Instructions Getting to Know your camera
Use this camera in the following order.
Set up the camera driver
Take a picture
Insert the USB cable
Check the camera’s power
Take a picture. (p.20)
Before connecting the camera to a PC,
via the USB cable, you will need to set
up the camera driver. Install the camera
driver that is contained in Application
software CD-ROM. (p.96)
Insert the supplied USB cable into the
PC’s USB port and the camera’s USB
connection terminal. (p.99)
Check the camera’s power. If the power
is turned off, preset the camera button
to turn it on.
Thank you for buying a Samsung Digital Camera.
Prior to using this camera, please read the user manual thoroughly.
When you require After Sales service, please bring the camera and the
cause of the camera malfunction (such as battery, Memory card etc.) to the
A/S centre.
Please check that the camera is operating properly prior to when you intend
to use it (e.g. for a trip or an important event) to avoid disappointment.
Samsung takes no responsibility for any loss or damage that may result
from camera malfunction.
Keep this manual in a safe place.
Specifications are subject to change without prior notice.
Microsoft, Windows and Windows logo are registered trademarks of Microsoft
Corporation incorporated in the United States and/or other countries.
All brand and product names appearing in this manual are registered
trademarks of their respective companies.
The contents and illustrations of this manual are subject to change without
prior notice for upgrading the camera functions.
Check [Removable Disk]
If you use a card reader to copy the images on the memory card to your PC,
the images could be damaged. When transferring the images taken with the
camera to your PC, be sure to use the supplied USB cable to connect the
camera to your PC. Please note that the manufacturer holds no responsibility
for loss or damage of images on the memory card due to the use of a card
reader.
Open Windows’s EXPLORER and
search for [Removable Disk]. (p.99)
<< 1 >>
Page 3
Danger Warning
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Do not attempt to modify this camera in any way. To do so may result in
fire, injury, electric shock or severe damage to you or your camera. internal
inspection, maintenance and repairs should only be carried out by your
dealer or Samsung Camera Service centre.
Please do not use this product in close proximity to flammable or explosive
gases, as this could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do not use
it. Switch off the camera, and then disconnect the power source. You must
contact your dealer or Samsung Camera Service centre. Do not continue to
use the camera as this may cause a fire or electric shock.
Do not insert or drop metallic or inflammable foreign objects into the camera
through access points e.g. the memory card slot and battery chamber. This
may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk of electric
shock.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Do not use the flash in close proximity to people or animals. Positioning the
flash too close to your subject’s eyes may cause eyesight damage.
For safety reasons keep this product and accessories out of reach of
children or animals to prevent accidents e.g.:
● Swallowing battery or small camera accessories. If an accident should
occur, please consult a doctor immediately.
● There is the possibility of injury from the camera’s moving parts.
Battery and camera may become hot during prolonged use and it may result
in camera malfunction. Should this be the case, allow the camera to sit idle
for a few minutes to allow it time to cool.
Do not leave this camera in places subject to extremely high temperatures,
such as a sealed vehicle, direct sunlight or other places of extremes in
temperature. Exposure to extreme temperatures may adversely affect the
camera’s internal components and could cause a fire.
When in use, do not cover the camera or Charger. This may cause heat to
build up and distort the camera body or cause a fire. Always use the camera
and its accessories in a well-ventilated area.
<< 2 >>
Page 4
Caution Contents
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in a minor or moderate injury.
Leaking, overheating, or damaged battery could result in fire or injury.
● Use battery with the correct specification for the camera.
● Do not short circuit, heat or dispose of battery in fire.
● Do not insert the battery with the polarities reversed.
Remove the battery when not planning to use the camera for a long
period of time. Otherwise the battery may leak corrosive electrolyte and
permanently damage the camera’s components.
Do not fire the flash while it is in contact with hands or objects. Do not touch
the flash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using the AC
Charger. After use, always switch off the camera before unplugging the
cable from the wall socket. Then make sure that any connector cords or
cables to other devices are disconnected before moving the camera. Failure
to do so may damage the cords or cables and cause a fire or electric shock.
Take care not to touch the lens or lens cover to avoid taking an unclear
image and possibly causing camera malfunction.
Avoid obstructing the lens or the flash when you capture an image.
Before inserting any cables or AC adapter, check the directions and do not
insert by force. It may cause breakage of cable or camera.
Credit cards may be demagnetized if left near case. Avoid leaving magnetic
strip cards near the case.
READY
RECORDING
007 System chart
008 Identification of features
008 Front & Top
009 Back
010 Bottom
010 5 Function button
012 Connecting to a Power Source
015 Inserting the memory card
Instructions on how to use the memory card
016
018
When Using the Camera for the First Time
019 LCD monitor indicator
020 Starting the recording mode
020 How to use the AUTO mode
020 How to use the PROGRAM mode
021 How to use the ASR mode
021 How to use the MANUAL mode
022 How to use the SCENE modes
022 Portrait, Night scene mode
023 How to use the MOVIE CLIP mode
023 Recording the movie clip without sound
<< 3 >>
Page 5
Contents
<< 4 >>
023 Pausing while recording a movie clip
(Successive Recording)
024 Things to Watch Out for When Taking
Pictures
025 Using the camera buttons to set the
camera
025 POWER button
025 SHUTTER button
025 ZOOM W / T button
027 Info / Up button
027 Macro / Down button
029 Focus lock
029 Flash / Left button
031 Self-timer / Right button
032 MENU / OK button
033 Face recognition(FR) button
034 E (Effect) button
035 E (Effect) button : Colour
036 E (Effect) button : Saturation
037 E (Effect) button : FUN
037 Pre-set focus frame
038 Composite shooting
040 Photo Frame
041 Fn button
042 Size
SETUP
042 Quality / Frame rate
043 Metering
043 Drive mode
044 ISO
045 White balance
046 Exposure compensation
046 Movie Clip frame stabilizer
047 Using the LCD monitor to adjust the
camera settings
047 How to use the menu
048 Sharpness
048 Contrast
048 Focus Area
049 Voice Memo
049 Voice Recording
050 Recording the movie clip without voice
051 SCENE mode
051 Sound menu
052 Sound
052 Volume
052 Start up sound
052 Shutter sound
052 Beep Sound
Page 6
Contents
PLAY
052 AF sound
053 Setup menu
054 Setup menu 1
054 File name
054 LANGUAGE
054 Setting up the Date / Time / Date type
055 Imprinting the recording date
055 LCD brightness
055 Auto Focus lamp
055 Start up image
056 Setup menu 2
056 Quick view
056 Auto power off
056 LCD save
057 Selecting Video out type
058 Formatting a memory
058 Initialisation
059 Starting play mode
059 Playing back a still image
059 Playing back a movie clip
060 Movie clip capture function
060 On camera movie trimming
061 Playing back a recorded voice
061 Playing back a voice memo
062 LCD monitor Indicator
062 Using the camera buttons to set the camera
062 Thumbnail / Enlargement button
064 Info / Up button
064 Play & Pause / Down button
065 Left / Right / Menu / OK button
065 Printer button
065 Delete button
066 E (Effect) button : Resize
067 E (Effect) button : Rotating an image
067 E (Effect) button : Colour
068 E (Effect) button : Special Colour
068 Colour Filter
069 Colour mask
070 E (Effect) button : Image editing
070 Red eye Removal
070 Brightness control
070 Contrast control
070 Saturation control
070 Noise Effect
071 Effect (E button) : FUN
071 Cartoon
<< 5 >>
Page 7
Contents
<< 6 >>
072 Preset focus frames
073 Composite image
075 Photo Frame
076 Sticker
076 Setting up the play back function using the
LCD monitor
078 Starting the slide show
078 Start the slide show
078 Selecting Images
079 Configure slide show effects
079 Setting play interval
079 Setting Background Music
080 Playback
080 Voice memo
080 Protecting images
081 Deleting images
081 DPOF
083 Copy To Card
084 PictBridge
085 PictBridge : Picture Selection
086 PictBridge : Print Setting
086 PictBridge : Reset
087 Important notes
088 Warning indicator
SOFTWARE
089 Before contacting a service centre
091 Specifications
094 Software Notes
094 System Requirements
095 About the software
096 Setting up the application software
098 Starting PC mode
101 Removing the removable disk
102 Setting up the USB Driver for MAC
102 Using the USB Driver for MAC
Removing the USB Driver for Windows 98SE
102
103 Samsung Master
106 FAQ
Page 8
System chart
Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional
equipment, contact your nearest Samsung dealer or Samsung service centre.
<Included items >
Camera case
DPOF compatible
printer (see p.81)
User manual,
Product warranty
SD memory card / MMC
Camera strap
(see p.17)
AC adapter (SAC-46) /
USB cable (SUC-C2)
Software CD
(see p.94)
Rechargeable battery
(SLB-0937)
Computer
(see p.99)
PictBridge compatible
printer (see p.84)
AV cable
External monitor
(see p. 57)
<< 7 >>
Page 9
Identification of features
Front & Top
Speaker
Flash
AF sensor/Self-timer lamp
<< 8 >>
Shutter button
Mode dial
Power button
Lens
Microphone
Page 10
Identification of features
Back
Camera status lamp
Zoom T button (Digital zoom)
Zoom W button (Thumbnail)
LCD monitor
E (Effect) button
Fn/Delete button
Eyelet for camera strap
5-function button
FR (Face Recognition) button
Play mode/Print button
<< 9 >>
Page 11
Identification of features
Bottom 5 Function button
Memory card slot
USB/AV connection terminal
Tripod socket
To open the battery chamber cover, slide it in the direction shown above.
<< 10 >>
Battery holder
Battery chamber
Battery chamber cover
Flash /
Left button
Information / Up button
MENU/OK button
Self-timer /
Right button
Macro / Down button
Play & Pause button
Page 12
Identification of features
Self-timer lamp
Icon
Camera Status Lamp
Power on
After taking a picture
When the USB cable is
inserted to a PC
Transmitting Data with a PC
When the USB cable is
inserted to a printer
When the printer is
printing
When the AF activates
Status Description
Blinking
Blinking
Blinking
For the 2 seconds, the lamp blinks quickly at
0.25-second intervals.
- For the first 8 seconds, the lamp blinks at 1
second intervals.
- For the final 2 seconds, the lamp blinks
quickly at 0.25-second intervals.
A picture will be taken after about 10 seconds and
2 seconds later a second picture will be taken.
Status Description
The lamp turns on and off when the camera
is ready to take a picture
The lamp blinks while saving the image data
and turns off when the camera is ready to take
a picture
The lamp lights up (LCD monitor turns off after
initializing the device)
The lamp blinks (LCD monitor turns off)
The lamp is off
The lamp blinks
The lamp turns on
(The camera focuses on the subject)
The lamp blinks
(The camera doesn't focus on the subject)
Mode icon : Refer to page 20~23 for more information about the
camera mode setting.
MODE Auto Program ASR Manual
ICON
MODE Portrait Night Movie Clip
ICON
MODE
ICON
MODE Dawn
ICON
Children
Landscape
Scene
Close-up Text Sunset
Back light
Fire works Beach & Snow
-
-
<< 11 >>
Page 13
Connecting to a Power Source
You should use the rechargeable battery SLB-0937 supplied with the
camera. Be sure to charge the battery before using the camera.
SLB-0937 rechargeable battery Specification
Model SLB-0937
Type Lithium Ion
Capacity 900mAh
Voltage 3.7V
Charging time(When the camera is turned off)
Number of images and battery life : Using the SLB-0937
Still image Movie
Number of
images
Approx. 200 shots
Approx. 200 shots
L830
L730
Battery life
Approx. 100 MIN
Approx. 100 MIN
Using the fully charged battery, Auto mode,
8M image size(L730 7M image size), Fine
image quality, Shot to shot interval: 30Sec.
Conditions
Changing the zoom position between the
Wide and the Tele after every shot. Using
the flash on every second shot. Using the
camera for 5 minutes and then Powering it
off for 1 minute.
These figures are measured under Samsung’s standard conditions and
shooting conditions and may vary depending on the user’s methods.
<< 12 >>
Approx. 180 MIN
Recording time
Approx. 90 MIN
Using the
fully charged
battery
Conditions
640x480
image size
30fps frame
rate
Important information about battery usage.
When the camera is not used, turn off the camera power.
Please remove the battery if the camera will not be used for long
periods. Batteries can lose power over time and are prone to
leaking if kept inside the camera.
Low temperatures (below 0°C) can affect the performance of the
battery and you may experience reduced battery life.
Batteries will usually recover at normal temperatures.
During extended use of the camera, the camera body may
become warm. This is perfectly normal.
Page 14
Connecting to a Power Source
You can charge the rechargeable battery SLB-0937 by using the SAC46 KIT which consists of the AC adapter (SAC-46) and the USB cable
(SUC-C2). When the SAC-46 and SUC-C2 are combined, they can be
used as an AC cable.
Using an AC cable
: Connect the AC adapter(SAC-46) to the USB
cable. It can be used as a power cable.
Using a USB cable
: Remove the AC adapter (SAC-46).
You can download stored images to your PC
(p.98) or supply the power to your camera
through the USB cable.
Important information about USB cable usage.
Use a USB cable (SUC-C2) with the correct specification.
If the camera is connected to the PC through a USB hub :connect
the camera directly to the PC.
the camera and other devices are connected to the PC at the
same time : remove other device.
If the USB cable is connected to a port located on the front of the
PC : remove the cable and connect it to a port located on the back
of the PC.
If the USB port of the PC doesn't meet the Power output
standard(5V, 500mA), the camera may not be charged.
<< 13 >>
Page 15
Connecting to a Power Source
How to charge the rechargeable battery (SLB-0937)
Charging LED
Before inserting any cables or AC adapter, check the directions
and do not insert by force. It may cause breakage of cable or
camera.
If the charging LED of the AC Charger does not turn on or blink
after inserting the rechargeable battery, please check whether the
battery is inserted correctly.
If you charge the battery with the camera power on, the battery
can't charge fully. Turn the camera off while charging the battery.
Charging LED of the AC Adapter
Charging LED
Being Charged Red LED is on
Charging is complete Green LED is on
Charging error Red LED is off or blinking
Being discharged
(Using the AC adapter)
Orange coloured LED is on
- If you insert the fully discharged battery to charge it, do not turn on the
camera at the same time. The camera may not be turned on because of
the low battery capacity. Charge the battery for more than 10 minutes
before using the camera.
- Do not use the flash frequently or take a movie clip with the fully
discharged battery charged for a short time. Even if the charger
is inserted, the camera power may be turned off because the
rechargeable battery is discharged again.
<< 14 >>
Page 16
Connecting to a Power Source Inserting the memory card
Insert the battery as shown
- If the camera does not turn on after you
have inserted battery, please check
whether the battery is inserted with the
correct polarity (+ / -).
- When the battery chamber cover
is opened, do not press the battery
chamber cover by force. This may cause
damage to the battery chamber cover.
There are 4 indicators for battery condition that are displayed on the
LCD monitor.
Battery indicator
Battery status
The battery is
fully charged
Low battery
capacity
(Prepare to
recharge
or use spare
battery)
Low battery
capacity
(Prepare to
recharge
or use spare
battery)
Battery
empty
(Recharge
or use spare
battery)
Insert the memory card as shown.
- Turn off the camera’s power before
inserting the memory card.
- Have the front of the memory card
facing toward the front of the camera
(Lens) and the card pins toward the
back of the camera (LCD monitor).
- Do not insert the memory card the wrong way round.
Doing so may damage the memory card slot.
