User’s Guide

Product Features

Small but Strong UMPC (Ultra Mobile PC)

VIA C7-M ULV Processor

●

● 512MB ~ Max. 1GB DDR2 Memory

● 1.8" High Capacity Hard Disk Drive of 30~60GB

7" WVGA TFT LCD

Basic Resolution of 800x480 Pixels, Maximum Resolution of 1600x1200 Pixels

●

(when an external display is connected)

● Auto Scaler (Automatic Resolution Adjustment) Function to Support High Resolu-

tion Output

●

Easy-to-Use Touch Screen usable with your fingers.

Microsoft Windows XP Tablet PC Edition

Resolve PDA and Pocket PC restrictions

●

● Usability Similar to a Normal PC with Windows

Powerful Multimedia Functions

Various Multimedia Programs Such as AVStation etc.

●

Multiple Network Support

Wireless LAN, Bluetooth (Optional)

●

● Resolves Space Restrictions through the Wireless Communication Function

Compact, Light-Weight Design for Portability / Polished Design

● A mere 746g (Including the Bluetooth modules)

● High-Gloss Front Panel

Optional Accessories for Additional Convenience

USB Data Cable Enabling Data Exchange with another PC.

●

● USB External ODD, Ultra-Slim USB External Keyboard

● Power Bank to Extend Use Time

Product Features 2

Using Your Document

Congratulations on your purchase of a computer with the Windows® XP operating system. Whether you are new to using a portable computer or are an experienced user, this user’s manu al can help you get the most from your computer.

Manual Documentation Conventions

Some devices and software may differ from the descriptions in the User's guide or may not be supplied with the product depending on your computer model.

The actual appearance of the computer may differ fr om the pictures prin ted on the cove r and in the User's guide.

This manual describes procedures with both the Stylus Pen and Mouse. 'Single-Click' in this manual also means 'Single-tap' for the Stylus Pen.

Information Icons

Three icons and their associated messages appear in this manual. The information icons are placed before the step/information they apply to:

Warning

Indicates the possibility of personal injury.

Caution

Warns you of possible damage to equipment or data.

Note

Informs you of special circumstances.

Before starting!

Informs you of special requirements or limitations for use of item(s).

p.xx

Shows the page number you can refer to for more detailed information.

Using Your Document 3

Product Features 2 Using Your Document 3 Contents 4 Safety Precautions 6 Maintaining a Proper Posture

While Using the Computer 11

Chapter 1. Getting Started

Overview 14

Front View / Status Indicators 14 Top View 15 Right View 16 Left View 16 Rear View 17

Turning the Computer On and Off 18

Turning the computer on 18 Turning the computer off 18

Chapter 2. Using the Computer

Stylus Pen 20 Entering Text 22

Using the Tablet PC Input Panel 22 Entering text using the Dialkeys 25

Volume Control 26 Using the Buttons 27

The Menu Button 27 The Quick Launch Button 28 The Auto Scaler Button 30

Using an external Monitor 31

Connecting a Monitor 31 Viewing on a Monitor 31 Dual View 32

Chapter 3. Using Microsoft Windows XP

About Microsoft Windows XP 35

Get Going with the Tablet PC 35 Tablet PC Tutorials 36 Reinstalling Windows XP 36

The Windows XP Screen Layout 37

Desktop 37 Understanding the Start Menu 38 Understanding a Window 39

Control Panel 40

Opening the Control Panel 40 User Account 41 Changing the Resolution and Colors 43

Chapter 4. Using the Network

Connecting to a Wireless LAN 45

Connecting to an Access Point (AP) 46 Connecting to computer-to-computer

networks (peer-to-peer or ad hoc) 47 Setting up a Wireless Network Setup

Using the Wireless LAN Setup Program 50

Using Samsung Network Manager 51

Setting Up a Network 51 Accessing a network

from a different location 54 Network Status Diagnosis 54

Using Bluetooth Devices 55

Bluetooth Software Setup 56 Using Bluetooth 58

Contents 4

Chapter 5. Using Applications

Chapter 7. Troubleshooting / Appendix

Introducing Programs 63 Using Samsung Update Plus 65 Program Launcher 67

Program Launcher Screen Layout 67 Using Program Launcher 68

Using AVStation premium 69

Start and Screen Layout 69 MUSIC Station 70 PHOTO Station 73 MOVIE Station 76

Using AVStation NOW / AVStation Viewer 79

Start / Exit AVStation NOW 79 Start / Exit AVStation Viewer 80 Screen Layout 81 MUSIC Station 81 PHOTO Station 83 MOVIE Station 84

CyberLink PowerDVD 86

Chapter 6. Settings

Using System Setup 89

Starting System Setup 89 The System Setup Screen 90

Setting a Booting Password 92 Changing the Booting Priority 95 Using the Battery 96

Removing and Attaching a Battery 96 Charging the Battery 97 Monitoring the Battery Charge 97 Extending the Battery Usage Time 99

Using Magic Doctor 103 Using Norton AntiVirus 104 Restoring the System 105

Creating a Restore Point 105 Returning your computer

to an earlier restore point 106 Undoing the last restoration 107

Reinstalling Software 108

Running the system software Media 108 Installing drivers and programs 109

Reinstalling Windows XP 110

Running the System Recovery Media 110 Quick Installation 111 Standard Installation 112 Installing Windows When Windows Fails 113

Questions and Answers 114

Windows Related 114 Display Related 114 Sound Related 116 Wireless LAN Related 117 Games and Programs Related 120 Bluetooth 121 Security Center 123 Other 125

Specifications 126 Glossary 128 Index 131 Important Safety Information 132 Regulatory Compliance Statements 133 WEEE Symbol Information 139 Contact SAMSUNG WORLD WIDE 140

Contents 5

Safety Precautions

For security purposes and to prevent damage, please read the following safety instructions carefully.

Warning

Failing to follow the instructions marked with this symbol may cause injury to y ourself and even fatality.

Caution

Failing to follow the instructions marked with this symbol may cause injury to yourself or damage the product.

Warning

Installation Related

• Do not install the product in places exposed to humidity such as bathrooms.

There is a danger of electric shock. Use the product within the operating conditions specified in the User Guide.

• Keep the plastic bags out of reach of children’s reach, as there is a danger of suffo-

cation.

Power Related

• Do not touch the power cord with wet hands, as there is a danger of electric shock.

• Take care not to exceed the standard capacity (voltage/current) of a multi-tap or

power outlet extension when using it for the product.

Electric leakage may cause electric shock or fire.

• If the power cord or power outlet makes a noise, disconnect the power cord from

the wall outlet and contact a service center, as there is a danger of electric shock or fire.

• Do not use a damaged or loose power cord or power outlet, as there is a danger of

electric shock or fire.

• Plug the power cord into the power outlet firmly.

Failing to do so may cause fire.

• Do not unplug the power cord by pulling only the cable.

If the cord is damaged, this may cause electric shock.

Safety Precautions 6

• Do not bend the power cord excessively and do not place heavy objects on the

power cord. Keep the power cord out of the reach of infants and pets.

A damaged cord may cause electric shock or fire.

• Use a wall outlet or multi-tap with a grounding port.

Failing to do so may cause electric shock.

• If water or another substance comes into contact with the power input jack or into

the computer, disconnect the power cord and contact a service center.

Damage to the device within the computer m a y ca u se electric shock or fire.

• Keep the power cord and power outlet clean.

Failing to do so may cause fire.

Use Related

• Do not place a cup or container filled with water or chemicals over or near the com-

puter.

If water or chemicals come into contact with the computer, it may cause fire or electric shock.

• When dropping the computer or the computer is broken, disconnect the power cord

and contact a service center for a safety check.

Using a broken computer may cause electric shock or fire.

• Avoid direct sunlight when in an air-tight location such as inside a vehicle.

The computer may become deformed or fire may be caused by high temperatures.

• Do not scratch the surface of the LCD with a sharp object such as a knife.

THE LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. For details see lamprecycle.org, eise.org, or call 1-800-Samsung.

Upgrade Related

• Never disassemble the power supply or AC adapter.

There is a danger of electric shock.

• Use only authorized parts (multi-bay, battery and memory) and never disassemble

parts.

There is a danger of damage to the product, electric shock or fire.

Custody and Movement Related

• Follow the instructions of the relevant location (e.g. airplane, hospital, etc.) when

using a wireless communication device (wireless LAN, Bluetooth, etc.).

Safety Precautions 7

Caution

Installation Related

• Do not block the ports (hole), vents, etc. of the product and take care not to insert

any alien substances into the product.

Damage to the device within the computer m a y ca u se electric shock or fire.

• Do not place heavy objects over the product, as this may cause a problem with the

computer. In addition, the object may fall and cause injury or damage the computer.

Battery Use Related

• Dispose of worn-out batteries properly.

Failing to do so may cause fire or an explosion. Follow the proper disposal method relevant to your region. The batte r y di sposal method may

differ depending on your location. Dispose of the used battery in the appropriate way.

• Do not throw or disassemble the battery, as this may cause injury, fire or an explo-

sion.

• Use only batteries authorized by Samsung Electronics.

Failing to do so, may cause an explosion.

• Avoid contact with metal objects such as car keys or clips when storing or carrying

a battery.

Contact with metal may cause excessive current and a high temperature and may damage the battery or cause fire.

