installation.

b) To get Best performance from the product,

1) Do not place foods too closely in front of
the vents at the rear of the appliance as it
can obstruct free air circulation in the freezer
compartment.

2) Wrap the food up properly or place it in
airtight containers before putting it into the
fridge or freezer.

3) Do not put any newly introduced food for
freezing near to already existing food.

c) Do not place glass or bottles or carbonated

beverages into the freezer.

- The container may freeze and break, and this
may result in injury.

d) Please observe maximum storage times and

expiry dates of frozen goods.

e) There is no need to disconnect the refrigerator

from the power supply if you will be away for
less than three weeks. But, Remove all the food
if you are going away for the three weeks or
more. Unplug the refrigerator and clean it, rinse
and dry.

USAGE CAUTIONS

CAUTION

• Do not re-freeze frozen foods that
have thawed completely. Do not place
carbonated or fizzy drinks in the freezer
compartment. Do not put bottles or
glass containers in the freezer.

- When the contents freeze, the glass may break
and cause personal injury.

• Use only the ice maker provided with
the refrigerator. The water supply to this
refrigerator must only be installed/connected
by a suitably qualified person and connected
to a potable water supply only. In order to
operate the ice maker properly, water pressure
of 20 ~ 125 psi is required. If you have a long
vacation or business trip and won’t use water
or ice dispensers, close the water valve.

- Otherwise, water leakage may occur.

• Wipe excess moisture from the inside and
leave the doors open.

- Otherwise, odor and mold may develop.

• Take out the right box in the refrigerator after
removing the guard(LMF-RL22*)

• Do not apply strong shock or excessiv e force
on to the surface glass.

- Broken glass may result in a personal injury
and property damage.

• Service warranty and Modification.
Any changes or modifications
performed by a 3rd party on this
finished appliance are not covered
under Samsung warranty service,
nor can Samsung be responsible for
safety issues that result from 3rd party
modifications.

• Do not block air holes.

- If the air holes are blocked, especially with
a plastic bag, the refrigerator can be over
cooled. If this cooling period lasts too long,
the water filter may break and cause water
leakage.

06_ Safety information

DA68-02657A-12.indb 6 2018. 10. 8. 오후 5:45

• If the refrigerator is disconnected from the
power supply, you should wait for at least five
minutes before plugging it back in.

• If you have a long vacation planned or the
refrigerator is not to be used for a long period
of time, you must empty the refrigerator and
pull out the power plug.

- Letting the refrigerator run for a long time
without using it can cause the insulation to
deteriorate and may cause a fire.

- Wipe excess moisture from the inside and
leave the doors open. Otherwise, odor and
mold may develop.

• To get the best performance from the product:

- Do not place foods too close to the vents at
the rear of the appliance as it can obstruct free
air circulation in the refrigerator compartment.

- Wrap food up properly or place it in airtight
containers before putting it into the refrigerator.

• Fill the water tank, ice tray, and water cubes
only with potable water.

• If the product is flooded, make sure to
contact your nearest service center.

- There is a risk of electric shock or fire.

• Do not keep vegetable oil in your refrigerator’s
door bins. The oil can solidify, making it foul­tasting and dicult to use. In addition, the
open container can leak and the leaked oil can
cause the door bin to crack. After opening an
oil container, it is best to keep the container in
a cool and shaded place such as a cupboard
or pantry.

- Examples of vegetable oil: olive oil, corn oil,
grape-seed oil, etc.

CLEANING CAUTIONS

CAUTION

• Do not directly spray water on the
inside or outside the refrigerator.

- There is a risk of fire or electric shock.

• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in
the refrigerator to remove bad odors.

- This may result in an electric shock or fire.

• Remove any foreign matter or dust
from the power plug pins. Do not use
a wet or damp cloth when cleaning
the plug.

- Otherwise, there is a risk of fire or electric
shock.

• Unplug the refrigerator before cleaning
or making repairs.

• Remove all foreign substances such as dust
or water from the power plug terminals and
contact points using a dry cloth on a regular
basis.

- Unplug the power plug and clean it with a dry
cloth.

- Failing to do so may result in an electric shock
or fire.

• Before cleaning or performing maintenance,
unplug the appliance from the wall socket.

- Failing to do so may result in an electric shock
or fire.

• Do not clean the appliance by spraying water
directly onto it.

• Do not use benzene, thinner or alcohol to
clean the appliance.

- This may result in discoloration, deformation,
damage, electric shock or fire.

• Do not spray inflammable gas near the
refrigerator.

• There is a risk of explosion or fire.

• Install the appliance in a cool, dry room with
adequate ventilation.

• Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat
(radiator, for example).

• Never block any vents or grilles on the
appliance. Allow warm food to cool down
before placing it in the appliance.

• Put frozen food in the refrigerator to thaw.
You can then use the low temperatures of the
frozen products to cool food in the refrigerator.

• Do not keep the door of the appliance open
for too long when putting food in or taking
food out.

• The shorter time for which the door is open,
the less ice will form in the freezer.

• Allow clearance to the right, left, back and top
when installing.

• This will help reduce power consumption and
keep your energy bills lower.

• In the event of a power failure, call the local
oce of your Electricity Company and ask how
long it is going to last.

- Most power failures that are corrected in an
hour or two will not aect your refrigerator
temperatures. However, you should minimize
the number of door openings while the power
is o.

- But Should the power failure last more than
24hours, remove all frozen food.

• If the key is provided with refrigerator, the keys

Safety information _07

DA68-02657A-12.indb 7 2018. 10. 8. 오후 5:45

should be kept out of the reach of children and
not be in the vicinity of the appliance.

• The appliance might not operate consistently
(possibility of defrosting of co tents or
temperature becoming too warm in the frozen
food compartment) when sited for an extended
period of time below the cold end of the range
of temperatures for which the refrigerating
appliance is designed.

• Do not store food which goes bad easily at low
temperature, such as bananas, melons.

• Your appliance is frost free, which means there
is no need to manually defrost your appliance,
as this will be carried out automatically.

• Temperature rise during defrosting can comply
with ISO requirements. But If you want to
prevent an undue rise in the temperature of
the frozen food while defrosting the appliance,
please wrap the frozen food up in several
layers of newspaper.

