Samsung P63FP-2 User Manual

SyncMaster P50HP, P50HP-2, P63FP, P63FP-2

PDP Display

User Manual

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property damage.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.

Note

Power

Prohibited

Do not disassemble

Do not touch

When not used for extended period of time, set your computer to DPM.

If using a screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases (or countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or

loose power outlet.

Important to read and understand at all times

Disconnect the plug from the outlet

Ground to prevent an electric shock

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or

plugging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power out-

let.

• Otherwise, it may result in electric shock or personal injury.

Safety Instructions

Ensure that the power plug is plugged into the power outlet

firmly and correctly.

• Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place

any heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

• Otherwise, this may result in damage to the product due to electric shock.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable.

Installation

• Otherwise, this may cause electric shock or fire.

Use only the power cord provided by our company. Do not use the provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Be sure to contact an authorized Service Center when installing your monitor in a location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24 hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Ensure that at least two persons lift and move the product.

• Otherwise, it may be dropped and cause personal injury, and/

or damage the product.

When installing the product in a cabinet or rack, make sure that the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGARETTES AND ANY HEATING APPLIANCES NEAR THE PRODUCT.

• Otherwise, this may result in fire.

Safety Instructions

Keep heating appliances as far away from the power cord or the product as possible.

• Otherwise, this may result in electric shock or fire.

Do not install it in a badly ventilated location such as a bookcase or closet.

• Otherwise, this may result in fire due to an increase in the in-

ternal temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall mount.

Clean

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that there is a clearance of more than 4 inches (10 cm) from the wall.

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children

play with it.

If the height of your monitor is adjustable, do not place any object or part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying

it.

When cleaning the PDP Display case or the surface of the TFT-PDP screen, wipe with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of

the structure and the screen surface may peel off.

Clean the product using a soft cloth with a monitor cleaner only.

• If you must use a cleaner other than the monitor cleaner, dilute

it with water at a ratio of 1:10.

Safety Instructions

When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth.

• Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and clean it with a soft, dry cloth.

• Do not use chemicals such as wax, benzene, alcohol, thinner,

mosquito repellant, lubricant, or cleaner.

• These may change the appearance of the product surface and

peel off the indication labels on the product.

Since the product housing is easily scratched, make sure to use the specified cloth only.

Others

When cleaning the product, do not spray water directly onto the main body of the product.

• Ensure that water does not enter the product and that it is not

wet.

• Otherwise, this may result in electric shock, fire or a malfunc-

tion.

The product is a high voltage product. Do not disassemble, repair or modify the product yourself.

• Otherwise, this may result in electric shock or fire.

• If the product needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming from the product, disconnect the power plug immediately and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust, smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

If thunder or lightning is occurring, do not touch the power cord or antenna cable.

• Otherwise, this may result in electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and left while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table or curtain.

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Do not place any containers containing water, vases, flowerpots, medicines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the

power cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and steel, or flammable objects, such as matches or paper, inside the product (through the ventilating openings, input and output terminals, etc).

• If water or foreign material enters the product, disconnect the

power cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain may occur.

• If you are not using your product for a long period of time, put

it into sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

When using headphones or earphones, do not turn the volume too high.

• Having the sound too loud may damage your hearing.

Safety Instructions

To avoid eyestrain, do not sit too close to the product.

Take a rest for at least five (5) minutes after using the monitor for one (1) hour.

• This reduces eye fatigue.

Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage

the product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect the power plug, antenna cable, and all the cables connected to the product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect the power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust,

and may result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as cookies etc. that may attract the attention of children and to the product.

• Your children may hang onto the product causing it to fall and

this may result in personal injury or death.

Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

• If children have had the battery in their mouths, consult your

doctor immediately.

When replacing the battery, insert it with the right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause

fire, personal injury or damage due to leakage of the internal liquid.

Use only the specified standardized batteries, and do not use a new battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, per-

sonal injury or damage due to a leakage of the internal liquid.

Safety Instructions

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

• The customer can return used or rechargeable batteries to a

nearby public recycling center or to a store selling the same type of the battery or rechargeable battery.

Do not place the product in a location exposed to direct sunlight or near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in

fire.

Do not drop any objects onto the product or cause any impact to the product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power plug; ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display panel becomes hot. Do not touch it.

Keep the small accessories in a location out of the reach of children.

Be careful when adjusting the angle of the product or the height of the stand.

• This may result in personal injury as your hand or fingers may

become caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children to reach.

• Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product

on a level and stable surface.

Safety Instructions

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the prod-

uct.

Introduction

Package Contents

Note

Please make sure the following items are included with your PDP Display.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Checking the Contents of the Package

Remove the lock from the package box, as shown in the figure above.

• After unpacking the package, make sure to check the contents of the package.

• Make sure to keep the package box for transporting the product in the future.

• After unpacking, you may use the lower part of the package box as a temporary stand for

Unpacking

Lift up the package box by

holding the grooves on

both sides of the package

box.

Note

product test or operation check.

Check the contents of the

package.

Remove the Styrofoam

and vinyl cover.

Manuals

Introduction

PDP Display

Quick Setup Guide Warranty Card

(Not available in all loca-

tions)

Cables

Power Cord D-Sub Cable

Others

Remote Control Batteries (AAA X 2)

(Not available in all loca-

tions)

User's Guide

Ferrite Core for Power

Cord

Sold separately

DVI Cable Wall Mount KIT BNC to BNC Cable

Network Box RGB to BNC Cable

Ferrite Core

• The ferrite cores are used to shield the cables from interfer-

ence.

• When connecting a cable, open the ferrite core and clip it

around the cable near the plug.

Introduction

Your PDP Display

Note

The PDP device may interfere with an amateur radio or AM radio.

Front

SOURCE button [SOURCE]

Switches from PC mode to Video mode. Changing the source is only allowed for external devices that are connected to the PDP Display at the time.

[PC] → [DVI] → [AV] → [HDMI] → [MagicInfo] → [BNC] → [Component]

Note

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port

and

network

box cannot be connected at the same time.

Enter button [ ]

Activates a highlighted menu item.

MENU button [MENU]

Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu.

- VOL+

Moves from one menu item to another horizontally or adjusts selected menu values. When OSD is not on the screen, push the button to adjust volume.

SEL

Moves from one menu item to another vertically or adjusts selected menu values.

Power button [ ]

Use this button for turning the PDP Display on and off.

Power indicator

Shows PowerSaver mode by blinking green

Note

Introduction

Rear

See PowerSaver power saving functions. For energy conservation, turn your PDP Display OFF when it is not needed or when leaving it unattended for long periods.

described in the manual for further information regarding

Remote Control Sensor

Aim the remote control towards this spot on the PDP Display.

Note

For detailed information concerning cable connections, refer to Connecting Cables under Setup. The PDP Display's configuration at the back may vary slightly depending on the PDP Display model.

POWER IN

The power cord plugs into the PDP Display and the wall plug.

Introduction

RS232C OUT/IN (RS232C Serial PORT)

MDC(Multiple Display Control) Program Port

RGB IN (PC Connection Terminal (In-

put))

• Use a D-Sub Cable (15 pin D-Sub) - PC mode (Analog PC)

• Connect the RGB IN port on the monitor to the BNC port on the PC using the RGB to BNC cable.

DVI IN (PC Video Connection Terminal)

Connect the [DVI IN] port on the monitor to the DVI port on the PC using the DVI cable.

DVI/RGB AUDIO IN (PC/DVI Audio Con-

nection Terminal (Input))

AV/COMPONENT AUDIO IN [R-AUDIO-

Connect the port of the DVD, VCR (DVD / DTV Set-Top Box) to the [R-AUDIO-L] port of the PDP Display.

DVI OUT

• Connect a monitor to another monitor through a DVI cable.

• Connect the [DVI OUT] port on the monitor to the [HDMI IN] port on the other monitor using the DVI to HDMI cable.

• DVI, HDMI and network signals sent via the [DVI OUT] port are displayed on the second display which has the DVI IN port.

Note

Up to 6 Full HD or 10 HD monitors can be connected (May differ depending on the product).

Introduction

AV IN [VIDEO]

Connect the AV IN [VIDEO] terminal of your monitor to the video output terminal of the external device using a VIDEO cable.

AUDIO OUT

Headphone/External speaker output terminal.

HDMI IN

Connect the HDMI terminal at the back of your PDP Display to the HDMI terminal of your digital output device using a HDMI cable.

Up to HDMI cable 1.2 can be supported.

BNC OUT [R, G, B, H, V] (BNC Terminal

(Output))

BNC (Analog PC) Connection: connecting the R, G, B, H, V ports.

The number of PDP Displays that can be connected to the loopout depends on the cables, signal source, etc. With cables or signal source where there is no degradation, up to 10 PDP Displays can be connected (May not be supported depending on the connected cable).

BNC/COMPONENT IN [R/PR, G/Y, B/ PB, H, V] (BNC/Component Connection Terminal (input))

- During BNC input, please check specifications for the input ports below.

