Turning the PDP On and Off
30 31
T urning the PDP On and Off
Press the Power button on the remote control.
The PDP will be turned on and you will be ready to use it’s
features.
You can also use the POWER( ) button on the front of the
PDP.
Notes:
• If your PDP isn’t turned on when the power button is
pressed: Press the
MODE
button to check if the TV mode
has been chosen ( ).
Viewing the Menus and Displays
Your PDP has a simple, easy-to-use menu system that appears on the PDP screen. This system makes it convenient and fast to use features on the PDP. Your PDP also lets you display the status of many of your PDP’s
features.
Viewing the Menus
1
With the power on, press the MENU button on the
remote control. The main menu appears on the screen.
The Picture menu is selected.
2
Press the UP/DOWN buttons to move items in the menu.
Press the LEFT/RIGHT buttons to display, change, or use
the selected items.
Press the ENTER ( ) button to enter items in the menu.
On screen menus disappear from the screen
automatically after about thirty seconds, or you can
press the EXIT button on your remote control to exit
the menu.
Displaying Status Information
Press the INFO button on the remote control. The PDP will
display the Picture mode, Sound mode, MTS, Signal and
Caption.
Press the INFO button on the remote control again.
The PDP will display the Clock.
Mode
Adjust
Color Tone
DNIe
Custom
Normal
On
Ant 6
Picture : Custom
Sound : Custom
MTS : Mono
Signal : Mono
Caption : Off
07 : 30 am
Move Enter Menu
Memorizing the Channels
Your PDP can memorize and store all of the available channels for both “off-air” (antenna)
and cable channels. After the available channels are memorized, use the CH and CH
buttons to scan through the channels. This eliminates the need to change channels by entering
the channel digits. There are three steps for memorizing channels: selecting a broadcast
source, memorizing the channels (automatic) and adding and deleting channels (manual).
32 33
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the type of
signal source that is connected to the PDP (i.e., an antenna or a cable system).
1
Press the MENU button. Press the UP or DOWN
button to select “Channel”, then press the ENTER
button.
2
Press the LEFT or RIGHT button to select “Ant”,
“STD”, “HRC” or “IRC”.
•If you are connected to an antenna, leave "Ant"
displayed. If you connected cable, press the
LEFT or RIGHT button to the display the type of
cable system: "STD", "HRC", or "IRC".
(If you are not sure which type of cable system you
have, contact your cable company).
3
Press the MENU button to exit.
Note
• STD, HRC and IRC identify various types of cable TV systems. Contact your local cable company
to identify the type of cable system that exists in your particular area.
At this point the signal source has been selected. Proceed to “Storing Channels in Memory”
(next page).
Storing Channels in Memory (Automatic Method)
1
First, select the correct signal source (Ant, STD, HRC,
IRC). See steps on previous page.
Press the MENU button. Press the UP or DOWN button
to select “Channel”, then press the ENTER button.
2
Press the UP or DOWN button to select “Auto Program”, then press the ENTER button.
3
The PDP will begin memorizing all of the available
channels.
After all the available channels are stored, the
Auto program menu reappears. Press the RIGHT
button to stop.
Note
• The PDP automatically cycles through all of the available channels and stores them in memory.
This takes about one to two minutes.
➤
➤
Quick way to access the Automatic Channel Setting : Just press the
“AUTO PROG.” button on the remote control.
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Channel
Ant
0
Off
Channel
STD
0
Off
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Enter Menu
Channel
Ant
0
Off
Channel
Ant
0
Off
Ant 50
Auto Program
: Stop
To View Memorized Channel (PIP Mode)
1
Press the MENU button. Press the UP or DOWN
button to select “Channel”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Ch Scan”,
then press the ENTER button.
Only the memorized channels are chosen.
Press the RIGHT button to stop.
34 35
Adding and Erasing Channels (Manual Method)
1
Use the number buttons to directly select the channel that
will be added or erased.
Ex) Channel “4”
2
Press the ADD/DEL button:
Repeatedly pressing this button will alternate between
“Added” and “Erased.”
Note
• You can view any channel (including an erased channel) by using the number buttons on the remote
control.
