Becoming Familiar with the Remote Control
The remote control is used mainly to:
◆ Change sources and adjust the volume
◆ Set up the PDP using the on-screen menu system
PDP ON
SOUND MODE SELECTION
PDP OFF
PICTURE MODE SELECTION
NUMERIC BUTTONS
PICTURE STILL
VOLUME INCREASE
TEMPORARY SOUND SWITCH-OFF
Press it again , or -/+ button
➢
to turn the sound back on.
VOLUME DECREASE
SETTING THE TIMER
DISPLAY AND CLOSE THE MENU/
RETURN TO THE PREVIOUS MENU
MOVE TO THE REQUIRED MENU
ADJUST AN OPTION VALUE
SCREEN EFFECT SELECTION
(BURNING PROTECTION)
AUTO ADJUSTMENT IN PC MODE
OPTION/
RESPECTIVELY
CURRENT TIME DISPLAY
ZOOM/PANNING MENU DISPLAY
(ONLY PC MODE)
NEXT CHANNEL
(NOT AVAILABLE FOR THIS MONITOR)
EXTERNAL INPUT SELECTION
PREVIOUS CHANNEL
(NOT AVAILABLE FOR THIS MONITOR)
INFORMATION DISPLAY
EXIT FROM ANY DISPLAY
CHANGE CONFIRMATION
ULTIPLE DISPLAY CONTROL
M
PICTURE SIZE SELECTION
English
The performance of the remote control may be affected by bright light.
➢
PIP FUNCTIONS;
-PIP ON/OFF
- SIZE SELECTION (SIZE)
- LOCATION SELECTION (LOCATE)
- INPUT SOURCE SELECTION
(SOURCE)
- INTERCHANGE THE MAIN AND THE
SUB PICTURE (SWAP)
- SOUND SELECTION (S.SEL)
Page 2
Connecting to the Audio/Video Input
The "VIDEO IN" connectors are used for the equipment with an Composite Video output, such as
video game devices or video disc players.
Rear of the PDP
(Input)
The "VIDEO OUT" connectors are used for the equipment with an
Composite Video input, such as a camcorder or VCR.
Rear of the PDP
(Output)
VCR
①
DVD
Decoder /
Video game device
Video disc player
Camcorder
Satellite receiver
②
①
If you have a second VCR and wish to copy cassettes tape, connect the source VCR to
the target VCR to
②
When you wish to record a programme, connect the receiver to
OUT”
so that you can redirect the signal from
Whenever you connect an audio or video system to your
☛
PDP, ensure that all
Refer to the documentation supplied with your equipment
for detailed connection instructions and associated safety
precautions.
“VIDEO OUT”
elements are switched off.
so that you can redirect the signal from
“VIDEO IN”
“VIDEO IN”
to
“VIDEO OUT”
“VIDEO IN”
and the VCR to
.
to
“VIDEO IN”
“VIDEO OUT”
“VIDEO
English
and
.
Page 3
Connecting to the S-Video Input
The S-VIDEO and RCA (AUDIO-L/R) connectors are used for equipment with an S-Video output,
such as a camcorder or VCR.
Rear of the PDP
Camcorder
①
and
①
To play picture and sound, both the S-VIDEO and RCA connectors must be used.
VCR
Connecting to the DVD/DTV RECEIVER Input
The “COMPONENT1 IN” (or “R(Pr)/G(Y)/B(Pb)” (video) and “AUDIO”) connectors are used for
equipment with a DVD/ DTV RECEIVER output. (480i, 480p, 720p, 1080i)
Rear of the PDP
English
Y / Pb / Pr
L / R
DVD
or
Pr / Y / Pb
Digital Set-Top Box
and
or
Page 4
Connecting to the DVI Input
The “DVI IN” (video) and “AUDIO” connectors are used for equipment with a DVI output.
Rear of the PDP
Personal Computer
and
Connecting to the RGB(PC) Input
The “RGB1(PC1) IN” (or
connectors are used for interfacing with your PC.
“R(Pr)/G(Y)/B(Pb)/H/V”) and “AUDIO”
Rear of the PDP
or
Personal Computer
English