• [R/PR] --> Red port input

• [G/Y] --> Green port input

• [B/PB] --> Blue port input

- During component input, please check specifications for the input ports below.

• [R/PR] --> Red port input

• [G/Y] --> Green port input

• [B/PB] --> Blue port input

Introduction

Kensington Lock

The Kensington Lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use.

Note

The location of the Kensington Lock may be different depending on its model.

Using the Anti-Theft Kensington Lock

Note

See Connecting Cables for further information regarding cable connections.

Remote Control

Note

The performance of the remote control may be affected by a TV or other electronic device operating near the PDP Display , causing a malfunction due to interference with the frequency.

1. Insert the locking device into the Ken-

sington slot on the Monitor and turn

it in the locking direction .

2. Connect the Kensington Lock cable.

3. Fix the Kensington Lock to a desk or a

heavy stationary object.

Introduction

POWER

OFF

Number Buttons

DEL / GUIDE button

- VOL +

SOURCE

D.MENU

TOOLS

Up-Down Left-Right buttons

INFO

COLOR BUTTONS

TTX/MIX

MTS/DUAL

ENTER/PRE-CH

MUTE

CH/P

RETURN

EXIT

MagicInfo

1. POWER

OFF

3. Number Buttons Used to enter the password during the OSD adjustment or

4. DEL / GUIDE button

Turns the product On.

Turns the product Off.

to use MagicInfo.

The "-" button is used to select Digital channels.

Electronic Program Guide (EPG) display.

- This button is disabled for this PDP display.

5. - VOL + Adjusts the audio volume.

6. SOURCE

D.MENU DTV menu display

8. TOOLS Use to quickly select frequently used functions.

Press this button to switch to MagicInfo or PC mode or a connected external input source.

- This button is disabled for this PDP display.

Introduction

9. Up-Down Left-Right buttons

10. INFO

11. COLOR BUTTONS Press to add or delete channels and to store channels to the

12.

13. MTS/DUAL - This function does not work for this PDP Display.

TTX/MIX

Moves from one menu item to another horizontally, vertically or adjusts selected menu values.

Current picture information is displayed on the upper left corner of the screen.

favorite channel list in the “Channel List” menu.

- This button is disabled for this PDP display.

TV channels provide written information services via teletext.

- Teletext Buttons

- This button is disabled for this PDP display.

MTS-

You can select MTS (Multichannel Television Stereo) mode.

Audio Type MTS/S_Mode Default

FM Stereo Mono Mono Manual

Stereo Mono ↔ Stereo

SAP Mono ↔ SAP Mono

DUAL-

STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM MONO/NICAM STEREO can be operated depending on the broadcasting type by using the DUAL button on the remote control while watching TV.

14.

15. MUTE

16. CH/P In TV mode, selects TV channels.

ENTER/PRE-CH

This button is used to return to the immediately previous channel.

- This button is disabled for this PDP display.

Pauses (mutes) the audio output temporarily. This is displayed on the lower left corner of the screen. The audio comes back on if MUTE or - VOL + is pressed in the Mute mode.

Change

- This button is disabled for this PDP display.

17. TV Selects the TV mode directly.

- This button is disabled for this PDP display.

18. MENU Opens the on-screen menu and exits from the menu or closes the adjustment menu.

19.

RETURN

Returns to the previous menu.

Introduction

20. EXIT

21. MagicInfo MagicInfo Quick Launch Button.

Exits from the menu screen.

This button is disabled for products that do not support MagicInfo.

Mechanical Layout(P50HP, P50HP-2)

Mechanical Layout

Note

PDP Display Head

Installation VESA Bracket

• When installing VESA, make sure to comply with the international VESA standards.

• Purchasing VESA Bracket and Installation Information : Please contact your nearest

SAMSUNG Distributor to place an order. After your order is placed, installation professionals will visit you and install the bracket.

• At least 2 persons are needed in order to move the PDP Display.

• SAMSUNG is not responsible for any product damage or any injury caused by installation

Dimensions

Introduction

at customer's discretion.

Notice

For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.

Wall Bracket Installation

• Contact a technician for installing the wall bracket.

• SAMSUNG Electronics is not responsible for any damages to the product or harm to

customers when the installation is done by the customer.

• This product is for installing on cement walls. The product may not stay in place when

installed on plaster or wood.

Components

Only use the components and accessories shipped with the product.

Wall Bracket(1) Hinge(Left 1, Right1)Plastic

Hanger (4)

Screw (A)(11)

Screw (B)(4)

Anchor (11)

Wall Bracket Assembly

Note

There are two hinges(left and right). Use the correct one.

1. Insert and tighten the Captive Screw in the direction of the arrow.

When done, mount the wall bracket on the wall.

Introduction

A - Captive Screw

B - Wall Bracket

C - Hinge (Left)

D - Hinge (Right)

2. Before drilling into the wall, check if the length between the two locking holes at the back

of the product is correct.

If the length is too short or long, loosen all or some of the 4screws on the wall bracket to adjust the length.

A - Length between the two locking holes

3. Check the installation diagram and mark the drill points on the wall. Use the 5.0 mm bit

to drill holes deeper than 35 mm. Fix each anchor in the corresponding hole. Match each

Introduction

of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A.

To mount the product on the wall bracket

The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same)

1. Remove the 4 screws on the back of the product.

2. Insert the screw B into the plastic hanger.

Notice

• Mount the product on the wall bracket and make sure it is properly fixed to the left and right plastic hangers.

• Be careful when installing the product on the bracket as fingers can be caught in the holes.

• Make sure the wall bracket is securely fixed to the wall, or the product may not stay in place after installation.

3. Tighten the 4 screws in step 2 (plastic hanger + screw B)to the rear holes of the product.

Introduction

4. Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket.

A - PDP Display

B - Wall Bracket

C - Wall

Wall Bracket Angle Adjustment

Adjust the bracket angle to -2° before installing it on the wall.

1. Fix the product to the wall bracket.

2. Hold the product at the top in the center and pull it forward (direction of the arrow) to adjust the angle.

Note

You can adjust the bracket angle between -2° and 15°.

Make sure to use the top center, and not the left or the right side of the product to adjust the angle.

Mechanical Layout(P63FP, P63FP-2)

Mechanical Layout

Introduction

PDP Display Head

Installation VESA Bracket

• When installing VESA, make sure to comply with the international VESA standards.

• Purchasing VESA Bracket and Installation Information : Please contact your nearest

• At least 2 persons are needed in order to move the PDP Display.

• SAMSUNG is not responsible for any product damage or any injury caused by installation

Dimensions

Introduction

SAMSUNG Distributor to place an order. After your order is placed, installation professionals will visit you and install the bracket.

at customer's discretion.

Notice

For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.

Wall Bracket Installation

• Contact a technician for installing the wall bracket.

• SAMSUNG Electronics is not responsible for any damages to the product or harm to

customers when the installation is done by the customer.

• This product is for installing on cement walls. The product may not stay in place when

installed on plaster or wood.

Components

Only use the components and accessories shipped with the product.

Wall Bracket(1) Hinge(Left 1, Right1)Plastic

Hanger (4)

Screw (A)(11)

Screw (B)(4)

Anchor (11)

Wall Bracket Assembly

Note

There are two hinges(left and right). Use the correct one.

1. Insert and tighten the Captive Screw in the direction of the arrow.

When done, mount the wall bracket on the wall.

Introduction

A - Captive Screw

B - Wall Bracket

C - Hinge (Left)

D - Hinge (Right)

2. Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct.

If the length is too short or long, loosen all or some of the 4screws on the wall bracket to adjust the length.

A - Length between the two locking holes

3. Check the installation diagram and mark the drill points on the wall. Use the 5.0 mm bit to drill holes deeper than 35 mm. Fix each anchor in the corresponding hole. Match each

Introduction

of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A.

To mount the product on the wall bracket

The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same)

1. Remove the 4 screws on the back of the product.

2. Insert the screw B into the plastic hanger.

Notice

• Mount the product on the wall bracket and make sure it is properly fixed to the left

and right plastic hangers.

• Be careful when installing the product on the bracket as fingers can be caught in the

holes.

• Make sure the wall bracket is securely fixed to the wall, or the product may not stay

in place after installation.

3. Tighten the 4 screws in step 2 (plastic hanger + screw B)to the rear holes of the product.

Introduction

A - PDP Display

B - Wall Bracket

C - Wall

Wall Bracket Angle Adjustment

Adjust the bracket angle to -2° before installing it on the wall.

1. Fix the product to the wall bracket.

2. Hold the product at the top in the center and pull it forward (direction of the arrow) to adjust the angle.

Note

You can adjust the bracket angle between -2° and 15°.

Introduction

Make sure to use the top center, and not the left or the right side of the product to adjust the angle.

Connections

Connecting a Computer

There are several ways to connect the computer to the monitor. Choose one from the following options.

Using the D-sub (Analog) connector on the video card.

