DVD Player

DVD-P181K

www.samsung.com/ph

AK68-01690G

PRECAUTIONS

1. Setting up

- Refer to the identification label located on the rear of your player for its proper operating voltage.

- Install your player in a cabinet with adequate ventilation holes. (7~10cm) Do not block ventilation holes on any of the components for air circulation.

- Do not push the disc tray in by hand.

- Do not stack components.

- Be sure to turn all components off before moving the player.

- Before connecting other components to this player, be sure to turn them off.

- Be sure to remove the disc and turn off the player after use, especially if you don’t use it for a long time.

- The mains plug is as a disconnect device and shall stay readily operable at any time.

2. For your safety

- This product utilizes a laser. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

- Do not open covers and do not repair yourself. Refer servicing to qualified personal.

3. Caution

- Your player is not intended for industrial use but for domestic purposes. Use of this product is for personal use only.

- Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

- Exterior influences such as lightning and static electricity can affect normal operation of this player. If this occurs, turn the player off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet. The player will operate normally.

- When condensation forms inside the player

due to sharp changes in temperature, the player may not operate correctly. If this occurs, leave the player at room temperature until the inside of the player becomes dry and operational.

4. Disc

- Do not clean record-cleaning sprays, benzene, thinner, or other volatile solvents that may cause damage to the disc surface.

- Do not touch the disc’s signal surface. Hold by the edges or by one edge and the hole in the center.

- Wipe the dirt away gently; never wipe a cloth back and forth over the disc.

5. Environmental info

- The battery used in this product contains chemicals that are harmful to the environ ment.

- So, dispose of batteries in the proper man ner, according to federal, state, and local regulations.

The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third parties. This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any unlicensed product unit or process conforming to ISO/OUR 11172-3 or ISO/OUR 13818-3 used or sold in combination with this product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/OUR 11172-3 or ISO/OUR 13818-3. No rights are granted under this license for product features or functions that do not conform to the ISO/OUR 11172-3 or ISO/OUR 13818-3.

CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

BEFORE

ARTT

Remote Control

User’s Manual

Install Batteries in the Remote control

1. Open the battery cover on the back of the remote control.

2. Insert two AAA batteries. Make sure that the polarities (+ and -) are aligned correctly.

3. Replace the battery cover.

If remote control doesn’t operate properly:

- Check the polarity + - of the batteries (Dry-Cell)

- Check if the batteries are drained.

- Check if remote control sensor is blocked by

obstacles.

- Check if there is any fluorescent lighting nearby.

YOU

Video/Audio

Cable

ABLE OF

TTABLE OF

CONTENT

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Before you start . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Setup

General Features . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Disc Type and Characteristics . . . . . . . . . . . . . . . . 5

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Tour of the Remote Control . . . . . . . . . . . . . . . . . . 8

Connections

Choosing a Connection . . . . . . . . . . . . . . . . . . . . . 9

Basic Functions

Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Using the Search and Skip Functions . . . . . . . . . 15

Using the Display Function . . . . . . . . . . . . . . . . . 15

Using the Disc and Title Menu . . . . . . . . . . . . . . 15

Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Slow Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Advanced Functions

Adjusting the Aspect Ratio (EZ View) . . . . . . . . . 17

Selecting the Audio Language . . . . . . . . . . . . . . . 17

Selecting the Subtitle Language. . . . . . . . . . . . . . 18

Changing the Camera Angle . . . . . . . . . . . . . . . . 18

Using the Bookmark Function . . . . . . . . . . . . . . . 18

Using the Zoom Function . . . . . . . . . . . . . . . . . . . 19

Clips Menu for MP3/WMA/JPEG/

CD Audio/MPEG4. . . . . . . . . . . . . . . . . . . . . . . . . 19

Folder Selection . . . . . . . . . . . . . . . . . . . . . . . . . . 19

MP3/WMA/CD Audio Playback. . . . . . . . . . . . . . . 19

MPEG4 Playback . . . . . . . . . . . . . . . . . . . . . . . . . 20

Picture CD Playback. . . . . . . . . . . . . . . . . . . . . . . 21

Karaoke Functions

Karaoke Functions . . . . . . . . . . . . . . . . . . . . . . . . 22

Changing Setup Menu

Using the Setup Menu . . . . . . . . . . . . . . . . . . . . . 22

Setting Up the Language Features . . . . . . . . . . . 23

Setting Up the Audio Options . . . . . . . . . . . . . . . . 24

Setting Up the Display Options . . . . . . . . . . . . . . 25

Setting Up the Parental Control . . . . . . . . . . . . . . 26

Reference

Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . 28

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

English

SETUP

General Features

Excellent Sound

Dolby Digital, a technology developed by Dolby Laboratories, provides crystal clear sound reproduction.

Screen

Both regular and widescreen(16:9) pictures can be viewed.

Slow Motion

An important scene can be viewed in slow motion.

Parental Control (DVD)

The parental control allows users to set the level necessary to prohibit children from viewing harmful movies such as those with violence, adult subject matter, etc.

Various On-Screen Menu Functions

You can select various languages (Audio/Subtitle) and screen angles while enjoying movies.

Progressive Scan

Progressive scanning creates an improved picture with double the scan lines of a conventional interlaced picture.

EZ VIEW (DVD)

Easy View enables picture adjustment to match your TV's screen size (16:9 or 4:3).

Digital Photo Viewer (JPEG)

You can view Digital Photos on your TV.

Repeat

You can repeat a song or movie simply by pressing the REPEAT button.

MP3/WMA

This unit can play discs created from MP3/WMA files.

MPEG4

This unit can play MPEG4 formats within an avi file.

Note

- Discs which cannot be played with this player.

• DVD-ROM • DVD-RAM

• CD-ROM • CDV

• CDI • CVD

• CDGs play audio only, not graphics.

- Ability to play back may depend on recording

conditions.

• DVD-R, +R

• CD-RW

• DVD+RW, -RW (V mode)

- The unit may not play certain CD-R, CD-RW and DVD-R due to the disc type or recording

conditions.

COPY PROTECTION

Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copyprotected DVD discs.

This product incorporates copyright protection technology that is protected by methods claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

PROGRESSIVE SCAN OUTPUTS (525p)

“CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE, IN CASE OF 525 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING YOUR TV SET COMPATIBILITY WITH THIS MODEL 525p DVD PLAYER, PLEASE CONTACT SAMSUNG'S CUSTOMER SERVICE CENTER.”

Disc Type and Characteristics

This DVD player is capable of playing the following types of discs with the corresponding logos:

Disc Types (Logos)

DVD

Recording Types Disc Size Max. Playing Time Characteristics

Audio

12 Cm

Video

VIDEO-CD

Audio

8 Cm

12 Cm

Video

AUDIO-CD

8 Cm

12 Cm

Audio

8 Cm

Disc Markings

Play Region Number

NTSC

STEREO

DIGITAL

SOUND

NTSC broadcast system in U.S.A, Canada, Korea, Japan, etc.

Dolby Digital disc

Stereo disc

Digital Audio disc

DTS disc

MP3 disc

You must only insert one DVD disc at a time. Inserting two or more discs will not allow to play them back and it may cause damage to the DVD player.

Single-sided 240 min.

Double-sided 480 min.

Single-sided 80 min.

Double-sided 160 min.

- DVD contains excellent sound and video due to Dolby Digital and MPEG-2 system.

- Various screen and audio functions can be easily selected through the on-screen menu.

74 min.