• Change the battery according to the instructions in the manual.

Failing to do so may damage the product. Do not place the battery into a fire or heat it, as there is a danger of fire or explosion.

Safety Precautions 8

Use Related

• Do not place a candle, lighted cigar, etc. over the product.

There is a danger of fire.

• Make sure that the product is tested by a service engineer after repairing the prod-

uct.

Using a repaired product without a safety test might cause electric shock or fire.

• In case of lightning, immediately turn the system off and disconnect the power

cord from the wall outlet, as there is a danger of electric shock or fire.

• Connect only permitted devices to the connectors or ports of the computer.

Failing to do so may cause electric shock or fire.

• When the computer is used for a long time, an ‘odd’ smell may arise.

Ventilate the room frequently and use the computer carefully.

• Do not press the Eject Button while the CD-ROM drive is operating, as this might

cause data to be lost. The disk may suddenly eject and cause injury.

• When using a walkie-talkie, please keep a distance of at least 1m between the

walkie-talkie and the computer. Since a walkie-talkie's transmission power is very high, this may cause the computer to malfunction.

• Avoid dropping the product while using it.

– Dropping the product may damage the product or cause data loss. – Take care not to drop the product when using the computer on the stand.

• Do not touch the antenna and power outlet, as there is a danger of electric shock.

Upgrade Related

• Take care when touching the product or any of the parts, as this may damage the

device or cause injury.

• Take care not to drop any computer part or device.

Dropping a device or part may cause injury, or damage the product.

• Use parts authorized by Samsung Electronics only.

Failing to do so may cause fire or damage the product.

• To connect a device that is not manufactured or authorized by Samsung Electron-

ics, ask at a service center before connecting the device.

Failing to do so may damage the product.

Safety Precautions 9

Custody and Movement Related

• When moving the product, turn the power off and separate all connected cables

first.

Failing to do so may damage the product or cause users to trip over the cables.

• Keep the Stylus Pen out of the reach of children.

Children may injure themselves by swallowing it or damaging their eyes.

• Use a computer cleansing solution when cleaning the product.

Using a cleansing solution or chemical not explicitly developed for computer use may damage the product.

• Do not use or watch the computer while driving a vehicle, as this may cause a traf-

fic accident. Concentrate on driving.

Avoiding Data Loss (HDD Management)

• Avoid damaging the data on a hard disk drive.

– A hard disk drive is extremely sens itive to external impact and may cause data loss on the

surface of the disk.

– The company is not liable for any loss of user data due to a user's carelessness or any

external impact.

• Possible causes of data loss of a hard disk drive.

– Data may be lost due to an external impact to the disk while disassembling or assembling

the computer.

– Data may be lost when the computer is turned off or reset by a power failure while the

hard disk drive is in operation.

– Data may be lost if the power is turned off while running a program. – Moving the computer or any impact caused to it while the hard disk drive is in operation,

may damage the data on the hard disk drive.

To prevent data loss due to damage to the hard disk drive, please backup your data frequently.

Safety Precautions 10

Maintaining a Proper Posture While Using the Computer

Maintaining a proper posture while using the computer is very important for avoiding physical discomfort or even harm.

The following instructions are about maintaining the proper posture while using the computer developed through human engineering. Please read and follow the instructions carefully for when using the computer.

Failing to do so may increase the probability of RSI (Repetitive Strain Injury) through repeated operations may increase and serious physical bodily harm may result.

The recommendations (System specification, p.126) have been prepared so that they can be applied within the coverage of general users. If users are not included in the coverage, the recommendations are to be applied according to the user's needs.

Proper Posture

• Do not use the computer on your lap or close to your skin for long periods.

There is a danger of burns due to the high temperature of the computer.

• To use the computer while talking over the telephone, use the ear-microphone phone.

When using the computer while holding a phone over your shoulder and talking on the phone, your posture becomes bad.

• Keep frequently used work items within an easy working range (where they can easily be

reached).

Eye Position

Keep a distance of at least 50cm between the LCD and your eyes.

• Adjust the height of the LCD screen so that its top height is equal to or lower than your eyes.

• Avoid setting the LCD excessively bright.

• Keep the LCD screen clean.

• When wearing glasses, clean them before using the computer.

Hand Position

• It is recommended connecting and using an external keyboard and mouse when using the

computer over long periods.

• Do not hold the Stylus Pen with excessive force.

• Do not press the touch screen with excessive force.

Maintaining a Proper Posture While Using the Computer 11

Volume Control (Headphones and Speakers)

Check the volume level before listening to music.

• Check if the volume level is too high before using the headphones.

• Do not set the volume to the maximum from th e beg inning. Set the volume low and find a

comfortable level while turning it up.

• Do not use the headphones for long periods of time.

Usage Time (Break Time)

• When working for more than one hour, take a 10 minute break after every 50 minutes of work.

• Using this computer for two hours or less a day is recommend ed .

Illumination

• Do not use the computer in a dark environment. The illumination level for computer use must

be as bright so when reading a boo.

• Indirect illumination is recommended. Use a curtain to prevent the reflection of the LCD screen.

Operating Conditions

• Do not use the computer in hot and humid locations.

• Use the computer within the allowed temperature and humidity ranges specified in the User

Guide.

Maintaining a Proper Posture While Using the Computer 12

Chapter 1. Getting Started

Overview 14

Front View / Status Indicators 14 Top View 15 Right View 16 Left View 16 Rear View 17

Turning the Computer On and Off 18

Turning the computer on 18 Turning the computer off 18

Overview

Before Starting!

The actual appearance and color of the contents may differ from the pictures used in th e material.

Front View / Status Indicators

z LCD

x Mono

Speaker

c Joystick

v Auto Scaler

Button

, Quick Launch Button

m Enter Button n Menu Button

b Status Indicators

LCD The screen images from the computer are displayed here.

Mono Speaker A device generating sound. One speaker is at the top left of the computer.

Joystick Plays the same role as the direction keys ( ← , → , ↑ , ↓ ) on the keyboard.

Auto Scaler Button (Automatic Resolution Adjustment Button)

Status Indicators Shows the operating status of the computer. The corresponding operating LED is lit

Menu Button Press this button to launch the Menu Program. ( p.27)

Enter Button Press this button to select an item. It is the same as the Enter key on the keyboard.

Quick Launch

Button

Used as a joystick when playing games.

Press this button to change the screen resolution. Auto Scaler provides 3-step resolutions. Whenever you press this button, the screen

resolution changes to 800x480 (Default Resolution) > 800x600 > 1024x600 sequentially. (

when the corresponding function operates. ( p.15)

The Menu Program provides shortcuts to frequently used functions on the computer. You can easily change the settings.

You can register a frequently used program to launch it just by pressing this button. ( p.28)

p.30)

Overview 14

Status Indicators

z HDD

x Wireless LAN

HDD This turns on while the hard disk drive is being accessed.

Wireless LAN This turns on when the wireless LAN is operating. ( p.45)

Charge Status This shows the power source and the battery charge status.

Power Status This shows the computer operating status.

Green: When the battery is fully charged or the battery is not installed. Amber: When the battery is being charged. Blinks: It blinks for a while when sliding the HOLD switch up or when pressing

a button when the HOLD switch is in the HOLD position.

Off

: When the computer is running on battery p ower without being connected to AC power.

On : When the computer is operating. Blinks: When the computer is in Standby mode.

v Power Status

c Charge Status

Top View

z Windows Security Button

x Volume Control Button

Windows Security

Button Volume Control

Button Power Switch /

AVStation NOW Switch

Vents

Stylus Pen /

Stylus Slot

c Power Switch / AVStation NOW Switch

Pressing this button is the same as pressing the <Ctrl>+<Alt>+<Del> keys on the keyboard. Press the Stylus Pen, display the Windows Task Manager window.

A button used to control the volume. ( p.26)

You can turn the computer on or off by sliding this switch to the right and releasing it. ( p.18) You can launch AVStation NOW by sliding this switch to the left when the computer is

turned off. ( p.79)

To turn the computer on, slide the Power switch to the right and hold it for more than 0.1 seconds before releasing it.

The internal heat of the computer is emitted through these holes.

If the vents are blocked the computer may over-heat. This may be dangerous, so avoid blocking the vents.

The Stylus is used to enter information through the touch screen. ( p.20) You can keep the Stylus Pen in the Stylus Slot.

v Vents

b Stylus Pen / Stylus Slot

Overview 15

Right View

Left View

Monitor Port

A jack used to connect a monitor, TV or projector supporting a 15-pin D-SUB interface. ( p.31)

USB Port

A port used to connect a USB device such as a USB keyboard, mouse, etc.

DC-in Jack

A port used to connect the AC adapter supplying power to the computer.

External ODD Power Port

A port used to supply power to the external USB ODD.

USB Port

A port used to connect a USB device such as a USB keyboard, mouse, USB ODD, etc.

Headphone Jack

A jack used to connect the headphones.

MIC Jack

The jack for connecting a microphone.

HOLD Switch

When sliding the HOLD switch into the HOLD position (upwards), no buttons will work.

When pressing a button or switch in the HOLD status, the Charge LED ( blinks for a moment.

To use the computer again, slide the HOLD switch down.

Hand Strap Hole

You can connect the Hand Strap here.