Ant 4
Ant 4
Added
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Enter Menu
Ch. Scan
Ant 7
: Stop
Channel
Ant
0
Off
Channel
Ant
0
Off
36 37
Setting Up Your Remote Control
This PDP's remote control can operate almost any VCR, cable box or DVD. After it has been set up
properly, your remote control can operate in four different modes :TV, VCR, Cable or DVD.
Pressing the corresponding button on the remote control allows you to switch between these modes,
and control whichever piece of equipment you choose.
Note :●The remote control may not be compatible with all DVD Players, VCRs, Cable boxes.
●
The remote control can operate only on STB made by Samsung.
Setting Up the Remote to Operate Your VCR, Cable box or DVD player
1
Turn off your VCR. (or Cable box, DVD player)
2
Press the MODE button. Mode is changed whenever
MODE button is pressed(New mode is displayed on
LED screen).
3
Press the SET button on your TV's remote control.
4
Using the number buttons on your remote control,
enter three digits of the VCR (or Cable box, DVD
player) code listed on page 38 of this manual for
your brand of VCR (or CATV, DVD). Make sure you
enter three digits of the code, even if the first digit
is a "0".
(If more than one code is listed, try the first one.)
5
Press the Power button on the remote control.
Your VCR (or CATV, DVD) should turn on if your
remote is set up correctly. If your VCR (or CATV,
DVD) does not turn on after setup, repeat steps
2, 3, and 4, but try one of the other codes listed for
your brand of VCR (or CATV, DVD).
If no other codes are listed, try each code, 000
through 089 (or Cable box: 000 through 077,
DVD player: 000 through 008).
Notes
• When your remote control is in “VCR” mode, the VCR control buttons (Stop, REW, Play/Pause, FF)
still operate your VCR.
• When your remote control is in “CATV” or “DVD” mode, the VCR control buttons (Stop, REW,
Play/Pause, FF) still operate your VCR.
Changing Channels
Using the Channel Buttons
Press the CH or CH buttons to change channels.
When you press the CH or CH buttons, the PDP changes channels
in sequence. You will see all the channels that the PDP has memorized.
(The PDP must have memorized at least three channels.)
You will not see channels that were either erased or not memorized.
Directly Accessing Channels
Press the number buttons to go directly to a channel. For example, to select
channel 27, press “2” then “7”. The TV will change channels when you
press the second number.
When you use the number buttons, you can directly select channels that were
either erased or not memorized. To change to single-digit channels (0~9) faster,
press “0” before the single digit. (For channel “4” press “0”, then “4”.
Using the Pre-CH button to select the previous channel
Press the PRE-CH button. The TV will switch to the last channel viewed.
To quickly switch between two channels that are far apart, tune to one
channel, then use the number button to select the second channel. Then,
use the PRE-CH button to quickly alternate between them.
Adjusting the Volume
Using the Volume Buttons
Press the VOL + or VOL – buttons to increase or decrease the volume.
Using Mute
Using the MUTE Buttons
At any time, you can temporarily cut off the sound using the MUTE button.
1
Press the MUTE button and the sound cuts off.
The word “Mute” will appear in the lower-left
corner of the screen.
2
To turn mute off, press the MUTE button again, or
simply press the VOL + or VOL – button.
Mute
38
PLASMA DISPLAY PANEL
Picture Control
Customizing the Picture ................................................................40
Using Automatic Picture Settings ....................................................41
Selecting the Color Tone................................................................42
DNIe (Digital Natural Image engine) ............................................43
Viewing the Picture-in-Picture..........................................................44
Changing the Screen Size ............................................................50
Freezing the Picture ......................................................................51
Remote Control Codes
VCR Codes
Cable Box Codes
DVD Codes
Customizing the Picture
You can use the on-screen menus to change the Contrast, Brightness, Sharpness, Color,
and Tint settings of your PDP.
41
1
Press the MENU button, then press the ENTER
button.
2
Press the LEFT or RIGHT button to select “Custom”,
“Dynamic”, “Standard” or “Movie” picture setting.
• You can select “High”, “Middle”, “Low” or
“Custom” in PC/DVI mode.
3
Press the MENU button to exit.
Using Automatic Picture Settings
Your PDP has automatic picture settings that allow you to adjust the video display easily.
40
1
Press the MENU button, then press the ENTER
button.
