PERSONAL MICRO
COMPONENT SYSTEM
MM-DJ8
V I D E O
COMPACT
DIGITAL AUDIO
COMPACT
DIGITAL VIDEO
Instruction Manual
Page 2
1
Safety Warnings
Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED, AVOID
EXPOSURE TO BEAM.
This symbol indicates that dangerous voltage which
can cause electric shock is present inside this unit.
This symbol alerts you to important operating and
maintenance instructions accompanying the unit.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE REAR COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CLASS 1 LASER PRODUCT
This Compact Disc player is classified
as a CLASS 1 LASER product.
CAUTION
Page 3
2
Precautions
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install your
player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4inches). Make sure the ventilation slots
are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other equipment which may become
hot. Before moving the player, ensure the disc tray is empty. This player is designed for continuous use. Switching off the DVD player to
the stand-by mode does not disconnect the electrical supply. In order to disconnect the player completely from the power supply,
remove the main plug from the wall outlet, especially when left unused for a long period of time.
Protect the player from moisture(i.e. vases) , and excess
heat(e.g.fireplace) or equipment creating strong magnetic or electric
fields (i.e.speakers...). Disconnect the power cable from the AC supply if
the player malfunctions. Your player is not intended for industrial use.
Use of this product is for personal use only.
Condensation may occur if your player or disc have been stored in cold
temperatures.
If transporting the player during the winter, wait approximately 2 hours
until the unit has reached room temperature before using.
During thunderstorms, disconnect AC main plug from the
wall outlet.
Voltage peaks due to lightning could damage the unit.
Do not expose the unit to direct sunlight or other heat
sources.
This could lead to overheating and malfunction of the unit.
The battery used with this product contain chemicals that
are harmful to the environment.
Do not dispose of batteries in the general household trash.
PREPARATION
Phones
Page 4
Features
3
Multi-Disc Playback & AM/FM Tuner, TAPE
The MM-DJ8 combines the convenience of multi-disc playback capability,
including DVD, VCD,CD,DivX,WMA, MP3-CD, CD-R, CD-RW, and DVD-RW,
with a sophisticated AM/FM tuner, TAPE, all in a single player.
Power Saving Function
The MM-DJ8 automatically shuts itself off after 20 minutes in the stop .
TV Screen Saver Function
The MM-DJ8 automatically brightens and darkens the brightness of the
TV screen after 3 minutes in the stop .
The MM-DJ8 automatically switches itself into the power saving mode
after 20 minutes in the screen saver mode.
Customized TV Screen Display
The MM-DJ8 allows you to select your favorite image during JPEG, DVD
playback and set it as your background wallpaper.
DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital
surround sound and MPEG-2 video compression technology. Now you can enjoy these
realistic effects in the home, as if you were in a movie theater or concert hall.
V I D E O
DVD players and the discs are coded by region. These regional codes must match in order
for the disc to play. If the codes do not match, the disc will not play.
The Region Number for this player is given on the rear panel of the player.
(Your DVD player will only play DVDs that are labeled with identical region codes.)
1 6
~
•
Many DVD discs are encoded with copy protection. Because of this, you should only connect your
DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture
from copy-protected DVD discs.
•
This product incorporates copyright protection technology that is protected by methods claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Copy Protection
Page 5
4
Contents
PREPARATION
Safety Warnings..................................................................................................................................................................1
Precautions .........................................................................................................................................................................2
Features..............................................................................................................................................................................3
Description ..........................................................................................................................................................................5
CONNECTIONS
Connecting the Speakers....................................................................................................................................................9
Connecting to a TV .............................................................................................................................................................10
Connecting External Components ......................................................................................................................................11
Connecting the FM,AM(MW/LW) and SW(option)Antennas...............................................................................................12
Setting the Clock.................................................................................................................................................................13
OPERATION
Disc Playback .....................................................................................................................................................................14
DivX Playback.....................................................................................................................................................................15
Displaying Disc Information ................................................................................................................................................17
Fast/Slow Playback.............................................................................................................................................................18
Skipping Scenes/Songs ......................................................................................................................................................19
Angle Function ....................................................................................................................................................................20
Repeat Playback.................................................................................................................................................................21
A-B Repeat Playback..........................................................................................................................................................23
Zoom Function ....................................................................................................................................................................24
Selecting Audio/Subtitle Language .....................................................................................................................................25
Moving Directly to a Scene/Song........................................................................................................................................26
JPEG File Playback ............................................................................................................................................................27
Using Disc Menu.................................................................................................................................................................29
Using the Title Menu ...........................................................................................................................................................30
SETUP
Setting the Language..........................................................................................................................................................31
Setting TV Screen type .......................................................................................................................................................33
Setting Parental Controls (Rating Level).............................................................................................................................35
Setting the Password ..........................................................................................................................................................36
Setting the Wallpaper..........................................................................................................................................................37
Setting the DRC (Dynamic Range Compression)...............................................................................................................39
AV SYNC Setup..................................................................................................................................................................40
RADIO OPERATION
Listening to Radio ...............................................................................................................................................................41
Presetting Stations..............................................................................................................................................................42
TAPE DECK
Listening to a Cassette .......................................................................................................................................................43
REPEAT A↔B Function .....................................................................................................................................................44
Selecting the Cassette Playback Mode ..............................................................................................................................44
Tape Counter ......................................................................................................................................................................44
MISCELLANEOUS
Timer Function ....................................................................................................................................................................45
Canceling the Timer............................................................................................................................................................46
Recording a Compact Disc .................................................................................................................................................47
Recording a Radio Program ...............................................................................................................................................49
EQ/S.BASS, SRS WOW Function .....................................................................................................................................50
Sleep Timer Function / Mute Function ................................................................................................................................51
TREBLE/BASS Function.....................................................................................................................................................52
DEMO Function / DIMMER Function ..................................................................................................................................53
Connecting Headphones/Microphone(option) ....................................................................................................................54
Cautions on Handling and Storing Discs ............................................................................................................................55
Before Calling for Service ...................................................................................................................................................56
Notes on Discs....................................................................................................................................................................57
Notes on Terminology.........................................................................................................................................................59
Specifications......................................................................................................................................................................60
Language Code List............................................................................................................................................................61
PREPARATION
Page 6
5
Description
—Front Panel—
1. FUNCTIONS (TUNER/DVD/CD/TAPE)
2.
STANDBY/ON
3. AUX
4.
SEARCH FUNCTION BUTTONS
TUNING MODE OR STOP BUTTON
5.
DEMO/DIMMER
6.
SLEEP
7.
HEADPHONE JACK CONNECTOR
8. MIC(OPTION)
9. REVERSE MODE
10. CD SYNCHRO / REC/PAUSE
11. VOLUME CONTROL
12. SRS WOW
13. DISC TRAY
14. CD DOOR OPEN/CLOSE
15. BASS LEVEL
16. TREBLE LEVEL
17.
PUSH EJECT
(CASSETTE DOOR OPEN/CLOSE)
1
2
3
4
5
6
7
9
8
10
11
12
14
13
15
16
17
Page 7
—Rear Panel—
OPEN/CLOSE
DVD TUNER AUX
EZ VIEW
NTSC/PAL
SLOW SUB TITLE
STEP
TUNING
PL II
R
E
T
U
R
N
M
E
N
U
I
N
F
O
M
U
T
E
MODE
ENTER
SOUND EDIT
TEST TONE
SLEEP
LOGO DIGEST
SLIDE MODE
CANCEL ZOOM
TUNER
MEMORY
PL II
EFFECT
VOLUME
DSP/EQ REPEAT
BAND
MO/ST
REMAIN
DIMMER
Video Cable FM Antenna Remote Control
User's Manual
AM Antenna
6
Accessories
Loudspeaker Connector Terminals
Voltage Selector(option)
AUX-Input
S-Video Output Connector
If the TV is equipped with an S-Video
input connector (S-VIDEO IN), connect
it to the player's S-Video output jack.
