Samsung NX10RW5VA0, X10 XTC 1700, X10 XTC 1300 RETAIL, X10 XTC 1500 II, X10 XTC 1300 II User Manual

Notices

1.1

No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical photocopying, recording or
otherwise, without the prior written permission of the manufacturer.

The information within this manual is subject to change without notice.

The manufacturer shall not be held liable for technical or editorial errors or omissions
contained in herein; nor for incidental or consequential damages resulting from the

furnishing, performance or use of this material.

Microsoft Windows is a registered trademark of the Microsoft Corporation.

Product names mentioned herein are for identification purposes only, and may be
trademarks and/or registered trademarks of their respective companies.

Macrovision Statement

If your computer has a DVD drive and an analog TV Out port, the following
paragraph applies:

This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

Copyright 2003 All rights are reserved

Notices i

Important Safety Information

Safety Instructions

Your system is designed and tested to meet the latest standards for safety of
information technology equipment. However, to ensure safe use of this product, it is
important that the safety instructions marked on the product and in the documentation
are followed.

Always follow these instructions to help guard against personal injury and
damage to your system.

i

Setting Up your System

• Read and follow all instructions marked on the product and in the

documentation before you operate your system. Retain all safety and operating
instructions for future use.

• Do not use this product near water or a heat source such as a radiator.

• Set up the system on a stable work surface.

• The product should be operated only with the type of power source indicated on

the rating label.

• Ensure that the electrical outlet you are using to power your equipment is easily

accessible in case of fire or short circuit.

• If your computer has a voltage selector switch, make sure that the switch is in

the proper position for your area.

• Openings in the computer case are provided for ventilation. Do not block or

cover these openings. Make sure you provide adequate space, at least 6 inches
(15 cm), around the system for ventilation when you set up your work area.
Never insert objects of any kind into the computer ventilation openings.

• Ensure that the fan vents on the bottom of the casing are clear at all times. Do

not place the computer on a soft surface, doing so will block the bottom vents.

• If you use an extension cord with this system, make sure that the total ampere

rating on the products plugged into the extension cord does not exceed the
extension cord ampere rating.

ii Users Manual

Care During Use

• Do not walk on the power cord or allow anything to rest on it.

• Do not spill anything on the system. The best way to avoid spills is to not eat or

drink near your system.

• Some products have a replaceable CMOS battery on the system board. There is

a danger of explosion if the CMOS battery is replaced incorrectly. Replace the
battery with the same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturer’s instructions. If the CMOS
battery requires replacement insure that a qualified technician performs the task

• When the computer is turned off, a small amount of electrical current still flows

through the computer. To avoid electrical shock, always unplug all power
cables, remove the battery and modem cables from the wall outlets before
cleaning the system.

• Unplug the system from the wall outlet and refer servicing to qualified

personnel if:

– The power cord or plug is damaged.
– Liquid has been spilled into the system.
– The system does not operate properly when the operating instructions are

followed.
– The system was dropped or the casing is damaged.
– The system performance changes.

Replacement Parts and Accessories

Use only replacement parts and accessories recommended by manufacturer.

To reduce the risk of fire, use only No. 26 AWG or larger telecommunications

line cord.

Do not use this product in areas classified as hazardous. Such areas include

patient care areas of medical and dental facilities, oxygen rich environments,

Writtenby:DarylL. Osden

or industrial areas.

Battery Disposal

Do not put rechargeable batteries or products powered by non-removable

rechargeable batteries in the garbage.

Contact the Samsung Helpline for information on how to dispose of batteries that you
cannot use or recharge any longer.

Follow all local regulations when disposing of old batteries.

Important Safety Information iii

Laser Safety

All systems equipped with CD or DVD drives comply with the appropriate safety
standards, including IEC 825. The laser devices in these components are classified as
“Class 1 Laser Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact
an authorized service location.

Laser Safety Note:

Use of controls or adjustments or performance of procedures other than those

specified in this manual may result in hazardous radiation exposure. To

prevent exposure to laser beams, do not try to open the enclosure of a CD or

DVD drive.

Power Cord Requirements

The power cord set (wall plug, cable and AC adapter plug) you received with your
computer meets the requirements for use in the country where you purchased your
equipment.

Power cord sets for use in other countries must meet the requirements of the country
where you use the computer. For more information on power cord set requirements,
contact your authorized dealer, reseller, or service provider.

General Requirements

The requirements listed below are applicable to all countries:

• The length of the power cord set must be at least 6.00 feet (1.8m) and a

maximum of 9.75 feet (3.0m).

• All power cord sets must be approved by an acceptable accredited agency

responsible for evaluation in the country where the power cord set will be used.

• The power cord set must have a minimum current capacity of 7 A and a

nominal voltage rating of 125 or 250 volts AC, as required by each country’s
power system.

• The appliance coupler must meet the mechanical configuration of an EN 60

320/IEC 320 Standard Sheet C7 connector, for mating with appliance inlet on
the computer.

iv Users Manual

Regulatory Compliance Statements

Wireless Guidance

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. The following section is a general overview of considerations while operating
a wireless device.

Additional limitations, cautions, and concerns for specific countries are listed in the
specific country sections (or country group sections). The wireless devices in your
system are only qualified for use in the countries identified by the Radio Approval
Marks on the system rating label. If the country you will be using the wireless device
in, is not listed, please contact your local Radio Approval agency for requirements.
Wireless devices are closely regulated and use may not be allowed.

The power output of the wireless device or devices that may be embedded in your
notebook is well below the RF exposure limits as known at this time. Because the
wireless devices (which may be embedded into your notebook) emit less energy than
is allowed in radio frequency safety standards and recommendations, manufacturer
believes these devices are safe for use. Regardless of the power levels, care should be
taken to minimize human contact during normal operation.

As a general guideline, a separation of 20 cm (8 inches) between the wireless device
and the body, for use of a wireless device near the body (this does not include
extremities) is typical. This device should be used more than 20 cm (8 inches) from the
body when wireless devices are on and transmitting.

This transmitter must not be collocated or operate in conjunction with any other
antenna or transmitter.

Some circumstances require restrictions on wireless devices. Examples of common
restrictions are listed below:

Radio frequency wireless communication can interfere with equipment on

commercial aircraft. Current aviation regulations require wireless devices to be

turned off while traveling in an airplane. 802.11B (also known as wireless

Ethernet or Wifi) and Bluetooth communication devices are examples of

devices that provide wireless communication.

Regulatory Compliance Statements v

In environments where the risk of interference to other devices or services is

harmful or perceived as harmful, the option to use a wireless device may be

restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas

laden atmospheres are limited examples where use of wireless devices may

be restricted or eliminated. When in environments where you are uncertain of

the sanction to use wireless devices, ask the applicable authority for

authorization prior to use or turning on the wireless device.

Every country has different restrictions on the use of wireless devices. Since

your system is equipped with a wireless device, when traveling between

countries with your system, check with the local Radio Approval authorities

prior to any move or trip for any restrictions on the use of a wireless device in

the destination country.

If your system came equipped with an internal embedded wireless device, do

not operate the wireless device unless all covers and shields are in place and

the system is fully assembled.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Please

contact manufacturer for service.

Only use drivers approved for the country in which the device will be used. See

the manufacturer System Restoration Kit, or contact manufacturer Technical

Support for additional information.

vi Users Manual

United States of America

Unintentional Emitter per FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device pursuant to Part 15 of the FCC Rules. These limits are

Writtenby:DarylL. Osden

If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet helpful:
“Something About Interference.” This is available at FCC local regional offices. Our
company is not responsible for any radio or television interference caused by
unauthorized modifications of this equipment or the substitution or attachment of
connecting cables and equipment other than those specified by our company. The
correction will be the responsibility of the user. Use only shielded data cables with this
system.

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generate uses and can radiate radio

frequency energy and if not installed and used in accordance with the

instructions may cause harmful interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Intentional emitter per FCC Part 15

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the United
States of America if an FCC ID number is on the system label.

Regulatory Compliance Statements vii

The FCC has set a general guideline of 20 cm (8 inches) separation between the device
and the body, for use of a wireless device near the body (this does not include
extremities). This device should be used more than 20 cm (8 inches) from the body
when wireless devices are on. The power output of the wireless device (or devices),
which may be embedded in your notebook, is well below the RF exposure limits as set
by the FCC.

This transmitter must not be collocated or operate in conjunction with any other
antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation of the device.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Contact

manufacturer for service.

FCC Statement for Wireless LAN use:

“While installing and operating this transmitter and antenna combination the

radio frequency exposure limit of 1mW/cm2 may be exceeded at distances

close to the antenna installed. Therefore, the user must maintain a minimum

distance of 20cm from the antenna at all times. This device can not be

colocated with another transmitter and transmitting antenna.”

FCC Part 68

This equipment compiles with part of the FCC rules. On the back of this equipment is
a label that contains, among other information, the FCC registration number and ringer
equivalence number (REN) for this equipment. If requested, this information must be
provided to the telephone company.

This equipment uses the following USOC jacks : RJ11C

An FCC compliant telephone cord and modular plug is provided with this equipment.
This equipment is designed to be connected to the telephone network or promises
wiring using a compatible modular jack which is Part 68 compliant. See Installation
Instructions for details.

The REN is used to determine the quantity of devices which may be connected to
telephone line. Excessive RENs on the telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by total RENs, contact the local telephone company
to determine the maximum REN for the calling area.

viii Users Manual

If the terminal equipment causes harm to the telephone network, the Telephone
Company will notify you in advance that temporary discontinuance of service may be
required. But if advance notice is not practical, the telephone company will notify the
customer as soon as possible. Also, you will be advised of your right to file a complaint
with the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If this happens, the
telephone company will provide advanced notice in order for you to make necessary
modifications to maintain uninterrupted service.

If trouble is experienced with this equipment (Modem) for repair or warranty
information, please contact your local distributor. If the equipment is causing harm to
the telephone network, the telephone company may request that you disconnect the
equipment until the problem is resolved.

The user must use the accessories and cables supplied by the manufacturer to get
optimum performance from the product.

No repairs may be done by the customer.

This equipment cannot be used on public coin phone service provided by the telephone
company. Connection to party line service is subject to state tariffs.

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to
use a computer or other electronic device, including fax machines, to send any message
unless such message clearly contains in a margin at the top or bottom of each
transmitted page or on the first page of the transmission, the date and time it is sent and
an identification of the business or other entity, or other individual sending the message
and the telephone number of the sending machine or such business, other entity, or
individual. (The telephone number provided may not be any number for which charges
exceed local or long-distance transmission charges.)

In order to program this information into your fax machine, refer to your
communications software user manual.

Regulatory Compliance Statements ix

Canada

Unintentional Emitter per ICES-003

This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the radio interference regulations of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limitesapplicables aux appareils numériques de Classe B prescrites dans le règlement
sur le brouillage radioélectrique édicté par Industrie Canada.

Intentional Emitter per RSS 210

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in Canada if an
Industry Canada ID number is on the system label.

As a general guideline, a separation of 20 cm (8 inches) between the wireless device
and the body, for use of a wireless device near the body (this does not include
extremities) is typical. This device should be used more than 20 cm (8 inches) from the
body when wireless devices are on.

The power output of the wireless device (or devices), which may be embedded in your
notebook, is well below the RF exposure limits as set by Industry Canada.

This transmitter must not be collocated or operate in conjunction with any other
antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation of the device.

x Users Manual

To prevent radio interference to licensed service, this device is intended to be

operated indoors and away from windows to provide maximum shielding.

