Samsung RB17AS, RB17NS Schematic

TFT-LCD MONITOR

RB17AS RB17NS

SERVICE

Manual

TFT-LCD MONITOR CONTENTS

1. Precautions

2. Product Specifications

3. Disassembly & Reassembly

4. Alignment & Adjustments

5. Troubleshooting

6. Exploded View & Parts List

7. Electrical Parts List

8. Block Diagram

9. Wiring Diagram

10. Schematic Diagrams

11. Panel Description

1 Precautions

DEVICE UNDER TEST

TEST ALL

EXPOSED METAL

SURFACES

(READING SHOULD

NOT BE ABOVE 0.5mA)

LEAKAGE CURRENT

TESTER

2-WIRE CORD

ALSO TEST WITH

PLUG REVERSED (USING AC ADAPTER PLUG AS REQUIRED)

EARTH

GROUND

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock.

1-1 Safety Precautions

1-1-1 Warnings

1. For continued safety, do not attempt to modify the circuit board.

2. Disconnect the AC power and DC Power Jack before servicing.

1-1-2 Servicing the LCD Monitor

1. When servicing the LCD Monitor Disconnect the AC line cord from the AC outlet.

2. It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this meter periodically.

1-1-3 Fire and Shock Hazard

Before returning the monitor to the user, perform the following safety checks:

1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the chassis and other metal parts in the monitor.

2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and compartment covers or shields, isolation resistor-capacitor networks, mechanical insulators, etc.

3. Leakage Current Hot Check (Figure 1-1):

WARNING: Do not use an isolation transformer during

this test.

Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI C101.1, Leakage Current for

Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).

Figure 1-1. Leakage Current Test Circuit

4. With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch first in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts. The current measured should not exceed 0.5 milliamp. Reverse the power-plug prongs in the AC outlet and repeat

the test.

1-1-4 Product Safety Notices

Some electrical and mechanical parts have special safety-related characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc. Parts that have special safety characteristics are identified by

on schematics and parts lists. A substitute replacement that does not have the same safety characteristics as the recommended replacement part might create shock, fire and / or other hazards. Product safety is under review continuously and new instructions are issued whenever appropriate.

RB17AS/RB17NS 1-1

1-2 Servicing Precautions

WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions

section of this manual.

Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the

safety precautions, always follow the safety precautions.

1-2-1 General Servicing Precautions

1. Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test component in parallel with an electrolytic capacitor.

2. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements to their original position.

3. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that the area around the serviced part has not been damaged.

4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input terminals and earphone jacks).

5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect an insulation resistance meter (500 V) to the blades of the AC plug.

The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be greater than 1 megohm.

6. Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last.

1-3 Electrostatically Sensitive Devices (ESD) Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated circuits and some fieldeffect transistors. The following techniques will reduce the incidence of component damage caused by static electricity.

1. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground. Alternatively, wear a discharging wriststrap device. To avoid a shock hazard, be sure to remove the wrist strap before applying power to the monitor.

2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent accumulation of an electrostatic charge.

3. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESDs.

4. Use only a grounded-tip soldering iron to solder or desolder ESDs.

5. Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static” can generate electrical charges sufficient to damage ESDs.

6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive materials.

7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material to the chassis or circuit assembly into which the device will be installed.

Caution: Be sure no power is applied to the

chassis or circuit and observe all other safety precautions.

8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD.

1-2 RB17AS/RB17NS

2 Product Specifications

2-1 Specifications

Item Description

LCD Panel TFT-LCD panel, RGB vertical stripe, normaly white, 17-Inch viewable,

0.264 (H) x 0.264 (V) mm pixel pitch

Scanning Frequency Horizontal : 30 kHz ~ 70 kHz (Automatic)

Vertical : 56 Hz ~ 85 Hz (Automatic)

Display Colors 16.7 Million colors

Maximum Resolution Horizontal : 1280 Pixels

Vertical : 1024 Pixels

Input Video Signal Analog 0.7 Vp-p ± 5% positive at 75 Ω, internally terminated

Input Sync Signal Type : Seperate H/V Sync-on-Green,

automatic synchronization without external switch of sync type

Level : TTL level

Maximum Pixel Clock rate 135 MHz

Active Display Horizontal/Vertical

AC power voltage & Frequency AC 110 ~ 240 Volts, 60/ 50 Hz ± 3 Hz

Power Consumption 52 W (Max)