2
Press the UP or DOWN button to select “Adjust”,
then press the ENTER button.
You will also see the items “Contrast”, “Brightness”,
“Sharpness”, “Color” and “Tint”.
3
Press the UP or DOWN button to select the item you
wish to change.
4
Press the LEFT or RIGHT button to change the value
of the item.
5
Press the MENU button to exit.
Note
• In the PC/DVI mode, you can’t adjust the Color and Tint.
➤
➤
Quick way to access the picture setting: Just press the “P.MODE”
button under the cover of the remote control.
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Mode
Adjust
Color Tone
DNIe
Move Enter Menu
Contrast
Brightness
Sharpness
Color
Tint R 50 G 50
Move Adjust Menu
Custom
Custom
On
Custom
Normal
On
Adjust
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Custom
Custom
On
Dynamic
Custom
On
80
50
50
50
82Contrast
42
Selecting the Color Tone
1
Press the MENU button, then press the ENTER
button.
2
Press the UP or DOWN button to select “Color
Tone”, then press the LEFT or RIGHT button to select
“Normal”, “Warm1”, “Warm2”, “Cool2” or
“Cool1”.
• You can select “Custom”, “Color1”, “Color2” or
“Color3” in PC mode.
• You can select “Color1”, “Color2” or “Color3” in
DVI mode.
3
Press the MENU button to exit.
.
DNIe (Digital Natural Image engine)
Samsung’ s New Technology brings you more detailed images with contrast and
white enhancement and 3D noise reduction.
1
Press the MENU button, then press the ENTER
button.
2
Press the UP or DOWN button to select “DNIe”,
then press the LEFT or RIGHT button to select
“On”, “Off” or “Demo”.
•On : Switches on the DNIe mode.
•Demo : The screen before applying DNIe
appears on the right and the screen after
applying DNIe appears on the left.
•Off : Switches off the DNIe mode.
3
Press the MENU button to exit.
43
➤
➤
Quick way to select DNIe : Simply press the “DNIe” button under
the cover of the remote control.
DNIe Demo
DNIe On DNIe Off
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Custom
Custom
On
Custom
Normal
On
Custom
Custom
On
Custom
Normal
On
Mode
Adjust
Color Tone
DNIe
Move Select Menu
Mode
Adjust
Color Tone
DNIe
Move Select Menu
4544
Selecting an External Signal
You can use PIP to view a signal from an external source, such as a VCR.
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the UP or DOWN button to select “Source”.
3
Press the LEFT or RIGHT button to cycle through
all of the available signal sources:
“TV”, “Video”, “S-Video”, “Component 1”,
“Component 2”, “PC” and “DVI”.
The signal from these inputs will not appear if you
have not connected any equipment to the PDP's
respective input jacks.
4
Press the MENU button to exit.
Note
• The PIP function operates in Wide screen.
• Using Multi-Screen in the Normal, Zoom1 or Zoom2 screen will change the size of the main screen
to Wide screen.
Viewing the Picture-in-Picture
Selecting the PIPScreen
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the LEFT or RIGHT button to select “On”.
The PIP image will appear in the corner of the
screen.
•Pressing the LEFT or RIGHT button will alternate
between “On” and “Off.”
3
Press the MENU button to exit.
PIP Settings
PIP screen
Main screen
TV Video S-Video Component 1 Component 2 PC DVI
TV
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
X
X
X
X
O
O
O
X
X
X
X
O
O
O
X
X
X
X
O
O
O
X
X
X
X
Video
S-Video
Component 1
Component 2
PC
DVI
O:
PIP and Swap Operate
X:
PIP doesn’t Operate
➤
➤
Quick way to access the PIP mode: Just press the “PIP” button on
the remote control.
Select
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
Off
Select Menu
PIP
On
TV
Large
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
PIP
On
Video
Large
Move Select Menu
4746
Changing the Size of the PIP Window
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the UP or DOWN button to select “Size”.
3
Press the LEFT or RIGHT button to select “Small”,
“Double” or “Large”.
4
Press the MENU button to exit.
Swapping the Contents of the PIP Image and Main Image
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the UP or DOWN button to select “Swap”,
then press the ENTER button.
•The image in the PIP window will appear on the
main screen, and vice versa.