• Any increase in temperature of frozen food
during defrosting can shorten its storage life.

• Do not re-freeze frozen foods that have thawed
completely.

• Install the appliance in a cool, dry room with
adequate ventilation.

• Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat
(radiator, for example).

• Never block any vents or grilles on the
appliance. Allow warm food to cool down
before placing it in the appliance.

• Put frozen food in the refrigerator to thaw.
You can then use the low temperatures of the
frozen products to cool food in the refrigerator.

• Do not keep the door of the appliance open
for too long when putting food in or taking
food out.

• The shorter time for which the door is open,
the less ice will form in the freezer.

• Allow clearance to the right, left, back and top
when installing.

• This will help reduce power consumption and
keep your energy bills lower.

• To get the best energy eciency of this
product, please leave all selves, drawers and
baskets on their original position like as above
illustration.

• Use only the ice maker provided with the
refrigerator.

• The water supply to this refrigerator must only
be installed/connected by a suitably qualified
person and connected to a potable water

supply only.

• In order to operate the ice maker properly,
water pressure of 0.1 ~ 0.7 MPa is required.

• If you have a long vacation or business trip and
won’t use water or ice dispensers, close the
water valve.

- Otherwise, water leakage may occur.

• Wipe excess moisture from the inside and
leave the doors open.

- Otherwise, odor and mold may develop.

• Never stare directly at the UV LED lamp for
long periods of time.

- This may result in eye strain due to the
ultraviolet rays.

• Do not allow babies or children go inside the
drawer.

- It can cause death from suocation by
entrapment or a personal injury.

• Do not sit on the Freezer door.

- The door may be broken and cause a personal
injury.

• To prevent children entrapment, you must
reinstall the divider using provided screw after
cleaning or other actions if you removed the
divider from the drawer.

• When you use this function the energy
consumption of the refrigerator will increase.

• Remember to turn it o when you don’t
need it and return the freezer to your original
temperature setting.

power freezing

• If you need to freeze large amount of food
stu, activate Power Freeze function at least
24 hours before.

• Use a clean sponge or soft cloth and a
mild detergent in warm water to clean the
refrigerator.

• Do not use abrasive or harsh cleansers
such as window sprays, scouring cleansers,
flammable fluids, muriatic acid, cleaning
waxes, concentrated detergents, bleaches, or
cleansers containing petroleum products on
exterior surfaces (doors and cabinet), plastic
parts, door and interior liners, and gaskets.

- These can scratch or damage the material.

• Do not use abrasive or harsh cleansers
such as window sprays, scouring cleansers,
flammable fluids, muriatic acid, cleaning
waxes, concentrated detergents, bleaches, or
cleansers containing petroleum products on

08_ Safety information

DA68-02657A-12.indb 8 2018. 10. 8. 오후 5:45

exterior surfaces (doors and cabinet), plastic
parts, door and interior liners, and gaskets.

• Do not clean glass shelves or covers with
warm water when they are cold. Glass shelves
and covers may break if exposed to sudden
temperature changes or impacts such as
bumping or dropping.

• Cyclopentane is used in the insulation.
The gases in the insulation material require
a special disposal procedure. Please
contact your local authorities in regard to the
environmentally safe disposal of this product.
Ensure that none of the pipes on the back of
the refrigerator are damaged prior to disposal.

CRITICAL DISPOSAL

WARNING

WARNINGS

• Risk of child entrapment. Before you
throw away your old refrigerator or

- Take o the doors.

- Leave the shelves in place so that children may

• Please dispose of the packaging material for

• Ensure that none of the pipes on the back of

• R600a or R134a is used as a refrigerant.

freezer:

not easily climb inside.

this product in an environmentally friendly
manner.

the appliance are damaged prior to disposal.

Check the compressor label on the rear of
the appliance or the rating label inside the
fridge to see which refrigerant is used for
your refrigerator. When this product contains
flammable gas(Refrigerant R600a) contact your
local authority in regard to safe disposal of this
product.
door/door seals and door latch so that
small children or animals cannot become
trapped inside. Children should be supervised
to ensure that they do not play with the
appliance.

Be careful that your fingers are not

CAUTION

caught in.

THIS APPLIANCE IS INTENDED
TO BE USED IN HOUSEHOLD
AND SIMILAR APPLICATIONS
SUCH AS

• sta kitchen areas in shops, oces and other
working environments;

• farm houses and by clients in hotels, motels
and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications.

contents

SETTING UP YOUR FRENCH DOOR REFRIGERATOR ………………………………… 10
OPERATING YOUR FRENCH DOOR REFRIGERATOR ………………………………… 19
TROUBLESHOOTING ………………………………………………………………………… 28
APPENDIX [HOW TO ASSEMBLY THE HANDLES] ……………………………………… 31

Safety information _09

DA68-02657A-12.indb 9 2018. 10. 8. 오후 5:45

Setting up your French Door
Refrigerator

GETTING READY TO INSTALL
THE REFRIGERATOR

Congratulations on your purchase of this Samsung
French Door Refrigerator.
We hope you enjoy the state-of-art features and
eciencies that this new appliance oers.

Selecting the best location for the
refrigerator

• A location with easy access to a water supply.

• A location without direct exposure to sunlight.

• A location with a level floor.

• A location with enough space for the
refrigerator doors to open easily.

• A location that allows sucient space to the
right, left, back and top for air circulation.

• A location that allows you to move the
refrigerator easily if it needs maintenance or
service.

• Do not install the refrigerator where the
temperature will go below 50 ºF (10 ºC).

• Do not locate the refrigerator where it may
become wet.

If your refrigerator has an ice maker, allow extra
space at the back for the water line connections.

When moving your refrigerator

To prevent floor damage, be sure the

CAUTION

front adjusting legs are in the up position
(above the floor). Refer to ‘Adjusting the
Level’ in the manual (on page 15).

