Samsung R810 User Manual
Samsung R810
(SCH-R810 Series)
PORTABLE TRI-BAND
MOBILE PHONE
User Manual
Please read this manual before operating your
phone, and keep it for future reference.
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to
the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to
Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited
to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation
and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or
otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All
applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.
Samsung Telecommunications America (STA), LLC
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein St.
Richardson, TX 75082 Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Internet Address: http://www.samsungusa.com
©2009 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc. and its related
entities.
Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsungwireless.com/support
R810_CC25_MM_033009_F4
GH68-22546A
Printed in Korea.
T9 Text Input is licensed by Tegic Communications and is covered by U.S. Pat. 5,818,437; U.S. Pat. 5,953,541; U.S. Pat. 6,011,554 and
other patents pending.
Nuance®, VSuite™ and the Nuance logo are trademarks or registered trademarks of Nuance Communications, Inc. or its affiliates in the
United States and/or other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are registered
trademarks and are wholly owned by the Bluetooth SIG.
microSD™ and the microSD logo are Trademarks of the SD Card Association.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE
WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
Table of Contents
Section 1: Getting Started .............................................. 4
Understanding this User Manual . . . . . . . . . . . . . . . . . . . . . . . .4
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting Up Your Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Memory Card (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Section 2: Understanding Your Phone ......................... 10
Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Side Views of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Command Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Understanding the Display Screen . . . . . . . . . . . . . . . . . . . . .14
Your Phone’s Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Section 3: Call Functions .............................................20
Making a Call — Number Entry Dialing . . . . . . . . . . . . . . . . . . 20
Making a Call — Contact Dialing . . . . . . . . . . . . . . . . . . . . . . 21
Making a Call — Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . 22
Making a Call — Voice Dialing . . . . . . . . . . . . . . . . . . . . . . . . 23
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Ignoring a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Adjusting the Call Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Calls Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1
Section 4: Menu Navigation ......................................... 34
Main Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using the Widget Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
The In-Use Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using Shortcuts Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Section 5: Understanding Your Contacts ....................38
Your Contacts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Adding a New Contacts Entry . . . . . . . . . . . . . . . . . . . . . . . . . 38
Finding a Contacts Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Editing an Existing Contact Entry . . . . . . . . . . . . . . . . . . . . . . 44
Speed Dial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Renaming a Contacts Group . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Deleting a Contacts Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Sending a Contacts Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Section 6: Entering Text ............................................... 52
Changing Text Entry Screens . . . . . . . . . . . . . . . . . . . . . . . . . 52
Changing the Text Entry Mode . . . . . . . . . . . . . . . . . . . . . . . . 55
Using T9® Mode (Phone Keypad Only) . . . . . . . . . . . . . . . . . . 56
Using Abc Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Entering Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Entering Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Section 7: Messaging ................................................... 59
Creating and Sending New Messages . . . . . . . . . . . . . . . . . . 59
Message Sending Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Receiving New Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Message Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Erasing Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Message Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
RemoMail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Section 8: Downloads (Brew) ......................................73
Launching Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Applications Shopping and Downloading (Brew) . . . . . . . . . . . 73
Changing Your Downloads Settings . . . . . . . . . . . . . . . . . . . . 73
Using On-line Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Section 9: WEB .............................................................76
Browser Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Launching the Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Using Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Using Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Web Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Launching Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Using the Web Application . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Using Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
How the Buttons Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Section 10: Multimedia ................................................79
Accessing Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
My Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
My Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
My Ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
My Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Section 11: Tools .......................................................... 86
Accessing Your Phone’s Tools . . . . . . . . . . . . . . . . . . . . . . . . 86
Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Memo Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
World Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Stop Watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Tip Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Section 12: Changing Your Settings .......................... 106
Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Widget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Sounds Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Memory Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
2
Section 13: Camera-Camcorder ................................126
Taking Pictures and Videos . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Taking Snap Shots (Single Pictures) . . . . . . . . . . . . . . . . . . . 126
Screen Layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Saving Pictures and Videos . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Camera Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Camera Settings — Camera Tab . . . . . . . . . . . . . . . . . . . . . 134
Camera Settings — Common Tab . . . . . . . . . . . . . . . . . . . .136
Camcorder Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Settings — Camcorder Tab . . . . . . . . . . . . . . . . . . . . . . . . . 139
Camcorder Settings — Common Tab . . . . . . . . . . . . . . . . . .140
The Photo Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Point, Click, and Send Pictures and Videos . . . . . . . . . . . . . . 144
Section 14: Music Player ............................................146
Accessing the Music Player . . . . . . . . . . . . . . . . . . . . . . . . .146
Section 15: Applications ............................................151
RealtoneVIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
RemoMail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Facebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Section 16: Video Player ............................................152
Launching the Video Player . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Video Player Controls (Portrait Mode) . . . . . . . . . . . . . . . . . . 153
Video Player Controls (Full Screen Mode) . . . . . . . . . . . . . . . 154
Section 17: Phone Info ...............................................155
Phone Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Icon Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
3
Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Section 18: Health and Safety Information ............... 156
Health and Safety Information . . . . . . . . . . . . . . . . . . . . . . . 156
Samsung Mobile Products and Recycling . . . . . . . . . . . . . . . 157
UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Consumer Information on Wireless Phones . . . . . . . . . . . . . . 158
Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Responsible Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Using Your Phone Near Other Electronic Devices . . . . . . . . . 167
FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless
Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Potentially Explosive Environments . . . . . . . . . . . . . . . . . . . . 169
Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Other Important Safety Information . . . . . . . . . . . . . . . . . . . . 171
Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Availability of Various Features/Ring Tones . . . . . . . . . . . . . . 172
Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . . . . . 173
Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Section 19: Warranty Information ............................. 176
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 176
End User License Agreement for Software . . . . . . . . . . . . . . 179
Index ............................................................................ 184
Section 1: Getting Started
This section explains how to start using your Samsung phone by
activating your service, setting up your Voicemail, or getting an
understanding of how this manual is put together.