Dimensions Unit (W x D x H) 16.20 x 7.99 x 16.31 Inches (412 x 203 x 414.5 mm)

Carton (W x D x H) 19.09 x 21.46 x 7.28 Inches (485 x 545 x 185 mm)

Weight 8.00 kg (17.63 Ibs)

Environmental Considerations Operating Temperature : 50 °F ~ 104 °F (10 °C ~ 40 °C)

TV System

Antena Input 75Ω, Coaxial Cable

Sound Characteristic – Headphone Out: RF => 5mW max (400m Vrms)

338.1 mm / 270.1 mm

Humidity : 10 % ~ 80 % Storage Temperature : -13 °F ~ 113 °F (-25 °C ~ 45 °C) Humidity : 5 % ~ 95 %

RB17NS RB17AS

Tunning Frequency Synthesize Frequency Synthesize Color NTSC PAL Sound BTSC, A2 STEREO, EIAJ NICAM, A2 STEREO

– MAX Internal speaker Out : Right => 5W

Left => 5W – BASS Control Range : -12dB~ + 12dB – TREBLE Control Range : -12dB~ + 12dB

A/V => 10mW max (580 Vrms), Max Input sound: -9dBm

– Output Frequency (TBD) : RF => 80 Hz ~ 15 kHz

A/V => 80 Hz ~ 20 kHz

RB17AS/RB17NS 2-1

2-2 Pin Assignments

Sync Type

Pin No.

Separate H/V Composite H/V

Sync-on-green

Pin No.

10 11 12 13 14 15

1 2 3 4 5 6 7 8 9

Sync Type

Red Green Blue GND GND (DDC Return) GND-Red GND-Green GND-Blue No Connection GND-Sync./Self Test GND DDC Data Horizontal sync. Vertical sync. DDC Clock

DTV 15pin connector

Red Green Blue GND GND (DDC Return) GND-Red GND-Green GND-Blue No Connection GND-Sync./Self Test GND DDC Data H/V-Sync. Not Used DDC Clock

Red Green + H/V Sync. Blue GND GND (DDC Return) GND-Red GND-Green GND-Blue Not Used GND-Sync./Self Test GND DDC Data Not Used Not Used DDC Clock

10 11 12 13 14 15

1 2 3 4 5 6 7 8 9

Red , Y Green , Pb Blue , Pr GND GND GND-Red GND-Green GND-Blue GND No Connection GND No Connection Horizontal sync. Vertical sync. No Connection

2-2 RB17AS/RB17NS

2-3 Timing Chart

Timing No. Originator Mode Name Resolution (HxV)

1 IBM VGA1 640x350

2 IBM VGA2 720x400

3 IBM VGA3 640x480

11 VESA 640/72Hz 640x480

17 VESA 640/75Hz 640x480

HORIZONTAL

Frequency Total time Active time Blank time Border (L / R) Data time Front porch Sync. width Back porch Sync. polarity

31.469kHz

31.778µs

26.058µs

5.720µs

0.318µs

25.422µs

0.318µs

3.813µs

1.589µs

Positive

31.469kHz

31.777µs

26.058µs

5.720µs

0.318µs

25.422µs

0.318µs

3.813µs

1.589µs

Negative

31.469kHz

31.788µs

26.058µs

5.720µs

0.318µs

25.422µs

0.318µs

3.813µs

1.589µs

Negative

37.861kHz

26.413µs

20.825µs

5.588µs

0.254µs

20.317µs

0.508µs

1.270µs

3.810µs

Negative

37.500kHz

26.667µs

20.317µs

6.350µs

0.000µs

20.317µs

0.508µs

2.032µs

3.810µs

Negative

VERTICAL

Frequency Total time Active time Blank time Border (T / B) Data time Front porch Sync. width Back porch Sync. polarity

70.086Hz

14.268ms

11.504ms

2.764ms

0.191ms

11.122ms

0.985ms

0.064ms

1.716ms Negative

70.087Hz

14.268ms

13.155ms

1.113ms

0.222ms

12.711ms

0.191ms

0.064ms

0.858ms

Positive

59.940Hz

16.683ms

15.761ms

0.922ms

0.254ms

15.253ms

0.064ms

0.794ms

Negative

72.809Hz

13.735ms

13.100ms

0.635ms

0.211ms

12.678ms

0.026ms

0.079ms

0.528ms

Negative

75.000Hz

13.333ms

12.800ms

0.533ms

0.000ms

12.800ms

0.027ms

0.080ms

0.427ms Negative

Dot Clock 25.175MHz 28.322MHz 25.175MHz 31.500MHz 31.500MHz

Sync. Type

Scan Type

Separate

N/I

Separate

N/I

Separate

N/I

Separate

N/I

Separate

N/I

This section of the service manual describes the timing that the computer industry recognizes as standard for computer-generated video signals.