Video Output Connector
Connect the TV's video input jacks
(VIDEO IN) to the VIDEO OUT connector.
FM Antenna Connector
AM Antenna Connector
SW Antenna Connector(option)
PREPARATION
Page 8
—Remote Control—
7
Description
SRS WOW button
TUNING button
MENU button
DVD POWER button
OPEN/CLOSE button
COUNTER RESET/STEP button
ZOOM button
AUX button
RETURN button
Number(0~9) buttons
EZ VIEW, NTSC/PAL button
REPEAT A<–> B button
LOGO button
SLEEP button
REMAIN button
SUB TITLE button
SLOW, MO/ST button
REPEAT button
INFO button
MUTE button
Direction/Enter button
EQ/S.BASS button
VOLUME button
SLIDE MODE button
TREBLE/BASS button
DIGEST button
TIMER ON/OFF button
TIMER/CLOCK button
CANCEL button
TUNER MEMORY button
DVD button
Play/Pause/Tape Play button
CD Skip/Tape Search button
Stop /Tuning Mode button
TAPE button
TUNER BAND button
Page 9
To open the remote control cover, push the
top of the cover, then slide downward.
8
Insert Remote Batteries
The remote control can be used up to approximately 23
feet/7 meters in a straight line. It can also be operated at
a horizontal angle of up to 30° from the remote control
sensor.
Range of Operation of the Remote Control
Remove the battery
cover on the back of
the remote by
pressing down and
sliding the cover in
the direction of the
arrow.
1
Insert two 1.5V AAA
batteries, paying
attention to the correct
polarities (+ and –).
2
Replace the battery
cover.
3
Follow these precautions to avoid leaking or cracking cells:
•
Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).
•
Use the correct type of batteries.Batteries that look similar may differ in voltage.
•
Always replace both batteries at the same time.
•
Do not expose batteries to heat or flame.
Caution
PREPARATION
Page 10
Loudspeakers
•
Place these speakers in front of your listening
position, facing inwards (about 45°) toward you.
•
Place the speakers so that their tweeters will be at
the same height as your ear.
•
Align the front face of the front speakers with the
front face of the center speaker or place them
slightly in front of the center speakers.
• Installation in a place near heating apparatus, under direct lay of light or with high humidity may cause
performance degradation of the speaker.
• Do not install on the wall or on a high place of pole or other unstable place to prevent any safety accident
caused by falling of the speaker.
• Do not take the speaker apart from TV or computer monitor.
The speaker near the TV or computer monitor may influence the quality of the screen display.
Position of the DVD Player
•
Place it on a stand or cabinet shelf, or under
the TV stand.
Selecting the Listening Position
The listening position should be located about 2.5 to 3
times the distance of the TV's screen size away from the
TV. Example: For 32" TVs 2~2.4m (6~8feet)
For 55" TVs 3.5~4m (11~13feet)
9
Connecting the Speakers
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
R
L
Directions in Installing Speaker
Right Speaker
Left Speaker
Red
Black
Red Black
L
S
P
E
A
K
E
R
R
S
Page 11
10
Please be sure to turn off the power and unplug the power cord before moving or installing this unit.
Please choose one of two video connection methods.
Use this method if your TV has an S-Video In jack.
Connecting to a TV
Method 1
Using Video Out (Cable Included)
Method 2
Using S-Video Out (Cable Not Included)
Connect Video Out on the player to Video In
on your TV.
1
Connect S-Video Out to S-Video In on your
TV.
1
•
Composite Video: A single video signal that is a composite of the black-and-white
information (Y) and the color information (C).
•
S-Video: A video transmission standard that provides a sharper, brighter picture
than ordinary composite video by separating brightness and color signals.
Note
CONNECTIONS
Press the TV/VIDEO button on the remote of TV
control to set the TV to "VIDEO".
2
Press the TV/VIDEO button on the remote control
of TV to set the TV to "S-VIDEO".
2
Page 12
11
Connect Audio In on the DVD player to Audio Out on the external analog component.
•
Be sure to match connector colors.
1
Example: Analog signal components such as a VCR, Camcorder, and TV.
Connecting to an External Analog Component
Connecting to External Components
Audio Cable
If the external analog component has
only one Audio Out, connect either left
or right.
Press AUX to select AUX.
•
‘
AUX’ appears in the display.
2
R
L
Page 13
12
CONNECTIONS
Connecting the FM, AM
(
MW/LW)andSW(option)Antennas
FM antenna connection AM(MW/LW) antenna connection
1. Connect the FM antenna supplied to the FM 75Ω
COAXIAL terminal as a temporary measure.
2. Slowly move the antenna wire around until you
find a location where reception is good, then
fasten it to a wall or other rigid surface.
•
If reception is poor, connect an outdoor antenna.
Before attaching a 75Ω coaxial cable (with a standard
type connector), disconnect the supplied FM antenna.
1. Connect the AM loop antenna supplied
to the AM and terminals.
2. If reception is poor, connect an outdoor
single vinyl-covered wire to the AM
terminal. (Keep the AM loop antenna
connected).
Page 14
13
Setting the Clock
For each step, you have a few seconds to set the required options.
If you exceed this time, you must start again.
•
You can display the time, even
when you are using another
function, by pressing
TIMER/CLOCK once.
•
CLOCK is displayed.
2
Press TIMER/CLOCK
twice.
1
Switch the system
on by pressing
POWER button.
•
"TIMER" appears in the display.
•
The current time is now set.
5
When the correct
time is displayed,
press ENTER.
•
Increase the minutes :
•
Decrease the minutes :
4
When the correct
hour is displayed,
press ENTER.
The minutes flash.
•
Increase the hours :
•
Decrease the hours :
3
Press ENTER.
The hour flashes.
Note
Checking the Remaining Time
CHAPTER REMAIN
TITLE REMAIN
CHAPTER ELAPSED
TITLE ELAPSED
TRACK REMAIN
TOTAL ELAPSED
TOTAL REMAIN
TRACK ELAPSED
Each time the REMAIN button is pressed
Press the REMAIN button.
•
For checking the total and remaining time of a title or chapter being played.
DVD
CD
VCD
•
By default, the video format is set to "PAL".
•
Each time the button is pressed, the video format switches between "NTSC" and "PAL".
•
Each country has a different video format standard.
•
For normal playback, the video format of the disc must be the same as the video format of your TV.
Turn off the main unit and then press NTSC/PAL.
Selecting the Video Format
Page 15
14
Disc Playback
2
Load a disc.
•
Place a disc gently into the tray with the disc’s label
facing up.
•
Depending on the content of the disc, the initial screen may appear different.
•
Depending on the recording mode, some MP3-CDs cannot be played.
•
Table of contents of a MP3-CD varies depending on the MP3 track format recorded
on the disc.
1
Press OPEN/CLOSE button to open the
disc tray.
3
Press OPEN/CLOSE button to close the disc
tray.
DVD VCD CD
•
Playback starts automatically.
DivX
MP3
JPEG
•
Playback starts automatically.
•
If the TV is on, a list of MP3s on
the CD will appear on the TV
screen.
Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl
DVD RECEIVER SMART NAVI
Note
•
To resume playback, press PLAY/PAUSE
button again.
To temporarily pause playback,
press PLAY/PAUSE during playback.
•
If pressed once, “PRESS PLAY” is displayed and the
stop position will be stored in memory. If PLAY/PAUSE
( ) button or ENTER button is pressed, playback
resumes from the stop position. (This function works
only with DVDs.)