Understanding this User Manual
The chapters of this manual generally follow the same order as
the menus and sub-menus in your phone. A robust index for
quick reference to most features begins on page 184.
Also included is important safety information that you should
know before using your phone. Most of this information is near
the back of the guide, beginning on page 156.
Notes and Tips
Throughout this manual some text is set apart from the rest. In
this way, important information, quick methods for activating
features, to define terms, and more are emphasized. The
definitions for these methods are as follows:
•
Notes
— Explain alternative options within the current feature, menu,
or sub-menu.
•
Tips
— Provide quick or innovative methods for performing functions
related to the subject at hand.
•
Important
— Points out important information about the current
feature that could affect performance, or even damage your phone.
Text Conventions
This manual provides condensed information about how to use
your phone. To make this possible, the following terms and icon
appear in place of repeatedly-used procedural steps:
select
Touch a menu item or screen item to launch, access,
or save a highlighted menu item or screen field of
interest.
➔ Used in place of “select” in long “drill down”
procedure steps.
Example:
“...
Settings
➔
Call Settings
➔
Call Answer
...”
Charging the Battery
Your phone is powered by a rechargeable standard Li-Ion battery.
Only use Samsung-approved charging devices and batteries.
Samsung accessories are designed to maximize battery life. Use
of other accessories may invalidate your warranty and may
cause damage.
Getting Started 4
Use the Travel Adapter
Incorrect
Correct
The travel adapter included
with your phone is a
convenient, light-weight
charger that rapidly charges
your phone from any 120/220
VAC outlet.
1. Plug the large end of the Travel Adapter into a standard
120 VAC or 220 VAC wall outlet.
Important!:
For connection to an electrical supply not located in North
America, you must use an adapter of the proper configuration for
the power outlet. Use of the wrong adapter could damage your
phone and void your warranty.
2. Insert the smaller end of the Travel Adapter into the
charger/accessory connector at the bottom end of your
phone.
5
Caution!:
The touch screen responds best to a light touch from either a finger
or a non-metallic stylus. Using excessive force or a metallic object
when pressing the touch screen may damage the tempered glass
surface and void the warranty noted (For more information, refer to
“Standard Limited Warranty” .)
Important!:
You must unplug the adapter before removing the battery from
the phone during charging to avoid damage.
Low battery indicator
The battery indicator ( ) in the upper-right corner of the
display indicates power level. Monitor the battery strength and
ensure your battery is adequately charged.
•
Five bars ( ) indicate a full charge.
•
An empty battery icon ( ) indicates a near empty battery.
•
A blinking empty battery icon ( ) and a tone sounding indicate
you have two to three minutes before the battery is too low to operate
the phone.
If you continue to use your phone without charging its battery, the
phone will shut down.
Activating Your Phone
Contact your Wireless Carrier and follow their instructions for
obtaining service, if necessary. We suggest that you read this
guide to fully understand the services your phone supports.
Install the Battery
Note:
Your phone comes packaged with a partially charged rechargeable
standard Li-Ion battery and travel adapter.
Important!:
You must fully charge the battery the first time you use your
phone, otherwise you could damage the battery. From fully
discharged to fully charged, the battery requires up to 4 hours of
charge time.
1. Insert the bottom end of
the battery first,
matching the gold
contacts on the inside of
the battery to those on
the phone.
2. Press lightly on the top end of the battery down into the
phone until it slips into place.
3. Place the battery cover
over the battery (1) and
slide the battery cover up
into place (2).
Remove the Battery
1. Press and hold to turn off the phone (if on).
2. Press down on the
battery cover (1), slide the
cover toward the bottom
end of the phone, then lift
it the cover (2) away from
the phone.