Table 2-1. Timing Chart (Continued)

Timing No. Originator Mode Name Resolution (HxV)

19 VESA 1024/75Hz 1024x768

32 VESA

Separate Composite Sync.-on-G N/I

640/67Hz 640x480

33 MAC 832/75Hz 832x624

HORIZONTAL

Frequency Total time Active time Blank time Border (L / R) Data time Front porch Sync. width Back porch Sync. polarity

60.023kHz

16.660

µs

13.033µs

3.657µs

0.000µs

13.033µs

0.203µs

1.219µs

2.235µs

Positive

35.000kHz

28.571

µs

21.164µs

7.407µs

0.000µs

21.164µs

2.116µs

3.175µs

Negative

49.726kHz

20.110µs

14.524µs

5.586µs

0.000µs

14.524µs

0.559µs

1.117µs

3.910µs

Negative

Negative Negative

VERTICAL

Frequency Total time Active time Blank time Border (T / B) Data time Front porch Sync. width Back porch Sync. polarity

75.029Hz

13.328ms

12.795ms

0.533ms

0.000ms

12.795ms

0.017ms

0.050ms

0.466ms

Positive

66.667Hz

15.000ms

13.714ms

1.286ms

0.000ms

13.714ms

0.086ms

1.114ms

74.551Hz

13.414ms

12.549ms

0.865ms

0.000ms

12.549ms

0.020ms

0.060ms

0.784ms

Dot Clock

78.750MHz

30.240MHz 57.284MHz

Sync. Type

Scan Type

Separate

N/I

2-4 RB17AS/RB17NS

Table 2-1. Timing Chart (Continued)

Timing No. Originator Mode Name Resolution (HxV)

12 VESA 800/56Hz 800x600

13 VESA 800/60Hz 800x600

14 VESA 800/72Hz 800x600

18 VESA 800/75Hz 800x600

16 VESA 1024/70Hz 1024x768

HORIZONTAL Frequency Total time Active time Blank time Border (L / R) Data time Front porch Sync. width Back porch Sync. polarity

35.156kHz

28.444µs

22.222µs

6.222µs

0.000µs

22.222µs

0.667µs

2.000µs

3.556µs Positive or Nehative

37.879kHz

26.400µs

20.000µs

6.400µs

0.000µs

20.000µs

1.000µs

3.200µs

2.200µs Positive

48.077kHz

20.800µs

16.000µs

4.800µs

0.000µs

16.000µs

1.120µs

2.400µs

1.280µs Positive

46.875kHz

21.333µs

16.162µs

5.171µs

0.000µs

16.162µs

0.323µs

1.616µs

3.232µs Positive

56.476kHz

17.707µs

13.653µs

4.054µs

0.000µs

13.653µs

0.320µs

1.813µs

1.920µs

Negative

VERTICAL Frequency

Total time Active time Blank time Border (T / B) Data time Front porch Sync. width Back porch Sync. polarity

56.250Hz

17.778ms

17.067ms

0.711ms

0.000ms

17.067ms

0.028ms

0.057ms

1.626ms Positive or Nehative

60.317Hz

16.579ms

15.840ms

0.739ms

0.000ms

15.840ms

0.026ms

0.106ms

0.607ms Positive

72.188Hz

13.853ms

12.480ms

1.373ms

0.000ms

12.480ms

0.770ms

0.125ms

0.478ms Positive

75.000Hz

13.333ms

12.800ms

0.533ms

0.000ms

12.800ms

0.021ms

0.064ms

0.448ms Positive

70.069Hz

14.272ms

13.599ms

0.673ms

0.000ms

13.599ms

0.053ms

0.106ms

0.513ms

Negative

Dot Clock 36.000MHz 40.000MHz 50.000MHz 49.500MHz 75.000MHz

Sync. Type

Scan Type

Separate

N/I

Separate

N/I

Separate

N/I

Separate

N/I

Separate

N/I

Timing No. Originator Mode Name Resolution (HxV)