B

B

A

A

E

E

C

C

D

D

Model RF220**/ RF221**

Depth “A” 34 3/4” (884 mm)

Width “B” 29 3/4” (758 mm)

Height “C” 65 1/4” (1655 mm)

Overall Height “D” 66 3/4” (1695 mm)

Depth “E” 37 1/4” (944 mm)

2”

(50 mm)

140° 140°

48 5/8”

(1234 mm)

13 3/8”

(340 mm)

29 3/4”

(758 mm)

1 5/8”

(40 mm)

3 3/4”

(95 mm)

46 1/8”

(1171 mm)

Flat-blade
screw driver(-)

Control Lever

30 7/8”

(784 mm)

First thing! Make sure that you can easily move
your refrigerator to its final location by measuring
doorways (both width and height), thresholds,
ceilings, stairways, etc.

• The measurements here are based on
the design dimension, which may dier
depending on the measuring method.

10_ setting up

DA68-02657A-12.indb 10 2018. 10. 8. 오후 5:45

FLOORING

For proper installation, you must place this
refrigerator on a level, hard surface that is the
same height as the rest of the floor. This surface
should be strong enough to support a fully loaded
refrigerator, or approximately 286.6 lbs (130 kg).
To protect the finish of the flooring, cut a large
section of the cardboard carton and place it under
the refrigerator where you are working. When
moving the refrigerator, you need to pull and push
it straight forwards or back. Do not wiggle it from
side to side.

REMOVING THE REFRIGERATOR
DOORS

Before removing the door/drawer, make sure you
read the following items:

WARNING

• Be careful not to get injured while removing the

• Reattach the door/drawer properly to avoid:

- Moisture from air leakage.

- Uneven door alignment.

- Wasting energy due to improper door seal.

Disassembling the fridge door

Disconnect power to the refrigerator
before removing the door or drawer.

• Be careful not to drop, damage or
scratch the door/drawer while removing
them.

door/drawer.

01 SETTING UP

ACCESSORIES AND REQUIRED
TOOLS

The following accessories are included with your
refrigerator:

Compression Fitting Compression Nut

Required Tools (Not provided)

You need the following tools to complete the
installation of your refrigerator:

Philips

screwdriver(+)

Flat-blade screw

driver(-)

Allen wrench

(3/16”) (5mm)

Socket wrench

(10mm)

WARNING

1. Remove the 3 screws holding down the top

2. Disconnect electric wire on the top of the

Be careful not to drop and scratch the
doors while removing the doors.

table and remove it.

Top Table

refrigerator.

setting up _11

DA68-02657A-12.indb 11 2018. 10. 8. 오후 5:46

3. Remove the 3 hex bolts that hold the hinge

on the top of the refrigerator with the 10 mm
socket wrench.

Socket wrench

4. Remove the screw that holds the ground wire

with a philips screwdriver(+).

ground wire

5. Separate the hinge from the electric wire and

ground wire as shown above.

7. Separate the cap on the middle hinge.

8. Remove the screw attached to the left

and right middle hinges with a philips
screwdriver(+). Remove the 2 hex head bolts
attached to the left and right middle hinges
with an allen wrench(3/16”).

Middle Hinge

Allen wrench

Disassembling the freezer door

1. After opening the Freezer door, lift the drawer

6. Lift the door straight up to remove.

Be careful not to drop and scratch the doors
while removing them.

12_ setting up

DA68-02657A-12.indb 12 2018. 10. 8. 오후 5:46

2. Remove 4 hex head bolt from both sides with

a socket wrench(10 mm)

3. Remove 4 hex head bolts from both sides with

a socket wrench(10 mm).

Reassembling the fridge door

1. Insert and tighten the screw into the left

and right middle hinges with a philips
screwdriver(+).

4. Place the hole in the bottom of the left door

over the middle hinge.

01 SETTING UP

5. Position the top table in place. Insert and

tighten the 3 screws into the top table with a
philips screwdriver(+).

Top Table

6. Insert the left upper hinge shaft into the hole

the corner of the fridge door.

2. Insert and tighten the 2 hex head bolts into

the left and right middle hinges with an allen
wrench(3/16”).

3. Replace the middle hinge cap.

7. Insert the upper hinges into the holes at the

top of the door. Insert and tighten the 3 hex
head bolts into the left and right upper hinges
with a socket wrench.

setting up _13

DA68-02657A-12.indb 13 2018. 10. 8. 오후 5:46

8. Insert and tighten the ground screw into

the left and right upper hinges with a philips
screwdriver(+).

ground wire

3. With the 10mm wrench, reattach 4 bolts to

connect the rail with the door.

9. Connect the electronic wire on the top of the

refrigerator.

Reassembling the freezer door

1. Pull out the rails to the full length on each sidle

of the cabinet evenly.

2. Hang the freezer door front onto open slot on

the sides.

4. With the drawer pulled out fully, insert the

drawer box into the rail system.

Be careful not to scratch or dent the

CAUTION

sliding rail by letting it strike the floor.

Make sure that you mount the freezer

CAUTION

basket in the right position when
removing / installing the freezer door.
Failing to do so may result in the door not
opening or closing properly.

Slot

14_ setting up

DA68-02657A-12.indb 14 2018. 10. 8. 오후 5:46

ADJUSTING THE LEVEL

Make sure the refrigerator is level so that you can
make final adjustments. Use a level to test if the
refrigerator is level both side to side and back to
front. If the refrigerator is not level, it will not be
possible to get the doors perfectly even, which
may cause moisture condensation and increased
energy bills. Below is an example of how to level
the refrigerator if the left side of the refrigerator is
lower than the right side.

How to adjust the level

1. Open the freezer drawer and remove the lower

basket.

2. Insert a flat-blade screwdriver (-) into the

notch on the left control lever, and then turn
it counter-clockwise to level the refrigerator.
(You turn the lever clockwise to lower the
refrigerator and counterclockwise to raise it.)

flat-blade
screwdriver (-)

Both control levers must be touching the

CAUTION

floor to avoid possible personal injury or
property damage because of tipping.

Control Lever

MAKING MINOR ADJUSTMENTS
BETWEEN DOORS

Remember, a leveled refrigerator is necessary
for getting the doors perfectly even. If you need
help, review the previous section on leveling the
refrigerator.

Fixed part

• The left door is fixed. To make minor
adjustments between doors, adjust only
the right door.