3. Lift the battery up (1) and
away (2) from the phone,
top end first.
Getting Started 6
Turn Your Phone On
LOCKLOC
K
Antenna
1. Press and hold the LOCK key
( ), on the top of the
phone.
Note:
As with any other radio-transmitting
device, do not touch the antenna (at the
bottom of the device) while using your
phone as this can affect call quality and
can cause the phone to operate at a higher
power level than is necessary.
2. The phone begins searching for a
network signal.
3. Once the phone finds a signal, the
time, date, and day appear in the
second line of the display.
4. You’re now ready to place and
receive calls.
7
Note:
If you are outside of your carrier’s coverage or roaming area, the No
Service icon ( ) appears at the top of the phone’s display. If you
cannot place or receive calls, try later when service is available, or at
another location.
Turn Your Phone Off
䊳
Press and hold the LOCK key ( ), on the top of the
phone, for two or more seconds. Your phone powers off.
Note:
If your phone is on and you press for less than one second, the
phone will not power off. This prevents your phone from being turned
off accidentally.
Setting Up Your Voicemail
Voicemail allows callers to leave voice messages, which can be
retrieved any time.
Note:
Once your Voicemail account has been set up, you can use the
Voicemail folder (under the Message menu) to view details of voice
messages in your Voicemail box.
1. In standby mode, touch the
Dialer
soft key, then touch and
hold or dial your own mobile number to dial
Voicemail. (For more information, refer to “Making a Call
— Number Entry Dialing” on page 20.)
Follow the prompts in the new user tutorial to setup your
2.
mail box.
Listen to Voicemail
1. In standby mode, touch the
Dialer
soft key, then touch and
hold or dial your own mobile number to dial
Voicemail. (For more information, refer to “Making a Call
— Number Entry Dialing” on page 20.) After connecting,
you will hear your voice greeting.
2. You are prompted to enter your password.
Memory Card (Optional)
You can install a microSDTM card to provide additional memory
for storing files (such as, sound files and photos) in your phone.
Install a Memory Card
1. Open the microSD cover on the right hand side of the
phone, as shown.
Incorrect
Correct
2. Make sure that the gold contacts of the card are face
down, as shown, then carefully slide the memory card into
the memory card slot until you feel it click into place.
3. Replace the microSD cover.
Remove a Memory Ca rd
1. Open the microSD cover on the right hand side of the
phone.
2. Carefully press the memory card inward until you feel it
release.
Getting Started 8
3.
Slowly release your pressure on the card. It will slide
outward a short distance.
4. Remove the memory card from the memory card slot.
5. If desired, install another memory card. (For more
information, refer to “Install a Memory Card” .)
6. Replace the microSD cover.
9
Section 2: Understanding Your Phone
This section outlines some key features of your phone. It also
describes the screen format and the icons that will be displayed
when the phone is in use.
Features of Your Phone
•
Full-screen Touch Screen [high-resolution (240 x400 pixels), color]
•
Widget menu
•
Full-HTML Browser
•
Messaging (Text, Picture, Video, and E-mail) with QWERTY Touch
Keypad
•
2.0 Megapixel wide screen Camera-Camcorder
•
High speed data (EVDO)
•
Bluetooth® Stereo (v2.0) Wireless Technology (see Note)
•
Global Positioning (GPS) Technology
•
PIM Functions
•
Voice and Touch Keypad Dial
•
Music (MP3) Player and Video (MP4) Player
•
Memory Card slot (for optional microSD™ cards)
Note:
Your phone supports the wireless hands-free profile and the serial port
profile for Bluetooth® v2.0 wireless technology. Your phone does not
support Bluetooth OBEX profiles.
Side Views of Your Phone
Features
1.
Headset Connector
— Used to connect an optional wired
headset or TTY device to your phone.
10
11
12
Understanding Your Phone 10
2.
Power / Accessory Connector
— Used to connect charging
accessories or any available accessory cables to your
phone.
3.
Volume Key
— Lets you adjust the ring volume in standby
mode, adjust the voice volume during a call, or mute the
ringer during an incoming call.
4.
Send Key
— Lets you place or receive a call. In standby
mode, press the key once to access the Recent Calls log.
5.
Clear Key
— Deletes characters from the display when you
are in text entry mode. Press this key to return to the
previous menu or screen when navigating features on your
phone.
6.
Display
— Indicates the status of your phone (including
numbers dialed, feature and function screens, status
icons, message indicators and contents, signal strength,
and so on) and shows all touch controls (hot buttons,
keypads, and menus).
7.
Earpiece / Speaker
— Lets you hear ringing and alert
tones, alarm tones, and the other parties to calls.
11
8.
Power On-Off/LOCK
key — Turns the power on and off.
