Samsung M1933N, M1913N User Manual

MICROWAVE OVEN

Owener’s Instructions and Cooking Guide

M1933N/M1913N

Quick Look-up Guide ................................................................2

Oven..........................................................................................3

Accessories...............................................................................3

Control Panel.............................................................................4

Using this Instruction Booklet....................................................5

Safety Precautions....................................................................5

Installing Your Microwave oven ................................................7

Setting the Time (M1933N).......................................................7

How a Microwave Oven Works.................................................8

Checking that Your Oven is Operating Correctly......................8

What to Do if You are in Doubt or Have a Problem..................9

Cooking / Reheating..................................................................9

Power Levels...........................................................................10

Stopping the Cooking..............................................................10

Adjusting the Cooking Time....................................................11

Manual Defrosting Food (M1913N).........................................11

Using the Auto Defrost Feature (M1933N) .............................11

Auto Defrost Settings (M1933N) .............................................12

Using the Instant Reheat/Cook Feature..................................12

Instant Reheat/Cook Settings .................................................13

Multistage Cooking (M1933N).................................................14

Switching the Beeper Off(M1933N) ........................................15

Safety-Locking Your Microwave Oven(M1933N)....................15

Remembering Function (M1933N)..........................................15

Cookware Guide .....................................................................16

Cooking Guide ........................................................................17

Cleaning Your Microwave Oven .............................................22

Storing and Repairing Your Microwave Oven.........................23

Technical Specification ...........................................................23

Quick Look-up Guide

Model: M1933N

If you want to cook some food

1. Place the food in the oven.

2. Select the cooking time by pressing the 10min, 1min or

3. Press the button.

If you want to defrost some food

1. Place the frozen food in the oven.

2. Select the weight by pressing the kg and g button as

3. Press the button.

Select the power level by pressing the button once or more times.

10s button as required.

Result :

Press the Auto ( )buttononceormoretimeaccording to the type of food to be defrosted. Refer to the table on the page 12 for further details.

required.

Cooking starts. The oven beeps four times when cooking is over.

Model: M1913N

If you want to cook some food

1. Place the food in the oven. Select the power level by rotating the COOKING POWER

CONTROL knob.

2. Select the cooking time by rotating the TIMER knob.

If you want to defrost some food

1. Turn the COOKING POWER CONTROL knob to defrost( ) symbol.

2. Turn the TIMER knob to select the appropriate time.

If you want to adjust the cooking time

Leave the food in the oven. Turn the TIMER knob to desired time.

If you want to add an extra 30 seconds

Leave the food in the oven. Press +30s once or more times for each extra 30 seconds thatyouwishtoadd.

Oven

Accessories

Model: M1933N

VENTILATION HOLES

DOOR

TURNTABLE

DOOR LATCHES

Model: M1913N

VENTILATION HOLES

DOOR

ROLLER RING

COUPLER

LIGHT

SAFETY INTERLOCK HOLES

LIGHT

DISPLAY

CONTROL PANEL

OPEN DOOR PUSH BUTTON

TIMER KNOB VARIABLE COOKING POWER CONTROL KNOB

Depending on the model that you have purchased, you are supplied with several accessories that can be used in a variety of ways.

1. Coupler, already placed over the motor shaft in the base of the oven. Purpose :

2. Roller ring,tobeplacedinthecentreoftheoven. Purpose :

3. Turntable,tobeplacedontherollerringwiththecentre fitting to the coupler. Purpose :

The coupler rotates the turntable.

The roller ring supports the turntable.

The turntable serves as the main cooking surface; it can be easily removed for cleaning.

☛ DO NOT operate the microwave oven without the roller ring and

turntable.

DOOR LATCHES

TURNTABLE

COUPLER

ROLLER RING

SAFETY INTERLOCK HOLES

OPEN DOOR PUSH BUTTON

Control Panel

Model:M1933N Model:M1913N

1. DISPLAY

2. INSTANT REHEAT/COOK

SELECTION

3. AUTO DEFROST FEATURE SELECTION

4. WEIGHT SELECTION

5. MICRO WAVE MODE SELECTION

6. CLOCK SETTING

7. TIME SETTING

8. STOP/CANCEL BUTTON

9. START BUTTON

10. OPEN DOOR PUSH BUTTON

1. DEFROST

2. COOKING POWER CONTROL KNOB

3. TIMER KNOB

4. INSTANT REHEAT/COOK

5. OPEN DOOR PUSH BUTTON

Using this Instruction Booklet

Safety Precautions

You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contain much valuable information on cooking with your microwave oven:

• Safety precautions

• Suitable accessories and cookware

• Useful cooking tips

Inside the cover you will find a quick look-up guide explaining three basic cooking operations:

• Cooking food

• Defrosting food

• Adding extra cooking time

At the front of the booklet you will find illustrations of the oven, and more importantly the control panel, so that you can find the buttons more easily.