1. Pull out the freezer drawer ( 1 ), then you can
see the lower hinge ( 2 ).

2. Insert a philips screwdriver (+) ( 3 ) into the
shaft ( 4 ) of the lower hinge.

3. Adjust the height by turning a philips
screwdriver (+) ( 3 ) clockwise (
counterclockwise ( UP ).

2

Adjustment
part

DOWN

) or

02 SETTING UP

• If the right side is lower, perform the
same procedure, but with the right
control lever.

1

4

3

3

• It is dicult to remove the cover leg
front from the refrigerator, so we do not
recommend making small adjustments
with the control lever. Instead, refer to
the next page for the best way to make
minor adjustments to the doors.

• When you turn a philips screwdriver (+)
counterclockwise ( UP ), the door will
move up.

setting up _15

DA68-02657A-12.indb 15 2018. 10. 8. 오후 5:46

INSTALLATION OF THE WATER
LINE

Before You Install the water line

• The water line installation is not warranted by
the refrigerator manufacturer.
So before you install the water line, read the
whole steps for installing and follow these
instructions carefully to minimize the risk of
expensive water damage.

• Banging pipes (water banging in the pipes) in
house plumbing can cause damage to fridge
parts and lead to water leakage or flooding.
Call a qualified plumber to correct the problem
before installing the water supply line to the
fridge.

• To prevent burns and product damage, do not
hook up the water line to the hot water line.

• Do not install the water line in areas where
temperatures fall below freezing.

• When using any electrical device (such as
a power drill) during installation, be sure the
device is insulated or wired in a manner to
prevent electric shock.

• All installations must be in a accordance with
local plumbing code requirements.

• Water line Kit and water filter are not
covered by Samsung’s Warranty.
The manufacturer (or dealer, installer)
of them is responsible for any defects
and all the loss caused by water filter &
water line kit.

• The filter should be replaced according to
manufacturer (or dealer)’s instruction.

• To order additional water filters, please contact
the manufacturer (or dealer) of the filter.

Using the water filter (not provided)

Connecting to water supply line

• Shut o the main water supply line and turn
the Ice maker to the o position.

• Locate the nearest cold drinking water line.

• Follow the instructions in the water filter
installation kit.

• After connecting the water supply line to the
Cartridge Holder inlet and installing the Filter
Cartridge (insert plastic line in fully).

• Turn on water supply and Flush 3 gallons
through filter before use (fl ush approximately
6 minutes)

1. Cold Water line

2. Pipe Clamp.

3. Plastic line

4. Compression Nut

5. Compression Sleeve

6. Packing Nut

7. Shut O Valve

8. Filter Cartridge

9. Cartridge Holder

90 degree

• The water filter must be installed outside
the refrigerator.
It is not provided with your new
refrigerator. The filter cartridge (8) and
holder (9) kit can be purchased from
the retailer where you purchased this
refrigerator.

• Do not use copper line.

• Cut the tubing, making sure the ends are
square and clean

Incorrect

Correct

There are several items that you need to purchase
to complete this connection.
You may find these items sold as a kit at your local
hardware store.

Use Copper Tubing Use Plastic Tubing

• ¼” copper tubing

• ¼” compression nut (1pc)

• Ferrule (2pc)

• ¼” plastic tubing
 Molded end(Bulb)

• ¼” compression nut (1pc)

Connect the water line to the fridge

• Connect the plastic line on the back of your
fridge to the cartridge holder outlet (fully insert
the plastic line to the cartridge holder outlet).

• Insert plastic clip to the cartridge holder inlet
and outlet.

• Turn water on and check for any leakage.

16_ setting up

DA68-02657A-12.indb 16 2018. 10. 8. 오후 5:46

Cartridge
Holder

Clip

Connect the water line to the fridge

1. Slip the compression nut through the plastic

tubing.

2. After inserting the compression nut into plastic

tubing, tighten the compression nut onto 1/4”
compression fitting (Purchased).

Filter
cartridge

Plastic line
(Purchased)

• You can purchase the necessary filter
cartridge at the retailer where you
purchased this refrigerator.

• Water line must be connected to drinkable
water only.

• When pushing the Refrigerator back, make
sure you don’t roll over the power cord or
water line(Icemaker supply line).

• Use the new hose-sets supplied with the
appliance only. Do not re-use an old hose set.

Keep ventilation openings, in the

WARNING

appliance enclosure or in the built-in
structure, clear of obstruction. Connect
to potable water supply only.

To use without the water filter

Connecting to the water supply line

• Shut o the main water supply line and turn the
Ice maker to the o position.

• Locate the nearest cold water drinking line.

1. Cold Water line

2. Pipe Clamp.

3. Plastic line

4. Compression Nut

5. Compression Sleeve

6. Packing Nut.

7. Shut O Valve

Household water line

Copper tubing or Plastic tubing

(Not supplied)

Ferrule

(Purchased)

Plastic Tubing

(Purchased)

Refrigerator

(Not supplied)

* Accesory included

Compression
Nut (1/4”)
(Purchased)

Bulb

Compression
fitting *

Compression
Nut (1/4”) *

• Do not overtighten the compression nut.

• Using Copper Tubing

- Slip the compression nut and ferrule on copper
tubing as shown.

• Using Plastic Tubing

- Insert the molded end(Bulb) of the plastic
tubing into the compression fitting.

Do not use without the molded end(Bulb)

CAUTION

of the plastic tubing.

3. Tighten the compression nut onto the
compression fitting.

4. Turn water on and check for any leakage.

• You can purchase the necessary filter
cartridge at the retailer where you
purchased this refrigerator.

• Water line must be connected to drinkable
water only.

• When pushing the Refrigerator back, make
sure you don’t roll over the power cord or
water line (Icemaker supply line).

01 SETTING UP

setting up _17

DA68-02657A-12.indb 17 2018. 10. 8. 오후 5:46

Do not use without the molded end (Bulb)

CAUTION

of the plastic tubing ( B ).

1. Tighten the compression nut ( B ) onto the

compression fitting.
Do not over-tighten the compression nut ( B ).

2. Turn water on and check for any leakage.

If you find water drops or leakage in the
connection areas, turn o the main water
supply. Check the connections and, if
necessary, tighten.

