Page 1
6 Electrical Parts List
6-1
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LNS3251HDX/XAX LN-S3251HD,E62A/32R70-GBD,32,LCD-TV,MEXI 0
0.1 M0001 BN90-00840B ASSY COVER FRONT;32R71,UO,BORDEAUX 1 S.N.A
..2 T0003 BN96-02996B ASSY COVER P-FRONT;32R71,UO,PC+ABS,V0,BK 1 S.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.48 S.N.A
...3 M0112 BN63-02318B COVER-FRONT;32R71,UO,PC+ABS,V0,BK25,S/MO 1 S.N.A
...3 T0056 BN63-02320A COVER-DECORATION;32R71,HIPS,HB,GR503,BLM 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 CIS BN63-01151A FELT-NON WOVEN;MM17NS,T0.5,393,10,BLACK 2 S.N.A
...3 T0069 BP60-00015D SPACER-FELT;617W,FELT,L760,T0.5,W10 2 S.N.A
...3 M0145 BN96-03404A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 S.A
....4 T0022 BN64-00442A KNOB CONTROL;26,32,40R71,PC,BLK,ACRYL CL 1 S.N.A
....4 M0145 BN96-03045A ASSY BOARD P-FUNCTION;BORDEAUX,FUNCTION 1 S.A
...3 M0146 BN96-03405A ASSY BOARD P-POWER;BORDEAUX1,CT5000-4140 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 T0175 BN96-04207A ASSY SPEAKER P;8ohm,VE Type,Left,10W,Hor 1 S.A
..2 T0175 BN96-04208A ASSY SPEAKER P;8ohm,VE Type,Right,10W,Ho 1 S.A
0.1 M0216 BN90-00842A ASSY STAND;32R71,BORDEAUX 1 S.N.A
..2 M0013 BN96-02998A ASSY STAND P-BASE;32R71,-,ABS+PMMA,HB,BK 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0920 BN61-02192A GUIDE-STAND;26,32R71,ABS,V0,BLK 1 S.A
....4 T0514 BN61-02367A BRACKET-SUPPORT;BORDEAUX 32,SECC,T1.2,-, 1 S.N.A
...3 BN61-02204A HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK 1 S.N.A
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02235A BRACKET-STAND BOTTOM;BORDEAUX 32,SECC,T2 1 S.N.A
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 S.N.A
...3 T0004 BN63-02321A COVER-STAND BASE;32R71,ABS+PMMA,-,-,-,HB 1 S.N.A
...3 BN63-02322A COVER-STAND SUB;32R71,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 8 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
0.1 M0002 BN90-00994H ASSY COVER REAR;32R71,UO(HOTEL),BORDEAUX 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 S.A
..2 M0013 BN96-02997Z ASSY COVER P-REAR;32R71,UO(HOTEL),PC+ABS 1 S.N.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 BN61-02776B HOLDER-WALL;32R7,ABS,VO,BLK 2 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.7 S.N.A
...3 M0006 BN63-02319C COVER-REAR;32R71,UO,PC+ABS,V0,BK25,H/GLA 1 S.N.A
...3 T0071 BN64-00447N INLAY-TERMINAL;32,37,40R71,PS,SHEET,T0.5 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0017 BN91-01005H ASSY CHASSIS;LNS3251HDX/XAA 1 S.N.A
..2 M0014 BN94-00850B ASSY PCB MAIN;LNS3251HDX/XAA 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA801 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004909 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG 1 S.A
...3 CN1003 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LNS3251HDX Parts List
Page 2
6 Electrical Parts List
6-2
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA330 3722-002312 JACK-PHONE;4P,-,SN,BLK,- 1 S.A
...3 CN1301 3722-002516 JACK-USB;4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 S.A
...3 CIS3 BN40-00081A TUNER;DNVS303HH261A,DNVS303HH261A,VSB/QA 1 S.A
...3 T0253 BN59-00498A MODULE-SPLITTER;UMX-NT-059,UMX-NT-059,2i 1 S.A
...3 T0852 BN96-01470A ASSY BOARD P-OPTICAL;HP-P5581,OPTICAL 1 S.A
....4 CN906 3707-001067 CONNECTOR-OPTICAL;PLUG,SM,-,4.4/2.0mm 1 S.A
...3 T0174 BN97-00810B ASSY SMD;LNS3251HDX/XAA 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/ 4.902 S.N.A
....4 D501 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D708 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D709 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D710 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D711 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D712 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D713 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D801 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D802 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D803 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D813 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D814 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D815 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D816 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D817 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D818 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D819 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D820 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D831 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D832 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D833 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D834 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D835 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D836 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D837 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D838 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D941_HT 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D901_HT 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D1301 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1302 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D206 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D821 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D822 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D839 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D840 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D901 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D902 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D903 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D904 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D905 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D906 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D907 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D908 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D909 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D910 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D911 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D912 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D207 0403-000746 DIODE-ZENER;RLZ3.9B,3.89-4.16V,500mW,LL- 1 S.A
....4 D205 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D804 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D827 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D601 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D602 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D603 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
Page 3
6 Electrical Parts List
6-3
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 D604 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D605 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D606 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D607 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D608 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D609 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D610 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D611 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D612 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D613 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D614 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D615 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D616 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D617 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D618 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D619 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D620 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D621 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D622 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D623 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D624 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D625 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D626 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D627 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D805 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D806 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D807 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D808 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D809 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D810 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D811 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D812 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D823 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D824 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D825 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D826 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D828 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D829 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D830 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D841 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D842 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D843 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D844 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D503 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D7302_HT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D7303_HT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D7306_HT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D201 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D202 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D203 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D204 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D301 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D302 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D401 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D402 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D403 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23, 1 S.A
....4 Q303 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23 1 S.A
....4 Q1304 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q204 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q205 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q301 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q302 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q404 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q502 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q941_HT 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q501 0501-000344 TR-SMALL SIGNAL;KSC1623-G,NPN,200mW,SOT- 1 S.A
....4 Q101 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q102 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
Page 4
6 Electrical Parts List
6-4
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 Q201 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q402 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q403 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q503 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q701 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q801 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q1305 0504-001129 TR-DIGITAL;KRC104S-I,NPN,200MW,47K/47K,S 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000275 FET-SILICON;SI4435DY,P,-30V,+-8.0A,0.014 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002198 IC-CMOS LOGIC;74LVC14,INVERTER,SOP,14P,1 1 S.A
