Samsung Bonn-E, NP-R518, NP-R520, NP-R522, Bonn-C Schematic

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

Sheet 1.
Sheet 2-7.
Sheet 8.

BONN-E/BONN-C

Sheet 9
Sheet 10-12.

Sheet 13-17.
Sheet 18.

CPU :
Chip Set :

Intel Penryn
PM45 & ICH9M

Graphic :

M96/M92/gDDR3 1g bit

Sheet 19.
Sheet 20-24.

Sheet 25.

Sheet 36-38.

C

Remarks :

Montevina Platform

Sheet 39-43.

Cover
Diagram (Block/Power) & Annotations

Clock Generator -CK505
Thermal Sensor & FAN

Penryn-6M CPU
Cantiga-MCH

DDR2 SODIMM A
DDR2 SODIMM B
ICH9-M
SPI ROM & Debug Connector

GFx_External_M9XSheet 26-31.
Graphics_Memory_gDDR3 1g bitSheet 32-35.
Graphic Interface

High Definition Audio (ALC272 GR)

D

C

LAN_Marvell_88E8057Sheet 44.

Model Name :
PBA Name :
PCB Code :

BONN-E/BONN-C
MAIN

GCE : BA41-01060A
NAN : BA41-01061A
HAN : BA41-01062A

Dev. Step :

MP
Revision : 1.0
T.R. Date :

2009.04.11

Sheet 47.

Sheet 51.

Sheet 54.

Sheet 60-61.

Express_CardSheet 45.
MultiCard_AU6336 (3 in 1)Sheet 46.
PCIE_Minicard_Slot

SATA I/F CONNSheet 48.
MICOM_Renesas2110Sheet 49.
Micom Glue LogicSheet 50.

LED_Switch
USB PortSheet 52.
USB I/F DevicesSheet 53.
HDA_Modem
PWR_MV_ChargerSheet 55.
PWR_MV_3V_5VSheet 56.
PWR_MV_MemorySheet 57.
PWR_MV_CantigaSheet 58.
PWR_CPU_MV_ISL6266Sheet 59.
PWR_GFX_MV_Ext

BB

PWR_MV_SwitchedSheet 62.
PWR_MV_DisChargerSheet 63.

Design

CHECK

APPROVAL

2 USB Port & Power S/W SUB B’DSheet 64.
SATA ODD SUB B’DSheet 65.
EMC Capacitor & MountSheet 66.

Test PointSheet 67.

A

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MAIN

COVER

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

1 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

4

Owner :

SEC Mobile R & D

Signature :

DRAW

CHECK

X

3

APPROVAL

MODULE CODE

2

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4

PG 28,29

PG 26

PG 27

HDMI

LCD

CRT

Clocking

CK-505

PG 12

HDMI

LCD

CRT

3

FAN

PG 8

CPU

Thermistor

(TBD)

PG 8

Mobile Processor

Penryn-6M

FSB 1067

478pin

PG 9-11

L2 Cache : 6/3MB

FSB
800/1067 MT/S

GMCH-M

Cantiga-PM

PM45

1329 FCBGA

PG 13-17

Channel A (Standard)

Dual channel

Channel B (Reverse)

2

CPU

DC/DC

IMVP-6

DDR II 667/800

DDR II 667/800

Charging

Circuit

ON BOARD

Termination

PG 18,19

DDR II
SODIMM 0

DDR II
SODIMM 1

PG 18

PG 19

Smart
Battery
Module

1

DC/DC

D

VCCP / DC-DC

PG 48

DDR II Power

PG 47

C

High Definition Audio

B

A

SPKR R

SPKR L

PG 31

HP
MIC-IN

Aud.

AMP

2P

Direct Media Interface

USB 0,2,6

PG 42, 52

ANT

PG 43

Bluetooth

PG 43

Camera

OPTION

Audio

ALC272

PG 30

PG 33

2P

PG 31

RJ11

2pin cable type

PG 25

PG 38

PG 53

MDC

Modem

SPI ROM

SATA

SATA ODD

Sub board

12P

Samsung

Samsung

PG 44

SPI

HDD

SATA 0

SATA 1

Confidential

Confidential

USB 0,2,6

USB 5

USB 8

HD Audio

HD Audio

HD Audio

12P

PG 38

34

x4, 1.5V

CLINK

ICH9-M

676 BGA

PG 20 - 24

LPC

3.3V LPC, 33MHz

80 Port

PG 25

Lane 4

PCIE x1

Lane 1

PCIE x1

USB 1

PCIE x1 Lane 2

PCIE x1 Lane 3
USB 7

USB 4

MICOM

H8S-2110B

TMKBC (TBD)

LED

PG 41

PG 39

2

PG 40

Touch

PAD

KBD

PG 40

DRAW

CHECK

APPROVAL

MODULE CODE

52P

PG 37

52P

PG 37

Touchpad

LED

PG 40

MS Yang

MK Kim

undefined

BL Lee

88E8057

PG 34

Mini Card 1

(WLAN)

Mini Card 2

(HSDPA)

Express Card

PG 35

3 IN 1

AU6366-MWF

PG 36

DATE

12/05/2008

DEV. STEP

MP

REV

REV 1.0

LAST EDIT

TITLE

ANT

SD(SDHC)

MMC

BONN-E

MAIN

BLOCK DIAGRAM

April 11, 2009 10:05:58 AM

1

RJ45

PG 34

PG 36

PG 36

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

2 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

SCHEMATIC ANNOTATIONS AND BOARD INFORMATION

D D

4

3

2

1

BOARD INFORMATION

PCI Devices

Devices IDSEL#
Cardbus

USB

Hub to PCI
LPC bridge/IDE/AC97/SMBUS

Internal MAC
AC Link - B­GLAN - -

C C

AD25

AD29(internal)

AD30(internal)
AD31(internal)

AD24(internal)

REQ/GNT#
3

-

-

-

-

Interrupts
A,B,C

USB2.0 #0 (USB0) : A
USB2.0 #1 (USB1) : D
USB2.0 #2 (USB4) : C
USB2.0 #3 (USB5) : E
USB2.0 #4 (EHCI) : H

­B

E
F

Crystal / Oscillator

TYPE FREQUENCY DEVICE

LCD Pannel Detect

Devices Resolution PANNEL_DETECT_0

32.768KHzCrystal
10MHzCrystal MICOM HD64F2169/2160

14.318MHzCrystal CLOCK-Generator CK-505
25MHzCrystal LAN Intel LAN

ICH8-M

(TBD)

USAGE
Real Time Clock

Voltage Rails

VDC
VCC_CORE
GFX_CORE Core Voltage for GPU
P1.05V (VCCP)
P3.3V_MICOM
P1.5V

P1.8V_AUX
P0.9V
P3.3V
P3.3V_AUX
P5.0V

P5.0V_ALW 5.0V always power rail

B B

PORT # ASSIGNED TO

A A

Primary DC system power supply (7 to 21V)
Core Voltage for CPU

VTT for CPU, Crestline & ICH8-M

3.3V always power rail (for Micom)

1.5V switched power rail (off in S3-S5)

1.8V switched power rail (off in S3-S5)P1.8V

1.8V power rail for DDR (off in S4-S5)

0.9V power rail for DDR (off in S3-S5)

3.3V switched power rail (off in S3-S5)

3.3V switched on power rail (off in S4-S5)

5.0V switched power rail (off in S3-S5)

5.0V switched on power rail (off in S4-S5)P5.0V_AUX

USB PORT Assign

0

SYSTEM PORT 0

1

SYSTEM PORT 1
SYSTEM PORT 2

2

NC

3

NC4
Bluetooth

5
6

Mini PCI Express 2

7

Camera

8

NC

9 NC

4

PCI Express Assign

PORT # ASSIGNED TO

NC

0
1

Mini Card 1 (WLAN)
NC

2
3

LOM
Mini Card 2 (ROBSON or DVB-T)4

5

NC

Samsung

Samsung

Confidential

Confidential

3

2

I C / SMB Address

Devices Address
ICH8-m

CPU Thermal Sensor
SODIMM0
SODIMM1

CK-505M (Clock Generator) 1101 001x

Master
0111 101x
1010 000x
1010 010x

0011 010x 34h -Thermal Sensor on SODIMM1

REVISION HISTORY

See rev notes for more information.

DRAW

CHECK

APPROVAL

MODULE CODE

2

Hex

­7Ah
A0h
A4h

D2h

MS Yang

MK Kim

BL Lee

undefined

Bus
SMBUS Master

Thermal Sensor

-

-

-30hThermal Sensor on SODIMM0 0011 000x
Clock, Unused Clock Output Disable

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MAIN

BOARD INFO

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

3 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

POWER DIAGRAM

D

KBC3_SUSPWR

(CHP3_S4_STATE*)

AC Adapter

Battery DC

C

VDC

P3.3V_MICOM

MICOM

ICH9-M

P1.8V_AUX

P0.9V

P5V_AUX

SODIMM (DDR II)

Cantiga

DDR II-Termination

ICH

P5.0V_ALW

USB

P12.0V_ALW

Samsung

B

Samsung

P3.3V_AUX

THERMAL SENSOR

ICH8-M
LAN
EXPRESS
MDC

KBC3_PWRON

(CHP3_SLPS3*)

P1.05V

P1.8V

P0.9V

P5.0V

P1.5V

EGFX_CORE

P3.3V

PENRYN
Cantiga

ICH9-M

PEG
GDDR-3 for PEG
ESATA-REPEATER

DDR II-Termination

ICH9-M
CRT
MICOM

ODD
TOUCHPAD CAMERA

PENRYN
CANTIGA
ICH9-M
CLOCK
EXPRESS CARD
HSPA

PEG

CLOCK
MEMORY
SPI
LCD
LOM

KBC3_VRON
P1.1V_PWRGD

VPU_CORE

HDD
THERMAL SENSOR
HDMI
AUDIO

2IN1

MCH

EXPRESS

ICH

WLAN

PEG

HSPA

AUDIO

PENRYN

LIDSWITCH
BLUETOOTH
LEDS

D

C

B

Power On/Off Table by S-state

Rail

State

+V*A(LWS)

+V*LAN

+1.8V_AUX

A

+0.9V

+V*AUX

+V

+V* (CORE)

P1.2V_LAN

LAN

P1.8V_LAN
P2.5V_LAN

Confidential

S0

ON

ON

ON

ON

ON

S4

ON

ON

ON

ON

ON

4

S5

S3

Confidential

S5-S4

3

LAN

S3

S0

A

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MAIN

POWER DIAGRAM

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

674

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4

220V

Adapter

MICOM 3V ( TBD A )

1.8V ( TBD A )

Battery

3

2

1

POWER RAILS ANALYSIS

Rev. 0.6 (060920)

D

5.0V_AUX ( TBD A )

3.3V_AUX ( TBD A )
CPU CORE ( TBD A )

1.05V ( TBD A )

1.5V ( TBD A )

1.25V ( TBD A )

3.3V ( TBD A )

5.0V ( TBD A )

1.8V_AUX ( TBD A )

C

B

0.9V( TBD A )

PEX IO (TBD A)

VDC INV ( TBD A )

RTC_Battery

VGA CORE (TBD A)

1.05V

CPU CORE

1.05V (VCCP)

1.5V

1.05V (MCH CORE)

1.05V (VCCP)

1.5V

1.25V

3.3V

1.8V_AUX

1.05V

1.5V

3.3V

3.3V_AUX
5V
5V_AUX
RTC_Battery

1.0V-1.1V (EGFX CORE)

1.8V

1.2V (PEX IO)

3.3V

1.8V_AUX

0.9V

0.1 A (TBD)

41 A (TBD)

4.5 A (TBD)

0.13 A (TBD)

7.7 A (TBD)

4.48 A (TBD)

0.125 A (TBD)

2.43A (TBD)

0.33 A (TBD)

3.79 A (TBD)

1.13 A (TBD)

2.4A (TBD)

0.374 A (TBD)

0.209 A (TBD)

0.001 A (TBD)

0.001 A (TBD)

0.006 A (TBD)

17.75 A (TBD)

6.53 A (TBD)

1.75 A (TBD)

0.67 A (TBD)

Samsung

Samsung

3.1 A (TBD)
1 A (TBD)

ITP

Penryn-6M

( 35 W )

Cantiga

GMCH

(8 - 8.5 W )

ICH9-M

( ~ 2.0 W )

PEG

DDR-2

(Dual slots)

3.3V

3.3V

3.3V

3.3V

3.3V

3.3V
5V

5V

5V

0.75 A (TBD)

0.25 A (TBD)

0.2 A (TBD)

0.01 A (TBD)

0.015 A (TBD)

0.06 A (TBD)

0.07 A (TBD)

1.5 A (TBD)

0.22 A (TBD)

Thermal
Sensor

CLOCK

KeyBoard

KBD LED

SPI

HD Audio

ODD

SATA

SATA HDD

MICOM 3V

3.3V

MICOM 3V

1.8V

3.3V

3.3V_AUX

3.3V_AUX

3.3V
5V

3.3V

3.3V_AUX

1.5V

3.3V_AUX

0.08 A (TBD)

0.08 A (TBD)

0.1 A (TBD)

0.6 A (TBD)

0.1 A (TBD)

1.5 A (TBD)

0.5 A (TBD)

0.75A (TBD)

0.5 A (TBD)

KBC

PWR LED

LAN

SD Card

Mini Card X 2

MDC

C

B

( ~ 5.0 W )

P3.3V_AUX
P1.2V_LAN

P1.8V/2.5V_LAN

0.08 A (TBD)

0.29 A (TBD)

0.15 A (TBD)

LAN (88E8055)

1.8V

3.3V (LCD 3V)
19V (VDC INV)

4 A (TBD)

0.67 A (TBD)

0.5 A (TBD)

Confidential

Confidential

gDDR3

LCD

5V

5V

5V

5V

0.16 A (TBD)

1.5 A (TBD)

2 A (TBD)

0.2 A (TBD)

FAN

Audio AMP

USB (x 3)

Touch Pad

A

Value by Datasheet/Application notes

4

3

(Value by measurement)

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MAIN

POWER RAILS

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

5 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D D

POWER

S/W

4

C C

3

P3.3V_MICOM

AC_DC / Battery

Adapter

ICSL6256

Battery

2

2-1) P12.0V_ALW

3

B

P5.0V_ALW

P3.3V_MICOM

4

KBC

110ms Delay

4) POWER_SW*

2) VDC

P3.3V_AUX & P5V_AUX

TPS51120

7

5

8) KBC3_SUSPWR

Host Boot / ME Off

(SLPS4* = S4_STATE*) > (SLPM* = SLPS3*)

M-1) KBC3_DDR_PWRON (TBD) = 8) KBC3_SUSPWR
M-2) KBC3_ME_PWRON = 15) KBC3_PWRON

Host / ME Boot

(SLPS4* = S4_STATE*) > SLPM* > SLPS3*

Host S5 / ME Boot

(SLPS4* = SLPM*) > S4_STATE* > SLPS3*

8

8) CHP3_SLPS5#/4#/3#

7) KBC3_RSMRST#

17) KBC3_PWRGD

15)VRM3_CPU_PWRGD

5) KBC3_SUSPWR

9) KBC3_PWRON

13) KBC3_VRON

13

SC486

9) KBC3_PWRON

AP4435

9-1

9-1) KBC3_PWRON_INV#

6) P5.0V_AUX

17

9

10) P1.5V

10) P5.0V

Samsung

Samsung

6) P3.3V_AUX

9

9) KBC3_PWRON

6

6) P3.3V_AUX

A A

LOM

Marvell

Sheet 46-47

4

6-1) P1.2V_LAN

6-1) P1.8V/P2.5V_LAN

BCP69

Sheet 46

11) VCCP3_PWRGD

Confidential

Confidential

3

10-1) ICH_CORE (P1.05V)

10

9) KBC3_PWRON

6) P1.8V_AUX

3

17) KBC3_PWRGD

17) KBC3_PWRGD

10) P5.0V

2) VDC

5) KBC3_SUSPWR

2) VDC

ISL6227

AP6680A

Sheet 40

AP6680A

Sheet 40

6) P3.3V_AUX

7) P1.05V_AUX

7) P1.5V_AUX

PWROK

ICH8-M

CL_PWROK

DDR2 POWER

SC486

Sheet 50

10-1) P3.3V

11-1) P1.8V

RTC

Battery

PRTC

PRTC

16

16) CLK3_PWRGD

INTVRMEN

LAN100_SLP

VRMPWRGD

Sheet 22-25

10) P1.1

10) P1.05V

11) VCCP3_PWRGD

15)VRM3_CPU_PWRGD

18) CPU1_PWRGDCPU

19) PLT3_RST*

19) PCI3_RST*

6) P1.8V_AUX

6) MEM1_VREF

10-2) 0.9V

11

PRTC_BAT

CHP3_RTCRST#

6) P1.8V_AUX
10-2) P0.9V

2

1

6

SC471

2

POWER SEQUENCE

15) VRM3_CPU_PWRGD

CK-505

Sheet 8

18

19

17) KBC3_PWRGD

17) KBC3_PWRGD

10) P1.05V (IGFX_CORE)

PM-model only

11-1) GFX_CORE

12)GCORE_PWRGD

Memory

Sheet 20-21

DRAW

CHECK

APPROVAL

MODULE CODE

16-1) Clock Running

12)GCORE3_PWRGD (PM-model)

13) KBC3_VRON (Back-up)

10-1) P1.5V
10-1) P1.05V

12

DDR3

DATE

MS Yang

MK Kim

BL Lee

undefined

DEV. STEP

REV

LAST EDIT

12/05/2008

MP

REV 1.0

(Test Option)

CPU

Sheet 10-12

PWROK

CL_PWROK

GMCH

Sheet 15-19

10-1) P3.3V
10-1) P1.8V

10) P1.5V

10-1) P1.2V

2) VDC

10-1) P3.3V

10-1) P3.3V
10-1) P1.8V

10) P1.5V

TITLE

BONN-E

MAIN

POWER SEQUENCE

April 11, 2009 10:05:58 AM

1

DC/DC B’d

20

PCIe
Devices

PEG

PCI
Devices

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

Rev. 0.7

CPU
VRM

14) VCC_CORE

20) CPU1_CPURST*

19) PLT3_RST*

6) P1.8V_AUX

10-1) P3.3V

SAMSUNG

PART NO.

PAGE

15

14

19

19) PCI3_RST*

ELECTRONICS

BA41-01060A

OF

676

B

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

P3.3V

D D

CLK3_PWRGD*

ITP_EN

CPU_STP*

SS(96/100) SEL

C

B

4

1

Main PLL

SSC

PLL3

SSC

48MHz PLL

xSLG8SP513r05)

FS(2:0)

266 MHz

MUX

266 MHz CLK0_HOST_GMCH/GMCH*

CLK1_PEG/PEG*

Samsung

Samsung

MUX

MUX

100 MHz (SRC0)

100 MHz (SRC4)

96 MHz

100 MHz

100 MHz (SRC 6,8,9,10)

100 MHz (SRC 3)

48 MHz

100 MHz (SRC 2)

33 MHz

CK-505M (w/ CLKREQ* & SSDC)

3

CLK0_HOST_CPU/CPU*

PCI Express Gfx

MCH3_CLKREQ*
CLK1_MCH3GPLL/3GPLL*

CLK1_DREFCLK/CLK*

CLK1_DREFSSC/SSC*

CLK1_PCIEICH/ICH*

CLK3_USB48

CHP3_SATACLKREQ*
CLK1_SATA/SATA*

CLK3_ICH1414.318 MHz

CLK3_PCLKICH

PEG

CPU

HPLL
MPLL

PCIE PLL

DPLLA

DPLLB

PCIEPLL
USBPLL

SATAPLL

32.768 KHz
OSC

FSB

DMI

BSEL

Cantiga

MCH

ICH9-M

2

CLOCK DISTRIBUTION

667/800 MHz

333/400 MHz

333/400 MHz

333/400 MHz

333/400 MHz

AUD3_BCLK

HD 24 MHz

HD Audio

CLK1_MCLK0/0#

CLK1_MCLK1/1#

CLK1_MCLK3/3#

CLK1_MCLK4/4#

100 MHz (SRC 6)

100 MHz (SRC 8)

100 MHz (SRC 9)

SODIMM #0

SODIMM #1

MIN3_CLKREQ*

CLK1_MINIPCIE/PCIE*

ITM3_CLKREQ*

CLK1_MINI2PCIE/PCIE*

LOM3_CLKREQ*

CLK1_PCIELOM/LOM*

EXP3_CLKREQ*

CLK1_EXPCARD#

1

Rev. 0.1

MINI PCIE
CARD 1

MINI PCIE
CARD 2

PCIE LAN

(Marvell)

EXPRESS

25 MHz

CARD

C

B

CLK3_PCLKMICOM

33 MHz

33 MHz

KBC

Confidential

Confidential

CLK3_PCLKPORT80

PORT 80

10 MHz

14 MHz

OSC

33 MHz

Buffer

PCI_STP*

A A

RTC Clock

32.768 KHz

14.318 MHz
Page 8

4

3

MDC3_BCLK

17.86 MHz

2

SPI3_CLK

DRAW

CHECK

APPROVAL

MODULE CODE

MDC

SPI

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MAIN

CLOCK DIAGRAM

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

677

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

CK505M

D

C

B

A

FSA

BSEL0

0
0 0
0
0
1
1
1
1

CLK REQ

CLK REQ A
CLK REQ B
CLK REQ E
CLK REQ F

SEL_LCDCLK*

LOW
HIGH

FSCFSB

BSEL2

BSEL1

0
1

1
0
0
1
1

DEVICE

SATA
GMCH
MINI CARD
EXP3_CLKREQ#

Pin 20/21

DOT_96/DOT_96#
SRC_0/SRC_0#

HOST CLK

0

266 MHz

1

333 MHz

0

200 MHz

1

400 MHz

0

133 MHz
100 MHz

1

166 MHz

0

RSVD

1

CLK3_FM48

CLK3_USB48
CPU1_BSEL0

CPU1_BSEL1
CPU1_BSEL2

CLK3_ICH14

CHP3_CPUSTP#

CHP3_PCISTP#

CLK3_PWRGD

CLK3_PCLKICH

CLK3_DBGLPC

CLK3_PCLKMICOM

MCH3_CLKREQ#

CHP3_SATACLKREQ#

SMB3_CLK

SMB3_DATA

SRC PORT

SRC2
SRC4
SRC6
SRC8

PEG_CLK/PEG_CLK#

4

Pin 24/25

27M & 27M_SS

10V

10V

100nF

100nF

C424

C416

R236
R216
R217

R228
R222

R220
R221
R218

CLK3_XTAL_IN_14_MN

Y1

1

14.31818MHz

2801-004518

C395

0.018nF

50V

Place 14.318MHz within
500mils of CK-505

10V

100nF

C700

2.2K

10K

33

22 5%

22
475
475

2

P3.3VP1.5VP3.3V

B30
BLM18PG181SN1

VDD_CPU_IOVDD_SRC_IO

10V

6.3V

10000nF-X5R

100nF

C413

C431

R234
R235

1%

5%22

5%
1%
1%

C396

Confidential

Confidential

0.018nF
50V

VDD_PLL3_IO

10V

6.3V

10000nF-X5R

100nF

C400

C401

33
33

Samsung

Samsung

50V

50V

50V

0.033nF

5%

0.033nF

5%

5%

0.033nF

C422

C418

C420

10V

6.3V

10000nF-X5R

100nF

C394

C433

P3.3V

1%10K

10K 1%

R224

R230

nostuff

CLK3_USB48_R_MN

CLK3_ICH14_R_MN

CLK3_PCLKICH_R_MN

CLK3_DBGLPC_R_MN

CLK3_PCLKMICOM_R_MN

MCH3_CLKREQ#_R_MN

CHP3_SATACLKREQ#_R_MN

1%

1%

10K

10K

R223

R229

nostuff

6.3V

10000nF-X5R

C381

nostuff

CLK3_VDD_SRC_IO_MN

19
33
43
52
56
27

55
17

64

5

44
45

63
14
13
12
11
10

8
7

6
3

2

18
59
22
15
26

1
30
36
49

U12
SLG8SP513

VDD_IO
VDD_SRC_IO1
VDD_SRC_IO2
VDD_SRC_IO3
VDD_CPU_IO
VDD_PLL3_IO

NC
USB_FS_A

FSB_TESTMODE
REF_FS_C_TEST_SEL

CPUSTOP#
PCISTOP#

CLKPWRGD_PWRDN#
PCIF_5_ITP_EN
PCI_4_SEL_LCDCLK#
PCI_3
PCI_2
PCI_1_CLKREQ_B#
PCI_0_CLKREQ_A#
SCL

SDA
XTAL_IN

XTAL_OUT
VSS_48

VSS_CPU
VSS_IO
VSS_PCI
VSS_PLL3
VSS_REF
VSS_SRC1
VSS_SRC2
VSS_SRC3

1205-003156

B31
BLM18PG181SN1

THERM_GND

65

CLK3_VDD_REF_MN

VDD_REF

VDD_48

VDD_PCI

VDD_PLL3

VDD_SRC
VDD_CPU

CPU0

CPU0#

CPU1_MCH

CPU1_MCH#

SRC11_CLKREQH#

SRC11#_CLKREQG#

SRC10

SRC10#

SRC9

SRC9#

SRC8_ITP

SRC8#_ITP#

SRC7_CLKREQF#

SRC7#_CLKREQE#

SRC6

SRC6#

SRC4

SRC4#

SRC3_CLKREQC#

SRC3#_CLKREQD#

SRC2

SRC2#

LCDCLK_27M

LCDCLK#_27M_SS

SRC0_DOT96

SRC0#_DOT96#

B28
BLM18PG181SN1

VDD_REF

4
16
9
23

46
62

61
60

58
57

40
39

41
42

37
38

54
53

51
50

48
47

34
35

31
32

28
29

CLK3_GFX_27M_R_MN

24

CLK3_GFX_27M_SS_R_MN

25
20

21

10V

100nF

C417

P3.3V

R565

10K
1%

VDD_48

10V

100nF

C397

R589
R127

10V

4700nF-Y5V

C393

22
22

VDD_PCI

10V

100nF

C409

VDD_PLL3

10V

10V

100nF

100nF

C429

C430

This part is 64pin QFN package.

IDT : 1205-003159
SL : 1205-003533

3

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

VDD_CPUVDD_IO VDD_SRC

10V

10V

4700nF-Y5V

100nF

C432

C404

CLK0_HCLK0
CLK0_HCLK0#

CLK0_HCLK1
CLK0_HCLK1#

ITM3_CLKREQ#
LOM3_CLKREQ#

CLK1_MINIPCIE2
CLK1_MINIPCIE2#

CLK1_PCIELOM
CLK1_PCIELOM#

CLK1_EXPCARD
CLK1_EXPCARD#

EXP3_CLKREQ#
MIN3_CLKREQ#

CLK1_MINIPCIE
CLK1_MINIPCIE#

CLK1_MCH3GPLL
CLK1_MCH3GPLL#

CLK1_PCIEICH
CLK1_PCIEICH#

CLK1_SATA
CLK1_SATA#

CLK3_GFX_27M
CLK3_GFX_27M_SS

CLK1_PEG
CLK1_PEG#

BONN-E

MAIN_CLOCK_CIRCUIT

CK_Clock_505M

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

8

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

67

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

C

SHDN_SEL MODE

0

HIGH Z

1

CH1(INTEL MODE)
CH3(DIODE MODE)

N/A (SHDN# NOT USED)

B

THERMAL SENSOR & FAN CONTROL

P3.3V_AUXP5.0V

R509

49.9
1%

C21

C506

10000nF-X5R

100nF

6.3V
10V

KBC3_PWRGD

FAN5_VDD

FAN3_FDBACK#

P3.3V_AUX

R26

200K

R1

1%

THM3_TRIP_SET_MN

93 degree C

R29

R2

51.1K

THM3_TRIP_SET_R_MN

1%

R36

Samsung

Samsung

20K
1%

C505

100nF
10V

THM3_SHDN_SEL_MN

0

R16

nostuff

THM3_VDD_3V_MN

U1
EMC2102

1

VDD_3V

24

VDD_5V_1

27

VDD_5V_2

14

POWER_OK

16

RESET#

10

FAN_MODE

25

FAN_1

26

FAN_2

28

TACH

13

THERMTRIP#

9

SHDN_SEL

11

TRIP_SET

8

NC_1

15

NC_2

21

NC_3

1209-001718

SMDATA

SYS_SHDN#

CLK_SEL

THRM_PAD

SMBUS Address 7Ah

SMCLK

ALERT#

CLK_IN

GND

DN1
DP1

DN2
DP2

DN3
DP3

P3.3V

22
23

19
12

2
3

4
5

THM3_THERMDN_MN

6

THM3_THERMDP_MN

7
17

18
20

29

1%

10K

10K

R211%R19

P3.3V_AUX

Check if PU is doubled to Micom Side.

C119

0.47nF

C508

2.2nF

50V

For ATI M9x

50V

1%10K

R644

C507

2.2nF
50V

KBC3_THERM_SMDATA
KBC3_THERM_SMCLK

THM3_ALERT#
THM3_STP#

CPU2_THERMDC
CPU2_THERMDA

GFX3_THERMDN
GFX3_THERMDP

2

MMBT3904

1

Q516

3

Opposite side of CPU.

1%

10K

R30

For Intel 45nm(From penryn)

10mil width and 10mil spacing.

D

C

B

TRIP_SET pin voltage = (T-75)/21

3.3 * [R2/(R1+R2)] = (T-75)/21

P3.3V

C111

10000nF-X5R

6.3V

R106

10K
1%

J503
HDR-4P-1R-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000456

Type:straight

DESIGN

CHECK

APPROVAL

MODULE CODE

2

Confidential

Confidential

Line Width = 20 mil

FAN5_VDD

FAN3_FDBACK#

A

4

3

MS Yang

MK Kim

BL Lee

M503
HEAD
DIA
LENGTH

BA61-01090A

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

M2
HEAD
DIA
LENGTH

BA61-01090A

TITLE

MP

THERMAL SENSOR

THERMAL SENSOR EMC2102

April 11, 2009 10:05:58 AM

BONN-E

M1
HEAD
DIA
LENGTH

BA61-01090A

To support heatsink

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

M3
HEAD
DIA
LENGTH

BA61-01090A

SAMSUNG

PART NO.

PAGE

ELECTRONICS

BA41-01060A

679

OF

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

3

24

1

D

P1.05V

H1
E2
G5

F1
H5

F21
E1

D20
B3

H4
C1

F3
F4
G3
G2

G6
E4

A6
A5
C4

D5
C6
B4
A3

K3
H2
K2
J3
L1

R87

56

CPU1_IERR#_MN

0
1
2
3
4

CPU1_ADS#
CPU1_BNR#
CPU1_BPRI#

CPU1_BREQ#
CPU1_DEFER#

CPU1_DRDY#
CPU1_DBSY#

CPU1_INIT#
CPU1_LOCK#

CPU1_RS0#
CPU1_RS1#
CPU1_RS2#
CPU1_TRDY#

CPU1_HIT#
CPU1_HITM#

CPU1_A20M#

CPU1_FERR#

CPU1_IGNNE#

CPU1_STPCLK#

CPU1_NMI
CPU1_SMI#
CPU1_REQ#(4:0)

C3895

0.1nF
50V

For ESD

C3896

0.1nF
50V

For ESD

CPU1_CPURST#

nostuff

CPU1_INTR

nostuff

CPU1_D#(15:0)

CPU1_DSTBN0#
CPU1_DSTBP0#

CPU1_DBI0#

CPU1_DSTBN1#

J501-2
PENRYN

0
1

3
4
5
6
7
8
9
10
11
12
13
14
15 47

16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

2 / 4

E22

D0#

F24

D1#

E26

D2#

G22

D3#

F23

D4#

G25

D5#

E25

D6#

E23

D7#

K24

D8#

G24

D9#

J24

D10#

J23

D11#

H22

D12#

F26

D13#

K22

D14#

H23

D15#

J26

DSTBN0#

H26

DSTBP0#

H25

DINV0#

N22

D16#

K25

D17#

P26

D18#

R23

D19#

L23

D20#

M24

D21#

L22

D22#

M23

D23#

P25

D24#

P23

D25#

P22

D26#

T24

D27#

R24

D28#

L25

D29#

T25

D30#

N25

D31#

L26

DSTBN1#

M26

DSTBP1#

N24

DINV1#

0143854500|bga_479p_sock

DATA GRP 0

DATA GRP 2

DSTBN2#
DSTBP2#

DINV2#

DATA GRP 1

DATA GRP 3

DSTBN3#
DSTBP3#

DINV3#

D32#
D33#
D34#
D35#
D36#
D37#
D38#
D39#
D40#
D41#
D42#
D43#
D44#
D45#
D46#
D47#

D48#
D49#
D50#
D51#
D52#
D53#
D54#
D55#
D56#
D57#
D58#
D59#
D60#
D61#
D62#
D63#

Y22
AB24
V24
V26
V23
T22
U25
U23
Y25
W22
Y23
W24
W25
AA23
AA24
AB25
Y26
AA26
U22

AE24
AD24
AA21
AB22
AB21
AC26
AD20
AE22
AF23
AC25
AE21
AD21
AC22
AD23
AF22
AC23
AE25
AF24
AC20

32
33
342
35
36
37
38
39
40
41
42
43
44
45
46

48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63

CPU1_D#(47:32)

CPU1_DSTBN2#
CPU1_DSTBP2#
CPU1_DBI2#
CPU1_D#(63:48)CPU1_D#(31:16)

CPU1_DSTBN3#
CPU1_DSTBP3#CPU1_DSTBP1#
CPU1_DBI3#CPU1_DBI1#

J501-1

PENRYN

CPU1_A#(16:3)

C

CPU1_ADSTB0#

CPU1_A#(35:17)

CPU1_ADSTB1#

B B

1 / 4

3

J4

A3#

4

L5

A4#

5

L4

A5#

6

K5

A6#

7

M3

A7#

8

N2

A8#

9

J1

A9#

10

N3

A10#

11

P5

A11#

12

P2

A12#

13

L2

A13#

14

P4

A14#

15

P1

A15#

16

R1

A16#

M1

ADSTB0#

17

Y2

A17#

18

U5

A18#

19

R3

A19#

20

W6

A20#

21

U4

A21#

22

Y5

A22#

23

U1

A23#

24

R4

A24#

25

T5

A25#

26

T3

A26#

27

W2

A27#

28

W5

A28#

29

Y4

A29#

30

U2

A30#

31

V4

A31#

32

W3

A32#

33

AA4

A33#

34

AB2

A34#

35

AA3

A35#

V1

ADSTB1#

0143854500|bga_479p_sock

0

ADDR GROUP

CONTROL

1

ICH

ADDR GROUP

ADS#
BNR#

BPRI#

BR0#

DEFER#

DRDY#

DBSY#

IERR#

INIT#

LOCK#

RESET#

RS0#
RS1#
RS2#

TRDY#

HIT#

HITM#

A20M#
FERR#

IGNNE#

STPCLK#

LINT0
LINT1

SMI#

REQ0#
REQ1#
REQ2#
REQ3#
REQ4#

Samsung

Samsung

CPU Socket : 3704-001153

D

C

Confidential

Confidential

MT6

RMNT-38-70-1P

MT7

RMNT-38-70-1P

MT3

RMNT-38-70-1P

A

4

MT4

RMNT-38-70-1P

CPU mount

3

A

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

CPU

PENRYN (1/3)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

6710

OFPAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

CPU1_PWRGDCPU

P1.05V

R88

56

P1.05V

C

R38

1K
1%

R37

2K
1%

B

P1.05V

CPU1_PROCHOT#_MN

CPU2_THERMDC

CPU1_THRMTRIP#

CPU1_GTLREF_MN

C31

100nF
10V

CPU1_VCCSENSE
CPU1_VSSSENSE

CLK0_HCLK0

CLK0_HCLK0#

CPU1_SLP#

CPU1_DPSLP#

CPU1_DPRSTP#

CPU1_DPWR#

CPU1_PSI#

CPU1_VID(6:0)

C3894

0.1nF
50V

nostuff

For ESD

CPU2_THERMDA

CPU1_BSEL2
CPU1_BSEL1
CPU1_BSEL0

1%

R43

1%

R42

1% 54.9

R52
R59

CPU1_COMP3_MN

54.9

CPU1_COMP2_MN

27.4

CPU1_COMP1_MN
CPU1_COMP0_MN

27.41%

CPU1_TEST1_MN
CPU1_TEST2_MN

1%

1K

1K 1%

R89

nostuff

R102

nostuff

J501-3
PENRYN

3 / 4

A22

BCLK0

A21

BCLK1

D7

SLP#

B5

DPSLP#

E5

DPRSTP#

D24

DPWR#

D6

PWRGOOD

AE6

6
5
4
3
2
1
0

PSI#

AE2

VID_6

AF3

VID_5

AE3

VID_4

AF4

VID_3

AE5

VID_2

AF5

VID_1

AD6

VID_0

D21

PROCHOT#

A24

THRMDA

B25

THRMDC

C7

THERMTRIP#

C21

BSEL2

B23

BSEL1

B22

BSEL0

AD26

GTLREF

Y1

COMP3

AA1

COMP2

U26

COMP1

R26

COMP0

AF7

VCCSENSE

AE7

VSSSENSE

C23

TEST1

D25

TEST2

C24

TEST3

AF26

TEST4

AF1

TEST5

A26

TEST6

C3

TEST7

0143854500|bga_479p_sock

H CLK

THERMAL

XDP/ITP SIGNALS

RSVD

Samsung

Samsung

VCCA_1
VCCA_2

VCCP_1
VCCP_2
VCCP_3
VCCP_4
VCCP_5
VCCP_6
VCCP_7
VCCP_8

VCCP_9
VCCP_10
VCCP_11
VCCP_12
VCCP_13
VCCP_14
VCCP_15
VCCP_16

PREQ#
PRDY#
BPM3#
BPM2#
BPM1#
BPM0#

TCK
TDO

TMS

TRST#

DBR#

RSVD_1

RSVD_2

RSVD_3

RSVD_4

RSVD_5

RSVD_6

RSVD_7

RSVD_8

RSVD_9

B26
C26

K6
J6
M6
N6
T6
R6
K21
J21
M21
N21
T21
R21
V21
W21
V6
G21

AC1
AC2
AC4
AD1
AD3
AD4

AC5
AA6

TDI

AB3
AB5
AB6
C20

M4
N5
T2
V3
B2
D2
D22
D3
F6

P1.5V

C97

10nF
25V

P1.05V

EC50
220uF

2.5V
AD

CPU1_TCK
CPU1_TDI

CPU1_TMS
ITP3_DBRESET#

C88

10000nF

6.3V

C65

100nF
10V

C71

100nF
10V

C3897

0.1nF
50V

For ESD

C57

C49

100nF

100nF

10V

10V

CPU1_TRST#

nostuff

C52

100nF
10V

C69

100nF
10V

CPU Core Voltage Table

Active Mode

VID(6:0)

0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0

0
0
0
0
0
0
0
0
0

DPRSLPVR
DPRSTP*
PSI2*

0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1

0

0
0

0

0

0
0

0

0

0

0

0

0

0

0

0
1

0
0

1
1

0

1

0
0

1
1

0

1

0

1

0
1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

1

0

1

1

1

1

1

1

1

1

1

1 1.1500 V

1

1

1

1

1

1

0

0
0

0
0

0
0

0

0

0

0

0
0

0

0

0

Voltage

0

0

1.5000 V

0

0

0

1

1.4875 V 0

0

1.4750 V

0

1

1

1.4625 V

0

1

1

0

0 0

1.4500 V

1

1

1.4375 V

0 1

0

1

1

1.4250 V

1.4125 V

1

1

1

1

1
0

0

0

1.4000 V

1

1.3875 V

00

0

0

1

1.3750 V

1

0

1.3625 V

1

0

1

1.3500 V

0
1

1

1.3375 V

0
1

0

1.3250 V

1

1.3125 V

1

1

1
0

1.3000 V

0

1

0

1.2875 V

0

0

1

0

1.2750 V

0

1

1.2625 V

1

0

0

1.2500 V

1

0

1.2375 V

1

1

1.2250 V

1

1

0

1

1

1

1

1.2125 V

1

0

0

0

1.2000 V

1.1875 V

1

0

0

1

0

1.1750 V

0

1.1625 V

1

1
0

0

1

1.1375 V

0

1

1

0

1

1.1250 V1

1.1125 V

1

1

1

0

0

0

1.1000 V

0

1

0

1.0875 V

1 1

0

0

1.0750 V

1

1

0

1.0625 V

0

1

0

1.0500 V

1

1

0

1.0375 V

1

1

0

1.0250 V

1

1

1

1

1

1.0125 V

Active
0
1
0 or 1

Active/Deeper Sleep
Dual Mode Region

VID(6:0)

0

1

0

0

0

1

0

1

0

0

0

1

0

1

0

0

1

0

0

1

0

0

1

0

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

0

1

1

1

0

1

1

0

1

1

0

1

1

0

1

0

1

1

0

1

1

1

0

1

0

0

1

0

0

1

0

1

0

0

0

1

0

1

0

0

0

1

0

0

1

0

1

0

0

1

0

0
0

0

1

0

0

1

0

1

0

1

0

0

1

0

0
0

0

1

0

1

1

0

1

DPRSLPVR
DPRSTP*
PSI2*

IMVP-6

Deeper Sleep/Extended Deeper Sleep
Dual Mode Region

Voltage

VID(6:0)

1

0

0

0

0

1

1

0

1

1

0
1

0

1

1

0

1

0

1

0

1

1

1

1

1

1

0

1

1

1

1

1

0

0

0

0

1

0

0

0

0

0

1

0

0

0

1

1

1

0

0

0
0

1

1

0

1

0

0
0

1

1

1

0

00

1

0

1

1

0

0
0

1

0

1
1

1

1

0

0

1

1

0

1

1

1

0

0

1

1

1

1

1

1

1

1

1

0

0

0

0
1

0

0

0

0

1

0

0
0

0

1

1

0

1

0

0
0

1

0

1

0

1

1

0

1

0

1

1
0

0

0

1

0

0

1

1

0

0

1
1

1

0

1
1

1

0

0

1

0

1

1
1 1

0

1

1
1

1

1

11

1
0

0

0

0

0

0

Deeper Slp
1
0
0 or 1

1

1.0000 V

0.9875 V

0.9750 V

0.9625 V

0.9500 V

0.9375 V

0.9250 V

0.9125 V

0.9000 V

0.8875 V

0.8750 V

0.8625 V

0.8500 V

0.8375 V

0.8250 V

0.8125 V

0.8000 V

0.7875 V

0.7750 V

0.7625 V

0.7500 V

0.7250 V

0.7125 V

0.7000 V

0.6875 V

0.6750 V

0.6625 V0

0.6500 V

0.6375 V

0.6125 V

0.6000 V

0.5875 V

0.5750 V

0.5625 V

0.5500 V

0.5375 V

0.5250 V

0.5125 V

0.5000 V

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1
1

1
1

1
1

1
1

1

1

1

1

1

11

1

1
1

1

1

1

1

1

1

1
1

1
1

1

*"1111111" : 0V power good asserted.

0

0
0

1
1

0
1 0

0
0

1

1

1

1

1

0

0

0

0

0
1

0

1

0

0

1

0

1
1

1
1

1

0

0
0

0

0

1
1

0

0

1

0

1

1

1

1

1

0

0

0

0

1

0
0

1

1

0
0

1

1

1
1

1
0

0

0

0
0

1

0

1
0

1
1

0

1

1

1

1

0

0

0

0

1

0
0

1

1

0
0

1
1

1

1

1

Voltage

0.4875 V

1

0.4750 V

0

0.4625 V

1

0.4500 V

1

0.4375 V

0

0.4250 V

0.4125 V

1
01

0.4000 V

0.3875 V

1
0

0.3750 V

1

0.3625 V

0.3500 V

0
1

0.3375 V

0.3250 V

0

0.3125 V

11

0.3000 V

0

0.2875 V

1
0

0.2750 V

1

0.2625 V

0.2500 V

0
1

0.2375 V

0.2250 V

00.7375 V
1

0.2125 V

0

1

0.2000 V

0.1875 V

1
0

0.1750 V

1

0.1625 V

0.1500 V

0
1

0.1375 V

0.1250 V

0

10.6250 V

0.1125 V

0

0.1000 V

1

0.0875 V

0

0.0750 V

0.0625 V

1
0

0.0500 V

0.0375 V

1

0.0250 V

0

0.0125 V

1

0.0000 V

0

0.0000 V

1

0.0000 V

0

0.0000 V

1
0

0.0000 V

0.0000 V

1

0.0000 V

0
1

0.0000 V

0

1
1

0

1

0
0

1
1

0
0

1
1

1
1

1

1

1

1

1
1

1

1

1
1

1
1

1
0

0
0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

1

0
0

1

0

1
1

0

1

0
0

1

0

1

0

1

1

1
1

1
1

1

1

1
1

1

1

1
1

1
1

1

D

C

1%

54.9

54.9

near the CPU

R41

R40

CPU1_TDI
CPU1_TMS

CPU1_TCK

1%

54.9

54.9

A

R39

R35

CPU1_TRST#

4

BSEL

FSB 1067 MHz
FSB 800 MHz

Confidential

Confidential

Pull-down
BSEL0, BSEL1, BSEL2

BSEL0, BSEL2

3

2

GTLREF : Keep the Voltage divider within 0.5"
of the first GTLREF0 pin with Zo=55ohm trace.
Minimize coupling of any switching signals to this net.