Locks and unlocks the keys and the touch screen and
lights the backlight.
9.
Memory Card Slot
— Used to plug in an optional
microSD™ memory card for additional multimedia file
storage.
10.
Voice Recognition Key
— Used to launch VoiceSignal voice
recognition system.
11.
Camera Key
— Launches the Camera-Camcorder feature
of your phone and takes pictures or records videos.
12.
End Key
— Ends a call. Returns you to standby mode from
any feature, function, or menu.
Front View of Your Phone
Features
1.
Earpiece / Speaker
— Lets you hear ringing and alert
tones, alarm tones, and the other parties to calls.
2.
Volume Key
— Lets you adjust the ring volume in standby
mode, adjust the voice volume during a call, or mute the
ringer during an incoming call.
3.
Display
— Indicates the status of your phone (including
numbers dialed, feature and function screens, status
icons, message indicators and contents, signal strength,
and so on) and shows all touch controls (hot buttons,
keypads, and menus).
4.
Send Key
— Lets you place or receive a call. In standby
mode, press the key once to access the recent calls log.
5.
Clear Key
— Deletes characters from the display when you
are in text entry mode. Press this key to return to the
previous menu or screen when navigating features on your
phone.
6.
Microphone
— Lets the other caller hear you clearly when
you are speaking to them.
7.
End Key
— Ends a call. Returns you to standby mode from
any feature, function, or menu.
8.
Camera Key
— Launches the Camera-Camcorder feature
of your phone and takes pictures or records videos.
Understanding Your Phone 12
9.
Voice Recognition Key
recognition system.
Rear View
1.
Camera Lens
13
— Used to launch VoiceSignal voice
— The lens of your built-in camera.
2.
Mirror
— Helps you take self-portrait photos.
3.
Battery Cover
4.
Camera Key
— Protects the battery.
— Launches the Camera-Camcorder feature
of your phone and takes pictures or records videos.
Command Keys
Power On-Off/LOCK key
•
Press and hold the Power On-Off/LOCK key ( ) to turn your
phone on or off.
•
With the phone keys and touch screen locked, press and hold the
Power On-Off/LOCK key ( ) to unlock the phone.
Note:
With the phone locked, you can still answer incoming calls by pressing
the Talk key.
Volume Key
•
In standby mode, press the Volume key on the upper left side of the
phone Up or Down to adjust the volume of the incoming calls ringer.
•
When receiving a call, press the Volume key Up or Down to mute the
ringer.
•
During a call, press the Volume key Up or Down to adjust the voice
volume in the Earpiece-Speaker.
•
When playing a music file or video clip, press the Volume key Up or
Down to adjust the playback volume.
Soft Keys
Functions for the soft keys are defined by what appears above
each in the display. There are four soft keys across the bottom of
the display.
Send Key
The Send key ( ) is used to answer calls, dial calls, and to
recall the last number(s) dialed, received, or missed.
•
Press once to answer calls.
•
Enter a number and briefly press to make a call.
•
Briefly press in standby mode to display a list of recent calls to
and from your phone.
•
Press twice in standby mode to call the most recent number.
•
Press to pick up a waiting call. Press again to switch back
to the other call.
Clear Key
The Clear key ( ) is used to erase or clear numbers, text,
or symbols from the display. You can also use the key to return to
a previous menu or to return to standby mode from any menu.
•
If you enter an incorrect character, briefly press to
backspace (and delete) the character.
•
To erase the entire sentence, press and hold .
•
To return to the previous menu level, briefly press .
End Key
•
Briefly press once to disconnect a call.
•
Press to return to standby mode from any menu, or to cancel the
last input.
Camera Key
Use the Camera key on the right side of the phone to launch the
Camera function on your phone by pressing and holding this key.
Understanding the Display Screen
1. The top line of your
phone’s display contains
icons that indicate
network status, battery
power, signal strength,
connection type, and
more.
2. Tapping the left side of
the display opens the
Widget Bar that lists
available shortcut
widgets.
Understanding Your Phone 14
3.
The bottom line of the display shows available soft keys.
The sample screen shows the following soft keys:
• Dialer
— Launches the Dialer screen that lets you place calls.
•Contacts
— Launches the
•Messages
•Menu
4. The center portion of the display shows information such
— Launches the
— Launches the Main Menu.
Contacts
Messages
list screen.
menu.
as call progress information, messages, and photos.
5. Tapping the top line of the display pulls down a four-icon
shortcut bar. To hide the four-icon shortcut bar, tap
anywhere on the screen below the shortcut bar.
Display Screen Icons
Your phone can show you definitions of the icons that appear on
the top line of the display.
To access the Icon Glossary:
䊳
In standby mode, press
Phone Info
➔
Menu
Icon Glossary
, then touch
Settings
➔
. A list appears showing the
icons that can appear on the top line of the displays.
