Samsung PN64E8000 User Manual

E-MANUAL

Thank you for purchasing this Samsung product.
To receive more complete service, please register

your product at

www.samsung.com/register

Model______________ Serial No.______________

Contents

Channel Menu

• Using the Channel Menu 1

• Memorizing Channels 36

• Other Features 41

Basic Feature

• Changing the Preset Picture Mode 46

• Adjusting Picture Settings 49

• Changing the Picture Size 54

• Changing the Picture Options 63

• Using the TV with Your PC 82

• Changing the Preset Sound Mode 86

• Adjusting Sound Settings 88

Preference Feature

• Connecting to the Network 101

• Setting up the Wired Network 112

• Setting up the Wireless Network 123

• Managing

the Network Connected Devices 147

• Setting the Time 154

• Blocking Programs 165

• Economical Solutions 185

• Picture In Picture (PIP) 189

• Using the TV

with a Keyboard and a Mouse 194

• Other Features 201

• Support Menu 223

Advanced Features

• Using the 3D function 245

• Smart Hub 263

• Customizing the Home Screen 285

• Using the Samsung Apps 315

• Search 324

• Your Video 330

• Family Story 332

• Fitness 342

• Kids 347

• Web Browser 360

• Skype 385

• SMART Interaction 387

• Specification for SMART Interaction 428

• AllShare Play 437

• Using the AllShare Play 458

• My List (In AllShare Play) 462

• Videos (In AllShare Play) 470

• Photos (In AllShare Play) 486

• Music (In AllShare Play) 502

• Using the DLNA Function 515

• Using the MHL function 526

• Anynet+ (HDMI-CEC) 532

Other Information

• Troubleshooting 549

• Picture (Troubleshooting) 563

• Sound (Troubleshooting) 570

• Antenna (Air / Cable) Connection

(Troubleshooting) 574

• PC Connection (Troubleshooting) 577

• Network Connection (Troubleshooting) 578

• Others (Troubleshooting) 579

• 3D (Troubleshooting) 589

• Anynet+ (HDMI-CEC) (Troubleshooting) 591

• AllShare Play (Troubleshooting) 598

• Smart Hub (Troubleshooting) 599

• Web Browser (Troubleshooting) 601

• Using the Smart Touch Control 610

• Supported Subtitle

and AllShare Play file formats 641

• Anti-theft Kensington Lock 649

• Licenses 653

Channel Menu

Using the Channel Menu

Channel

Channel

→

™

Using this function, you can add or

delete channels, set favorite channels,

edit the channel name for analog

broadcasts.

N

The American Academy of Pediatrics

discourages television viewing for

children younger than two years of

age.

●

All

Shows all channels.

●

Added Ch.

Shows all added channels. These are

the channels that appear when you

select CH List

press the CH LIST button.

Remote Control

●

Favorites 1 – Favorites 5

for Smart Touch Control

for Standard

Shows all favorite channels, in up to

five groups. Each group has separate

or

channels.

N

The TV displays Favorites only if

you have added favorites using Edit

Favorites.

N

If the Highlight located in the

Favorites 1 – Favorites 5 category, you

can change the name of category by

selecting b using your remote.

●

Recently Viewed

Shows the most recently viewed

channels.

●

Mostly Viewed

Shows the most frequently viewed

channels.

Using the colored and function buttons

with the Channel

●

When the Highlight located in the

category, you can use these options:

–

Air / Cable

a

Switches the mode and display

between Air and Cable.

N

Appears only if your TV stored

both Air and Cable.

Return

–

R

Return to the previous menu.

●

When the Highlight located in the

channel list, you can use these options:

–

Air / Cable

a

Switches the mode and display

between Air and Cable.

N

Appears only if your TV stored

both Air and Cable.

–

Delete

b

Delete the selected channel(s).

Information

–

`

Displays details of the selected

channel.

Page

–

k

Scrolls the channel list to the next or

previous page.

–

–

Select / Deselect

E

Select or deselect a channel.

Tools

T

Displays the option menu.

Return

–

R

Return to the previous menu.

Using the Tools menu with Channel

●

Add / Delete

Delete a channel from or add a channel

to the Channel list.

To delete a channel in Channel, follow

these steps:

If you want to delete a channel,

1.

select a category of the channel.

Select a channel in the category. A

2.

mark appears to the left of the

c

channel.

N

You can select more than one

channel.

