Samsung MG23K3575AW Operating Instructions

Microwave Oven

User manual

MG23K3575

MG23K3575AK_EU_DE68-04403D-00_EN.indd 1 1/7/2016 11:50:38 AM

Contents

Using this user manual 3

Contents

The following symbols are used in this User Manual: 3

Safety instructions 3

Important safety instructions 3 Correct Disposal of This Product

(Waste Electrical & Electronic Equipment) 8

Installation 11

Accessories 11 Installation site 11 Turntable 11

Maintenance 12

Cleaning 12 Replacement (repair) 12 Care against an extended period of disuse 12

Quick look-up guide 13

Oven features 13

Oven 13 Control panel 14

Oven use 14

How a microwave oven works 14 Checking that your oven is operating correctly 15 Cooking/Reheating 15 Setting the time 16 Power levels and time variations 16 Adjusting the cooking time 17 Stopping the cooking 17 Setting the energy save mode 17 Using the heat wave grill features 18 Using the heat wave auto features 18 Using the quick defrost features 21 Using the auto cook features 22 Using the keep warm features 24 Combining microwaves and grill 25 Using the grill+30s features 26 Using the child lock features 26 Switching the beeper off 26

Cookware guide 27

Cooking guide 28

Troubleshooting and information code 37

Troubleshooting 37 Information code 40

Technical specifications 41

2 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 2 1/7/2016 11:50:38 AM

Using this user manual

You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contains valuable information on cooking with your microwave oven:

• Safety precautions

• Suitable accessories and cookware

• Useful cooking tips

• Cooking tips

Safety instructions

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.

MICROWAVE FUNCTION ONLY

Using this user manual

The following symbols are used in this User Manual:

WARNING

Hazards or unsafe practices that may result in severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or property damage.

NOTE

Useful tips, recommendations, or information that helps users manipulate the product.

WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.

WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

This appliance is intended to be used in household only and it is not intended to be used such as:

• staff kitchen areas in shops, offices and other working environments;

• farm houses;

English 3

MG23K3575AK_EU_DE68-04403D-00_EN.indd 3 1/7/2016 11:50:39 AM

Safety instructions

• by clients in hotels, motels and other residential environments;

• bed and breakfast type environments.

Only use utensils that are suitable for use in microwave ovens. When heating food in plastic or paper containers, keep an eye

on the oven due to the possibility of ignition. Metallic containers for food and beverages are not allowed

during microwave cooking. The microwave oven is intended for heating food and

beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.

If smoke is observed (emitted), switch off or unplug the appliance and keep the door closed in order to stifle any flames.

Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.

The oven should be cleaned regularly and any food deposits removed.

Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

The microwave oven is intended to be used on the counter top (freestanding) use only, the microwave oven shall not be placed in a cabinet.

The appliance should not be cleaned with a water jet. The appliance is not intended for installing in road vehicles,

caravans and similar vehicles etc. This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.

4 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 4 1/7/2016 11:50:39 AM

appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play

with the appliance.

This appliance can be used by children aged from 8 years and

OVEN FUNCTION ONLY  OPTIONAL

above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

This oven should be positioned proper direction and height permitting easy access to cavity and control area.

Before using the your oven first time, oven should be operated with the water during 10 minute and then used.

If the oven generates a strange noise, a burning smell, or smoke is emitted, unplug the power plug immediately and contact your nearest service center.

The microwave oven has to be positioned so that plug is accessible.

WARNING: When the appliance is operated in the combination

mode, children should only use the oven under adult

supervision due to the temperatures generated.

During use the appliance becomes hot. Care should be taken to

avoid touching heating elements inside the oven.

WARNING: Accessible parts may become hot during use. Young

children should be kept away.

A steam cleaner is not to be used.

Do not use harsh abrasive cleaners or sharp metal scrapers to

clean the oven door glass since they can scratch the surface,

which may result in shattering of the glass.

WARNING: Ensure that the appliance is switched off before

replacing the lamp to avoid the possibility of electric shock.

Do not use harsh abrasive cleaners or sharp metal scrapers to

clean the oven door glass since they can scratch the surface,

which may result in shattering of the glass.