....4 IC104 0801-002267 IC-CMOS LOGIC;74LCX14,-,SOIC,14P,150MIL, 1 S.A
....4 IC104 0801-002633 IC-CMOS LOGIC;NC7WBD3125,2BIT BUS SWITCH 1 S.A
....4 IC104 0801-002716 IC-CMOS LOGIC;74LCX157,MULTIPLEXER,SOIC, 1 S.A
....4 IC301 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC202 1001-001109 IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C 1 S.A
....4 IC806 1001-001109 IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C 1 S.A
....4 IC106 1001-001363 IC-VIDEO SWITCH;PI3HDMI412FT,HDMI TMDS S 1 S.A
....4 IC107 1002-001399 IC-D/A CONVERTER;PCM1754,24BIT,SSOP,16P, 1 S.A
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001385 IC-EEPROM;24C256,256Kbit,32Kx8,SOP,8P,5x 1 S.A
....4 IC113 1105-001571 IC-DRAM;K4D551638,GDDR,256Mbit,4x4Mx16,T 1 S.A
....4 IC113 1105-001571 IC-DRAM;K4D551638,GDDR,256Mbit,4x4Mx16,T 1 S.A
....4 IC113 1105-001674 IC-DRAM;EM6A9320BI,-,128Mbit,4Mx32Bit,FB 1 S.A
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 S.A
....4 DU410 1201-000541 IC-OP AMP;062,SOP,8P,153MIL,DUAL,6V/mV,P 1 S.A
....4 T0085 1201-002136 IC-AUDIO AMP;LM4810,MSOP,8P,3x3mm,DUAL,- 1 S.A
....4 T0085 1201-002246 IC-AUDIO AMP;STA323W,SO,36P,15.9x11mm,-, 1 S.A
....4 IC206 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-001816 IC-POSI.FIXED REG.;78M08,TO-252,3P,-,PLA 1 S.A
....4 IC402 1203-001824 IC-VOL. DETECTOR;7042,SOT-89,3P,-,PLASTI 1 S.A
....4 T0087 1203-002699 IC-POSI.FIXED REG.;78D05,DPAK,3P,6.6X6.1 1 S.A
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 S.A
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 T0087 1203-003561 IC-POSI.FIXED REG.;NCP551SN15T1G,TSOP-5, 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003697 IC-POSI.FIXED REG.;SC1566I5M-2.5TRT,TO-2 1 S.A
....4 T0087 1203-003697 IC-POSI.FIXED REG.;SC1566I5M-2.5TRT,TO-2 1 S.A
....4 T0087 1203-003952 IC-POSI.FIXED REG.;KA7805ERTM,DPAK,3P,6. 1 S.A
....4 IC302 1204-002471 IC-AUDIO PROCESSOR;STV8258DSX,TQFP,80P,1 1 S.A
....4 IC118 1204-002496 IC-VIDEO PROCESS;S4LD158X01,QFP,128P,14x 1 S.N.A
....4 IC118 1204-002503 IC-VIDEO PROCESS;SVP-PX56-7256,PQFP,256P 1 S.N.A
....4 IC1301 1204-002534 IC-DECODER;S5H2111,BGA,416P,27x27mm,PLAS 1 S.A
....4 IC1302 1205-002250 IC-CLOCK GENERATOR;CY24204-3,TSSOP,16P,1 1 S.A
....4 R1519 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R1520 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R1201 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1202 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1008 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R270 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R275 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R501 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
Page 5
6 Electrical Parts List
6-5
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R503 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1105 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 32_ 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 HOTEL_ 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1001 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1010 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1011 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1012 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1013 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1014 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1015 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1016 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1017 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1018 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1020 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1021 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1022 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1023 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1024 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1025 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1026 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1027 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1028 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1029 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1030 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1031 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1032 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1033 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1038 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1055P 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1304 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1326 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1329 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1343 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1345 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1353 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1355 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1357 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1359 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1601 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1603 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1604 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1619 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1620 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1621 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1627 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1701 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R200_HT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R235 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R237 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R246 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R247 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R248 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R249 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R259 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R261 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R262 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R272 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R329 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R405 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R406 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R506 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R507 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R509 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R511 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R521 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R522 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R704 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
Page 6
6 Electrical Parts List
6-6
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R705 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R708 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R709 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R722 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R723 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R724 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R807 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R835 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R909 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R9124_HT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R9125_HT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R9140_HT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R9143_HT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R922 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R923 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R925 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R929 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R930 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R933 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R935 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R936 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1040 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1101 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1102 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1204 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1205 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1206 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1207 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1322 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R133_HT 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1409 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1410 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1412 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1414 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R253 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R323 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R810 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R814 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R817 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R822 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R836 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R837 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R874 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R876 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R878 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R879 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R882 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R883 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R884 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R885 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R886 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R887 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R888 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R889 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R890 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R891 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R892 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R893 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1379 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1380 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1413 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1415 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1416 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1417 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R711 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R712 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R803 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R804 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R816 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
Page 7
6 Electrical Parts List
6-7