3
Press the MENU button to exit.
➤
➤
Quick way to access swapping: Just press the “SWAP” button under
the cover of the remote control.
➤
➤
Quick way to access the PIP size: Just press the “SIZE” button
under the cover of the remote control.
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Enter Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Small
Ant
Ant 5
4948
Changing the PIP Channel
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the UP or DOWN button to select “Ant/CATV”
.
Press the LEFT or RIGHT button to select “Ant”,
“STD”, “HRD” or “IRC”.
3
Press the UP or DOWN button
to select “Channel”.
Press the LEFT or RIGHT button to change the
channel that appears in the PIP window.
4
Press the MENU button to exit.
Changing the Location of the PIP Image
1
Press the MENU button. Press the UP or DOWN
button to select “PIP”, then press the ENTER button.
2
Press the UP or DOWN button to select “Locate”.
3
Press the LEFT or RIGHT button to move the PIP
screen where you want.
4
Press the MENU button to exit.
➤
➤
Quick way to change the PIP channel: Just press the “CH▲“
or
“CH▼” button under the cover of the remote control.
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
STD
STD 5
PIP
On
TV
Large
STD
STD 9
5150
Changing the Screen SizeChanging the Screen Size
WWide
ide
Sets the picture to 16:9 wide mode.
Panorama
Converts regular 4:3 aspect ratio screen to
wide screen.
Zoom1
The screen size when Wide screen is vertically
enlarged.
Zoom2
The screen size when the Zoom1 screen is
vertically enlarged.
Normal (4:3)
Sets the picture to 4:3 normal mode.
Notes
• In TV, VIDEO, S-VIDEO and Component(480i) modes, all screen modes can be selected.
(Wide ➝ Panorama ➝ Zoom1 ➝ Zoom2 ➝ Normal).
• In PC/DVI mode, only Wide & Normal modes can be selected.
• In Component(480p, 720p. 1080i) modes, Panorama mode can’t be selected.
• In Component(480p, 720p. 1080i) modes, you can move the picture on screen by pressing
the Up▲ or Down▼ button. (All screen modes)
• Changing the screen size to Normal, Zoom1 or Zoom2 during PIP mode will cause the PIP
window to disappear.
When you press the ASPECT button on the remote control, the PDP’s screen mode should appear in
sequence. The screen displays in this order: Wide, Panorama, Zoom1, Zoom2, Normal.
Note
• If you watch a still image or the Normal (4:3) mode for a long time (over 2 hours), an image may
be burned onto the screen. View the monitor in Wide or Panorama mode as much as possible.
Wide
Panorama
Normal
Zoom1
Up/Down
Zoom2
Up/Down
Still
Press the Still button on the remote control to freeze a
moving picture. Press again to cancel.
PLASMA DISPLAY PANEL
Sound Control
Customizing the Sound ................................................................54
Using Automatic Sound Settings ....................................................55
Choosing a Multi-Channel Sound (MTS)Soundtrack ..........................56
Using the Auto Volume..................................................................57
Using Dolby Virtual ......................................................................58
Using a Subwoofer ......................................................................59
55
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the LEFT or RIGHT button to select “Adjust”,
“Standard”, “Music”, “Movie” or “Speech” sound
setting.
3
Press the MENU button to exit.
54
Customizing the Sound
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Adjust”,
then press the ENTER button.
You will also see the items “Bass”, “Treble” and
“Balance”.
3
Press the UP or DOWN button to select the item you
wish to change.
4
Press the LEFT or RIGHT button to change the value
of the item.
5
Press the MENU button to exit.
Using Automatic Sound Settings
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Enter Menu
Bass
Treble
Balance
Move Adjust Menu
Sound
Custom
Mono
Off
Off
Sound
Custom
Mono
Off
Off
Adjust
L 50
R 50
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Sound
Music
Off
Off
Off
Off
50
50
82Bass
57
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Auto
Volume”.
3
Press the LEFT or RIGHT button to select “On”.
•Pressing the LEFT or RIGHT button will alternate
between “On” and “Off.”
4
Press the MENU button to exit.
56
Choosing a Multi-Channel Sound (MTS)
Soundtrack
Depending on the particular program being broadcast, you can listen to stereo, mono,
or a Separate Audio Program. (SAP audio is usually a foreign-language translation.