Equipment (or its transmit antenna) that is installed outdoors is subject to

licensing.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Contact

manufacturer for service.

Telecommunications per DOC notice (for products fitted with an IC-compliant modem)

The Industry Canada label identifies certified equipment. This certification means that
the equipment meets certain telecommunications network protective, operation, and
safety requirements. The Department does not guarantee the equipment will operate to
the users’ satisfaction.

Before installing this equipment, users should make sure that it is permissible to be
connected to the facilities of the local telecommunications company. The equipment
must also be installed using an acceptable method of connection. In some cases, the
inside wiring associated with a single-line individual service may be extended by
means of a certified connector assembly. The customer should be aware that
compliance with the above conditions may not prevent degradation of service in some
situations.

Repairs to certified equipment should be made by an authorized Canadian maintenance
facility designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company
cause to request the user to disconnect the equipment.

Users should make sure, for their own protection, that the electrical ground connections
of the power utility, telephone lines, and internal metallic water pipe system, if present,
are connected together. This precaution may be particularly important in rural areas.

To avoid electrical shock or equipment malfunction do not attempt to make

electrical ground connections by yourself. Contact the appropriate inspection

authority or an electrician, as appropriate.

The Ringer Equivalence Number (REN) assigned to each terminal device provides
an indication of the maximum number of terminals allowed to be connected to a
telephone interface. The termination on an interface may consist of any combination of
devices subject only to the requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5.

Regulatory Compliance Statements xi

European Union

The following information is only applicable to systems labeled with the CE mark .

European Directives

This Information Technology Equipment has been tested and found to comply with the

following European directives:

• EMC Directive 89/336/EEC with amending directives 92/31/EEC & 93/68/

EEC as per

– EN 55022 Class B

– EN 61000-3-2

– EN 61000-3-3

– EN 55024

• Low Voltage Directive (Safety) 73/23/EEC as per EN 60950(A1/A2/A3/A4/

A11)

• Radio and Telecom Terminal Equipment Directive 199/5/EC as per

– CTR21 (if fitted with a modem device)

– ETS 300 328 (if fitted with a 2.4 GHz band embedded wireless device)

– ETS 301 489-1 (if fitted with a 2.4 GHz band embedded wireless device)

– ETS 301 489-17 (if fitted with a 2.4 GHz band embedded wireless device)

European Radio Approval Information (for products fitted with EU-approved radio devices)

This Product is a Notebook computer; low power, Radio LAN type devices (radio
frequency (RF) wireless communication devices), operating in the 2.4 GHz band, may
be present (embedded) in your notebook system which is intended for home or office
use. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the European
Union or associated areas if a CE mark with a Notified Body Registration Number
and the Alert Symbol is on the system label.

The power output of the wireless device or devices that may be embedded in you
notebook is well below the RF exposure limits as set by the European Commission
through the R&TTE directive.

xii Users Manual

European States qualified under wireless approvals:

EU

Austria, Belgium, Denmark, Finland, France (with frequency
restrictions),

Germany, Greece, Ireland, Italy, Luxembourg, The

Netherlands, Portugal, Spain, Sweden and the United Kingdom.

Accept EU

Iceland, Liechtenstein, Norway and Switzerland

European States with restrictions on use:

EU

In France, the frequency range is restricted to 2446.5-2483.5 MHz for
devices above 10 mW transmitting power such as wireless LAN.

Accept EU No limitations at this time.

European Telecommunication Information (for products fitted with EU-approved modems)

Marking by the symbol indicates compliance of this equipment to the Radio and
Telecom Terminal Equipment Directive 1999/5/EC. Such marking is indicative that
this equipment meets or exceeds the following technical standards:

CTR 21 – Attachment requirements for pan-European approval for connection to the
analogue Public Switched Telephone Networks (PSTNs) of TE (excluding TE
supporting voice telephony services) in which network addressing, if provided, is by
means of Dual Tone Multi-Frequency (DTMF) signaling.

Although this equipment can use either loop disconnect (pulse) or DTMF

(tone) signaling, only the performance of the DTMF signaling is subject to

regulatory requirements for correct operation. It is therefore strongly

recommended that the equipment is set to use DTMF signaling for access to

public or private emergency services. DTMF signaling also provides faster call

setup.

This equipment has been approved to Council Decision 98/482/EEC—“CTR 21” for
Pan-European single terminal connection to the Public Switched Telephone Network
(PSTN).

However, due to differences between the individual PSTNs provided in different
countries, the approval does not, of itself, give an unconditional assurance of
successful operation on every PSTN termination point. In the event of problems, you
should contact manufacturer Technical Support.

Regulatory Compliance Statements xiii

Japan

VCCI Statement

This equipment is in the Class B category (Information Technology Equipment to be
used in a residential area or an adjacent area thereto) and conforms to the standards set
by the Voluntary Control Council for Interference by Information Technology
Equipment aimed at preventing radio interference in such residential areas. When used
near a radio or TV receiver, it may become the cause of radio interference. Read
instructions for correct handling.

Wireless Devices

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in Japan if a
TELEC ID is on the system label.

Operational guidelines for 2.4 GHz band wireless equipment (if equipped)

This equipment uses the 2.4 GHz ISM frequency band. The ISM band is the industrial,
scientific, and medical device band. Devices that might also use this band are
microwave ovens, other LAN devices, amateur radio stations, licensed premises radio
stations, and non-licensed specified low-power radio stations.

xiv Users Manual

Prior to setting up your device:

1. Make sure that there are no other devices in your area using the same frequency

band.

2. Change the channel, location, or discontinue device use if you are interfering with
any other radio station.

3. Contact manufacturer if you have any problems with this device.

Regulatory Compliance Statements xv

Using Your Documentation

Congratulations on your purchase of a notebook computer with the Windows® XP
operating system. Whether you are new to using a portable computer or are an
experienced user, this user’s manual can help you get the most from your computer.

Manual Documentation Conventions

Information Icons

Three icons and their associated messages appear in this manual. The information
icons are placed before the step/information they apply to:

Warning:

Indicates the possibility of personal injury.

Caution:

Warns you of possible damage to equipment or data.

Note:

Informs you of special circumstances.

Technical Information:

Informs you of special requirements or limitations for use of item(s).

Keyboard Conventions

Keys that you need to press to perform certain functions are displayed in the manual in
brackets. For example:

<Ctrl> indicates the control key (Ctrl on the keyboard).

If you need to press two keys at the same time, the key names are shown joined by a
plus sign. For example:

<Fn+F8> means that you should press the Fn key and hold it and then press the F8
key.

Using Your Documentation 1

CD-ROM Device Naming Convention

In many installation programs you will have to get a program from the CD-ROM
device. The program installation sequence assumes that the CD is drive d:\, however
this is not always the case. The name of the CD-ROM drive is the letter following the
letter assigned to your last HDD. For instance, if you have one HDD with two
partitions, the HDD is drives C: and D: and the CD-ROM drive is then drive E.

Touchpad Conventions

You may be asked to click or double-click on items on the display screen. As a general
note the touchpad actions act much in the same way as a wheel mouse, any differences
are explained fully.

The object that needs to be clicked upon will be displayed in Bold text or shown in a
small figure such as the “Start Button” shown on the right =>.

Table 1. Touchpad Click Conventions

Action Process

Click Depress the touchpad left button and release

Double-click Quickly click the left touchpad button two times

Windows Conventions:

Almost all “Windows” programs will display the name/function of a button or
icon if you place the touchpad pointer on the item you want information about.

Software User Documentation

Your computer is shipped from the factory with several software programs installed.
The software may include its own online or printed documentation. Refer to the
documentation or the Help options in the software for more information.

The figures and illustrations in this manual may not be identical to those on
your system.

General Icon Note:

Some of the Icons used in Windows XP may be placed on the taskbar by
selecting (ex: Place the volume icon in the taskbar) in the properties dialog
box.

2 Users Manual

Introducing Your Computer

Your computer is a lightweight portable computer that includes following features to
meet your computing needs at home or on the road:

- Home Theater System Support (dependant on configuration)

- CD-RW/DVD-ROM Combo Drive

Factory options (Figures may be different depending on options)

- Fingerprint recognition system - Memory Stick

- Wireless LAN (802.11b) - Bluetooth

Where Everything Is

The next section will explain the location of all of the buttons, LEDs and equipment
needed to operate your notebook computer.

Front

LCD Cover Latch

Scroll Wheel/

Fingerprint Sensor

* Either fingerprint sensor
or scroll wheel is installed
depending on factory
configuration.

Speaker

Memory Stick Slot (option)

SENS Keyboard Buttons

LEDs

Power Button

Keyboard

Touchpad

Touchpad Buttons

Speaker

LEDs

Introducing Your Computer 3

Right Side

Fan Vent

Earphone Jack

Left Side

Modem Port LAN Port

Back Side

Microphone Jack

VGA Port

CD-RW/DVD-ROM
Combo Drive

USB Port PCMCIA Slot

USB Port

1394 Port

TV-Out
Port
(S-VHS)

S/PDIF Jack

4 Users Manual

DC Jack

Battery

Security Lock Port

Bottom

Battery Latches

Mini-PCI

Compartment*

HDD

Compartment

* Wireless communication module(option) is installed in the mini PCI compartment.

Memory
Compartment

Introducing Your Computer 5

Using Your Computer for the First Time

This section gives you detailed information on using your computer for the first time.

Turning On the Computer

To turn on the computer’s power for the first time:

1. Install the battery and connect the AC adapter according to the Installation Guide.

2. Slide the LCD cover latch to the right.

3. Lift up the cover.

4. Press and then release the power button.

The power LED is on when the computer’s power is on.

Power
Button

6 Users Manual

LCD Cover Latch

Power LED

Initial Computer Startup:

The first time you start your computer you will see the operating system
registration screens. Simply read each screen and follow the simple directions.
You must complete this process in order to use your computer. A tutorial is
provided if you require it.

Turning Off Your Computer

Prior to shutting down your computer ensure all of your data and current work are
saved. The system will ask if you wish to save any unsaved work, saving your work
first will speed the shutdown process.

To turn off the computer, complete the following steps:

1. Click on the taskbar.

If you need to restart your computer after software (re)installation or because it is
not responding select the Restart option in step 3 below.

2. Click Shut Down Computer to display the shutdown popup window shown
below.

3. Click Turn Off to complete the shutdown sequence.

Power Off:

If the system does not power off, then press and hold the power button for over
4 seconds. See ”Using Power Management Options” on page 66.

Power Button Functions:

The power button has several functions other than just turning on and off your
computer, see “Using Power Management Options” on page 66.

You can also perform a soft boot by saving your files and pressing
<Ctrl+Alt+Del> to pop-up the “Windows Task Manager” window.
Click Shut Down > Restart.

You can perform a cold boot by pressing the power button for more than 4 seconds to
turn the computer off, waiting more than five seconds, and then pressing the power
button to turn the computer on. The system may perform some extra checks during the
restart.

Using Your Computer for the First Time 7

Tips for Using Your Computer

The following information helps you avoid potential problems as you use your
computer:

Do not try to disassemble your computer. Opening the system chassis voids
your warranty. Only an authorised manufacturer service center can replace or
add any parts inside the chassis.

• Follow all the instructions and cautions in your computer user documentation.

• The LCD has a polarized surface and can be damaged easily. To prevent

damage, avoid touching the screen.

• Use only approved AC adapters, auto adapters, memory modules and other

options.

