LFD DISPLAY
User Manual
ME32C ME40C ME46C ME55C
The color and the appearance may differ depending on the
product, and the specifications are subject to change without
prior notice to improve the performance.
BN46-00098R-04
Table of contents
Before Using the Product
Copyright 7
Safety Precautions 8
Symbols 8
Cleaning 8
Storage 9
Electricity and Safety 9
Installation 10
Operation 12
Preparations
Checking the Contents 16
Removing the Packaging
(for ME32C ME40C and ME46C models only) 16
Removing the Packaging
(for ME55C models only) 17
Checking the Components 18
Parts 20
Control Panel 20
Assembling the Holder-Wire stand 23
Anti-theft Lock 23
Remote Control 24
Connection Using an IR Stereo Cable (sold
separately) 27
Before Installing the Product
(Installation Guide) 28
Tilting Angle and Rotation 28
Ventilation 28
Dimensions 29
Installing the Wall Mount 30
Preparing before installing Wall-Mount 30
Installing the Wall Mount Kit 30
Wall Mount Kit Specifications (VESA) 31
Remote Control (RS232C) 32
Cable Connection 32
Connection 35
Control Codes 36
Connecting and Using a Source
Device
Before Connecting 46
Pre-connection Checkpoints 46
Connecting to a PC 47
Connection using the D-SUB cable
(Analog type) 47
Connection using a DVI cable (Digital type) 48
Connection Using an HDMI-DVI Cable 48
Connection Using an HDMI Cable 49
Connection Using an DP Cable 49
Changing the Resolution 50
Changing the Resolution on Windows XP 50
Changing the Resolution on Windows Vista 50
Changing the Resolution on Windows 7 51
Changing the Resolution on Windows 8 51
Connecting an External Monitor 52
Connecting to a Video Device 53
Connection Using the AV Cable 53
Connection Using the component Cable 54
Connection Using an HDMI-DVI Cable 54
Connection Using an HDMI Cable 55
Connecting to an Audio System 56
Connecting the antenna 56
Connecting the network box
(Sold separately) 57
MagicInfo 57
Changing the Input source 60
Source 60
Using MDC
Configuring Settings for Multi Control 61
Configuring settings for Multi Control 61
MDC Program Installation/Uninstallation 62
Installation 62
Uninstallation 62
What is MDC? 63
Connecting to MDC 63
Connection Management 66
User Login 67
Auto Set ID 68
Cloning 69
Command Retry 70
2
Table of contents
Getting Started with MDC 71
Main Screen Layout 72
Menus 72
Screen Adjustment 74
Advanced features 77
Sound Adjustment 79
System Setup 79
Tool Settings 88
Other Functions 91
Group Management 92
Schedule Management 94
Troubleshooting Guide 96
Screen Adjustment
Picture Mode 98
If the input source is PC, DVI or DisplayPort 98
If the input source is AV, Component, HDMI1,
HDMI2, or TV
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R)
Screen Adjustment 100
Picture Size 100
Position 102
Zoom/Position 102
PC Screen Adjustment 103
Resolution Select 103
Auto Adjustment 104
Rotation 104
98
99
Aspect Ratio 105
Advanced Settings 106
Dynamic Contrast 107
Black Tone 107
Flesh Tone 107
RGB Only Mode 107
Color Space 107
White Balance 108
10p White Balance 108
Gamma 108
Expert Pattern 109
Motion Lighting 109
Picture Options 110
Color Tone 111
Color Temp. 111
Digital Noise Filter 111
MPEG Noise Filter 111
HDMI Black Level 112
Film Mode 112
Auto Motion Plus (for ME55C models only) 113
Dynamic Backlight 113
Reset Picture 114
Sound Adjustment
Sound Mode 115
Sound Effect 116
Broadcast Audio Options 117
Speaker Settings 118
Reset Sound 119
Channel
Antenna 120
Auto Program 121
Clear Scrambled Channel 122
Fine Tune 123
Crosstalk Noise Reduction 124
Network
Network Settings 125
Connecting to a Wired Network 125
Wired Network Settings 127
Connecting to a Wireless Network 129
Wireless Network Setting 130
WPS(PBC) 133
Network Status 134
Wi-Fi Direct 135
Soft AP 136
AllShare Settings 137
Device Name 137
3
Table of contents
System
Setup 138
Initial settings (Setup) 138
Multi Control 139
Configuring settings for Multi Control 139
Time 140
Clock 140
Sleep Timer 141
On Timer 142
Off Timer 143
Holiday Management 143
Menu Language 144
Rotate Menu 145
Eco Solution 146
Energy Saving 146
Eco Sensor 146
No Signal Power Off 146
Auto Power Off 146
Caption 147
Caption 147
Caption Mode 147
Digital Caption Options 148
Security 149
Safety Lock 149
Button Lock 149
Program Rating Lock 149
Change PIN 151
PIP 152
Auto Protection Time 153
Screen Burn Protection 154
Pixel Shift 154
Timer 155
Immediate Display 156
Side Gray 156
Ticker 157
Video Wall 158
Video Wall 158
Format 158
Horizontal 158
Vertical 159
Screen Position 159
Source AutoSwitch Settings 160
Source AutoSwitch 160
Primary Source Recovery 160
Primary Source 160
Secondary Source 160
General 161
Max. Power Saving 161
Game Mode 161
BD Wise 161
Menu Transparency 161
Sound Feedback 162
Auto Power 162
Standby Control 162
Lamp Schedule 163
OSD Display 163
Power On Adjustment 163
Temperature Control 163
Anynet+ (HDMI-CEC) 164
Anynet+ (HDMI-CEC) 164
Auto Turn Off 165
Troubleshooting for Anynet+ 166
DivX® Video On Demand 168
Player Mode 168
Magic Clone 169
Reset System 169
Reset All 170
PC Module Power 170
Synced Power-On 170
Synced Power-Off 170
4
Table of contents
Support
Software Update 171
By USB 171
Contact Samsung 172
Contents Home 173
Channel List 173
Channel Manager 174
Icons in Channel 174
Adding a channel (Channel) 175
Deleting a channel in Channel 175
Using Tools in Channel 176
Edit Favorites 176
Rename Channel 178
Add / Delete 178
Select All / Deselect All 178
Adding a favorite channel 179
Deleting a Channel from a list of favorite channels
180
MagicInfo Lite
MagicInfo Premium S 181
MagicInfo Videowall S 182
AllShare Play 182
Source 183
181
AllShare Play
What is AllShare Play? 184
Read the following before using
AllShare Play
Using a USB device 186
Connecting to a PC over a network 187
Using the AllShare Play features 188
Using the Basic AllShare Play Features 189
Sorting the file lists 189
Playing Selected Files 190
Copying Files 190
Creating a Playlist 190
My List 191
My List options 191
Videos 192
Playing a Video 192
Photos 193
Viewing a Photo (or Slide Show) 193
Music 194
Playing Music 194
Videos / Photos / Music Play Option menu 195
Supported Subtitle and AllShare Play file
formats 197
Subtitle 197
Supported image resolutions 197
Supported music file formats 198
Supported Video Formats 198
with a USB device 184
MagicInfo Lite
File Formats Compatible with
MagicInfo Lite Player
Read before using MagicInfo Lite Player 200
Approving a connected device
from the server 205
MagicInfo Lite 207
MagicInfo Lite Player 207
Local Schedule Manager 210
Content Manager 217
Settings 219
When Content is Running 221
200
MagicInfo Premium S
File Formats Compatible with MagicInfo
Premium S Player
Read before using
MagicInfo Premium S Player
Approving a connected device
from the server 229
MagicInfo Premium S 231
MagicInfo Premium S Player 231
Local Schedule Manager 234
Template Manager 241
Content Manager 244
Settings 246
When Content is Running 248
223
223
5
Table of contents
MagicInfo Videowall S
File Formats Compatible with MagicInfo
Videowall S Player
Read before using
MagicInfo Videowall S Player
MagicInfo Videowall S 253
Settings 253
When Content is Running 254
250
250
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 255
Testing the Product 255
Checking the Resolution and Frequency 255
Check the followings. 256
Q & A 263
Specifications
General 265
PowerSaver 268
Preset Timing Modes 269
Appendix
Contact SAMSUNG WORLD WIDE 271
Responsibility for the Pay Service
(Cost to Customers) 273
Not a product defect 273
A Product damage caused by
customer's fault 273
Others 273
Optimum Picture Quality and
Afterimage Burn-in Prevention 274
Optimum Picture Quality 274
Prevention of Afterimage Burn-in 275
License 277
Terminology 278
6
Chapter 01
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2013 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
7
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Cleaning
―
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―
Take the following steps when cleaning.
―
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Power off the product and computer.
1
Disconnect the power cord from the product.
2
―
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
Wipe the product with a clean, soft and dry cloth.
3
•
Do not use detergents that contain alcohol, solvent or
surface-active agents.
!
•
Do not spray water or detergent directly on the product.
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Wet a soft and dry cloth in water and wring thoroughly to clean the
4
exterior of the product.
Connect the power cord to the product when cleaning is finished.
5
Power on the product and computer.
6
8
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create whitecolored stains on the product.
―
Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
―
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•
An electric shock or fire may result.
Do not use multiple products with a single power socket.
•
Overheated power sockets may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated
devices only).
•
An electric shock or injury may result.
!
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•
Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•
A fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•
A fire may result.
!
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
Insert the power plug all the way in so it is not loose.
•
An unsecure connection may cause a fire.
!
9
Caution
!
!
!
Do not disconnect the power cord while the product is being used.
•
The product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•
A fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
•
The power cord must be disconnected to cut off power to the product
when an issue occurs.
