User’s Guide

BASIC

This guide provides information concerning installation, basic operation and troubleshooting on windows.

ADVANCED

This guide provides information about the installation, advanced configuration, operation and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

Storing the toner cartridge 41

1. Introduction

Key benefits 4

Features by models 6

Useful to know 8

About this user’s guide 9

Safety information 10

Machine overview 16

Control panel overview 19

Turning on the machine 21

Installing the driver locally 22

Reinstalling the driver 24

2. Learning the Basic Usage

Redistributing toner 43

Replacing the toner cartridge 44

Cleaning the machine 46

Tips for moving & storing your machine 50

4. Troubleshooting

Tips for avoiding paper jams 52

Clearing paper jams 53

Understanding the status LED 56

5. Appendix

Specifications 60

Media and tray 26

Basic printing 35

3. Maintenance

Ordering supplies and accessories 39

Available supplies 40

Regulatory information 69

1. Introduction

This chapter provides information you need to know before using the machine.

•Key benefits 4

• Features by models 6

• Useful to know 8

• About this user’s guide 9

• Safety information 10

• Machine overview 16

• Control panel overview 19

• Turning on the machine 21

• Installing the driver locally 22

• Reinstalling the driver 24

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports the Eco feature (see "Easy Eco Driver" on page 148).

• To save paper, you can print multiple pages on a single sheet of paper (see "Using advanced print features" on page 133).

• To save paper, you can print on both sides of the paper (manual doublesided printing) (see "Using advanced print features" on page 133).

• To save electricity, this machine automatically conserves electricity by substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Print with excellent quality and speed

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

- M202x series/M202xW series

▪ For single-side printing, 20 ppm (A4) or 21 ppm (Letter).

- SL-M2024 series/SL-M2024W series

▪ For single-side printing, 18 ppm (A4) or 19 ppm (Letter).

Convenience

• Simply touch your cell phone on the NFC tag on your printer and get the print job done (see "Using the NFC feature" on page 122).

• Samsung Easy Printer Manager is a program that monitors and informs you of the machine’s status and allows you to customize the machine’s settings (see "Using Samsung Easy Printer Manager" on page 151).

• Smart Update allows you to check for the latest software and install the latest version during the printer driver installation process. This is available only for Windows OS users.

• If you have Internet access, you can get help, support application, machine drivers, manuals, and order information from the Samsung website, www.samsung.com > find your product > Support or Downloads.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 62).

• Print watermark: You can customize your documents with words, such as “Confidential” (see "Using advanced print features" on page 133).

• Print posters: The text and pictures of each page of your document are magnified and printed across the multiple sheets of paper and can then be taped together to form a poster (see "Using advanced print features" on page 133).

• You can print in various operating systems (see "System requirements" on page 65).

• Your machine is equipped with a USB interface.

Supports various wireless network setting method

Wireless networking may not be available depending on the model (see "Features by models" on page 6).

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on the machine and the access point (a wireless router).

•Using the USB cable

- You can connect and set various wireless network settings using a USB cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 94.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

Software

Operating System M202x series M202xW series

Windows ● ●

Mac ● ●

Linux ● ●

Unix

Software M202x series M202xW series

PCL printer driver

SPL printer driver ● ●

PS printer driver

XPS printer driver

Samsung Easy Printer Manager ● ●

SyncThru™ Web Service ●

SyncThru™ Web Admin Service ●

Features by models

Variety feature

(●: Included, Blank: Not available)

Samsung Printer Status ● ●

Easy Eco Driver Anyweb Print ● ●

Easy Capture Manager ● ●

a. For XPS driver, it is only supported for windows through the Samsung website (www.samsung.com)

Software M202x series M202xW series

Features M202x series M202xW series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX wired LAN

Network Interface 802.11b/g/n wireless LAN ●

NFC printing ●

IPv6 ●

Eco printing(Easy Eco Driver)

a. Setting the ECO settings is available from the windows driver.