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R818 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R831 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R832 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1019 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1034 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1035 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1036 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1037 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1039 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1044 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1050 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1058 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1302 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1303 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1305 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1306 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1307 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1308 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1309 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1310 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1311 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1313 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1314 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1315 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1316 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1317 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1327 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1328 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1330 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1331 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1332 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1333 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1336 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1337 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1338 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1339 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1341 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1342 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1346 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1347 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1348 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1349 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1350 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1381 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1382 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1383 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1384 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1401 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1402 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1403 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1404 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1405 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1406 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1407 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1408 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1612 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1628 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R223 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R225 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R226 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R234 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R236 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R238 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R239 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R240 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R241 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R242 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R243 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R244 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
Page 8
6 Electrical Parts List
6-8
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R250 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R251 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R252 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R254 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R255 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R256 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R258 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R320 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R321 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R325 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R326 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R327 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R407 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R502 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R510 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R601 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R603 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R614 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R615 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R616 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R619 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R620 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R703 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R706 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R707 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R710 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R720 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R721 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R7613_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R7614_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R7615_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R821 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R823 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R824 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R825 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R826 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R9122_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R9123_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R953_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R954_HT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1056 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R274 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R515 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1046 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1434 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1435 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R609 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R610 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R612 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R613 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R827 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R828 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R859 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R860 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1002 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1043 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1051 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R112 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1312 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1323 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1340 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R233 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R266 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R408 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R415 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R416 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R508 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R524 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R847 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
Page 9
6 Electrical Parts List
6-9
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R924 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R849 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1048 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1049 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R927_HT 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R928_HT 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1045 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R113 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1301 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R131_HT 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1325 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R132_HT 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1361 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1362 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1363 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1364 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1365 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1366 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1367 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1368 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1369 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1370 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1371 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1372 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1373 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1374 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1375 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1386 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1387 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1388 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1389 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1390 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1418 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1419 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1420 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1421 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1422 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1423 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1424 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1605 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1607 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1609 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1613 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1622 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1623 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1624 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1625 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1626 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R257 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R263 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R267 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R268 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R322 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R328 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R414 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R523 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R701_HT 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R702_HT 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R719 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R916 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R919 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R921 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R926 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R927 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R404 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 S.A