WARNING: The appliance and its accessible parts become hot

during use.

Safety instructions

Care should be taken to avoid touching heating elements.

English 5

MG23K3575AK_EU_DE68-04403D-00_EN.indd 5 1/7/2016 11:50:39 AM

Safety instructions

Children less than 8 years of age shall be kept away unless continuously supervised.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

The door or the outer surface may get hot when the appliance is operating.

The temperature of accessible surfaces may be high when the appliance is operating.

The appliances are not intended to be operated by means of an external timer or separate remote-control system.

This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children unless they are

older than 8 and supervised.

Keep the appliance and its cord out of reach of children less

than 8 years.

General safety

Any modifications or repairs must be performed by qualified personnel only.

Do not heat food or liquids sealed in containers for the microwave function.

Do not use benzene, thinner, alcohol, or steam or high-pressure cleaners to clean

the oven.

Do not install the oven: near a heater or flammable material; locations that are

humid, oily, dusty or exposed to direct sunlight or water; or where gas may leak;

or an uneven surface.

This oven must be properly grounded in accordance with local and national codes.

Regularly use a dry cloth to remove foreign substances from the power plug

terminals and contacts.

Do not pull, excessively bend, or place heavy objects on the power cord.

If there is a gas leak (propane, LP, etc) ventilate immediately. Do not touch the

power cord.

Do not touch the power cord with wet hands.

While the oven is operating, do not turn it off by unplugging the power cord.

Do not insert fingers or foreign substances. If foreign substances enter the oven,

unplug the power cord and contact a local Samsung service centre.

6 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 6 1/7/2016 11:50:39 AM

Do not apply excessive pressure or impact to the oven. Do not place the oven over fragile objects. Ensure the power voltage, frequency, and current matches the product specifications. Firmly plug the power plug into the wall socket. Do not use multiple plug adapters, extension cords, or electric transformers. Do not hook the power cord on metal objects. Make sure the cord is between objects or behind the oven. Do not use a damaged power plug, power cord, or loose wall socket. For damaged power plugs or cords, contact a local Samsung service centre. Do not pour or directly spray water onto the oven. Do not place objects on the oven, inside, or on the oven door. Do not spray volatile materials such as insecticide on the oven. Do not store flammable materials in the oven. Because alcohol vapours can contact hot parts of the oven, use caution when heating food or drinks containing alcohol. Children may bump themselves or catch their fingers on the door. When opening/ closing the door, keep children away.

Microwave warning

Microwave heating of beverages may result in delayed eruptive boiling; always use caution when handling the container. Always allow beverages to stand at least 20 seconds before handling. If necessary, stir during heating. Always stir after heating. In the event of scalding, follow these First Aid instructions:

1. Immerse the scalded area in cold water for at least 10 minutes.

2. Cover with a clean, dry dressing.

3. Do not apply any creams, oils, or lotions.

To avoid damaging the tray or rack, do not put the tray or rack in water shortly after cooking. Do not use the oven for deep fat frying because the oil temperature cannot be controlled. This could result in a sudden boil over of hot oils.

Microwave oven precautions

Only use microwave-safe utensils. Do not use metallic containers, gold or silver

trimmed dinnerware, skewers, etc.

Remove wire twist ties. Electric arcing may occur.

Do not use the oven to dry papers or clothes.

Use shorter times for small amounts of food to prevent overheating or burning.

Keep the power cord and power plug away from water and heat sources.

To avoid the risk of explosion, do not heat eggs with shells or hard-boiled eggs. Do

not heat airtight or vacuum-sealed containers, nuts, tomatoes, etc.

Do not cover the ventilation slots with cloth or paper. This is a fire hazard. The

oven may overheat and turn off automatically and will remain off until it cools

sufficiently.

Always use oven mitts when removing a dish.

Stir liquids halfway during heating or after heating ends and allow the liquid stand

at least 20 seconds after heating to prevent eruptive boiling.

Stand at arms length from the oven when opening the door to avoid getting

scalded by escaping hot air or steam.