● ●

Wi-Fi Protected Setup™ (WPS) ●

Manual duplex (2-sided) printing ● ●

AirPrint ●

Google Cloud Print™ ●

Useful to know

Where can I download the machine’s driver?

• Visit www.samsung.com to download the latest machine’s driver, and install it on your system.

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/region to view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and troubleshoot accordingly (see "Understanding the status LED" on page 56).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

The machine does not print.

• Open the print queue list and remove the document from the list (see "Canceling a print job" on page 36).

• Remove the driver and install it again (see "Installing the driver locally" on page 22).

• Select your machine as your default machine in your Windows.

A paper jam has occurred.

• Open and close the top cover (see "Front view" on page 17).

• Check the instructions on removing jammed paper in this manual and troubleshoot accordingly (see "Clearing paper jams" on page 53).

About this user’s guide

This user's guide provides information for your basic understanding of the machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine depending on its options or model you purchased.

• The screenshots in this user's guide may differ from your machine depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

Conventions

General icons

Icon Text Description

Gives users information to protect the machine from

Caution

Note

possible mechanical damage or malfunction.

Provides additional information or detailed specification of the machine function and feature.

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to your machine. Be sure to read and understand all of these instructions before using the machine. After reading this section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Warning

Caution

Hazards or unsafe practices that may result in severe personal injury or death.

Hazards or unsafe practices that may result in minor personal injury or property damage.

Operating environment

Warning

Do not use if the power cord is damaged or if the electrical outlet is not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes strange noises, or generates an odd odor, immediately turn off the power switch and unplug the machine.

Do not attempt.

• The user should be able to access the power outlet in case of emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the plug with wet hands.

This could result in electric shock or fire.

1. Introduction

Safety information

Caution

During an electrical storm or for a period of non-operation, remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears damaged, unplug the machine from all interface connections and request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions have been followed, unplug the machine from all interface connections and request assistance from qualified service personnel.

Operating method

Caution

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper tray.

You may get injured.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the electrical outlet.

Otherwise, this could result in electric shock or fire.

If the plug does not easily enter the electrical outlet, do not attempt to force it in.

Call an electrician to change the electrical outlet, or this could result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC interface cords.

This could result in electric shock or fire and/or injury to your pet.

Be care when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper output area may get hot. Do not allow children to touch.

Burns can occur.

When r emov ing j amme d pap er, d o not use t weez ers o r sha rp m etal objects.

It can damage the machine.

1. Introduction

Safety information

Do not allow too many papers to stack up in the paper output tray.

It can damage the machine.

Do not block or push objects into the ventilation opening.

This could result in elevated component temperatures which can cause damage or fire.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Installation / Moving

Warning

Do not place the machine in an area with dust, humidity, or water leaks.

This could result in electric shock or fire.

Caution

Before moving the machine, turn the power off and disconnect all cords. The information below are only suggestions based on the units weight.If you have a medical condition that prevents you from lifting, do not lift the machine. Ask for help, and always use the appropriate amount of people to left the device safety.

Then lift the machine:

• If the machine weighs under 20 kg (44.09 lbs), lift with 1 person.

• If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18 lbs), lift with 2 people.

• If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or more people.

The machine could fall, causing injury or machine damage.

Choose a flat surface with enough space for ventilation to place the machine. Also consider the space required to open the cover and trays.

The place should be well-ventilated and be far from direct light, heat, and humidity.

Place the machine in the environment where it meets the operating temperature and humidity specification.

Otherwise, quality problems can occur and cause damage to the machine.

See "General specifications" on page 60.

When using the machine for a long period of time or printing a large number of pages in a non-ventilated space, it could pollute the air and be harmful to your health. Place the machine in a wellventilated space or open a window to circulate the air periodically.

Do not place the machine on an unstable surface.

The machine could fall, causing injury or machine damage.

1. Introduction

Safety information

Use only No.26 AWGa or larger, telephone line cord, if necessary.

Otherwise, it can cause damage to the machine.