N

If you select the selected channel

again, a

Open the Tools menu using your

3.

mark disappears.

c

remote.

Select the Delete. The message

4.

Deleted the selected channel(s).

appears, and then select OK.

N

You can delete the selected channel

immediately by selecting b using

your remote.

N

When you delete a channel in the

Recently Viewed or Mostly Viewed

category, the channel will disappear

from the category list. But, the

channel is not deleted.

To add a channel in Channel, follow

these steps:

On the Channel screen, select the All

1.

category.

Select a grayed out channel in the All

2.

category. A

mark appears to the

c

left of the channel.

N

You can select more than one

channel.

N

If you select the selected channel

again, a

N

A gray colored channel indicates

mark disappears.

c

the channel has been deleted.

Open the Tools menu using your

3.

remote.

Select the Add. The message Added

4.

the selected channel(s). appears, and

then select OK.

N

The Add menu option only appears

for deleted channel.

N

All deleted channels will be shown

on the All category. You add

channels back to the Added Ch.

category on the All category.

●

Edit Favorites

Sets channels you watch frequently as

favorites, or removes a channel from

list of favorites using the Tools menu.

To set channels as favorites, follow

these steps:

Select the All or Added Ch. category.

1.

Select a channel in the category. A

2.

mark appears to the left of the

c

channel.

N

You can select more than one

channel.

N

If you select the selected channel

again, a

Open the Tools menu using your

3.

mark disappears.

c

remote.

Select the Edit Favorites. The Edit

4.

Favorites screen appears.

Select

5.

using your remote. The

a

selected channel will be moved to

the favorite group.

N

Also, you can select a channel in

the Edit Favorites screen.

N

You can add a favorite channel

to any one of the groups. To

change favorites group, select }

using your remote. Each time you

select }, a favorites group will be

changed.

When done, select OK. The channel

6.

is made as a favorite and is assigned

to the favorite group you selected.

N

The TV displays the “ ” symbol

next to the channel, indicating it

is a favorite.

Using the colored and function buttons

with the Edit Favorites

●

When the Highlight located in the

Added Ch., you can use these

options:

–

Add

a

Add selected channels to the

favorites group.

–

Change Fav.

}

Change the favorites group. Each

time you select } using your

remote, a favorites group will be

changed.

–

Ÿ

Go To

Move to the Highlight to a channel

number immediately by pressing

the number button using your

remote.

Return

–

R

Return to the previous menu.

●

When the Highlight located in the

favorites group, you can use these

options:

–

–

–

Delete

a

Delete the selected channel.

Change order

b

Change the favorites group list

order.

Copy

{

Copy a selected channel to other

favorites groups.

–

Change Fav.

}

Change the favorites group. Each

time you select } using your

remote, a favorites group will be

changed.

–

–

Ÿ

R

Go To

Move to the Highlight to a channel

number immediately by pressing

the number button using your

remote.

Return

Return to the previous menu.

To remove a channel from the list of

favorites, follow these steps:

Select the favorites group category.

1.

Select a channel in the selected

2.

favorites group. A

mark appears

c

to the left of the channel.

N

You can select more than one

channel.

N

If you select the selected channel

again, a

Open the Tools menu using your

3.

mark disappears.

c

remote.

Select Delete. The message Do you

4.

want to delete the selected item(s)?

appears.

Select OK. The message Deleted the

5.

selected item(s). appears.

N

You can delete the selected channel

from the list of favorites group

immediately by selecting b using

your remote.

●

Rename Channel

(Appears only if you have selected an

analog channel.)

Lets you assign a name of up to five

characters to an analog channel. For

example, Food, Golf, etc. This makes it

easier to find and select a channel.

●

Select All / Deselect All

Select all channels in the list. / Deselect

all channels you selected.

Display Icons Used in the Channel screens

: An analog channel.

: A favorite channel.

: A locked channel.

Schedule Manager

Schedule Manager

→

™

Using this function, you can set

the TV to display a desired channel

automatically on a day and at a time of

your choice.

N

You must set the current time first

using the Time

Clock function in

→

System menu to use this function.

To use the Schedule Viewing, follow

these steps:

On the Schedule Manager screen,

1.

select a using your remote.

Set Antenna, Channel, Repeat, and

2.

Start Time.

●

Antenna

You can view an antenna source. If

your TV has digital broadcasts, you

can change a source from analog to

digital.