• Connect the D-sub to the 15-pin, [RGB IN] port on the back of your PDP Display and the 15 pin D-sub Port on the computer.

Using the DVI (Digital) connector on the video card.

• Connect the DVI Cable to the [DVI IN] port on the back of your PDP Display and the DVI port on the computer.

Connections

Using the HDMI (digital) output on the graphics card.

• Connect the [HDMI IN] port on the PDP Display to the HDMI port on the PC using the HDMI cable.

Note

When the HDMI cable to the PC, ensure that you select HDMI from both the Source List and Edit Name before selecting PC or DVI device so that normal PC screen and sound can be outputted. Note that sound is only

available when connected according to the option

Using the BNC (Analog) connector on the video card.

• Connect the [BNC/COMPONENT IN] port on the monitor to the BNC port on the PC using the BNC to BNC cable.

that follows.

Connections

Connect the audio cable for your PDP Display to the audio port on the back of the PDP Display.

Connect the power cord for your PDP Display to the power port on the back of the PDP Display. .

Note

• Turn on both your computer and the PDP Display.

• Contact a local SAMSUNG Electronics Service Center to buy optional items.

Connecting to Other devices

• AV input devices such as DVD players, VCRs or camcorders as well as your computer can be connected to the PDP Display. For detailed information on connecting AV input devices, refer to the contents under Adjusting Your PDP Display.

• The PDP Display's configuration at the back may vary slightly depending on the PDP Display model.

Connecting AV Devices

1. Connect an audio cable to the audio output port on the external device and [AV/COM-

PONENT AUDIO IN[R-AUDIO-L]] port on the monitor, and connect the video output port on the external device to the [AV IN [VIDEO]] port on the monitor.

2. Play the DVD, VCR or Camcorder with a DVD disc or tape inserted.

3. Select AV using the SOURCE button on the front of the PDP display or on the remote.

Connecting to a Camcorder

Connections

1. Locate the AV output jacks on the camcorder. They are usually found on the side or back

of the camcorder. Connect a set of audio cables between the AUDIO OUTPUT jacks on the camcorder and the [AV/COMPONENT AUDIO IN [R-AUDIO-L]] on the PDP Display .

2. Connect a video cable between the VIDEO OUTPUT jack on the camcorder and the [AV

IN [VIDEO]] on the PDP Display .

3. Select AV for the Camcorder connection using the SOURCE button on the front of the

PDP Display or on the remote control.

4. Then, start the Camcorder with a tape inserted.

Note

The audio-video cables shown here are usually included with a Camcorder. (If not, check your local electronics store.) If your camcorder is stereo, you need to connect a set of two cables.

Connecting the BNC to BNC cable

Connections

1. Connect the [BNC/COMPONENT IN [R/PR, G/Y, B/PB]] ports on the monitor to the BNC

port on the external device using the BNC to BNC cable.

2. Select BNC using the SOURCE button on the front of the PDP Display or on the remote

control.

Connecting Using a DVI Cable

1. Connect between the [DVI OUT] port on the PDP Display and the input port on another

monitor using a DVI cable.

2. Connect between the [AUDIO OUT] port on the PDP Display and the audio input port on

another monitor using a stereo cable.

3. Select DVI using the SOURCE button on the front of the PDP Display or on the remote

control.

Note

DVI OUT does not support HDCP.

Connecting Using a HDMI Cable

Connections

1. Connect input devices such as a Blu-Ray/DVD player to the [HDMI IN] terminal of the

PDP Display using an HDMI cable.

2. Select HDMI using the SOURCE button on the front of the PDP Display or on the remote

control.

Note

In HDMI mode, only PCM format audio is supported.

Connecting Using a DVI to HDMI Cable

1. Connect the DVI output terminal of a digital output device to the [HDMI IN] terminal of

the PDP Display using a DVI to HDMI cable.

2. Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored

audio output terminals of the digital output device, and connect the opposite jack to the [DVI / RGB AUDIO IN] terminal of the PDP Display.

3. Select HDMI using the SOURCE button on the front of the PDP Display or on the remote

control.

Connecting a DVD Player

Connections

1. Connect a set of audio cables between the [AV/COMPONENT AUDIO IN [R-AUDIO-L]]

on the PDP Display and the AUDIO OUT jacks on the DVD player.

2. Connect a Component cable between the [BNC/COMPONENT IN [R/PR, G/Y, B/PB]]

port on the PDP Display and the PR, Y, PB jacks on the DVD player.

Note

• Select Component for the connection to a DVD player using the SOURCE button on the front of the PDP Display or on the remote control.

• Then, start the DVD Player with a DVD disc inserted.

• A component cable is optional.

• For an explanation of Component video, consult your DVD manual.

Connections

Connecting a DTV Set Top (Cable/Satellite) Box

1. Connect a Component cable between the [BNC/COMPONENT IN [R/PR, G/Y, B/PB]]

port on the PDP Display and the PR, Y, PB jacks on the Set Top Box.

2. Connect a set of audio cables between the [AV COMPONENT AUDIO IN [R-AUDIO-L]]

on the PDP Display and the AUDIO OUT jacks on the Set Top Box.

Note

• Select Component for the connection to a DTV Set Top Box using the SOURCE button on the front of the PDP Display or on the remote control.

• For an explanation of Component video, see your Set Top Box owner's manual.

Connecting to an Audio System

1. Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and

[AUDIO OUT] on PDP Display.

Using the Software

MDC

Installation

1. Insert the installation CD into the CD-ROM drive.

2. Click the Serial MDC installation program.

Note

If the screen for installing the software does not appear, install it using the Serial MDC execution file in the MDC folder of the CD-ROM.

3. If the installation wizard screen does appear, click "Next."

4. The "License Agreement" screen will appear. Click "Yes."

5. The "Customer Information" window will appear. Register the user information and click

"Yes."

6. The "Choose Destination Location" window will appear. Specify the file location to install

to and click "Next."

Note

If the file location is not specified, the program will be installed in the default file location.

7. The "Start Copying Files" window will appear. Confirm the file location and click "Next."

8. The installation progress screen will appear.

9. The "InstallShield Wizard Complete" screen will appear. Click "Finish."

Note

Select " Launch Serial MDC" and click "Finish." The MDC program will immediately be run.

10. If the installation is successfully completed, the quick Serial MDC execution icon will

appear on the desktop.

MDC execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key.

Installation Problems

The installation of MDC can be affected by such factors as the video card, motherboard and the network environment.

Uninstall

The MDC program can be removed only by using the "Add or Remove Programs" option of the Windows® Control Panel.

Perform the following steps remove MDC.

Select "Setting/Control Panel" on the "Start" menu and then double-click "Add/Delete a program".

Select Serial MDC from the list and then click the "Add/Delete" button.

Using Serial MDC

Using the Software

Introduction

A Multiple Display Control (MDC) is an application allowing various displays to be easily and simultaneously operated on a PC. RS-232C, a standard of serial communication, is used for the communication between a PC and a display. Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display.

Main Screen

Click Start > Program > Samsung > MDC System to start the program.

Select a set to see the volume of the selected set within the slider.

Main Icons All Remote control Selection Buttons Safety Lock Refresh Port Selection Display Selection Lamp Control Info Grid Option... Control Tools Dropdown Selectors OSD Display

1. Use the main icons to switch into each screen.

2. Allows you to enable or disable the remote control signal receiving function of the display unit.

3. Set the Safety Lock function. When setting the Lock function, you can only operate power and lock buttons on the remote control and set.

4. The setting for the PC Serial Port can change. The original value is COM1.

5. Selects a Lamp adjustment mode.

6. Adjusts the number of LFD IDs and the frequency of search repeats.

7. Defines the range of LFD IDs to display. You can select or deselect the displayed IDs using the Select or Clear button.

8. All of the monitors can be selected or deselected.

9. Selects (Select) or deselects (Clear) LFD IDs displayed by configuring 7 and 8.

10. This searches for monitors. The maximum number is indicated in the Max LFD Id field.

11. Select a display from Display Selection.

12. Use Grid to view brief information on selected display.

13. Use Control Tools to control displays.

14. Switches the OSD function On/Off.

- May not be supported depending on the product.

<Note> The remote control Enable/Disable function operates whether or not the power is On/Off, and this

applies to all displays connected to the MDC. However, regardless of the status at the time the MDC is shut down, the remote control signal receiving function of all displays is initialized to Enable when the MDC is closed.

Port Selection

1. The Multiple Display Control is originally set to COM1.

2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu.

3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.

4. The select ed p ort is stor ed in th e pr ogra m and used for the next program as well.

Power Control

1. Click Power Control of the main icons and the Power Control screen appears.

Info Grid shows some basic information necessary to Power Control.

1) (Power Status)

2) Input

3) Image Size

4) On Timer

5) Off Timer

2. Selects displays you want to adjust using the Select button or checkboxes.

Power Control allows controlling some of the functions of the selected display.

1) Power On/Off

urns the power of the selected display On/Off.