The step-by-step procedures use two different symbols.

☛✉

Important Note

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

Failure to observe the following safety precautions may result in harmful exposure to microwave energy. (a) Underno circumstances should any attempt be made to operate the oven with

the door open or to tamper with the safety interlocks (door latches) or to insert anything into the safety interlock holes.

(b) Do not place any object between the oven door and front face or allow food or

cleaner residues to accumulate on sealing surfaces. Ensure that the door and door sealing surfaces are kept clean by wiping after use first with a damp cloth and then with a soft dry cloth.

qualified microwave service technician trained by the manufacturer. It is particularly important that the oven door closes properly and that there is no damage to the: (1) Door, door seals and sealing surfaces (2) Door hinges (broken or loose) (3) Power cable

(d) The oven should not be adjusted or repaired by anyone other than a properly

qualified microwave service technician trained by the manufacturer.

Important Safety Instructions. Read Carefully and keep for future reference. Before cooking food or liquids in your microwave oven, please check

that the following safety precautions are taken.

1. DO NOT use any metallic cookware in the microwave oven:

• Metallic containers

• Dinnerware with gold or silver trimmings

• Skewers, forks, etc. Reason:

2. DO NOT heat:

• Airtight or vacuum-sealed bottles, jars, containers

• Airtightfood.

Reason: Tip:

3. DO NOT operate the microwave oven when it is empty. Reason: Tip:

4. DO NOT cover the rear ventilation slots with cloths or paper. Reason:

5. ALWAYS use oven gloves when removing a dish from the oven. Reason:

6. DO NOT touch heating elements or interior oven walls. Reason:

7. To reduce the risk of fire in the oven cavity:

• Do not store flammable materials in the oven

• Remove wire twist ties from paper or plastic bags

• Do not use your microwave oven to dry newspapers

• If smoke is observed, keep the oven door closed and switch off or

Electric arcing or sparking may occur and may damage the oven.

Ex) Baby food jars

Ex) Eggs, nuts in shells, tomatoes

The increase in pressure may cause them to explode. Remove lids and pierce skins, bags, etc.

Theovenwallsmaybedamaged. Leave a glass of water inside the oven at all times. The water will absorb the microwaves if you accidentally set the oven going when it is empty.

The cloths or paper may catch fire as hot air is evacuated from the oven.

Some dishes absorb microwaves and heat is always transferred from the food to the dish. The dishes are therefore hot.

These walls may be hot enough to burn even after cooking has finished, even though they do not appear to be so. Do not allow inflammable materials to come into contact with any interior area of the oven. Let the oven cool down first.

disconnect the oven from the power supply

Safety Precautions (continued)

8. Take particular care when heating liquids and baby foods.

• ALWAYS allow a standing time of at least 20 seconds after the oven has been switched off so that the temperature can equalize.

• Stir during heating, if necessary, and ALWAYS stir after heating.

• Take care when handling the container after heating. You may burn yourself if the container is too hot.

• Take particular care when heating liquids and baby foods.

• A risk of delayed eruptive boiling exists.

• To prevent delayed boiling and possible scalding, you should put a plastic spoon or glass stick into the beverages and stir before, during and after heating. Reason:

• In the event of scalding, follow these FIRST AID instructions: * Immerse the scalded area in cold water for at least 10 minutes. * Cover with a clean, dry dressing. * Do not apply any creams, oils or lotions.

• NEVER fill the container to the top and choose a container that is wider at the top than at the bottom to prevent the liquid from boiling over. Bottles with narrow necks may also explode if overheated.

• ALWAYS check the temperature of baby food or milk before giving it to the baby.

• NEVER heat a baby’s bottle with the teat on, as the bottle may explode if overheated.

9. Be careful not to damage the power cable.

• Do not immerse the power cable or plug in water and keep the power cable away from heated surfaces.

• Do not operate this appliance if it has a damaged power cable or plug.

During the heating of liquids the boiling point can be delayed; this means that eruptive boiling can start after the container is removed from the oven. You may scald yourself.

IMPORTANT SAFETY INSTRUCTIONS

During cooking, you should look into the oven from time to time when food is being heated or cooked in disposable containers of plastic, paper or other combustible materials.

