Samsung PS-42Q91HP, PS-50Q91HP User Manual

Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.

▪ Model _______________ ▪ Serial No. _______________

PDP-TELEVISION
(PLASMA DISPLAY PANEL)

Owner’s Instructions

Before operating the unit,

please read this manual thoroughly,

and retain it for future reference.

ON-SCREEN MENUS

Picture In Picture (PIP)

Energy Saving
TELETEXT (Option)
SRS TruSurround XT

Digital Natural Image engine

User Instructions

 Screen Image retention

Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the
plasma monitor panel for more than 2 hours as it can cause screen image retention. This image
retention is also known as “screen burn”. To avoid such image retention, reduce the degree of
brightness and contrast of the screen when displaying a still image.

 Height

The PDP can normally operate only under 2000m in height. It might abnormally function at a place
over 2000m in height so do not install and operate there.

 Heat on the top of the PDP TV

The top side of the product may be hot after long period of use as heat dissipates from the panel
through the vent hole in the upper part of the product. This is normal and does not indicate any defect
or operation failure of the product. However, children should be prevented from touching the upper
part of the product.

 The product is making a ‘cracking’ noise.

A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding
environment such as temperature or humidity. This is normal and not a defect of the unit.

 Cell Defects

The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require
sophisticated technology to produce. However, there may be few bright or dark pixels on the screen.
These pixels will have no impact on the performance of the product.

 Avoid operating the TV at temperatures below 5°C(41°F)

 A still image displayed too long may cause permanent damage to the PDP Panel.

 Afterimage on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may
produce partial afterimages. To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when
displaying still images.

 Warranty

- Warranty does not cover any damage caused by image retention.

- Burn-in is not covered by the warranty.

 Installation

Be sure to contact an authorized service centre, when installing your set in a location with heavy
dust, high or low temperatures, high humidity, chemical substance and where it operates continually
such as the airport, the train station etc. Failure to do so may cause a serious damage to your set.

Watching the PDP TV in 4:3 format for a long period of time may leave traces
of borders displayed on the left, right and centre of the screen caused by the
difference of light emission on the screen. Playing a DVD or a game console
may cause similar effect to the screen. Damages caused by the above effect are
not covered by the Warranty.

© 2007 Samsung Electronics Co., Ltd. All rights reserved.

English - 2

English - 3

Contents

General Information

 User Instructions ............................................. 2

 Checking Parts ................................................ 4

 Using the Stand-Base ..................................... 4

 Control Panel .................................................5

 Connection Panel ............................................ 6

 Viewing the Remote Control

(depending on the model) ............................... 8

Operation

 Switching Your Television On and Off ............. 9

 Viewing the Menus ........................................ 10

 Freezing the Current Picture ......................... 10

 Plug & Play Feature ...................................... 10

 Viewing an External Signal Sources ............. 12

 Editing Device Names ................................... 12

Channel Control

 Storing Channels Automatically .................... 13

 Sorting the Stored Channels ......................... 13

 Storing Channels Manually ........................... 14

 Adding / Locking Channels ...........................15

 Assigning Names to Channels ...................... 16

 Fine Tuning Channel Reception ....................16

Picture Control

 Changing the Picture Standard ..................... 17

 Customizing the Picture Settings .................. 17



Configuring Detailed Settings on the Picture

 Selecting the Picture Size ............................. 19



Digital NR / Active Colour / DNIe / Movie Plus

.. 18

... 20

Sound Control

 Sound Features ............................................ 21

 Selecting the Sound Mode

(depending on the model) ............................. 22

Function Description

 Time Features ............................................... 23



Language / Blue Screen / Melody / Light Effect /
Energy Saving / HDMI Black Level

 Using the Game Mode .................................. 25

 Wall- mount adjustment (Sold separately) .... 25

 Viewing the Picture in Picture (PIP) .............. 26

 Screen Burn Protection ................................. 27

.................. 24

PC Display

 Setting up Your PC Software

(Based on Windows XP) ............................... 28

 Input Mode (PC) ............................................ 29

 Setting the PC ............................................... 30

 Setting the Home Theatre PC ....................... 31

About Anynet

 What is Anynet+? .......................................... 32

 Connecting Anynet+ Devices ........................ 32

 Setting Up Anynet+ ....................................... 33

 Scanning and Switching between Anynet+

Devices ......................................................... 33

 Recording ...................................................... 34

 Listening through a Receiver ........................35

 Check Points before Requesting Service ..... 35

+

Appendix

 Teletext Feature (depending on the model) .. 36

 Setting Up Your Remote Control ...................38

 Installing the Wall Mount Kit .......................... 43

 How to assemble the Stand-Base

(depending on the model) ............................. 44

 Troubleshooting ............................................44

 Specifications ................................................ 45

Symbols

Press

☛ ➢

Important

Note

Checking Parts

Owner’s Instructions Remote Control/AAA Batteries Power Cord Cloth-Clean

Warranty Card/

Registration Card/

Safety Guide Manual

S-Video Cable Antenna Cable Component Cables Audio Cables Video Cable

PC Cable PC Audio Cable HDMI Cable HDMI/DVI Cable

Ferrite Core (Power Cord, Side-Video Cable,

➢

Headphones Cable, S-Video Cable)

The ferrite core is used to shield the cable from
interference. When connecting a cable, open the
ferrite core and clip it around the cable.

Cover-Bottom / Screws (2ea)

(Refer to page 44)

Sold Separately

Ferrite Core for Power Cord /

Side-Video Cable /

S-Video Cable

Ferrite Core for

Headphones Cable /

Power Cord

Using the Stand-Base

Two or more people should carry

➢ 

the PDP. Never lay the PDP on the
floor because of possible damage
to the screen. Always keep the
PDP upright.

 The PDP can rotate 20 degrees in

right and left directions.

-20° ~ 20°

English - 4

English - 5

Control Panel

Front (or Side) Panel

Speaker

The product colour and shape may vary depending on the model.

➢

1

SOURCE

Displays a menu of all of the available
input sources (TV, AV1, AV2, S-Video,

Component1, Component2, PC, HDMI1,
HDMI2, and HDMI3).

2

MENU

Press to see the on-screen menu of your TV’s
features.

3

+ VOL −

Press to increase or decrease the volume.
In the on-screen menu, use the + VOL −
buttons as you use the + and − buttons on the
remote control.

4

CH

Press to change channels. In the on-screen
menu, use the CH buttons as you use
the and buttons on the remote control.

5

(ENTER/OK)

Press to confirm a selection.

6

(Power) button

Press to turn the TV on and off.

Power Indicator

− Power Off: Blue

− Power On: Off

Remote Control Sensor

Aim the remote control towards this spot on
the TV.

Connection Panel

Side Panel

1

2

3

The product colour and shape may vary depending on the model.

➢

 Whenever you connect an audio or video system to your set, ensure that all elements are

☛

switched off.

 When connecting an external device, match the colour of the connection terminal to the cable.

1

HDMI IN 3

Connect to the HDMI jack of a device with
HDMI output.

2

AV IN 2(S-VIDEO or VIDEO / AUDIO R/L)

Video (S-Video or Video) and audio inputs for
external devices, such as a camcorder or VCR.

or

3

Headphones jack

You can connect a set of headphones if you
wish to watch a television programme without
disturbing the other people in the room.

Prolonged use of headphones at a high

➢

volume may damage your hearing.

English - 6

Continued...

English - 7

Rear Panel

9

1

or

Cable Television
Network

4

or

8

The product colour and shape may vary depending on the model.

➢

 Whenever you connect an audio or video system to your set, ensure that all elements are

☛

switched off.

 When connecting an external device, match the colour of the connection terminal to the cable.

6

57

3

2

1

ANT IN

75Ω Coaxial connector for Aerial/Cable
Network.

2

HDMI IN 1

Connect to the HDMI jack of a device with
HDMI output.

3

PC IN / AUDIO

Connect to the video and audio output jack on
your PC.

4

SERVICE

Connector for service only.

5

COMPONENT IN 1, COMPONENT IN 2

Video (Y/PB/PR) and audio (AUDIO R/L) inputs
for Component.

6

AV IN 1(VIDEO / AUDIO R/L)

Connect RCA cable to an appropriate external
A/V device such as VCR, DVD or Camcorder.

7

AUDIO OUT(AUDIO R/L)

Connect RCA audio signals from the TV to an
external source, such as Audio equipment.

8

HDMI IN 2

- Connect to the HDMI jack of a device with
HDMI output. These inputs can also be used
as a DVI connection with separate analog
audio inputs.

An optional HDMI/DVI cable will be necessary
to make this connection. When using the
optional HDMI/DVI adapter, the DVI analog
audio inputs on your TV allow you to receive
left and right audio from your DVI device.
(Not compatible with PC)

- When connecting this product via HDMI or
DVI to a Set Top Box, DVD Player or Games
Console etc, make sure that it has been set
to a compatible video output mode as shown
in the table below. Failure to observe this may
result in picture distortion, image breakup or
no picture.

- Do not attempt to connect the HDMI/DVI
connector to a PC or Laptop Graphics Card.
(This will result in a blank screen being
displayed)

DVI IN (HDMI 2) AUDIO R/L
DVI audio outputs for external devices.

9

POWER IN

Connect the supplied power cord.

Supported modes for HDMI/DVI and Component

HDMI/DVI 50Hz X X X O O O

HDMI/DVI 60Hz X O X X O O

Component O O O O O O

480i 480p 576i 576p 720p 1080i

Viewing the Remote Control (depending on the model)

This is a special remote control for the visually impaired persons, and has Braille points on the

➢ 

POWER, Channel, Volume, STOP, and PLAY/PAUSE buttons.

 The performance of the remote control may be affected by bright light.

1

POWER button

(turns the TV on and off)

2

Number buttons for direct

channel access

3

One/Two-digit channel

selection

4

Channel control button

(Refer to page 15)

5

Selects the TV mode directly

6

:Volume increase

:Volume decrease

7

Temporary sound switch-off

8

Displays the main on-screen

menu

9

Returns to the previous

menu

0

Sound effect selection

(Refer to page 21)

!

Picture effect selection

(Refer to page 17)

$

Picture-In-Picture On/Off

%

Sound mode selection

^

TruSurround XT mode

button

&

Remote control setup

*

Selects a target device to be

controlled by the Samsung
remote control (TV, DVD,
STB, CABLE, VCR)

(

Press to activate backlight of

the VOL, CH, and the active
source button (TV, DVD,
CABLE, STB, VCR) on the
remote.

)

Available source selection

a

Previous channel

b

Automatic Power-off

c

Records for Live

Broadcasting (Not available)

d

VCR/DVD Function (Rewind,

Stop, Play/Pause, Fast/
Forward

e

:Next channel

:Previous channel

f

Exit the on-screen menu

g

Move to the required menu

option / Adjust an option
value respectively

h

Use to see information on

the current broadcast

i

Runs the Anynet+ view

functions and sets up Anynet
devices. Please refer to the
Anynet+ Owner’s Instruction.

j

Picture size selection

k

Picture freeze

l

Sub picture (PIP) source

selection

m

Sub picture (PIP) channel

selection

n

Sub picture (PIP) location

selection

o

If your remote control is not

functioning properly, take out
the batteries and press the
reset button for about 2~3
seconds.
Re-insert the batteries and
try using the remote control
again.