3. Flush 1 gallon of water through the filter

before drinking or using the water from the
refrigerator. (Flush approximately 6 minutes.)
To flush, press a large glass or cup against the
water dispenser lever. Fill the glass, empty it
into the kitchen sink after it is filled, and then
repeat.

4. After you turn on the refrigerator, let the ice

maker make ice for 1 to 2 days. Over that
period of time, throw out the first 1 or 2
buckets of ice the freezer makes to ensure all
impurities have been removed from the water
line.

• Only connect the water line to a
drinkable water source.

• If you have to repair or disassemble the water
line, cut o 1/4” of the plastic tubing to make
sure you get a snug, leak-free connection.

COMPLETING THE SET UP

Now that you have your new refrigerator installed
in place, you are ready to set up and enjoy the
features and functions of the appliance.
By completing the following steps, your refrigerator
should be fully operational.

1. Make sure your refrigerator is in an appropriate

location with reasonable clearance between it
and the wall. Refer to installation instructions in
this manual.

2. Once the refrigerator is plugged in, make sure

the interior light comes on when you open the
doors.

3. Set the Temperature control to the coldest

temperature and wait for an hour. The freezer
will get slightly chilled and the motor will run
smoothly. Reset the refrigerator and freezer to
the temperatures you want.

4. After you plug the refrigerator in, it will

take a few hours to reach the appropriate
temperature. You can store food and drinks
in the refrigerator after the temperature is
suciently cool.

18_ operating

DA68-02657A-12.indb 18 2018. 10. 8. 오후 5:46

Operating your French Door
Refrigerator

CHECKING THE CONTROL PANEL

[RF221, RF220]





~
G



w
G




{
G


v

1 2 3

[RL225]

4

[RL220]

6

( 1 )
Freezer
(Hold 3 sec for
Power Freeze)

( 2 )
Fridge

( 3 )
Energy Saver

( 4 )
Ice O

( 5 )
Alarm On/O

( 6 )
Power Freeze

Press the Freezer button to set the freezer temperature between colder and coldest.
Press and hold the Freezer button for 3 seconds to activate Power Freezer function which
speeds up the freezing process in the freezer.

Press the Fridge button to set the Fridge temperature between cold and coldest.

For better energy eciency, press the Energy Saver button. If condensation occurs on the
doors, turn the Energy Saver Button function o.

If you don’t want to make more ice, Press the Ice O button. The LED will light up and the
Ice-Maker stops making ice.

Press the Alarm On/O button to turn the door open alarm on and o.

Press this button to activate Power Freezer function which speeds up the freezing process
in the freezer.

02 OPERATING

5

operating _19

DA68-02657A-12.indb 19 2018. 10. 8. 오후 5:46

USING THE CONTROL PANEL

Freezer/Fridge (Temperature
adjustment)

Press the Freezer or Fridge button until the desired
temperature is set. For lower temperature, press
the Freezer or Fridge button until more LED
lights (coldest). For higher temperature, press
the Freezer or Fridge button until less LED lights
(colder).
Each time you press the Freezer or Fridge button,
temperature indicator will change in below order.

Power Freeze

RF221 / RF220 / RL225

This icon will light up when you activate the Power
Freeze function. Power Freeze function generates
cool air for 50 hours continuously and it makes the
inside of the refrigerator cool faster. This function
is useful when you make ice more quickly.
When you have enough, just press and hold
the Freeze (Hold 3 sec for Power Freeze) button
again for 3 seconds to cancel the Power Freeze
function.

Ice O

This LED will light up when you activate the Ice O
function. In this case, the ice will not be produced.

Alarm On/O

If the door alarm is set to On, an alarm beeps if
any refrigerator door is left open for more than
three minutes. The beeping stops when you close
the door. The door alarm function is pre-set to On
in the factory. You can turn it o by touching and
then releasing this button. You can turn it back on
in the same fashion. The LED lights up when the
function is on.

Canceling cooling o mode (Freezer/
Fridge Temperature Indicator moving)

• Cooling o function is for store display,
and it makes the refrigerator not to
generate cool air. (Only for product sold
in U.S)

[RF221, RF220]

RL220

This icon will light up when you activate the Power
Freeze function. Power Freeze function generates
cool air for 50 hours continuously and it makes
the inside of the refrigerator cool faster. When you
have enough, just press the Power Freeze button
again to cancel the Power Freeze function.

• When you use this function the energy
consumption of the refrigerator may
increase. Remember to turn it o when
you do not need it and return the freezer
to your original temperature setting.

Energy Saver

This LED will light up when you activate the Energy
Saver function. The Energy Saver function is
automatically set to “ON” when power is supplied
to the Refrigerator. If condensation occurs on the
doors, turn the Energy Saver function o.

• In some places, water drop may be
generated on the door part. In this case,
it is recommended to turn o the Energy
saver function.

20_ operating

①

[RL225]

①

[RL220]

①

In case of Cooling o Mode, refrigerator

CAUTION

may seem like working but it does not
make cool air. To cancel this mode, press
the “Cooling O Key” at the same time
for 5 seconds until “Ding-dong” sounds.

①

①

①

COOLING OFF KEY

RF221, RF220, RL225 Model :
Ice O + Freezer Key
RL220 Model :
Power Freeze + Freezer Key

DA68-02657A-12.indb 20 2018. 10. 8. 오후 5:46

Reverse Osmosis Water Supply

IMPORTANT :

The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet
valve of the refrigerator needs to be between 35
and 120 psi (241 and 827 kPa).
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 40 to 60 psi (276 to 414 kPa.) If
the water pressure to the reverse osmosis system
is less than 40 to 60 psi (276 to 414 kPa):

• Check to see whether the sediment filter in the
reverse osmosis system is blocked. Replace
the filter if necessary.

• Allow the storage tank on the reverse osmosis
system to refill after heavy usage.

• If your refrigerator has a water filter, it may
further reduce the water pressure when used
in conjunction with a reverse osmosis system.
Remove the water filter.

If you have questions about your water pressure,
call a licensed, qualified plumber.

USING THE COLD WATER
DISPENSER

Using the Water dispenser (RF221**)

Place a glass underneath
the water outlet and push
gently against the water
dispenser lever with your
glass. Make sure the
glass is in line with the
dispenser to prevent the
water from splashing out.

