SAMSUNG RCD-M70 Service Manual Part List
*S.N.A. : Service Not Available
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
4. Electrical Parts List
Location no. Code no. Description & Specifiation Remarks
|
AH26-00130A |
TRANS POWER |
-,RCD-M70,-,-,115/230V,-,-,-,5 |
|
AH39-10001K |
POWER-CORD |
CP2,KLCE-2F,2M,KKS-15,VDE |
|
AH59-00043G |
REMOCON-ASSY |
RCDM70,-,-,-,15KEY,-,-,-,-,-,- |
|
AH68-00674E |
MANUAL-USERS |
RUSSIAN |
|
AH92-00755A ASSY PCB |
RCDM70,MAIN PCB |
|
ED1 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
FD1 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
FD2 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
FD3 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
ID1 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
ID2 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD1 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD2 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD3 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD4 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD88 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
JD89 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD1 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD2 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD3 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD4 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD5 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
KD6 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
RD6 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
RD88 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
UD1-5 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
UD50-55 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
UD60-61 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
UD7 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
UD8 |
0401-000101 |
DIODE-SWITCHING |
1N4148,100V,200mA,500mW,4nS |
CD2 |
0402-000127 |
DIODE-RECTIFIER |
1N4002,100V,1A,DO-41 |
CD3 |
0402-000127 |
DIODE-RECTIFIER |
1N4002,100V,1A,DO-41 |
UND1 |
0402-000127 |
DIODE-RECTIFIER |
1N4002,100V,1A,DO-41 |
|
0403-000362 |
DIODE-ZENER |
UZ6.2BSC,6.2V,6.16-6.4V,500 |
BZD1 |
0403-000379 |
DIODE-ZENER |
UZP12B,12V,11.4-12.6V,1W,DO |
HZD1 |
0403-000393 |
DIODE-ZENER |
UZP5.1B,5.1V,4.8-5.4V,1W,DO |
RZD1 |
0403-000398 |
DIODE-ZENER |
UZP8.2B,8.2V,7.7-8.7V,1W,DO |
OKV1 |
0405-001061 |
DIODE-VARACTOR |
SVC344,30V,100NA,TP |
JQ1 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
JQ2 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
JQ5 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
JQ51 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
JQ52 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
QQ3 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
RIC1 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
RQ2 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
ZQ3 |
0501-000010 |
TR-SMALL SIGNAL |
KSC1008-YTA,NPN,80V,60V,700mA, |
IQ2 |
0501-000294 |
TR-SMALL SIGNAL |
KSA708-YTA,PNP,-80V,-60V, |
CQ1 |
0501-000303 |
TR-SMALL SIGNAL |
KSA733YTA,PNP,-60V,-50V,-150mA |
JQ4 |
0501-000303 |
TR-SMALL SIGNAL |
KSA733YTA,PNP,-60V,-50V,-150mA |
SQ4 |
0501-000303 |
TR-SMALL SIGNAL |
KSA733YTA,PNP,-60V,-50V,-150mA |
UQ1 |
0501-000303 |
TR-SMALL SIGNAL |
KSA733YTA,PNP,-60V,-50V,-150mA |
UQ4 |
0501-000303 |
TR-SMALL SIGNAL |
KSA733YTA,PNP,-60V,-50V,-150mA |
IQ1 |
0501-000392 |
TR-SMALL SIGNAL |
KSC838-OTA,35V,30V,30mA,250 |
KQ31 |
0501-000394 |
TR-SMALL SIGNAL |
KSC900-LTA,30V,25V,50mA,250 |
KQ1 |
0501-000398 |
TR-SMALL SIGNAL |
KSC945-YTA,NPN,60V,50V,150MA, |
KQ51 |
0501-000398 |
TR-SMALL SIGNAL |
KSC945-YTA,NPN,60V,50V,150MA, |
QQ1 |
0501-000398 |
TR-SMALL SIGNAL |
KSC945-YTA,NPN,60V,50V,150MA, |
QQ51 |
0501-000398 |
TR-SMALL SIGNAL |
KSC945-YTA,NPN,60V,50V,150MA, |
UQ12 |
0501-000398 |
TR-SMALL SIGNAL |
KSC945-YTA,NPN,60V,50V,150MA, |
RQ1 |
0501-000610 |
TR-SMALL SIGNAL |
KSA928A,PNP,-30V,-30V,-2A,1W |
ZQ2 |
0501-000610 |