)

Overview 16

Rear View

z 20° Stand

x 80° Stand c Battery Latch

v Battery

20° Stand You can position the computer at a 20° degree angle so that you can comfortably

80° Stand You can position the computer at an 80° degree angle so that you can comfortably

Battery Latch The latch used to remove or install the battery. ( p.96)

Battery A Lithium Ion rechargeable battery which supplies power to the computer. ( p.96)

enter text.

view the screen.

Overview 17

Turning the Computer On and Off

Turning the computer on

1 Install the battery and connect the AC adapter. (Refer to the Getting Started Guide.) 2 Adjust the stand at the back of the computer to a comfortable angle. 3 Slide the Power Switch to the right, hold it for more than 0.1 seconds and then release it.

The computer is turned on.

When running the computer on battery power, the LCD brightness is automatically dimmed to save battery power. Press the ( p.27). Alternatively, press the + or down the

button and then

button to adjust the LCD brightness.

Brightness Up

Volume Control

Brightness Up

buttons at the top of the computer while holding

to adjust the LCD brightness.

Turning the computer off

1 Click the start button ( ) on the taskbar. 2 Click Turn Off Computer.

3 Click Turn Off.

When the system cannot be shut down due to a syste m erro r, turn it off by sliding and holding the Power Switch for more than 4 seconds.

After that, when turning it on by sliding the Power Switch, the disk checking program may launch.

Turning the Computer On and Off 18

Chapter 2. Using the Computer

Stylus Pen 20 Entering Text 22

Using the Tablet PC Input Panel 22 Entering text using the Dialkeys 25

Volume Control 26 Using the Buttons 27

The Menu Button 27 The Quick Launch Button 28 The Auto Scaler Button 30

Using an external Monitor 31

Connecting a Monitor 31 Viewing on a Monitor 31 Dual View 32

Stylus Pen

A Stylus Pen instead of a mouse is supplied with the computer and provides the same function.

Before Starting!

It is recommended connecting and using a USB keyboard and m ouse when u sing the computer over long periods.

Removing the Stylus Pen from the computer

Pull the Stylus Pen upwards and out.

When finished, return it to the Stylus Slot.

Stylus Pen Functions

Mouse Stylus Pen Function

Single-click Single-tap Single-tap with the pen to select an item. Double-click Double-tap Doub le-tap with the pen to run an item.

Right-click Press and Hold

Drag Drag Press an item and drag it with the pen to move the item.

Press and hold for more than 3 seconds with the pen to display the Pop-up menu.

Learning How to Use the Stylus Pen

Select Start > Get Going with Tablet PC to learn how to use the Stylus Pen. ( p.35)

Operate the touch screen LCD with a Stylus Pen or your finger. Sharp objects may scratch or damage the LCD surface.

Stylus Pen 20

Calibrating the Stylus Pen

When using the Stylus Pen for the first time or the pointing position of the Stylus Pen is incorrect, you can correct the pointing position using the TouchKit program.

1 Select Start > All Programs > Touchkit > Configure Utility. 2 In the Tools tab, select 4 Points Calibration.

Enhancing the Accuracy If greater precision is required, you can correct the pointing position by using 9-Points or 25-

Points Calibration.

To setup 9-Point or 25 Point Calibration, follow these steps:

z Before beginning with the Calibration, click on the Settings tab in the TouchKit. x In the Linearization Style item in the Settings tab, select 9-Points or 25-Points and

then press the Apply button.

c To calibrate, click the Tools tab. v x Select Linearization from the Tools tab. The higher the number, the more precise the

correction.

3 Press and hold the X-symbol displayed on the screen until it stops blinking. The X-symbol

appears repeatedly according to the selected number of points.

4 If the Calibration Result window appears, click the OK button. The pointing position of the

Stylus Pen is corrected.

Stylus Pen 21

Entering Text

You can enter text by using the Tablet PC Input Panel or the DialKeys on-screen keyboard.

Before Starting!

Using a USB keyboard and Notepad is more convenient than using the Tablet PC Input Panel or the Dialkeys when entering large amounts of text.

For example, to enter texts in Notepad, select Start > All Programs > Accessories > Note-

pad and run Notepad.

Using the Tablet PC Input Panel

The Tablet PC Input Panel is an on-screen letter input pad provided by Windows. Letters can be

entered with the Stylus Pen when a keyboard is not available. There are three ways in which letters can be entered using the Tablet PC.

Input Panel: with the Writing Pad, with the Character Pad, and with th e On-Screen Keypad. To open the Tablet PC Input Panel, click on the Tablet PC Input Panel ( ) icon on the taskbar.

A picture of the Tablet PC Input Panel is displayed below.

Writing Pad

Character

Pad

On-Screen

Keyboard

Tablet PC Input Panel icon

Close Tools and

Options Help

You can learn detailed usage for the Tablet PC Input Panel.

Entering text using the Writing Pad

The Writing Pad converts text written with the Stylus Pen into electronic text.

To use the Writing Pad, follow these steps:

1 Open the Tablet PC Input Panel and an editing program. 2 In the Tablet PC Input Panel, click the Writing Pad icon ( ). 3 Enter text into the input area of the Writing Pad using the Stylus Pen and wait a moment. The

written letters are converted into the corresponding com p uter characters.

Entering Text 22

4 Press the Insert button to enter the converted letters.

Editing Letters

Write over incorrect letters or press the lower part of a letter to select another letter from the displayed letters.

Insert

Entering text using the Character Pad

The Character Pad is divided into cells separated by lines. Text entered with the stylus pen into each cell is converted into electronic text.

To use the Character Pad, follow these steps:

1 Open the Tablet PC Input Panel and an editing program. 2 In the Tablet PC Input Panel, click the Character Pad icon ( ). 3 Write a letter in the cell of the Character Pad with the Stylus Pen and wait a moment. The writ-

ten letter is converted into the corresponding computer character.

Entering Text 23

4 Press the Insert button to enter a converted letter.

Insert

Entering text using the On-Screen Keyboard

The On-Screen Keyboard displays a standard keyboard on the screen. Text is entered by pressing the corresponding keys on the screen.

To use the On-Screen Keyboard, follow these steps:

1 Open the Tablet PC Input Panel and an editing program. 2 In the Tablet PC Input Panel, click the On-Screen Keyboard icon ( ). 3 Select letters using the Stylus Pen.

Entering Text 24

Entering text using the Dialkeys

DialKeys is an on-screen keyboard designed to be used with compact touch screen computers.

You can enter letters using the DialKeys by pressing key on the screen wi th your thumbs while holding both of the lower corners of the computer with your hands.

To launch the DialKeys for the first time, click Start > All Programs > Microsoft Touch Pack for Tablet PC > DialKeys. You can launch the DialKeys as follows after the first launch.

To use DialKeys, Follow thexe steps:

1 Click on the Dialkeys icon () on the taskbar. 2 Select Show/Hide DialKeys from the pop-up menu.

3 Open an editing program. 4 The Dialkeys appears on both lower corners of the screen. Enter letters using your thumbs.

Corresponds to the Enter key on a keyboard. Corresponds to the space bar on a keyboard. Minimizes the Dialkeys. Corresponds to the Backspace on a keyboard.

Move the current window upwards.

To View Detailed Usage of the Dialkeys

Click on the Dialkeys icon ( ) on the taskbar for more than 3 seconds and select Help from the pop-up menu.

Entering Text 25

Volume Control

You can control the volume with the Volume Control button or Volume Control program.

Controlling the Volume Using the Volume Control Button

Press the right side (+) of the Volume Control button ( ) to turn the volume up and press the left side (-) to turn the volume down.

Using the Volume Control Program

Click on the Volume icon ( ) on the taskbar and slide the volume bar up or down.

Alternatively, double-click on the Volume icon ( ) and adjust the master volume control.

Volume Control 26

Using the Buttons

The procedures to use the Menu, Quick Launch and Auto Scaler buttons are described below.

The Menu Button ( )

Press the Menu button to launch the Menu Program. The Menu Program provides shortcuts to frequently used functions on the computer. You can easily change the settings.

Press the Menu button again or press a point on the scre en to hide the Menu Program.

Menu Items Function Brightness Up This increases the LCD brightness by one step. Brightness Down This decreases the LCD brightness by one step. Wireless LAN ON (OFF) Turns the Wir eless LAN on or off. Sound ON (OFF) Turns the volume on or off. Backlit OFF Turns the LCD backlight off. Press a point on the screen once to turn it on again. Etiquette Mode ON (OFF) You can select Etiquette Mode for a tranquil work enviornment.

Using the Buttons 27

Press the item to view screen images on an external monitor. When pressing this item once, screen images are displayed on the LCD. When

pressing this item twice, screen images are displayed on both the LCD and the

LCD/CRT

Battery Shows the remaining battery charge.

Rotation

CRT (external monitor) simultaneously.

CRT Output Only is not supported.

Whenever this item is pressed, the screen rotates by 90 degrees to the left.

When rotating the screen, a part of the screen image may not be displayed in some software programs.

The Quick Launch Button

You can register a frequently used program, and launch a program just by pressing this button.

The procedures to change the default settings are described below.

Default Setting

The Quick Launch button is defined as follows by default.