- Video with CD sound, VHS quality & MPEG-1 compression tech-

20 min.

74 min.

nology.

- CD is recorded as a Digital Signal with better audio quality, less distortion and less deteriora-

20 min.

tion of audio quality over time.

Region Number

Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play.

The Region Number for this player is described on the rear panel of the player.

DivX Certification

DivX, DivX Certified, and associated logos are trademarks of DivXNetworks, Inc and are used under license.

English

Description

Front Panel Controls

1. STANDBY/ON ( )

When STANDBY/ON is pressed on, the indicator goes out and the player is turned on.

2. STANDBY indicator

When the unit is first plugged in, this indicator lights.

3. DISC TRAY

Place the disc here.

4. MIC

Connect Microphone for karaoke functions.

5. MICROPHONE VOLUME

Use to adjust microphone volume level. Use the button by pressing it. Turn it to the left or right to control the volume.

6. DISPLAY

Operation indicators are displayed here.

7. OPEN/CLOSE /STOP ( )

Stops disc play. Press to open and close the disc tray.

8. PLAY/PAUSE ( )

Begin or pause disc play.

Front Panel Display

Total playing time/Displays various messages concerning operations such as PLAY, STOP, LOAD ...

nodSC: No disc loaded. OPEn: The disc tray is open. LOAd: Player is loading disc information.

Rear Panel

2 3

1. AUDIO OUT JACKS

- Connect to the Audio input jacks of your television or audio/video receiver.

2. VIDEO OUT JACK

- Use a video cable to connect to the Video input jack on your television

3. COMPONENT VIDEO OUT JACKS

- Use these jacks if you have a TV with Component Video in jacks. These jacks provide P video.

- If P-SCAN Video Output is selected in Setup Menu, progressive scan mode will work.

- If I-SCAN Video Output is selected in Setup Menu,

interlaced scan mode will work.

, PBand Y

English

4. DIGITAL AUDIO OUT JACKS

- Use either coaxial digital cable to connect to a compatible Dolby Digital receiver.

- Use either coaxial digital cable to connect to an A/V Amplifier that contains a Dolby Digital, MPEG2 or DTS decoder.

Note

- Consult your TV User’s Manual to find out if your TV supports Progressive Scan.

If Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan settings in the TV’s menu system.

- See pages 25 to get more information on how to use the setup menu.

Tour of the Remote Control

6 7 8

1. DVD Power Button

Turns the power on or standby.

2. NUMBER Buttons

3. TITLE MENU (number 7) Button

Brings up the Title menu.

4. ZOOM/- /-- Button

Enlarge DVD Picture Use this button to select the channel of TV program by inserted the channel number (TV mode).

5. TV VOLUME

TV VOL(+,-) button

16 17

23 24

27 28

6. SEARCH Buttons (

Allow you to search forward/backward through a disc.

7. VIDEO SEL.Button

Change video output mode

8. SKIP Buttons (

Use to skip the title, chapter or track.

9. STOP Button ( )

10. MENU Button

Brings up the DVD player’s menu.

11. ENTER/

This button functions as a toggle switch.

12. EZ VIEW Button

The aspect ratio of a picture can easily be adjusted

according to the screen size of your TV (16:9 or 4:3)

13. DISC MENU Button

Brings up the Disc menu.

14. OPEN/CLOSE ( ) Button

To open and close the disc tray

15. AUDIO Button

Use this button to access various audio functions on a disc.

16. DVD Button

Use to operate DVD

17. TV Button

Use to operate TV

18. KARAOKE (Number 8) Button

Use to begin Karaoke functions.

19. BOOKMARK (Number 9 Button)

Quickly find bookmark sections of a DVD or VCD.

20. STEP /TV SOURCE Button

Advances play one frame at a time/Press this button to

select an available TV source (TV mode).

21. TV CH Buttons

Use to change channel.

22. SUBTITLE Button

23. PLAY/PAUSE Button ( )

Begin/Pause disc play.

24. RETURN Button

Returns to a previous menu.

25. INFO Button

Displays the current disc mode.

26. CANCEL Button

Use to remove menus or status displays from the

screen.

27. REPEAT A-B Button

Allows you to repeat A-B disc.

28. REPEAT Button

Allows you to repeat play a title, chapter, track, or disc.

/,¦¦/

Buttons

)

CONNECTIONS

Choosing a Connection

The following shows examples of connections commonly used to connect the DVD player with a TV and other components.

Before Connecting the DVD Player

- Always turn off the DVD player, TV, and other components before you connect or disconnect any cables.

- Refer to the user’s manual of the additional components you are connecting for more information on those particular components.

Connection to a TV (For Video)

Using component video cables (not included), connect the

VIDEO OUT on the rear of the DVD player to the VIDEO IN terminal of TV.

WHITE

RED

Turn on the DVD player and TV.

Audio Cable

YELLOW

Video Cable

WHITE

YELLOW

RED

Press the TV/VIDEO button on the TV's remote control to select Video.

English

Note

- Noise may be generated if the audio cable is too close to the power cable.

- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 12 to 13)

- The number and position of terminals can vary depending on your TV set. Please refer to the user's manual of the TV.

- If you press the VIDEO SEL. button when DVD Player is in stop mode or no disc is inserted, the Video Output mode changes in the following sequence:

(I-SCAN ➝ P-SCAN)

Connection to a TV (Interlace)

- Connecting to your TV using Component video cables.

- You will enjoy high quality and accurate color reproduction images. Component video separates the picture element into black and white(Y), blue(PB), red(PR) signals to present clear and clean images. (Audio signals are delivered through the audio output.)

Using component video cables (not included), connect the COMPONENT VIDEO OUT terminal on the rear of the DVD player to the COMPONENT IN terminal of TV.

Audio Cable

WHITE

RED

WHITE

BLUE

GREEN

RED

Component cable (not included)

GREEN

BLUE

RED

Using the audio cables, connect the AUDIO (red and white) OUT on the rear of the DVD player to the AUDIO (red and white) IN terminals of TV. Turn on the DVD play-

er and TV.

Press the TV/VIDEO button on the TV's remote control to select Component or DVD.

Set the Video Output to Component (I-SCAN) in the Display Setup menu. (See pages 25)

Note

- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 12 to 13)

- The component terminal of TV can be marked by “R-Y, B-Y, Y” or “Cr, Cb, Y” instead of “P

depending on the manufacturer. The number and position of terminals can vary depending on the TV set. Please refer to the user's manual of the TV.

, PB, Y”

Connection to a TV (Progressive)

Using component video cables (not included), connect the COMPONENT VIDEO OUT terminal on the rear of the DVD player to the COMPONENT IN terminal of TV.

Using the audio cables, connect the AUDIO (red and white) OUT on the rear of the DVD player to the AUDIO (red and white) IN terminals of TV. Turn on the DVD play-

er and TV.

Press the input selector on your TV remote control until the Component signal from the DVD player appears on the TV screen.

Audio Cable

WHITE

RED

WHITE

BLUE

GREEN

RED

Component cable (not included)

GREEN

BLUE

RED

Set the Video Output to Component (P-SCAN) in the Display Setup menu. (See pages 25)

To see the progressive video output,

- Consult your TV User’s Manual to find out if your TV supports Progressive Scan. If Progressive

You need a TV set supporting the progressive scan

Scan is supported, follow the TV User’s Manual regarding Progressive Scan settings in the TV’s

input function. And you have to set up the TV

menu system.

- Depending on your TV, the connection method may differ from the illustration above.