....4 R102 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R103 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R106 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R107 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
Page 10
6 Electrical Parts List
6-10
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R1104 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1334 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1335 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1376 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1377 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1378 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1432 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1433 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1608 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R201 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R202 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R203 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R204 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R205 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R208 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R210 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R212 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R213 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R214 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R215 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R217 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R218 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R219 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R220 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R221 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R222 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R227 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R230 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R231 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R260 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R265 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R271 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R273 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R309 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R310 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R331 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R412 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R419 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R801 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R802 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R806 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R808 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R809 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R829 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R830 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R834 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R913 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R9144_HT 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R9145_HT 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R915 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R928 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R934 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R937 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R108 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1320 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1321 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R333 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
....4 R334 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
....4 R848 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
....4 R517 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1425 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R301 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R302 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R303 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R304 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R305 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R306 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R307 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
Page 11
6 Electrical Parts List
6-11
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R308 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R311 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R312 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R313 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R314 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R315 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R316 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R317 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R318 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R101 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R330 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R332 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R335 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R336 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R418 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R512 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R520 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R621 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R622 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R504 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 S.A
....4 R505 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1324 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1344 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1351 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1352 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1354 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1356 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1358 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1385 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1501 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1502 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1503 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1504 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1505 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1506 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1507 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1508 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1509 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1510 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1511 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1512 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1513 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1514 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1515 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1516 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1517 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1518 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1606 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1610 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1611 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1614 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1615 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1616 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R1618 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R911 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R912 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R914 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R861 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 1 S.A
....4 R319 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 S.A
....4 R715 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R716 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R717 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R850 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R411 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1426 2007-000130 R-CHIP;39Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1427 2007-000130 R-CHIP;39Kohm,5%,1/10W,TP,1608 1 S.A
....4 R602 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R604 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R605 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
Page 12
6 Electrical Parts List
6-12
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R862 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R863 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R864 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R865 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R866 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R867 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R868 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R869 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R870 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R871 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R872 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R873 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R875 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R877 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R880 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R881 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R901 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R902 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R903 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R904 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R905 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R906 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R907 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R908 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1428 2007-000329 R-CHIP;11Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1429 2007-000329 R-CHIP;11Kohm,5%,1/10W,TP,1608 1 S.A
