Samsung HT-DS100 User Manual

DIGITAL HOME

OPEN/CLOSE

DVD TUNER AUX

EZ VIEW SLOW SUB TITLE

STEP

PL II

R

E

T

U

R

N

M

E

N

U

I
N
F

O

M
U
T

E

MODE

ENTER

SOUND EDIT

TEST TONE

SLEEP

LOGO DIGEST

SLIDE MODE

CANCEL ZOOM

TUNER
MEMORY

PL II
EFFECT

VOLUME

DSP/EQ REPEAT

BAND

MO/ST

REMAIN

DIMMER

P.SCAN

TUNING

V I D E O

COMPACT

DIGITAL AUDIO

COMPACT

DIGITAL VIDEO

THEATER SYSTEM

HT-DS100

Instruction Manual

Safety Warnings

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

Note to CATV system installer :

This reminder is provided to call the CATV system
installer’s attention to Section 820~40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1
LASER product.

Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.

CAUTION-INVISIBLE LASER RADIATION WHEN OPEN

AND INTERLOCKS DEFEATED, AVOID
EXPOSURE TO BEAM.

This symbol indicates that dangerous voltage which can cause electric shock is present inside
this unit.

This symbol alerts you to important operating and maintenance instructions accompanying
the unit.

WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

1

Precautions

Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install your
player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4inches). Make sure the ventilation slots
are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other equipment which may become
hot. Before moving the player, ensure the disc tray is empty. This player is designed for continuous use. Switching off the DVD player to
the stand-by mode does not disconnect the electrical supply. In order to disconnect the player completely from the power supply,
remove the main plug from the wall outlet, especially when left unused for a long period of time.

PREPARATION

During thunderstorms, disconnect AC main plug from the
wall outlet.
Voltage peaks due to lightning could damage the unit.

Phones

Protect the player from moisture(i.e. vases) , and excess
heat(e.g.fireplace) or equipment creating strong magnetic or electric
fields (i.e.speakers...). Disconnect the power cable from the AC supply if
the player malfunctions. Your player is not intended for industrial use.

Use of this product is for personal use only.
Condensation may occur if your player or disc have been stored in cold

temperatures.
If transporting the player during the winter, wait approximately 2 hours

until the unit has reached room temperature before using.

Do not expose the unit to direct sunlight or other heat
sources.

This could lead to overheating and malfunction of the unit.

The battery used with this product contain chemicals that
are harmful to the environment.
Do not dispose of batteries in the general household trash.

2

Features

Multi-Disc Playback & AM/FM Tuner

The HT-DS100 combines the convenience of multi-disc playback capability,
including DVD, VCD, CD, MP3-CD, CD-R/RW, and DVD-R/RW, with a
sophisticated AM/FM tuner, all in a single player.

Dolby Pro Logic II

Dolby Pro Logic II is a new form of multi-channel audio signal decoding technology that
improves upon existing Dolby Pro Logic.

DTS (Digital Theater Systems)

DTS is an audio compression format developed by Digital Theater
Systems Inc. It delivers full-frequency 5.1 channel sound.

TV Screen Saver Function

The HT-DS100 automatically brightens and darkens the brightness of
the TV screen after 3 minutes in the stop mode.
The HT-DS100 automatically switches itself into the power saving mode
after 20 minutes in the screen saver mode.

Power Saving Function

The HT-DS100 automatically shuts itself off after 20 minutes in the stop mode.

Customized TV Screen Display

The HT-DS100 allows you to select your favorite image during JPEG,
DVD, or VCD playback and set it as your background wallpaper.

3

Contents

PREPARATION

Safety Warnings..................................................................................................................................................................1

Precautions.........................................................................................................................................................................2

Features..............................................................................................................................................................................3

Notes on Discs....................................................................................................................................................................5

Description..........................................................................................................................................................................7

CONNECTIONS

Connecting the Speakers....................................................................................................................................................13

Connecting the Video Out to TV.........................................................................................................................................15

P.SCAN(Progressive Scan) Function.................................................................................................................................16

Connecting External Components......................................................................................................................................17

Connecting the Antennas....................................................................................................................................................19

OPERATION

Disc Playback .....................................................................................................................................................................21

MP3-CD Playback...............................................................................................................................................................22

JPEG File Playback............................................................................................................................................................23

Displaying Disc Information ................................................................................................................................................25

Checking the Remaining Time............................................................................................................................................26

Fast/Slow Playback.............................................................................................................................................................27

Skipping Scenes/Songs......................................................................................................................................................28

Repeat Playback.................................................................................................................................................................29

A-B Repeat Playback..........................................................................................................................................................30

Angle Function....................................................................................................................................................................31

Zoom Function....................................................................................................................................................................32

Selecting Audio/Subtitle Language.....................................................................................................................................33

Moving Directly to a Scene/Song........................................................................................................................................34

Using Disc Menu.................................................................................................................................................................35

Using the Title Menu...........................................................................................................................................................36

SETUP

Setting the Language..........................................................................................................................................................37

Setting TV Screen type.......................................................................................................................................................39

Setting Parental Controls (Rating Level).............................................................................................................................41

Setting the Password..........................................................................................................................................................43

Setting the Wallpaper..........................................................................................................................................................45

Setting the Speaker Mode ..................................................................................................................................................47

Setting the Test Tone..........................................................................................................................................................48

Setting the Delay Time........................................................................................................................................................49

Setting the Audio Quality ....................................................................................................................................................51

Setting the DRC (Dynamic Range Compression)...............................................................................................................53

Sound Field (DSP)/EQ Function.........................................................................................................................................54

Dolby Pro Logic II Mode......................................................................................................................................................55

Dolby Pro Logic II Effect .....................................................................................................................................................56

RADIO OPERATION

Listening to Radio...............................................................................................................................................................57

Presetting Stations..............................................................................................................................................................58

MISCELLANEOUS

Convenient Functions.........................................................................................................................................................59

Before Calling for Service...................................................................................................................................................61

Cautions on Handling and Storing Discs ............................................................................................................................63

Specifications......................................................................................................................................................................64

Notes on Terminology.........................................................................................................................................................65

Warranty .............................................................................................................................................................................66

PREPARATION

4

V I D E O

1 6

~

Notes on Discs

DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital

surround sound and MPEG-2 video compression technology. Now you can enjoy these
realistic effects in the home, as if you were in a movie theater or concert hall.

DVD players and the discs are coded by region. These regional codes must match in order
for the disc to play. If the codes do not match, the disc will not play.
The Region Number for this player is given on the rear panel of the player.

(Your DVD player will only play DVDs that are labeled with identical region codes.)

Playable Discs

Disc Type Disc Size Max. Playing Time

DVD

VIDEO-CD

AUDIO-CD

Mark (Logo)

V I D E O

COMPACT

DIGITAL VIDEO

COMPACT

DIGITAL AUDIO

Recorded Signals

Audio + Video

Audio + Video

Audio

5"

3 1/2"

5"

3 1/2"

5"

3 1/2"

Approx. 240 min. (single-sided)

Approx. 480 min. (double-sided)

Approx. 80 min. (single-sided)

Approx. 160 min. (double-sided)

74 min.
20 min.
74 min.
20 min.

Do not use the following types of disc!

LD, CD-G, CD-I, CD-ROM and DVD-ROM cannot be played on this player.

•

If such discs are played, a "WRONG DISC FORMAT" message appears on the TV screen.

DVD discs purchased abroad may not play on this player.

•

If such discs are played, a "WRONG REGION CODE" message appears on the TV screen.

Copy Protection

Many DVD discs are encoded with copy protection. Because of this, you should only connect your

•

DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture
from copy-protected DVD discs.

This product incorporates copyright protection technology that is protected by methods claims of certain

•

U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

5

PREPARATION

Disc Recording Format

CD-R Discs

Depending on the disc recording device (CD-Recorder or PC ) and the condition of the disc, some CD-R discs

•

may not be playable.
Use a 650MB/74 minute CD-R. Avoid CD-R media, as they may not be playable.