Note

- What is "Progressive Scan"? Progressive scan has twice as many scanning lines as the interlace output method has. Progressive scanning method can provide better and clearer picture quality.

English

Connection to an Audio System (2 Channel Amplifier)

Using the audio cables, connect the AUDIO (red and white) OUT on the rear of the DVD player to the AUDIO (red and white) IN terminals of the Amplifier.

Using the video signal cable(s), connect the VIDEO or COMPONENT OUT terminals on the rear of the DVD play- er to the VIDEO orCOMPONENT IN terminal of your TV.

Turn on the DVD player, TV, and Amplifier.

WHITE

RED

Audio Cable

WHITE

RED

Press the input select button of the Amplifier to select external input in order to hear sound from the DVD player.

Note

- Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears.

- Please set the audio in the menu screen according to the Amplifier. (See pages 24-25)

- The position of terminals can vary depending on the Amplifier. Please refer to the user's manual of the Amplifier.

Connection to an Audio System (Dolby digital, MPEG2 or DTS Amplifier)

If using a coaxial cable (not included), connect the DIGITAL AUDIO OUT (COAXIAL) terminal on the rear of the

DVD player to the DIGITAL AUDIO IN (COAXIAL) terminal of the Amplifier.

Using the video signal cable(s), connect the VIDEO or COMPONENT OUT terminals on the rear of the DVD play- er to the VIDEO or COMPONENT IN terminal of TV.

Audio Cable

Turn on the DVD player, TV, and Amplifier.

Press the input select button of the Amplifier to select

external input in order to hear sound from the DVD player.

English

Note

- Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears.

- Please set the audio in the menu screen according to the Amplifier. (See pages 24-25)

- The position of terminals can vary depending on the Amplifier. Please refer to the user's manual of the Amplifier.

BASIC

SELECT MENU LANGUAGE

BASIC

FUNCTIONS

Playing a Disc

Before Play

- Turn on your TV and set it to the correct Video Input by pressing TV/VIDEO button on the TV remote control.

- If you connected an external Audio System, turn on your Audio System and set it to the correct Audio Input.

After plugging in the player, the first time you press the DVD POWER button, this screen comes up: If you want to select a language, press a NUMBER button. (This screen will only appear when you plug in the player for the first time.) If the language for the startup screen is not set, the settings may change whenever you turn the power on or off. Therefore, make sure that you select the language you want to use. Once you select a menu language, you can change it by pressing the button on the front panel of the unit for more than 5 seconds with no disc in the unit. Then the SELECT MENU LANGUAGE window appears again where you can reset your preferred language.

Press 1 for English

Touche 2 pour Français

Drücken Sie 3 für Deutsch

Pulsar 4 para Español

Premere 5 per Italiano

Druk op 6 voor Nederlands

Playback

1. Press the OPEN/CLOSE ( ) button. The STANDBY indicator light goes out and the tray opens.

2. Place a disc gently into the tray with the disc’s label facing up.

- You must only insert one DVD disc at a time. Inserting two or more discs will not allow to play them back and it may cause damage to the DVD player.

3. Press the PLAY/PAUSE ( ) button or OPEN/ CLOSE ()button to close the disc tray.

When you stop disc play, the player remembers

where you stopped, so when you press PLAY/PAUSE ( ) button again, it will pick up where you left off. (unless the disc is removed or the player is unplugged, or if you press the STOP ( ) button twice.)

4. Stopping Play Press the STOP ( ) button during play.

5. Removing Disc Press the OPEN/CLOSE ( ) button.

6. Pausing Play Press the PLAY/PAUSE ( ) or STEP button on the remote control during play.

- Screen stops, no sound. To resume, press the PLAY/PAUSE ( )

button once again.

7. Step Motion Play (Except CD) Press the STEP button on the remote control during play.

- Each time the button is pressed, a new frame will

appear.

- No sound is heard during STEP mode.

- Press the PLAY/PAUSE ( ) button to resume

normal play.

- You can only perform step motion play in the

forward direction.

8. Slow Motion Play Press SEARCH ( ) button to choose the play speed between 1/2, 1/4, 1/8 and 1/16 of normal during PAUSE or STEP mode.

- No sound is heard during slow mode.

- Press the PLAY/PAUSE ( ) button to resume

normal play.

- Reverse slow motion play will not work.

Note

- If the player is left in the stop mode for more than one minute without any user interaction, a screen saver will be activated. Press the PLAY/PAUSE ( ) button to resume normal play.

- If the player is left in the stop mode for more than about 30 minutes, the power will automatically shut off. (Automatic Power-Off Function)

- If the player is left for about 5 minutes in pause mode, it will stop.

- This ( ) icon indicates an invalid button press.

Using the Search and Skip Functions

During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection.

Searching through a Chapter or Track.

During play, press the SEARCH ( or ) button on the remote control.

2X, 4X, 64X, 128X

DVD

4X, 8X

VCD

2X, 4X, 8X

Note

- The speed marked in this function may be different from the actual speed of playback.

Skipping Tracks

During play, press the SKIP ( or ) button.

- When playing a DVD, if you press the SKIP ( ) button, it

moves to the next chapter. If you press the SKIP ( )

button, it moves to the beginning of the chapter. One more

press makes it move to the beginning of the previous

chapter.

- When playing a VCD 2.0 in Menu Off mode, or a VCD 1.1

or a CD, if you press the SKIP ( ) button, it moves to

the next track. If you press the SKIP ( ) button, it moves

to the beginning of the track. One more press makes it

move to the beginning of the previous track.

- If a track exceeds 15 minutes when playing a VCD and

you press the button, it moves forward 5minutes.

If you press the button, it moves backward 5 minutes.

Note

Only Menu Off is available for VCD2.0. Each press of the DISC MENU button toggles between Menu On and Menu

Off

2. Press the /buttons to select the desired item.

3. Press the ¦/ buttons to make the desired setup and then

press the ENTER button.

- You may use the number buttons of the remote control to directly access a title, chapter or to start the playback from the desired time.

4. To make the screen disappear, press the RETURN button again.

Note

To access the desired title when there is more than one in the disc. For example, if there is more than one movie on a DVD, each movie will be identified.

Most DVD discs are recorded in chapters so that you can quickly find a specific passage

Allows playback of the film from a desired time. You must enter the starting time as a reference.The time search function does not operate on some disc.

Refers to the language of the film soundtrack. In the example, the soundtrack is played in English 5.1CH. A DVD disc can have up to eight different soundtracks.

Refers to the subtitle languages available in the disc. You will be able to choose the subtitle languages or, if you prefer, turn them off from the screen. A DVD disc can have up to 32 different subtitles.

To access the desired Angle function. Some DVD discs are have more angle function from any picture.

Using the Disc and Title Menu

Using the Disc Menu

1. Press the MENU button on the remote control.

English

Using the Display Function

When Playing a DVD/VCD/MPEG4

1. During play, press the INFO button on the remote control.

2. Press the / buttons to select Disc Menu, then press the

 or ENTER button.

.. Language Setup Page ..

Player Menu E N G

Disc Menu E N G

Audio ORI

Subtitle A U T O

Note

- Depending on a disc, the Disc Menu may not work.

- You can also use the Disc Menu, using the DISC MENU button on the remote control.

- Only Menu Off is available for VCD2.0. Each press of the DISC MENU button toggles between Menu On and Menu Off.

Repeat Play

Press the REPEAT button to change playback mode.

When playing a DVD/VCD

- DVD repeat play by chapter,title or disc VCD repeat play by disc or track.