....4 R805 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R833 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R224 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R839 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R840 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R841 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R842 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R843 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R844 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R845 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R846 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R851 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R852 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R853 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R854 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R855 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R856 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R857 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R858 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 R402 2007-000593 R-CHIP;22ohm,5%,1/8W,TP,2012 1 S.A
....4 R410 2007-000593 R-CHIP;22ohm,5%,1/8W,TP,2012 1 S.A
....4 R1318 2007-000659 R-CHIP;27ohm,5%,1/10W,TP,1608 1 S.A
....4 R1319 2007-000659 R-CHIP;27ohm,5%,1/10W,TP,1608 1 S.A
....4 R109 2007-000701 R-CHIP;3.6Kohm,1%,1/10W,TP,1608 1 S.A
....4 R111 2007-000701 R-CHIP;3.6Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1702 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R1057 2007-000903 R-CHIP;430ohm,1%,1/10W,TP,1608 1 S.A
....4 R1430 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1431 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1203 2007-001014 R-CHIP;51OHM,5%,1/10W,TP,1608 1 S.A
....4 R1208 2007-001014 R-CHIP;51OHM,5%,1/10W,TP,1608 1 S.A
....4 R1103 2007-001139 R-CHIP;7.5Kohm,1%,1/10W,TP,1608 1 S.A
....4 R606 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R607 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R608 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R611 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R617 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R618 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R1411 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R811 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R812 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R813 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R819 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
Page 13
6 Electrical Parts List
6-13
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R820 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R104 2007-002768 R-CHIP;6.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R105 2007-002768 R-CHIP;6.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R401 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.A
....4 R403 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.A
....4 R409 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.A
....4 R413 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.A
....4 IC1203 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1201 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1202 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1203 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1204 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1205 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1206 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1207 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1401 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1402 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1403 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1404 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA501 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA502 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA503 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA202 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA301 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA1501 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1502 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1503 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1504 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1505 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1506 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1507 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1508 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1509 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1510 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1511 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1601 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1602 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1603 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1604 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1605 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1606 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1607 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1608 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1609 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA1610 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA201 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 C428 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1 S.A
....4 C1307 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C315 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C327 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C103 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C105 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C107 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1107 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1108 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1111 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1112 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1113 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1116 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1117 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1121 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1125 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1126 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1127 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1128 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1129 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1133 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1134 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
Page 14
6 Electrical Parts List
6-14
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C1135 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1136 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1137 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1140 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1141 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1144 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1145 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1147 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1148 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1149 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1150 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1156 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1157 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1158 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1159 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C116 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1160 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1161 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1162 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1163 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1164 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1165 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1166 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1167 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C117 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C124 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1302 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C13_HT 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1401 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1403 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C153 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C155 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C157 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1705 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1706 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1707 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1708 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1709 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1713 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1714 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1715 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1716 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1717 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1718 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1719 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1723 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1724 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1725 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1726 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1727 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1728 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1729 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1733 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1734 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1744 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1747 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1756 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1757 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1758 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1759 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1760 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1761 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C1762 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C210 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C211 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C313 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C322 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C323 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C324 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
Page 15
6 Electrical Parts List
6-15