Teletext Functions

(Refer to page 36)

8

Teletext index

@

Fastext topic selection

#

Teletext display/mix both

teletext information and the
normal broadcast

$

Teletext hold

)

Teletext mode selection

(LIST/FLOF)

a

Teletext sub page

e

P :Teletext next page

P :Teletext previous page

f

Teletext cancel

h

Teletext reveal

l

Teletext size

n

Teletext store

+

English - 8

Continued...

English - 9

Installing Batteries in the Remote Control

1 Lift the cover at the back of the remote control upward as

shown in the figure.

2 Install two AAA size batteries.

 Make sure to match the “+” and “–” ends of the

➢

batteries with the diagram inside the compartment.

 Do not mix battery types, i.e. alkaline and manganese.

3 Close the cover as shown in the figure.

Remove the batteries and store them in a cool and dry

➢

place if you won’t be using the remote control for a long
time. The remote control can be used up to about 23 feet
from the TV. (Assuming typical TV usage, the batteries last
for about one year.)

If the remote control doesn’t work! Check the following:

➢

1. Is the TV power on?

2. Are the plus and minus ends of the batteries reversed?

3. Are the batteries drained?

4. Is there a power cut, or is the power cord unplugged?

5. Is there a special fluorescent light or a neon sign nearby?

Switching Your Television On and Off

The mains lead is attached to the rear of the television.

1 Plug the mains lead into an appropriate socket.

The main voltage is indicated on the rear of the television and the frequency is 50 or 60Hz.

➢

2 Press the (Power) button (On/Off) on the front of the television or press the POWER button on the

remote control to switch the television on. The programme that you were watching last is re-selected
automatically. If you have not yet stored any channels, no clear picture appears. Refer to “Storing
Channels Automatically” on page 13 or “Storing Channels Manually” on page 14.

If the television is initially powered on, several basic customer settings proceed automatically.

➢

Refer to “Plug & Play Feature” on pages 10~11.

3 To switch the television off, press the (Power) button (On/Off) on the front of the television or press

the POWER button on the remote control.

4 To switch the TV on, press the (Power) button (On/Off) on the front of the TV or press the POWER

button or number buttons on the remote control.

Viewing the Menus

1 Press the MENU button.

The main menu is displayed on the screen.
Its left side has five icons: Picture, Sound, Channel, Setup,
and Input.

2 Press the ▲ or ▼ button to select one of the icons.

Press the ENTER/OK button to access the icon’s sub-menu.

3 Press the ▲ or ▼ button to move to items in the menu.

Press the ENTER/OK button to enter items in the menu.

4 Press the ▲/▼/◄/► button to change the selected items.

Press the RETURN button to return to the previous menu.

5 Press the EXIT button to exit from the menu.

Freezing the Current Picture

You can freeze the picture when watching a television
programme simply by pressing the “STILL” button. To return
to normal viewing, press it again.

To prevent screen burn-in, this function will automatically

➢

become inactive in 5 minutes.

T V

Mode :
Contrast 100
Brightness 45
Sharpness 75
Colour 55
Tint G 50 R 50
Colour Tone :

Detailed Settings

 More

Move


Dynamic 

Cool1 

Enter Exit



Plug & Play Feature

When the television is initially powered on, several basic
customer settings proceed automatically and subsequently.
The following settings are available.

1 If the television is in standby mode, press the POWER button

on the remote control. The message Start Plug & Play. is
displayed. Press the ENTER/OK button. Language menu is
displayed.

If any language is not selected on the Language menu, the

➢

Language menu will disappear about 30 seconds later.

2 Select the appropriate language by pressing the ▲ or ▼ button.

Press the ENTER/OK button. The message Select Home
Mode when installing this TV at home. is displayed.

English - 10

Language

Move

Plug & Play

Start Plug & Play.

Enter

Plug & Play

Français

Enter

OK

English

Exit

Skip

Continued...

English - 11

3 Press the ◄ or ► button to select Shop or Home, then press

the ENTER/OK button. The message to check the connected
status of the antenna is displayed.

 The default selection is Home.

➢

 We recommend setting the TV to Home mode for the

best picture in your home environment.

 Shop mode is only intended for use in retail

environments.

 If the unit is accidentally set to Shop mode and you

want to return to Dynamic (Home) mode, press the
Volume button and then hold down the MENU button
for five seconds on the TV pannel.

4 Make sure that the antenna is connected to the TV.

Press the ENTER/OK button. Area menu is displayed.

5 Select your country or area by pressing the ▲ or ▼ button,

then press the ENTER/OK button. Auto Store menu is
displayed.

6 Press the ENTER/OK button to start search the channels.

The channel search will start and end automatically. After
all the available channels are stored, Clock Set menu is
automatically displayed. Press the ENTER/OK button.

To stop the search before it has finished, press the

➢

ENTER/OK button with Stop selected.

7 Press the ◄ or ► button to select Month, Day, Year, Hour,

Minute or am/pm. Set these by pressing the ▲ or ▼ button.

You can set the Month, Day, Year, Hour, and Minute

➢

directly by pressing the numeric buttons on the remote
control.

8 Press the ENTER/OK button to confirm your setting.

The message Enjoy your viewing is displayed.
When you have finished, press the ENTER/OK button.

Even if the ENTER/OK button is not pressed, the

➢

message will automatically disappear after several
seconds.

Plug & Play feature is available in the TV mode only.

➢

Plug & Play

Select Home Mode
when installing this TV at home.

Enter

Plug & Play

OK

Enter

Plug & Play

Asia/W.Europe

CIS/E.Europe

China

Hong Kong/UK

▼

Enter

Plug & Play

Start

Enter

Plug & Play

: -- am

Move

Home

Shop

Move

Check antenna input.

Area

Move

Auto Store
P 1 C -- 40 MHz
0 %

Clock Set

Month Day Year Hour Minute

▼

-- -- --- - --

▼

Adjust

Skip

Skip

Skip

Skip

Enter

am/pm

If you want to reset this feature …

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ENTER/OK button again to select Plug & Play.

The message Start Plug & Play. is displayed.

Enjoy your viewing

OK

T V

Plug & Play
Language :
Time

Game Mode : Off

Blue Screen :
Melody : Off 

PC
Home Theatre PC : Off

Light Effect :
 More

Move

Setup

English 





Off 





On 

Enter



Return

Viewing an External Signal Sources

You can switch between viewing signals from connected
equipment, such as a VCR, DVD, Set-Top Box, and the TV

T V

source (broadcast or cable).

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Input, then press the

ENTER/OK button.
3 Press the ENTER/OK button again to select Source List.
5 Press the ▲ or ▼ button to select the signal source, then press

the ENTER/OK button.
Available signal sources:

TV, AV1, AV2, S-Video,

T V

Component1, Component2, PC, HDMI1, HDMI2, HDMI3

Only the connected devices can be selected.

➢

You can select these options simply by pressing the SOURCE

➢

button on the remote control.

To watch television programme again, press the TV button and

➢

select the channel number required.

Press the INFO button on the remote control to see the current

➢

input source.

Move

Move

Input

Source List

Enter

Enter

Source List :
Edit Name
Anynet+ (HDMI-CEC)

TV
AV1 :
AV2 :
S-Video :
Component1 :
Component2 : −−−−
PC :
HDMI1 :
HDMI2 :
HDMI3 :

TV 

Return

−−−−

−−−−

−−−−

−−−−

−−−−

−−−−

−−−−

−−−−

Return



Editing Device Names

You can give a name to the external source.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Input, then press the

ENTER/OK button.
3 Press the ▲ or ▼ button to select Edit Name, then press the

ENTER/OK button.
4 Press the ▲ or ▼ button to select the external source to be

edited, then press the ENTER/OK button.
5 Select the required device by pressing ▲ or ▼, then press the

ENTER/OK button.

Available device names:

HD STB, Satellite STB, AV Receiver, DVD Receiver, Game,

Camcorder, DVD Combo, DHR (DVD HDD Recorder), PC
6 Press the EXIT button to exit.

VCR, DVD, D-VHS, Cable STB,

English - 12

T V

Source List :
Edit Name
Anynet+ (HDMI-CEC)

T V

AV1 :

AV2 :
S-Video :
Component1 :
Component2 :
PC :
HDMI1 :
HDMI2 :
HDMI3 :

Move

Move

Edit Name

Input

TV 

Enter

−−−−

−−−−

−−−−

VCR

−−−−

DVD

−−−−

D-VHS

−−−−

Cable STB

−−−−

HD STB

−−−−

Satellite STB

−−−−

−−−−

Enter



Return

▼

Return

English - 13

Storing Channels Automatically

You can scan for the frequency ranges available to you
(availability depends on your country).

T V

Automatically allocated programme numbers may not
correspond to actual or desired programme numbers.
However you can sort numbers manually and clear any
channels you do not wish to watch.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.
3 Press the ENTER/OK button to select Area.

T V

4 Select your area by pressing the ▲ or ▼ button, then press the

ENTER/OK button.
5 Press the ▲ or ▼ button to select Auto Store, then press the

ENTER/OK button.
6 Press the ENTER/OK button again to start the search.

The search will end automatically.

To stop the search before it has finished, press the

➢

RETURN or the ENTER/OK button.

Move

Move

Auto Store

--

Start

Enter

Channel

Enter

Return

Channel

Asia/W.Europe

CIS/E.Europe

China

Hong Kong/UK

Australia

NZL/Indonesia

South Africa

America

Enter

Return

40 MHz

Return

Area : Asia/W.Europe
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

Area : Asia/W.Europe

Auto Store
Manual Store
Channel Manager
Sort
Name
Fine Tune

P 1 C
0 %



Sorting the Stored Channels

This operation allows you to change the programme numbers
of the stored channels.
This operation may be necessary after using the auto store.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.
3 Press the ▲ or ▼ button to select Sort, then press the

ENTER/OK button.
4 Select the channel that you wish to move by pressing the

▲ or ▼ button, then press the ENTER/OK button.
5 Select the number of the programme to which the channel is

to be moved by pressing the ▲ or ▼ button.

Press the ENTER/OK button. The channel is moved to its new

position and all other channels are shifted accordingly.
6 Repeat steps 4 to 5 until you have moved all the channels to

the required programme numbers.

7 Press the EXIT button to exit.

T V

Area :
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

Move

T V

Prog. Ch. Name



0 C−−

1 C76

2 C5

3 C7

4 C8



Move

Channel

Asia/W.Europe 

Enter

Sort

Enter

Return



Return

Storing Channels Manually

You can store television channels, including those received via
cable networks.
When storing channels manually, you can choose:

 Whether or not to store each of the channels found.
 The programme number of each stored channel which you wish

to identify.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.
3 Press the ▲ or ▼ button to select Manual Store, then press

the ENTER/OK button.
4 Select the required option by pressing the ▲ or ▼ button, then

press the ENTER/OK button.
5 When you are satisfied with your setting, press the ENTER/OK

button.