If you want to change an antenna

source between Air and Cable, select

an antenna source you want in

Antenna menu (Channel

●

Channel

→

Select the desired channel.

N

You can only select memorized

channels.

●

Repeat

Select Once, Manual, Sat~Sun,

Antenna).

Mon~Fri or Everyday. If you select

Manual, you can set the day you

want.

N

The

mark indicates a day you’

c

ve selected.

Date: You can set a desired date.

N

The Date is available only when

you select Once in Repeat.

●

Start Time

You can set the start time you want.

When done, select OK. The selected

3.

channel is scheduled for viewing.

N

On the Schedule Manager screen,

you can check a list of Schedule

Viewing.

To delete an item in a list of scheduled

viewing, follow these step:

On the Schedule Manager screen,

1.

highlight an item you want to delete.

Open the Tools menu using your

2.

remote.

Select Cancel Schedule. The Cancel

3.

selected list(s)? message appears.

Select Yes. The selected schedule

4.

will be canceled.

N

If you press the INFO button

for

Standard Remote Control

Smart Touch Control

after highlighting an

or select Info

for

item, the Information screen appears.

On the Information screen, you

can change or cancel the Schedule

Viewing.

Cancel Schedule: Cancel the

Schedule Viewing.

Edit Schedule: Change the Schedule

Viewing.

Return: Return to the previous

screen.

Channel List

Using this function, you can view

channel list, program information,

favorite channel, and manage schedules

of timer viewing.

Press the CH LIST button

1.

Remote Control

or select CH List

for Standard

for

Smart Touch Control

. The Channel List

screen is displayed immediately.

Change a channel or channel list

2.

mode.

●

Added Ch.

Shows all added channels.

●

Favorites 1 – Favorites 5

Shows all favorite channels, in up

to five groups. Each group has a

separate screen.

N

The TV displays favorite groups

only if you have added favorites

using Edit Favorites.

Using the colored and function buttons

with the Channel List

N

If you press the INFO button

for

Standard Remote Control

for Smart Touch Control

or select Info

, the TV displays

details of the selected program.

●

Antenna

a

Switches the mode and display

between Air and Cable.

N

Appears only if your TV stored both

Air and Cable.

●

Program View / Channel View

{

For digital channels, switches the

display between Program View and

Channel View.

When you select a digital channel in

Channel List, select once to display a

list of programs on that channel. select

again to re-display the Channel View.

●

CH Mode / Channel

lr

On Channel View screen, Toggles

between the Favorites list (if you have

added favorites using Edit Favorites)

and the Added Ch. list. / On Program

View screen, change a channel.

●

Watch / Information

E

Displays the channel you selected. /

Displays details of the selected channel.

●

Page

k

Scrolls the Channel List to the next or

previous page.

Display Icons Used in the Channel List

screens

: An analog channel.

: A reserved program.

: A locked channel.

Using the Schedule Viewing in Channel List

(digital channels only)

You can use the Schedule Viewing

in Channel List to schedule a digital

channel program for viewing. The TV

will turn on and display the digital

channel program when the program

begins.

Press the CH LIST button

1.

Remote Control

Smart Touch Control

or select CH List

. The Channel List

for Standard

for

screen appears.

Select a desired digital channel.

2.

Select

3.

using your remote. The TV

{

displays program list of the selected

channel.

Select a desired program in the

4.

program list, and then select

Information using your remote.

On the Information screen, select

5.

the Schedule Viewing. The selected

program is set to Schedule Viewing.

N

If you want to cancel the Schedule

Viewing, follow Steps 1 through

4, and then select the Cancel

Schedule.

Memorizing Channels

Antenna

Menu

Before your television can memorize

the available channels, you must select

your TV's signal source, Air (using an

antenna) or Cable. Select Air or Cable.

After you have selected the signal

source, go on to the Auto Program

function.

Channel

→

Antenna

→

N

Selecting the signal source using the

Antenna function also determines

the signal source the TV is tuned to.

For example, if you receive your TV

signal over the air, and you select

Cable, you will see only snow. You

must select Air to see a picture.

Auto Program

Menu

The Auto Program function memorizes

all channels that are available over the

air or through your cable system and

Channel

→

Auto Program

→

adds them to the Channel list.

To start the Auto Program, follow these

steps:

Go to the Auto Program menu.

1.

Select Air or Cable or both, and then

2.

select Next. A

mark appears in

c

the check box.

N

If you selected Air or Cable in the

Antenna menu, your choice will

already be selected.