TR-SMALL SIGNAL |
KSA928A,PNP,-30V,-30V,-2A,1W |
KQ2 |
0504-000118 |
TR-DIGITAL |
KSR1003TA,NPN,300MW,22K-22KOHM |
UQ2 |
0504-000118 |
TR-DIGITAL |
KSR1003TA,NPN,300MW,22K-22KOHM |
CQ5 |
0504-000121 |
TR-DIGITAL |
KSR1007TA/108M,300MW,22K-47K |
UQ3 |
0504-000121 |
TR-DIGITAL |
KSR1007TA/108M,300MW,22K-47K |
CQ2 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
CQ3 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
JQ56 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
JQ6 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
SQ2 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
ZQ5 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
ZQ55 |
0504-000122 |
TR-DIGITAL |
KSR1009TA, 300MW,4.7KOHM,TO-9 |
CQ4 |
0504-001003 |
TR-DIGITAL |
KSR2003TA,300mW,22K-22Kohm |
IQ3 |
0504-001003 |
TR-DIGITAL |
KSR2003TA,300mW,22K-22Kohm |
JQ3 |
0504-001003 |
TR-DIGITAL |
KSR2003TA,300mW,22K-22Kohm |
QQ2 |
0504-001003 |
TR-DIGITAL |
KSR2003TA,300mW,22K-22Kohm |
UQ5 |
0504-001003 |
TR-DIGITAL |
KSR2003TA,300mW,22K-22Kohm |
BLED1 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
BLED2 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
BLED3 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
BLED4 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
BLED5 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
BLED6 |
0601-001385 |
LED |
LTL-87HKESS-UA,PURE GRN |
AR1 |
2001-000003 |
R-CARBON |
330ohm,5%,1/8W,AA,TP,1.8x3.2mm |
AR51 |
2001-000003 |
R-CARBON |
330ohm,5%,1/8W,AA,TP,1.8x3.2mm |
IR1 |
2001-000003 |
R-CARBON |
330ohm,5%,1/8W,AA,TP,1.8x3.2mm |
Location no. Code no. Description & Specifiation Remarks
IR4 |
2001-000003 |
R-CARBON |
330ohm,5%,1/8W,AA,TP,1.8x3.2mm |
IR3 |
2001-000005 |
R-CARBON |
390ohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR6 |
2001-000008 |
R-CARBON |
15Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
BR5 |
2001-000034 |
R-CARBON |
220ohm,5%,1/4W,AA,TP,2.4x6.4mm |
2001-000038 |
R-CARBON |
390ohm,5%,1/4W,AA,TP,2.4x6.4mm |
|
KR2 |
2001-000241 |
R-CARBON |
1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KR52 |
2001-000241 |
R-CARBON |
1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m |
RR2 |
2001-000241 |
R-CARBON |
1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR12 |
2001-000273 |
R-CARBON |
100Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR62 |
2001-000273 |
R-CARBON |
100Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UR4 |
2001-000273 |
R-CARBON |
100Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR16 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
QR4 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR12 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR1 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR11 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR2 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR3 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR4 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR5 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR6 |
2001-000281 |
R-CARBON |
100ohm,5%,1/8W,AA,TP,1.8x3.2mm |
CR5 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
DR5 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
DR55 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
FR3 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HR14 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HR15 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HR16 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IR23 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IR24 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR14 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR16 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR9 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KR66 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
OR11 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
QR57 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