2) Volume

- Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider.

(If you deselect a single display or all displays, the default value 10 will be restored.)

(Mute On/Off)

- Turns on/off the Mute function of the selected display. When selecting one set at a time, turn on the Mute function for the selected set. The Mute function is disabled automatically when you adjust the volume level. (The values return to the default settin

s when you undo the selections or choose "Select All".)

The Power Control feature is available for all displays. The Volume Control and Mute features are available only for the displays whose power status is ON.

3. Selects whether to display the menu screen using the OSD Display menu.

1) Source OSD

- Sets whether the Source OSD will be displayed to indicate when the Source is changed.

2) Not Optimum Mode OSD

- Sets whether the Optimum Mode OSD will be displayed to indicate if the current mode is not supported.

3) No Signal OSD

- Sets whether the No Signal OSD will be displayed to indicate when there is no signal.

4) MDC OSD

- Sets whether the MDC OSD will be displayed to indicate when the settings are changed using the MDC.

Input Source

1. Click Input Source of the main icons and the Input Source control screen appears. Selects displays you want to adjust using the Select button or checkboxes.

• TV Mode

• PC Mode

Info Grid shows some basic information necessary to Input Source Control.

- Changes the Input Source of the selected display to PC.

2) BNC

- Changes the Input Source of the selected display to BNC.

3) DVI

- Changes the Input Source of the se le c t ed d is p lay to DVI.

4) TV

-Chan

5) DTV

-Chan

6) AV

-Chan

7) S-Video

- Changes the Input Source of the selected display to S-Video.

8) Component

-Chan

9) MagicInfo

10) HDMI1/HDMI2

-Chan

11) DP

- Switches the input source for the selected Display to DP.

12) Channel

- Channel arrow appears when the Input Source is TV.

HDMI2 may not be supported depending on the product. DP may not be supported depending on the product. TV Source can be selected only in products with TV and controlling channels is allowed only when

Input Source is TV. The Input Source Control feature is available only for the displays whose power status is ON.

es the Input Source of the selected display to TV.

es the Input Source of the selected display to DTV.

es the Input Source of the selected display to AV.

es the Input Source of the selected display to Component.

he Input source of MagicInfo works only on MagicInfo model.

es the Input Source of the selected display to HDMI.

Image Size

PC, BNC, DVI, DP

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

( Power Status)

- Shows the power status of the current display.

2) Image Size

- Shows the current Image Size of the display in use.

3) Input

- Info Grid displays only the displays whose Input Source is PC, BNC, DVI and DP.

4) PC Source

- Click Image Size in the main menu to display the PC, BNC, DVI and DP tabs.

- The Image Size Control button controls Image Size available for PC, BNC, DVI and DP.

5) Video Source

- Using the Image Size adjustment button, you can adjust the Image Size to a value available in the PC, BNC, DVI and DP.

DP may not be supported depending on the product. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Image Size Control is available only for the displays for which power status is ON.

Image Size

TV, AV, S-Video, Component, DVI(HDCP), HDMI1, HDMI2, DTV.

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

1) To adjust Image Size in TV, AV, S-Video, Component, HDMI1, HDMI2 or DTV mode, click the Video Source tab. Select the display you want to adjust by using the Select button or by checking the checkbox.

2) Info Grid displays only the display having TV, AV, S-Video, Component, HDMI1, HDMI2 or DTV as input source.

3) Switch Image Size of the selected display randomly.

4) The screen modes can only be adjusted when a TV (PAL only) is connected and the Image Size item is set to Auto Wide.

HDMI2 may not be supported depending on the product. Custom may not be supported depending on the product. Auto Wide, Zoom1 and Zoom2 are not available for selection when the input signal type for Component

and DVI (HDCP) is 720p or 1080i. (The Auto Wide mode is available only for TV, AV, and S-Video.)

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. The Image Size Control feature is available only for the displays whose power status is ON.

Time

1. Click Time of the main icons and the Time Control screen appears.

Info Grid shows some basic information necessary to Time Control.

1) Set clock

- Set the current time for the selected display (PC Time).

- To change the current time, first change the PC Time.

2) Timer

- Sets up Timer1, Timer2, Timer3 and Holiday Management.

3) Shows whether Timer is activated.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Time Control is available only for the displays for which the power status is ON.

Time

Setting up Timer and Holiday Management

1. 1. Setting up Timer1, Timer2 and Timer3

1) On Time

- Sets the time in hours, in minutes and as AM/PM for turning the selected monitor on.

2) Off Time

- Sets the time in hours, in minutes and as AM/PM for turning the selected monitor off.

3) Volume

- Selects the volume when the selected monitor is turned on.

4) Source

- Selects the external input source that will be displayed when the selected monitor is turned on.

5) Holiday

- Applies the Holiday Management function to the Timer.

6) Repeat

- Available selections include Once, EveryDay, Mon~Fri, Mon~Sat, Sat~Sun, and Manual.

z Once : The Timer goes off only once. z EveryDay : EveryDay: The Timer repeats daily. z Mon~Fri : The Timer repeats from Monday through Friday. z Mon~Sat : The Timer repeats from Monday through Saturday. z Sat~Sun : Sat~Sun: The Timer goes off on Saturday and Sunday. z Manual : Select a day of the week you want the Timer to go off.

2. Setting Holiday Management The Holiday Management function specifies the dates in which the monitor will not be turned on or off by the Timer.

1) Specifies the date.

2) Delete All

- Deletes all of the holidays.

3) Add

- Adds the specified date.

- Deletes the schedule in the selected line.

The Holiday Management function can be turned on or off in the Timer setup menu. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Time Control is available only for the displays for which the power status is ON. Only enabled for a TV when Source is set to TV in On Time mode. Only enabled for a model with MagicInfo installed when Source is set to MagicInfo in On Time mode.

PIP

PIP Size

1. Click PIP of the main icons and the PIP control screen appears. Selects displays you want to adjust using the Select button or checkboxes.

Info Grid shows some basic information necessary to PIP Size Control.

1) PIP Size

- Shows the current PIP Size of the display in use.

2) OFF

- Turns off the PIP of the selected display.

3) Large

- Turns on the PIP of the selected display and changes the size to Large.

4) Small

- Turns on the PIP of the selected display and changes the size to Small.

5) Double 1

- Turns on the PIP of the selected display and changes the size to Double 1.

6) Double 2

- Turns on the PIP of the selected display and changes the size to Double 2.

7) Double 3 (Picture By Picture)

- Turns on the PBP of the selected display and changes the size to Double 3.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. PIP Size can be controlled with turning on the LCD Display power.

PIP

PIP Source

1. Click PIP of the main icons and the PIP control screen appears.

Info Grid shows some basic information necessary to PIP Source Control.

1) PIP Source

- PIP Source can be controlled with turning on the LCD Display power.

2) PC

- Changes the source of the PIP of the selected display to PC.

3) BNC

- Changes the source of the PIP of the selected display to BNC.

4) DVI

- Changes the source of the PIP of the selected display to DVI.

5) TV

- Changes the source of the PIP of the selected display to TV.

6) DTV

- Changes the source of the PIP of the selected display to DTV.

7) AV

- Changes the source of the PIP of the selected display to AV.

8) S-Video

- Changes the source of the PIP of the selected display to S-Video.

9) Component

- Changes the source of the PIP of the selected display to Component.

10) HDMI1/HDMI2

- Changes the source of the PIP of the selected display to HDMI.

11) DP

- Switches the PIP Source of the selected Display to DP.

HDMI2 may not be supported depending on the product. DP may not be supported depending on the product. Some of the PIP Sources may not be available for selection, depending on the input source type of the

Main Screen. The Input source of MagicInfo works only on MagicInfo model. The PIP Control feature is available only for the displays whose power status is ON and the PIP

function is set to ON.

Settings


1. Click Settings of the main icons and the Settings Control screen appears.

Basic information required to adjust the Picture is displayed in the main menu. Settings for the selected monitor will be displayed if one of the connected monitors is selected, and the default settings will be displayed if all monitors are selected by clicking All and Select. If a value is changed in this screen, the current mode will automatically switch to custom mode.

1) Picture

- Available only for TV, AV, S-Video, Component, HDMI1, HDMI2, DTV.

2) Contrast usts Contrast of the selected display.

-Ad

3) Brightness

- Adjusts Brightness of the selected display.

4) Sharpness usts Sharpness of the selected display.

-Ad

5) Color usts Color of the selected display.

-Ad

6) Tint

- Adjusts Tint of the selected display.

- Available only for NT.

7) Color Tone

-Ad

usts the Color Tone for the selected display.

Color Temp

usts the Color Temp for the selected display.

-Ad

9) Brightness Sensor usts the Brightness Sensor for the selected display.

-Ad

10) Dynamic Contrast usts the Dynamic Contrast for the selected display.

