imagine endless possibilities
everywhere you go
Samsung Q1 Ultra UM PC
SAMSUNG recommends Genuine Windows Vista™ Business
Mobility
Lighter and smaller than any laptop yet more powerful than any PDA. The Q1 Ultra strikes
the perfect balance between performance and portability.
Communication
Voice, video chat, email or just surfing the web. The Q1 Ultra lets you choose what works best
for you and how you want to make it happen.
Productivity
With full Windows compatibility, all your standard PC applications are fully functional. And with
its unique, built-in split QWERTY keypad and 7" wide touch screen LCD, the Q1 Ultra makes
it easy to take your office with you.
Connectivity
Wireless or wired. The Q1 Ultra is always ready to go and has all the connections you need to take
the hassle out of mobile computing.
Fun
Watch a movie. Make a video. Play a game. Listen to tunes. With two integrated digital cameras,
a dual-array microphone and a joystick for enhanced mobile gaming, the Q1 Ultra is as fun as
it is practical.
Introducing the Samsung Q1 Ultra.
For everywhere life takes you.
Your music, videos, photos and games.
Your business contacts, emails, spreadsheets and presentations.
All your personal and professional information and applications.
Brought together in one incredibly smart, ultra-portable device.
A handheld never held so much.
SAMS UNG re comme nds Genu ine Wi ndows V ista™ Bus iness
Amazing Portability
Take your work with you, thanks to its amazingly small size
(9"W x 5"H x 0.9"D), incredibly light weight (1.5 lbs.) and
4.5 hours of continuous battery life. The Q1 Ultra is your
perfect traveling companion or supplement to your desktop
or full-size notebook computer.
Full PC Functionality
Create, read, edit and store all your critical documents with
a full-featured Windows Vista™ or XP™ operating system
that runs all your essential applications like Microsoft
Office™. The Q1 Ultra does it all with an amazingly bright,
LED-backlit, 7" wide LCD, 1GB of system RAM and
up to 80GB of file storage.
Multiple Input Choices
Choose from a range of convenient input methods,
including a touch screen LCD with stylus and full
handwriting recognition, a choice of on-screen “virtual”
keyboards, fully-functional mouse capabilities and an
innovative split-QWERTY keypad for fast text input.
Enhanced System Security
Never worry about forgetting your password again. Protect
your personal and professional information with advanced
fingerprint recognition security that can be combined with
or replace passwords.
Imagine more choices for what you need
in an Ultra Mobile PC.
When you hit the road, you can bring your PDA. And your MP3 player.
And your GPS receiver. And your PMP player. And your notebook
computer. Or you can just bring the Q1 Ultra. The Samsung Q1 Ultra
is the first of its kind to deliver on the promise of convergence —
the merging of productivity, connectivity, entertainment and your life.
Super-bright, High Resolution, Widescreen LCD Display
Split-QWERTY Keypad and Fully-functional Mouse
User Definable Function Keys and Full System I/O
THE POWER TO TAKE YOUR WORK ANYWHERE
Get more done, no matter where you are. With
the Q1 Ultra’s small size and light weight, superior
ease-of-use and professional computing power,
you can go anywhere without ever leaving
the office.
INDUSTRY & PUBLIC SERVICEBUSINESS & EDUCATION COMMUTING & ON-THE-GOHEALTHCARE & MEDICINE
THE DELIGHT OF A PORTABLE MEDIA CENTER
Enjoy your favorite videos, music, photos and games
or video chat with your friends and colleagues
— anytime you want. With a high-resolution screen,
surround sound and dual cameras, the Q1 Ultra
takes mobile entertainment to the next level.
Stunning Widescreen Video
See your favorite movies, TV, photos and more in vibrant
detail, with an ultra bright, super high-resolution 7" WSVGA
LCD display.
High-Fidelity Audio
Experience home theater-quality sound anywhere,
with digital SRS TruSurround sound, 1.5W stereo speakers
and support for Bluetooth wireless headsets and all
music formats.
Digital Video Camcorder/
Still and Video Chat Cameras
Take high-quality videos or still pictures with a forwardfacing 1.3 Megapixel camera, or video chat/conference
using the rear-facing 300 Pixel camera.
Mobile Gaming Joystick and User Defined Keys
Enhance the fun of single-player and online gaming with an
innovative 8-way joystick and four user-defined keybuttons.
HIGH-SPEED, WIRELESS CONNECTIVITY
ANYWHERE
Stay on top of your digital world. With the latest
high-speed wireless communications capabilities,
the Q1 Ultra makes it easy to leave your home
or office without ever leaving anything behind.
Information To-Go
With integrated WiFi, Bluetooth and Ethernet connections,
the Q1 Ultra enables high-speed communications at
wireless “hot spots,” at your local network or with all your
Bluetooth devices.
Connect Anywhere, Anytime
With the optional HSDPA cellular data modem, the Q1 Ultra
connects to the latest high speed 3.5g wireless data networks
— so you can connect to the Internet or your home or
business network wherever your cell phone is supported.
Better Internet Experience
Take full advantage of Internet services like VoIP calling
and video chat wherever you are, with the integrated
video camera and special dual-array microphone.
On-The-Road Companion
Need help navigating? With the Q1 Ultra’s optional GPS
receiver, just plug in the receiver and follow the directions.
SAMS UNG re comme nds Genu ine Wi ndows V ista™ Bus iness
What will you do
with your Q1 Ultra?