•

If possible, do not use CD-RW (Rewritable) media, as they may not be playable.

•

Only CD-Rs that are properly "closed" can be fully played. If the session is closed but the disc is left open,

•

you may not be able to fully play the disc.

CD-R MP3 Discs

Only CD-R discs with MP3 files in ISO 9660 or Joliet format can be played.

•

MP3 file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).

•

Use discs recorded with a compression/decompression data rate greater than 128Kbps.

•

Only files with the ".mp3" and ".MP3" extensions can be played.

•

Only a consecutively written Multi session disc can be played. If there is a blank segment in the Multi session disc,

•

the disc can be played only up to the blank segment.
If the disc is not closed, it will take longer to begin playback and not all of the recorded files may be played.

•

For files encoded in Variable Bit Rate (VBR) format, i.e. files encoded in both low bit rate and high bit rate (e.g.,

•

32Kbps ~ 320Kbps), the sound may skip during playback.
If more than 500 tracks are recorded on a single CD, a maximum of 500 tracks can be played.

•

If more than 300 folders are recorded on a single CD, a maximum of 300 folders can be played.

•

What is MP3?

MP3 is short for MPEG-1 Audio Layer 3 and MPEG is an acronym for Moving Pictures Experts
Group. MP3 is a file format with compression ratio of 1:12 (128 Kbps*) That is, you can use MP3
format to record about 12 times the usual amount of data on a regular CD.

CD-R JPEG Discs

Only files with the ".jpeg" and ".JPEG" extensions can be played.

•

If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played.

•

Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.

•

JPEG file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).

•

Only a consecutively written multi session disc can be played. If there is a blank segment in the multi session disc, the

•

disc can be played only up to the blank segment.
A maximum of 9,999 images can be stored on a single CD.

•

When playing a Kodak/Fuji Picture CD, only the JPEG files in the picture folder can be played.

•

Picture discs other than Kodak/Fuji Picture CDs may take longer to start playing or may not play at all.

•

6

Description

DSP

TITLE PBC

CHAP

PRGM

ST

TUNED

kHz

MHz

LINEAR PCM

MPEG

L C R

SW

LS S RS

—Front Panel—

Power ( ) button

Stop ( ) button

Open/Close button

Play/Pause ( ) button

Function button

Volume control

Standby indicator

SPEAKER indicator

Disc Tray

DOLBY DIGITAL indicator

LINEAR PCM indicator

DSP indicator

TITLE indicator

DTS Disc indicator

PRO LOGIC indicator

MPEG indicator

CHAPTER indicator

PBC indicator

Tuning Up & Skip ( ) buttons
Tuning Down & Skip ( ) buttons

STEREO indicator

PROGRAM indicator

System Status Display

TUNER indicator

RADIO FREQUENCY

indicator

7

SUBWOOFER REARRFRONT

R

CENTER REARLFRONT

L

IMPEDANCE
FRONT / CENTER / REAR : 6Ω

SUBWOOFER : 3Ω

—Rear Panel—

PREPARATION

Use this to connect external equipment capable of digital output.

External Digital in Optical Input Connector

5.1 Channel Speaker
Output Terminals

Accessories

Video Output Connector

Connect the TV's video input jacks

(VIDEO IN) to the VIDEO OUT connector.

External Audio

Component Input

Connector

COMPONENT VIDEO

Connect a TV with component

video inputs to these jacks.

S-Video Output Connector

If the TV is equipped with an S-Video input
connector (S-VIDEO IN), connect it to the
player's S-Video output jack.

FM Antenna
Connector

AM Antenna
Connector

OUTPUT jacks

OPEN/CLOSE

DVD TUNER AUX

DIMMER

EZ VIEW SLOW SUB TITLE

BAND

STEP

REMAIN

MO/ST

DSP/EQ REPEAT

MODE
PL II

VOLUME

TUNING

N
R
U
T

E
R

M
E

N
U

EFFECT

PL II

I
N
F
O

ENTER

M
U
T
E

SLEEP

LOGO DIGEST

TEST TONE

SOUND EDIT

SLIDE MODE

CANCEL ZOOM

TUNER
MEMORY

P.SCAN

Remote Control

Audio Cable Video Cable

FM Antenna User's Manual AM Antenna

8

Description

OPEN/CLOSE

DVD TUNER AUX

EZ VIEW SLOW SUB TITLE

STEP

PL II

RETURN

MENU

INFO

MUTE

MODE

ENTER

SOUND EDIT

TEST TONE

SLEEP

LOGO DIGEST

SLIDE MODE

CANCEL ZOOM

TUNER

MEMORY

PL II

EFFECT

VOLUME

DSP/EQ REPEAT

BAND

MO/ST

DIMMER REMAIN

TUNING

—Remote Control—

TV, DVD POWER button

DIMMER button

OPEN/CLOSE button

EZ VIEW button

STEP button

DSP/EQ button

REMAIN button

DVD button

TUNER BAND button

SUB TITLE button
SLOW, MO/ST button
REPEAT button

AUX button

PL II MODE button

VOLUME button

MENU button

RETURN button

Number(0~9) buttons

SLEEP button

LOGO COPY button

SLIDE MODE button

Play/Pause button

Stop button

Tuning Preset/CD Skip button

PL II EFFECT button

TUNING button

INFO button

MUTE button

Direction/Enter button

TEST TONE button

SOUND EDIT button
TUNER MEMORY, P.SCAN button

ZOOM button

CANCEL button

DIGEST button

9

Insert Remote Batteries

PREPARATION

1

Caution

Remove the battery
cover on the back of
the remote by
pressing down and
sliding the cover in
the direction of the
arrow.

Follow these precautions to avoid leaking or cracking cells:

Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).

•

Use the correct type of batteries.Batteries that look similar may differ in voltage.

•

Always replace both batteries at the same time.

•

Do not expose batteries to heat or flame.

•

Insert two 1.5V AAA

2

batteries, paying
attention to the correct
polarities (+ and –).

Replace the battery

3

cover.

Range of Operation of the Remote Control

To open the remote control cover, push the

The remote control can be used up to approximately 23
feet/7 meters in a straight line. It can also be operated at
a horizontal angle of up to 30° from the remote control
sensor.

top of the cover, then slide downward.

10

RSLS

C

L

SW

R

Connecting the Speakers

R

L

C

RS

LS

SW

Before moving or installing the product, be sure to turn off the power and disconnect the power cord.

Position of the DVD Player

Place it on a stand or cabinet shelf, or under

•

the TV stand.

Front Speakers

Place these speakers in front of your listening

•

position, facing inwards (about 45°) toward you.
Place the speakers so that their tweeters will be at

•

the same height as your ear.
Align the front face of the front speakers with the

•

front face of the center speaker or place them
slightly in front of the center speakers.

Center Speaker

It is best to install it at the same height as the front

•

speakers.
You can also install it directly over or under the TV.

•

11

Selecting the Listening Position

The listening position should be located about 2.5 to 3 times
the distance of the TV's screen size away from the TV.
Example : For 32" TVs 2~2.4m (6~8feet)

For 55" TVs 3.5~4m (11~13feet)

Rear Speakers

Place these speakers behind your listening position.

•

If there isn't enough room, place these speakers so they face each other.

•

Place them about 60 to 90cm (2 to 3feet) above your ear, facing slightly

•

downward.

Unlike the front and center speakers, the rear speakers are used to

*

mainly handle sound effects and sound will not come from them all
the time.

Subwoofer

The position of the subwoofer is not so critical.

•

Place it anywhere you like.
Usually, it is placed by a corner near the front speakers.

•

Center Speaker

Rear Speaker (L) Front Speaker (L)

CONNECTIONS

Green

Purple

Subwoofer

Blue

Gray

Rear Speaker (R) Front Speaker (R)

White

Red

Back of the Speakers Back of the Main Unit

Press down the terminal

1

tab on the back of the
speaker.