If you selected the Cable, the cable

3.

system screen appears. Select the

Digital Cable System.

N

If you selected the Air only, the

Auto Program starts.

Select the correct cable signal format

4.

- STD, HRC or IRC.

N

Most cable systems use STD

(Standard).

Repeat for Analog Cable System.

5.

Select Next. The Auto Program

6.

starts.

N

After all the available channels are

stored, the Auto Program removes

scrambled channels. When done,

the Auto Program menu then

reappears. This process can take

up to 30 minutes.

Other Features

Clear Scrambled Channel

Menu

→

Channel

This function filters out scrambled

channels after the Auto Program is

completed. This process may take up

to 30 minutes.

N

This function is only available in

Channel

Clear Scrambled

→

Cable mode.

How to Stop the Clear Scrambled Channel

function

To stop the Clear Scrambled Channel

1.

function, select Stop.

The message Stop searching for

2.

scrambled channels? appears. Select

Yes.

The Clear Scrambled Channel

3.

function will be stopped.

Fine Tune

Menu

(analog channels only)

Channel

→

Fine Tune

→

If the reception is clear, you do not

have to fine tune the channel, as this is

done automatically during the search

and store operation. If the signal is

weak or distorted, fine tune the channel

manually. Scroll to the left or right until

the image is clear.

N

Select the channel, and then select

Fine Tune.

N

Fine tuned channels that have been

saved are marked with an asterisk “*”

on the right-hand side of the channel

number in the channel banner.

N

To reset fine-tuning, select the

channel, select Fine Tune, and then

select Reset on the Fine Tune screen.

Crosstalk Noise Reduction

Menu

Channel

→

Crosstalk Noise

→

Reduction

(analog channels only)

This function reduce diagonal noise

in picture caused by the crosstalk of

signals. If your TV displays with a

noise while watching TV, turns on this

function.

Basic Feature

Changing the Preset Picture Mode

Picture Mode

Menu

Picture modes apply preset adjustments

to the picture.

N

●

Dynamic


→

When your TV is connected to a PC

Picture Mode

→

via the HDMI to DVI cable, you can

only select Entertain and Standard.

Brightens the screen. Suitable for a

bright room.

●

Standard

Suitable for a normal environment.

●

Natural

for LED TV

/ Relax

for PDP TV

Suitable for reducing eye strain.

●

Movie

Darkens the screen, making it less

glary. Suitable for watching movies in a

darkened room.

●

Entertain

Sharpens the picture. Suitable for

games.

N

Only available when the TV is

connected to a PC via an HDMI to

DVI and an HDMI to HDMI cables.

Adjusting Picture Settings

Backlight

Menu


→

Adjusts the brightness of the screen

by adjusting the brightness of the

individual pixels.

Contrast

for LED TV

Backlight / Cell Light

→

/ Cell Light

for PDP TV

Menu

Increases or decreases the contrast

between dark and light areas of the


→

Contrast

→

picture.

Brightness

Menu

Adjusts the brightness of the screen.

Not as effective as Backlight / Cell

Light.

Sharpness

Menu


→


→

Brightness

→

Sharpness

→

Sharpens or dulls the edges of objects.

Color

Menu

Adjusts the color saturation. The higher

the Color setting, the more intense the

color. Low settings remove color and

the picture becomes black, white and

gray.


→

Color

→

Tint (G/R)

Menu


→

Tint (G/R)

→

Adjusts the amount of green and red in

the picture. As you increase the amount

of green, the amount of red decreases

and vice versa.

To adjust picture quality, follow these steps:

Select an option you want to adjust.

1.

When you select an option, a slider

screen appears.

Adjust the option value using your

2.

remote.

N

When you make change to option

value, the OSD will be adjusted

accordingly.

N

When your TV is connected to a PC

via the HDMI to DVI cable, Color and

Tint (G/R) is not available.

N

You can adjust and store Settings for

each external device connected to

the TV.

N

Lowering picture brightness reduces

power consumption.

Changing the Picture Size

Screen Adjustment

Menu

Using this function, you can make

change to various picture size and

aspect ratio options.

●

Picture Size

If you have a cable box or satellite


→

Screen Adjustment

→

receiver, it may have its own set of

screen sizes as well. However, we

highly recommend you use your TV's

16:9 mode most of the time.

N

If you have set Double (

à, Œ

)

mode in PIP (Picture-in-Picture), you

cannot adjust the Picture Size.