T V

Area :
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

Move

T V

Manual Store

Programme :
Colour System : Auto 
Sound System : BG 
Channel : C 4
Search : 63 MHz
Store : ?

Channel

Asia/W.Europe 

Enter

P 1

Return

6 Press the EXIT button to exit.

 Programme (Programme number to be assigned to a channel)

− Press the ▲ or ▼ button until you find the correct number.
You can also select the channel number directly by pressing the numeric buttons (0~9) on the

➢

remote control.

Move

Enter

Return

 Colour System: Auto/PAL/SECAM/NTSC 4.43/NTSC 3.58

− Press the ▲ or ▼ button to select the required colour standard.

 Sound System: BG/DK/I/M

− Press the ▲ or ▼ button to select the required sound standard.

 Channel (When you know the number of the channel to be stored)

− Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel).

− Press the ► button, then press the ▲ or ▼ button to select the required number.
You can also select the channel number directly by pressing the numeric buttons (0~9) on the

➢

remote control.

If there is abnormal sound or no sound, re-select the sound standard required.

➢

 Search (When you do not know the channel numbers)

− Press the ▲ or ▼ button to start the search.

− The tuner scans the frequency range until the first channel or the channel that you selected is

received on the screen.

 Store (When you store the channel and associated programme number)

− Set to OK by pressing the ENTER/OK button.

Channel mode

☛

 P (Programme mode): When completing tuning, the broadcasting stations in your area have

been assigned to position numbers from P00 to P99. You can select a channel by entering the
position number in this mode.

 C (Air channel mode): You can select a channel by entering the assigned number to each air

broadcasting station in this mode.

 S (Cable channel mode): You can select a channel by entering the assigned number for each

cable channel in this mode.

English - 14

English - 15

Adding / Locking Channels

Using the Channel Manager, you can conveniently add or lock
channels.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Channel Manager, then

press the ENTER/OK button.

 Adding channels

Using the Channel List, you can add channels.

4 Press the ENTER/OK button again to select Channel List.
5 Move to the ( ) field by pressing the ▲/▼/◄/► buttons,

select a channel to be added, and press the ENTER/OK button
to add the channel.

If you press the ENTER/OK button again, the ( ) symbol

➢

next to the channel disappears and the channel is not
added.

 Locking channels

This feature allows you to prevent unauthorized users, such as
children, from watching unsuitable programmes by muting out
video and audio.

6 Press the ▲ or ▼ button to select Child Lock, then press the

ENTER/OK button.

7 Select On by pressing the ▲ or ▼ buttons, then press the

ENTER/OK button.

8 Press the ▲ or ▼ button to select Channel List, then press

the ENTER/OK button.

9 Move to the ( ) field by pressing the ▲/▼/◄/► buttons,

select a channel to be locked, and press the ENTER/OK
button.

If you press the ENTER/OK button again, the ( )

➢

symbol next to the channel disappears and the channel
lock is canceled.
A blue screen is displayed when Child Lock is activated.

➢

10 Press the EXIT button to exit.

T V

Area :
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

Move

T V

T V

Channel Manager

Channel List
Child Lock : Off 

Move

Channel List

P 1 C 4

Prog.

0 C -

-

1 C 4
2 C 24
3 C 2
4 C 5
5 C 80
6 C 7
7 C 36
8 C 52
9 C 11

Add Lock
Move Enter

Page

Channel Manager

Channel List

Child Lock : Off

Channel

Asia/W.Europe 

Enter

Enter

Return

Off

On

Return



Return

1/10

▲

▼

You can select these options simply by pressing the CH LIST

➢

button on the remote control.

Move

Enter

Return

Assigning Names to Channels

Channel names will be assigned automatically when channel
information is broadcast. These names can be changed,

T V

allowing you to assign new names.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Name, then press the

ENTER/OK button.

4 Press the ▲ or ▼ button to select the channel to be assigned

to a new name, then press the ENTER/OK button.

T V

5 Press the ▲ or ▼ button to select a letter, a number, or a

symbol (Results in this sequence: A~Z, 0~9, +, -, *, /, blank).
Move on to the previous or next letter by pressing the ◄ or ►
button, then press the ENTER/OK button.

6 Repeat steps 4 to 5 for each channel to be assigned to a new

name.

7 Press the EXIT button to exit.

Fine Tuning Channel Reception

If the reception is clear, you do not have to fine tune the
channel, as this is done automatically during the search and
store operation.
If the signal is weak or distorted, you may have to fine tune the
channel manually.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Channel, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Fine Tune, then press the

ENTER/OK button.

4 To obtain a sharp, and clear picture and good sound quality,

press the ◄ or ► button until you reach the optimal setting.
Press the ENTER/OK button.

To reset the fine tuning to 0, select Reset by pressing the

➢

▲ or ▼ button. Press the ENTER/OK button.

5 Press the EXIT button to exit.

Press the INFO button. Fine Tune Store will change the

➢

colour of the Channel OSD (On Screen Display) from white
to red and add the “

” mark.

*

T V

P 1

+2

P 1 *
Mono

Picture : Dynamic
Sound : Custom
SRS TS XT : Off

−−

Channel

Area :
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

Prog. Ch. Name

0 C−− −−−−−

1 C76 −−−−−

2 C5 −−−−−

3 C7 −−−−−

4 C8 −−−−−

Area :
Auto Store 
Manual Store 
Channel Manager 
Sort 
Name 
Fine Tune 

*

Adjust

:

−− am

Asia/W.Europe 

Move

Enter

Name

A

Move Adjust

Channel

Asia/W.Europe 

Move

Enter

Fine Tune

Reset

Save

Return

Return

Return

Return

English - 16

English - 17

Changing the Picture Standard

You can select the type of picture which best corresponds to
your viewing requirements.

1 Press the MENU button to display the menu.
2 Press the ENTER/OK button to select Picture.
3 Press the ENTER/OK button again to select Mode.
4 Select the required mode by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available modes:

The settings values may vary depending on the input

➢

source. (ex. RF, Video, Component, PC, or HDMI)

Dynamic, Standard, Movie

5 Press the EXIT button to exit.

Choose Dynamic for viewing the TV during the day or

➢ 

when there is bright light in the room.



Choose Standard for general TV watching mode.
Choose Movie when viewing the movie.



You can select these options simply by pressing the P.MODE

➢

button on the remote control.

Customizing the Picture Settings

Your television has several setting options that allow you to
control the picture quality.

1 Press the MENU button to display the menu.
2 Press the ENTER/OK button to select Picture.
3 Press the ENTER/OK button again to select Mode.
4 Select the required mode by pressing the ▲ or ▼ button,

then press the ENTER/OK button.
Available modes:
5 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.
6 When you are satisfied with your setting, press the ENTER/OK

button.
7 Press the EXIT button to exit.

 Contrast – Brightness – Sharpness – Colour – Tint

In TV, AV, S-Video modes of the PAL system, you cannot

➢

use the Tint function.

Contrast – Brightness – Colour Tone : PC Mode

Press the ◄ or ► button until you reach the optimal setting.
 Colour Tone: Cool2/Cool1/Normal/Warm1/Warm2

When the picture mode is set to Dynamic or Standard,

➢

Warm1 and Warm2 cannot be selected.

 Reset: Cancel/OK
Select

OK. You can return to the factory defaults picture settings.

The reset function is set for each picture mode and colour tone.

➢

Dynamic, Standard, Movie

T V

Mode :
Contrast 100
Brightness 45
Sharpness 75
Colour 55
Tint G 50 R 50
Colour Tone :

Detailed Settings

 More

T V

Mode :
Contrast 100
Brightness 45
Sharpness 75
Colour 55
Tint G 50 R 50
Colour Tone :

Detailed Settings

 More

T V

Mode :
Contrast 100
Brightness 45
Sharpness 75
Colour 55
Tint G 50 R 50
Colour Tone :

Detailed Settings

 More

Contrast 100

Move Adjust

T V

Mode :
Contrast 100
Brightness 45
Sharpness 75
Colour 55
Tint G 50 R 50
Colour Tone :

Detailed Settings

 More

Move

Move

Move

Move


Dynamic 

Cool1 

Enter


Dynamic 

Cool1

Enter


Dynamic 

Cool1 

Enter


Dynamic 

Cool1

Enter

Dynamic

Standard

Movie

Cool2

Cool1

Normal

Warm1
Warm2

Return

Return

Return

Return

Return





Configuring Detailed Settings on the Picture

You can set detail picture settings.

1 Press the MENU button to display the menu.
2 Press the ENTER/OK button to select Picture.
3 Press the ▲ or ▼ button to select Detailed Settings, then

press the ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options: Black Adjust

, Dynamic Contrast,

Gamma, Colour Space, White Balance, My Colour
Control, Edge Enhancement.

5 When you are satisfied with your setting, press the ENTER/OK

button.

6 Press the EXIT button to exit.

When the picture mode is set to Movie or Standard, Detailed

➢

Settings can be selected.
If DNIe is Off, the Detailed Settings cannot be selected when

➢

the Picture mode is in Standard mode.

T V

Mode : Movie 
Contrast 80
Brightness 65
Sharpness 35
Colour 55
Tint G 50 R 50
Colour Tone :
Detailed Settings

 More

T V

Black Adjust :
Dynamic Contrast : Off 
Gamma : 0 
White Balance 
My Colour Control 
Edge Enhancement
Colour Space : Auto 

Move

Detailed Settings

Move


 Black Adjust: Off/Low/Medium/High

You can directly select the black level on the screen to adjust the screen depth.

 Dynamic Contrast: Off/Low/Medium/High

You can adjust the screen contrast so that the optimal contrast is provided.

 Gamma: -3 ~ +3

You can adjust the middle brightness of pictures.
Press the ◄ or ► button until you reach the optimal setting.

 White Balance: R Offset/G Offset/B Offset/R Gain/G Gain/B Gain/Reset

You can adjust the colour temperature for more natural picture colours.
R Offset/G Offset/B Offset/R Gain/G Gain/B Gain:

Changing the adjustment value will refresh the adjusted screen.
Select the required option by pressing the ▲ or ▼ button, then press the ENTER/OK button.
Press the ◄ or ► button until you reach the optimal setting.

Reset: The previously adjusted white balance will be reset to the factory defaults.

 My Colour Control: Pink/Green/Blue/White/Reset

This setting can be adjusted to suit your personal preferences.
Pink/Green/Blue/White: Changing the adjustment value will refresh the adjusted screen.

Select the required option by pressing the ▲ or ▼ button, then press the ENTER/OK button.
Press the ◄ or ► button until you reach the optimal setting.

When running the My Colour Control feature, the current picture is captured as a still image

➢

before being displayed on the screen.

Reset: The previously adjusted colours will be reset to the factory defaults.

 Edge Enhancement: Off/On

You can emphasize object boundaries.

