WELCOME
WELCOME
Thank you for choosing U.S. Cellular.
This guide will introduce you to the features and
functions of your new phone.
For assistance, go to http://www.uscellular.com/.
or contact Customer Care at 1-888-944-9400.
NOTE: Screen images and icons are simulated. Actual display may
vary. Instructions in this guide may change depending on the
software version on your device. All procedures begin in portrait
mode, with phone open unless otherwise noted.
8
9
7
6
54
3
2
1
YOUR DEVICE
4
FRONT AND BACK FEATURES
1. HEADSET
CONNECTOR
2. FRONT FACING
CAMERA
3. DISPLAY
4. MENU KEY
5. HOME KEY
6. BACK KEY
7. SEARCH KEY
8. EARPIECE
9. CAMERA LENS
10. FLASH
YOUR DEVICE
5
YOUR DEVICE
2
3
1
SIDE FEATURES
1. VOLUME KEY
2. CHARGER/USB
CONNECTOR
3. POWER/LOCK KEY
NOTE: The microSD card slot is
located under the battery
cover.
YOUR DEVICE
6
BATTERY INSTALLATION/REMOVAL
Your device is powered by a rechargeable, standard
Li-Ion battery.
NOTE: Although the battery comes partially charged, you must fully
charge this battery before using your phone for the first.
WARNING: Use only Samsung-approved charging devices and
batteries. Samsung accesories are designed to maximize
battery life. Using other accessories may invalidate your
warranty and may cause damage.
Installing the Battery
Release Latch
1. Hold the device firmly and locate the cover
release latch.
2. Place your fingernail in the opening and firmly
“pop” the cover off the device (similar to a
soda can).
3. Slide the battery into the compartment (3) so
that the tabs on the end align with the slots
at the bottom of the phone, making sure the
connectors align.
4. Gently press down to secure the battery (4).
5. Replace the battery cover by sliding it back into
place and snapping the edges securely at all
four corners.
Removing the Battery
1. Place your fingernail in the opening on the
cover release latch and firmly “pop” the cover
off the device (similar to a soda can).
2. Place your finger into the battery groove.
3. Grip the battery at the top end (5) and lift it up
and out of the battery compartment (6).
Battery Insertion Battery Removal
7
YOUR DEVICE
CHARGING YOUR BATTERY
Your device comes with a USB cable and charging
head to rapidly charge your phone from any 120/220
VAC outlet.
NOTE: Although the battery comes partially charged, you must fully
charge this battery before using your phone for the first.
1. Connect the USB cable to the charging head.
2. Plug the charging head into a standard AC
power outlet.
CHARGING HEAD
INCORRECT
CORRECT
YOUR DEVICE
8
CORRECT
9
YOUR DEVICE
3. Insert the USB cable into the device’s Power/
USB connector. The device turns on with the
screen locked and indicates both its charge
state and percent of charge.
4. Once complete, unplug the charging head from
the power outlet and remove the USB cable
from the device.
INCORRECT
YOUR DEVICE
10
TURNING YOUR PHONE ON OR OFF
To power on your device:
X Press and hold (Power/Lock) until the
device turns on.
To power off your device:
1. Press and hold the (Power/Lock) until
the device options screen appears.
2. Touch Power off.
11
DEVICE FUNCTIONS
EXTENDING YOUR BATTERY LIFE
Active applications, light levels, Bluetooth usage,
and GPS functionality all act to drain your battery.
The following is a list of helpful tips that can help
conserve your battery power:
● Reduce your backlight on time.
● Turn Bluetooth off when not in use.
● Turn Wi-Fi off when not in use.
● Deactivate the GPS when not needed. Most
applications using this function will periodically
query the GPS satellites for your current location;
each query drains your battery.
● Do not wait until your battery is completely
depleted before charging your device. Repeating
this process of a complete discharge and recharge
can over time reduce the storage capacity of any
battery.
● Turn off Automatic application sync.
DEVICE FUNCTIONS
DEVICE FUNCTIONS
12
● Use the Power Control Widget to deactivate
hardware functions such as Wi-Fi, Bluetooth, GPS,
Synchronization, or LCD brightness setting.
● Check the Battery use screen to review what
features or functions have been consuming your
battery resources.
● Check the Running Services and close any
unnecessary applications.
● Use the Task Manager feature to end/shutdown
background applications that are still running.
These minimized applications can, over time, cause
your device to “slow down”.