<< 15 >>
Page 17
Instructions on how to use the memory card
Be sure to format the memory card (see p.58) if you are using a newly
purchased memory card for the first time, if it contains data that the
camera cannot recognise, or if it contains images captured with a
different camera.
Turn off the camera power whenever the memory card is being inserted
or removed.
Repeated use of the memory card will eventually reduce the memory
card’s performance. Should this be the case, you will need to purchase
a new memory card. Wear and tear on the memory card is not covered
by the Samsung warranty.
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy impact.
Do not store the memory card in an environment with strong electronic
or magnetic fields, e.g. near loud speakers or TV receivers.
Please do not use or store in an environment where there are
extremes in temperature.
Do not allow the memory card to become dirty or to come into contact
with any liquid. Should this happen, clean the memory card with a soft
cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the
memory card is warm. This is perfectly normal.
Do not use a memory card that is used in another digital camera. To
use the memory card in this camera, format the memory card using
this camera.
Do not use a memory card formatted by another digital camera or
memory card reader.
If the memory card is subjected to any of the following, the recorded
data may become corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while
recording, deleting (formatting) or reading.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up e.g.
floppy disks, hard disks, CD etc.
If there is insufficient memory available :
A [Memory Full!] message will appear and the camera will not operate.
To optimise the amount of memory in the camera, replace the memory
card or delete unnecessary images stored on the memory card.
Don't remove the memory card when the camera status lamp is
blinking as this may cause damage to data in the memory card.
<< 16 >>
Page 18
Instructions on how to use the memory card
The camera can use SD/ SDHC Memory Cards and MMC (Multi Media
Cards).
Card pins
Write protect
switch
Label
[SD (Secure Digital) memory card]
The SD/ SDHC memory card has a write protect switch that prevents
image files from being deleted or formatted. By sliding the switch to the
bottom of the SD memory card, the data will be protected. By sliding
the switch to the top of the SD memory card, the data protection will be
cancelled.
Slide the switch to the top of the SD memory card before taking a picture.
When using a 256MB MMC memory, the specified shooting capacity will
be as follows. These figures are approximate as image capacities can be
affected by variables such as subject matter and memory card type.
- L830
Recorded image size
Still
*Movie
clip
Super Fine
Fine
Normal
53 104 151
63 118 197
76 144 223
94 181 256
142 264 363
459 710 822
30FPS 20FPS 15FPS
---
---
---
---
---
---
----
---
---
About 9'02"-About 17'37"
About 36'36"-About 60'21"
About 8'48"
-
- L730
Recorded image size
Still
*Movie
clip
The recording times can be changed by the zoom operation.
The zoom button doesn’t function during the movie recording.
Super Fine
Fine
Normal
67 128 188
80 157 223
30FPS 20FPS 15FPS
---
--95 183 269
95 183 269
142 269 363
459 710 822
---
---
---
----
---
---
About 9'02"-About 17'37"
About 36'36"-About 60'21"
About 8'48"
-
<< 17 >>
Page 19
When Using the Camera for the First Time
Charge the rechargeable battery fully before using the camera for the
first time.
When the camera is turned on for the first time, a menu will be displayed
to set date / time and language in the LCD monitor. This menu will not
be displayed after setting up. Set up the date / time and language before
using this camera.
Setting up the Language
1. Select the [Language] menu by pressing
the UP/ DOWN button and press the
RIGHT button.
2. Select the desired sub menu by pressing
the UP / DOWN button and press the OK
button.
You can select one of 22 languages. These are listed below :
- English, Korean, French, German, Spanish, Italian, S.Chinese,
T.Chinese, Japanese, Russian, Portuguese, Dutch, Danish,
Swedish, Finnish, Thai, Bahasa (Malay/ Indonesian), Arabic,
Czech, Polish, Hungarian and Turkish.
Even if the camera is restarted, the language setting will be
maintained.
SETUP1
Date&Time
Back Set
ENGLISHLanguage
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
OK
Setting up the date, time and date type
1. Select the [Date&Time] menu by pressing
the UP/ DOWN button and press the
RIGHT button.
2. Select the desired sub menu by pressing
the UP/ DOWN/ LEFT/ RIGHT button and
press the OK button.
RIGHT button : Selects YEAR/ MONTH/ DAY/HOUR/ MINUTE/
DATE TYPE
LEFT button : Moves the cursor to the [Date&Time] main menu if the
cursor is at the first item of the date and time setup. In
all other instances, the cursor will be shifted to the left
of its current position.
UP/ DOWN button : Changes the value of each item.
SETUP1
Language
Date&Time
Back Set
07/07/01
12:00
yy/mm/dd
OK
<< 18 >>
Page 20
LCD monitor indicator
The LCD monitor displays information about the shooting functions and
selections.
1 ) (&*
2
3
4
5
6
7
8
0
9 -
[Image & Full Status]
No. Description Icons Page
1 Recording mode p.11
2 Color / Saturation p.35/36
3 Face Recognition p.33
4 Flash p.31
5 Self-timer p.32
6 Macro p.27
No. Description Icons Page
7 Contrast p.48
8 Sharpness p.48
9
^
%
$
#
@
!
~
=
Auto Focus Frame
10
Camera shake Warning
11 Date / Time 2007/07/01 01:00 PM p.54
Exposure compensation
12
13
White Balance
14
15
ISO
L830
L730
Drive mode /
Stabiliser
16 Metering p.43
Image Quality / Frame Rate
17
18
Size
L830
L730
p.48
p.21
p.46
p.45
p.44
p.43/46
p.42
p.42
19 Battery p.15
Optical / Digital Zoom bar /
20
Digital Zoom rate
p.26
21 Voice Memo/Mic. Off p.49/50
Number of available shots
22
remaining / Remaining time
Memory card icon /
23
Internal memory icon
6/00:00:00
p.17
-
<< 19 >>
Page 21
Starting the recording mode
How to use the AUTO mode
Please select this mode for quick and easy picture taking with minimal
user interaction.
1. Insert the batteries (p.15). Insert the
batteries taking note of the polarity (+ / -).
2. Insert the memory card (p.15). As this
camera has a 10MB internal memory, you
do not need to insert the memory card. If
the memory card is not inserted, an image
will be stored in the internal memory. If the
memory card is inserted, an image will be
stored on the memory card.
3. Close the battery chamber cover.
4. Press the power button to turn on the camera. (If the date/ time that
is displayed on the LCD monitor is incorrect, reset the date/ time
before taking a picture.)
5. Select the AUTO mode by rotating the mode dial.
6. Point the camera towards the subject and compose the image by
using the LCD monitor.
7. Press the shutter button to capture an image.
If the auto focus frame turns to red when you press the shutter
button down half way, it means that the camera cannot focus
on the subject. Should this be the case, the camera is unable to
capture an image clearly.
<< 20 >>
Avoid obstructing the lens or the flash when you capture an image.
How to use the PROGRAM mode
Selecting the automatic mode will configure the camera with optimal
settings. You can still manually configure all functions except the aperture
value and shutter speed.
1. Select the PROGRAM mode by rotating the
mode dial.
2. Press the Fn button to configure advanced
functions such as Image Size (p.42), Quality
(p.42), Metering (p.43), Drive mode (p.43),
ISO (p.44), White Balance (p.45), and
Exposure Value(p.46).
Page 22
Starting the recording mode
How to use the ASR mode
This mode will reduce the effect of camera shake and help you get a
well-exposed image in dim conditions.
1. Select the ASR mode by rotating the
Mode dial.
2. Point the camera towards the subject and
compose the image by using the LCD
monitor.
3. Press the shutter button to capture an
image.
Things to watch out for using the ASR mode
- The digital zoom will not operate in the ASR mode.
- If the lighting condition is brighter than fluorescent lighting conditions,
the ASR will not activate.
- If the lighting condition is darker than in fluorescent lighting conditions,
camera shake warning indicator (
only take pictures in situations where the camera shake warning
indicator ( ) is not displayed.
- If the subject is moving, the captured image may be blurred.
- Avoid moving the camera while the [Capturing!] message is displayed
to achieve a better result.
- As the ASR uses the camera's digital signal processor, it may take a
little longer for the camera to process and save the images.
L830 : If the image size is or , the ASR mode can't be selected.
-
-
L730 : If the image size is or , the ASR mode can't be selected.
) will display. For best results
How to use the MANUAL mode
You can manually configure all functions aperture value and shutter
speed.
1. Select the MANUAL mode by rotating the
mode dial.
2. Press the Fn button and menu for the shutter
speed and aperture value will display.
Up / Down button : changes aperture value
Left / Right button : changes shutter speed.
3. Press the Fn button twice and take an image.
Smaller Aperture values make the object sharp but blur the
background. Larger Aperture values make both the object and
background sharp.
High Shutter speeds can capture a moving object in a still image as
if the object is not moving. Low Shutter speeds can capture a moving
object with an ‘active’ effect.
<< 21 >>
Page 23
Starting the recording mode
CAF
How to use the SCENE modes
Use the menu to easily configure optimal settings for a variety of
shooting situations.
1. Select the Scene mode by rotating the
Mode dial.
2. Point the camera towards the subject and
compose the image by using the LCD
monitor.
3. Press the shutter button to capture an image.
The scene modes are listed below.
[Children] ( ) : To take a picture of fast moving objects,
for example, children.
[Landscape] (
[Close Up] (
) : To take pictures of distant scenery.
) : Close-up shooting for small objects such as
plants and insects.
[Text] (
[Sunset] (
[Dawn] (
[Backlight] (
) : Use this mode to shoot a document.
) : For taking pictures of sunsets.
) : Daybreak scenes.
) : Portrait without shadows caused by
backlight.
[Firework] (
[Beach & Snow] (
) : Firework scenes.
) : For ocean, lake, beach and snowscape
scenes.
CAF
CAF
Portrait, Night scene mode
Select a desired mode by rotating the mode dial.
- Portrait : To take a picture of a person.
- Night : Use this for shooting still images at night or in other dark
conditions.
[PORTRAIT mode]
[NIGHT mode]
<< 22 >>
Page 24
Starting the recording mode
How to use the MOVIE CLIP mode
A movie clip can be recorded for as long as the available recording time
of the memory capacity allows.
1. Select the Movie clip mode by rotating the
Mode dial.
2. Point the camera towards the subject and
compose the image by using the LCD
monitor.
3. Press the shutter button once and movie
clips are recorded for as long as the
available recording time allows. Movie clips
will still be recorded if the shutter button
is released. If you wish to stop recording, press the shutter button
again.
Image size and type are listed below.
- Image size : 800x592, 640x480, 320x240(Selectable)
- Movie clip file type : AVI (MPEG-4)
- Frame Rate : 30FPS, 20FPS, 15FPS
- When the 800X592 image size is selected, the 30FPS and 15FPS
can't be selected. And when the 640x480 or 320x240 image size
is selected, 20FPS can't be selected.
Recording the movie clip without sound
You can record the movie clip without sound.
Steps from 1-3 are the same as those for
MOVIE CLIP mode.
4. Press the Menu button.
5. Select the [RECORDING] menu by pressing the Left / Right button.
6. Press the Down button to select the [Voice Mute] menu and press the
Right button.
7. Select the [On] menu by pressing the Up / Down button.
8. Press the OK button. You can record a movie without sound.
Pausing while recording a movie clip (Successive Recording)
This camera allows you to temporarily stop during unwanted scenes,
while recording a movie clip. Using this function, you can record your
favourite scenes into a movie clip without having to create multiple
movie clips.
Using Successive Recording
Steps from 1-2 are the same as those for
MOVIE CLIP mode.
3. Point the camera towards the subject and
compose the image by using the LCD
monitor. Press the shutter button and
movie clips are recorded for as long as the
available recording time. Movie clips will still be recorded if the shutter
button is released.
4. Press the Pause button ( ) to pause recording.
5. Press the Pause button ( ) again to resume the recording.
6. If you wish to stop recording, press the shutter button again.
Stop REC
SH
00 : 00 : 18
<< 23 >>
Page 25
Things to Watch Out for When Taking Pictures
Pressing the shutter button down half way.
Lightly press the shutter button to confirm focus and flash battery
charge. Press the shutter button all way down to take the picture.
[Lightly press the shutter button]
The available memory capacity may vary depending on shooting
conditions and camera settings.
When the Flash Off or Slow synchro mode is selected in a low lighting
condition, the camera shake warning indicator ( ) may appear on the
LCD monitor. In this case, use a tripod, support the camera on a solid
surface or change to flash shot mode.
Shooting against the light : Please do not take pictures against the sun.
Doing so may make the picture dark. To
take a picture against the light, please use
the [BACKLIGHT] in the scene shooting
mode (see page 22), fill-in flash (see
page 30), spot metering (see page 43), or
exposure compensation (see page 46).
Avoid obstructing the lens or the flash when you capture an image.
Compose the image by using the LCD monitor.
[Press the shutter button]
Under certain conditions the auto focus system may not perform as
expected.
- When photographing a subject that has little contrast.
- If the subject is highly reflective or shiny.
- If the subject is moving at high speed.
- When there is strong reflected light, or when the background is very
bright.
- When the subject matter has only horizontal lines or the subject is
very narrow (such as a stick or flagpole).
- When the surroundings are dark.
<< 24 >>
Page 26
Using the camera buttons to set the camera
The recording mode function can be set up by using the camera buttons.
POWER button
Used for turning the camera’s power on / off.
If there is no operation during the specified
time, the camera's power will be turned off
automatically to save battery life.
Refer to page 56 for more information about
the auto power off function.
SHUTTER button
Used for taking an image or recording voice in the RECORDING mode.
In MOVIE CLIP mode
Pressing the shutter button down fully starts
the process for recording a movie clip.
Press the shutter button once and the movie
clip is recorded for as long as the available
recording time in the memory allows. If you
wish to stop recording, press the shutter button again.
In STILL IMAGE mode
Pressing the shutter button down halfway activates the autofocus and
checks the condition of the flash. Pressing the shutter button down fully
takes and stores the image. If you select voice memo recording, the
recording will start after the camera has finished storing the image data.
ZOOM W / T button
If the menu is not displayed, this button works
as the OPTICAL ZOOM or DIGITAL ZOOM
button.This camera has a 3X optical zoom
and a 5X digital zoom function.
Using both will offer a total zoom ratio of 15X.
TELE Zoom
Optical zoom TELE : Pressing the ZOOM T button. This will zoom
Digital zoom TELE : When the maximum (3X) optical zoom
[WIDE zoom]
into the subject i.e. the subject will appear
nearer.
is selected, pressing the ZOOM T button
activates the digital zoom software. Releasing
ZOOM T button stops the digital zooming at
the required setting. Once the maximum digital
zoom (5X) is achieved, pressing the ZOOM T
button will have no effect.
Pressing
the ZOOM
T button
[TELE zoom] [Digital zoom 5.0X]
Pressing
the ZOOM
T button
<< 25 >>
Page 27
ZOOM W / T button
WIDE Zoom
Optical zoom WIDE : Pressing the ZOOM W button. This will zoom
[TELE zoom]
Digital zoom WIDE : When the digital zoom is in operation, pressing
Optical zoom
Digital zoom
out from the subject i.e. the subject will appear
further away. Pressing the ZOOM W button
continuously will set the camera to its minimum
zoom setting i.e. the subject appears at its
furthest from the camera.