Use the power cord supplied with your machine for safe operation. If you are using a cord which is longer than 2 meters (6 feet) with a 110 V machine, then the gauge should be 16 AWG or larger.

Otherwise, it can cause damage to the machine, and could result in electric shock or fire.

Make sure you plug the power cord into a grounded electrical outlet.

Otherwise, this could result in electric shock or fire.

Do not overload wall outlets and extension cords.

This can diminish performance, and could result in electric shock or fire.

Do not put a cover over the machine or place it in an airtight location, such as a closet.

Maintenance / Checking

Caution

Unplug this product from the wall outlet before cleaning the inside of the machine. Do not clean the machine with benzene, paint thinner or alcohol; do not spray water directly into the machine.

This could result in electric shock or fire.

When you are working inside the machine replacing supplies or cleaning the inside, do not operate the machine.

You could get injured.

Keep cleaning supplies away from children.

Children could get hurt.

If the machine is not well-ventilated, this could result in fire.

The machine should be connected tothe power level which is specified on the label.

If you are unsure and want to check the power level you are using, contact the electrical utility company.

a. AWG: American Wire Gauge

Do not disassemble, repair or rebuild the machine by yourself.

It can damage the machine. Call a certified technician when the machine needs repairing.

1. Introduction

Safety information

• Do not remove any covers or guards that are fastened with screws.

• Fuser units should only be repaired by a certified service technician. Repair by non-certified technicians could result in fire or electric shock.

• The machine should only be repaired by a Samsung service technician.

Supply usage

Caution

To clean and operate the machine, strictly follow the user's guide provided with the machine.

Otherwise, you could damage the machine.

Keep the power cable and the contact surface of the plug clean from dust or water.

Otherwise, this could result in electric shock or fire.

Do not disassemble the toner cartridge.

Toner dust can be dangerous if inhaled or ingested.

Do not burn any of the supplies such as toner cartridge or fuser unit.

This could cause an explosion or uncontrollable fire.

When storing supplies such as toner cartridges, keep them away from children.

Toner dust can be dangerous if inhaled or ingested.

When changing the toner cartridge or removing jammed paper, be careful not to let toner dust touch your body or clothes.

Toner dust can be dangerous if inhaled or ingested.

When toner gets on your clothing, do not use hot water to wash it.

Hot water sets toner into fabric. Use cold water.

1. Introduction

Safety information

Using recycled supplies, such as toner, can cause damage to the machine.

In case of damage due to the use of recycled supplies, a service fee will be charged.

For supplies that contain toner dust (toner cartridge, waste toner bottle, imaging unit, etc.) follow the instructions below.

• When disposing of the supplies, follow the instructions for disposal. Refer to the reseller for disposal instructions.

• Do not wash the supplies.

• For a waste toner bottle, do not reuse it after emptying the bottle.

If you do not follow the instructions above, it may cause machine malfunction and environmental pollution. The warranty does not cover damages caused by a user's carelessness.

1. Introduction

Machine overview

Components

The actual component may differ from the illustration below. Some components may change depending on the circumstances.

Power cord Quick installation guide

Software CD

a. The software CD contains the printer drivers and software applications. b. Miscellaneous accessories included with your machine may vary by country of purchase and specific model.

Misc. accessories

1. Introduction

Machine overview

Front view

• This illustration may differ from your machine depending on its model.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 6).

1 Output tray 5 NFC (Near Field Communication) tag

2 Control panel 6 Top cover

3 Tray 7 Toner cartridge

4 Output support 8 Paper width guide

1. Introduction

Machine overview

Rear view

• This illustration may differ from your machine depending on its model.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 6).

1USB port

2Power receptacle

1. Introduction

Control panel overview

This control panel may differ from your machine depending on its model. There are various types of control panels.

WPS

Configures the wireless network connection easily without a computer (see "Wireless network setup" on page 93).

• Configuration sheet

- Press and hold this button for about 10 seconds until the green LED blinks slowly, and release.