Do not operate the oven when it is empty. The oven will automatically shut down

for 30 minutes for safety purposes. We recommend placing a glass of water inside

the oven at all times to absorb microwave energy in case the oven is started

accidentally.

Install the oven in compliance with the clearances in this manual. (See Installing

your microwave oven.)

Use caution when connecting other electrical appliances to sockets near the oven.

Microwave operation precautions

Failure to observe the following safety precautions may result in harmful exposure

to microwave energy.

• Do not operate the oven with the door open. Do not tamper with the safety interlocks (door latches). Do not insert anything into the safety interlock holes.

• Do not place any object between the oven door and front face or allow food or cleaner residue to accumulate on sealing surfaces. Keep the door and door sealing surfaces clean by wiping with a damp cloth and then with a soft, dry cloth after each use.

Safety instructions

English 7

MG23K3575AK_EU_DE68-04403D-00_EN.indd 7 1/7/2016 11:50:39 AM

Safety instructions

• Do not operate the oven if it is damaged. Only operate after it has been repaired by a qualified technician. Important: the oven door must close properly. The door must not be bent; the door hinges must not be broken or loose; the door seals and sealing surfaces must not be damaged.

• All adjustments or repairs must be done by a qualified technician.

Limited warranty

Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the damage to the unit or accessory was caused by the customer. Items this stipulation covers include:

• Door, handles, out-panel, or control panel that are dented, scratched, or broken.

• A broken or missing tray, guide roller, coupler, or wire rack.

Use this oven only for its intended purpose as described in this instruction manual. Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your oven. Because these following operating instructions cover various models, the characteristics of your microwave oven may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact a local Samsung service centre or find help and information online at www.samsung.com. Use this oven for heating food only. It is intended for domestic use only. Do not heat any type of textiles or cushions filled with grains. The manufacturer cannot be held liable for damage caused by improper or incorrect use of the oven. To avoid deterioration of the oven surface and hazardous situations, always keep the oven clean and well maintained.

Product group definition

This product is a Group 2 Class B ISM equipment. The definition of group 2 which contains all ISM equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and EDM and arc welding equipment. For Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purposes.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH visit: samsung.com/uk/aboutsamsung/ samsungelectronics/corporatecitizenship/data_corner.html

8 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 8 1/7/2016 11:50:40 AM

INSTALLATION & WIRING INSTRUCTIONS

IMPORTANT NOTE :

The mains lead on this equipment is supplied with a moulded plug incorporating a fuse.

The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BS1363 of the same rating must be used.

Never use the plug with the fuse cover omitted if the cover is detachable. If a replacement fuse cover is required, it must be of the same colour as the pin face of the plug.

Replacement covers are available from your Dealer. If the fitted plug is not suitable for the power points in your house or the cable is not long enough to reach a power point, you should obtain a suitable safety approved extension lead or consult your Dealer for assistance. However, if there is no alternative to cutting off the plug, remove the fuse and then safely dispose of the plug. Do not connect the plug to a mains socket, as there is a risk of shock hazard from the bared flexible cord.

WIRING INSTRUCTIONS

WARNING THIS APPLIANCE MUST BE EARTHED.

This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock providing an escape wire for the electric current. The appliance is equipped with a mains lead which includes an earth wire for connecting to the earth terminal of your mains plug. The plug must be plugged into a socket that is properly installed and earthed.

IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:

• Green and yellow : Earth

• Blue : Neutral

• Brown : Live

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings indentifying the terminals in your plug, proceed as follows.

Connect the green and yellow wire to the terminal in the plug marked with the letter E or the earth symbol ( ) or coloured green or green-and-yellow.

Connect the blue wire to the terminal marked with the letter N or coloured black.

IMPORTANT: Consult a qualified electrician or service technician if in doubt about any of these instructions.

The manufacturer of this oven will not accept any liability for damage to persons or material for non observance of these requirements.

There are no user-serviceable parts inside the oven and if the mains lead of this appliance is damaged, it must only be replaced by qualified service personnel approved by the manufacturer because special tools are required.