•
If pressed twice, “STOP” is displayed, and if
PLAY/PAUSE ( ) button is pressed, playback
starts from the beginning.
To stop playback,
press STOP during playback.
CONNECTIONS
Page 16
15
Fast playback
DivX Playback
Skip Forward/Back
During playback, press the button.
•
Go to the next file whenever you press button, if there are over
2 files in the disk.
•
Go to the previous file whenever you press button, if there are over
2 files in the disk.
Press and hold button.
•
Each time the button is held down during playback,
the playback speed changes as follows:
•
DivX files can be played in
Zoom X2 mode only.
Note
Zoom Function
2
Press Cursor , ,
, buttons to
move to the area
you want to enlarge.
1
Press ZOOM
button.
•
Each time you press the button,
your selection will toggle between
“ZOOM X2” and “ZOOM OFF”.
Page 17
16
5 Minute Skip function
•
When playing the DivX disk, you can play the file with extension of AVI only.
•
Among the available DivX audio formats, DTS Audio is not supported.
•
WMV V8 is not supported for WMV files.
•
When burning a subtitle file to a CD-ROM with your PC, be sure to burn it as an SMI file.
During playback, press the , button.
•
Go to the screen about 5 minutes after whenever you press button.
•
Go to the screen about 5 minutes earlier whenever you press button.
Note
OPERATION
Subtitle Display
Press the SUBTITLE button.
DivX Feature Table
DivX Supported
Avi files are used to contain the audio and video data; these must be stored on CD in the ISO 9660 format.
MPEGs containing DivX can be divided into Video and Audio.
•
Video compatibility : All versions of DivX later than 3.11 (including
the latest 5.1) are supported. In addition, XviD is supported.
For WMV, V1, V2, V3, and V7 formats are possible.
•
Audio compatibility : MP3s encoded at bitrates from 80kbps to
320kbps, AC3s from 128kbps to 448kbps, and WMAs from 56kbps
to 160kbps are supported.
•
In addition, for subtitles, this unit will support Text format (SMI).
SPEC
VIDEO Compatibility DivX3.11 Up to the latest VERSION
WMV WMV V1/V2/V3/V7
AUDIO Compatibility MP3 CBR : 80kbps~320kbps
AC3 CBR : 128kbps~448kbps
WMA CBR : 56kbps~160kbps
1
In Stop mode, press the , , , button, select the desired subtitle
( ) from the TV screen, and then press the ENTER button.
•
Each time you press the button, your selection will toggle between “SUBTITLE ON” and “SUBTITLE OFF”.
•
If the disc has only one subtitle file, it will be played automatically.
•
Up to 8 subtitle languages are supported.
If the disc has more than one subtitle file
If the disc has more than one subtitle file, the default subtitle may not match the movie and you will have to
select your subtitle language as follows:
2
When you select the desired DivX file from the TV screen, the movie
will be played normally.
Page 18
17
Displaying Disc Information
You can view playback information on the disc on the TV screen.
Press INFO button.
•
Each time the button is pressed, the display changes as follows:
DVD
Display disappears
Display disappears Display disappears
VCD CD
Something like you
Back for good
Love of my life
More than words
DVD RECEIVER SMART NAVI
DivX
MP3
JPEG
•
What is a Title?
A movie contained in a DVD disc.
•
What is a Chapter?
Each title on a DVD disc is divided into several smaller sections called "chapters".
•
appears on the TV screen!
If this symbol appears on the TV screen while buttons are being operated, that
operation is not possible with the disc currently being played.
•
What is a Track (File)?
A section of video or a music file recorded on a VCD, CD, or MP3-CD.
Screen Display
DVD display
VCD display
CD display
MP3 CD display
CHAPTER display
TRACK (FILE) display
TITLE display
REPEAT PLAYBACK display
AUDIO LANGUAGE display
ELAPSED TIME display
STEREO (L/R) display
DOLBY DIGITAL display
SUBTITLE display
ANGLE display
•
Depending on the disc, the disc
information display may appear different.
•
Depending on the disc, you can also
select DOLBY DIGITAL, or PRO LOGIC.
Note
DivX display
Page 19
Fast/Slow Playback
Fast Playback
DVD VCD CD MP3
Press and hold .
•
Each time the button is held down during playback,
the playback speed changes as follows:
Press SLOW button.
•
Each time the button is pressed during playback,
the playback speed changes as follows:
Slow Playback
OPERATION
DVD VCD DivX
•
Reverse slow playback does not
work with VCDs and DivX.
Note
18
Page 20
19
Skipping Scenes/Songs
DVD VCD MP3
DVD
DVD VCD MP3
Briefly press .
•
Each time the button is pressed briefly during playback, the previous or next chapter,
track, or directory (file) will be played.
•
But, you cannot skip chapters consecutively.
•
During fast playback of a CD or MP3-CD, sound is heard only at 2x speed, and not at 4x, 8x, and 32x speeds.
•
No sound is heard during slow playback and step motion playback.
•
The picture moves forward one frame each time the
button is pressed during playback.
Playing Frame by Frame
Press STEP button.
•
When watching a VCD with a track
longer than 15 minutes, each time
is pressed, playback
will skip back or forward 5 minutes.
TITLE 01/05 CHAPTER 002/040
TITLE 01/05 CHAPTER 004/040
Note
DVD RECEIVER SMART NAVI
DVD RECEIVER SMART NAVI
DVD RECEIVER SMART NAVI
Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl
Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl
Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl
Page 21
20
Angle Function
This function allows you to view the same scene in different angles.
DVD
2
Press Cursor
button to move to
ANGLE display.
1
Press INFO button.
1/3
•
Each time the button is pressed, the angle changes as follows:
3
Press Cursor , buttons or numeric buttons
to select the desired angle.
2/3
3/3
1/3
1/3
•
The Angle function works only with discs on which multiple angles
have been recorded.
Note
OPERATION
Page 22
Repeat Playback
Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file).
21
Press REPEAT button.
•
Each time the button is pressed during playback, the repeat playback mode changes as follows:
DVD
VCD CD
MP3 JPEG
•
Repeat playback operation is not possible with version 2.0 VCD discs if PBC is turned on.
To use Repeat Playback on a VCD with PBC, you should set the PBC to OFF in the disc menu. (See page 29.)
CHAPTER
Repeatedly plays the selected chapter.
TITLE
Repeatedly plays the selected title.
RANDOM
Plays tracks in random order.
(A track that has already been played
may be played again.)
TRACK
Repeatedly plays the selected track.
DIR
Repeatedly plays all tracks in the
selected folder.
DISC
Repeatedly plays the entire disc.
OFF
Cancels Repeat Playback.
DVD VCD CD MP3 JPEG
Repeat Playback Options
Note
Page 23
22
DVD
VCD CD
•
For MP3 and JPEG discs, you cannot select Repeat Play
from the information display screen.
•
For VCD Version 2.0 discs, you can select Repeat Play in
PBC off mode.
Note
2
Press Cursor button
to move to REPEAT
PLAYBACK display.
1
Press INFO button
twice.
4
Press ENTER
button.
3
Press Cursor
button to select the
desired Repeat
Playback mode.
DVD VCD CD
To Select a Repeat Playback Mode
in the Disc Information Screen
OPERATION
For a VCD or CD,Press INFO button
once.
Page 24
23
A-B Repeat Playback
•
A–B Repeat Playback does not work on MP3 and JPEG discs.
•
To select AB Repeat Playback from the information display screen,
press REP. A↔B.
2
Press REP. A↔B
at the end of the
section.
1
Press REP. A↔B
at the beginning of
the section you
want to repeat.
To cancel AB Repeat Playback, press REP. A↔B to
select "REPEAT PLAYBACK: OFF".