Button Function Description u1 Mouse Scroll Up Scrolls up in the current window. u2 Back Moves to the previous page in Internet Explorer or Windows Explorer.

u3 Mouse Scroll Down

u4 Forward Moves to the next page in Internet Explorer or Windows Explorer.

Scrolls down in the current window.

Using the Buttons 28

Changing the Settings

The procedures to change the default settings are described below.

1 Double-click the Magic Keyboard icon ( ) on the taskbar. 2 Click the add button. 3

Enter a name in the

Group Name

field and select a shortcut key in the

Select Shortcut Key

field.

4 Select the Run Program option, click the Browse button, select a program to be launched

and click the Open button.

Example) C

Select a program and cl ick the Apply button.

:\Program Files\Internet Explorer\IEXPLORE

Keyboard Effect Function

A Keyboard Effect Function is used to simulate key combinations that are diffi cult to enter using the Tablet PC Input Pad.

For example, to simulate the Ctrl+C key combination by pressing the u2 button, select Key- board Effect, select Ctrl and C and click Apply.

5 Click OK to finish the setting.

Using the Buttons 29

The Auto Scaler Button

The default resolution of this computer is 800x480 pixels. In the default resolution, the complete screen image of programs designed for high resolutions may not be displayed properly. In this case, press the Auto Scaler button(Automatic Resolution Adjustment Button) on the left side of the computer and select a higher screen resolution.

When pressing the Auto Scaler button, the Auto Scaler menu appears. Whenever this button is pressed, the screen resolution changes between 800 x 480 (Default Resolution) > 800 x 600 > 1024 x 600 sequentially.

Example) Selecting a 800 x 480 pixels resolution

Example) Selecting a 800 x 600 pixels resolution

The Au to Scaler button provides a function that fits high resolu tion screen images to the screen size and does not support all resolutions supported by the graphics chipset. To select a resolution, which is not supported by Auto Scaler, use the Display Properties. ( p.43)

Using the Buttons 30

Using an external Monitor

Using an external display device is useful when giving a presentation or watching a movie.

Connecting a Monitor

Open the Monitor OUT port cover by pulling the cover and connecting a monitor.

Viewing on a Monitor

1 Press the Menu button. 2 Press the LCD/CRT item once to display screen images on the LCD screen.

When pressing the item twice, you can view screen images on both the LCD and CRT screens simultaneously.

LCD: Computer Screen CRT: External Monitor Screen

The Menu button does not support the function to display CRT only. To display CRT only, connect an external mouse, and configure it by selecting the ‘Display Prop-

erties’. For more detailed setup procedures, refer to the ‘Getting Started Guide’.

Using an external Monitor 31

Dual View

Dual View is a function that enables a computer screen to be viewed over two display devices. The Menu button does not support Dual Vi ew mode. You have to use Windows 'Display Properties'

to use Dual View.

When using Dual View, use a USB mouse. Using a mouse to move between screens is convenient. You can not move between screens using

the Stylus Pen.

Using Dual View to View an Extended Screen

Check if an external display device has been properly connected and configure Dual View.

1 Select Start > Control Panel > Appearance and Themes > Display. 2 Click the Settings tab. 3 Click the monitor '2' icon, select the 'Extend my Windows desktop onto this monitor'

check box and click Apply and then the OK button.

4 If the LCD is set as the primary display device, the primary display device (th e LCD) is indicated

as '1', and the secondary display device is indicated as '2'. Now you can view the screen through two monitors.

Using an external Monitor 32

It is recommended setting the LCD screen as the primary device ('1') when using Dual View.

If the screen of the secondary display device is display ed at 640x480 pi xels with 256 colors, select Start > Control Panel > Appearance and Themes > Display > Settings tab >

Monitor 2 and change the settings to the desired screen resolution and color quality.

To Move a Window between Monitors in Dual View Mode

Click and hold a window title bar on the primary display device ('1') with the mouse and drag the window title bar to the secondary display dev ic e ('2 ') to m ove the window.

Deactivating Dual View Mode

1 Select the Start > Control Panel > Appearance and Themes > Display > Settings tab. 2 Click the monitor '2' icon, unselect the 'Extend my Windows desktop onto this monitor'

check box and then click Apply.

Using an external Monitor 33

Chapter 3. Using Microsoft Windows XP

About Microsoft Windows XP 35

Get Going with the Tablet PC 35 Tablet PC Tutorials 36 Reinstalling Windows XP 36

The Windows XP Screen Layout 37

Desktop 37 Understanding the Start Menu 38 Understanding a Window 39

Control Panel 40

Opening the Control Panel 40 User Account 41 Changing the Resolution and Colors 43

About Microsoft Windows XP

The Microsoft Windows XP Tablet PC Edition (hereafter, Windows) operating system is installed on this computer. The Microsoft Windows XP Tablet PC Edition is an operating system based on Microsoft Windows XP Professional. Additional features for the tablet PC, such as a hand-writing recognition function, have been added.

You can learn elementary functions for using this PC through the Get Going with Tablet PC and Tablet PC Tutorials.

The computer has adopted touch screens so that yo u can operate the computer with you r hands and does not accord completely with the characteristics of a typical tablet PC.

In addition, since a Stylus Pen is provided instead of a Ta blet Pen, the Tablet and Pen Settings provided by the Windows XP Tablet PC Edition are not completely supported by the Pen Op- tions.

To calibrate the Pen, use the Touchkit program. ( p.21)

Get Going with the Tablet PC

Select Start > All Programs > Get Going with Tablet PC. The

Welcome to Tablet Computing

screen appears. Click

Start

to learn how to use your tablet PC.

About Microsoft Windows XP 35

Tablet PC Tutorials

You can tour elementary functions of your tablet PC and learn how to hand-write on the Writing Pad through the Tablet PC Tour.

The Tablet PC Tutorials only supports the 1024x768 pixels resolution. Before running the Tutorials, select the Start > Control Panel > Appearance and Themes > Display > Settings tab and change the screen resolution to 1024x768 pixels.

Select Start > All Programs > Tablet PC > Tablet PC Tutorials. The Tablet PC Tour screen appears. Click Next to learn how to perform 'Note Writing', 'Entering

texts with the Tablet PC Input Panel', etc.

Reinstalling Windows XP

If Windows cannot be started up due to damage to the system or errors frequently occur, you can reinstall Windows using the System Recovery Media (DVD). ( p.110)

You can use the system recovery media by connecting the external USB ODD to the system.

About Microsoft Windows XP 36

The Windows XP Screen Layout

The screen layout of Windows XP Tablet PC Edition is the same as that of Windows XP.

Desktop

The desktop is the working area on the computer. It consists of a large workspace and a taskbar at the bottom as shown in the figure below.

z Start

x Tablet PC Input Panel

Start Opens the Start menu. Tablet PC Input Panel The Input Pad used to enter letters. Taskbar Programs currently running are displayed here.

System Tray with Clock

Displays some program icons that are currently running. Infrequently used icons are hidden. Clicking the left arrow icon, displays hidden icons.

c Taskbar

v System Tray with Clock

The Windows XP Screen Layout 37

Understanding the Start Menu

The Start menu includes everything required to start Windows. From the Start menu it is possible to run a program, open a file, assign system users with the Contro l Panel, receive sup port by selectin g Help and Support, and search for items on the computer or on the Internet by selecting Search.

My Computer

Frequently used

programs

Control Panel

All Programs

Start Button

My Computer

Control Panel Enables users to configure settings on the computer.

Help and Support

Search Enables users to search for information in files or the Internet. Run Runs programs or documents.

Displays the contents of the hard disk, the CD-ROM drive, the network drive(s), and floppy disks. It can also be used to search and open files and folders.

Provides on-line help, information on Windows and troubleshooting.

Help and Support

The Windows XP Screen Layout 38

Understanding a Window

A window is the basic display compon ent of Wind ows computer s. The My Comput er window, wh ich displays information on the computer's hard drive, will be used as an example to show the basic composition of a window.

Click Start > My Computer.

Minimize Button

Maximize Button Close Button

Folder Icon

Drive Icon (Storage Device)

Title Bar

Tool Bar

Quick Task

Window

Menu Bar

Double-click the hard drive (local disk) to view the folders and files stored on in it. If the contents do not appear, click Show the contents of this folder.

What is a drive?

A storage device on which files and folders are saved in, and read from.

What is a folder?

A folder is used to group and manage files systematically, and may include files in sub-folders. It is similar to a filing cabinet.

What is a file?

A file is a document or a collection of various kinds of data generated as a result of program operation.

To view the entire structure of the drive

Click the Folder icon in the taskbar to view the entire stru cture. Clic k the ico n again to return to the Quick Task Window.

The Windows XP Screen Layout 39

Control Panel

The Control Panel contains tools to configure Windows.

Opening the Control Panel

Select Start > Control Panel.

Icon Name Function

Appearance and Themes

Network and Internet Connections

Add or Remove Programs

Sound, Speech and Audio Devices

Performance and Maintenance

Printers and Other Hardware

User Accounts This function is used to add or set up a Windows XP user account.

Date, Time, Language and Regional Options

Accessibility Options

Security Center

Changes the appearance of Windows. This function is used to change the Desktop, apply a theme and a screen

saver to the computer, and change the Start menu and Taskbar. This function is used to configure the network settings or configure and

add Internet connections.

This function is used to add remove a program from Windows.