If you have just installed the refrigerator or installed
a new water filter, Flush 11 L through filter before
use (flush approximately 6 minutes). Make sure
water flows cleanly before drinking.

If you have a long vacation or business
trip, close the water valve and shut o

CAUTION

the water supply to the Refrigerator. This
will help prevent accidental leakages.

• Water clouding phenomenon

• All water provided to refrigerators flows
through the core filter which is an
alkaline water filter. In this process, the
pressure in the water that has flowed
out of the filter gets increased, and
oxygen and nitrogen become saturated.
When this water flows out in the air, the
pressure plummets and the oxygen and
nitrogen get supersaturated so that they
turn into gas bubbles. The water could
look misty due to these oxygen bubbles.
The water may look temporarily cloudy
due to these oxygen bubbles. After a
few seconds, the water will look clear.

PUSH

02 OPERATING

• The water tank’s capacity is
approximately 1 L.

• Please wait 1 second before removing
the cup after dispensing water to
prevent spills.

operating _21

DA68-02657A-12.indb 21 2018. 10. 8. 오후 5:46

PARTS AND FEATURES

Use this page to become more familiar with the parts and features of the refrigerator

LAMP

Vertical Hinged

Section

Internal Water

Dispenser (RF221**)

Vegetable &

Fruit Drawers

Light

QUICK-SPACE
GLASS SHELF

Vegetable &

Fruit Drawers

FZ Ice-Maker

(OPTION -RL225*)

Ice Bucket

FZ Ice-Maker

Ice Bucket






~
G


w
G





{
G

v

LAMP

Quick-Space
Glass Shelf (on
some models)

Door Bins

Freezer
Drawer Bin

Freezer Drawer Bin

• When closing the door, make sure the Vertical Hinged Section is in the correct position to
avoid scratching the other door.

• If the Vertical Hinged Section is reversed, put it back to the right position and close the door.

• Moisture may appear at times on the Vertical Hinged Section.

• The door handle may become loose over time. If this happens, tighten the bolts found on the
inside of the door.

• If you close one door with a lot of force, the other door may open.

• When the interior or exterior LED lamp has gone out, please contact your service agents.

22_ operating

DA68-02657A-12.indb 22 2018. 10. 8. 오후 5:46

REMOVING THE REFRIGERATOR
ACCESSORIES

1. Door Bins

• Door Bins
To remove - Simply lift the bin up and pull straight
out.
To relocate - Slide it in above the desires location
and push down until it stops.






~
G



w
G




{
G


v

• Injury may occur if the door bins are not

• Do not allow children to play with bins.

CAUTION

2. Tempered Glass shelves

To remove - Tilt up the front of the shelf in the

direction shown ( 1 ) and lift it up vertically ( 2 ).
Pull the shelf out.
To relocate - Tilt the front of the shelf up and
guide the shelf hooks into the slots at a desired
eight. Then lower the front of the shelf so that the
hooks can drop into the slots.

CAUTION

firmly assembled.

Sharp

corners of the bins may cause injury.

Do not adjust a bin full of food. Remove
the food first.
Dust removal method - Remove the
guard and wash in water.

The Tempered Glass shelves are heavy.
Use special care when removing them.

3. Vegetable & Fruit Drawers

To remove - Pull the drawer out to full extension.

Tilt up the front of the drawer and pull straight out.
To relocate - Insert the drawer into the frame rails
and push back into place.

The drawers need to be removed before

CAUTION

the glass shelf above them can be lifted
out.

4. Pantry (applicable models only)

To remove the Pantry – Pull the pantry out to full

extension. Tilt up the front side of the pantry and
pull straight out.

Using the doors

Ensure that the doors close all the way and are
securely sealed.
When the refrigerator door is only partially open,
it will automatically close. But, the door will stay
open when opened more than the auto close
range and you must close it manually.

REMOVING THE REFRIGERATOR
ACCESSORIES

1.

ICE BUCKET

To remove - Lift the ice bucket ( 1 ).
To relocate - Place the ice bucket into the Super
extended drawer ( 2 ).

02 OPERATING

2

1

2

1

operating _23

DA68-02657A-12.indb 23 2018. 10. 8. 오후 5:46

2. Super Extended Drawer

To remove - Pull the drawer out to full extension.
Tilt up the rear of the drawer and lift straight out.
To relocate - Place the drawer onto the rails ( 4 )
by tilting it up. Lower the drawer into place until it
is horizontal and slide the Drawer ( 3 ) in.

4

3

3. Freezer Drawer

To remove the freezer drawer - Pull the freezer
drawer out fully. Tilt up the rear of the bin and lift it
out to remove.
To relocate the freezer drawer - Place the bin
into the rail assembly.

Do not allow babies or children go inside

CAUTION

the freezer drawer. They could damage
the refrigerator and seriously injure
themselves.
Do not sit on the freezer door. The door
may break. Do not allow children to
climb into the freezer drawer.

CLEANING THE REFRIGERATOR

Caring for your Samsung French Door Refrigerator
prolongs the life of your appliance and helps keep
the refrigerator free of odor and germs.

Cleaning the Interior

Clean the inside walls and accessories with a mild
detergent and then wipe dry with a soft cloth. You
can remove the drawers and shelves for a more
thorough cleaning. Just make sure to dry drawers
and shelves before putting them back into place.

Cleaning the Exterior

Wipe the control panel and digital display with
a damp, clean, soft cloth. Do not spray water
directly on the surface of the refrigerator.
The doors, handles, and cabinet surfaces should
be cleaned with a mild detergent and then wiped
dry with a soft cloth. To keep your appliance
looking its best, polish the exterior once or twice a
year.

Do not remove the divider.

CAUTION

If trapped inside, children may be injured

WARNING

or suocate to death.

Do not spray water directly on the

CAUTION

refrigerator. Use a clean, damp cloth to
clean.

Do not use benzene, thinner, or Clorox

CAUTION

for cleaning. They may damage the
surface of the appliance and may cause
a fire.

You can erase the printed

CAUTION

letters on the display if you
apply stainless cleaner
directly to the area where
the letters are printed.