•
Note that the product is not completely powered down by using only
the power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
•
An electric shock or fire may result.
Installation
Warning
!
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•
A fire may result.
Have a technician install the wall-mount hanger.
•
Installation by an unqualified person can result in an injury.
•
Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
•
An increased internal temperature may cause a fire.
Install the product at least 10cm away from the wall to allow ventilation.
•
An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
•
Children may suffocate.
!
10
Bend and keep part of the outdoor TV antenna cable hanging downwards
(the part inside the room) to prevent rainwater from entering the product.
•
If rainwater enters the product, a fire or electric shock can occur.
!
When using an outdoor antenna, be sure to install the antenna away from
nearby power lines to prevent the antenna from collapsing onto them in
strong winds.
•
A collapsed antenna can cause an electric shock or injury.
!
!
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•
The product may fall and become damaged and/or cause an injury.
•
Using the product in an area with excess vibration may damage the
product or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•
A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•
The product lifespan may be reduced or a fire may result.
Edible oil, such as soybean oil, can damage or deform the product. Do not
install the product in a kitchen or near a kitchen counter.
Do not install the product within the reach of young children.
•
The product may fall and injure children.
•
As the front is heavy, install the product on a flat and stable surface.
11
Caution
!
!
Do not drop the product while moving.
•
Product failure or personal injury may result.
Do not set down the product on its front.
•
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•
The product may fall and become damaged and/or cause an injury.
•
Install the product only on cabinets or shelves of the right size.
Set down the product gently.
•
Product failure or personal injury may result.
Operation
Warning
!
!
There is a high voltage inside the product. Never disassemble, repair or
modify the product yourself.
•
A fire or electric shock may result.
•
Contact Samsung Customer Service Center for repairs.
Before moving the product, turn off the power switch and disconnect the
power cord, antenna cable and all other connected cables.
•
Damage to the cord may result in a fire or electric shock.
If the product generates abnormal sounds, a burning smell or smoke,
disconnect the power cord immediately and contact Samsung Customer
Service Center.
•
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
•
Children may become injured or seriously harmed.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport
SAMSUNG
!
or train station where the product should operate continuously for an
extended period of time) may seriously affect its performance.
•
Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.
If the product is dropped or the outer case is damaged, turn off the power
switch and disconnect the power cord. Then contact Samsung Customer
Service Center.
•
Continued use can result in a fire or electric shock.
12
Do not leave heavy objects or items that children like (toys, sweets, etc.) on
top of the product.
•
The product or heavy objects may fall as children try to reach for the
toys or sweets resulting in a serious injury.
Do not use or keep combustible spray or an inflammable substance near
the product.
•
An explosion or fire may result.
!
During a lightning or thunderstorm, power off the product and remove the
power cable.
•
A fire or electric shock may result.
!
Do not drop objects on the product or apply impact.
•
A fire or electric shock may result.
!
100
Ensure the vents are not blocked by tablecloths or curtains.
•
An increased internal temperature may cause a fire.
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects
that burn easily (paper, matches, etc) into the product (via the vent or input/
output ports, etc).
•
Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
Do not move the product by pulling the power cord or any cable.
•
Product failure, an electric shock or fire may result from a damaged
cable.
•
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
•
Be sure to power off the product and disconnect the power cord
If a gas leakage is found, do not touch the product or power plug. Also,
ventilate the area immediately.
•
Sparks can cause an explosion or fire.
!
GAS
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•
Product failure, an electric shock or fire may result.
Do not lift or move the product by pulling the power cord or any cable.
•
Product failure, an electric shock or fire may result from a damaged
cable.
13
Caution
!
-_-
!
Leaving the screen fixed on a stationary image for an extended period of
time may cause afterimage burn-in or defective pixels.
•
Activate power-saving mode or a moving-picture screen saver if you
will not be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on
using the product for an extended period of time (vacation, etc).
•
Dust accumulation combined with heat can cause a fire, electric shock
or electric leakage.
Use the product at the recommended resolution and frequency.
•
Your eyesight may deteriorate.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
•
Eye fatigue will be relieved.
!
Do not touch the screen when the product has been turned on for an
extended period of time as it will become hot.
Store small accessories out of the reach of children.
!
!
Do not hold the product upside-down or move it by holding the stand.
•
The product may fall and become damaged or cause an injury.
Looking at the screen too close for an extended period of time can
deteriorate your eyesight.
!
Do not use humidifiers or stoves around the product.
•
A fire or electric shock may result.
!
Exercise caution when adjusting the product angle or stand height.
•
Your hand or finger may get stuck and injured.
•
Tilting the product at an excessive angle may cause the product to fall
and an injury may result.
Do not place heavy objects on the product.
•
Product failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
•
Having the sound too loud may damage your hearing.
14
Be careful that children do not place the battery in their mouths when
removed from the remote control. Place the battery in a location that
children or infants cannot reach.
•
If children have had the battery in their mouths, consult your doctor
immediately.
When replacing the battery, insert it with the right polarity (+, -).
•
Otherwise, the battery may become damaged or it may cause fire,
personal injury or damage due to leakage of the internal liquid.
Use only the specified standardized batteries, and do not use a new battery
and a used battery at the same time.
•
Otherwise, the batteries may be damaged or cause fire, personal injury
!
!
or damage due to a leakage of the internal liquid.
The batteries (and rechargeable batteries) are not ordinary refuse and must
be returned for recycling purposes. The customer is responsible for returning
the used or rechargeable batteries for recycling.
•
The customer can return used or rechargeable batteries to a nearby
public recycling center or to a store selling the same type of the
battery or rechargeable battery.
15
Chapter 02
Preparations
Checking the Contents
Removing the Packaging (for ME32C ME40C and
ME46C models only)
―
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Remove the black locking device at the bottom of the box.
1
Remove the styrofoam from the product.
2
Check the product and remove the styrofoam and plastic bag.
3
―
The appearance of the actual product may differ from the image shown.
―
This image is for reference only.
Store the box in a dry area so that it can be used when moving the product in the future.
4
16
Removing the Packaging (for ME55C models only)
―
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Remove the black locking device at the bottom of the box.
1
321
Using the grooves in the box, lift and remove the top of the box.
2
Check the components and remove the styrofoam and plastic bag.
3
―
The appearance of actual components may differ from the image shown.
Store the box in a dry area so that it can be used when moving the product in the future.
4
17
Checking the Components
-
Contact the vendor where you
purchased the product if any
components are missing.
-
The appearance of the components and
items sold separately may differ from the
image shown.
-
A stand is not provided with the product.
To install a stand, you can purchase one
separately.
Components
―
Components may differ in different locations.
Quick setup guide
-
-
Batteries (P. 25)
(Not available in some locations)
+
+
Warranty card
(Not available in some
locations)
Remote Control (P.24)
(AA59-00714A)
User manual
MagicInfo Lite Edition Software
CD
Power cord D-SUB cable (P. 47)
Holder-Ring (4EA)
(BN61-07295A)
Holder-Wire stand
(BN61-05491A)
18
-
The following items can be purchased
at your nearest retailer.
-
The RS232C adapter can be used to
connect to another monitor using the
D-SUB (9-pin) type RS232C cable.
-
Ensure you connect each of the adapters
to the correct RS232C IN or OUT port on
the product.
Items sold separately
Wall-mount Kit Stand RS232C-Stereo cable (P.63) DVI cable (P. 48) HDMI-DVI cable (P. 48)
DP cable (P. 49) HDMI cable (P.49) Video cable (P.53) Stereo cable (P.27) Component cable (P.54)
RCA stereo cable (P. 56) RCA cable (P. 53) AV/Component adapter (P.53) AUDIO adapter (P. 53) External sensor Kit (P. 27)
RS232C(IN) adapter RS232C(OUT) adapter LAN cable Network Box
DP-DVI cable
(Used to connect a network
box)
19
Parts
Control Panel
―
The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve
quality.
Panel Key
Buttons Description
Power on the product.
If you press the button when the product is turned on, the control menu will be
displayed.
―
POWER
To exit the OSD menu, press and hold the panel key for at least one second.
Panel Key
Speaker
POWER
ON
Remote sensor
Remote sensor
Move to the upper or lower menu. You can also adjust the value of an option.
Change the channel in TV mode.
Move to the left or right menu.
―
You can adjust the volume by moving the panel key left or right when the control
menu is not displayed.
Press a button on the remote control pointing at the sensor on the front of the
product to perform the corresponding function.
―
Using other display devices in the same space as the remote control of this
product can cause the other display devices to be inadvertently controlled.
20
―
If you press the
the control menu will be displayed.
button on the panel key (P. 20) when the product is turned on,
Control menu
CONTENT
Buttons Description
Select the connected input source.
Source
MENU
Move the panel key right to select Source
of input sources is displayed, move the panel key up or down to select the desired
input source. Next, press the panel key.
Display the OSD menu.
Move the panel key left to select menu
screen will appear. Move the panel key right to select the desired menu. You can
select a sub-menu item by moving the panel key up, down, left, or right. To change
settings, select the desired menu and press the panel key.
in the control menu. When the list
in the control menu. The OSD control
Return
CONTENT
Contents Home
Power O
Return
Enter Contents Home mode.
Move the panel key up to select Contents Home
Power off the product.
Move the panel key down to select Power off
panel key.
Exit the control menu.