Pressing
the ZOOM
W button
[Optical zoom 2X]
Pressing
the ZOOM
W button
[WIDE zoom]
the ZOOM W button will reduce the digital
zooming in steps. Releasing ZOOM W button
stops digital zooming. Pressing the ZOOM W
button will reduce the digital zoom and then it
will continue to reduce the optical zoom until the
minimum setting is reached.
Pressing
the ZOOM
W button
Pressing
the ZOOM
W button
Images taken using the digital zoom may take a little longer for the
camera to process. Allow time for this to take place.
The digital zoom cannot be used in movie clip shots.
You may notice a decrease in image quality when using the digital
zoom.
To view a clearer digital zoom image, press the shutter button
halfway at the maximum optical zoom position and press the zoom
T button again.
The digital zoom can't be activated in some Scene modes (Children,
Text, Close-up, Fireworks), Night mode, Motion Capture mode,
ASR mode, movie clip mode and Face recognition.
Take care not to press the lens as this may cause a camera
malfunction.
If the Zoom buttons are being pressed during the Movie clip shots,
the voice will not recorded.
[Digital zoom 5.0X]
<< 26 >>
[TELE zoom]
[WIDE zoom]
Page 28
( )
Info
While the menu is showing, the Up button operates as a direction button.
In the recording modes or playback mode, pressing this button will
display the image information.
/ Up button
Info ( ) button
Macro
While the menu is showing, press the DOWN button to move from the
main menu to a sub menu, or to move down the sub menu. When the
menu is not showing, you can use the MACRO / DOWN button to take
macro pictures.
The distance ranges are shown below. Press the Macro button until the
desired macro mode indicator appears on the LCD monitor.
( )
/ Down button
[Auto Focus] [Macro ( )]
[Auto Macro ( )]
<< 27 >>
Page 29
Macro
Types of focus mode and focus range (W : Wide, T : Tele)
( )
/ Down button
Mode Auto ( ) Program ( )
Focus Type
Focus range
Auto macro
W : 10~
Infinity
T : 50~
Infinity
When the macro mode is selected, be particularly careful to avoid
( )
Normal
W : 80~
T : 80~
Infinity
Infinity
Macro
( )
W : 10~80
T : 50~80
camera shake.
When you take a picture within 20cm (Wide zoom) or 50cm
(Tele zoom) in the Macro mode, select the FLASH OFF mode.
When you take a picture within the 10cm macro range, the auto-
focus on the camera will take longer to set the correct focus
distance.
Normal
W : 80~
T : 80~
(Unit: cm)
Infinity
Infinity
Available focusing method, by recording mode
( : Selectable, : Infinity focus range)
Mode Auto macro Macro Normal
Mode
Auto macro Macro Normal
SCENE
<< 28 >>
Page 30
Focus lock Flash
To focus on a subject not positioned in the centre of the picture, use the
focus lock function.
Using the Focus Lock
1. Ensure the subject is in the centre of the autofocus frame.
2. Press the SHUTTER button halfway. When the green auto focus
frame lights up, it means the camera is focused on the subject. Be
careful not to press the SHUTTER button all the way down to avoid
taking an unwanted picture.
3. With the SHUTTER button still pressed down only halfway, move
the camera to recompose your picture as desired, and then press
the SHUTTER button completely to take the picture. If you release
your finger from the SHUTTER button, the focus lock function will be
cancelled.
1. The image to be
captured.
2. Press the SHUTTER
button halfway and
focus on the subject.
3. Recompose the picture
and fully depress the
SHUTTER button.
When the menu is displayed on the LCD
monitor, pressing the LEFT button makes the
cursor shift to the left tab.
When the menu is not displayed on the LCD
monitor, the LEFT button operates as the
FLASH button.
Selecting the flash mode
1. Press the Mode button to select a RECORDING mode with the
exception of the Movie clip mode or the ASR mode.
2. Press the Flash button until the desired flash mode indicator is
displayed on the LCD monitor.
3. A flash mode indicator will be displayed on the LCD monitor.
Use the correct flash to suit the environment.
Flash range
ISO
AUTO 0.3 ~ 4.6 0.5 ~ 2.6 0.2 ~ 0.8 0.5 ~ 0.8 0.2 ~ 4.6 0.5 ~ 2.6
( )
/ Left button
[Selecting the Auto flash]
(Unit: m)
Normal Macro Auto macro
WIDE TELE WIDE TELE WIDE TELE
<< 29 >>
Page 31
Flash
( )
/ Left button
If you press the shutter button after selecting the Auto, Fill-in, Slow
synchro flash, the first flash fires to check the shooting condition
(Flash range and Power ratio of flash).
Do not move the camera until the second flash fires.
Using the flash frequently will reduce the life of the battery.
Under normal operating conditions the re-charging time for
the flash is usually within 4 seconds. If the battery is weak, the
charging time will be longer.
In the ASR mode, [Landscape], [Close up], [Text], [Sunset],
[Dawn], [Firework] scene modes and the Movie clip mode, the
flash function will not operate.
(Exceptionally, the flash function will operate when you use the
wise shot in the ASR mode)
Take photographs within the flash range.
The image quality is not guaranteed if the subject is too close or
highly reflective.
When taking an image in poorly lit conditions with the flash, there
may be a white speck in the captured image. The speck is caused
by the flash light reflecting off atmospheric dust.
<< 30 >>
Flash mode indicator
Icon Flash mode Description
If the subject or background is
Auto flash
dark, the camera flash will operate
automatically.
Auto & Red eye
reduction
If a subject or background is dark, the
camera flash will work automatically
and will reduce the red-eye effect by
using the red-eye reduction function.
The flash fires regardless of the
Fill in flash
available light. The intensity of the
flash will be automatically controlled
to suit the prevailing conditions.
The flash operates with a slow shutter
Slow synchro
speed to obtain a balanced correct
exposure. In poor lighting conditions
the camera shake warning indicator
) will display on the LCD monitor.
(
The flash does not fire.
Select this mode when capturing
images in a place or situation where
Flash off
flash photography is prohibited. When
you capture an image in a poorly lit
condition, the camera shake warning
indicator (
monitor.
) will appear on the LCD
When a shot with "red eye" is
Red-eye reduction
detected, this mode will reduce the
red-eye effect automatically.
Page 32
Flash
( )
/ Left button Self-timer
Available flash mode, by recording mode
( )
/ Right button
( : Selectable)
When the menu is displayed on the LCD monitor, pressing the Right
button makes the cursor shift to the right tab.
When the menu is not displayed on the LCD monitor, the RIGHT button
operates as the Self-timer (
) button. This function is used when the
photographer would also like to be in the image.
If you operate the Self-timer button during the self-timer operation,
the self-timer function is cancelled.
Use a tripod to prevent the camera from shaking.
In Movie Clip mode, only the 10SEC self-timer will work.
<< 31 >>
Page 33
Self-timer
Selecting the self-timer
( )
/ Right button
1. Select a RECORDING mode with the
exception of VOICE RECORDING mode.
2.
Press the SELF-TIMER ( ) button until the
desired mode indicator displays on the LCD
monitor. A 10 second, 2 second, or Double selftimer icon appears on the LCD monitor.
[Selecting the 10 SEC self-timer]
2SEC self-timer ( ):
Pressing the shutter button will allow an
interval of 2 seconds before the image is taken.
10SEC self-timer ( ):
Pressing the shutter button will allow an interval of 10 seconds
before the image is taken.
Double self-timer ( ):
A picture will be taken after about 10 seconds and 2 seconds later
a second picture will be taken. When using the flash, the 2-second
self-timer may be delayed for longer than 2 seconds depending on
the flash charging time.
3. When you press the SHUTTER button, the picture will be taken after
the specified time has elapsed.
If you operate the Self-timer button during the self-timer operation,
the self-timer function is cancelled.
Use a tripod to prevent the camera from shaking.
MENU / OK button
MENU button
- When you press the MENU button, a menu related to each camera
mode will be displayed on the LCD monitor. Pressing it again will
return the LCD to the initial display.
- A menu option can be displayed when the following are selected :
MOVIE CLIP and STILL IMAGE mode. There is no menu available
when the VOICE RECORDING mode is selected.
RECORDING
NormalSharpness
Contrast
Voice Recording
MENU
OK button
[Pressing the MENU button]
[Menu off]
- When the menu is displayed on the LCD monitor, this button is used
for shifting the cursor to the sub menu or for confirming data.
Normal
Center AFFocus Area
OffVoice Memo
Exit Move
[Menu on]
<< 32 >>
Page 34
Face recognition(FR) button
This mode detects the face position of the subject automatically and then
sets the focus and exposure. Select this mode for quick and easy face
portraits.
Selectable modes : Auto, Program, ASR, Manual, Portrait, Scene
modes (Children, Beach & Snow )
1. Press the FR (Face Recognition) button
( ) in the selectable modes.
The FR icon will be displayed on the left side
of the screen.
2. The size and position of the auto focus
frame is set on the face of the subject
automatically.
3. Press the shutter button halfway. The focus frame turns to green
when the focus is activated.
4. Press the shutter button fully to take a picture.
This function can detect up to 9 people.
When the camera recognises many people at the same time,
it will focus on the nearest person.
The Digital zoom is not activated in this mode.
The effects functions are not activated in this mode.
When the camera detects a target face, the white colour focus
frame will be displayed over the target face and the gray colour
focus frame appears over the remaining faces(up to 8). Press the
shutter button halfway down to focus on the face and the white
focus frame turns green.(Total 9)
Return to previous AF mode if face detection was failure.
In some conditions this function cannot work properly.
- When a person wears dark glasses or some part of the face
is hidden
- When the person being photographed does not look at the
camera.
The maximum available Face Recognition range is 3.1m (Wide).
The nearer the subject, the faster the camera can recognize the
subject.
<< 33 >>
Page 35
E (Effect) button
It is possible to add special effects to your images by using this button.
Still image mode : You can select the colour, image editing and
Movie clip mode : You can select the colour menu.
Available Effects, by recording mode
Fun menu. In the Auto mode, you can select the
[COLOR] menu only.
(
: Selectable)
This button will not operate in ASR, Night, Voice recording
mode and some scene modes (Text, Sunset, Dawn, Backlight,
Fireworks, Beach&Snow).
Even if the camera is turned off, the effect setting will be
preserved. To cancel the special effect, select sub menu in
the Colour menu and select the sub menu in the rest effect
menus.
L830 : If the image size is or , the FUN menu can't be
selected.
L730 : If the image size is or , the FUN menu can't be
selected.
<< 34 >>
Page 36
E (Effect) button : Colour
By using the camera’s digital processor, it is possible to add special
effects to your images
Press the E button in an available recording mode. (p.34)
Custom colour : You can change the R (Red),
G (Green) and B (Blue) values
of the image.
CUSTOM COLOR
COLOR
E
Move Exit
E
COLOR
Move Exit
E
[Still image mode] [Movie clip mode]
1. Select a desired sub menu by pressing the Up/Down button and
press the OK button.
: No effect is added to the image.
: Captured images will be stored in black and white.
: Captured images will be stored in a sepia tone
(a gradient of yellowish brown colours).
: Captured images will be stored in a red tone.
: Captured images will be stored in a green tone.
: Captured images will be stored in a blue tone.
: Save the image in negative mode.
: Captured image will be saved in set RGB tone.
2. Press the shutter button to capture an image.
Move Set
- Up/Down button : Selects R, G, B
- Left/Right button : Changes the values
CUSTOM COLOR
Move Set
In the Auto mode, the Custom Color can't be selected.
OK
OK
<< 35 >>
Page 37
E (Effect) button : Saturation
You can change the saturation of the image.
Press the E button in an available recording mode. (p.34)
IMAGE ADJUST
Move Exit
<< 36 >>
E
[Final Image]
Select Saturation menu ( ) and
a bar for changing the saturation will
be displayed.
Press the Shutter button to take a picture.
Saturation
Move Set
OK
Bar for changing the saturation
Change the saturation by pressing the
Left/Right button.
+ direction: High saturation (The colour will be intense)
- direction: Low saturation (The colour will be subtle)
Press the OK button and the
saturation of image will be changed.
Saturation
Move Set
OK
Page 38
E (Effect) button : FUN
Pre-set focus frame
You can make the subject stand out from its surroundings. The subject will
be sharp and in focus while making the rest out of focus.
Press the E button in an available recording mode. (p.34)
FUN
E
Move Exit
E
1. Select a proper menu by pressing the Left/Right button and press
the OK button.
High Light
E
OK
Range Set
Moving and changing the focus frame
You can change the focus frame after selecting a Range menu.
E
SH Fn
Capture Edit
[Point the camera towards the
subject and compose the image by
using the LCD monitor.]
Pressing the Fn button
SH
Capture Move
[The range is activated : The
colour of focus frame turns
white.]
Pressing the Up/Down/
Left/Right button
E
High light
OK
Range Set
High light
E
Range Set
High light
OK
E
OK
Range Set
E
[Range 1] [Range 2] [Range 3] [Range 4]
2. The preset focus frame will appear.
Press the shutter button to capture an
image.
Capture Edit
High light
Range Set
SH Fn
Pressing the Fn button
SH Fn
Capture Edit
OK
E
E
Pressing the shutter button
Capture Move
[After changing the range]
E
SH
[Final image]
<< 37 >>
Page 39
E (Effect) button : FUN
Composite shooting
You can combine 2 ~ 4 different shots in a still image.
Press the E button in an available recording mode. (p.34)
FUN
E
Move Exit
E
1. Select a desired menu by pressing Left/Right button and press the
OK button.
Composite
Compose Set
[Composite 1] [Composite 2] [Composite 3] [Composite 4]
Composite
OK
E
OK
Compose Set
E
2. After selecting a desired menu, press the shutter button to take a
picture.
<< 38 >>
Composite
Composite
OK
Compose Set
E
E
OK
Compose Set
Composite
Compose Set
OK
E
Selecting 2 composite shots
Pressing the
shutter button
SH Fn
Capture
SH
[Ready for taking]
Capture Delete
[First shot]
Pressing the
shutter button
Pressing the
OK button
OK Fn
Save Delete
[The final picture]
[Second shot]
After taking the last image, press the OK button to save the image.
You can use the flash, self-timer, macro focus and the Zoom W / T
button during the composite shooting.
If you press the Play mode, MENU, E button or turn Mode button
dial during the composite shots, each camera working mode is
executed. The previously captured images will be deleted.
Page 40
E (Effect) button : FUN
Changing a part of composite shot before taking the last shot
Before taking the last composite shot, you can change a part of
composite shot.
1. During the composite shots, press the Fn button.
2. A previous image will be deleted and new frame will be displayed.
To delete a previously taken image, press the Fn button again.
Pressing the Fn button
SH Fn
Capture Delete
[Before taking the 3rd shot]
SH Fn
Capture Delete
[Moving backward to the 2nd shot]
Changing a part of composite shot after taking the last shot
1. After taking the last shot, a cursor to select a frame will appear.
Press the Up/Down/Left/Right button to select the frame.
2. Press the Fn button and an image will be deleted. Composite frame
will be activated.
3. Press the Shutter button. You can take other images again by using
the Press the Up/Down/Left/Right button and Fn button.
4. Press the OK button again to save the captured image.
Pressing the up
button
OK Fn
Save Delete
[After taking 4th shot]
OK Fn
Save Delete
[Moving backward to the 2nd shot]
3. Press the shutter button to capture a new image.
Pressing the
Shutter button
OK Fn
Save Delete
Capture
SH
[Deleting 2nd shot]
Pressing the
OK button
Pressing the Fn
button
[Final Image][Taking 2nd shot again]
<< 39 >>
Page 41
E (Effect) button : FUN
Photo Frame
You can add 9 types of frame-like borders to a still image you want to
capture.