24_ operating

DA68-02657A-12.indb 24 2018. 10. 8. 오후 5:46

If the rubber door seals are dirty, the doors may
not close properly, and the refrigerator will not
operate eciently. Keep the door seals free of
dust or stains by cleaning the doors with a mild
detergent and damp cloth. Wipe dry with a clean,
soft cloth.

Do not clean the refrigerator with

CAUTION

benzene, thinner, or car detergent due to
risk of fire.

Cleaning the rear side of the refrigerator

To keep cords and exposed parts free of dust and
dirt accumulation.
Vacuum the rear side of the appliance once or
twice a year.

Do not remove the back cover ( 1 ).

CAUTION

You could suer an electric shock.

1

02 OPERATING

operating _25

DA68-02657A-12.indb 25 2018. 10. 8. 오후 5:46

FOOD STORAGE TIPS

Foods Refrigerator Freezer Storage Tips

DAIRY PRODUCTS

Butter 2-3 Weeks 6-9 Months Wrap or cover tightly.

Check date code. Most milk and similar prod-

Milk 1-2 Weeks Not recommended

Cream Cheese, cheese
food, and cheese spread

Hard Cheese (unopened) 3-4 Months 6 Months

Hard Cheese (opened) 2 Months Not recommended

Cottage Cheese 10-15 Days Not recommended

Cream 7-10 Days 2 Months Check date code. Most yogurt, creams, and

Sour Cream 2 Weeks Not recommended

Cream Dips (opened) 1 Week Not recommended

Yogurt 10-14 Days Not recommended

Frozen Yogurt na 2 Months

EGGS

Eggs (uncooked) 3-4 Weeks Not recommended

Eggs (cooked) 1 Week Not recommended Store in covered container

Leftover egg dishes 3-4 Days Not recommended Store in covered container

FRESH FRUITS

Apples 1 Month Not recommended

Bananas 2-4 Days Not recommended

Peaches, Melons, Pears,
Avocados

Berries and Cherries 2-3 Days 12 Months

Apricots 3-5 Days Not recommended

Grapes 2-5 Days na

Pineapple (un-cut) 2-3 Days Not recommended

Pineapple (cut) 5-7 Days 6-12 Months

Citrus 1-2 Weeks Not recommended Store uncovered.

Juice 6 Days Not recommended

Frozen Juice Thawing only 12 Months Check date code. Do not re-freeze.

2-4 Weeks Not recommended

3-5 Days Not recommended

ucts are sold in date-coded cartons that indicate
a products’s peak freshness. Re-seal with cap
or wrap tightly. Do not return unused portions to
original container.

Check date code. Keep all cheese tightly packed
in moisture proof wrap

similar products are sold in date-coded cartons
that indicate a product’s peak freshness. Re-seal
or cover tightly. Do not return unused portions to
original container.

Check date code. Keep covered.

Check date code. Store eggs in coldest part of
refrigerator and in their original container.

If storing in refrigerator, do not wash fruit before
storing. Store in moisture resistant bags or
containers. Wrap cut fruits. Some fruits darken
when refrigerated.

Check date code and re-seal in original con­tainer. Do not return unused portions to original
container.

26_ operating

DA68-02657A-12.indb 26 2018. 10. 8. 오후 5:46

Foods Refrigerator Freezer Storage Tips

FISH AND SHELLFISH

Fish

Fatty Fish (mack­erel, trout, salmon)

Lean Fish (cod,
flounder, etc)

Frozen or Breaded na 3 Months

Shellfish

Shrimp (uncooked) 1-2 Days 12 Months

Crab 3-5 Days 10 Months

Cooked Fish or
Shellfish

MEAT

Fresh, Uncooked

Chops 2-4 Days 6-12 Months

Ground 1 Day 3-4 Months

Roast 2-4 Days 6-12 Months

Bacon 1-2 Weeks 1-2 Months

Sausage 1-2 Days 1-2 Months

Steak 2-4 Days 6-9 Months

Poultry 1 Day 12 Months

Lunch meat 3-5 Days 1 Month

Cooked

Meat 2-3 Days 2-3 Months

Poultry 2-3 Days 4-5 Months

Ham 1-2 weeks 1-2 Months

1-2 Days 2-3 Months

1-2 Days 6 Months

2-3 Days 3 Months

Keep in original wrapper and store in coldest part of
refrigerator. Package in vapor-proof and moisture
proof wrap for freezer. Freeze at 0ºF(or -18°C ).
Thaw in refrigerator or check date code. Freeze in
original packaging.

To freeze, package in vapor-proof and moisture-proof
container.

Check date code for use. Store in coldest part of
refrigerator in original packaging. Package in moisture­proof and vapor-proof container for freezing. Recom­mended refrigerator temperature 33ºF to 36ºF (or
1°C to 2°C ) and freezer temperature 0ºF to 2ºF (or

-18°C to -16°C )

Check date code for use. Store in coldest part of
refrigerator in original packaging. Package in moisture­proof and vapor-proof container for freezing.

02 OPERATING

Sources:

American Meat Institute Foundation. 1994. Yellow pages: answers to predictable questions consumers ask about
meat and poultry. American Meat Institute Food Marketing Institute. 1999. The food keeper. Food Marketing Institute,
Washington, D.C. Freeland-Graves, J.H. and G.C. Peckham. 1996. Foundations of food preparation, 6th ed. Prentice­Hall, Inc. Englewood Clis, NJ. Hillers, V.N. 1993. Storing foods at home. Washington State University Cooperative
Extension, Pullman, WA. Publ. EB 1205.
National Restaurant Association. 2001. Be cool-chill out! Refrigerate promptly. National Restaurant Association
Education Foundation¼s International Food Safety Council, Washington, D.C. USDA. 1997. Basics for handling food
safely. U.S. Department of Agriculture, Food Safety and Inspection Service, Washington, D.C.

operating _27

DA68-02657A-12.indb 27 2018. 10. 8. 오후 5:46

Troubleshooting

PROBLEM SOLUTION

The refrigerator
does not work at
all or it does not
chill suciently.

The food in the
fridge is frozen.

You hear unusual
noise or sounds.