• Because a notebook computer is small and has restricted air flow around

components, it is more likely to overheat than a desktop computer. A fan inside
your computer runs when needed to help eliminate heat. Make sure the fan vent
on the left side of your computer is not blocked when you use the computer.
Occasionally check the vents and remove any accumulated dust on the outside.

• Avoid using or storing the computer in extremely hot or cold areas, such as a

car on a hot day. Keep the computer away from heaters and out of direct
sunlight. Exposure to excessive heat may damage computer components. If you
have left your computer in a hot place, let it cool down slowly to room
temperature (with the LCD panel open) before using it.

• Do not remove the memory-module compartment door, or try to install a

memory module when the computer is on. (For information on installing
memory modules, see “Installing a Memory Module” on page 80.)

• Set up your computer work area to avoid physical strain. Sit with your back

straight and supported by your chair. Adjust your chair or work table so that
your arms and wrists can remain in a relaxed position, parallel with the floor.
Avoid bending or twisting your wrists as you work. Your hands should “float”
slightly above the keyboard. Refer to a book on office ergonomics for more
information on setting up your work area.

• Take frequent breaks from working at the computer to rest your eyes and

stretch your muscles.

• Remember to save your data files frequently and to make backup copies of your

files.

8 Users Manual

Travelling with Your Computer

Air Travel

If you are travelling by air, follow these tips:

• Take the computer with you as carry-on luggage. Do not check the computer

with your baggage.

• Allow the computer and disks to go through the X-ray security devices. Do not

hand-carry disks through the walk-through metal detectors, which can cause
loss of data.

• Make sure that the battery is charged or the power cord is easily accessible.

You may be required to turn on the computer for airport security personnel.

• Be prepared to turn off the computer during take off and landing.

Locking your Computer

As a precaution when you are travelling or using your computer in an unsecured area,
you should keep your computer as safe as possible. An option to do this is the Security
Lock System. Follow the Security Lock System manufacturers instructions for specific
installation and use. The following figure shows generally how to use the lock.

Using Your Computer for the First Time 9

Handling Spills

Do not spill anything on your computer. The best way to avoid spills is to avoid eating
and drinking around your computer. If you do spill something on your computer, turn
off your computer, unplug it immediately, and do the following:

• If you spill liquid on the keyboard, drain as much of the liquid from the

keyboard as possible. Be careful not to let the liquid drip onto the LCD panel.
Allow the system to dry for several days before trying to use it.

• If you spill liquid on an external keyboard or keypad, unplug it and drain as

much of the liquid as possible. Allow the keyboard to sit at room temperature
for a full day before trying to use it.

Sweet liquids leave a sticky residue that may jam the keyboard despite your
efforts to dry it.

• If you spill liquid on the LCD panel, clean it immediately with a soft cloth and

denatured alcohol or a proprietary LCD screen cleaner. Do not use water,
window cleaner, acetone, aromatic solvent, or dry, rough towels to clean it.

Some liquids damage the polarized LCD screen. If your screen is damaged,
contact your authorized manufacturer’s service center for a replacement.

Storing the Computer for Long Periods

If possible, leave the power cord connected to the computer and an electrical outlet
when the computer is not in use. This extends the life of the battery and keeps the
battery fully charged.

If you will not be using the computer for a long period of time (a month or more), you
should charge the battery until it is completely full. After you have done so, remove the
battery from the unit.

10 Users Manual

Using the Keyboard

Your computer has an 87/88-key keyboard. By pressing designated key combinations,
you can have access to all the key functions of a full-sized keyboard.

Function & Special Purpose Keys

Function

Key

Windows

Key

Embedded Numeric Keypad

Although the layout of the keys on your computer’s keyboard is different from
that on a desktop computer’s keyboard, the keyboard feels like a full-sized
keyboard when you use it.

Application Key

The keys on the keyboard can be grouped into the following categories:

• Full-sized Alphanumeric typewriter keys are arranged like a standard

typewriter keyboard and are used for text entry. The Windows keys on either
side of the spacebar open Windows menus and perform other special functions.

• Function keys, when pressed together with the <Fn> key, enable special

functions.

• Cursor and Screen control keys move the cursor. They may perform other

functions, depending on your software.

Using the Keyboard 11

Cursor/Screen

Control Keys

To clean the computer keyboard, use slightly damp cotton swabs. Scrub the keys and
the surface around the keys.

Do not allow liquid to drip into the keyboard or you may damage the keyboard.

Using the Numeric Keypad

Your keyboard includes a numeric keypad, which is a group of keys that you can set to
type numbers and mathematical symbols, such as the plus sign. A number or symbol
on the right corner of each keypad key shows its numeric function.

Num Lock LED

Press <Fn+F11> to turn on the embedded numeric keypad. The numeric functions of
the keypad are enabled and the Num Lock LED turns on. (See ”Reading the System
Status Lights” on page 19 for the location of the Num Lock LED.)

While the numeric functions are enabled, you can temporarily return a key to its normal
function by pressing the key and the <Fn> key. For example to type the letter m, press
<Fn+M>, this operation displays the letter m.

To turn the numeric keypad off, press <Fn+F11> again. The Num Lock LED turns off.

12 Users Manual

Using Special Function Keys

The function key activates special functions when it is pressed in combination with
another keys. Table 2 shows the special key combinations.

Table 2. Description of Special Function Key Combinations

<Fn> Key
Combinations

<Fn+Esc> Esc

<Fn+F2> F2

<Fn+F4> F4

<Fn+F6> F6

Key Name Key Function

Rest

Gauge

LCD/CRT

Mute

Rest Puts the computer into Suspend mode. To resume

Gauge Displays the battery gauge and the power source in

LCD/CRT Switches the display between the LCD, the external

Mute Mutes the audio.

normal operation from rest, press the power button.

the upper-left corner of your screen. The gauge
closes in a few seconds.

display device, and simultaneous display on both the
LCD and the external display device.

<Fn+F7> F7

<Fn+F11> F11

<Fn+F12> F12

<Fn+Up Arrow> Up Arrow Brightness UpIncreases the LCD brightness.

<Fn+Down Arrow> Down Arrow Brightness

<Fn+Right Arrow> Right Arrow Volume Up Increases the audio volume.

<Fn+Left Arrow> Left Arrow Volume

S/PDIF

Num Lock

Scroll

S/PDIF Toggles the S/PDIF function On/Off.

Num Lock Activates the numeric keypad.

Scroll In some applications, sets the cursor-control keys to

Down

Down

scroll the page up or down while the cursor position
does not change. Pressing key combination again
turns off the scrolling function.

Decreases the LCD brightness.

Decreases the audio volume.

When you press a function key combination, the system sound may be
temporarily muted.

Using the Keyboard 13

User Defined Buttons (SENS Keyboard)

You may program the four buttons to the left of the power button to start any program
you have installed on your computer.

The default settings for these buttons are:

Icon Name Function

Internet Button Launches Internet Explorer.

E-Mail Button Launches Outlook Express.

User Button Executes user-defined action.

14 Users Manual

WLAN/Bluetooth
On/Off Button

Turns WLAN/bluetooth on and off.
(If you do not have WLAN/Bluetooth module installed, an additional
User Button is provided instead.)

What is Bluetooth?

Bluetooth is a worldwide standard for the wireless exchange of data between
two devices.

Using Wireless LAN/Bluetooth Button

Loading or unloading wireless LAN/Bluetooth driver takes about 5 seconds.
Therefore, if you turn wireless LAN/Bluetooth on/off using the wireless LAN/
Bluetooth button, the button does not work in 5 seconds. (For wireless LAN/
Bluetooth installed models)

To reprogram the Sens Keyboard, follow the steps below:

1. Double-click icon on the Windows taskbar, the Key Setting window is

displayed.

2. Use the Browse button to locate the program you wish to assign to the SENS
Keyboard button selected.

3. Click on your program choice to select it. Click Open.

4. Click OK to close window and complete programming the Sens Keyboard.

Using the Keyboard 15

Using the Touchpad

Your computer is equipped with a touchpad, which is an integrated-pointing device
that is used to perform standard mouse functions. The touchpad is an advanced and
reliable pointing device that works with a touch of your finger.

Touchpad

Touchpad Buttons

Scroll Wheel or Fingerprint Sensor

Scroll Wheel Use

If the scroll wheel does not function properly, install the scroll wheel driver
provided on the Software CD.

16 Users Manual

Press on the touchpad gently. The touchpad responds to light pressure.

d

Action Process and Comment

Click/Tap Process

Depress the touchpad left button and release or position the pointer
over the object and quickly tap the touchpad once with your finger.
This action is called clicking.

Comment

This will cause a process to begin or select an object on the screen.

Double-click/Tap Process

Click-Hold Process

Right-click

Quickly click the left touchpad button two times or position the pointer
over the object and quickly tap the touchpad twice with your finger.
This action is called Double-clicking.

Comment

This will cause a process to begin or open a file folder.

Depress the left touchpad button and do not release.

Comment

This is used to move/drag objects to new locations. See ”Drag (Move)”
on page 18.

Process

Position the pointer over the object. Quickly press and release the right
button once.
This action is called Right-clicking.

Comment

This is usually used to obtain information about an object or access a
short cut menu.

Scroll Up/Down Process

Roll the wheel up/down to display upper/lower part of current window.
(Supported when you have the scroll wheel option.)

Using the Touchpad 17

Drag (Move)

To move a window on the desktop, complete the following:

1. Click the window title bar of the window which you want to drag using the

touchpad.

2. Press the left touchpad button and hold it.

3. Drag the window using the touchpad.

2 Drag your finger to move the window.

1 Click the Window Title Bar and Hold.

Area or Multiple item selection:

The drag function may be used to select an area or multiple items in an area
by clicking in one area and then dragging to create a selection window. The
items inside the window will be selected.

18 Users Manual

Reading the System Status Lights

System Top

System Status lights show the status of computer functions.

LED Name Function

Num Lock Changes a portion of the keyboard to a numeric keypad.

Caps Lock Changes all alphabet letter input into capital letters.

Scroll Lock Scroll lock in certain software.

HDD Access Blinking Green - HDD is being accessed.

See ”Using the Numeric Keypad” on page 12.

No changes occur to numeric and special keys.

System Bottom

LED Name Function

Battery Status Green - No battery pack installed/battery fully charged.

Power Green - System power on.

Amber - Charging.
Blinking - Bad Battery.

Blinking - Standby mode.

Reading the System Status Lights 19

Connecting to the Internet

This section explains how to connect you to the internet. For details on how to establish
the connection contact the Internet Service Provider (ISP) or system administrator
(SysAdmin).

Using the Modem

Install the Modem cable by simply plugging the cable into the modem slot as shown in
the figure below.

Your notebook computer may have both a modem and a LAN socket, please ensure
you plug the modem cable into the correct socket.

1. Contact your Internet Service Provider to obtain information or CD required to

2. After the cable is connected create a “Dialup” connection by clicking

3. Click Set up or change your Internet connection > Setup to start the connection

4. Follow the instructions in provided in the Make New Connection wizard.

20 Users Manual

make the connection in your area.

Start > Control Panel > Network and Internet Connections.

wizard.

Precautions Before Use

Country Selection

Country Selection:

Because you may use your computer in more than one country, please
ensure you select the country you are calling from to avoid connection
problems.

To change the country selection proceed as follows:

1. Click Start > Control Panel > Network and Internet Connections.

2. Click Phone and Modem Options.

3. Click on the connection you wish to edit in the Locations: box.

4. Click Edit in the Dialing Rules Tab.

5. Select the Country/region you are calling from in the General tab.

6. Click OK to close the “Edit Locations” box.

7. Click OK to close “Phone and Modem Options” box.

Digital Phone Lines:

If you connect the modem to a digital phone line (such as a company
4-wire system), the modem may be damaged.