-Ad

HDMI2 may not be supported depending on the product. Brightness Sensor may not be supported depending on the product. The Input source of MagicInfo works only on MagicInfo model. Color Temp is only enabled if the Color Tone is set to Off. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Picture PC

1. Click Settings of the main icons and the Settings Control screen appears.

Basic information required to adjust settings is displayed. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select. If a value is changed in this screen, the current mode will automatically switch to custom mode.

1) Picture PC

- Available only for PC, BNC, DVI and DP.

2) Contrast usts Contrast of the selected display.

-Ad

3) Brightness

usts Brightness for the selected display.

-Ad

4) Red usts red Color of the selected display.

-Ad

- Available only for NT.

5) Green

-Ad

usts green Color of the selected display.

- Available only for NT.

6) Blue

-Ad

usts blue Color of the selected display.

- Available only for NT.

7) Color Tone

-Ad

usts the Color Tone for the selected display.

8) Color Temp usts the Color Temp for the selected display.

-Ad

9) Brightness Sensor usts the Brightness Sensor for the selected display.

-Ad

10) Dynamic Contrast usts the Dynamic Contrast for the selected display.

-Ad

DP may not be supported depending on the product. Brightness Sensor may not be supported depending on the product. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Color Temp is only enabled if the Color Tone is set to Off. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Audio

1. Click Settings of the main icons and the Settings Control screen appears.

Basic information required to adjust Audio is displayed in the display window. Settings for the corresponding SET will

be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select. If a value is changed in this screen, the current mode will automatically switch to custom mode.

1) Audio

- Controls audio settings for all input sources.

2) Bass

usts Bass of the selected display.

-Ad

3) Treble

usts Treble of the selected display.

-Ad

4) Balance

usts Balance of the selected display.

-Ad

5) SRS TS XT

- SRS TS XT Sound ON/OFF of the selected display.

6) Sound Select

- Select either Main or Sub when PIP is On.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Image Lock

1. Click Settings of the main icons and the Settings Control screen appears.

Info Grid shows some basic information necessary to Settings Control.

1) Image Lock

- Available only for PC, BNC.

2) Coarse

- Adjusts Coarse of the selected display.

3) Fine

- Adjusts Fine of the selected display.

4) Position

- Adjusts Position of the selected display.

5) Auto Adjustment

- Self-Adjust to the incoming PC signal.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Settings Control is available only for the displays for which the power status is ON.

Maintenance

Lamp Control

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

An "Info Grid" showing several basic data items appears.

1) Maintenance

- Allows the Maintenance Control function for all input sources.

2) Lamp Control

- Automatically adjusts the backlight of the selected display at a specified time. he Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control.

- Allows you to adjust the backlight of the selected display regardless of the time. he Auto Lamp Control automatically turns off if you adjust using the Manual Lamp Control.

3) Ambient Light

- Detects the ambient light intensity at the designated monitor and automatically adjusts the picture brightness.

- You can specify a Reference value and designate a monitor that will automatically determine Lamp Value (the light

intensity from the lamp), based on the ambient light intensity.

Ambient Light is only supported for models that have a brightness sensor and is only enabled when Ambient Brightness Mode is selected in the Lamp Control menu.

Auto Lamp Control and Manual Lamp Control are only enabled when User Control Mode is selected in the Lamp Control menu.

The Maintenance Control feature is available only for the displays whose power status is ON. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model.

Maintenance

Scroll

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

1) Scroll

- This function is used to remove the afterimages that occur when a still screen is displayed on the selected

display for a long time.

2) Pixel Shift

- This allows the screen to be moved finely at the specified time interval.

3) Safety Screen

- The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the

monitor for a long time. The Interval item is used to set the repetition cycle in hour units and the Time item is used to set the time when the Safety Screen function must be performed. The Type item can be set to Scroll, Pixel, Bar, Eraser, All White, or Pattern.

4) Safety Screen2

- This function is used to prevent afterimages from occurring. There are five (5) types that you can select and

control with this function.

For the Scroll type, the Time item can be set to 1, 2, 3, 4 or 5. For the Bar and Eraser types, it can be set to 10, 20, 30, 40 or 50. For the All White and Pattern type, it can be set to 1, 5, 10, 20 or 30.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. The Maintenance Control feature is available only for the displays whose power status is ON.

Maintenance

Video Wall

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

1) Video Wall

- A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole

picture or so that the same picture is repeated on each screen.

2) Video Wall Control

- Video Wall properties can be configured.

1) On / Off

urns on/off the Video Wall function of the selected display.

2) Format he format can be selected to see a divided screen.

z Full

z Natural

3) Video Wall (Screen divider)

- The screen can be divided into. You can select a number of screens with a different layout when dividing.

z Select a mode from Screen divider. z Select a display from Display Selection. z The place will be set up by pressing a number in the selected mode. z The maximum number of monitors that can be arranged: Horizontal X Vertical = 100 z Up to 15 monitors can be arranged in a row. The maximum value for Horizontal is 6 if Vertical is set to 15 while

the maximum value for Vertical is 6 if Horizontal is set to 15.

4) Viewing Screen Splits

- You can view and change the layout of screens using the Screen Divider settings.

The range of the Screen Divider setting may differ depending on the model. You may not operate this function in MagicInfo.

The Input source of TV works only on TV model. The Maintenance Control function is available only for the displays where the power status is ON.

Troubleshooting

1. The display you wish to control does not appear on the Power Control Info Grid

- Check the connection of RS232C. (Check if it is properly connected to the Com1 port)

- Check the displays to see if any of the other displays connected have the same ID. If more than one displays have the same ID, those displays are not properly detected by the program due to data conflict.

- For monitors that support a Set ID between 0 to 99, you have to set the Set ID to a value between 0 and 99.

Note : Check if the Set ID of the monitor is a value between 0 and 99 (set the value using the Display menu).

2. The display you wish to control does not appear on the other Control Info Grids

- Check to see if the display power is ON. (You can check this in Power Control Info Grid)

- Check if you can change the input source of the display.

3. The dialogue box appears repeatedly.

- Check to see if the display you wish to control is selected.

4. Both On Timer and Off Timer have been set but different time is showing.

- Apply current time to synchronize the display clocks.

5. The remote may not function properly when you turn off the remote Function, disconnect the RS-232C cable, or exit the program in an Irregular manner. Rerun the program and turn the remote function again to Restore normal functions.

<Note> This program may malfunction due to problems in communication circuits or interference from electronic

appliances nearby.

Settings Value Display In Multiple Display Mode

When there are more than one displays connected, the settings values are displayed as follows.

1. No selection: Displays the Factory Default Value.

2. Selected one display: Fetches and displays the settings value for the selected display.

3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of ID 1, fetches and displays the value of ID3.

4. If all sets are selected at the same time by clicking All and Select, the default value will be restored.

Adjusting the PDP Display

Input

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

Component

Note

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

Source List

MENU → ENTER → → ENTER → → , → ENTER

Use to select PC, DVI or other external input sources connected to the PDP Display. Use to select the screen of your choice.

1. PC

2. DVI

3. AV

4. HDMI

5. MagicInfo

6. Component

7. BNC

• The direct button on the remote control is the 'SOURCE' button.

Edit Name

MENU → ENTER → → → ENTER → → , → ENTER

Note

Adjusting the PDP Display

Name the input device connected to the input jacks to make your input source selection easier.

VCR / DVD / Cable STB / HD STB / Satellite STB / AV Receiver / DVD Receiver / Game / Camcorder / DVD Combo / DHR / PC

Note

• When connecting a PC to the HDMI or DVI terminal, set Edit Name to PC.

• In other cases, set Edit Name to AV.

• However, since 640x480, 720P (1280x720), and 1080p (1920x1080) are common signals for AV and PC, make sure to set the Edit Name in accordance with the input signal.

• The Picture menu changes depending on the input signal and Edit Name.

Picture [PC / DVI / BNC / MagicInfo Mode]

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

MagicBright

MENU → → ENTER → → ENTER → → , → ENTER

Component

Note

Adjusting the PDP Display

MagicBright is a new feature providing the optimum viewing environment depending on the contents of the image you are watching. Currently four different modes are available: Entertain, Internet, Text and Custom. Each mode has its own pre-configured brightness value. You can easily select one of the four settings by simply pressing the MagicBright control button.

1. Entertain

High brightness

For watching motion pictures such as a DVD or VCR.

2. Internet

Custom

Medium brightness

For working with a mixture of images such as texts and graphics.

3. Text

Normal brightness

For documentations or works involving heavy text.

4. Custom

Although the values are carefully chosen by our engineers, the pre-configured values may not be comfortable to your eyes depending on your taste.

If this is the case, adjust the brightness and contrast by using the OSD menu.

By using the on-screen menus, the contrast and brightness can be changed to your personal preference.

MENU →

Note

→ ENTER → → → ENTER →

Contrast

By adjusting the picture using the Custom function, MagicBright will change to Custom mode.

MENU → → ENTER → → → ENTER → → ENTER→ → , → ENTER

Adjusts the Contrast.

Brightness

MENU → → ENTER → → → ENTER → → → ENTER→

Adjusts the Brightness.