COMP0,2(COMP1,3) should be connected with Zo=27.4ohm(55ohm)
trace shorter than 1/2" to their respective Banias socket pins.

GND test points within 100mil of the VCC/VSSsense at the end of the line.
Route the VCC/VSSsense as a Zo=55ohm traces with equal length.
Observe 3:1 spacing b/w VCC/VSSsense lines and 25mil away
(preferred 50mil) from any other signal. And GND via 100mil away
from each of the VCC/VSS test point vias.

DRAW

CHECK

APPROVAL

MODULE CODE

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

*Yonah Processor (2.33 GHz / 800 MHz : TBD)

BONN-E

CPU

PENRYN (2/3)

April 11, 2009 10:05:58 AM

1

SAMSUNG

PART NO.

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

ELECTRONICS

BA41-01060A

11 67

OF

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3 1

2

D

A11

VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60

CPU_CORE

A14
A16
A19

A2
A23
A25

A4

A8

AA11
AA14
AA16

CPU_CORE

C

CPU1_VCCSENSE

CPU1_VSSSENSE

R22

R20

1%100

20%

20%

22000nF-X5R

22000nF-X5R

C40

C124

1%100

nostuff
nostuff

6.3V

6.3V

Prodlizer used

Samsung

B B

Samsung

Confidential

Confidential

AA19

AA2
AA22
AA25

AA5

AA8

AB1
AB11
AB13
AB16
AB19
AB26

AB4

AB8
AC11
AC14
AC16
AC19
AC21
AC24

AC3

AC6

AC8
AD11
AD13
AD16
AD19

AD2
AD22
AB23
AD25

AD5

AD8

AE1
AE11
AE14
AE16
AE19
AE23
AE26

AE4

AE8
AF11
AF13
AF16
AF19

AF21

AF2

AA10
AA12
AA13
AA15
AA17
AA18
AA20

AB10
AB12
AB14
AB15
AB17
AB18
AB20

AC10
AC12
AC13
AC15
AC17
AC18

AD10
AD12
AD14
AD15
AD17
AD18

AE10
AE12
AE13
AE15
AE17
AE18
AE20

A10
A12
A13
A15
A17
A18
A20

A7
A9

AA7
AA9

AB7
AB9

AC7
AC9

AD7
AD9

VSS_163

Y6

K23

K26

VSS_121

VSS_122K4VSS_123

VCC_1
VCC_2
VCC_3
VCC_4
VCC_5
VCC_6
VCC_7
VCC_8
VCC_9
VCC_10
VCC_11
VCC_12
VCC_13
VCC_14
VCC_15
VCC_16
VCC_17
VCC_18
VCC_19
VCC_20
VCC_21
VCC_22
VCC_23
VCC_24
VCC_25
VCC_26
VCC_27
VCC_28
VCC_29
VCC_30
VCC_31
VCC_32
VCC_33
VCC_34
VCC_35
VCC_36
VCC_37
VCC_38
VCC_39
VCC_40
VCC_41
VCC_42
VCC_43
VCC_44
VCC_45
VCC_46
VCC_47
VCC_48
VCC_49
VCC_50

VSS_161

VSS_162

Y3

Y24

VSS_160

Y21

L21

L24

VSS_124

VSS_125

VSS_158

VSS_159

W4

W26

L3

L6

VSS_126

VSS_127M2VSS_128

PENRYN

VSS_155

VSS_156

VSS_157

V5

W1

W23

M25

M22

VSS_130M5VSS_131N1VSS_132

VSS_129

J501-4

4 / 4

VSS_153

VSS_154

VSS_152

V2

V25

V22

N23

VSS_133

VSS_150

VSS_151

U3

U6

N26

P21

VSS_134N4VSS_135

VCC_51
VCC_52
VCC_53
VCC_54
VCC_55
VCC_56
VCC_57
VCC_58
VCC_59
VCC_60
VCC_61
VCC_62
VCC_63
VCC_64
VCC_65
VCC_66
VCC_67
VCC_68
VCC_69
VCC_70
VCC_71
VCC_72
VCC_73
VCC_74
VCC_75
VCC_76
VCC_77
VCC_78
VCC_79
VCC_80
VCC_81
VCC_82
VCC_83
VCC_84
VCC_85
VCC_86
VCC_87
VCC_88
VCC_89
VCC_90
VCC_91
VCC_92
VCC_93
VCC_94
VCC_95
VCC_96
VCC_97
VCC_98
VCC_99

VCC_100

VSS_148

VSS_149

T4

U21

U24

P24

VSS_136

VSS_137P3VSS_138P6VSS_139

VSS_145

VSS_146

VSS_147

T1

T23

T26

R2

R22

VSS_140

VSS_141

CPU_CORE

AE9
AF10
AF12
AF14
AF15
AF17
AF18
AF20
AF9
B10
B12
B14
B15
B17
B18
B20
B7
B9
C10
C12
C13
C15
C17
C18
C9
D10
D12
D14
D15
D17
D18
D9
E10
E12
E13
E15
E17
E18
E20
E7
E9
F10
F12
F14
F15
F17
F18
F20
F7
F9

VSS_142

VSS_143

VSS_144

R5

R25

VSS_120
VSS_119
VSS_118
VSS_117
VSS_116
VSS_115
VSS_114
VSS_113
VSS_112
VSS_111
VSS_110
VSS_109
VSS_108
VSS_107
VSS_106
VSS_105
VSS_104
VSS_103
VSS_102
VSS_101
VSS_100

VSS_99
VSS_98
VSS_97
VSS_96
VSS_95
VSS_94
VSS_93
VSS_92
VSS_91
VSS_90
VSS_89
VSS_88
VSS_87
VSS_86
VSS_85
VSS_84
VSS_83
VSS_82
VSS_81
VSS_80
VSS_79
VSS_78
VSS_77
VSS_76
VSS_75
VSS_74
VSS_73
VSS_72
VSS_71
VSS_70
VSS_69
VSS_68
VSS_67
VSS_66
VSS_65
VSS_64
VSS_63
VSS_62
VSS_61

0143854500|bga_479p_sock

K1
J5
J25
J22
J2
H6
H3
H24
H21
G4
G26
G23
G1
F8
F5
F25
F22
F2
F19
F16
F13
F11
E8
E6
E3
E24
E21
E19
E16
E14
E11
D8
D4
D26
D23
D19
D16
D13
D11
D1
C8
C5
C25
C22
C2
C19
C16
C14
C11
B8
B6
B24
B21
B19
B16
B13
B11
AF8
AF6
AF25

D

C

A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

CPU

PENRYN (3/3)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

12 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4

CPU1_D#(63:0)

P1.05V

R153

221
1%

R159

100
1%

C

C221

100nF
10V

SI request

MCH1_HXSWING

P1.05V

R154

1K
1%

R151

2K
1%

C3921

100nF
10V

SI request

MCH1_HVREF

B

CPU1_CPURST#

CPU1_SLP#

MCH1_HXSWING

MCH1_HVREF

*POCAFEB-12 Only (Remove in MP Model)

CFG#

A

CFG(5)
CFG(6) iTPM Host Interface Enable iTPM Host Interface Disable (def.)
CFG(7)
CFG(9)
CFG(10)
CFG(16)
CFG(19)

CFG(20)

Current Setting

Low

DMIx2

ME Crypto no confidentiality
PEG Reversal (def.)
PCIE Loop Back Enable
Dynamic ODT Disabled

DMI Lane Normal (def.)
SDVO or PCIE X1
Only(def.)

(def. : default Option)

High

DMIx4 (def.)

ME Crypto confidentiality (def.)
Normal
PCIE Loop Back Disable(def)
Dynamic ODT

DMI Lane Reversal
SDVO and PCIE X1

Simultaneously

Enabled (def.)

4

R158

3

P1.05V

EC8
220uF

2.5V
AD

0 4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63

MCH1_H_RCOMP_MN

24.9 1%

1608

MCH1_VTTLF1_MN
MCH1_VTTLF2_MN
MCH1_VTTLF3_MN

470nF

470nF

470nF

16V

16V

C335

C204

C285

C376

C304

22000nF-X5R

220nF

20%

10V

6.3V

22-D2

F2

H_D#_0

G8

H_D#_1

F8

H_D#_2

E6

H_D#_3

G2

H_D#_4

H6

H_D#_5

H2

H_D#_6

F6

H_D#_7

D4

H_D#_8

H3

H_D#_9

M9

H_D#_10

M11

H_D#_11

J1

H_D#_12

J2

H_D#_13

N12

H_D#_14

J6

H_D#_15

P2

H_D#_16

L2

H_D#_17

R2

H_D#_18

N9

H_D#_19

L6

H_D#_20

M5

H_D#_21

J3

H_D#_22

N2

H_D#_23

R1

H_D#_24

N5

H_D#_25

N6

H_D#_26

P13

H_D#_27

N8

H_D#_28

L7

H_D#_29

N10

H_D#_30

M3

H_D#_31

Y3

H_D#_32

AD14

H_D#_33

Y6

H_D#_34

Y10

H_D#_35

Y12

H_D#_36

Y14

H_D#_37

Y7

H_D#_38

W2

H_D#_39

AA8

H_D#_40

Y9

H_D#_41

AA13

H_D#_42

AA9

H_D#_43

AA11

H_D#_44

AD11

H_D#_45

AD10

H_D#_46

AD13

H_D#_47

AE12

H_D#_48

AE9

H_D#_49

AA2

H_D#_50

AD8

H_D#_51

AA3

H_D#_52

AD3

Samsung

Samsung

H_D#_53

AD7

H_D#_54

AE14

H_D#_55

AF3

H_D#_56

AC1

H_D#_57

AE3

H_D#_58

AC3

H_D#_59

AE11

H_D#_60

AE8

H_D#_61

AG2

H_D#_62

AD6

H_D#_63

C12

H_CPURST#

E11

H_CPUSLP#

C5

H_SWING

E3

H_RCOMP

B11

H_DVREF

A11

H_AVREF

Confidential

Confidential

A8

VTTLF_1

AB2

VTTLF_2

L1

VTTLF_3

16V

CPU1_BSEL0
CPU1_BSEL1
CPU1_BSEL2

C339

220nF
10V

VTTLF

C317

100nF
10V

AA28

AB34

AC26

AA34

AA33

VCC_3

VCC_1

VCC_4

VCC_5

VCC_2

HOST DATA BUS

CFG_1

CFG_0

CFG_2

CFG_3

CFG_4

CFG_5

T25

P25

P20

P24

R25

C25

AC34

AE26

AC28

AC33

VCC_8

VCC_6

VCC_7

CFG_6

CFG_7

CFG_8

E21

N24

C23

M24

MCH1_CFG6_MN

R179

2.2K

AE33

VCC_9

VCC_10

CFG

CFG_10

CFG_9

C24

nostuff

AF23

AF25

VCC_11

CFG_11

P21

N21

AF28

AF33

VCC_12

VCC_13

CFG_12

CFG_13

T21

R20

AG24

AG25

VCC_14

VCC_15

CFG_14

CFG_15

L21

M20

AG26

AG33

VCC_16

VCC_17

VCC_18

VCC CORE

CFG_16

CFG_17

CFG_18

P29

H21

AH23

AG34

VCC_19

CFG_19

T28

R28

AH25

AH28

VCC_20

VCC_21

VCC_22

VCC_NCTF_1

CFG_20

AA29

AJ23

AJ26

AJ33

AK33

VCC_23

VCC_24

VCC_25

VCC_26

VCC_NCTF_2

VCC_NCTF_4

VCC_NCTF_5

VCC_NCTF_3

AA30

AB30

AA32

AC29

U34

V33

V34

AM33

T32

U33

VCC_30

VCC_31

VCC_27

VCC_28

VCC_29

U513-1
EB88CTPM

1 OF 5

0904-002483

VCC_NCTF_10

VCC_NCTF_7

VCC_NCTF_8

VCC_NCTF_9

VCC_NCTF_6

AF30

AE32

AE29

AE30

AC30

AC32

W33

VCC_32

VCC_33

VCC_NCTF_11

VCC_NCTF_12

AG29

iTPM option

3

T10

Y33

Y34

VCC_34

VCC_35

VCC_NCTF_13

VCC_NCTF_14

VCC_NCTF_15

VCC_NCTF_16

AH29

AH30

AH32

AG30

AG32

2

T11

T12

T13

VTT_1

VTT_2

VTT_3

VTT_4T2VTT_5T5VTT_6T6VTT_7T7VTT_8T8VTT_9

VCC_NCTF_17

VCC_NCTF_18

VCC_NCTF_19

VCC_NCTF_20

VCC_NCTF_21

AJ29

AJ32

AK23

AK24

AK25

2

T9

VTT_10U1VTT_11

NC

VCC_NCTF_22

VCC_NCTF_23

VCC_NCTF_24

VCC_NCTF_25

VCC_NCTF_26

AK26

AK28

AK29

AK30

AK32

DRAW

CHECK

APPROVAL

MODULE CODE

U10

U11

U12

U13

VTT_12

VTT_13

VTT_14

VTT_15U2VTT_16U3VTT_17U5VTT_18U6VTT_19

VTT

VCC_NCTF_27

VCC_NCTF_28

VCC_NCTF_29

VCC_NCTF_30

VCC_NCTF_31

AL26

AL28

AL29

AL30

U7

VCC_NCTF_32

VCC_NCTF_33

VCC_NCTF_34

VCC_NCTF_35

U30

U32

AL32

AM30

AM32

MS Yang

MK Kim

BL Lee

undefined

V3

VTT_20U8VTT_21U9VTT_22

VTT_23V1VTT_24V2VTT_25

VCC_NCTF_37

VCC_NCTF_38

VCC_NCTF_39

VCC_NCTF_40

VCC_NCTF_36

V29

V30

W29

W30

W32

DATE

12/05/2008

DEV. STEP

REV

LAST EDIT

P1.05V

C365

470nF
16V

HOST ADDRESS BUS

HOST CONTROL

VCC_NCTF_41

VCC_NCTF_42

VCC_NCTF_43

VCC_NCTF_44

Y29

Y30

Y32

TITLE

MP

REV 1.0

C377

C346

4700nF

2200nF

10V

10V

H_A#_3
H_A#_4
H_A#_5
H_A#_6
H_A#_7
H_A#_8

H_A#_9
H_A#_10
H_A#_11
H_A#_12
H_A#_13
H_A#_14
H_A#_15
H_A#_16
H_A#_17
H_A#_18
H_A#_19
H_A#_20
H_A#_21
H_A#_22
H_A#_23
H_A#_24
H_A#_25
H_A#_26
H_A#_27
H_A#_28
H_A#_29
H_A#_30
H_A#_31
H_A#_32
H_A#_33
H_A#_34
H_A#_35

H_ADS#
H_ADSTB#_0
H_ADSTB#_1

H_BNR#

H_BPRI#

H_BREQ#

H_DEFER#

H_DBSY#

H_DPWR#

H_DRDY#

H_HIT#

H_HITM#
H_LOCK#
H_TRDY#

HPLL_CLK

HPLL_CLK#

H_DINV#_0
H_DINV#_1
H_DINV#_2
H_DINV#_3

H_DSTBN#_0
H_DSTBN#_1
H_DSTBN#_2
H_DSTBN#_3

H_DSTBP#_0
H_DSTBP#_1
H_DSTBP#_2
H_DSTBP#_3

H_REQ#_0
H_REQ#_1
H_REQ#_2
H_REQ#_3
H_REQ#_4

H_RS#_0
H_RS#_1
H_RS#_2

BONN-E

MCH_CANTIGA_PM_DDR2

CANTIGA (1/5)

April 11, 2009 10:05:58 AM

A14
C15
F16
H13
C18
M16
J13
P16
R16
N17
M13
E17
P17
F17
G20
B19
J16
E20
H16
J20
L17
A17
B17
L16
C21
J17
H20
B18
K17
B20
F21
K21
L20

H12
B16
G17
A9
F11
G12

E9
B10
J11
F9

H9
E12
H11
C9

AH7
AH6

J8
L3
Y13
Y1

L10
M7
AA5
AE6

L9
M8
AA6
AE5

B15
K13
F13
B13
B14

B6
F12
C8

1

EC7

C369

220uF

4700nF

2.5V

10V

AD

3

5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35

CPU1_ADS#
CPU1_ADSTB0#
CPU1_ADSTB1#
CPU1_BNR#
CPU1_BPRI#
CPU1_BREQ#

CPU1_DEFER#
CPU1_DBSY#
CPU1_DPWR#
CPU1_DRDY#

CPU1_HIT#
CPU1_HITM#
CPU1_LOCK#
CPU1_TRDY#

CLK0_HCLK1
CLK0_HCLK1#

CPU1_DBI0#
CPU1_DBI1#
CPU1_DBI2#
CPU1_DBI3#

CPU1_DSTBN0#
CPU1_DSTBN1#
CPU1_DSTBN2#
CPU1_DSTBN3#

CPU1_DSTBP0#
CPU1_DSTBP1#
CPU1_DSTBP2#
CPU1_DSTBP3#

0
1
2
3
4

CPU1_REQ#(4:0)

CPU1_RS0#
CPU1_RS1#
CPU1_RS2#

P1.05V

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

CPU1_A#(35:3)

ELECTRONICS

BA41-01060A

13 67

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

D

C

B

P3.3V

A

R170
R178
R175

10K

1%10K
1%

10K

PEG1_RXN(15:0)

H32

CRT_DDC_CLK

J32

CRT_DDC_DATA

J29

CRT_HSYNC

L29

CRT_VSYNC

E28

CRT_BLUE

G28

CRT_GREEN

J28

CRT_RED

E29

CRT_TVO_IREF

G29

CRT_IRTN

C31

TV_DCONSEL_0

E32

TV_DCONSEL_1

F25

TVA_DAC

H25

TVB_DAC

K25

TVC_DAC

H24

TV_RTN

K33

L_DDC_CLK

J33

L_DDC_DATA

M32

L_CTRL_CLK

M33

L_CTRL_DATA

M29

L_VDD_EN

G32

L_BKLT_EN

L32

L_BKLT_CTRL

H47

LVDSA_DATA#_0

E46

LVDSA_DATA#_1

G40

LVDSA_DATA#_2

A40

LVDSA_DATA#_3

H48

LVDSA_DATA_0

D45

LVDSA_DATA_1

F40

LVDSA_DATA_2

B40

LVDSA_DATA_3

C40

LVDSA_CLK

C41

LVDSA_CLK#

A41

LVDSB_DATA#_0

H38

LVDSB_DATA#_1

G37

LVDSB_DATA#_2

J37

LVDSB_DATA#_3

B42

LVDSB_DATA_0

G38

LVDSB_DATA_1

F37

LVDSB_DATA_2

K37

LVDSB_DATA_3

A37

LVDSB_CLK

B37

LVDSB_CLK#

C44

LVDS_IBG

B43

LVDS_VBG

E37

LVDS_VREFH

E38

LVDS_VREFL

B28

HDA_BCLK

A28

HDA_SYNC

B30

HDA_RST#

B29

HDA_SDI

C29

HDA_SDO

MCH3_CLKREQ#
MCH3_EXTTS0#
MCH3_EXTTS1#

TV VGA

LVDSHDA

2 54

3

H44

J46

L44

PEG_RX#_0

PEG_RX#_1

PEG_RX#_2

NC_3

NC_2

NC_1

A46

A44

A43

3

PEG1_RXP(15:0)

L40

N41

P48

PEG_RX#_5

PEG_RX#_3

PEG_RX#_4

8

76

9

N44

T43

U43

Y43

PEG_RX#_6

PEG_RX#_7

PEG_RX#_8

14

1310

12

11 30

Y48

Y36

AA43

AD37

PEG_RX#_9

PEG_RX#_10

PEG_RX#_11

PEG_RX#_12

PEG_RX#_13

15

H43

AC47

AD39

PEG_RX#_14

PEG_RX#_15

1

L43

L41

J44

PEG_RX_2

PEG_RX_0

PEG_RX_1

5

6

N40

P47

N43

PEG_RX_3

PEG_RX_4

PEG_RX_5

PEG_RX_6

7

94

8 112

T42

U42

Y42

PEG_RX_7

PEG_RX_8

PCIE GFX

12 1510

10 13

W47

Y37

PEG_RX_9

PEG_RX_10

PEG_RX_11

14

AC48

AA42

AD36

PEG_RX_14

PEG_RX_12

PEG_RX_13

0 3

100nF

100nF

C613

AD40

J41

PEG_TX#_0

PEG_RX_15

4 7

2 51

100nF

100nF

C630

C631

C615

M46

M47

M40

PEG_TX#_1

PEG_TX#_2

PEG_TX#_3

100nF

100nF

100nF

C647

C640

C639

M42

R48

N38

PEG_TX#_4

PEG_TX#_5

PEG_TX#_6

8 116 9

10 13

100nF

100nF

100nF

C658

C657

C648

T40

U37

U40

PEG_TX#_7

PEG_TX#_8

PEG_TX#_9

12 15

100nF

100nF

100nF

100nF

C664

C675

C674

C665

Y40

AA46

AA37

AA40

PEG_TX#_10

PEG_TX#_11

PEG_TX#_12

100nF

100nF

C680

C682

AD43

AC46

PEG_TX#_13

PEG_TX#_14

PEG_TX#_15

U513-2
EB88CTPM

AA15

AA21

AA20

VCC_AXG_1

VCC_AXG_2

Samsung

Samsung

VCC_AXG_NCTF_8

VCC_AXG_NCTF_9

AE17

AE16

AE19

Confidential

Confidential

NC_4

NC_5A5NC_6A6NC_7B4NC_8

A47

B45

B47

AB25

AA24

AA25

AB15

AB20

AB23

AA23

VCC_AXG_6

VCC_AXG_7

VCC_AXG_8

VCC_AXG_9

VCC_AXG_4

VCC_AXG_3

VCC_AXG_5

VCC_AXG_10

VCC_AXG_NCTF_15

VCC_AXG_NCTF_16

VCC_AXG_NCTF_10

AF16

NC_9

B48

VCC_AXG_NCTF_17

VCC_AXG_NCTF_11

VCC_AXG_NCTF_12

VCC_AXG_NCTF_13

VCC_AXG_NCTF_14

AF17

AF19

AH16

AG17

AG19

AG16

NC_14

NC_15

NC_16

NC_13

NC_10

NC_11

NC_12

BE2

BD1

BC1

BE47

BD48

BC48

AC20

AC21

AC23

AC24

AE15

VCC_AXG_11

VCC_AXG_12

VCC_AXG_13

VCC_AXG_14

VCC_AXG_15

AE20

AE21

VCC_AXG_16

VCC_AXG_17

AE23

AE24

AE25

AF15

VCC_AXG_18

VCC_AXG_19

VCC_AXG_20

VCC_AXG_21

GFX VCC

AG21

AH15

AF20

AG15

VCC_AXG_24

VCC_AXG_25

VCC_AXG_22

VCC_AXG_23

AH20

AJ15

VCC_AXG_26

VCC_AXG_27

2 OF 5

GFX VCC NCTF

VCC_AXG_NCTF_25

VCC_AXG_NCTF_26

VCC_AXG_NCTF_27

VCC_AXG_NCTF_28

VCC_AXG_NCTF_20

VCC_AXG_NCTF_21

VCC_AXG_NCTF_22

VCC_AXG_NCTF_18

VCC_AXG_NCTF_19

AJ16

AJ19

AK16

AK17

AH17

AH19

NC_20

NC_21

NC_17

NC_18

NC_19

BF1

BF3

BG1

BG2

BF48

BF46

VCC_AXG_NCTF_29

VCC_AXG_NCTF_23

VCC_AXG_NCTF_24

VCC_AXG_NCTF_30

VCC_AXG_NCTF_31

VCC_AXG_NCTF_32

VCC_AXG_NCTF_33

VCC_AXG_NCTF_34

AL16

AL19

AL21

AK20

AK21

AK19

AM16

AM17

AM19

AM20

AM21

NC RSVD

NC_22

NC_23

NC_24

NC_25

NC_26

NC_27

NC_28

NC_29

NC_30

NC_31

NC_32

NC_33

BH2

BH3

BH43

BH44

BH46

BH47

BH5

BG4

BG45

BG47

BG48

T16

AJ21

AL15

AM14

AM15

AN14

T14

VCC_AXG_28

VCC_AXG_29

VCC_AXG_30

VCC_AXG_31

VCC_AXG_32

VCC_AXG_33

0904-002483

VCC_AXG_NCTF_40

VCC_AXG_NCTF_35

VCC_AXG_NCTF_36

VCC_AXG_NCTF_37

VCC_AXG_NCTF_38

VCC_AXG_NCTF_39

V17

V19

V16

U16

U19

U20

U21

NC_34C3NC_35

NC_36

NC_37D2NC_38

NC_39

E1

C46

C48

D47

BH6

T17

U14

U15

V15

VCC_AXG_34

VCC_AXG_35

VCC_AXG_36

VCC_AXG_37

VCC_AXG_NCTF_41

VCC_AXG_NCTF_42

VCC_AXG_NCTF_43

VCC_AXG_NCTF_44

V21

V23

V24

V25

NC_40

NC_41

NC_42

NC_43

F1

F48

E48

3

Y15

Y21

Y24

Y26

VCC_AXG_38

VCC_AXG_39

VCC_AXG_40

VCC_AXG_41

VCC_AXG_42

VCC_AXG_NCTF_45

VCC_AXG_NCTF_46

VCC_AXG_NCTF_47

VCC_AXG_NCTF_48

VCC_AXG_NCTF_49

VCC_AXG_NCTF_50

VCC_AXG_NCTF_51

V26

V28

W16

W17

W19

W20

W21

RSVD11

RSVD_2

RSVD_3

RSVD_4

RSVD_5

RSVD_1

AH9

AL34

AK34

AH12

AH13

AH10

VCC_AXG_NCTF_52

RSVD_6

2

PEG1_TXN(15:0)

2 5

6 9

4

0 314 1

100nF

100nF

100nF

100nF

100nF

100nF

100nF

C627

C614

C636

C635

C601

C624

J42

L46

M48

M39

M43

R47

PEG_TX_0

PEG_TX_1

PEG_TX_2

PEG_TX_3

PEG_TX_4

PEG_TX_5

AB17

AA19

AB16

AB19

AA16

VCC_AXG_NCTF_4

VCC_AXG_NCTF_2

VCC_AXG_NCTF_3

VCC_AXG_NCTF_5

VCC_AXG_NCTF_1

GFX VCC NCTF

VCC_AXG_NCTF_53

VCC_AXG_NCTF_54

VCC_AXG_NCTF_55

VCC_AXG_NCTF_56

VCC_AXG_NCTF_57

VCC_AXG_NCTF_58

Y16

W23

W24

W25

W26

W28

RSVD10

RSVD12

RSVD13

RSVD_7

RSVD_8

RSVD_9

RSVD_10B2RSVD_11

RSVD_12

B31

BF18

AY21

AN35

AM35

24

7

8 11

12 15

100nF

100nF

100nF

100nF

100nF

100nF

C643

C669

C661

C651

C644

C660

C652

Y39

Y46

AA36

N37

T39

U36

U39

PEG_TX_6

PEG_TX_7

PEG_TX_8

PEG_TX_9

PEG_TX_10

PEG_TX_11

AC17

AC16

VCC_AXG_NCTF_7

VCC_AXG_NCTF_6

VCC_AXG_NCTF_60

VCC_AXG_NCTF_59

Y19

Y17

RSVD_16

RSVD_17

RSVD_15

RSVD_18

RSVD_13

RSVD_14

M1

K12

N36

M36

BF23

BH18

BG23

DRAW

APPROVAL

MODULE CODE

141310

100nF

100nF

100nF

C683

C679

C670

AA39

AD42

AD46

PEG_TX_12

PEG_TX_13

PEG_TX_14

PEG_TX_15

RSVD_19

RSVD_20

RSVD_21

RSVD_22

T24

T33

R33

PCIE GFX

PEG1_TXP(15:0)

DMICLKMEPMMISC

DPLL_REF_CLK

DPLL_REF_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

PM_EXT_TS#_0
PM_EXT_TS#_1

DDPC_CTRLCLK

DDPC_CTRLDATA

SDVO_CTRLCLK

SDVO_CTRLDATA

MS Yang

MK Kim

BL Lee

undefined

PEG_COMPI

PEG_COMPO

GFX_VID_0
GFX_VID_1
GFX_VID_2
GFX_VID_3
GFX_VID_4

GFX_VR_EN

DMI_RXN_0
DMI_RXN_1
DMI_RXN_2
DMI_RXN_3

DMI_RXP_0
DMI_RXP_1
DMI_RXP_2
DMI_RXP_3

DMI_TXN_0
DMI_TXN_1
DMI_TXN_2
DMI_TXN_3

DMI_TXP_0
DMI_TXP_1
DMI_TXP_2
DMI_TXP_3

PEG_CLK

PEG_CLK#

CL_CLK

CL_DATA

CL_PWROK

CL_RST#
CL_VREF

PM_SYNC#

PM_DPRSTP#

DPRSLPVR

PWROK

RSTIN#

THERMTRIP#

CLKREQ#

ICH_SYNC#

TSATN#

DATE

12/05/2008

DEV. STEPCHECK

REV

LAST EDIT

MP

REV 1.0

PEG1_TXN0_C_MN
PEG1_TXN1_C_MN
PEG1_TXN2_C_MN
PEG1_TXN3_C_MN
PEG1_TXN4_C_MN
PEG1_TXN5_C_MN
PEG1_TXN6_C_MN
PEG1_TXN7_C_MN
PEG1_TXN8_C_MN
PEG1_TXN9_C_MN
PEG1_TXN10_C_MN
PEG1_TXN11_C_MN
PEG1_TXN12_C_MN
PEG1_TXN13_C_MN
PEG1_TXN14_C_MN
PEG1_TXN15_C_MN

T37
T36

B33
B32
G33
F33
E33

C34
AE41

AE37
AE47
AH39

AE40
AE38
AE48
AH40

AE35
AE43
AE46
AH42

AD35
AE44
AF46
AH43

B38
A38

E41
F41

F43
E43

AH37
AH36
AN36
AJ35

AH34
R29

B7
R32

AT40
AT11

T20
N33
P32

N28
M28

G36
E36

K36
H36

B12

MCH1_COMPIO_R_MN

MCH1_CL_VREF_MN

CHP3_PM_SYNC#
CPU1_DPRSTP#
CHP3_DPRSLPVR

100

R212

CPU1_THRMTRIP#_R_MN

MCH1_SDVO_CTRLDATA_MN

R164

MCH1_TSATN#_MN

R157

TITLE

MCH_CANTIGA_PM_DDR2

CANTIGA (2/5)

April 11, 2009 10:05:58 AM

1

PEG1_TXP0_C_MN
PEG1_TXP1_C_MN
PEG1_TXP2_C_MN
PEG1_TXP3_C_MN
PEG1_TXP4_C_MN
PEG1_TXP5_C_MN
PEG1_TXP6_C_MN
PEG1_TXP7_C_MN
PEG1_TXP8_C_MN
PEG1_TXP9_C_MN
PEG1_TXP10_C_MN
PEG1_TXP11_C_MN
PEG1_TXP12_C_MN
PEG1_TXP13_C_MN
PEG1_TXP14_C_MN
PEG1_TXP15_C_MN

49.9 1%

R188

DMI1_TXN_0
DMI1_TXN_1
DMI1_TXN_2
DMI1_TXN_3

DMI1_TXP_0
DMI1_TXP_1
DMI1_TXP_2
DMI1_TXP_3

DMI1_RXN_0
DMI1_RXN_1
DMI1_RXN_2
DMI1_RXN_3

DMI1_RXP_0
DMI1_RXP_1
DMI1_RXP_2
DMI1_RXP_3

CLK1_MCH3GPLL
CLK1_MCH3GPLL#

CHP3_CL_CLK_0
CHP3_CL_DATA_0
KBC3_PWRGD
CHP3_CL_RST_0#

1%

PLT3_RST#_R_MN

SHORT564

0

nostuff

P1.05V

56

BONN-E

1

P1.05V_PEG

1608 Size

P1.05V

R201

C372

1K

100nF

1%

10V

TP2105

R203

499
1%

KBC3_PWRGD

R1005-SHORT

MCH3_CLKREQ#

500 ohm for Cantiga

CPU1_THRMTRIP#

MCH3_EXTTS0#
MCH3_EXTTS1#

C3899

0.1nF
50V

PLT3_RST#

nostuff

Added by EMC

MCH3_ICHSYNC#

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

14

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4 3

MEM1_ABS(2:0)

MEM1_ADM(7:0)

MEM1_ADQS#(7:0)

MEM1_ADQS(7:0)

C

MEM1_AMA(14:0)

MEM1_ACAS#
MEM1_ARAS#

MEM1_AWE#

MEM1_CS0#
MEM1_CS1#

MEM1_ODT0

B

P1.8V_AUX

R226

80.6
1%

R232

80.6
1%

MEM1_ODT1
MEM1_CKE0

MEM1_CKE1

CLK1_MCLK0

CLK1_MCLK0#

CLK1_MCLK1

CLK1_MCLK1#

MCH1_SM_RCOMP_MN

MCH1_SM_RCOMP#_MN

P1.8V_AUX

R219

1K
1%

C421

C419

2200nF

10nF

R227

A

3.01K
1%

R231

1K
1%

25V

C425

10nF
25V

10V

C427

2200nF
10V

4

MCH1_SM_RCOMP_V_OH_MN

MCH1_SM_RCOMP_V_OL_MN

Route as short as possible

MEM1_ADQ(63:0)

0

BD21

SA_BS_0

1

BG18

SA_BS_1

2

AT25

SA_BS_2

0

AM37

SA_DM_0

1

AT41

SA_DM_1

AY41

SA_DM_2

3

AU39

SA_DM_3

4

BB12

SA_DM_4

5

AY6

SA_DM_5

6

AT7

SA_DM_6

7

AJ5

SA_DM_7

0

AJ43

SA_DQS#_0

1

AT43

SA_DQS#_1

2

BA44

SA_DQS#_2

3

BD37

SA_DQS#_3

4

AY12

SA_DQS#_4

5

BD8

SA_DQS#_5

6

AU9

SA_DQS#_6

7

AM8

SA_DQS#_7

0

AJ44

SA_DQS_0

1

AT44

SA_DQS_1

2

BA43

SA_DQS_2

3

BC37

SA_DQS_3

4

AW12

SA_DQS_4

5

BC8

SA_DQS_5

6

AU8

SA_DQS_6

7

AM7

SA_DQS_7

0

BA21

SA_MA_0

1

BC24

SA_MA_1

2

BG24

SA_MA_2

3

BH24

SA_MA_3

4

BG25

SA_MA_4

5

BA24

SA_MA_5

6

BD24

SA_MA_6

7

BG27

SA_MA_7

8

BF25

SA_MA_8

9

AW24

SA_MA_9

10

BC21

SA_MA_10

11

BG26

SA_MA_11

12

BH26

SA_MA_12

13

BH17

SA_MA_13

14

AY25

SA_MA_14

BD20

SA_CAS#

BB20

SA_RAS#

AY20

SA_WE#

BA17

SA_CS#_0

AY16

SA_CS#_1

BD17

SA_ODT_0

AY17

SA_ODT_1

BC28

SA_CKE_0

AY28

SA_CKE_1

AP24

SA_CK_0

AR24

SA_CK#_0

AT21

SA_CK_1

AR21

SA_CK#_1

BG22

SM_RCOMP

BH21

SM_RCOMP#

BF28

SM_RCOMP_V_OH

BH28

SM_RCOMP_V_OL

Cantiga

DDR2

2

1

0

AJ38

SA_DQ_0

2

3

AN38

AJ41

SA_DQ_1

SA_DQ_2

4

5

AJ36

AM38

SA_DQ_4

SA_DQ_3

7

AM44

AJ40

SA_DQ_6

SA_DQ_5

AM42

AN43

SA_DQ_7

SA_DQ_8

11315

AN44

AU40

SA_DQ_9

SA_DQ_10

13

12

AT38

AN41

AN39

SA_DQ_11

SA_DQ_12

AU44

AU42

AV39

SA_DQ_13

SA_DQ_14

SA_DQ_15

174719

AY44

BA40

BD43

SA_DQ_16

SA_DQ_17

SA_DQ_18

21

AV41

AY43

BB41

SA_DQ_20

SA_DQ_21

SA_DQ_19

23

2425

BC40

AY37

BD38

SA_DQ_22

SA_DQ_23

SA_DQ_24

28

27 542214

291026

AV36

AW36

AV37

AT36

AY38

BB38

SA_DQ_30

SA_DQ_25

SA_DQ_26

SA_DQ_27

SA_DQ_28

SA_DQ_29

SYSTEM MEMORY A

34

BD13

AU11

BC11

SA_DQ_31

SA_DQ_32

SA_DQ_33

35237

36

BA12

AU13

AV13

SA_DQ_34

SA_DQ_35

SA_DQ_36

38

SA_DQ_37

39

41

403216

BC12

BB9

BD12

SA_DQ_40

SA_DQ_38

SA_DQ_39

42 504410

43

BA9

AU10

AV9

SA_DQ_41

SA_DQ_42

45

4620

BA11

BD9

AY8

SA_DQ_43

SA_DQ_44

SA_DQ_45

U513-3
EB88CTPM
3 OF 5

SYSTEM MEMORY A

Samsung

Samsung

SB_DQ_5

SB_DQ_4

SB_DQ_3

SB_DQ_6

SB_DQ_7

SB_DQ_8

SB_DQ_2

SB_DQ_0

SB_DQ_1

AP46

AP47

AK47

AH46

Confidential

Confidential

0

1

SM_RCOMP : 80 ohm to P1.8V_AUX
SM_RCOMP# : 80 ohm to VSS

SB_DQ_9

SB_DQ_10

SB_DQ_11

SB_DQ_12

AJ48

AJ46

42

6

5

AT47

AP48

BA48

AY48

AU47

AU46

AM48

AR47

10 12 36 52

8

13

11

SB_DQ_13

SB_DQ_14

SB_DQ_15

BA47

BC47

BC46

153317

16

SB_DQ_16

SB_DQ_17

SB_DQ_18

BF43

BC44

BG43

19

18

SB_DQ_19

SB_DQ_20

BE45

BC41

2220

21

3

0904-002483

SYSTEM MEMORY B

SB_DQ_38

SB_DQ_39

SB_DQ_34

SB_DQ_35

SB_DQ_36

BG8

BF11

BH12

38

SB_DQ_37

BF8

BC5

BG7

4139123731

40

SB_DQ_40

BC6

42

SB_DQ_28

SB_DQ_29

SB_DQ_30

SB_DQ_31

SB_DQ_32

SB_DQ_27

BH40

BG39

BG34

30

29

BH34

32

BH14

33

BG12

34

SB_DQ_33

BH11

35

SB_DQ_21

SB_DQ_22

SB_DQ_23

SB_DQ_24

SB_DQ_25

SB_DQ_26

BF40

BF41

BF38

BH35

BG38

BG35

26

24

237

27

259

28 54

SB_DQ_41

SB_DQ_42

SB_DQ_43

BF6

AY3

AY1

44

45

43

47

49

48608

AV7

BA6

AV5

SA_DQ_46

SA_DQ_47

SA_DQ_48

SB_DQ_44

SB_DQ_45

SB_DQ_46

BF5

BA1

BD3

4614

2

529

AT9

AN8

AU5

SA_DQ_49

SA_DQ_50

SA_DQ_51

SB_DQ_48

SB_DQ_49

SB_DQ_47

AV2

AU3

AR3

51 53

49

50

5351

55

AU6

AT5

AN10

SA_DQ_52

SA_DQ_53

SA_DQ_54

SB_DQ_50

SB_DQ_51

SB_DQ_52

AY2

AV1

AN2

DRAW

CHECK

APPROVAL

MODULE CODE

57

58

AM11

AM5

AJ9

SA_DQ_55

SA_DQ_56

SA_DQ_57

SB_DQ_53

SB_DQ_54

SB_DQ_55

AL1

AP3

AR1

573059

55

56

61

6066218 56

59

AJ8

AN12

AM13

SA_DQ_59

SA_DQ_60

SA_DQ_58

SB_DQ_56

SB_DQ_57

SB_DQ_58

AJ1

AL2

AH1

6048

58

6331

AJ11

AJ12

SA_DQ_61

SA_DQ_62

SA_DQ_63

SB_DQ_59

SB_DQ_60

SB_DQ_61

AH3

AM2

AM3

62

63

61

MS Yang

MK Kim

BL Lee

SM_REXT
SM_VREF

SM_DRAMRST#

SM_PWROK

SB_CAS#
SB_RAS#

SB_WE#

SB_CS#_0
SB_CS#_1

SB_ODT_0
SB_ODT_1

SB_CKE_0
SB_CKE_1

SB_CK_0

SB_CK#_0

SB_CK_1

SB_CK#_1

SB_DM_0
SB_DM_1
SB_DM_2
SB_DM_3
SB_DM_4
SB_DM_5
SB_DM_6
SB_DM_7

SB_DQS#_0
SB_DQS#_1
SB_DQS#_2
SB_DQS#_3
SB_DQS#_4
SB_DQS#_5
SB_DQS#_6
SB_DQS#_7

SB_DQS_0
SB_DQS_1
SB_DQS_2
SB_DQS_3

SYSTEM MEMORY B

SB_DQS_4
SB_DQS_5
SB_DQS_6
SB_DQS_7

SB_MA_0
SB_MA_1
SB_MA_2
SB_MA_3
SB_MA_4
SB_MA_5
SB_MA_6
SB_MA_7
SB_MA_8

SB_MA_9
SB_MA_10
SB_MA_11
SB_MA_12
SB_MA_13
SB_MA_14

SB_BS_0

SB_BS_1

SB_BS_2

SB_DQ_62

SB_DQ_63

AJ3

DATE

12/05/2008

DEV. STEP

REV

LAST EDIT

MEM1_SM_REXT_MN

BF17
AV42

BC36
AR36

BG16
AU17
BF14

AV16
AR13

BF15
AY13

AY36
BB36

AV24
AU24
AU20
AV20

AM47
AY47
BD40
BF35
BG11
BA3
AP1
AK2

AL46
AV47
BH41
BH37
BG9
BC2
AT2
AN5

AL47
AV48
BG41
BG37
BH9
BB2
AU1
AN6

AV17
BA25
BC25
AU25
AW25
BB28
AU28
AW28
AT33
BD33
BB16
AW33
AY33
BH15
AU33

BC16
BB17
BB33

MEM1_BDQ(63:0)

TITLE

MP

REV 1.0

1

MEM1_VREF

1%

499

R225

MEM1_VREF

MEM1_BCAS#
MEM1_BRAS#
MEM1_BWE#

MEM1_CS2#
MEM1_CS3#

MEM1_ODT2
MEM1_ODT3

MEM1_CKE2
MEM1_CKE3

CLK1_MCLK2
CLK1_MCLK2#
CLK1_MCLK3
CLK1_MCLK3#

0
1
2
3
4
5

7

0
1
2
3
4
5
6
7

1
2
3
4
5
6
7

0
1
2
3
4
5
6
7
8
9

11
13

14

0
1
2

MEM1_BDM(7:0)

MEM1_BDQS#(7:0)

MEM1_BDQS(7:0)

MEM1_BMA(14:0)

MEM1_BBS(2:0)

BONN-E

MCH_CANTIGA_PM_DDR2

CANTIGA (3/5)

April 11, 2009 10:05:58 AM

1

PLACE EACH CAP NEAR AV42 PIN

C407

C408

100nF

100nF

10V

10V

nostuff
nostuff

SM_PWROK
DDR2 : GND
DDR3 : Connect to VRM.