This function is used to adjust the volume, select a sound scheme, and set up the speakers.

This function is used to configure the Windows performance options. In addition, you can manage the hard disk drive and hardware.

This function is used to add or configure a printer, mouse, keyboard, scanner, camera, or gaming device, etc.

This function is used to configure the date, time, language, and regional settings.

This function is used to select options for disabled persons and people with bad vision.

This function is used to check the current security status to protect a user's computer and configure the security settings for the firewall, virus antivirus program, etc.

Control Panel 40

User Account

Windows XP allows multi ple user to use a computer with their own user account. The procedures to add a user account and switch between user accounts are described below.

Adding a User Account

1 Select Start > Control Panel. 2 Double-click User Accounts and click Create a New account.

3 Click the Tablet PC Input Panel icon, enter a name and then click th e Next button. 4 Select an account type, click Create Account, and then check the newly created account in

the user account screen. If you cannot see the bottom of the screen, press and drag the scroll bar of the window with

the Stylus Pen.

5 To change the user account information, click on account to be changed.

You can change the account name, password, type and picture.

Control Panel 41

Deleting a User Account

1 Select Start > Control Panel > User Accounts. 2 Click on user account to be deleted and click Delete Account.

You cannot delete a currently logged in user account.

Switching Users

1 Select Start > Log Off. 2 Click Switch User.

3 Click on user account to login to the Start screen.

Control Panel 42

Changing the Resolution and Colors

The resolution means the number of pixels displayed on the screen. When selecting a higher resolution, items on the Desktop become smaller and more items can be displayed on the screen. The color quality can also be configured. The hig her the co lor qual ity, the mo re colors are displ aye d on the screen.

To change the screen resolution or color quality, follow these steps:

1 Select Start > Control Panel > Appearance and Themes > Display. 2 Click on Settings and change the Screen Resolution and Color Quality. 3 Click OK.

You can check your graphics chipset.

To set the color quality, select a color quality in the Color quality field.

To set the resolution, slide the resolution slide bar to a desired resolution in the Screen resolution field.

If the 800x480 resolution is not available

When selecting the 800x600 or 1024x600 resolution by pressing the Auto Scaler button, the 800x480 resolution may not appear in the Display Properties window. In this case, press the Auto Scaler button and select the 800x480 resolution.

About the 1024X768 Pixels Resolution

The 1024x768 pixels resolution is also fits to the screen size. You can select the 1024X768 pixels resolution by selecting the Start > Control Panel > Appearance and Themes > Display > Setting tab.

Control Panel 43

Chapter 4. Using the Network

Connecting to a Wireless LAN 45

Connecting to an Access Point (AP) 46 Connecting to computer-to-computer networks (peer-to-peer or ad hoc) 47 Setting up a Wireless Network Setup

Using the Wireless LAN Setup Program 50

Using Samsung Network Manager 51

Setting Up a Network 51 Accessing a network from a different location 54 Network Status Diagnosis 54

Using Bluetooth Devices 55

Bluetooth Software Setup 56 Using Bluetooth 58

Connecting to a Wireless LAN (Optional)

A wireless network (Wireless LAN) environment is a network envi ronment that enable s communication be tween multiple computers using wireless LAN devices.

Using the wireless network connections between computer systems, you can use no rmal net w ork functions such as sharing of files, folders and printers.

A wireless LAN card is optional. The model of the wireless LAN card is determined by the relevant product. To view the installed wireless LAN card, click Start > Control Panel > Performance and Maintenance > System > Hardware tab > Device Manager. The wireless LAN connection settings are described on the basis of a W indo ws XP S ervic e Pack 2 installed computer. It is recommended using the default settings provided by Windows XP as the wireless LAN settings for Windows XP installed computers. To setup the wireless card using the software supplied by the wirele ss LAN card man ufa ctur er, refer to "Setting up a Wireless Network Setup Using the Wireless LAN Setup Program" (p50). To use the Wireless LAN, the Wireless LAN must be turned on. Press the Menu button and press the Wireless LAN ON item to turn it on. If the Wireless LAN is turned on, the Wireless LAN LED ( ) is lit up.

Wireless Network Connection Types

Wireless network connections can be classified into two categories.

1) Access Point (AP)

You can connect to an AP to use the network. Th is is only possi ble in an enviro nment equipped wit h an AP. For details, see “Connecting to an Access Point (AP)” on page 46.

What is an Access Point (AP)?

An AP is a network device that bridges wired and wireless LANs, and act a s a wireless hub. You can connect multiple wireless LAN installed computers to an AP.

2) Computer-to-computer (ad hoc)

This is also called a peer-to-peer network. In computer-to-computer wireless networks, you can wirelessly connect 2 or more computers that

have wireless LAN modules. For details, see “Connecting to computer-to-computer networks (peerto-peer or ad hoc)” on page 47.

Connecting to a Wireless LAN (Optional) 45

Connecting to an Access Point (AP)

This section describes how t o connect to an AP. You can access t he network when you are co nnected to an AP.

For more detailed information, about your network, such as the network key (encryption key), ask your network administrator.

To connect to an AP, follow these steps:

1 Right-click(press and hold the S tylus Pen for more than 3 seconds) on the Wireless Network

Connections ( ) icon on the taskbar, and select View Available Wireless Networks.

2 Select an AP (E.g. see the Test network diagram below) to connect to and click Connect.

If there is a configured network key for the AP, the Enter Network Key window appears. Enter the Network Key and click the Connect button.

When on network key is defined for a selected AP, click on Link t o display the warning mess age box. Then click on Connect again in the box.

Now when Connected is displayed in the right corner of the AP information window, y ou can access the network.

Checking the connection status

Move the mouse pointer over the Wireless N etwork Connection ( ) icon on the taskbar to display the connection status.

Connecting to a Wireless LAN (Optional) 46

Connecting to computer-to-computer networks

In computer-to-computer wireless networks, you can connect two or more computers that have wireless LAN modules. Using this method, a computer that is not connected to the Internet can access the Internet through another computer connected to the Internet.

You can connect by completing the following steps:

(peer-to-peer or ad hoc)

• Step 1. Set up a computer-to-computer network on a computer.

• Step 2. Connect to the configured computer from other computers.

Step 1. Setting up a computer-to-computer network

1 Right-click(press and hold the S tylus Pen for more than 3 seconds) on the Wireless Network

Connection ( ) icon on the taskbar, and select View Available Wireless Networks.

2 Click Change the order of Preferred Networks.

3 In the Wireless Network tab, click Advanced. 4 Make sure the 'Automatically connect to non-default network' checkbox is not, s elected. Sel ect

'Computer-to-computer (ad hoc) networks only', and click Close.

5 In the Wireless Networks tab, click Add.

Connecting to a Wireless LAN (Optional) 47

6 Enter the network name (e.g. samsung), and unselect 'The key is provided for me automatical-

ly'. Enter the encryption key in the Network key field, and clic k OK.

To prevent a network access from unauth orized user, it is better to confi gure a network key (en cryption key). A network key consists of 5 ~ 13 alphanumeric characters (e.g. magic), or of 10 ~ 26 hexadecimal numbers (a hexadecimal number is represented by the numbers '0' to '9' and the letters 'a' to 'f').

7 Check that the configured network name (e.g. samsung) is in the ’Preferred networks’ item,

and click OK.

Now your wireless network setup has been completed.

Connecting to a Wireless LAN (Optional) 48

Step 2. Connecting to the configured computer

1 Right-click(press and hold the S tylus Pen for more than 3 seconds) on the Wireless Network

Connection ( ) icon on the taskbar, and select View Available Wireless Networks.

2 Select the wireless network name (e.g. samsung) specified in ”Connectin g to computer-to-com-

puter networks (peer-to-peer or ad hoc)” on page 47, and click Connect.

3 Enter a cryptographic key in the network key box and click Connect.

If the network key is not configured in ”Conne cting to computer-to-computer networks (peer-topeer or ad hoc)” on page 47, just click Connect, without any keystrokes.

When connected to the wireless network, the system displays Connected in the selected net work of the Network Connection window.

Checking the connection status

Move the mouse pointer over the Wireless Network Connection ( ) icon on the taskbar, to display the connection status is displayed.

Connecting to a Wireless LAN (Optional) 49

Setting up a Wireless Network Setup Using the Wireless LAN Setup Program

The procedures to connect to an access point using a wireless LAN configuration program are described below. Since the wireless LAN configuration program i s included on the System Software

Media, the user has to install the program.

Before Starting!

To use the system software media, the external USB ODD must be connected to the computer. The following descriptions presuppose that the external ODD is connected.

1 Insert the System Software Media into the CD drive and install the wireless LAN configura-

tion program (ACU: Atheros Client Utility). Select System Software Media > User Installation > Wireless LAN Driver ReadMe,

click ReadMe and install the program according to the instructions.

2 Right-click( press and hold the Stylus Pen for more than 3 seconds) on the wireless LAN con-

figuration program ( ) on the taskbar and select Open Atheros Client Utility. Alternatively, click Start > All Programs > Atheros Client Utility > Atheros Client Util-

ity.

3 In the Profile Management tab, click Scan to search for available wireless networks. 4 Select the name of an access point (AP) to connect to f rom the network name (SSID) and t hen

click Activate.