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C325 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C342 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C344 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C345 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C352 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C355 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C403 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C407 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C412 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C429 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C501 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C502 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C504 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C508 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C517 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C521 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C528 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C533 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C539 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C709 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C802 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C804 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C813 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C912 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C913 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C914 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C915 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C916 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C917 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C918 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C919 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C920 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C921 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C922 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C923 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C924 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C925 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C926 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C927 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C928 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C929 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C930 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C931 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C932 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C933 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C937 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C25020_HT 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C25021_HT 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C25022_HT 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C25023_HT 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C433 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C604 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C609 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C806 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C807 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C818 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C1006 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C101 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1015 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1019 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C102 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1022 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1027 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C104 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C114 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C118 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1208 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1209 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1210 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
Page 16
6 Electrical Parts List
6-16
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C1211 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1212 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1218 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1219 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1222 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C127 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C12_HT 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1314 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C132 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C149 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1603 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1710 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1711 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1712 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1720 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1721 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1722 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1730 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1731 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1732 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1763 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1764 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C1765 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C213 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C318 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C520 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C532 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C707 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C713 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C714 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C716 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C906 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C907 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C908 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C909 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C910 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C319 2203-000357 C-CER,CHIP;0.15nF,5%,50V,C0G,1608 1 S.A
....4 C145 2203-000405 C-CER,CHIP;0.18nF,5%,50V,C0G,1608 1 S.A
....4 C146 2203-000405 C-CER,CHIP;0.18nF,5%,50V,C0G,1608 1 S.A
....4 C901 2203-000426 C-CER,CHIP;0.018nF,5%,50V,C0G,1608 1 S.A
....4 C905 2203-000426 C-CER,CHIP;0.018nF,5%,50V,C0G,1608 1 S.A
....4 C1003 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1007 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1016 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1020 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1021 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1304 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1308 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C206 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C25017_HT 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C25019_HT 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C404 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C405 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C431 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C432 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C540 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C535 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
....4 C1123 2203-000531 C-CER,CHIP;2.7nF,10%,50V,X7R,1608 1 S.A
....4 C1131 2203-000531 C-CER,CHIP;2.7nF,10%,50V,X7R,1608 1 S.A
....4 C207 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C208 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C1303 2203-000681 C-CER,CHIP;0.027nF,5%,50V,C0G,1608 1 S.A
....4 C1305 2203-000681 C-CER,CHIP;0.027nF,5%,50V,C0G,1608 1 S.A
....4 C331 2203-000681 C-CER,CHIP;0.027nF,5%,50V,C0G,1608 1 S.A
....4 C340 2203-000681 C-CER,CHIP;0.027nF,5%,50V,C0G,1608 1 S.A
....4 C147 2203-000715 C-CER,CHIP;3.3nF,10%,50V,X7R,1608 1 S.A
....4 C148 2203-000715 C-CER,CHIP;3.3nF,10%,50V,X7R,1608 1 S.A
Page 17
6 Electrical Parts List
6-17
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C413 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C422 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C605 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C606 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C607 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C608 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C610 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C613 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C614 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C810 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C811 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C823 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C824 2203-000783 C-CER,CHIP;0.33nF,5%,50V,C0G,1608 1 S.A
....4 C353 2203-000798 C-CER,CHIP;33nF,10%,16V,X7R,TP,1608,- 1 S.A
....4 C354 2203-000798 C-CER,CHIP;33nF,10%,16V,X7R,TP,1608,- 1 S.A
....4 C601 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C602 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C603 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C808 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C809 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C1310 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C1203 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C1204 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C1205 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C536 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C903 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C904 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C329 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
....4 C527 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
....4 C934 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
....4 C715 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
....4 C1405 2203-001397 C-CER,CHIP;2.2nF,5%,50V,NP0,1608 1 S.A
....4 C1406 2203-001397 C-CER,CHIP;2.2nF,5%,50V,NP0,1608 1 S.A
....4 C320 2203-001402 C-CER,CHIP;220nF,+80-20%,16V,Y5V,TP,1608 1 S.A
....4 C1309 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,1608 1 S.A
....4 C434 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,1608 1 S.A
....4 C531 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,1608 1 S.A
....4 C1312 2203-001630 C-CER,CHIP;330nF,+80-20%,16V,Y5V,1608 1 S.A
....4 C316 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 1 S.A
....4 C326 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 1 S.A
....4 C368 2203-001724 C-CER,CHIP;4700nF,+80-20%,16V,Y5V,3216 1 S.A
....4 C1005 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1009 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1010 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1014 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1018 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1023 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1026 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1030 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C109 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1101 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1104 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C111 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1152 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1153 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1201 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1202 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1206 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1207 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C121 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1216 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1217 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C125 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C126 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C129 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1306 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1313 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C134 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C136 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