● Animated wallpapers use processing power,
memory, and more power. Change your Live
Wallpaper to a non-animated Wallpaper gallery or
Gallery image.
13
DEVICE FUNCTIONS
LOCKING AND UNLOCKING YOUR DEVICE
By default, the device screen locks when the
backlight turns off.
To unlock your device from the lock screen:
X With your device turned on, press
(Power/Lock) to wake the display and sliding
your finger across the screen in any direction.
To lock your device screen:
X Press (Power/Lock). The screen goes
black.
DEVICE FUNCTIONS
14
CREATING A NEW GOOGLE ACCOUNT
You should create a Google™ Account when you
first use your device in order to fully utilize the
functionality. This account provides access to several
device features such as Gmail, Google Maps, Google
Search, and Android Market applications. Before you
are able to access Google applications, you must
enter your account information. These applications
sync between your device and your online Google
account.
To create a new Google Account from your
phone:
1. From the Home screen, tap
(Market).
2. Read the introduction and tap Next g Create
to begin.
3. Follow the on-screen instructions to create a
Google Account.
– or–
If this is not the first time you are starting the
phone, tap (Applications) g
(Gmail).
15
DEVICE FUNCTIONS
To create a new Google Account from the Web:
1. From a computer, launch a Web browser and
navigate to www.google.com.
2. On the main page, click Sign-in
g Create an
account now.
3. Follow the on-screen prompts to create your
free account.
4. Look for an email from Google in the email
box you provided, and respond to the email to
confirm and activate your new account.
DEVICE FUNCTIONS
16
SETTING UP VOICEMAIL
Voicemail allows callers to leave voice messages,
which can be retrieved any time. Your device
automatically transfers all unanswered calls to
voicemail, even if your device is in use or turned off.
IMPORTANT: Always use a password to protect against unauthorized
access.
1. From the Home screen, tap (Phone) and
then touch and hold until the device
dials voice mail. You may be prompted to enter
a passcode.
2. Follow the prompts in the new user tutorial to
setup your mail box.
Listening to Your Voicemail
1. From the Home screen, tap (Phone) and
then touch and hold until the device
dials voice mail. After connection, you will hear
your voice greeting.
2. When connected, follow the voice prompts from
the voice mail center.
17
DEVICE FUNCTIONS
Accessing Your Voicemail From
Another Phone
1. Dial your wireless phone number.
2. When you hear your voicemail greeting, press the
asterisk key on the dialpad you are using.
3. Enter your passcode.
CALLING FEATURES
Making a Call
1. From the Home screen, tap (Phone).
2. Enter the number you wish to call (using the
keypad) and tap (Send) to place a call.
If you make a mistake while dialing, tap to
clear the last digit. Touch and hold to clear
the entire sequence.
Ending a Call
X From within an active call, tap
End Call
(End Call).
DEVICE FUNCTIONS
18
Answering a Call
X Touch and slide (Answer) to the right to
answer an incoming call.
Reject a Call
X Touch and slide (Reject) to the left.
This action routes the incoming call to your
voicemail system.
Using the Speakerphone
X During an active call, touch
(Speakerphone) to switch between the
earpiece and the speakerphone.
19
DEVICE FUNCTIONS
Call Waiting
Call Waiting notifies you of incoming calls during a
call. You have the option of answering or ignoring an
additional incoming call.
X While in a current call, in a single motion,
touch
and slide it to the right to answer
the new incoming call. Your original call is
placed on hold and the new call is now active.
To return to your original call:
X Tap
Swap
(Swap) to switch to the orginal call.
To alternate between calls:
X Tap
Swap
(Swap) calls to alternate between the
two calls.
DEVICE FUNCTIONS
20
Making a Three-way Call
Three-way calling is similar to a conference call with
a total of three people (including yourself). Make a
call to two numbers and connect them together on
your device using three-way calling.
1. From the Home screen, tap
(Phone).
2. Enter the number you wish to call (using the
keypad) and tap (Send).
3. Once connected to the first caller tap
(Add call) to place the first caller on hold and
begin your second call.
4. Enter the second party’s phone number and tap
(Send).
5. Once the second party answers, tap
(Merge calls) to connect all three parties.
21
DEVICE FUNCTIONS
CONTACTS
Creating a New Contact
1. From the Home screen, tap (Phone).
2. Enter the number using the on-screen dialpad.
3. Press (Menu) and then tap Add to
contacts g Create contact.
4. Enter the desired information into the
appropriate fields.