5 Enter a profile name to be used for the connection an d select the secu rity settings of the AP to

be connected to in the Security tab.

The network authentication, encryption type and password of an access point are configured through the access point management program. For the security information, check the security settings of an access point or ask your wireless network administrator.

Refer to the following when configuring a WEP key.

• Data encryption (WEP): The IEEE 802.11 WEP (Wired Equivalent Privacy) standard

defines two levels of encryption, a 64-bit key (this is sometimes represente d by 40bits) and a 128-bit key. When connecting to an Atheros access point, you can use the 152-bit key (32 hexadecimal digits or 16 ASCII characters).

• Key index: Select the current encryption key index used by the access point from between

1 to 4.

• Using an encryption key: Enter 5 (for 64-bit) or 13 (for 128-bit) alphanumeric characters

(represented by 0-9, a-z, or A-Z).

6 Click OK and then OK again in the Profile Management window.

If the profile is created, the profile appears in the list in the Profile Management tab and the connection is established using the profile.

Connecting to a Wireless LAN (Optional) 50

Using Samsung Network Manager

Samsung Network Manager is a program that helps configure the network settings.

Samsung Network Manager provides the following features.

• You can easily configure the network and printer settings.

• You can immediately use the network without defining new network settings again

after moving locations.

By setting the network settings (IP address, printer settings, etc.) for each location, you can immediately access the network without following network setting proc edures each time regardless of your location.

• You can diagnose the network status.

You can diagnose the network status when the network is not properly connected.

Setting Up a Network

The setup procedures include the procedures to add a printer to the network.

Before Starting!

Before configuring the network settings, cl ick the Auto Scaler butt on and set the resol ution to 800 x 600 or 1024 x 600 pixels. At the default resolution (800x480), the lower part of the software screen may not be displayed.

1 To use a wireless LAN, make sure it is on.

Press the Menu button and click the Wireless LAN ON item to turn it on. When the wireless LAN is turned on, the Wireless LAN LED () lights up.

2 Run Samsung Network Manager.

Select Start > All Programs > Samsung > Samsung Network Manager > Samsung Network Manager or double click the Samsung Network Manager( ) icon on the

Desktop.

3 Click the Add button. You may need to rotate the screen to access the Add button. 4 Select a network location icon and enter the name of the loc ation (e.g. Ho me). Click the Next

button.

Using Samsung Network Manager 51

5 Select Internet direct connection and click the Next butt on.

6 Select the LAN device, configur e the IP address, and click the Next button.

Select Device

Setup IP Address

Select Device

Select a device to be connected to the Internet. Select Wireless LAN.

Setting up the IP Address

To allocate an IP address automatically (DHCP), select Get IP Automatically. To use a static IP address, unselect Get IP Automatically and enter an IP addres s. For the IP

address information, ask your network administrator.

7 When the Printer Setting window appears, cl ick Finish.

To add a printer, click Add Printer. The Add Printer Wizard appears. Set up the printer according to the instructions displayed on the screen.

When the printer has been added, click the Show printer button, select the newly added printer and then click the Finish button.

To not add a printer, select No Default Printer and then click the Finish button.

When the network setting is complete, the ’Do you want to move to newly added location now?’ message appears. If you select ’Yes’, the net work settings for the adde d location are applied. When the network settings for the added location are applied, the added place and the corresponding network connection information is displayed in

The detailed Information for window

Using Samsung Network Manager 52

When the network setting is complete, an icon for the added location is created within the Saved Locations window. Now you can use the Internet at that location or add a new network location.

Current Place Information

Saved Locations

Wireless LAN AP Connection Procedures

To use a wireless LAN, first connect to a wireless LAN AP to acc ess the network even when at a different location. Or moving location and then you can access the netw ork even when connecting to a wireless LAN AP.

z Right-click over the Wireless Network Connection ( ) icon on the Taskbar and click

View Available Wireless Networks.

x Click Search AP from the Wireless menu to search for wireless LAN APs.

Select an available wireless network (e.g. SAMSUNG) and click the Connect button. For information on available wireless LAN APs, ask your network administrator.

Available AP

Connect

c The network key (security key) input window appears.

- If a network key has been configured for the wireless LAN AP, enter the network key and click the Connect button. For the network key information, ask your network administrator.

- If no network key has been configured for the wireless LAN AP, click the Connect button without entering the network key.

v When the computer is connected to the wireless LAN AP, the Connected message will ap-

pear on the Wireless Network icon in the Taskbar.

Using Samsung Network Manager 53

Accessing a network from a different location

By configured the network settings (IP address, printer setting, etc.) for each location, you can immediately access the network without performing the network setting procedures regardless of your location.

To access a network you have entered into the Network Manager, follow thes e ste ps :

1 Run Samsung Network Manager when connected to the Internet. 2 Select an icon that represents the corresponding location from the Saved Locations window and

then click Move. You may need to rotate the screen to click Move.

3 When the network settings of the selected location are applied, the new location and the net-

work connection information are displayed in The detailed Information for window.

Network Status Diagnosis

You can diagnose the network status when the network is not properly connected.

1 Run Samsung Network Manager. 2 Select Auto Diagnosis from the Manage menu. 3 The Network Connections figure window appears. Click the Start button to start the network

diagnosis.

4 When the diagnosis is c omplete, devi ces which ar e out of order are marked by the exclamation

mark icon. For detailed device status, read the description at the bottom of the window. Reconnect and set up the device according to the diagnosis result.

Using Samsung Network Manager 54

Using Bluetooth Devices (Optional)

Bluetooth is a wireless communication technology tha t allows access to nearby de vices such as computers, mobile phones, printers, keyboards or mice without a cable connection. Bluetooth enables file transmissions, Internet access, a private area network function, and access to a keyboard, mouse and printer between devices supporting the Bluetooth function without a cable connection.

Before Starting!

• The Bluetooth function is only available between devices supporting Bluetooth (computers,

mobile phones, PDAs, printers, etc.), and the function may be restricted depending on the device profile.

• The Bluetooth function is optional and may not be supported depending on your model.

• Compatibility with a Bluetooth device not certified by a Bluetooth certification or logo is not

guaranteed.

Bluetooth Functions

• File Transmission ( )

You can exchange files between 2 Bluetooth devices. You can exchan ge files with other computers, mobile phones, PDAs, etc.

• Network Access ( )

You can connect to another computer using the Bluetooth function as if accessing a wireless LAN in Ad-Hoc mode or connect to the Internet through an AP or Internet Connecting Sharing Server.

• Network Access through a Phone Connection ( )

You can connect to the Internet through a Bluetooth mobile phone.

• Data Sync (Synchronization) ( )

You can synchronize the PIMS data (Outlook E-mail address data) with mobile phones, PDAs, notebook computers, etc. supporting Bluetooth.

• Electronic Business Card (Vcard) Exchange ( )

You can exchange electronic business cards with mobile phones, PDAs, no tebook computers, etc. supporting Bluetooth.

• Sound Output ( )

You can listen to audio from the computer through another Bluetooth device or listen to audio of another Bluetooth device through the computer.

• HID Connections ( )

You can connect a keyboard, mouse, joystick, etc. supporting Bluetooth.

To use the Bluetooth function, refer to the online help of the corresponding Bluetooth device.

Using Bluetooth Devices (Optional) 55

Bluetooth Software Setup

Bluetooth software is installed on computers supporting Bluetooth. For first time use, configure the Bluetooth software as follows.

1 Double-click the My Bluetooth Environment icon ( ) on the Desktop.

2 Click the Next button to start the configuration.

In the configuration steps, enter a device name to be displayed in the Bluetooth Manager program. Enter a Name in the Computer Name field and select Laptop for the Computer Type field.

Also, a step appears for selecting the services to be provided by your Bluetooth device for othe r Bluetooth devices. At this point, the program automatically detects available services and displays them as selected. It is recommended keeping the default selection.

If you change the service settings, the drivers nec essary for the additionally selected services are installed.

At this point, a warning message may appear informing you that there is no Microsoft logo. Since it does not affect the operation, continue the in stallation.

Using Bluetooth Devices (Optional) 56

3 If the driver installation is complete, the next step proceeds which searches for nearby Blue-

tooth devices. Since you do not have to search while setting up, click the Skip button and finish the settings.

4 If the settings are complete, the My Bluetooth Environment window appears.

Using Bluetooth Devices (Optional) 57

Using Bluetooth

Describes how to exchange files between computers supporting Bluetooth and how to use other Bluetooth devices.

Bluetooth Help

Bluetooth Help provides detailed procedures on using Bluetooth functions.

Double-click on My Bluetooth Settings on the Desktop and click Help > Bluetooth Help from the top menu.

Select Start > Help and Support > Networking and the Web > Networking > Wireless networking > Bluetooth devices (wireless) to view Windows Help.

Exchanging Files between Bluetooth computers

The procedures to exchange files and folders between Bluetooth computers are described below.

1 On the computer which is sending a file (hereafter Computer A), right-click(press and hold the

Stylus Pen for more than 3 seconds) the Bluetooth icon ( ) on the taskbar and select Quick Connection > File Transmission > Search for Device.

2 In the Select Device window, click on a computer to be connected (hereafter Computer B).

Using Bluetooth Devices (Optional) 58

3 If the Bluetooth Security Settings window app ears, enter the Bluetooth Security Code (or

Bluetooth PIN) and click on Start Pairing.