16:9: Sets the picture to the 16:9 wide

screen format.

Zoom1: Provides moderate

magnification of the picture. Sides, top,

and bottom are cut off.

Zoom2: Provides larger magnification

of the picture. Sides, top, and bottom

are cut off.

Wide Fit: Enlarges the aspect ratio of

the picture so it fits the entire screen.

N

Available with HD 1080i / 720p

signals in 16:9 mode.

4:3: Sets the picture to basic (4:3)

mode.

N

Do not set your TV to 4:3 format for

a long time. The borders displayed

on the left and right, or top and

bottom of the screen may cause

image retention (screen burn) which

is not covered by the warranty.

Screen Fit: When your TV inputs HDMI

(720p / 1080i / 1080p) or Component

(1080i / 1080p) signals, displays the full

image without any cut-off.

Smart View 1: Reduces the 16:9 picture

by 50%.

for LED TV

Smart View 2: Reduces the 16:9 picture

by 25%.

for LED TV

N

Smart View 1 is enabled only in

HDMI mode.

N

Smart View 2 is enabled only in

HDMI or DTV mode.

N

The picture size can vary depending

on the input resolution when you

play content from Videos in AllShare

Play.

●

Position

Adjusts the picture position. Position

is only available if Picture Size is set to

Zoom1, Zoom2, Wide Fit, or Screen Fit.

N

In DTV mode, Position is not

available when Picture Size is set to

Screen Fit.

To use the Position function after

selecting Zoom1, Zoom2, Wide Fit or

Screen Fit, follow these steps:

Select the Position.

1.

On the Position screen, select

2.

Position, and then move the picture

to position you want using your

remote.

When done, select Position again,

3.

and then select Close.

N

To reset the picture position,

select Reset.

Picture Sizes available by Input Source:

–ATV, AV: 16:9, Zoom1, Zoom2, 4:3

–Component (480i, 480p): 16:9,

Zoom1, Zoom2, 4:3

–DTV (720p): 16:9, Wide Fit, 4:3,

Smart View 2

for LED TV

–DTV (1080i, 1080p): 16:9, Wide Fit,

4:3, Screen Fit, Smart View 2

TV

for LED

–Component(720p): 16:9, Wide Fit, 4:3

–Component(1080i, 1080p): 16:9, Wide

Fit, 4:3, Screen Fit

–HDMI (720p, 1080i, 1080p): 16:9,

Wide Fit, 4:3, Screen Fit, Smart View

1

for LED TV

N

Depending on the input source, the

, Smart View 2

for LED TV

picture size options may vary.

N

The available items may differ

depending on the selected mode.

N

HD (High Definition): 16:9 -

1080i/1080p (1920x1080), 720p

(1280x720)

N

You can adjust and store settings

for each external device you have

connected to an input on the TV.

Changing the Picture Options

Advanced Settings

Menu

Using this function, you can configure

advanced picture settings to create

your preferred picture.

N


→

Advanced Settings is available only

Advanced Settings

→

when the Picture Mode is set to

Standard or Movie mode.

N

When connecting a PC using the

HDMI-DVI cable, you can only

make changes to White Balance and

Gamma.

●

Dynamic Contrast

Adjusts the screen contrast.

●

Black Tone

Darker settings make blacks look

darker.

●

Flesh Tone

Adjusts the amount of red in skin

tones.

●

RGB Only Mode

Displays the Red, Green and Blue colors

so you can make fine adjustments to

hue and saturation.

●

Color Space

Adjusts the range and variety of colors

(the color space) available to create

images.

N

To adjust Color, Red, Green, Blue and

Reset, set the Color Space to Custom.

●

White Balance

Adjusts the color temperature of the

picture so that white objects look white

(instead of, for example, slightly pink or

slightly yellow) and the overall color of

the picture looks natural.

R-Offset / G-Offset / B-Offset: Adjusts

each color’s (red, green, blue) darkness.

R-Gain / G-Gain / B-Gain: Adjusts each

color’s (red, green, blue) brightness.

Reset: Resets the White Balance to it’s

default settings.

●

10p White Balance

Controls the white balance in 10 point

intervals by adjusting the red, green,

and blue brightness.

N

Available when the Picture Mode is

set to Movie and when the external

input is set to all input.

N

Some external devices may not

support this function.

Interval: Select interval to adjust.

Red: Adjust the red level.