Sharpness

Adjusting the PDP Display

→ , → ENTER

MENU →

Adjusts the Sharpness.

Color Tone

MENU → → ENTER → → → →ENTER → → , → ENTER

The color tones can be changed.

1. Off

→ ENTER → → → ENTER → → → → ENTER →

→ , → ENTER

2. Cool

3. Normal

4. Warm

5. Custom

Note

If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp function is disabled.

If you set the Color Tone to Off, the Color Control function is disabled

Color Control

Adjusts individual Red, Green, Blue color balance.

MENU → → ENTER → → → → → ENTER →

Red

Green

Blue

Adjusting the PDP Display

Note

If you adjust the picture by using the Color Control function, Color Tone will turn to the Custom mode.

MENU → → ENTER → → → → → ENTER → → ENTER →

MENU → → ENTER → → → → → ENTER → → → ENTER→ → , → ENTER

→ , → ENTER

MENU → → ENTER → → → → → ENTER → → → → ENTER → → , → ENTER

Color Temp.

MENU → → ENTER → → → → → ENTER → → , → ENTER

Color Temp. is a measure of the 'warmth' of the image colors.

This function is only enabled if the Color Tone is set to Off.

Image Lock

Image Lock is used to fine-tune and get the best image by removing noise that creates unstable images with jitters and shakiness. If satisfactory results are not obtained using the Fine adjustment, use the Coarse adjustment and then use Fine again.

Note

Coarse

Available in PC mode only

MENU → → ENTER → → → → → → ENTER →

MENU → → → , → ENTER

→ ENTER → → → → → → ENTER → → ENTER

Fine

H-Position

Adjusting the PDP Display

Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control menu.

MENU → → ENTER → → → → → → ENTER → → → ENTER → → , → ENTER

Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed).

MENU → → ENTER → → , → ENTER

Adjusts the screen location horizontally.

V-Position

MENU → → ENTER → → → → → → ENTER → → → → → ENTER → → , → ENTER

Adjusts the screen location vertically.

Auto Adjustment

MENU → → ENTER → → → → → → → ENTER →

→ ENTER → → → → → → ENTER → → →

The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution in the control panel, the auto function is performed.

Note

Available in PC mode only

Signal Balance

This is used to make up for the weak RGB signal transmitted by a long signal cable.

MENU → → ENTER → → → → → → → → ENTER →

Signal Balance

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER → → , → ENTER

Selects either On or Off with the signal Balance.

Signal Control

MENU → → ENTER → → → → → → → → ENTER →

1. R-Gain

Adjusting the PDP Display

→ → ENTER →

MENU →

ENTER

2. G-Gain

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER

3. B-Gain

MENU → → ENTER → → → → → → → → ENTER →

, → ENTER

→ ENTER → → → → → → → → ENTER →

→ → ENTER → → ENTER → → , →

→ → ENTER → → → ENTER → → ,

→ → ENTER → → → → ENTER → →

4. R-Offset

MENU →

5. G-Offset

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER → → → → → → → → ENTER →

→ → ENTER → → → → → ENTER →

→ , → ENTER

→ → ENTER → → → → → → ENTER →

→ , → ENTER

Size

Adjusting the PDP Display

6. B-Offset

MENU → → ENTER → → → → → → → → ENTER →

→ → ENTER → → → → → → → ENTER

→

MENU → → ENTER → → → → → → → → → ENTER → → ,

→ ENTER

→ , → ENTER

The Size can be switched.

1. 16:9

2. 4:3

Picture [ AV / HDMI / Component Mode]

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

Component

Note

• MagicInfo can only be enabled when a network box is connected.

Mode

• The HDMI port and network box cannot be connected at the same time.

MENU → → ENTER → → ENTER → → , → ENTER

Adjusting the PDP Display

The PDP Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and "Custom") that are preset at the factory.

Dynamic, Standard, Movie, or Custom can be activated.

1. Dynamic

2. Standard

3. Movie

4. Custom

Custom

By using the on-screen menus, the contrast and brightness can be changed to your personal preference.

MENU → → ENTER → → → ENTER →

Contrast

MENU → → ENTER → → → ENTER → → ENTER→ → , → ENTER

Adjusts the Contrast.

Brightness

MENU → → ENTER → → → ENTER → → → ENTER→

→ , → ENTER

Adjusts the Brightness.

Sharpness

MENU →

Adjusts the picture Sharpness.

→ ENTER → → → ENTER → → → → ENTER→

→ , → ENTER

Color

Tint

Adjusting the PDP Display

MENU → → ENTER → → → ENTER → → → → → ENTER → → , → ENTER

Adjusts the picture Color.

MENU → → → , → ENTER

Adds a natural tone to the display.

Color Tone

MENU → → ENTER → → → → ENTER → → , → ENTER

The color tones can be changed. The individual Color components are also user adjustable.

1. Off

→ ENTER → → → ENTER → → → → → → ENTER

2. Cool2

3. Cool1

4. Normal

5. Warm1

6. Warm2

Note

If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp function is disabled.

Color Temp.

MENU → → ENTER → → → → → ENTER → → , → ENTER

Color temp. is a measure of the 'warmth' of the image colors.

Size

Adjusting the PDP Display

Note

This function is only enabled if the Color Tone is set to Off.

MENU → → ENTER → → → → → → ENTER → → , → ENTER

The Size can be switched.

1. 16:9 - Sets the picture to 16:9 wide mode.

2. Zoom 1 - Magnifies the size of the picture on the screen.

3. Zoom 2 - Magnifies the size of the picture more than “Zoom 1”.

4. 4:3 - Sets the picture to 4:3 normal mode.

5. Just Scan - Displays the input scenes as they are without any cutoff when HDMI / Com-

ponent 720p, 1080i, 1080p signals are input.

Note

Certain external devices may feed the display an out of spec signal that may cause cutoff even when using the Just Scan feature.

ZOOM1, ZOOM2 will be unavailabel in HDMI / Component mode.

Note

The Position and Reset functions are available when Zoom1 or Zoom2 is run.

Digital NR (Digital Noise Reduction)

MENU → → ENTER → → → → → → → ENTER → → ,

→ ENTER

Turns the Digital Noise Reduction feature Off/On. The Digital Noise Reduction feature allows you to enjoy clearer and crisper images.

Deactivated in HDMI / AV with a resolution of 1080p.

1. Off

2. On

Digital NR function is not available for all resolutions.

Film Mode

MENU → → ENTER → → → → → → → → ENTER → → , → ENTER

Adjusting the PDP Display

Note

Sound

The Film Mode feature offers you a theater-quality viewing experience.

Film Mode is supported in AV, Component (480i / 1080i) and HDMI (480i / 1080i).

(In HDMI mode, this function can be available when the input signal is interlaced scan; it cannot be available with progressive scan signal.)

1. Off

2. On

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

Component

Mode

Note

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

MENU → → → ENTER → → ENTER → → , → ENTER

Adjusting the PDP Display

The PDP Display has a built-in high fidelity stereo amplifier.

1. Standard

Selects Standard for the standard factory settings.

2. Music

Selects Music when watching music videos or concerts.

3. Movie

Custom

Bass

Selects Movie when viewing movies.

4. Speech

Selects Speech when watching a show that is mostly dialogue (i.e., news).

5. Custom

Selects Custom if you want to adjust the settings according to your personal preferences.

The sound settings can be adjusted to suit your personal preferences.

MENU → → → ENTER → → → ENTER →

Note

• You can hear the sound even when sound value is set to 0.

• If you adjust sound using Custom function, Mode will turn to Custom mode.

MENU →

→ ENTER

→ → ENTER → → → ENTER → →ENTER→ → ,

Treble

Emphasizes low frequency audio.

MENU → → , → ENTER

→ → ENTER → → → ENTER → → →ENTER→

Emphasizes high frequency audio.

Balance

MENU → → → ENTER → → → ENTER → → → →ENTER→

Allows you to Adjusts the sound balance between the left and right speakers.

Auto Volume

MENU → → → ENTER → → → → ENTER → → , → ENTER

Adjusting the PDP Display

→ , → ENTER

Reduces the difference in volume control between broadcasters.

1. Off

2. On

SRS TS XT

MENU → → → ENTER → → → → → ENTER → → , → ENTER

SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers. It is fully compatible with all multichannel formats.

1. Off

Setup

2. On

Available Modes

•

PC / DVI / BNC

•

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

Language

MENU → → → → ENTER → → ENTER → → , → ENTER

Adjusting the PDP Display

HDMI

MagicInfo

Component

Note

Time

Clock Set

You can choose one of 13 languages.

Note

The language chosen affects only the language of the OSD. It has no effect on any software running on the computer.

You can set the time.

MENU → → → → ENTER → → → ENTER →

MENU →

→ → → ENTER → → → ENTER → → ENTER→

→ , → , → ENTER

Current Time Setting.

Sleep Timer

MENU → → → → ENTER → → → ENTER → → → ENTER→

Turns the PDP Display off automatically at certain times.