CONTENT
in the control menu.
in the control menu. Next, press the
21
Reverse Side
Port Description
―
The color and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
RS232C IN
RS232C
OUT
IR /
AMBIENT
SENSOR IN
AUDIO
OUT
RGB / DVI /
HDMI / AV /
COMPONENT
/ AUDIO IN
USB
HDMI IN 2
DP IN
HDMI IN 1
POWER
RS232C IN
RS232C OUT
IR / AMBIENT SENSOR IN
AUDIO OUT
RGB / DVI / HDMI / AV / COMPONENT /
AUDIO IN
USB
DP IN
HDMI IN 1, HDMI IN 2
DVI IN / MAGICINFO IN
DP OUT
ANT IN
Connects to MDC using an RS232C-stereo adapter.
Supplies power to the external sensor board or receives the light sensor signal.
Connects to the audio of a source device.
Receives sound from a PC via an audio cable.
Connect to a USB memory device.
Connects to a PC using a DP cable.
Connects to a source device using an HDMI cable.
DVI IN: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: To use MagicInfo, make sure to connect the DP-DVI cable.
Connects to another product using a DP cable.
Connect to an antenna cable.
DVI IN /
MAGICINFO IN
DP OUT RGB IN RJ45
ANT IN
COMPONENT IN
IR
OUT
RGB IN
AV IN / COMPONENT IN
IR OUT
RJ45
Connects to a source device using a D-SUB cable.
Connects to a source device using the AV/Component adapter.
Receives the remote control signal via the external sensor board and outputs the
signal via LOOP OUT.
Connects to MDC using a LAN cable.
22
Assembling the Holder-Wire stand Anti-theft Lock
―
An anti-theft lock allows you to use the product securely even in public places.
―
The locking device shape and locking method depend on the manufacturer. Refer to the user guide
provided with your anti-theft locking device for details.
―
Stand: Sold separately
To lock an anti-theft locking device:
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
1
Put one end of the cable through the loop on the other end.
2
Insert the locking device into the anti-theft lock slot at the back of the product.
3
Lock the locking device.
4
-
An anti-theft locking device can be purchased separately.
-
Refer to the user guide provided with your anti-theft locking device for details.
-
Anti-theft locking devices can be purchased at electronics retailers or online.
23
Remote Control
―
Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
Power on the product.
Press to select additional
channels (digital) being broadcasted by the
same station. For example, to select channel
“54-3”, press “54”, then press “-” and “3”.
Adjust the volume.
Change the input source.
MagicInfo Lite, MagicInfo Premium S,
MagicInfo Videowall S Launch Button.
The buttons can vary according to the
Player Mode settings.
.QZ
1
GHI
4
PRS
7
DEL-/--
VOL
MagicInfo
Lite/S
ABC
2
JKL
5
TUV
8
SYMBOL
0
CONTENT
(HOME)
SOURCE
MENU
OFF
DEF
3
MNO
6
WXY
9
MUTE
CH
BLANK
Power off the product.
Number buttons
Enter the password in the OSD menu.
Mute the sound.
Unmuting the sound: Press MUTE again or press
the volume control(+ VOL -) button.
Contents Home Launch Button.
Change the channel in TV mode.
Temporarily turn off the video and mute the
audio.
Disabling the BLANK function
- Press BLANK one more time.
- Press SOURCE.
- Turn the product off and then on again.
Display or hide the onscreen display menu, or
return to the previous menu.
-
Remote control button functions may
differ for different products.
24
3D
Quickly select frequently used functions.
Return to the previous menu.
It sets safe lock function.
MagicInfo Quick Launch Button.
This button is disabled for products
that do not support MagicInfo.
MagicInfo can only be enabled
when a network box is connected.
TOOLS INFO
PC
A
MAGICINFO
DVI
B
HDMI
C
LOCK
Display information about the current input
source.
Move to the upper, lower, left or right menu, or
adjust an option's setting.
Confirm a menu selection.
EXITRETURN
DP
D
Exit the current menu.
In TV mode, configure settings such as the
program guide for digital channels. In other
modes, manually select a connected source
device. In media and HDMI-CEC modes,
configure settings for the functions assigned to
the color buttons on the remote control. Enable
or disable lock mode.
Use these buttons in Videos, Photos, Music and
Anynet+ modes.
-
Remote control button functions may
differ for different products.
To place batteries in the remote control
25
Adjusting the OSD with the Remote Control
Buttons Description
Open the OSD menu.
1
Select an option you want to change settings for from
2
Picture, Sound, Channel, Network, System, and
Support on the left side of the OSD menu.
Remote Control Reception Range
Change settings as desired.
3
Finish setting.
4
Close the onscreen display (OSD) menu.
5
30˚
7m ~ 10m
Use the remote control within 7m to 10m from the sensor on the product at an angle of 30 from the
left and right.
―
Store used batteries out of reach of children and recycle.
―
Do not use a new and used battery together. Replace both batteries at the same time.
―
Remove batteries when the remote control is not to be used for an extended period of time.
30˚
26
Connection Using an IR Stereo Cable (sold
separately)
1 2
Make sure to connect the external sensor kit while the product is powered off.
Then, power on the product.
Controlling more than one display product using
your remote control
•
Connect the IR OUT port on the product to the IR / AMBIENT SENSOR IN
port on the other display product using the dedicated stereo cable.
•
A command sent from the remote control pointed at product
received by both display products
―
The appearance may differ depending on the product.
1
and 2.
1
will be
Controlling more than one display product using an
external sensor kit (sold separately)
•
A command sent from the remote control pointed at product
which the external sensor kit is connected) will be received by both display
products
―
The appearance may differ depending on the product.
1
and 2.
1
(to
IR OUT IR/AMBIENT
SENSOR IN
IR/AMBIENT
SENSOR IN
IR OUT IR/AMBIENT
POWERPOWER
1 2
POWERPOWER
SENSOR IN
POWER
SOURCE
27
Before Installing the Product
(Installation Guide)
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
•
Ensure that an authorized installation company installs the wall mount.
•
Otherwise, it may fall and cause personal injury.
•
Make sure to install the specified wall mount.
15 ˚
Tilting Angle and Rotation
―
Contact Samsung Customer Service Center for further details.
•
The product can be tilted at a maximum angle of 15
•
To use the product vertically (portrait), turn it clockwise so that the LED is pointing down.
from a perpendicular wall surface.
Ventilation
Installation on a Perpendicular Wall
A Minimum 40 mm
B Ambient temperature: Under 35
A
•
When installing the product on a perpendicular wall, allow at least 40 mm of space between the product and wall surface
for ventilation and ensure that the ambient A temperature is kept below 35
C
C.
B
Figure 1.1 Side view
28
Figure 1.3 Side view
B
Installation on an Indented Wall
―
Contact Samsung Customer Service Center for further details.
A
C
E
Figure 1.2 Side view
Dimensions
1
2
D D
5
4
3
Plane view
A Minimum 40 mm
B Minimum 70 mm
C Minimum 50 mm
D Minimum 50 mm
E Ambient temperature: Under 35
―
When installing the product on an indented wall, allow at least the space specified above between the product and wall for
ventilation and ensure that the ambient temperature is kept below 35
Model name
ME32C 734.8 (28.9) 702.4 (27.7) 396.8 (15.6) 433.8 (17.1) 29.9 (1.2)
ME40C 922.1 (36.3) 890.6 (35.1) 503.2 (19.8) 539.4 (21.2) 29.9 (1.2)
ME46C 1057.6 (41.6) 1023.0 (40.3) 577.6 (22.7) 615.8 (24.2) 29.9 (1.2)
ME55C 1248.0 (49.1) 1213.6 (47.8) 684.4 (26.9) 722.4 (28.4) 29.9 (1.2)
―
All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice.
Refer to the dimensions prior to performing installation of your product. Not responsible for typographical or printed errors.
1
C
C.
Unit: mm (inches)
2
3 4
5
29
Installing the Wall Mount
1
Preparing before installing Wall-Mount
To install a wall-mount from another manufacturer, use the Holder-Ring(1).
Installing the Wall Mount Kit
The wall mount kit (sold separately) allows you to mount the product on the wall.
For detailed information on installing the wall mount, see the instructions provided with the wall mount.
We recommend you contact a technician for assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the
wall mount on your own.
30
Wall Mount Kit Specications (VESA)
―
Install your wall mount on a solid wall perpendicular to the floor. Before
attaching the wall mount to surfaces other than plaster board, please contact
your nearest dealer for additional information.
If you install the product on a slanted wall, it may fall and result in severe
personal injury.
•
Samsung wall mount kits contain a detailed installation manual and all parts necessary for assembly are provided.
•
Do not use screws that are longer than the standard length or do not comply with the VESA standard screw
specifications. Screws that are too long may cause damage to the inside of the product.
•
For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ
depending on the wall mount specifications.
•
Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
•
Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the
consumer fails to follow the product installation instructions.
•
Do not mount the product at more than a 15 degree tilt.
•
Always have two people mount the product on a wall.
•
Standard dimensions for wall mount kits are shown in the table below.
Unit: mm (inches)
Model name VESA screw hole
Standard Screw Quantity
specs (A * B) in
millimeters
ME32C
200 × 200 (7.9 × 7.9)
ME40C
M8 / L14~16 4
ME46C
400 × 400 (15.7 × 15.7)
ME55C
―
Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock.
