LCD MONITOR
P2070,P2270,P2370,P2070G,P2270G,P2370G
quick start guide
ii
Introduction
Package Contents
Note
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer
Unpacking
Manuals
to buy optional items.
Monitor
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User's Guide
Cables
'DVI-A to D-Sub' Cable Power Cord DC-Adapter
Others
Cleaning Cloth Stand Body Stand Base
Note
Cleaning Cloth is only provided for highly polished black products as a product feature.
Sold separately
Your Monitor
Initial Settings
Introduction
DVI Cable
Select the language using the up or down key.
The displayed content will disappear after 40 seconds.
Turn the Power button off and on. It will be displayed again.
It can be displayed up to three (3) times. Make sure to adjust the resolution of your PC before
reaching the maximum count.
Note
The resolution displayed on the screen is the optimal resolution for this product.
Adjust your PC resolution so that it is the same as the optimal resolution for this product.
Front
Introduction
MENU button [MENU/ ]
Opens the on-screen menu and exits from the menu. Also use to exit the
OSD menu or return to the previous menu.
Customized Key[ ]
You can customize key assignment for the Custom button according to
your preferences.
Note
You can configure the customized key for a required function via Setup >
Customized Key.
Brightness button [ ]
When OSD is not on the screen, push the button to adjust brightness.
Adjust buttons [ ]
These buttons allow you to adjust items in the menu.
[ ] Button / [ ] Enter button
Activates a highlighted menu item.
Push the '
the / button is pressed to change the input mode, a message appears in the upper left of the screen displaying the current mode -- analog
or digital input signal.)
/ ', then selects the video signal while the OSD is off. (When
Note
If you select the digital mode, you must connect your monitor to the graphic
card's DVI port using the DVI cable.
Rear
Introduction
AUTO button
Use this button for auto adjustment.
Power button [ ]
Use this button for turning the product on and off.
Power Indicator
This light is lit when operating normally, and blinks once when your adjustments are saved.
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your monitor OFF
when it is not needed or when leaving it unattended for long periods.
Note
The configuration at the back of the product may vary from product to product.
DC 12V
DVI IN port
Connect the DC adapter for your monitor to
the power port on the back of the monitor.
Plug the power cord for the monitor into a
nearby outlet. .
Kensington Lock
Introduction
Connect the 'DVI-A to D-Sub' Cable to the
DVI-I port on the back of your monitor.
The Kensington Lock is a device used to
physically fix the system when using it in a
public place. The locking device has to be
purchased separately. The appearance and
locking method may differ from the illustration depending on the manufacturer. Refer to
the manual provided with the Kensington
Lock for proper use. The locking device has
to be purchased separately.
Note
The location of the Kensington Lock may be
different depending on its model.
Using the Anti-Theft Kensington
Lock
1. Insert the locking device into the Ken-
sington slot on the Monitor ( ) and turn
it in the locking direction ( ).
2. Connect the Kensington Lock cable.
3. Fix the Kensington Lock to a desk or a
heavy stationary object.
Note
See Connecting Cables for further information regarding cable connections.