5. Tap Save to store the new entry.
DEVICE FUNCTIONS
22
Adding a Number to an Existing
Contact
1. From the Home screen, tap (Contacts).
2. Touch and hold an entry and from the
on-screen context-menu, select Edit to reveal
the Contact entry’s details screen.
3. Tap within the Phone number field and
enter a new phone number.
Tap on the on-screen keypad to remove
entered phone number.
4. Tap Save to complete and store the new entry.
Deleting a Contact
1. From the Home screen, tap (Contacts).
2. Touch and hold an entry and from the on-
screen context-menu, select Delete g OK.
23
DEVICE FUNCTIONS
Copying Contact Information to the
microSD Card
This procedure allows you to copy entry information
saved on the phone’s memory, onto the microSD
card.
NOTE: These must be contacts stored on the phone. External entries
(Google, Exchange, etc...) can not be transferred in this
manner.
1. From the Home screen, tap (Contacts).
2. Press (Menu) and then tap
Import/Export g Export to SD card.
3. Tap OK to choose all current phone contact
entries.
DEVICE FUNCTIONS
24
BLUETOOTH
Bluetooth is a short-range communications
technology that allows you to connect wirelessly to
a number of Bluetooth devices, such as headsets
and hands-free car kits, and Bluetooth-enabled
handhelds, computers, printers, and wireless devices.
Turn Bluetooth On and Off
To turn Bluetooth on:
X From the Home screen, press
(Menu) and then tap Settings g Wireless
& networks g Bluetooth settings g
Bluetooth. Tapping the Bluetooth field
activates the feature (checkmark indicates
active). When active, displays in the Status
area.
To turn Bluetooth off:
X From the Home screen, press
(Menu) and then tap Settings g Wireless
& networks g Bluetooth settings g
Bluetooth. Tapping the Bluetooth field again
deactivates the feature.
25
DEVICE FUNCTIONS
Pairing Bluetooth Devices
1. Verify Bluetooth is active.
2. Place the other Bluetooth device in visable
mode. (See the device user manual for more
information.)
3. From the Bluetooth settings page, tap Visable.
Your device must be visible to successfully pair
with an external device.
4. Tap Scan devices. Your device displays a list
of discovered in-range Bluetooth devices.
5. Tap a device from the list to initiate pairing.
6. Enter the passkey or PIN code, if needed, and
tap OK.
7. The external device must accept the connection
and enter your device’s PIN code.
8. Once successfully paired to a headset,
displays in the Status area. If successfuly
paired to a device displays in the Status
area.
DEVICE FUNCTIONS
26
WEB BROWSING
Your device is equipped with a Google browser to
navigate the Web.
To open the Browser screen:
X From the Home screen, tap
(Browser).
Entering a URL
You can access a website quickly by entering the
URL. Websites are optimized for viewing on your
device.
X Tap the URL field at the top of the screen, enter
the URL and tap
.
27
DEVICE FUNCTIONS
Adding a bookmark
1. While viewing a webpage, press (Menu)
g More g Add bookmark.
2. Update the Name and Location if desired and
tap OK.
Opening a bookmark
1. While viewing a webpage, press (next to
the URL field) g touch the Bookmarks tab.
2. Touch a bookmark to load the page.
DEVICE FUNCTIONS
28
SETTING UP EMAIL
In addition to Gmail, your device supports the
following account types: POP3, IMAP, and Exchange.
Internet Email Account Set Up:
1. From the Home screen, tap (Email).
NOTE: If you already have email accounts, your accounts screen is
displayed.
2. Enter your email address in the Email address
field.
3. Enter your password in the Password field and
tap Next.
4. At the Your accounts screen, name the
account and enter a screen name to identify
yourself on this account.
5. Tap Done to store the new account.
29
DEVICE FUNCTIONS
Manual Internet Email Account Set Up
1. From the Home screen, tap (Email).
NOTE: If you already have email accounts, your accounts screen is
displayed.
2. Enter your email address in the Email address
field.
3. Enter your password in the Password field and
tap Manual.
4. Tap a setup option (IMAP or POP3) g enter
the account details and tap Next:
IMAP (Internet Message Access Protocol): This
protocolis frequently used in large networks and
commercial settings.
POP3 (Post Office Protocol): This protocol is
supported by most ISPs (Internet service providers)
and common among consumer applications.
5. At the Your accounts screen, name the
account and enter a screen name to identify
yourself on this account.