Page 18
6 Electrical Parts List
6-18
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C141 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C144 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1501 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1502 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1505 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1506 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1507 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1508 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1509 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1510 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1511 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1512 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1513 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1514 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1515 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1516 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1518 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1519 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1602 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1604 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1606 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1607 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1609 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1611 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1748 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1749 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1750 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1751 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1752 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1753 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1754 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1755 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1767 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1771 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1772 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1773 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1774 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1775 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1776 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1777 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1778 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1779 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1780 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1781 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1782 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1783 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1784 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1785 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1786 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1787 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1788 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1789 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1790 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1791 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1792 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C1793 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C202 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C205 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C209 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C302 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C332 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C350 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C356 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C357 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C358 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C359 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C361 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C365 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C370 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
Page 19
6 Electrical Parts List
6-19
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C371 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C372 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C373 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C421 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C506 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C611 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C710 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C805 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C814 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C817 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C819 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C821 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C902 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C991_HT 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C992_HT 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C993_HT 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C994_HT 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C995_HT 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C414 2203-005030 C-CER,CHIP;470nF,+80-20%,50V,Y5V,TP,3216 1 S.A
....4 C423 2203-005030 C-CER,CHIP;470nF,+80-20%,50V,Y5V,TP,3216 1 S.A
....4 C1001 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1002 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1004 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1008 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1013 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1017 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1024 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C1025 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C122 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C212 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C425 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C9401_HT 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C402 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C406 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C408 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C410 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C415 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C416 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C417 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C418 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C419 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C420 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C424 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C426 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C427 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C430 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C436 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C530 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C362 2203-005533 C-CER,CHIP;1000nF,20%,6.3V,X7R,TP,1608 1 S.A
....4 C367 2203-005533 C-CER,CHIP;1000nF,20%,6.3V,X7R,TP,1608 1 S.A
....4 C1031 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1032 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1102 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1105 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1109 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1110 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1114 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1115 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1118 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1119 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1122 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1124 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1130 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1132 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1138 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1139 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1142 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1143 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1146 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
Page 20
6 Electrical Parts List
6-20
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C1402 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1608 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1610 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1766 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1768 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1769 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1770 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C201 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C204 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C303 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C304 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C305 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C306 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C307 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C308 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C309 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C310 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C347 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C409 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C411 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C524 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C537 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C538 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C612 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C801 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C803 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C812 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C815 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C816 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C820 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C822 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1012 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C110 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1106 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C130 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1301 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C137 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C138 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1407 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1408 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1412 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C154 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1794 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C366 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C503 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C516 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C911 2402-000209 C-AL,SMD;22uF,20%,16V,WT,TP,5.3x5.3mm 1 S.A