QR58 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
QR7 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
QR8 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
RR9 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR10 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR11 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR59 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR9 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
UR17 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
UR18 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
UR32 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
ZR5 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
ZR55 |
2001-000290 |
R-CARBON |
10Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
UR159 |
2001-000295 |
R-CARBON |
10MOHM,5%,1/8W,AA,TP,1.8*3.2 |
IR14 |
2001-000302 |
R-CARBON |
10ohm,5%,1/8W,AA,TP,1.8x3.2mm |
RR5 |
2001-000302 |
R-CARBON |
10ohm,5%,1/8W,AA,TP,1.8x3.2mm |
KR57 |
2001-000331 |
R-CARBON |
12Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KR7 |
2001-000331 |
R-CARBON |
12Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
RR10 |
2001-000331 |
R-CARBON |
12Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
BR6 |
2001-000362 |
R-CARBON |
150ohm,5%,1/8W,AA,TP,1.8x3.2mm |
BR7 |
2001-000362 |
R-CARBON |
150ohm,5%,1/8W,AA,TP,1.8x3.2mm |
BR8 |
2001-000362 |
R-CARBON |
150ohm,5%,1/8W,AA,TP,1.8x3.2mm |
CR2 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HR4 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IR29 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR1 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR2 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR5 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR51 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR52 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JR55 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR7 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
SR8 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
ZR4 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
ZR56 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
ZR6 |
2001-000429 |
R-CARBON |
1Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HR10 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR11 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR12 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR13 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR17 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR2 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR3 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HR5 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR10 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR11 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR40 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR60 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR61 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KR58 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KR8 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QR56 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QR6 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
Samsung Electronics |
4-1 |
Location no. Code no. |
Description & Specifiation Remarks |
|
Location no. Code no. |
Description & Specifiation Remarks |
|
|
|
|
|
UNR10 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
IR17 |
2001-000890 |
R-CARBON |
6.8Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UNR12 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UR2 |
2001-000977 |
R-CARBON |
8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m |
UNR13 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR3 |
2001-001006 |
R-CARBON |
82ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR7 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JR53 |
2001-001006 |
R-CARBON |
82ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UNR8 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
BR5 |
2001-001107 |
R-CARBON(S) |
220ohm,5%,1/2W,AA,TP,2.4x6.4mm |
UNR9 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
RR7 |
2008-000157 |
R-FUSIBLE |
4.7ohm,5%,1/4W,AA,TP,2.6x6.7mm |
UR1 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
BR1 |
2008-000158 |
R-FUSIBLE |
4.7OHM,5% 1W AA TP 4.3*13MM |
UR10 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
RR3 |
2008-000158 |
R-FUSIBLE |
4.7OHM,5% 1W AA TP 4.3*13MM |
UR11 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
ZR1 |
2008-000158 |
R-FUSIBLE |
4.7OHM,5% 1W AA TP 4.3*13MM |
UR13 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
CSVR1 |
2103-000341 |
VR-SEMI |
2Kohm,30%,1/10W,TOP |
UR14 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
ISVR2 |
2103-000461 |
VR-SEMI |
50Kohm,30%,1/10W,TOP |
UR15 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
ISVR1 |
2103-000492 |
VR-SEMI |
5Kohm,30%,1/10W,TOP |
UR16 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
EC7 |
2201-000144 |
C-CERAMIC,DISC |
100pF,5%,50V,NPO,8.0X4.0mm,5mm |
UR9 |
2001-000449 |
R-CARBON |
2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC9 |
2201-000144 |
C-CERAMIC,DISC |
100pF,5%,50V,NPO,8.0X4.0mm,5mm |
JR7 |
2001-000472 |
R-CARBON |
2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
IC20 |
2201-000144 |
C-CERAMIC,DISC |
100pF,5%,50V,NPO,8.0X4.0mm,5mm |
KR1 |
2001-000508 |
R-CARBON |
220Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC3 |
2201-000144 |
C-CERAMIC,DISC |
100pF,5%,50V,NPO,8.0X4.0mm,5mm |
KR51 |
2001-000508 |
R-CARBON |
220Kohm,5%,1/8W,AA,TP,1.8x3.2m |
FC5 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
SR5 |
2001-000508 |
R-CARBON |
220Kohm,5%,1/8W,AA,TP,1.8x3.2m |
FC6 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
SR55 |
2001-000508 |
R-CARBON |
220Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC19 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
SR6 |
2001-000508 |
R-CARBON |
220Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC3 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
IR2 |
2001-000515 |
R-CARBON |
220ohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC4 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
QR5 |
2001-000515 |
R-CARBON |
220ohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC53 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
QR55 |
2001-000515 |
R-CARBON |
220ohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC54 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
BR2 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC1 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
CR6 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC37 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
ER10 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC38 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
ER11 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC51 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
KR32 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC8 |
2201-000146 |
C-CERAMIC,DISC |
100pF,5%,50V,SL,5x3.5mm,5mm,TP |
KR40 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC9 |
2201-000163 |
C-CERAMIC,DISC |
10nF,+80-20%,50V,Y5V,6.5*5,5MM |
KR9 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
OC6 |
2201-000202 |
C-CERAMIC,DISC |
10pF,5%,50V,NPO,5.0*3.0,5MM,TP |
RR1 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC1 |
2201-000247 |
C-CERAMIC,DISC |
15pF,5%,50V,NPO,4x3.5mm,5mm,TP |
RR98 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC11 |
2201-000338 |
C-CERAMIC,DISC |
2.2nF,20%,50V,Y5T,5.0*3.0,5MM, |
SD121 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC61 |
2201-000338 |
C-CERAMIC,DISC |
2.2nF,20%,50V,Y5T,5.0*3.0,5MM, |
UR28 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC3 |
2201-000338 |
C-CERAMIC,DISC |
2.2nF,20%,50V,Y5T,5.0*3.0,5MM, |
UR5 |
2001-000522 |
R-CARBON |
22Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC53 |