Insert the wire into the

2

terminal and release the
terminal tab.

Insert the black wire into the black

•

(–) terminal and the gray wire into
the gray (+) terminal.
Make sure the polarities (+ and –)

•

are correct.

Black

Gray

Connect the connecting jacks (6)

3

to the back of the DVD player.

Make sure the colors of the speaker terminals

•

match the colors of the connecting jacks.
Make sure the polarities (+ and -) are correct.

•

12

Connecting the Video Out to TV

Composite

Video

Component

Video

S-Video

TV

Depending on your TV, Component Video input jacks may be marked as DVD Video input.

*

Composite Video (Good Quality)

Connect the supplied video cable from the VIDEO OUT jack on the back panel of the
system to the VIDEO IN jack on your television.

S-Video (Better Quality)

If you television is equipped with an S-Video input, connect an S-Video cable (not supplied)
from the S-VIDEO OUT jack on the back panel of the system to the S-VIDEO IN jack on
your television.

Component Video (Best Quality)

If your television is equipped with Component Video inputs, connect a component video
cable (not supplied) from the Pr, Pb and Y jacks on the back panel of the system to the
corresponding jacks on your television.

When the Progressive scan mode is selected, the VIDEO and S-VIDEO outputs do not feed

Note

13

•

any signals. See page 14 to select Progressive Scan.

P.SCAN(Progressive Scan) Function

Unlike regular Interlace Scan, in which two fields of picture information are alternated to create
the entire picture (odd scan lines, then even scan lines), Progressive Scan uses one field of
information (all lines displayed in one pass) to create a clear and detailed picture without visible
scan lines.

While the player is in the Stop mode, hold the P.SCAN button down for longer
than 5 second.

Pressing and holding the button for over 5 seconds will select "Progressive Scan" and "Interlace Scan"

•

repetitively.

What is Progressive (or Non-Interlaced) Scanning?

CONNECTIONS

Interlaced Scan (1 FRAME = 2 FIELDS)

In interlaced-scan video, a frame consists of two
interlaced fields (odd and even), where each field
contains every other horizontal line in the frame.
The odd field of alternating lines is displayed first, and
then the even field is displayed to fill in the alternating
gaps left by the odd field to form a single frame.
One frame, displayed every 1/30th of a second, contains
two interfaced fields, thus a total of 60 fields are
displayed every 1/60th of a second.
The interlaced scanning method is intended for capturing
a still object.

This function works only on TVs equipped with component video inputs (Pr, Pb, Y,) that support Progressive

Note

•

Video. (It does not work on TVs with conventional component inputs, i.e., non-progressive scan TVs.)
Depending on the brand and model of your TV, this function may not work.

•

Progressive Scan (FULL FRAME)

The progressive scanning method scans one full frame of
video consecutively down the screen, line by line.
An entire image is drawn at one time, as opposed to the
interlaced scanning process by which a video image is
drawn in a series of passes.
The progressive scanning method is desirable for dealing
with moving objects.

Selecting the Video Format

Press and hold NTSC/PAL button on the remote controller for over 5 seconds while the power is turned off.

"NTSC" or "PAL" will appear in the display.

•

At this time, press the NTSC/PAL button shortly to select between "NTSC" and "PAL".
Each country has a different video format standard.

•

For normal playback, the video format of the disc must be the same as the video format of your TV.

•

14

Connecting External Components

Connecting an External Digital Component

Example: Digital signal components such as a Set-Top Box or CD Recorder.

Optical Cable
(not included)

DIGITAL OUT

Connect the Digital Input (OPTICAL) to the Digital Output on the external

1

digital component.

Press AUX on the remote control to select ‘DIGITAL IN’.

2

Each time the button is pressed, the selection changes as follows: DIGITAL IN ➝ AUX.

•

You can also use the FUNCTION button on the main unit.

•

The mode switches as follows: DVD/CD ➝ DIGITAL IN ➝ AUX ➝ FM ➝ AM.

15

Connecting an External Analog Component

L

AUDIO OUT

R

Example: Analog signal components such as a VCR, and TV.

Audio Cable

If the external analog

component has only one

Audio Out, connect either

left or right.

CONNECTIONS

Connect Audio In on the DVD player to Audio Out on the external analog component.

1

Be sure to match connector colors.

•

Press AUX on the remote control to select AUX.

2

Each time the button is pressed, the selection changes as follows: DIGITAL IN ➝ AUX.

•

You can also use the FUNCTION button on the main unit.

•

The mode switches as follows: DVD/CD ➝ DIGITAL IN ➝ AUX ➝ FM ➝ AM.

16

Connecting the Antennas

FM antenna connection

FM Antenna (supplied)

1

2

17

Connect the FM antenna supplied to the FM 75Ω COAXIAL terminal as a
temporary measure.

Slowly move the antenna wire around until you find a location where reception
is good, then fasten it to a wall or other rigid surface.

SUBWOOFER REARRFRONT

R

CENTER REARLFRONT

L

IMPEDANCE
FRONT / CENTER / REAR : 6Ω

SUBWOOFER : 3Ω

AM antenna connection

123

If AM reception is poor, connect an outdoor

AM antenna(not supplied).

AM Loop Antenna

(supplied)

Snap the tabs on the loop into the

slots of the base to assemble the

AM loop antenna.

Connect the AM loop antenna supplied to the AM and terminals.

1

CONNECTIONS

If reception is poor, connect an outdoor single vinyl-covered wire to the AM
terminal. (Keep the AM loop antenna connected).

2

Cooling Fan

The cooling fan dissipates the heat generated inside the unit so that the unit can be operated
normally. The cooling fan is activated automatically to supply cool air to the unit.

Please observe the following cautions for your safety.

•

Make sure the unit is well-ventilated. If the unit has poor ventilation, the temperature inside the unit could rise
and may damage it.

•

Do not obstruct the cooling fan or ventilation holes. (If the cooling fan or ventilation holes are covered with a
newspaper or cloth, heat may build up inside the unit and fire may result.)

18

Disc Playback

Press OPEN/CLOSE button to
open the disc tray.

1

Press OPEN/CLOSE button

3

to close the disc tray.

DVD VCD CD

Playback starts automatically.

•

Note

Depending on the content of the disc, the initial screen may appear different.

•

Load a disc.

2

Place a disc gently into the tray with the

•

disc’s label facing up.

To stop playback,
press STOP during playback.

If pressed once, “PRESS PLAY” is displayed and the

•

stop position will be stored in memory. If PLAY/PAUSE
( ) button or ENTER button is pressed, playback
resumes from the stop position. (This function works
only with DVDs.)
If pressed twice, “STOP” is displayed, and if

•

PLAY/PAUSE ( ) button is pressed, playback
starts from the beginning.

TV Broadcast System

This device is designed to work with the NTSC video format.

•

For normal playback, the video format a DVD disc is recorded in must coincide with your TV's video format.

•

To temporarily pause playback,
press PLAY/PAUSE during

To resume playback, press PLAY/PAUSE

•

button again.

19

MP3-CD Playback

Data CDs (CD-ROMs, CD-Rs, CD-RWs) encoded in MP3 format can be played.

MP3

Press the

OPEN/CLOSE

1

button to open the
disc tray, and then
load the MP3 disc.

The MP3 menu screen will appear

•

and playback will start.
Depending on the MP3 disc, the

•

appearance of the menu may be
different.

To change the album,
use to

3

select another album
in Stop mode, and
then press the
ENTER button.

In Stop mode, use

to select

2

the album, and
then press the
ENTER button.

Press the STOP
button to stop

4

playback.

OPERATION

To select another album and track,

•

repeat Steps 2 and 3 above.

Depending on the recording mode, some MP3-CDs may not play.

Note

•

Table of contents of a MP3-CD varies depending on the MP3 track format recorded on the disc.

•

MP3 file support: MPEG1 LAYER3 (BITRATE : 128KBPS~320KBPS , SAMPLING FREQ.:

•

32K/44.1K/48KHz)

20

JPEG File Playback

Images captured with a digital camera or camcorder, or JPEG files on a PC can be
stored on a CD and then played back with this DVD player.