....4 C1011 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1103 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C115 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C11_HT 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1213 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1214 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1215 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1404 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1503 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1504 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C156 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1601 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1795 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C360 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C363 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C505 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C507 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
....4 C1220 2402-001097 C-AL,SMD;0.1UF,20%,50V,WT,TP,4.3X4.3X5.2 1 S.A
....4 C1221 2402-001097 C-AL,SMD;0.1UF,20%,50V,WT,TP,4.3X4.3X5.2 1 S.A
....4 C1151 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1154 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1155 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
Page 21
6 Electrical Parts List
6-21
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C133 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1702 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1703 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1704 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1745 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C1746 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C314 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C375 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C519 2402-001128 C-AL,SMD;100¥ìF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C312 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C321 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C330 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C341 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C374 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C529 2402-001147 C-AL,SMD;3.3UF,20%,50V,WT,TP,4X5.8MM 1 S.A
....4 C1028 2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C1029 2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C708 2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C369 2402-001160 C-AL,SMD;330UF,20%,16V,WT,TP,1008 1 S.A
....4 C311 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C317 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C339 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C343 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C349 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C351 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C301 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
....4 C328 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
....4 C996_HT 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
....4 C1701 2402-001210 C-POLYMER AL CHIP;100uF,20%,10V,WT,TP,7. 1 S.A
....4 C108 2402-001218 C-AL,SMD;22UF,20%,35V,WT,TP,6.6X6.6X5.8M 1 S.A
....4 C120 2402-001218 C-AL,SMD;22UF,20%,35V,WT,TP,6.6X6.6X5.8M 1 S.A
....4 C1410 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
....4 C1411 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
....4 C1413 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
....4 C1414 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
....4 C1517 2402-001230 C-AL,SMD;2.2uF,¡¾20%,35V,WT,TP,3*5.2 1 S.A
....4 C337 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C338 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C346 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C348 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C534 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C401 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
....4 C435 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
....4 C1311 2402-001262 C-AL,SMD;47uF,+-20%,6.3V,WT,SMD,5x5.2 1 S.A
....4 C106 2402-001268 C-AL,SMD;100uF,+-20%,25V,WT,REEL,8x6.3 1 S.A
....4 C112 2402-001268 C-AL,SMD;100uF,+-20%,25V,WT,REEL,8x6.3 1 S.A
....4 C113 2402-001268 C-AL,SMD;100uF,+-20%,25V,WT,REEL,8x6.3 1 S.A
....4 C119 2402-001268 C-AL,SMD;100uF,+-20%,25V,WT,REEL,8x6.3 1 S.A
....4 C123 2402-001268 C-AL,SMD;100uF,+-20%,25V,WT,REEL,8x6.3 1 S.A
....4 C128 2409-001029 C-ORGANIC,SMD;120¥ìF,20%,6.3V,WT,TP,8.3x 1 S.A
....4 C135 2409-001029 C-ORGANIC,SMD;120¥ìF,20%,6.3V,WT,TP,8.3x 1 S.A
....4 C364 2409-001029 C-ORGANIC,SMD;120¥ìF,20%,6.3V,WT,TP,8.3x 1 S.A
....4 C140 2409-001065 C-ORGANIC;82uF,20%,16V,WT,TP,8X6.9mm,- 1 S.A
....4 C160 2409-001065 C-ORGANIC;82uF,20%,16V,WT,TP,8X6.9mm,- 1 S.A
....4 C518 2409-001118 C-POLYMER ,CHIP;47uF,-+20,10V,WT,REEL,3. 1 S.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
Page 22
6 Electrical Parts List
6-22
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000417 INDUCTOR-SMD;220uH,5%,3225 1 S.A
....4 T0052 2703-001426 INDUCTOR-SMD;680uH,20%,7070 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-002915 INDUCTOR-SMD;22uH,20%,8080 1 S.A
....4 T0052 2703-002915 INDUCTOR-SMD;22uH,20%,8080 1 S.A
....4 T0052 2703-002915 INDUCTOR-SMD;22uH,20%,8080 1 S.A
....4 T0052 2703-002915 INDUCTOR-SMD;22uH,20%,8080 1 S.A
....4 X1301 2801-000258 CRYSTAL-SMD;0.032768MHz,20ppm,SMD,12.5pF 1 S.A
....4 X201 2801-003326 CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH 1 S.A
....4 X301 2801-003954 CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh 1 S.A
....4 X901 2801-004483 CRYSTAL-SMD;28.322MHz,30ppm,HC-49,20pF,5 1 S.A
....4 X1302 2804-001370 OSCILLATOR-CLOCK;48MHz,100ppm,10TTL/CMOS 1 S.A
....4 X1303 2806-001308 OSCILLATOR-VCXO;27MHZ,-,30PF,TP,3.3V,50M 1 S.A
....4 F103 2901-001114 FILTER-EMI SMD;25VDC,2.0ADC,-,100nF,3.2x 1 S.A
....4 T0568 3301-001082 BEAD-SMD;60ohm,3225,TP,43ohm/40MHz,83ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608,-,-,- 1 S.N.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
Page 23
6 Electrical Parts List
6-23
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 JA802 3701-001311 CONNECTOR-HDMI;21P,2R,FEMALE,SMD-S,AU30U 1 S.A
....4 JA804 3701-001311 CONNECTOR-HDMI;21P,2R,FEMALE,SMD-S,AU30U 1 S.A
....4 CN330 3711-005291 HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,SMD- 1 S.A
....4 CN330 3711-005292 HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,SMD- 1 S.A
....4 CN330 3711-005497 HEADER-BOARD TO CABLE;BOX,15P,1R,1.25MM, 1 S.A
....4 L101 BN27-00008A COIL CHOKE-SMD;SMD12*12*8.5,GH15/17PS,22 1 S.A
....4 L102 BN27-00008A COIL CHOKE-SMD;SMD12*12*8.5,GH15/17PS,22 1 S.A
....4 T0077 BN41-00808A PCB MAIN;BORDEAUX,FR-4,4,1.0,1.6,194 * 2 1 S.N.A
....4 M0018 BN97-01333A ASSY MICOM;T-BORHNUS5-0001,LNS3251HDX,20 1 S.N.A
.....5 IC520 0903-001389 IC-MICROCONTROLLER;S3F866B,8Bit,QFP,44P, 1 S.N.A
....4 M0018 BN97-01333B ASSY MICOM;T-BORHNUS0-0003,LNS3251HDX,20 1 S.N.A
.....5 IC115 1107-001228 IC-FLASH MEMORY;28F640,64Mbit,8Mx8/4Mx16 1 S.N.A
...3 T0568 BP39-00217A CBF IF;HLR5668WAX,1PIN,1365#26,80mm,BK,D 1 S.A
...3 T0066 BP62-00017A HEAT SINK-ES;SP-50L2HX,A6063S,T2.0,26.2, 1 S.N.A
...3 T0066 BP62-00047B HEAT SINK-ES;MU15UO,A6063S,T2.5,13,13,TA 1 S.N.A
0.1 M0019 BN91-01017S ASSY LCD;LS32BH*,AMLCD 1 S.N.A
..2 M0215 BN07-00368A LCD-PANEL;LTA320WT-L16,LTA320WT-L16,8bit 1 S.A
0.1 M0112 BN91-01131G ASSY SHIELD;LNS3251HDX/XAA 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 7 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 3 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 8 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
..2 M2893 BH39-00362G LEAD CONNECTOR;SONOMA,UL1007#26,5PIN,100 1 S.A
..2 M2893 BN39-00603M LEAD CONNECTOR;LE40R73BDX,UL1007#26,UL/C 1 S.A
..2 M2893 BN39-00691B LEAD CONNECTOR;LE32R71BX,UL1007#26,16P,1 1 S.A
..2 M2893 BN39-00712C LEAD CONNECTOR-LVDS;Bordeaux,UL1571#30,U 1 S.A
..2 M2893 BN39-00726C LEAD CONNECTOR;bordeaux,UL20276#30,UL/CS 1 S.A
..2 M0114 BN61-01709A HOLDER-WIRE;NYLON 6/6,NATURAL,DAWS-1ND 2 S.N.A
..2 M0146 BN61-02196A BRACKET-PANEL SIDE;Bordeaux 32,SECC,T1.2 1 S.N.A
..2 M0146 BN61-02197A BRACKET-PANEL SIDE;Bordeaux 32,SECC,T1.2 1 S.N.A
..2 M0115 BN61-02201A BRACKET-STAND LINK;Bordeaux 32,SECC,T1.6 1 S.A
..2 CCMM1 BN73-00024D SILICON/RUBBER;BORDEAUX,SILICON,28x28XT6 1 S.N.A
..2 T0447 BN96-02999B ASSY BRACKET P-PANEL;BORDEAUX,32,AMLCD,S 1 S.N.A
...3 M0146 BN61-02194A BRACKET-PANEL TOP;Bordeaux 32,SECC,T1.2 1 S.N.A
...3 BN61-02195A BRACKET-PANEL BOTTOM;Bordeaux 32,SECC,T1 1 S.N.A
...3 BN61-02198B BRACKET-GUIDE MAIN;Bordeaux 32,SECC,T1.2 1 S.N.A
...3 BN61-02200A BRACKET-GUIDE POWER;Bordeaux 32,SECC,T1. 1 S.N.A
...3 BN61-02199B BRACKET-GUIDE POWER;Bordeaux 32,SECC,T1. 1 S.N.A
...3 M0131 AA63-01437A GASKET;Bordeaux,Conductive Fabric,20mm,9 1 S.N.A
...3 M0131 AA63-01438A GASKET;Bordeaux,Conductive Fabric,7mm,8m 1 S.N.A
..2 M0059 BN96-03006D ASSY BOARD P-HOLDER AV;32R71,UO,PC+ABS,V 1 S.N.A
...3 M2893 BN39-00672A LEAD CONNECTOR;LNR329DX/XAA,UL2835#28,UL 1 S.A
...3 BN61-02193B HOLDER-SIDE AV;32R71,UO,PC+ABS,V0,BK25,H 1 S.N.A
...3 T0578 BN64-00454B INLAY AV;BORDEAUX,PS SHEET,T0.3,-,-,BLAC 1 S.N.A
...3 M0020 BN96-02439A ASSY BOARD P-SUB AV SIDE;MILANO,CT5000-3 1 S.N.A
..2 T0175 BN96-03298B ASSY SHIELD P-PCB MAIN;BORDEAUX,32,SECC, 1 S.N.A
...3 M0131 AA63-01436A GASKET;Bordeaux,Conductive Fabric,5mm,7m 1 S.N.A
...3 T0603 BN63-02325A SHIELD-PCB MAIN;Bordeaux 32,SECC,T0.5,BU 1 S.N.A
...3 M0131 BN63-02532A GASKET;Bordeaux,Conductive Fabric,13mm,7 1 S.N.A
..2 T0159 BN96-03057C ASSY PCB P-SMPS;BRD32P,Hotel,LE32,AC100V 1 S.N.A
0.1 M0019 BN92-01596P ASSY LABEL;LNS32.40,Bordeaux,Black 1 S.N.A
0.1 M0003 BN92-01663V ASSY BOX;32R71,UO(XAX),BORDEAUX 1 S.N.A
..2 BN69-01260B BOX-01,SET;32R71,DY-01,AB,YEL,A1,AMERICA 1.01 S.N.A
0.1 M0113 BN92-01664B ASSY P/MATERIAL;32R71,UO,BLK,NEW,PE-BAG 1 S.N.A
Page 24
6 Electrical Parts List
6-24
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.035 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.006 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 6.45 S.N.A
..2 T0524 6902-000738 BAG PE;HDPE/HDPE/NITRON (DOUBLE),T0.015/ 1 S.N.A
0.1 M0045 BN92-01498L ASSY ACCESSORY;LNS2651HDX/XAA 1 S.N.A
..2 M0045 BN96-02327D ASSY ACCESSORY;LNS2651HDX/XAA 1 S.A
...3 T0268 3903-000085 CBF-POWER CORD;DT,US,BP3/YES,I(IEC C13/C 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 ACCESSORY BN39-00654A CBF IF-STEREO/MODULAR;ROME HOTEL,4P/6P,U 1 S.A
...3 T0511 BN68-01083B MANUAL USERS;COMM,SAMSUNG,English,N.Amer 1 S.N.A
...3 M0045 BN96-01800A ASSY ACCESSORY;ROME32,SCREW 1 S.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
....4 ACCESSORY 6902-000128 BAG ZIPPER;LDPE,T0.05,W200,L150,TRP,8,2- 1 S.N.A
Loading...