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

15 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

D

P1.05V

P1.05V_PEG

C

P1.5V

C276

C277

100nF

10nF
25V

10V

R171

B

A

4

EC10

220uF

C226

10000nF

6.3V

nostuff

C360

100nF
10V

MCH1_P1.5V_QDAC_MN

0

nostuff

P1.8V_AUX

C398

22000nF-X5R

2.5V

20%

AD

6.3V

C373

1000nF

6.3V

A21
B21
B22

AF48
AG47
AH47
AH48

B27
A26

A25

A24
B24

M25

L28

R173

0

J48

L37

M38

K47

MCH1_VCC_SM_LF_7_MN
MCH1_VCC_SM_LF_6_MN
MCH1_VCC_SM_LF_5_MN
MCH1_VCC_SM_LF_4_MN
MCH1_VCC_SM_LF_3_MN
MCH1_VCC_SM_LF_2_MN
MCH1_VCC_SM_LF_1_MN

3

22000nF-X5R

VCC_AXF_1
VCC_AXF_2
VCC_AXF_3

VCC_DMI_1
VCC_DMI_2
VCC_DMI_3
VCC_DMI_4

C399

20%

6.3V

C415

100nF
10V

C410

100nF
10V

VCC AXG

VCC AXGCRT / TV POWERLVDS POWER

AW16

BA36

BB21

BB24

BD16

VCC_SM_NC_3

VCC_SM_NC_4

VCC_SM_NC_5

VCC_SM_NC_6

VCC_SM_NC_7

AT13

AW13

BH32

BH29

BH31

VCC_SM_35

VCC_SM_34

VCC_SM_NC_1

VCC_SM_NC_2

BG29

BG30

BG31

BG32

VCC_SM_30

VCC_SM_31

VCC_SM_32

VCC_SM_33

BF29

BF31

BF32

BD32

VCC_SM_26

VCC_SM_27

VCC_SM_28

VCC_SM_29

BB32

BC29

BC32

BD29

VCC_SM_25

VCC_SM_22

VCC_SM_23

VCC_SM_24

VCC_SM

AY32

BA29

BA32

BB29

VCC_SM_18

VCC_SM_19

VCC_SM_20

VCC_SM_21

AV32

AY29

AW29

AW32

VCC_SM_14

VCC_SM_15

VCC_SM_16

VCC_SM_17

AV29

AU29

AU32

VCC_SM_10

VCC_SM_11

VCC_SM_12

VCC_SM_13

AT29

AT32

AR32

VCC_SM_7

VCC_SM_8

VCC_SM_9

AP33

AR29

VCC_SM_5

VCC_SM_6

U513-4

VCCA_CRT_DAC_1
VCCA_CRT_DAC_2

EB88CTPM

4 OF 5

VCC_SM_CK_2

VCC_SM_CK_3

VCC_SM_CK_1

BF20

BF21

0904-002483

VCCA_SM_CK_NCTF_1

VCCA_SM_CK_NCTF_2

VCCA_SM_CK_NCTF_3

VCCA_SM_CK_NCTF_4

VCCA_SM_CK_NCTF_5

VCCA_SM_CK_NCTF_6

VCCA_SM_CK_NCTF_7

VCCA_SM_CK_NCTF_8

AL23

AL24

AL25

AM23

AM24

AM25

AM26

AM28

C380

100nF

10V

VCCA_SM_CK_4

VCCA_SM_CK_5

VCCA_SM_CK_3

AP25

AP28

C402

2200nF

10V

nostuff

VCCA_SM_9

VCCA_SM_CK_1

VCCA_SM_CK_2

AN28

AN24

AN25

P1.05V

C331

22000nF-X5R

20%

6.3V

VCCA_SMVCCA_SM_CKVCCA_SM_CK_NCTF

VCCA_SM_6

VCCA_SM_7

VCCA_SM_8

AT16

AR17

AR20

VCCA_DAC_BG

VCCA_TV_DAC_1
VCCA_TV_DAC_2

VCCD_TVDAC

VCCD_QDAC

VCCA_LVDS

VCCD_LVDS_1
VCCD_LVDS_2

VCC_TX_LVDS VSS_AXG_SENSE

Samsung

Samsung

VCC_SM_LF_5

VCC_SM_LF_6

VCC_SM_LF_7

AY5

AV44

BA37

BB13

100nF

10V

C414

6.3V 1000nF-X5R

C411

220nF

10V

C405

6.3V

1000nF-X5R

C403

Confidential

Confidential

220nF

10V

C406

16V

470nF

C375

100nF

10V

C378

P1.8V_AUX

B29
BLM18PG181SN1

MCH1_P1.8VAUX_SM_CK_R_MN

VCC_SM_LF_1

VCC_SM_LF_2

VCC_SM_LF_3

VCC_SM_LF_4

AV21

AM10

AM40

R233

1

C426

10000nF

6.3V

VCC_SM_CKVCC_SM_LF

VCC_SM_CK_4

BH20

BG20

MCH1_P1.8VAUX_SM_CK_MN

C423
100nF

10V

3

AP32

AP29

AN32

AN33

VCC_SM_2

VCC_SM_4

VCC_SM_3

VCCA_SM_3

VCCA_SM_4

VCCA_SM_5

AP16

AP17

AP20

AR16

2

VCC_SM_1

VCCA_SM_1

VCCA_SM_2

AN20

AN17

C366

1000nF

6.3V

2

VCC HADVCC_HVPEG POWER

PLL POWER

VCC_AXG_SENSE

AXG SENSE

C379

4700nF

10V

CHECK

APPROVAL

MODULE CODE

VCC_HDA

VCC_HV_1
VCC_HV_2
VCC_HV_3

VCC_PEG_1
VCC_PEG_2
VCC_PEG_3
VCC_PEG_4
VCC_PEG_5

VCCA_PEG_BG

VCCA_PEG_PLL

VCCD_PEG_PLL

VCCA_DPLLA

VCCA_DPLLB

VCCA_HPLL

VCCA_MPLL

VCCD_HPLL

C392

22000nF-X5R

20%

6.3V

A32

A35
B35
C35

U46
U47
U48
V47
V48

AD48

AA48

AA47

F47

L48

AD1

AE1

AF1

AJ14
AH14

22000nF-X5R

100nF

MCH1_P1.05V_PEG_PLL_MN

MCH1_P1.05V_MPLL_MN

R205

0

R204

0

nostuff
nostuff

MCH1_VCC_AXG_SENSE_MN
MCH1_VSS_AXG_SENSE_MN

C334

20%

6.3V

nostuff

DATEDRAW

MS Yang

DEV. STEP

MK Kim

REV

BL Lee

LAST EDIT

P1.5V

C292

P1.05V

EC9
220uF

2.5V
AD

12/05/2008

REV 1.0

P3.3V

C599
100nF

Cantiga : 1.5V

10V

C367

100nF
10V

C353

100nF
10V

P1.05V

TITLE

MP

10V

C361

4700nF-X5R

R200

1

P1.05V

MCH1_P3.3V_HV_R_MN

R621

2A routing

C656

4700nF-X5R
10V

10V

1

C333

22000nF-X5R
20%

6.3V

3

12.1

1 2

1%

BAT54A
D518

P1.05V_PEG

EC508

C655

22000nF-X5R

220uF

20%

2.5V

6.3V

AD

C666
100nF

10V

C364

100nF
10V

BLM18PG181SN1

B25

R199

1

MCH1_P1.05V_MPLL_R_MN

BONN-E

MCH_CANTIGA_PM_DDR2

CANTIGA (4/5)

April 11, 2009 10:05:58 AM

1

P1.05V

INSTPAR

SHORT504

INSTPAR

SHORT503

P1.05V

B515

R650

1

BLM18PG181SN1

MCH1_P1.05V_PEG_PLL_R_MN

C673

10000nF

6.3V

P1.05V

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

16 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

A12

VSS_1

A15

VSS_2

A18

VSS_3

A20

VSS_4

A23

VSS_5

A29

VSS_6

A31

VSS_7

A34

VSS_8

AA1

VSS_9

AA10

VSS_10

AA12

VSS_11

AA14

VSS_12

AA26

VSS_13

AA35

VSS_14

AA38

VSS_15

AA41

VSS_16

AA44

VSS_17

AA7

VSS_18

AB21

VSS_19

AB24

VSS_20

AB26

VSS_21

AB28

VSS_22

AB33

VSS_23

AB47

VSS_24

AC15

VSS_25

AC2

C

B

AC25
AD12

AD2
AD38
AD41

AD47

AD5

AD9
AE10
AE13

AE2
AE28
AE34
AE36
AE39
AE42

AE7

AF2
AF21
AF24
AF26
AF34
AF47
AG20
AG23
AG28
AH11

AH2
AH21
AH24
AH26
AH33
AH35
AH38
AH41
AH44

AH5

AH8
AJ10
AJ13

AJ20
AJ24

VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62
VSS_63
VSS_64
VSS_65
VSS_66
VSS_67

AJ2

VSS_68
VSS_69
VSS_70

AJ39

AJ42

AJ47

AJ7

AK15

AL3

AL33

AL48

VSS_77

VSS_78

VSS_79

VSS_SCB_2

VSS_SCB_3

VSS_SCB_4C1VSS_SCB_5

A48

BH1

BH48

VSS_80

VSS_81

AM1

VSS_82

VSS_83

VSS_NCTF_1

AA17

AJ25

AJ28

AJ34

AJ37

VSS_75

VSS_76

VSS_71

VSS_72

VSS_73

VSS_74

VSS

Samsung

Samsung

TV & LVDS

VSS SCB VSS NCTF VSS

VSS

VSS_SCB_1

VSSA_DAC_BG

VSSA_LVDS

Confidential

Confidential

A3

J47

B25

AM12

AM34

AM36

AM39

VSS_84

VSS_85

VSS_86

VSS_NCTF_2

VSS_NCTF_3

VSS_NCTF_4

AF29

AB29

AB32

AC19

AM46

AM6

AM41

AM43

VSS_90

VSS_87

VSS_88

VSS_89

F38

VSS_241

F44

VSS_242

F46

VSS_243

F5

VSS_244

G11

VSS_245

G13

VSS_246

G16

VSS_247

G21

VSS_248

G24

VSS_249

G25

VSS_250

G41

VSS_251

G47

VSS_252

G9

VSS_253

H1

VSS_254

H17

VSS_255

H28

VSS_256

H29

VSS_257

H33

VSS_258

H37

VSS_259

H40

VSS_260

H46

VSS_261

H5

VSS_262

J12

VSS_263

J21

VSS_264

J24

VSS_265

J25

VSS_266

J36

VSS_267

J38

VSS_268

J43

VSS_269

J5

VSS_270

J7

VSS_271

K16

VSS_272

K2

VSS_273

K20

VSS_274

K24

VSS_275

K28

VSS_276

K29

VSS_277

K32

VSS_278

L12

VSS_279

L13

VSS_280

L24

VSS_281

L25

VSS_282

L33

VSS_283

L36

VSS_284

L39

VSS_285

L42

VSS_286

L47

VSS_287

L5

VSS_288

L8

VSS_289

M10

VSS_290

M17

VSS_291

M2

VSS_292

M21

VSS_293

M41

VSS_294

VSS_NCTF_5

VSS_NCTF_6

VSS_NCTF_7

VSS_NCTF_8

AJ17

AJ30

AL17

AF32

AM9

AN11

AN13

AN16

VSS_91

VSS_92

VSS_93

VSS_94

VSS_NCTF_9

VSS_NCTF_10

VSS_NCTF_11

VSS_NCTF_12

U17

U23

AL20

AM29

AN42

AN47

AN7

AN21

AN29

AN37

AN40

VSS_95

VSS_96

VSS_97

VSS_98

VSS_99

VSS_100

VSS_101

U513-5
EB88CTPM

5 OF 5

0904-002483

VSS

VSS_206

VSS_349

VSS_NCTF_14

VSS_NCTF_15

VSS_NCTF_16

VSS_NCTF_13

AJ6

V20

V32

U26

BG21

BG28

AN9

AP2

VSS_102

VSS_103

VSS_104

VSS

VSS_207

VSS_208

VSS_209

BG33

BG36

AP21

AR2

VSS_105

VSS_106

VSS_210

VSS_211

BG40

BG42

AR25

AR28

VSS_107

VSS_108

VSS_212

VSS_213

BG6

BH23

AR46

AR33

VSS_109

VSS_214

BH25

BH38

AR48

AT10

VSS_110

VSS_111

VSS_112

VSS

VSS_216

VSS_217

VSS_215

C11

BH8

AT12

AT17

VSS_113

VSS_114

VSS_295
VSS_296
VSS_297
VSS_298
VSS_299
VSS_300
VSS_301
VSS_302
VSS_303
VSS_304
VSS_305
VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313
VSS_314
VSS_315
VSS_316
VSS_317
VSS_318
VSS_319
VSS_320
VSS_321
VSS_322
VSS_323
VSS_324
VSS_325
VSS_326
VSS_327
VSS_328
VSS_329
VSS_330
VSS_331
VSS_332
VSS_333
VSS_334
VSS_335
VSS_336
VSS_337
VSS_338
VSS_339
VSS_340
VSS_341
VSS_342
VSS_343
VSS_344
VSS_345
VSS_346
VSS_347
VSS_348

VSS_218

VSS_219

C14

C17

AT20

AT24

VSS_115

VSS_116

VSS_220

VSS_221

C20

C26

AT28

AT37

VSS_117

VSS_118

M44
M6
N11
N13
N16
N20
N25
N29
N32
N39
N42
N47
N7
P1
P28
P3
P33
P36
P46
R17
R21
R24
R3
R46
T29AD44
T35
T38
T41
T44
T47
U24
U25
U28
U29
U35
U38
U41
U44
V46
W15
W34
Y11
Y2
Y20
Y23
Y25
Y28
Y35
Y38
Y41
Y44
Y47
Y5
Y8

VSS_222

VSS_223

C28

C32

AT42

AT39

VSS_119

VSS_224

C37

C38

AT6

AT8

VSS_120

VSS_121

VSS_122

VSS_225

VSS_226C6VSS_227

C43

AU16

AU2

VSS_123

VSS_124

VSS_228

VSS_229

E13

E16

AU21

AU36

VSS_125

VSS_126

VSS_230

VSS_231

E24

E25

AU38

AU41

AU43

VSS_127

VSS_128

VSS_129

VSS_232E8VSS_233

VSS_234

F20

E40

AU48

AU7

VSS_130

VSS_131

VSS_235

VSS_236

F24

F28

AV10

AV12

AV25

VSS_132

VSS_133

VSS_134

VSS_237F3VSS_238

VSS_239

F29

F32

AV28

VSS_135

VSS

VSS_240

F36

VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179
VSS_180
VSS_181
VSS_182
VSS_183
VSS_184
VSS_185
VSS_186
VSS_187
VSS_188
VSS_189
VSS_190
VSS_191
VSS_192
VSS_193
VSS_194
VSS_195
VSS_196
VSS_197
VSS_198
VSS_199
VSS_200
VSS_201
VSS_202
VSS_203
VSS_204
VSS_205

AV3
AV33
AV40
AV43
AV46
AV6
AV8
AW17
AW2
AW20
AW21
AW37
AW47
AY11
AY24
AY42
AY46
AY7
B23
B26
B34
B36
B39
B41
B8
B9
BA13
BA16
BA2
BA20
BA28
BA33
BA38
BA46
BA5
BB11
BB25
BB37
BB40
BB47
BB8
BC13
BC17
BC20
BC3
BC33
BC38
BC43
BC9
BD11
BD25
BD28
BD36
BD41
BD46
BD6
BE4
BF12
BF24
BF26
BF34
BF37
BF44
BF9
BG10
BG13
BG14
BG15
BG17
BG19

D

C

B

A

MS Yang

DEV. STEPCHECK

APPROVAL

MODULE CODE

4

3

2

MK Kim

BL Lee

REV

LAST EDIT

12/05/2008

REV 1.0

TITLEDATEDRAW

MP

MCH_CANTIGA_PM_DDR2

BONN-E

CANTIGA (5/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

17 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

DDR SO-DIMM #0

3

2

1

D

MEM1_ADQ(63:0)

D

P0.9V

DDR501-1
DDR2-SODIMM-200P-STD

MEM1_AMA(14:0)

R387
R388

MEM1_ABS(2)
MEM1_ABS(0)

MEM1_ABS(1)

MEM1_CS0#
MEM1_CS1#

CLK1_MCLK0

CLK1_MCLK0#

CLK1_MCLK1

CLK1_MCLK1#

MEM1_CKE0
MEM1_CKE1

MEM1_ACAS#
MEM1_ARAS#

MEM1_AWE#

MEM3_CHA_SA0_MN

10K 1%

MEM3_CHA_SA1_MN

10K 1%

SMB3_CLK

SMB3_DATA

MEM1_ODT0
MEM1_ODT1

MEM1_ADM(7:0)

C

B

MEM1_ADQS(7:0)

MEM1_ADQS#(7:0)

A

4

1/2

0

102

A0

1

101

A1

2

100

A2

3

99

A3

4

98

A4

5

97

A5

6 6

94

A6

7

92

A7

8

93

A8

9

91

A9

10

105

A10_AP

11

90

A11

12

89

A12

13

116

A13

14

86

A14

84

A15

85

A16_BA2

107

BA0

106

BA1

110

S0*

115

S1*

30

CK0

32

CK0*

164

CK1

166

CK1*

79

CKE0

80

CKE1

113

CAS*

108

RAS*

109

WE*

198

SA0

200

SA1

197

SCL

195

SDA

114

ODT0

119

ODT1

0

10

DM0

1

26

DM1

2

52

DM2

3

67

DM3

4

130

DM4

5

147

DM5

6

170

DM6

7

185

DM7

0

13

DQS0

1

31

DQS1

2

51

DQS2

3

70

DQS3

4 56

131

DQS4

5

148

DQS5

6

169

DQS6

7

188

DQS7

0

11

DQS*0

1

29

DQS*1

2

49

DQS*2

3

68

DQS*3

4

129

DQS*4

5

146

DQS*5

6

167

DQS*6

7

186

DQS*7

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

5
7
17
19
4
6
14
16
23
25
35
37
20
22
36
38
43
45
55
57
44
46
56
58
61
63
73
75
62
64
74
76
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194

3709-001325

0
1
2 5
3
4
5

7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

MCH3_EXTTS0#

27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44

Samsung

Samsung

45
46
47
48
49
50
51
52
53
54
55

57
58
59
60
61
62
63

Confidential

Confidential

C3586

100nF
10V

MEM1_VREF

P3.3V

C3605

100nF
10V

CLK1_MCLK0

CLK1_MCLK0#

CLK1_MCLK1

CLK1_MCLK1#

C3625

2200nF
10V

C889

2200nF

10V

P1.8V_AUX

C3913
C3914
C3915
C3916

DDR501-2
DDR2-SODIMM-200P-STD

2/2

112
111
117

96
95

118

81
82
87

103

88

104
199

83

120

50
69

163

201
202

47
133
183

77

12

48
184

78

71

72
121
122
196
193

VDD1
VDD2
VDD3
VDD4
VDD5
VDD6
VDD7
VDD8
VDD9
VDD10
VDD11
VDD12

VDDSPD
NC1

NC2
NC3
NC4
NCTEST

1

VREF
GND0

GND1
VSS1

VSS2
VSS3
VSS4
VSS5
VSS6
VSS7
VSS8
VSS9
VSS10
VSS11
VSS12
VSS13
VSS14

8

VSS15

3709-001325

0.012nF

0.012nF

0.012nF

0.012nF

nostuff
nostuff
nostuff
nostuff

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57

50V
50V
50V
50V

18
24
41
53
42
54
59
65
60
66
127
139
128
145
165
171
172
177
187
178
190
9
21
33
155
34
132
144
156
168
2
3
15
27
39
149
161
28
40
138
150
162

EMC request

3

2

MEM1_AMA(14:0)

MEM1_CS0#
MEM1_CS1#

MEM1_CKE0
MEM1_CKE1

MEM1_ODT0
MEM1_ODT1

MEM1_ABS(0)
MEM1_ABS(1)
MEM1_ABS(2)

MEM1_ACAS#
MEM1_ARAS#

MEM1_AWE#

P0.9V

C3773

100nF

10V

P1.8V_AUX

EC522
220uF

2.5V
AD

DRAW

CHECK

APPROVAL

MODULE CODE

0

R402

1

R369

2

R401

3

R368

4

R400
R366

6

R399

7

R398

8

R367

9

R364

10

R370

11

R397

12

R365

13

R407

14

R396
R405

R375
R362

R395
R406

R374
R371

R403
R363

R373
R404
R372

56
56
56
56
56
56
56
56
56
56
56
56
56
56
56

56
56

56
56

56
56

56
56
56

56
56
56

Place one cap close to every 2 pull-up resistors terminated to P0.9V

C3607

10V

C927

100nF100nF

C862

100nF

10V

10V

C895

100nF

10V

ME POWER RAIL UNDER ME ENABLE

C912

100nF

10V

100nF

10V

C3366

100nF

10V

100nF

10V

C909

100nF

10V

C3393

C3175

Place near SO-DIMM0

C911

C878

C3558

nostuff

C3210

2200nF
10V

MS Yang

MK Kim

BL Lee

2200nF
10V

DATE

DEV. STEP

REV

LAST EDIT

2200nF
10V

12/05/2008

REV 1.0

2200nF
10V

TITLE

MP

C3585

C3749

100nF

2200nF

10V

10V

BONN-E

SODIMM_DDR2

SODIMM_DDR2 #1

April 11, 2009 10:05:58 AM

C926

C3574

C3172

100nF

10V

C3556

100nF
10V

100nF

10V

C3604

100nF

100nF

10V

C3606

100nF
10V10V

nostuff
nostuff
nostuff
nostuff
nostuff
nostuff

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

ELECTRONICS

BA41-01060A

6718

OF

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

DDR SO-DIMM #1

3

2

1

R344
R345

MEM1_BDQ(63:0)

MEM1_BMA(14:0)

MEM1_BBS(2)
MEM1_BBS(0)

MEM1_BBS(1)

MEM1_CS2#
MEM1_CS3#

CLK1_MCLK2

CLK1_MCLK2#

CLK1_MCLK3

CLK1_MCLK3#

MEM1_CKE2
MEM1_CKE3

MEM1_BCAS#
MEM1_BRAS#

MEM1_BWE#

MEM3_CHB_SA0_MN

10K 1%

MEM3_CHB_SA1_MN

10K 1%

SMB3_CLK

SMB3_DATA
MEM1_ODT2

MEM1_ODT3

MEM1_BDM(7:0)

MEM1_BDQS(7:0)

MEM1_BDQS#(7:0)

DDR500-1
DDR2-SODIMM-200P-RVS

1/2

0

102

A0

1

101

A1

2

100

A2

3

99

A3

4

98

A4

5

97

A5

6

94

A6

7

92

A7

8

93

A8

9

91

A9

10

105

A10_AP

11

90

A11

12

89

A12

13

116

A13

14

86

A14

84

A15

85

A16_BA2

107

BA0

106

BA1

110

S0*

115

S1*

30
32

CK0*

164

CK1

166

CK1*

79

CKE0

80

CKE1

113

CAS*

108

RAS*

109

WE*

198

SA0

200

SA1

197

SCL

195

SDA

114

ODT0

119

ODT1

0

10

DM0

1

26

DM1

2

52

DM2

3

67

DM3

4

130

DM4

5

147

DM5

6

170

DM6

7

185

DM7

0

13

DQS0

1

31

DQS1

2

51

DQS2

3

70

DQS3

4

131

DQS4

5

148

DQS5

6

169

DQS6

7

188

DQS7

0

11

DQS*0

1

29

DQS*1

2

49

DQS*2

3

68

DQS*3

4

129

DQS*4

5

146

DQS*5

6

167

DQS*6

7

186

DQS*7

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24CK0
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

MEM1_BMA(14:0)

P1.8V_AUX

0

5

1

7

2

17

3

19

4

4

5

6

6

14

7

16

8

23

9

25

10

35

11

37

12

20

13

22

14

36

15

38

16

43

17

45

18

55

19

57

20

44
46
56
58
61
63
73
75
62
64
74
76
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194

MCH3_EXTTS1#

21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

Samsung

Samsung

46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63

Confidential

Confidential

C3819

100nF
10V

MEM1_VREF

P3.3V

C3682

100nF
10V

C923

2200nF
10V

C935

2200nF
10V

CLK1_MCLK2

CLK1_MCLK2#

CLK1_MCLK3

CLK1_MCLK3#

DDR500-2
DDR2-SODIMM-200P-RVS

2/2

112

VDD1

111

VDD2

117

VDD3

96

VDD4

95

VDD5

118

VDD6

81

VDD7

82

VDD8

87

VDD9

103

VDD10

88

VDD11

104

VDD12

199

VDDSPD

83

NC1

120

NC2

50

NC3

69

NC4

163

NCTEST

1

VREF

201

GND0

202

GND1

47

VSS1

133

VSS2

183

VSS3

77

VSS4

12

VSS5

48

VSS6

184

VSS7

78

VSS8

71

VSS9

72

VSS10

121

VSS11

122

VSS12

196

VSS13

193

VSS14

8

VSS15

3709-001327

C3917
C3918
C3919
C3920

0.012nF

0.012nF

0.012nF

0.012nF

nostuff
nostuff
nostuff
nostuff

18

VSS16

24

VSS17

41

VSS18

53

VSS19

42

VSS20

54

VSS21

59

VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57

65
60
66
127
139
128
145
165
171
172
177
187
178
190
9
21
33
155
34
132
144
156
168
2
3
15
27
39
149
161
28
40
138
150
162

MEM1_CS2#
MEM1_CS3#

MEM1_CKE2
MEM1_CKE3

MEM1_ODT2
MEM1_ODT3

MEM1_BBS(0)
MEM1_BBS(1)
MEM1_BBS(2)

MEM1_BCAS#
MEM1_BRAS#

MEM1_BWE#

Place one cap close to every 2 pull-up resistors terminated to P0.9V

P0.9V

C3591

C898

C3241

100nF

100nF

100nF

10V

10V

10V

P1.8V_AUX

50V
50V
50V
50V

EC11
220uF

2.5V
AD

nostuff

0
1
2
3
4
5
6
7
8
9
10
11
12
13
14

C887

C904

100nF

10V

10V

Place near SO-DIMM1

C3427

2200nF 2200nF
10V

C493

2200nF

10V

10V

R338
R320
R337
R319
R336
R318
R334
R335
R317
R316
R322
R332
R315
R342
R333

R341
R325

R314
R313

R343
R326

R321
R339
R331

R324
R340
R323

C3597

10V

C928

100nF100nF

10V

C496

2200nF
10V

D

C

P3.3V

B

C925

100nF

10V

56
56
56
56
56
56
56
56
56
56
56
56
56
56
56

56
56

56
56

56
56

56
56
56

56
56
56

C3563

2200nF
10V

C881

100nF100nF

10V

P0.9V

C893

100nF

10V

C3784C495

100nF
10V

C899

100nF
10V

C867

100nF

10V

C3622

100nF

10V

C492

100nF
10V 10V

C491

100nF

C3424

100nF

10V

nostuff
nostuff
nostuff

nostuff
nostuff

nostuff

D

C

B

3709-001327

A

4

3

EMC request

DRAW

CHECK DEV. STEP

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

SODIMM_DDR2

SODIMM_DDR2 #2

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

6719

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

D

P3.3V_MICOM

D519

BAT54C

3

1 2

C

J21

1

2
MNT1
MNT2

3711-000541

HDR-2P-SMD

Angel type

RTC1_BATT_MN

3
4

R697

RTC1_BATT_R_MN

1K

B

PRTC_BAT

CHP3_INTRUDER#_R_MN

C459

1000nF-X5R

20K

R257

20K

R254

C460

1000nF-X5R

6.3V

nostuff
nostuff

Internal VR Strap
INTVRMEN

VccSus1_05, VccSus1_5, VccCL1_5
VccLAN1_05, VccCL1_05

19-B3 9-D4

1M

R255

1%

1%

C473

1000nF-X5R

6.3V

19-B4 9-D4

9-D419-B4

C732

10000nF

6.3V

CHP3_SATALED#

3

Pull up

PRTC_BAT

R282

P3.3V

300K

1%

R733
R732

R751
R750

R726
R727

SAT1_HDD_RXN

SAT1_HDD_RXP
SAT1_HDD_TXN
SAT1_HDD_TXP

SAT1_ODD_RXN
SAT1_ODD_RXP

SAT1_ODD_TXN
SAT1_ODD_TXP

CHP3_INTRUDER#

CHP3_RTCRST#

R253

0

CHP3_ME_RTCRST#

nostuff

For RTC Reset

HDA3_AUD_BCLK

HDA3_MDC_BCLK
HDA3_AUD_SYNC

HDA3_MDC_SYNC

HDA3_AUD_RST#

HDA3_MDC_RST#

Samsung

Samsung

R354

10K

1%

Confidential

Confidential

SATA Cap. Place ment :
Distance b/w the ICH9-M & cap on the "P" signal should be identical
distance b/w the ICH9-M & cap on the "N" signal same pair.

CHP3_RTCRST#

CHP3_ME_RTCRST#

CHP3_INTRUDER#

22
22

22
22

22
22

HDA3_AUD_SDO
HDA3_MDC_SDO

CHP3_INTVRMEN_MN

MDC

MDC

MDC

C748
C747
C744
C746

C759
C755
C751
C750

Y501

C734

32.768KHz

0.007nF

23

2801-003856

C736

0.007nF

P1.5V

CHP3_COMPIO_MN

R696

HDA3_BCLK_R_MN
HDA3_SYNC_R_MN

HDA3_RST#_R_MN

HDA3_AUD_SDI0
HDA3_MDC_SDI1

R741
R740

10nF

25V

10nF

25V

10nF 25V

25V

10nF

25V

10nF

25V10nF
25V10nF
25V10nF

14

R275

10M

CHP3_XTALOUT_MN

9-D4 19-B4

19-B49-D4
19-B39-D4

C3268

0.015nF

nostuff

50V

1%

24.9

HDA3_SDO_R_MN

22
22

MDC

SAT1_HDD_RXN_C_MN
SAT1_HDD_RXP_C_MN
SAT1_HDD_TXN_C_MN
SAT1_HDD_TXP_C_MN

SAT1_ODD_RXN_C_MN
SAT1_ODD_RXP_C_MN
SAT1_ODD_TXN_C_MN
SAT1_ODD_TXP_C_MN

U518-1
NH82801IBM

CHP3_XTALIN_MN

1 / 5

C23

RTCX1

C24

RTCX2

A25

RTCRST#

F20

SRTCRST#

C22

INTRUDER#

B22

INTVRMEN

A22

LAN100_SLP

E25

GLAN_CLK

C13

LAN_RTCSYNC

F14

LAN_RXD0

G13

LAN_RXD1

D14

LAN_RXD2

D13

LAN_TXD0

D12

LAN_TXD1

E13

LAN_TXD2

B10

GLAN_DOCK#_GPIO56

B28

GLAN_COMPI

B27

GLAN_COMPO

AF6

HDA_BIT_CLK

AH4

HDA_SYNC

AE7

HDA_RST#

AF4

HDA_SDIN0

AG4

HDA_SDIN1

AH3

HDA_SDIN2

AE5

HDA_SDIN3

AG5

HDA_SDOUT

AG7

HDA_DOCK_EN#_GPIO33

AE8

HDA_DOCK_RS#_GPIO34

AG8

SATALED#

AJ16

SATA0RXN

AH16

SATA0RXP

AF17

SATA0TXN

AG17

SATA0TXP

AH13

SATA1RXN

AJ13

SATA1RXP

AG14

SATA1TXN

AF14

SATA1TXP

0904-002378

2 1

0

K5

CPU LPCSATA

IHDA LAN / GLAN RTCSATA

FWH0_LAD0
FWH1_LAD1
FWH2_LAD2
FWH3_LAD3

FWH4_LFRAME#

LDRQ0#

LDRQ1#_GPIO23

A20GATE

A20M#

DPRSTP#

DPSLP#

FERR#

CPUPWRGD

IGNNE#

RCIN#

STPCLK#

THRMTRIP#

SATA4RXN
SATA4RXP
SATA4TXN
SATA4TXP

SATA5RXN
SATA5RXP
SATA5TXN
SATA5TXP

SATA_CLKN

SATA_CLKP

SATARBIAS#

SATARBIAS

INIT#
INTR

SMI#

PECI

NMI

1

K4

2

L6

3

K2
K3
J3

J1
N7

AJ27
AJ25

AE23
AJ26
AD22
AF25
AE22

AG25
L3

AF23
AF24

AH27

CPU1_THRMTRIP#_RR_MN

AG26
AG27

SAT1_ESATA_RXN_C_MN

AH11

SAT1_ESATA_RXP_C_MN

AJ11

SAT1_ESATA_TXN_C_MN

AG12

SAT1_ESATA_TXP_C_MN

AF12
AH9

AJ9
AE10
AF10

AH18
AJ18

AJ7
AH7

SAT1_ARBIAS_MN

R357

24.9
1%

CPU1_FERR#_R_MN

R262

R269

25V
25V
25V 10nF
25V 10nF

CLK1_SATA#
CLK1_SATA

KBC3_CPURST#

KBC3_A20G

LPC3_LAD(3:0)

LPC3_LFRAME#

KBC3_A20G

CPU1_A20M#
CPU1_DPRSTP#

CPU1_DPSLP#

CPU1_IGNNE#
CPU1_INIT#

CPU1_INTR

CPU1_NMI
CPU1_SMI#

CPU1_STPCLK#

10nF
10nF

P1.05V

56

P1.05V

R268

56

54.9

1%

Place 56 ohm resistor within 2" of ICH9M
Place PU resistor within 2" of 56ohm res.

C930

SAT1_ESATA_RXN

C3197

SAT1_ESATA_RXP

C3560

SAT1_ESATA_TXN

C920

SAT1_ESATA_TXP

R384
R347

R263

56

CPU1_FERR#
CPU1_PWRGDCPU

C3892

0.1nF
50V

nostuff

For ESD

For ESD

CPU1_THRMTRIP#

10K

10K

C3900

0.1nF
50V

D

P3.3V

1%

1%

C

KBC3_CPURST#

nostuff

B

A

DRAW

CHECK

APPROVAL PART NO.

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

ICH_9M_B

ICH9-M (1/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

BA41-01060A

20 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4 3

2

1

HIGH
HIGH
LOW

R265

10K

D

C

P3.3V

B

D

P3.3V

P3.3V

10K

R360

10K

R378

LPC option ; These are used with LPC

B

P3.3V_AUX

CHP3_SERIRQ
PCI3_CLKRUN#

PEX1_MINIRXN1

PEX1_MINIRXP1
PEX1_MINITXN1
PEX1_MINITXP1

PEX1_MINIRXN2

PEX1_MINIRXP2
PEX1_MINITXN2
PEX1_MINITXP2

Samsung

Samsung

PEX1_EXPCARDRXN3

PEX1_EXPCARDRXP3
PEX1_EXPCARDTXN3
PEX1_EXPCARDTXP3

PEX1_GLAN_RXN4
PEX1_GLAN_RXP4

PEX1_GLAN_TXN4
PEX1_GLAN_TXP4

C462
C461

C464
C463

C466
C465

C468
C467

R361
R391
R353
R359

100nF
100nF

100nF

100nF
100nF

100nF

10V
10V

10V
10V100nF

10V
10V

10V100nF
10V

CHP3_PIRGA#_MN

10K

CHP3_PIRGB#_MN

10K

CHP3_PIRGC#_MN

10K

CHP3_PIRGD#_MN

10K

PEX1_MINITXN1_C_MN
PEX1_MINITXP1_C_MN

PEX1_MINITXN2_C_MN
PEX1_MINITXP2_C_MN

PEX1_EXPCARDTXN3_C_MN
PEX1_EXPCARDTXP3_C_MN

PEX1_GLAN_TXN4__C_MN

PEX1_GLAN_TXP4_C_MN

U518-2
NH82801IBM

2/5

D11

AD0

C8

AD1

D9

AD2

E12

AD3

E9

AD4

C9

AD5

E10

AD6

B7

AD7

C7

AD8

C5

AD9 C_BE0#

G11

AD10

F8

AD11

F11

AD12

E7

AD13

A3

AD14

D2

AD15

F10

AD16

D5

AD17

D10

AD18

B3

AD19

F7

AD20

C3

AD21

F3

AD22

F4

AD23

C1

AD24

G7

AD25

H7

AD26

D1

AD27

G5

AD28

H6

AD29

G1

AD30

H3

AD31

J5

PIRQA#

E1

PIRQB#

J6

PIRQC#

C4

PIRQD#

N29

PERN1

N28

PERP1

P27

PETN1

P26

PETP1

L29

PERN2

L28

PERP2

M27

PETN2

M26

PETP2

J29

PERN3

J28

PERP3

K27

PETN3

K26

PETP3

G29

PERN4

G28

PERP4

H27

PETN4

H26

PETP4

0904-002378

AC caps : PCIE need to be within 250mils of the driver
Resistor for Test : Place Stuffing Option to minimize stubs

PCI

REQ1#_GPI050
GNT1#_GPIO51
REQ2#_GPIO52
GNT2#_GPIO53
REQ3#_GPIO54
GNT3#_GPIO55

PIRQE#_GPIO2

Interrupt I/F

PIRQF#_GPIO3
PIRQG#_GPIO4
PIRQH#_GPIO5

PCI - Express

PERN6_GLAN_RXN

PERP6_GLAN_RXP

PETN6_GLAN_TXN
PETP6_GLAN_TXP

SPI

SPI_CS1#_GPIO58_CLGPIO6

REQ0#
GNT0#

C_BE1#
C_BE2#
C_BE3#

IRDY#

PAR

PCIRST#

DEVSEL#

PERR#

PLOCK#

SERR#
STOP#
TRDY#

FRAME#

PLTRST#

PCICLK

PME#

PERN5
PERP5
PETN5

PETP5

SPI_CLK

SPI_CS0#
SPI_MOSI

SPI_MISO

F1
G4
B6
A7
F13
F12
E6
F6

D8
B4
D6
A5

D3
E3
R1
C6
E4
C2
J4
A4
F5
D7

C14
D4
R2

H4
K6
F2
G2

FFS3_INT_R_MN

E29
E28
F27
F26

C29
C28
D27
D26

D23
D24
F23
D25
E23

PCI3_REQ0#_MN

PCI3_GNT0#_MN

PCI3_IRDY#_MN

PCI3_PCIRST#_MN

PCI3_EDVSEL#_MN

PCI3_PERR#_MN

PCI3_PCLK#_MN
PCI3_SERR#_MN
PCI3_STOP#_MN
PCI3_TRDY#_MN

PCI3_FRAME#_MN

R762

nostuff

P3.3V

nostuff

R266

1K
1%

SPI3_CLK_R_MN

SPI3_CS0#_R_MN

R267

SPI3_MOSI_R_MN

R385

R352
R358
R389
R380
R377
R382
R351

P3.3V

0

iTPM Disable

1%
10K

R761

12.1

R376

1K
1%

nostuff

R390

R278
R272

1%

P3.3V

10K

10K

10K
10K
10K
10K
10K
10K
10K

PLT3_RST_ORG#
CLK3_PCLKICH

FFS3_INT

BIOS
LPCCHIGH
SPI
PCI

12.1

12.1

SPI3_MOSI
SPI3_MISO

Boot BIOS Select

PCI3_GNT0#

LOW
HIGH

1%
1%

SPI3_CS1#_R_MN

SPI3_CLK
SPI3_CS0#

SPI3_CS1#

U519

5

7SZ08

1

SHORT557

R1005-SHORT

+

4

2

-

3

nostuff

R720

100K

1%

Confidential

Confidential

C3893

0.1nF
50V

For ESD

PLT3_RST#

nostuff

A

12/05/2008

REV 1.0

TITLEDRAW

BONN-E

MP

ICH_9M_B

ICH9-M (2/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

6721

OF

DATE

MS Yang

CHECK

APPROVAL

MODULE CODE

3

2

MK Kim

BL Lee

undefined

DEV. STEP

REV

LAST EDIT

PLT3_RST_ORG#

A

4

10K

1K 1%

10K 1%

4.7K

4.7K

4

nostuff
nostuff

1%10K

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

P3.3V_AUX

D

R312

R305

P3.3V

R288

R349

C

R329

R328

B

P3.3V

R393

10K

1%

R350

10K
1%

nostuff
nostuff

A

R394

10K

1%

R346

10K
1%

nostuff
nostuff

4

SMB3_ALERT#

PEX3_WAKE#

CHP3_BIOSWP#

AUD3_SPKR

SMB3_DATA

SMB3_CLK

High

No Woofer
Sub-Woofer

Low

CHP3_GPIO18
CHP3_GPIO20

PU : No Reboot Mode

KBC3_RSMRST#

NoWoofer

Sub-Woofer

P3.3V

R279

10K

R707

0

nostuff

P3.3V_AUX

P3.3V_AUX

R292

P3.3V_AUX

PEX3_WAKE#

P3.3V

10K
1%

R304

10K
1%

VRM3_CPU_PWRGD

Added by EMC

KBC3_PWRGD

100 1%

R711

9-B4

48-C3

19-D3

R297

10K

R309

4.7K
5%

1%

Samsung

Samsung

CHP3_SATACLKREQ#

Confidential

Confidential

CHP3_BIOS_CRI#

R302

nostuff

P3.3V

BIOS CRISIS RECOVER STRAP
PLACE NEAR KEYBOARD

( Put it a debugger connector)