JPEG

Slide Mode

1

2

•

•

3

•

•

Place the JPEG disc on the disc tray.

Press the OPEN/CLOSE button.

Playback starts automatically.
Each image is shown for 5 seconds before another image is displayed.

Press SLIDE MODE button.

Playback starts automatically.
Each time the button is pressed, the image makes the transition as follows:

From top to bottom

From bottom to top

21

Rectangular shape in the center

Vertical curtain shape

Each time a new image is displayed, slide modes
(1~11) will be randomly and automatically be applied.

Cancels the slide mode.

Press to skip to the next slide.

Each time the button is pressed, the slide moves backward or forward.

•

Digest Function

You can view 9 JPEG images on the TV screen.

Press DIGEST
button during

1

playback.

JPEG files will be shown in

•

9 windows.

To view the previous or next image with 9 windows, press .

Press Cursor , , , buttons
to select the desired image and

2

then press ENTER button.

The selected image is played for 5 seconds before moving to

•

the next image.

Rotate/Flip Function

Press Cursor , , , buttons during playback.

OPERATION

Original Image

button: Flip Vertically

button: Rotate 90°
Counterclockwise

button: Flip Horizontally

22

Displaying Disc Information

Something like you
Back for good
Love of my life
More than words

DVD RECEIVER SMART NAVI

You can view playback information on the disc on the TV screen.

Press INFO button.

Each time the button is pressed, the display changes as follows:

•

DVD

The information display

disappears from the screen

Note

Depending on the disc, the disc

•

information display may appear different.
Depending on the disc, you can also

•

select DTS, DOLBY DIGITAL, or PRO
LOGIC.

VCD CD

The information display

disappears from the screen

appears on the TV screen!

•

If this symbol appears on the TV screen while buttons are being operated, that
operation is not possible with the disc currently being played.

What is a Title?

•

A movie contained in a DVD disc.

What is a Chapter?

•

Each title on a DVD disc is divided into several smaller sections called "chapters".

What is a Track (File)?

•

A section of video or a music file recorded on a VCD, CD, or MP3-CD.

MP3 JPEG

The information display

disappears from the screen

Screen Display

DVD display

VCD display

CD display

23

MP3 CD display

TITLE display

CHAPTER display

TRACK (FILE) display

ELAPSED TIME display

REPEAT PLAYBACK display

AUDIO LANGUAGE display

SUBTITLE display

STEREO (L/R) display

DOLBY DIGITAL display

ANGLE display

Checking the Remaining Time

TRACK REMAIN

TOTAL ELAPSED

TOTAL REMAIN

TRACK ELAPSED

CHAPTER REMAIN

TITLE REMAIN

CHAPTER ELAPSED

TITLE ELAPSED

TRACK ELAPSED

TRACK REMAIN

Press the REMAIN button.

For checking the total and remaining time of a title or chapter

•

being played.

Each time the REMAIN button is pressed

DVD

MP3

CDVCD

24

Fast/Slow Playback

Fast Playback

Press and hold .

Each time the button is held down during playback,

•

the playback speed changes as follows:

DVD VCD CD MP3

Slow Playback

Press SLOW button.

Each time the button is pressed during playback,

•

the playback speed changes as follows:

25

DVD

VCD

Note

Reverse slow playback does not work with VCDs.

•

Skipping Scenes/Songs

TITLE 01/05 CHAPTER 002/040

TITLE 01/05 CHAPTER 004/040

Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl

DVD RECEIVER SMART NAVI

Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl

DVD RECEIVER SMART NAVI

Something like you
Back for good
Love of my life
More than words
I need you
My love
Uptown girl

DVD RECEIVER SMART NAVI

DVD VCD MP3

Briefly press .

Each time the button is pressed briefly during playback, the previous or next chapter, track, or

•

directory (file) will be played.
You cannot skip chapters consecutively.

•

DVD

VCD MP3

When watching a VCD with a track

•

longer than 15 minutes, each time

is pressed, playback

will skip back or forward 5 minutes.

OPERATION

Playing Frame by Frame

Press STEP button.

The picture moves forward one frame each time the

•

button is pressed during playback.

Note

During fast playback of a CD or MP3-CD, sound is heard only at 2x speed,

•

and not at 4x, 8x, and 32x speeds.
No sound is heard during slow playback and step motion playback.

•

DVD VCD

26

Repeat Playback

Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file).

DVD VCD CD MP3 JPEG

Press REPEAT button.

Each time the button is pressed during playback, the repeat playback mode changes as follows:

•

DVD

VCD CD

MP3 JPEG

Repeat Playback Options

CHAPTER

Repeatedly plays the selected chapter.

TITLE

Repeatedly plays the selected title.

RANDOM

Plays tracks in random order.
(A track that has already been played may
be played again.)

TRACK

Repeatedly plays the selected track.

DIR

Repeatedly plays all tracks in the selected
folder.

DISC

Repeatedly plays the entire disc.

OFF

Cancels Repeat Playback.

To Select a Repeat Playback Mode in the Disc Information Screen

Note

Repeat playback operation is

•

not possible with version 2.0
VCD discs if PBC is turned
on. To use Repeat Playback
on a VCD with PBC, you
should set the PBC to OFF in
the disc menu. (See page 33.)

27

Press INFO button twice.

1

Press Cursor button to

2

move to REPEAT
PLAYBACK ( ) display.

Press Cursor button

3

to select the desired
Repeat Playback mode.

Press ENTER button.

4

For MP3 and JPEG discs, you cannot select Repeat

*

Play from the information display screen.

DVD

VCD CD

A-B Repeat Playback

A -

A -?

REPEAT : A—

A - B

REPEAT : A—B

DVD VCD CD

Press INFO button
twice.

1

For a VCD or CD, press INFO

•

button once.

Press Cursor , buttons
to select ‘A-’ and then press

3

ENTER button at the beginning

of the desired segment.

When ENTER button is pressed,

•

the selected position will be stored in
memory.

Press Cursor button
to move to REPEAT

2

PLAYBACK ( ) display.

Press ENTER
button at the end

4

of the desired
segment.

The specified segment will be played

•

repeatedly.

OPERATION

To return to normal playback, press Cursor ,
buttons to select OFF.

Note

The A-B Repeat function will not work on an MP3 or JPEG disc.

•

28

Angle Function

1/3

2/3

3/3

1/3

1/3

This function allows you to view the same scene in different angles.

DVD

Press Cursor

Press INFO button.

1

Press Cursor , buttons or numeric buttons
to select the desired angle.

3

button to move to

2

ANGLE ( )
display.

Each time the button is pressed, the angle changes as follows:

•

Note

29

The Angle function works only with discs on which multiple angles have been recorded.

•

Zoom Function

This function allows you to enlarge a particular area of the displayed image.

Zoom (Screen Enlarge) Function

Press ZOOM
button.

1

SELECT ZOOM POSITION

Aspect Ratio

Press Cursor , ,

, buttons to

move to the area

2

you want to enlarge.

DVD

DVD VCD

Press ENTER
button.

3

Each time the button is pressed, the

•

zoom level changes as follows:

OPERATION

Press EZ VIEW button.

Each time the button is pressed, the zoom function will switch between On

•

and Off.
When a movie is played in Widescreen format, black bars at the top and

•

bottom of the TV screen can be removed by pressing the EZ VIEW button.

EZ VIEW OFFEZ VIEW

Note

This function will not work if the DVD is recorded with multi-camera angle format.

•

Black bars may not disappear because some DVD discs have a built-in horizontal to vertical ratio.

•

30

Selecting Audio/Subtitle Language

SP 2/3

FR 3/3

EN

Audio Language Selection Function

Press INFO button
twice.

1

Subtitle Language Selection Function

Press INFO button
twice.

1

DVD

Press Cursor ,
buttons or numeric
buttons to select the

2

desired audio language.