2201-000338 |
C-CERAMIC,DISC |
2.2nF,20%,50V,Y5T,5.0*3.0,5MM, |
AR3 |
2001-000527 |
R-CARBON |
22ohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC34 |
2201-000368 |
C-CERAMIC,DISC |
220pF,10%,50V,SL,6.5*3.0,5mm,T |
KR33 |
2001-000527 |
R-CARBON |
22ohm,5%,1/8W,AA,TP,1.8x3.2mm |
FC4 |
2201-000381 |
C-CERAMIC,DISC |
22nF,+80%,-20% 50V Y5V 8.0*4.0 |
AR2 |
2001-000552 |
R-CARBON |
270ohm,5%,1/4W,AA,TP,2.4x6.4mm |
IC1 |
2201-000381 |
C-CERAMIC,DISC |
22nF,+80%,-20% 50V Y5V 8.0*4.0 |
AR52 |
2001-000552 |
R-CARBON |
270ohm,5%,1/4W,AA,TP,2.4x6.4mm |
IC30 |
2201-000381 |
C-CERAMIC,DISC |
22nF,+80%,-20% 50V Y5V 8.0*4.0 |
CR3 |
2001-000554 |
R-CARBON |
270ohm,5%,1/8W,AA,TP,1.8x3.2mm |
UC1 |
2201-000381 |
C-CERAMIC,DISC |
22nF,+80%,-20% 50V Y5V 8.0*4.0 |
IR15 |
2001-000563 |
R-CARBON |
27Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
FC1 |
2201-000389 |
C-CERAMIC,DISC |
22pF,5%,50V,NPO,5.0*3.0,5MM,TP |
IR16 |
2001-000563 |
R-CARBON |
27Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
OC1 |
2201-000389 |
C-CERAMIC,DISC |
22pF,5%,50V,NPO,5.0*3.0,5MM,TP |
IR21 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UC7 |
2201-000389 |
C-CERAMIC,DISC |
22pF,5%,50V,NPO,5.0*3.0,5MM,TP |
IR22 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UC8 |
2201-000389 |
C-CERAMIC,DISC |
22pF,5%,50V,NPO,5.0*3.0,5MM,TP |
IR27 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC2 |
2201-000423 |
C-CERAMIC,DISC |
27pF,5%,50V,NPO,5.0*3.0,5MM,TP |
IR28 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KC14 |
2201-000470 |
C-CERAMIC,DISC |
330pF,10%,50V,SL,8x4mm,5mm,TP |
IR8 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KC7 |
2201-000470 |
C-CERAMIC,DISC |
330pF,10%,50V,SL,8x4mm,5mm,TP |
JR15 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UC5 |
2201-000483 |
C-CERAMIC,DISC |
33pF,5%,50V,NPO,5x3.5mm,5mm,TP |
SR13 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UC6 |
2201-000483 |
C-CERAMIC,DISC |
33pF,5%,50V,NPO,5x3.5mm,5mm,TP |
SR3 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
SC4 |
2201-000557 |
C-CERAMIC,DISC |
470pF,10%,50V,SL,10.0X4.0mm,5m |
SR53 |
2001-000591 |
R-CARBON |
3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m |
SC54 |
2201-000557 |
C-CERAMIC,DISC |
470pF,10%,50V,SL,10.0X4.0mm,5m |
IR10 |
2001-000660 |
R-CARBON |
33Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
FC3 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
IR26 |
2001-000660 |
R-CARBON |
33Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC18 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
IR9 |
2001-000660 |
R-CARBON |
33Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC12 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
HR6 |
2001-000666 |
R-CARBON |
33ohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC15 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
KR5 |
2001-000666 |
R-CARBON |
33ohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC2 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
IR6 |
2001-000702 |
R-CARBON |
39Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC26 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
CR1 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
UC3 |
2201-000565 |
C-CERAMIC,DISC |
47nF,+80% -20% 50V Y5V 12.5*4. |
FR2 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC10 |
2201-000681 |
C-CERAMIC,DISC |
82PF,5%,50V,SL,4*3.5 |
IR7 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QC56 |
2201-000783 |
C-CERAMIC,DISC |
100nF,+80%,-20%,50V,Y5V,-,5mm, |
OR10 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QC57 |
2201-000783 |
C-CERAMIC,DISC |
100nF,+80%,-20%,50V,Y5V,-,5mm, |
QR11 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QC6 |
2201-000783 |
C-CERAMIC,DISC |
100nF,+80%,-20%,50V,Y5V,-,5mm, |
QR9 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QC7 |
2201-000783 |
C-CERAMIC,DISC |
100nF,+80%,-20%,50V,Y5V,-,5mm, |
RR6 |
2001-000734 |
R-CARBON |
4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC7 |