DOS support

• Windows XP: Does not support pure DOS mode and the modem does not

support a DOS box in Windows. So you cannot use a
communication application which runs under DOS.

Using the Modem on a PBX system

If you use a Windows Communication Program:

1. Click Start > Control Panel > Network and Internet Connections.

2. Click Phone and Modem Options.

3. Click Properties in the Modems tab section.

4. Check off “Wait for dial tone before dialing” check box in the Modem tab section.

5. Click OK to close the dialog box.

6. Click OK to close “Modem Properties” dialog box.

Connecting to the Internet 21

If you use a simple terminal program (i.e. hyper terminal):

Type the “ATX3&W” or “ATX3” command as an initialization command.

MODEM Notes:

1. In order to use the V.90 feature, be sure to check if the standards
supported by the on-line service provider and the modem are identical.
Download speed is limited to 53Kbps. Upload speed is limited to 31.2Kbps.
Speeds can vary by line condition.

2. If you use a PBX phone system, you can not connect using the V.90 mode.

3. Internationally connected calls will be limited to 33.6K (Max.)

Configuring the Wired LAN Connections

You may connect to the network using either a LAN cable or by establishing a wireless
connection if factory option is installed.

Cable Connection

Install the LAN cable by simply plugging the cable into the slot in the left side of the
computer.

Your computer’s LAN adapter is ready to use for most situations, however if your
system does not have access to a DHCP server or you wish to personally configure your
LAN connection, proceed as outlined in “Configuring Network Environment” below.

22 Users Manual

Network Protocols:

You may need to consult your SysAdmin if their network protocols and settings
are required for your LAN environment.

Configuring Network Environment

Configure the Network Adapter as follows:

1. Click Start > Control Panel > Network and Internet Connections.

2. Click icon (Network Connections).

3. Right-click the icon (Local Area Network) then click Properties button.

4. Select Internet Protocol (TCP/IP) in the “This connection uses the following

items:” box.

5. Click Properties. The TCP/IP Properties window opens.

Step 7

Step 8

6. Click “Use the following IP address” in the General tab.

7. In the “Use the following IP address” box, enter your IP address:, subnet mask:
and Default Gateway:.

8. In the “Use the following DNS server addresses” box, enter your Preferred DNS
server: and Alternate DNS server:.

9. Click OK when you finish the TCP/IP set-up.

Connecting to the Internet 23

Using Both DHCP and Static IP Simultaneously

When you are alternatively using networks with either DHCP or static IP addressing,
you can use both of the network connections without reconfiguring using alternative
settings that enable simultaneous configurations of DHCP and static IP.

This function is provided only when your operating system is Windows XP.

1. Click Start > Control Panel > Network and Internet Connections > Network
Connections > Local Area Connection, press the right button of the touchpad,
and then select Properties.

2. Select the Internet Protocol (TCP/IP) item, and then click Properties.

3. In the Alternate Configuration tab, click User configured, and then enter the

appropriate values for the following: IP address, Subnet mask, Default gateway,
Preferred and alternate DNS server, and Preferred and alternate WINS server.

4. When the configuration has been completed, click OK.

24 Users Manual

Now you can connect to both networks using DHCP and static IP respectively.

Wake On LAN Function

<Wake On LAN> is a function that activates the system in rest mode when a signal
(such as ping or magic packet commands) arrives from network(wired LAN).

To use <Wake On LAN> function:

1. Click Start > My Computer > My Network Places > View network
connections.

2. Click the right button on the touchpad over Local Area Connection, and select
Properties.

3. Click Configure, and select Power Management tab. Select 'Allow this device to

bring the computer out of standby', then click OK. Restart the system.

If the system in rest mode is activated when there is no received signal, use the system
after disabling <Wake On LAN> function.

Connecting wired LAN while using wireless LAN may not execute <Wake On LAN>
function. Configure wireless LAN to 'Disable' to use <Wake On LAN> function.

Connecting to the Internet 25

Configuring the Network Environment Settings for Wireless Network (WLAN)

A wireless network (Wireless LAN) environment is a network environment that
enables communication between multiple computers at home or a small-size office
through wireless LAN devices.

Using the wireless network connections between the systems, you can use normal
network functions such as sharing of files, folders and printers. Using computer-to­computer network (ad hoc) connections, you can access the Internet through a
computer connected directly to the Internet even if your computer is not directly
connected to the Internet. For details, see “Using Network Services” on page 37.

The information provided in this section only applies to models equipped with
an optional wireless LAN device.

Wireless network connections can be classified into two categories.

1) Access Point

You can connect to an AP to use the network. This is possible only in an environment
equipped with an AP. For details, see “Connecting to an Access Point (AP)” on page

27.

2) Computer-to-computer (ad hoc)

This is also called a peer-to-peer or ad hoc network.

In computer-to-computer wireless networks, you can wirelessly connect 2 or more
computers that have wireless LAN modules. Using computer-to-computer wireless
networks, you can access the Internet through a computer that is connected to the
Internet even if your computer is not directly connected to the Internet. For details, see
“Connecting to computer-to-computer networks (peer-to-peer or ad hoc)” on page 28.

26 Users Manual

What is an Access Point (AP)?

An AP is a network device that bridges wired and wireless LANs, and
corresponds to a wireless hub in a wired network. You can connect multiple
wireless LAN installed computers to an AP.

Connecting to an Access Point (AP)

This section describes how to connect to an AP. You can use the network when you are
connected to an AP.

In this section, the configuration procedures are described for Windows XP
installed computers. For information on the configuration procedures for other
operating systems, see “Using Wireless Networks in Other Operating
Systems” on page 33. Please ask your network administrator about detailed
configuration information such as the network key (encryption key).

1. Right-click on the Wireless Network Connection ( ) icon on the taskbar, and
select View Available Wireless Networks.

2. Select your desired AP (e.g. Test) to connect, and enter the encryption key for the
AP in the Network key field, and click Connect.

If the network key is not configured for the desired AP, select 'Allow me to
connect to the selected wireless network, even though it is not secure’.

Now you are connected to the AP, and you can access the network.

Connecting to the Internet 27

Checking the connection status

Move the mouse pointer over the Wireless Network Connection ( ) icon on
the taskbar, and the connection status is displayed.

Connecting to computer-to-computer networks (peer-to-peer or

ad hoc)

In computer-to-computer wireless networks, you can wirelessly connect 2 or more
computers that have wireless LAN modules.

You can connect by completing the following steps:

• Step 1. Set up a computer-to-computer network on a computer.

• Step 2. Connect to the configured computer from other computers.

In this section, the configuration procedures are described for Windows XP
installed computers. For information on the configuration procedures for other
operating systems, see “Using Wireless Networks in Other Operating
Systems” on page 33.

28 Users Manual

Step 1. Setting up a computer-to-computer network

1. Right-click on the Wireless Network Connection ( ) icon on the taskbar, and
select View Available Wireless Networks.

2. Click Advanced.

3. On the Wireless Network tab, click Advanced.

4. Clear 'Automatically connect to non-default network' check box, if it is selected.
Select 'Computer-to-computer (ad hoc) networks only', and click Close.

5. In the Wireless Networks tab, click Add.

Connecting to the Internet 29

6. Enter the network name (e.g. samsung), and unselect 'The key is provided for me
automatically'. Enter the encryption key in the Network key field, and click OK.

To prevent a network connection from an unauthorized user, it would be better
to configure a network key (encryption key). A network key consists of 5 or 13
alphanumeric characters (e.g. magic), or of 10 or 26 hexadecimal numbers (a
hexadecimal number is represented by numbers '0' to '9' or letters 'a' to 'f').

30 Users Manual

7. Check that the configured network name (e.g. samsung) is in the ’Preferred
networks’ item, and click OK.

Now your wireless network setup has been completed.

Step 2. Connecting to the configured computer

1. Right-click on the Wireless Network Connection ( ) icon on the taskbar, and
select View Available Wireless Networks.

2. Select the wireless network name (e.g. samsung) specified in ”Connecting to
computer-to-computer networks (peer-to-peer or ad hoc)” on page 28, enter the
encryption key in the Network key field, and then click Connect.

Connecting to the Internet 31

If the network key is not configured in ”Connecting to computer-to-computer
networks (peer-to-peer or ad hoc)” on page 28, select 'Allow me to connect to
the selected wireless network, even though it is not secure'.

The two computers are connected and are able to communicate with each other. When
the computers are connected, the 'Wireless Network Connection' message is displayed
for a short time over the Wireless Network Connection icon of the two computers.

Checking the connection status

Move the mouse pointer over the Wireless Network Connection ( ) icon on
the taskbar, and the connection status is displayed.

32 Users Manual

Using Wireless Networks in Other Operating Systems

In a operating system other than Windows XP, you have to install additional wireless
LAN configuration program, and configure wireless network settings.

To use wireless network connection, complete the following procedures.

• Step1. Install the wireless LAN configuration program (PROSet).

• Step2. Configure wireless network settings through the wireless LAN

configuration program.

Step 1. Installing the wireless LAN configuration program (PROSet)

You can install the wireless LAN client administrator program following the
instruction displayed automatically when you insert the system software CD. Insert the
system software CD into the CD-ROM drive, and install the wireless LAN
configuration program.

To not display 'Intel Configuration Service' window afterward

After installing the wireless LAN configuration program, select "Do not show
this again." check box, then click Close.

Step 2. Using the wireless LAN configuration program (PROSet)

Double-click the wireless LAN program ( ) icon on the taskbar.

(Or, click Start > All Programs > Intel Network Adapters > Intel(R) PROSet.)

In some languages, some buttons on the window may not be displayed.
Resize the window to use the program.

Configure wireless network settings in PROSet following the procedures below.

Connecting to the Internet 33

To connect to an Access Point:

To connect to an access point or existing computer-to-computer (Ad Hoc) network,
refer to the following procedures. (To create a new computer-to-computer network,
refer to the following "To create computer-to-computer (Ad Hoc) network" section.)

1. Click Scan in the Networks tab.

2. Select the name of desired access point or computer-to-computer network to
connect from the searched available networks list, and click Connect.

If your desired network does not appear, click Refresh.

An access point is represented by ( ) icon, and a computer-to-computer
network is represented by ( ) icon. An ( ) icon is displayed in front of an
access point or a computer-to-computer network with configured security
settings.

3. Select "Yes, create a profile for this Network.", and click OK.

4. Enter Profile Name and click Next.

5. Enter the network authentication, data encryption (WEP), key index, and
password configured for the target access point or computer-to-computer network
in the Security Settings window, and click Finish.

34 Users Manual

The network authentication, data encryption (WEP), key index, and password
of a access point are configured in the access point management program.
For the information on the security information, check the security settings of
the access point or ask your wireless network administrator.

To connect to an existing computer-to-computer (Ad Hoc) network, enter the
password configured when creating the computer-to-computer network for the
first time. You do not need to enter network authentication and key index.

Security Settings

- Network authentication: Network authentication has two options of Open
System and Shared Key. If you select Open, no authentication procedure is
used. If you select Shared, WEP key is used as authentication procedure.
Default option setting is Open.

- Data encryption (WEP): IEEE 802.11 WEP (Wired Equivalent Privacy)
standard has two security levels of 64-bit key (40-bit key for some cases) and
128-bit key.

- Key index: Select the current encryption key index used by the access point
out of 1 to 4.