15
Dialogue Boxes
Dialogue boxes prompt for action, inform you of status, or warn
of situations such as low battery. Dialogue boxes and their
definitions are outlined below.
•
Choice
–
Example:
“Save Message?”
•
Reconfirm
–
Example:
“Erase All Messages?”
•
Performing
–
Example:
“Sending...” “Connecting...”
•
Completed
–
Example:
“Message Saved”
•
Information
–
Example:
“New Message”
•
Error
–
Example:
“System Error!”
•
Warning
–
Example:
“Low Battery,” “Memory Full!”
Backlight
The backlight illuminates the display. It goes off when the screen
and phone keys are not pressed within a period of time set in the
Backlight Time
menu. The backlight turns on when you press a
key.
Note:
During a phone call, the display backlight dims and turns off after 10
seconds to conserve battery power, regardless of the Backlight Time
setting.
(For more information, refer to “Backlight” on page 109.)
Your Phone’s Modes
Call Answer Mode
You can choose to answer a call by pressing any key except
or , or by pressing only the key. (For more
information, refer to “Call Answer” on page 113.)
Input Mode
Input mode determines how you enter text, numbers, and
symbols. While at any text entry screen, press the down arrow in
the upper left corner of the screen, then select the input mode
from the drop-down menu. Optional input modes are:
•
3X4Keypad
(phone-style touch keypad)
•
QWERTY
(full touch keypad — changes display to landscape mode)
•
Handwriting box
•
Handwriting full screen
(divided pallet)
(undivided pallet)
(For more information, refer to “Changing the Text Entry Mode”
on page 55.)
Tip:
When using the 3X4Keypad mode, you can also choose between
ABC, T9 Word
, and
123
by pressing the
Entry Mode
soft key.
Abc
Lock Mode
When the phone is in Lock Mode, restrictions are placed on
phone use. You can receive calls and messages, but cannot place
outgoing calls (except for emergency numbers) until you unlock
the phone. Lock Mode also restricts access to menus and the
Volume key.
To enter Lock Mode:
䊳
In standby mode, press
on the top of the
phone. The lock mode screen
appears momentarily in the
display, then the screen goes
dark.
To exit Lock Mode:
䊳
While in Lock mode, press
and hold until the
standby mode screen
appears in the display.
Understanding Your Phone 16
/
(For more information, refer to “Change Lock Code” on
page 117.)
Standby Mode
Standby mode is the state of the phone once it has found service
and is idle. The phone goes into standby mode:
•
After you power the phone on.
•
When you press the End key after a call or from within a menu.
In standby mode, you will see the time, day, and date as well as
all phone status icons.
Place Calls in Standby Mode
1. In standby mode, enter a phone number, and press
to place a call.
2. Press to return to standby mode.
Receive Messages in Standby Mode
While your phone is in standby mode, new incoming messages
automatically appear in the screen as they are received. Use the
Navigation key to scroll through text or to view complete images.
Talk Mode
You can place and receive calls only when your phone is on.
While in a call, your phone is in talk mode. Press the
Clear
key to
display a list of menu options. (For more information, refer to
“The In-Use Options” on page 35.)
17
Enter/Exit Silent Mode
Silences the ringers, the alerts, and the tones your keypad makes
when you press a key.
To enter Silent Mode:
䊳
In standby mode, repeatedly press the Volume key
( ) Down until “
To exit Silent Mode:
䊳
While in Silent mode and standby mode, repeatedly press
the Volume key ( ) Up until “
Silence All
” appears in the display.
Silence All
”
disappears from the display and the desired ringer value
appears.
Vibrate Mode
䊳
In standby mode, repeatedly press the Volume key
( ) down until “
Vibrate only
” appears in the
display.
Note:
The Volume key is on the left side of phone.
Adjust the Ringer
To adjust the Ringer volume, while in standby mode, press the
Volume key up or down.
䊳
In standby mode, press the Volume key up or down to set
the call ringer volume as desired.
Options are:
• Silence All • Low/Medium
• Alarm only • Medium
• Vibrate only • Medium/High
•1 Beep •High
•Low
Note:
The Vibrate icon ( ) appears in the display when the phone is in
Vibrat e
mode. The No Ring icon ( ) appears in the display when the
phone is in
Silence All
mode.
Music Player Mode
The Music Player in your phone can play music files (MP3), but
only if they are stored in the My Music folder on an optional
microSD Memory Card.
Note:
For more information, refer to “Memory Card (Optional)” on page 8.
•
Entering Music Player Mode:
–
In standby mode, display the shortcut menu by selecting the status bar
at the top of the display, then touch ( ).