DVD VCD CD
Note
REPEAT : A–
REPEAT : OFF
REPEAT : A–B
Page 25
Zoom Function
This function allows you to enlarge a particular area of the displayed image.
Zoom (Screen Enlarge) Function
DVD VCD
Aspect Ratio
DVD
2
Press Cursor , ,
, buttons to
move to the area
you want to enlarge.
1
Press ZOOM
button.
•
Each time the button is pressed, the
zoom level changes as follows:
3
Press ENTER
button.
Press EZ VIEW button.
•
Each time the button is pressed, the zoom function will switch between On
and Off.
•
When a movie is played in Widescreen format, black bars at the top and
bottom of the TV screen can be removed by pressing the EZ VIEW button.
•
This function will not work if the DVD is recorded with multi-camera angle format.
•
Black bars may not disappear because some DVD discs have a built-in horizontal to vertical ratio.
Note
EZ VIEW OFFEZ VIEW
ENTER ZOOM
POSITION
24
OPERATION
Page 26
25
Selecting Audio/Subtitle Language
•
Depending on the number of languages on a
DVD disc, a different audio language (KOREAN,
ENGLISH, JAPANESE, etc.) is selected each
time the button is pressed.
2
Press Cursor ,
buttons or numeric
buttons to select the
desired audio language.
1
Press INFO button
twice.
•
You can use the SUBTITLE button on the
remote control to select a subtitle
language.
•
Depending on the disc, the Subtitle and
Audio Language functions may not work.
Audio Language Selection Function
DVD
Subtitle Language Selection Function
DVD
Note
2
Press Cursor
button to move to
SUBTITLE display.
1
Press INFO button
twice.
3
Press Cursor
button or numeric
buttons to select
the desired subtitle.
SP 2/3
FR 3/3
EN 1/3 EN 01/ 03
OFF
SP 02/ 03
FR 03/ 03
OFF / 03
Page 27
26
Moving Directly to a Scene/Song
•
The selected file will be played.
•
An MP3 or JPEG disc cannot be moved
from the disc information screen.
•
When playing an MP3 or JPEG disc, you
cannot use , to move a folder.
To move a folder, press (Stop) and
then press , .
DVD VCD CD
MP3 JPEG
2
Press Cursor , buttons
or numeric buttons to select
the desired title/track and then
press ENTER button.
1
Press INFO button.
01/05
001/040 0:00:37 1/1
03/05
001/002 0:00:01 1/1
01/05
001/040 0:00:01 1/1
Moving to a Title/Track
4
Press Cursor , buttons
or numeric buttons to select
the desired chapter and
then press ENTER button.
01/05
025/040 0:00:01 1/1
Moving to a Chapter
6
Press the numeric
buttons to select the
desired time and then
press ENTER button.
01/05
028/040 1:30:00 1/1
Moving to a Specific Time
3
Press Cursor ,
buttons to move to
Chapter display.
Moving to a Chapter
01/05
025/040 1:17:30 1/1
5
Press Cursor ,
buttons to move to
time display.
Moving to a Specific Time
Press the numeric
buttons.
•
You can press on the remote
control to move directly to the desired
title, chapter, or track.
•
Depending on the disc, you may not
be able to move to the selected title or
time.
Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl
DVD RECEIVER SMART NAVI
SELECT 03
Move Select Stop
Note
OPERATION
Page 28
JPEG File Playback
Images captured with a digital camera or camcorder, or JPEG files on a PC can be
stored on a CD and then played back with this DVD player.
Slide Mode
JPEG
27
Place the JPEG disc on the disc tray.
•
Each time the button is pressed, the slide moves backward or forward.
Press to skip to the next slide.
1
•
Playback starts automatically.
•
Each image is shown for 5 seconds before another image is displayed.
Press the OPEN/CLOSE button.
2
•
Playback starts automatically.
•
Each time the button is pressed, the image makes the transition as follows:
Press SLIDE MODE button.
3
From top to bottom
From bottom to top
Rectangular shape in the center
Vertical curtain shape
Each time a new image is displayed, slide modes
(1~11) will be randomly and automatically be applied.
Cancels the slide mode.
Page 29
Rotate/Flip Function
button: Flip Vertically
button: Flip Horizontally
button: Rotate 90°
Counterclockwise
button: Rotate 90° Clockwise
Digest Function
2
Press Cursor , , , buttons
to select the desired image and
then press ENTER button.
1
Press DIGEST
button during
playback.
•
JPEG files will be shown in
9 windows.
You can view 9 JPEG images on the TV screen.
•
The selected image is played for 5 seconds before moving to
the next image.
28
To view the previous or next image with 9 windows, press .
Press Cursor , , , buttons during playback.
Original Image
OPERATION
Page 30
Using Disc Menu
You can use the menus for the audio language, subtitle language, profile, etc.
DVD menu contents differ from disc to disc.
DVD
29
2
•
When playing a VCD (version 2.),
this toggles between PBC ON and
OFF.
•
When you select the disc menu that is not
supported by the disc, the "This menu is not
supported" message appears on the screen.
1
Press MENU button
in the stop mode.
Press Cursor ,
buttons to move to
‘DISC MENU’ and then
press ENTER button.
4
Press ENTER
button.
3
Press Cursor , ,
, buttons to
select the desired
item.
PBC (Playback Control) Function
When playing a VCD (version 2.0), you can select and view various scenes according to the menu screen.
PBC ON: This VCD disc is version 2.0. The disc is played back according to the menu screen. Some functions may be
disabled. When some functions are disabled, select "PBC OFF" to enable them.
PBC OFF: This VCD disc is version 1.1. The disc is played back in the same way as with a music CD.
Note
Page 31
Using the Title Menu
For DVDs containing multiple titles, you can view the title of each movie.
Depending on the disc, this function may either not work at all or may work differently.
2
Press Cursor ,
button to move to
‘Title Menu’.
DVD
1
Press MENU button
in the stop mode.
3
Press ENTER
button.
•
The title menu appears.
30
Press MENU button to exit the setup screen.
OPERATION
Page 32
Setting the Language
OSD language is set to English by default.
21
Press MENU button
in the stop mode.
Press Cursor
button to move to
‘Setup’ and then
press ENTER button.
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
31
• To select other language, select OTHER and enter the language code of your country.
(See 61 page for language code of countries)
AUDIO, SUB TITLE and DISC MENU language can be selected.
Note
Page 33
*
If the language you selected is
not recorded on the disc, menu
language will not change even
if you set it to your desired
language.
Selecting the
OSD Language
Selecting the
Audio Language
(recorded on the disc)
4
•
Once the setup is complete, if the language was
set to English, OSD will be displayed in English.
3
Selecting the
Subtitle Language
(recorded on the disc)
Selecting the Disc Menu
Language (recorded on the disc)
Press ENTER
button.
5
Press Cursor ,
button to select the
desired item and then
press ENTER button.
Press Cursor ,
button to select the
desired language and then
press ENTER button.
SETUP
32
Page 34
33
Setting TV Screen type
21
43
Press MENU button
in the stop mode.
Press Cursor
button to move to
‘Setup’ and then
press ENTER button.
•
Once the setup is complete, you will
be taken to the previous screen.
Press Cursor
button to move to ‘TV
DISPLAY’ and then
press ENTER button.
Press Cursor ,
button to select the
desired item and then
press ENTER button.
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
Page 35
34
The horizontal to vertical screen size ratio of conventional TVs is 4:3, while that of wide screen and high
definition TVs is 16:9. This ratio is called the aspect ratio. When playing DVDs recorded in different
screen size, you should adjust the aspect ratio to fit your TV or monitor.
✱ For a standard TV, select either "4:3LB" or "4:3PS" option according to
personal preference. Select "16:9" if you have a wide screen TV.