 Colour Space: Auto/Wide

You can set the colour reproduction space for the input signal to Auto or Wide.

Warm2 

Enter

Return

Off 

: Off 

Enter

Return



English - 18

English - 19

Selecting the Picture Size

You can select the picture size which best corresponds to
your viewing requirements.

1 Press the MENU button to display the menu.
2 Press the ENTER/OK button to select Picture.
3 Press the ▲ or ▼ button to select Size, then press the

T V

 More
Size :
Digital NR :
Active Colour : On 
DNIe :
Movie Plus :
Reset :


16 : 9 
Auto 

On 
On 
OK 

ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options:

16 : 9, Wide Zoom, Zoom, 4 : 3, Just Scan

 16 : 9: Sets the picture to 16:9 wide mode.
 Wide Zoom: Magnify the size of the picture more than

4:3. Move the screen up/down using the ▲ or ▼ button
after selecting the by pressing the ► or ENTER/OK
button.

T V

Move

16 : 9
Wide Zoom
Zoom
4 : 3

Just Scan

Enter

Size

Return

 Zoom: Magnify the size of the picture vertically on

screen.

 4 : 3: Sets the picture to 4:3 normal mode.
 Just Scan: Use this function to see the full image without

Move

Enter

Return

any truncation when HDMI(720p/1080i) signals are input.
With the HDMI Just Scan picture size, depending on the AV

➢

devices, the screen may be cut off or a specific appears on
the screen.

5 Press the EXIT button to exit.

You can change the picture size simply by pressing the P.SIZE button on the remote control.

➢

Depending on the input source, the picture size options may vary.

➢

The items available may differ depending on the selected mode.

➢

Positioning and Sizing the screen using Zoom

 Resizing the screen using the Zoom enables the positioning and sizing of the screen to up/down

direction using the ▲ or ▼ button as well as the screen size.

 Move the screen up/down using the ▲ or ▼ button after selecting the by pressing the ◄ or ►

button.

 Resize the screen vertically using the ▲ or ▼ button after selecting the by pressing the ◄ or ►

button.

Digital NR / Active Colour / DNIe / Movie Plus

1 Press the MENU button to display the menu.

T V

2 Press the ENTER/OK button to select Picture.
3 Select the required option by pressing the ▲ or ▼ button, then

press the ENTER/OK button.

Available options:

Digital NR, Active Colour, DNIe,

Movie Plus

 More
Size :
Digital NR :
Active Colour : On 
DNIe :
Movie Plus :
Reset :


16 : 9 
Auto 

On 
On 
OK 

4 When you are satisfied with your setting, press the ENTER/OK

button.

5 Press the EXIT button to exit.

Move

Enter

Return

 Digital NR: Off/Low/Medium/High/Auto

If the signal received by the television is weak, you can activate this feature to reduce any static and
ghosting that may appear on the screen.

 Active Colour: Off/On

If you turn on this option, the colours of the sky and grass will be stronger and clearer for a more vivid
on-screen picture.

This function is not available in PC mode.

➢

When you select Standard or Movie in Picture Mode, the Active Colour automatically changes to

➢

Off and it is deactivated. When the Picture Mode is set to Dynamic, the Active Colour is activated
regardless of the value of Picture Mode.

 DNIe: Off/Demo/On

This TV includes the DNIe function so as to provide a high visual quality. If you set DNIe to on, you
can view the screen with the DNIe feature activated. If you set the DNIe to Demo, you can view the
applied DNIe and normal pictures on the screen, for demonstration purposes. Using this function, you
can view the difference in the visual quality.

DNIeTM (Digital Natural Image engine)

➢

This feature brings you more detailed image with 3D noise reduction, detail enhancement,
contrast enhancement and white enhancement. New image compensation Algorithm gives
brighter, clearer, more detailed image to you. DNIeTM technology will fit every signal into your
eyes.
This function is not available in PC mode.

➢

When the picture mode is set to Movie, DNIe cannot be selected.

➢

 Movie Plus: Off/On

You can view more natural skin and clear text even in fast moving scenes.

The Wide Zoom, Zoom and Just Scan mode is not supported.

➢

English - 20

English - 21

Sound Features

1 Press the MENU button to display the menu.

T V

2 Press the ▲ or ▼ button to select Sound, then press the

ENTER/OK button.

3 Select the required option by pressing the ▲ or ▼ button, then

press the ENTER/OK button.

Available options:

Mode, Equalizer, SRS TS XT, Auto Volume,

Internal Mute, Sound Select, Reset (If Game Mode is On)

4 When you are satisfied with your setting, press the ENTER/OK

button.

5 Press the EXIT button to exit.

< If Game Mode is On >

T V

 Mode: Standard/Music/Movie/Speech/Custom

You can select the type of special sound effect to be used
when watching a given broadcast.

Choose Standard for the TV standard factory

➢ 

settings.

Mode :
Equalizer 
SRS TS XT : Off 
Auto Volume : Off 
Internal Mute : Off 

Sound Select : Main 
Reset

Mode : Custom

Equalizer 
SRS TS XT : Off 
Auto Volume : Off 
Internal Mute : Off 

Sound Select : Main 

Reset

Move

Sound

Custom 

Enter

Sound

Return

 Choose Music when watching the music videos or

concerts.

 Choose Movie when watching movies.

Move

Enter

Return

 Choose Speech when watching a show that is mostly

dialog(i.e., news).

 Choose Custom to recall your personalized settings.

You can select these options simply by pressing the

➢

S.MODE button on the remote control.

 Equalizer: Balance/100Hz/300Hz/1kHz/3kHz/10kHz

The television has several settings which allow you to control

T V

Equalizer

the sound quality.

R/L Sound Balance Adjustment:

➢ 

To adjust the sound balance of the R/L speakers.

 Bandwidth Adjustment(100Hz, 300Hz, 1kHz, 3kHz,

10kHz) : To adjust the level of different bandwidth
frequencies.

If you make any changes to these settings, the sound

➢

standard is automatically switched to Custom.

R

+

0

-

L

Balance 100Hz 300Hz 1kHz 3kHz 10kHz

Move Adjust

+

0

-

Return

 SRS TS XT: Off/On

TruSurround XT is a patented SRS technology that solves
the problem of playing 5.1 multichannel content over two
speakers. TruSurround delivers a compelling, virtual surround
sound experience through any two-speaker playback system,
including internal television speakers. It is fully compatible
with all multichannel formats.

TruSurround XT, SRS and Symbol are trademarks of SRS Labs, Inc.

➢

TruSurround XT technology is incorporated under license from SRS Labs,
Inc.

You can select these options simply by pressing the SRS button on the remote control.

➢

 Auto Volume: Off/On

Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume
every time the channel is changed. This feature lets you automatically adjust the volume of the
desired channel by lowering the sound output when the modulation signal is high or by raising the
sound output when the modulation signal is low.



Continued...

 Internal Mute: Off/On

If you want to hear the sound through separate speakers, cancel the internal amplifier.

The VOL +, VOL -, S.MODE, and MUTE buttons do not operate when the Internal Mute is set to

➢

On.

 Sound Select: Main/Sub

When the PIP feature is activated, you can listen to the sound of the sub (PIP) picture.

− Main: Used to listen to the sound of the main picture.

− Sub: Used to listen to the sound of the sub picture.

 Reset

If Game Mode is On, the Reset Sound function is activated. Selecting the Reset function after setting
the equalizer resets the equalizer setting to the factory defaults.

Selecting the Sound Mode (depending on the model)

The DUAL I-II button displays/controls the processing and
output of the audio signal. When power is switched on, the
mode is automatically preset to either “DUAL-I” or “Stereo”,
depending on the current transmission.

Type of broadcast On-screen indication

Regular broadcast

(Standard audio)

Regular + NICAM Mono NICAM

NICAM

Stereo

NICAM Stereo

Mono (Normal use)

NICAM

Stereo

Mono

(Normal)

Mono

(Normal)

NICAM DUAL-I/II

Regular broadcast

A2

Stereo

➢ 





(Standard audio)

Bilingual or DUAL-I/II DUAL I

Stereo Stereo

If the receiving conditions deteriorate, listening will be easier if the mode is set to Mono.

If the stereo signal is weak and automatic switching occurs, switch to Mono.

When receiving a mono sound in the AV mode, connect to the “AUDIO-L” input connector on the
panel (front or side). If the mono sound comes out only from left speaker, press the DUAL I-II

NICAM

DUAL-1

NICAM

DUAL-2

Mono (Normal use)

Mono

(Normal)

DUAL II

Mono

(Forced mono)

button.

English - 22

English - 23

Time Features

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Time, then press the

ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options:

Clock Set, Sleep Timer, Timer1, Timer2,

Timer3

5 When you are satisfied with your setting, press the ENTER/

OK button.

6 Press the EXIT button to exit.

 Clock Set

You can set the television clock so that the current time is

T V

Plug & Play
Language :
Time 

Game Mode : Off

Blue Screen :
Melody :

PC
Home Theatre PC : Off 

Light Effect :
 More

T V

Clock Set :
Sleep Timer : Off 

Timer1 : Inactivated 
Timer2 : Inactivated 
Timer3 : Inactivated 

Move

Setup

Time

English 



Off 
Off 



On 

Enter

Return

−− : −− am 

displayed when pressing the INFO button on the remote
control. You must also set the time if you wish to use the
automatic on or off timers.

− Press the ◄ or ► button to select Month, Day, Year, Hour,

Move

Enter

Return

Minute, or am/pm.

Set these by pressing the ▲ or ▼ button.

You can set the Month, Day, Year, Hour, and Minute

➢

directly by pressing the numeric buttons on the remote
control.
In the event of a power interruption or the set being turned

➢

off at the supply, the settings for the Clock will be lost.

 Sleep Timer

You can select a time period of between 30 and 180 minutes
after which the television automatically switches to standby
mode.

− Select the preset time interval (Off, 30, 60, 90, 120, 150,

180) for staying on by pressing the ▲ or ▼ button.
You can select these options simply by pressing the SLEEP button on the remote control.

➢

 Timer1 / Timer2 / Timer3

You can set the On/Off timers so that the television will switch on or off automatically at the time you
select.

You must set the clock first.

☛

− Press the ◄ or ► button to select the required item below.
Press the ▲ or ▼ button to adjust to the setting satisfied.

On Time : Select hour, minute, am/pm, and No/Yes. (To activate timer with the setting satisfied,
set to Yes.)
Off Time : Select hour, minute, am/pm, and No/Yes. (To activate timer with the setting satisfied,
set to Yes.)

Repeat : Select Once, Everyday, Mon ~ Fri, Mon ~ Sat, or Sat ~ Sun.
Volume : Select the required volume level.
Programme : Select the required channel.

You can set the hour, and minute directly by pressing the number buttons on the remote control.

➢

Auto Power Off

☛

When you set the timer “On”, the TV will eventually turn off, if no controls are operated for 3 hours
after the TV was turned on by timer. This function is only available in timer “On” mode and prevents
overheating, which may occur if a TV is on for too long time.