- To use pass phrase: Click Use pass phrase to activate, and enter 5 (for 64­bit) or 13 (for 128-bit) alphanumeric characters (represented by 0-9, a-z, or A­Z).

- To use WEP key: Click Use WEP keys to activate, and enter a hexadecimal
number (represented by 0-9 and A-F) of 10 (for 64-bit) or 26 (for 128-bit) digits
in the WEP key field.

When a wireless connection to an access point is established, connection icon
( ) appears in front of the name of connected profile.

To create a computer-to-computer (Ad Hoc) network:

To create a new computer-to-computer (Ad Hoc) network or to connect to a hidden
access point (Stealth/Closed Mode), refer to the following procedures.

A hidden access point is an access point that exists, but is configured not to
be detected by the scan operation to prevent access attempts from
unauthorized users.

1. Click Add in the Networks tab.

2. Enter Profile Name and Network name (SSID), select Operating Mode, then
click Next.

What is a network name (SSID)?

Network name (SSID) is a name that a wireless adapter uses for identifying
connection. Enter the name of computer-to-computer network to create (e.g.,
P2P) or the name of access point to connect. The network name identifies
cases. (capital and lowercase) For the name of access point, check the
settings of the access point, or ask your wireless network administrator.

Operating Mode:

- Infrastructure - Connect to an Access Point - Select to connect to an
access point.

- Ad hoc - Connect directly to other computers - Select to create a
computer-to-computer (Ad Hoc) network.

Connecting to the Internet 35

3. Configure password setting to be used for computer-to-computer network
connection in the Security Settings window.
To connect to an access point, enter the network authentication, data encryption
(WEP), key index, and password configured in the access point.

It is recommended to configure data encryption for security purposes when
creating a computer-to-computer network connection profile. For more
information on security settings refer to the security settings in Connecting to
AP or Help.

When you are creating a computer-to-computer network connection profile,
the network authentication setting is disabled.

4. When a profile creation is completed, the new created profile appears in the
profiles list in the Networks tab. Select corresponding profile, and click Connect
to connect to the created profile.

When a wireless connection to the created profile is established, connection icon
( ) appears in front of the name of connected profile.

36 Users Manual

Using Network Services

While the computer is connected to the network, you can use network services to share
files, folders, and printers. Using computer-to-computer wireless networks, you can
access the Internet through a computer that is connected to the Internet even if your
computer is not directly connected to the Internet.

Network services are provided for the computers that are connected to the
network through wired or wireless network connections. For details, see
“Configuring the Wired LAN Connections” on page 22 and see “Configuring
the Network Environment Settings for Wireless Network (WLAN)” on page 26.

Sharing files or folders

This section describes how to share files and folders between computers connected to
the network.

To share files, complete the following procedures:

• Step 1. Configuring the sharing of files and folders on a computer.

• Step 2. Accessing shared files and folders from another computer.

When a file or folder is shared, anyone connected to the network can open and
delete the shared file or folder.
Configure a file sharing network only when the network is secure, and do not
share important data.

Connecting to the Internet 37

Step 1. Configuring Sharing

1. Right-click the target file or folder to share in My Computer, and select Sharing
and Security.

2. Click 'IF you understand the security risks but want to share files without running

the wizard, click here'.

It has the same security effect as that of the 'Network Setup Wizard'.
This screen does not appear if Internet Sharing Network Wizard has been
installed in the computer-to-computer wireless network environment.

3. Select 'Just enable file sharing', and click OK.

4. In the 'Network sharing and security' field, select 'Share this folder on the network',

The file and folder sharing configuration has been completed.

38 Users Manual

enter the share name, and click OK.

Be cautious when selecting 'Allow network users to change my files' since
other network users can change the files in the shared folder.

Step 2. Using Shared Files or Folders

This section describes how to access shared files or folders if your computer is a
member of the same workgroup.

1. Click Start > My Computer. Under Other Places, click My Network Places in
your computer.

2. Click 'View workgroup computers', and click the desired computer to access the
shared file.

If your computer is a member of another workgroup:

1. Click Other Places > Microsoft Windows Network.

2. Click the desired workgroup.

3. Click the desired computer to display the shared files or folders.

Sharing Printers

This section describes how to share a printer between computers connected to a
network.

To share a printer, complete the following procedures:

• Step 1. Configure printer sharing in the computer connected to the printer.

• Step 2. Add and use the shared printer in other computers on the network.

Connecting to the Internet 39

Step 1. Configuring Printer Sharing

1. From the computer connected to the printer, click Start > Printers and Faxes.

2. Right-click the printer you want to share, and click Sharing.

3. Select 'Share this printer', enter a share name for the shared printer, and click OK.

4. In the Printers and Faxes window, you will find the printer icon has been changed

to another icon on a hand.

Step 2. Adding and Using a Shared Printer.

1. From a different computer that wants to use the shared printer, click Start >

2. Click Add a printer.

3. In the Add Printer Wizard, click Next.

4. Select 'A network printer, or a printer attached to another computer', and click

40 Users Manual

Printers and Faxes.

Next.

5. Select 'Browse for a printer', and click Next.

6. Select the workgroup or computer, select the desired printer, and click Next.

If you cannot find the desired printer, try again after a while.

7. Read the warning about a shared printer, and click Yes to install the shared printer.

8. Select Yes for 'Do you want to use this printer as a default printer?', and click Next.

9. Click Finish.

10. When the printer sharing configuration has been completed, the shared printer

appears in the Printers and Faxes window.

Now you can print using the shared printer even if your computer is not directly
connected to a printer.

Connecting to the Internet 41

Sharing an Internet Connection

Using computer-to-computer (peer-to-peer) network connections, you can access the
Internet through a computer connected to the Internet even if your computer is not
directly connected to the Internet.

To share an Internet connection, the computers should be connected to a
computer-to-computer (peer-to-peer) wireless network. For details, see
“Connecting to computer-to-computer networks (peer-to-peer or ad hoc)” on
page 28.
Also, one of the computers has to be connected to the Internet (external
network).
The configuration procedure to share an Internet connection are described for
Windows XP installed computers.

To share an Internet connection, complete the following procedures:

• Step 1. Configuring a Internet connection sharing from the computer connected

to the Internet.

• Step 2. After completing the shared Internet connection configuration, check

that the other computers can access the Internet through the shared Internet
connection.

Step 1. Configuring Internet Sharing.

Configuring a shared Internet connection on the computer connected to the Internet.

1. Click Start > Control Panel > Network and Internet Connections > Network

2. Right-click on the device connected to the Internet, the external network, and

42 Users Manual

Connections.

select Properties.

If the computer is connected to the Internet through a wired LAN, select 'Local
Area Connection'.

3. On the Advanced tab, select 'Allow other network users to connect through this
computer's Internet connection', and click OK.

Step 2. Checking the Shared Internet Connection.

When the Internet connection sharing configuration has been completed, the network
icon in the Network Connections window is displayed as follows:

Click Start > Control Panel > Network and Internet Connections > Network
Connections.

– A computer connected to the Internet.

– A computer sharing the remote Internet connection (other computer).

If the icon does not appear after a long time, restart the computer.

Computers on the network can access the Internet through the shared Internet
connection only when the computer connected to the Internet is turned on.

Connecting to the Internet 43

Using the Disk Drives

Using the CD-RW/DVD-ROM Combo Drive

You have to install the CD Writer software provided on a separate CD to write
a CD. For more information, read the manual included in the CD.

You have to install the DVD software provided on a separate CD to view a
DVD title.

1. Press the button on the CD-RW/DVD-ROM Combo drive, and the tray slides out.

CD-ROM Drive Warnings:

Do not place reflective objects other than the CD/DVD disks in the disk slot
because of possible hazardous laser emissions. The laser beam used in this
CD-ROM drive is harmful to the eyes. Do not attempt to disassemble the CD­ROM drive. Refer servicing to your authorized service center.

Please do not lean or exert undue pressure on the CD-ROM tray as it may
cause damage not covered under warranty.

2. Insert a CD/DVD, label side up (or remove a disc, if you have finished using it).

44 Users Manual

CD-ROM Precautions:

The tray may be stuck, in which case straighten out a paper clip, insert
it into the Emergency Eject hole in the front of the CD-RW/DVD-ROM Combo
drive and push it until the tray ejects.

A LED on the drive tray is on when the computer is reading from a CD. Do not
remove a disc when this LED is on.

To clean a CD/DVD, wipe from the center outwards with clean and dry cloth.
Remove the CD/DVD when the drive CD-ROM LED is off.

3. Push the tray in gently to close the drive tray.

Emergency Eject Hole
Eject Button

CD-ROM LED

Install and/or start a CD-based program as you would run a program on a floppy disk.

Using the Memory Stick (Factory Option)

The Memory Stick is a factory option that will increase your computer storage capacity as well

as increase data portability. The Memory Stick may used in many types of equipment such as
digital cameras and PDAs for example.

Memory Stick and are a trademarks of the Sony Corporation.

Memory Stick Support

The Magic Gate model is not currently supported.

Inserting the Memory Stick

To insert the memory stick proceed as follows:

Ensure you Insert the Memory Stick into the slot with the correct orientation
(Name Up) so that the Memory Stick will operate properly and be recognized
by the computer.

Using the Disk Drives 45

1. Slide the Memory stick into the slot until you feel the first latch catch.

2. Then push the Memory stick in until it clicks into place.

Using the Memory Stick

The Memory Stick is used the same as the FDD drive on your computer but with much
larger capacity, currently up to 128MB.

Formatting the Memory Stick

The Memory Stick may need to be formatted before use, if so insert it into the
slot and format it the same as the FDD Drive.

To see the contents of the Memory Stick:

1. Double-click “My Computer” on the desktop, the My Computer window opens.

2. Double-click the icon in the Devices with Removable Storage section of the

46 Users Manual

Protecting Data on the Memory Stick

To prevent overwriting/deleting your data in the Memory Stick, move the slide
lock to the “Lock” position.

window.

Removing the Memory Stick

To remove the Memory Stick proceed as follows:

Ensure any operations using the Memory stick have completed before you
remove it. Otherwise you will corrupt your data.

When you are using Windows 2000, remove a memory stick after at least 20
seconds after finishing a task, such as formatting, copying, or deleting.
Removing a memory stick directly after executing a task may cause a problem
in Windows 2000.

1. Push the Memory Stick in until it clicks and release.

2. The Memory Stick will pop out about 1 cm and then you can slide it out.

Using the Disk Drives 47

Working with PC Cards

By installing PC Cards, you can add functions to your notebook computer similar to
those found on add-in boards for desktop computers. Available PC Cards include:

• Input/output, such as modem, network, video capture, and SCSI cards.

• Storage, such as hard drive and flash memory cards.

Your computer includes the following PC Card support:

• One PC-Card slot: You can install Type I or II cards in the slot.

• CardBus hardware and software: CardBus enables the computer to use 32-bit

PCMCIA Cards. Windows supports 32-bit and 16-bit PC Cards.

Maintaining PC Cards

To maintain your PC Cards, follow these guidelines:

• Keep cards away from excessive heat, direct sunlight, and liquids.

• Do not drop, bend, flex, or crush cards when handling.

• Keep dust, magnets, and static electricity away from PC Cards.

• When a card is not in use, carry it in its protective carrying case.

• Some PC Cards include cables that extend from the back of the cards. Be

careful not to bend or put excessive strain on these cables.

Using PC Cards

To insert a PC Card into a slot:

1. If a dummy card is in place, push the eject button once to pop it outward, then push

the eject button again to eject the dummy card.