31
Remote Control (RS232C)
Cable Connection
RS232C Cable
•
Pin assignment
1 2 3 4 5
Interface
Pin
Bit rate
Data bits
Parity
Stop bit
Flow control
Maximum length
RS232C (9 pins)
TxD (No.2), RxD (No.3), GND (No.5)
9600 bps
8 bit
None
1 bit
None
15 m (only shielded type)
6 7 8 9
Pin Signal
1
2
3
4
5
6
7
8
9
Detect data carrier
Received data
Transmitted data
Prepare data terminal
Signal ground
Prepare data set
Send request
Clear to send
Ring indicator
32
•
RS232C cable
Connector: 9-Pin D-Sub to Stereo Cable
59
1
6
-P1-
-P1- -P1- -P2- -P2-
3
2
1
-P2-
LAN Cable
•
Pin assignment
1 2 3 4 5 6 7 8
Female Rx
Tx
Gnd
2
3
5
-------->
<--------
----------
3
2
5
Tx
Rx
Gnd
STEREO
PLUG
(3.5ø)
Pin No Standard Color Signal
1 White and orange TX+
2 Orange TX-
3 White and green RX+
4 Blue NC
5 White and blue NC
6 Green RX-
7 White and brown NC
8 Brown NC
33
•
Connector : RJ45
Direct LAN cable (PC to HUB)
Cross LAN cable (PC to PC)
HUB
P1P2
RJ45 RJ45 MDC
Signal
TX+
TX-
RX+
RX-
P1
P1 P2 Signal
1 <--------> 1 TX+
2 <--------> 2 TX-
3 <--------> 3 RX+
6 <--------> 6 RX-
P2
Signal
TX+
TX-
RX+
RX-
RJ45
P1 P2
P1 P2 Signal
1 <--------> 3 RX+
2 <--------> 6 RX-
3 <--------> 1 TX+
6 <--------> 2 TX-
34
Connection
•
Connection 1
•
Connection 2
RJ45 RJ45
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
•
Connection 3
RS232C
RJ45 RS232C
OUT
IN OUT
RS232C
IN OUT
RS232C
IN OUT
35
Control Codes
No. Command type Command Value range
Viewing control state (Get control command)
Header Command ID Data length Checksum
0xAA Command type 0
Controlling (Set control command)
Header Command ID Data length Data Checksum
0xAA Command type 1 Value
Command
No. Command type Command Value range
1
2
3
4
Power control 0x11 0~1
Volume control 0x12 0~100
Input source control 0x14 -
Screen mode control 0x18 -
10
11
•
All communications take place in hexadecimals. The checksum is calculated by adding up all
values except the header. If a checksum adds up to be more than 2 digits as shown below
(11+FF+01+01=112), the first digit is removed.
E.g. Power On & ID=0
Header Command ID Data length Data 1 Checksum
0xAA 0x11 1 "Power"
Header Command ID Data length Data 1 12
0xAA 0x11 1 1
•
To control all devices connected by a serial cable simultaneously irrespective of IDs, set the ID as
"0xFE" and transmit commands. Commands will be executed by each device but ACK will not
respond.
Video Wall On 0x84 0~1
Video Wall User Control 0x89 -
5
6
7
8
9
Screen size control 0x19 0~255
PIP on/off control 0x3C 0~1
Auto adjustment control (PC and
BNC only)
Video wall mode control 0x5C 0~1
Safety Lock 0x5D 0~1
0x3D 0
36
Power control
Volume control
•
Function
A product can be powered on and off using a PC.
•
Viewing power state (Get Power ON / OFF Status)
Header Command ID Data length Checksum
0xAA 0x11 0
•
Setting power ON/Off (Set Power ON / OFF)
Header Command ID Data length Data Checksum
0xAA 0x11 1 "Power"
"Power": Power code to be set on a product.
1: Power ON
0: Power OFF
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x11 "Power"
"Power": Power code to be set on a product.
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
•
Function
The volume of a product can be adjusted using a PC.
•
Viewing volume state (Get Volume Status)
Header Command ID Data length Checksum
0xAA 0x12 0
•
Setting the volume (Set Volume)
Header Command ID Data length Data Checksum
0xAA 0x12 1 "Volume"
"Volume": Volume value code to be set on a product. (0-100)
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x12 "Volume"
"Volume": Volume value code to be set on a product. (0-100)
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x12 "ERR"
0xAA 0xFF 3 'N' 0x11 "ERR"
"ERR" : A code showing what error has occurred.
"ERR" : A code showing what error has occurred.
37
Input source control
•
Function
The input source of a product can be changed using a PC.
•
Viewing input source state (Get Input Source Status)
Header Command ID Data length Checksum
0xAA 0x14 0
•
Setting the input source (Set Input Source)
Header Command ID Data length Data Checksum
0xAA 0x14 1 "Input Source"
"Input Source": An input source code to be set on a product.
0x24 HDMI2_PC
0x25 DisplayPort
―
DVI_video, HDMI1_PC and HDMI2_PC cannot be used with the Set command. They only respond to
"Get" commands.
―
This model does not support HDMI1, HDMI1_PC, HDMI2 and HDMI2_PC ports.
―
MagicInfo is only available with models that contain the MagicInfo function.
―
RF(TV), DTV are only available with models that include a TV.
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x14 "Input
Source"
0x14 PC
0x18 DVI
0x0C Input source
0x08 Component
0x20 MagicInfo
0x1F DVI_video
0x30 RF( TV)
0x40 DT V
0x21 HDMI1
0x22 HDMI1_PC
0x23 HDMI2
"Input Source": An input source code to be set on a product.
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x14 "ERR"
"ERR" : A code showing what error has occurred.
38
Screen mode control
•
Function
The screen mode of a product can be changed using a PC.
Screen mode cannot be controlled when the Video Wall function is enabled.
―
This control can only be used on models that include a TV.
•
Viewing screen status (Get Screen Mode Status)
Header Command ID Data length Checksum
0xAA 0x18 0
•
Setting the picture size (Set Picture Size)
Header Command ID Data
length
0xAA 0x18 1 "Screen
"Screen Mode": A code that sets the product status
0x01 16 : 9
0x04 Zoom
Data Checksum
Mode"
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x18 "Screen
Mode"
"Screen Mode": A code that sets the product status
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x18 "ERR"
"ERR": A code showing what error has occurred
0x31 Wide Zoom
0x0B 4 : 3
39
Screen size control
PIP On/Off control
•
Function
The screen size of a product can be changed using a PC.
•
Viewing the screen size (Get Screen Size Status)
Header Command ID Data length Checksum
0xAA 0x19 0
•
Ack
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x19 "Screen
"Screen Size": product screen size (range: 0 – 255, unit: inch)
•
Nak
Header Command ID Data
length
0xAA 0xFF 3 'N' 0x19 "ERR"
"ERR": A code showing what error has occurred
Ack/Nak r-CMD Val1 Checksum
Size"
Ack/Nak r-CMD Val1 Checksum
•
Function
The PIP mode of a product can be turned on or off using a PC.
―
Only available on models that have the PIP function.
―
The mode cannot be controlled if Video Wall is set to On.
―
This function is not available in MagicInfo.
•
Viewing PIP on/off state (Get the PIP ON / OFF Status)
Header Command ID Data length Checksum
0xAA 0x3C 0
•
Setting PIP on/off (Set the PIP ON / OFF)
Header Command ID Data length Data Checksum
0xAA 0x3C 1 "PIP"
"PIP": A code used to turn the PIP mode of a product on or off
1: PIP ON
0: PIP OFF
•
Ack
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x3C "PIP"
"PIP": A code used to turn the PIP mode of a product on or off
•
Nak
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x3C "PIP"
"ERR": A code showing what error has occurred
Ack/Nak r-CMD Val1 Checksum
40
Auto adjustment control (PC and BNC only)
Video Wall Mode Control
•
Function
Automatically adjust the PC system screen using a PC.
•
Viewing auto adjustment state (Get Auto Adjustment Status)
None
•
Setting auto adjustment (Set Auto Adjustment)
Header Command ID Data length Data Checksum
0xAA 0x3D 1 "Auto
Adjustment"
"Auto Adjustment" : 0x00 (at all times)
•
Ack
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x3D "Auto
•
Nak
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x3D "ERR"
"ERR": A code showing what error has occurred
Ack/Nak r-CMD Val1 Checksum
Adjustment"
Ack/Nak r-CMD Val1 Checksum
•
Function
Video Wall mode can be activated on a product using a PC.
This control is only available on a product whose Video Wall is enabled.
•
Viewing video wall mode (Get Video Wall Mode)
Header Command ID Data length Checksum
0xAA 0x5C 0
•
Setting the video wall (Set Video Wall Mode)
Header Command ID Data length Data Checksum
0xAA 0x5C 1 "Video Wall Mode"
"Video Wall Mode": A code used to activate Video Wall mode on a product
1: Full
0: Natural
•
Ack
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x5C "Video Wall
"Video Wall Mode": A code used to activate Video Wall mode on a product
•
Nak
Ack/Nak r-CMD Val1 Checksum
Mode"
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x5C "ERR"
"ERR": A code showing what error has occurred
Ack/Nak r-CMD Val1 Checksum
41
Safety Lock
•
Function
PC can be used to turn the Safety Lock function on or off on a product.
This control is available regardless of whether or not the power is turned on.
•
Viewing the safety lock state (Get Safety Lock Status)
•
Nak
Header Command ID Data
length
0xAA 0xFF 3 'N' 0x5D "ERR"
Ack/Nak r-CMD Val1 Checksum
Header Command ID Data length Checksum
0xAA 0x5D 0
•
Enabling or disabling safety lock (Set Safety Lock Enable / Disable)
Header Command ID Data length Data Checksum
0xAA 0x5D 1 "Safety Lock"
"Safety Lock": Safety lock code to be set on a product
1: ON
0: OFF
•
Ack
Header Command ID Data
length
0xAA 0xFF 3 'A' 0x5D "Safety Lock"
"Safety Lock": Safety lock code to be set on a product
Ack/Nak r-CMD Val1 Checksum
"ERR": A code showing what error has occurred
42
Video Wall On
•
Function
Turn Video Wall on or off on the product from your computer.