6. Tap Done to store the new account.
DEVICE FUNCTIONS
30
Microsoft Exchange Email Set Up
Your device also provides access to your company’s
Outlook Exchange server. If your company uses either
Microsoft Exchange Server 2003 or 2007, you can
use this email application to wirelessly synchronize
your email, Contacts, and Calendar information
directly with your company’s Exchange server.
1. From the Home screen, tap
(Email).
2. Enter your Email address and Password
information, and then tap Next. Consult your
Network or IT Administrator for further details
and support.
3. Tap Microsoft Exchange ActiveSync (from the
add new email account screen).
4. Enter a Domain (typically inserted on-screen
before the user name) and confirm your
Username and Password information.
31
DEVICE FUNCTIONS
5. Enter your Server information within the
appropriate field.
Exchange server: your Exchange Server’s
remote email address. Typically starts with
mail.XXX.com. Obtain this information from
your company network administrator. Do not
accept the default entry as this is a guess
based on returned information.
If your network requires SSL encryption, tap the
Accept all SSL certificates field to place a check
mark in the box and activate this additional level.
IMPORTANT: If your exchange server requires this feature, leaving this
field unchecked can prevent connection.
6. With the new information entered, tap Next.
7. Read the on-screen activation disclaimer and,
if prompted, tap Yes.
8. Adjust the various on-screen configuration
fields and tap Next. Identify your new account
with a unique name and provide the outgoing
name text then tap Done.
DEVICE FUNCTIONS
32
MESSAGING
Accessing Messages
X From the Home screen, tap (Messaging).
Create and Send a Text Message
1. From the Home screen, tap (Messaging)
g (New message).
2. Enter either the recipient’s phone number or
e-mail address.
3. Tap the Tap to enter message field and use
the on-screen keypad to enter a message.
4. Add more recipients by tapping the To field.
5. Review your message and tap Send.
33
DEVICE FUNCTIONS
Create and Send a Mutimedia Message
Picture messages are text messages that contain
file attachments like a voice memo, ringtone, image,
video, or downloaded melody.
NOTE: You can send a Picture message to up to ten recipients. Enter
each recipient’s address or phone number in a separate To
field of the Picture message composer.
1. From the Home screen, tap (Messaging)
g (New message).
2. Enter either the recipient’s phone number or
e-mail address.
3. Tap the Tap to enter message field and use
the on-screen keypad to enter a message.
4. Add more recipients by tapping the To field.
5. Press (Attachment) to insert various
file types to your message (such as pictures,
videos, or audio).
Select the file and complete the on-screen
instructions to insert it to the current message.
6. Review your message and tap Send.
DEVICE FUNCTIONS
34
USING ANDROID MARKET
Android Market provides access to downloadable
applications and games to install on your phone.
Accessing the Market
1. From the Home screen, tap (Market).
2. If not already logged in to your Google account,
tap Next.
3. Tap Sign in and enter your Google account
information.
4. Tap Accept to agree to the Market’s terms of
service.
Downloading a New Google Application
To download a new application, you will need to use
your Google account to sign in to Android Market.
1. From the Home screen, tap
(Market).
2. Browse through the categories, find an
application you’re interested in, and tap the
name.
3. Read the application descriptions.
4. Tap Install.
35
DEVICE FUNCTIONS
Moving Third-party Applications to
your SD Card
Your phone’s built in memory is augmented by using
a microSD card to store additional data. When the
phone’s built-in memory capacity is reached, it can
be possible to move some applications over to the
internal microSD card. Freeing up memory space on
the phone can help avoid any sluggish performance
when the phone has to work harder to manage
memory resources.
NOTE: Only certain downloaded applications are capable of being
moved from phone to card.
1. From the Home screen, press (Menu)
and then tap Settings g Applications g
Manage applications.
2. Tap the Downloaded tab and select your
desired application.
3. Tap Move to SD card (from within the Storage
section of the Application info page).
DEVICE FUNCTIONS
36
CUSTOMIZING YOUR PHONE
You can customize the Home screens (panels) to
display Widgets, Shortcuts, Folders, or Wallpapers.
Manage Shortcuts
NOTE: To move a shortcut from one screen to another, you must
carefully touch and hold the shortcut and slowly drag it to the
edge of the screen. As the shortcut turns light blue, you can
begin to move it to the adjacent screen. If this does not work,
delete it from its current screen. Activate the new screen and
then add the selected shortcut.
To add a shortcut from the Applications screen:
1. From the Home screen, select a location
(screen) for your new shortcut by scrolling
across your available screens until you reach
the desired one.
2. Tap
(Applications) to reveal all your
current available applications.