2. If the eject button is still projecting out, push it firmly in to lock in place. It will
protect the eject button from damage.

48 Users Manual

3. Align the card with a slot and insert the card into the slot until it locks in place.

Eject Button

Windows automatically assigns computer resources (such as communication ports and
memory addresses) to a PC Card installed in your computer.

To remove a PC Card from your computer:

Use the following procedures to remove PC Cards, or you may lose data that
is being stored to a card.

1. Click icon on the taskbar.

2. Select the card currently in use, and click the Stop button.

The eject button for the card slot operates in two steps, therefore to remove a PC
Card:

Eject Button

3. Push the eject button once to pop it outward then push the eject button again to
eject the card.

4. Pull the card out of the PC Card slot.

Working with PC Cards 49

Multi Media Functions/Equipment

Media Player

The Windows Media player is used to play audio files while the computer is on. You
can play audio/video CD files using the Windows Media Player, as well as watching
TV, video and listening to the radio through internet. The instructions to play a video
CD-ROM are the same as the instructions for the audio CD below.

Playing an Audio/Multimedia CD

To play a CD follow the instructions below:

1. Insert a compact disc into your CD-ROM drive.

2. Press the eject button on the CD-ROM drive to open the CD-ROM device.

3. Insert a CD, label side up.

4. Carefully push the tray in to close the drive tray. The Windows Media Player

button appears on the taskbar if not already there, and the music begins to play. If
the disk does not play click Start > All Programs > Accessories >
Entertainment > Windows Media Player.

CD-ROM LED On:

A LED on the drive tray is on when the computer is reading from a CD. Do not
remove a disc when this LED is on.

50 Users Manual

If you maximize or restore down the window while playing a media such as an
audio CD on Media Player, the screen may not displayed properly for a
moment.

Removing the Audio/Multimedia CD

To remove the CD follow the instructions below:

1. Click Start > All Programs > Accessories > Entertainment > Windows Media
Player to open the Windows Media Player window, if not already open.

2. Click Stop in the Windows Media Player window or simply close the Windows

media player.

3. Press the button on your CD-ROM drive. The drive tray opens and you can remove
the CD from the CD-ROM drive.

4. For more information on playing compact discs, see the Help menu in the
Windows Media Player window.

Dolby Digital & Home Theater System (S/PDIF Port)

This product supports 5.1 channel output, which is a basic function for home theater
systems and DVD drives. It provides 3D surround sound and a vivid screen.

Home theater system usually consists of a TV, DVD, 5.1 channel speakers,
and a digital amplifier to provide a high-resolution vivid (MPEG2) picture and
3D surround sound (Dolby 5.1 or DTS). With a home theater system, you can
enjoy the same vivid picture and sound in your home that you would in a movie
theater.

You will need the following to enjoy a home theater system:

• 5.1 channel speaker system / Digital amplifier (Purchased separately).

• DVD drive and DVD program

• S/PDIF cable (Option)

Multi Media Functions/Equipment 51

Setting Up Your Home Theater

1. Connect the digital amplifier to the S/PDIF port of your computer.

2. Connect the speakers to the digital amplifier.

Digital Amplifier

Front Left Speaker

Surround Left Speaker Surround Right Speaker

Computer

TV

Center

Speaker

Sub

Woofer

Front Right Speaker

If your computer supports a TV-Out port, you can connect and enjoy a large
screen.

After connecting the TV, you will need to select the TV as the display device
using the Windows Display Properties window.

After making all connections, ensure you enable S/PDIF:

1. Enable S/PDIF in Windows.

2. Enable S/PDIF in the DVD program.

Using the S/PDIF Connection

1. Use <Fn+F7> keys to set the S/PDIF port to digital.

52 Users Manual

When purchasing a 5.1 channel speaker system, make sure it supports a S/
PDIF (optical) port.

Enabling S/PDIF on the DVD Program

When using 5.1 channel speakers, you will need to install the “Power DVD” program
on the DVD Installation CD (supplied separately) and then set it up as described below:

1. Run the “Power DVD” program and click the settings button. The configurations
window pops up.

Settings Button

2. On the Audio tab, change the Audio Output setting to “Use SPDIF” and click OK.

3. You are ready to enjoy your home theater system with your own DVD.

To control the sound volume on your 5.1 channel speaker system, use the
control on the digital amplifier. (Please refer to the speaker manual.)

Multi Media Functions/Equipment 53

Volume Control

The instructions below are for controlling speaker volume when the computer is on.

Using the Keyboard

Changing the volume with your keyboard.

Use <Fn+Left Arrow> to decrease the volume or <Fn+Right Arrow> to increase the
volume.

Using the Volume Control Icon

Double-click icon in the active program tray. The Volume Control window pops
up. Use this window to adjust the volume. You can pop up a simple volume slider by
a single click icon.

Movie Maker

You can edit audio and video data using this Movie Maker included with Windows XP.
It is also possible to make a slide show with each frame or picture.

To start the program:

Click Start > All Programs > Accessories > Windows Movie Maker.

54 Users Manual

Please refer to the on-line help manual to operate the Windows Movie Maker.

Using the Battery

Your computer uses a smart rechargeable Lithium-ion (Li-ion) battery pack for power
when the AC adapter is not attached to an electrical outlet. The smart battery gives a
accurate measurement of the current battery capacity which helps extend operating
time by enabling effective power management in operating systems that take
advantage of the accurate information supplied by the battery.

Charging the Battery

Your computer’s battery starts charging automatically when you connect the power to
the computer and to an electrical outlet.

Approximate charging time for the Li-Ion battery is 2 hours. While the battery is
charging normally, the battery charge light on the computer is amber. When the battery
is fully charged, the light changes to green.

When you use a new battery pack for the first time or use a battery after a long period
of storage, the initial battery life is shorter than normal. Normal battery life resumes
after a few discharge-recharge cycles.

Follow these rules for charging your battery:

• A battery normally discharges power when not used for long periods of time.

Be sure to recharge the battery every two months when it is not in use.

• Make it a practice to discharge your battery fully before recharging the battery.

This can help extend the life of the battery.

• Do not attempt to charge the battery in temperatures of under 5

o

C or over 45oC

All batteries eventually wear out and lose the ability to hold a charge. You may
need to replace your battery pack after a year of average usage.

Battery charging time may differ depending on system environment or using
condition.

Using the Battery 55

Safely Using the Battery

Follow these guidelines to safely use the battery:

• Turn off your computer and unplug it if you accidentally:

– Expose the equipment to liquid.

– Drop, jar, or damage the computer.

• Use only approved battery chargers.

• Do not disassemble the battery, heat it above 100°C, or burn it. The battery

used in this computer may cause a fire or chemical burn if mistreated.

• Your computer's rechargeable battery may be considered hazardous waste. If

you replace your battery with a new one:

– Keep the old battery out of the reach of children.

– Dispose of the old battery promptly.

– Make sure that you follow all local requirements when you dispose of the

old battery.

Installing the Battery

To install the battery pack:

1. With the computer’s power off, close the LCD panel and turn the computer over

56 Users Manual

so the bottom of the unit faces up.

Insert the battery into the battery compartment, ensuring the correct
orientation so that the battery fits in its compartment properly.

2. Insert the battery into the battery compartment until the battery latch snaps into
place.

Left Battery Latch

3

Right Battery Latch

2

3. Slide the left battery latch toward center to lock the battery in place.

Removing the Battery

Your computer comes with the battery pack inserted in the computer.

To remove the battery from the computer:

1. Turn the computer’s power off.

2. Close the LCD panel, and turn the computer over so that the bottom of the unit

faces up.

3. Slide the left battery latch outward.

4. While holding the right battery latch outward, slide the battery out of the battery

compartment.

Left Battery Latch

Right Battery Latch

Using the Battery 57

Monitoring the Battery Charge

Battery life is affected by factors such as the power-management settings in System
Setup, the applications you use, and the brightness settings of the LCD. Under normal
usage, the battery charge lasts approximately 2 hours.

Battery life estimates are subject to variation. The actual life of your battery
may be less than the estimates given in the manual.

You can monitor the charge of the battery pack installed in your computer by using the
Power Meter or Battery Gauge.

Power Meter

The Power Meter displays the charge of the batteries and the current source of
computer power, AC or batteries. You may monitor the battery charge or usage by
using the “Power Meter”. To access the power meter click icon on the taskbar or
click Start > Control Panel > Performance and Maintenance > Power Options >
Power Meter tab.

The Power Status icons shown below are displayed

during Battery Charging Operations.

58 Users Manual

At ~15% and 10% remaining battery power the

current power source and the battery icons

respectively change to the icon shown below and

you should follow the instructions in “Battery

Warnings” section below.

Battery Gauge

You may display the battery gauge while you are in any program by pressing
<Fn+F2>. The battery gauge is only displayed for a few seconds.

When using this function, the LCD display may not operate properly.

Power Source:

Indicates that the computer is
powered by the AC adapter.

Battery Level:

Indicates the approximate amount of
the primary battery charge remaining.

You may also determine the charge of your battery by simply pushing the symbol
below the word PUSH located on the side of the battery. The green LEDs will
illuminate to show you the percentage of charge remaining in the battery.

Indicates that the computer is
powered by the battery.

Push

Using the Battery 59

Battery Warnings

If the battery charge is low (about 10%) you have ~ 5–10 minutes of battery life left.

You should:

• Save your work and,

• Connect the power cord to the computer or turn off the computer and install a

fully charged battery.

You can adjust the battery alarm features by using the operating systems power
management program (Start > Control Panel > Power Options in Windows).

If you cannot run your computer from the battery and the battery will not charge when
you attach the power cord, the problem may be that:

• The battery temperature is below 0°C or over 45°C. If you think the battery

temperature is too hot or too cold, turn off the computer, remove the battery,
and let the battery reach room temperature. Then try charging the battery again.

• The battery may be defective, please try running your system from the AC

adaptor with the battery removed from the system. Please contact the Samsung
helpline if you are unsure.

Battery Calibration

Calibrating your battery once a month is one of the recommended methods of
increasing your computer’s battery life. To calibrate the battery complete the following
steps:

1. Disconnect the AC power adapter after turning off the system.

2. Restart your computer and press <F2> to enter BIOS setup.

3. Using the arrow keys, highlight Smart Battery Calibration in the Boot menu.

4. Press <Enter> to start calibration process. The calibration usually takes 3 to 5

5. When the calibration process is complete, recharge the battery fully.

60 Users Manual

Calibration Notes:

You should start the battery calibration process with a fully charged battery,
battery status LED is green. The power meter may not show 100%.

Before you commence the battery calibration process you should fully charge,
then fully discharge and finally fully recharge the battery again.

hours depending on the current battery charge.

Using System Setup

The System Setup (BIOS) program enables you to configure your computer hardware
and set security and power-savings options. The settings you choose are stored in
battery-maintained CMOS memory that saves the information even when the
computer’s power is turned off. When your computer is turned back on, it is configured
with the values found in this memory.

Run System Setup if you get a message prompting you to run the program. You may
also want to run System Setup, particularly the first time you use your computer, to set
the time and date, use security or power-management features, or alter the settings of
other features.

BIOS Caution:

If you are not familiar with BIOS setup and what the parameters mean, seek
help from a person who is knowledgeable. Incorrect settings may cause your
system to “Crash”.

Your computer’s version of System Setup may not include all the fields listed
here or may include additional fields. Field names and order of appearance
can vary according to the version of the BIOS (basic input/output system) on
your computer.

Starting System Setup

To start System Setup, turn on your computer and then press <F2> and hold until the
System Setup screen appears.