•
Get Video Wall On/Off Status
Header Command ID Data length Checksum
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x84 ERR
"ERR": A code showing what error has occurred
0xAA 0x84 0
•
Set Video Wall On/Off
Header Command ID Data length Data Checksum
0xAA 0x84 1 V.Wall_On
•
V.Wall_On: Video Wall code to be assigned to the product
1: Video Wall ON
0: Video Wall OFF
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'A' 0x84 V.Wall_
On
V.Wall_On : Same as above
Video Wall User Control
•
Function
Turn the Video Wall function on or off on the product from your computer.
•
Get Video Wall Status
Header Command ID Data length Checksum
0xAA 0x89 0
•
Set Video Wall
Header Command ID Data length Val1 Val2 Checksum
0xAA 0x89 2 Wall_Div Wall_SNo
Wall_Div: Video Wall Divider code assigned to the product
43
10x10 Video Wall Model
O
1
2
3
4
5
6
7
8
9
10
11
1 2 3 4 5 6 7 8 9 10 11 12 13 14
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
0x11 0x12 0x13 0x14 0x15 0x16 0x17 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E
0x21 0x22 0x23 0x24 0x25 0x26 0x27 0x28 0x29 0x2A 0x2B 0x2C 0x2D 0x2E
0x31 0x32 0x33 0x34 0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C 0x3D 0x3E
0x41 0x42 0x43 0x44 0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C 0x4D 0x4E
0x51 0x52 0x53 0x54 0x55 0x56 0x57 0x58 0x59 0x5A 0x5B 0x5C 0x5D 0x5E
0x61 0x62 0x63 0x64 0x65 0x66 0x67 0x68 0x69 0x6A 0x6B 0x6C 0x6D 0x6E
0x71 0x72 0x73 0x74 0x75 0x76 0x77 0x78 0x79 0x7A 0x7B 0x7C 0x7D 0x7E
0x81 0x82 0x83 0x84 0x85 0x86 0x87 0x88 0x89 0x8A 0x8B 0x8C N/A N/A
0x91 0x92 0x93 0x94 0x95 0x96 0x97 0x98 0x99 0x9A 0x9B N/A N/A N/A
0xA1 0xA2 0xA3 0xA4 0xA5 0xA6 0xA7 0xA8 0xA9 0xAA N/A N/A N/A N/A
0xB1 0xB2 0xB3 0xB4 0xB5 0xB6 0xB7 0xB8 0xB9 N/A N/A N/A N/A N/A
15
0x00
0x1F
0x2F
0x3F
0x4F
0x5F
0x6F
N/A
N/A
N/A
N/A
N/A
12
13
14
15
0xC1 0xC2 0xC3 0xC4 0xC5 0xC6 0xC7 0xC8 N/A N/A N/A N/A N/A N/A
0xD1 0xD2 0xD3 0xD4 0xD5 0xD6 0xD7 N/A N/A N/A N/A N/A N/A N/A
0xE1 0xE2 0xE3 0xE4 0xE5 0xE6 0xE7 N/A N/A N/A N/A N/A N/A N/A
0xF1 0xF2 0xF3 0xF4 0xF5 0xF6 N/A N/A N/A N/A N/A N/A N/A N/A
N/A
N/A
N/A
N/A
44
Wall_SNo: Product Number code assigned to the product
10x10 Video Wall Model : ( 1 ~ 100)
Set Number Data
1 0x01
2 0x02
... ...
99 0x63
100 0x64
•
Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Val2 Checksum
0xAA 0xFF 4 'A' 0x89 Wall_Div Wall_SNo
•
Nak
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3 'N' 0x89 ERR
"ERR": A code showing what error has occurred.
45
Chapter 03
Connecting and Using a Source Device
Before Connecting
Check the following before you connect this product with other devices. Devices that can be connected to this product
include PCs, camcorders, speakers, set top boxes and DVD/Blu-ray Disc players.
POWER
Pre-connection Checkpoints
―
Before connecting a source device, read the user manual provided with it.
The number and locations of ports on source devices may differ from device to
device.
―
Do not connect the power cable until all connections are completed.
Connecting the power cable during connection may damage the product.
―
Connect the sound ports correctly: left = white and right = red.
―
Check the types of ports at the back of the product you want to connect.
46
Connecting to a PC
•
Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
•
A PC can be connected to the product in a variety of ways.
Select a connection method suitable for your PC.
―
Connecting parts may differ in different products.
Connection using the D-SUB cable (Analog
type)
POWER
RGB IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
47
Connection using a DVI cable (Digital type)
DVI IN /
MAGICINFO IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
POWER
Connection Using an HDMI-DVI Cable
―
When you connect a PC to the product using an HDMI-DVI cable, set Edit
Name to DVI PC to access video and audio content stored on the PC.
POWER
HDMI IN 1, HDMI IN 2
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
48
Connection Using an HDMI Cable
Connection Using an DP Cable
•
Precautions for using DP
―
To increase the standby power capacity, the product stops DP
communication when it is turned off or in power-saving mode. If the
product in dual monitor mode is turned off or goes into power-saving
mode, monitor setting changes may not be updated. As a result, screen
output may not be displayed properly. In the occurrence of this issue, set
Max. Power Saving to Off before using the product.
―
Some graphics cards that are not compliant with the DP standard may
prevent the Windows Booting/Bios screen from being displayed when the
product is in power-saving mode. If this is the case, make sure to turn on
the product first before turning on your PC.
POWER
HDMI IN 1, HDMI IN 2
POWER
DP IN
49
Changing the Resolution
―
Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture quality.
―
The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected.
Changing the Resolution on Windows XP
Go to Control Panel Display Settings, and change the resolution.
Changing the Resolution on Windows Vista
Go to Control Panel Personal Settings Display Settings, and change the resolution.
50
Changing the Resolution on Windows 7
Go to Control Panel Display Screen Resolution, and change the resolution.
Changing the Resolution on Windows 8
Go to Settings Control Panel Display Screen Resolution, and change the resolution.
51
Connecting an External Monitor
―
Connecting parts may differ in different products.
POWER
DP OUT
DP IN
52
Connecting to a Video Device
•
Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
•
You can connect a video device to the product using a cable.
―
Connecting parts may differ in different products.
―
Press the SOURCE button on the remote control to change the source.
Connection Using the AV Cable
POWER
AV IN / COMPONENT IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
53
Connection Using the component Cable
Connection Using an HDMI-DVI Cable
―
Audio will not be enabled if the product is connected to a video device using
an HDMI-DVI cable. To resolve this, additionally connect an audio cable to
the audio ports on the product and video device. When you connect a video
device to the product using an HDMI-DVI cable, set Edit Name to DVI Devices
to access video and audio content stored on the video device.
―
Supported resolutions include 1080p (50/60Hz), 720p (50/60Hz), 480p, and
576p.
POWER
AV IN / COMPONENT IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
POWER
HDMI IN 1, HDMI IN 2
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
54
Connection Using an HDMI Cable
Using an HDMI cable or HDMI to DVI Cable
(up to 1080p)
•
For better picture and audio quality, connect to a digital device using an
HDMI cable.
•
An HDMI cable supports digital video and audio signals, and does not
require an audio cable.
-
To connect the product to a digital device that does not support HDMI
output, use an HDMI-DVI and audio cables.
•
The picture may not display normally (if at all) or the audio may not work if
an external device that uses an older version of HDMI mode is connected to
the product. If such a problem occurs, ask the manufacturer of the external
device about the HDMI version and, if out of date, request an upgrade.
•
Be sure to use an HDMI cable with a thickness of 14 mm or less.
•
Be sure to purchase a certified HDMI cable. Otherwise, the picture may not
display or a connection error may occur.
•
A basic high-speed HDMI cable or one with ethernet is recommended.
This product does not support the ethernet function via HDMI.
POWER
HDMI IN 1, HDMI IN 2
55
Connecting to an Audio System
―
Connecting parts may differ in different products.
Connecting the antenna
―
Connecting parts may differ in different products.
―
When the product is powered on for the first time, basic settings are configured
automatically. Take extra care to ensure the wires inside the antenna cable are
not bent.
POWER
AUDIO OUT
POWER
ANT IN
56
Connecting the network box (Sold separately)
MagicInfo Setup Wizard - v.1.12
Select Application - step 1
MagicInfo Pro (LAN, WAN based version)
MagicInfo-i Premium (Web-based version)
Select Later
< Back(B) Next(N) > Finish Cancel
―
For details on how to connect to a network box, refer to the user's manual provided with the network box upon purchase.
MagicInfo
To use MagicInfo, a network box (sold separately) must be connected to the product.
―
To change the MagicInfo settings, run "MagicinfoSetupWizard" on the desktop.
―
For details on how to use MagicInfo, refer to the DVD provided with the network box.
―
The information in this section is subject to change without notice for quality improvement.
―
If a problem occurs after installing an operating system other than the one provided with the network box, restoring the previous version of the operating system, or
installing software that is not compatible with the operating system provided, you will not be able to benefit from technical support and will be charged a fee for a visit
from a service technician. A product exchange or refund will also not be available.
Entering MagicInfo mode
1
2
3
After installing and connecting the network box (sold separately) to the product, power on the product.
Press SOURCE on the remote control, and select MagicInfo.
―
Connecting the network box to the DVI IN / MAGICINFO IN port on the product will change Source from DVI to
MagicInfo.
Select the default application you want to run when MagicInfo starts.
57
MagicInfo Setup Wizard - v.1.12
Select TCP/IP - step 2
Obtain an IP address automatically
Use the following IP address:
IP address:
Subnet mask:
Default gateway:
192 . 168 . 0 . 102
255 . 255 . 255 . 0
192 . 168 . 0 . 1
Obtain DNS server address automatically
Use the following DNS server address:
Preferred DNS server:
Alternate DNS server:
10 . 44 . 33 . 22
10 . 33 . 22 . 11
< Back(B) Next(N) > Finish Cancel
Enter the IP information.