Green: Adjust the green level.

Blue: Adjust the blue level.

Reset: Resets the 10p White Balance to

its default settings.

●

Gamma

Adjusts the primary color intensity.

●

Expert Pattern

Use the Expert Pattern function to

calibrate the picture. If the OSD menu

disappears or a menu other than the

Picture menu is opened, the TV saves

the calibration and the Expert Pattern

screen disappears.

Off: Turns the Expert Pattern function

of f.

Pattern1: This test screen demonstrates

the effect of the display settings on

shades of grey and black.

Pattern2: This test screen demonstrates

the effect of the display settings on

colors.

N

After selecting Pattern1 or Pattern2,

you can adjust any of the advanced

settings for desired effect.

N

While the Expert Pattern is running,

the TV does not output sound.

N

Only enabled in DTV, Component,

and HDMI modes.

●

xvYCC

Setting xvYCC on increases picture

detail and enlarges the color space

when you are watching movies input

from an external device (e.g. BD/DVD

player) connected to the TV’s HDMI or

Component IN jacks.

N

Available only when you set

the Picture Mode to Movie and

the external input to HDMI or

Component.

N

Some external devices may not

support this function.

●

Motion Lighting

When on, the TV automatically

adjusts the brightness of the screen in

response to the brightness of the room.

In bright light, the screen brightens. In

dim light, the screen dims.

N

Only available in Standard mode.

N

This feature is not supported in 3D

mode.

N

When you change the Backlight

for LED TV

/ Cell Light

for PDP TV

Contrast or Brightness, the TV sets

the Motion Lighting to Off.

●

Black Enhancer

for LED TV

Enhance picture depth by adjusting

,

black color depth.

N

Available only when Picture Mode is

set to Movie.

Picture Options

Menu

Using this function, you can configure

additional picture settings to suit your

preference.

N


→

When your TV is connected to a PC

Picture Options

→

via the HDMI to DVI cable, you can

only make changes to Color Tone.

●

Color Tone

Cool makes the picture bluer (cooler).

Warm1 and Warm2 make the picture

redder (warmer).

N

Warm1 and Warm2 are deactivated

when the Picture Mode is set to

Dynamic.

N

You can adjust and store settings for

each external device connected to an

input on the TV.

●

Digital Noise Filter

If the broadcast signal received by your

TV is weak, you can activate the Digital

Noise Filter feature to reduce any static

and ghosting that may appear on the

screen.

Auto Visualization: When changing

analog channels, displays signal

strength.

N

When the signal is weak, try all the

options until the TV displays the best

picture.

N

Only available for analog channels.

N

When the bar is green, you are

receiving the best possible signal.

●

MPEG Noise Filter

Reduces MPEG noise to provide

improved picture quality.

●

HDMI Black Level

Lets you adjust the screen depth by

selecting a black level.

N

Available only in HDMI mode.

●

Film Mode

Sets the TV so that it senses and then

processes film signals from all sources

automatically and adjusts the picture

for optimum quality.

N

Available in TV, AV, Component (480i

/ 1080i) and HDMI (1080i).

●

Auto Motion Plus

for LED TV

Removes blur and judder from scenes

with larger amounts of rapid movement

to provide a clearer picture.

Blur Reduction: Adjusts the blur

reduction level for signals input from

all video sources.

Judder Reduction: Adjusts the Judder

reduction level for signals input from

a video source through which you are

playing a movie.

Reset: Reset the custom settings.

N

The info screen on your TV displays

the resolution and frequency of

the incoming video signal (60 Hz).

This displayed frequency is not the

frequency of the picture the TV is

displaying when you have Auto

Motion Plus on.

N

If noise occurs on the screen,

please set the Auto Motion Plus to

Off. If the Auto Motion Plus is set

to Custom, you can control Blur

Reduction and Judder Reduction

manually and use Reset to reset both

to their default settings.

N

If the Auto Motion Plus is set

to Demo, you can compare the

difference between a picture with

Auto Motion Plus On and Auto

Motion Plus Off modes.

●

LED Motion Plus

for LED TV

Removes blur and judder from scenes

with large amounts of rapid movement

to provide a clearer picture.

N

Available only when Picture Mode is

set to Dynamic, Standard, or Movie.

Reset Picture

Menu

Resets your current picture mode to its

default settings.


→

Reset Picture

→

Using the TV with Your PC

Using Your TV as a Computer (PC)

Display

Entering the Video Settings (Based on

Windows 7)

For your TV to work properly as a

computer display, you must enter the

correct video settings.