Date & Time information will not be printed on the stored image taken
with Photo Frame menu.
Press the E button in an available recording mode. (p.34)
FUN
Move Exit
Capture Move
<< 40 >>
Photo Frame
E
E
Frame Set
E
OK
Pressing the OK
button
1. The selected photo frame will be displayed. Press the shutter button
to take a picture.
Pressing the Fn
E
SH
button
Capture Frame
SH Fn
E
Page 42
Fn button
You can use the Fn button to set the following menus.
Size
Quality/
Frame rate
Metering
Drive
ISO
White Balance
EV
Stabilisation
*1
p.43
p.44
(
: Selectable)
Page
p.42
p.42
p.43
p.45
p.46
p.46
How to use the Fn menu
1. Press the Fn button in an available mode.
2. Select a desired menu by pressing the Up / Down button. And then a
sub menu will be displayed at the bottom left of the LCD monitor.
SIZE
Up / Down
3264X2448
button
3. Select a desired menu by pressing the Left / Right button and then
press the OK button.
QUALITY
Fine
*1. This menu is only available in the Children scene mode ( ).
SIZE
3264X2448
Left / Right
button
SIZE
3264X2176
<< 41 >>
Page 43
Size Quality / Frame rate
You can select the image size appropriate for your application.
- L830
Icon
Still
mode
Movie clip
mode
Size
Icon
Size
3264 x
3264 x
3264 x
2592 x
2448
2176
1836
1944
2048 x
1536
800 x 592 640 x 480 320 x 240
- L730
Icon
Still
mode
Movie clip
mode
3072 x
3072 x
3072 x
2592 x
Size
2304
2048
1728
1944
2048 x
1536
Icon
Size 800 x 592 640 x 480 320 x 240
SIZE
3264X2448
[ STILL IMAGE mode ]
[ MOVIE CLIP mode ]
SIZE
800X592
The higher the resolution, the lower the number of shots available
because high resolution images require more memory.
<< 42 >>
1024 x
768
1024 x
768
You can select the compression ratio appropriate for your application of the
captured images. The higher the compression ratio, the lower the picture quality.
Mode STILL IMAGE mode MOVIE CLIP mode
Icon
Super
Sub
menu
File
Format
Fine
jpeg jpeg jpeg avi avi avi
[ STILL IMAGE mode ]
This file format complies with the DCF (Design rule for Camera
Fine Normal 30FPS 20FPS 15FPS
QUALITY
Fine
File system).
JPEG (Joint Photographic Experts Group) :
JPEG is the image compression standard developed by the Joint
Photographic Experts Group. This type of compression is most
commonly used for compressing photos and graphics because it
can compress the files efficiently.
FRAME RATE
20fps
[ MOVIE CLIP mode ]
Page 44
Metering Drive mode
If you cannot obtain suitable exposure conditions, you can change the
metering method to take brighter pictures.
[Multi] : Exposure will be calculated based
on an average of the available light
in the image area. However, the
calculation will be biased towards
the centre of the image area. This is
suitable for general use.
METERING
Multi
[Spot] : Only the rectangular area in the
centre of the LCD monitor will be metered for light.
This is suitable when the subject in the centre is exposed
correctly, regardless of the back lighting.
If the subject is not the centre of the focus area, do not use the
spot metering as this may result in an exposure error. In this
circumstance, it is better to use exposure compensation.
You can select continuous shot, and AEB (Auto Exposure Bracketing).
[Single] : Take one picture only.
[Wise Shot] : Two images are taken at a
[Continuous] : Images will be taken continuously until the shutter
[AEB] : Take three pictures in a series in different exposures:
[Motion Capture] :
High resolution and picture quality increases file saving time, which
increases stand-by time.
If the [Continuous], [AEB] or [Motion Capture] sub menu is selected,
the flash will be off automatically.
If less than 3 pictures are available in the memory, the AEB shooting
is not available.
It is best to use a tripod for the AEB shooting as the time to save each
image file is longer and blurring caused by camera shake may occur.
If less than 30 pictures are availabe in the memory, the Motion
Capture shooting is not available.
time. One is taken in the FillIn Flash mode and the other
is taken in the ASR mode.
DRIVE
Single
button is released.
standard exposure (0.0EV), short exposure (-1/3EV)
and over exposure (+1/3EV).
This takes 6 shots per second, and for max 5 seconds,
when the shutter is pressed and held down. The
maximum number of shots is 30 and the image size is
fixed as VGA.
<< 43 >>
Page 45
Drive mode ISO
Wise Shot
2 images are taken at a time. One is taken
in the Fill-In Flash mode and the other is
taken in the ASR mode.
How to use the wise shot
1. Select the ASR mode by rotating the mode
dial and press the Fn button.
2. Select Drive menu tab by pressing the Up and Down button.
3. Press the Shutter button to capture images.
4. The captured images are saved.
In the Wise shot, the shutter speed value shown on the LCD may
be different from the real shutter speed.
DRIVE
Wise Shot
You can select the ISO sensitivity when taking pictures.
The speed or specific light-sensitivity of a camera is rated by ISO numbers.
[Auto] : The camera's sensitivity is
[ISO 80, 100, 200, 400, 800, 1600 ] :
You can increase the shutter speed while
the same amount of light is present, by
increasing the ISO sensitivity. However, the image may be saturated in
high luminance.
The higher the ISO value, the higher the camera’s sensitivity to
light and therefore the greater its capacity to take pictures in dark
conditions. However, the noise level in the image will increase as the
ISO value increases, making the image appear coarse.
automatically changed by variables
such as lighting value or subject
brightness.
ISO
Auto
<< 44 >>
Page 46
White balance
The white balance control allows you to adjust the colours to appear
more natural.
[Auto WB] : The camera
[Daylight] : For taking images outside.
[Cloudy] : For taking images under a cloudy and overcast
[Fluorescent_H] : For shooting under daylight fluorescent types of
[Fluorescent_L] : Shooting under white fluorescent lighting.
[Tungsten] : For shooting under tungsten (standard light bulb)
[Custom Set] : Allows the user to set the white balance
Different lighting conditions may cause a colour cast on your images.
automatically selects
the appropriate white
balance settings,
depending on the
prevailing lighting
conditions.
sky.
three-way fluorescent lighting.
lighting.
according to the shooting condition.
WHITE BALANCE
Auto WB
Using the Custom White Balance
White balance settings may vary slightly depending on the shooting
environment. You can select the most appropriate white balance
setting for a given shooting environment by setting up the custom white
balance.
1. Select the CUSTOM (
) menu of
the White Balance and place a sheet
of white paper in front of the camera so
that the LCD monitor shows only white.
2. MENU/OK button : selects previous
White paper
custom white balance.
Shutter button : saves new custom white balance.
- The custom white balance value will be applied, starting with the
next picture you take.
- The user configured white balance will be remain effective until it
is overwritten.
<< 45 >>
Page 47
Exposure compensation
This camera automatically adjusts the exposure according to the
ambient lighting conditions.
You can also select the exposure value by using the Fn button.
Movie Clip frame stabiliser
This function helps stabilize images captured during movie recording.
You can select this menu only in the MOVIE CLIP mode.
Compensating Exposure
1. Press the Fn button, and then use the UP
and DOWN buttons to select the exposure
compensation icon (
The exposure compensation menu bar will
appear as shown.
).
-2 -1 0 +1 +2
E V
2. Use the LEFT and RIGHT buttons to set
the desired exposure compensation factor.
3. Press the Fn button again. The value you set will be saved and the
Exposure Compensation setup mode will close.
If you change the exposure value, the exposure indicator (
be displayed on the bottom of the LCD monitor.
) will
A negative exposure compensation value reduces the exposure.
Note that a positive exposure compensation value increases the
exposure and the LCD monitor will appear white or you may not get
good pictures.
<< 46 >>
[Off] : Movie clip frame stabilizer function is
disabled.
[On] : This function helps stabilize images
captured during movie recording.
STABILIZER
Off
Page 48
Using the LCD monitor to adjust the camera settings
You can use the menu on the LCD monitor to set up recording functions.
The items indicated by are default settings.
How to use the menu
1. Turn on the camera and press the MENU button. A menu for each
camera mode appears.
2. Use the LEFT and RIGHT buttons to navigate through the menus.
Menu Sub menu Available mode Page
Soft+ Soft
Sharpness
Normal Vivid
p.48
Vivid+ -
Contrast
High Normal
Low -
p.48
Focus Area Center AF Multi AF p.48
Voice Memo Off On
Voice Record -
p.49
~p.50
RECORDING
NormalSharpness
Contrast
Normal
Focus Area
Center AF
OffVoice Memo
Voice Record
Exit Move
MENU
3. Use the UP and DOWN buttons to select a sub menu.
RECORDING
NormalSharpness
Contrast
Normal
Center AF
Focus Area
OffVoice Memo
Voice Record
Move Change
4. Select a sub menu, and then the value you set will be saved.
Press the MENU button and the menu will disappear.
Voice Mute Off On p.50
Children, Landscape,
Close Up, Text,Sunset,
Scene mode
Dawn, Backlight,
p.51
Firework,
Beach & Snow,
Menus are subject to change without prior notice.
Press the
LEFT or
RIGHT
button.
Press the
UP or
DOWN
button.
SOUND
Start Sound
Shutter Sound
AF Sound
Exit Move
MENU
RECORDING
Contrast
Focus Area
Voice Record
Move Change
MediumVolu me
Off
Sound 1
Sound 2Beep Sound
On
NormalSharpness
Normal
Center AF
OffVoice Memo
Press the
LEFT or
RIGHT
button.
Press the
UP or
DOWN
button.
SETUP1
Language
Date & Time
lmprint
LCD
AF Lamp
Exit Move
MENU
RECORDING
Contrast
Focus Area
Voice Record
Move Change
SeriesFile
ENGLISH
07/07/01
Off
Normal
On
NormalSharpness
Normal
Center AF
OffVoice Memo
<< 47 >>
Page 49
Sharpness
Focus Area
You can adjust the sharpness of the picture
you are about to take. You cannot check the
sharpness effect on the LCD monitor before
you take a picture, because this function is
applied only when the captured image is
stored on the memory.
[
]/ [
Soft+
] : The edges of the image are softened. This effect is
Soft
RECORDING
Contrast
Focus Area
Voice Record
Back Set
Soft+ Sharpness
Soft
Normal
VividVoice Memo
Vivid+
Vivid+
OK
suitable for editing images on your PC.
[Normal] : The edges of the image are sharp.
This is suitable for printing.
[Vivid]/ [Vivid+] : The edges of the image are emphasized.
The edges will appear sharp, but noise may occur in
the recorded image.
Contrast
You can set the difference between bright part of the image and dark
part of the image.
[High] : The image contrast is high.
[Normal] : The contrast is normal.
[Low] : The image contrast is more
subtle.
<< 48 >>
RECORDING
Sharpness
Contrast
Focus Area
Voice Record
Back Set
High
Normal
LowVoice Memo
OK
You can select your preferred Focus Area according to the shooting
conditions.
[Center AF] : The rectangular area in the
center of the LCD monitor will
be focused
[Multi AF] : This camera selects all of
available AF point from the 9
AF points.
[Center AF] [Multi AF]
RECORDING
Sharpness
Contrast
Focus Area
Voice Record
Back Set
Center AF
Multi AFVoice Memo
OK
When the camera focuses on the subject, the auto focus frame turns to
green. When the camera doesn't focus on the subject, the auto focus
frame turns to red.
Page 50
Voice Memo
You can add your voice-over to a stored still
image. (Max. 10 sec.)
- If the voice memo indicator is displayed on
the LCD monitor, the setting is completed.
- Press the shutter button and take a picture.
The picture is stored on the memory card.
- Voice memo will be recorded for ten
seconds from the moment the picture
is stored. In the middle of the sound
recording, pressing the shutter button will
stop the voice memo.
RECORDING
Sharpness
Contrast
Focus Area
Voice Memo
Voice Record
Back Set
Voice Recording
A voice can be recorded for as long as the available recording time
Off
On
OK
Stop
SH
(Max. 10 hour) allows.
Press the shutter button to record a voice.
- Press the shutter button once and voice
is recorded for as long as the available
recording time (max:10 hour) allows. The
recording time will be displayed on the
LCD monitor. Voice will still be recorded if
the shutter button is released.
- If you wish to stop recording, press the
shutter button again.
- File type : *.wav
RECORDING
Sharpness
Contrast
Focus Area
Voice Record
SH OK
Normal
Normal
Center AF
AF
OffVoice Memo
OK
Move Set
REC Exit
[Voice recording mode]
<< 49 >>
Page 51
Voice Recording
Pausing while recording a voice
Using this function, you can record your
favourite voice clips into a voice recording
file without having to create multiple voice
recording files.
1. Press the Pause button (
) to pause
recording.
2. Press the Pause button (
) again to
resume the recording.
3. If you wish to stop recording, press the shutter button again.
A distance of 40cm between you and the camera (microphone) is
the best distance to record sound.
If the camera power is turned off while the voice recording is
paused, the voice recording is cancelled.
Stop Pause
SH
[Voice recording mode]
Recording the movie clip without voice
You can record the movie without voice.
Select [On] of [Voice Mute] menu in the
Movie clip mode.
) icon will appear on the LCD monitor.
(
Press the Shutter button and a movie will
record for as long as the memory capacity
allows without voice.
RECORDING
Voice Mute
Back Set
Off
On
OK
<< 50 >>
Page 52
SCENE mode
Use the menu to easily configure optimal settings for a variety of
shooting situations.
Press the MENU button and select a desired
sub menu.
Refer to page 22 for more information.
RECORDING
Scene
Focus Area
Voice Memo
Voice Record
Back Set
[Mode Menu]
Children
Landscape
Close up
Text
Sunset
Dawn
OK
Sound menu
In this mode, you can set up sound settings. You can use the setup menu
in all camera modes, except Voice Recording mode.
The items indicated by are default settings.
Mode Menu Sub Menu
Off
Volume
Low
Medium
High
Off
Start Sound
Sound 1
Sound 2
Sound 3
Off
(SOUND)
Shutter Sound
Sound 1
Sound 2
Sound 3
Off
Beep Sound
Sound 1
Sound 2
Sound 3
Off
AF Sound
On
Available mode Page
p.52
p.52
p.52
p.52
p.52
<< 51 >>
Page 53
Sound
( )
Volume
You can select a volume of start up sound, shutter sound, beep sound and
AF sound.
- [Volume] sub menu : [Off], [Low], [Medium],
[High]
SOUND
Vol um e
Start Sound
Shutter Sound
AF Sound
Off
Low
Medium
HighBeep Sound
OK
Back Set
Start up sound
You can select the sound that is activated whenever the camera is turned on.
- Start up sound : [Off], [Sound 1], [Sound 2],
[Sound 3]
SOUND
Vol um e
Start Sound
Shutter Sound
Beep Sound
AF Sound
Back Set
Off
Sound 1
Sound 2
Sound 3
OK
Shutter sound
You can select the shutter sound.
Beep Sound
If you set sound to ON, various sounds will be activated for camera startup,
when buttons are pressed, so that you can be
aware of the camera operation status.
- [Beep Sound] sub menu : [Off], [Sound 1, 2, 3]
AF sound
If you set AF sound to ON, AF sound will be activated when a subject is
focused so that you can be aware of the camera
operation status.