: Select this to view a 16:9 picture in the full-screen
mode on your wide screen TV.
• You can enjoy the wide screen aspect.
: Select this to play a 16:9 picture in the letter box
mode on a conventional TV.
• Black bars will appear at the top and bottom of the screen.
: Select this to play a 16:9 picture in the pan & scan
mode on a conventional TV.
• You can see the central portion of the screen only (with the
sides of the 16:9 picture cut off).
4:3LB
(4:3 Letterbox)
WIDE
4:3PS
(4:3 Pan&Scan)
• If a DVD is in the 4:3 ratio, you cannot view it in wide screen.
• Since DVD discs are recorded in various image formats, they will look different depending on
the software, the type of TV, and the TV aspect ratio setting.
Note
Adjusting the TV Aspect Ratio (Screen Size)
SETUP
Page 36
35
Setting Parental Controls (Rating Level)
Use this to restrict playback of adult or violent DVDs you do not want children to view.
•
This function works only if a DVD disc
contains the rating level information.
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
21
Press MENU button
in the stop mode.
Press Cursor
button to move to
‘Setup’ and then
press ENTER button.
4
•
The password is set to "7890" by default.
•
Once the setup is complete, you will be
taken to the previous screen.
•
If you have selected Level 6, you
cannot view DVDs with Level 7 or
higher.
•
The higher the level, the closer the
content is to violent or adult material.
3
5
Press Cursor
button to move to
‘PARENTAL’ and then
press ENTER button.
Press Cursor , button
to select the desired rating
level and then press
ENTER button.
Enter the password
and then press
ENTER button.
Note
Page 37
36
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
21
Press MENU button
in the stop mode.
Press Cursor
button to move to
‘Setup’ and then
press ENTER button.
4
•
Enter the old password, a new
password, and confirm new password.
•
The setting is complete.
3
5
Press Cursor button to
move to ‘PASSWORD’
and then press ENTER
button.
Press ENTER
button.
Enter the password
and then press
ENTER button.
Setting the Password
You can set the password for the Parental (rating level) setting.
SETUP
Page 38
Setting the Wallpaper
While watching a DVD, VCD, or JPEG CD, you can set the image you like as a wallpaper.
DVD VCDJPEG
•
“LOGO COPY DATA” will be
displayed on the TV screen.
•
The selected wallpaper will be
displayed.
•
You can repeat Steps 1 and 2 to
set up to 3 wallpapers.
21
43
During playback, press
PLAY/PAUSE button
when the image you
like comes up.
Press LOGO
button.
Press OPEN/
CLOSE to close
the disc tray.
The power will turn off
and then back on and
the disc tray will open
automatically.
PAUSE
LOGO COPY DATA
Setting the Wallpaper
Select this to set the
Samsung Logo image as
your wallpaper.
Select this to set the desired
image as your wallpaper.
37
Page 39
SETUP
21 3
Press MENU button
in the stop mode.
Press Cursor
button to move to
‘Setup’ and then
press ENTER button.
Press Cursor
button to move to
‘LOGO’ and then
press ENTER button.
To Change the Wallpaper
54
Press MENU
button to exit the
setup screen.
Press to select
the desired ‘USER’,
and then press
ENTER.
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
38
Page 40
39
Setting the DRC (Dynamic Range Compression)
You can use this function to enjoy Dolby Digital sound when watching movies at
low volume at night.
1
2
Press MENU button in the
stop mode.
Press Cursor button to
move to ‘Audio’ and then
press ENTER button.
•
The Cursor button is pressed, the greater
the effect, and the Cursor button is
pressed, the smaller the effect.
3
4
If “DRC” is selected,
press ENTER.
Press Cursor , to
adjust the ‘DRC’.
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
Page 41
40
SETUP
AV SYNC Setup
Press RETURN button to return to the previous level.
Press MENU button to exit the setup screen.
•
'Audio' menu appears.
21
•
Setup menu appears.
•
AV-SYNC screen appears.
3
Press Cursor , buttons
to move to ‘Audio’ and then
press ENTER button.
Press Cursor , buttons
to move to ‘AV-SYNC’ and
then press ENTER button.
Press the MENU button in
the stop mode.
4
•
You can set the audio delay time between 0 ms
and 300 ms. Set it to the optimal status.
Press Cursor , buttons
to select the Delay Time of
AV-SYNC and then press the
ENTER button.
Video may look slower than the audio if it is connected with digital TV.
In this case, adjust the delay time of audio to optimal status to fit the video.
Page 42
41
Listening to Radio
You can listen to the chosen band (FM, MW, LW,SW1,SW2 broadcast stations)
by using either the automatic or manual tuning operation.
2
1
•
The selection toggles back
and forth between "FM➝ MW
➝ LW➝
(SW1,2)" each time
the TUNER(BAND) button is
pressed.
Tune in to the
desired station.
Press TUNER/
BAND button.
21
Select a broadcast
station.
Press the STOP ( )
button to select
PRESET and then press
button to select the preset station.
Automatic Tuning 1
Press the Function
button to select the
desired band (FM,
MW, LW,
SW1,2
).
Press the STOP
( )
button
to select "AUTO" and then
press button to automatically
search the band.
Automatic Tuning 2
Press STOP
( )
to select
MANUAL and then briefly
press to tune in to a lower or
higher frequency.
Manual Tuning
•
Each time the button is pressed, the sound switches between "STEREO" and "MONO".
•
In a poor reception area, select MONO for a clear, interference-free broadcast.
Press MO/ST button to listen in Mono/Stereo.
(This applies only when listening to an FM station.)
Press the STOP ( ) button
to select PRESET and then
press button to select the preset station.
Automatic Tuning 1
Remote Control Unit
Main Unit
Manual Tuning
Press the STOP
( )
button to
select "AUTO" and then press
button to automatically search the band.
Press the STOP
( )
button to
select "MANUAL",Briefly press
to increase or decrease
the frequency incrementally.
Automatic Tuning 2
Page 43
42
Presetting Stations
To tune in to a preset station, press on the
remote control to select a channel.
•
Refer to Step 2 on page 39 to
automatically or manually tune in
to a station.
21
•
Each time the button is pressed,
the band switches between
"FM
➝
MW ➝ LW➝ SW1,2".
•
“PROG” flashes in the
display.
3
Example: Presetting FM 89.1 in the memory
Press to
select "89.10".
Press the
TUNER(BAND)
button and select
the FM band.
•
Press the TUNER MEMORY button before
‘
PROG
’ disappears from the display.
•
‘
PROG
’ disappears from the display and
the station is stored in memory.
54
•
You can select between 1 and
15.
Press the TUNER
MEMORY button.
Press the TUNER
MEMORY button.
6
To preset another
station, repeat
steps 2 to 5.
Press to
select preset
number.
kHz
MHz
kHz
MHz
kHz
MHz
kHz
MHz
kHz
MHz
RADIO OPERATION
You can store up to:
15 FM stations
15 AM stations
15 FM stations
8 AM(MW) stations
7 LW stations
15 FM stations
5 MW stations
5 SW1 stations
5 SW2 stations
• FM Frequency Modulation
• AM(MW) Medium Wave
• LW Long Wave
• SW Short Wave
OPTION
OPTION
OPTION
Page 44
43
Listening to a Cassette
Always treat your cassettes with care; refer, if necessary, to the section entitled
“Precautions When Using Audio Cassettes” on page 55.
•
Insert a cassette with the
recording/playback side facing
the cassette holder, and then
push the cassette door shut.
21 3
Press TAPE on
the player to
select the Tape
function.
Switch the system
on by pressing
POWER.
•
Rewind the cassette / DOWN
button.
•
Fast-forward the cassette UP /
button.
54
•
Side A : Tape ( ) button once.