3

2.2K

2.2K

R308

R327

P3.3V_AUX

R298

10K
1%

0

C3901

0.1nF
50V

nostuff

P3.3V_AUX

R355

10K
1%

KBC3_RSMRST#_R_MN

R710

10K
1%

P3.3V

R392

10K

1%

iTPM Disable

3

P3.3V_AUX

R311

10K
1%

SMB3_CLK

SMB3_DATA

CHP3_SUSSTAT#

ITP3_DBRESET#

CHP3_PM_SYNC#

SMB3_ALERT#

CHP3_PCISTP#

CHP3_CPUSTP#

PCI3_CLKRUN#

CHP3_SERIRQ
THM3_ALERT#

CHP3_SLPS3#
CHP3_SLPS4#
CHP3_SLPS5#

CHP3_DPRSLPVR

R330

KBC3_PWRBTN#

CLK3_PWRGD
KBC3_PWRGD

KBC3_EXTSMI#

CHP3_BIOSWP#

KBC3_RUNSCI#

KBC3_WAKESCI#

CHP3_GPIO18
CHP3_GPIO20

CHP3_BIOS_CRI#

R277
R301

R734

AUD3_SPKR

MCH3_ICHSYNC#

CLK3_ICH14

CLK3_USB48

PEX3_WAKE#_R_MN

10K

10K

1%
1%

10K
10K

1%

P3.3V

CHP3_LINKALERT#_MN

CHP3_SMLINK0_MN
CHP3_SMLINK1_MN

CHP3_BATLOW#_MN

1%

SATA_PWR_EN0#
SATA_PWR_EN1#

CHP3_SDATAOUT0_MN
CHP3_SDATAOUT1_MN

CHP3_GPIO57_MN

nostuff

CHP3_SUSCLK_MN

CHP3_SATA4GP_MN

47K

R273

0

U518-3
NH82801IBM
3 / 5

G16

SMBCLK

A13

SMBDATA

E17

LINKALERT#_GPIO60_CLGPIO4

C17

SMLINK0

B18

SMLINK1

F19

RI#

R4

SUS_STAT#_LPCPD#

G19

SYS_RESET#

M6

PMSYNC#_GPIO0

A17

SMALERT#_GPIO11

A14

STP_PCI#_GPIO15

E19

STP_CPU#_GPIO25

L4

CLKRUN#_GPIO32

E20

WAKE#

M5

SERIRQ

AJ23

THRM#

D21

VRMPWRGD

A20

TP8

C16

SLP_S3#

E16

SLP_S4#

G17

SLP_S5#

C10

S4_STATE#_GPIO26

G20

PWROK

M2

DPRSLPVR_GPIO16

B13

BATLOW#

R3

PWRBTN#

D20

LAN_RST#

R927

D22

RSMRST#

R5

CK_PWRGD

R6

CLPWROK

B16

SLP_M#

AG19

TACH1_GPIO1

AH21

TACH2_GPIO6

AG21

TACH3_GPIO7

A21

GPIO8

C12

LANPHYPC_GPIO12

C21

ENGDET_GPIO13

AE18

TACH0_GPIO17

K1

GPIO18

AF8

GPIO20

AJ22

SCLOCK_GPIO22

A9

QRT_STATE0_GPIO27

D19

QRT_STATE1_GPIO28

L1

SATACLKREQ#_GPIO35

AE19

SLOAD_GPIO38

AG22

SDATAOUT0_GPIO39

AF21

SDATAOUT1_GPIO48

AH24

GPIO49

A8

GPIO57_CLGPIO5

M7

SPKR

AJ24

MCH_SYNC#

B21

TP3

AH20

PWM0

AJ20

PWM1

AJ21

PWM2

H1

CLK14

AF3

CLK48

P1

SUSCLK

AH23

SATA0GP_GPIO21

AF19

SATA1GP_GPIO19

AE21

SATA4GP_GPIO36

AD20

SATA5GP_GPIO37

0904-002378

2

SYS GPIO SMBGPIOMISC

Controller LinkUSB Direct Media Interface

GPIO Clocks Power MGT

SATA

2

DMI0RXN
DMI0RXP
DMI0TXN
DMI0TXP

DMI1RXN
DMI1RXP
DMI1TXN
DMI1TXP

DMI2RXN
DMI2RXP
DMI2TXN
DMI2TXP

DMI3RXN
DMI3RXP
DMI3TXN
DMI3TXP

DMI_CLKN
DMI_CLKP

DMI_ZCOMP

DMI_IRCOMP

CL_CLK0
CL_CLK1

CL_DATA0
CL_DATA1

CL_VREF0
CL_VREF1

CL_RST0#
CL_RST1#

MEM_LED_GPIO24

ALERT#_GPIO10

NETDETECT_GPIO14

WOL_EN_GPIO9

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N

EHCI0

USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P

EHCI1

USBP9N
USBP9P

USBP10N

USBP10P

USBP11N

USBP11P

OC0#_GPIO59
OC1#_GPIO40
OC2#_GPIO41
OC3#_GPIO42
OC4#_GPIO43
OC5#_GPIO29
OC6#_GPIO30
OC7#_GPIO31
OC8#_GPIO44

OC9#_GPIO45
OC10#_GPIO46
OC11#_GPIO47

USBRBIAS

USBRBIAS#

DRAW

CHECK

APPROVAL

MODULE CODE

V27
V26
U29
U28

Y27
Y26
W29
W28

AB27
AB26
AA29
AA28

AD27
AD26
AC29
AC28

T26
T25

AF29
AF28

F24
B19

F22
C19

C25
A19

F21
D18

A16
C18
C11
C20

AC5
AC4
AD3
AD2
AC1
AC2
AA5
AA4
AB2
AB3
AA1
AA2
W5
W4
Y3
Y2
W1
W2
V2
V3
U5
U4
U1
U2

N4
N5
N6
P6
M1
N2
M4
M3
N3
N1

CHP3_EXTGFX_SEL_MN

P5
P3

AG2
AG1

CHP3_USBBIAS#_MN

DATE

MS Yang

DEV. STEP

MK Kim

REV

BL Lee

LAST EDIT

DMI1_RXN_0
DMI1_RXP_0
DMI1_TXN_0
DMI1_TXP_0

DMI1_RXN_1
DMI1_RXP_1
DMI1_TXN_1
DMI1_TXP_1

DMI1_RXN_2
DMI1_RXP_2
DMI1_TXN_2
DMI1_TXP_2

DMI1_RXN_3
DMI1_RXP_3
DMI1_TXN_3
DMI1_TXP_3

CLK1_PCIEICH#
CLK1_PCIEICH

R256

CHP3_DMI_COMP_MN

CHP3_CL_CLK_0

CHP3_CL_DATA_0

CHP3_CL_RST_0#

USB3_P0­USB3_P0+
USB3_WIMAX­USB3_WIMAX+
USB3_P2­USB3_P2+
USB3_MINIPCIE2­USB3_MINIPCIE2+
USB3_MMC­USB3_MMC+
USB3_BLUETOOTH­USB3_BLUETOOTH+
USB3_P6­USB3_P6+
USB3_EXPCARD­USB3_EXPCARD+
USB3_CAMERA­USB3_CAMERA+

USB3_P10­USB3_P10+

Ext GFX Select

R381

R379

12/05/2008

MP

REV 1.0

24.9
1%

CHP3_CL_VREF0_MN

1K
1%

22.6 1%

TITLE

April 11, 2009 10:05:58 AM

P1.5V

1608

BONN-E

ICH_9M_B

ICH9-M (3/5)

1

P3.3V

R694

3.24K
1%

C722

R695

100nF

453

10V

1%

USB0 : eSATA/Chargerble USB
USB1 : WIMAX
USB2 : Single USB
USB3 : HSDPA
USB4 : MMC Card
USB5 : Bluetooth
USB6 : USB (Sub Board)
USB7 : Express Card
USB8 : Camera
USB10 : USB(Sub Board)

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

D

C

B

A

6722

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

P1.5V

B32
BLM18PG181SN1

Need switched P5V_ALW controled by alws_on

P5.0V_AUX

R410

P3.3V_AUX

2

100

1%

3

1

C874
1000nF-X5R

P1.5V

B34
BLM18PG181SN1

B

4

BAT54A

D8

P1.5V

P1.5V

330ohm@100MHz

CHP3_P1.5V_5_B_MN

EC521

C475

220uF

20%

2.5V
AD

6.3V

22000nF-X5R

nostuff

P5.0V

R745

100
1%

C775

1000nF-X5R

CHP3_P5.0VAUX_VREF_SUS_MN

CHP3_P1.5V_VCSATAPLL_MN

C924

10000nF

6.3V

22000nF-X5R

C482

20%

6.3V

PRTC_BAT

P3.3V

2

BAT54A

D521

1

CHP3_P5.0V_V5REF_MN

C872

1000nF-X5R

6.3V

P1.5V

P1.5V

P3.3V

C3671

100nF
10V

3

C497

100nF
10V

C3596

100nF
10V

3

H25

VCC1_5_B_17

J24

VCC1_5_B_18

J25

VCC1_5_B_19

K24

VCC1_5_B_20

K25

VCC1_5_B_21

L23

VCC1_5_B_22

L24

VCC1_5_B_23

L25

VCC1_5_B_24

M24

VCC1_5_B_25

M25

VCC1_5_B_26

N23

VCC1_5_B_27

C720

2200nF
10V

C484

100nF
10V

C3587

100nF
10V

P3.3V

N24

VCC1_5_B_28

N25

VCC1_5_B_29

P24

VCC1_5_B_30

P25

VCC1_5_B_31

R24

VCC1_5_B_32

R25

VCC1_5_B_33

R26

VCC1_5_B_34

R27

VCC1_5_B_35

T24

VCC1_5_B_36

T27

VCC1_5_B_37

T28

VCC1_5_B_38

T29

VCC1_5_B_39

U24

VCC1_5_B_40

U25

VCC1_5_B_41

V24

VCC1_5_B_42

V25

VCC1_5_B_43

U23

VCC1_5_B_44

W24

VCC1_5_B_45

W25

VCC1_5_B_46

K23

VCC1_5_B_47

Y24

VCC1_5_B_48

Y25

VCC1_5_B_49

A23

VCCRTC

A6

V5REF

AE1

V5REF_SUS

AJ19

VCSATAPLL

AC16

VCC1_5_A_01

AD15

VCC1_5_A_02

AD16

C933

1000nF

6.3V

C888

1000nF

6.3V

C766
100nF

10V

VCC1_5_A_03

AE15

VCC1_5_A_04

AF15

VCC1_5_A_05

AG15

VCC1_5_A_06

AH15

VCC1_5_A_07

AJ15

VCC1_5_A_08

AC11

VCC1_5_A_09

AD11

VCC1_5_A_10

AE11

VCC1_5_A_11

AF11

VCC1_5_A_12

AG10

VCC1_5_A_13

AG11

VCC1_5_A_14

AH10

VCC1_5_A_15

AJ10

VCC1_5_A_16

AC9

VCC1_5_A_17

Samsung

Samsung

AC18

VCC1_5_A_18

AC19

VCC1_5_A_19

AC21

VCC1_5_A_20

G10

VCC1_5_A_21

G9

VCC1_5_A_22

AC12

VCC1_5_A_23

AC13

VCC1_5_A_24

AC14

VCC1_5_A_25

AJ5

VCCUSBPLL

AA7

VCC1_5_A_26

AB6

VCC1_5_A_27

AB7

VCC1_5_A_28

AC6

VCC1_5_A_29

AC7

VCC1_5_A_30

Confidential

Confidential

A10

VCCLAN1_05_1

A11

VCCLAN1_05_2

A12

VCCLAN3_3_1

B12

VCCLAN3_3_2

A27

VCCGLANPLL

D28

VCCGLAN1_5_1

D29

VCCGLAN1_5_2

E26

VCCGLAN1_5_3

E27

VCCGLAN1_5_4

A26

VCCGLAN3_3

H24

VCC1_5_B_13

VCC1_5_B_14

VCC1_5_B_15

VCC1_5_B_16

VCCA3GP

ARXATXUSB CORE

LOGIC_IO

LAN

GLAN POWER

VCCSUS3_3_20

VCCSUS3_3_19

T7

Y7

VCC1_5_B_08

VCC1_5_B_09

VCC1_5_B_10

VCC1_5_B_11

VCC1_5_B_12

U518-4
NH82801IBM

4/5

0904-002378

VCCPUSB

VCCSUS3_3_14

VCCSUS3_3_15

VCCSUS3_3_16

VCCSUS3_3_17

VCCSUS3_3_18

V6

V7

Y6

W6

W7

AB24

AB25

AC24

AC25

AD24

VCC1_5_B_03

VCC1_5_B_04

VCC1_5_B_05

VCC1_5_B_06

VCC1_5_B_07

VCCSUS3_3_09

VCCSUS3_3_10

VCCSUS3_3_11

VCCSUS3_3_12

VCCSUS3_3_13

T4

T5

T6

U6

U7

AA24

AA25

VCC1_5_B_01

VCC1_5_B_02

DMIHDA

VCCSUSHDA

VCCSUS1_05_1
VCCSUS1_05_2

VCCSUS1_5_1
VCCSUS1_5_2

VCCSUS3_3_01
VCCSUS3_3_02
VCCSUS3_3_03
VCCSUS3_3_04

CONTROL LINK VCCPSUS PCI VCCP CORE CORE

VCCSUS3_3_05

VCCSUS3_3_06

VCCSUS3_3_07

VCCSUS3_3_08

T1

T2

T3

AF1

VCC1_05_01
VCC1_05_02
VCC1_05_03
VCC1_05_04
VCC1_05_05
VCC1_05_06
VCC1_05_07
VCC1_05_08
VCC1_05_09
VCC1_05_10
VCC1_05_11
VCC1_05_12
VCC1_05_13
VCC1_05_14
VCC1_05_15
VCC1_05_16
VCC1_05_17
VCC1_05_18
VCC1_05_19
VCC1_05_20
VCC1_05_21
VCC1_05_22
VCC1_05_23
VCC1_05_24
VCC1_05_25
VCC1_05_26

VCCDMIPLL

VCC_DMI_1
VCC_DMI_2

V_CPU_IO_1
V_CPU_IO_2

VCC3_3_01
VCC3_3_02
VCC3_3_07
VCC3_3_03

VCC3_3_04
VCC3_3_05
VCC3_3_06

VCC3_3_08
VCC3_3_09
VCC3_3_10
VCC3_3_11
VCC3_3_12
VCC3_3_13
VCC3_3_14

VCCHDA

VCCCL1_05

VCCCL1_5

VCCCL3_3_1
VCCCL3_3_2

A15
B15
C15
D15
E15
F15
L11
L12
L14
L16
L17
L18
M11
M18
P11
P18
T11
T18
U11
U18
V11
V12
V14
V16
V17
V18

R29
W23

Y23
AB23

AC23
AG29
AJ6
AC10
AD19

AF20
AG24
AC20

B9
F9
G3
G6
J2
J7
K7

AJ4
AJ3
AC8

F17
AD8

CHP3_VCCSUS1_5_2_MN

F18
A18

D16
D17
E22

G22
G23
A24

B24

C910

22nF
25V

CHP3_VCCL1_05_MN

AD25

AE25

AE26

AE27

AE28

AE29

F25

G25

3

2

CHP3_P1.5V_VCCDMIPLL_MN

CHP3_P1.05V_VCC_DMI_MN

C905

C3573

100nF

100nF

10V

10V

nostuff
nostuff

CHP3_VCC1_5_MN

C485

C483

100nF

1000nF

10V

6.3V

nostuff
nostuff

P3.3V_AUX

C3801

C3670

22nF

100nF

25V

10V

2

P3.3V

C3762

100nF
10V

C896

100nF
10V

C3745

100nF
10V

P1.05V

C721

10nF
25V

C486

100nF
10V

DRAW

CHECK

APPROVAL

MODULE CODE

C916

100nF
10V

C499

4700nF
10V

C719

B518

10000nF

BLM18PG181SN1

6.3V

B33
BLM18PG181SN1

P3.3V

C3559

C3624

100nF

100nF

10V

10V

P3.3V_AUX

C886

100nF
10V

P3.3V

MS Yang

MK Kim

BL Lee

C488

100nF
10V

C3628

100nF
10V

P3.3V_AUX

C897

100nF
10V

DATE

DEV. STEP

REV

LAST EDIT

P1.5V

P1.05V

P1.05V

C749

C489

4700nF

100nF

10V

10V

P3.3V

C469

C458

100nF

100nF

10V

10V

P3.3V

C3590

100nF
10V

Internal : P1.5V level
External : P3.3V level

TITLE

12/05/2008

MP

REV 1.0

1

BONN-E

ICH_9M_B

ICH9-M (4/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

23 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

DD

CC

B

AA

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

AA26

VSS_001

AA27

VSS_002

AA3

VSS_003

AA6

VSS_004

AB1

VSS_005

AA23

VSS_006

AB28

VSS_007

AB29

VSS_008

AB4

VSS_009

AB5

VSS_010

AC17

VSS_011

AC26

VSS_012

AC27

VSS_013

AC3

VSS_014

AD1

VSS_015

AD10

VSS_016

AD12

VSS_017

AD13

VSS_018

AD14

VSS_019

AD17

VSS_020

AD18

VSS_021

AD21

VSS_022

AD28

VSS_023

AD29

VSS_024

AD4

VSS_025

AD5

C

B

AD6
AD7

AD9
AE12
AE13
AE14
AE16
AE17

AE2
AE20
AE24

AE3

AE4

AE6

AE9

AF13
AF16
AF18
AF22

AH26

AF26
AF27

AG13
AG16
AG18
AG20
AG23

AG3

AG6

AG9
AH12
AH14
AH17
AH19

AH2
AH22

AH25
AH28

AH5

AH8

AJ12
AJ14
AJ17

VSS_026
VSS_027
VSS_028
VSS_029
VSS_030
VSS_031
VSS_032
VSS_033
VSS_034
VSS_035
VSS_036
VSS_037
VSS_038
VSS_039
VSS_040
VSS_041
VSS_042
VSS_043
VSS_044
VSS_045
VSS_046
VSS_047
VSS_048

AF5

VSS_049

AF7

VSS_050

AF9

VSS_051
VSS_052
VSS_053
VSS_054
VSS_055
VSS_056
VSS_057
VSS_058
VSS_059
VSS_060
VSS_061
VSS_062
VSS_063
VSS_064
VSS_065
VSS_066
VSS_067
VSS_068
VSS_069
VSS_070
VSS_071
VSS_072

AJ8

VSS_073

B11

VSS_074

B14

VSS_075

B17

VSS_076

B2

VSS_077

B20

VSS_078

A

H29

J23

VSS_106H5VSS_107

VSS_079B5VSS_080B8VSS_081

B23

C26

J26

J27

VSS_108

VSS_109

VSS_110

VSS_084

VSS_082

VSS_083

E11

C27

AC22

K28

VSS_111

VSS_112

VSS_085

VSS_086

E14

E18

K29

L13

VSS_113

VSS_114

VSS_087

VSS_088

E2

E21

L5

M12

L15

L2

L26

L27

VSS_119L7VSS_120

VSS_121

VSS_115

VSS_116

VSS_117

VSS_118

GND

U518-5
NH82801IBM

5/5

0904-002378

VSS_089E5VSS_090E8VSS_091

VSS_092

VSS_093

VSS_094

VSS_095

F16

F28

F29

E24

G12

M13

M14

VSS_122

VSS_123

VSS_096

VSS_097

G14

G18

M15

M16

VSS_124

VSS_125

VSS_098

VSS_099

G21

G24

M17

M23

M28

VSS_126

VSS_127

VSS_128

VSS_100

VSS_101G8VSS_102H2VSS_103

G26

G27

N11

M29

VSS_130

VSS_129

VSS_104

H23

N12

N13

VSS_131

VSS_132

VSS_NCTF_01
VSS_NCTF_02
VSS_NCTF_03
VSS_NCTF_04
VSS_NCTF_05
VSS_NCTF_06
VSS_NCTF_07
VSS_NCTF_08
VSS_NCTF_09
VSS_NCTF_10
VSS_NCTF_11
VSS_NCTF_12

VSS_105

H28

N14

VSS_133

N15

VSS_134

N16

VSS_135

N17

VSS_136

N18

VSS_137

N26

VSS_138

N27

VSS_139

P12

VSS_140

P13

VSS_141

P14

VSS_142

P15

VSS_143

P16

VSS_144

P17

VSS_145

P2

VSS_146

P23

VSS_147

P28

VSS_148

P29

VSS_149

P4

VSS_150

P7

VSS_151

R11

VSS_152

R12

VSS_153

R13

VSS_154

R14

VSS_155

R15

VSS_156

R16

VSS_157

R17

VSS_158

R18

VSS_159

R28

VSS_160

T12

VSS_161

T13

VSS_162

T14

VSS_163

T15

VSS_164

T16

VSS_165

T17

VSS_166

T23

VSS_167

B26

VSS_168

U12

VSS_169

U13

VSS_170

U14

VSS_171

U15

VSS_172

U16

VSS_173

U17

VSS_174

AD23

VSS_175

U26

VSS_176

U27

VSS_177

U3

VSS_178

V1

VSS_179

V13

VSS_180

V15

VSS_181

V23

VSS_182

V28

VSS_183

V29

VSS_184

V4

Samsung

Samsung

VSS_185

V5

VSS_186

W26

VSS_187

W27

VSS_188

W3

VSS_189

Y1

VSS_190

Y28

VSS_191

Y29

VSS_192

Y4

VSS_193

Y5

VSS_194

AG28

VSS_195

AH6

VSS_196

AF2

VSS_197

B25

VSS_198

A1
A2
A28
A29
AH1
AH29

Confidential

Confidential

AJ1
AJ2
AJ28
AJ29
B1
B29

DRAW

CHECK

APPROVAL

MODULE CODE

3

24

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

ICH_9M_B

ICH9-M (5/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

24 67

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

D

C

B

A

OFPAGE

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4

16MBit

SPI3_CS0#

SPI3_MISO

CHP3_BIOSWP#

C

R787

3

SPI_BIOS_ROM

12.1

SPI3_MISO_R_MN

1%

R789

100K

U19
MX25L1605D

1

CE*

2

SO

3

WP*

4

VSS

1%

1107-001709

C-die : 1107-001600

VDD

HOLD*

SCK

SI

8

SPI3_HOLD#_MN

7
6

R788

5

10K 1%

C845

100nF

P3.3V

10V

SPI3_CLK
SPI3_MOSI

2

02 VERIFY REAL MODE
03 DISABLE NMI
04 GET CPU TYPE
06 INIT. SYSTEM H/W
08 INIT. CHIPSET REG.
09 SET IN POST FLAG
0A INIT CPU.REG
0B CPU CACHE ON
0C INIT.CACHE TO POST
OE INIT. I/O VALUE
0F ENABLE THE L-BUS IDE
10 INIT. POWER MANAGER
11 LOAD ALTERNATE REG.
13 PCI BUS MASTER RESET

WITH INITIAL POST VALUE
14 INIT. KEYBOARD CONTROLLER
16 CHECK CHECKSUM
18 8254 TIMER INIT.
1A 8237 DMA CONTROLLER INIT.
1C RESET INTERRUP CONTROLLER
20 TEST DRAM REFRESH
22 TEST 8742 KEYBOARD CONTROLLER
24 SET ES SEGMENT REG. TO 4GB
26 ENABLE A20
28 AUTO SIZING DRAM
32 COMPUTE THE CPU SPEED
34 TESET CMOS RAM
38 SHADOW SYSTEM BIOS ROM
3A AUTO SIZING CACHE
3C CONFIGURE ADVANCED CHIPSET REG.
3D LOAD ALTER REG. WITH CMOS VALUE
42 INIT. INTERRUPT VECTOR
44 INIT. BIOS INTERRUPT
46 CHECK ROM COPYRIGHT NOTICE
47 INIT. I20 SUPPORT IF INSTALLED
48 CHECK VIDEO CONFIGURE AGAINST CMOS
49 INIT. PCI BUS AND DEVICE
4A INIT. ALL VIDEO BIOS ROM
4C SHADOW VIDEO BIOS ROM
50 DISPLAY CPU TYPE AND SPEED
52 TEST KEYBOARD
54 SET KEYCLICK IF ENABLED
56 ENABLE KEYBOARD
58 TEST FOR UNEXPECTED INTERRUPTS

5A DISPLAY " PRESS ...... SETUP"

5C TEST RAM GETWEEN 512K AND 640K
60 TEST EXTENDED MEMORY
62 TEST EXTENDED MEMORY ADDRESS LINE
64 JUMP TO USER PATCH 1

1

66 CONFIGURE ADVANCE CACHE REG.
6A DISPLAY EXTERNAL CACHE SIZE
6C DISPLAY SHADOW MESSAGE
6E DISPLAY NON-DISPOSABLE SEGMENT
70 DISPLAY ERROR MESSAGE
72 CHECK FOR CONFIGURATION ERROR
74 TEST REAL-TIME CLOCK
76 CHECK FOR KEYBOARD EERROR
7C SETUP HARDWARE INTERRUPT VECTOR
7E TEST COPROCESSER IF PRESENT
80 DISABLE ON-BOARD I/O PORT
82 DETECT AND INSTALL EXT.RS232C
84 DETECT AND INSTALL EXT.PARALLEL
86 RE-INIT. ON-BOARD I/O PORT
88 INIT. BIOS DATA ROM
8A INIT.EXTENDED BIOS DATA AREA
8C INIT. FDD CONTROLLER
9A SHADOW OPTION ROMS
9C SETUP POWER MANAGEMENT
9E ENABLE H/W INTERRUPT
A0 SET TIME OF DAY
A4 INIT. TYPEMATIC RATE
A8 ERASE F2 PROMPT
AA SCAN FOR F2 KEY STROKE
AC ENTER SETUP
AE CLEAR IN POST FLAG
B0 CHECK FOR ERRORS
B2 POST DONE-PREPARE TO BOOT O/S
B4 ONE BEEP
B6 CHECK PASSWORD (OPTION)
B7 ACPI INIT
BA DMI INIT
BE CLEAR SCREEN
C0 TRY BOOT WITH INT19
D0 INTERRUPT HANDLER ERROR
D2 UNKNOWN INTERRUPT ERROR
D4 PENDING INTERRUPT ERROR
D6 SHUTDOWN 5
D8 SHUTDOWN ERROR
DA EXTENDED BLOCK MOVE
DC SHUTDOWN 10
89 ENABLE NMI
90 INIT. HDD CONTROLLER
91 INIT. LOCAL BUS HDD CONTROLLER
92 JUMP TO USER PATCH 2
94 DISABLE A20 ADDRESS LINE
96 CLEAR HUGE ES SEGMENT REG.
98 SEARCH FOR OPTION ROMS

D

C

Samsung

B

Samsung

B

80H DECODER CONNECTOR

P3.3V

J504

Confidential

Confidential

PLT3_RST#

CLK3_DBGLPC

LPC3_LFRAME#

LPC3_LAD(3)
LPC3_LAD(2)
LPC3_LAD(1)

A

4

LPC3_LAD(0)

HDR-10P-1R-SMD

1
2
3
4
5
6
7
8
9
10

11

MNT1

12

MNT2

3711-000386

Type : straight

3

A

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

SPI_BIOS_ROM
SPI_BIOS_ROM

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

25 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

C242
C246

C263
C269
C279
C294

C308
C318
C321
C332
C337

C359
C351
C248
C251
C262
C268
C278
C290
C300

C330
C336
C342
C349
C363
C354

R142

C146
C141
C157
C148
C174
C167
C190
C183

BONN-E

EXT_GFX

M9x (1/5)

1

0
1
2
3
4
5
6
7
8

9
10
11
12
13
14
15

0

1

2

3

4

5

6

8

9
10
11
1212
13
14
15

10V
10V
10V

10V100nF
10V100nF
10V

PEG1_RXP(15:0)

PEG1_RXN(15:0)

1%1.24K
1%2K

LCD3_BRIT

MCH3_LCDVDDON

LCD1_ACLK
LCD1_ACLK#

LCD1_ADATA0
LCD1_ADATA0#

LCD1_ADATA1
LCD1_ADATA1#

LCD1_ADATA2
LCD1_ADATA2#

PEG3_TXCP_HDMI
PEG3_TXCN_HDMI
PEG3_TX0P_HDMI
PEG3_TX0N_HDMI
PEG3_TX1P_HDMI
PEG3_TX1N_HDMI
PEG3_TX2P_HDMI
PEG3_TX2N_HDMI

16V

100nF

16V

100nF

16V

100nFC252

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nFC301

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nFC345

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nFC306

16V

100nFC314

16V

100nFC322

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

16V

100nF

R160
R165

10K 1%

100nF
100nF
100nF
100nF 10V
100nF 10V

100nF

PEG3_TXCP_HDMI_C_MN
PEG3_TXCN_HDMI_C_MN
PEG3_TX0P_HDMI_C_MN
PEG3_TX0N_HDMI_C_MN
PEG3_TX1P_HDMI_C_MN
PEG3_TX1N_HDMI_C_MN
PEG3_TX2P_HDMI_C_MN
PEG3_TX2N_HDMI_C_MN

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

PEG1_RXP0_C_MN
PEG1_RXP1_C_MN
PEG1_RXP2_C_MN
PEG1_RXP3_C_MN
PEG1_RXP4_C_MN
PEG1_RXP5_C_MN
PEG1_RXP6_C_MN
PEG1_RXP7_C_MN
PEG1_RXP8_C_MN
PEG1_RXP9_C_MN
PEG1_RXP10_C_MN
PEG1_RXP11_C_MN
PEG1_RXP12_C_MN
PEG1_RXP13_C_MN
PEG1_RXP14_C_MN
PEG1_RXP15_C_MN

PEG1_RXN0_C_MN
PEG1_RXN1_C_MN
PEG1_RXN2_C_MN
PEG1_RXN3_C_MN
PEG1_RXN4_C_MN
PEG1_RXN5_C_MN
PEG1_RXN6_C_MN
PEG1_RXN7_C_MN
PEG1_RXN8_C_MN
PEG1_RXN9_C_MN
PEG1_RXN10_C_MN
PEG1_RXN11_C_MN
PEG1_RXN12_C_MN
PEG1_RXN13_C_MN
PEG1_RXN14_C_MN
PEG1_RXN15_C_MN

P1.1V

ELECTRONICS

BA41-01060A

OF

6726

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D D

GFX3_GPIO0
GFX3_GPIO1
GFX3_GPIO2

GFX3_VOLTID2
MCH3_BKLTEN

GFX3_GPIO11
GFX3_GPIO12
GFX3_GPIO13

GFX3_VOLTID0

CLK3_GFX_27M_SS

C

GFX3_VOLTID1

GFX3_BBEN

ADT3_SEL#

PEG3_HPD_HDMI

P1.8V

B18

BLM18PG181SN1

C178

10000nF

6.3V

B

P1.1V

B506

BLM18PG181SN1

C574

10000nF

6.3V

CLK3_GFX_27M

GFX3_THERMDP
GFX3_THERMDN

P1.8V

B19

BLM18PG181SN1

C196

10000nF

6.3V

A

4

P3.3V_GFX

Q18

RHU002N06

G

1

R115

499

C177

C180

1000nF

100nF

6.3V

10V

GFX3_P1.8V_DPLL_PVDD_MN

GFX3_P1.1V_DPLL_VDDC_MN

C579

C577

100nF

1000nF

6.3V

10V

100

R593

1%

GFX3_P1.8V_TSVDD_MN

C191

C192

1000nF

100nF

6.3V

10V

R137

10K
1%

ADT3_SEL#_F_MN

D

3

S

2

P1.8V

GFX3_VREFG_MN

1%

R118

249
1%

CLK3_GFX_27M_MN

M9X_TP NET NAME

AK26

AJ26

AH20
AH18
AN16
AH23

AJ23

AH17

AJ17

AK17

AJ13

AH15

AJ16

AK16

AL16
AM16
AM14
AM13

AK14

AG30

AN14

AM17

AL13

AJ14

AK13
AN13

AM23

AN23
AK23

AL24
AM24

AJ19

AK19

AJ20

AK20

AJ24

AH26
AH24

AK24

AH13

C128

100nF

10V

AM32

AN32

AN31

AV33
AU34

R592

150
1%

AF29

AG29

AK32

AJ32

AJ33

U510-1
M96-M

SCL

I2C

SDA

GENERAL PURPOSE I/O

GPIO_0
GPIO_1
GPIO_2
GPIO_3_SMBDATA
GPIO_4_SMBCLK
GPIO_5_AC_BATT
GPIO_6
GPIO_7_BLON
GPIO_8_ROMSO
GPIO_9_ROMSI
GPIO_10_ROMSCK
GPIO_11
GPIO_12
GPIO_13
GPIO_14_HPD2
GPIO_15_PWRCNTL_0
GPIO_16_SSIN
GPIO_17_THERMAL_INT
GPIO_18_HPD3
GPIO_19_CTF
GPIO_20_PWRCNTL_1
GPIO_21_BB_EN
GPIO_22_ROMCSB
GPIO_23_CLKREQB
JTAG_TRSTB
JTAG_TDI
JTAG_TCK
JTAG_TMS
JTAG_TDO
GENERICA
GENERICB
GENERICC
GENERICD
GENERICE_HPD4
GENERICF
GENERICG

HPD1

VREFG

DPLL_PVDD
DPLL_PVSS

DPLL_VDDC

XTALIN
XTALOUT

DPLUS

THERMAL

DMINUS

TS_FDO
TSVDD
TSVSS

0904-002460

GFX3_SCL_MN
GFX3_SDA_MN
GFX3_GPIO8_MN
GFX3_GPIO9_MN
GFX3_GPIO10_MN
GFX3_GPIO14_MN
GFX3_GPIO18_MN
GFX3_GPIO19_MN
GFX3_GPIO22_MN
GFX3_GPIO23_MN

1 / 5

DAC1

HSYNC
VSYNC

AVSSQ

VDD1DI

VSS1DI

DAC2

H2SYNC

V2SYNC

VDD2DI

VSS2DI

A2VDD

A2VDDQ

A2VSSQ

Samsung

Samsung

DDC/AUXPLL/CLOCK

NC_DDCDATA_AUX7N

R2SET

DDC1CLK

DDC1DATA

AUX1N
AUX1P

DDC2CLK

DDC2DATA

AUX2N
AUX2P

DDCCLK_AUX3P

DDCDATA_AUX3N

DDCCLK_AUX4P

DDCDATA_AUX4N

Confidential

Confidential

DDCCLK_AUX5P

DDCDATA_AUX5N

DDC6CLK

DDC6DATA

NC_DDCCLK_AUX7P

M92-LP : 0904-002461

4

RSET
AVDD

COMP

R

R#

G

G#

B

B#

R2

R2#

G2

G2#

B2

B2#

C

Y

3

GFX3_JTAG_TRSTB_MN
GFX3_JTAG_TDI_MN
GFX3_JTAG_TCK_MN
GFX3_JTAG_TMS_MN
GFX3_JTAG_TDO_MN
GFX3_GENERICB_MN
GFX3_GENRICC_MN
GFX3_XTALOUT_MN
GFX3_H2SYNC_MN
GFX3_V2SYNC_MN
GFX3_NC_PWRGOOD_MN

P1.8V_VDDDI

P1.8V_AVDD

AD39
AD37

AE36
AD35

AF37
AE38

AC36
AC38

AB34
AD34

AE34
AC33

AC34

AC30
AC31

AD30
AD31

AF30
AF31

AC32
AD32
AF32
AD29
AC29

AG31
AG32

AG33
AD33
AF33
AA29
AM26

AN26
AL27

AM27
AM19

AL19

GFX3_DAC2_R2SET_MN

AM20
AN20

R155

715
1%

AL30
AM30

AL29
AM29

AN21
AM21

AJ30
AJ31

AK30
AK29

P1.8V

3

R148

150
1%

GFX3_DAC1_REST_MN

R163

499
1%

P1.8V_VDDDI

P3.3V_GFX

P1.8V_A2VDDQ

BLM18PG181SN1

B524

R156

150
1%

C198

100nF

10V

C597

100nF

10V

C3873

10000nF-X5R

6.3V

R149

150
1%

C216

6.3V

1000nF-X5R

nostuff

C596

10V

100nF

C3875

1000nF-X5R

6.3V

C209

0.012nF
50V

B8

C131

BLM18PG181SN1

6.3V

10000nF-X5R

B510

BLM18PG181SN1

C600

6.3V
10000nF-X5R

P1.8V_AVDD

C3874

100nF
10V

PEG1_TXP(15:0)

PEG1_TXN(15:0)

C229

C210

0.012nF

0.012nF
50V

50V

P1.8V

P1.8V

CRT3_DDCCLK
CRT3_DDCDATA

LCD3_EDID_CLK
LCD3_EDID_DATA

PEG3_HDMI_CLK
PEG3_HDMI_DATA

GFX3_DVPDATA_20_MN
GFX3_DVPDATA_21_MN

GFX3_DVPDATA_22_MN
GFX3_DVPDATA_23_MN

CRT3_RED

CRT3_GREEN

CRT3_BLUE

CRT3_HSYNC
CRT3_VSYNC

CLK1_PEG#

PLT3_RST#

LCD1_BCLK

LCD1_BCLK#

LCD1_BDATA0

LCD1_BDATA0#

LCD1_BDATA1

LCD1_BDATA1#

LCD1_BDATA2

LCD1_BDATA2#

CLK1_PEG

P1.8V

R585
R587
R586
R584

2

0

AA38

PCIE_RX0P

1

Y35

PCIE_RX1P

2

W38

PCIE_RX2P

3

V35

PCIE_RX3P

4

U38

PCIE_RX4P

5

T35

PCIE_RX5P

6

R38

PCIE_RX6P

7

P35

PCIE_RX7P

8

N38

PCIE_RX8P

9

M35

PCIE_RX9P

10

L38

PCIE_RX10P

11

K35

PCIE_RX11P

12

J38

PCIE_RX12P

13

H35

PCIE_RX13P

14

G38

PCIE_RX14P

15

F35

PCIE_RX15P

0

Y37

PCIE_RX0N

1

W36

PCIE_RX1N

2

V37

PCIE_RX2N

3

U36

PCIE_RX3N

4

T37

PCIE_RX4N

5

R36

PCIE_RX5N

6

P37

PCIE_RX6N

7 7

N36

PCIE_RX7N

8

M37

PCIE_RX8N

9

L36

PCIE_RX9N

10

K37

PCIE_RX10N

11

J36

PCIE_RX11N

H37

PCIE_RX12N

13

G36

PCIE_RX13N

14

10K
10K
10K
10K

nostuff
nostuff
nostuff
nostuff

F37

15

E37

AB35
AA36

AJ21
AK21
AH16

AA30

AK35

AL36

AJ38
AK37

AH35

AJ36
AG38

AH37
AF35

AG36

AR8
AU8
AP8

AW8

AR3
AR1
AU1
AU3

AW3

AP6

AW5

AU5
AR6

AW6

AU6
AT7
AV7
AN7
AV9
AT9

AR10

AW10

AU10
AP10
AV11
AT11
AR12

1%
1%

AW12

1%

AU12
AP12

1%

DRAW

CHECK

APPROVAL

MODULE CODE

PCIE_RX14N
PCIE_RX15N

CLOCK

PCIE_REFCLKP
PCIE_REFCLKN

NC_1
NC_2
NC_PWRGOOD

PERSTB

TXCLK_UP_DPF3P
TXCLK_UN_DPF3N

TXOUT_U0P_DPF2P
TXOUT_U0N_DPF2N

TXOUT_U1P_DPF1P
TXOUT_U1N_DPF1N

TXOUT_U2P_DPF0P
TXOUT_U2N_DPF0N

TXOUT_U3P
TXOUT_U3N

MUTI GFX

DVPCNTL_MVP_0
DVPCNTL_MVP_1
DVPCNTL_0
DVPCNTL_1
DVPCNTL_2
DVPCLK
DVPDATA_0
DVPDATA_1
DVPDATA_2
DVPDATA_3
DVPDATA_4
DVPDATA_5
DVPDATA_6
DVPDATA_7
DVPDATA_8
DVPDATA_9
DVPDATA_10
DVPDATA_11
DVPDATA_12
DVPDATA_13
DVPDATA_14
DVPDATA_15
DVPDATA_16
DVPDATA_17
DVPDATA_18
DVPDATA_19
DVPDATA_20
DVPDATA_21
DVPDATA_22
DVPDATA_23

PCI EXPRESS INTERFACE

CALIBRATION

PCIE_CALRP
PCIE_CALRN

LVDS CONTROL

TXCLK_LP_DPE3P
TXCLK_LN_DPE3N

TXOUT_L0P_DPE2P
TXOUT_L0N_DPE2N

TXOUT_L1P_DPE1P
TXOUT_L1N_DPE1N

TXOUT_L2P_DPE0P
TXOUT_L2N_DPE0N

LVTMDP

TXCAP_DPA3P

TXCAM_DPA3N

TX0P_DPA2P

DPA

TX0M_DPA2N

TX1P_DPA1P

TX1M_DPA1N

TX2P_DPA0P

TX2M_DPA0N

TXCBP_DPB3P

TXCBM_DPB3N

TX3P_DPB2P

DPB

TX3M_DPB2N

TX4P_DPB1P

TX4M_DPB1N

TX5P_DPB0P

TX5M_DPB0N

TXCCP_DPC3P

TXCCM_DPC3N

TX0P_DPC2P

TX0M_DPC2N

DPC

TX1P_DPC1P

TX1M_DPC1N

TX2P_DPC0P

TX2M_DPC0N

TXCDP_DPD3P

TXCDM_DPD3N

TX3P_DPD2P

TX3M_DPD2N

DPD

TX4P_DPD1P

TX4M_DPD1N

TX5P_DPD0P

TX5M_DPD0N

DEV. STEP

REV

LAST EDIT

12/05/2008

MP

REV 1.0

MS Yang

MK Kim

BL Lee

2

PCIE_TX0P
PCIE_TX1P
PCIE_TX2P
PCIE_TX3P
PCIE_TX4P
PCIE_TX5P
PCIE_TX6P
PCIE_TX7P
PCIE_TX8P

PCIE_TX9P
PCIE_TX10P
PCIE_TX11P
PCIE_TX12P
PCIE_TX13P
PCIE_TX14P
PCIE_TX15P

PCIE_TX0N

PCIE_TX1N

PCIE_TX2N

PCIE_TX3N

PCIE_TX4N

PCIE_TX5N

PCIE_TX6N

PCIE_TX7N

PCIE_TX8N

PCIE_TX9N
PCIE_TX10N
PCIE_TX11N
PCIE_TX12N
PCIE_TX13N
PCIE_TX14N
PCIE_TX15N

VARY_BL

DIGON

TXOUT_L3P
TXOUT_L3N

TITLEDATE

Y33
W33
U33
U30
T33
T30
P33
P30
N33
N30
L33
L30
K33
J33
K30
H33
Y32
W32
U32
U29
T32
T29
P32
P29
N32
N29
L32
L29
K32
J32
K29
H32

Y30

GFX3_PCIE_CALRP_MN

Y29

GFX3_PCIE_CALRN_MN

AK27
AJ27

AP34
AR34

AW37
AU35

AR37
AU39

AP35
AR35

AN36
AP37

AU24
AV23
AT25
AR24
AU26
AV25
AT27
AR26
AR30
AT29
AV31
AU30
AR32
AT31
AT33
AU32
AU14
AV13
AT15
AR14
AU16
AV15
AT17
AR16
AU20
AT19
AT21
AR20
AU22
AV21
AT23
AR22

April 11, 2009 10:05:58 AM

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3 2

1

U510-5

D D

PEG1_DQA(63:0)

C C

B B

P1.5V

R202

100
1%

R198

100
1%

C352

100nF
10V

GFX3_MVREFDA_MN GFX3_MVREFDB_MN

C309

100nF
10V

GFX3_MEM_CALRP1_MN

R184

240

0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63

AG12

AH12

C37
C35

G32
D33

D31
C30

C28

D27
C26

C24

C22

D21

D19
C18

D17

D15

D13

D11

C10
G13
H13

H11
G10

N12

M12
M27

A35
E34

F32
E32

F30
A30

F28
A28

E28
F26
A26

F24
A24

E24
A22

F22
A20

F20
E18
A18

F18
A16

F16
E14

F14
F12

A12
F10

A10

J13

G8
K9

K10

G9
A8
C8
E8
A6
C6
E6
A5

L18
L20

L27

M96-M

DQA_0
DQA_1
DQA_2
DQA_3
DQA_4
DQA_5
DQA_6
DQA_7
DQA_8
DQA_9
DQA_10
DQA_11
DQA_12
DQA_13
DQA_14
DQA_15
DQA_16
DQA_17
DQA_18
DQA_19
DQA_20
DQA_21
DQA_22
DQA_23
DQA_24
DQA_25
DQA_26
DQA_27
DQA_28
DQA_29
DQA_30
DQA_31
DQA_32
DQA_33
DQA_34
DQA_35
DQA_36
DQA_37
DQA_38
DQA_39
DQA_40
DQA_41
DQA_42
DQA_43
DQA_44
DQA_45
DQA_46
DQA_47
DQA_48
DQA_49
DQA_50
DQA_51
DQA_52
DQA_53
DQA_54
DQA_55
DQA_56
DQA_57
DQA_58
DQA_59
DQA_60
DQA_61
DQA_62
DQA_63

MVREFDA
MVREFSA

NC_MEM_CALRN0
NC_MEM_CALRN1
NC_MEM_CALRN2

MEM_CALRP1
NC_MEM_CALRP0
NC_MEM_CALRP2

0904-002460

MEMORY INTERFACE A

A A

4

5 / 5

MAA_0
MAA_1
MAA_2
MAA_3
MAA_4
MAA_5
MAA_6
MAA_7
MAA_8

MAA_9
MAA_10
MAA_11
MAA_12

MAA_BA2
MAA_BA0
MAA_BA1

DQMA_0
DQMA_1
DQMA_2
DQMA_3
DQMA_4
DQMA_5
DQMA_6
DQMA_7

RDQSA_0
RDQSA_1
RDQSA_2
RDQSA_3
RDQSA_4
RDQSA_5
RDQSA_6
RDQSA_7

WDQSA_0
WDQSA_1
WDQSA_2
WDQSA_3
WDQSA_4
WDQSA_5
WDQSA_6
WDQSA_7

ODTA0

ODTA1

CLKA0

CLKA0#

CLKA1

CLKA1#

RASA0#
RASA1#

Samsung

Samsung

CASA0#
CASA1#

CSA0_0#
CSA0_1#

CSA1_0#
CSA1_1#

CKEA0

CKEA1

WEA0#

WEA1#
RSVD_1

RSVD_2
RSVD_3

RSVD_5

Confidential

Confidential

RSVD_6
RSVD_9

RSVD_11

G24
J23
H24
J24
H26
J26
H21
G21
H19
H20
L13
G16
J16
H16
J17
H17

A32
C32
D23
E22
C14
A14
E10
D9

C34
D29
D25
E20
E16
E12
J10
D7

A34
E30
E26
C20
C16
C12
J11
F8

J21
G19

H27
G27

J14
H14

K23
K19

K20
K17

K24
K27

M13
K16

K21
J20

K26
L15

AF28
AG28
AL31

H23
J19

T8
W8

0
1
2
3
4
5

7
8

9
10
11
12

2

0

1

0

1

2

3

4

5

6

724

0

1

2

3

4

5

6

7

0

1

2

3

4

5

6

7

PEG1_MAA(12:0)