Depending on the number of languages on a

•

DVD disc, a different audio language (ENGLISH,
SPANISH, FRENCH, etc.) is selected each
time the button is pressed.

DVD

Press Cursor
button to move to
SUBTITLE ( )

2

display.

3

31

Press Cursor
button or numeric
buttons to select
the desired subtitle.

EN 1/3

EN 01/ 03

SP 02/ 03

FR 03/ 03
OFF / 03

OFF

Note

You can use the SUBTITLE

•

button on the remote control to
select a subtitle language.
Depending on the disc, the

•

Subtitle and Audio Language
functions may not work.

Moving Directly to a Scene/Song

01/05

001/040 0:00:37 1/1

03/05

001/002 0:00:01 1/1

01/05

001/040 0:00:01 1/1

01/05

025/040 0:00:01 1/1

01/05

028/040 1:30:00 1/1

01/05

025/040 1:17:30 1/1

DVD VCD CD

Press INFO button.

1

Moving to a Chapter

Press Cursor , buttons
or numeric buttons to select
the desired chapter and then

4

press ENTER button.

Moving to a Title/Track

Press Cursor , buttons
or numeric buttons to select
the desired title/track and then

2

press ENTER button.

Moving to a Specific Time

Press Cursor ,
buttons to move to

5

time display.

Moving to a Chapter

Press Cursor ,
buttons to move to
Chapter ( )

3

display.

Moving to a Specific Time

Press the numeric
buttons to select the
desired time and then

6

press ENTER button.

OPERATION

MP3 JPEG

Press the numeric
buttons.

•

•

•

The selected file will be played.
An MP3 or JPEG disc cannot be moved
from the disc information screen.
When playing an MP3 or JPEG disc, you
cannot use , to move a folder.
To move a folder, press (Stop) and
then press , .

Note

You can press on the remote

•

control to move directly to the desired
title, chapter, or track.
Depending on the disc, you may not

•

be able to move to the selected title or
time.

32

DVD

Using Disc Menu

You can use the menus for the audio language, subtitle language, profile, etc.
DVD menu contents differ from disc to disc.

In Stop mode,
press MENU

1

button.

When playing a VCD (version 2.),

•

this toggles between PBC ON
and OFF.

Press Cursor , ,

, buttons to

3

select the desired
item.

Press Cursor ,
buttons to move to

2

‘DISC MENU’ and then
press ENTER button.

When you select the disc menu that is not

•

supported by the disc, the "This menu is not
supported" message appears on the screen.

Press ENTER
button.

4

Note

PBC (Playback Control) Function

Press the MENU button while VCD 2.0 version disk is played.

Each time you press the button, "PBC ON" and "PBC OFF" will be repetitively selected in the display.

• PBC ON: This VCD disc is version 2.0. The disc is played back according to the menu screen.
Some functions may be disabled. When some functions are disabled, select "PBC OFF" to enable them.

• PBC OFF: This VCD disc is version 1.1. The disc is played back in the same way as with a music CD.

33

DVD

Using the Title Menu

For DVDs containing multiple titles, you can view the title of each movie.
Depending on the disc, this function may either not work at all or may work differently.

In Stop mode,
press MENU

1

button.

Press Cursor ,
button to move to

2

‘Title Menu’.

Press ENTER
button.

3

The title menu appears.

•

OPERATION

Press MENU button to exit the setup screen.

34

Setting the Language

OSD language is set to English by default.

In Stop mode,

press MENU

button.

Press Cursor
button to move to

21

‘Setup’ and then

press ENTER button.

35

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

Press ENTER

button.

3

4

Press Cursor ,
button to select the
desired item and then

press ENTER button.

5

•

Press Cursor ,
button to select the
desired language and then

press ENTER button.

Once the setup is complete, if the language was
set to English, OSD will be displayed in English.

SETUP

Selecting the

OSD Language

Selecting the

Audio Language

(recorded on the disc)

Selecting the

Subtitle Language

(recorded on the disc)

Selecting the Disc Menu

Language (recorded on the disc)

If the language you selected is

*

not recorded on the disc, menu
language will not change even
if you set it to your desired
language.

36

Setting TV Screen type

Depending on your TV type (Wide Screen TV or conventional 4:3 TV), you can select the
TV's aspect ratio.

In Stop mode,

press MENU

button.

Press Cursor
button to move to ‘TV
DISPLAY’ and then

Press Cursor
button to move to

21

‘Setup’ and then

press ENTER button.

Press Cursor ,
button to select the

43

desired item and then

press ENTER button.

Once the setup is complete, you will

•

be taken to the previous screen.

37

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

Adjusting the TV Aspect Ratio (Screen Size)

The horizontal to vertical screen size ratio of conventional TVs is 4:3, while that of wide screen and high
definition TVs is 16:9. This ratio is called the aspect ratio. When playing DVDs recorded in different
screen sizes, you should adjust the aspect ratio to fit your TV or monitor.

✱ For a standard TV, select either "4:3LB" or "4:3PS" option according to

personal preference. Select "16:9" if you have a widescreen TV.

WIDE

4:3LB

(4:3 Letterbox)

4:3PS

(4:3 Pan&Scan)

Note

• If a DVD is in the 4:3 ratio, you cannot view it in widescreen.

• Since DVD discs are recorded in various image formats, they will look different depending on
the software, the type of TV, and the TV aspect ratio setting.

: Select this to view a 16:9 picture in the full-screen

mode on your widescreen TV.

•You can enjoy the widescreen aspect.

: Select this to play a 16:9 picture in the letter box

mode on a conventional TV.

•Black bars will appear at the top and bottom of the screen.

: Select this to play a 16:9 picture in the pan & scan

mode on a conventional TV.

•You can see the central portion of the screen only (with the
sides of the 16:9 picture cut off).

SETUP

38

Setting Parental Controls (Rating Level)

Use this to restrict playback of adult or violent DVDs you do not want children to view.

In Stop mode,

press MENU

button.

Press Cursor
button to move to

21

‘Setup’ and then

press ENTER button.

39

Press Cursor
button to move to
‘PARENTAL’ and then

3 5

press ENTER button.

Press Cursor ,
buttons to select the
desired rating level and

4

then press ENTER button.

Enter the password
and then press

ENTER button.

If you have selected Level 6, you

•

cannot view DVDs with Level 7 or
higher.
The higher the level, the closer the

•

content is to violent or adult material.

Note

This function works only if a DVD disc contains rating level information.

•

The password is set to "7890" by default.

•

Once the setup is complete, you will be

•

taken to the previous screen.

SETUP

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

40

Setting the Password

You can set the password for the Parental (rating level) setting.

Press Cursor

Press MENU button.

button to move to

21

‘Setup’ and then

press ENTER button.

41

Note

The password is set to "7890" by default.

•

Press Cursor button to
move to ‘PASSWORD’

and then press ENTER

3 5

button.

4

Press ENTER

button.

Enter the old password, a new

•

password, and confirm new password.
The setting is complete.

•

Enter the password
and then press

ENTER button.

SETUP

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

42

Setting the Wallpaper

While watching a DVD, VCD or JPEG CD, you can set the image you like as a wallpaper.

VCD DVDJPEG

Setting the Wallpaper

During playback, press

PLAY/PAUSE button

when the image you
like comes up.

PAUSE

The power will turn off
and then back on and
the disc tray will open
automatically.

The selected wallpaper will be

•

displayed.

Press LOGO

21

•

43

•

button.

“COPY LOGO DATA” will be

displayed on the TV screen.

COPY LOGO DATA

Press OPEN/
CLOSE to close

the disc tray.

You can repeat Steps 1 and 2 to
set up to 3 wallpapers.

43

Select this to set the
Samsung Logo image as
your wallpaper.

Select this to set the desired
image as your wallpaper.

To Change the Wallpaper

In Stop mode,

press MENU

button.

Press to select
the desired ‘USER’,
and then press

ENTER.

Press Cursor
button to move to
‘Setup’ and then

21 3

press ENTER button.