Table 3. System Setup Menus

Menu Function

Main Changes the basic system.

Advanced Configures advanced features on your computer.

Security Enables security features, including passwords.

Boot Specifies the order of boot devices and configures boot

Exit Specifies how to exit System Setup.

features.

To open the menu you need to use, use the left or right arrow keys to select the menu
name.

Using System Setup 61

Table 4. System Setup Navigation Keys

Navigation Key Function

<F1> Displays the General Help window.

<Esc> Exits the current menu.

<Up Arrow> or
<Down Arrow>

<Left Arrow> or
<Right Arrow>

<F5> Scrolls backwards through the options for the highlighted field.

<F6> Scrolls forward through the options for the highlighted field.

<F9> Sets the parameters for the current menu to their default values.

<F10> Save changes and exit system setup.

<Enter> Executes commands or opens a submenu.

Moves the cursor up and down between fields.

Selects different menus. Pressing the <Esc>key at the Main
menu brings you to the Exit menu.

62 Users Manual

Changing Booting Priority

The Boot menu in System Setup enables you to select the booting device and to set
booting options.

Boot Device Priority field enables:

You to select the order in which the computer attempts to boot from different devices.
The field has four (4) options: CD-ROM Drive, Removable Devices, Hard Drive

and MBA UNDI (Bus2 Slot5).

To change the booting device priority, choose the device positions by completing
the following:

1. At startup, press <F2> to open System Setup.

2. Use <Right Arrow> to select the Boot menu.

3. Press <Enter> to enter Boot Options.

4. Highlight the 1

5. Press <F6> key until the option moves up in the list to the desired position or press
<F5> key until the option moves down in the list to the desired position.

6. Press <F10> to exit and save your changes.

7. Press <Enter> again to restart the computer.

st Boot Device option with <Up Arrow> or <Down Arrow> keys.

Changing Booting Priority 63

Configuring the Password

Setting the Supervisor Password

By configuring a supervisor password, you can restrict system access to authorized
users only.

To use a fingerprint in the fingerprint sensor installed model, refer to the
supplied manual for the fingerprint sensor.

1. Select the Security menu in the System Setup. To enter System Setup, see “Starting
System Setup” on page 61.

2. On the Set Supervisor Password item, press <Enter>.

3. Enter a password, press <Enter>, re-enter the password for confirmation, and
press <Enter> again.

4. When a message confirming the password configuration appears in the [Setup
Notice] window, press <Enter>.

Setting the User Password

You can configure user passwords so that other users can use the system.

On the Set User Password item, press <Enter>, and complete step 3-4 of "Setting the
Supervisor Password".

64 Users Manual

Before configuring a user password, a supervisor password must have been
configured.
Users can start the system with their user password, but cannot enter into the
System Setup.
Deactivating the supervisor password also deactivates the user password.

Activating the Booting Password

Before activating the booting password, the supervisor password must have
been configured.

Set the Password on boot option to [Enabled].

From now on, system booting will not proceed without the password.

Activating the Hard Disk Drive Password

Activating the hard disk drive password prevents the currently installed hard disk drive
from being used in other systems.

Before activating the hard disk drive password, the supervisor password must
have been configured.

On the Set HDD 0 Password item, press <Enter>, and complete step 3-4 of
Configuring the Supervisor Password.

Deactivating the Password

1. On the password to delete, press <Enter>. (e.g. supervisor password)

2. Enter the current configured password, and press <Enter>.

3. Leave the 'New Password' and 'Confirm New Password' field empty, and press
<Enter> to deactivate the password.

Configuring the Password 65

Using Power Management Options

Your computer includes Power Management options that can help the battery charge
last longer and extend the life of the battery. Power-management options will slow
down or shut off system components when the components are not being used.

Power management may slow down system performance. Your computer runs fastest
with the power cord attached, when power management is disabled.

In the next sections, basic and advanced methods of power management will be
discussed.

Basic Power Management Schemes

This section discusses the basic schemes of power management when the computer is
operating on battery power or using AC power.

Standby vs. Hibernation

Hibernation is a state where the contents of memory are stored in a special file
on the hard disk, and Standby simply keeps a small holding current through
the memory to keep the data. You are more likely to sustain loss of data in
Standby mode so it is recommended to save all open files before entering
Standby.

To enter the power management window complete the following:

1. Click Start > Control Panel > Performance and Maintenance.

2. Click icon to display the Power Options Properties window.

66 Users Manual

Changing Devices:

Do not change PC Cards while in standby or hibernate modes.

3. Click the Power Schemes tab to display the basic power management options.

Power Schemes Tab

4. Select the time that you wish each of the following actions to occur in Battery and
AC power mode.

• Turn off monitor

• Turn off hard disks

• System standby

• System hibernates

Turning off the monitor and HDDs will save a substantial battery power, therefore
when in battery only mode select the shortest time practical.

a Hibernate Mode (Power Management or Manual Method)

When hibernation is used, your computer turns off and when you power up again,
everything is restored exactly as you left it—including programs and documents
you may not have saved or closed. Everything in memory gets saved to the HDD,
and the monitor and hard disk get turned off.

Using Power Management Options 67

If You Reinstall Windows:

You should re-establish hibernate in power options by opening Power

Options Properties window and click on the Hibernate tab then click
“Enable Hibernation”.

Hibernate Tab

Frequent Interruptions:

If you experience frequent interruptions, you might also consider putting your
computer into automatic hibernation after a specified number of minutes using
the power management options.

a Standby Mode (Power Management or Manual Method)

Standby is used mainly for conserving battery power in your notebook computer. It
also gives you the benefit of getting right back to your work without waiting for the
computer to restart. Standby turns off your monitor and hard disks, placing your entire
system in a low-power state. When you return to your computer, restores your desktop
exactly as you left it. It is recommended that you do not enter standby mode with less
than 20% battery power.

5. Click OK to set your power management options and close the window.

68 Users Manual

Rest Key:

The manual <Fn+Esc> key combination will not activate Standby or Hibernate
modes while you are playing a multimedia program or have an active USB
device connected.

Advanced Power Management Schemes

This section discusses the advanced power management schemes. There are two
buttons that you can use to manually conserve power.

To enter the power management window complete the following:

1. Click Start > Control Panel > Performance and Maintenance.

2. Click icon to display the Power Options Properties window.

3. Click the Advanced tab to display the advanced power management options.

Advanced Tab

Power & Sleep Button
Programming Windows

4. Select the mode (Do nothing/Ask me what to do/Standby/Hibernate/Shut
down) assigned to the Power button and/or Rest <Esc> key. Also select the action
(Do nothing/Standby/Hibernate) associated with closing the computer lid.

The “Rest” key is assigned to the <Fn+Esc> key combination. See ”Basic
Power Management Schemes” on page 66 for a better understanding of
Standby and Hibernate modes.

5. Click OK to set your power management options and close the window.

You can return to normal operation after you have used one of the “Power
Management” buttons by quickly pushing and releasing the Power button.

Using Power Management Options 69

Using the Hard Drive

Your computer includes a removable IDE (integrated drive electronics) hard drive. The
IDE hard drive can store the data and programs your computer uses. The drive plugs
into a connector on the system board.

The hard drive that comes with your computer has already been formatted. Do
not format the hard drive. Doing so destroys all data contained on the drive. If
you need to format a new drive, or want to erase all data on your existing hard
drive, refer to the manual for your operating system.

Installing/Reinstalling a HDD

To install a new HDD you should contact a Service Centre, replacement of the HDD is
not a user task. You should follow the instructions below before the HDD is replaced.

• Back up data files of your old hard drive.

• For system boot with CD-ROM, under the Boot menu in System setup, set

Bootable CD Check to Enabled and set Boot Device Priority is ordered starting
from the [DVD/CD-ROM].

When you are ready to install the new HDD, use the Recovery CD-ROM to install the
device driver.

(Re)Installing Windows and Device Drivers

Use System Recovery CD to (re)install OS and System Software CD to (re)install
device drivers. For details, see “Reinstalling Windows XP” on page 95 and
”Reinstalling Software” on page 93.

70 Users Manual

Video Features and Configuration

Resolution and Colour Depth

The resolution of the LCD is the sharpness of the image it can display. Resolution is
measured by the number of pixels (individual dots) displayed on the entire screen. In
general, the more pixels the LCD can display, the better the image.

The number of colours the LCD can display is measured by how many bits the LCD
uses to represent each pixel:

• 16-bit colour can support 64 K (65,536) colours.

• 32-bit colour can support 16 M (16.8 million) colours.

All these video modes can be displayed on an external monitor. However, if you
disconnect an external monitor that was attached to your computer and then start the
computer, the LCD may revert to a different resolution than the one you chose for the
external monitor.

Adjusting the LCD Brightness

There are 9 levels of LCD brightness (1: Dimmest ~ 9: Brightest). The default LCD
brightness setting is level 5. Whenever you change the power source, the brightness
level is changed to the following setting:

• When operating on AC power : Level 9 (Brightest)

• When operating on battery power : Level 3 (Slightly dimmer)

Once the LCD brightness has been changed, the changed setting will be maintained
after restarting the computer. When the power source is changed (AC to battery or
battery to AC) while in operation, both the default brightness settings described above
will be restored.

You can adjust the LCD brightness by pressing <Fn+Up Arrow> or <Fn+Down
Arrow> on the keyboard.

Video Features and Configuration 71

Configuring Display Features

The following sections describe how to configure the display settings on your
computer.

Display Resolution Notes:

When Windows XP is initially installed it will automatically adjust the resolution
to maximum available.

Changing Colour Depth and Resolution

To change the colour depth and resolution of your LCD:

1. Click Start > Control Panel > Appearance and Themes.

2. Click icon. The Display Properties window appears.

3. Click the Settings tab. The Settings screen appears.

4. To change the colour depth, click the arrow next to the Colour quality palette and

select the available colour depth you want.

5. To change the resolution, click and drag the slider under the Screen resolution
until you select the available resolution you want.

6. Click OK.

7. Follow the prompts that appear on the screen.

Using PowerMizer

The PowerMizer technology supplied with your graphics adapter to extend battery life.

To activate PowerMizer proceed as follows:

1. Click Start > All Programs > Appearance and Themes > Display > Settings
tab > Advanced > GeForce4 4x0 Go xxM tab > Additional Properties >
PowerMizer tab.

2. Move the slider to the left to set to the Maximum Power Savings.

72 Users Manual

PowerMizer Use Limitations

Activating PowerMizer will reduce your graphic card performance.

SIC (Smart Inverter Control) Function

SIC is a function that adjusts the LCD brightness automatically when the system is
operating on battery power so that you can use the battery for a long time.

SIC function is activated as a default. If you feel the screen is too dim, deactivate the
SIC function following the procedures below.

1. Restart the system.

2. Press <F2> key to run System Setup.

3. Change the Smart Inverter Control item in Advanced menu to [Disabled].

4. Use the screen brightness adjustment keys on the keyboard to adjust the LCD

brightness to the comfortable level.

Video Features and Configuration 73

Using External Display Devices

Using external display devices such as a monitor, projector, TV, etc allows you to view
screen images alternatively or simultaneously on each device. You can also split a
screen into two display devices, or view different images on each display device. Using
external display devices is especially useful when you are giving a presentation or
watching a movie through your TV.

Switching Display Devices Using the Shortcut Key

You can watch the screen through either the LCD or an external display device, or you
can even watch the screen through both the LCD and an external display device
simultaneously.