- [AF sound] sub menu : [Off], [On]
SOUND
Vol um e
Start Sound
Shutter Sound
Beep Sound
AF Sound
Back Set
SOUND
Vol um e
Start Sound
Shutter Sound
Beep Sound
AF Sound
Back Set
Off
Sound 1
Sound 2
Sound 3
OK
Off
On
OK
- Shutter sound : [Off], [Sound 1], [Sound 2],
[Sound 3]
<< 52 >>
SOUND
Vol um e
Start Sound
Shutter Sound
Beep Sound
AF Sound
Back Set
Off
Sound 1
Sound 2
Sound 3
OK
Page 54
Setup menu
In this mode, you can set up basic settings. You can use the setup menu in all
camera modes, except Voice Recording mode.
The items indicated by are default settings.
Menu tab
Main menu
File
Sub menu
Reset p.54
Series
Page
Language p.54
(Setup
menu 1)
Date & Time
–
07/07/01 13:00
yy/mm/dd Off
–
p.54
dd/mm/yy mm/dd/yy
Imprint
LCD
Off Date
Date&Time -
Auto Dark
Normal Bright
p.55
p.55
AF Lamp Off On p.55
Start Image
Off Logo
User Image -
p.55
Menu tab
Main menu Sub menu Page
Quick View Off 0.5, 1, 3 sec p.56
Power Off Off 1, 3, 5, 10 min p.56
(Setup
menu 2)
LCD Save Off On p.56
Video Out NTSC PAL p.57
Format No Yes p.58
Reset No Yes p.58
Menus are subject to change without prior notice.
<< 53 >>
Page 55
Setup menu 1
( )
File name
This function allows the user to select the file naming format.
[Reset] : After using the reset function,
[Series] : New files are named using
- The first stored folder name is 100SSCAM, and the first file name of
- File names are assigned sequentially from SL380001
- The folder number is assigned sequentially from 100 to 999 as
- Maximum numbers of files in a folder are 9999.
- The files used with the memory card conform to the DCF (Design rule
<< 54 >>
the next file name will be set
from 0001 even after formatting,
deleting all or inserting a new
memory card.
numbers that follow the previous
SETUP 1
Language
Date&Time
Imprint
LCD
AF Lamp
Back Set
SeriesFile
Reset
OK
sequence, even when a new memory card is used, or after
formatting, or after deleting all pictures.
L830 is SL380001. (The first file name of L730 is SL370001.)
SL380002 ~ SL389999.
follows: 100SSCAM
101SSCAM ~ 999SSCAM.
for Camera File systems) format. If you change the image file name,
the image may not play back.
LANGUAGE
There is a choice of languages that can be displayed on the LCD monitor.
Even if the battery is removed and inserted again, the language setting will
be preserved.
- LANGUAGE sub menu
: English, Korean, French, German,
Spanish, Italian, S.Chinese, T.Chinese,
Japanese, Russian, Portuguese, Dutch,
Danish, Swedish, Finnish, Thai, Bahasa
(Malay / Indonesian), Arabic, Czech,
Polish, Hungarian and Turkish.
SETUP 1
File
Language
Date&Time
Imprint
LCD
AF Lamp
Back Set
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
OK
Setting up the Date / Time / Date type
You can change the date and time that will be displayed on the captured
images and set up the date type.
SETUP 1
- Setting Date/ Time & Selecting Date Format
RIGHT button : Selects the year/ month/day/
hour/ minute date type.
LEFT button : Moves the cursor to the
File
Language
Date&Time
Imprint
LCD
AF Lamp
Back Set
[Date&Time] main menu
if the cursor is at the first item of the date and time
setup. In all other cases, the cursor will be shifted to
the left of its current position.
UP and DOWN buttons : Changes the setting value
- Date type : [yy/mm/dd], [Off], [dd/mm/yy], [mm/dd/yy]
07/07/01
13:00
yy/mm/dd
OK
Page 56
Setup menu 1
( )
Imprinting the recording date
There is an option to include DATE / TIME on still images.
- Sub menus
[Off] : The DATE & TIME will not be
imprinted on the image file.
[Date] : Only the DATE will be
imprinted on the image file.
SETUP 1
File
Language
Date & Time
Imprint
LCD
AF Lamp
Back Set
Off
Date
Date&Time
OK
[Date&Time] : The DATE & TIME will be imprinted on the image file.
The Date & Time are imprinted at the bottom right side of the still image.
The imprint function is applied only to still images except for the images
taken in photo frame effect mode.
Depending on the manufacturer and print mode, the date printed on an
image may not be printed correctly.
LCD brightness
You can adjust the LCD brightness.
- Sub menus : [Auto], [Dark], [Normal],
[Bright]
SETUP 1
File
Language
Date & Time
Imprint
LCD
AF Lamp
Back Set
Auto
Dark
Normal
Bright
OK
Auto Focus lamp
You can turn on and off the Auto Focus lamp.
- Sub menus
[Off] : The AF lamp will not light up in low
light conditions.
[On] : The AF lamp will light up in low light
conditions.
SETUP 1
File
Language
Date & Time
Imprint
LCD
AF Lamp
Back Set
Off
On
OK
Start up image
You can select the image that is first displayed on the LCD monitor whenever
the camera is turned on.
- Sub menus : [Off], [LOGO], [User Image]
- Use a saved image for the start-up image
with the [Start Image] in the [RESIZE] menu
in the play mode.
- The start-up image will not be deleted by
[Delete] or [Format] menu.
- The User images will be deleted by [Reset]
menu.
SETUP 1
Language
Date & Time
Imprint
LCD
AF Lamp
Start Image
Back Back
Off
OK
<< 55 >>
Page 57
Setup menu 2
( )
Quick view
If you enable Quick View before capturing an image, you can view the image
you just captured on the LCD monitor for the duration set in the [Quick View]
setup. Quick view is possible only with still images.
- Sub menus
[Off] : The quick view function
can’t be activated.
[0.5, 1, 3 sec] : The captured image is
briefly displayed during the
selected time.
<< 56 >>
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
2
Off
0.5 sec
1 sec
3 sec
OK
Back Set
Auto power off
This function switches the camera off after a set amount of time in order to
prevent unnecessary battery drainage.
- Sub menus
[Off] : The power off function will
not operate.
[1, 3, 5, 10 min] : The power will turn off
automatically if not used for
the period of time specified.
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
Back
2
Off
1 min
3 min
5 min
10 min
OK
Set
- After replacing the battery, the power off
setting will be preserved.
- Note that the automatic power off function will not operate if the
camera is in the PC / Printer mode, slide show, playing back a voice
recording and playing back a movie clip.
LCD save
If you set the [LCD save] to On and the camera isn't operated during the
specified time, the LCD monitor will be turned off automatically.
- Sub menus
[Off] : The LCD monitor will not be turned off.
[On] : If the camera isn't operated during the
specified time (about 30 SEC.), the
camera power will be idle (Camera
status lamp:Blinking) automatically.
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
- You can’t set the [LCD save] menu of Playback Mode.
Off
On
OK
Back Set
2
Page 58
Setup menu 2
( )
Selecting Video out type
The Movie output signal from the camera can be NTSC or PAL.
Your choice of output will be governed by the type of device (monitor or TV,
etc.) to which the camera is connected. PAL mode can support only BDGHI.
Connecting to an external monitor
When the camera is connected to an
external monitor, the image and menus
on the LCD monitor will be visible on the
external monitor and the LCD monitor of the
camera.
Yellow - Video
White - sound
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
2
NTSC
PAL
OK
Back Set
- NTSC : U.S.A, Canada, Japan, South Korea, Taiwan, Mexico.
- PAL : Australia, Austria, Belgium, China, Denmark, Finland,
Germany, U.K., Holland, Italy, Kuwait, Malaysia, New
Zealand, Singapore, Spain, Sweden, Switzerland, Thailand,
Norway.
- When using a TV as an external monitor, you will need to select the
external or AV channel of the TV.
- There will be a digital noise on the external monitor, but it is not a
malfunction.
- If the image is not in the centre of the screen, use the TV controls to
centre it.
- When the camera is connected to an external monitor, some parts of
the image may not be displayed.
<< 57 >>
Page 59
Setup menu 2 ( )
Formatting a memory
This is used for formatting the memory. If you run [Format] on the memory, all
images, including the protected images, will be deleted. Be sure to download
important images to your PC before formatting the memory.
- Sub menus
[No] : The memory will not be formatted.
[Yes] : A window for confirming the
selection displays. Select the [Yes]
menu. A [Processing!] message
appears and the memory will be
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
formatted. If you run FORMAT in
Play mode, a [No Image!] message
will appear.
Be sure to run [Format] on the following types of memory card.
- A new memory card, or an unformatted memory card
- A memory card that has a file this camera can't recognise or one that
has been taken from another camera.
- Always format the memory card using this camera. If you insert a
memory card that has been formatted using other cameras, memory
card readers, or PCs, you will get a [Card Error!] message.
<< 58 >>
2
No
Yes
OK
Back Set
Initialisation
All camera menu and function settings will be restored to their default values.
However, values for DATE / TIME, LANGUAGE, and VIDEO OUT will not be
changed.
- Sub menus
[No] : Settings will not be restored to their
defaults.
[Yes] : A window to confirm the selection will
be displayed. Select the [Yes] menu
and all settings will be restored to
their defaults.
SETUP 2
Quick View
Power Off
LCD Save
Video Out
Format
Reset
No
Yes
OK
Back Set
2
Page 60
Starting play mode
Turn the camera on and select Play mode by pressing the play mode button
( ). The camera can now play back the images stored in the memory.
If the memory card is inserted in the camera, all the camera functions apply
only to the memory card.
If the memory card is not inserted in the camera, all the camera functions
apply only to the internal memory.
Playing back a still image
1. Select the PLAY mode by pressing
the play mode button ( ).
2. The last image stored on the memory
is displayed on the LCD monitor.
3. Select an image that you want to view
by pressing the Left/ Right button.
Press and hold the Left or Right
button to play back the images quickly.
Playing back a movie clip
1. Select the recorded movie clip that you
want to play back by using the Left/Right
button.
2. Press the play & pause button ( ) to
play back a movie clip file.
- To pause a movie clip file while playing it
back, press the play & pause button
( ) again.
- Pressing the play & pause button
( ) again will cause the movie clip
file to restart.
- To rewind the movie clip while it is
playing, press the Left button. To fast
forward the movie clip, press the Right
button.
- To stop playback of the movie clip, press the play & pause button
( ), and then press the Left or Right button.
/
E
Play Capture
<< 59 >>
Page 61
Starting play mode
Movie clip capture function
You can capture still images from the movie clip.
How to capture the movie clip
1. Press the Play / Pause button ( )
while playing the movie clip. Then press
the E button.
2. The paused movie clip is saved in a new
file name.
The captured movie clip file is the same
size as the original movie clip (800x592,
640x480, 320x240).
When you press the E button at the
beginning of the movie clip, the first frame
of the movie clip will be saved as a still
image.
<< 60 >>
T E
Trim Capture
[Paused]
[Press the E button]
On camera movie trimming
You can extract desired frames of movie clip during the movie clip play back.
If the running time is under 10 seconds, the movie clip can’t be trimmed.
1. Press the Pause button ( ) at the point
of the movie clip where you want to start
extracting.
2. Press the T button.
3. Press the Play & Pause button ( )
and the extracted range will be displayed
on the status bar.
4. Press the Play & Pause button ( )
once more at the point where you wish the
extracted file to stop.
5. Press the T button and a confirmation
window will be displayed.
6. Select a desired sub menu by pressing the
Up/Down button and press the OK button.
[No] : The movie trimming will be
cancelled.
[Yes] : The extracted frames are saved
as a new file name.
If you don't specify the ending point of the movie clip, the trimming
confirmation window will be displayed at the point of the last
frame.
T E
Trim Capture
T E
Trim Capture
Trimming?
No
Yes
OK
Confirm
Page 62
Starting play mode
Playing back a recorded voice
1. Select the recorded voice that you want to
play back by using the Left/Right button.
2. Press the play & pause button ( ) to
play back a recorded voice file.
- To pause a recorded voice file, while
playing it back, press the play & pause
button ( ) again.
- To resume playback of the voice file, press the play & pause button
- To rewind the voice file while it is playing, press the Left
(REW)button.
To fast forward the voice file, press the Right (FF)button.
- To stop playback of the voice memo, press the play & pause button
and then press the MENU/OK button.
Play
Playing back a voice memo
1. Select a still image that has the voice
memo.
2. Press the play & pause button (
play back the voice memo.
- To pause the voice memo, while playing
it back, press the play & pause button
) again.
(
- To resume playback of the voice memo,
press the Down button.
- To stop playback of the voice memo,
press the MENU / OK button.
) to
REW
Play
Pause
FF
<< 61 >>
Page 63
LCD monitor Indicator
Using the camera buttons to set the camera
The LCD monitor displays shooting information about the displayed image. In Play mode, you can use the buttons on the camera to conveniently set up
the Play mode functions.
Thumbnail ( ) / Enlargement ( ) button
You can view multiple pictures, enlarge a selected picture, and crop and save
a selected area of an image.
Thumbnail display
1. While an image is displayed on full screen,
press the thumbnail button.
2. The thumbnail display will highlight the
No. Description Icon Page
1 Battery
2 Folder name & File name 100-0010 p.54
3 Memory card indicator
4 Playback mode
5 Voice Memo
6 Protect
7 DPOF
8 Recording date 2007/07/01 p.55
9 Image size 3264x2448 ~ 256X192 p.42
10 Flash On / Off p.29
11 Shutter speed 8 ~ 1/1,500 p.21
12 Aperture value F3.0 ~ F14.1 p.21
13 ISO 80 ~ 1600 p.44
<< 62 >>
p.15
p.59
p.80
p.80
p.81
image that had been showing at the time the
thumbnail mode was selected.
3. Press the 5 function button to move to a
desired image.
4. To view an image separately, press the enlargement button.
Pressing the thumbnail
button ( )
Pressing the enlargement
button ( )
Highlighted image
[Highlighted image]
[ Thumbnail display mode ]
Page 64
Thumbnail
Image enlargement
( )
/ Enlargement
( )
1. Select an image that you want to enlarge
and press the enlargement button.
2. Different parts of the image can be viewed
by pressing the 5 function button.
3. Pressing the thumbnail button will zoom
back to the original full sized image.
- You can tell whether the image displayed
is an enlarged view by checking the
image enlargement indicator shown
at the top left of the LCD monitor. (If
the image is not an enlarged view, the
indicator will not be displayed.) You can also check the area of
enlargement.
- Movie clips and WAV files can’t be enlarged.
- If an image is enlarged, a loss of quality may occur.
button
The maximum enlargement rate in proportion to the image size
- L830
Image size
Maximum
enlargement
X12.8 X12.4 X12.8 X10.1 X8.0 X4.0
- L730
Image size
Maximum
enlargement
Trimming : You can extract part of the image that you want and save it
X12.0 X12.0 X12.0 X10.1 X8.0 X4.0
separately.
1. Select an image that you want to enlarge
and press the enlargement button.
Press the MENU/OK button and a message
will be displayed.
2. Select a desired sub menu by pressing the
Up / Down button and press the OK button.
Trimming?
No
Yes
Confirm
OK
- [No] : The trimming menu will disappear.
- [Yes] : The trimmed image will be saved as a new file name, and
appear on the LCD monitor.
If there is not enough memory space to save the trimmed image, the
image can’t be trimmed.