2201-000806 |
C-CERAMIC,DISC |
1NF,10%,400V,Y5P,TP,10*5, |
KR4 |
2001-000773 |
R-CARBON |
470Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC8 |
2201-000806 |
C-CERAMIC,DISC |
1NF,10%,400V,Y5P,TP,10*5, |
UR6 |
2001-000773 |
R-CARBON |
470Kohm,5%,1/8W,AA,TP,1.8x3.2m |
EC8 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
RR99 |
2001-000780 |
R-CARBON |
470ohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC10 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR19 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC11 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR20 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC20 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR21 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
HC6 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR22 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC31 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR23 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC32 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR24 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC6 |
2202-000781 |
C-CERAMIC,MLC-AXIAL |
100pF,10%,50V,Y5P,3.5x19mm,-,T |
UR30 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC16 |
2202-000807 |
C-CERAMIC,MLC-AXIAL |
22nF,+80-20%,25V,Y5V,3.5x19mm, |
UR31 |
2001-000786 |
R-CARBON |
47Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC17 |
2202-000807 |
C-CERAMIC,MLC-AXIAL |
22nF,+80-20%,25V,Y5V,3.5x19mm, |
FR1 |
2001-000793 |
R-CARBON |
47ohm,5%,1/8W,AA,TP,1.8x3.2mm |
IC19 |
2202-000807 |
C-CERAMIC,MLC-AXIAL |
22nF,+80-20%,25V,Y5V,3.5x19mm, |
JR20 |
2001-000793 |
R-CARBON |
47ohm,5%,1/8W,AA,TP,1.8x3.2mm |
RC10 |
2202-000807 |
C-CERAMIC,MLC-AXIAL |
22nF,+80-20%,25V,Y5V,3.5x19mm, |
KR31 |
2001-000793 |
R-CARBON |
47ohm,5%,1/8W,AA,TP,1.8x3.2mm |
QC5 |
2202-000820 |
C-CERAMIC,MLC-AXIAL |
5.6nF,20%,16V,Y5R,3.5x19mm,-,T |
IR11 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
QC55 |
2202-000820 |
C-CERAMIC,MLC-AXIAL |
5.6nF,20%,16V,Y5R,3.5x19mm,-,T |
IR12 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
IC29 |
2202-000854 |
C-CERAMIC,MLC-AXIAL |
47nF,+80-20%,50V,Y5V,3.5x19mm, |
IR25 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
KC32 |
2301-000365 |
C-FILM,PEF |
1.5nF,10%,50V,5.5x12x3,TP |
IR5 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC1 |
2301-000370 |
C-FILM,PEF |
1.8nF,10%,50V,5.5x12x3,TP |
JR17 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC2 |
2301-000370 |
C-FILM,PEF |
1.8nF,10%,50V,5.5x12x3,TP |
JR4 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC51 |
2301-000370 |
C-FILM,PEF |
1.8nF,10%,50V,5.5x12x3,TP |
JR54 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC52 |
2301-000370 |
C-FILM,PEF |
1.8nF,10%,50V,5.5x12x3,TP |
JR58 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
HC16 |
2301-000375 |
C-FILM,PEF |
100nF,10%,50V,11x12.5x6.5,TP |
JR8 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
OC5 |
2301-000375 |
C-FILM,PEF |
100nF,10%,50V,11x12.5x6.5,TP |
QR1 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
IC4 |
2301-000379 |
C-FILM,PEF |
10nF,10%,50V,6x12x3.5,TP |
QR51 |
2001-000802 |
R-CARBON |
5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m |
IC5 |
2301-000379 |
C-FILM,PEF |
10nF,10%,50V,6x12x3.5,TP |
UR158 |
2001-000850 |
R-CARBON |
560Kohm,5%,1/8W,AA,TP,1.8x3.2m |
JC59 |
2301-000379 |
C-FILM,PEF |
10nF,10%,50V,6x12x3.5,TP |
UR3 |
2001-000864 |
R-CARBON |
56Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
JC9 |
2301-000379 |
C-FILM,PEF |
10nF,10%,50V,6x12x3.5,TP |
UR49 |
2001-000864 |
R-CARBON |
56Kohm,5%,1/8W,AA,TP,1.8x3.2mm |
AC3 |
2301-000400 |
C-FILM,PEF |
1nF,10%,50V,5.5x12x3,TP |
KR3 |
2001-000869 |
R-CARBON |
56ohm,5%,1/8W,AA,TP,1.8x3.2mm |
AC53 |
2301-000400 |
C-FILM,PEF |
1nF,10%,50V,5.5x12x3,TP |
KR53 |
2001-000869 |
R-CARBON |
56ohm,5%,1/8W,AA,TP,1.8x3.2mm |
KC56 |
2301-000404 |
C-FILM,PEF |
2.2nF,10%,50V,5.5x12x3,TP |
4-2 |
Samsung Electronics |
Loading...
