Samsung LU32H850UMUXEN User Manual

User Manual

U*H75* U*H85*

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Trademarks other than that of Samsung Electronics are owned by their respective owners.

• An administration fee may be charged if either ‒ (a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

‒ (b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

• The amount of such administration charge will be advised to you before any work or home visit is carried out.

Table of contents

Before Using the Product

Securing the Installation Space 4

Precautions for storage 4

Safety Precautions 4

Symbols 4 Cleaning 5 Electricity and Safety 5 Installation 6 Operation 7

Preparations

Parts 10

Control Panel 10 Direct Key guide 11 Function Key Guide 12 Configuring Eye Saver Mode, Brightness and Contrast

from the Initial Screen 14 Changing the Volume setting 14 Reverse Side 15 Adjusting the Product Tilt and Height 16 Rotating the Monitor Screen (U32H850UM*) 16 Rotating the monitor (U32H850UM*) 17 Anti-theft Lock 17 Precautions for moving the monitor 18

MagicRotation Auto (U32H850UM*) 19

Installing a Wall-mount Kit or Desktop Stand (U28H750UQ*) 20

Installing a Wall-mount Kit or Desktop Stand (U32H850UM*) 21

Installation 22

Attaching the Stand (U28H750UQ*) 22 Attaching the Stand (U32H850UM*) 23 Removing the Stand (U28H750UQ*) 24 Removing the Stand (U32H850UM*) 25

Connecting and Using a Source Device

Read below before installing the monitor. 26

Connecting and Using a PC 26

Connection Using the HDMI Cable 26 Connection Using the HDMI-DVI Cable 27 Connection Using the DP Cable 27 Connection Using the MINI DP Cable

(U32H850UM*) 27 Connecting to Headphones 27

Connecting the Product to a PC as a USB HUB (U32H850UM*) 28

Connecting a PC to the Product 28 Utilizing the Product as a USB HUB 28 Connecting the Power (U28H750UQ*) 29 Connecting the Power (U32H850UM*) 29 Tidying Up the Connected Cables (U28H750UQ*) 30 Tidying Up the Connected Cables (U32H850UM*) 31

Correct posture to use the product 32

Driver Installation 32

Setting Optimum Resolution 32

Screen Setup

SAMSUNG MAGIC Bright 33

Black Equalizer 34

Brightness 34

Contrast 34

Sharpness 34

Color 35

SAMSUNG MAGIC Angle (U28H750UQ*) 35

HDMI Black Level 36

Eye Saver Mode 36

Game Mode 36

Response Time 36

Picture Size 37

Screen Adjustment 37

Configuring the PIP/PBP Settings

PIP/PBP Mode 38

Size 39

Position 39

Sound Source 39

Source 40

Table of contents

Picture Size 40

Contrast 41

Adjusting OSD (On Screen Display) settings

Transparency 42

Language 42

Display Time 42

Setup and Reset

FreeSync 43

Eco Saving Plus 45

Off Timer Plus 45

USB Super Charging (U32H850UM*) 45

Installing the Software

Easy Setting Box 48

Restrictions and Problems with the Installation 48 System Requirements 48

Troubleshooting Guide

Requirements Before Contacting Samsung Customer Service Center 49

Testing the Product 49 Checking the Resolution and Frequency 49 Check the following. 49

Q & A 51

Specifications

General 52

Standard Signal Mode Table 53

Appendix

Responsibility for the Pay Service (Cost to Customers) 57

Not a product defect 57 A Product damage caused by customer's fault 57 Others 57

PC/AV Mode 46

DisplayPort Ver. 46

Source Detection 46

Key Repeat Time 46

Power LED On 46

Reset All 46

Information 47

Chapter 01

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and damage the product. Be sure to allow the amount of space as shown below or greater when installing the product.

―

The exterior may differ depending on the product.

10 cm (3.93 Inches)

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used nearby.

―

Contact your nearest Samsung Customer Service Center if you want to clean the inside of the product (Service fee will be charged.)

Do not press the monitor screen with hands or other objects. There is a risk of damaging the screen.

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been included with this product.

10 cm (3.93 Inches)

Symbols

Warning

Caution

A serious or fatal injury may result if instructions are not followed.

Personal injury or damage to properties may result if instructions are not followed.

Cleaning

―

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―

Take the following steps when cleaning.

Power off the product and computer.

Disconnect the power cord from the product.

―

Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock may result.

Wipe the monitor with a clean, soft and dry cloth.