– or –
–
In standby mode, press the
Menu
soft key, then touch
Music Player
Note:
For more information, refer to “Music Player” on page 146.
•
Exiting Music Player Mode
— Press .
Camera Mode
Camera mode lets you take pictures with your phone’s camera.
In Camera mode, you can also adjust the resolution and
appearance of your pictures.
For more information, refer to “Camera-Camcorder” on
page 126.
•
Entering Camera Mode:
–
In standby mode, press and hold the Camera key ( ) — on the
right side of the phone.
–
In standby mode, press the
Camera
.
–
In Camcorder mode, touch .
•
Exiting Camera Mode
Menu
soft key, then touch
— Press .
Camcorder Mode
Camcorder mode lets you record videos with your phone’s
camera. In Camcorder mode, you can also adjust the resolution
and appearance of your videos.
For more information, refer to “Camera-Camcorder” on
page 126.
.
Understanding Your Phone 18
Multimedia
➔
•
Entering Camcorder Mode:
–
In standby mode, press and hold the Camera key ( ) — on the
right side of the phone — then, select .
–
In standby mode, press the
Camcorder
–
•
Exiting Camcorder Mode
.
In Camera mode, press .
Menu
soft key, then touch
— Press the key.
Multimedia
Video Player Mode
The Video Player in your phone can play video files [3GS, MP4,
H.263, and H.264 (Decoding: QCIF Only)], but only if they are
stored in the My Video folder in the phone or on an optional
microSD Memory Card.
Note:
For more information, refer to “Memory Card (Optional)” on page 8.
•
Entering Video Player Mode:
1. In standby mode, press
Videos
.
Menu
, then touch
Multimedia
– or –
In camcorder mode, press .
A list of thumbnail images appears in the display.
2. Tap the thumbnail icon to view the thumbnail images.
19
➔
3. Select the desired video. The Video Player screen appears
in the display and begins playing the highlighted video.
➔
Note:
For more information, refer to “Video Player” on page 152.
Speakerphone Mode
Lets you use your phone handsfree and/or lets you share a call
with other people nearby.
To enter Speakerphone Mode during a call:
1. During a call, press LOCK key ( ), at the top of the
phone, or press .
2. Press the
Speaker on
changes color from black to blue, and the other party can
be heard through the speaker.
Caution!:
My
Keep the phone away from you ear while in Speakerphone Mode.
(For more information, refer to “Responsible Listening” on
page 165.)
To exit Speaker Mode:
䊳
During a call using Speakerphone mode, press the
on
key ( ). The Speaker on icon changes color to black
and the other party cannot be heard through the speaker.
key ( ). The Speaker on icon
Speaker
Section 3: Call Functions
This section explains how to make or answer a call. This section
also includes the features and functionality associated with
making or answering a call.
Making a Call — Number Entry Dialing
1. In standby mode, touch the
Dialer
soft key. The touch
keypad screen appears in the
display.
2. Enter the number you wish to
call using the touch keypad.
3. Touch or the
Voice Call
soft key to place the call.
Dialing Emergency Numbers
When you call an Emergency Number, such as 911, your phone
locks itself in emergency mode, only allowing you to make calls
to the emergency call center you originally contacted. This
enables emergency operators to more easily dispatch aid, such
as police, fire fighting, and emergency medical personnel.
1. In standby mode, touch the
Dialer
soft key. The touch
keypad screen appears in the display.
2. Enter 911 using the touch keypad.
3. Touch or the
Important!:
Emergency number 911 is preset into your phone. You can dial
this number almost any time, even when the phone is locked or
restricted.
If you call 911 an audible tone is heard and an Emergency
prompt appears in the display for the duration of the call.
Important!:
Because of various transmission methods, network parameters,
and user settings necessary to complete a call from your
wireless phone, a connection cannot always be guaranteed.
Therefore, emergency calling may not be available on all
wireless networks at all times.
Important!:
DO NOT depend on this phone as a primary method of calling
911 or for any other essential or emergency communications.
Note:
You can specify other numbers than 911 as emergency numbers using
the Emergency # settings. (For more information, refer to “Emergency
#” on page 118.)
Voice Call
soft key to place the call.
Call Functions 20
Manual Pause Calling
When you call automated systems (like banking services), you
are often required to enter a password or account number.
Instead of manually entering the numbers each time, you can
store the numbers in your Contacts along with special characters
called pauses.
•
Wait
— Hard Pause — Stops the calling sequence until you touch
.
•
2-Sec Pause
— Stops the calling sequence for two seconds and then
automatically sends the remaining digits.
To manually call a number with pause(s) without storing it to your
Contacts:
1. In standby mode, touch the
Dialer
soft key. The touch
keypad screen appears in the display.