PEG1_BAA(2:0)

PEG1_DQMA(7:0)

PEG1_RDQSA(7:0)

PEG1_WDQSA(7:0)

PEG1_ODTA0
PEG1_ODTA1

PEG1_MCLKA0
PEG1_MCLKA0#

PEG1_MCLKA1
PEG1_MCLKA1#

PEG1_RASA0#
PEG1_RASA1#

PEG1_CASA0#
PEG1_CASA1#

PEG1_CSA00#

PEG1_CSA10#

PEG1_MCKEA0
PEG1_MCKEA1

PEG1_WEA0#
PEG1_WEA1#

3

P1.5V

R169

100
1%

R166

100
1%

PEG1_DQC(63:0)

C233

C254

100nF

100nF

10V

10V

GFX3_TESTEN_MN

GFX3_CLKTESTA_MN
GFX3_CLKTESTB_MN

R152

R147

1K

4.7K

1%

2

0

C5

DQB_0

1

C3

DQB_1

2

E3

DQB_2

3

E1

DQB_3

4

F1

DQB_4

5

F3

DQB_5

6

F5

DQB_6

7

G4

DQB_7

8

H5

DQB_8

9

H6

DQB_9

10

J4

DQB_10

11

K6

DQB_11

12

K5

DQB_12

13

L4

DQB_13

14

M6

DQB_14

15

M1

DQB_15

16

M3

DQB_16

17

M5

DQB_17

18

N4

DQB_18

19

P6

DQB_19

20

P5

DQB_20

21

R4

DQB_21

22

T6

DQB_22

23

T1

DQB_23

24

U4

DQB_24

25

V6

DQB_25

26

V1

DQB_26

27

V3

DQB_27

28

Y6

DQB_28

29

Y1

DQB_29

30

Y3

DQB_30

31

Y5

DQB_31

32

AA4

DQB_32

33

AB6

DQB_33

34

AB1

DQB_34

35

AB3

DQB_35

36

AD6

DQB_36

37

AD1

DQB_37

38

AD3

DQB_38

39

AD5

DQB_39

40

AF1

DQB_40

41

AF3

DQB_41

42

AF6

DQB_42

43

AG4

DQB_43

44

AH5

DQB_44

45

AH6

DQB_45

46

AJ4

DQB_46

47

AK3

DQB_47

48

AF8

DQB_48

49

AF9

DQB_49

50

AG8

DQB_50

51

AG7

DQB_51

52

AK9

DQB_52

53

AL7

DQB_53

54

AM8

DQB_54

55

AM7

DQB_55

56

AK1

DQB_56

57

AL4

DQB_57

58

AM6

DQB_58

59

AM1

DQB_59

60

AN4

DQB_60

61

AP3

DQB_61

62

AP1

DQB_62

63

AP5

DQB_63

Y12

MVREFDB

AA12

MVREFSB

AD28

TESTEN

AK10

CLKTESTA

AL10

CLKTESTB

R138

4.7K

DESIGN

CHECK

APPROVAL

MODULE CODE

MEMORY INTERFACE B

DATE

MS Yang

DEV. STEP

MK Kim

REV

BL Lee

LAST EDIT

12/05/2008

REV 1.0

MAB_0
MAB_1
MAB_2
MAB_3
MAB_4
MAB_5
MAB_6
MAB_7
MAB_8

MAB_9
MAB_10
MAB_11
MAB_12

MAB_BA2
MAB_BA0
MAB_BA1

DQMB_0
DQMB_1
DQMB_2
DQMB_3
DQMB_4
DQMB_5
DQMB_6
DQMB_7

RDQSB_0
RDQSB_1
RDQSB_2
RDQSB_3
RDQSB_4
RDQSB_5
RDQSB_6
RDQSB_7

WDQSB_0
WDQSB_1
WDQSB_2
WDQSB_3
WDQSB_4
WDQSB_5
WDQSB_6
WDQSB_7

ODTB0

ODTB1

CLKB0

CLKB0#

CLKB1

CLKB1#

RASB0#
RASB1#

CASB0#
CASB1#

CSB0_0#
CSB0_1#

CSB1_0#
CSB1_1#

CKEB0

CKEB1

WEB0#

WEB1#

DRAM_RST

TITLE

MP

0

P8

1

T9

2

P9

3

N7

4

N8

5

N9

66

U9

7

U8

8

Y9

9

W9

10

AC8

11

AC9

12

AA7

2

AA8

0

Y8

1

AA9

0

H3

1

H1

2

T3

3

T5

4

AE4

5

AF5

6

AK6

7

AK5

0

F6

1

K3

2

P3

3

V5

4

AB5

5

AH1

6

AJ9

7

AM5

0

G7

1

K1

2

P1

3

W4

4

AC4

5

AH3

6

AJ8

7

AM3
T7

W7
L9

L8
AD8

AD7
T10

Y10
W10

AA10
P10

L10
AD10

AC10
U10

AA11
N10

AB11

R146

AH11

R143

4.7K

nostuff

BONN-E

EXT_GFX

M9x (2/5)

April 11, 2009 10:05:58 AM

4.7K

C188

1000nF-X5R

6.3V

P1.5V

1

PEG1_MAC(12:0)

PEG1_BAC(2:0)

PEG1_DQMC(7:0)

PEG1_RDQSC(7:0)

PEG1_WDQSC(7:0)

PEG1_ODTC0
PEG1_ODTC1

PEG1_MCLKC0
PEG1_MCLKC0#

PEG1_MCLKC1
PEG1_MCLKC1#

PEG1_RASC0#
PEG1_RASC1#

PEG1_CASC0#
PEG1_CASC1#

PEG1_CSC00#

PEG1_CSC10#

PEG1_MCKEC0
PEG1_MCKEC1

PEG1_WEC0#
PEG1_WEC1#

PEG1_DRAMRST#

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

6727

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

150
1%

U510-4
M96-M

DP C/D POWER DP A/B POWER

AP20

NC_DPC_VDD18_1

AP21

NC_DPC_VDD18_2

AP13

DPC_VDD10_1

AT13

DPC_VDD10_2

AN17

DPC_VSSR_1

AP16

DPC_VSSR_2

AP17

DPC_VSSR_3

AW14

DPC_VSSR_4

AW16

DPC_VSSR_5

AP22

NC_DPD_VDD18_1

AP23

NC_DPD_VDD18_2

AP14

DPD_VDD10_1

AP15

DPD_VDD10_2

AN19

DPD_VSSR_1

AP18

DPD_VSSR_2

AP19

DPD_VSSR_3

AW20

DPD_VSSR_4

AW22

DPD_VSSR_5

AW18

DPCD_CALR

DP E/F POWER DP PLL POWER

AH34

DPE_VDD18_1

AJ34

DPE_VDD18_2

AL33

DPE_VDD10_1

AM33

DPE_VDD10_2

AN34

DPE_VSSR_1

AP39

DPE_VSSR_2

AR39

DPE_VSSR_3

AU37

DPE_VSSR_4

AW35

DPE_VSSR_5

AF34

DPF_VDD18_1

AG34

DPF_VDD18_2

AK33

DPF_VDD10_1

AK34

DPF_VDD10_2

AF39

DPF_VSSR_1

AH39

DPF_VSSR_2

AK39

DPF_VSSR_3

AL34

DPF_VSSR_4

AM34

DPF_VSSR_5

AM39

DPEF_CALR

0904-002460

4 / 5

NC_DPA_VDD18_1
NC_DPA_VDD18_2

DPA_VDD10_1
DPA_VDD10_2

DPA_VSSR_1
DPA_VSSR_2
DPA_VSSR_3
DPA_VSSR_4
DPA_VSSR_5

NC_DPB_VDD18_1
NC_DPB_VDD18_2

DPB_VDD10_1
DPB_VDD10_2

DPB_VSSR_1
DPB_VSSR_2
DPB_VSSR_3
DPB_VSSR_4
DPB_VSSR_5

DPAB_CALR

DPA_PVDD

DPA_PVSS

DPB_PVDD
DPB_PVSS

DPC_PVDD

DPC_PVSS

DPD_PVDD

DPD_PVSS

DPE_PVDD

DPE_PVSS

NC_DPF_PVDD

NC_DPF_PVSS

2

AN24
AP24

AP31
AP32

AN27
AP27
AP28
AW24
AW26

AP25
AP26

AN33
AP33

AN29
AP29
AP30
AW30
AW32

R588

AW28

GFX3_DPAB_CALR_MN

AU28
AV27

AV29
AR28

AU18
AV17

AV19
AR18

AM37
AN38

AL38
AM35

DESIGN

CHECK

APPROVAL

MODULE CODE

GFX3_P1.1V_DPA_VDD10_MN

GFX3_P1.8V_DPA_PVDD_MN

150
1%

GFX3_P1.8V_DPE_PVDD_MN

DATE

MS Yang

DEV. STEP

MK Kim

REV

BL Lee

LAST EDIT

12/05/2008

REV 1.0

C134

100nF

C169

100nF

C576

100nF

C592

100nF

MP

10V

10V

10V

C156

100nF
10V

C168

100nF
10V

C144

100nF
10V

10V

TITLE

1000nF

6.3V

C153

1000nF-X5R

6.3V

1000nF

6.3V

C152

1000nF-X5R

6.3V

C113

1000nF-X5R

6.3V

C155

1000nF-X5R

6.3V

C593

1000nF

6.3V

C139

C132

10000nF

6.3V

C145

10000nF-X5R

6.3V

C578

C118

10000nF

6.3V

C149

10000nF-X5R

6.3V

C110

10000nF-X5R

6.3V

C116

10000nF-X5R

6.3V

C591

10000nF

6.3V

BONN-E

EXT_GFX

M9x (3/5)

April 11, 2009 10:05:58 AM

P1.1V

B7

BLM18PG181SN1

P1.1V

INSTPAR

SHORT553

nostuff
nostuff

P1.8V

B6

BLM18PG181SN1

P1.8V

nostuff
nostuff
nostuff
nostuff
nostuff
nostuff

P1.8V

B509

BLM18PG181SN1

SAMSUNG

PART NO.

28 67

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

ELECTRONICS

BA41-01060A

D D

P1.1V

SHORT551

P1.1V

SHORT552

INSTPAR

INSTPAR

C C

P1.8V

P1.1V

B20

BLM18PG181SN1

B13

BLM18PG181SN1

B B

C125

10000nF-X5R

6.3V

C120

10000nF-X5R

6.3V

C211

10000nF

6.3V

C163

10000nF

6.3V

C126

1000nF-X5R

6.3V

nostuff
nostuff

C127

1000nF-X5R

6.3V

nostuff

nostuff

C212

1000nF-X5R

6.3V

C162

1000nF

6.3V

Samsung

Samsung

P3.3V_GFX CONTROL CIRCUIT

Q25

3

D

G

P3.3VGFX_QR_MN

3

Q24
RHU002N06

2

P3.3V_GFX

R919

10K

Confidential

Confidential

C3910

1000nF-X5R

6.3V

nostuff

P3.3V_AUX

SI2315BDS-T1

2

S

1

C611

100nF

10V

R918

A A

P1.1V_PWRGD

R628

10K

R150

10K

10K

C620

220nF

D

G

1

S

10V

4

GFX3_P1.1V_DPC_VDD10_MN

C122

100nF
10V

GFX3_P1.1V_DPD_VDD10_MN GFX3_P1.1V_DPB_VDD10_MN

C123

100nF
10V

C213

100nF
10V

C182

100nF
10V

P1.8V_DPE

C200

1000nF-X5R

6.3V

P1.1V_DPE

P1.8V_DPE

P1.1V_DPE

R139

GFX3_DPCD_CALR_MN

R591

150

1%

GFX3_DPEF_CALR_MN

3

C302

1000nF

6.3V

C313

1000nF

6.3V

C340

nostuff

100nF
10V

3

M96-M

MEM I/O PCIE

G11

VDDR1_1

G14

VDDR1_2

G17

VDDR1_3

G20

VDDR1_4

G23

VDDR1_5

G26

VDDR1_6

G29

VDDR1_7

H10

VDDR1_8

J7

VDDR1_9

J9

VDDR1_10

K8

VDDR1_11

K11

VDDR1_12

K13

VDDR1_13

L7

VDDR1_14

L12

VDDR1_15

L16

VDDR1_16

L21

VDDR1_17

L23

VDDR1_18

L26

VDDR1_19

M11

VDDR1_20

N11

VDDR1_21

P7

VDDR1_22

R11

VDDR1_23

U7

VDDR1_24

U11

VDDR1_25

Y7

VDDR1_26

Y11

VDDR1_27

AC7

VDDR1_28

AD11

VDDR1_29

AF7

VDDR1_30

AG10

VDDR1_31

AJ7

VDDR1_32

AK8

VDDR1_33

AL9

VDDR1_34

LEVEL
TRANSLATION

AF26

VDD_CT_1

AF27

VDD_CT_2

AG26

VDD_CT_3

AG27

VDD_CT_4

I/O

AF23

VDDR3_1

AF24

VDDR3_2

AG23

VDDR3_3

AG24

VDDR3_4

AF13

VDDR5_1

AF15

VDDR5_2

AG13

VDDR5_3

AG15

VDDR5_4

AD12

VDDR4_1

AF11

VDDR4_2

AF12

VDDR4_3

AG11

VDDR4_4

MEM CLK

M20

VDDRHA

M21

VSSRHA

V12

VDDRHB

U12

VSSRHB

PLL

AB37

PCIE_PVDD

H7

NC_MPV18_1

H8

NC_MPV18_2

AM10

NC_SPV18

AN9

SPV10

AN10

SPVSS

BACK BIAS

AA13

BBP_1

Y13

BBP_2

0904-002460

U510-3

POWER

PCIE_VDDR_1
PCIE_VDDR_2
PCIE_VDDR_3
PCIE_VDDR_4
PCIE_VDDR_5
PCIE_VDDR_6
PCIE_VDDR_7
PCIE_VDDR_8

PCIE_VDDC_1
PCIE_VDDC_2
PCIE_VDDC_3
PCIE_VDDC_4
PCIE_VDDC_5
PCIE_VDDC_6
PCIE_VDDC_7
PCIE_VDDC_8

PCIE_VDDC_9
PCIE_VDDC_10
PCIE_VDDC_11
PCIE_VDDC_12

CORE

ISOLATED
CORE I/O

3 / 5

VDDC_1
VDDC_2
VDDC_3
VDDC_4
VDDC_5
VDDC_6
VDDC_7
VDDC_8

VDDC_9
VDDC_10
VDDC_11
VDDC_12
VDDC_13
VDDC_14
VDDC_15
VDDC_16
VDDC_17
VDDC_18
VDDC_19
VDDC_20
VDDC_21
VDDC_22
VDDC_23
VDDC_24
VDDC_25
VDDC_26
VDDC_27
VDDC_28
VDDC_29
VDDC_30
VDDC_31
VDDC_32
VDDC_33
VDDC_34
VDDC_35
VDDC_36
VDDC_37
VDDC_38
VDDC_39
VDDC_40
VDDC_41
VDDC_42
VDDC_43
VDDC_44
VDDC_45
VDDC_46
VDDC_47
VDDC_48
VDDC_49
VDDC_50
VDDC_51
VDDC_52
VDDC_53
VDDC_54
VDDC_55
VDDC_56
VDDC_57
VDDC_58
VDDC_59
VDDC_60
VDDC_61
VDDC_62
VDDC_63
VDDC_64
VDDC_65
VDDC_66
VDDC_67
VDDC_68
VDDC_69
VDDC_70
VDDC_71
VDDC_72
VDDC_73
VDDC_74

VDDCI_1
VDDCI_2
VDDCI_3
VDDCI_4

V28
W29
W30
Y31
AA31
AA32
AA33
AA34

G30
G31
H29
H30
J29
J30
L28
M28
N28
R28
T28
U28

M16
M18
M23
M26
N15
N17
N20
N22
N24
N27
R13
R16
R18
R21
R23
R26
T15
T17
T20
T22
T24
T27
U16
U18
U21
U23
U26
V15
V17
V20
V22
V24
V27
Y16
Y18
Y21
Y23
Y26
Y28
AA15
AA17
AA20
AA22
AA24
AA27
AB13
AB16
AB18
AB21
AB23
AB26
AB28
AC12
AC15
AC17
AC20
AC22
AC24
AC27
AD13
AD16
AD18
AD21
AD23
AD26
AF17
AF20
AF22
AG16
AG18
AG21
AH22
AH27
AH28

M15
N13
R12
T12

3

2

GFX3_P1.8V_PCIE_VDDR_MN

C257

C234

1000nF

1000nF

6.3V

nostuff
nostuff

C235

C275

1000nF

1000nF

6.3V

C240

1000nF

6.3V

C284

100nF

6.3V

C219

1000nF

6.3V

C296

100nF

10V

DESIGN

CHECK

APPROVAL

MODULE CODE

nostuff

nostuff
nostuff

nostuff

2

C239

100nF

10V

C328

100nF

10V

C201

1000nF

6.3V

6.3V

C298

1000nF

6.3V

C206

1000nF

6.3V

C312

100nF

10V

10V

GFX3_GCORE_VDDCI_MN

C270

100nF

10V

C295

100nF
10V

C258

1000nF

6.3V

C207

1000nF

6.3V

C247

1000nF

6.3V

C265

100nF

10V

C289

10000nF

6.3V

MS Yang

MK Kim

BL Lee

C231

100nF

C232

1000nF

6.3V

10V

C261

1000nF

6.3V

C249

1000nF

6.3V

nostuff

C281

1000nF

6.3V

C305

1000nF

6.3V

C303

1000nF

6.3V

C316

1000nF

6.3V

nostuff

C297

1000nF

6.3V

C244

1000nF

6.3V

C228

1000nF

6.3V

C245

100nF

10V

C250

10000nF

6.3V

nostuff
nostuff

DATE

DEV. STEP

REV

LAST EDIT

C227

1000nF

6.3V

C256

1000nF

6.3V

nostuff

C218

1000nF

6.3V

C220

100nF

10V

C267

10000nF

6.3V

C307

100nF
10V

12/05/2008

REV 1.0

C310

C224

1000nF

1000nF

6.3V

6.3V

C273

C272

1000nF

1000nF

6.3V

6.3V

nostuff

C255

C202

1000nF

1000nF

6.3V

6.3V

nostuff

C271

C236

100nF

100nF

10V

10V

C193

C222

10000nF10000nF

6.3V

6.3V

C283

C293

1000nF

1000nF

6.3V

6.3V

TITLE

MP

April 11, 2009 10:05:58 AM

C230

10000nF

6.3V

C357

10000nF

6.3V

C259

1000nF

6.3V

C299

1000nF

6.3V

C237

1000nF

6.3V

C274

100nF

10V

C238

10000nF

6.3V

C356

10000nF

6.3V

BONN-E

EXT_GFX

M9x (4/5)

1

P1.8V

B21

BLM18PG181SN1

P1.1V

EGFX_CORE

EGFX_CORE

B24

BLM18PG181SN1

SAMSUNG

PART NO.

29 67

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

ELECTRONICS

BA41-01060A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

P1.5V

D

P1.8V

nostuff

nostuff
nostuff

C187

1000nF

6.3V

C223

1000nF

6.3V

C355

10000nF

6.3V

B9

BLM18PG181SN1

C C

P3.3V_GFX

P1.8V

B11

BLM18PG181SN1

C175

10000nF

C154

10000nF

6.3V

C189

1000nF

6.3V

6.3V

C151

10000nF-X5R

6.3V

B10

BLM18PG181SN1

P1.5V

B B

B26

BLM18PG181SN1

C150

10000nF-X5R

6.3V

C326

1000nF

6.3V

B23

BLM18PG181SN1

P1.8V

B511

BLM18PG181SN1

EGFX_CORE

B15

BLM18PG181SN1

A A

0

R130

EGFX_BBP

SHORT571

Back Bias Voltage

nostuff

R1608-SHORT

C264

1000nF

6.3V

C609

10000nF

6.3V

C161

10000nF

6.3V

R920

C217

1000nF

6.3V

C344

1000nF

6.3V

C185

10000nF

6.3V

C203

1000nF

C194

1000nF

C608

1000nF

6.3V

C159

1000nF

6.3V

6.3V

6.3V

C165

1000nF-X5R

6.3V

C172

1000nF-X5R

6.3V

C288

C325

C215

0

C160

1000nF

6.3V

C341

1000nF

6.3V

10000nF

6.3V

1000nF

C607

100nF

10V

100nF

10V

C138

1000nF

6.3V

C186

1000nF

6.3V

C260

1000nF

6.3V

C208

10000nF

6.3V

C184

100nF
10V

6.3V

C173

100nF
10V

C164

100nF
10V

M96
M96
M96

C140

100nF

10V

C311

C324

1000nF

6.3V

C329

1000nF

6.3V

C199

100nF
10V

C195

1000nF

6.3V

GFX3_P1.8V_VDDRHA_MN

GFX3_P1.8V_VDDRHB_MN

GFX3_GCORE_SPV10_MN

C282

1000nF

1000nF

6.3V

6.3V

nostuff

C348

C343

1000nF

1000nF

6.3V

6.3V

C280

C327

100nF

100nF

10V

10V

GFX3_P1.8V_VDD_CT_MN

GFX3_P1.8V_VDDR5_MN

GFX3_P1.8V_VDDR4_MN

Samsung

Samsung

GFX3_P1.8V_PCIE_PVDD_MN

Confidential

Confidential

GFX3_GCORE_EBP_MN

4

D

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

U510-2
M96-M

E39

PCIE_VSS_1

F34

PCIE_VSS_2

F39

PCIE_VSS_3

G33

PCIE_VSS_4

G34

PCIE_VSS_5

H31

PCIE_VSS_6

H34

PCIE_VSS_7

H39

PCIE_VSS_8

J31

PCIE_VSS_9

J34

PCIE_VSS_10

K31

PCIE_VSS_11

K34

PCIE_VSS_12

K39

PCIE_VSS_13

L31

PCIE_VSS_14

L34

PCIE_VSS_15

M34

PCIE_VSS_16

M39

PCIE_VSS_17

N31

PCIE_VSS_18

N34

PCIE_VSS_19

P31

W31
W34

AB39

P34
P39
R34
T31
T34
T39
U31
U34
V34
V39

Y34
Y39

PCIE_VSS_20
PCIE_VSS_21
PCIE_VSS_22
PCIE_VSS_23
PCIE_VSS_24
PCIE_VSS_25
PCIE_VSS_26
PCIE_VSS_27
PCIE_VSS_28
PCIE_VSS_29
PCIE_VSS_30
PCIE_VSS_31
PCIE_VSS_32
PCIE_VSS_33
PCIE_VSS_34
PCIE_VSS_35

C

GND

AA16

GND_101

AA18

GND_102

AA21

GND_103

AA23

GND_104

AA26

GND_105

AA28

GND_106

AB12

GND_107

B B

AB15
AB17
AB20
AB22
AB24
AB27
AC11
AC13
AC16
AC18

AC2
AC6

GND_108
GND_109
GND_110
GND_111
GND_112
GND_113
GND_114
GND_115
GND_116
GND_117
GND_118
GND_119

0904-002460

2 / 5

A3

GND_1

A37

GND_2

B7

GND_3

B9

GND_4

B11

GND_5

B13

GND_6

B15

GND_7

B17

GND_8

B19

GND_9

B21

GND_10

B23

GND_11

B25

GND_12

B27

GND_13

B29

GND_14

B31

GND_15

B33

GND_16

C1

GND_17

C39

GND_18

E5

GND_19

E35

GND_20

F7

GND_21

F9

GND_22

F11

GND_23

F13

GND_24

F15

GND_25

F17

GND_26

F19

GND_27

F21

GND_28

F23

GND_29

F25

GND_30

F27

GND_31

F29

GND_32

F31

GND_33

F33

GND_34

G2

GND_35

G6

GND_36

H9

GND_37

J2

GND_38

J6

GND_39

J8

GND_40

J27

GND_41

K7

GND_42

K14

GND_43

L2

GND_44

L6

GND_45

L11

GND_46
GND_47
GND_48
GND_49
GND_50
GND_51
GND_52
GND_53
GND_54
GND_55
GND_56
GND_57
GND_58
GND_59
GND_60

L17
L22
L24
M17
M22
M24
N2
N6
N16
N18
N21
N23
N26
R2

Samsung

Samsung

AC21
AC23
AC26
AC28

AD9
AD15
AD17
AD20
AD22
AD24
AD27

AE2

AE6
AF10
AF16
AF18
AF21

AG2

AG6

AG9
AG17
AG20
AG22
AH21
AH29

AJ10
AJ11
AJ28

AK7
AK11
AK31

AL11
AL14
AL17
AL20
AL21
AL23
AL26
AL32

AM9
AM11
AM31
AN11

AN2

AN6

AN8
AN30

AP7

AP9
AP11

AR5

AW34

GND_120
GND_121
GND_122
GND_123
GND_124
GND_125
GND_126
GND_127
GND_128
GND_129
GND_130
GND_131
GND_132
GND_133
GND_134
GND_135
GND_136
GND_137
GND_138
GND_139
GND_140
GND_141
GND_142
GND_143
GND_144

AJ2

GND_145

AJ6

GND_146
GND_147
GND_148
GND_149
GND_150
GND_151
GND_152

AL2

GND_153

AL6

GND_154

AL8

GND_155
GND_156
GND_157
GND_158
GND_159
GND_160
GND_161
GND_162
GND_163
GND_164
GND_165
GND_166
GND_167
GND_168
GND_169
GND_170
GND_171
GND_172
GND_173
GND_174
GND_175
GND_176

GND

GND_61
GND_62
GND_63
GND_64
GND_65
GND_66
GND_67
GND_68
GND_69
GND_70
GND_71
GND_72
GND_73
GND_74
GND_75
GND_76
GND_77
GND_78
GND_79
GND_80
GND_81
GND_82
GND_83
GND_84
GND_85
GND_86
GND_87
GND_88
GND_89
GND_90
GND_91
GND_92
GND_93
GND_94
GND_95
GND_96
GND_97
GND_98
GND_99

GND_100

VSS_MECH_1
VSS_MECH_2
VSS_MECH_3

R6
R15
R17
R20
R22
R24
R27
T11
T13
T16
T18
T21
T23
T26
U2
U6
U13
U15
U17
U20
U22
U24
U27
V11
V13
V16
V18
V21
V23
V26
W2
W6
Y15
Y17
Y20
Y22
Y24
Y27
AA2
AA6

A39
AW1
AW39

C

Confidential

Confidential

A A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

EXT_GFX

M9x (5/5)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

30 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D D

4

3

2

1

M9X STRAPS

TX_PWRS_ENB
PCIE FULL TX OUTPUT SWING
0 : 50% TX OUTPUT SWING

=> LOW LOSS INTERCONNECT

1 : FULL TX OUTPUT SWING

GFX3_GPIO0

C

TX_DEEMPH_EN
PCIE TRANSMITTER DE-EMPHASIS ENABLED

0 : TX DE-EMPHASIS DISABLED
1 : TX DE-EMPHASIS ENABLED

(USING MXM OR ON BOARD)

GFX3_GPIO1

B

BIF_GEN2_EN_A

0 : 2.5GT/s CAPABLE FOR PCIe DEVICE
1 : 5.0GT/s CAPABLE FOR PCIe DEVICE

=> 5.0GT/s CAPABILITY WILL BE

CONTROLLED BY SOFTWARE

GFX3_GPIO2

R125

R133

R119

R122

P3.3V_GFX

10K

nostuff

P3.3V_GFX

10K

nostuff

P3.3V_GFX

10K

nostuff

10K

AUD[1:0]

00 : No Audio Function
01 : Audio for DP & HDMI if adapter is detected
10 : Audio for DP Only
11 : Audio for Both DP & HDMI

CRT3_HSYNC

CRT3_VSYNC

If BIOS_ROM_EN=1, ROMCFGID[2:0]
If BIOS_ROM_EN=0, Memory Aperture Size

GFX3_GPIO13

GFX3_GPIO12

GFX3_GPIO11

GFX3_GPIO(13 : 11)

Samsung

Samsung

R624

R625

(INTERNAL PULL DOWN)

000 : 128MB
001 : 256MB
010 : 64MB
011 : RESERVED
1XX : RESERVED

R124

R120

R121

P3.3V_GFX

10K

10K

P3.3V_GFX

nostuff

10K

10K

10K

GFX3_BBEN

3

D

SHORT572

BACK BIAS LOGIC

EGFX_CORE

2

S

RHU002N06

Q15

1

G

GFX3_P5.0V_BB_R_MN

R1608-SHORT

GFX3_BBEN_R_MN

EGFX_BBP

R117

10K

3

D

G

1

2

S

SI2315BDS-T1

1

G

R114

D

3

Q14
RHU002N06

S

2

C143

1000nF-X5R

6.3V

Q20

P1.8V

P5.0V

1%100K

C

B

Confidential

Confidential

A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

EXT_GFX

M9x Straps & PU

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

31

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

P1.5V

PEG1_MAA(12:0)

C

PEG1_MCLKA0

PEG1_MCLKA0#

PEG1_MCKEA0

PEG1_BAA(0)
PEG1_BAA(1)
PEG1_BAA(2)

PEG1_DRAMRST#

PEG1_CSA00#

PEG1_RASA0#
PEG1_CASA0#

P1.5V

B B

PEG1_WEA0#

PEG1_DQMA(0)
PEG1_DQMA(2)

R208

PEG1_ODTA0

4.99K
1%

GMEM_VREF1_MN GMEM_VREF3_MN

C384

R209

100nF

4.99K

10V

1%

GMEM_ZQ1_MN

R243

240

0

N3
P7
P3
N2
P8
P2
R8
R2

T8

R3

L7
R7
N7

T3

T7

M7

J7
K7

K9

M2

N8

M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

VDD_1B2VDD_2D9VDD_3G7VDD_4K2VDD_5K8VDD_6

A9

1
2
3
4
5
6
7
8
9
10
11
12

P1.5V

R241

4.99K
1%

R242

4.99K
1%

GMEM_VREF2_MN

C444

100nF
10V

M96
M96
M96
M96
M96
M96
M96

P1.5V

N1

N9

R9

VDD_7

VDD_8R1VDD_9

U14
K4W1G1646E-HC12

1105-002019

VSS_1

VSS_2B3VSS_3E1VSS_4G8VSS_5

VSS_6J8VSS_7

J2

M1

M9

P1.5V

D2

VDDQ_1A1VDDQ_2A8VDDQ_3C1VDDQ_4C9VDDQ_5

Samsung

Samsung

VSS_10P9VSS_11T1VSS_12

VSS_8

VSS_9

T9

P1

Confidential

Confidential

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#

DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

E9
F1
H2
H9

0

D7

4

C3

1

C8

6

C2

3

A7

7

A2

2

B8

5

A3

20

E3

17

F7

21

F2

18

F8

23

H3

16

H8

22

G2

19

H7
C7

F3
B7

G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

M96

A-Channel #0

PEG1_MAA(12:0)

PEG1_DQA(7:0)

PEG1_DQA(23:16)

PEG1_RDQSA(0)
PEG1_RDQSA(2)

PEG1_WDQSA(0)
PEG1_WDQSA(2)

P1.5V

P1.5V

PEG1_DRAMRST#

R691

4.99K
1%

C715

R692

100nF

4.99K

10V

1%

R670

4.99K
1%

GMEM_VREF4_MN

C695

R671

100nF

4.99K

10V M96

1%

PEG1_MCLKA0

PEG1_MCLKA0#

PEG1_MCKEA0

PEG1_BAA(0)
PEG1_BAA(1)
PEG1_BAA(2)

PEG1_CSA00#

PEG1_RASA0#
PEG1_CASA0#

PEG1_WEA0#

PEG1_DQMA(1)
PEG1_DQMA(3)

PEG1_ODTA0

GMEM_ZQ2_MN

R672

240

P1.5V

P1.5V

P1.5V

N3
P7
P3
N2
P8
P2
R8
R2
T8
R3

L7
R7
N7
T3
T7

M7

J7
K7

K9

M2

N8

M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

B2

VDD_1D9VDD_2G7VDD_3K2VDD_4K8VDD_5

U517
K4W1G1646E-HC12

1105-002019
E-DIEE-DIE

VSS_1

VSS_2E1VSS_3

A9

B3

0
1
2
3
4
5
6
7
8
9
10
11
12

M96
M96
M96
M96
M96

M96

VDD_6N9VDD_7R1VDD_8R9VDD_9

VSS_4J2VSS_5J8VSS_6M1VSS_7

G8 N1

A1

VDDQ_1A8VDDQ_2C1VDDQ_3

VSS_8

VSS_9

P9

P1

M9

C9

VDDQ_4D2VDDQ_5

VSS_10T1VSS_11T9VSS_12

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#
DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

E9
F1
H2
H9

D7
C3
C8
C2
A7
A2
B8
A3

E3
F7
F2
F8
H3
H8
G2
H7

C7
F3

B7
G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

M96

PEG1_MCLKA0#

15
10
14
11
12

8

13

9

31
24
29
26
28
27
30
25

PEG1_MCLKA0

PEG1_DQA(15:8)

PEG1_DQA(31:24)

PEG1_RDQSA(1)
PEG1_RDQSA(3)

PEG1_WDQSA(1)
PEG1_WDQSA(3)

R238
R237

PEG1_MCLKA0_R_MN

56
56

C449

M96

10nF

M9625V
M96

P1.5V

A

C390

1000nF-X5R

6.3V

M96

C708

C391

1000nF-X5R

6.3V

M96

C389

1000nF-X5R

6.3V

M96

C368

1000nF-X5R

6.3V

M96

C717

10000nF-X5R

6.3V

M96

C445

10000nF-X5R

6.3V

M96

C443

10000nF-X5R

6.3V

M96

C446

10000nF-X5R

6.3V

M96

C440

100nF
10V

M96

4

C706

100nF
10V

M96

C386

100nF
10V

M96

C707

100nF
10V

M96

C388

100nF
10V

M96

C387

100nF
10V

M96

3

C441

10nF

10nF

16V

16V

M96

M96

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

Graphics_Memory(gDDR3_1.5V)

Graphics_Memory_ATI A #0

April 11, 2009 10:05:58 AM

BONN-E

SAMSUNG

ELECTRONICS

PART NO.REV

BA41-01060A

32 67

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

C

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

P1.5V P1.5V

PEG1_MAA(12:0)

C C

PEG1_MCLKA1

PEG1_MCLKA1#

0
1
2
3
4
5
6
7
8
9
10
11
12

PEG1_MCKEA1

PEG1_BAA(0)
PEG1_BAA(1)
PEG1_BAA(2)

PEG1_DRAMRST#

PEG1_CSA10#

PEG1_RASA1#
PEG1_CASA1#

P1.5V

R240

4.99K

B B

1%

R239

4.99K
1%

PEG1_WEA1#

PEG1_DQMA(5)
PEG1_DQMA(4)

PEG1_ODTA1

GMEM_VREF5_MN

C437

100nF
10V

GMEM_ZQ3_MN

R207

240

N3
P7
P3
N2
P8
P2
R8
R2

T8

R3

L7
R7
N7

T3

T7
M7

J7
K7

K9
M2

N8
M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

B2

A0
A1

VDD_1D9VDD_2G7VDD_3K2VDD_4K8VDD_5N1VDD_6N9VDD_7R1VDD_8R9VDD_9

A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

U13
K4W1G1646E-HC12

1105-002019

VSS_1

A9

B3

VSS_8P1VSS_9

VSS_2E1VSS_3G8VSS_4J2VSS_5J8VSS_6M1VSS_7

M9

A1

VDDQ_6
VDDQ_7
VDDQ_8

VDDQ_1A8VDDQ_2C1VDDQ_3C9VDDQ_4D2VDDQ_5

VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#

DQSL#

NC_CE1

VSSQ_1
VSSQ_2

Samsung

Samsung

VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

VSS_10T1VSS_11T9VSS_12

P9

P1.5V

R206

4.99K
1%

GMEM_VREF6_MN GMEM_VREF8_MN

C383

R210

100nF

4.99K

10V

1%

M96
M96
M96
M96
M96
M96
M96

Confidential

Confidential

P1.5V

E9
F1
H2
H9

43

D7

45

C3

40

C8

44

C2

42

A7

47

A2

41

B8

46

A3

35

E3

36

F7

32

F2

39

F8

34

H3

38

H8

33

G2

37

H7
C7

F3
B7

G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

M96

A-Channel #1

P1.5V P1.5V

N9

R9

VDD_8R1VDD_9

VDDQ_1A1VDDQ_2A8VDDQ_3C1VDDQ_4C9VDDQ_5

VSS_10P9VSS_11T1VSS_12

VSS_6J8VSS_7M1VSS_8M9VSS_9

P1

D2

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#

DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

T9

PEG1_MAA(12:0)

PEG1_DQA(47:40) PEG1_DQA(63:56)

PEG1_DQA(39:32)

PEG1_MCLKA1

PEG1_MCLKA1#

PEG1_MCKEA1

PEG1_BAA(0)
PEG1_RDQSA(5)
PEG1_RDQSA(4)

PEG1_WDQSA(5)
PEG1_WDQSA(4)

P1.5V

R668

4.99K
1%

R666

4.99K
1%

PEG1_BAA(1)

PEG1_BAA(2)

PEG1_DRAMRST#

PEG1_CSA10#
PEG1_RASA1#

PEG1_CASA1#

PEG1_WEA1#

PEG1_DQMA(7)
PEG1_DQMA(6)

PEG1_ODTA1

GMEM_VREF7_MN

C692

100nF
10V

GMEM_ZQ4_MN

R688

240

0

N3
P7
P3
N2
P8
P2
R8
R2

T8

R3

L7
R7
N7

T3

T7
M7

J7
K7

K9
M2

N8
M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

VDD_1B2VDD_2D9VDD_3G7VDD_4K2VDD_5K8VDD_6N1VDD_7

U516
K4W1G1646E-HC12

1105-002019
E-DIEE-DIE

VSS_1

VSS_2B3VSS_3E1VSS_4G8VSS_5

J2

A9

1
2
3
4
5
6
7
8
9
10
11
12

P1.5V

R690

4.99K
1%

R689

4.99K
1%

C714

100nF
10V

M96
M96
M96
M96
M96
M96
M96

P1.5V

E9
F1
H2
H9

63

D7

59

C3

62

C8

56

C2

60

A7

57

A2

61

B8

58

A3

51

E3

52

F7

49

F2

53

F8

48

H3

54

H8

50

G2

55

H7
C7

F3
B7

G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

M96

PEG1_MCLKA1

PEG1_MCLKA1#

PEG1_DQA(55:48)

PEG1_RDQSA(7)
PEG1_RDQSA(6)

PEG1_WDQSA(7)
PEG1_WDQSA(6)

R686
R687

PEG1_MCLKA1_R_MN

56
56

C713

M96

10nF
25V

M96
M96

P1.5V

A A

C705

1000nF-X5R

6.3V

M96

4

C704

C435

1000nF-X5R

1000nF-X5R 10000nF-X5R

6.3V

6.3V

M96

M96

C382

1000nF-X5R

6.3V

M96

M96

C385

6.3V

C709

10000nF-X5R

6.3V

M96

C691

C442

10000nF-X5R 100nF

6.3V

M96

10000nF-X5R

6.3V

M96

M96

C436

100nF
10V

C412

C694

10nF

10nF

16V

16V

M96

M96

M96

C439

100nF
10V

M96

C438

100nF
10V

M96

C702

10V

M96

C703

100nF
10V

M96

C693

100nF
10V

3

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

Graphics_Memory(gDDR3_1.5V)

Graphics_Memory_ATI A #1

April 11, 2009 10:05:58 AM

BONN-E

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

33 67

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

P1.5V P1.5V

R9

PEG1_MAC(12:0)

C C

PEG1_MCLKC0

PEG1_MCLKC0#

PEG1_MCKEC0

PEG1_BAC(0)
PEG1_BAC(1)
PEG1_BAC(2)

PEG1_DRAMRST#

PEG1_CSC00#
PEG1_RASC0#

PEG1_CASC0#

P1.5V

P1.5V

R180

4.99K
1%

R185

4.99K
1%

R172

4.99K
1%

GMEM_VREF10_MN

R176

4.99K
1%

B

PEG1_DQMC(0)
PEG1_DQMC(2)

GMEM_VREF9_MN

C323

100nF
10V

C291

100nF
10V

PEG1_WEC0#

PEG1_ODTC0

0
1
2
3
4
5
6
7
8
9
10
11
12

GMEM_ZQ5_MN

240

P1.5V

N3
P7
P3
N2
P8
P2
R8
R2
T8
R3

L7
R7
N7
T3
T7
M7

J7
K7

K9
M2

N8
M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

R1

VDD_1B2VDD_2D9VDD_3G7VDD_4K2VDD_5K8VDD_6N1VDD_7N9VDD_8

U9
K4W1G1646E-HC12

1105-002019
E-DIE E-DIE

VSS_1

VSS_2B3VSS_3E1VSS_4G8VSS_5J2VSS_6J8VSS_7 VDD_9

A9

D2

VDDQ_1A1VDDQ_2A8VDDQ_3C1VDDQ_4C9VDDQ_5

Samsung

Samsung

VSS_10P9VSS_11T1VSS_12

VSS_8M9VSS_9

T9

P1

M1

Confidential

Confidential

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU
DQSL

DQSU#

DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

E9
F1
H2
H9

D7
C3
C8
C2
A7
A2
B8
A3

E3
F7
F2
F8
H3
H8
G2
H7

C7
F3

B7
G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

B-Channel #0

P1.5V

PEG1_DQC(7:0)

1
7
0
4
3
6
2
5

PEG1_DQC(23:16)

20
18
22
16
21
17
23
19

PEG1_RDQSC(0)
PEG1_RDQSC(2)

PEG1_WDQSC(0)
PEG1_WDQSC(2)

PEG1_MAC(12:0)

P1.5V

R651

4.99K
1%

R646

4.99K
1%

P1.5V

R629

4.99K
1%

GMEM_VREF12_MN

R630

4.99K
1%

PEG1_MCLKC0

PEG1_MCLKC0#

PEG1_MCKEC0

PEG1_BAC(0)
PEG1_BAC(1)
PEG1_BAC(2)

PEG1_DRAMRST#

PEG1_CSC00#

PEG1_RASC0#
PEG1_CASC0#

PEG1_WEC0#

PEG1_DQMC(1)
PEG1_DQMC(3)

PEG1_ODTC0

GMEM_VREF11_MN

C659

100nF
10V

C642

100nF
10V

0
1
2
3
4
5
6
7
8
9
10
11
12

GMEM_ZQ6_MN

R636R181

240

P1.5V P1.5V

B2

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10_AP

R7

A11

N7

A12

T3

A13

T7

A14

M7

A15_BA3

J7

CK

K7

CK#

K9

CKE_CKE0

M2

BA0

N8

BA1

M3

BA2

T2

RESET#

L2

CS#_CS0#

L1

NC_CS1#

J3

RAS#

K3

CAS#

L3

WE#

D3

DMU

E7

DML

K1

ODT_ODT0

J1

NC_ODT1

H1

VREFDQ

M8

VREFCA

L8

ZQ_ZQ0

L9

NC_ZQ1

D9

VDD_1

VDD_2G7VDD_3K2VDD_4K8VDD_5N1VDD_6N9VDD_7R1VDD_8R9VDD_9

U511
K4W1G1646E-HC12

1105-002019

VSS_2E1VSS_3G8VSS_4J2VSS_5J8VSS_6M1VSS_7M9VSS_8P1VSS_9

VSS_1

B3

A9

A1

VDDQ_1A8VDDQ_2C1VDDQ_3C9VDDQ_4D2VDDQ_5

VSS_11T9VSS_12

VSS_10

T1

P9

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU
DQSL

DQSU#
DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

E9
F1
H2
H9

D7
C3
C8
C2
A7
A2
B8
A3

E3
F7
F2
F8
H3
H8
G2
H7

C7
F3

B7
G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

P1.5V

15
10
14
11
12

8

13

9

31
24
30
26
28
27
29
25

PEG1_MCLKC0

PEG1_MCLKC0#

PEG1_DQC(15:8)