The Bluetooth PIN Code is a password used for the connection betwe en two Bluetooth devic es, the user just enter the same PIN Code (E.g. same numbers) on both Bluetooth devices to make a connection.

4 After a short while, the Bluetooth PIN Code required dialog box appears on Computer B,

enter the same code entered in Step 3 above.

5 If the FTP File Access Privilege Request window appears on Computer B, click on the window.

If the Select Access Permission window appears , cl ick the OK button.

Using Bluetooth Devices (Optional) 59

6 The file transmission window appears on computer A. Drag files or folders to send onto the

window, and the files or folders are automatically transmitted.

7 If the file transmission is complete, close the File Transmission window.

The received files are saved in the C:\Documents and Settings\[user name]\My Documents

\Bluetooth Exchange folder.

Connecting Keyboard, Mouse, Joystick and Headset devices

The procedures to use Bluetooth HID devices (keyboard, mouse, joystick, etc.) or a headset, etc. on the computer are described below.

The Bluetooth PIN Code is a password used for the connection be tween two B luetooth de vices, the user simply enters the same PIN Code on both Bluetooth devices to make a connection.

1 Turn on the Bluetooth function on the device to connect to (mouse, keyboard, joystick or head-

set). Some devices have a button to turn on the Bluetooth function , so ref e r to th e corres ponding

device manual.

2 Double-click on the My Bluetooth Settings icon ( ) on the Desktop.

3 If the My Bluetooth Settings window appears, click on View Devices within Coverage.

If the device to connect to appears, click on the device. (E.g. mouse)

Using Bluetooth Devices (Optional) 60

If the device does not appear, click the View Devices w ithin Coverage. If the device has not appeared yet, since this menu changes to Search Devices within Coverage, click the Search Devices within Coverage to show the device.

4 If the Bluetooth PIN Code input window appears, enter a PIN code referring to the manual

of the corresponding device. The PIN code for an HID device is generally printed in the manual of the corresponding device.

5 If you enter the PIN code, you can immediately use the device.

A Bluetooth keyboard and mouse work only in Windows. They wil l not work in MS-DOS mode or in Hibernation mode.

Stopping a Bluetooth device

Right-click(press and hold the Stylus Pen for more than 3 seconds) the Bluetooth icon () on the taskbar and select Stop the Bluetooth Device.

To use a Bluetooth device after stopping it, select Start Bluetooth device as above.

Usage Instructions

• Bluetooth devices must be within a 3m (10 ft.) distance.

• For a better communications environment, use the devices in an open space where no wall or

obstacle exists.

• For a telephone connection, data synchronization, electronics business card exchange, fax

transmission/reception, sound related functions, and serial port function, you can connect with only one Bluetooth device.

• Using the network connection or file transmission function, multiple Bluetooth devices can be

connected. However, since connecting wi th multiple devices may slow down the data rate or make the connection unstable, connecting with one device at a time is recommended.

• The Bluetooth function of a Bluetooth PDA, mobile phone, mou se or key b oard may be tu rned

off. To use them in connection with a Samsung computer supporting Bluetooth, you must check if the Bluetooth function of the device to connect to is turned on.

For the procedures on turning on the Bluetooth function of a device, refer to the manual of the device.

• The services provided by Bluetooth devices may vary depending on their capability. For the

services provided by Bluetooth devices, refer to the manual of the device.

Using Bluetooth Devices (Optional) 61

Chapter 5. Using Applications

Introducing Programs 63 Using Samsung Update Plus 65 Program Launcher 67

Program Launcher Screen Layout 67 Using Program Launcher 68

Using AVStation premium 69

Start and Screen Layout 69 MUSIC Station 70 PHOTO Station 73 MOVIE Station 76

Using AVStation NOW / AVStation Viewer 79

Start / Exit AVStation NOW 79 Start / Exit AVStation Viewer 80 Screen Layout 81 MUSIC Station 81 PHOTO Station 83 MOVIE Station 84

CyberLink PowerDVD 86

Introducing Programs

Using software supplied with the Samsung computer, you can easily use functio ns and tro ubleshoo t problems. For detailed information, refer to the help of the corresponding software.

Before Starting!

Not every software program may be provided or the version may differ depending on your computer model.

Multi Media Functions

• Program Launcher

The Program Launcher cate gorizes frequent ly used programs, fol ders, web sites so t hat you can easily manage and access them. This program i s designed for the small LCD size so that you can easily use this program with the Stylus Pen or your fingers. (

p.67)

• AVStation premium ( )

AVStation premium is an integrated multimedia program that enables users to enjoy better music, photographs, video, movies, etc. quality all with a single program. (

p.69)

• AVStation Viewer

AVStation Viewer is a program that enables you to easily run AVStation premium in full screen.

p.79)

(

• AVStation NOW

AVStation NOW is an integrated mu ltimed ia pr ogram t hat en ables us ers to enjo y ph otog raphs, video, DVDs, music, etc. all with a single program and without booting Windows even when the computer is turned off. (

p.79)

Introducing Programs 63

• CyberLink PowerDVD ( )

CyberLink PowerDVD is a DVD player program suppl ied with the ext ernal USB OD D. To use this program, you have to install this program manually. (

p.86)

Management Functions

• Samsung Update Plus ( )

Samsung Update Plus is software that examines and updates the Samsung software and drivers installed on your Samsung computer to the most recent versions. (

p.65)

• Samsung Network Manager ( )

Samsung Network Manager is a program provided to support net work and Internet sharing set up.

You can configure the network settings by location and diagnose you r network. (

p.51).

• Samsung Battery Manager (

Samsung Battery Manager is a power management program that provides easy-to-use power management and power saving settings so that the battery usage time can be extended. (

)

• Samsung Display Manager

Samsung Display Manager is a program that displays the setting statu s of some but tons on the screen.

Example) The icon that appears when pressing the Menu button and clicking Brightness Up.

• Touchkit ( )

Touchkit is a program used to calibrate the Stylus Pen when the pointer position is not correct.

Troubleshooting Functions

• Magic Doctor ( )

Magic Doctor is troubleshooting software provid ed by Samsung Computer. A user can diagnose system problems via one-click or by selecting diagnostic items. (

p.103)

• Norton AntiVirus ( )

Norton AntiVirus is a program that examines the computer for viruses and deals with any found viruses. Since viruses may damage the files and data on your computer, it is recommended to examine your system frequently with the Norton AntiVirus program. (

p.104)

p.99

)

(

p.21)

Introducing Programs 64

Using Samsung Update Plus

Samsung Update Plus is software that examines and updates Samsung software and drivers installed on your Samsung computer to the latest version. To use S amsung Update Plus, your computer has to be con nected to the Internet.

To Update Samsung Software and Drivers

1 Select Start > All Programs > Samsung > Samsung Update Plus > Samsung Update

Plus.

If this is the first time you are running the program, a window will appear asking you if you agree to the agreement in the window.

Click Agree to use this software.

2 Click Search for and Install Updates and click the Search for New Updates button.

3 If there are available software or driver updates for your computer, the available updates will

be listed. Select the required updates from the list and click Install Update to start the update. (The update list on the screen may differ depending on the computer model.)

Updates that must be installed separately.

If you select Install as an update item that must be installed separately, a message appears informing you of this. Follow the instruction message to correctly install it.

Using Samsung Update Plus 65

Automatic update items display

By default, your computer is configured to automatically search for updates. If there is a new update available, this is displayed in the notification area. Click the balloon help icon in the notification area, to locate the latest available updates.

To change the automatic update settings, click the Configuration button in Figure 2 and change the settings.

Samsung Update Plus does not provide updates for additionally installed software and device drivers.

Using Samsung Update Plus 66

Program Launcher

The Program Launcher categorizes frequently used progra ms, folders, and websites so that you can easily manage and access them. This program is designed for the small LCD size so that you can easily use this program with the Sty lus Pen or your fingers.

Program Launcher Screen Layout

To launch the Program Launcher, click Start > All Programs > Microsoft Touch Pack for Tablet PC > Program Launcher.

The Program Launcher is launched.

Battery Charge Status

When clicking the icon, the Power Option Properties window appears.

Wireless LAN Status

When clicking the icon, the Network Connections window appears.

View Taskbar

Using Program Launcher

As an example, the procedures to launch the Calculator on the Program Launcher are described below.

1 Run the Program Launcher. 2 Select More Programs > Calculator. The Calculator program is launched.

• For more detailed usage

For more detailed usage, click Program Launcher Help from the Tools category.

• Program Launcher User Setting functions

You can add a category and add or delete a shortcut icon. Click on Customize Launcher from the Tools category to change the settings.

Program Launcher 68

Using AVStation premium

AVStation premium is an integrated multimedia program that enables users to enjoy music, photographs, video, movies, etc. all with a single program.

Before Starting!

• AVStation premium is optional and is not always provided depending on the model.

• The screenshots used in this manual may differ from the actual screens according to the pro-

gram version.

• TV Station is only available for systems supporting the TV function.

• To play an audio CD or DVD, you have to connect the external USB ODD to the computer.

The following descriptions presuppose that the external ODD is connected.

• For detailed usage, refer to the program help.

Start and Screen Layout

To launch the program, select Start > All Programs > Samsung > AVStation premium > AVStation premium.