‒ Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor. ‒ Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Electricity and Safety

Warning

• Do not use a damaged power cord or plug, or a loose power socket.

• Do not use multiple products with a single power socket.

• Do not touch the power plug with wet hands.

• Insert the power plug all the way in so it is not loose.

• Connect the power plug to a grounded power socket (type 1 insulated devices only).

• Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.

• Do not place the power cord or product near heat sources.

• Clean any dust around the pins of the power plug or the power socket with a dry cloth.

Caution

• Do not disconnect the power cord while the product is being used.

• Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.

• Keep the power socket where the power cord is connected unobstructed.

‒ The power cord must be disconnected to cut off power to the product when an issue occurs.

• Hold the plug when disconnecting the power cord from the power socket.

Installation

Warning

• DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

• Do not install the product in poorly ventilated spaces such as a bookcase or closet.

• Install the product at least 10 cm away from the wall to allow ventilation.

• Keep the plastic packaging out of the reach of children.

‒ Children may suffocate.

• Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)

‒ The product may fall and become damaged and/or cause an injury. ‒ Using the product in an area with excess vibration may damage the product or cause a fire.

• Do not install the product in a vehicle or a place exposed to dust, moisture (water drips, etc.), oil, or smoke.

• Do not expose the product to direct sunlight, heat, or a hot object such as a stove.

‒ The product lifespan may be reduced or a fire may result.

• Do not install the product within the reach of young children.

‒ The product may fall and injure children.

• Edible oil (such as soybean oil) may damage or distort the product. Keep the product away from oil pollution. And do not install or use the product in the kitchen or near the kitchen stove.

Caution

• Do not drop the product while moving.

• Do not set down the product on its front.

• When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is not protruding.

‒ The product may fall and become damaged and/or cause an injury. ‒ Install the product only on cabinets or shelves of the right size.

• Set down the product gently.

‒ Product failure or personal injury may result.

• Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances, extreme temperatures or a significant presence of moisture, or a place where the product will operate continuously for an extended period of time) may seriously affect its performance.

‒ Be sure to consult Samsung Customer Service Center if you want to install the product at such a

place.

Operation

Warning

• There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.

‒ Contact Samsung Customer Service Center for repairs.

• To move the product, first disconnect all the cables from it, including the power cable.

• If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately and contact Samsung Customer Service Center.

• Do not let children hang from the product or climb on top of it.

‒ Children may become injured or seriously harmed.

• If the product is dropped or the outer case is damaged, turn off the power and disconnect the power cord. Then contact Samsung Customer Service Center.

‒ Continued use can result in a fire or electric shock.

• Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.

‒ The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a

serious injury.

• During a lightning or thunderstorm, power off the product and remove the power cable.

• Do not drop objects on the product or apply impact.

• Do not move the product by pulling the power cord or any cable.

• If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.

• Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc) into the product (via the vent or input/output ports, etc).

‒ Be sure to power off the product and disconnect the power cord when water or other foreign

substances have entered the product. Then contact Samsung Customer Service Center.

• Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.

‒ Be sure to power off the product and disconnect the power cord when water or other foreign

substances have entered the product. Then contact Samsung Customer Service Center.

• Do not lift or move the product by pulling the power cord or any cable.

• Do not use or keep combustible spray or an inflammable substance near the product.

• Ensure the vents are not blocked by tablecloths or curtains.

‒ An increased internal temperature may cause a fire.

Caution

• Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.

‒ Activate power-saving mode or a moving-picture screen saver if you will not be using the

product for an extended period of time.

• Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).

‒ Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.

• Use the product at the recommended resolution and frequency.

‒ Your eyesight may deteriorate.

• Do not put AC/DC adapters together.

• Remove the plastic bag from the AC/DC adapter before you use it.

• Do not let water enter the AC/DC adapter device or get the device wet.

‒ An electric shock or fire may result. ‒ Avoid using the product outdoors where it can be exposed to rain or snow. ‒ Be careful not to get the AC/DC adapter wet when you wash the floor.

• Do not put the AC/DC adapter near to any heating apparatus.

‒ Otherwise, a fire may result.

• Keep the AC/DC adapter in a well-ventilated area.

• If you place the AC/DC power adapter so that it is hanging with the cord input facing upwards, water or other foreign substances could enter the Adapter and cause the Adapter to malfunction.

Make sure to rest the AC/DC power adapter flat on a table or the floor.

• Insert the power plug into the AC/DC adapter until a click sound is heard.

• Do not insert only the power plug into the power outlet.

• Do not use an AC/DC adapter other than the provided one.