Language / Blue Screen / Melody / Light Effect / Energy Saving / HDMI Black Level

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Select the required option by pressing the ▲ or ▼ button, then

press the ENTER/OK button.

4 When you are satisfied with your setting, press the ENTER/OK

button.

5 Press the EXIT button to exit.

T V

Plug & Play
Language :
Time

Game Mode : Off

Blue Screen :
Melody : Off 

PC
Home Theatre PC : Off

Light Effect :
 More

Move

Setup

English 





Off 





On 

Enter



Return

 Language

It is variable depending on the model. When you start using the television for the first time, you must
select the language which will be used for displaying menus and indications.

 Blue Screen: Off/On

If no signal is being received or the signal is very weak, a blue screen automatically replaces the
noisy picture background. If you wish to continue viewing the poor picture, you must set the Blue
Screen to Off.

 Melody: Off/Low/Medium/High

The TV power on/off melody sound can be adjusted.

 Light Effect: Off/Standby Mode On/Watching Mode On/On

You can turn on/off the blue LED on the front of TV according to the situation. Use it for saving power
or when the LED dazzles your eyes.

- Off: The blue LED is always off.

- Standby Mode On: The blue LED lights while in Standby mode and it turns off when your TV is

turned on.

- Watching Mode On: The blue LED lights when watching TV and it turns off when your TV is turned
off.

- On: The blue LED always lights.

Set the Light Effect to Off to reduce the power consumption.

➢

 Energy Saving: Off/Low/Medium/High

This feature adjusts the screen brightness depending on the surrounding lighting conditions.

- Off: Switches off the Energy Saving mode.

- Low: Operates in standard mode regardless of the surrounding illumination.

- Medium: Enters medium power saving mode regardless of the surrounding illumination.

- High: Enters maximum power saving mode regardless of the surrounding illumination.

 HDMI Black Level: Normal/Low

Using this function, you can adjust the image quality when the screen burn (appearance of black level,
low contrast, low colour, etc.) is encountered by the HDMI input for RGB limited range (16 to 235).

This function is active only when the externel input connects to HDMI(RGB signals).

➢

English - 24

English - 25

Using the Game Mode

When connecting to a game console such as PlayStationTM or
XboxTM, you can enjoy a more realistic gaming experience by
selecting game menu.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Game Mode, then press

the ENTER/OK button.

4 Select Off or On by pressing the ▲ or ▼ button, then press

the ENTER/OK button.

5 Press the EXIT button to exit.

Restrictions on Game mode (Caution)

➢

 To disconnect the game console and connect another

T V

Plug & Play

Language :
Time 
Game Mode : Off
Blue Screen :
Melody :

PC
Home Theatre PC : Off 

Light Effect :
 More

Move

AV1

Game Mode

Setup

English 

Off 
Off 



On 

Enter

external device, set Game Mode to Off.

 If you display the TV menu in Game Mode, the screen

shakes slightly.

 The mark ( ) appears on the screen which means that Game Mode is On with the

selected source.

If Game Mode is On :

➢

 Picture Mode is automatically changed to Standard and users cannot change the mode.
 Sound Mode in the Sound menu is deactivated. Adjust the sound using the equalizer.
 The Reset Sound function is activated. Selecting the Reset function after setting the

equalizer resets the equalizer setting to the factory defaults.

Game Mode is not available in TV mode.

➢

If the picture is poor when external device is connected to TV, check if Game Mode is On.

➢

Set Game Mode to Off and connect external devices.

Wall- mount adjustment (Sold separately)

Once the wall mount is installed, the position of your TV can be easily adjustable.

TV Rear Panel

Auto Wall-Mount





Return

Serial Cable(1P to 1P)(Not supplied)

Entering the menu

1 Press the

MENU button to display the menu.
Press the ▲ or ▼ button to select Setup, then press the
ENTER/OK button.

2 Press the ▲ or ▼ button to select Wall-Mount Adjustment

then press the ENTER/OK button.

T V

 More
Wall-Mount Adjustment
Energy Saving : Off 

HDMI Black Level : Normal 

,

PIP 

Screen Burn Protection 

Move

Setup



Enter

Return

Continued...

3 Adjust to the desired position using the ▲/▼/◄/► buttons.
Press the

If you press an arrow button when no OSD is displayed on the

➢

TV screen, the Adjustment screen appears.

When you turn the power off, your TV moves to the initial

➢

installation position.When you turn the power on, your TV

EXIT button to exit.

moves to the last remembered position you adjusted.

Using the remote Control Buttons

Button Operations

Wall-mount angle

Tilt Up, Tilt Down, Move right, Move left

adjustment

Wall-Mount Adjustment

Position1

Position

Adjust

1 2 3

INFO

Center

Exit

Reset

Remembering the
position and moving to
the remembered position

For installation, refer to the Installation Manual provided.

➢

For product installation and the installation and moving of the wall mount, make sure to consult a

➢

specialized installation company.

This installation manual is to be used when attaching the wall mount to a wall. When attaching to

➢

other building materials, please contact your nearest dealer

Moves to the initial installation position

Remembers 3 positions with the Red, Green and Yellow
buttons. Moves to the remembered position using these
3 colour buttons.

Viewing the Picture in Picture (PIP)

You can display a sub picture within the main picture. In this
way you can watch TV program or monitor the video input
from any connected devices.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select PIP, then press the

ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button, then

press the ENTER/OK button.

Available options:

PIP(Off/On), Source, Size, Position,

Programme

5 When you are satisfied with your setting, press the ENTER/OK

button.

6 Press the EXIT button to exit.

 PIP: Off/On

You can activate or deactivate the PIP function.

You can select these options simply by pressing the PIP

➢

button on the remote control.

T V

 More

Wall-Mount Adjustment

Energy Saving : Off 

HDMI Black Level : Normal 

PIP 
Screen Burn Protection 

Move

T V

PIP : On 
Source : TV 

Size :

Position :

Programme : P 1 

Move

Setup



Enter

PIP





Enter

Return

Return

English - 26

Continued...

English - 27

 Source: TV/AV1/AV2

You can select a source of the sub-picture.

You can select these options simply by pressing the SOURCE button on the remote control.

➢

 Size:

/

/

You can select a size of the sub-picture.

It is available in HDMI mode.

➢

 Position:

/

/

/

You can select a position of the sub-picture.

You can select these options simply by pressing the POSITION button on the remote control.

➢

 Programme

You can select a channel of the sub-picture only when the Source is set to TV.

You can select the channel of the sub picture simply by pressing the P or P button.

➢

Table of PIP Settings

X - This PIP combination is not available.
O - This PIP combination is available.

Sub

Main

TV analog AV1 AV2 S-Video Component HDMI PC

Component O O O X X X X
HDMI O O O X X X X
PC O O O X X X X

Screen Burn Protection

To reduce the possibility of screen burn, this unit is equipped
with screen burn prevention technology. This technology
enables you to set picture movement up/down (Vertical Line)
and side to side (Horizontal Dot). The Time setting allows
you to program the time between movement of the picture in
minutes.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select Screen Burn Protection,

then press the ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options:

Pixel Shift, All White, Signal Pattern,

Side Gray

5 When you are satisfied with your setting, press the

ENTER/OK button.

6 Press the EXIT button to exit.

 Pixel Shift: Using this function, you can minutely move pixels

on the PDP in horizontal or vertical direction to minimize after
image on the screen.

− Set Pixel Shift to On by pressing the ▲ or ▼ button, then

press the ENTER/OK button.

− Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options: Horizontal Dot, Vertical Line, Time

T V

 More

Wall-Mount Adjustment

Energy Saving : Off 

HDMI Black Level : Normal 
PIP 

Screen Burn Protection 

Move

T V

T V

Screen Burn Protection

Pixel Shift
All White 
Signal Pattern 
Side Gray : Dark 

Move

Pixel Shift :
Horizontal Dot : 2 
Vertical Line : 2 
Time : 2 min 

Move

Setup



Enter

Enter

Pixel Shift

On 

Enter

Return



Return

Return

Continued...

Optimum condition for pixel shift;

➢

TV/AV1/AV2/S-Video/

PC

Horizontal Dot 1 2

Vertical Line 1 2

Time (minute)

The Pixel Shift value may differ depending on the monitor size (inches) and mode.

➢

 All White: This function helps remove after images on the screen by changing the colour of pixels to

white. Use this function when there are remaining after images or symbols on the screen especially
when you displayed a still image on the screen for a long time.

 Signal Pattern: This function helps remove after images on the screen by moving all the pixels on

the PDP according to a pattern. Use this function when there are remaining after images or symbols
on the screen especially when you displayed a still image on the screen for a long time.

 Side Gray: When you watch TV with the screen ratio of 4:3, the screen is prevented from any

damage by adjusting the white balance on both extreme left and right sides.

Dark: When you set the screen ratio to 4:3, it darkens the left and right sides.
Light: When you set the screen ratio to 4:3, it brightens the left and right sides.
To remove after images on the screen, use either All White or Signal Pattern function.

➢

Although both of the two functions remove after images on the screen, Signal Pattern is more
effective.

The after image removal function has to be executed for a long time (approximately 1 hour) to

➢

effectively remove after images on the screen. If after image is not improved after the execution of the
function, repeat the function again.

Press any button on the remote control to cancel this feature.

➢

2 min 2 min

Component/HDMI

Setting up Your PC Software (Based on Windows XP)

The Windows display-settings for a typical computer are shown below. But the actual screens
on your PC will probably be different, depending upon your particular version of Windows and
your particular video card. But even if your actual screens look different, the same, basic set-up
information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung
Dealer.)

1 Right click the mouse on the Windows Desktop, then click on

Properties.
The Display Properties will be displayed.

2 Click on Settings tab, then set the Display Mode with

reference to the Display Modes Table. You do not need to
change the Colours settings.

3 Click on Advanced. A new settings dialog box will be

displayed.

4 Click on the Monitor tab, then set the Screen refresh rate

with reference to the Display Modes Table. Set the Vertical
Frequency and Horizontal Frequency individually if you can do
so instead of setting the Screen refresh rate.

5 Click on OK to close the window, then Click on OK button to

the Display Properties window. Automatic re-booting may commence at this moment.

English - 28

English - 29

Input Mode (PC)

Both screen position and size will vary depending on the type of PC monitor and its resolution.
The table below shows all of the display modes that are supported:

Video

Signal

IBM PC / AT

Compatible

 The interlace mode is not supported.
 The television might operate abnormally if a non-standard video format is selected.
 480i/p, 576i/p, 720p, or 1080i is not available in PC mode.
 For the PS-42Q91H/PS-42Q91HP, PC text quality is optimum in XGA mode (1024 x 768@60Hz).
 For the PS-50Q91H/PS-50Q91HP, PC text quality is optimum in WXGA mode (1360 x 768@60Hz).

(The three pixels each on the left and right are grayed at the resolution setting of 1360 x 768@60Hz.
This is not a mechanical problem but a result caused by the pixel difference between the standard
resolution and the PDP panel.)