1. Off

2. 30

3. 60

Adjusting the PDP Display

→ , → ENTER

4. 90

5. 120

6. 150

7. 180

Timer1 / Timer2 / Timer3

MENU → → → → ENTER → → → ENTER → → → → → →

→ ENTER→ [Timer1 / Timer2 / Timer3]

→ , / , → ENTER

You can set the PDP display to automatically turn on or off at a specified time.

Note

• Only enabled when the clock is set using the Clock Set menu.

• The Manual option allows you to select a day of the week.

Holiday Management

MENU → → → → ENTER → → → ENTER → → → → ENTER→ [Holiday Management]

• Add

Adjusting the PDP Display

MENU → → → → ENTER → → → ENTER → → → → → →

→ ENTER → [Holiday Management]→ ENTER → [Add]

→ , / , → ENTER

You can register holidays.

• Delete Selected

MENU → → → → ENTER → → → ENTER → → → → → →

→ ENTER → [Holiday Management]→ , → ENTER → → , → ENTER → [Delete

Selected]

→ , → ENTER

You can delete selected holidays.

Note

• Only enabled when registered holidays are selected.

• More than one holiday can be selected and deleted.

• Delete All

MENU → → → → ENTER → → → ENTER → → → → → →

→ ENTER → [Holiday Management]→ → → ENTER → [Delete All]

→ , → ENTER

You can delete all the registered holidays.

Menu Transparency

MENU → → → → ENTER → → → → ENTER → → ,

→ ENTER

Change the transparency of the background of the OSD.

1. High

2. Medium

3. Low

Adjusting the PDP Display

4. Opaque

Safety Lock

Change PIN

MENU → → → → ENTER → → → → → ENTER → → ENTER

→

→ [0∼9] → [0∼9] → [0∼9] → [0∼9]

The password can be changed.

The preset password for the PDP Display is "0000".

Note

Lock

MENU → → → → ENTER → → → → → ENTER → → → ENTER →

→ [0∼9] → [0∼9] → [0∼9] → [0∼9]

This is the function that locks the OSD in order to keep the current settings or to prevent others from adjusting the settings.

Energy Saving

MENU → → → → ENTER → → → → → → ENTER → → , → ENTER

This feature adjusts the power consumption of the unit in order to save energy.

1. Off

2. On

Adjusting the PDP Display

Note

If Energy Saving mode is Off, you can obtain the maximum display brightness.

HDMI Black Level

MENU → → → → ENTER → → → → → → → ENTER →

When a DVD or set-top box is connected to your TV via HDMI, it may cause a degradation in the screen quality, such as an increase in the black level, a low contrast, or discoloration, etc., depending on the external device connected. In this case, adjust the screen quality of your TV by configuring the HDMI black level.

1. Normal

→ , → ENTER

2. Low

Video Wall

A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen.

When the Video Wall is on, you can adjust the Video Wall screen setting.

MENU →

→ → → ENTER → → → → → → → → ENTER →

When Video Wall is running, the Auto Adjustment, Image Lock, and Size functions are not available. Video Wall does not operate in MagicInfo mode.

Video Wall

Adjusting the PDP Display

Note

Format

MENU →

→ , → ENTER

Turns Off/On the Video Wall function of the selected display Off/On.

1. Off

2. On

MENU →

→ → → ENTER → → → → → → → → ENTER → → ENTER →

→ → → ENTER → → → → → → → → ENTER → → → ENTER →

Horizontal

→ , → ENTER

The Format can be selected to see a divided screen.

1. Full

Provides a full screen without any margins.

2. Natural

Displays a natural image with the original aspect ratio intact.

MENU →

→ → → ENTER → → → → → → → → ENTER → → → → ENTER →

Vertical

Adjusting the PDP Display

→ , → ENTER

Sets how many parts the screen should be divided horizontally.

Five adjustment levels: 1, 2, 3, 4, and 5.

MENU → → → → ENTER → → → → → → → → ENTER →

→ → → → ENTER →

→ , → ENTER

Sets how many parts the screen should be divided vertically.

Five adjustment levels: 1, 2, 3, 4, and 5.

Screen Divider

MENU →

The screen can be divided into several images. A number of screens can be selected with a different layout when dividing.

• Select a mode in Screen Divider.

→ → → ENTER → → → → → → → → ENTER → → → → → → ENTER →

• Select a display in Display Selection.

• The selection will be set up by pressing a number in the selected mode.

Safety Screen

The Safety Screen function is used to prevent afterimages that may appear when a still picture is displayed on the screen over a long time.

• The Safety Screen function scrolls the screen for the specified period of time.

• This function is not available when the power is turned off.

Adjusting the PDP Display

Pixel Shift

MENU →

To prevent after-images on the screen you can use this function, so that every minute pixels on the PDP are moved in horizontal or vertical direction.

1. Off

2. On

→ → → ENTER → → → → → → → → → ENTER →

→ ENTER → → ENTER → → , → ENTER

Horizontal Dot

MENU → → → → ENTER → → → → → → → → → ENTER →

ENTER

Sets how many pixels the screen moves horizontally.

Five adjustment levels: 0, 1, 2, 3, and 4.

Vertical Line

MENU → → → → ENTER → → → → → → → → → ENTER →

ENTER

→ ENTER → → → ENTER → → , →

→ ENTER → → → → ENTER → → , →

Time

Adjusting the PDP Display

Sets how many pixels the screen moves vertically.

Five adjustment levels: 0, 1, 2, 3, and 4.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ ENTER → → → → → ENTER → → , →

ENTER

Timer

Set the time interval for performing the horizontal or vertical movement, respectively.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → ENTER → → , → ENTER

You can set the timer for Screen Burn Protection.

If you start the operation to erase any residual image, the operation will be performed for the set period of time and then automatically finish.

1. Off

2. On

Mode

MENU →

→ → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → → ENTER → → , → ENTER

Adjusting the PDP Display

You can change the Safety Screen Type.

1. Scroll

2. Bar

3. Eraser

4. All White

5. Pattern

Period

Time

MENU →

Use this function to set the execution period for each mode set in the timer.

MENU → → → → ENTER → → → → → → → → → ENTER →

ENTER

→ → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → → → ENTER → → , → ENTER

→ → ENTER → → → → → ENTER → → , →

Within the set period of time specify a time for execution.

• Mode-Scroll : 1~5 sec

• Mode-Bar, Eraser : 10~50 sec

Scroll

Adjusting the PDP Display

• Mode-All White, Pattern : 1, 5, 10, 20 30 min

Bar

MENU →

This function prevents after-images on the screen by moving all the pixels on the PDP according to a pattern.

Use this function when there are remaining after-images or symbols on the screen, especially when you displayed a still image on the screen for a long time.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → → ENTER → → → → → → → → → ENTER →

→ → → ENTER →

→ → → →ENTER →

Eraser

All White

This function prevents after-images on the screen by moving long black and white vertical lines.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → → → →ENTER →

This function prevents after-images on the screen by moving a rectangular pattern.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → → → → →ENTER →

Pattern

Adjusting the PDP Display

This function prevents after-images on the screen by changing the color of pixels to white.

Use this function when there are remaining after-images or symbols on the screen, especially when you displayed a still image on the screen for a long time.

MENU →

This function prevents after-images on the screen by moving a diagonal pattern stored in the panel repeatedly.

Resolution Select

MENU → → → → ENTER → → → → → → → → → →ENTER →

→ → → ENTER → → → → → → → → → ENTER →

→ → → → → → →ENTER →

→ , → ENTER

When the picture is not displayed properly on the screen when setting the graphics card resolution of the computer to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768@ 60Hz or 1366 x 768 @ 60Hz, by using this function(Resolution Select), you can have the picture displayed on the screen in the specified resolution.

Note

Available in PC or BNC mode only

1. Off

2. 1024 x 768

3. 1280 x 768

4. 1360 x 768

5. 1366 x 768

Note

Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz.

Power On Adjustment

MENU → → → → ENTER → → → → → → → → → → → ENTER → → , → ENTER

Adjusting the PDP Display

Adjusts the Power On time for the screen.

Caution: Set the Power On time to be longer to avoid overvoltage.

Side Gray

MENU → → → → ENTER → → → → → → → → → → → → ENTER → → , → ENTER

Select the brightness of the grey for the screen background.

1. Off

Reset

2. Light

3. Dark

Reverts the product settings to factory defaults. The Reset function is only available when PC / DVI is being used.

MENU → → → → ENTER → → → → → → → → → → → → → ENTER →

Image Reset

MENU → → → → ENTER → → → → → → → → → → → → → ENTER → → ENTER → → , → ENTER

Note

Available in PC mode only

The Reset function is not available when Video Wall is On.