1 274M 1080i/60iHz 1920x1080

2 296M

720p/60Hz

1280x720

3 293M 480p/60Hz 720x483

HORIZONTAL Frequency Total time Border (L / R) Data time Front porch Sync. width Back porch Sync. polarity

33.750kHz

29.630

µs

0.000

µs

25.859

µs

0.593

µs

0.593

µs

2.586

µs

45.000kHz

22.222

µs

0.000

µs

17.239

µs

0.943

µs

0.539

µs

3.502

µs

31.469kHz

31.778

µs

0.000

µs

26.667

µs

0.593

µs

2.333

µs

2.185

µs

VERTICAL Frequency Total time Border (T / B) Data time Front porch Sync. width Back porch Sync. polarity

30Hz

33.333ms

0.000ms

0.059ms

0.148ms

0.444ms

60Hz

16.667ms

0.000ms

16.000ms

0.111ms

0.444ms

60Hz

16.683ms

0.000ms

15.349ms

0.191ms

0.953ms

Dot Clock 75MHz 75MHz 27MHz

2-4 DTV Timing Chart

Table 2-2. DTV Timing chart

2-6 RB17AS/RB17NS

3 Disassembly and Reassembly

This section of the service manual describes the disassembly and reassembly procedures for the RB17AS/17NS monitor.

WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling

these components.

3-1 Disassembly

Cautions:1. Disconnect the monitor from the power source before disassembly.

2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

3-1 General Alignment Instuction

1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation. Check the basic characteristics such as height, horizontal and vertical sync.

2. Use the specified test equipment or its equivalent.

3. Correct impedance matching is essential.

4. Avoid overload. Excessive signal from a sweep generator might overload the front-end of the TV. When inserting signal markers, do not allow the marker generator to distort test result.

3-2 Replacement Order of Lamp Assemblies

5. Connect the TV only to an DC power source with voltage and frequency as specified on the backcover nameplate.

6. Do not attempt to connect or disconnect any wire while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts.

7. To protect aganist shock hazard,use an isolation transform.

1. After confirm there is nothing on the desk Turn the LCD module over and put it on a flat desk set to the ground.

RB17AS/RB17NS 3-1

3 Disassembly and Reassembly

2. Push down the stopper and slide the lamp unit.

3. Please take out the lamp units from the LCD module.

4. Please fix the new lamp units on the LCD module : opposite process 2 and 3

* Replacement of lamp unit should be done at the power off state and recommended clean bench

condition.

3-3 Reassembly

Reassembly procedures are in the reverse order of Disassembly procedures.

3-2 RB17AS/RB17NS

4 Alignments and Adjustments

4-1 General Alignment Instuction

1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation.

Check the basic characteristics such as height, horizontal and vertical sync.

2. Use the specified test equipment or its equivalent.

3. Correct impedance matching is essential.

4. Avoid overload. Excessive signal from a sweep generator might overload the front-end

of the TV. When inserting signal markers,do not allow the marker generator to distort

test result.

5. Connect the TV only to an DC power source with voltage and frequency as specified on

the backcover nameplate.

6. Do not attempt to connect or disconnect any wire while the TV is turned on. Make sure

that the power cord is disconnected before replacing any parts.

7. To protect aganist shock hazard,use an isolation transform.

RB17AS/RB17NS 4-1

5 Troubleshooting

5-1 No Power

Does proper DC 12 V appear at

DC jack connected to CN117?

Yes

Does proper DC 5 V appear at

Pin 1 of IC118?

Yes

Does proper DC 12V appear at

Pin 2 of IC109?

Yes

Does proper DC 3.3 V appear at

Pin 1 of IC120?

Check SMPS PCB and Adapter.

Check IC118.

Check IC109.

Check IC120.

Yes

Does proper DC 2.5 V appear at

Pin 3 of IC120?

Yes

Check IC122.

RB17AS/RB17NS 5-1

Check IC120.

5-2 No Video (PC Signal)

Power indicator is green.

Does the signal appear at

Pin 7, 15, 22, of IC134?

Yes

Does the clock pulse appear at

Pin 115, 117 of IC134?

Yes

Does the clock pulse appear at

output of RA100 ~ RA105?

Yes

Does the clock pulse appear at

Pin 37 ~ 48 of IC106?

Check R490, R491, R492,

C437, C439, C441.

Check IC134 and related circuit of IC134.

Check related circuit of IC119.

Check IC106 and related circuit of IC106.