MagicInfo Setup Wizard - v.1.12
Select Language -step 3
Select the language you want to install on the system for menus and
dialogs.
Current Language : Engilsh
German
English
French
Italian
Chinese [Traditional]
Japanese
Korean
Russian
Swedish
Turkish
Chinese [Simplified]
Portuguese
< Back(B) Next(N) > Finish Cancel
4
Select a language. (The default language is English.)
5
58
MagicInfo Setup Wizard - v.1.12
Select Screen Type - step 4
Landscape
Portrait
< Back(B) Next(N) > Finish Cancel
Select a display mode.
MagicInfo Setup Wizard - v.1.12
Setup Information
1. Application : MagicInfo Pro [LAN,WAN based version\
2. Internet Protocol [TCP/IP]
IP : 192.168.0.102
3. Language : English
4. Screen Type : Landscape
Do not show again
< Back(B) Apply Finish Cancel
6
Double-check the settings you have just configured.
7
―
If the execution icon does not appear, double-click the MagicInfo icon on the desktop. The icon will appear at the bottom
right of the screen.
59
Changing the Input source
Source
MENU m → Support → Contents Home → Source → ENTER E
Source
AV
Component
-
The displayed image may differ depending on the model.
TV
HDMI1
HDMI2
DisplayPort
PC
DVI
---
PC
PC
---
---
---
---
---
Tools Return
Source allows you to select a variety of sources and change source device names.
You can display the screen of a source device connected to the product. Select a source from source list to display the screen
of the selected source.
―
The input source can also be changed by using the SOURCE button on the remote control.
―
The screen may not display correctly if an incorrect source is selected for the source device you want to convert to.
60
Chapter 04
Using MDC
Conguring Settings for Multi Control
MENU m → System → Multi Control → ENTER E
Assign an individual ID to your product.
Conguring settings for Multi Control
•
ID Setup
Assign an ID to a set. (Range: 0~99)
Press
•
ID Input
Enter the ID number of the product connected to the input cable for input signal reception.
Enter the number you want using the number buttons on the remote control.
•
MDC Connection
Select a method to connect to MDC to receive the MDC signal.
-
-
to select a number, and press E.
RS232C MDC
Communicates with the MDC via a RS232C MDC cable.
RJ45 MDC
Communicates with the MDC via an RJ45 MDC cable.
•
DisplayPort Daisy Chain
To display the DP IN video input through the DP OUT output port, select a device connection
method from Single Stream Transport (SST ) and Multi Stream Transport (MST).
Clone: In this Single Stream Transport (SST) output mode, the same screen output is displayed on
two display devices connected.
―
If Clone is selected, the PC recognizes the two displays as a single monitor.
―
Clone mode is enabled if the input source is a digital input other than DisplayPort, such as
DVI, HDMI1, HDMI2, MagicInfo.
Expand: In this Multi Stream Transport (MST) mode, a different screen output is displayed on two
display devices connected.
―
If Expand is selected, the PC recognizes the two displays as separate monitors.
―
The mode functions only on a PC that supports DisplayPort 1.2 MST.
―
For Full HD resolution (1920x1080) displays, a maximum of four displays can be connected.
61
MDC Program Installation/Uninstallation
Installation
MDC installation can be affected by the
graphics card, mother board and network
conditions.
If a software installation window is not
displayed on the main screen, install with
the MDC Unified execution file in the
MDC folder on the CD.
If the directory path is not specified, the
program will be installed in the default
directory path.
Select "Launch MDC Unified" and
click "Finish" to run the MDC program
immediately.
Insert the installation CD into the CD-ROM drive.
1
Click the MDC Unified installation program.
2
Select a language for installation. Next, click "OK".
3
When the "Welcome to the InstallShield Wizard for MDC_Unified" screen appears, click "Next".
4
In the "License Agreement" window displayed, select "I accept the terms in the license agreement" and click "Next".
5
In the displayed "Customer Information" window, fill out all the information fields and click "Next".
6
In the displayed "Destination Folder" window, select the directory path you want to install the program in and click "Next".
7
In the displayed "Ready to Install the Program" window, check the directory path to install the program in and click "Install".
8
Installation progress will be displayed.
9
Click "Finish" in the displayed "InstallShield Wizard Complete" window.
10
The MDC Unified shortcut icon will be created on the desktop after installation.
11
-
The MDC execution icon may not be
displayed depending on the PC system
or product specifications.
-
Press F5 if the execution icon is not
displayed.
Uninstallation
Select Settings > Control Panel on the Start menu and double-click Add/Delete Program.
1
Select MDC Unified from the list and click Change/Remove.
2
62
Multiple display control "MDC" is an
application that allows you to easily
control multiple display devices
simultaneously using a PC.
What is MDC?
Connecting to MDC
Using MDC via RS-232C (serial data communications standards)
An RS-232C serial cable must be connected to the serial ports on the PC and monitor.
POWER
Monitor 1
RS232C IN/OUT
Monitor 2
Computer
63
Using MDC via Ethernet
Enter the IP for the primary display device and connect the device to the PC. One display device can connect to another using an RS-232C serial cable.
Connection using a direct LAN cable
―
Multiple products can be connected using the RJ45 port on the product and the LAN ports on the HUB.
POWER
Monitor 1
RJ45
HUB
Monitor 2
Computer
64
Connection using a cross LAN cable
―
Multiple products can be connected using the RS232C IN / OUT port on the product.
POWER
RS232C OUTRJ45
Monitor 1
Monitor 2
Computer
65
Connection Management
Connection management includes the Connection list and Connection list modification options.
Connection list - Connection list shows the details of the connections such as connection setting (IP/COM, Port No, MAC, and Connection Type), connection status, Set ID
Range, and detected devices.
Each connection can contain a maximum of 100 devices connected in serial daisy-chain fashion. All the LFDs detected in a connection are displayed in the Device list,
where the user can make groups and send commands to detected devices.
Connection list modification options - Connection modification options includes Add, Edit, Delete, and Refresh.
66
User Login
Launching the program displays the user login window.
The initial login ID (password: admin) and password (Auto Login: admin) are set to admin.
―
After logging in for the first time, make sure to change the password to ensure security.
―
To change the password, go to Home > User Settings.
After you are logged in, [User Login : admin] appears at the right bottom of the program.
To log in automatically when the program restarts, select the Auto Login checkbox in the User Login window.
67
Auto Set ID
Auto Set ID feature assigns a Set ID for all the LFDs connected in daisy-chain of a selected connection.
There can be a maximum of 100 LFDs in a connection.
The Set ID is assigned sequentially in the daisychain running from 1 to 99, and then finally to Set ID 0.
―
ID for the last 100th LFD is set to 0.
68
Cloning
Using the Cloning feature, you can copy the setting of one LFD and apply it to multiple selected LFDs.
You can select specific tab categories or all tab categories for cloning, using the copy setting option window.
―
To delete the settings you have configured, click the Paste Settings button.
69
Command Retry
This feature is used to specify the maximum number of times the MDC command will be retried in case of there being no reply or a corrupted reply from an LFD.
The retry count value can be set using the MDC options window.
The retry count value must be between 1-10. The default value is 1.
70
Getting Started with MDC
To start the program, click Start → Programs → Samsung → MDC Unified.
1
The login window appears after the MDC program is launched.
Enter the user ID and password.
•
The default user ID and password are admin.
•
Make sure to change the password after the first login.
Click Add to add a display device.
2
SET ID Range: Select a range of the unique ID assigned to a monitor.
-
If the connection is established via RS232C, go to Serial and specify the COM Port.
-
If the connection is established via Ethernet, enter the IP that was entered for the display device.
71
Main Screen Layout
2 3
1
6
1
Menu Bar
Change the status of a display device or the properties of the program.
Menus
Home
5
4
2
3
1
2
Device Category
3
Schedule Category
4
Set List
5
Modify the Set List
6
Help Topics
You can power on or off a selected device or change the input source or volume of the device.
Choose display devices from the list of sets, and select the Home tab.
Select an item and change the corresponding setting.
Power
•
On: Power on a selected display.
•
Off: Power off a selected display.
Input
•
Input Source : Change the input source.
-
Input sources available can vary depending on the Display Device Models.
-
The input source can be changed only for displays that are turned on.
•
Channel: Change the channel.
-
The TV channel can be changed by using the up/down arrow keys.
-
The channel can be changed only when the input source is TV.
-
Only registered channels can be selected.
-
Only applicable to models that support TVs.
View a list of connected display devices or device groups.
View a list of schedules for display devices.
Select the display device you want to adjust.
Add, edit, regroup or delete sets.
Display help topics for the program.
72
Volume
3
2
―
The volume can be changed or the sound can be muted only for displays that are turned on.
Volume
•
Adjust the volume of a selected display.
•
The volume can be adjusted using the slider bar in the range of 0 to 100.
Mute
•
Enable or disable Mute for a selected display.
Mute will automatically be disabled if Volume is adjusted when Mute is on.
Alert
3
Fault Device
•
This menu shows a list of display devices which have following errors - fan error, temperature error, brightness sensor
error, or lamp error.
•
Select a display device from the list. The Repair button will be enabled.
•
Click the Refresh button to refresh the error status of the display device. The recovered display device will disappear from
the Fault Device List.
Fault Device Alert
•
Display device in which error is detected will be reported by email.
•
Fill in all required fields. The Test and OK buttons will be enabled.
Ensure the Sender information and at least one Recipient are entered.
73
User Login
User Settings
•
Add, delete or edit login information.