•
Side B : Tape ( ) button twice.
Press the PUSH
EJECT ( ) of the
cassette deck to open
the cassette door and
insert a cassette.
Press the ,
button if necessary.
6
When you have
finished playback,
press STOP button.
Press the
button. The cassette
starts playing.
Page 45
44
REPEAT A↔B Function
•
Use this to listen to a specific section again during playback.
•
Set the start and end points of the section you want to repeat 3 times.
•
This is a useful when learning a foreign language.
•
The TAPE REPEAT function can be used only on sections that are longer
than 7 seconds.
Press REP. A↔B button.
Selecting the Cassette Playback Mode
Tape Counter
Your micro component system has three cassette playback modes which enable
you to listen to both sides of a cassette automatically.
When playing a cassette, a counter is displayed to enable you to take note of the counter
value at the start of each track and thus start playback at the beginning of the track to
which you wish to listen.
Press REV.MODEuntil the appropriate symbol is
displayed.
•
: One side of the selected cassette and then stops.
•
: One side of the cassette.
The other side of the cassette and then stops.
•
: Both sides of the cassette indefinitely until you press stop.
•
You cannot set the end point (B) within 7 seconds after
setting the start point (A).
Note
TAPE DECK
•
The counter is only displayed when a cassette is being played.
Before starting to record a cassette for which you wish to take note of the
counter values at the beginning of each track, reset the counter by pressing
Counter Reset.
Page 46
45
Timer Function
•
The timer enables you to switch the system on or off at specific times.
•
If you no longer want the system to be switched on or off automatically, you must cancel the timer.
•
Before setting the timer, check that the current time is correct.
•
For each step, you have a few seconds to set the required options.
If you exceed this time, you must start again.
Example: You wish to wake up to music every morning.
•
ON TIME is displayed (instead
of the equalizer symbols) for a
few seconds, followed by any
switch-on time already set; you
can set the timer switch-on time.
•
The source to be selected is
displayed.
2
1
3
Switch the system
on by pressing
POWER.
Press
TIMER/CLOCK
until TIMER is
displayed.
Press the ENTER
button.
•
is displayed to the top-right
of the time, indicating that the
timer has been set.
•
The system will switch on and off
automatically at the required
times.
87
9
Press or button
to select the source to
be played when the
system switches on.
Press ENTER to
confirm the timer.
Press POWER to
set the system to
standby mode.
54
a. Set the hour by pressing or
button.
b. Press ENTER.
•
The minutes flash.
c. Set the minutes by pressing or
button.
d. Press ENTER.
•
OFF TIME is displayed (instead
of the equalizer symbols) for a few
seconds, followed by any switchoff time already set; you can now
set the timer switch-off time.
•
TAPE (cassette) : Insert a cassette
tape.
•
TUNER (radio) : a Press ENTER.
b Select a preset
station by pressing
Tuning or .
•
CD (compact disc) : Load a compact
disc.
a. Set the hour by pressing or
button.
b. Press ENTER.
•
The minutes flash.
c. Set the minutes by pressing or
button.
d. Press ENTER.
•
VOL 10 is displayed, where 10
corresponds to the volume
already set.
Set the timer
switch-off time.
6
Press or button
to adjust the volume
level and press
ENTER.
Set the timer
switch-on time.
Note
•
If the timer switch on and off times are identical, the word ERROR is displayed.
Page 47
46
Canceling the Timer
Note
•
You can cancel the timer while the power is on or while the player is in standby.
After having set the timer, it will start automatically as shown by the TIMER indication on the display.
If you no longer wish to use the timer, you must cancel it.
• is no longer displayed.
To cancel the timer, press TIMER ON/OFF
once.
•
is displayed again.
To resume the timer, press TIMER ON/OFF
again.
MISCELLANEOUS
Page 48
47
Recording a Compact Disc
You can record a compact disc on a cassette in two different ways:
This feature enables you to synchronize the start of the recording with the start of the disc or track of your choice.
•
Press the OPEN/CLOSE button ( )
to open the CD door.
•
Insert a CD and press the
OPEN/CLOSE button ( ) to close
the CD door.
•
Press the PUSH/EJECT button ( )
to open the cassette door, insert a
cassette, and then close the cassette
door.
•
Insert the cassette with the safety
tabs.
2
1
3
Insert a blank
cassette in Deck.
Switch the system
on by pressing
POWER.
•
When stopped, press the button to
start the recording from the first
piece of music.
•
Press and hold (REC/PAUSE)
button during the playback of CD to
start the recording from the first part
of the music being played.
54
•
Use the CD selection ( , )
buttons to select the desired song.
Load a compact
disc.
Press and hold CD
SYNCHRO button.
6
To stop recording,
press button.
Press the DVD/CD
( ) button.
Synchronised recording
Page 49
48
The direct recording mode enables you to start recording with any track on the compact disc.
•
Press the OPEN/CLOSE button ( )
to open the CD door.
•
Insert a CD and press the
OPEN/CLOSE button ( ) to close
the CD door.
•
Press the PUSH/EJECT button ( )
to open the cassette door, insert a
cassette, and then close the cassette
door.
•
Insert the cassette with the safety
tabs.
2
1
3
Insert a blank
cassette in Deck.
Switch the system
on by pressing
POWER.
•
Recording will begin.
•
To stop recording, press button.
54
•
Use the CD selection ( , )
buttons to select the desired song.
Load a compact
disc.
Press REC/ PAUSE
button.
Press the DVD/CD
( ) button.
Direct recording
•
The cassette tape you want to record
on must have the safety tabs intact.
Note
MISCELLANEOUS
Page 50
49
Recording a Radio Program
You can record a radio program of your choice.
You do not need to adjust the volume, as it has no effect on the recording.
2
1 3
Insert a blank
cassette in Deck.
Switch the system
on by pressing
POWER.
•
REC is displayed in red and
recording starts.
54
Select the
TUNER function
by pressing
TUNER/BAND.
Press REC/PAUSE
button.
6
To stop recording,
press button.
Select the radio
station that you wish
to record by pressing
/DOWN or UP/
button .
Page 51
50
EQ/S.BASS, SRS WOW Function
•
Press the button repeatedly to select “PASS➝ POP➝
ROCK➝CLASSISC ➝ JAZZ➝ S,BASS ➝ P,SOUND”.
•
S.BASS Function : S.Bass function emphasizes the bass
sound to produce the effect of explosion or booms.
•
P.SOUND Function : You can experience the powerful
and realistic sound by amplifying bass and improving
the sound quality of high- and low-pitched sounds by
two-fold.
Press EQ/S.BASS on the remote control
until the required option is selected.
EQ/S.BASS Function
Your micro component system is equipped with a preset equalizer that
allows you to choose the most appropriate balance between treble and
bass frequencies, according to the type of music you are listening to.
The function of Power Sound amplifies bass and improves high key or
bass twice as much for you to appreciate powerful real sound.
•
Each time the button is pressed, the selection changes as
follows: TRU BASS ➝ SRS ➝ SRS WOW➝ PASS.
•
TruBASS Function : Enhances the bass and low frequencies to
produce deep and rich bass sounds.
•
SRS Function : Provides the surround sound that fills the room.
•
SRS WOW Function : Provides the surround sound effects with
enhanced sound field depth and bass, through speakers and
headphones.
Press the SRS WOW button.
SRS WOW Function
You can enjoy realistic surround sound by using the SRS and TruBass
sound field functions and the SRS WOW function that enhances sound
clarity.
•
is a trademark of SRS Labs, Inc.
•
WOW technology is incorporated under license from
SRS Labs, Inc.
Note
MISCELLANEOUS
Page 52
51
TREBLE/BASS Function
BASS Function
BASS function stresses low tones providing thudding sound effects.