01 02

WARNING: Ensure that the plug and power cord are not damaged before use. If you have any reason to remove the moulded plug from this appliance, immediately remove the fuse and dispose of the plug.

Do not connect the plug to a mains socket under any circumstances as there is a danger of electric shock.

CIRCUITS: Your microwave oven should be operated on a separate circuit from other appliances. Failure to do this may cause the

03 04

circuit breaker to trip, the fuse to blow, or the food to cook more slowly.

01 GREEN AND YELLOW 02 13 AMP FUSE 03 BLUE 04 BROWN

Safety instructions

English 9

MG23K3575AK_EU_DE68-04403D-00_EN.indd 9 1/7/2016 11:50:40 AM

Safety instructions

COOKING INSTRUCTIONS ON FOOD PACKAGING

Microwave Symbols

On the front of your oven there is a microwave oven symbol, as shown below.

This symbol has been introduced for your benefit when cooking or reheating packaged food.

Packaged food is also, increasingly, using a microwave symbol similar to the one below. When you see this

Symbol on food packaging, cooking instructions are based on either the IEC Power Output Rating, or the Reheating Categories A, B, C, D or E.

COOKING INSTRUCTIONS

The IEC Power Output rating is an internationally standardised rating, so all microwave manufacturers now use the same method of measuring power output.

If food packaging gives cooking instructions based on IEC Power ratings, set cooking times according to the IEC Power of your oven.

For example :

If the cooking instructions are based on a 650 W oven, then you will need to reduce some cooking time for the MG23K3575** (800 W).

Ready meals are now very convenient and popular. These are meals which are already prepared and cooked by the food manufacturer, and then frozen, chilled or vacuum sealed for long life.

Increasingly, heating times for such ready meals are being based on the Heating Categories A, B, C, D and E.

On this instance, simply match the heating category of your oven to the instructions on the food package, and set your timer accordingly.

For example :

If the heating instructions are 3 minutes on HIGH for a D category oven, then you will need to set your timer for less than 3 minutes on HIGH for the MG23K3575** (E category).

IMPORTANT: Always remember that cooking instructions are intended only as a guide. If you have followed the instructions and the food is still not piping hot throughout, simply return it to the oven and cook it until it is.

10 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 10 1/7/2016 11:50:40 AM

Installation

Accessories

Depending on the model that you have purchased, you are supplied with several accessories that can be used in a variety of ways.

IMPORTANT

DO NOT operate the microwave oven without the roller ring and turntable.

01 Roller ring, to be placed in the centre

of the oven. Purpose: The roller ring supports the

turntable.

02 Turntable, to be placed on the roller

ring with the centre fitting to the coupler. Purpose: The turntable serves as the

main cooking surface; it can be easily removed for cleaning.

03 Grill rack, to be placed on the turntable.

Purpose: The metal rack can be used

in grill and combination cooking.

Installation site

20 cm above

85 cm of the

floor

Turntable

10 cm

behind

10 cm on

the side

• Select a flat, level surface approx. 85 cm above the floor. The surface must support the weight of the oven.

• Secure room for ventilation, at least 10 cm from the rear wall and both sides, and 20 cm from above.

• Do not install the oven in hot or damp surroundings, such as next to other microwave ovens or radiators.

• Conform to the power supply specifications of this oven. Use only approved extension cables if you need to use.

• Wipe the interior and the door seal with a damp cloth before using your oven for the first time.

Remove all packing materials inside the oven. Install the roller ring and turntable. Check that the turntable rotates freely.

Installation

English 11

MG23K3575AK_EU_DE68-04403D-00_EN.indd 11 1/7/2016 11:50:41 AM

Maintenance

Cleaning

Clean the oven regularly to prevent impurities from building up on or inside the oven. Also pay special attention to the door, door sealing, and turntable and roller ring (applicable models only). If the door won’t open or close smoothly, first check if the door seals have built up impurities. Use a soft cloth in soapy water to clean both the inner and outer sides of the oven. Rinse and dry well.

To remove stubborn impurities with bad smells from inside the oven

1. With an empty oven, put a cup of diluted lemon juice on the centre of the

Maintenance

turntable.