2. Enter the number you wish to call.
3. Touch the Add Pause soft key.
A pop-up menu containing the following options appears in
the display:
•
Wait
•
2-Sec Pause
21
Tip:
You can create pauses longer than two seconds by entering multiple 2Sec Pauses.
4. Select the desired pause option. The respective letter (W or
P) is added to your number entry.
5. Touch or the
Voice Call
soft key to call the number.
Making a Call — Contact Dialing
You can store phone numbers and
contact names in your phone’s
Contacts list. To call one of your
contacts, do the following:
1. In standby mode, touch the
Dialer
soft key. The touch
keypad screen appears in the
display.
2. Touch the
( ). The
Contacts
Contacts
button
list
appears in the display.
3. Touch the desired Contact entry, then touch
Add
.
To select a number other than
4.
the marked Contacts entry’s
default number, touch the
radio button to the right of the
number you want to display
and touch
Add
. The entry’s
information appears in the
display.
•
Touch the entry you wish to dial.
5. Touch
Voice Calls
.
The number dials.
Making a Call — Speed Dialing
Speed Dialing lets you quickly and easily dial any contact in your
Contacts list by using that contact’s Favorites number in the list.
You can assign and change Favorites (speed dial) numbers for
your contacts. (For more information, refer to “Assigning a Speed
Dial Number” on page 47.)
One-Touch Dialing
Speed Dial numbers 002 through 009 are special One-Touch
dialing numbers. You can call the phone numbers stored in your
phone’s Contacts list and assigned Speed Dial numbers 002
through 009 by pressing and holding a single key.
Example:
For Speed Dial number 003, touch the
and hold until the name and number appear in the display
and the number is dialed.
Dialer
soft key, then press
Two-Touch Dialing
Memory locations 010 through 030 are special Two-Touch
dialing locations.
Example:
For Speed Dial number 013, touch the
touch , then press and hold until the name and number
appear in the display and the number is dialed.
Dialer
soft key, then briefly
Pause Dialing From a Contacts Entr y
•
If you speed dial a contact that contains hard Waits, wait for the
appropriate prompt(s) from the number you are calling (credit card
number, bank account number, and so on) and touch to continue
your dialing sequence.
•
If you speed dial a contact that contains 2-Sec Pause(s) simply wait for
the pauses to pass and the dialing to complete.
Note:
For more information about dialing pauses, refer to “Manual Pause
Calling” on page 21.
Call Functions 22
Favorites Screen Dialing
You can also dial Contacts entries
with assigned Speed Dial numbers
from the
Favorites
screen.
1. In standby mode, touch the
Dialer
soft key. The touch
keypad screen appears in the
display.
2. Touch the
Favorites
( ). The
button
Favorites
screen appears in the display.
23
3. Find and touch the desired
Favorite. Two buttons pop-up
in the display.
4. To call the selected Favorite,
touch .
Making a Call — Voice Dialing
Your mobile phone includes state-of-the-art voice recognition
software that lets you dial numbers using your voice.
Using Voice Dial
Use the Voice Dial command to dial any number stored in your
Contacts list by saying the name of the contact (Name Dialing).
You can also use Voice Dial to dial any valid telephone number,
even numbers not stored in your contact list, by speaking the
individual digits in the number (Digit Dialing).
Voice Dialing Tips:
•
Wait for the beep before speaking.
•
Speak clearly at a normal volume, as if you were talking to someone
on the phone.
•
When saying a name, say the first name then the last name.
Dialing a Name
To dial a name, do the following:
1. In standby mode, touch the
Voice Recognition
key ( ).
“Say a Command” appears in the display and is
pronounced through the earpiece.
2. Say, “Call”. You are prompted to “Say the name or #”.
3. Speak clearly and say the name of a person in your
Contacts list, first name followed by last name.
If the name is recognized, Voice Dial repeats the name and
dials the number.
If Voice Dial is not sure which name you said, it prompts
you with “Please try again.”
4. Do one of the following:
•
Touch one of the name buttons.
•
Say “
Yes
” to confirm the first name.
•
Say “No” to hear the next name.
•
Say “
Repeat
” to hear the names again.
•
Say “
Cancel
” to exit Voice Service without dialing.
(For more information, refer to “Confirmation” on
page 87.)
If the recognized/selected name has multiple numbers
stored for it (that is, Home, Work, Mobile, and so on), Voice
Dial displays the possible choices and prompts you with
“Try again?”
5. Say one of the following number types:
•“Home
”
•“Work
”
•“Mobile
”
Voice Dial dials the specified number.
Dialing a Number
To dial a number using Voice Dial, do the following:
1. In standby mode, touch the
Voice Recognition
“Say a Command” appears in the display and is
pronounced through the speaker.
Call Functions 24
key ( ).
2.
Say “Call”. VoiceSignal prompts you to “Say the name or
#”.