<< 63 >>
Page 65
( )
Info
/ Up button Play & Pause
When the menu is displayed on the LCD monitor, the UP button operates as a
direction button.
When the menu is not displayed on the LCD monitor, pressing the Info button
will display image information on the LCD monitor.
Info ( ) button
Info ( ) buttonInfo ( ) button
(
) / Down button
In Play mode, the play & pause/ down button works as follows:
- If the menu is displayed
Press the DOWN button to move from the main menu to a sub menu,
or to move down the sub menu cursor.
- If a still image with a voice memo, a voice file, or a movie clip is playing
·In Stop mode : Plays a still image with a voice memo, a voice
file, or a movie clip.
·During playback : Temporarily stops playback.
·In Pause mode : Resumes playback
<< 64 >>
Play Stop
[ Voice recording is stopped ]
Pause
OK
Stop
[ Voice recording is playing ] [ Voice recording is paused ]
Play
OK
Page 66
Left / Right / Menu / OK button Delete
Prev
Next
( )
button
LEFT / RIGHT / MENU / OK buttons activate the following.
- LEFT button : While the menu is showing, the LEFT button
operates as a direction button. While the menu is
not showing, press the LEFT button to select the
previous image.
- RIGHT button : While the menu is showing, the RIGHT button
operates as a direction button. While the menu is not
showing, press the RIGHT button to select the next
image.
- MENU button : When you press the MENU button, the play
mode menu will be displayed on the LCD monitor.
Pressing it again will return the LCD to the initial
display.
- OK button : When the menu is displayed on the LCD monitor,
the OK button is used for confirming data that is
changed by using the 5 function button.
Printer ( ) button
When the camera is connected to a PictBridge printer, you can print images by
pressing the Printer button.
Print Menu
OK
This deletes images stored on the memory card.
1. Select an image that you want to delete by pressing the Left / Right
button and press the DELETE ( ) button.
Delete ?
No
Yes
T
Select Confirm
OK
[Single Image] [Thumbnail Image]
Delete ?
No
Yes
Confirm
OK
2. To delete images, press the T button.
- Left/Right button : Selects images
- T button : checks for deletion
- OK button : confirm the selection
Prev
Next
T
OK
Select Delete
3. Select the submenu values by pressing the Up / Down button and
then press the OK button.
- If [No] is selected : cancels "Delete Image".
- If [Yes] is selected : deletes the selected images.
<< 65 >>
Page 67
E (Effect) button : Resize
Change the resolution (size) of pictures taken. Select [Start image] to save an
image to be the start-up image.
1. Press the play mode button and press the
E button.
2. Press the Left / Right button and select
RESIZE
the [RESIZE] ( ) menu tab.
3. Select a desired sub menu by pressing
the Up / Down button and press the OK
button.
Image Resize Types
- L830
Move Exit
( : Selectable)
E
5M 3M 1M
5M 3M 1M
5M 2M 1M
<< 66 >>
- L730
5M 3M 1M
5M 3M 1M
- A large sized image can be resized to a smaller sized image, but not
vice versa.
- Only JPEG images can be resized. Movie clip (AVI), Voice recording
(WAV) files can’t be resized.
- You can change the resolution of only those files compressed in the
JPEG 4:2:2 format.
- The resized image will have a new file name. The [Start Image] image
is stored not on the memory card but on the internal memory.
- If a new user image is saved, one of the two user images will be
deleted in order.
- If the memory capacity is insufficient to store the resized image, a
[Memory Full!] message will appear on the LCD monitor and the
resized image can't be stored.
Page 68
E (Effect) button : Rotating an image
E (Effect) button : Colour
You can rotate the stored images by various degrees.
1. Press the play mode button and press the
E button.
ROTATE
2. Press the LEFT / RIGHT button and select
the [ROTATE] (
3. Select a desired sub menu by pressing the
UP / DOWN button.
Right 90°
OK
Set Back
[ : Right 90˚]
: Rotate picture in a
clock-wise direction
) menu tab.
Left 90°
E
Horizontal
OK
[ : Horizontal]
: Rotate picture horizontally
OK
[ : Left 90˚]
:
Rotate picture in a counterclock-wise direction
E
Set Back
E
Set Back
Vertical
Move Exit
180°
OK
Set Back
[ : 180˚]
: Rotate picture 180 degrees
OK
E
Set Back
[ : Vertical]
: Rotate picture vertically
E
E
If you display the rotated image on the LCD monitor, empty spaces
may appear to the left and right of the image.
It is possible to add colour effects to your images by using this button.
1. Press the play mode button and press
the E button.
COLOR
2. Select ( ) menu tab by pressing the
Left / Right button.
Move Exit
E
3. Select a desired sub menu by pressing the Up / Down button and
press the OK button.
: Captured images will be stored in black and white.
: Captured images will be stored in a sepia tone
(a gradient of yellowish brown colours).
: Captured images will be stored in a red tone.
: Captured images will be stored in a green tone.
: Captured images will be stored in a blue tone.
: Save the image in negative mode.
: Captured images will be stored in set RGB tone.
4. The changed image is saved as a new file name.
<< 67 >>
Page 69
E (Effect) button : Colour E (Effect) button : Special Colour
Custom colour
You can change the R (Red), G (Green) and
B (Blue) values of the image.
- OK button : Select / setup the
Custom Colour
- Up / Down button : Selects R, G, B
- Left / Right button : Change the values
Custom Color
Move Set
Custom Color
Move Set
OK
OK
1. Press the play mode button and press the E button.
2. Select ( ) menu tab by pressing the Left/Right button.
Colour Filter
With this menu, you can change the colour information of the image
(excluding Red, Blue, Green and Yellow) to Black and White.
1. Select ( ) by pressing the Up/Down button.
SPECIAL COLOR
Color Filter
<< 68 >>
E
Move Exit
OK
Set Back
E
2. Press the OK button and the image is saved as a new file name.
Page 70
E (Effect) button : Special Colour
Colour mask
With this menu, you can select a part you want to highlight. The rest of the image will be in black and white.
SPECIAL COLOR
Move Exit
Color Mask
Select ( ) the selected area will be
E
shown.
OK E
Set Back
Press the OK button and you can set
the size and location of the part to be
highlighted.
OK
Move Size
T/W
Set
W / T button : Changing size
of selected part
Set
OK
Move Size
T/W
Press the OK button twice and the colour
masked image will be saved as a new file
name.
Up/Down/Left/Right button:
Changing the location
[Final image]
Set
OK
Move Size
T/W
<< 69 >>
Page 71
E (Effect) button : Image editing
1. Press the play back button and press the E button.
2. Select ( ) menu tab by pressing the Left/Right button.
Red eye Removal
Red eye effect can be removed from the captured image.
1. Select ( ) by pressing the Up/Down
button and press the OK button.
2. The image is saved as a new file name.
Brightness control
You can change the brightness of the image.
1. Select ( ) by pressing the Up/Down
button and a bar for selecting the
brightness will be displayed.
2. Change the brightness by pressing the
Left/Right button.
3. Press the OK button and the image will
be saved as a new file name.
<< 70 >>
Red Eye Fix
OK E
Set Back
Brightness
Move Set
Contrast control
You can change the contrast of the image.
1. Select ( ) by pressing the Up/Down
button and a bar for selecting the contrast
Contrast
will be displayed.
2. Change the contrast by pressing the Left/
Right button.
3. Press the OK button and the image will
Move Set
OK
be saved as a new file name.
Saturation control
You can change the saturation of the image.
1. Select (
button and a bar for selecting the
) by pressing the Up/Down
Saturation
saturation will be displayed.
2. Change the saturation by pressing the
Left/Right button.
3. Press the OK button and the image will
Move Set
OK
be saved as a new file name.
Noise Effect
OK
You can add noise to an image to add a more classic feel to your photo.
1. Select ( ) by pressing the Up/Down
button and press the OK button.
Add Noise
2. The [Proccessing!] message be displayed
and the image is saved as a new file name.
Set Back
OK E
Page 72
E (Effect) button : FUN
Cartoon
You can add a text box to the image to make the image cartoon like.
The cartoon image is saved as 1M image size.
FUN
Move Exit
Select Cartoon ( )
E
E
Cartoon
Frame Set
Select a desired position by
pressing the Up/Down/Left/
Select a desired frame by
pressing the Left/Right button
Right button and press the OK
button.
and then press the OK button
E
OK
Move Set
E
OK
Press the OK button and
the image is saved. Press
the OK button again to
E
OK E
Select Back
open a new image to save.
Select an image by pressing the Up/Down/Left/Right
button and press the OK button.
Select the third image with the same procedure.
Select the position of image and
text box with the same procedure.
E
OK
Move Set
E
OK Fn
Search Delete
Change the location of the
text box by pressing the
Left/Right button.
E
OK Fn
Save Delete
OK
E
Move Set
Press the OK button and the file is
saved as a new file name.
<< 71 >>
Page 73
E (Effect) button : FUN
Before saving the cartoon image, you can change the selected image.
1. Pressing the Fn button deletes the images in order.
2. Press the OK button and you can select images.
Preset focus frames
You can make the subject stand out from its surroundings. The subject will be
sharp and in focus while making the rest out of focus.
Pressing the Fn
E
OK Fn
Save Delete
button
E
OK Fn
Search Delete
3. After selecting desired images, press the OK button to save the
image as a new file name.
<< 72 >>
FUN
Move Exit
E
E
High Light
Range Set
E
OK
Select a desired frame by pressing the Left/Right button and press the
OK button.
High Light
OK
Range Set
[Range 1] [Range 2] [Range 3] [Range 4]
High Light
E
OK
Range Set
High Light
E
OK
Range Set
High Light
E
OK
E
Range Sets
Page 74
E (Effect) button : FUN
Moving and changing the focus frame
You can change the focus frame after selecting a Range menu.
1. Select a focus frame by pressing the Left/Right button and press the
OK button.
2. Move the location of the frame by pressing the Up/Down/Left/Right
button.
3. Press the OK button and the file is saved as a new file name.
High Light
Pressing the
OK button
Composite image
You can combine 2 - 4 different shots in a still image.
FUN
Move Exit
E
E
Composite
E
OK
Compose Set
E
OK
Range Set
Pressing the
OK button
E
OK
Move Save
[The frame is activated]
Pressing Up/
Down/Left/Right
button
E
OK
Move Save
[After changing the frame
position]
Press the OK button.
(You can select 2-4 composite images)
E
OK
Move Set
If you press the Shutter and Play mode button, a capture mode is
executed.
The composite image is saved as 1024 X 768 image size.
<< 73 >>
Page 75
E (Effect) button : FUN
Selecting 2 composite shots
Before selecting the last composite image, you can change a part of
composite image.
E
OK
Move Set
E
OK E
Select Back
[Selecting the second image]
Save
OK
E
Fn
Move Delete
<< 74 >>
Pressing the
Up/Down/Left/Right button
Pressing the
OK button
Select an image by pressing the 5
function button and press the OK button
Change the location of second image by pressing the
Up/Down/Left/Right button
save the image.
E
OK
Move Set
[Changing the position]
Pressing the
OK button
E
OK Fn
Search Delete
and press the OK button to
1. During the composite image editing, press the Fn button.
2. A previous image will be deleted. Press the OK button and you can
select a new image. After selecting an image, press the Fn button
again and the image will be deleted again.
Pressing the Fn button
E
OK Fn
Search Delete
[Before selecting the 3rd image]
Search Delete
[Moving backward to the 2nd image]
OK Fn
E
3. Press the OK button and you can select an image again.
Page 76
E (Effect) button : FUN
Photo Frame
You can add 9 types of frame-like borders to a still image you want to capture.
Date & Time information will not be printed on the stored image taken with
Photo Frame menu.
FUN
Move Exit
E
E
Photo Frame
Frame Set
E
OK
Select a desired sub menu by pressing the Left/Right button.
- Press the E button and the frame will be canceled.
Press the OK button and the image is
saved.
L730 only : The size of Photo frame image is fixed to 1M.
<< 75 >>
Page 77
E (Effect) button : FUN
Sticker
You can add various stickers to the image.
FUN
Select ( )
E
Move Exit
Select a location of sticker
by pressing the
Save
OK
Move
AddFn
※ You can add additional stickers by pressing
the Fn button.
Press the OK button to store the image.
Left/Right
Up/Down/
button
Sticker
OK
Sticker Set
Select a desired
sticker by pressing the
Left/Right
button and
press the OK button
OK
Move
Save
Setting up the play back function using the LCD monitor
PLAY mode functions can be changed by using the LCD monitor.
In the PLAY mode, pressing the MENU button displays the menu on the LCD
monitor. The menus you can set up in Play mode are as follows. To capture an
image after setting up the play menu, press the PLAY mode button or shutter
button.
Menu Tab Main Menu Sub Menu Secondary Menu Page
Show
Images
SLIDE
SHOW
(
Effect
)
Interval 1, 3, 5, 10 sec -
Music Off / Music 1, 2, 3 -
Voice Memo
AddFn
Protect
PLAY
BACK
(
Delete
)
DPOF
Copy To Card
Play / Repeat Play
- p.78
All -
Select -
Off Basic Classic
Memories Rhythmic Delight
Off On -
Select
All
Select
All
Standard
- p.80
- p.81
Select / All / Cancel
Index No / Yes
Size
No
Ye s
Select / All / Cancel
-
-
p.78Date -
p.79
p.80
p.81
~p.83
p.83
<< 76 >>
Page 78
Setting up the play back function using the LCD monitor
This menu is available while the camera is connected to a PictBridge
supporting printer (direct connection to the camera, sold separately) with a
USB cable.
Menu Tab Main Menu Sub Menu Secondary Menu Page
Images
Size
Layout
One Pic -
All Pics -
Auto -
PostCard -
Card -
4X6 -
L-
2L -
Letter -
A4 A3 -
Auto -
Full -
12489-
16 -
Index -
p.85
p.86
Menu Tab Main Menu Sub Menu Secondary Menu Page
Ty p e
Quality
Date Print
File Name
Reset
Menus are subject to change without prior notice.
Auto Plain -
Photo -
FastPhoto -
Auto Draft -
Normal -
Fine -
Auto -
Off On -
Auto -
Off On -
No -
Ye s -
p.86
<< 77 >>
Page 79
Starting the slide show
( )
Images can be displayed continuously at pre-set intervals.
You can view the slide show by connecting the camera to an external monitor.
1. Press the play mode button and press the menu button.
2. Press the LEFT / RIGHT button and select the [SLIDE SHOW] menu
tab.
Start the slide show
The slide show can start only in the [Show] menu.
1. Use the Up / Down buttons to select the
[Show] menu and press the Right button.
2. Select a desired sub menu by pressing the
Up / Down button.
[Play] : The slide show is closed
after one cycle.
[Repeat Play] : The slide show is repeated until cancelled.
3. Press the OK button and the slideshow will be started.
- To pause the slide shown while playing it back, press the play &
pause( ) button again.
- Pressing the play & pause( ) button again will cause the
slide show restart.
- To stop playback of the slide show, press the play & pause
( ) button, and then press the OK / Menu button.
SLIDE SHOW
Show
Images
Effect
lnterval
Music
Back Set
Play
Repeat Play
OK
Selecting Images
You can select image to view
1. Use the Up / Down buttons to select the
[Image] menu and press the Right button.
2. Select a desired sub menu by pressing the
Up / Down button.
[All] : All images saved in the Memory
are played back.
[Date] : Images taken in a specified date
are played back.
[Select] : You can select desired images to play back
Press the OK button and thumbnail images will appear.