- Chapter : repeats the chapter that is playing.

- Title : repeats the title that is playing.

- Disc : repeats the disc that is playing.

- Track : repeats the track that is playing.

- Off

DVD/VCD

Not

- A-B REPEAT allows you to set point(B) directly after point (A) has been set.

- Depending on a disc, the Repeat function may not work.

- Only Menu Off is available for VCD2.0. Each press of the DISC MENU button toggles between Menu On and Menu Off.

Slow Play

This feature allows you slowly to repeat scenes containing sports, dancing, musical instruments being played etc., so you can study them more closely.

Using the A-B Repeat function

1. Press the REPEAT A-B button on the remocon at the point

where you want repeat play to start (A).

2. Press the REPEAT A-B button on the remocon at the

point where you want the repeat play to stop (B).

3. To return to normal play, press REPEAT A-B button

again.

When playing a DVD/VCD

1. During play, press the PLAY/PAUSE ( ) button.

2. Press the SEARCH () button repeatedly to choose the play speed between 1/2, 1/4,1/8,1/16 of normal during PAUSE mode.

If you are using a 4:3 TV

ADV

FUNCTIONS

ANCED

Adjusting the Aspect Ratio (EZ View)

To play back using aspect ratio (DVD)

Press the EZ VIEW button.

- The screen size changes when the button is pressed repeatedly.

- The screen zoom mode operates differently depending on the screen setting in the Display Setup menu.

- To ensure correct operation of the EZ VIEW button, you

should set the correct aspect ratio in the Display Setup menu. (See pages 25).

If you are using a 16:9 TV

For 16:9 aspect ratio discs

- WIDE SCREEN Displays the content of the DVD title in 16:9 aspect ratio.

- SCREEN FIT

The top and bottom portions of the screen are cut off. When playing a 2.35:1 aspect ratio disc, the black bars at the top and bottom of the screen will disappear. The picture will look vertically stretched. (Depending on a type of disc, the black bars may not disappear completely.)

- ZOOM FIT

The top, bottom, left and right of the screen are cut off and the central portion of the screen is enlarge

For 4:3 aspect ratio discs

- Normal Wide

Displays the content of the DVD title in 16:9 aspect ratio. The picture will look horizontally stretched.

- SCREEN FIT

The top and bottom portions of the screen are cut off and the full screen appears. The picture will look vertically stretched.

- ZOOM FIT

The top, bottom, left and right portions of the screen are cut off and the central portion of the screen is enlarged.

- Vertical Fit

When a 4:3 DVD is viewed on a 16:9 TV, black bars will appear at the left and right of the screen in order to prevent the picture from looking horizontally stretched.

For 16:9 aspect ratio discs

- 4:3 Letter Box

Displays the content of the DVD title in 16:9 aspect ratio. The black bars will appear at the top and bottom of the screen.

- 4:3 Pan&Scan

The left and right portions of the screen are cut off and the central portion of the 16:9 screen is displayed.

- SCREEN FIT

The top and bottom portions of the screen are cut off and a full screen appears. The picture will look vertically stretched.

- ZOOM FIT

The top, bottom, left and right of the screen are cut off and the central portion of the screen is enlarged.

For 4:3 aspect ratio discs

- Normal Screen

Displays the content of the DVD title in 4:3 aspect ratio.

- SCREEN FIT

The top and bottom portions of the screen are cut off and the

full screen appears. The picture will look vertically stretched.

- ZOOM FIT

The top, bottom, left and right portions of the screen are cut

off and the central portion of the screen is enlarged.

Note

This function may behave differently depending on the type of disc.

Selecting the Audio Language

You can select a desired audio language quickly and easily with the AUDIO button.

Using the AUDIO button

1. Press the Audio button. The Audio changes when the audio button is press repeatedly. The audio languages are represented by abbreviations.

DVD

When playing a VCD, you can select among STEREO, LEFT, RIGHT.

2. To remove the AUDIO icon, press the CANCEL or RETURN button.

English

Note

English

Bookmark

Play

Clear

Bookmark

Play

Clear

TT:01 CH:05 Time 0:39:23

Bookmark

Play

Clear

TT:01 CH:05 Time 0:39:23

Bookmark

Play

Clear

TT:01 CH:05 Time 0:39:23

- This function depends on audio languages are encoded on the disc and may not work.

- A DVD disc can contain up to 8 audio languages.

- To have the same audio language come up whenever you play a DVD; Refer to “Using the Audio Language” on page

23.

Selecting the Subtitle Language

You can select a desired subtitle quickly and easily with the SUBTITLE button.

Using the SUBTITLE button (DVD)

1. Press the SUBTITLE button. The subtitle languages are represented by abbreviations. The subtitle changes when the button is pressed repeatedly.

DVD

Using the Bookmark Function

This feature lets you bookmark sections of a DVD or VCD (Menu Off mode) so you can quickly find them at a later time.

Using the Bookmark Function (DVD/VCD)

1. During play, press the Bookmark button on the remote control.

2. When you reach the scene you want to mark, press the

ENTER button. Up to12 scenes may be marked at a time.

DVD/VCD

Note

- You have to change the desired subtitle in the Disc Menu, according to discs. Press the INFO MENU button.

- This function depends on what subtitles are encoded on the disc and may not work on all DVDs.

- A DVD disc can contain up to 32 subtitle languages.

- To have the same subtitle language come up whenever you play a DVD; Refer to “Using the Subtitle Language” on page 23.

Changing the Camera Angle

When a DVD contains multiple angles of a particular scene, you can use the ANGLE function.

Using the ANGLE Function (DVD).

If the disc contains multiple angles, the ANGLE appears on the screen.

1. During play, press the INFO button on the remote control.

2. Press the / buttons to select

3. Press the ¦/ buttons or you can use the number buttons

on the remote control to select the desired angel Angle.

Note

- Depending on a disc, the Bookmark function may not work.

Recalling a Marked Scene

1. During play, press the bookmark button on the remocon

2. Press the /¦/ buttons to select a marked scene.

3. Press the PLAY/PAUSE ( ) button to skip to the marked scene.

Clearing a Bookmark

1. During play, press the Bookmark button on the remocon.

2. Press the /¦/ buttons to select the bookmark number you want to delete.

3. Press the CANCEL button to delete a bookmark number.

Using the Zoom Function

001/004

Off

128kbps

03:12

00:01

track 1

track 2

track 3

track 4

001/004

Off

Using the Zoom Function (DVD/VCD)

- During DVD or VCD play or pause mode, press ZOOM button on the remocontrol repetedly to zoom in 2X/3X/4X

- During VCD play, press ZOOM button to zoom in 2X/4X/2X/Normal in order.

- : STOP file icon.

- : PLAY file icon

- : WMA file icon

- : MP3 file icon.

- : JPG file icon.

- : AVI file icon.

- : CD file icon.

- : Folder file icon

- : current file icon

English

Clips Menu for MP3/WMA/JPEG/CD Audio/MPEG4

CD Audio or discs with MP3/WMA/JPEG/MPEG4 contain individual songs and/or pictures that can be organized into folders as shown below. They are similar to how you use your computer to put files into different folders.

Open the disc tray. Place the disc on the tray. Close the tray. The tray closes and this screen displays.

-: Current Playback Mode : There are four

modes. They can be selected in order by pressing the REPEAT button.

- Off: Normal Playback

- Track: Repeats the current track.

- Folder: Repeats the current folder.

- Random: Files in the disc will be played in random order.