Press MENU

54

button to exit the
setup screen.

Press Cursor
button to move to
‘LOGO’ and then

press ENTER button.

SETUP

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

44

Setting the Speaker Mode

Signal outputs and frequency responses from the speakers will automatically be adjusted
according to your speaker configuration and whether certain speakers are used or not.

In Stop mode,

press MENU

button.

In the Speaker
Setup, press the

ENTER button again.

Press Cursor
button to move to
‘Audio’ and then

21

press ENTER button.

Press Cursor , ,

, buttons to move

to the desired

43

speaker and then

press ENTER button.

For C, LS, and RS, each time the button

•

is pressed, the mode switches

alternately as follows: SMALL ➝ NONE.

For L and R, the mode is set to SMALL.

•

45

SMALL

: Select this when using the speakers.

NONE : Select this when no speakers are installed.

Note

Depending on PRO LOGIC and STEREO, the speaker mode may vary.

•

Setting the Test Tone

Press the Test Tone to check the speaker connections and to adjust the speaker levels.

In Stop mode,

press MENU

button.

Press RETURN button to return to the previous level.

Press Cursor
button to move to
‘Audio’ and then

21

press ENTER button.

Press Cursor button
to move to ‘TEST
TONE’ and then press

3

ENTER button.

The test tone will be sent to L ➝ C ➝

•

R ➝ RS ➝ LS ➝ SW in that order.

If the ENTER button is pressed again
at this time, the test tone will stop.

SETUP

Press MENU button to exit the setup screen.

When manually testing using the TEST TONE button

Press TEST TONE button.

Test tone will be produced as follows:

•

When playing a DVD or CD, this will work
only in Stop mode.
Use this function to check that each speaker is

•

correctly connected and that there is no problem.

To end the test tone,

press TEST TONE button.

Multi-Channel Pro Logic Mode

L: Front Speaker (L) C: Center Speaker SW: Subwoofer
R: Front Speaker (R) LS: Rear Speaker (L) RS: Rear Speaker (R)

Start

46

Setting the Delay Time

If the speakers cannot be placed at equal distances from the listening position, you can adjust the
delay time of the audio signals from the center and rear speakers.

In Stop mode,

press MENU

1

button.

Press Cursor button
to move to ‘Audio’ and

2

then press ENTER

button.

47

Setting up the Speaker Delay Time

When 5.1CH Surround Sound is played, you can enjoy the best sound if
the distance between you and each speaker is the same. Since the sounds
arrive at the listening position at different times depending on the
placement of speakers, you can adjust this difference by adding a delay
effect to the sound of the Center and Surround Speakers.

Note

With (Dolby Pro Logic II), the delay time may be different for each

•

mode.
With AC-3 and DTS, the delay time can be set between 00 and 15mSEC.

•

Press Cursor button
to move to ‘DELAY
TIME’ and then press

43 5

ENTER button.

Press Cursor , ,

, buttons to move
to the desired
speaker and then

press ENTER button.

Press Cursor ,
to set the Delay
time

You can set the delay time for C

•

between 00 and 05mSEC and for
LS and RS between 00 and
15mSEC.

SETUP

Setting CENTER SPEAKER

•

If the distance of Dc is equal to or longer than the
distance of Df in the figure, set the mode as 0ms.
Otherwise, change the setting according to the table.

Distance between Df and Dc Delay Time

0 Inches

13.6 Inches

27.2 Inches

40.8 inches

54.4 Inches

68.0 inches

• Setting REAR (SURROUND) SPEAKERS

If the distance of Df is equal to the distance of Ds
in the figure, set the mode as 0ms. Otherwise,
change the setting according to the table.

Distance between Df and Ds Delay Time

0 Inches

40.8 Inches

81.6 Inches

122.4 inches

163.0 Inches

203.8 inches

0 ms
1 ms
2 ms
3 ms
4 ms
5 ms

0 ms
3 ms
6 ms

9 ms
12 ms
15 ms

Ideal CENTER
SPEAKER placement

Ideal
SURROUND
SPEAKER
placement

It is desirable to place all speakers within this circle.

Df: The distance from FRONT SPEAKER
Dc: The distance from CENTER SPEAKER
Ds: The distance from SURROUND SPEAKER

48

Setting the Audio Quality

You can adjust the balance and level for each speaker.

Method 1

When adjusting the audio quality using the setup screen

In Stop mode,

press MENU

button.

Press Cursor button
to move to ‘SOUND
EDIT’ and then press

ENTER button.

Press Cursor
button to move to

21

‘Audio’ and then press

ENTER button.

Press Cursor , , ,

buttons to select and

43

adjust the desired item and

then press ENTER button.

49

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

Method 2

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

When manually adjusting with the SOUND EDIT button

Adjusting Front Speaker Balance Adjusting Rear Speaker Balance

Press SOUND
EDIT button and

then press Cursor

21

, .

Adjusting Rear Speaker Level

Adjusting Subwoofer Speaker Level

Press SOUND
EDIT button and

then press Cursor

4 5

, .

Press SOUND
EDIT button and

then press Cursor

, .

Press SOUND
EDIT button and

then press Cursor

, .

Adjusting Center Speaker Level

Press SOUND
EDIT button and

then press Cursor

3

, .

SETUP

Note

Adjusting Front/Rear Speaker Balance

You can select between 00 and –06 and OFF.

•

The volume decreases as you move closer to –6.

•

Adjusting Center/Rear/Subwoofer Speaker Level

The volume level can be adjusted in steps from +6dB to –6dB.

•

The sound gets louder as you move closer to +6dB and quieter as you get closer to -6dB.

•

50

Setting the DRC (Dynamic Range Compression)

You can use this function to enjoy Dolby Digital sound when watching movies at
low volume at night.

In Stop mode, press

12

34

MENU button.

Press Cursor button to
move to ‘DRC’ and then

press ENTER button.

•

Press Cursor button to
move to ‘Audio’ and then

press ENTER button.

Press Cursor , to
adjust the ‘DRC’.

The Cursor button is pressed, the greater the effect, and
the Cursor button is pressed, the smaller the effect.

51

Press RETURN button to return to the previous level.

Press MENU button to exit the setup screen.

Sound Field (DSP)/EQ Function

DSP(Digital Signal Processor) DSP modes have been designed to simulate different acoustic environments.
EQ: You can select from ROCK, POP, or CLASSIC, depending on the genre of music.

Press DSP/EQ button.

"DSP" appears on the display panel.

•

Each time the button is pressed, the selection changes as follows:

•

Note

POP, JAZZ, ROCK: Depending on the genre of music, you can select from POP, JAZZ, and ROCK.
STUDIO : Provides a sense of presence as if in a studio.
CLUB : Simulates the sound of a dance club with a throbbing bass beat.
HALL : Provides a clear vocal as if listening in a concert hall.
MOVIE: Provides the feeling of a movie theater.
CHURCH: Gives the feel of being in a grand church.

This feature works with CDs, MP3-CDs and 2 channel

•

DVD-Audio and Dolby Digital discs.
When playing a DVD disc encoded with two or mor channels,

•

multi-channel mode will be selected automatically and
DSP/EQ function does not work.

SETUP

52

Dolby Pro Logic II Mode

You can select the desired Dolby Pro Logic II audio mode.

Press PL II MODE button.

Each time the button is pressed, the mode changes as follows.

•

Note

53

When selecting Pro Logic II mode, connect your external device to the

•

AUDIO INPUT jacks (L and R) on the player. If you connect to only one of
the inputs (L or R), you cannot listen to 5.1 channel surround sound.

PRO LOGIC II

MUSIC: When listening to music, you can experience sound effects as if you are listening to the actual performance.

•

CINEMA: Adds realism to the movie soundtrack.

•

PRO LOGIC: You will experience a realistic multi-channel effect, as if using five speakers,

•

while using just the front left and right speakers.

MATRIX: You will hear 5.1 channel surround sound.