Search desired images by using the Up/Down buttons.
You can choose desired images by pressing the T button.
3. Press the OK button and the settings are saved.
4. Select [Play] or [Repeat Play] in the [Show] menu to start the slide
show.
SLIDE SHOW
Show
Effect
Interval
Music
Back Set
All
Date
Select
OK
<< 78 >>
Page 80
Starting the slide show
( )
Configure slide show effects
Unique screen effects can be used for the slide show.
1. Select the [Effect] sub menu by pressing
the UP / DOWN button and press the
RIGHT button.
2. Use the Up / Down button to select the
type of effect.
[Off] : No effect.
[Basic] : Fade In/Out effect is added and the Images are
displayed at set interval.
[Classic] : You can add noise to the image to give a classic feel.
[Memories] : Scratches are added to give an old movie effect.
[Rhythmic] : Images are displayed with a special effect.
[Delight] : Images are displayed with a special effect.
3. Press the OK button to confirm the setting.
SLIDE SHOW
Show
Effect
Interval
Music
Back Set
Off
Basic
Classic
Memories
Rhythmic
Delight
OK
Setting play interval
Set the slide show play interval.
1. Select the [Interval] sub menu by pressing
the UP / DOWN button and press the
RIGHT button.
2. Use the Up / Down buttons to select the
desired interval.
Press the OK button to save the configuration.
3.
The loading time depends on the image size and quality.
While the slide show is playing, only the first frame of a MOVIE file
is displayed.
While the slide show is playing, the voice recording file will not be
displayed.
The interval menu functions in the [Off], [Basic] and [Classic] menu only.
Setting Background Music
Set the slide show music.
1. Select the [Music] sub menu by pressing
the UP / DOWN button and press the
RIGHT button.
2. Use the Up / Down buttons to select the
desired Music.
3. Press the OK button to save the configuration.
SLIDE SHOW
Show
Effect
Interval
Music
Back Set
SLIDE SHOW
Show
Effect
Interval
Music
Back Set
1 sec
3 sec
5 sec
10 sec
OK
Off
Music 1
Music 2
Music 3
OK
<< 79 >>
Page 81
Playback
Start : Shutter
( )
Voice memo
You can add your voice to a stored still image.
PLAYBACK
OffVoice Memo
Protect
Delete
DPOF
Copy to Card
- Press the shutter button to take a picture. The images are saved on
- To stop the recording, press the shutter button.
<< 80 >>
On
OK
Back Set
Start : Shutter
SH
[Ready for recording] [Voice is recording][Voice memo menu]
the memory. After saving the image, the voice will record for
10 seconds.
Stop
정지
00:00:05
Protecting images
This is used to protect specific shots from being accidentally erased (Lock).
It also unprotects images that have been previously protected (Unlock).
1. Press the Up / Down button and select the
[Protect] menu tab. And then press the Right
button.
2. Select a desired sub menu by pressing
the UP / DOWN button and press the OK
button.
[Select ] : Selection window for an image
to be protected / released is
displayed.
- Up / Down / Left / Right : Select an image
- Zoom W / T Button : Protect / release the
- OK button : Your changes will be saved
and the menu will disappear.
[All] : Protect / release all saved images
- If you protect an image, the protect icon
will be displayed on the LCD monitor.
(An unprotected image has no indicator)
- An image in LOCK mode will be protected
from the delete function or [Delete]
functions, but will NOT be protected from
the [Format] function.
PLAYBACK
Viuce Memo
Protect
Delete
DPOF
Copy To Card
Back Set
T/W OK
Unlock Set
Confirm
Select
All
OK
Protect All?
Unlock
Lock
OK
Page 82
Playback
( )
Deleting images
This deletes images stored on the memory. If the memory card is inserted,
images on the memory card are deleted.
Otherwise, images in the internal memory are deleted.
1.
Press the Up / Down button and select the [Delete]
menu tab. And then press the Right button.
2.
Select a desired sub menu by pressing the UP /
DOWN button and press the OK button.
[Select] : Selection window for an image to delete is
displayed.
- Up/ Down/ Left/ Right : Select an image
- Zoom T Button : Select the image for deletion.
( mark)
- OK Button : Press the OK button to display the
confirmation message. Select the
[Yes] menu and press the OK button to
delete marked images.
[All] : Displays confirmation window. Select the [Yes]
menu and press the OK button to delete all
unprotected images. If there aren’t protected
images, all the images are deleted and a [No
Image!] message will appear.
3. After deletion, the screen will be changed to the play mode scree
Of all the files stored in the memory card, the unprotected files in the DCIM subfolder
will be deleted. Remember that this will permanently delete unprotected images.
Important shots should be stored on a computer before deletion takes place. The
startup image is stored in the camera's internal memory (i.e., not on the memory card)
and it will not be deleted even if you delete all files on the memory card.
PLAYBACK
Voice Memo
Protect
Delete
DPOF
Copy To Card
Select
All
Confirm
OK
Back Set
T
Select
Delete All?
No
Yes
OK
n.
OK
Delete
DPOF
DPOF(Digital Print Order Format) allows you to embed printing
information on your memory card’s MISC folder. Select the pictures to
be printed and how many prints to make.
The DPOF indicator will display on the LCD monitor when an image
that has DPOF information plays back. Images can then be printed on
DPOF printers, or at an increasing number of photo labs.
This function is not available for Movie clips and Voice recording files.
When the wide angle image is printed as a wide angle print, 8% of the
left and right side of the image may not be printed. Check that your
printer can support the wide angle image when you print the image.
When you print the image at a photo lab, request that the image is
printed as a wide angle image. (Some photo labs may not support the
wide angle size print.)
<< 81 >>
Page 83
Playback
WW
00 Images
T
Standard
( )
This function allows you to embed printing quantity information on a stored
image.
1. Press the Up / Down button and select
the [DPOF] menu tab. And then press the
Right button.
PLAYBACK
Standard
Index
Size
Select
All
Cancel
2. Press the Right button again and
[Standard] sub menu will display.
3. Select a desired sub menu by pressing the
Back Set
OK
Up / Down button and press the OK button.
[Select] : Selection window for an image to
print is displayed.
-
Up / Down / Left / Right : Select an image to
print.
-
Zoom W / T Button : Select the number of
W 00 Images
Set
OK
T
prints.
[All] : Configure number of prints for all
pictures except movie and voice files.
- W / T button : Select a number of prints
[Cancel] : Cancel the print setup.
00 Images
T
Set
OK
4. Press the OK button to confirm the setting.
If an image carries DPOF instructions, the DPOF indicator ( )
will show.
Index
Images (except for movie clips and voice file) are printed as index type.
1. Press the Up / Down button and select the
[DPOF] menu tab. And then press the Right
button.
2. Press the Right button again and [Index] sub
menu will display.
3. Select a desired sub menu by pressing the
PLAYBACK
Standard
Index
Size
Back Set
No
Yes
OK
UP / DOWN button.
If [No] is selected : Cancel the index print setting.
If [Yes] is selected : The image will be printed in index format.
4. Press the OK button to confirm the setting.
<< 82 >>
Page 84
Playback
WW
Cencel
T
Print size
( )
You can specify the print size when printing images stored on the memory
card. The [Size] menu is available only for DPOF 1.1 compatible printers.
1. Press the Up / Down button and select the
[DPOF] menu tab. And then press the Right
button.
2. Press the Right button again and select the
[Size]. Sub menu will display.
3. Select a desired sub menu by pressing the
PLAYBACK
Sandard
Index
Size Cancel
Select
All
OK
Back Set
UP / DOWN button and press the OK button.
[Select] : Selection window to change
the printed size of the image is
displayed.
- Up / Down / Left / Right : Select an image.
W
Cancel
OK
Set
T
- Zoom W / T Button : Change the print size.
- OK button : Your changes will be saved and
the menu will disappear.
[All] : Change print size of all saved images.
Cencel
- W / T button : Select a print size
- OK button : Confirm the changed setting.
OK
Set
T
[Cancel] : Cancel all of the print size settings.
※ DPOF [Size] secondary menu : Cancel, 3X5, 4X6, 5X7, 8X10
Depending on the manufacturer and print model, cancelling the
printing may take a little longer for the printer to process.
Copy To Card
This enables you to copy image files, movie clips and voice recording files to
the memory card.
1. Select the [Copy To Card] menu tab by
pressing the Up / Down button. And then
press the Right button.
2. Select a desired sub menu by pressing the
UP/ DOWN button and press the OK button.
- [No] : Cancels "Copy to Card".
- [Yes] : All images, movie clips and
voice recording files saved in the
internal memory are copied to the memory card after the
[Processing!] message is displayed. After copying has been
completed, the screen will return to play mode.
PLAYBACK
Voice Memo
Protect
Delete
DPOF
Copy To Card
Back Set
No
Yes
OK
<< 83 >>
Page 85
Playback
( )
[Copy To Card] will not be selected without inserting a memory
card.
If there is not enough space available in the memory card to copy
saved images in the internal memory (10 MB), the [Copy To Card]
command will copy only some of the images and display [Memory
Full!] message. Then the system will return to the playback mode.
Please be sure to delete any unnecessary files to free up space
before inserting the memory card into the camera.
When you move the images that are stored in the internal memory
by doing [Copy To Card] to the card, the next number of file names
will be created in the card to avoid duplication of the file name.
- When the [Reset] of the [File] setup menu is set : The copied
file names start from after the last stored file name.
- When the [Series] of the [File] setup menu is set : The copied
file names start from after the last captured file name. After
completing [Copy To Card], the last stored image of the last
copied folder is displayed on the LCD monitor.
<< 84 >>
PictBridge
You can use the USB cable to connect this camera to a printer that supports
PictBridge (sold separately) and print the stored images directly.
Movie clips and voice files cannot be printed.
Setting up the camera for connection to
the printer
1. Connect the camera and printer with USB cable.
2. Select the [Printer] menu by pressing Up / Down
button and press the OK button.
Connecting the Camera to a Printer
If the [USB] menu is set to the [Computer], you cannot connect a
Pictbridge compatible printer to the camera through USB cable with
[Connecting Computer] message. In this case, remove the cable and
do the step 1 and 2 again.
Select USB
Computer
Printer
OK
Confirm
Page 86
PictBridge PictBridge : Picture Selection
0
0
Easy printing
When you connect the camera to printer in the
Play back mode, you can print a picture easily.
- Pressing the Left / Right button :
Selects a previous / next image.
- Pressing the printer (
Currently displayed image will be printed with the printer’s default
) button :
Print Menu
OK
setting.
You can select images you want to print.
Setting the Number of Copies to Print
1. Press the Menu button and the PictBridge
menu will display.
2. Use the Up / Down buttons to select the
[Images] menu and press the Right button.
3. Use the Up / Down buttons to select a
desired sub menu and press the OK button.
- Select [One Pic] or [All Pics]. A screen where you can set the
number of copies to print will appear as shown below.
PICTBRIDGE
Size
Layout
Type
Quality
Date
Back Set
One PicImages
All Pics
OK
0
Prev Next
SH OK
Exit Set
When [One Pic] is selected]
[When [All Pics] is selected]
SH OK
Exit Set
0
- Press the Up / Down button to select the number of prints.
- When [One Pic] is selected : Use the Left / Right button to select
another picture. After selecting
another picture, select the number of
prints for another picture.
- After setting the number of prints, press the OK button to save.
- Press the Shutter button to return to the menu without setting the
number of prints.
4. Press the Print button ( ) and images will be printed.
<< 85 >>
Page 87
PictBridge : Print Setting PictBridge : Reset
You can select the Paper Size, Print Format, Paper Type, Print Quality, Date
Print, and File Name Print menus for printed pictures.
1. Press the Menu button and the PictBridge
menu will display.
2. Use the Up / Down buttons to select the
desired menu, and then press the Right button.
3. Use the Up / Down buttons to select the
desired sub menu value, and then press the
OK button.
PICTBRIDGE
Size
Layout
Type
Quality
Date
Back Set
AutoImages
PostCard
Card
4×6
4X6
L
L
2L
2L
OK
Menu Function Sub menu
Size
Layout
Type
Quality
Set the size of the printing
paper
Set the number of pictures to
be printed on a sheet of paper
Set the quality of the printing
paper
Set the quality of the picture to
be printed
Auto, PostCard, Card,
4X6, L, 2L, Letter, A4, A3
Auto, Full, 1, 2, 4, 8,
9, 16, Index
Auto, Plain, Photo,
FastPhoto
Auto, Draft, Normal,
Fine
Date Set whether to print the date Auto, Off, On
File Name
Set whether to print the file name
Auto, Off, On
Some menu options are not supported on all printers.
If not supported, the menus are still displayed in the LCD, but are not
selectable.
<< 86 >>
Initialises user-changed configurations.
1. Use the Up / Down buttons to select the
[Reset] menu tab. And then press the Right
button.
2. Use the Up / Down buttons to select the
desired sub menu value, and then press
the OK button.
If [No] is selected : Settings will not be reset.
If [Yes] is selected : All print and image settings will be reset.
Default print setting varies depending on the printer manufacturer.
For your printer’s default setting, refer to the user’s guide that came
with your printer.
PICTBRIDGE
Layout
Type
Quality
Date
File Name
Reset
Back Set
No
Yes
OK
Page 88
Important notes
Be sure to observe the following precautions!
This unit contains precision electronic components. Do not use or store this
unit in the following locations.
- Areas exposed to severe changes in temperature and humidity.
- Areas exposed to dust and dirt.
- Areas exposed to direct sunlight or the inside of a vehicle in hot
weather.
- Environments where there is high magnetism or excessive vibration.
- Areas with high explosives or highly flammable materials.
Do not leave this camera in places subject to dust, chemicals (like
naphthalene and mothballs), high temperature and high humidity.
Keep this camera with silica gel in a hermetically sealed box when not
planning to use the camera for a long period of time
Sand can be particularly troublesome to cameras.
- Do not let sand get inside the camera when using it on beaches,
coastal dunes, or other areas where there is lots of sand.
- Doing so may result in failure or may permanently render the camera
unusable.
Handling the camera
- Never drop the camera or subject it to severe shocks or vibrations.
- Protect the large size LCD monitor from an impact. When this
camera is not used, keep it in the camera case.
- Avoid obstructing the lens or the flash when you capture an image.
- This camera is not waterproof.
To avoid dangerous electrical shocks, never hold or operate the
camera with wet hands.
- If you use this camera in wet places, such as beach or pool, do not let
water or sand get inside the camera. Doing so may result in failure or
may permanently damage the unit.
Extremes in temperature may cause problems.
- If the camera is transferred from a cold to a warm and humid environment,
condensation can form on the delicate electronic circuitry. If this occurs,
turn the camera off and wait for at least 1 hour until all moisture is
dispersed. Moisture built up can also occur on the memory card. If this
happens, turn off the camera and remove the memory card. Wait until the
moisture has dispersed.
Caution on Using the Lens
- If the lens is subjected to direct sunlight, it could result in the
discoloration and deterioration of the image sensor.
- Take care not to get fingerprints or foreign substances on the surface
of the lens.
If the digital camera is not used for a long period, an electric discharge can
occur. It is a good idea to remove the battery and the memory card if you do
not intend using the camera for an extended period of time.
If the camera is exposed to an electronic interference, it will turn itself off to
protect the memory card.
<< 87 >>
Page 89
Important notes Warning indicator
Camera Maintenance
- Use a soft brush (available from photo stores) to gently clean the lens
and LCD assemblies. If this does not work, lens-cleaning paper with
lens cleaning fluid can be used.