Logout
•
Log out from the current user account as follows.
•
Click Logout. The message "Do you want to log admin out?" is displayed
•
Click Yes. The user login window appears.
•
If you do not want to log in, click Close. The program is closed.
―
If you close the program using Logout, the login window will appear prompting you to enter user information even if
the Auto Login checkbox is selected.
Screen Adjustment
Custom
The screen settings (contrast, brightness, etc.) can be adjusted.
Choose display devices from the list of sets, and select the Picture tab.
Select an item and change the corresponding screen setting.
Picture Mode
•
Adjust the picture mode for the selected display device.
Contrast
•
Adjust the contrast for the selected display device.
Brightness
•
Adjust the brightness for the selected display device.
74
Color
-
Color and Tint (G/R) are not available if the input source is PC.
-
Color, Tint (G/R), Color Tone and Color Temp. are not available if both PC Source and Video
Source are selected.
Color
•
Adjust the colors for the selected display device.
Tint (G/R)
•
Adjust the tint for the selected display device.
Color Tone
•
Adjust the background color tone for the selected display device.
Color Temp.
•
Adjust the color temperature for the selected display device.
―
This option is enabled if Color Tone is set to Off.
HDMI Black Level
•
Adjust the HDMI Black Level for the selected display device.
Options
Auto Motion Plus
This option is used to view dynamic images.
•
Off: Disable the Auto Motion Plus function.
•
Clear: Set the level of Auto Motion Plus to clear. This mode is suitable to display vivid images.
•
Standard: Set the level of Auto Motion Plus to standard.
•
Smooth: Set the level of Auto Motion Plus to smooth. This mode is suitable to display smooth images.
•
Custom: Customize the level of screen burn-in or flickering.
•
Demo: This function demonstrates the technology of Auto Motion Plus. The result when the mode is changed can be
previewed on the left side of the window.
―
Auto Motion Plus may not be available depending on the product.
•
Detail: View detailed information about the selected display device.
Brightness Sensor
•
Enable or disable the Brightness Sensor for the selected display device.
•
The Brightness Sensor detects the ambient light intensity and automatically adjusts the screen brightness.
―
Brightness Sensor may not be available depending on the product.
75
MPEG Noise Filter
Reduces MPEG noise to provide improved picture quality.
•
Off / Low / Medium / High / Auto
Smart LED
Controls the LED backlight to maximize picture clarity.
Cinema Black
In Movie mode, this feature dims the top and bottom areas of the video image to provide a more immersive viewing
experience.
•
Off: Turns off the Cinema Black feature.
•
On: Adjusts the dimming of the top and bottom areas of the screen according to the video.
Size
Picture Size
•
Adjust the screen size for the selected display device.
•
The Detail item will be disabled if Picture Size is set to a mode that does not support detailed configuration.
•
The -/+ buttons can be used to adjust Zoom.
•
The screen can be relocated using the up/down/left/right buttons.
Detail
•
You can view details of the selected screen size.
PC Screen Adjustment
•
Frequency adjustment or fine-tuning is available by using the -/+ buttons in Coarse or Fine.
•
To relocate the screen, click one of the four images below Position.
•
To automatically adjust the frequency, fine-tune or relocate the screen, click Auto Adjustment.
76
Advanced features
3D Mode
Select the 3D input format.
3D L/R Change
Swap the left and right pictures.
3D 2D
Displays the image for the left eye only.
3D Auto View
3D Control
If you set 3D Auto View to Message Notice, a pop up message window appears when the product receives a 3D signal.
3D Optimization
The overall adjustment of 3D effect.
3D Expert Pattern
View a 3D pattern.
3D Eect
Adjust 3D effects like perspective and depth for your preferred 3D viewing experience.
•
Auto: Automatically adjust the perspective and depth settings in accordance with the 3D input source.
•
Manual: Manually adjust the perspective and depth settings.
77
Advanced Settings
Dynamic Contrast
Adjust the screen contrast.
Gamma Control
Adjust the primary color intensity.
RGB Only Mode
Displays the Red, Green and Blue color for making fine adjustments to the hue and saturation.
Flesh Tone
Emphasize pink “Flesh Tone.”
Motion Lighting
Reduces power consumption by reducing screen brightness when the picture on the screen is in motion.
LED Motion Plus
Removes blur and judder from scenes with larger amounts of rapid movement to provide a clearer picture.
Color Space
Adjusts the range and variety of color (the color space) available to create images.
•
Auto / Native / Custom
-
To adjust Color, Red, Green, Blue and Reset, set Color Space to Custom.
White Balance
Adjust the color temperature for a more natural picture.
•
R-Offset / G-Offset / B-Offset
Adjust each color (red, green, blue) darkness.
•
R-Gain / G-Gain / B-Gain
Adjust each color (red, green, blue) brightness.
•
Reset
Resets the White Balance to it’s default settings.
78
Sound Adjustment
You can change the sound settings.
Choose display devices from the list of sets, and select the Sound tab.
Bass
•
Adjust the bass for the selected display.
Treble
•
Adjust the treble for the selected display.
-
The Bass or Treble item will be disabled if the item is not supported by the selected set.
System Setup
Video Wall
Balance(L/R)
•
Adjust the volume of the left and right speakers of the selected display device.
SRS TS XT
•
Enable or disable the SRS TS XT effect for the selected display device.
Choose display devices from the list of sets, and select the System tab.
The Video Wall function can be used to display part of a whole picture or repeat the same picture on each of connected
multiple display devices.
―
Video Wall is enabled only when devices are in the group.
Video Wall
•
Enable or disable Video Wall.
79
Format
•
Select the format to display the split screen.
Full Natural
PIP
-
Basic information required to adjust PIP will appear in the menu screen.
H
•
Select the number of horizontal display devices.
•
A maximum of 15 displays can be arranged in a row.
―
A maximum of 6 can be assigned to V if 15 is assigned to H.
V
•
Select the number of vertical display devices.
•
A maximum of 15 displays can be arranged in a row.
―
A maximum of 6 can be assigned to H if 15 is assigned to V.
Screen Position
•
View the layout of displays (configured by the screen divider) or change the layout as required.
•
Screen Position and Preview are enabled when Video Wall is set to on.
•
Note that if multiple sets are selected, Preview is enabled only if the settings for H and V match the layout of the selected
sets.
•
To change the Position, select a set and drag it to a new position.
―
The range of screen divider settings may differ depending on the model.
PIP Size
•
View the PIP Size of the current display.
PIP Source
•
Select a PIP input source.
Sound Select
•
Select and enable the sound from either the primary screen or secondary screen.
Channel
•
The channel can be changed if PIP Source is TV.
-
PIP will be disabled when Video Wall is On.
-
Note that Picture Size is disabled when PIP is On.
80
General
User Auto Color
•
Automatically adjust the screen colors.
―
Available only in PC mode.
Auto Power
•
Set the product to automatically power on.
Standby Control
•
Set the standby mode to activate if an input source is not detected.
Fan & Temperature
Configure the settings required to detect the fan speed and internal temperature for the product's protection.
Fan Control
•
Select a method to configure the fan speed.
Fan Speed Setting
•
Configure the fan speed.
Temperature
•
Detect the internal temperature by specifying the range of temperature.
81
Security
Safety Lock
•
Lock the on-screen menus.
―
To unlock the menus, set Safety Lock to Off.
Button Lock
•
Lock the buttons on the display device.
―
To unlock the buttons, set Button Lock to Off.
OSD Display
Source OSD
•
Select whether to display a message when the Source is changed.
Not Optimum Mode OSD
•
Select whether to display a message when a non-compatible mode is selected.
No Signal OSD
•
Select whether to display a message when there is no input signal.
MDC OSD
•
Select whether to display a message when settings are changed by the MDC.
82
Time
Clock Set
Change the current time on the selected display device according to the time set on a PC.
If the time is not set on the display device, null values will be displayed.
Timer
On Timer
•
Repeat: Specify the period for which you want to repeat the selected Timer.
Once, EveryDay, Mon~Fri, Mon~Sat, Sat~Sun, Manual
•
Holiday Apply: The Holiday Management settings can be applied to the Timer.
•
On Time: Set the time to power on the selected display device.
•
Volume: Specify the volume of the display device when it is powered on by On Time.
•
Source: Specify the input source of the display device when it is powered on by On Time.
O Timer
•
Repeat: Specify the period for which you want to repeat the selected Timer.
Once, EveryDay, Mon~Fri, Mon~Sat, Sat~Sun, Manual
•
Holiday Apply: The Holiday Management settings can be applied to the Timer.
•
Off Time: Set the time to power off the selected display device.
―
The checkboxes to select days of the week below Repeat are enabled only if Manual is selected.
83
Holiday Management
Holiday Management allows you to prevent devices that are set to be powered on by the Timer from turning on at a
specified date.
―
The Holiday Management function can be enabled or disabled in the Timer settings menu.
•
Add: You can specify holidays.
Click the Add button in the Holiday Management window.
•
Delete: Delete holidays. check the corresponding checkboxes and click this button.
•
List of holidays: View a list of holidays you have added.
Screen Burn Protection
Pixel Shift
Move the screen slightly at specified time intervals to prevent screen burn-in.
84
Screen Saver
―
Period (Hour) and Time (Sec) can be configured when Repeat is
selected.
This function prevents screen burn-in when the screen of the selected display device is left idle for an extended period of time.
Timer: You can set the timer for Screen Saver.
•
Off
•
Repeat: Display the image retention-preventive pattern set in Mode at specified time intervals (Period).
•
Interval: Display the image retention-preventive pattern set in Mode for a specified period of time (from Start Time to
End Time).
•
Mode: Select a screen protective pattern to display.