Yes

Does the clock pulse appear at

output of FT105 ~ 114?

Yes

Replace LCD Panel.

5-2 RB17AS/RB17NS

Replace FT105 ~ FT114.

5-3 No Picture (TV, Video 1, Video 2)

Check Pin 9 (5V_TUNER)

of CN113.

Yes

Check Pin 1 (RF_CVBS) of CN113.

Yes

Check IC121 (VPC3230D).

Yes

Check IC119 (PW364A) and

replace mainboard.

Check CN137 and related circuit of IC137.

Replace Tuner.

Check related circuit of IC121

and replace IC121.

RB17AS/RB17NS 5-3

5-4 No Sound

Does the Low signal at

Pin 16 of IC151?

Yes

Check Pin 10 and 13 of

IC151(TA1101B)?

Yes

Check Pin 67 of

IC112 (MSP3451 or 21)?

Yes

Check CN113 and tuner and

related circuit of CN113 and tuner.

Check Pin 4 of CN121

and Headphone output.

Replace IC151.

Replace IC112 (MSP3451 or 21).

5-4 RB17AS/RB17NS

5-5 No Picture (DTV [NTSC only])

Power inductor is green.

Yes

Does the signal appear at

Pin 3, 9, 15 of IC132?

Yes

Dose the signal appear at Pin

88(R447) of IC132?

Yes

Dose the clock pulse appear at

output of RA110 ~ RA117?

Yes

Does the clock pulse appear at

Pin 37 ~ 48 of IC106?

Check R554, R555, R556, C447, C450,

C451, C494, C495, C496, C448, C449, C452.

Check IC132 and related circuit of IC132.

Check related circuit of IC113.

Check IC106 and related circuit of IC106.

Yes

Does the clock pulse appear at

output of FT105 ~ FT114?

Yes

Replace LCD Panel.

RB17AS/RB17NS 5-5

Replace

FT105 ~ FT114.

7 Electrical Parts List

7-1 RB17AS Main PCB Parts

Loc. No. Code No. Description Specification Remarks

- BN91-00033E PROCESS RB17AS,-,-,C138 2409-001004 C-ORGANIC 100uF,20%,16V,LL,BK,8x10.5mm,3 C197 2409-001004 C-ORGANIC 100uF,20%,16V,LL,BK,8x10.5mm,3 C339 2409-001004 C-ORGANIC 100uF,20%,16V,LL,BK,8x10.5mm,3 CIS 0201-001223 ADHESIVE-TS HT-130S,RED,700+/- 50,CIS BN63-00048A GASKET-EMI RB17AS,-,3MM,13MM,142MM,-,-,EMI SNA CIS BN70-00181A SHIELD-D/SUB RB17AS,SPTE,-,0.5,-,-,- SNA CIS BN46-00007W MICOM-S/W,REMBRANT17 RB17AS(REMBRANT),-,-,-,-,-,- SNA CN100 3711-000057 CONNECTOR-HEADER BOX,3P,1R,2.5mm,ANGLE,SN SNA CN107 3711-004270 CONNECTOR-HEADER BOX,2P,1R,2MM,ANGLE,SN SNA CN108 3711-004386 CONNECTOR-HEADER BOX,3P,1R,2mm,ANGLE,SN SNA CN113 3701-001227 CONNECTOR-DSUB 15P,3R,FEMAIL,STRAIGHT,AU CN116 3701-001219 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF CN117 3722-000117 JACK-DC POWER 3P,3.5mm,AG,BLK,NO SNA CN120 3722-001055 JACK-PHONE 5P/2C,3.6mm,AG,BLK,#16-22 SNA IC103 0903-001194 IC-MICROCONTROLLER IC103_SOCK 3704-001071 SOCKET-IC 42P,DIP,SN,1.778mm BD1 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm SNA BD2 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm SNA BD3 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm SNA C100 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C101 2203-001077 C-CERAMIC,CHIP 0.056nF,5%,50V,NP0,TP,2012 C103 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C104 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C108 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C111 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C112 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C113 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C115 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C116 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C118 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C120 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C121 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C122 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C134 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C140 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C141 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C142 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C150 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C152 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C155 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C157 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C163 2203-000972 C-CERAMIC,CHIP 47nF,10%,16V,X7R,TP,1608 C164 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C165 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608