Color Reset

MENU → → → → ENTER → → → → → → → → → → → → → ENTER → → → ENTER → → , → ENTER

Adjusting the PDP Display

OSD Rotation

MENU → → → → ENTER → → → → → → → → → → →

→ → → → ENTER →

→ , → ENTER

OSD Rotate

1. Landscape

2. Portrait

Multi Control

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

Multi Control

Assigns an individual ID to the SET.

MENU → → → → → ENTER → → ENTER → , → [0~9]

Adjusting the PDP Display

Component

Note

MagicInfo

• ID Setup

Assigns distinctive IDs to the SET.

• ID Input

Use to select the transmitter functions of the individual SET. Only a SET where the ID corresponds to the transmitter setting becomes activated.

Available Modes

•

PC / DVI / BNC

•

HDMI

•

MagicInfo

•

Component

Note

• MagicInfo can only be enabled when a network box is connected.

• The HDMI port and network box cannot be connected at the same time.

Note

• The remote control can be used to select MagicInfo. However, it is recommended to use a separate USB keyboard to utilize MagicInfo fully.

Adjusting the PDP Display

• For MagicInfo in Device mode, moving external devices while booting may cause errors. Set up external devices only if the PDP Display turns on.

• Do not unplug the LAN cable used for the network (ex: video display). Otherwise, the program (MagicInfo) may stop. If you do unplug the cable, restart the system.

• Do not unplug the LAN cable used by an USB device (ex: video display). Otherwise, the program (MagicInfo) may stop.

• To access other sources, press the SOURCE button in MagicInfo.

• The preset password for the PDP Display is "000000".

• The server program's Power-On option works only if the PDP Display's power is completely shut off.

Please make sure not to use the Power-On option when the PDP Display is in the process of shutting down since this may cause system errors on the PDP Display.

• When using MagicInfo with the MagicInfo Server Program: perform Network mode.

• When using MagicInfo with the device directly connected to PDP Display : execute Device mode.

MagicInfo

• Press ESC to directly go to the MagicInfo Window screen.

• To setup MagicInfo on a Windows screen, a keyboard and mouse are required.

• To setup MagicInfo on a Windows screen, refer to the MagicInfo Server Help.

It is highly recommended not to turn off the AC power during an operation.

• For pivoted PDP Displays, ticker transparency is not supported.

• For pivoted PDP Displays, a screen resolution of up to 720*480(SD) is supported for movies.

• For drive D:, EWF is not applied.

• To save Setup contents that have been changed when EWF is in the Enable state, you must Commit them.

• By selecting Disable, Enable or Commit, the system is restarted.

1. Select Application - step 1

Adjusting the PDP Display

You can select an Application to be executed in your computer when Windows starts.

2. Select TCP/IP - step 2

In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop to make your settings for TCP/IP. You just do that at step 2 of MagicInfo installation.

3. Select Language - step 3

Adjusting the PDP Display

When using multiple languages, you can choose and set a specific language among them.

4. Select Screen Type - step 4

You can select which rotation type will be applied to your device.

5. Setup Information

Adjusting the PDP Display

Shows the settings that have been selected by the user.

Note

If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon on the window desktop. The icon will appear.

Troubleshooting

Self-Test Feature Check

Note

Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself.

Self-Test Feature Check

1. Turn off both your computer and the PDP Display.

2. Unplug the video cable from the back of the computer.

3. Turn on the PDP Display.

The figure shown below ("Check Signal Cable") appears on a black background when the PDP Display is working normally even though no video signal is detected: While in the Self-Test mode, the LED power indicator remains green and the figure moves around on the screen.

4. Turn off your PDP Display and reconnect the video cable; then turn on both your com-

puter and the PDP Display

If your PDP Display screen remains blank after using the previous procedure, check your video controller and computer system; your PDP Display is functioning properly.

Warning Messages

You can even view the screen at a resolution of 1920 x 1080. However, you will receive the following message for a minute; You can choose to change the screen resolution or stay in the current mode during that time. And if the resolution is more than 85Hz, you will see the black screen because the PDP Display does not support over 85Hz.

Note

Refer to Specifications > Preset Timing Modes for the resolutions or frequencies supported by the PDP Display.

Maintenance and Cleaning

1) Maintaining the PDP Display Case.

Clean with a soft cloth after disconnecting the power cord.

Troubleshooting

• Do not use benzene, thinner or other flammable substances, or a wet cloth.

2) Maintaining the Flat Panel Display Screen.

Clean with a soft cloth (cotton flannel) smoothly.

• Never use acetone, benzene or thinner.

(They may cause flaws or deformation of the screen surface.)

• The user will be required to pay costs and related expenses for repairing damages caused.

Symptoms and Recommended Actions

Note

A PDP Display recreates visual signals received from the computer. Therefore, if there is a problem with the computer or the video card, this can cause the PDP Display to become blank, have poor coloring, become noisy, and video mode not supported, etc. In this case, first check the source of the problem, and then contact a Service Center or your dealer.

1. Check if the power cord and the video cables are properly connected to the computer.

2. Check if the computer beeps more than 3 times when booting.

3. If you installed a new video card or if you assembled the PC, check if you installed the

4. Check if the scanning ratio of the video screen is set to between 50 Hz ~ 85 Hz.

5. If you have problems in installing the Adaptor (video) driver, boot the computer in Safe

Check List

• The following table lists possible problems and their solutions. Before calling for assis-

(If it does, request an a service for the main board of the computer.)

Adaptor(video).

(Do not exceed 60Hz when using the maximum resolution.)

Mode, remove the Display Adaptor in the "Control Panel −> System −> Device Administrator" and then reboot the computer to reinstall the Adaptor (video) driver.

Note

tance, check the information in this section to see if you can remedy any problems for yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.

Problems related to the Installation (PC Mode)

Note

Problems related to the PDP Display installation and their solutions are listed.

Q: The PDP Display screen flickers.

A: Check if the signal cable between the computer and the PDP Display is securely con-

nected.

(Refer to Connecting a Computer)

Problems related to the Screen

Note

Problems related to the PDP Display screen and their solutions are listed.

Q: The screen is blank and the power indicator is off.

A: Ensure that the power cord is firmly connected and the PDP Display is on.

(Refer to the Connecting a Computer)

Q: "Check Signal Cable" message.

A: Ensure that the signal cable is firmly connected to the PC or video sources.

(Refer to the Connecting a Computer)

Troubleshooting

A: Ensure that the PC or video sources are turned on.

Q: "Not Optimum Mode" message.

A: Check the maximum resolution and the frequency of the video Adaptor.

A: Compare these values with the data in the Preset Timing Modes Chart.

Q: The picture rolls vertically.

A: Check if the signal cable is securely connected. Re-connect it, if necessary.

(Refer to Connecting a Computer)

Q: The image is not clear; picture is blurred.

A: Run Frequency Coarse and Fine tuning.

A: Turn on again after removing all accessories (video extension cable, etc.)

A: Set the resolution and frequency to the recommended ranges.

Q: The picture image is unstable and shakes.

A: Check if the resolution and frequency set for the computer video card falls in the range

supported by the PDP Display. If not, reset them referring to the current Information under the PDP Display menu and Preset Timing Modes.

Q: Ghost images are shown in the picture.

A: Check if the resolution and frequency set for the computer video card falls in the range

supported by the PDP Display. If not, reset them referring to the current Information under the PDP Display menu and Preset Timing Modes.

Q: The image is too light or too dark.

A: Adjusts the brightness and contrast.

(Refer to the Brightness, Contrast)

Samsung P63FP-2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PDP Display

Safety Instructions

Notational

Power

Installation

Clean

Others

Introduction

Package Contents

Checking the Contents of the Package

Unpacking

Your PDP Display

Front

Rear

Remote Control

Mechanical Layout(P50HP, P50HP-2)

Mechanical Layout

PDP Display Head

Installation VESA Bracket

Dimensions

Wall Bracket Installation

Components

Wall Bracket Assembly

To mount the product on the wall bracket

Wall Bracket Angle Adjustment

Mechanical Layout(P63FP, P63FP-2)

Mechanical Layout

PDP Display Head

Installation VESA Bracket

Dimensions

Wall Bracket Installation

Components

Wall Bracket Assembly

To mount the product on the wall bracket

Wall Bracket Angle Adjustment

Connections

Connecting a Computer

Connecting to Other devices

Connecting AV Devices

Connecting to a Camcorder

Connecting the BNC to BNC cable

Connecting Using a DVI Cable

Connecting Using a HDMI Cable

Connecting Using a DVI to HDMI Cable

Connecting a DVD Player

Connecting a DTV Set Top (Cable/Satellite) Box

Connecting to an Audio System

Using the Software

Installation

Uninstall

Adjusting the PDP Display

Input

Source List

Edit Name

Picture [PC / DVI / BNC / MagicInfo Mode]

MagicBright

Custom

Contrast

Brightness

Sharpness

Color Tone

Color Control

Green

Blue

Color Temp.

Image Lock

Coarse

Fine

H-Position

V-Position

Auto Adjustment

Signal Balance

Signal Balance

Signal Control

Size

Picture [ AV / HDMI / Component Mode]