1. Connect the external display device (e.g. a monitor or a projector) to the
corresponding port of the system.To connect a TV, connect the TV to the TV
output port of the system.

2. Press the <Fn+F4 / LCD/CRT> key. Provided that an external display device is
connected, the display option changes in LCD > CRT > LCD+CRT order
whenever the <Fn+F4/LCD/CRT> key is pressed.

74 Users Manual

Provided that multiple external display devices are connected, the display
order would be LCD > CRT > LCD+CRT > TV > LCD+TV > CRT+TV whenever
the <Fn+F4 / LCD/CRT> key is pressed. You cannot view the screen via the
LCD, CRT, and TV simultaneously.

In the full screen DOS mode of Windows, <Fn> + <F4 / LCD/CRT> keys do
not work.

If you configure display device to display on both LCD and CRT, and start the
system with a language using 2-byte characters, some vertical noises may
appear on the screen.

Using nView to View Extended Screen

You can expand the screen into two display devices and work conveniently in a wide
workspace.

1. Connect the external display device (e.g. a monitor or a projector) to the
corresponding port of the system. To connect a TV, connect the TV to the TV
output port of the system.

2. Click Start > Control Panel > Appearance and Themes > Display.

3. On the [Display Properties] window, click Settings tab > Advanced > nView tab.

Select the desired item, and click Apply.

nView provides the following three display modes:

• Standard Mode

The Screen image is displayed only through the primary device, LCD.

• Duplication Mode

The same screen image is displayed through both the primary device, (the LCD)
and the external display device.

• Horizontal/Vertical Span Mode

The screen image is spanned to the primary device(the LCD), and the external
display device.

Horizontal Span ModeDuplication Mode Vertical Span Mode

Pressing the <Fn+F4 / LCD/CRT> shortcut key combination switches the
display mode between the standard and duplication modes of nView.

Using External Display Devices 75

Using Dual View to View Extended Screen

You can expand the screen into two display devices and work conveniently in separate
workspaces.

In Dual View mode, you can select the screen resolution and color quality for each
display device, as if there were two separate graphics cards.

1. Connect the external display device (e.g. a monitor or a projector) to the
corresponding port of the system. To connect a TV, connect the TV to the TV
output port of the system.

2. Click Start > Control Panel > Appearance and Themes > Change the screen
resolution.

3. Click the monitor '2' icon, select the 'Extend my Windows desktop onto this
monitor' check box, and then click Apply.

76 Users Manual

4. Click OK. The primary display device(the LCD) is indicated as '1', and the
secondary display device is indicated as '2'. Now you can use each of the two
display devices as independent display devices.

2 : Secondary1 : Primary

When using Dual View, it is recommended that LCD is kept as '1', the primary
display device.

If the screen of the secondary display device is displayed at 640x480 pixels,
with 256 colors, change the settings to the desired screen resolution and color
quality in the [Display Properties] window.

Deactivating Dual View Mode

Click the monitor '2' icon, clear the 'Extend my Windows desktop onto this monitor'
check box, and then click Apply.

To move a window between display devices in nView or Dual View mode.

Click the title bar of the window in the primary display device(1, the LCD), and
drag it to the secondary display device (2). The window is move to the
secondary display device.

Using External Display Devices 77

Using Options

You can select these options at purchase:

• Wireless communication module

(802.11b, bluetooth)

• Fingerprinter recognition system / scroll wheel

• Memory stick slot

You can purchse these options separately:

• Extra battery pack (3 cell/6 cell)

• Battery charger

• Ear set

The options that are available may change periodically. Contact your reseller for
updated information on current and new options.

78 Users Manual

Memory Modules

You can increase system memory by installing optional memory modules.

To avoid possible system problems, use only approved memory modules in
your computer. Please consult the appropriate sections of this manual,
Samsung Technical Support, or the support Web site (www.samsungpc.com)
for additional information.

Before You Install Memory

To prevent personal injury and damage to the equipment, follow the
precautions listed here before installing a memory module.

Take the following precautions when installing a memory module:

• Before you remove the memory module compartment door, turn off the

computer, unplug the power cord, and remove the battery. Also, disconnect any
peripheral devices.

• Before handling a memory module, discharge any static electricity by touching

a grounded surface or using a grounding wrist strap.

• Do not insert objects with conductive material, such as metal screwdrivers or

graphite pencils, into the memory-module compartment.

• Be careful in handling the metal plate of the memory door.

Using Options 79

Installing a Memory Module

Handle a memory module carefully. Hold them only by the edges.

To install a memory module:

1. Turn the computer over so that the bottom faces up.

2. Using a screwdriver, remove the screw that holds the memory-module

compartment door in place.

Screw

3. Grasp the edge of the door and pull the door off the chassis.

Memory Module Precautions:

When removing the module, pull on the plastic portion of the connector slots
tabs only. Do not pull on the metal part of the tabs, this may damage the tabs.

4. Remove the installed module if necessary.

a. Pull the tabs on the connector slot outward slightly, until the edge of the

memory module pops up.

b

a

a

connector slot tab

3

80 Users Manual

b. Hold the memory module by the edges and pull it forward out of the

compartment.

5. Align the connector on the memory module with the connector of the slot.

6. Push the memory module into the slot at a slight angle (~30

are fully engaged.

6

7

7. Push down on the edge of the memory module until the module snaps into place.

8. Align the memory module compartment door with the compartment and push the

door down until it snaps into place.

9. Reinstall the screw you removed in step 2.

o

) until the connectors

Wireless Communication Module

You have one of these options on your computer:

• No wireless communication module

• 802.11b

• Bluetooth

Check the option your computer has, and see “Configuring the Network Environment
Settings for Wireless Network (WLAN)” on page 26 or the Quick Guide for Samsung
Bluetooth Software for details.

Fingerprint Recognition System

You have either fingerprint sensor or scroll wheel on your computer. For details on
using the fingerprint recognition, read the Quick Guide for Fingerprint Recognition
Software and Fingerprint Recognition Software Help files.

Using Options 81

Troubleshooting

Complete the following in the order presented until your system is functioning
properly. If all of the steps below fail then contact your local reseller for assistance.

 Questions and Answers

Please see “Questions and Answers” on page 83 for assistance in correcting any
computer operational problems.

 Check the Connections

Verify all of the power and peripheral cables are securely plugged into their sockets
and that your system and power supply is on.

 Norton AntiVirus

Run Norton AntiVirus to ensure a virus is not affecting your computer.

To run Norton AntiVirus proceed as follows:

Click Start > All Programs > Norton AntiVirus > Norton AntiVirus 2002.

The Norton Antivirus Subscription on your Samsung notebook will expire within 3
months. It is your responsibility to update the virus definitions, and renew subscription
with Symantec when the subscription expires.

 Windows Help and Support

Run Windows Help and Support to find problem that may be affecting your
computer.

To run Windows Help and Support proceed as follows:

Click Start > Help and Support.

 Reinstalling Software

If for some reason your system crashes you may corrupt your HDD, Windows
operating system and/or some of your device drivers. If this is the case, use System
Recovery CD to reinstall OS and System Software CD to reinstall the corrupt device
drivers.

82 Users Manual

System Recovery Precaution:

Before you start restoring your windows operating system insure you backup
all data on your hard drive.
Samsung is NOT responsible for any data loss.

Questions and Answers

This section provides information on possible problems, solutions and other references
for system use.

Windows Related

Q1 The system does not shutdown properly.

A When the system does not shutdown normally, press and hold the Power button

until the system manually shuts off. If the Power-Saving Mode is configured into
the Power button, press and hold for more than 4 seconds to shut the system off.
When the system is turned on after such manual shutdown, Scandisk will run to
check errors in the system.

Q2 The system freezes during program operation

A1 There is an error with the program currently being used. Press the <Ctrl>, <Alt>,

and <Delete> keys simultaneously and click and Task in the [Windows Task
Manager] window.

A2 There is an error with the Windows OS. Reboot the system by using the Power

button.

Display Related

Q1 The LCD screen is blank.

A Adjust the LCD screen brightness. Use the <Fn+Up Arrow>, <Fn+Down

Arrow> keys.

Q2 The screen saver disturbs screen viewing during Media Player or video file

operation.

A Under the Media Player Options, in Player > Enable Screen Saver During Use,

uncheck the box and restart the player.

Troubleshooting 83

Q3 In DOS mode or with a screen resolution lower than 1024x768 pixels,

pressing the Fn+F2 key does not display the icon clearly.

A The screen image is extended across the LCD size when the screen resolution

setting is lower than 1024x768 pixels. If the icon appears unclear, it is because
the video chip does not support this function, but it does not affect the system
performance.

Q4 When the horizontal or vertical span function is used, connecting an

external monitor with a screen resolution lower than 1024x768 pixels in
Windows XP or 2000, the screen image is not displayed on the external
monitor.

A The horizontal or vertical span mode does not support a screen resolution lower

than 1024x768 pixels.
Set the screen resolution to higher than or equal to 1024x768 pixels.

Q5 Running the program after configuring the horizontal or vertical span mode

displays a program window spanned to the LCD and the external display
device.

A Since Dual View (Extended Desktop) mode enables each display device to

operate as if there were two separate graphics cards, you can select the screen
resolution and color quality for each display device. Therefore dual view mode
displays a program window on either the LCD or the external monitor, while the
horizontal or vertical span mode may display a program window onto the LCD
and the external monitor because the horizontal or vertical span mode displays a
single screen image spanned over two display devices.

Q6 In DOS mode, changing the full screen DOS mode by pressing

A The DOS mode which supports 2 Byte characters such as Korean and Japanese

Q7 In the following cases, the screen blinks or displays noise for a short time:

A This may happen while the video driver is examining the connected device.

84 Users Manual

<ALT+Enter> key displays a broken image for a short period.

runs in graphic not in text mode. In this case, a broken image may be displayed
while changing the video mode settings.

(Clicking the nView tab, changing the resolution, changing the display
device, removing the AC adapter, restarting the system, or changing the
PowerMizer level)

Q8 When I connect a projector, and change the setting to display screen image

on both the LCD and the projector by pressing <Fn>+<F4 / LCD/CRT>
keys, screen is not displayed properly.

A Press <Fn>+<F4 / LCD/CRT> keys once again.

Modem Related

Q1 I cannot hear the modem sound.

A1 Check that the telephone line is properly connected to the modem.

A2 Check that the modem driver is installed properly.

1. Click Start > Control Panel > Performance and Maintenance > System.

2. Select Hardware tab > Device Manager > Modems in the System Properties

window, and check if there is a yellow exclamation mark on the installed modem
icon. If there is, delete the modem device driver and reinstall the driver, because
the yellow exclamation mark represents a not properly installed driver.

3. If there is no yellow exclamation mark, double-click the installed modem, and

click Diagnostics tab > Query Modem in the Modem Properties window to
diagnose the modem.

No message in either of Command and Response in the Diagnostics tab means
that the modem is not operating properly.

Diagnose the modem again after restarting the system or reinstalling the driver.

(You have to exit all programs using modem in the advance of diagnostics of the
modem).

A3 Although I can make a connection with the modem, I cannot hear the dial tone

and modem connection sound. In this case check the following list:

1. Click Start > All Programs > Accessories > Entertainment > Volume Control.

2. Clear the Mute check box in the Telephone Line item.

(Depending on the sound driver, it may be displayed as another name such as
Modem, Phone, Mono. If there is no corresponding item, click Options >
Properties > Volume Control, select 'Playback', and select the 'Telephone Line'
under the 'Display the following volume controls'. Click OK.)

Troubleshooting 85