3P863,8Bit,SDIP,42P,600MIL,12MHz,ST,CMOS,PLASTIC,5V,-,-40to+85C,1040BYTE,48KBYTE

SNA

RB17AS/RB17NS 7-1

Loc. No. Code No. Description Specification Remarks

C166 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C167 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C168 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C169 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C170 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C171 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C172 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C173 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C174 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C175 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C176 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C177 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C178 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C179 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C180 2203-000716 C-CERAMIC,CHIP 3.3nF,10%,50V,X7R,TP,2012,C181 2203-000716 C-CERAMIC,CHIP 3.3nF,10%,50V,X7R,TP,2012,C182 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C183 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C184 2203-001607 C-CERAMIC,CHIP 0.22nF,5%,50V,NP0,TP,1608 C185 2203-001656 C-CERAMIC,CHIP 0.47nF,5%,50V,NP0,TP,1608 C186 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C187 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C188 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C189 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C190 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,C191 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,C192 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C193 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C194 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C195 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C196 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C198 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C199 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C200 2203-000701 C-CERAMIC,CHIP 0.002nF,0.25pF,50V,NP0,TP,2012 C201 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C202 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C203 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C204 2203-001077 C-CERAMIC,CHIP 0.056nF,5%,50V,NP0,TP,2012 C205 2203-001077 C-CERAMIC,CHIP 0.056nF,5%,50V,NP0,TP,2012 C206 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C207 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C208 2203-000701 C-CERAMIC,CHIP 0.002nF,0.25pF,50V,NP0,TP,2012 C209 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C210 2203-001656 C-CERAMIC,CHIP 0.47nF,5%,50V,NP0,TP,1608 C211 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C212 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C213 2203-001077 C-CERAMIC,CHIP 0.056nF,5%,50V,NP0,TP,2012

7-2 RB17AS/RB17NS

Loc. No. Code No. Description Specification Remarks

C215 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C216 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C217 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C218 2409-001029 C-ORGANIC 120uF,20%,6.3V,WT,TP,10.3x10.3x10.3mm,9 C219 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C220 2203-001656 C-CERAMIC,CHIP 0.47nF,5%,50V,NP0,TP,1608 C222 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C223 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C224 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C225 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C226 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C227 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C228 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C229 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C230 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C231 2402-000144 C-AL,SMD 3.3uF,20%,50V,GP,TP,4.3x4.3x5. C232 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C233 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C234 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C235 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C236 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C237 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C238 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C239 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C243 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C247 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C248 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C249 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C250 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C251 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C252 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C253 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C254 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C255 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C256 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C257 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C258 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C260 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C261 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C263 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C264 2203-000989 C-CERAMIC,CHIP 47nF,10%,50V,X7R,TP,2012 C265 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C266 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4 C267 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4 C268 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C269 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C270 2203-000784 C-CERAMIC,CHIP 0.33nF,5%,50V,NP0,TP,2012

RB17AS/RB17NS 7-3

Loc. No. Code No. Description Specification Remarks

C271 2203-001630 C-CERAMIC,CHIP 330nF,+80-20%,16V,Y5V,TP,1608 C273 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C274 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C276 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C278 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C279 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C280 2203-001630 C-CERAMIC,CHIP 330nF,+80-20%,16V,Y5V,TP,1608 C281 2203-001140 C-CERAMIC,CHIP 68nF,10%,16V,X7R,TP,1608,C282 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C284 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C285 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C286 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C287 2203-000784 C-CERAMIC,CHIP 0.33nF,5%,50V,NP0,TP,2012 C288 2203-001140 C-CERAMIC,CHIP 68nF,10%,16V,X7R,TP,1608,C289 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C290 2203-001140 C-CERAMIC,CHIP 68nF,10%,16V,X7R,TP,1608,C291 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C292 2203-002442 C-CERAMIC,CHIP 330nF,+80-20%,25V,Y5V,TP,2012 C293 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C294 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C295 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C296 2203-000972 C-CERAMIC,CHIP 47nF,10%,16V,X7R,TP,1608 C297 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C298 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C299 2203-000839 C-CERAMIC,CHIP 0.39nF,5%,50V,NP0,TP,2012 C300 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C301 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C302 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C303 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C304 2203-000491 C-CERAMIC,CHIP 2.2nF,10%,50V,X7R,TP,1608,C305 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C306 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C307 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C308 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C309 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C310 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C311 2402-000179 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 C312 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C313 2203-000972 C-CERAMIC,CHIP 47nF,10%,16V,X7R,TP,1608 C314 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C315 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C316 2409-001029 C-ORGANIC 120uF,20%,6.3V,WT,TP,10.3x10.3x10.3mm,9 C317 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C318 2203-000972 C-CERAMIC,CHIP 47nF,10%,16V,X7R,TP,1608 C319 2203-000140 C-CERAMIC,CHIP 1.5nF,10%,50V,X7R,TP,1608,C320 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C321 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608