Whether you’re a frequent traveler looking to
lighten your load, an educator needing to present
your latest lecture, a salesman with the latest
pitch, a medical professional taking patient
notes, a logistics foreman capturing inventory
data, or a student trying to keep up with your
class notes, the Samsung Q1 Ultra UMPC
gives you the freedom to take your world
everywhere you go.
Lighter than any laptop, more powerful than any
PDA and designed with unmatched convenience
and style, it’s the ultimate traveling companion.
And don’t forget to choose from a full range of
optional accessories to make the most of your
Q1 Ultra.
• Included
n Differences
MODEL / SPECI FICATIONS
Q1U-EL
P/N:NP-Q1UAY01
Q1U-XP
P/N:NP-Q1U/000
Q1U-V
NP-Q1UA000
Q1U-CMV
P/N:
LCD
Size 7" WSVGA 7" WSVGA 7" WSVGA 7" WSVGA
Display Resolutions 1024x600 (n ative) 1024x600 (n ative) 1024x600 (n ative) 1024x600 (n ative)
800x600, 640x480 800x600, 640x480 800x600, 640x480 800x600, 640x480
Technology LED Backlit LED Backlit LED Backlit LED Backlit
Brightness 300 nits 300 nits 300 nits 300 nits
Touch Screen TSP TSP TSP TSP
CPU
Intel Ultra Mobile Processor / Model A100 A110 A110 A110
Clock/Front Side Bus Speed 600 MHz / 400 MHZ 600 MHz / 400 MHZ 600 MHz / 400 MHZ 600 MHz / 400 MHZ
VIDE O/GR APH ICS
Manufacturer / Model Intel GMA950 Intel GMA950 Intel GMA950 Intel GMA950
Shared Memory 128 MB 128 MB 128 MB 128 MB
RAM 1 GB 1 GB 1 GB 1 GB
Memory Type DDR2 400 MHZ DDR2 400 MHZ DDR2 400 MHZ DDR2 400 MHZ
HDD
Capacity 40 GB 60 GB 60 GB 80 GB
Size/Speed 1.8" - 4200 RPM 1.8" - 4200 RPM 1.8" - 4200 RPM 1.8" - 4200 RPM
KEy PAD INT EGRATE D INT EGRATE D INT EGRATE D INT EGRATE D
Type Split QWERT Y Split QWERT Y Split QWERT Y Split QWERT Y
WIR ELE SS COMMUn ICAtIOn S
802.11 b/g Wi-Fi • • • •
Bluetooth 2.0 + EDR • • • •
HSDPA Cellular Modem •
WIR ED COMMUn ICAtIOnS
10/100 BaseTX Ethernet (RJ45) • • • •
SEC URIt y
Fingerprint Reader (Authentec) •
CAME RAS
Front Facing – Video Chat (300P) • • •
Rear Facing – Video/Still (1.3MP) • • •
SOU nD HD AU DIO HD AUDI O HD AUDIO HD A UDI O
Speakers 1.5W x 2 1.5W x 2 1.5W x 2 1.5W x 2
Microphone Dual Array Dual Array Dual Array Dual Array
EnH AnCEME nt SLOt N/A SD/ MMC SD/ MMC SD/ MMC
InPU t / O UtPUt
8-Way Direction Button & Mouse Function • • • •
4-User Defined Keys • • • •
Volume Control • • • •
Quick Launch Menu Button • • • •
Camera Shutter Button • • • •
USB 2 - 2.0 2 - 2.0 2 - 2.0 2 - 2.0
Audio Jack • • • •
RJ-45 Jack • • • •
2-in1 Memory Slot (SD/MMC) • • •
POW ER MAnAGE MEn t
Battery Li-Ion (Prismatic) Li-Ion (Prismatic) Li-Ion (Prismatic) Li-Ion (Prismatic)
Battery Life 4.5 Hours Over 4.5 Hours 4.5 Hours Up to 4.5 Hours
AC Adapter 100~240VAC 100~240VAC 100~240VAC 100~240VAC
MEC HAnICA L
Dimensions 8.96"(L) x 4.88"(H) x 0.93" (D) 8.96"(L) x 4.88"(H) x 0.93" (D) 8.96"(L) x 4.88"(H) x 0.93" (D) 8.96"(L) x 4.88"(H) x 0.93" (D)
Weight 1.52lbs 1.52lbs 1.52lbs 1.52lbs
OPER AtInG S yStE M
Operating System — Microsoft Windows Vista Home Premium XP Tablet Vista Home Premium Vista Home Premium
DOCKING STATION
AA-RD0UQ1U
GPS RECEIVER
P/N:AA-PK1UNAV
USB KEYBOARD
P/N:AA-SK0TKBD
6-CELL EXTENDED
LIFE BATTERY
P/N:AA-PL1UC6B
8-CELL POWER BANK
P/N:AA-PL0UC8B
AUTO ADAPTER
P/N:AA-PC0NCAR
STYLUS PENS (3 PAK)
P/N:AA-EX1UPEN
A/C ADAPTER
P/N:SPA-P30
DUAL LAYER DVD DRIVE
P/N:AA-ES2U12B
PORTFOLIO CASE
Samsung Electronics America, Inc.
105 Challenger Rd.
Ridgefield Park, NJ 07660
To learn more about the Samsung Q1 Ultra UM PC,
or to find your nearest retailer, please visit:
samsung.com/q1ultra