Alternatively double-click the AVStation premium icon ( ) on the Desktop.

MUSIC

You can play a music file or an audio CD.


You can view or edit a photograph (image), and also view the photographs through in a SlideShow.

MOVIE

You can play a video (movie) file or a DVD/VCD title.

Station Bar

z x Menu Bar c Library v Exit

Press the Exit button to exit the program.

Using AVStation premium 69

MUSIC Station

Launch AVStation premium and click MUSIC on the Station Bar.

MUSIC Menu Bar

x Station Bar c MUSIC Library v Register a File b Playlist n Playlist Control Buttons m Play Control Buttons , Volume Control . Play Options

Playing an Audio CD

The procedures to play an audio CD are described below.

1 Launch AVStation premium and insert an audio CD into the CD drive. 2 In the Audio CD window, select Play Audio CD using Samsung AVStation and click the

OK button.

Using AVStation premium 70

3 The tracks on the audio CD are displayed in the Playlist and the first track is automati cally

played.

If an audio CD is already in the CD drive, double-click the album title in the Audio CD folder of the Library and add the tracks to the Playlist. The tracks added to the Playlist are played.

Playing a Music File

If a music file is registered to the MUSIC Library, you can easily play the music file. For the procedures to register tracks to the Library, refer to (

p.72).

1 Move to MUSIC Station and double-click on All Music. 2 Double-click a music file. The file is added to the playlist and played.

Using AVStation premium 71

• Playing a Track not registered to the Library

Click File > Open, select a music file to be play ed and c lic k Open. The sel ect ed tra ck is regis tered to the Library and played.

• Creating My Playlist

My Playlist is a personal album used to collect, manage and play your favorite music files. For the procedures to create My Playlist, refer to the descriptions of MUSIC Station in Help.

Adding Music Files to the Library

MUSIC Library is a library of music files used by MUSIC Station. The procedures to add music files saved on the computer to the Library are described below.

You can add files, folders or search and add files. As an example, the procedures to add a folder are described below.

1 Click on the Register a File ( ) button below the Library and click on Add by Folders.

2 Select a folder which includes music files and click the OK but ton. The mu sic files i n the folder

are added to the Library.

The tracks used in AVStation are automatically added to the Library.

Using AVStation premium 72

PHOTO Station

Launch AVStation premium and click PHOTO on the Station Bar.

PHOTO Menu Bar

x Station Bar c PHOTO Library v Register a File b Image Viewer Tab n Image Editor Tab m Move to a Higher-Level Folder , Preview/Zoom-in

Viewing an Image

The procedures to view images registered to the PHOTO Library indivedually or via a SlideShow are described below.

For the procedures to register image files to the Library, refer to (

p.75).

1 Move to PHOTO Station and double-click on All Images. 2 Click on a folder which includes images, and the images in the folder are displayed in the Image

Viewer window.

Image Viewer Window


Using AVStation premium 73

3 Double-click on an image. The selected image is zoomed in on.

• Viewing an Image not registered to the Library

Click File > Open, select an image file to view and click Open. The selected image file is registered to the Library and displayed in the Image Viewer window.

• Viewing an Image in Full Screen or through a SlideShow.

Click the Full Screen () button or SlideShow ( ) button below the Image Viewer window.

To return to the Image Viewer window, double-click on the screen.

• Watching a SlideShow while Listening to Music

To view a SlideShow while listening to music, play music from MUSIC Station and run SlideShow.

• Setting an Image as the Background.

Click the Set as Background ( ) button below the Image Viewer window. The selected image is set as the Desktop background.

Editing an Image

You can change the shape of an image, edit an image or apply special effects to an image. The image editor functions are described below.

1 Select an image to edit in the Image Viewer window, and select the Image Editor tab. The

Image Editor screen appears.

Using AVStation premium 74

The Image Editor screen consists of an Image Workspace window and 3 Tool tabs.

Image Workspace

Zoom In / Zoom Out

Tool Tabs

2 Edit the image using the Shape, Edit and Effect tools.

Shape tool: Change the shape of an image through cut, resize. Edit tool: Draw a line, add some clip art or enter letters. Effect tool: Apply various effects to an image.

3 When finishing editing an image, click the Save Edited Image ( ) button below the Im-

age Editor window. The edited image is saved.

Adding Images to the Library

The PHOTO Library is a library storing image files to be used by PHOTO Station. The procedures to add image files saved on the computer to the Library are described below.

You can add files, add folders or search and add files. As an example, the procedures to add folders are described below.

1 Click the Register a File ( ) button below the Library and click on Add by Folders.

2 Select a folder with image files and click the OK button. The image files in the folder are added

to the Library.

The image files used in AVStation are automatically added to the Library.

Using AVStation premium 75

MOVIE Station

Launch AVStation premium and click on MOVIE on the Station Bar.

x c v b n m , Capture Button

MOVIE Menu Bar Station Bar MOVIE Library Register a File Video Play window Play Control Buttons Volume Control

Playing a DVD

The procedures to play a DVD title are described below.

To play a DVD title, DVD playing software (e.g. CyberLin k PowerDVD) must be installed. Install the DVD playing software fir s t .

1 Launch AVStation premium and insert a DVD title into the DVD drive. 2 In the 'What do you want Windows to do?' window, select Play DVD Video using Sam-

sung AVStation and click the OK button.

Using AVStation premium 76

3 The DVD title is played.

If a DVD title is already in the DVD drive, double-click the DVD title in the DVD / VCD folder of the Library. The DVD title is played.

Playing a Movie(Video) File

The procedures to play a video file registered to the MOVIE Library are described below. For the procedures to register files to the Library, refer to

p.78.

1 Move to MOVIE Station and double-click All Movies. 2 Double-click a video file. The file is played .

• Playing a Video File not Registered to the Library

Click File > Open, select a video file to be played and click Open. The selected file is registered to the Library and played.

Using AVStation premium 77

• Playing a Video File in Full Screen

1) Double-click on the current playback screen.

2) The video is played in full screen. In full screen, move the mouse pointer to the bottom of the screen to show the Play Control bar.

To play at the default screen size, double-click on the screen.

• Capturing the Video Screen

Click on Capture Current Screen ( ) below the Play window when the desired image appears on the screen and click the OK button.

Captured images are saved in the C:

x.x

\Data\Captured Images folder.

In addition, you can view captured images in the PHOTO Station > Captured Images folder.

\Program Files\Samsung\AVStation premium

Adding Videos to the Library

The MOVIE Library is a library storing video fi les to be used by MOVIE Station. The procedures to add video files saved on the computer to the Library are described below.

You can add files, add folders or search and add files. As an example, the procedures to add folders are described below.

1 Click the Register a File ( ) button below the Library and click Add by Folders.

2 Select a folder which includes video files and click the OK button. The video files in the folder

are added to the Library.

The video files used in AVStation are automatically added to the Library.

Using AVStation premium 78

Using AVStation NOW / AVStation Viewer

Using these programs, you can play music, photographs, video and movies in full screen. You can enjoy multimedia files using AVStation NOW when the c omputer is off and using AVStation V iewer when the computer is on.

Before Starting!

• AVStation NOW and AVStation Viewer are optional and may not be provided depending on

the model.

• AVStation NOW Restrictions

You can only use AVStation NOW when the computer is turned off. Using AVStation NOW, you can play files re gist ered to the AVStatio n premium Library, saved

to My Computer, and saved on the multi-card slot. ( For the procedures t o register files t o the Library, refer to p.72,

If a login password for a Windows user account has been defined or if the folder is protected, you cannot play the files in the folder in AVStation NOW.

• In AVStation NOW, the Auto Scaler function is not available.

• AVStation Viewer Restrictions

Using AVStation Viewer, you can only play files registered to the AVStation premium Library. (For the procedures to register files to the Library, refer to

• Since the screen layout and usage of the two programs are similar, the manual describes the

functions and screens on the basis of AVStation NOW.

• The screenshots figures may differ from actual ones depending on the program version.

• TV Station is only available for systems supporting the TV function.

p.75 and p.78.)

p.72, p.75 and p.78.)

Start / Exit AVStation NOW

Starting

To turn the computer on, slide the Power switch/AVS NOW switch to the left ( ) and hold it for more than 0.1 seconds.

If the HOLD switch on the left side of the comput er is slid upwards all buttons of the computer are locked and do not function. If AVStation NOW is not launched, check the position of the HOLD switch.

Using AVStation NOW / AVStation Viewer 79

Exiting

Move the mouse pointer to the top screen and click the Exit () button.

Alternatively, slide and hold the Power switch/AVS NOW switch to the right for more than 0.1 seconds.

Start / Exit AVStation Viewer

Starting

Select Start > All Programs > Samsung > AVStation premium > AVStation Viewer from Windows.

Exiting

Move the mouse pointer to the top of the screen and click the Exit () button.

Using AVStation NOW / AVStation Viewer 80

Screen Layout

MUSIC

You can play a music file or audio CD.


You can view a photograph or image file one by one or in a SlideShow.

MOVIE

You can play a video, DVD or VCD title.

Settings

You can configure the Music, Photo and Movie settings.

Move to the start screen while using the program

Click over the top left in the current screen. Then the icon appears. When dicking this icon, you can move to the start screen.