7-4 RB17AS/RB17NS

Loc. No. Code No. Description Specification Remarks

C322 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C323 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C324 2203-000839 C-CERAMIC,CHIP 0.39nF,5%,50V,NP0,TP,2012 C326 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C327 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C329 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C330 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C331 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C332 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C334 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C335 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C336 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C337 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C338 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C340 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C341 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4 C342 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C343 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C345 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C346 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C347 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C348 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C349 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C350 2402-000179 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 C351 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C352 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C353 2402-000144 C-AL,SMD 3.3uF,20%,50V,GP,TP,4.3x4.3x5. C354 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C355 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C357 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C358 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C359 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C360 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C361 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C366 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C367 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C368 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C374 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C381 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C382 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C383 2203-000815 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1608 C384 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C385 2203-000843 C-CERAMIC,CHIP 39nF,10%,25V,X7R,TP,1608,C387 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C388 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C390 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C393 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608

RB17AS/RB17NS 7-5

Loc. No. Code No. Description Specification Remarks

C395 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C396 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C397 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C398 2203-000726 C-CERAMIC,CHIP 3.9nF,10%,50V,X7R,TP,1608,C403 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C404 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C405 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C406 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C407 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C408 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C409 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C410 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C411 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C412 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C414 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C415 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C424 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C425 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C426 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C427 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C428 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C432 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C436 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C437 2203-002526 C-CERAMIC,CHIP 56nF,10%,25V,X7R,BK,1608,C438 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C439 2203-002526 C-CERAMIC,CHIP 56nF,10%,25V,X7R,BK,1608,C440 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C441 2203-002526 C-CERAMIC,CHIP 56nF,10%,25V,X7R,BK,1608,C442 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C443 2409-001029 C-ORGANIC 120uF,20%,6.3V,WT,TP,10.3x10.3x10.3mm,9 C444 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C445 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C446 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C453 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C454 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C457 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C459 2203-001158 C-CERAMIC,CHIP 0.068nF,5%,50V,NP0,TP,2012 C460 2203-001158 C-CERAMIC,CHIP 0.068nF,5%,50V,NP0,TP,2012 C461 2203-001630 C-CERAMIC,CHIP 330nF,+80-20%,16V,Y5V,TP,1608 C462 2203-001630 C-CERAMIC,CHIP 330nF,+80-20%,16V,Y5V,TP,1608 C463 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C468 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C469 2203-001402 C-CERAMIC,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 C470 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C471 2203-000784 C-CERAMIC,CHIP 0.33nF,5%,50V,NP0,TP,2012 C472 2203-000784 C-CERAMIC,CHIP 0.33nF,5%,50V,NP0,TP,2012 C475 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm

7-6 RB17AS/RB17NS

Loc. No. Code No. Description Specification Remarks

C476 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C478 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C488 2203-001088 C-CERAMIC,CHIP 0.005nF,0.25pF,50V,NP0,TP,2012 C489 2203-001088 C-CERAMIC,CHIP 0.005nF,0.25pF,50V,NP0,TP,2012 C490 2203-001088 C-CERAMIC,CHIP 0.005nF,0.25pF,50V,NP0,TP,2012 C491 2203-001088 C-CERAMIC,CHIP 0.005nF,0.25pF,50V,NP0,TP,2012 C497 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C498 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C499 2203-000903 C-CERAMIC,CHIP 0.0047nF,0.25pF,50V,NP0,TP,1608 C501 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C502 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C503 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C504 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C505 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C506 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C507 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C508 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C509 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C510 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C511 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C512 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C513 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C514 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C515 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C516 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C526 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C527 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C528 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C529 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C530 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C531 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C532 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm C533 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C534 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C535 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C536 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C537 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C538 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C539 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C540 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C541 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C542 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C543 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C544 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C545 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C546 2203-005189 C-CERAMIC,CHIP 680nF,+80-20%,16V,Y5V,TP,2012, C547 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608

RB17AS/RB17NS 7-7

+ 55 hidden pages