Folder Selection

- To select the Parent Folder

Press the RETURN button to go to parent folder, or press the

/

buttons to select “..” and press ENTER to go to the

parent folder.

MP3/WMA/CD Audio Playback

1. Open the disc tray. Place the disc on the tray. Close the tray.

- Only one kind of file is played back when a disc or a folder contains both MP3 and WMA files.

2. Press the /buttons to select a song file. Press ENTER to begin playback of the song file.

Repeat/Random playback

Press the REPEAT button to change the playback mode. There are four modes, such as Off, Track, Folder and Random.

- Off: Normal Playback

- Track: Repeats the current song file.

- Folder: Repeats the song files which have the same extension in the current folder.

- Random: Song files which have the same extension will be played in random order.

CD-R MP3/WMA file

001/005

Off

MPEG4 Playback

When you record MP3 or WMA files on CD-R, please refer to the following.

- Your MP3 or WMA files should be ISO 9660 or JOLIET format.

ISO 9660 format and Joliet MP3 or WMA files are compatible with Microsoft's DOS and Windows, and with

Apple's Mac. This format is the most widely used.

- When naming your MP3 or WMA files, do not exceed 8 characters, and enter “.mp3, .wma” as the file extension.

General name format : Title.mp3. or Title.wma. When composing your title, make sure that you use 8 characters or less, have no spaces in the name, and avoid the use of special characters including: (.,/,\,=,+).

- Use a decompression transfer rate of at least 128 Kbps when recording MP3 files.

Sound quality with MP3 files basically depends on the rate of compression/decompression you choose. Getting CD audio sound requires an analog/digital sampling rate, that is conversion to MP3 format, of at least 128 Kbps and up to 160 Kbps. However, choosing higher rates, like 192 Kbps or more, only rarely give better sound quality. Conversely, files with decompression rates below 128 Kbps will not be played properly.

- Use a decompression transfer rate of at least 64Kbps when recording WMA files.

Sound quality with WMA files basically depends on the rate of compression/decompression you choose. Getting CD audio sound requires an analog/digital sampling rate, that is conversion to WMA format, of at least 64Kbps and up to 192Kbps. Conversely, files with decompression rates below 64Kbps or over 192Kbps will not be played properly.

- Do not try recording copyright protected MP3 files.

Certain "secured" files are encrypted and code protected to prevent illegal copying. These files are of the following types: Windows Media SDMI

(registered trade mark of Microsoft Inc) and

(registered trade mark of The SDMI Foundation). You

cannot copy such files.

- Important:

The above recommendations cannot be taken as a guarantee that the DVD player will play MP3 recordings, or as an assurance of sound quality. You should note that certain technologies and methods for MP3 file recording on CD-Rs prevent optimal playback of these files on your DVD player (degraded sound quality and in some cases, inability of the player to read the files).

- This unit can play a maximum of 500 files and 500 folders per disc.

MPEG4 Play Function

AVI files are used to contain the audio and video data. Format files with the “.avi&DivX” extensions can be played.

1. Open the disc tray. Place the disc on the tray. Close the tray.

/

2. Press the

buttons to select an avi file

(DivX/XviD), then press the ENTER button.

Repeat Playback

Press the REPEAT button to change playback mode. There are 4 modes, such as Off, Folder, Title an A-B.

-Folder : Repeats the AVI files which have the same exten sion in the current folder.

-Title : repeats the title that is playing.

-A-B : repeats a segment of the file that you selecting.

MPEG4 Function Description

Function Description Reference page

Skip

( or )

Slow Motion

Step Motion

During play, press the or

button, it moves forward or

backward 5 minutes. During play, press the SEARCH (

or ) button and press again to search at a faster speed. to search at a faster speed in an AVI file. (2X, 4X, 8X)

Allows you to search at a slower speed in an AVI file. (1/2X, 1/4X,

Play

1/8X,1/16X) Each time the STEP button is

pressed, a new frame will

Play

appear.

Allows you

- These functions may not work depending on MPEG4 file.

CD-R AVI file

This unit can play the following video compression formats within the AVI file format:

- DivX 3.11 contents

- DivX 4 contents (Based on MPEG4 Simple Profile)

- DivX 5 contents (MPEG4 simple profile plus additional features such as bi-directional frames. Qpel and GMC are also supported.)

- XviD MPEG4 compliant Contents.

This unit supports all resolutions up to maximum below.

P14

DivX3.11 & DivX4 & XviD DivX5

Bitrate may fluctuate:

Device may skip decoding the

high bitrate portions and begin

decoding again when Bitrate

returns to

normal.

720 x 480 @30fps

720 x 576 @25fps

: Maximum bitrate : 4Mbps

Zoom

- Each time zoom button is pressed, the picture is enlarged. zoom mode : 100% -125%-150%-200%-100% .

Slide show

- When you press the ENTER/PLAY at JPEG file,it will go to full screen mode and automaically slide show.

Note

- Some MPEG4 files created on a personal computer may not be play back. That is why Codec Type, Version and Higher resolution over specification is not supported.

- This unit supports CD-R/RW written in MPEG4 in accordance with the “ISO9660 format”.

Picture CD Playback

1. Select the desired folder.

2. Press the

Rotation

- Each time the

- Each time the button is pressed,the picture

/

buttons to select a Picture file in the clips

menu and then press the ENTER button.

¦/

button is pressed,the picture

rotates 90 degree clockwise.

rotate 180 degree.

Note

- Depending on a file size, the amount of time between each picture may be different from the manual.

- If you don’t press any button, the slide show will start automatically in about 8 seconds by default.

CD-R JPEG Discs

- Only files with the “.jpg” and “.JPG” extensions can be played.

- If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played.

- Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.

- The name of the JPEG file may not be longer than 8 characters and should contain no blank spaces or special characters (. / = +).

- Only a consecutively written multi-session disc can be played. If there is a blank segment in the multi-session disc, the disc can be played only up to the blank segment.

- A maximum of 500 images can be stored on a single CD.

- Kodak Picture CDs are recommended.

- When playing a Kodak Picture CD, only the JPEG files in the pictures folder can be played.

- Kodak Picture CD: The JPEG files in the pictures folder can be played automatically.

- Konica Picture CD: If you want to see the Picture, select the JPEG files in the clips menu.

- Fuji Picture CD: If you want to see the Picture, select the JPEG files in the clips menu.

- QSS Picture CD: The unit may not play QSS Picture CD.

- If the number of files in 1 Disc is over 500, only 500 JPEG files can be played.

- If the number of folders in 1 Disc is over 500, only JPEG files in 500 folders can be played

English

- Each time the



button is pressed,the picture

go to miror appearance.

KARAOKE

FUNCTIONS

CHANGING SETUP

Karaoke Functions

Operation Sequence

1. Connect the Mixed Audio Out terminals with the TV or Amplifier. (see page 9 to 12)

2. Connect Mic into Mic jack. When a MIC is connected, the karaoke functions can be used.

Key Control

1. Playback the Karaoke Disc containing the wanted songs. Press the KARAOKE button.

¦¦/

2. Press the

Note

- If you hear feedback(squealing or howling) while using the karaoke feature, move the microphone away from the speakers or turn down the microphone volume or the speaker volume.

- When playing MP3, WMA, DTS and LPCM disc, the karaoke functions will not operate.

- When the MIC is connected, Digital Out does not work.

- If the MIC is connected in VCD 2.0, Playback is selected to Menu off mode automatically.