N

Depending on your version of

Windows and your video card, the

procedure on your PC will probably

differ slightly from the procedure

presented here.

N

However, the same basic information

will apply in most cases. (If not,

contact your computer manufacturer

or Samsung Dealer.)

Click “Control Panel” on the

1.

Windows start menu.

Click “Appearance and Themes”

2.

in the “Control Panel” window. A

display dialog box appears.

Click “Display”. Another display

3.

dialog box appears.

Click the “Settings” tab on the

4.

display dialog box.

–On the Settings tab, set the

correct resolution (screen size).

The optimal resolution for this TV

is 1920 x 1080.

–If a vertical-frequency option

exists on your display settings

dialog box, select “60” or “60 Hz”.

Otherwise, just click “OK” and exit

the dialog box.

Changing the Preset Sound Mode

Sound Mode

Menu

Sound modes apply preset adjustments

to the sound.

N

●

Standard

Selects the normal sound mode.

Sound

→

If Speaker Select is set to External

Sound Mode

→

Speaker, the Sound Mode is disabled.

●

Music

Emphasizes music over voices.

●

Movie

Provides the best sound for movies.

●

Clear Voice

Emphasizes voices over other sounds.

●

Amplify

Increase the intensity of high-frequency

sound to allow a better listening

experience for the hearing impaired.

Adjusting Sound Settings

Sound Effect

Menu

N

N

●

Virtual Surround

This function provides a virtual 5.1

Sound

→

If Speaker Select is set to External

Sound Effect

→

Speaker, the Sound Effect is disabled.

Available only when the Sound Mode

is set to Standard.

channel surround sound experience

through a pair of speakers using HRTF

(Head Related Transfer Function)

technology.

●

Dialog Clarity

This function allows you to increase the

intensity of a voice over background

music or sound effects so that dialog

can be heard more clearly.

●

Equalizer

The Equalizer displays a series of

sliders. Use the arrow buttons to select

a slider, and change the slider’s value.

To Reset the Equalizer, select the Reset.

A pop-up appears asking if you want

to reset, select Yes. To exit, select

Close.

Balance L/R: Adjusts the balance

between the right and left speaker.

100Hz / 300Hz / 1kHz / 3kHz / 10kHz

(Bandwidth Adjustment): Adjusts

the loudness of specific bandwidth

frequencies.

Reset: Resets the equalizer to its default

settings.

3D Audio

Menu

3D audio technology provides the

immersive sound corresponding to the

pop-up effect of 3D video by audio

depth control in perspective.

N

Sound

→

Available only when watching 3D

3D Audio

→

image.

Broadcast Audio Options

Menu

Sound

→

Broadcast Audio Options

→

●

Preferred Language

(digital channels only)

Digital-TV broadcasts can

simultaneously transmit many audio

tracks (for example, simultaneous

translations of the program into foreign

languages). You can only select a

language from among the ones being

broadcasted.

●

Multi-Track Sound

The broadcasts can transmit one or

more audio tracks. You can select a

sound you want to listen from among

the ones being broadcasted.

N

While watching TV, open the Tools

menu using your remote, you can

select the Multi-Track Sound in Tools

menu immediately.

N

Multi-Track Sound may differ

depending on the program being

broadcast or broadcast signal.

SPDIF Output

Menu

SPDIF (Sony Philips Digital Interface)

provides digital audio output to speakers

and various digital devices such as A/V

Receivers and Home Theaters which

reduces interference and distortion.

●

Audio Format

Sound

→

SPDIF Output

→

You can select the Digital Audio output

(SPDIF) format. The available Digital

Audio output (SPDIF) format may differ

depending on the input source.

●

Audio Delay

Lets you correct timing mismatches

between the audio track and the video

when you are watching the TV and

listening to digital audio output from

the TV through an external device such

as an AV receiver. When you select the

Audio Delay, a slider screen appears.

Adjust the option value using your

remote (0ms ~ 250ms).

Speaker Settings

Menu

●

Speaker Select

If you are listening to the sound track

of a broadcast or movie through an

external receiver, you may hear a

sound echo caused by the difference

in decoding speed between the TV’s

Sound

→

Speaker Settings

→

speakers and the speakers attached to

your audio receiver. If this occurs, set

the TV to External Speaker.

N

When the Speaker Select is set to