3. Speak clearly and say the telephone number of the person
you want to call. For example, say “7 8 1 9 7 0 5 2 0 0."
If it recognizes the number, Voice Dial repeats and dials the
number. If Voice Dial is not sure it has recognized the
number, it displays and prompts you with “Call?” followed
by a choice list of up to three numbers.
4. Do one of the following:
•
Touch one of the number buttons.
•
Say “
Yes
” to confirm the first number.
•
Say “No” to hear the next number.
•
Say “
Repeat
” to hear the numbers again.
•
Say “
Cancel
” to exit Voice Service without dialing.
(For more information, refer to “Confirmation” on
page 87.)
Pause Dialing From a Contacts Entry
•
If you voice dial a contact that contains hard Waits, wait for the
appropriate prompt(s) from the number you are calling (credit card
number, bank account number, and so on) and enter the appropriate
response(s).
25
•
If you voice dial a contact that contains (two-second) 2-Sec Pause(s)
simply wait for the pauses to pass and the dialing to complete.
Answering a Call
Your phone notifies you of a call in the following ways:
•
A ring tone sounds and/or your phone vibrates (Your phone provides
nine ring volume settings including:
,
1 Beep
,
only
High
•
A phone number (unless blocked by the caller) and a name appear in
Low, Low/Medium, Medium, Medium/High
, and/or
different ring types to distinguish callers.)
Silent all, Alarm only
,
Vibrate
the display (If the caller’s number and name are stored in your
Contacts list).
•
If the caller can’t be identified,
restricted number
•
Your phone continues to notify you of the call until one of the following
Call from unavailable#, Call from
, or no number appears in the display.
events occurs:
•
You answer the call.
•
You ignore the call.
•
The calling party ends the call.
•
The call is sent to voicemail.
Answering an Incoming Call
䊳
Touch the key. The ring tone and/or vibration stop
and the caller’s voice can be heard in the earpiece.
, or
Tip:
You can set your phone to answer calls automatically or when you touch
any key but . (For more information, refer to “Call Settings” on
page 113.)
Ignoring a Call
When you ignore an incoming call, the call is immediately
forwarded to your voice mail.
䊳
During an incoming call, touch the key. The caller is
forwarded to your voice mail.
Adjusting the Call Volume
䊳
In standby mode, repeatedly touch the
Volume
key Down
until the Call Volume Level desired appears in the display.
The Volume key is on the left side of phone.
Calls Log
The Calls log retains information about Outgoing, Incoming, and
Missed calls. You can also view times for your last call and the
time totals for all calls.
Review the Calls Log
1. In standby mode, touch the
Menu soft key, then touch
Calls. The Calls list appears
in the display showing
All
calls.
2. Touch the Down arrow in the
upper right corner of the
screen. The following Calls
log options appear in a drop-
down menu:
•
All
•
Incoming
•
Outgoing
•
Missed
•Data
Note:
To review your Call Timers or Data Counters, touch the
key or the
Data Counter
3. Select the Calls log that you wish to review.
soft key.
Call Timer
soft
Call Functions 26
Note:
In cases where a Calls log entry concerns a call to or from a Contacts
entry, the Contact name associated with the number appears in the
Calls log list instead of the number.
4. The following functions are also available:
•Erase
— Touch this soft key to delete selected or All unlocked calls
from the displayed call log.
•Lock
/
Unlock
— Touch this soft key to block/permit deletion of
individual calls.
• Call Timer
— Touch this soft key to list the duration of the Last
Call; total durations of all Outgoing Calls, Incoming Calls, Roaming
Calls, All Calls since the timers were last reset; the date and time
the timers were last reset; and the total duration of Lifetime Calls (all
calls since your phone was activated — this timer cannot be reset).
• Data Counter
— Touch this soft key to list the amount of data (in
kilobytes) Transmitted, Received, and Total data transferred since
the timers were last reset; the date and time the timers were last
reset; and the total amount of data transferred in Lifetime Data
Counter (all data calls since your phone was activated — this timer
cannot be reset).
Outgoing Calls
Your phone retains information about the last 90 outgoing calls
and stores them in the Outgoing calls log. You can review the
Outgoing calls log for the time and date of a call, as well as other
information.
27
Note:
In standby mode, you can quickly view your most recent calls of all
types by briefly touching . A list containing up to 270 of your
most recent outgoing, incoming, and missed calls appears in the
display.
1. In standby mode, touch the Menu soft key, then touch
Calls. The Calls list appears in the display showing
calls.
2. Touch the Down arrow in the upper right corner of the
screen, then touch
Outgoing
. A list of Outgoing Calls
appears in the display.
3. Select a call to view further
information about it. The call
information screen shows the
recipient’s name (Contacts
only), the number dialed, the
time and date the call was
made, and the duration of the
call.
All