•
Period (Hour): Specify the time interval to activate the Screen Saver function.
―
The option is enabled when Repeat is selected for Timer.
•
Time (Sec): Specify the duration to keep the Screen Saver function on.
―
The option is enabled when Repeat is selected for Timer.
•
Start Time: Set start time to display screen saver.
―
The option is enabled when Interval is selected for Timer.
•
End Time: Set end time to display screen saver.
―
The option is enabled when Interval is selected for Timer.
―
Start Time and End Time can be configured when Interval is selected.
85
Safety Screen
The Safety Screen function can be used to prevent screen burn-in when a stationary image displays on the screen of a display
device for an extended period of time.
Lamp Control
Lamp Control is used to adjust the backlight to reduce power consumption.
Automatically adjust the backlight of the selected display device at a specified time.
If Manual Lamp Control is adjusted, Auto Lamp Control will automatically switch to Off.
Manually adjust the backlight for the selected display.
If Auto Lamp Control is adjusted, Manual Lamp Control will automatically switch to Off.
•
Ambient Light: Ambient Light detects ambient light intensity and automatically adjusts the screen brightness of all the
LFDs in the same serial chain.
86
Ticker
Input text while a video or image is displayed and display the text on the screen.
Ticker
Enable or disable Ticker.
•
Off / On
Message
Enter a message to display on the screen.
Timer
Set the Start Time and End Time to display a message (Message).
Position
Select an orientation to display a message (Message) from Horizontal and Vertical.
Motion
Specify the Direction and Speed to display a message (Message).
Font Options
Specify the message Size, Foreground Color, Foreground Opacity, Background Color and Background Opacity.
87
Tool Settings
Security
Reset
•
Panel Control: Turn on or off the screen of a display device.
•
Remote Control: Enable or disable the remote control.
•
Reset Picture: Reset the screen settings.
•
Reset Sound: Reset the sound settings.
•
Reset System: Reset the system settings.
•
Reset All: Reset the screen, sound and system settings at the same time.
88
Edit Column
Options
Configure the settings for the items that will be displayed on the list of displays.
•
Language: Select a language to use in the MDC program. After selecting a language, restart the MDC program to use the
selected language.
•
Command Retry Count: Specify the number of retry attempts when a command fails.
•
Error Status Interval: Specify the time interval to query the display device in order to check if "Fault Device" has
occurred.
•
Mail Alert Interval: Specify the time interval for email notifications in the event when "Fault Device" occurs.
Edit Column
Select the items you want to display in the list of sets.
89
Monitor Window
A window appears showing details for data transfer between the computer and display devices.
•
Filter
Information
View the program information.
90
Other Functions
Resizing a Window
Place the mouse pointer on a corner of the program window. An arrow will appear.
Move the arrow to customize the size of the program window.
91
Group Management
Creating Groups
Create groups and manage the list of sets on a group basis.
―
Duplicate group names cannot be used.
Right-click and select Group Edit in the display device list section on the left side of the program window.
1
In the Edit Group window displayed, click Add on the same level or Add on the sub level.
2
-
The Add on the same level button is enabled only if at least one group is created.
•
Add on the same level: Create a group on the same level as the selected group.
92
Deleting Groups
•
Add on the sub level: Create a sub-group under the selected group.
Enter the group name.
3
Select a group name, and click Edit.
1
In the Edit Group window displayed, click Delete.
2
Click Yes. The group will be deleted.
3
93
Renaming Groups
Rename
Select a group name, and click Edit.
1
In the Edit Group window displayed, click Rename.
2
If a cursor appears in the old group name, enter a new group name.
3
Schedule Management
Creating Schedules
Create and register a schedule on a group basis.
Click All Schedule List in the schedule section on the left side of the program window. The Add button will be enabled
1
in the middle.
94
Click the Add button. The Add Schedule window will appear.
2
Click Add below the Device Group item, and select the group you want to add a schedule to.
3
Select Date&Time/Action and click OK. The schedule will be added and a list of schedules will appear in the set list
4
window.
-
Device Group: Select a group.
-
Date&Time
Instant Execution: Run the schedule immediately.
Timer: Set the date, time and interval to run the schedule.
-
Action: Select a function that will activate at the specified time and interval.
Schedule Modification
To modify a schedule, select the schedule and click Edit.
Deleting a Schedule
To delete a schedule, select the schedule and click Delete.
95
-
This program may malfunction
sometimes due to a communication
problem between the PC and display
or electromagnetic waves emitted from
nearby electronic devices.
Troubleshooting Guide
Issue Solution
The display you want to control does not
appear on the system information chart.
Check the connection of the RS232C cable (check that the cable is properly connected to appropriate serial port).
1
Check that another display with a duplicate ID is not connected. Connecting displays with a duplicate ID can cause
2
the displays not to be shown due to data collision.
Check that the display ID is within the range of 0 and 99. (Change the ID using the Display menu.)
3
―
For a display that supports the ID in a range of 0 to 99, the ID should be set between 0 and 99.
The display you want to control does not
appear on the other Control Info Grids.
The following message appears
repeatedly.
Displays power on or o at dierent
time from one another even though On
Time or O Time is set.
The remote control does not work.
Check that the display is powered on. (See the power status in the system information chart.)
Ensure you select the input source the display is connected to.
Check that the display you want to control is selected.
Adjust the time on the PC to synchronize the time between the connected displays.
The remote control may not work if the RS-232C cable is removed or the program is closed abnormally while the Remote
Control function is Disable. To resolve this, run the program again and set Remote Control to Enable.
96
How display properties are shown when multiple displays are used
When no display is selected: The default value is displayed.
1
When one display is selected: Settings for the selected display are displayed.
2
When two displays are selected (e.g. in sequence of ID 1 and ID 3): The settings for ID 1 are displayed before the settings for ID 3.
3
When the All+Select checkbox is checked and all displays are selected: The default settings are displayed.
4
97
Chapter 05
Screen Adjustment
Configure the Picture settings (Backlight, Color Tone, etc.).
-
The layout of the
menu options may vary depending on the product.
Picture Mode
MENU m → Picture → Picture Mode → ENTER E
Select a picture mode (Picture Mode) suitable for the environment where the
product will be used.
Different Picture Mode options are displayed depending on the current input
source.
Picture Mode
·
Backlight
·
Contrast
·
Brightness
·
Sharpness
·
Color
·
Tint (G/R)
Information
60
70
45
50
50
G 50 R 50
If the input source is PC, DVI or DisplayPort
•
Information: This mode reduces eye fatigue and is suitable for displaying information to the public.
•
Advertisement: This mode is suitable for displaying video content and indoor/outdoor advertisements.
If the input source is AV, Component, HDMI1, HDMI2, or TV
•
Dynamic: This mode is suitable when the ambient light is bright.
•
Standard: This mode is generally suitable for any environment.
•
Natural: Suitable for reducing eye strain.
•
Movie: This mode reduces eye fatigue.
-
The displayed image may differ depending on the model.
98
Backlight / Contrast / Brightness /
Sharpness / Color / Tint (G/R)
MENU m → Picture → ENTER E
Your product has several options for adjusting picture quality.
Input source Picture Mode Adjustable options
PC, DVI, DisplayPort, HDMI1 (when
a PC is connected), HDMI2 (when a
PC is connected)
Information Backlight / Contrast / Brightness /
Sharpness
Advertisement Backlight / Contrast / Brightness /
Sharpness / Color
Picture Mode
·
Backlight
·
Contrast
·
Brightness
·
Sharpness
·
Color
·
Tint (G/R)
-
The displayed image may differ depending on the model.
Information
G 50 R 50
60
70
45
50
50
AV, Component, HDMI1, HDMI2, TV Dynamic, Standard, Natural, Movie Backlight / Contrast / Brightness /
Sharpness / Color / Tint (G/R)
―
When you make changes to Backlight, Contrast, Brightness, Sharpness, Color or Tint (G/R), the OSD will be adjusted
accordingly.
―
You can adjust and store settings for each external device you have connected to an input on the product.
―
Lowering picture brightness reduces power consumption.
99
Screen Adjustment
choose size and aspect ratio picture displayed on screen.
MENU m → Picture → Screen Adjustment → ENTER E
Screen Adjustment
Picture Size 16:9
·
Zoom/Position
PC Screen Adjustment
Resolution Select
-
The displayed image may differ depending on the model.
O
Picture Size
―
Different Screen Adjustment options are displayed depending on the current input source.
•
16:9: Sets the picture to 16:9 wide mode.
•
Zoom1: Use for moderate magnification. Cuts off the top and sides.
•
Zoom2: Use for a stronger magnification.
•
Smart View 1: Reduces the 16:9 picture by 50%.
―
Smart View 1 is enabled only in HDMI1, HDMI2 mode.
•
Smart View 2: Reduces the 16:9 picture by 25%.
―
Smart View 2 is enabled only in HDMI1, HDMI2 mode.
•
Wide Fit: Enlarges the aspect ratio of the picture to fit the entire screen.
•
4:3: Sets the picture to basic (4:3) mode.
―
Do not set your product to 4:3 format for a long time.
The borders displayed on the left and right, or top and bottom of the screen may cause image retention (screen burn)
which is not covered by the warranty.
•
Screen Fit: Displays the full image without any cut-off when HDMI1, HDMI2 (720p / 1080i / 1080p) or Component (1080i
/ 1080p) signals are inputted.
•
Custom: Changes the resolution to suit the user's preferences.
•
Original Ratio: If the input source is PC, DVI, HDMI1(PC connection), HDMI2 (PC connection), or DisplayPort, the video
will display in the original aspect ratio.
―
Available ports may differ depending on the model.
100