• Prints supplies info report / usage count report

- Press and hold this button for about 15 seconds until the green LED on, and release.

• Manual print

- Press this button each time you load a sheet of paper in the tray if you have selected Manual Feeder for Source in your printer driver.

1Toner

LED

Shows the status of the toner (see "Status LED" on page

57).

1. Introduction

Control panel overview

screen

• Prints the screen

- Press this button and the green LED will start blinking. If you want to print only the active screen, release the button when the green LED stops blinking. If you want to print the whole screen, release the button while it’s blinking.

• Print Screen can only be used in the Windows and Mac operating systems.

• You can only use this function with USBconnected machine.

• When printing the active window/whole monitor screen using the print screen button, the machine may use more toner depending on what is being printed.

• You can only use this function if the machine’s

Easy Printer Manager program is installed if you are a Mac OS user, you need to enable

Screen Print Settings from the Easy Printer Manager to use the Print Screen feature.

3 Power You can turn the power off or wake the machine up from

the sleep mode with this button.

4 Status

LED

a. M202xW only. b. M202x only.

Shows the status of your machine (see "Status LED" on page 57).

• Configuration sheet

- Press and hold this button for about 10 seconds until the green LED blinks slowly, and release.

• Prints supplies info report / error report

- Press and hold this button for about 15 seconds until the green LED on, and release.

• Manual print

- Press this button each time you load a sheet of paper in the tray if you have selected Manual

Feeder for Source in your printer driver.

1. Introduction

Turning on the machine

Connect the machine to the electricity supply first.

Press (power) on the control panel.

If you want to turn the power off, press (power) on the control panel.

1. Introduction

Installing the driver locally

A locally connected machine is a machine directly attached to your computer using the cable.

• If you are a Mac or Linux OS user, refer to the "Software Installation" on page 83.

• The installation window in this User’s Guide may differ depending on the machine and interface in use.

• Only use a USB cable no longer than 3 meters (118 inches).

Windows

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CDROM drive and click OK.

• For Windows 8,

Review and accept the installation agreements in the installation

window. Then, click Next.

If the installation window does not appear, from Charms, select Search > Apps and search for Run. Type in X:\Setup.exe, replacing “X” with the letter that represents your CD-ROM drive and click OK.If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Select USB connection on the Printer Connection Type screen. Then,

click Next.

Follow the instructions in the installation window.

1. Introduction

Installing the driver locally

From the Windows 8 Start Screen

• The V4 driver is automatically downloaded from the Windows Update if your computer is connected to the Internet. If not, you can manually download the V4 driver from Samsung website, www.samsung.com > find your product > Support or downloads.

• You can download Samsung Printer Experience app from the Windows

Store. You need have a Microsoft account to use the Windows Store.

1 From Charms, select Search. 2 Click Store. 3 Search and click Samsung Printer Experience. 4 Click Install.

• If you install the driver using the supplied software CD, V4 driver is not installed. If you want to use the V4 driver in the Desktop screen, you can download from the Samsung website, www.samsung.com >find your product > Support or downloads.

• If you want to install Samsung’s printer management tools, you need to install them using the supplied software CD .

Make sure that your computer is connected to the Internet and powered

on.

Make sure that the machine is powered on.

Connect the computer and the machine with a USB cable.

The driver is automatically installed from the Windows Update.

1. Introduction

Reinstalling the driver

If the printer driver does not work properly, follow the steps below to reinstall the driver.

Windows

Make sure that the machine is connected to your computer and

powered on.

From the Start menu, select Programs or All Programs > Samsung

Printers > Uninstall Samsung Printer Software.

• For Windows 8,

1 From Charms, select Search > Apps.

2 Search and click Control Panel.

3 Click Programs and Features.

4 Right-click the driver you want to uninstall and select Uninstall.

From the Windows 8 Start Screen

Make sure that the machine is connected to your computer and

powered on.

Click on the Uninstall Samsung Printer Software tile in the Start

screen.