•

STEREO: Select this to listen to sounds from the front left and right speakers and the

subwoofer only.

Dolby Pro Logic II Effect

DSP

CMX

LINEAR PCM

MPEG-2 AAC MPEG

L C R

SW

LS RS

TITLE PBC

CHAP

PRGM RDS RT

TA TUNED

kHz

MHz

ST

DSP

CMX

LINEAR PCM

MPEG-2 AAC MPEG

L C R

SW

LS RS

TITLE PBC

CHAP

PRGM RDS RT

TA TUNED

kHz
MHz

ST

DSP

CMX

LINEAR PCM

MPEG-2 AAC MPEG

L C R

SW

LS RS

TITLE PBC

CHAP

PRGM RDS RT

TA TUNED

kHz
MHz

ST

DSP

CMX

LINEAR PCM

MPEG-2 AAC MPEG

L C R

SW

LS RS

TITLE PBC

CHAP

PRGM RDS RT

TA TUNED

kHz
MHz

ST

This function works only in Dolby Pro Logic MUSIC mode.

Press PL II MODE

12

button to select ‘MUSIC’
mode.

Press

34

and then press Cursor ,

PL II EFFECT button

buttons to select the next mode.

You can select between 0 and 7.

•

Press
and then press Cursor ,
buttons to select the mode.

You can select either 0 or 1.

•

Press
and then press Cursor ,
buttons to select the mode.

You can select between 0 and 6.

•

PL II EFFECT button

PL II EFFECT button

SETUP

Note

When playing a DVD disc encoded with two or more channels, multi-channel mode will be

•

selected automatically and (Dolby Pro Logic II) button does not work.

PANORAMA: This mode extends the front stereo image to include the surround speakers for

•

an exciting "wraparound" effect with side wall imaging.

CENTER WIDTH: Sound is output to the center speaker only. The front left and right speakers

•

produce phantom sound.

DIMENSION: Incrementally adjusts the sound field (DSP) from the front or rear.

•

54

Listening to Radio

You can listen to the chosen band (FM, AM broadcast stations) by using either
the automatic or manual tuning operation.

Remote Control Unit

Press TUNER/
BAND button.

The selection toggles back

•

and forth between "FM" and
"AM" each time the

TUNER(BAND) button is

pressed.

Main Unit

Press the Function

button to select the
desired band (FM, AM).

Tune in to the
desired station.

21

Automatic Tuning 1

Automatic Tuning 2

Manual Tuning

When is pressed, a
preset broadcast station is
selected.

Press and hold to
automatically search for
active broadcasting stations.

Briefly press to
increase or decrease the
frequency incrementally.

Select a broadcast
station.

21

Automatic Tuning 1

PRESET and then press
button to select the preset station.

Automatic Tuning 2

then press and hold button to
automatically search the band.

Manual Tuning

press to tune in to a lower or
higher frequency.

Press the STOP ( )
button to select

Press the STOP
to select "MANUAL" and

Press STOP
MANUAL and then briefly

( )

( )

button

to select

55

Press MO/ST button to listen in Mono/Stereo.

(This applies only when listening to an FM station.)

Each time the button is pressed, the sound switches between "STEREO" and "MONO".

•

In a poor reception area, select MONO for a clear, interference-free broadcast.

•

Presetting Stations

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

TITLE

RDS RT

ST

TUNED

kHz

MHz

TITLE

RDS RT

ST

TUNED

kHz

MHz

TITLE

CHAP

RDS RT

ST

TUNED

kHz

MHz

You can store up to:

15 FM stations

•

15 AM stations

•

Example: Presetting FM 89.1 in the memory

Press the

TUNER(BAND)

button and select
the FM band.

• FM Frequency Modulation

• AM Medium Wave

Press to

21

select "89.10".

Press the TUNER

3

MEMORY button.

Each time the button is pressed,

•

the band switches between
"FM" and "AM".

Press
to select preset
number.

You can select between 1 and

•

15.

Refer to Step 2 on page 55 to

•

automatically or manually tune in
to a station.

Press the TUNER

MEMORY button

54

again.

Press the TUNER MEMORY button before

•

‘PRGM’ disappears from the display.
‘PRGM’ disappears from the display and

•

the station is stored in memory.

“PRGM” flashes in the display.

•

To preset another
station, repeat

6

steps 2 to 5.

RADIO OPERATION

To tune in to a preset station, press on the
remote control to select a channel.

56

Convenient Functions

Sleep Timer Function

You can set the time that the DVD player will shut itself off.

Press SLEEP button.

"SLEEP" will be displayed. Each time the button is pressed,

•

the preset time changes as follows: 10 ➝ 20 ➝ 30 ➝ 60 ➝
90 ➝ 120 ➝ 150 ➝ OFF.

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz

MHz

To confirm the sleep timer setting, press SLEEP button.

The remaining time before the DVD player will shut itself off is displayed.

•

Pressing the button again changes the sleep time from what you have set

•

earlier.

To cancel the sleep timer, press SLEEP button until

OFF appears on the display.

57

Adjusting Display Brightness

TITLE

CHAP

PRGM RDS RT

ST

TUNED

kHz
MHz

You can adjust the brightness of the display on the
main unit so it won't interfere with your movie viewing.

Press DIMMER button.

Each time the button is pressed, the brightness changes as

•

follows: SLIGHTLY DARK ➞ DARK ➞ BRIGHT.

Mute Function

This is useful when answering a doorbell or
telephone call.

Press MUTE button.

‘MUTE’ flashes in the display.

•

To switch the sound back on (at the same volume as

•

before), press MUTE again or the VOLUME buttons.

58

MISCELLANEOUS

Before Calling for Service

Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not
listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact
the nearest authorized dealer or Samsung Electronics Service Center.

Symptom Check/Remedy

Disc tray does not open.

Playback does not start.

Playback does not start
immediately when the
Play/Pause button is pressed.

Sound is not produced.

Sound can be heard only
from a few speakers and
not all six.

Is the power cord plugged securely into the outlet?

•

Turn off the power and then turn it back on.

•

Check the region number of the DVD.

•

DVD discs purchased from abroad may not be playable.
CD-ROMs and DVD-ROMs cannot be played on this DVD

•

player.
Make sure that the rating level is correct.

•

Are you using a deformed disc or a disc with scratches on

•

the surface?
Wipe the disc clean.

•

No sound is heard during fast playback, slow playback, and step

•

motion playback.
Are the speakers connected properly? Is the speaker setup

•

correctly customized?
Is the disc severely damaged?

•

When listening to a CD or radio, sound is output to the front

•

speakers (L/R) only. Select "PRO LOGIC II" by pressing
(Dolby Pro Logic II) on the remote control to use all six speakers.
Make sure that the DVD disc is 5.1-CH compatible.

•

If you set C, SL, and SR to NONE in the speaker mode in the

•

audio setup of the setup screen, no sound is heard from the
center speaker and the front left and right speakers. Set C, SL,
and SR to SMALL.

Picture does not appear, sound
is not produced, or the disc
tray opens 2 to 5 seconds later.

Dolby Digital 5.1 CH
Surround Sound is not
produced.

Was the DVD player suddenly moved from a cold place to a warm

•

one? When condensation forms inside the player, remove the disc
and let the player stand for 1 or 2 hours with the power on. (You
can use the player again after condensation disappears.)

Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby Digital 5.1

•

CH Surround Sound is produced only if the disc is recorded with

5.1 channel sound.
Is the audio language correctly set to DOLBY DIGITAL 5.1-CH in

•

the information display?

59

Symptom Check/Remedy

Is the TV power on?

• Disc is rotating but no
picture is produced.

• Picture quality is poor and

•

Are the video cables connected properly?

•

Is the disc dirty or damaged?

•

A poorly manufactured disc may not be playable.

•

picture is shaking.

Is the remote control being operated within its operation range of

The remote control does not
work.

•

angle and distance?
Are the batteries exhausted?

•

Audio language and
subtitles do not work.