2. Heat the oven for 10 minutes at max power.

3. When the cycle is complete, wait until the oven cools down. Then, open the

door and clean the cooking chamber.

To clean inside swing-heater models

To clean the upper area of the cooking chamber, lower the top heating element by 45° as shown. This will help clean the upper area. When done, reposition the top heating element.

CAUTION

• Keep the door and door sealing clean and ensure the door opens and closes smoothly. Otherwise, the oven’s lifecycle may be shortened.

• Take caution not to spill water into the oven vents.

• Do not use any abrasive or chemical substances for cleaning.

• After each use of the oven, use a mild detergent to clean the cooking chamber

after waiting for the oven to cool down.

Replacement (repair)

WARNING

This oven has no user-removable parts inside. Do not try to replace or repair the oven yourself.

• If you encounter a problem with hinges, sealing, and/or the door, contact a qualified technician or a local Samsung service centre for technical assistance.

• If you want to replace the light bulb, contact a local Samsung service centre. Do not replace it yourself.

• If you encounter a problem with the outer housing of the oven, first unplug the power cord from the power source, and then contact a local Samsung service centre.

Care against an extended period of disuse

• If you don’t use the oven for an extended period of time, unplug the power cord and move the oven to a dry, dust-free location. Dust and moisture that builds up inside the oven may affect the performance of the oven.

12 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 12 1/7/2016 11:50:41 AM

Quick look-up guide

Oven features

If you want to cook some food.

If you want to grilling some food

If you want to add an extra 30 seconds.

Place the food in the oven. Press the

START/+30s button.

Result: Cooking starts. When it has

finished.

1) The oven beeps 4 times.

2) The end reminder signal will beep 3 times (once every minute).

3) The current time is displayed again.

Place the food in the oven. Press the

Grill+30s button.

Result: Grilling starts.

1) The oven beeps 4 times.

2) The end reminder signal will beep 3 times (once every minute).

3) The current time is displayed again.

1. Press the START/+30s button one or more times for each extra 30 seconds that you wish to add.

2. By turning the Dial Knob, You can set the time as you want.

Oven

01 02 060504

01 Door handle 02 Door 03 Ventilation holes

04 Plate grill 05 Heating element 06 Light

07 Door latches 08 Turntable 09 Coupler

10 Roller ring 11 Safety interlock holes

1007

11 120908

12 Control panel

Quick look-up guide

English 13

MG23K3575AK_EU_DE68-04403D-00_EN.indd 13 1/7/2016 11:50:41 AM

Oven features

Oven use

Control panel

01 Heat Wave Grill Button 02 Heat Wave Auto Button 03 Quick Defrost Button 04 Auto Cook Button 05 Microwave Button 06 Keep Warm Button

Oven features

07 Combi Button 08 Grill+30s Button 09 Dial Knob (Weight/Serving/Time) 10 Select/Clock Button 11 Stop/Eco Button 12 Start/+30s Button

How a microwave oven works

Microwaves are high-frequency electromagnetic waves; the energy released enables food to be cooked or reheated without changing either the form or the colour.

You can use your microwave oven to:

• Defrost

• Reheat

• Cook

Cooking principle.

1. The microwaves generated by the magnetron reflected at cavity and are distributed uniformly as the food rotates on the turntable. The food is thus cooked evenly.

2. The microwaves are absorbed by the food up to a depth of about 1 inch (2.5 cm). Cooking then continues as the heat is dissipated within the food.

3. Cooking times vary according to the container used and the properties of the food:

• Quantity and density

• Water content

• Initial temperature (refrigerated

or not)

IMPORTANT

As the centre of the food is cooked by heat dissipation, cooking continues even when you have taken the food out of the oven. Standing times specified in recipes and in this booklet must therefore be respected to ensure:

• Even cooking of the food right to the centre.

• The same temperature throughout the food.

14 English

MG23K3575AK_EU_DE68-04403D-00_EN.indd 14 1/7/2016 11:50:42 AM

+ 30 hidden pages