- The MIC sound outputs only from Analog Audio Out.

buttons to change the desired tone.

Key+ 00

Using the Setup Menu

The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have.

1. Press the MENU button on the remote control.Use the buttons to select Setup, then press the or ENTER button.

.. Language Setup Page .. ..

Player Menu ENG

Disc Menu ENG Audio ORI Subtitle AUTO

Language Setup page: Setup of the Language.

❶

Audio Setup page: Setup of the Audio Options.

❷

Display Setup page: Setup of the Display Options. Use

❸

to select which type of screen you want to watch and several display options. Parental Setup page: Setup of the Parental Level. Allows

❹

users to set the level necessary to prevent children from viewing unsuitable movies such as those with violence, adult subject matter, etc.

❺

DivX(R) page : Please use the Registration code

to register this player with the DivX(R) Video On

Demand format. To learn more go to www.divx.com/vod.

¦/

2. Press the Press the

3. To make the setup screen disappear after setting up, press the MENU button again.

Note

Depending on the disc, some Setup Menu selections may not work.

buttons to access the different features.



or ENTER button to access the sub features.

¦/

Setting Up the Language Features

If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie.

Using the Player Menu Language

1. Press the MENU button.

¦/

2. Press the press the

3. Press the



the

4. Press the then press ENTER button.

- The language is selected and the screen returns to Language Setup page.

- To make the setup menu disappear, press the MENU

button.

Using the Disc Menu Language

This function changes the text language only on the disc menu screens.

1. Press the MENU button.

2. Press the then press the

3. Press the the ENTER button.

4. Press the then press the ENTER button.

- The language is selected and the screen returns to

Language Setup page

- To make the setup menu disappear, press the MENU

button.

buttons to select Language Setup, then



or ENTER button.

/

buttons to select Player Menu, then press

or ENTER button.

/

buttons to select the desired language,

.. Language Setup Page .. ..

Player Menu ENG

Disc Menu ENG Audio ORI Subtitle AUTO

¦/

buttons to select Language Setup page,



or ENTER button.

/

buttons to select Disc Menu, then press

/

buttons to select the desired language,

English Français Deutsch Español Italiano Nederlands

Using the Audio Language

1. Press the MENU button.

¦/

2. Press the then press the

3. Press the

buttons to select Language Setup page,



or ENTER button.

/

buttons to select Audio, then press ENTER

button.

4. Press the /buttons to select the desired language, then press ENTER button.

- Select “Original” if you want the default soundtrack language to be the original language the disc is recorded in.

- If the selected language is not recorded on the disc, the original pre-recorded language is selected.

- The language is selected and the screen returns to Language Setup menu.

- To make the setup menu disappear, press the MENU button.

.. Language Setup Page .. ..

Player Menu ENG

Disc Menu ENG

Audio ORI

Subtitle AUTO

Original

English

Français

Deutsch

Español

Italiano

Nederlands

Cesky

Using the Subtitle Language

1. Press the MENU button.

¦/

2. Press the press the

3. Press the or ENTER button.

4. Press the then press the ENTER button.

- Select “Automatic” if you want the subtitle language to

be the same as the language selected as the audio language.

- Some discs may not contain the language you select as

your initial language; in that case the disc will use its original language setting.

- The language is selected and the screen returns to

setup menu.

- To make the setup menu disappear, press the MENU

button.

buttons to select Language Setup, then



or ENTER button.

/

buttons to select Subtitle, then press the

/

buttons to select the desired language,



English

.. Language Setup Page .. ..

Player Menu ENG

Disc Menu ENG

Audio ORI

Subtitle AUTO

English

Français

Deutsch

Español

Italiano

Nederlands

Cesky

Dansk

.. Language Setup Page .. ..

Player Menu ENG

Disc Menu ENG

Audio ORI

Subtitle AUTO

Automatic

English

Français

Deutsch

Español

Italiano

Nederlands

Cesky

Using the DivX Subtitle Language

DivX(R) Video on demand

your registration code is:

XR3YJ4HZ

http://www.divx.com/vod

1. Press the MENU button.

2. Press the

3. Press the

4. Press the



the

or ENTER button.

the



or ENTER button.

¥/

buttons to select DivX Page, then press

/

buttons to select DivX Subtitle, then press

/

buttons to select the desired language,

then press the ENTER button.

- The language is selected and the screen returns to

Language Setup menu.

- To make the setup menu disappear, press the

MENU button.

.. DivX Page..

Western

Divx Subtitle

Divx VOD

Western

Central

Cyrillic

Greek

Turkish

Arabic

Using the DivX VOD

1. With the unit in stop mode, press the menu button.

2. Press the press the

3. Press the press the

button to select



or ENTER.button

/

button to select



or ENTER .button.

DivX Page

DivX VOD

, then

¥/

4. Press OK to see the DivX registration number.

Note

- If you press ok will make the setup menu dissa pear.

- Divx VoD item only can acces at stop mode.

Setting Up the Audio Options

Audio Options allows you to setup the audio device and sound status settings depending on the audio system in use.

1. Press the MENU button.

2. Press the

3. Press the

❶

❷

❸

❹

¥/

buttons to select Audio Setup, then



press the

or ENTER button.

/

buttons to select the desired item, then



or ENTER button.

.. Audio Setup Page ..

Dolby Digital Out PCM

MPEG2 Digital Output PCM

Dynamic Compression On

PCM Down Sampling On

.. Audio Setup Page ..

Dolby Digital Out PCM PCM

MPEG2 Digital Output PCM BItstream

Dynamic Compression On

PCM Down Sampling On

Dolby Digital Out

- PCM : Converts to PCM(2CH) audio.

- Bitstream : Outputs Dolby Digital via the digital output.Select Bitstream when connecting to a Dolby Digital Decoder.

MPEG-2 Digital Output

- PCM : Converts to PCM(2CH) audio.

- Bitstream : Converts to MPEG-2 Digital Bitstream (5.1CH or 8CH). Select Bitstream when using the Digital Audio Output.

Dynamic Compression

- On : To select dynamic compression.

- Off : To select the standard range.

PCM Down Sampling

- On : Select this when the Amplifier connected to the

player is not 96KHz compatible. In this case, the 96KHz signals will be down converted to 48KHZ.

- Off : Select this when the Amplifier connected to the player is 96KHz compatible. In this case, all signals will be output without any changes.

Note

Even when PCM Down sampling is Off

• Some discs will only output down sampled audio through the digital outputs.

• To make the Setup menu disappear, press the MENU button.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Setting Up the Display Options

Display options enable you to set various video functions of the player.

1. Press the MENU button.

2. Press the

3. Press the

❶

¦¦/

buttons to select Display Setup page



then press the

press the

or ENTER button.

/

buttons to select the desired item, then



or ENTER button.

.. Display Setup Page ..

Tv Aspect Wide

Screen Message On

Video Output I-Scan

Black Level Off

TV System NTSC

TV Aspect

Depending on a type of television you have, you may want to adjust the screen setting (aspect ratio).

- 4:3 Pan&Scan : Select this for conventional size TVs when you want to see the central portion of the 16:9 screen. (Extreme left and right side of movie picture will be cut off.)

- 4:3 Letter Box : Select when you want to see the total 16:9 ratio screen DVD supplies, even though you have a TV with a 4:3 ratio screen. Black bars will appear at the top and bottom of the screen.

- 16:9 Wide : You can view the full 16:9 picture on your wide screen TV.

.. Display Setup Page ..