IMPORTANT

Young children should NEVER be allowed to use or play with the microwave oven. Nor should they be left unattended near the microwave oven when it is in use. Items of interest to children should not be stored or hidden just above the oven.

10. Stand at arm’s length from the oven when opening the door. Reason:

11. Keep the inside of the oven clean. Reason:

12. You may notice a “Clicking” sound during operation(especially when the oven is in defrosting). Reason

13. When the microwave oven is operating without any load, the power will be cut off automatically for safety. You can operate normally after letting it stand for over 30 minutes.

The hot air or steam released may cause scalding.

Food particles or spattered oils stuck to oven walls or floor can cause paint damage and reduce the efficiency of the oven.

: This sound is normal when the electrical power output is changing.

InstallingYour Microwave oven

Setting the Time(M1933N)

Place the oven on a flat, level surface that strong enough to safely bear the weight of the oven.

20 cm above

10 cm

behind

of the side

1. When you install your oven, Make sure there is adequate ventilation for your oven by

10 cm

leaving at least 10 cm (4 inches) of space behind, on the sides of the oven and 20 cm (8 inches) of above.

2. Remove all packing materials inside the oven. Install the roller ring and turntable. Check that the turntable rotates freely.

3. This microwave oven has to be positioned so that plug is accessible.

☛ Never block the air vents as the oven may overheat and

automatically switch itself off. It will remain inoperable until it has cooled sufficiently.

☛ For your personal safety, plug the cable into a 3-pin, 230 Volt,

50Hz, AC earthed socket. If the power cable of this appliance is damaged, it must be replaced by a special cable (I-SHENG SP022, KDK KKP4819D, EUROELECTRIC 3410, SAMIL SP106B, MOONSUNG EP-48E, HIGH PROJECT H.P 3). Contact your local dealer to have it replaced. The power cable of ISRAEL is PENCON(ZD16A), S/AFRICA APEX LEADS SA16 and NIGERIA, GHANA, KENYA and U.A.E is PENCON(UD13A1).

☛ Do not install the microwave oven in hot or damp surroundings

like next to a traditional oven or radiator. The power supply specifications of the oven must be respected and any extension cable used must be of the same standard as the power cable supplied with the oven. Wipe the interior and the door seal with a damp cloth before using your microwave oven for the first time.

Your microwave oven has an inbuilt clock. The time can be displayed in either the 24-hour or 12-hour notation. You must set the clock:

• When you first install your microwave oven

• After a power failure

✉ Do not forget to reset the clock when you switch to and from

summer and winter time.

1. To display the time in the...Then press the button...

24-hour notation Once 12-hour notation Twice

2. Set the hour with the h button and the minutes with the min button.

3. When the right time is displayed, press the button

againtostarttheclock. Result :

The time is displayed whenever you are not using the microwave oven

How a Microwave OvenW orks

Checking that Your Oven is Operating Correctly

Microwaves are high-frequency electromagnetic waves; the energy

released enables food to be cooked or reheated without changing either the form or the colour.

You can use your microwave oven to:

• Defrost

• Instant Reheat /Cook

•Cook

Cooking Principle

1. The microwaves generated by the magnetron are distributed uniformly as the food rotates on the turntable. The food is thus cooked evenly.

2. Themicrowavesareabsorbedbythefooduptoa depth of about 1 inch (2.5 cm). Cooking then continues as the heat is dissipated within the food.

3. Cooking times vary according to the recipient used and the properties of the food:

• Quantityand density

• Water content

• Initial temperature (refrigerated or not)

☛ As the centre of the food is cooked by heat dissipation, cooking

continues even when you have taken the food out of the oven. Standing times specified in recipes and in this booklet must therefore be respected to ensure:

• Even cooking of the food right to the centre

• The same temperature throughout the food

The following simple procedure enables you to check that your oven is working correctly at all times.

First, place a bowl of water on the turntable. Then, close the door.

Model: M1933N

1. Press the button and set the time to 4-5 minutes by

pressing the 1min button the appropriate number of times.

2. Press the button. Result :

The oven heats the water for 4 to 5 minutes. The water should then be boiling.

Model: M1913N

1. Set the power level to maximum by turning COOKING POWER CONTROL knob.

2. Setthetime4to5minutesbyturningtheTIMER knob.

The water should then be boiling.

✉ The oven must be plugged into an appropriate wall socket. The

turntable must be in position in the oven. If a power level other than the maximum is used, the water takes longer to boil.

+ 16 hidden pages