Resolution

(Dot X Line)

640 x 350 70.086 31.469 N P
720 x 400 70.087 31.469 P N

640 x 480

800 x 600

1024 x 768

1360 x 768 60.015 47.712 P P

Vertical

frequency

(Hz)

59.940 31.469 N N

70.000 35.000 N/P N/P

72.809 37.861 N N

75.000 37.500 N N

60.317 37.879 P P

70.000 43.750 N/P N/P

72.188 48.077 P P

75.000 46.875 P P

60.004 48.363 N N

70.069 56.476 N N

72.000 57.672 N/P N/P

75.029 60.023 P P

Horizontal
frequency

(kHz)

Vertical
polarity

Horizontal

polarity

PS-42Q91H/

PS-42Q91HP

(N: Negative / P: Positive)

PS-50Q91H/

PS-50Q91HP

✔ ✔

✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔
✔ ✔

✔ ✔

✔

Setting the PC

Preset to the PC mode by pressing the SOURCE button.

➢

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

3 Press the ▲ or ▼ button to select PC, then press the

ENTER/OK button.

4 Select the required option by pressing the ▲ or ▼ button,

then press the ENTER/OK button.

Available options:

Image Lock, Position, Auto Adjustment,

Image Reset

5 When you are satisfied with your setting, press the ENTER/OK

button.

6 Press the EXIT button to exit.

 Image Lock: Coarse/Fine

The purpose of picture quality adjustment is to remove or
reduce picture noise.
If the noise is not removed by Fine-tuning alone, then adjust
the frequency as best as possible (coarse) and Fine-tune
again.
After the noise has been reduced, re-adjust the picture so that
it is aligned on the center of screen.
1 Press the ▲ or ▼ button to select Coarse or Fine, then

press the ENTER/OK button.

2 Press the ◄ or ► button to adjust the screen quality,

vertical stripes may appear or the picture may be blurry.
Press the ENTER/OK button.

 Position

Adjust the PC’s screen positioning if it does not fit the TV
screen.

1 Adjust the position by pressing the ▲/▼/◄/► button.
2 Press the ENTER/OK button.

 Auto Adjustment

Auto adjustment allows the PC screen of set to self-adjust to
the incoming PC video signal.
The values of fine, coarse and position are adjusted
automatically.

 Image Reset

You can replace all image settings with the factory default
values.

T V

Plug & Play

Language : English 
Time
Game Mode : Off
Blue Screen :
Melody :
PC 
Home Theatre PC : Off
Light Effect :

 More

Move

T V

Image Lock
Position 
Auto Adjustment 
Image Reset 

Move

T V

T V

Image Lock

Coarse 50
Fine 0

Move

Move

Auto Adjustment in Progress

Please wait.

Setup



Off 
Off 

On 

Enter

PC

Enter

Enter

Position

Enter



Return

Return

Return

Return







English - 30

Image Reset is completed.

Return

English - 31

Setting the Home Theatre PC

Preset to the PC mode by pressing the SOURCE button.

➢

You can view higher quality pictures by configuring the
screen settings in PC Mode.
If you set the Home Theatre PC function to On, you can
configure the Detailed Settings (when Picture Mode is set to
Standard or Movie) as in PC Mode.

1 Press the MENU button to display the menu.
2 Press the ▲ or ▼ button to select Setup, then press the

ENTER/OK button.

T V

Plug & Play

Language : English 
Time
Game Mode : Off
Blue Screen :
Melody :
PC 
Home Theatre PC : Off
Light Effect :

 More

Move

3 Press the ▲ or ▼ button to select Home Theatre PC, then

press the ENTER/OK button.

4 Select Off or On by pressing the ▲ or ▼ button, then press the ENTER/OK button.
5 Press the EXIT button to exit.

This function is available only in PC mode.

➢

Setup



Off 
Off 



On 

Enter





Return

What is Anynet+?

Anynet+ is an AV network system that enables an easy-to-use AV interface for users by controlling
all connected AV devices through the Anynet+ menu when Samsung Electronics AV devices are
connected.

Connecting Anynet+ Devices

The Anynet+ system supports AV devices supporting Anynet+ only.

Check if there is an Anynet+ mark on the AV device to be connected to the TV.

To directly connect to TV

TV

Anynet

+

Device 1

Anynet

+

Device 2

Anynet

+

Device 3

Connect the [HDMI 1], [HDMI
2] or [HDMI 3] jack on the TV
and the HDMI OUT jack of
the corresponding Anynet+
device using the HDMI cable.

HDMI Cable

HDMI Cable

HDMI Cable

To connect to Home Theater

TV

Anynet

+

Device 1

Anynet

+

Device 2

1 Connect the [HDMI 1],

[HDMI 2] or [HDMI 3]
jack on the TV and the
HDMI OUT jack of the
corresponding Anynet+
device using the HDMI
cable.

2 Connect the HDMI IN jack

HDMI Cable

Home Theater

HDMI Cable

Anynet

+

Device 3

of the home theater and
the HDMI OUT jack of the
corresponding Anynet+
device using the HDMI
cable.

HDMI Cable

Connect only one receiver.

➢

You can connect an Anynet+ device using the HDMI Cable. Some HDMI cables may not support

➢

Anynet+ functions.
Anynet+ works when the AV device supporting Anynet+ is in the Standby or On status.

➢

Anynet+ supports up to 8 AV devices in total.

➢

HDMI Cable

English - 32

English - 33

Setting Up Anynet

+

The following settings are to use Anynet+ functions.

Using the Anynet+ Function

1 Press the Anynet+ button.

Press the ▲ or ▼ button to select Setup, then press the
ENTER/OK button.

2 Press the ENTER/OK button to select Anynet+ (HDMI-CEC),

then press the ENTER/OK button.

3 Press the ▲ or ▼ button to select On, then press the

ENTER/OK button.

The Anynet+ (HDMI-CEC) function is enabled.

➢

If you select Off, Anynet+ (HDMI-CEC) is disabled.

➢

TV P 1

View TV

Select Device

Record

Menu on Device

Device Operation

Receiver :Off 

Setup

Move

Return

Anynet+ (HDMI-CEC)

Auto Turn Off

Searching Connections

Enter

: Off











Setup

: Off

Off

On

Move

Enter Return

Turning an Anynet+ Device Off Automatically when the TV is Turned Off

2 Press the ▲ or ▼ button to select Auto Turn Off, then press

the ENTER/OK button.

3 Press the ▲ or ▼ button to select On, then press the

ENTER/OK button.

The Auto turn off function is enabled.

➢

If you select Off, the Auto turn off function is canceled.

➢

Press the EXIT button to exit.
The Select Device setting of the TV remote control is to be set

➢

to TV to use the Anynet+ function.
If you set Auto Turn Off to On, connected external devices are also turned off when the TV is turned

➢

off. However, if the device is recording, it may not be turned off.
When the Anynet+ (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated.

➢

Anynet+ (HDMI-CEC)

Auto Turn Off

Searching Connections

Move

Setup

: On

: Off

Off

On

Enter Return

Scanning and Switching between Anynet+ Devices

1 Press the Anynet+ button.
2 Press the ▲ or ▼ button to select Select Device, then press

the ENTER/OK button.

3 Press the ▲ or ▼ button to select to a particular device and

press the ENTER/OK button.
It is switched to the selected device.

4 If you cannot find a device you want, press the ▲ or ▼ button

to select Searching Connections, then press the ENTER/OK
button.

The meassage Configuring Anynet+ connection... is

displayed. When searching devices completes, the connected
devices are listed in the Anynet+ menu.

Switching to the selected devices may take up to 2 minutes.

➢

You cannot cancel the operation during the switching
operation.
The time required to scan for devices is determined by the

➢

number of connected devices.
When the device scan is complete, the number of found

➢

devices is not displayed.
Although the TV automatically scans devices when it is turned

➢

on using the POWER button, devices connected when the TV is on or under a specific circumstance
are not displayed in the device list. Therefore select Searching Connections menu to search
devices.
If you have selected external input mode by pressing the SOURCE button, you cannot use the

➢

Anynet+ function. Make sure to switch to an Anynet+ device by using the Anynet+ button.

TV P 1

View TV

Select Device 

Record 

Menu on Device 

Device Operation

Receiver :Off

Setup 

Move

Return

Anynet+ (HDMI-CEC)

Auto Turn Off

Searching Connections 

Move

Enter

: On

DVDR1

DVDR2

DVD1
DVD2





Setup

: On

Enter Return





Anynet+ Menu

The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected
to the TV.

Anynet+ Menu Description

View TV Switches from Anynet+ to TV broadcast mode.
Select Device Your TV connects to the corresponding device.
Record Starts a recording. (This menu works only for a device supporting

Menu on Device Shows the menu of the connected device.

Device Operation Shows the play control menu of the connected device.

Receiver Sound is output through the receiver.
Setup You can set the environment for using Anynet+.

TV Remote Control Buttons Available in Anynet+ Mode

Device Type Operating Status Available Buttons

Anynet+ Device

Device with built-in Tuner

Audio Device When Receiver is activated

Anyview2 When watching TV ►

The Anynet+ function only works when the remote control is set to TV.

➢

The REC button works only while in the recordable state.

➢

You cannot control Anynet+ devices using the buttons on the side of the TV. You can control Anynet+

➢

devices only using the TV remote control.
The TV remote control may not work under certain conditions. In this case, re-select the Anynet+

➢

device.
The Anynet+ functions don’t operate for the products from other manufacturers.

➢

In Anynet+ mode, the colour buttons may not work properly.

➢

The ◄◄, ►► operations may differ depending on the device.

➢

recording.)

Example. When a DVD Recorder is connected, the DVD Recorder’s
title menu appears.

Example. When a DVD Recorder is connected, the play control
menu of the DVD Recorder appears.

After switching to the
device, when the menu of
the corresponding device is
displayed on the screen.

After switching to the device,
while playing a file

After switching to the device,
when you are watching a TV
program

Numeric buttons
▲/▼/◄/►/ENTER/OK buttons
Colour buttons
EXIT button

◄◄ (Backward search)
►►(Forward search)
(Stop)
►

 

(Play/Pause)

CH ▲/▼ button

VOL +/- button
MUTE button

 

(Play/Pause)

Recording

You can make a recording of a TV program using a recorder.

Press the REC button.
Recording begins. (Only when the Anynet+ enabled recording device is connected.)

The current TV program is recorded in the Watching TV status. If you are watching video from

➢

another device, the video from the device is recorded.
You can also record the source streams by selecting Record after pressing the Anynet+ button.

➢

English - 34

English - 35

Listening through a Receiver

You can listen to sound through a receiver instead of the TV speaker.

1 Press the Anynet+ button.

Press the ▲ or ▼ button to select Receiver, then press the ENTER/OK
button.

2 Press the ◄ or ► button to select to On, then press the ENTER/OK button.

Now you can listen to sound through the receiver.

3 Press the EXIT button to exit.

When the receiver is set to On, you can listen to the TV sound through the

➢

2-channel receiver.
If the receiver is exclusively for a home theater only (supporting audio only),

➢

it may not appear in the device list.
In case of a content with copyright problem, listening through the receiver may not properly operate.