Menu screen does not appear even
when the menu function is selected.

Aspect ratio cannot be
changed.

Can't receive radio
broadcast.

•

The main unit is not working.

(Example: The power goes out or
a strange noise is heard.)

• The DVD player is not
working normally.

The password for rating
level has been forgotten.

Audio language and subtitles will not work for DVDs not containing

•

them. And depending on the disc, they may work differently.

Are you using a disc that does not contain menus?

•

You can play 16:9 DVDs in 16:9 WIDE mode, 4:3 LETTER BOX

•

mode, or 4:3 PAN SCAN mode, but 4:3 DVDs can be seen in 4:3
ratio only. Refer to the DVD disc jacket and then select the
appropriate function.

Is the antenna connected properly?

•

If the antenna's input signal is weak, install an external FM

•

antenna in an area with good reception.

Turn off the power and hold the button on the main unit for

•

longer than 5 seconds.

Using the RESET function will erase all stored settings.
Do not use this unless necessary.

While “NO DISC” message appears on the display of main unit, hold

•

the main unit's button for longer than 5 seconds. “INITIALIZE”
appears on the display and all settings will return to the default values.
Press the POWER button.

•

Using the RESET function will erase all stored settings.
Do not use this unless necessary.

MISCELLANEOUS

60

Cautions on Handling and Storing Discs

Small scratches on the disc may reduce sound and picture quality or cause breaks in
playback. Be especially careful not to scratch discs when handling them.

Handling discs

Do not touch the playback side of the disc. Hold
the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.

Disc Storage

Do not keep in
direct sunlight

Caution

•

•

Do not allow the discs to become contaminated with dirt.
Do not load cracked discs or discs that are scratched.

Keep in a cool
ventilated area

Handling and Storing Discs

When you get fingerprints or dirt on the disc, clean it
with a mild detergent diluted in water and wipe with a
soft cloth.

When cleaning, wipe gently from the inside to the outside of the disc.

•

Note

Keep in a clean
Protection jacket.
Store vertically.

61

Condensation may form if warm air comes into contact with cold parts

•

inside the player. When condensation forms inside the player, the player
may not operate correctly. If this occurs, remove the disc and let the
player stand for 1 or 2 hours with the power on.

Specifications

M

M

G

Power Consumption

E

Weight

N
E

Dimensions (W x H x D)

R

Operating Temperature Range

A

Operating Humidity Range

L

T

Usable Sensitivity

U

F

N

S/N Ratio

E
R

Distortion

T

Usable Sensitivity

U

A

N

S/N Ratio

E
R

Distortion
Composite Video

O

V

U

I

Component Video

T

D

P

E

U

O

S-VIDEO

T

Front speaker output

A
M

Center speaker output

P

Rear speaker output

L

Subwoofer speaker output

I

Frequency range

F

S/N Ratio

I

Channel separation

E
R

Input sensitivity

Speaker system

S

Impedance

P

Frequency range

E
A

Output sound pressure level

K

Rated input

E

Maximum input

R

Dimensions
Weights

(W x H x D)

110W

13.7Ibs

14.2 x 2.6 x 16.1 inches
41°F ~ 95°F

10% ~ 75%
10dB

60dB

0.5%
54dB
40dB
2%

1.0Vp-p(75Ω load)
Y:1.0Vp-p(75Ω load)
Pr:0.70Vp-p(75Ω load)
Pb:0.70Vp-p(75Ω load)
Luminance Signal: 1.0Vp-p(75Ω load)
Color Signal: 0.286Vp-p(75Ω load)
40W(6Ω)/CH
40W(6Ω)
40W(6Ω)/CH
55W(3Ω)
20Hz~20kHz
75dB
50dB
(AUX)500mV

5.1ch speaker system

Front/Center/Rear speaker

6Ω x 5
150Hz~20kHz
85dB/W/M
40W
80W

3.3 x 3.7 x 3.7 inches

0.7 Ibs

3Ω
30Hz~150Hz
86dB/W/M
55W
110W

5.1 x 12.6 x 13.2 inches

9.5 Ibs

Subwoofer speaker

MISCELLANEOUS

62

Notes on Terminology

Recorded onto some DVD discs are scenes which have been simultaneously shot from a number

ANGLE

of different angles (the same scene is shot from the front, from the left , from the right , etc.).
With such discs, the Angle button can be used to change the angle of view for specific scenes.

CHAPTER

NUMBER

DVD

PCM

PBC

(PLAYBACK

CONTROL)

REGION NUMBER

SUBTITLES

TITLE NUMBER

TRACK NUMBER

These numbers are recorded on DVD discs. A Title is subdivided into many
sections, each of which is numbered, and specific parts of the video can be
searched quickly using these numbers.

A high-density optical disc on which high-quality pictures and sound have been recorded by
means of digital signals. Incorporating a new video compression technology (MPEG-2) and high­density recording technology, a DVD disc comprises two 0.6 mm thick discs bonded together.

An acronym for Pulse Code Modulation - another name for digital audio.

This is recorded on a video CD (version 2.0). Selected scenes or information can
be chosen from the menu displayed on the TV monitor.

Both the DVD player and DVD discs are encoded with a region number.
If the region number on the DVD disc does not correspond to the region number
of the DVD player, the player cannot play the disc.

Translated appearing at the bottom of the screen. A DVD disc can contain up to
32 subtitle languages.

These numbers are recorded on DVD discs. When a disc contains two or more
movies, these movies are numbered as Title 1, Title 2, etc.

These numbers are assigned to the tracks which are recorded on video and
audio CDs. They enable specific tracks to be located quickly.

63

VIDEO CD

Contains recordings of pictures and sound whose quality is roughly comparable
to that of video tape.
This player also supports video CDs with playback control (version 2.0).

You can enjoy 5.1 (or 6) channels of high fidelity digital sound from various
digital input sources such as DVD, CD etc.
DTS provides a realistic, clear surround sound that has not previously been
available from conventional surround sound.

5.1 (or 6) Channel Digital Surround sound reproduced from DVDs and LDs
recorded as a digital signals (with disc marking). With better sound quality,
dynamic range, and directionality than traditional Dolby surround technology, you
can enjoy dynamic, realistic sound.

A 4 channel analog sound reproduced from a program source such as a
videotape or LD with the mark. You can enjoy a more realistic, robust
sound unavailable from regular stereo sources.

Samsung Limited Warranty

Samsung Electronics Canada Inc. (SECA), warrants that this product is

free from defective material and workmanship.
SECA further warrants that if this product fails to operate properly within the

specified warranty period and the failure is due to improper workmanship or
defective material SECA will repair or replace the product at its option.

All warranty repairs must be performed by a SECA authorized service
centre. (The name and address of the location nearest you can be obtained by
calling toll free 1-800-726-7864 or visiting our web site at

www.samsung.ca)

Labour Parts

one (1) year (carry-in) one (1) year

On carry-in models, transportation to and from the service centre is the
customer’s responsibility.

The original dated sales receipt must be retained by the customer and is the
only acceptable proof of purchase. It must be presented to the authorized
service centre at the time service is requested.

Exclusions

This warranty does not cover damage due to accident, fire flood and/or other
acts of God; misuse, incorrect line voltage, improper installation, improper or
unauthorized repairs, commercial use, or damage that occurs in shipping.
Exterior and interior finish, lamps and glass are not covered under this
warranty. Customer adjustments which are explained in the instruction
manual are not covered under the terms of this warranty.
This warranty will automatically be voided for any unit found with a
missing or altered serial number. This warranty is valid only on products
purchased and used in Canada.

MISCELLANEOUS

64

SAMSUNG ELECTRONICS CANADA, INC.

HEADQUARTERS

7037 Financial Drive, Mississauga, Ontario, Canada L5N 6R3

TEL: [phone]

www.samsung.ca

SERVICE DIVISION

7037 Financial Drive, Mississauga, Ontario, Canada L5N 6R3

1-800-SAMSUNG (1-800-726-7864)

AH68-01489S