Tv Aspect

Screen Message On

Video Output I-Scan

Black Level Off

TV System NTSC

Wide

4:3 Pan&Scan

4:3 letter Box

16:9 Wide

Screen Message

❷

Use to turn on-screen messages On or Off.

Video Output

❸

Select Video Output.

- I-SCAN: Select when you want to use Component Interlace (525i) Out.

- P-SCAN: Select when you want to use Component Progressive (525p) Out.

• If you press the VIDEO SEL. button, Video

output mode is changed in regular sequence in no disc mode. (

Black Level

❹

Adjusts the brightness of the screen.(On or Off) It does not function in

TV System

➎

- NTSC : In case of using NTSC disc

I-SCAN ➝ P-SCAN).

.. Display Setup Page ..

Tv Aspect

Screen Message On

Video Output I-Scan

Black Level Off

TV System NTSC

PAL TV system

Wide

P-SCAN

I-SCAN

• If your TV system only has PAL-Video input, you must choose “PAL”. When you choose “PAL”, Interlace output format is PAL 60 Hz output.

• If your TV system only has NTSC, input you must choose “NTSC ”.

• If you set up the NTSC TV system

- PAL : In case of using PAL disc

• If your TV system only has NTSC-Video input, you must choose “NTSC”.

• If your TV system only has PAL input, you must choose “PAL ”.

• If you set up the PAL TV system.

.. Display Setup Page ..

Tv Aspect Wide

Screen Message On

Video Output I-Scan

Black Level Off

TV System NTSC

PAL

AUTO

NTSC

• Consult your TV User’s Manual to find out if your TV supports Progressive Scan. If Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan settings in the TV’s menu system.

• If Video Output is set incorrectly, the screen may be blocked.

• When the resolution is changed during playback, it may take a few seconds for a normal image to appear.

English

Setting Up the Parental

Sandi

Password

Cancel

Control

The Parental Control function works in conjunction with DVDs that have been assigned a rating, which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc.

Setting Up the Rating Level

1. Press the MENU button.

2. Press the

3. Press the /buttons to select Parental, then press the

¦¦/

then press the



or ENTER button.

buttons to select parental setup page,



or ENTER button.

.. Parental Page ..

Parental Password

Note

❶ KID SAFE ❷

G(General Audiences) : All Ages Admitted

❸

PG(Parental Guidance suggested): Some material may not be suitable for young children.

❹

PG-13 (PG-13-Parents strongly cautioned) : Some material may be inapproriate for children under 13

❺

PGR ( parental guidance Recommended): These are not necessarily unsuitable for children, but viewer discretion is advised, and parents and guardians are encouraged to supervise younger viewers.

❻

R( Restricted): Under 17 requires accompanying adult

❼

NC17( NC-17) : No one 17 and under admitted

❽

Adult

Note

•

To make the setup menu disappear, press the MENU button.

Changing the Password

1. Press the MENU button.

2. Press the

¦¦/

then press the

buttons to select parental setup page,



or ENTER button.

4. Press the /buttons to select the Rating Level you want, then press the ENTER button. e.g) Setting up in KID SAFE

.. Parental Page .. Parental Password

1 KID SAFE 2 G 3 PG 4 PG 13 5 PGR 6 R 7 NC17 8 ADULT

5. Enter your password.

- By default, password is set to 0000.

.. Parental Page .. Parental Password

/

3. Press the press the

buttons to select PASSWORD, then



or ENTER button.

.. Parental Page ..

Parental

Password

4. The Enter password screen appear. Enter your pasword (default password), Enter the new password again

.. Parental Page .. Parental

Password

Change

Note

If you have forgotten your password, see “Forgot Password” in the Troubleshooting Guide.

English

REFERENCE

SELECT MENU LANGUAGE

REFERENCE

Firmware upgrade

Introduction

Samsung will often support the software upgrade to improve the performance of this unit to the lastest status , trough samsung Internet Site(www.samsung.com)

Because the specially new mpeg4 codec continuse and it is appearing.What improvements are made depends on the upgrade software your are using as well as the software that your DVD-player contained before the upgrde.

How to make an upgrade disc

Write the downloaded file onto a blank CD-R or CDRW disc, using the following settings:

You have to download a new file trough Download center of Samsung Internet Site (http://www.sam sung.com).

Write the file to disc using CD-RW driver of your computer.

Note

- File system CD-ROM

- Chracteer set ISO 9660

- Finalized, single session

- Write speed low

Update procedure

1.Open the disc tray. Place disc the on the tray. close the tray. The Firm ware Upgrade sreen appears.

Upgrade file detected Curent version: 07.12.15.00 Upgrade ? Press Play to start

2.Press enter or play to start upgrade.

- Other key to cancel upgrade back to samsung logo and eject the disc.

Upgrade file detected Curent version: 07.12.15.00 Upgrade ? Press Play to start File copying

Firmware upgrade Start

Upgrade file detected Curent version: 07.12.15.00 Upgrade ? Press Play to start Upgrade

Firmware upgrade Start

- In the middle of the writing, the tray will open automatically. After taking out the disc, please wait for about 2 minutes.

- If the unit was succesfully update, the unit will turn off and on after closing the tray automatically. When the unit turns on, this screen will display.

3.Press the number buttons to select the desired language

Press 1 for English

Touche 2 pour Français

Drücken Sie 3 für Deutsch

Pulsar 4 para Español

Premere 5 per Italiano

Druk op 6 voor Nederlands

Note

- If the “Select Menu Language”doesn’t appear,

please contact to “Samsung Service Center- If the unit was succesfully update, the unit will

turn off and on after closing the tray automatical

- Do not press any button and plug the power code during upgrade.

- The upgrade procedure may change, refer to the web site( www.samsung.com)

Firmware upgrade

Appears

Troubleshooting

Before requesting service (troubleshooting), please check the following.

Problem

No operations can be performed with the remote control.

Disc does not play.

5.1 channel sound is not being reproduced.

The icon appears on screen.

Disc Menu doesn’t appear.

Play mode differs from the Setup Menu selection.

The screen ratio cannot be changed.

No audio.

The screen is blocked

Forgot password

Action

• Check the batteries in the remote control. They may need replacing.

• Operate the remote control at a distance of no more than 20 feet.

• Remove batteries and hold down one or more buttons for several minutes to drain

the microprocessor inside the remote control to reset it. Reinstall batteries and try to operate the remote control again.

• Ensure that the disc is installed with the label side facing up.

• Check the region number of the DVD.

• 5.1 channel sound is reproduced only when the following conditions are met. :

1) The DVD player is connected with the proper Amplifier

2) The disc is recorded with 5.1 channel sound.

• Check whether the disc being played has the “5.1 ch” mark on the outside.

• Check if your audio system is connected and working properly.

• In a SETUP Menu, is the Audio Output set to Bitstream?

• The features or action cannot be completed at this time because:

1. The DVD’s software restricts it.

2. The DVD’s software doesn’t support the feature (e.g., angles).

3. The feature is not available at the moment.

4. You’ve requested a title or chapter number or search time that is out of range.

• Check if the disc has a Menu.

• Some of the functions selected in the Setup Menu may not work properly if the

disc is not encoded with the corresponding function.

• The Screen Ratio is fixed on your DVDs.

• Make sure you have selected the correct Digital Output in the Audio Options

Menu.

•

Press the button (in front panel) for more than 5 seconds under no disc

inside. All settings will revert to the factory settings.

• Press the button

under no disc inside. All settings including the password will revert to the factory settings. Don't use this unless absolutely necessary.