Clean the camera body with a soft cloth. Do not allow this camera to
come into contact with solvent materials such as benzol, insecticide,
thinners etc. This may damage the body shell of the camera and also
affect its performance. Rough handling can damage the LCD monitor.
Take care to avoid damage and keep the camera in its protective carry
case at all times when not in use.
Do not attempt to disassemble or modify the camera.
Under certain conditions, static electricity can cause the flash unit to
fire. This is not harmful to the camera and is not a malfunction.
When images are uploaded or downloaded, the data transfer may be
affected by static electricity. In this case, disconnect and re-connect the
USB cable before trying the transfer again.
Before an important event or going on a trip, you should check the
camera condition.
- Take a picture for testing the camera condition and prepare extra
battery.
- Samsung cannot be held responsible for camera malfunctions.
There are several warnings that may appear on the LCD display.
[ Card Error !]
ᆞMemory card error
→ Turn off the camera power and turn it on again
→ Insert the memory card again
→ Insert and format the memory card (p.58)
[ Card Locked! ]
ᆞThe memory card is locked
→ SD/SDHC memory card : Slide the write protect switch to the top of
[ No Card! ]
ᆞ A memory card is not inserted
→ Insert the memory card again
→ Turn off the camera power and turn it on again
[ No Image! ]
ᆞThere are no images stored on the memory
→ Take images
→ Insert a memory card that is holding some images
the memory card
<< 88 >>
Page 90
Warning indicator Before contacting a service centre
[ File Error! ]
ᆞFile error
→ Delete the file.
ᆞMemory card error
→ Contact a camera service centre.
[ Low Battery! ]
ᆞThere is low battery capacity
→ Insert fresh batteries.
[ Low Light! ]
ᆞWhen taking pictures in dark places
→ Take pictures in Flash Photography mode.
Please check the following
The camera doesn’t switch on
ᆞThere is low battery capacity
→ Insert fresh batteries. (p.15)
ᆞBattery is inserted incorrectly with the polarities reversed.
→ Insert the battery according to the polarity marks (+, -).
The camera power ceases while in use
ᆞThe battery is exhausted
→ Insert fresh batteries.
ᆞThe Camera is turned off automatically
→ Turn on the camera power again.
Battery power quickly drains
ᆞThe Camera is being used in low temperatures
→ Keep the camera in warm conditions (i.e. inside a coat or jacket)
and only remove it in order to take images.
<< 89 >>
Page 91
Before contacting a service centre
Camera does not take images when pressing the Shutter button
There is insufficient memory capacity
Delete unnecessary image files
The memory card has not been formatted
→ Format the memory card (p.58)
The memory card is exhausted
→ Insert a new memory card
The memory card is locked
→ Refer to [Card Locked!] error message
The camera's power is off
→ Turn the camera power on
The battery is exhausted
→ Insert fresh batteries (p.15)
Battery is inserted incorrectly with the polarities reversed.
→ Insert the battery according to the polarity marks (+, -)
The camera suddenly stops working while in use
The camera stopped due to a malfunction
→ Remove /re-insert battery and switch the camera on
The images are unclear
A picture was taken of the subject without setting an appropriate
macro mode
→ Select an appropriate macro mode to take a clear image.
Taking a picture beyond the flash range
→ Take a picture within the flash range
The lens is smudged or dirty
→ Clean the lens
<< 90 >>
The flash does not fire
Flash off mode has been selected
→ Dis-engage flash off mode
The camera mode can't use the flash
→ Refer to the FLASH instruction (p.30)
Incorrect date and time is displayed
The date and time have been set incorrectly or the camera has
adopted the default settings
→ Reset the date and time correctly
The camera buttons do not operate
Camera malfunction
→ Remove/re-insert battery and switch the camera on
A card error has occurred while the memory card is in the camera.
Incorrect memory card format
→ Re-format the memory card
The images don't play back
Incorrect file name (Violation of DCF format)
→ Do not change the image file name
Colour of image is different to the original scene
White balance or effect setting is incorrect
→ Select appropriate White balance and effect
Page 92
Before contacting a service centre Specifications
Images are too bright
Exposure is excessive
→ Reset exposure compensation
No image on external monitor
The external monitor has not been connected properly with
the camera
→ Check the connection cables
There are incorrect files in the memory card
→ Insert a memory card that has correct files
When using the PC’s explorer, the [Removable Disk] file does not show
Cable connection is incorrect
→ Check the connection
The camera is off
→ Turn the camera on
The operating system is not Windows 98SE, 2000, ME, XP, Vista /
Mac OS 10.0 - 10.4. Alternatively the PC does not support USB
→ Install Windows 98SE, 2000, ME, XP, Vista / Mac OS 10.0 - 10.4 to
PC that supports USB
The camera driver is not installed
→ Install a [USB Storage Driver]
Image Sensor - Type : 1/2.5" CCD
- Effective Pixel : L830 : Approx. 8.1 Mega-pixel
L730 : Approx. 7.2 Mega-pixel
- Total Pixel : L830 : Approx. 8.3 Mega-pixel
L730 : Approx. 7.4 Mega-pixel
Lens - Focal Length : NV Lens f = 6.3 ~ 18.9mm
- F No. : F 3.0 ~ F 7.7(Wide), F 5.6~F 14.1(Tele)
- Digital Zoom : L830 : ·Still Image mode : 1.0X ~ 5.0X
·Play mode : 1.0X ~ 12.8X
(depends on image size)
L730 : ·Still Image mode : 1.0X ~ 5.0X
·Play mode : 1.0X ~ 12.0X
(depends on image size)
LCD Monitor - 2.5" color TFT LCD (230,000 dots)
Focusing - Type : TTL auto focus, Center-AF, Multi-AF, Face
- Range
Normal Macro Auto Macro
Wide
Tele 50cm ~ 80cm 50cm ~ Infinity
80cm ~ Infinity
(35mm film equivalent : 38 ~ 114mm)
Recognition AF
10cm ~ 80cm 10cm ~ Infinity
Shutter - Speed 1 ~ 1/1,500 sec. (Manual : 8 ~ 1/1,500 sec.)
<< 91 >>
Page 93
Specifications
Exposure - Control : Program AE
- Metering : Multi, Spot, Face Recognition
- Compensation : ±2EV (1/3EV steps)
- ISO : L830 : Auto, 80, 100, 200, 400, 800, 1600
Flash - Modes : Auto, Auto & Red-eye reduction, Fill-in flash,
- Range :
- Recharging Time : Approx. 4 sec
Sharpness - Soft+, Soft, Normal, Vivid, Vivid+
Color Effect - Normal, B&W, Sepia, Red, Blue, Green, Negative,
White Balance - Auto, Daylight, Cloudy, Fluorescent_H, Fluorescent_L,
Voice Recording - Voice Recording (max. 10 hours)
- Voice Memo in Still Image (max. 10 sec.)
Date Imprinting - Date, Date & Time, Off (user selectable)
Shooting - Still Image
·Mode :
·Scene :
·Shooting : Single, Wise shot, Continuous, AEB,
·Self-timer : 2 sec., 10 sec., Double
<< 92 >>
L730 : Auto, 80, 100, 200, 400, 800, 1600
Slow sync, Flash off, Red-eye Fix
Wide : 0.2m ~ 4.6m, Tele : 0.5m ~ 2.6m(ISO AUTO)
Custom Color
Tungsten, Custom
Auto, Program, ASR, Manual, Scene, Portrait, Night
Children, Landscape, Close-up, Text, Sunset,
Dawn, Backlight, Fireworks, Beach & Snow
Motion Capture
- Movie Clip
·With Audio or without Audio(user selectable,
recording time : memory capacity dependent)
The maximum memory capacity of continuous
·Size : 800x592, 640x480, 320x240
·Frame rate : 30 fps, 20 fps, 15 fps
Storage - Media
·Internal memory : 10MB flash memory
·External Memory (Optional)
: SD (up to 2GB guaranteed)
- File Format
·Still Image :
·Movie Clip : AVI (MPEG-4)
·Audio : WAV
- Image Size
· L830
3264X
2448
· L730
3072X
2304
movie clip is 2 hours.
(20fps Only 800x592 quality)
(30fps / 15fps Only 640x480, 320x240 quality)
SDHC Card (up to 4GB guaranteed)
MMC Plus (Up to 1GB, 4bit 20MHz)
JPEG (DCF), EXIF 2.2, DPOF 1.1, PictBridge 1.0
3264X
2176
3072X
2048
3264X
1836
3072X
1728
2592X
1944
2592X
1944
2048X
1536
2048X
1536
1024X
768
1024X
768
Page 94
Specifications
- Capacity (256 MB Size)
· L830
Super Fine
Fine 104 118 144 181 264 710
Normal 151 197 223 256 363 822
· L730
53 63 76 94 142 459
Interface - Digital output connector : USB 2.0 High Speed
- Audio : Mono
- Video output : NTSC, PAL (user selectable)
Power Source - Rechargeable battery : SLB-0937, 3.7V (900mAh)
- Adaptor : SAC-46 (DC 4.2V, 450mA)
Dimensions (WxHxD)
- 95 X 59 X 21mm (excluding protrusions)
Super Fine
Fine 128 157
Normal 188 223
These figures are measured under Samsung standard conditions
and may vary depending on shooting conditions and camera
settings.
“E” Button - Effect : Color, Image Adjust, Fun
- Editing : Resize, Rotate, Color, Special Color, Image
Image Play - Type :
67 80
95
183
269
( Highlight, Composite, Photo Frame)
Adjust (Red Eye Fix, Brightness, Contrast
,Saturation ,Add Noise), Fun (Cartoon ,
Highlight, Composite, Photo Frame, Sticker)
Single image, Thumbnails, Slide show, Movie Clip
95 142 459
183 269 710
269 363 822
Weight - Approx. 132.6g (without batteries and card)
Operating Temperature
- 0 ~ 40°C
Operating Humidity
- 5 ~ 85%
Software - Samsung Master, Adobe Reader
Specifications are subject to change without prior notice.
All trademarks are the property of their respective owners.
<< 93 >>
Page 95
Software Notes System Requirements
Please ensure that you read the instruction manual carefully before use.
- The attached software is a camera driver and image editing software
tool for Windows.
- Under no circumstances should all or part of either the software or the
user manual be reproduced.
- Copyrights for software are licensed only for use with a camera.
- In the unlikely event of a manufacturing fault, we will repair or exchange
your camera.
We cannot, however, be held responsible in any way for damage
caused by inappropriate use.
- Using a Hand-made PC or a PC and OS that has not been guaranteed
by the manufacturer is not covered by the Samsung warranty.
- Before reading this manual, you should have a basic knowledge of
computers and O/S (Operating Systems).
<< 94 >>
For Windows For Macintosh
PC with processor better than
Pentium II 450MHz
(Pentium 800MHz recommended)
Windows 98SE / 2000 / ME / XP/Vista Mac OS 10.0 ~ 10.4
Minimum 128MB RAM
(Over 512MB recommended)
200MB of available hard disk space (Over
1GB recommend)
USB port USB port
CD-ROM drive CD-ROM drive
1024x768 pixels, 16bit color display
compatible monitor
(24bit color display recommended)
MicroSoft DirectX 9.0C
Power Mac G3 or later
Minimum 64MB RAM
110MB of available harddisk space
MPlayer (For movie clip)
Page 96
About the software
After inserting the CD-ROM provided with this camera into the CD-ROM drive,
the following window should automatically run.
Before connecting the camera to the PC, you
should first install the camera driver.
Camera driver : This enables images to transfer between the camera
and PC.
This camera uses the USB Storage Driver as the camera driver. You
can use the camera as a USB card reader. After installing the driver
and connecting this camera to the PC, you can find [Removable Disk]
in [Windows Explorer] or [My computer]. A USB Storage Driver is
provided only for Windows. A USB Driver for MAC is not included with
the Application CD. You can use the camera with Mac OS 10.0~10.4.
Samsung Master : This is the all-in-one multi media software solution.
You can download, view, edit and save your digital images and movie
clips with this software. This software is only compatible with Windows.
Be sure to check the system requirements before installing the
driver.
You should allow 5 ~ 10 seconds for running the automatic setup
program according to the capability of your computer. If the frame
does not appear, run the [Windows Explorer] and select [Installer.
exe] in the CD-ROM Drive root directory.
<< 95 >>
Page 97
Setting up the application software
To use this camera with a PC, install the application software first.
After this has been done, the stored images in the camera can be moved to
the PC and can be edited by an image editing program.
You can visit the Samsung web-site through the internet.
http://www.samsungcamera.com : English
http://www.samsungcamera.co.kr : Korean
1. The auto run frame will display.
Click the [Install] menu in the
Auto run frame.
2. Install the camera driver, DirectX, XviD, Samsung Master and
Adobe Reader by selecting a button shown on the monitor. If a latest
version of DirectX was installed on your computer, DirectX may not
be installed.
The XviD codec is distributed according to the GNU General Public
License and everyone can copy, distribute and change this codec. This
License applies to any program or other work which contains a notice
placed by the copyright holder saying it may be distributed under the
terms of this General Public License. For more information, see the
License documents (http://www.gnu.org/copyleft/gpl.html).
<< 96 >>
Page 98
Setting up the application software
3. After restarting the computer, connect the PC to the camera with the
USB cable.
4. Turn the camera power on.
The [Found New Hardware Wizard] will
open and the computer will recognise
the camera.
If your OS is Windows XP/ Vista, an
image viewer program will open.
If the download window of Samsung
Master opens after starting Samsung
Master, the camera driver was set up
successfully.
<< 97 >>
Page 99
Setting up the application software Starting PC mode
If you have installed the camera driver, the [Found New Hardware
Wizard] may not open.
On a Windows 98SE system, the Found New Hardware Wizard
dialog box opens and a window asking you to select a driver file may
appear. In this case, specify "USB Driver" in the CD supplied.
PDF documents of user manual are included in the Software
CD-ROM supplied with this camera. Search the PDF files with
Windows explorer.
Before opening the PDF files, you must install the Adobe Reader
included in the Software CD-ROM.
To install the Adobe Reader 6.0.1 correctly, Internet Explorer 5.01 or
later has to be installed. Visit "www.microsoft.com" and upgrade the
Internet Explorer.
If you connect the USB cable to a USB port on your PC and then turn on the
power, the camera will automatically switch to "computer connection mode".
In this mode, you can download stored images to your PC through the USB
cable.
Camera settings for connection
1. Turn on the camera
2. Connect the camera and computer with the
supplied USB cable.
3. Turn on the computer. The camera and
computer are connected.
4. External device selection menu will be
displayed on the LCD monitor.
5. Select the [Computer] by pressing the Up / Down button and press
the OK button.
Select USB
Computer
Printer
OK
Confirm
<< 98 >>
Page 100
Starting PC mode
Connecting the camera to a PC
If you selected [Printer] in Step 5, when you connect the camera to
your computer, the [Connecting Printer] message will display and the
connection will not be established.
In this case, disconnect the USB cable, and then follow the procedure
from Step 2 and onward.
Disconnecting the camera and PC
Refer to page 101 (Removing the removable disk).
Downloading stored images
You can download the still images stored on the camera to your PC's
hard disk and print them or use a photo editing software to edit them.
1. Connect the camera to your PC with the USB cable.
2. On your computer's desktop display,
select [My computer] and double click
[Removable Disk
DCIM 100SSCAM].
The image files will then be displayed.
3. Select an image and press the right
mouse button.
<< 99 >>