3. Touch and hold the on-screen icon. The new
shortcut then appears to hover over the current
screen.
37
DEVICE FUNCTIONS
4. While still holding the on-screen icon, position
it on the current screen. Once complete,
release the screen to lock the shortcut into its
new position.
To add a shortcut from the Home screen:
1. From the Home screen, touch and hold an
empty area of the screen.
2. From the Add to Home screen window tap
Shortcuts.
3. Tap a selection from the available list.
Manage Widgets
Widgets are self-contained applications that can
be placed on any screen. Unlike shortcuts, widgets
appear as applications.
To add a Widget:
1. From the Home screen, touch and hold an
empty area of the screen.
2. From the Add to Home screen window tap
Widgets.
3. Tap an available Widget to place it on your
current screen.
DEVICE FUNCTIONS
38
To remove a Widget:
1. Touch and hold an on-screen Widget until it
unlocks from the current screen.
2. Drag the widget over the Remove tab area
(located at the bottom of the screen) until the
Widget turns red, and then release it.
Wallpaper
1. From the Home screen, touch and hold an
empty area of the screen.
2. From the Add to Home screen window tap
Wallpapers.
3. Choose a source for images:
Gallery: Choose a picture from an installed
memory card. Tap a picture to select it, then use
the crop tool to resize the picture, if desired. Tap
Save to save the picture as wallpaper.
Live wallpapers: Choose from pre-loaded
interactive animated wallpapers. Tap a wallpaper to
see an example, then touch Set wallpaper.
Wallpaper gallery: Choose from pre-loaded
wallpaper images. Tap a wallpaper, then tap Set
wallpaper.
39
DEVICE FUNCTIONS
CAMERA & CAMCORDER
Use your phone’s built-in Camera to take pictures
and record video.
Camera
1. From the Home screen, tap (Camera).
2. Using the display as a viewfinder, compose
your shot by aiming the lens at the subject.
3. Touch to take a picture.
4. After taking your picture, touch
(Image Viewer) to view the image.
DEVICE FUNCTIONS
40
Camcorder
1. From the Home screen, tap (Camera)
g tap (Mode changer) to select
(Camcorder).
2. Using the display as a viewfinder, compose
your shot by aiming the lens at the subject.
Touch to start recording.
Touch again to stop and save recording.
3. After recording, touch (Image Viewer) and
touch to view the video.
41
DEVICE FUNCTIONS
GPS NAVIGATION
Your device is equipped with GPS hardware that
supplemented by positioning information from nearby
wireless networks.
To enable GPS location:
1. From the Home screen, press
(Menu)
and then tap Settings g Location & security.
2. Tap Use GPS satellites. A green check
mark indicates the GPS location feature has
been enhanced by using Wi-Fi and/or mobile
networks to increase accuracy.
DEVICE FUNCTIONS
42
Launching the Navigation Application
Get free, turn-by-turn GPS navigation for driving,
walking, and public transit directions. Google Maps
Navigation users can search by one of the following
methods:
● Search in plain English: No need to know the
address. You can type a business name or even a
kind of a business, just like you would on Google.
● Search by voice: Speak your destination instead
of typing (English only): “Navigate to the de Young
Museum in San Francisco”.
● Search along route: Search for any kind of
business along your route, or turn on popular layers
such as gas stations, restaurants, or parking.
For more information visit: http://www.google.com/
mobile/navigation/
X From the Home screen, tap
(Applications) g (Navigation).
43
DEVICE FUNCTIONS
Your Navigator Deluxe
With Your Navigator Deluxe, get all of the features of
an advanced car navigation system on your mobile
phone with voice turn-by-turn navigation enabled
by GPS. Search for any destination including gas
stations, ATMs, restaurants, and more. Get detailed
maps of any location.
1. To use Your Navigator Deluxe, you must first
turn on your phones location and GPS settings.
2. From the Home screen, press
(Menu)
and then tap Location & Security g Use GPS
satellites.
Once turned on press to return to the
Home screen.
DEVICE FUNCTIONS
44
3. From the screen, tap
(Your Navigator
Deluxe).
From the Your Navigator Deluxe Home screen
you can select:
Drive To for turn by turn direction to an address,
airport, contacts addresses and more
Places to search for nearby businesses, the
cheapest gas prices and more
Maps & Traffic to see where you currently are
located on a map and what traffic is in the area
Local Apps to search for local Movies, Weather
and Commute Alerts
45
NOTES
Loading...