(in front panel )

for more than 5 seconds

Page

English

P12-13

P24-25

P22-27

P25

P24-25

P14

P26

If you experience other problems.

The picture is noisy or distorted

• Go to the contents and find the section of the instruction book that contains the

explanations regarding the current problem, and follow the procedure once again.

• If the problem still cannot be solved, please contact your nearest authorized ser-

vice center.

• Make sure that the disc is not dirty or scratched.

• Clean the disc.

Specifications

General

Disc

Video

Output

Audio

Output

Power Requirements

Power Consumption

Weight

Dimensions

Operating Temperature Range

Operating Humidity Range

DVD

(DIGITAL VERSATILE DISC)

CD : 12Cm

(COMPACT DISC)

CD : 8Cm

(COMPACT DISC)

VCD : 12Cm

Composite Video

Component Video

2 Channel

*Frequency Response

*S/N Ratio

*Dynamic Range

*Total Harmonic Distortion

AC 110-240 V, 50/60 Hz

9 W

1.3 Kg

360mm (W) X 200mm (D) X 37mm (H)

+5°C to +35°C

10 % to 75 %

Reading Speed : 3.49 ~ 4.06 m/sec. Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.

Reading Speed : 4.8 ~ 5.6 m/sec. Maximum Play Time : 74 min.

Reading Speed : 4.8 ~ 5.6 m/sec. Maximum Play Time : 20 min.

Reading Speed : 4.8 ~ 5.6 m/sec. Maximum Play Time : 74 min. (Video + Audio)

1 channel : 1.0 Vp-p (75 Ω load)

Y : 1.0 Vp-p (75 Ω load) Pr : 0.70 Vp-p (75 Ω load) Pb : 0.70 Vp-p (75 Ω load)

L(1/L), R(2/R)

48 kHz Sampling : 4 Hz to 22 kHz 96 kHz Sampling : 4 Hz to 44 kHz

110 dB

100 dB

0.004 %

*: Nominal specification

- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.

- Weight and dimensions are approximate.

Contact SAMSUNG WORLD WIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer

center

care

Region Country Customer Care Center  Web Site

North America

Latin America

Europe

CIS

Asia Paciﬁ c

Middle East &

Africa

CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com ARGENTINE 0800-333-3733 www.samsung.com/ar BRAZIL 0800-124-421 , 4004-0000 www.samsung.com CHILE 800-SAMSUNG(726-7864) www.samsung.com/cl NICARAGUA 00-1800-5077267 HONDURAS 800-7919267 COSTA RICA 0-800-507-7267 www.samsung.com/latin ECUADOR 1-800-10-7267 www.samsung.com/latin EL SALVADOR 800-6225 www.samsung.com/latin GUATEMALA 1-800-299-0013 www.samsung.com/latin JAMAICA 1-800-234-7267 www.samsung.com/latin PANAMA 800-7267 www.samsung.com/latin PUERTO RICO 1-800-682-3180 www.samsung.com/latin REP. DOMINICA 1-800-751-2676 www.samsung.com/latin TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) www.samsung.com/latin VENEZUELA 0-800-100-5303 www.samsung.com/latin COLOMBIA 01-8000112112 www.samsung.com.co BELGIUM 0032 (0)2 201 24 18 www.samsung.com/be

CZECH REPUBLIC

DENMARK 70 70 19 70 www.samsung.com/dk FINLAND 030-6227 515 www.samsung.com/ﬁ

FRANCE

GERMANY HUNGARY 06-80-SAMSUNG(726-7864) www.samsung.com ITALIA 800-SAMSUNG(726-7864) www.samsung.com LUXEMBURG 0035 (0)2 261 03 710 www.samsung.com/be NETHERLANDS NORWAY 815-56 480 www.samsung.com/no POLAND 0 801 801 881 , 022-607-93-33 www.samsung.com/pl PORTUGAL 80820-SAMSUNG(726-7864) www.samsung.com/pt SLOVAKIA 0800-SAMSUNG(726-7864) www.samsung.com/sk SPAIN 902 10 11 30 www.samsung.com SWEDEN 0771-400 200 www.samsung.com/se U.K 0845 SAMSUNG (7267864) www.samsung.com EIRE 0818 717 100 www.samsung.com/ie AUSTRIA 0800-SAMSUNG(726-7864) www.samsung.com/at SWITZERLAND 0800-SAMSUNG(726-7864) www.samsung.com/ch RUSSIA 8-800-555-55-55 www.samsung.com KAZAHSTAN 8-10-800-500-55-500 www.samsung.kz UZBEKISTAN 8-10-800-500-55-500 www.samsung.uz KYRGYZSTAN 00-800-500-55-500 TADJIKISTAN 8-10-800-500-55-500 UKRAINE 8-800-502-0000 www.samsung.com LITHUANIA 8-800-77777 www.samsung.lt LATVIA 800-7267 www.samsung.com/lv ESTONIA 800-7267 www.samsung.ee AUSTRALIA 1300 362 603 www.samsung.com NEW ZEALAND 0800SAMSUNG(726-7864) www.samsung.com/nz CHINA 800-810-5858 , 010-6475 1880 www.samsung.com HONG KONG 3698-4698 www.samsung.com/hk INDIA 3030 8282 , 1800 110011 www.samsung.com INDONESIA 0800-112-8888 www.samsung.com JAPAN 0120-327-527 www.samsung.com/jp MALAYSIA 1800-88-9999 www.samsung.com/my PHILIPPINES 1800-10-SAMSUNG(726-7864) www.samsung.com/ph SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com THAILAND 1800-29-3232 , 02-689-3232 www.samsung.com TAIWAN 0800-329-999 www.samsung.com/tw VIETNAM 1 800 588 889 www.samsung.com TURKEY 444 77 11 www.samsung.com SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com U.A.E 800-SAMSUNG (726-7864), 8000-4726

844 000 844 Distributor pro Českou republiku: Samsung Zrt., česka organizační složka Vyskočilova 4, 14000 Praha 4

3260 SAMSUNG ( 08 25 08 65 65 ( 01805 - SAMSUNG(726-7864) ( 0,14/Min)

0900-SAMSUNG(726-7864) ( 0,10/Min)

0,15/Min),

0,15/Min)

www.samsung.com/cz

www.samsung.com

www.samsung.com/nl

www.samsung.com

If you have any questions or comments relating to Samsung products,

☎

Contact SAMSUNG WORLD WIDE

please contact the SAMSUNG customer care centre.

1800-10-SAMSUNG(726-7864)/ www.samsung.com/ph

AK68-01690G

Samsung P181K, 525p User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PRECAUTIONS

SETUP

General Features

Disc Type and Characteristics

Description

Tour of the Remote Control

CONNECTIONS

Choosing a Connection

Playing a Disc

Using the Search and Skip Functions

Using the Disc and Title Menu

Using the Display Function

Repeat Play

Slow Play

Adjusting the Aspect Ratio (EZ View)

Selecting the Audio Language

Selecting the Subtitle Language

Using the Bookmark Function

Changing the Camera Angle

Using the Zoom Function

Clips Menu for MP3/WMA/JPEG/CD Audio/MPEG4

Folder Selection

MP3/WMA/CD Audio Playback

MPEG4 Playback

Picture CD Playback

Karaoke Functions

Using the Setup Menu

Setting Up the Language Features

Setting Up the Audio Options

Setting Up the Display Options

REFERENCE

Firmware upgrade

Troubleshooting

Specifications