Turn BASS knob on the front
panel to select from BASS -07
to BASS 07 , total 15 steps.
1
You can select the level of low
tones you desire.
2
TREBLE Function
Treble function stresses low tones providing thudding sound effects.
Turn TREBLE knob on the
front panel to select from TRE -
07 to TRE 07 , total 15 steps.
1
You can select the level of
high tones you desire.
2
Page 53
Sleep Timer Function / Mute Function
•
The remaining time before the DVD player will shut itself off is displayed.
•
Pressing the button again changes the sleep time from what you have set
earlier.
To confirm the sleep timer setting, press SLEEP button.
•
Each time the button is pressed, the selection changes as follows:
90 MIN ➝ 60 MIN ➝ 45 MIN ➝ 30 MIN ➝ 15 MIN ➝ OFF.
Press SLEEP button.
Sleep Timer Function
You can set the time that the DVD player will shut itself off.
To cancel the sleep timer, press SLEEP button until
OFF appears on the display.
•
‘
MUTE ’ appears in the display.
•
To turn off mute, press the button again.
Mute Function
This is useful when answering a doorbell or telephone call.
Press MUTE button.
MHz
MISCELLANEOUS
52
Page 54
53
•
The various functions available are listed in turn on the
display.
•
All these functions are described in detail in this booklet.
For instructions on how to use them, refer to the
appropriate sections.
DEMO Function
You can view the various functions available on
your system.
To cancel this function, press
DEMO/DIMMER again.
Press and hold DEMO/DIMMER
button.
•
Each time the button is press, the brightness changes as
follows: DIMMER ON(Dim) ➞ DIMMER OFF(Bright).
DIMMER Function
You can adjust the brightness of the display on the main
unit so it won't interfere with your movie viewing.
Press DEMO/DIMMER button.
DEMO Function / DIMMER Function
Page 55
•
The loudspeakers are no longer used to output the sound.
•
Connect the Microphone.
Connect the headphones to the PHONES jack on the front panel.
Connecting Headphones/Microphone(option)
You can connect a set of headphones to your micro component system so that you
can listen to music or radio programmers without disturbing other people in the room.
The earphones must have a 3.5ø jack or an appropriate adapter.
•
Prolonged use of headphones at a high volume may damage your hearing.
Note
Plug the microphone with a 3.5ø MIC jack into microphone
terminal.
54
MISCELLANEOUS
Page 56
55
Do not touch the playback side of the disc. Hold
the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.
When you get fingerprints or dirt on the disc, clean it
with a mild detergent diluted in water and wipe with a
soft cloth.
•
When cleaning, wipe gently from the inside to the outside of the disc.
Handling discs
Handling and Storing Discs
Cautions on Handling and Storing Discs
Small scratches on the disc may reduce sound and picture quality or cause breaks in
playback. Be especially careful not to scratch discs when handling them.
•
Condensation may form if warm air comes into contact with cold parts
inside the player. When condensation forms inside the player, the player
may not operate correctly. If this occurs, remove the disc and let the
player stand for 1 or 2 hours with the power on.
Note
•
Check that the tape in the cassette is sufficiently taut.
•
To prevent erasing a cassette that you wish to keep, remove the safety tab on the upper edge of the
cassette. To record a cassette, where the tab has been broken, simply cover the opening with adhesive
tape.
•
When you have finished playing a cassette, always put it back in its case.
•
Store your cassettes in a clean place, out of direct sunlight, where they will not be exposed to high
temperatures.
•
Avoid using 120-minute cassettes as they place unnecessary strain on the tape mechanism.
Precautions When Using Audio Cassettes
Page 57
Before Calling for Service
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not
listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact
the nearest authorized dealer or Samsung Electronics Service Center.
•
Is the power cord plugged securely into the outlet?
•
Turn off the power and then turn it back on.
•
Check the region number of the DVD.
DVD discs purchased from abroad may not be playable.
•
CD-ROMs and DVD-ROMs cannot be played on this DVD
player.
•
Make sure that the rating level is correct.
•
Are you using a deformed disc or a disc with scratches on
the surface?
•
Wipe the disc clean.
Disc tray does not open.
Playback does not start.
Playback does not start
immediately when the
Play/Pause button is pressed.
•
No sound is heard during fast playback, slow playback, and step
motion playback.
•
Are the speakers connected properly? Is the speaker setup
correctly customized?
•
Is the disc severely damaged?
Sound is not produced.
•
Was the DVD player suddenly moved from a cold place to a warm
one? When condensation forms inside the player, remove the disc
and let the player stand for 1 or 2 hours with the power on. (You
can use the player again after condensation disappears.)
Picture does not appear, sound
is not produced, or the disc
tray opens 2 to 5 seconds later.
Symptom Check/Remedy
•
Is the TV power on?
•
Are the video cables connected properly?
•
Is the disc dirty or damaged?
•
A poorly manufactured disc may not be playable.
• Disc is rotating but no
picture is produced.
• Picture quality is poor and
picture is shaking.
•
Is the remote control being operated within its operation range of
angle and distance?
•
Are the batteries exhausted?
The remote control does
not work.
56
MISCELLANEOUS
Page 58
57
•
Audio language and subtitles will not work for DVDs not containing
them. And depending on the disc, they may work differently.
Audio language and
subtitles do not work.
•
The TAPE function has not been selected.
•
The cassette has not been inserted correctly.
•
The cassette player has not been closed.
•
The tape is either slack or broken.
The tape does not start
playing
•
The audio heads are dirty.
•
The rollers or drive capstans are dirty.
•
The tape is worn.
The volume falls off
The cassette is not erased correctly
There is excessive wow and flutter
•
Are you using a disc that does not contain menus?
Menu screen does not appear even
when the menu function is selected.
•
While the player is in the stop mode, hold the main unit's TUNING
MODE/ button for longer than 5 seconds. “INITIAL” appears on the
display and all settings will return to the default values.
•
Press the POWER button.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
•
Turn off the power and hold the SRS WOW button on the main unit
for longer than 5 seconds.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
The password for rating
level has been forgotten.
•
The main unit is not working.
(Example: The power goes out or
strange noise is heard.)
• The DVD player is not
working normally.
•
Is the antenna connected properly?
•
If the antenna's input signal is weak, install an external FM
antenna in an area with good reception.
Can't receive radio
broadcast.
Symptom Check/Remedy
•
You can play 16:9 DVDs in 16:9 WIDE mode, 4:3 LETTER BOX
mode, or 4:3 PAN SCAN mode, but 4:3 DVDs can be seen in 4:3
ratio only. Refer to the DVD disc jacket and then select the
appropriate function.
Aspect ratio cannot be
changed.
Page 59
CD-R Discs
•
Depending on the disc recording device (CD-Recorder or PC ) and the condition of the disc, some CD-R discs
may not be playable.
•
Use a 650MB/74 minute CD-R. Avoid CD-R media, as they may not be playable.
•
If possible, do not use CD-RW (Rewritable) media, as they may not be playable.
•
Only the CD-Rs that are properly "closed" can be fully played. If the session is closed but the disc is left open,
you may not be able to fully play the disc.
CD-R JPEG Discs
•
Only files with the ".jpeg" and ".JPEG" extensions can be played.
•
If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played.
•
Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.
•
JPEG file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).
•
Only a consecutively written multisession disc can be played. If there is a blank segment in the multisession disc, the
disc can be played only up to the blank segment.
•
A maximum of 9,999 images can be stored on a single CD.
•
When playing a Kodak/Fuji Picture CD, only the JPEG files in the picture folder can be played.
•
Picture discs other than Kodak/Fuji Picture CDs may take longer to start playing or may not play at all.
Disc Recording Format
CD-R MP3 Discs
•
Only CD-R discs with MP3 files in ISO 9660 or Joliet format can be played.