➢

When listening through the receiver, there are restrictions for using the PIP and audio-related menu.

➢

TV P 1

View TV

Select Device 

Record

Menu on Device

Device Operation

Receiver :On

Setup 

Move

Return

Enter

Check Points before Requesting Service

Symptom Solution
Anynet+ does not work. ■ Check if the device is an Anynet+ device. The Anynet+ system

I want to start Anynet+. ■ Check if the Anynet+ device is properly connected to the TV and

I want to exit Anynet+. ■ Select View TV in Anynet+ menu.

The Connecting to Anynet+
device… message appears
on the screen.

The Anynet+ device does
not play.
The connected device is not
displayed.

The TV program cannot be
recorded.

supports Anynet+ devices only.

■ Connect only one receiver.

■ Check if the Anynet+ device power cord is properly connected.

■ Check the Anynet+ device’s Video/Audio/HDMI Cable connections.

■ Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+
setup menu.

■ Check whether the TV remote control is in TV mode.

■ Check whether it is Anynet+ exclusive remote control.

■ Anynet+ doesn’t work at a certain condition. (Searching channels)

check if the Anynet+ (HDMI-CEC) is set to On in the Anynet+ Setup
menu.

■ Press the TV button on the TV remote control to switch to TV. Then
press the Anynet+ button to show the Anynet+ menu and select a
menu you want.

■ Press the

SOURCE button on the TV remote control and select a

device other than Anynet+ devices.

■ Press any of CH, CH LIST, PRE-CH, and such to change to the
TV mode. (Note that the channel button operates only when a
tuner-embedded Anynet+ device is not connected.)

■ You cannot use the remote control when you are configuring
Anynet+ or switching to a view mode.

■ Use the remote control when the Anynet+ setting or switching to
view mode is complete.

You cannot use the play function when an auto channel scan is in
progress. Stop the currently running function.

■ Check whether or not the device supports Anynet+ functions.

■ Check whether or not the HDMI Cable is properly connected.

■ Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+
setup menu.

■ Search Anynet+ devices again.

■ You can connect an Anynet+ device using the HDMI Cable only.
Some HDMI cables may not support Anynet+ functions.

Check whether the antenna jack on the recording device is properly
connected.









Teletext Feature (depending on the model)

Most television stations provide written information services via teletext. The index page of the
teletext service gives you information on how to use the service. In addition, you can select
various options to suit your requirements by using the remote control buttons.

For teletext information to be displayed correctly, channel reception must be stable.

☛

Otherwise, information may be missing or some pages may not be displayed.

1

(index)

Used to display the index (contents) page at any time while
you are viewing teletext.

2

(teletext on/mix)

Press to activate teletext mode after selecting the channel
providing the teletext service. Press it twice to overlap the
teletext with the current broadcasting screen.

3

(hold)

Used to hold the display on a given page if the selected
page is linked with several secondary pages which follow on
automatically. To resume, press it again.

4

(mode)

Press to select the teletext mode (LIST/FLOF).
If you press it in the LIST mode, it switches into the List save
mode.
In the List save mode, you can save teletext page into list
using the (store) button.

5

(sub-page)

Used to display the available sub-page.

6

(page up)

Used to display the next teletext page.

7

(page down)

Used to display the previous teletext page.

8

(cancel)

Used to display the broadcast when searching for a page.

9

(reveal)

Used to display the hidden text (answers to quiz games, for
example). To display normal screen, press it again.

0

Coloured buttons (red/green/yellow/blue)

If the FASTEXT system is used by a broadcasting company,
the different topics covered on a teletext page are colour­coded and can be selected by pressing the coloured buttons.
Press one of them corresponding to the required. The page is
displayed with other coloured information that can be selected
in the same way.
To display the previous or next page, press the corresponding
coloured button.

!

(size)

Press to display the double-size letters in the upper half of the
screen. For lower half of the screen, press it again.
To display normal screen, press it once again.

@

(store)

Used to store the teletext pages.

You can change teletext pages by pressing the numeric

➢

buttons on the remote control.

English - 36

Continued...

English - 37

The teletext pages are organized according to six categories:

Part Contents

A
B
C
D
E
F

Teletext information is often divided between several pages

➢

displayed in sequence, which can be accessed by:

 Entering the page number
 Selecting a title in a list
 Selecting a coloured heading (FASTEXT system)

Press the TV button to exit from the teletext display.

➢

Selected page number.
Broadcasting channel identity.
Current page number or search indications.
Date and time.
Text.
Status information.
FASTEXT information.

Setting Up Your Remote Control

After it has been set up properly, your remote control can operate in five different modes: TV, VCR,
Cable, DVD, or Set-Top Box. Pressing the corresponding button on the remote control allows you
to switch between these modes, and control whichever piece of equipment you choose.

The remote control might not be compatible with all DVD Players, VCRs, Cable boxes, and Set-Top

☛

Boxes.

Setting Up the Remote to Operate Your VCR

1 Turn off your VCR.

2 Press the VCR button on your TV’s remote control.

3 Press the SET button on your TV’s remote control.

4 Using the number buttons on your remote control, enter three

digits of the VCR code listed on page 40 of this manual for your
brand of VCR. Make sure you enter three digits of the code, even
if the first digit is a “0”. (If more than one code is listed, try the first
one.)

5 Press the POWER (

should turn on if your remote is set up correctly.

If your VCR does not turn on after set-up, repeat steps 2, 3 and 4,

but try one of the other codes listed for your brand of VCR. If no
other codes are listed, try each VCR code, 000 through 080.

Note on Using Remote Control Modes: VCR
When your remote control is in “VCR” mode, the volume buttons still
control your TV’s volume.

) button on the remote control. Your VCR

Setting Up the Remote to Operate Your Cable Box

1 Turn off your cable box.

2 Press the CABLE button on your TV’s remote control.

3 Press the SET button on your TV’s remote control.

4 Using the number buttons on your remote control, enter three

digits of the cable box code listed on page 41 of this manual for
your brand of cable box.
Make sure you enter three digits of the code, even if the first digit
is a “0”. (If more than one code is listed, try the first one.)

5 Press the POWER (

Your cable box should turn on if your remote is set up correctly.

If your cable box does not turn on after set-up, repeat steps 2, 3

and 4, but try one of the other codes listed for your brand of cable
box. If no other codes are listed, try each code, 000 through 046.

Note on Using Remote Control Modes: Cable Box
When your remote control is in “CABLE” mode, the volume buttons
still control your TV’s volume.

) button on the remote control.

English - 38

Continued...

English - 39

Setting Up the Remote to Operate Your DVD

1 Turn off your DVD.

2 Press the DVD button on your TV’s remote control.

3 Press the SET button on your TV’s remote control.

4 Using the number buttons on your remote control, enter three

digits of the DVD code listed on page 42 of this manual for your
brand of DVD. Make sure you enter three digits of the code, even
if the first digit is a “0”. (If more than one code is listed, try the first
one.)

5 Press the POWER ( ) button on the remote control.

Your DVD should turn on if your remote is set up correctly.

If your DVD does not turn on after set-up, repeat steps 2, 3 and 4,

but try one of the other codes listed for your brand of DVD. If no
other codes are listed, try each code, 000 through 141.

Note on Using Remote Control Modes: DVD
When your remote control is in “DVD” mode, the volume buttons still
control your TV’s volume.

Setting Up the Remote to Operate Your Set Top Box

1 Turn off your STB.

2 Press the STB button on your TV’s remote control.

3 Press the SET button on your TV’s remote control.

4 Using the number buttons on your remote control, enter three

digits of the STB code listed on page 41 of this manual for your
brand of STB. Make sure you enter three digits of the code, even
if the first digit is a “0”. (If more than one code is listed, try the first
one.)

5 Press the POWER ( ) button on the remote control.

Your STB should turn on if your remote is set up correctly.

If your STB does not turn on after set-up, repeat steps 2, 3 and 4,

but try one of the other codes listed for your brand of STB. If no
other codes are listed, try each code, 000 through 074.

Note on Using Remote Control Modes: STB
When your remote control is in “STB” mode, the volume buttons still
control your TV’s volume.

Continued...

Setting Up Your Remote Control

Remote Control Codes

VCR

Brand

SAMSUNG
ADMIRAL
AIWA
AKAI
AUDIO DYNAMICS
BELL&HOWELL
BROKSONIC
CANDLE
CANON
CITIZEN
COLORTYME
CRAIG
CURTIS MATHES
DAEWOO
DB
DIMENSIA
DYNATECH
ELECTROHOME
EMERSON

FISHER
FUNAI
GENERAL ELECTRIC
GO VIDEO
LG(Goldstar)
HARMAN KARDON
HITACHI
INSTANT REPLAY
JC PENNEY
JCL
KENWOOD
KLH
LIOYD
LOGIK
LXI
JVC
MAGNAVOX
MARANTZ
MARTA
KONIA
ORION
MEI
MEMOREX
MGA
MIDLAND
MINOLTA

Code

000 001 002 003 004 005 077 078 079
020
025
004 027 032
007 026
018
022
002 003 006 008 015 055
021 056
002 003 006 008 015 055
007
002 024
002 007 008 017 021 025 056 064 066
003 010 011 012 013 014 015 016
007 026
017
025
034
001 003 006 021 022 025 030 032 034
040 047 050 052 060 063 065 066 067
069 073
018 024 028 029 048 051 061
025
002 005 017 021 056
002
006 007 008 009 010
007
019 025 041 042 074
021
002 007 018 019 021 026 037 041 054 056
007 008 018 021 026 037
007 008 018 026 037
070
025
038
025
081 082 083
021 056 059
007 008 018 021 026 037 062
006
036
073 074 075 076
021
006 021 024 025
034
005
019 041 075

Brand

MITSUBISHI
MONTGOMERY WARD
MTC
MULTITECH
NEC
OPTIMUS
PANASONIC
PENTAX
PENTEX RESEARCH+
PHILCO
PHILIPS
PIONEER
PORTLAND
PROSCAN
QUARTZ
QUASAR
RADIO SHACK/REALISTIC
RCA
SANSUI
SANYO
SCOTT
SEARS
SHARP
SHIMTOM
SIGNATURE
SONY
SYLVANIA
SYMPHONIC
TANDY
TASHIKA
TATUNG
TEAC
TECHNICS
TEKNIKA
TMK
TOSHIBA
TOTEVISION
UNITECH
VECTOR RESEARCH
VICTOR
VIDEO CONCEPTS
VIDEOSONIC
WARDS

YAMAHA
ZENITH

Code

019 034 041 046
020
002 025
002 005 025 038
007 008 018 026 037 062 064
020
021 056 071 072
019 041 075
008
021 056 059
021 080
019 026 039 053
015 049 055
017
018
021 056
006 018 020 021 024 025 029 034 048 056
002 017 019 021 035 041 043 057 068 076
026
018 024
003 047 052 067
006 018 019 024 028 029 041 048 051
020 034 045 015
027 033 038 058
025
027 033 044
021 025 056 059
025
018 025
006
037
025 037 068
021
006 021 025 031
066
003 019 029 051 052
002 006
002
007 026
026
007 026
002
002 003 006 019 020 021 024 025 034
038 041
007 008 018 026 037
023 027 033

English - 40

Continued...