Follow the instructions in the window.

• If you cannot find a Samsung Printer Software tile, unintstall from the desktop screen mode.

• If you want to uninstall Samsung’s printer management tools, from the

Start screen, right-click the app > Uninstall > right-click the program you want to delete > Uninstall and follow the instruction in the window.

5 Follow the instructions in the window.

Follow the instructions in the installation window.

Insert the software CD into your CD-ROM drive and install the driver

again (see "Installing the driver locally" on page 22).

1. Introduction

2. Learning the Basic Usage

After installation is complete, you may want to set the machine’s default settings. Refer to the next section if you would like to set or change values.

• Media and tray 26

• Basic printing 35

Media and tray

This chapter provides information on how to load print media into your machine.

• Using print media that does not meet these specifications may cause problems or require repairs. Such repairs are not covered by Samsung’s warranty or service agreements.

• Make sure not to use the inkjet photo paper with this machine. It could cause damage to the machine.

• Using inflammable print media can cause a fire.

• Use designated print media (see "Print media specifications" on page 62).

The use of inflammable media or foreign materials left in the printer may lead to overheating of the unit and, in rare cases may cause a fire.

1 Paper width guide

If you do not adjust the guide, it may cause paper registration, image skew, or jamming of the paper.

2 Tray

Tray overview

To change the size, you need to adjust the paper guide.

2. Learning the Basic Usage

Media and tray

Loading paper in the tray

Open the tray.

Adjust the tray size to the media size you are loading (see "Tray overview"

on page 26). Then place the paper with the side you want to print facing up and open the output tray.

Squeeze the paper width guide and slide it to the edge of the paper stack

without causing it to bend.

Flex or fan the edge of the paper stack to separate the pages before

loading papers.

2. Learning the Basic Usage

Media and tray

• Do not push the paper width guide too far causing the media to warp.

• If you do not adjust the paper width guide, it may cause paper jams.

• Do not use a paper with a leading-edge curl, it may cause a paper jam or the paper can be wrinkled.

When you print a document, set the paper type and size for the tray (see

"Setting the paper size and type" on page 34).

2. Learning the Basic Usage

Media and tray

Manual feeding in the tray

The manual feeder can hold special sizes and types of print material, such as postcards, note cards, and envelopes (see "Print media specifications" on page

62).

Tips on using the manual feeder

• Load only one type, size and weight of print media at time in the manual feeder.

•If you select Paper > Source > Manual Feeder for the paper source in

your software application, you need to press (Print screen) or

(WPS) button each time you print a page and load only one type,

size and weight of print media at a time on the manual tray.

• To prevent paper jams, do not add paper while printing when there is still paper in the manual feeder.

• When the machine is in a power save mode, the machine does not feed paper from the manual feeder. Wake up the machine by pressing the power button before using the manual feeder.

• Print media should be loaded face up with the top edge going into the manual feeder first and be placed in the center of the tray.

• To ensure printing quality and to prevent paper jams, only load the available paper (see "Print media specifications" on page 62).

• Flatten any curl on postcards, envelopes, and labels before loading them into the manual feeder.

• When printing on special media, you must follow the loading guidelines (see "Printing on special media" on page 30).

2. Learning the Basic Usage

Media and tray

Printing on special media

Types

Tray

Envelope ●

The table below shows the special media usable in tray.

To change the paper setting set in the machine, from the Printing preferences window > Paper tab > Paper Type (see "Opening printing preferences" on page

36).

When using special media, we recommend you feed one sheet at a time (see "Print media specifications" on page 62).

To see for paper weights for each sheet, refer to "Print media specifications" on page 62.

Types

Tray

Plain ●

Thick ●

Preprinted ●

Cotton ●

Recycled ●

Archive ●

a. The paper types available manual feeding in tray.

(●: Supported)

Thin ●

Bond ●

Color ●

CardStock ●

Labels ●

2. Learning the Basic Usage

+ 169 hidden pages