•
MP3 file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).
•
If the name of a file is in Korean, the name will be displayed on the TV screen in Korean and * will be shown in the
display of the main unit.
•
Use discs recorded with a compression/decompression data rate greater than 128Kbps.
•
Only files with the ".mp3" and ".MP3" extensions can be played.
•
Only a consecutively written Multisession disc can be played. If there is a blank segment in the Multisession disc, the
disc can be played only up to the blank segment.
•
If the disc is not closed, it will take longer to begin playback and not all of the recorded files may be played.
•
For files encoded in Variable Bit Rate (VBR) format, i.e. files encoded in both low bit rate and high bit rate (e.g.,
32Kbps ~ 320Kbps), the sound may skip during playback.
•
If more than 500 tracks are recorded on a single CD, a maximum of 500 tracks can be played.
•
If more than 300 folders are recorded on a single CD, a maximum of 300 folders can be played.
What is MP3?
MP3 is short for MPEG-1 Audio Layer 3 and MPEG is an acronym for Moving Pictures Experts
Group. MP3 is a file format with compression ratio of 1:12 (128 Kbps*) That is, you can use MP3
format to record about 12 times the usual amount of data on a regular CD.
Notes on Discs
58
MISCELLANEOUS
Page 60
59
Notes on Terminology
Recorded onto some DVD discs are scenes which have been simultaneously shot
from a number of different angles (the same scene is shot from the front, from the
left , from the right , etc.).
With such discs, the Angle button can be used to change the angle of view for
specific scenes.
ANGLE
These numbers are recorded on DVD discs. A Title is subdivided into many
sections, each of which is numbered, and specific parts of the video can be
searched quickly using these numbers.
A high-density optical disc on which high-quality pictures and sound have been
recorded by means of digital signals. Incorporating a new video compression
technology (MPEG-2) and high-density recording technology, a DVD disc
comprises two 0.6 mm thick discs bonded together.
An acronym for Pulse Code Modulation - another name for digital audio.
This is recorded on a video CD (version 2.0). Selected scenes or information can
be chosen from the menu displayed on the TV monitor.
Both the DVD player and DVD discs are encoded with a region number.
If the region number on the DVD disc does not correspond to the region number
of the DVD player, the player cannot play the disc.
Translated appearing at the bottom of the screen. A DVD disc can contain up to
32 subtitle languages.
These numbers are recorded on DVD discs. When a disc contains two or more
movies, these movies are numbered as Title 1, Title 2, etc.
These numbers are assigned to the tracks which are recorded on video and
audio CDs. They enable specific tracks to be located quickly.
Contains recordings of pictures and sound whose quality is roughly comparable
to that of video tape.
This player also supports video CDs with playback control (version 2.0).
5.1 (or 6) Channel Digital Surround sound reproduced from DVDs and LDs
recorded as a digital signals (with disc marking). With better sound quality,
dynamic range, and directionality than traditional Dolby surround technology, you
can enjoy dynamic, realistic sound.
CHAPTER
NUMBER
DVD
PCM
PBC
(PLAYBACK
CONTROL)
REGION NUMBER
SUBTITLES
TITLE NUMBER
TRACK NUMBER
VIDEO CD
Page 61
Specifications
Power Consumption
Weight
Dimensions (W x H x D)
Operating Temperature Range
Operating Humidity Range
Usable Sensitivity
S/N Ratio
Distortion
Usable Sensitivity
S/N Ratio
Distortion
Composite Video
S-VIDEO
Speaker output
Frequency range
S/N Ratio
Channel separation
Input sensitivity
G
E
N
E
R
A
L
T
U
N
E
R
F
M
T
U
N
E
R
MW
/LW
/SW
VIDEO
OUTPUT
A
M
P
L
I
F
I
E
R
85W
11.5Kg
194 x 172 x 310 mm
+5°C~+35°C
10%~75%
3dB
60dB
1.0%
56dB/40dB
40dB
2%
1.0Vp-p(75Ω load)
Luminance signal : 1.0Vp-p(75Ω load)
Color Signal : 0.286Vp-p(75Ω load)
45W/ch
20Hz~20kHz
75dB
50dB
(AUX)500mV
60
MISCELLANEOUS
Impedance
Frequency range
Output sound pressure level
Rated input
Maximum input
Dimensions
(W x H x D)
Weights
S
P
E
A
K
E
R
speaker system
Loudspeakers
4Ω x 2
20 Hz - 20 KHz (± 1 dB)
84dB/W/M
35W
90W
150(W) x 237 (H) x 249(D) mm
4.7 Kg
Speaker system
Page 62
Language Code List
Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle”
and/or “Disc Menu” (See page 31).
Code Language Code Language Code Language Code Language
1027 Afar 1181 Frisian 1334 Latvian, Lettish 1506 Slovenian
1028 Abkhazian 1183 Irish 1345 Malagasy 1507 Samoan
1032 Afrikaans 1186 Scots Gaelic 1347 Maori 1508 Shona
1039 Amharic 1194 Galician 1349 Macedonian 1509 Somali
1044 Arabic 1196 Guarani 1350 Malayalam 1511 Albanian
1045 Assamese 1203 Gujarati 1352 Mongolian 1512 Serbian
1051 Aymara 1209 Hausa 1353 Moldavian 1513 Siswati
1052 Azerbaijani 1217 Hindi 1356 Marathi 1514 Sesotho
1053 Bashkir 1226 Croatian 1357 Malay 1515 Sundanese
1057 Byelorussian 1229 Hungarian 1358 Maltese 1516 Swedish
1059 Bulgarian 1233 Armenian 1363 Burmese 1517 Swahili
1060 Bihari 1235 Interlingua 1365 Nauru 1521 Tamil
1069 Bislama 1239 Interlingue 1369 Nepali 1525 Tegulu
1066 Bengali; Bangla 1245 Inupiak 1376 Dutch 1527 Tajik
1067 Tibetan 1248 Indonesian 1379 Norwegian 1528 Thai
1070 Breton 1253 Icelandic 1393 Occitan 1529 Tigrinya
1079 Catalan 1254 Italian 1403 (Afan) Oromo 1531 Turkmen
1093 Corsican 1257 Hebrew 1408 Oriya 1532 Tagalog
1097 Czech 1261 Japanese 1417 Punjabi 1534 Setswana
1103 Welsh 1269 Yiddish 1428 Polish 1535 Tonga
1105 Danish 1283 Javanese 1435 Pashto, Pushto 1538 Turkish
1109 German 1287 Georgian 1436 Portuguese 1539 Tsonga
1130 Bhutani 1297 Kazakh 1463 Quechua 1540 Tatar
1142 Greek 1298 Greenlandic 1481 Rhaeto-Romance 1543 Twi
1144 English 1299 Cambodian 1482 Kirundi 1557 Ukrainian
1145 Esperanto 1300 Kannada 1483 Romanian 1564 Urdu
1149 Spanish 1301 Korean 1489 Russian 1572 Uzbek
1150 Estonian 1305 Kashmiri 1491 Kinyarwanda 1581 Vietnamese
1151 Basque 1307 Kurdish 1495 Sanskrit 1587 Volapuk
1157 Persian 1311 Kirghiz 1498 Sindhi 1613 Wolof
1165 Finnish 1313 Latin 1501 Sangro 1632 Xhosa
1166 Fiji 1326 Lingala 1502 Serbo-Croatian 1665 Yoruba
1171 Faeroese 1327 Laothian 1503 Singhalese 1684 Chinese
1174 French 1332 Lithuanian 1505 Slovak 1697 Zulu
61
Page 63
AH68-01407K
THIS APPLIANCE IS MANUFACTURED BY:
Loading...