The cabinet-door
sealing area of the
appliance is hot
and condensation
is occurring.

Ice Maker is not
producing ice.

You can hear
water bubbling in
the refrigerator.

There is a bad
smell in the
refrigerator.

Frost forms on
the walls of the
freezer.

Water dispenser
is not functioning.

Auto close
system does not
work with the
freezer door.

• Check if the power plug is properly connected.

• Check if the set temperature on the digital display is warmer than the freezer or fridge
inner temperature. If it is, set the refrigerator colder.

• Is the refrigerator in direct sunlight or located near a heat source?

• Is the back of the refrigerator too close to the wall, preventing proper ventilation?

• Check if the set temperature on the digital display is too low.

• Try setting the refrigerator to a warmer temperature.

• Is the temperature in the room too low? Set the refrigerator warmer.

• Did you store the food which is juicy in the coldest part of the refrigerator? Try moving
those items to the other shelves in the fridge instead of keeping them in the colder
areas or bins.

• Check if the refrigerator is level and stable.

• Is the back of the refrigerator too close to the wall, preventing proper ventilation?
Try moving the back of the refrigerator at least 2 inches from the wall.

• Was anything dropped behind or under the refrigerator?

• A “ticking” sound is heard from inside the refrigerator. This is normal and occurs
because various accessories are contracting or expanding according to the
temperature of the refrigerator interior.

• If it sounds as if something is hitting something else inside the refrigerator, this is normal.
The sound is caused by the compressor operating at high capacity.

• Some heat is normal as anti-condensators are installed in the vertical hinged section
of the refrigerator to prevent condensation.

• Is the refrigerator door ajar? Condensation can occur when you leave the door open
for a long time.

• Did you wait for 12 hours after installation of the water supply line before making ice?

• Is the water line connected and the shut-o valve opened?

• Did you manually stop the ice making function?

• Is the freezer temperature too warm? Try setting the freezer temperature lower.

• This is normal. The bubbling comes from refrigerant circulating through the refrigerator.

• Check for spoiled food.

• Foods with strong odors (for example, fish) should be tightly covered.

• Clean out your freezer periodically and throw away any spoiled or suspicious food.

• Is the air vent blocked? Remove any obstructions so air can circulate freely.

• Allow sucient space between the stored foods for ecient air circulation.

• Is the freezer drawer closed properly?

• Is the water line connected and the shut-o valve opened?

• Has the water supply line tubing been crushed or kinked?

• Make sure the tubing is free and clear of any obstruction.

• Is the water tank frozen because the fridge temperature is too low?
Try selecting a warmer setting on the Digital display.

• Is there an imbalance between the right and left parts of the door?

• Open and close the door smoothly 1~2 times.
After you do this, the auto close system usually works properly again.

• Try opening the door smoothly to avoid unbalancing the right and the left part of the
door.

28_ Troubleshooting

DA68-02657A-12.indb 28 2018. 10. 8. 오후 5:46

Warranty (USA)

WARRANTY ON SAMSUNG REFRIGERATOR

LIMITED WARRANTY (U.S.A.)
SAMSUNG REFRIGERATOR
LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER WITH PROOF OF PURCHASE

This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG)
and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against
manufacturing defects in materials or workmanship for the limited warranty period of:

One (1) year parts and labor
Five (5) years parts and labor on Sealed Refrigeration System Only (Compressor, Evaporator, Condenser, Drier,
and Connecting Tubing)
Ten (10) years part and Five (5) years labor on Digital Inverter Compressor Only

This limited warranty is valid only on products purchased and used in the United States that have been installed,
operated, and maintained according to the instructions attached to or furnished with the product. To receive
warranty service, the purchaser must contact SAMSUNG at the address or phone number provided below
for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG
authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to
SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.

SAMSUNG will provide in-home service within the contiguous United States during the warranty period at no
charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic area. If in­home service is not available, SAMSUNG may elect, at its option, to provide transportation of the product
to and from an authorized service center. If the product is located in an area where service by a SAMSUNG
authorized servicer is not available, you may be responsible for a trip charge or required to bring the product to a
SAMSUNG authorized service center for service.
To receive in-home service, product must be unobstructed and accessible to the service agent.

During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded,
at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or
replace the product with a new or reconditioned product. Replacement parts and products are warranted for the
remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All replaced parts
and products are the property of SAMSUNG and you must return them to SAMSUNG.

This limited warranty covers manufacturing defects in materials or workmanship encountered in normal
household, noncommercial use of this product and shall not cover the following: damage that occurs in
shipment, delivery, installation, and uses for which this product was not intended; damage caused by
unauthorized modification or alteration of the product; product where the original factory serial numbers have
been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage including
scratches, dents, chips, and other damage to the product’s finishes; damage caused by abuse, misuse, pest
infestations, accident, fire, floods, or other acts of nature or God; damage caused by use of equipment, utilities,
services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not
supplied or authorized by SAMSUNG; damage caused by incorrect electrical line current, voltage, fluctuations
and surges; damage caused by failure to operate and maintain the product according to instructions; in-home
instruction on how to use your product; and service to correct installation not in accordance with electrical or
plumbing codes or correction of household electrical or plumbing (i.e., house wiring, fuses, or water inlet hoses).
The cost of repair or replacement under these excluded circumstances shall be the customer’s responsibility.

Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this
limited warranty. Please contact SAMSUNG at the number below for assistance with any of these issues.

DA68-02657A-12.indb 29 2018. 10. 8. 오후 5:46

IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

EXCLUSION OF IMPLIED WARRANTIES

PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some
states do not allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not
apply to you. This warranty gives you specific rights, and you may also have other rights, which vary from state to
state.

YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF THE

LIMITATION OF REMEDIES

PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG SHALL NOT
BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO TIME
AWAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES, LOSS OF REVENUE
OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON
WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This warranty gives you specific rights, and you may also have other
rights, which vary from state to state.
SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee given by
any other person, firm, or corporation with respect to this product shall be binding on SAMSUNG.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
1-800-SAMSUNG (726-7864)
www.samsung.com/us/support

DA68-02657A-12.indb 30 2018. 10. 8. 오후 5:46