PEG1_DQC(31:24)

PEG1_RDQSC(1)
PEG1_RDQSC(3)

PEG1_WDQSC(1)
PEG1_WDQSC(3)

R192
R187

PEG1_MCLKC0_R_MN

56
56

C319

10nF
25V

D

B

A A

C583

10000nF-X5R

3

C214

6.3V6.3V

10000nF-X5R

C241

100nF
10V 10V

C587

100nF

C617

100nF
10V

C616

100nF
10V

C147

100nF
10V

C197

100nF
10V

C137

6.3V

1000nF-X5R

C142

6.3V

1000nF-X5R

C374 C158

1000nF-X5R

1000nF-X5R

6.3V6.3V

C205

6.3V

10000nF-X5R

C225

6.3V

10000nF-X5R

4

C170

10nF
16V

C612

10nF
16V

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

Graphics_Memory(gDDR3_1.5V)

Graphics_Memory_ATI C #0

April 11, 2009 10:05:58 AM

BONN-E

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

34 67

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

P1.5V P1.5V

N1

B2

PEG1_MAC(12:0)

C C

PEG1_MCLKC1

PEG1_MCLKC1#

PEG1_MCKEC1

PEG1_BAC(0)
PEG1_BAC(1)
PEG1_BAC(2)

PEG1_DRAMRST#

PEG1_CSC10#
PEG1_RASC1#

PEG1_CASC1#

P1.5V

R145

4.99K

P1.5V

1%

R141

4.99K
1%

R144

4.99K
1%

R140

4.99K
1%

B B

PEG1_WEC1#

PEG1_DQMC(5)
PEG1_DQMC(4)

PEG1_ODTC1

GMEM_VREF13_MN GMEM_VREF15_MN

C176

100nF
10V

GMEM_VREF14_MN

C171

100nF
10V

GMEM_ZQ7_MN

P1.5V

0
1
2
3
4
5
6
7

9
10
11
12

R134

240

N3
P7
P3
N2
P8
P2
R8
R2
T8
R3

L7
R7
N7
T3
T7

M7

J7
K7

K9

M2

N8

M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

K8

VDD_6N9VDD_7R1VDD_8R9VDD_9

VDD_1D9VDD_2G7VDD_3K2VDD_4

U6
K4W1G1646E-HC12

1105-002019
E-DIE E-DIE

VSS_1

VSS_2E1VSS_3 VDD_5

VSS_4J2VSS_5J8VSS_6M1VSS_7M9VSS_8P1VSS_9

A9

B3

G8

C9

A1

VDDQ_6
VDDQ_7
VDDQ_8

VDDQ_4D2VDDQ_5

VDDQ_1A8VDDQ_2C1VDDQ_3

VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#
DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3

Samsung

Samsung

VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

VSS_10T1VSS_11T9VSS_12

P9

Confidential

Confidential

P1.5V

E9
F1
H2
H9

43

D7

45

C3

42

C8

44

C2

40

A7

47

A2

41

B8

46

A3

34

E3

37

F7

32

F2

39

F8

36

H3

38

H8

33

G2

35

H7
C7

F3
B7

G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

B-Channel #1

PEG1_MAC(12:0)

PEG1_DQC(47:40)

PEG1_DQC(39:32)

PEG1_MCLKC1

PEG1_MCLKC1#

PEG1_MCKEC1

PEG1_RDQSC(5)
PEG1_RDQSC(4)

PEG1_WDQSC(5)
PEG1_WDQSC(4)

P1.5V

P1.5V

R626

4.99K
1%

R622

4.99K
1%

R623

4.99K
1%

R620

4.99K
1%

PEG1_DRAMRST#

PEG1_CSC10#
PEG1_RASC1#

PEG1_CASC1#

PEG1_DQMC(7)
PEG1_DQMC(6)

C598

100nF
10V

GMEM_VREF16_MN

C595

100nF
10V

PEG1_BAC(0)
PEG1_BAC(1)
PEG1_BAC(2)

PEG1_WEC1#

PEG1_ODTC1

0
1
2
3
4
5
6
7
88
9
10
11
12

GMEM_ZQ8_MN

R606

240

N3
P7
P3
N2
P8
P2
R8
R2
T8
R3

L7
R7
N7
T3
T7

M7

J7
K7

K9

M2

N8

M3

T2

L2

L1

J3
K3

L3
D3

E7
K1

J1
H1

M8

L8

L9

P1.5V

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10_AP
A11
A12
A13
A14
A15_BA3

CK
CK#

CKE_CKE0
BA0

BA1
BA2

RESET#
CS#_CS0#

NC_CS1#
RAS#
CAS#
WE#

DMU
DML

ODT_ODT0
NC_ODT1

VREFDQ
VREFCA

ZQ_ZQ0
NC_ZQ1

K8

VDD_1B2VDD_2D9VDD_3G7VDD_4K2VDD_5

VDD_6N1VDD_7N9VDD_8R1VDD_9

U509
K4W1G1646E-HC12

1105-002019

VSS_4G8VSS_5J2VSS_6J8VSS_7M1VSS_8M9VSS_9

VSS_1

VSS_2B3VSS_3

E1

A9

P1.5V

R9

C1

VDDQ_1A1VDDQ_2A8VDDQ_3

VSS_10P9VSS_11T1VSS_12

T9

P1

D2

VDDQ_4C9VDDQ_5

VDDQ_6
VDDQ_7
VDDQ_8
VDDQ_9

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQSU

DQSL

DQSU#
DQSL#

NC_CE1

VSSQ_1
VSSQ_2
VSSQ_3
VSSQ_4
VSSQ_5
VSSQ_6
VSSQ_7
VSSQ_8
VSSQ_9

E9
F1
H2
H9

D7
C3
C8
C2
A7
A2
B8
A3

E3
F7
F2
F8
H3
H8
G2
H7

C7
F3

B7
G3

J9

B1
B9
D1
D8
E2
E8
F9
G1
G9

P1.5V

63
59
62
56
60
57
61
58

51
52
49
55
48
54
50
53

PEG1_MCLKC1

PEG1_MCLKC1#

PEG1_DQC(63:56)

PEG1_DQC(55:48)

PEG1_RDQSC(7)
PEG1_RDQSC(6)

PEG1_WDQSC(7)
PEG1_WDQSC(6)

R602
R604

PEG1_MCLKC1_R_MN

56
56

C590

10nF
25V

A A

C370

C286

C362

6.3V

1000nF-X5R

4

6.3V

1000nF-X5R

C619

6.3V

1000nF-X5R

C626

6.3V

1000nF-X5R

C253

10000nF-X5R

C628

6.3V6.3V

10000nF-X5R

C358

6.3V

10000nF-X5R

3

C676

6.3V

10000nF-X5R

C641

100nF
10V

C347

100nF
10V

C646

100nF
10V

C634

100nF
10V

C350

100nF
10V

C266

100nF
10V

C338

10nF
16V

10nF
16V

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

Graphics_Memory(gDDR3_1.5V)

Graphics_Memory_ATI C #1

April 11, 2009 10:05:58 AM

BONN-E

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

6735

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3 2

1

D D

Backlight On

P3.3V

5

1

R500

100K
1%

+

4

2

-

LCD3_BKLTON_R_MN

3

U500
7SZ08

R503

1K

1%

LCD3_BKLTON

KBC3_BKLTON

MCH3_BKLTEN

C

R504

100K
1%

LED Power

VDC

B

R4

150K
1%

R3

P3.3V

R7

10K

P3.3V_VDD_INV_EN_MN

51.1K
1%

P3.3V_VDD_INV_EN_Q_MN

D

3

Q3
RHU002N06

G

1%

1

S

2

nostuff
nostuff

0

R49

0

R50

SI2307BDS-T1-E3

C11

100nF
25V

P3.3V_VDD_INV_EN_QR_MN

VDD_LED

Samsung

Samsung

Q4

3

2

D

S

1

G

C46

100nF
25V

Confidential

Confidential

LVDS

MCH3_LCDVDDON

LCD3_BRIT

LCD1_BCLK

LCD1_BCLK#

LCD1_BDATA1

LCD1_ACLK

LCD1_ACLK#

LCD1_ADATA1

LCD1_ADATA1#

LCD Power

MCH3_LCDVDDON_Q_MN

MCH3_LCDVDDON_R_MN

10K

R501

R502

100K

P5.0V_STB

R1

200K
1%

1%

G

1

1%

D

3

Q2
RHU002N06

S

2

P3.3V_AUX

R2

1%30.1K

MCH3_LCDVDDON_QR_MN

C8

330nF
10V

2Ch. LCD Connector

P3.3V

C530

1000nF-X5R

LCD_VDD3V

6.3V

C531

100nF

10V

C3922

4700nF-X5R

VDD_LED

25V

JLCD1

4
5 6
7 8
9110
11 12
13 14
15 16
17 18
19220

22

21
23 24
25 26
27 28
29330

31

MNT1

32

MNT2

3710-002498

SOCK-30P-2R-SMD-MNT

Type : angle

EBL Purpose

Q1

SI2315BDS-T1

2

S

1

G

P3.3V

C529

22000nF-X5R

20%

6.3V

P3.3V

2.2K

2.2K

R520

R521

3

D

LCD3_BKLTON
LCD1_BDATA2

LCD1_BDATA2#
LCD1_BDATA0
LCD1_BDATA0#LCD1_BDATA1#

LCD1_ADATA2
LCD1_ADATA2#
LCD1_ADATA0
LCD1_ADATA0#
LCD3_EDID_CLK
LCD3_EDID_DATA

LCD_VDD3V

C9

100nF

SI team request

C

B

A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

GRAPHICS_IF

LVDS

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

36 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

VCC_CRT

MMBD4148

C520

CRT3_HSYNC

U502
SN74AHCT1G125DCKR

2 4

5

+

-

OE*

3

1

VCC_CRT

100nF
10V

R516

CRT5_HSYNC_R_MN

C

OE*

1

P3.3V_GFX

R11

+

C512

100nF
10V

5

R514

-

CRT5_VSYNC_R_MN

3

G

1

Q500

S

2

RHU002N06

nostuff
nostuff

D

3

0

U501
SN74AHCT1G125DCKR

CRT3_VSYNC

2 4

P3.3V_GFX

R507

2.2K

B B

D506

13

40.2

VCC_CRT

R508

2.2K

P5.0V

5%40.2

5%

CRT5_HSYNC

CRT3_RED

CRT3_GREEN

CRT3_BLUE

CRT5_VSYNC

CRT5_DDCDATA

CRT5_DDCCLK

CRT5_HSYNC
CRT5_VSYNC

CRT5_DDCDATACRT3_DDCDATA

Samsung

Samsung

CRT

C518

C521

0.022nF

0.022nF
50V 50V

50V

CRT CONNECTOR

L504

L503

L502

C516

0.022nF

82nH

82nH

82nH

0.022nF

C523

50V

0.022nF

C29

CRT3_RED_L_MN

CRT3_GREEN_L_MN

CRT3_BLUE_L_MN

150

50V

50V

0.022nF

R517

C24

1%

150

1%1%150

270pF

C16

50V

nostuff
nostuff
nostuff

C23

0.1nF

0.1nF

50V

C20

2 1

PGB1010603NR

50V

R518

R519

270pF

50V

C27

D507

2 1

1

BAV99LT1
D500

3

D504

D505

2 1

PGB1010603NR

PGB1010603NR

2

3

1

BAV99LT1
D501

CRT5_DDCDATA_CLK_D_MN

2

nostuff
nostuff

P5.0V

1

D503
MMBD4148

3

CRT3_P5.0V_D_MN

B505

BLM18PG181SN1

C513

100nF
10V

J6
DSUB-15-VGA

1
6

11

2
7

12

3
8

13

4
9

14

5
10
15

3701-001515

Type : angle

16
17

C

P3.3V_GFX

P3.3V_GFX

R510

2.2K

CRT3_DDCCLK

A A

Check "CRT3_DDCCLK/DATA" Voltage Level

RHU002N06

R15

G

1

S

2

2N06 Can be replaced with SM6K2

4

Q501

nostuff
nostuff

VCC_CRT

R512

2.2K

D

3

0

CRT5_DDCCLK

Confidential

Confidential

DESIGN

CHECK

APPROVAL

MODULE CODE

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

GRAPHICS_IF

CRT

April 11, 2009 10:05:58 AM

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

6737

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

P5.0V

1

D

B17
ACM2012H-900-2P

PEG3_TX2P_HDMI

PEG3_TX2N_HDMI

PEG3_TX1P_HDMI

PEG3_TX1N_HDMI

PEG3_TX0P_HDMI

PEG3_TX0N_HDMI

C C

B B

A A

PEG3_TXCP_HDMI

PEG3_TXCN_HDMI

PEG3_HDMI_DATA

PEG3_HDMI_CLK

P3.3V_GFX

R599

10K

1%

P3.3V_GFX

R598

10K

1%

P3.3V_GFX

1

S

2

Q514
RHU002N06

R582

P3.3V_GFX

1

S

2

Q513
RHU002N06

R594

G

G

4

3

124

B14
ACM2012H-900-2P

3

124

nostuff
nostuff

D

3

0

nostuff
nostuff

D

3

0

B16
ACM2012H-900-2P

3

124

B12

ACM2012H-900-2P

3

124

Samsung

Samsung

PEG5_HDMI_DATA

PEG3_TX2P_HDMI
PEG3_TX2N_HDMI
PEG3_TX1P_HDMI
PEG3_TX1N_HDMI
PEG3_TX0P_HDMI

PEG3_TX0N_HDMI
PEG3_TXCP_HDMI
PEG3_TXCN_HDMI

Confidential

Confidential

PEG5_HDMI_CLK

3

HDMI

PEG3_TX2P_HDMI_B_MN

PEG3_TX2N_HDMI_B_MN
PEG3_TX1P_HDMI_B_MN

PEG3_TX1N_HDMI_B_MN
PEG3_TX0P_HDMI_B_MN

PEG3_TX0N_HDMI_B_MN
PEG3_TXCP_HDMI_B_MN

PEG3_TXCN_HDMI_B_MN

PEG5_HDMI_CLK

PEG5_HDMI_DATA

VGA5_HDMI_HPD

R609
R608
R607
R605
R603
R601
R600
R597

PEG3_TX_HDMI_PU_Q_MN

RHU002N06

499
499
499
499
499
499 1%
499
499

Q519

PEG3_P5.0V_HDMI_D_MN

2.2K

2.2K

R583

R590

0.01nF

C575

0.5pF

50V

0.01nF

C580

PEG5_HDMI_CLK_L_MN
PEG5_HDMI_DATA_L_MN

For EMI

For ESD

0.5pF

1

50V

BAV99LT1
D5

PEG3_HPD_HDMI

DESIGN

CHECK

APPROVAL

MODULE CODE

3

2

1

BAV99LT1
D4

BLM18PG181SN1B508
BLM18PG181SN1B507

nostuff
nostuff

1%
1%
1%
1%
1%

1%
1%

P3.3V

D

3

G

1

S

2

R627

100K

nostuff

2

1

2

C571

100nF
10V

3

2

MMBT3904

MS Yang

MK Kim

BL Lee

TH501
miniSMDC110-2

D511
CRS06

C568

100nF

10V

nostuff
nostuff

P3.3V

Q520

DATE

DEV. STEP

REV

LAST EDIT

J10
HDMI-19P-FEMALE

1

TMDS_DATA2

2

TMDS_DATA2_SHIELD

3

TMDS_DATA2#

4

TMDS_DATA1

5

TMDS_DATA1_SHIELD

6

TMDS_DATA1#

7

TMDS_DATA0

8

TMDS_DATA0_SHIELD

9

TMDS_DATA0#

10

TMDS_CLOCK

11

TMDS_CLOCK_SHIELD

12

TMDS_CLOCK#

13

CEC

14

RESERVED

15

SCL

16

SDA

17

DDC_GROUND

18

5V_POWER

19

HOT_PLUG_DETECT

nostuff

VGA5_HDMI_HPD_R_MN

3

1

R618

2

R619

47K

TITLE

12/05/2008

MP

REV 1.0

HDMI

3701-001597

Type : angle

1%100K

BONN-E

GRAPHICS_IF

HDMI

April 11, 2009 10:05:58 AM

20

MNT1

21

MNT2

22

MNT3

23

MNT4

VGA5_HDMI_HPD

SAMSUNG

PART NO.

38

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

ELECTRONICS

BA41-01060A

D

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

P3.3V

C804

C803

10000nF-X5R

100nF

10V

10V

Codec Pin9 Setting

S/B with Low Voltage IO

Pin9 : 1.5V

P4.75V_AUD

R757

20K
1%

C C

R756

AUD3_SPKR

1K 1%

AUD3_SPKR_R_MN

AUD3_SPKR_Q_MN

D

3

Q546
RHU002N06

G

1

S

2

G_AUD

AUD5_SENS_MIC#

AUD5_SENS_HP#

B

S/B without Low Voltage IO

C801

R758

4.7nF

1K

25V

1%

G_AUD

R755
R721

Pin9 : 3.3V

HDA3_AUD_SDO

HDA3_AUD_BCLK

HDA3_AUD_SDI0

HDA3_AUD_SYNC

HDA3_AUD_RST#

AUD3_DMIC_CLK1

AUD3_DMIC_DATA1

AUD3_GPIO1#

1%20K

5.1K

1%

G_AUD

Samsung

Samsung

R759

C802

C3906

0.047nF
50V

R742

AUD5_SENS_MIC#_R_MN
AUD5_SENS_HP#_R_MN

SHORT507

SHORT506

HDA3_AUD_SDI0_R_MN

5%

22

1000nF-X5R

B528
B529

C3907

0.047nF
50V

nostuff
nostuff

20K

P4.75V_AUD

RGND-SHORT

RGND-SHORT

AUD3_SPKR_C_MN

6.3V

AUD3_DMIC_CLK1_R_MN

AUD3_DMIC_DATA1_R_MN

nostuff

BLM18PG181SN1

nostuff

BLM18PG181SN1

AUD3_JDREF_MN

1%

C770

100nF
10V

AUD3_AVSS_MN

AUDIO

C798

100nF
10V

U524
ALC272-GR

1

DVDD

9

DVDD-IO

5

SDATA-OUT

6

BCLK

8

SDATA-IN

10

SYNC

11

RESET#

12

PC_BEEP

46

DMIC-CLK1_2

44

DMIC-CLK3_4

2

GPIO0_DMIC01_2

3

GPIO1_DMIC-3_4

47

EAPD

45

SPDIFO2

48

SPDIFO1

43

NC

40

JDREF

13

SENSEA

34

SENSEB

4

DVSS_1

7

DVSS_2

25

AVDD1

38

AVDD2

26

C764

AVSS1

100nF

42

AVSS2

10V

1205-003526

LOUT1-R_PORT-D-R

LOUT1-L_PORT-D-L
LOUT2-L_PORT-A-L

LOUT2-R_PORT-A-R

HPOUT-R_PORT-I-R

HPOUT-L_PORT-I-L

LINE1-R_PORT-C-R

LINE2-R_PORT-E-R

CBP
CBN

CPVEE

MIC1-R_PORT-B-R

MIC1-L_PORT-B-L

MIC1-VREFO

MIC2-R_PORT-F-R

MIC2-L_PORT-F-L

MIC2-VREFO

LINE1-L_PORT-C-L

LINE1-VREFO

LINE2-L_PORT-E-L

LINE2-VREFO

MONO-OUT

VREF

36
35

39
41

32
33

AUD3_CBP_MN

29

AUD3_CBN_MN

30

AUD3_CPVEE_MN

C761

31

AUD5_MIC1_RIGHT_C_MN

22

AUD5_MIC1_LEFT_C_MN

21
28

AUD5_MIC2_RIGHT_C_MN

17

AUD5_MIC2_LEFT_C_MN

16
19
24

23
18
15

14
20
37
27

G_AUD

AUD5_VREF_MN

C762

10000nF-X5R
10V

C760

2200nF-X5R
10V

C773
C772

C787
C786

AUD5_MIC1_VREF_LEFT

C765

100nF
10V

2200nF-X5R
10V

1000nF-X5R

6.3V

1000nF-X5R

6.3V

AUD3_MIC2_VREFO_MN

1000nF-X5R

6.3V

6.3V

1000nF-X5R

R730
R729

AUD5_LINE_O_RIGHT
AUD5_LINE_O_LEFT

AUD5_HP_O_RIGHT
AUD5_HP_O_LEFT

5%4.7K

AUD5_MIC1_VREF_RIGHT

4.7K 5%

AUD5_MIC1_VREF_LEFT
AUD5_MIC1_RIGHT

AUD5_MIC1_LEFT

AUD5_MIC2_RIGHT
AUD5_MIC2_LEFT

AUD5_MIC2_VREF

3

12

BAT54A

D520

AUD5_LFE_O

AUD5_MIC1_VREF_RIGHT

B

G_AUD

P5.0V_AUD

U525
MIC5252-4.75BM5

1 5

IN

2

GND

3

BYPASS

1203-003344

G_AUD

GMT : 1203-005579

EN

MIC5_EYPASS_MN

G_AUD

C800

100nF

10V

SHORT509

R1608-SHORT

SHORT508

R1608-SHORT

3

Confidential

Confidential

C808

10000nF-X5R

10V

A

4

OUT

C791

1000nF-X5R

6.3V

P4.75V_AUD

4

G_AUD

G_AUD

C792

100nF

C788

10000nF-X5R
10V

10V

G_AUD

SHORT513
SHORT512

G_AUD

R1608-SHORT

R1608-SHORT

A

DESIGN

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

HDA_CODEC

AUDIO CODEC ALC272

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

39

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

67

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

P5.0V_AMP

AUD5_LINE_O_LEFTGND_C_MN
AUD5_LINE_O_LEFT_C_MN
AUD5_LINE_O_RIGHTGND_C_MN AUD5_LINE_O_RIGHTGND_R_MN

AUD5_LINE_O_RIGHT_C_MN

AUD5_LINE_O_LEFT

AUD5_LINE_O_RIGHT

C780
C779

C757
C763

220nF

220nF

220nF 10V

10V

10V220nF

10V

C781
C778

C

G_AUD

B

AUD3_SHDN# AUD3_GPIO1#

G_AUD

Samsung

Samsung

AUD5_LINE_O_LEFTGND_R_MN
AUD5_LINE_O_LEFT_R_MN

AUD5_LINE_O_RIGHT_R_MN

R736
R735

R725
R722

10V

220nF

10V

220nF

Q600

RHU002N06

15K

1%

1%

15K

1%15K

1%

15K

AUD3_LBYPASS_MN

AUD3_RBYPASS_MN

G_AUD

R719

D

3

R731

G

1

S

2

KBC3_SPKMUTE_U_MN

G_AUD

U520
TPA6020A2RGWR

12

LIN+

13

LIN-

16

RIN+

17

RIN-

11

LBYPASS

15

RBYPASS

2

GND1

5

GND2

8

NC1

10

NC2

1201-002810

10K

1%

1K
1%

LOUT+

ROUT+

ROUT­L_SD#

R_SD#

THERM

P3.3V

LVDD

RVDD

LOUT-

NC3
NC4

R724

1K
1%

7
19

G_AUD

4
6

1
3

9
14

18
20

21

G_AUD

KBC3_SPKMUTE

C754

100nF

10V

C758

100nF
10V

C752

10000nF-X5R

10V

SPK5_L_P
SPK5_L_M

SPK5_R_P
SPK5_R_M

AUD3_SHDN#

C809

10000nF-X5R

10V

SPK5_R_M

SPK5_R_P
SPK5_L_M

SPK5_L_P

P5.0V_AUD

G_AUD

SHORT568
SHORT567

G_AUD

SHORT510
SHORT511

R1608-SHORT

R1608-SHORT

R1608-SHORT

R1608-SHORT

J15
HDR-4P-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000922

SMD_A

Type : angle

P5.0V_AMP

C793

100nF
10V

G_AUD

C789

10000nF-X5R
10V

D

C

B

Confidential

Confidential

A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

HDA_CODEC

SPK AMP TPA6017

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

40 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

AUD5_MIC2_VREF

C724

G_AUD

10nF 25V

Mono Mic Ass’y

J19
HDR-2P-SMD

1
2

3

MNT1

4

MNT2

3711-000541

Type : angle

R746

Nearby Codec

2.2K

B519

330

P3.3V

BLM18PG181SN1

B525

C3904

0.047nF
50V

R700

AUD5_MIC2_VREF_R_MN

SMD_A

J22
HDR-4P-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000922

Type : angle

AUD5_MIC2_RIGHT

C

AUD5_MIC2_LEFT

B

Nearby Codec

SHORT550

R1608-SHORT

AUD3_DMIC_CLK1

AUD3_DMIC_DATA1

C785

47nF
25V

G_AUD

Samsung

Samsung

Confidential

Confidential

Digital MIC CONNECTOR

B526
BLM18PG181SN1

B527

C3905

0.047nF
50V

C480

0.047nF
50V

BLM18PG181SN1

BLM18PG181SN1

nostuff
nostuff
nostuff
nostuff
nostuff
nostuff
nostuff

AUD5_MIC2_VREF_B_MN

C723

0.1nF
50V

G_AUD

G_AUD

D

C

B

A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

HDA_CODEC

MIC AMP LMV358

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

6741

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3 1

2

D

D

HEADPHONE(BLACK)

J23
JACK-PHONE-6P-BLACK

G_AUD

5
4

R

3
6

L

2
1

G1
G2

3722-002588

Type : angle

C

AUD5_SENS_HP#

AUD5_HP_O_RIGHT

AUD5_HP_O_LEFT

P3.3V

10K

R702

1%1K

KBC3_SPKMUTE_Q_MN

D

3

G

1

S

2

Q537
RHU002N06

C

KBC3_SPKMUTE

R701

KBC3_SPKMUTE_R_MN

R716 56

P3.3V

2

1

3

KBC3_SPKMUTE_QQ_MN

56R713

Q539
DTA114YUA

R714

20K

AUD5_HP_O_RIGHT_R_MN

AUD5_HP_O_LEFT_R_MN

R715
20K

G_AUD

R704

1%1K

R708

1%

1K

AUD5_HP_O_RIGHT_Q_MN
AUD5_HP_O_LEFT_Q_MN

3

Q540

1

MMBT3904

2

3

1

2

G_AUD

B521
B520

Q538
MMBT3904

AUD5_HP_O_RIGHT_B_MN

AUD5_HP_O_LEFT_B_MN

BLM18PG181SN1
BLM18PG181SN1

50V

0.1nF

C740

50V

0.1nF

C739

50V

0.1nF

C733

nostuff

MIC JACK(BLACK)

AUD5_MIC1_RIGHT_B_MN

B517

AUD5_MIC1_LEFT_B_MN

BLM18PG181SN1B516
BLM18PG181SN1

50V

0.1nF

50V

0.1nF

50V

0.1nF

C729
C735
C742

B

G_AUD

25V10nF

25V

10nF

25V10nF

Samsung

Samsung

AUD5_SENS_MIC#

AUD5_MIC1_RIGHT

AUD5_MIC1_LEFT

R684
R685

330
330

AUD5_MIC1_RIGHT_R_MN

AUD5_MIC1_LEFT_R_MN

J20
JACK-PHONE-6P-BLACK

5
4

R

3
6

L

2
1

G1
G2

3722-002588

Type : angle

B

C710

C712

C711

nostuff

G_AUD

Confidential

Confidential

A A

12/05/2008

REV 1.0

TITLEDESIGN

MP

BONN-E

HDA_CODEC

H/P JACK AND MIC JACK

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

6742

OF

DATE

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DEV. STEP

REV

LAST EDIT

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

50V

P4.75V_AUD

U528-1
LMV358M

8

2

-

V

OUT

3

G

+

4

G_AUD

2.2nF

47K

1

C831

P4.75V_AUD

C825

1000nF-X5R

6.3V

G_AUD

1000nF-X5R

6.3V

AUD5_LFE_O_P_R_MN

AUD5_LFE_O_M_C1_MN

R773

R776

10K
1%

R772

10K
1%

Samsung

Samsung

C828

R775

P4.75V_AUD

6

47K

5

P5.0V_AMP

­+

G_AUD

8

V

OUT

G

4

0.047nF

47K

U528-2
LMV358M

7

G_AUD

C832

R778

AUD5_LFE_O_CR_MN

AUD5_LFE_O_C_MN

R774

AUD5_LFE_O

C826

1000nF-X5R

6.3V

33.2K
1%

C

AUD5_LFEO_U_MN

B

SUB-WOOFER

50V

C834

100nF
25V

C833

1000nF-X5R

6.3V

AUD5_LFE_O_M
AUD5_LFE_O_P

Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer

Sub-Woofer

AUD3_SHDN#

R791

10K
1%

AUD3_SHDN#_P3.3V_R_MN

R790

1M

R926

D

0

P3.3V

C

C848

100nF
25V

U530

5

7SZ08

1

+

4

2

-

3

nostuff
nostuff
nostuff
nostuff

AUD3_LFE_SHDN#

B

J24

C835

100nF
10V

C847

10000nF-X5R

10V

SPK5_LFE_P
SPK5_LFE_M

AUD3_LFE_SHDN#

Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer
Sub-Woofer

Sub-Woofer
Sub-Woofer
Sub-Woofer

2

DESIGN

CHECK

APPROVAL

MODULE CODE

SPK5_LFE_M

SPK5_LFE_P

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

C846

100nF

U529

AUD5_LFE_O_P

AUD5_LFE_O_M

C841
C840

AUD5_LFE_O_P_C_MN

10V

220nF

220nF

10V

AUD5_LFE_O_M_C_MN

C844
C839

AUD5_LFE_O_P_CR_MN

R786
R785

AUD5_LFE_O_M_CR_MN

AUD5_LFE_O_LBYPASS_MN

220nF
220nF

AUD5_LFE_O_RBYPASS_MN

10V
10V

39.2K

39.2K

A

G_AUD

4

TPA6020A2RGWR

1%

12

1%

LIN+

13

LIN-

16

RIN+

17

RIN-

Confidential

Confidential

11

LBYPASS

15

RBYPASS

2

GND1

5

GND2

8

NC1

10

NC2

1201-002810

G_AUD

LVDD
RVDD

LOUT+
LOUT-

ROUT+

ROUT­L_SD#

R_SD#

NC3
NC4

THERM

3

10V

7
19

G_AUD

4
6

1
3

9
14

18
20

21

G_AUD

R728
R723

12/05/2008

REV 1.0

AUD5_LFE_P_R_MN

TITLE

MP

AUD5_LFE_M_R_MN

0
0

HDR-2P-SMD

1
2

3

MNT1

4

MNT2

3711-000541

Type : angle

BONN-E

HDA_CODEC

SUB-WOOFER

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

43 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

LOM3_CLKREQ#

C

B

P3.3V

R540

10K

P3.3V_AUX

C565

4700nF-X5R
25V

C569

10000nF

6.3V

Place nearby Pin32

P3.3V_AUX

P3.3V_AUX

C100

100nF
10V

nostuff

C90

100nF
10V

R541

10K

PEX3_WAKE#

CLK1_PCIELOM

nostuff

CLK1_PCIELOM#
PEX1_GLAN_RXP4
PEX1_GLAN_RXN4

PEX1_GLAN_TXP4

PEX1_GLAN_TXN4

C570

C542

100nF

100nF

10V

10V

C96

C77

100nF

100nF

10V

10V

C86

100nF
10V

PLT3_RST#

P1.2V_LAN

C541

100nF
10V

P1.8V_LAN

C80

100nF
10V

PEX1_GLAN_RXP4_C_MN

PEX1_GLAN_RXN4_C_MN

100nF

C557

100nF

C558

C540

100nF
10V

C81

100nF
10V

P1.8V_LAN

U506
88E8057

5

PERST#

6

WAKE#

55

REFCLK+

56

REFCLK-

49

10V

TX+

50

10V

TX-

54

RX+

53

RX-

42

CLKREQ#

43

NC_9

37

SPI_CLK

35

SPI_DI

34

SPI_DO

36

SPI_CS#

38

VPD_CLK

41

VPD_DATA

1

VDDO_TTL_1

40

VDDO_TTL_2

45

VDDO_TTL_3

61

VDDO_TTL_4

8

AVDDH

2

VDD_1

7

VDD_2

13

VDD_3

33

VDD_4

39

VDD_5

44

VDD_6

48

VDD_7

58

VDD_8

32

AVDD18_OUT

28

AVDDL_2

22

NC_4

19

AVDDL_1

57

NC_12

52

NC_11

51

NC_10

23

NC_5

Samsung

Samsung

64

NC_13

1205-003587

LED_ACTIVE#

LED_LINK10_100#

LED_LINK1000#

LED_DUPLEX#

VMAIN_AVLBL

LOM_DISABLE#

MDI+_3

MDI-_3

MDI+_2

MDI-_2

MDI+_1

MDI-_1

MDI+_0

MDI-_0

CTRL12

PD18LDO

NC_1
NC_2

NC_3

XTALI

XTALO

TESTMODE

NC_8
NC_6
NC_7
RSET

THERMAL

30
31
26
27
20
21
17
18

59
60
62
63

Trace width 12mils

3
4

9
11

12
47
10

R578

LAN3_LOM_DISABLE#_MN

15
14

46
29
24
25
16

R576

LAN3_RSET_MN

65

1%

4.99K

LAN3_MDI+_3_MN
LAN3_MDI-_3_MN
LAN3_MDI+_2_MN
LAN3_MDI-_2_MN
LAN3_MDI+_1_MN
LAN3_MDI-_1_MN
LAN3_MDI+_0_MN
LAN3_MDI-_0_MN

25-A4

LAN3_CTL12

P3.3V

P3.3V_AUX

10K

Y500

25MHz

LAN3_XTALO_MN

1 2

LAN3_XTALI_MN

2801-004517

C102

C108

0.015nF

0.015nF
50V

50V

Place crystal within 0.75inches from LAN chip.

10V

100nF

C559

10V

100nF

C556

10V

100nF

C551

10V

100nF

C567

TD4-

12

TD4+

11

TCT4

10

TD3-

9

TD3+

8

TCT3

7

TD2-

6

TD2+

5

TCT2

4

TD1-

3

TD1+

2

TCT1

1

LFE9261A-R
LT1

2603-000107

ALT BOM

LFE9261A-R
2603-000107

MX4­MX4+

MCT4

MX3­MX3+

MCT3

MX2­MX2+

MCT2

MX1­MX1+

MCT1

13
14
15

16
17
18

19
20
21

22
23
24

LAN3214-50
2603-000110

1%
75

R574

1%
75

R558

1%
75

R551

1%
75

R537

C560

1nF
3KV

ALT3_MX4-_MN
ALT3_MX4+_MN
ALT3_MX2-_MN
ALT3_MX3-_MN
ALT3_MX3+_MN

ALT3_MX2+_MN

ALT3_MX1-_MN
ALT3_MX1+_MN

3722-002843

MNT2

10

MNT1

9

TERM4

8

TERM3

7

RD-

6

TERM2

5

TERM1

4

RD+

3

TD-

2

TD+

1

JACK-LAN-8P
J9

D

C

B

P3.3V_AUX

B5
BLM18PG181SN1

R111

4.7K

A

LAN3_CTL12

25-C3

Confidential

Confidential

LAN3_CTL12_R_MN

C133

C114

4700nF

100nF

10V

10V

C130

22000nF-X5R
20%

6.3V

3

4

2 4

1

U508
BCP69-16

P1.2V_LAN

LAN3_CTL12_U_MN

C121

10000nF

6.3V

C115

4700nF
10V

C109

100nF
10V

A

DESIGN

CHECK

APPROVAL

MODULE CODE

23

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

LAN

LAN_MARVELL_8057

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

6744

OFPAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

C

B

C783

100nF
10V

CHP3_SLPS3#

PLT3_RST#

Express Card Power Switch

P1.5V P3.3VP3.3V_AUX

C794

100nF
10V

C777

100nF
10V

C3909

0.1nF
50V

nostuff

U522
R5538D001-TR-F

2
4

12
14

17
18
20

1
6

19

3.3VIN_1

3.3VIN_2

1.5VIN_1

1.5VIN_2

AUXIN
RCLKEN
SHDN*

STBY*
SYSRST*

OC*

1205-002807

3.3VOUT_1

3.3VOUT_2

1.5VOUT_1

1.5VOUT_2

THERMAL

GMT : 1205-003667

AUXOUT

PERST*

CPPE*

CPUSB*

NC_5

GND

3
5

11
13

15
8

10
9

16
7
21

Express Card

SMB3_CLK_MN

P3.3V

P3.3V_AUX_EXPP1.5V_EXPP3.3V_EXP

EXP3_PERST#
EXP3_CPPE#
EXP3_CPUSB#

Samsung

Samsung

EXP3_CLKREQ#

R408

10K
1%

USB3_EXPCARD-

USB3_EXPCARD+

EXP3_CPUSB#

SMB3_CLK

SMB3_DATA

PEX3_WAKE#

EXP3_PERST#

EXP3_CPPE#

CLK1_EXPCARD#

CLK1_EXPCARD

PEX1_EXPCARDRXN3
PEX1_EXPCARDRXP3

PEX1_EXPCARDTXN3

PEX1_EXPCARDTXP3

SMB3_DATA_MN
PEX3_WAKE#_MN

R749
R748

R754

nostuff

nostuff
nostuff

0
0

0

J25
EDGE-XPRESS-26P

2

USB_D-

3

USB_D+

4

CPUSB#

7

SMB_CLK

8

SMB_DATA

11

WAKE#

13

PERST#

16

CLKREQ#

17

CPPE#

18

REFCLK-

19

REFCLK+

21

PERN0

22

PERP0

24

PETN0

25

PETP0

3711-007016

Type : angle

+3.3V_2
+3.3V_1

+3.3V_AUX

+1.5V_1

+1.5v_2

GND_4
GND_3
GND_2
GND_1

RESERVED_2
RESERVED_1

MNT1
MNT2

D

P3.3V_AUX_EXPP3.3V_EXP P1.5V_EXP

C3618

C900

100nF

100nF

10V

15
14

12
10

9

26
23
20
1

6
5

27
28

10V 10V

C795

C784

100nF 100nF

10V

C

B

TYPE - II

J26
EXPRESS-26P-FRAME

1

MNT1

2

MNT2

3709-001566

MS Yang

MK Kim

BL Lee

Angle type

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

EXPRESS CARD
EXPRESS CARD

April 11, 2009 10:05:58 AM

Confidential

Confidential

A A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

Type 2 module

54.00 mm

INSERT

THIS SIDE UP

75.00 mm
EXPRESS CARD

54.00 mm W
X

75.00 mm L
X

5.00 mm H

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

45 67

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OFPAGE

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

3 IN 1 CARD (AU6336)

15
24

17
19
21
22
23
12
11

10
18

16
26

MCD3_SDCLK_R_MN

1
5

MCD3_REXT_MN

29

R769

330

P3.3V_MCD

R771

C824

0.022nF
50V

C829

100nF

10V

MCD3_SDDATA0
MCD3_SDDATA1
MCD3_SDDATA2
MCD3_SDDATA3

33

C836

0.022nF
50V

nostuff

R779

150K
1%

MCD3_SDCD#
MCD3_SDWP
MCD3_SDCMD
MCD3_SDCLK

MCD3_SDDATA3

MCD3_SDCMD

MCD3_SDCLK

MCD3_SDDATA0
MCD3_SDDATA1
MCD3_SDDATA2

MCD3_SDCD#

MCD3_SDWPCLK3_FM48

R783

R782
R781
R784

MCD3_SDDATA0_MN
MCD3_SDDATA1_MN
MCD3_SDDATA2_MN

P3.3V

C823

1000nF-X5R

C C

C815

C820

4700nF-Y5V

100nF

10V

10V

USB3_MMC+

USB3_MMC-

nostuff
nostuff

6.3V

USB3_MMC_R_MN
USB3_MMC#_R_MN

C3169

C866

0.018nF

0.018nF

50V

50V

R765
R766

C816

MCD3_RSTN_MN

B B

U527

C810

100nF

AU6336C52-MWF

10V

2

VD33P

9

VDDHM

14

VDD33C

28

VDD

8

VDDU

0

3

DP

0

4

DM

20

CLED

470nF

16V

27 13

RSTN

25

EXTCLK

6

NC1

7

NC2

0904-002453

Samsung

Samsung

SD_V33

SDDATA0
SDDATA1
SDDATA2
SDDATA3
SDDATA4
SDDATA5
SDDATA6
SDDATA7

TRIST

SDCDN

SDWP

SDCMD

SDCLK

REXT

VS33P

GND

49.9 1%

49.9 1%

P3.3V_MCD

R780

100K
1%

MCD3_SDDATA3_R_MN

1%49.9

1%49.9

C837

1000nF-X5R

6.3V

J506
EDGE-SD-9P

1

CD_DAT3

2

CMD

3

VSS1

4

VDD

5

CLK

6

VSS2

7

DAT0

8

DAT1

9

DAT2

10

CARD_DETECT

11

WRITE_PROTECT

12

MNT1

13

MNT2

3709-001492

3-in-1 Socket

Support : SD/MMC/SDHC

Type : angle

D

Confidential

Confidential

AA

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

MULTICARD
2 IN 1 CARD

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

6746

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

WLAN, 4mm

3

2

1

D

MIN3_CLKREQ#

CLK1_MINIPCIE#

CLK1_MINIPCIE

PEX1_MINIRXN1

PEX1_MINIRXP1

PEX1_MINITXN1
PEX1_MINITXP1

C

M502
HEAD
DIA
LENGTH

BA61-01090A

FULLSIZE

PEM : WLAN minicard + Half minicard

B

ITM3_CLKREQ#

CLK1_MINIPCIE2#

CLK1_MINIPCIE2

PEX1_MINIRXN2
PEX1_MINIRXP2

PEX1_MINITXN2
PEX1_MINITXP2

P3.3V

A

C89

C581

10000nF-X5R

6.3V

100nF
10V

C582

100nF
10V

4

P3.3V

M501

HEAD

DIA

LENGTH

BA61-01090A

P3.3V

R417

10K
1%

11
13
15

17
19
21

25
27
29
31
33
35
37
39
41
43
45
47
49
51

HALFSIZE

HSDPA, 7mm

P3.3V

Bonn-E : stuff
Canne : nostuff

J502
MINICARD-52P

1

WAKE*

3

RSVD_1

5

RSVD_2

7

CLKREQ*

9

GND_2

11

REFCLK-

13

REFCLK+

15

GND_3

17

SIM_RSVD_C8

19

SIM_RSVD_C4

21

GND_5

23
25

PERP0

27

GND_7

29

GND_8

31

PETN0

33

PETP0

35

GND_10

37

RSVD_11

39

RSVD_12

41

RSVD_13

43

RSVD_14

45

RSVD_15

47

RSVD_16

49

RSVD_17

51

RSVD_18

3709-001506

J505
EDGE-MINIPCI-E-52P

1

WAKE*

3

RSVD_1

5

RSVD_2

7

CLKREQ*

9

GND_2
REFCLK­REFCLK+
GND_3

SIM_RSVD_C8
SIM_RSVD_C4
GND_5
PERN0
PERP0
GND_7
GND_8
PETN0
PETP0
GND_10
RSVD_11
RSVD_12
RSVD_13
RSVD_14
RSVD_15
RSVD_16
RSVD_17
RSVD_18

3709-001498

Angle type

P3.3V_1
P1.5V_1

SIM_VCC_C1

SIM_DATAIO_C7

SIM_CLK_C3

SIM_RESET_C2

SIM_VPP_C6

W_DISABLE*

PERST*

P3.3V_AUXPERN0

P1.5V_2

SMB_CLK

SMB_DATA

USB_D­USB_D+
GND_11

LED_WWAN*

LED_WLAN*
LED_WPAN*

P1.5V_3
GND_12
P3.3V_2

Type : angle

P3.3V

P3.3V

C3641

100nF

P3.3V

P3.3V

R596

10K

R595

MIN3_LED_WWAN#2_MN
MIN3_LED_WLAN#2_MN

10V

2

P3.3V_1

4

GND_1

6

P1.5V_1

SIM_VCC_C1

SIM_DATAIO_C7

SIM_RESET_C2

SIM_VPP_C6

LED_WWAN*

GND_1

GND_4

GND_6

GND_9

MNT1
MNT2

8
10
12

SIM_CLK_C3

14
16

18

GND_4

20

W_DISABLE*

22

PERST*

2423

P3.3V_AUX

26

GND_6

28

P1.5V_2

30

SMB_CLK

32

SMB_DATA

34

GND_9

36

USB_D-

38

USB_D+

40

GND_11

42
44

LED_WLAN*

46

LED_WPAN*

48

P1.5V_3

50

GND_12

52

P3.3V_2

53

MNT1

54

MNT2

P1.5V

C135

100nF

Samsung

Samsung

10V

2
4
6
8
10
12
14
16

18

KBC3_RFOFF#_R_MN

20
22
24
26
28
30
32

Confidential

Confidential

34
36
38
40
42
44
46
48
50
52

53
54

3

C863

100nF
10V

KBC3_RFOFF#
PLT3_RST#

C3898

0.1nF
50V

nostuff

Added by EMC

USB3_WIMAX-

SIM3_C1
SIM3_C7
SIM3_C3
SIM3_C2
SIM3_C6

0

KBC3_RFOFF#
PLT3_RST#

USB3_MINIPCIE2­USB3_MINIPCIE2+

SIM3_DETECT#

USB3_WIMAX+

MIN3_LED_WWAN#1_MN
MIN3_LED_WLAN#1_MN
MIN3_LED_WPAN#1_MN

C136

100nF
10V

nostuff

M500
HEAD
DIA
LENGTH

BA61-01103A|screw-118-2b-h0450

Mini PCI Express Card

30.00 mm

Top

50.95 mm

Pin 1

Odd Pins : Top side
Even Pins : Bottom Side

HSDPA

HSDPA

HSDPA

HSDPA

HSDPA

HSDPA
HSDPA

HSDPA

48.05 mm

P3.3V

C819

10000nF

6.3V

SIM3_DETECT#

D514

BAV99LT1

C796

C817

100nF

100nF

P3.3V

SIM3_C1
SIM3_C2
SIM3_C3 SIM3_C7

P3.3V

2

3

1

D512

BAV99LT1

BAV99LT1

D517

BAV99LT1

D515

nostuff
nostuff
nostuff
nostuff

Mini PCI Express Card

30.00 mm

48.05 mm

Top

50.95 mm

Pin 1

Odd Pins : Top side
Even Pins : Bottom Side

2

R47

10K
1%

1

2

3

DESIGN

CHECK

APPROVAL

MODULE CODE

1

C818

10000nF

2

3

6.3V

P3.3V

C3640

2

1

nostuff
nostuff

KBC3_RFOFF#

100nF

SIM CARD CONN.