English - 41

Setting Up Your Remote Control

CABLE BOX

Brand

SAMSUNG
GI
HAMLIN
HITACHI
JERROLD
MACOM
MAGNAVOX
OAK
PANASONIC
PHILIPS
PIONEER
RCA
REGAL

SAMSUNG SET-TOP BOX

Product

Ground wave STB
Satellite STB
CABLE STB
STB DVD COMBO
Satellite STB HDD COMBO Standard

SET-TOP BOX

Brand

ALPHASTAR
ANAM
CHANNEL MASTER
CROSSDIGITAL
CHAPARRAL
DIRECT TV

DAEWOO
DISH NETWORK SYSTEM
DISHPRO
DRAKE
DX ANTENNA
ECHOSTAR
EXPRESSVU
GOI
GE
GENERAL INSTRUMENT
HTS
HOME CABLE
HITACHI
HUGHES NETWORK
IQ
IQ PRISM
JANEIL
JERROID
JVC

Code

000 001 002 003 004 005 006 007
041
003 024 031
025 030
038 039
025 030
019 023 028
026
003 022 027 037 044
019 021 023 028
004 018 020 044
014 022 040
003

Code

001 002
003
004
008
009

Code

023
043
018 034
019
035
015 016 017 019 022 045 060 061 062 065
066 067 068
074
069 070
069
018 024 032
027
025 069 070 071
069
069
065
046 047 048 063 064
069
056
022
015 017
020
020
059
063
069 070

Brand

REGENCY
SA
SCIENTIFIC ATLAN
SPRUCER
STARGATE 2000
SYLVANIA
TEXSCAN
TOCOM
UNIVERSAL
VIEWSTAR
WARNER AMEX
ZENITH

Product

Satellite STB HDD COMBO Premium
CABLE STB HDD COMBO Standard
CABLE STB HDD COMBO Premium
Ground wave STB HDD COMBO Standard
Ground wave STB HDD COMBO Premium

Brand

LG(Goldstar)
MAGNAVOX
MEMOREX
MOTOROLA
MACOM
MITSUBISHI
NEXT LEVEL
PHILIPS

PRIMESTAR
PANASONIC
PAYSAT
PROSCAN
RCA
RADIOSHACK
REALISTIC
STS
STAR TRAK
SKY
SKY LIFE
SHACK
STAR CHOICE
SONY
TOSHIBA
ULTIMATE TV
UNIDEN
ZENITH

Code

015 023
042 043
042 043
022
036
016
016
032
033 034
019 021 023 028
046
017 029 035 037 045

Code

010
011
012
013
014

Code

044 073
016 021 036 038 039 040 041 042
016
064
018
015
047 048 064
015 016 017 021 033 036 038 039 040 041
042 067
046 049 050 063
058 059 061 062
016
065 066
051 052 053 065 066
064
057
020 027
026
031
005 006 007
064
064
054 060
015 017 028 029 030 072
060 066
016 021 037 055 056 057
024 031 068

Continued...

Setting Up Your Remote Control

SAMSUNG DVD

Product

DVD
DVDR
BD Record
VCR COMBO
VCR Record
DHR COMBO

DVD

Brand

ANAM
AUDIOVOX
AUDIOLOGIC
ANABA
APEX DIGITAL
AIWA
BROKSONIC
BLAUPUNKT
B&K
CURTIS MATHES
CYBER HOME
CLARION
CIRRUS
CINEVISION
DAEWOO
DENON
FARENHEIT
FISHER
GPX
GO VIDEO
GE
GREENHILL
HITACHI
HITEKER
HOYO
HARMAN / KARDON
IRT
INTEGRA
JBL
JVC
JATON
KENWOOD
KISS
KONKA
KLH
LG(Goldstar)
LOEWE
LASONIC
MOBILE AUTHORITY
MEMOREX
MALATA
MAGNAVOX
MINTEK
MONYKA

Code

000 001 002
003 004
005 006
007 008 009 010 011
012
013

Code

030
075
085
072
070 071 074 086 083 084 088 111 112
114
062
074
122 123
027
065 077 078 079 082
080 125
081
095
066
146
067 068
090
060
061 089 133 135
069 074
074
064 113
071
073
091 110
089
092
091
022 033 115 116
073
051 108 109
073
059 100 106 107
074 075
025 031
057
058
054
055
056
076 093
074 094
073

Product

Home Theater VCR COMBO
HDD Record COMBO
TWIN TRAY COMBO
STB DVD COMBO
DVD Receiver
AV Receiver

Brand

NORCENT
NEXT BASE
NEC
NANTAUS
NESA
OPTOMEDIA ELECTRONICS
OPTIVIEW
ONKYO
PHILCO
PRINCETON
PROSCAN
PANASONIC
PHILIPS
ROTEL
RIO
RCA
RAITE
ROWA
SAMPO
SONY
SHERWOOD
SVA
SYLVANIA
SHARP
SANSUI
SANYO
SHINSONIC
SANYO
THOMSON
TOSHIBA
TECHNICS
TVIEW
TOKAI
TEAC
TECHWOOD
TREDEX
URBAN CONCEPTS
VENTURER
VOCOPRO
YAMAHA
YAMAKAWA
XWAVE
ZENITH

Code

014 015 016
017
018
019
020
021

Code

048 049 050
052
053
144
074
105
072
076 092 119
044 045
046 047
023
024 034 124 134 136 137 138
036 076
117 118
120
023 035 074 075 131 132
073
038
104
026 029 126 127 128 129 130 141
039 041
042
043 093
140
062
062
094
090
145
028 062 076
139
072
073
096
097
098 099 101
076
075
102
032 063
040 073
103
076 121

English - 42

English - 43

Installing the Wall Mount Kit

Wall Mount Kit Specifications ( VESA )
This installation is to be used when attaching the wall mount to a wall.

When attaching to other building materials, please contact your nearest dealer.

Product Family inch VESa Spec. (A * B) Standard Screw (C * D) Quantity

23 ~ 26 200 * 100 M4 * L10 4

LCD-TV

PDP-TV

1 We provide the standard dimensions for wall mount kits as shown in the table above.
2 When purchasing our wall mount kit, a detailed installation manual and all parts necessary for

assembly are prvided.

3 Do not use screws longer than the standard dimension, as they may cause damage to the inside of

the TV set.

4 Our 63” model does not comply with VESA Specifications. Therefore, you should use our dedicated

wall mount kit for this model.

32 ~ 40 200 * 200 M6 * L10 4

46 ~ 52 600 * 400

M8 * L15 457 700 * 400

42 ~ 50 600 * 400

63 No VESA M8 6

How to assemble the Stand-Base (depending on the model)

Using the 6 screws for securing the stand base and the
monitor, firmly attach the monitor to the stand base.
(The exterior of the set may be different than the picture.)

Warning

Firmly secure the stand to the TV
before moving it, as the stand may
fall and could cause serious injury.

Two or more people should

➢

carry the TV. Never lay the
TV on the floor because of
possible damage to the screen.
Always store the TV upright.

In case of installing your TV on the
wall, close the cover (1) on the
stand-base connection part using
two screws for hiding.

Troubleshooting

Before contacting the Samsung after-sales service, perform the following simple checks.
If you cannot solve the problem using the instructions below, note the model and serial number of
the television and contact your local dealer.

No sound or picture

 Check that the mains lead has been connected to a wall socket.
 Check that you have pressed the (Power) button (On/Off) on the front panel or press the POWER

button on the remote control.

 Check the picture contrast and brightness settings.
 Check the volume.
 Check if Internal Mute is set to On.

Normal picture but no sound

 Check the volume.
 Check whether the volume MUTE button on the remote control has been pressed.

No picture or black and white picture

 Adjust the colour settings.
 Check that the broadcast system selected is correct.

Sound and picture interference

 Try to identify the electrical appliance that is affecting the television, then move it further away.
 Plug the television into a different main socket.

Blurred or snowy picture, distorted sound

 Check the direction, location and connections of your aerial.

This interference often occurs due to the use of an indoor aerial.

Remote control malfunctions

 Replace the remote control batteries.
 Clean the upper edge of the remote control (transmission window).
 Check that the “+” and “–” ends of the batteries are inserted correctly.
 Check that the batteries are drained.

Screen is black and power indicator light blinks steadily

 On your computer check; Power, Signal Cable.
 The TV is using its power management system.
 Move the computer’s mouse or press any key on the keyboard.

 On your equipment check (STB, DVD, etc) ; Power, Signal Cable.
 The TV is using its power management system.
 Press the Source button on the panel or remote control.
 Turn the TV off and on.

English - 44

English - 45

Specifications

Model Name PS-42Q91H PS-42Q91HP PS-50Q91H PS-50Q91HP

Screen Size (Diagonal) 42 inch 50 inch

PC Resolution 1024 x 768 @ 60 Hz 1360 x 768 @ 60 Hz

Sound (Output) 10 W + 10 W 15 W + 15 W

Dimension (WxHxD)

Body
With stand

Weight

Body
With stand

Environmental Considerations

Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

 This device is a Class B digital apparatus.

➢

 Design and specifications are subject to change without prior notice.
 For the power supply, refer to the label attached to the product.

1055 X 700 X 104 mm
1055 X 757 X 316 mm

31 kg
34 kg

10 °C to 40 °C (50 °F to 104 °F)

10% to 80%, non-condensing

-20 °C to 45 °C (-4 °F to 113 °F)
5% to 95%, non-condensing

1231 X 789 X 104 mm
1231 X 849 X 316 mm

42 kg
44 kg

This page is intentionally

left blank.

This page is intentionally

left blank.

Contact SAMSUNG WORLD-WIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care centre.

Country

AUSTRALIA 1300 362 603 www.samsung.com/au
CHINA 800-810-5858, 010- 6475 1880 www.samsung.com.cn
HONG KONG 3698-4698 www.samsung.com/hk
INDIA 3030 8282, 1800 1100 11 www.samsung.com/in
INDONESIA 0800-112-8888 www.samsung.com/id
JAPAN
MALAYSIA
PHILIPPINES 1800-10-SAMSUNG (7267864) www.samsung.com/ph
SINGAPORE 1800-SAMSUNG (7267864) www.samsung.com/sg
SOUTH AFRICA
TAIWAN
THAILAND 1800-29-3232, 02-689-3232 www.samsung.com/th
U.A.E 800SAMSUNG (7267864), 8000-4726 www.samsung.com/mea
VIETNAM 1 800 588 889 www.samsung.com/vn

Customer Care Centre 

0120-327-527 www.samsung.com/jp
1800-88-9999 www.samsung.com/my

0860 7267864 (SAMSUNG) www.samsung.com/za
0800-329-999 www.samsung.com/tw

Web Site

BN68-01131D-01