Bonn-E : stuff
Canne : nostuff

C1
C2
C3

C4 1
C8

3

C44

C43

C42

1000nF
10%

6.3V

0.01nF

0.5pF

MS Yang

MK Kim

BL Lee

0.01nF

0.5pF

50V

50V

DATE

DEV. STEP

REV

LAST EDIT

J5
EDGE-SIM-8P-MNT

C5

C1

C6

C2

C7

C3
CD_U

MNT1

CD_L

MNT2

3709-001478

Type : angle

TITLE

12/05/2008

MP

REV 1.0

C5
C6
C7

2

MINI_PCIE_CONN

WLAN & HSDPA & SIM CARD

April 11, 2009 10:05:58 AM

BONN-E

D

3

Q547
RHU002N06

G

1

S

2

P3.3V

2

C45

0.01nF

0.5pF
50V

nostuff
nostuff

2

3

1

1

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

WLON_LED#

3

D513

HSDPA
HSDPA
HSDPA
HSDPA
HSDPA
HSDPA

SIM3_C6

BAV99LT1

D516

BAV99LT1

ELECTRONICS

BA41-01060A

OF

D

C

B

A

6747

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

SATA HDD CONN

JHDD500
HDD-22P-SMD

S1

C

B

SAT1_HDD_TXP

SAT1_HDD_TXN
SAT1_HDD_RXN

SAT1_HDD_RXP

P3.3V

C799

10000nF

6.3V

P5.0V

C776

C782

10000nF

100nF

6.3V

10V

C811

100nF
10V

C814

100nF
10V

C790

10000nF

6.3V

nostuff

nostuff
nostuff
nostuff

C769

C767

100nF 100nF
10V

10V

GND1

S2

TX+

S3

TX-

S4

GND2

S5

RX-

S6

RX+

S7

GND3

P1

3.3V_1

P2

3.3V_2

P3

3.3V_3

P4

GND4

P5

GND5

P6

GND6

P7

5V_1

P8

5V_2

P9

5V_3

P10
P11
P12
P13
P14
P15

M1

M2

3710-002788

POWER SIGNAL

GND7
RESERVE
GND8
12V_1
12V_2
12V_3

MNT1
MNT2

Samsung

Samsung

Type : angle

SATA I/F CONN

MAIN TO SUB SATA ODD CONN

P5.0V

C697

C428

nostuff
nostuff
nostuff
nostuff
nostuff

C699

100nF

C434

10000nF-X5R
10V

10V

10000nF-X5R
10V

100nF
10V

C696

100nF
10V

SAT1_ODD_RXN
SAT1_ODD_RXP

SAT1_ODD_TXP
SAT1_ODD_TXN

J17
CONN-12P-FPC

1
2
3
4
5
6
7
8
9
10
11
12

3708-002190

Type : angle

D

C

B

Confidential

Confidential

A A

DESIGN

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

SATA_DEVICES

HDD & ODD SUB CONNECTOR

April 11, 2009 10:05:58 AM

BONN-E

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

48 67

PAGE OF

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

D

KBC3_RCIN#

KBC3_CHKPWRSW#

KBC3_MD

KBC5_TPAD_CTRL#

KBC5_LED_CTRL

KBC5_TCLK

KBC5_TDATA

KBC3_SCLED#

KBC3_NUMLED#

KBC3_CAPSLED#

KBC3_EXTSMI#
KBC3_RUNSCI#

KBC3_USBPWRON#

KBC3_CHG4.2V

KBC3_RFOFF#

KBC3_LED_POWER#

KBC3_PWRGD
KBC3_PWRON

KBC5_KSI(0:7)

KBC5_KSO(0:7)

B

LPC3_LAD(0:3)

LPC3_LFRAME#

PLT3_RST#

CLK3_PCLKMICOM

CHP3_SERIRQ

CLK3_MICOM_XTALIN_MN

C447

0.018nF

CLK3_MICOM_EXTAL_MN

Y2

1

2

2801-004665

10MHz

C448

0.018nF

A

4

P3.3V_MICOM

C637

100nF

C671
100nF

1

100

7

NMI

RES*

RESO*

C681

100nF

48

PA0

47

PA1

31

PA2

30

PA3

21

PA4

20

PA5

11

PA6

10

PA7

91

PB0

90

PB1

81

PB2

80

PB3

69

PB4

68

PB5

58

PB6

57

PB7

0

79

P10

1

78

P11

2

77

P12

3

76

P13

4

75

P14

5

74

P15

6

73

P16

7

72

P17

0 13

67

P20

1

66

P21

2

65

P22

3

64

P23

4

63

P24

5

62

P25

6

61

P26

7

60

0
1
2
3

P27

82

P30

83

P31

84

P32

85

P33

86

P34

87

P35

88

P36

89

P37

2

XTAL

3

EXTAL

P5.0V

R673

R667

10K

10K

1%

1%

KBC3_STBY#_MN

36

VCC_1

H8S-2110B

VSS_1

15

4

37

59

9

8

6

5

VCL

MD0

MD1

VCC_2

VCC_3

U10

0903-001439

VSS_2

VSS_3

VSS_4

VSS_5

46

70

71

92

Confidential

Confidential

P40

VCCB

STBY*

P41
P42
P43
P44
P45
P46
P47

P50
P51
P52

P60
P61
P62
P63
P64
P65
P66
P67

P70
P71
P72
P73
P74
P75
P76
P77

Samsung

Samsung

P80
P81
P82
P83
P84
P85
P86

P90
P91
P92
P93
P94
P95
P96
P97

3

KBC3_RCIN#

P3.3V_MICOM

C663

100nF

10V

49
50
51
52
53
54
55
56

14
13
12

26
27
28
29
32
33
34
35

8

38

9

39

10

40

11

41

12

42
43

14

44

15

45
93

94
95

KBC3_P3.3V_PU_R_MN

96
97
98
99

KBC3_P3.3VMICOM_PU_R_MN

25
24
23
22
19
18
17
16

R660

10K

1%

R676

KBC3_RSMRST#
KBC3_SUSPWR
KBC3_THERM_SMDATA
KBC3_BKLTON
KBC3_PWRBTN#
KBC3_VRON
KBC3_BLCKPWRSW#
KBC3_CPURST#

KBC3_LED_ACIN#
KBC3_LED_CHARGE#
KBC3_SMCLK#

LID3_SWITCH#
KBC3_PRECHG
KBC3_P5ALWON
KBC3_CHGEN

CHP3_SLPS3#
PEX3_WAKE#
KBC5_KSO(8:15)

KBC3_WAKESCI#
KBC3_A20G
PCI3_CLKRUN#

KBC3_TX
KBC3_RX
KBC3_THERM_SMCLK

10K

KBC3_CHKPWRSW#
ADT3_SEL#
KBC3_SPKMUTE
CHP3_SUSSTAT#
CHP3_SLPS5#
CHP3_SLPS4#
KBC3_SMDATA#

MICOM Crisis Update

Condition: P90=P91=P92=High(MICOM_P3V)
MD0=MD1=Low(0V)

Serial Port: P84 & P85

3

1203-002364

RESET*

2

VDD

3

GND

TPS3809

U512

1

GMT : 1203-005592

VRM3_CPU_PWRGD

C3911

0.1nF
50V

nostuff

For ESD

P3.3V

P3.3V_MICOM

2

R652

100

1%

KBC3_RCIN#_R_MN

R654

100K

nostuff

P3.3V_MICOM

R656

2

MICOM RESET

C638

100nF

25V

THM3_STP#_VDC_MN

300K

1%

C678

100nF
10V

KBC3_BLCKPWRSW#

KBC3_PWRSW#

KBC3_MD

KBC3_TX
KBC3_RX

DRAW

APPROVAL

MODULE CODE

VDC

P3.3V_MICOM

R632

330K

THM3_STP#_QR_MN

G

1

R637

150K
1%

BAT3_DETECT#

DATE TITLE

MS Yang

DEV. STEPCHECK

MK Kim

REV

BL Lee

LAST EDIT

1

3

Q523
RHU002N06

THM3_STP#_Q_MN

R635

47K

R641

47K

D

3

Q521
RHU002N06

S

2

KBC5_TCLK

KBC5_TDATA

KBC3_SMDATA#

KBC3_SMCLK#

R661

100K

12/05/2008

R659

10K
1%

1%

POWER SWITCH BLOCK WHILE MICOM UPDATE

TP2000

1

MODE0

2

TX

3

RX

4

GND

MP

REV 1.0

D

G

1

S

2

BSS84
Q526

3

nostuff
nostuff
nostuff
nostuff
nostuff
nostuff
nostuff

R665

10K
1%

D

3

Q530
RHU002N06

S

2

KBC3_MD

KBC3_TX
KBC3_RX

R642

100K
1%

R657
R662

D

R675
R674

C654

10nF
25V

P3.3V_MICOM

G

1

BONN-E

MICOM

MICOM_Renesas2110_100p

April 11, 2009 10:05:58 AM

1

P3.3V_AUX

R643

4.7K

THM3_STP#_R_MN

2

S

G

1

10kohm pull-up to P3.3V_AUX

should be at the thermal sensor side.

10K
10K

4.7K

4.7K

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

P5.0V

1%
1%

P3.3V_MICOM

KBC3_CHKPWRSW#

C685

330nF
10V

J18
HDR-4P-1R-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000456

Type : straight

SAMSUNG

PART NO.

49 67

PAGE

THM3_STP#

nostuff

ELECTRONICS

BA41-01060A

OF

D

CC

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4 1

3

2

Micom Glue Logic

TOUCHPAD LED

D

C

B

A

nostuff when 2111b(144p) is used

KBC5_KSI(0:7)

KBC5_KSO(0:15)

KBC3_TX

MT5

RMNT-25-90-1P

MT9

RMNT-25-90-1P

Keyboard Mount

KEYBOARD

1%

1%

1%

1%

1%

1%

10K

10K

10K

10K

10K

10K

R611

R615

R613

R610

R612

R614

EMI

BA70-00601A

CONTACT-PLATE-EMI

Contact to Touchpad

4

P3.3V

1%

1%

10K

10K

R617

R616

CANNES

EMI3

J12
FPC-KBD-25P

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

26

MNT1

27

MNT2

3708-002166

Type : angle

Contact to Touchpad

EMI

BA70-00601A

CONTACT-PLATE-EMI

P5.0V_STB

TOUCHPAD

3708-002402

1
2
3
4
5
6
MNT1
MNT2

CONN-6P-FPC
J13

TCH1_LED1_MN
TCH1_LED2_MN
TCH1_LED3_MN
TCH1_LED4_MN
TCH1_LED5_MN
TCH1_LED6_MN
TCH1_LED7_MN
TCH1_LED8_MN
TCH1_LED9_MN

KBC5_LED_CTRL

P3.3V_LED

R412

R409

R413

R411

R777

R416

R414

R415

R767

DESIGN

CHECK

APPROVAL

MODULE CODE

2

P5.0V

C602

100nF
10V

KBC5_TDATA
TPD5_R_BUTTON#
TPD5_L_BUTTON#

KBC5_TCLK

TPD5_R_BUTTON#

Samsung

Samsung

Confidential

Confidential

BONN

EMI2

TPD5_L_BUTTON#

TPD5_R_BUTTON#

TPD5_L_BUTTON#

C603

1nF
50V

P5.0V

P5.0V

C606

0.01nF

0.5pF
50V

D6

BAT54C

2

BAV99LT1

2

BAV99LT1

D10

C605

C604

1nF

1nF

50V

50V

3

R633

1 2

100K
1%

SW2
SW-TACT-4P

1

234

3

1

D9

nostuff

SW1
SW-TACT-4P

1

234

3

1

nostuff

7
8

KBC5_TPAD_CTRL#

nostuff
nostuff

Type : angle

3

KBC5_LED_CTRL_Q_MN

KBC5_LED_CTRL_R_MN

R640

475

1%

475

1%

1%

475

475

1%

1%

475

1%

475

475

1%

475

1%

MS Yang

MK Kim

BL Lee

G

1%

10K

1

R638

100K
1%

1 2

LED14
LTST-C193TBKT-AC

1 2

LED10
LTST-C193TBKT-AC

1 2

LED15
LTST-C193TBKT-AC

2

1

LED12
LTST-C193TBKT-AC

1 2

LED13
LTST-C193TBKT-AC

1 2

LED18
LTST-C193TBKT-AC

1 2

LED16
LTST-C193TBKT-AC

1 2

LED17
LTST-C193TBKT-AC

1 2

LED11
LTST-C193TBKT-AC

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

R645

200K
1%

D

3

Q522
RHU002N06

S

2

MP

R639

TITLE

P3.3V_AUX

1%

30.1K

KBC5_LED_CTRL_QR_MN

MICOM GLUE LOGIC

KETBOARD & TOUCHPAD

SI2315BDS-T1

2

S

1

C650

330nF
10V

G

P3.3V_LED

R289

R283

R281

R284

R303

R310

R306

BONN-E

April 11, 2009 10:05:58 AM

1

P3.3V_LED

Q527

3

D

C672

100nF

1 2

1%

475

LED6
LTST-C193TBKT-AC

1 2

475

1%

LED1
LTST-C193TBKT-AC

1%

475

1 2

LED2
LTST-C193TBKT-AC

475

1%

1 2

LED3
LTST-C193TBKT-AC

1%

475

1 2

LED4
LTST-C193TBKT-AC

475

1 2

1%475

LED5
LTST-C193TBKT-AC

4751%

1%

1 2

LED7
LTST-C193TBKT-AC

TCH1_LED11_MN
TCH1_LED12_MN
TCH1_LED13_MN
TCH1_LED14_MN
TCH1_LED15_MN
TCH1_LED16_MN
TCH1_LED17_MN

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

50 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

D

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

FUNCTION KEY LED

LED19

KBC3_NUMLED#

C

KBC3_CAPSLED#

KBC3_SCLED#

CHP3_SATALED#

WLON_LED#

B

LTST-C193TBKT-AC

1

2

LED20

LTST-C193TBKT-AC

1

2

LED21

LTST-C193TBKT-AC

1

2

LED22

LTST-C193TBKT-AC

2

LED23

LTST-C193TBKT-AC

2

1 1

KBC3_NUMLED#_LED_MN

KBC3_CAPSLED#_LED_MN

KBC3_SCLED#_LED_MN

CHP3_SATALED#_LED_MN

WLON_LED#_LED_MN

Samsung

Samsung

R797

R798

R799

R800

R801

P3.3V

475

1%

475

1%

KBC3_LED_CHARGE#

475

1%

475

1%

475

1%

KBC3_LED_POWER#

ADAPTERIN/CHARGING LED

KBC3_LED_ACIN#_Q_MN

1%475

1%

5

+

­3

U531
7SZ14FU

BSS84
Q549

3

2

S

D

1

G

BSS84
Q548

3

2

S

D

1

G

KBC3_LED_POWER#_U_MN

R802

R803

1M
1%

C859

1000nF

6.3V

KBC3_LED_ACIN#

P3.3V_MICOM

R795

P3.3V_MICOM_LED_ACIN#_R_MN

R794

P3.3V_MICOM

R793

P3.3V_MICOM_LED_CHARGE#_R_MN

R792

10K 1%

KBC3_LED_ACIN#_R_MN

475 1%

10K

KBC3_LED_CHARGE#_R_MN

P3.3V_AUX

2 4

LED24
LTST-C195KGJRKT

123

G

4

R

KBC3_LED_CHARGE#_Q_MN

1%

475

LED25

KBC3_LED_POWER#_R_MN

LTST-C193TBKT-AC

1 2

D

C

B

Confidential

Confidential

A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

LED_SWITCH
LED_SWITCH

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

6751

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

USB + eSATA CONNECTOR

2

USB Single connector

USB3_P2-_B_MN

USB3_P2+_B_MN

R280

200K
1%

D

3

Q27
RHU002N06

S

2

R928

20K
1%

MP

REV 1.0

P3.3V

C3923

1nF
50V

TITLE

P5.0V_AUX_USB

C3908

100nF
10V

Type : straight

BONN-E

USB_CONN

USB & eSATA

April 11, 2009 10:05:58 AM

EC511

C687

100uF

100nF

16V
AS

10V

J16
JACK-USB-4P

PWR
D­D+
GND

5

MNT1

6

MNT2

7

MNT3

8

MNT4

3722-002767

Type : angle

KBC5_P5ALWON#

Bonn : nostuff
Canne : stuff

J507
HDR-4P-1R-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000456

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

C689

100nF
10V

nostuff

CANNES
CANNES
CANNES

SAMSUNG

PART NO.

PAGE

ELECTRONICS

BA41-01060A

6752

OF

D

KBC3_USBPWRON#

KBC5_P5ALWON#

C C

KBC3_USBPWRON#_R_MN

USB3_P0-

USB3_P0+

USB SUB B’D CONNECTOR

B B

KBC3_USBPWRON#

A

R649

nostuff

C662

100nF

10V

C48

100nF

R190

10V

P5.0V_ALW

0

0

nostuff
nostuff

P5.0V_ALW

4

U7
TPS2062ADRBR

2

IN

8

OC1#

5

OC2#

3

EN1#

4

EN2#

T_GND

1205-003683

R182
R186

213

B513
ACM2012-900-2P-T

U4
TPS2062ADRBR

2

IN

8

OC1#

5

OC2#

3

EN1#

4

EN2#

1205-003683

P5.0V_AUX_USB

1

GND

7

OUT1

6

OUT2

9

0
0

4

GND
OUT1
OUT2

T_GND

USB3_P6+

USB3_P10-

USB3_P10+

KBC3_PWRSW#

LID3_SWITCH#

0

R934

nostuff

TPS1_P5.0VAUX_USBPWR1_MN

1

TPS3_P5.0VAUX_USBPWR1_MN

7

R46

6

TPS3_P5.0AUX_USBPWR2_MN

9

USB3_P6-

Need 2A Routing

EC510

C621

100uF

100nF

16V
AS

10V

USB3_P0-_B_MN

USB3_P0+_B_MN

SAT1_ESATA_TXP

SAT1_ESATA_TXN
SAT1_ESATA_RXN

SAT1_ESATA_RXP

0

P3.3V

C33

100nF

10V

0

R932

BONN

0

R679

0

R681

C622

C623

100nF

0.033nF

10V

50V

nostuff
nostuff

J14
JACK-USB-ESATA-11P

1

VBUS

2

D-

3

D+

SHORT559
SHORT560

SHORT561
SHORT562

Samsung

Samsung

R1005-SHORT
R1005-SHORT

R1005-SHORT
R1005-SHORT

SAT1_TXP4_R_MN
SAT1_TXN4_R_MN

SAT1_RXN4_R_MN
SAT1_RXP4_R_MN

6
7

9

10

TXP
TXN

RXN
RXP

3722-002850

Type : angle

4

GND1

5

GND2

8

GND3

11

GND4

12

MNT1

13

MNT2

14

E-SATA USB

MNT3

15

MNT4

USB3_P2-

USB3_P2+

nostuff
nostuff

KBC3_P5ALWON

1

4

2

3

B27

ACM2012-900-2P-T

for sleep in charge

P5.0V_STB

G

1

LID SWITCH for Canne

PLACE CLOSE TO USB SUB B’D Conenctor

R933

20K
1%

BONN

J7
HDR-12P-SMD

Confidential

Confidential

1
2
3
4
5
6
7
8
9
10
11
12

3711-000556

Type : angle

KBC3_PWRSW#

DESIGN

CHECK

APPROVAL

MODULE CODE

LID3_SWITCH#

MS Yang

MK Kim

BL Lee

DATE

12/05/2008

DEV. STEP

REV

LAST EDIT

P3.3V_MICOM

3

2

BAV99LT1

D502

3

1

nostuff

2

D

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

D

4

3

2

1

USB I/F Devices

D

Bluetooth Interface

P3.3V

J27
HDR-4P-1R-SMD

1
2
3
4

5

MNT1

6

MNT2

3711-000456

Type : straight

USB3_CAMERA-

USB3_CAMERA+

C813

C812

100nF

100nF

10V

C

10V

USB3_BLUETOOTH-

USB3_BLUETOOTH+

CAMERA

P5.0V

C633

C632

100nF

100nF

10V

10V

4

USB3_CAMERA-_B_MN

213

B22
ACM2012-900-2P-T

USB3_CAMERA+_B_MN

J11
HDR-6P-SMD

1
2
3
4
5
6

7

MNT1

8

MNT2

3711-002049

Type : angle

Free Fall Sensor

P3.3V

Samsung

B B

Samsung

USING THE CLOCK AND DATA OF ICH

1
2
3

SMB3_CLK

SMB3_DATA

A

4

4
5

Confidential

Confidential

VDD_IO
NC_1
NC_2
SCL_SPC
GND_1

1209-001876

P3.3V

14

15

16

VDD

GND_4

U526
LIS331DL

RESERVED_2

RESERVED_1

SDA_SDI_SDO

CS

SDO

8

6

7

R921
R922

3

C822

10000nF-X5R

6.3V

GND_3
GND_2

INT1
INT2

C821

100nF
10V

13
12
11
10
9

FFS3_INT2_MN

P3.3V

10K
10K

FFS3_INT

FFS
FFS
FFS
FFS
FFS

DESIGN

CHECK

APPROVAL REV

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

USB_DEVICES

BLUETOOTH & CAMERA

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

53 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

C

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

D

MDC connector

J30

1
3 4
5 6
7 8
9

10
11 12
MNT1
MNT2
MNT3
MNT4
MNT5
MNT6

3710-002133

2

P3.3V_AUX

C843

1nF
3KV

P3.3V_AUX

C857

100nF
10V

C856

100nF
10V

MDC1_CON2_B1_MN

MDC1_CON2_B2_MN

14-D1

C860

R796

10000nF

10K

6.3V

nostuff

J29
HDR-2P-SMD

1
2

3

MNT1

4

MNT2

3711-000541

Type : angle

Mainboard to RJ11 cable

MDC

MDC
MDC
MDC

MDC
MDC
MDC
MDC

MDC
MDC

MDC

M4
HEAD
DIA
LENGTH

BA61-00784A

EMI1

CONTACT-PLATE-EMI

EMI

MDC
MDC

C

B

Internal : P1.5V_AUX
External : P3.3V_AUX

C

B

HDA3_MDC_SDO

HDA3_MDC_SYNC

HDA3_MDC_SDI1

HDA3_MDC_RST# HDA3_MDC_BCLK

14-D1

HDA3_MDC_SDI1_R_MN

14-D1
14-D2
14-D1

R739

10K

J28

HDR-2P-SMD

Samsung

Samsung

MNT2

4

MNT1

3

2
1

3711-000541

Type : angle

MDC to mainboard

R386

R383

10K

nostuff
nostuff

MDC1_CON1_B1_MN

MDC1_CON1_B2_MN

22

13
14
15
16
17
18

SOCK-12P-2R-SMD

Type : straight

B522 CIC21J601NE

CIC21J601NEB523

C842

1nF
3KV

Confidential

Confidential

A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

MDC CONNECTOR
MDC CONNECTOR

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A

6754

OF

COM-22C-015(1996.6.5) REV. 3

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

J2

HDR-4P-1R

D

CHGVR_DCJACK_JB_NS_MN

1
2
3
4

5

MNT1

6

MNT2

3711-007003

Type : angle

VCHG=12.602V@2600 Cell
VCHG=13.050V@2950 Cell

IPRECHG=0.27A
ICHG=2.56A FOR 5200mAh & 4000mAh

4

B3
HU-1M2012-121JT

B4
HU-1M2012-121JT

C

VREF BGATE

B

KBC3_PRECHG

KBC3_CHG4.2V

Low : [email protected](2950 Cell)

High : [email protected](2600 Cell)

RHU002N06

CHGVR_KBC3_PRECHG_RQ_MN

R531

R532

10K

475K
1%

nostuff

G_CHG

CHGVR_KBC3_CHG4.2V_RQ_MN

R523

10K

A

4

R68

200K
1%

R67

150K
1%

Q510

CHGVR_CHLIM_RQ_MN

3

D

G

1

S

2

G_CHG

CHGVR_VADJ_RQ_MN

R525

475K
1%

G_CHG

C4

100nF
25V

G_CHG

R69

10K
1%

R929

470K
1%

G

1

nostuff

R61

300K
1%

R63

30K
1%

D

S

G_CHG

C6

10nF
25V

EMC request

R48

24.3K
1%

R528

30K
1%

3

G_CHG

2

Q509
RHU002N06

Rtop
Rbot

C7

1nF
50V

nostuff

C58

10nF
16V

[email protected]

[email protected]

VREF

R53

200K
1%

AD_DC

BONN / CANNES Only

C12

R6

1000nF

100K

25V

1%

CHRVR_AD_DC_RCQ_MN

VDC_ADPT

[email protected]

VREF

G_CHG

nostuff
R56

300K
1%

R74

10K
1%

R70

30.1K
1%

M96
M96

VREF

VDC

G_CHGG_CHG

R77

200K
1%

R57

27.4K
1%

M92
M92

G_CHG

Adapter configuration

60W / 3.03A / 96%

Value

SEC Code

2007-007334

200K

27.4K 2007-007274

3

VDC_ADPT

Q5
AO4435L

1
2
3

R5

100K
1%

S1
S2
S3

Q502

AO4435L

8

8

D1

D1

7

7

D2

D2

6

6

D3

D3

5

D45G

D44G

EMI

C18

C17

100nF

100nF

25V 25V

D

3

G

S

1

2

C41

100nF
25V

G_CHG

C528

1000nF

25V

CHGVR_DCIN_NS_MN

CHGVR_ACSET_MN
CHGVR_DCSET_MN

R524

1%

Samsung

Samsung

C66

6.8nF

R66

50V

100
1%

C70

100nF

CHGVR_ICM_RC_MN

25V

CHGVR_VCOMP_RC_MN

Confidential

Confidential

G_CHG G_CHGG_CHG G_CHG

90W / 4.32A / 91.2%

Value

SEC Code

2007-007142

10K

2007-002910

30.1K

R54

300K
1%

R51

27.4K
1%

Q7
BSS84

C532

1000nF

25V

CHARGER & POWER MANAGEMENT

CHGVR_VDC_ADPT_RQ_NS_MN

1

S1

2

S2

3

S3

4

CHGVR_SGATE_RQ_MN

nostuff

nostuff
R13

R18

0

0

CHGVR_SGATE_MN

(1.26V)

CHGVR_VDDP_MN

5.1

CHGVR_VDD_MN

CHGVR_CHLIM_MN

CHGVR_VADJ_MN

CHGVR_ACLIM_MN

CHGVR_ICM_MN

CHGVR_ICOMP_MN

CHGVR_VCOMP_MN

C64

10nF
16V

R75

CHGVR_DCPRN_MN

10K
1%

R506

300K
1%

P3.3V_MICOM

R12

43.2K
1%

D

3

CHGVR_SGATE_RRQ_MN

G

1

CHGVR_P3.3V_MICOM_RQ_MN

S

Q6

2

RHU002N06

CHGVR_CSIP_NS_MN

U3
ISL6256AHRZ-T

CSIP

18

SGATE

25

DCIN

27

ACSET

28

DCSET

13

VDDP

26

VDD

7

CHLIM

9

VADJ

8

ACLIM

5

ICM

3

ICOMP

4

VCOMP

23

ACPRN

24

DCPRN

1203-004471

SHORT566

R1005-SHORT

EMC request

C500

100nF
25V

R8

10K

ADT3_SEL#

CSIN

BGATE

BOOT
UGATE
PHASE
LGATE

PGND

CSOP

CSON

VREF

EN

CELLS

GND

THERM

R515

R34

2.2

C35

CHGVR_CSIN_NS_MN

2019
17

CHGVR_BST_CHG_NS_MN

14
15

CHGVR_TG_CHG_NS_MN

16

CHGVR_PHASE_CHG_NS_MN

12

CHGVR_BG_CHG_NS_MN

11
21

CHGVR_CSOP_MN

22

CHGVR_CSON_MN

6
1

CHGVR_EN_MN

2
10

29

G_CHG

G_CHG

VDC

0.02

1W

1%

R33

22

100nF

25V

D508

3

1 2

R522

4.7

CHGVR_BST_CHG_RC_NS_MN

CELLS
VDD
GND
Float

BAT54A

2402-001144

EC500
68uF

25V

AL

BGATE

C522

100nF
25V

Cells N/B

C517

4700nF-X5R
25V

4
3

2

P3.3V_MICOM

R44

20K

G_CHG

SHORT500

INSTPAR

1%

ADT3_SEL#

(ACTIVE LOW)

3

C38

1nF
50V

C28

100nF
25V

G

2

G

4

2

7 8

D1

D2

S

1

D1

5

6

D2

S

3

nostuff

Q9-2
AP4232GM

G_CHG

2

Q9-1
AP4232GM

R17

10

C32

1nF
50V

C63

1nF
50V

L505

8.2uH

SIQ1250-8R2PF

R25

10

R32

22

CHGVR_PHASE_RC_MN

R65

1K
1%

DRAW

CHECK

APPROVAL

MODULE CODE

VDC_CHG

Q8

8

1

D1

S1

7

2

D2

S2

6

3

D3

S3

5

D44G

AO4435L

R513

0.02
1W
1%

R31

CHGVR_PHASE_RL_MN

22

C36

47nF
50V

VREF

470K 1%

R14

4700nF-X5R

100nF 25V

C514

C15

( 2.39V )

25V

25V

4700nF-X5R

4700nF-X5R

C14

C19

25V

4700nF-X5R

C22

P3.3V_MICOM

KBC3_CHGEN

2

3

D2

BAV99LT1

1

BAT3_SMDATA# KBC3_SMDATA#

BAT3_SMCLK# KBC3_SMCLK#

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

MP

REV 1.0

TITLE

HU-1M2012-121JT

HU-1M2012-121JT

25V

CHGVR_BAT3_SMCLK#_CBJ_MN

CHGVR_BAT3_DETECT#_CBJ_MN

CHGVR_BAT3_SMDATA#_CBJ_MN

C503

0.1nF

50V

C502

nostuff

0.1nF

50V

C501

0.1nF

nostuff

50V

2

3

BAV99LT1

D1

1

BONN-E

PWR_MV_Charger

CHARGER (ISL6256)

April 11, 2009 10:05:58 AM

1

J4

B501

B500

B504
BLM18PG181SN1

nostuff

B503
BLM18PG181SN1

B502
BLM18PG181SN1

R10

R9

BATT-CONN-7P

CHGVR_VDC_CHG_BJ_NS_MN

7
6
5
4
3
2

1

3711-007011

Type : angle

1%100
1%

100

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

BAT3_DETECT#

BAT3_SMDATA#

BAT3_SMCLK#

ELECTRONICS

BA41-01060A

OF

D

C

B

A

6755

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

P3.3V_AUX & P5.0V_AUX

D

P5.0V_FILT

nostuff

R568

27.4K
1%

R563

11.8K
1%

9
10
11
12
13
14
15
16

SYSVR_CS2_MN

P3.3V_MICOM

C555

10000nF

6.3V

2203-006852

SYSVR_EN2_MN

R564

0

SYSVR_VFB2_MN

EN5
EN3
PGOOD2
EN2
VBST2
DRVH2
LL2
DRVL2

R561

13K
1%

P5.0V_FILT

G_P3.3V

8

4

6

5

7

VO2

GND

VFB1

VFB2

VREF2

COMP2

U505

TPS51120RHBR

1203-004687

VIN

VREG3

VREG5

PGND2

V5FILT

CS2

19

21

17

20

18

R538

10K
1%

R79

5.1
1%

C75

1000nF

6.3V

G_P3.3V

SYSVR_VREF2_MN

1

3

2

VO1

COMP1

SKIPSEL

TONSEL

PGOOD1

VBST1

DRVH1

DRVL1

CS1

PGND1

22

23

24

SYSVR_CS1_MN

C546

6.3V

2203-006090

10000nF-X5R

P5.0V OCP(Typ) : 8.75A
P3.3V OCP(Typ) : 5.92A

C566

0.068nF

50V

VDC

C584

EC530

100nF

68uF

25V

25V

TONSEL VREF2

AL

5V / 3.3V : 280KHz / 430KHz

(4A)

C

B B

P3.3V_AUX

EC509
330uF

6.3V

2409-001175

17 mohm

P5.0V_ALW

R648
R647

KBC3_SUSPWR

C629

100nF
10V

P5.0V_AUX

0
0

R631

nostuff
nostuff

P5.0V_ALW_RQ_P5.0V_AUX_MN

R669

1K

C688

1%

10nF
25V

nostuff

3.9uH

SIQ1048-3R9

P5.0V_ALW

100K

1%

D

G

1

S

L509

R132

10

SYSVR_PHASE_P3.3V_RC_MN

Q524

AO6409L

C649

10nF

16V

3

R634

P5.0V_ALW_RCQ_P5.0V_AUX_MNKBC3_SUSPWR_RCQ_P5.0V_AUX_MN

10K

1%

Q525
RHU002N06

2

SYSVR_PHASE_P3.3V_NS_MN

R131

10

C166

1nF
50V

P5.0V_AUX

D4
D3

5 6
2

4

S

D1D2

1

3

G

C677

4700nF

6.3V

D1

78

Q515-1

D2

S

2

1

D1

56

D2

S

4

3

RdsOn 30mohm

Samsung

Samsung

C684

100nF
10V

Confidential

Confidential

AP4232GM

G

G

Q515-2

AP4232GM

C563

100nF
25V

SYSVR_BST_P3.3V_RC_NS_MN

SYSVR_TG_P3.3V_NS_MN

SYSVR_BG_P3.3V_NS_MN

P5.0V_STB

R571

3.3

G_P3.3V

SYSVR_BST_P3.3V_NS_MN

SYSVR_VFB1_MN

33

PAD

32
31
30
29

EN1

28
27
26

LL1

25

P5.0V_STB

nostuff

R559

0

G_P3.3V

G_P3.3V

SYSVR_BST_P5.0V_NS_MN

C539

1000nF

6.3V

C554

R557

0.033nF

43.2K

50V

1%

R556

R555

100K

11.8K
1%

1%

5.09V @ HDMI

C534

1nF
50V

G_P3.3V

C74

100nF

R78

3.3

25V

SYSVR_BST_P5.0V_RC_NS_MN

SYSVR_TG_P5.0V_NS_MN
SYSVR_PHASE_P5.0V_NS_MN
SYSVR_BG_P5.0V_NS_MN

AP6680AGM

SYSVR_EN1_MN

R530

47K
5%

G_P3.3V

R567

150K
1%

G_P3.3V G_P3.3V

Q512

C564

100nF
25V

5D16

7 8

D2 D3

G

4

S1

S2 S3

1 2

5 6

7 8

D1

D2 D3

G

4

S1

S2 S3

1 2

D4

Q511

AP6680AGM

3

D4

3

RdsOn 16.5mohm

R572

10K
1%

P3.3V_MICOM

VDC

C549

100nF
25V

R95

10

SYSVR_PHASE_P5.0V_RC_MN

C87

1nF
50V

12

3

R85

100K
1%

EC533
68uF

25V
AL

R90

10

KBC3_P5ALWON

D510

BAT54C

KBC3_SUSPWR

AUX3_PWRGD

EC503
68uF

25V
AL

L507

3.9uH

SIQ1048-3R9

P5.0V_ALW

C653

100nF
10V

EC507
330uF

6.3V

2409-001175

17 mohm

(6A)

D

C

INSTPAR

A

4

3

SHORT2

G_P3.3V

A

DRAW

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

01/09/2008

REV 1.0

TITLE

MP

BONN-E

PWR_MV_3V_5V

P3.3V_AUX / P5.0V_AUX

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

56 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

DDR2 Power

D

VDC

EC514

EC516

C741

D1

7 8

S

1

D1

5 6

S

3

C726

100nF
10V

2

D2

Q541-1
AP4232GM

D2

P0.9V

100nF
25V

DRAW

CHECK

APPROVAL

MODULE CODE

R717

10
5%

DDR2VR_PHASE_P1.8V_RC_MN

C756

1nF
50V

P5.0V_AUX

C

P3.3V_AUX

R271

10K

VRM3_DDR_PWRGD

KBC3_PWRON

KBC3_SUSPWR

AUX3_PWRGD

B

R258

R264

C3902

0.1nF
50V

Added by EMC

1%

1%1K

1K
1%

nostuff
nostuff

Tracking Discharge

A

4

P5.0V_STB

R299

0
5%

nostuff

fs = 340KHz

C472

10nF
50V

G_DDR2

R290

0
5%

C477

1000nF-X5R
25V

VDC

R270

750K
1%

SHORT569

R1608-SHORT

SHORT570

R1608-SHORT

U16

DDR2VR_CS_MN

DDR2VR_S5_MN

RT8207GQW

15

VDDP

14

VDD

16

CS

12

TON

13

PGOOD

10

S3

11

S5

4

MODE

6

DEM

3

GND

1

VTTGND

25

PAD

1203-005570

INSTPAR

SHORT3

UGATE

PHASE

BOOT

LGATE

PGND

VDDQ

VLDOIN

VTTSNS

NC1

NC2

VTTREF

G_DDR2

21

20

22

19

18

9

FB

8

23

24

VTT

2

7

17
5

DDR2VR_TG_P1.8V_NS_MN

DDR2VR_PHASE_P1.8V_NS_MN

R699

DDR2VR_BST_P1.8V_NS_MN

DDR2VR_BST_P1.8V_RC_NS_MN

3.3

DDR2VR_BG_P1.8V_NS_MN

DDR2VR_FB_MN

G_DDR2

DDR2VR_NC1_MN

MEM1_VREF

DDR2VR_NC2_MN

G_DDR2

5%

R252

43.2K
1%

R248

43.2K
1%

G_DDR2

C454

10000nF-X5R

6.3V

C453

33nF
16V

C727

100nF

25V

nostuff

C457

1nF
50V

R930

100K
1%

Q541-2
AP4232GM

G_DDR2

C725

10000nF-X5R

6.3V

nostuff

C452

10000nF-X5R

6.3V

G

2

G

4

C456

100nF
10V

nostuff

G_DDR2

Samsung

Samsung

Confidential

Confidential

R276

5.1
1%

C476

1000nF-X5R
25V

OCP=6.25A

DDR2VR_TON_NS_MN

Skip Mode

G_DDR2

DDR2VR_VDDP_MN

DDR2VR_VDD_MN

R709

20K
1%

DDR2VR_MODE_MN

DDR2VR_DEM_MN

3

68uF

25V
AL

R712

10
5%

MS Yang

MK Kim

BL Lee

undefined

68uF

25V
AL

L512

2.2uH

SIQ1048-2R2

2703-003232

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

P1.8V_AUX

(4A)

1.825V

EC520

C806

330uF

100nF

2.5V

10V

2409-001176

ESR=15mohm

TITLE

BONN-E

MP

PWR_MEMORY

DDR2 POWER

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

57 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

D

C

B

A

OF

COM-22C-015(1996.6.5) REV. 3

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

C

B

A

EC515

330uF

2409-001176

CHIPSET POWER(P1.5V & P1.05V)

D

R743

10

C771

1nF
50V

C738

100nF
25V

MK Kim

BL Lee

nostuff

SIQ1045-1R8PF

VDC

EC519

EC517

68uF

68uF

25V

25V

AL

AL

L511

1.8uH

CHSETVR_PHASE_P1.05V_RC_MN

D7

MMBD4148

1 3

R287

1K
1%

DATE

12/05/2008

DEV. STEP

REV

REV 1.0

LAST EDIT

P1.05V

(6A)

EC518

C731

330uF

100nF
25V

VCCP3_PWRGD

2.5V

2409-001176

C

B

KBC3_PWRON

A

TITLE

BONN-E

MP

PWR_MV_Cantiga

P1.5V_AUX, P1.05V

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

58 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

VDC

EC513

EC512
68uF

25V
AL

P1.5V

(6A)

C753

2.5V

100nF
25V

P1.05V Set : 1.053V

L510

2.2uH

SIQ1048-2R2

P2.0V_REF

R296

15K
1%

R294

100K
1%

G_P1.05V

C701

68uF

100nF

25V

25V

AL

R698

R693

10

10

5%

5%

C718

1nF
50V

[ near to FET ]

CHSETVR_PHASE_P1.5V_RC_MN

P1.5V SET : 1.510V

P5.0V_VCC

R295

20K
1%

8

7

5

6

D3D4

S1S223S3

1

8

S1S223S3

1

P5.0V_STB

Samsung

Samsung

G_P1.05V

Confidential

Confidential

4

[ near to IC ]

D1D2

Q535
AP6680AGM

G

4

D156D27D3D4

G

4

Q536
AP6680AGM

nostuff

R274

47

5%

C481

1000nF-X5R

6.3V

VDC

C474

1000nF-X5R
25V

CHSETVR_PHASE_P1.5V_NS_MN

C728

CHSETVR_BST_P1.5V_RC_NS_MN

100nF

25V

C470

0.022nF
50V

G_P1.05V

C479

1000nF-X7R

6.3V

SHORT563

CHSETVR_ILIM1_R_MN

G_P1.05V

R249

200K
1%

I LIMIT = 11.5A

G_P1.05V

3

CHSETVR_TG_P1.5V_NS_MN

CHSETVR_BST_P1.5V_NS_MN

5%

3.3

CHSETVR_BG_P1.5V_NS_MN

R259

R260

100K

100K

1%

1%

CHSETVR_FB1_MN

R261

43.2K
1%

CHSETVR_LDO_MN

C730

4700nF-X7R

6.3V

CHSETVR_REFIN2_MN

R1005-SHORT

CHSETVR_ONLDO_MN

CHSETVR_ILIM1_MN

R251

150K

1%

G_P1.05V

U17
MAX17020ETJ+

6

IN

15

DH1

16

LX1

17

BST1

18

DL1

9

BYP

10

OUT1

11

FB1

20

SECFB

19

VDD

7

LDO

3

VCC

32

REFIN2

4

ONLDO

12

ILIM1

21

AGND

1203-005563

SHORT505

G_P1.05V

INSTPAR

DH2

BST2

DL2

PGND

OUT2

PG2

PG1
RTC

REF

SKIP

LDOREFIN

ON1
ON2

TON

ILIM2

PAD

CHSETVR_TG_P1.05V_NS_MN

26
25

LX2

CHSETVR_BST_P1.05V_NS_MN

24

R706

23

CHSETVR_BG_P1.05V_NS_MN

22

30

28

13

CHSETVR_RTC_MN

5

P2.0V_REF

1

CHSETVR_SKIP_MN

29

8

14

CHSETVR_ON_MN

27

CHSETVR_TON_MN

2

CHSETVR_ILIM2_MN

31

33

G_P1.05V

CHSETVR_PHASE_P1.05V_NS_MN

5%

CHSETVR_BST_P1.05V_RC_NS_MN

100nF

3.3

C490

100nF
25V

G_P1.05V

SHORT558

P5.0V_VCC

Ton ; Open
fs ; 400KHz / 300KHz

CHSETVR_ILIM2_R_MN

R307

R293

200K

150K

1%

1%

I LIMIT = 11.4A

C737

25V

Q543

AP6680AGM

G_P1.05V

G_P1.05V

2

5 6

D1

D2 D3

G

4

S1

1 2

5 6

D1

D2 D3

G

4

S1

1 2

P3.3V

R1005-SHORT

P5.0V_VCC

nostuff

G_P1.05V

7 8

D4

S2 S3

3

7 8

D4

S2 S3

3

R250

100K
1%

DRAW

CHECK

APPROVAL

MODULE CODE

Q542
AP6680AGM

[ near to FET ]

R286

0
5%

R285

0
5%

nostuff

C745

100nF
25V

R737R703

10

C478

1000nF-X5R

6.3V

G_P1.05V

undefined

MS Yang

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

CPU VRM [INTERSIL]

D D

VDC

P3.3V

EC504
15uF

25V

2409-001173

S3

2 3

EC502
15uF

25V

2409-001173

Q508
AON6710L

S3

2 3

EC501
15uF

25V

2409-001173

R23

10
5%

CPUVR_PHASE1_CPU_RC_MN

C30

1nF
50V

VRM_VSUM
VRM_ISEN1

VRM_VCC_PRM

VRM_ISEN2

VDC

EC505
15uF

25V

2409-001173

R28

10
5%

CPUVR_PHASE2_CPU_RC_MN

C25

1nF
50V

VRM_VSUM
VRM_ISEN2

VRM_VCC_PRM

VRM_ISEN1

DRAW

CHECK

APPROVAL

MODULE CODE

R27

10
5%

R24

10
5%

R554

3.3K
5%

R55

3.3K
5%

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

REV

LAST EDIT

MPO104-R39

R539

10K
1%

MPO104-R39

R71

10K
1%

12/05/2008

L500

0.39uH

L501

0.39uH

REV 1.0

R547

5%

C547

220nF
16V

R62

5%

C68

220nF
16V

TITLE

MP

R536

1

1

5%

nostuff

R529

1

1

5%

nostuff

BONN-E

PWR_CPU_MV_ISL6266

CPUI VRM (IMVP6+)

April 11, 2009 10:05:58 AM

[Prodliger]
Routing Recommendation
should be met

- Hound tooth like

- GDN,VCC > 10VIA / pad

CPU_CORE

1

EC3
1000uF

2

2.5V

SAMSUNG

PART NO.

59 67

PAGE

4

3

ELECTRONICS

BA41-01060A

OF

EC2

330uF

2V
AL

nostuff

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

C

VRM3_CPU_PWRGD

B

A

CPU1_PSI#

VRM_VCC_PRM

C98

4.7nF
25V

R100

8.2K

5%

CPU1_VCCSENSE

CPU1_VSSSENSE

VRM_VCC_PRM

VRM_VSUM

R92

10K

1%

G_CPU

C92

R104

100K
1%

CPUVR_COMP_R_MN

P3.3V

R98

499
1%

R96

R105

15nF

C91

0.068nF
50V

CPUVR_FB_RC_MN

C94

R103

0.1nF

10K
1%

50V

R86

R83

4

1%

50V

CPUVR_RBIAS_R_MN

100K 1%

4.99K

CPUVR_NTC_R_MN

R101

CPUVR_FB2_RC_MN

5%

47

0

0

5%

5%

C76

0.33nF

R94

1K
1%

50V

2.2nF

G_CPU

47K

R566

10K

R97
R99

470K

5%

1%

C95

50V

G_CPU

CPUVR_PMON_MN

CPUVR_RBIAS_MN

CPUVR_VR_TT#_MN

CPUVR_NTC_MN

1%

CPUVR_SOFT_MN

CPUVR_OCSET_MN

CPUVR_VW_MN

CPUVR_COMP_MN

CPUVR_FB_MN

R93

1K1%

C84

0.33nF
50V

R560

C550

100nF
10V

Place near to L_Phase1
(1404-001152)

C83

100nF

25V

G_CPU

1

PGOOD

2

PSI#

3

PMON

4

RBIAS

5

VR_TT#

6

NTC

7

SOFT

8

OCSET

9

VW

10

COMP

11

FB

12

CPUVR_FB2_MN

FB2

CPUVR_VDIFF_MN

CPUVR_VSEN_MN

C561

1K

1%

C552
C553
R553

R552

1 2

CPUVR_VRM_VCC_PRM_RTH_MN

TH500
NTCG163JF103HT

C526

C524

100nF

100nF

25V

C39

1nF
50V

C34

1nF
50V

25V

5

D

Q503

G

AON6414L

4

G

4

nostuff

Q507

S1 S2

S3

AON6710L

1

2 3

5

D

S1 S2

S3

1

2 3

5

D

G

4

S1 S2

1

P5.0V

C527

C525

100nF

100nF

25V

25V

5

D

Q506

G

AON6414L

4

S1

S2 S3

1

2

3

5

D

G

4

S1 S2

S3

1

2 3

nostuff

5

D

G

4

S1 S2

1

2

R84

0

R81

0

R80

nostuff

CPUVR_DPRSTP#_MN

CPUVR_VR_ON_MN

CPUVR_CLK_EN#_MN

44

48

47

46

49

EP

3V3

VR_ON

CLK_EN#

DPRSTP#DROOP

DPRSLPVR

U5

ISL6266AHRZ-T

1203-005009

VO

VSEN

VDIFF

14

15

13

Samsung

Samsung

50V

CPUVR_RTN_MN

1nF

C82

0.22nF 50V

R562

1%2.49K

47nF

50V

220nF

16V

10K

1%

Confidential

Confidential

2.21k

RTN

DFB

18

17 45

16

CPUVR_DFB_MN

CPUVR_DROOP_MN

1%

VSS

VSUM

VIN

21

19

20

CPUVR_VIN_NS_MN

VDD

22

CPUVR_VDD_MN

G_CPU

5%

ISEN2

23

38

37

VDI139VDI240VDI341VDI442VDI543VDI6

VID0

BOOT1
UGATE1
PHASE1

PGND1

LGATE1

PVCC

LGATE2

PGND2
PHASE2
UGATE2

BOOT2

ISEN1

24

R543

C543

1000nF-X7R

6.3V

CHP3_DPRSLPVR
VCCP3_PWRGD

KBC3_VRON

CPU1_VID(6)
CPU1_VID(5)
CPU1_VID(4)
CPU1_VID(3)
CPU1_VID(2)
CPU1_VID(1)
CPU1_VID(0)

36
35
34
33
32
31
30
29
28
27
26
25

NC

G_CPU

VRM_ISEN1
VRM_ISEN2

P5.0V

10
1%

R73

CPUVR_BST1_CPU_RC_NS_MN

3.3
5%

CPUVR_BST1_CPU_NS_MN

CPUVR_TG1_CPU_NS_MN

CPUVR_BG1_CPU_NS_MN
CPUVR_PVCC_MN
CPUVR_TG2_CPU_NS_MN

CPUVR_BG2_CPU_NS_MN

CPUVR_BST2_CPU_RC_NS_MN

R60

3.3
5%

CPUVR_BST2_CPU_NS_MN

Keep away from Vphase

C56

220nF
25V

C51

220nF
25V

CPUVR_PHASE1_CPU_NS_MN

Q504

AON6710L

R64

C62

C61

220nF

220nF

16V

16V

CPUVR_PHASE2_CPU_NS_MN

Q505

AON6710L

1

CPU1_DPRSTP#

499

1%

VDC

R546

C545

10

22nF

1%

50V

G_CPU

SHORT502

INSTPAR

G_CPU

3

C

B

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

C

B

VCCP3_PWRGD

KBC3_PWRON

GFX3_VOLTID0

GFX3_VOLTID1

GFX3_VOLTID2

R526

R527

MMBD4148

D509

Ext. GFX Core Power [Semtech]

D3
BAT54A

EGFXVR_PGOOD_MN

R91

3.3

P5.0V

5%

3

1 2

R82

C78

1000nF-X7R

6.3V

Q11
AON6414L

EGFXVR_BST_GFX_RC_NS_MN

C85

100nF

25V

12.4K 1%

C181

0.27nF
50V

G

4

G

4

nostuff

BOM Table

5

D

S1

1S22 3

5

D

S1

1 2

S3

S2 S3

3

AON6710L

Q21

C93

100nF
25V

5

D

G

4

S1 S2

2 3

1

EGFXVR_PHASE_GFX_NS_MN

5

D

G

4

S1

1S22 3

P3.3V

Q10
BSS84

EGFX_CORE

R76

C72

51.1K

10nF

1%

25V

C535

0.47nF

R924

2.21k
1%

C538

6.8nF

G_EGFX

50V

50V

R544

61.9K
1%

EGFXVR_D0_D1_RC_MN

RD0

0

5%

nostuff

1%10K

13

R542

R545

R548

C537

100nF
10V

1%10K

1%

10K

M96

1%10K

nostuff

G_EGFX

G_EGFX

R917

R535

3.01K

5.11K

1%

1%

M96

M92

R534

R925

24.3K

14.7K
1%

1%

M96

M92

Samsung

Samsung

G_EGFX

P5.0V

R911

22K
1%

M92

R72

680K
1%

R550

2K
1%

M96

R916

0

3

M96

2

1

S

G

D

R58

470K

nostuff

1%

nostuff

VOUT Rising Time Adjustment

EGFXVR_VOUT_MN

10

EGFXVR_EN_MN

12

EGFXVR_G0_MN

14

EGFXVR_G1_MN

15

EGFXVR_D1_MN

7

EGFXVR_D0_MN

8

EGFXVR_FB_MN

9
6

17

G_EGFX

EGFXVR_D1_R_MN

R549

9.09K
1%

M96

RD1

U504
SC471MLTRT

VOUT
EN
G0
G1
D1
D0
FB
RTN
THERM

1203-004943

OCP ; 33.7A

C544

2.2nF
50V

nostuff

G_EGFX

SHORT1

INSTPAR

VCC

PGOOD

BST

ILIM

GND

P3.3V

R533

20K
1%

C536

100nF
10V

nostuff

3

11

EGFXVR_BST_GFX_NS_MN

2

16

DH

EGFXVR_TG_GFX_NS_MN

1

LX

13

EGFXVR_ILIM_GFX_NS_MN

4

DL

EGFXVR_BG_GFX_NS_MN

5

EC5ALEC4
15uF

25V

Q12

AON6414L

S3

Q22

AON6710L

S3

VDC

15uF

25V
AL

M96
M96

M96

MPO104-R39

R136

R135

10

10

5%

EGFXVR_PHASE_GFX_RC_MN

C179

1nF
50V

L508

0.39uH

EGFX_CORE

M96

EC534

EC5065%

C586

100nF
10V

330uF

330uF

2.5V

2.5V
AL

AL

2402-001316

2402-001316

ESR=15mohm ESR=15mohm ESR=15mohm

OCP ; 33.7A

EC6
330uF

2.5V
AL

2402-001316

D

C

B

G_EGFX

Confidential

Confidential

Power Table (by AMD Power Play)

Condition

A

High Performance 1.139V

UVD

Battery - Dual Display

Battery - Single Display

GFX3_VOLTID2

Reserved

Reserved

Reserved

Reserved

GFX3_VOLTID1

Reserved

Reserved

Reserved

GFX3_VOLTID0

1

1Reserved

0

M92-M2 LP

0.95V1

0.95V

0.95V

0.90V

4

GFX3_VOLTID2

CalculatedSpec

0.953V

0.953V

0.953V

0.908V

Reserved

Reserved

Reserved

Reserved

GFX3_VOLTID1

1

1

0 1

0

GFX3_VOLTID0

1

0

0

Spec

1.15V

1.10V

1.00V

0.90V

3

M96

Calculated

1.073V

0.997V

0.904V

Measured

1.1543V

1.0865V

1.0085V

0.9133V

DESIGN

CHECK

APPROVAL

MODULE CODE

2

nostuff

nostuff

nostuff

nostuff

nostuff

MS Yang

MK Kim

BL Lee

A

12/05/2008

REV 1.0

TITLE

MP

BONN-E

GFX_POWER

EXT. GFX VDDC (SC471M)

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

60 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

DATE

DEV. STEP

REV

LAST EDIT

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D D

P1.1V

P1.1V(External Gfx)

P5.0V_ALW

C C

56-B160-C4 61-C462-B2

KBC3_PWRON

VCCP3_PWRGD

P1.1V_PWRGD

Burst mode : R569 nostuff & R570 stuff

B B

Continuous mode : R569 stuff & R570 nostuff

5%

47K

R575

1K1%

R573

nostuff

P5.0V_ALW

Samsung

Samsung

R577

10K

1%

P3.3V

SHORT565

C104

22000nF-X5R
20%

6.3V

C103

22000nF-X5R
20%

6.3V

R1005-SHORT

C562

47nF
25V

P1.1V_SYNCH_MN

P1.1V_EN_MN

U507
ISL8014IRZ-T

1

VIN_1

2

VIN_2

3

VDD

5

EN

7

PG

4

SYNCH

6

NC_1

13

NC_2

16

NC_3

1203-005382

LX_1
LX_2

PGND_2
PGND_1

VFB

SGND_1
SGND_2

EP

14

P1.1V_PHASE_P1.1V_NS_MN

15

12
11

8

P1.1V_VFB_MN

9
10

17

L506

0.82uH

P1.1V_PHASE_R_MN

FB Ref =0.8V

R580

100K
1%

R579

12.7K
1%

R581

300K
1%

C573

0.047nF
50V

C105

22000nF-X5R
20%

6.3V

P1.1V

C106

22000nF-X5R
20%

6.3V

Confidential

Confidential

A A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

PWR_MV_Switched

P1.1V

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

61

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

67

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

3

24

1

Switched Power

D D

Switched Power On (P3.3V)

R107

100K
1%

P12.0V_ALW

D

3

G

1

S

2

P3.3V_AUX

G

1

Q16
RHU002N06

R108

470K
1%

P12.0V_ALW_RCQ_P3.3V_MN

D

3

Q17
RHU002N06

S

2

Q13
AP6680AGM

D4
D3

7 8
6
5

D1 D2

G

C117

4.7nF

25V

P3.3V

3

S2 S3
S1

1 2

4

C112

4700nF
10V

P5.0V_ALW_RQ_P5.0V_MN

KBC3_PWRON

P5.0V_STB

KBC3_PWRON_INV#

C

KBC3_PWRON

Switched Power On (P5.0V)

P5.0V_ALW

Q50
AO4435L

8

1

D1

S1

7

2

D2

S2

6

3

D3

S3

4

C287

R167

10nF

100K
1%

50V

P5.0V_ALW_RCQ_P5.0V_MN

R168

10K
1%

3

D

Q26
RHU002N06

G

1

S

2

D45G

C315

100nF
10V

P5.0V

SHORT554
SHORT555
SHORT556

C320

4700nF
10V

P5.0V_AUD

INSTPAR

INSTPAR
INSTPAR

C

Switched Power On (P1.8V)

P12.0V_ALW

P12.0V_ALW

B

P1.1V_PWRGD

VCCP3_PWRGD

0

R113

5%

0

R112

5%

VCCP3_PWRGD_RQ_P1.8V_MN

nostuff

R126

470K
1%

P12.0V_ALW_RQ_P1.8V_MN

D

3

G

1

S

2

Q23
RHU002N06

Q19
RHU002N06

R129

200K
1%

P12.0V_ALW_RCQ_P1.8V_MN

D

3

G

1

S

2

Confidential

Confidential

P1.8V_AUX

Samsung

Samsung

Q517
AP6680AGM

8

D4

7

D3
D2
D1

5 6

G

C589

6.8nF
50V

P1.8V

VDC

S3
S2

2 3

S1

4

C588

1

4700nF-X5R
10V

R910

30.1K
1%

VDC_RCQZD_P12.0V_ALW_MN

C610

1nF

50V

ZD500
BZX84C12L

3

1

Q518
MMBT3904

2

3

C594

1

10000nF

25V

P12.0V_ALW

B

A A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

PWR_MV_SWITCHED

SWITCHED POWER

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

62 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

R653

10K

C C

B

KBC3_PWRON_INV#

KBC3_SUSPWR

P3.3V

D

3

G

1

S

2

R678

10

Q532
RHU002N06

P3.3V_GFX

R931

10

Samsung

Samsung

D

3

Q553
RHU002N06

G

1

S

2

1%

KBC3_SUSPWR_RQ_DISCHG_MN

nostuff

P5.0V

R680

1K
1%

DISCHG_P5.0V_RQ_MNDISCHG_P3.3V_RQ_MN DISCHG_P1.5V_RQ_MN DISCHG_P1.05V_RQ_MN

D

3

Q550
RHU002N06

G

1

S

2

POWER DISCHARGER

P5.0V_STB P5.0V_AUX

R658

1K
1%

DISCHG_P5.0V_AUX_RQ_MN

D

3

Q529
RHU002N06

G

1

S

2

nostuff
nostuff

R752

49.9
1%

DISCHG_P1.8V_RQ_MN DISCHG_P1.1V_RQ_MN

D

3

Q545
RHU002N06

G

1

S

2

D

G

1

S

R655

100K
1%

DISCHG_P5.0V_STB_RQ_MN

3

Q528
RHU002N06

2

nostuff
nostuff

EGFX_CORE P1.05V

R923

10

D

3

Q552
RHU002N06

G

1

S

2

P1.8V_AUX

R663

49.9
1%

DISCHG_P1.8V_AUX_RQ_MN DISCHG_P3.3V_AUX_RQ_MN

D

3

Q551
RHU002N06

G

1

S

2

nostuff
nostuff

P1.5V

R682

10
1%

D

3

Q533
RHU002N06

G

1

S

2

P1.1VP1.8V

R747

10
1%

D

3

Q544
RHU002N06

G

1

S

2

P3.3V_AUX

G

1

D

G

1

S

R677

1K

D

3

Q531
RHU002N06

S

2

nostuff
nostuff

R683

10

3

Q534
RHU002N06

2

D

B

nostuff
nostuff

Confidential

Confidential

nostuff
nostuff

nostuff
nostuff

nostuff
nostuff

nostuff
nostuff

A A

DRAW

CHECK

APPROVAL

MODULE CODE

4

3

2

MS Yang

MK Kim

BL Lee

undefined

DATE

DEV. STEP

LAST EDIT

12/05/2008

REV 1.0

TITLE

MP

BONN-E

PWR_MV_DISCHARGER

DISCHARGING LOGIC

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.REV

BA41-01060A

6763

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

2 USB PORT & POWER S/W SUB B’D

D

USB3_P6-_SUB

USB3_P6+_SUB

C

USB3_P10-_SUB

USB3_P10+_SUB

B

EC1

C3

100uF

100nF

16V
AS

10V

G_SUB

4

213

B1
ACM2012-900-2P-T

B2
ACM2012-900-2P-T

4

213

USB3_P6-_SUB_B_MN
USB3_P6+_SUB_B_MN

USB3_P10-_SUB_B_MN
USB3_P10+_SUB_B_MN

LID_SWITCH (Bonn only)

P3.3V_SUB

U532
HED53XXU12

1

C3912

1000nF-X5R

6.3V

SUPPLY

3

GND

1009-001046

OUTPUT

2

P5.0V_USB_SUB

C1

C2

100nF

0.033nF
50V

10V

nostuff
nostuff

G_SUB

Samsung

Samsung

LID3_SWITCH#_B_SUB

J1
JACK-8P-LED-MNT

1

PWR0

2

USB0-

3

USB0+

4

GND1

5

PWR1

6

USB1-

7

USB1+

8

GND2

9

MNT1

10

MNT2

11

MNT3

12

MNT4

3722-002601

Type : angle

Power ON LED

LTST-C193TBKT-AC

G_SUB

LED1_P3.3V_PWON_MN

LED500

1

2

Put this LED located near PWRSW from ME recommedation

Power LED, Blue color

R505

475

P3.3V_SUB

1%

SUB TO MAIN USB CONN

P3.3V_SUB

USB3_P6-_SUB

USB3_P6+_SUB

USB3_P10-_SUB

USB3_P10+_SUB

KBC3_PWRSW#_SUB

LID3_SWITCH#_B_SUB

P5.0V_USB_SUB

C5

100nF

10V

G_SUB

MT2001

RMNT-25-70-1P

G_SUB

Type : angle

G_SUB

MT2002

RMNT-25-70-1P

G_SUB

J3
HDR-12P-1R-SMD

1
2
3
4
5
6
7
8
9
10
11
12

3711-002046

D

C

B

G_SUB

Confidential

Confidential

Bonn : stuff
Canne : nostuff

A

4

BONN
BONN

SW-TACT-4P

3404-001311

Power Switch Button

KBC3_PWRSW#_SUB

SW500

3

1 2

3 4

G_SUB

DESIGN

CHECK

APPROVAL

MODULE CODE

2

USB sub board mount hole

12/05/2008

REV 1.0

TITLE

MP

BONN-E

SUB BOARD1

2 USB & POWER SW

April 11, 2009 10:05:58 AM

DATE

MS Yang

DEV. STEP

MK Kim

REV PART NO.

BL Lee

LAST EDIT

SAMSUNG

ELECTRONICS

BA41-01060A

64 67

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

OF

A

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

D

P5.0V_ODD

C60

C59

C54

C

B

A

100nF
10V

G_ODD

SUB TO MAIN SATA ODD CONN

P5.0V_ODD

SAT1_ODD_TXP_SUB
SAT1_ODD_TXN_SUB

SAT1_ODD_RXN_SUB
SAT1_ODD_RXP_SUB

10000nF-X5R

4

10000nF-X5R

6.3V6.3V

nostuff

SATA ODD & LID SW SUB BOARD

SATA ODD SUB BOARD

C55

C53

100nF100nF

SAT1_ODD_TXP_SUB

10V

10V

SAT1_ODD_TXN_SUB
SAT1_ODD_RXN_SUB

SAT1_ODD_RXP_SUB

G_ODD

Samsung

Samsung

3708-002190

12
11
10
9

G_ODD

8
7
6
5
4
3
2
1

CONN-12P-FPC
J500

Type : angle

Confidential

Confidential

SATA ODD CONN

J8
CDROM-SATA-13P

P2

P5V_1

P3

P5V_2

S2

TX+

S3

TX-

S5

RX-

S6

RX+

P1

DP

P4

MD

S1

GND_1

S4

GND_2

S7

GND_3

P5

GND_4

P6

GND_5

14

MNT1

15

MNT2

3710-002635

Type : angle

MT2008

RMNT-25-70-1P

G_ODD G_ODD

ODD sub board mount hole

3

MT2007

RMNT-25-70-1P

P3.3V_LID_SUB

C515

1000nF-X5R

6.3V

G_LID_SUB

HDR-4P-SMD

MNT1
MNT2

3711-000922

Type : angle

J508

1
2
3
4

LID SWITCH SUB BOARD (Canne only)

U503

HED53XXU12

1

SUPPLY

2

OUTPUT

3

GND

1009-001046

P3.3V_LID_SUB

5
6

G_LID_SUB

DRAW

CHECK

APPROVAL

MODULE CODE

2

LID3_SWITCH#_SUB

LID3_SWITCH#_SUB

DATE

MS Yang

DEV. STEP

MK Kim

REV

BL Lee

LAST EDIT

undefined

12/05/2008

REV 1.0

TITLE

MP

MT2009

RMNT-25-60-1P

G_LID_SUB

BONN-E

SUB BOARD2

SATA ODD SUB BOARD

April 11, 2009 10:05:58 AM

1

CANNES
CANNES
CANNES

Bonn : nostuff
Cannes : stuff

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

65 67

PAGE

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

D

C

B

A

OF

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4

3

2

1

Mainboard Mount ((30,80)x9), (30,90)x9), (25,70)x1))

D

C

B

A

P1.5V

C3829

1nF
50V

P5.0V

C3857

100nF
10V

P5.0V_ALW

P3.3V

C519

1nF
50V

P3.3V

C494

1nF
50V

VDC

C854

100nF
25V

VDC

C99

100nF
25V

P3.3V_AUX

C101

100nF
10V

C3848

100nF
10V

P1.5V

P1.5V

C3831

C3830

1nF

1nF

50V

50V

P5.0V

P3.3V P3.3V

C3836

C3858

100nF

100nF
10V

10V

P5.0V_ALW

P5.0V_ALW

C3849

100nF
10V

P3.3V

P3.3V P3.3V

C455

1nF
50V

P3.3V

C3718

1nF
50V

VDC

VDC

C849

100nF
25V

P5.0V_AUD

VDC

C3247

100nF

VDC_ADPT

AD_DC

C13

100nF
25V

P1.5V

P1.5V

C3832

1nF
50V

P3.3V

P3.3V

C3837

100nF
10V

P5.0V_ALW

C3850

100nF
10V

C243

C3369

1nF

1nF

50V

50V

P3.3V

C50

C107

1nF

1nF

50V 50V

50V

VDC

C858

C67

100nF

100nF

25V

25V

P5.0V_AUD

C852

C855

100nF

100nF

10V

10V

VDC_CHG

C504

C511

100nF

100nF

25V

25V

4

C3833

1nF
50V

C3838

100nF
10V

C3851

100nF
10V

P5.0V_AUD

P5.0V_ALW

P1.5V

C3834

1nF
50V

P3.3V

C3839

100nF
10V

P5.0V_ALW

C3852

100nF
10V

P3.3V

C922

1nF
50V

P3.3V

C851

1nF
50V

VDC

C37

100nF
25V

C853

100nF
10V

P3.3V

C774

1nF
50V

P1.5V

C3835

1nF
50V

C3841

100nF
10V

P5.0V_ALW

P3.3V

C698

1nF
50V

P3.3V

C585

1nF

VDC

C548

100nF
25V

P5.0V_AUD

C850

100nF
10V

P3.3V

C894

1nF
50V

P3.3V

C3853

100nF
10V

P5.0V_AUD

VDC

C3869

100nF
25V

C3842

100nF
10V

P3.3V_AUX

P3.3V

C3828

1nF
50V

C3370

1nF
50V

VDC

C26

100nF
25V

C3608

100nF
10V

P3.3V

C768

1nF
50V

VDC

VDC

C3868

C3870

100nF

100nF

25V

25V

P3.3V

P3.3V

C3844

C3843

100nF

100nF
10V

10V

P3.3V_AUX

P3.3V_AUX

C3862

C3861

100nF

100nF

10V

10V

P3.3V

P3.3V

C3399

1nF
50V

P3.3V

P3.3V

C129

1nF
50V

Samsung

Samsung

VDC

VDC

C716

100nF
25V

P5.0V_AUD

P5.0V_AUD

C827

100nF
10V25V

Confidential

Confidential

CPU_CORE

CPU_CORE

C10

1nF
50V

P5.0V

C3855

100nF
10V

P5.0V_ALW

P3.3V_AUX

C3864

100nF
10V

P3.3V

C371

1nF
50V

P3.3V

C668

1nF
50V

P5.0V

P5.0V_ALW

C3846

100nF
10V

P3.3V_AUX

CPU_CORE

P1.05V

C3856

100nF
10V

C510

1nF
50V

C645

1nF
50V

P5.0V

C3854

100nF
10V

P5.0V_ALW

C3845

100nF
10V

C3863

100nF
10V

C73

1nF
50V

C451

1nF
50V

Add for EMC (5th Layer), 2008.11.19

VDC

VDC

C3589

C838

C743

100nF
25V

C667

100nF
10V

C47

100nF
10V

P5.0V_AUD

G_AUD

100nF
25V

C929

100nF
10V

C805

1nF
50V

100nF
25V

P3.3V_AUX

C625

100nF
10V

C807

1nF
50V

G_AUD

Add for EMC (Bottom), 2008.11.19

3

P5.0V

C3859

100nF
10V

C3847

100nF
10V

C3866

C3865

100nF

100nF
10V

10V

Add for EMC , 2009.01.06

P5.0V

C3860

100nF
10V

P3.3V_AUXP3.3V_AUX

P1.8V_AUX

P3.3V_LEDP3.3V

EMI

EMI13

CONTACT-PLATE-EMI

EMI

EMI8

CONTACT-PLATE-EMI

C3867

100nF
10V

P1.8V_AUX

C498

1nF
50V

P3.3V_LED

C487

1nF
50V

EMI

EMI4

CONTACT-PLATE-EMI

EMI

EMI9

CONTACT-PLATE-EMI

P1.8V_AUX

C914

1nF
50V

P3.3V_LED

C830

1nF
50V

EMI

EMI10

CONTACT-PLATE-EMI

MT2

RMNT-30-90-1P

MT15

RMNT-30-90-1P

P1.8V_AUX

C797

C932

1nF

1nF

50V

50V

P3.3V_LED

C3171

C3311

1nF

1nF
50V

50V

EMI

EMI

EMI6

EMI12

CONTACT-PLATE-EMI

CONTACT-PLATE-EMI

EMI

EMI

CONTACT-PLATE-EMI

EMI11

CONTACT-PLATE-EMI

EMI14

Add for EMC , 2009.01.07

2

MT13

RMNT-30-90-1P

RMNT-30-80-1P

C3787

1nF
50V

P3.3V_LED

C3694

1nF
50V

P5.0V_STB

P3.3V_MICOM

nostuff

nostuff
nostuff

nostuff
nostuff
nostuff

nostuff

nostuff

nostuff

MT1

RMNT-30-90-1P RMNT-30-90-1P

MT8

MT11

RMNT-30-90-1P

P1.8V_AUX

C3695

1nF
50V

P3.3V_LEDP3.3V P3.3V_LED

C3414

1nF
50V

P5.0V_STB

C3884

100nF
25V

P1.8V_AUXP1.8V_AUX

P3.3V_LED

P5.0V_STB

C3876

100nF
25V

RMNT-30-90-1P

C931

1nF
50V

C3193

1nF
50V

P3.3V_MICOM

C3885

25V

DRAW

CHECK

APPROVAL

MODULE CODE

C3886

100nF100nF
25V

MS Yang

MK Kim

BL Lee

C3557

1nF
50V

MT14

RMNT-30-90-1P

MT504

RMNT-25-70-1P

Top : (30,80) x 9
Bot : (30,90) x 9

P0.9V

C450

1nF
50V

MT10

MT12

P0.9V

P3.3V_LED

C3592

C3758

1nF1nF
50V

50V

Add for EMC (Bottom), 2008.11.19

P5.0V_STB

P5.0V_STB

C3878

C3877

100nF

100nF

25V

25V

C3887

100nF
25V

12/05/2008

REV 1.0

P3.3V_MICOM

TITLE

MP

P3.3V_MICOM

DATE

DEV. STEP

REV

LAST EDIT

C3879

100nF
25V

C3888

100nF
25V

P0.9V

C471

1nF
50V

P3.3V_LED

C3627

1nF
50V

nostuff
nostuff
nostuff
nostuff

P5.0V_STB

C3880

100nF
25V

P3.3V_MICOM

BONN-E

ICT PORT
ICT PORT

April 11, 2009 10:05:58 AM

CPU_CORE

CPU_CORE

C509

C79

100nF

1nF
50V

10V

Add for EMC (Top), 2008.11.19

P5.0V_STB

P5.0V_STB

C3881

C3882

100nF

100nF
25V

25V

C3889

100nF
25V

C3890

100nF
25V

Add for EMC , 2009.02.02

SAMSUNG

PART NO.

PAGE

1

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

P5.0V_STB

C3883

100nF
25V

P3.3V_MICOMP3.3V_MICOM

C3891

100nF
25V

ELECTRONICS

BA41-01060A

OF

D

C

B

A

6766

SAMSUNG PROPRIETARY

THIS DOCUMENT CONTAINS CONFIDENTIAL

PROPRIETARY INFORMATION THAT IS

SAMSUNG ELECTRONICS CO’S PROPERTY.

DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS

EXCEPT AS AUTHORIZED BY SAMSUNG.

4 3 2

1

D D

SIM3_C1
SIM3_C2
SIM3_C3
SIM3_C6
SIM3_C7
SPK5_L_P
SPK5_L_M
SPK5_R_P
SPK5_R_M
CPU1_NMI
CPU1_TCK
CPU1_TDI
CPU1_TMS
CRT3_RED
FAN5_VDD
SMB3_CLK
SPI3_CLK
VRM_VSUM
ADT3_SEL#
AUD3_SPKR
CLK3_FM48
CPU1_BNR#
CPU1_INTR
CPU1_PSI#
CPU1_RS0#
CPU1_RS1#

C C

B B

CPU1_RS2#
CPU1_SLP#
CPU1_SMI#
CRT3_BLUE
KBC3_A20G

KBC5_TCLK
MCD3_SDWP
SMB3_DATA
SPI3_CS0#
SPI3_MISO
SPI3_MOSI
THM3_STP#
VRM_ISEN1
VRM_ISEN2
WLON_LED#
AUD3_SHDN#
AUX3_PWRGD
PLT3_RST#
CLK3_PWRGD
CLK3_USB48
CPU1_A20M#
CPU1_BPRI#
CPU1_BREQ#
CPU1_BSEL0
CPU1_BSEL1
CPU1_BSEL2
CPU1_D#(0)
CPU1_DBSY#
CPU1_DRDY#
CPU1_FERR#
CPU1_HITM#
CPU1_INIT#
CPU1_LOCK#
CPU1_TRDY#
CPU1_TRST#
CRT3_GREEN
CRT3_HSYNC
CRT3_VSYNC
EXP3_CPPE#
KBC3_CHGEN
KBC3_PWRGD
KBC3_PWRON
KBC5_TDATA
LAN3_CTL12
MCD3_SDCD#
MCD3_SDCLK
MCD3_SDCMD
MCH1_HVREF
PEX3_WAKE#
AUD3_GPIO1#

BAT3_SMCLK#
CHP3_GPIO18
CHP3_GPIO20
CHP3_SERIRQ
CHP3_SLPS4#
CHP3_SLPS5#
CLK3_DBGLPC
CPU1_DEFER#
CPU1_DPSLP#
CPU1_IGNNE#
CPU1_VID(0)
CPU1_VID(1)
CPU1_VID(2)
CPU1_VID(3)
CPU1_VID(4)
CPU1_VID(5)
CPU1_VID(6)
CRT3_DDCCLK
EXP3_CPUSB#
EXP3_PERST#
KBC3_BKLTON
KBC3_PRECHG
KBC3_PWRSW#
KBC3_RFOFF#
KBC3_SCLED#
KBC3_SMCLK#
KBC3_SUSPWR
KBC5_KSI(0)
KBC5_KSI(1)
KBC5_KSI(2)
KBC5_KSI(3)
KBC5_KSI(4)
KBC5_KSI(5)
KBC5_KSI(6)
KBC5_KSI(7)
KBC5_KSO(0)
KBC5_KSO(1)
KBC5_KSO(2)
KBC5_KSO(3)
KBC5_KSO(4)
KBC5_KSO(5)
KBC5_KSO(6)
KBC5_KSO(7)
KBC5_KSO(8)
KBC5_KSO(9)
LPC3_LAD(0)
LPC3_LAD(1)
LPC3_LAD(2)
LPC3_LAD(3)
MCH3_BKLTEN
SMB3_ALERT#
THM3_ALERT#
VCCP3_PWRGD

Samsung

Samsung

VRM_VCC_PRM
BAT3_DETECT#
BAT3_SMDATA#
CHP3_BIOSWP#
CHP3_CPUSTP#
CHP3_PCISTP#
CHP3_RTCRST#
CLK1_DREFCLK
CPU1_CPURST#
CPU1_DPRSTP#
CPU1_STPCLK#
CPU2_THERMDA
CPU2_THERMDC
CRT3_DDCDATA
EXP3_CLKREQ#
FAN3_FDBACK#
HDA3_AUD_SDO
HDA3_MDC_SDO
ITM3_CLKREQ#
KBC3_CPURST#

Confidential

Confidential

KBC3_EXTSMI#
KBC3_NUMLED#
KBC3_P5ALWON
KBC3_PWRBTN#

KBC3_RSMRST#
KBC3_RUNSCI#
KBC3_SMDATA#
KBC3_SPKMUTE
KBC5_KSO(10)
KBC5_KSO(11)
KBC5_KSO(12)
KBC5_KSO(13)
KBC5_KSO(14)
KBC5_KSO(15)
LID3_SWITCH#
LPC3_LFRAME#
MCD3_SDDATA0
MCD3_SDDATA1
MCD3_SDDATA2
MCD3_SDDATA3
MCH1_HXSWING
MCH3_CLKREQ#
MCH3_EXTTS0#
MCH3_EXTTS1#
MIN3_CLKREQ#
PCI3_CLKRUN#
SIM3_DETECT#
AUD5_SENS_HP#
CHP3_CL_CLK_0
CHP3_DPRSLPVR
CHP3_PM_SYNC#
CHP3_SATALED#
CHP3_SUSSTAT#
HDA3_AUD_BCLK
HDA3_AUD_RST#
HDA3_AUD_SDI0
HDA3_AUD_SYNC
HDA3_HDMI_SDO
HDA3_MDC_BCLK
HDA3_MDC_RST#
HDA3_MDC_SDI1
HDA3_MDC_SYNC
ITP3_DBRESET#
KBC3_CAPSLED#

KBC3_WAKESCI#
KBC5_P5ALWON#
LCD3_EDID_CLK
MCH3_HDMI_CLK
MCH3_ICHSYNC#
MCH3_LCDVDDON
PEG5_HDMI_CLK
PLT3_RST_ORG#
VGA5_HDMI_HPD
AUD3_DMIC_CLK1
AUD5_HP_O_LEFT
AUD5_MIC1_LEFT
AUD5_MIC2_LEFT
AUD5_MIC2_VREF
AUD5_SENS_MIC#
CHP3_BIOS_CRI#
CHP3_CL_DATA_0
CHP3_CL_RST_0#
CHP3_INTRUDER#
CLK3_PCLKMICOM
CPU3_THRMTRIP#
HDA3_HDMI_BCLK
HDA3_HDMI_RST#
HDA3_HDMI_SDI2
HDA3_HDMI_SYNC
KBC3_CHKPWRSW#
KBC3_LED_ACIN#
KBC3_USBPWRON#
LCD3_EDID_DATA
MCH3_HDMI_DATA
PEG5_HDMI_DATA
TPD5_L_BUTTON#
TPD5_R_BUTTON#
VGA1_HDMI_HPD#
VRM3_CPU_PWRGD
VRM3_DDR_PWRGD

AUD3_DMIC_DATA1
AUD5_HP_O_RIGHT
AUD5_MIC1_RIGHT
AUD5_MIC2_RIGHT
CHP3_ME_RTCRST#
KBC3_BLCKPWRSW#
KBC3_LED_POWER#
KBC3_PWRON_INV#
KBC3_PWRSW#_SUB
AUD5_LINE_O_LEFT
CHP3_SATACLKREQ#
KBC3_LED_CHARGE#
KBC3_THERM_SMCLK
LID3_SWITCH#_SUB
VGA3_HDMI_HPD_LV
AUD5_LINE_O_RIGHT
KBC3_THERM_SMDATA
AUD5_MIC1_VREF_LEFT
AUD5_MIC1_VREF_RIGHT

AD_DC
AD_DC
AD_DC
AD_DC
CPU_CORE
CPU_CORE
CPU_CORE
CPU_CORE
G_AUD
G_AUD
G_AUD
G_AUD
G_CHG
G_CHG
G_CHG
G_CHG
G_CPU
G_CPU
G_CPU
G_CPU
G_MIC
G_MIC
G_MIC
G_MIC
G_ODD
G_ODD
G_ODD
G_ODD
G_SUB
G_SUB
G_SUB
G_SUB
G_DDR2
G_DDR2
G_DDR2
G_DDR2
G_P1.05V
G_P1.05V
G_P1.05V
G_P1.05V
LCD_VDD3V
LCD_VDD3V
LCD_VDD3V
LCD_VDD3V
MEM1_VREF
MEM1_VREF
MEM1_VREF
MEM1_VREF
P0.9V
P0.9V
P0.9V
P0.9V
P1.5V
P1.5V
P1.5V
P1.5V
P5.0V
P5.0V

P5.0V
P5.0V
PRTC_BAT
PRTC_BAT
PRTC_BAT
PRTC_BAT
P1.2V_LAN
P1.2V_LAN
P1.2V_LAN
P1.2V_LAN
P1.5V_AUX
P1.5V_AUX
P1.5V_AUX
P1.5V_AUX
P1.5V_EXP
P1.5V_EXP
P1.5V_EXP
P1.5V_EXP
P1.8V_AUX
P1.8V_AUX
P1.8V_AUX
P1.8V_AUX
P1.8V_LAN
P1.8V_LAN
P1.8V_LAN
P1.8V_LAN
P2.1V_REF
P2.1V_REF
P2.1V_REF
P2.1V_REF
P3.3V_EXP
P3.3V_EXP
P3.3V_EXP
P3.3V_EXP
P3.3V_LED VDD_LED
P3.3V_LED
P3.3V_LED
P3.3V_LED
P3.3V_MCD
P3.3V_MCD
P3.3V_MCD
P3.3V_MCD
P3.3V_SUB
P3.3V_SUB
P3.3V_SUB
P3.3V_SUB
P5.0V_ALW
P5.0V_ALW
P5.0V_ALW
P5.0V_ALW
P5.0V_AMP
P5.0V_AMP
P5.0V_AMP
P5.0V_AMP
P5.0V_AUD
P5.0V_AUD
P5.0V_AUD
P5.0V_AUD
P5.0V_AUX
P5.0V_AUX
P5.0V_AUX
P5.0V_AUX
P5.0V_ODD
P5.0V_ODD
P5.0V_ODD
P5.0V_ODD
P5.0V_STB
P5.0V_STB
P5.0V_STB
P5.0V_STB
P5.0V_VCC
P5.0V_VCC
P5.0V_VCC
P5.0V_VCC
P1.05V_PEG
P1.05V_PEG
P1.05V_PEG

P1.05V_PEG
P12.0V_ALW
P12.0V_ALW
P12.0V_ALW
P12.0V_ALW
P4.75V_AUD
P4.75V_AUD
P4.75V_AUD
P4.75V_AUD
P3.3V_MICOM
P3.3V_MICOM
P3.3V_MICOM
P3.3V_MICOM
P3.3V_AUX_EXP
P3.3V_AUX_EXP
P3.3V_AUX_EXP
P3.3V_AUX_EXP
P5.0V_AUX_USB
P5.0V_AUX_USB
P5.0V_AUX_USB
P5.0V_AUX_USB
VDC
VDC
VDC
VDC
VCC_CRT
VCC_CRT
VCC_CRT
VCC_CRT
VDC_CHG
VDC_CHG
VDC_CHG
VDC_CHG
VDD_LED

VDD_LED
VDD_LED
VDC_ADPT
VDC_ADPT
VDC_ADPT
VDC_ADPT

EGFX_BBP
EGFX_CORE
G_EGFX
G_P3.3V
P1.05V
P1.1V
P1.1V_DPE
P1.8V
P1.8V_A2VDDQ
P1.8V_AVDD
P1.8V_DPE
P1.8V_VDDDI
P3.3V_GFX

A

4 3

DESIGN

CHECK

APPROVAL

MODULE CODE

2

MS Yang

MK Kim

BL Lee

DATE

DEV. STEP

REV

LAST EDIT

12/05/2008

REV 1.0

TITLE

BONN-E

MP

TEST POINT
TEST POINT

April 11, 2009 10:05:58 AM

1

SAMSUNG

ELECTRONICS

PART NO.

BA41-01060A

67 67

PAGE OF

D:/Users/mobile39/mentor/BONN-E/BONN-E_mp10

A