Sometimes SAP has unrelated information like news or weather.)
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the UP or DOWN button to select “MTS”.
3
Press the LEFT or RIGHT button to select “Mono”,
“Stereo” or “SAP”.
4
Press the MENU button to exit.
• Choose
Stereo
Stereo for channels that are broadcasting in stereo.
• Choose
Mono
Mono for channels that are broadcasting in mono, or if you are having difficulty receiving
a stereo signal.
• Choose
SAP
SAP to listen to the Separate Audio Program, which is usually a foreign-language translation.
Note
• The MTS function operates in TV mode only.
Using the Auto Volume
Each broadcasting station has its own signal conditions, which can make it necessary to
adjust the volume every time the channel is changed. “Auto volume” lets you automatically
adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low.
➤
➤
Quick way to access the MTS menu: Just press the “MTS” button on
the remote control.
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Stereo
Off
Off
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Mono
On
Off
59
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Woofer”,
then press the ENTER button.
3
Press the LEFT or RIGHT button to select “On”.
•Pressing the LEFT or RIGHT button will alternate
between “On” and “Off.”
4
Press the UP or DOWN button to select “Volume”,
then press the LEFT or RIGHT button to adjust the
value of the item.
This sets the volume for the subwoofer.
5
Press the UP or DOWN button to select “Cutoff
Freq.”, then press the LEFT or RIGHT button to adjust
the value of the item.
This sets the cutoff frequency for the subwoofer.
For example, if you set the cutoff frequency at
130Hz, the subwoofer will reproduce frequencies
of 130Hz and lower.
6
Press the MENU button to exit.
58
Using Dolby Virtual
This feature allows the PDP’s optional L/R speakers to provide a Home Theater-like Dolby
effect. The center and surround sounds are mixed into the L/R speakers.
1
Press the MENU button. Press the UP or DOWN
button to select “Sound”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Dolby
Virtual”.
3
Press the LEFT or RIGHT button to select “On”.
•Pressing the LEFT or RIGHT button will alternate
between “On” and “Off.”
4
Press the MENU button to exit.
Using a Subwoofer
➤
➤
Quick way to access the Surround: Just press the “SURROUND”
button on the remote control.
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Mono
Off
On
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Enter Menu
Woofer
Volum e
Cutoff Freq.
Move Select Menu
Woofer
Volum e
Cutoff Freq.
Move Adjust Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Woofer
On
120Hz
Woofer
On
120Hz
50
50
Woofer
Volum e
Cutoff Freq.
Move Adjust Menu
Woofer
On
130Hz
65Volume
50
PLASMA DISPLAY PANEL
Channel Control
Fine Tuning Channels....................................................................62
LNA (Low Noise Amplifier)............................................................63
63
Fine Tuning Channels
Use fine tuning to manually adjust a particular channel for optimal reception.
62
1
Press the MENU button. Press the UP or DOWN
button to select “Channel”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Fine
Tune”.
3
Press the LEFT or RIGHT button to adjust the fine
tuning.
4
To store the fine tuning setting in the TV’s memory,
press the UP button.(A star icon<*>will appear.)
To reset the fine tuning to “0”, press the DOWN
button.
5
Press the MENU button to exit.
LNA (Low Noise Amplifier)
If the TV is operating in a weak-signal area, sometimes the LNA function can improve
the reception (a low-noise preamplifier boosts the incoming signal).
1
Press the MENU button. Press the UP or DOWN
button to select “Channel”, then press the ENTER
button.
2
Press the UP or DOWN button to select “LNA”.
3
Press the LEFT or RIGHT button to select “On.”
• Pressing the LEFT or RIGHT button will alternate
between “On” and “Off.”
4
Press the MENU button to exit.
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Air / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Adjust Menu
Air / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Add/Erase Adjust Menu
Air / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Channel
Ant
0
Off
Channel
Air
0
Off
Channel
Air
+3
Off
Channel
Air
+3
Off
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Air / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Air / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Channel
Ant
0
Off
Channel
Air
0
Off
Channel
Air
0
On
Add/Erase Adjust Menu
PLASMA DISPLAY PANEL
Connecting a PC and Operation
Connecting to a PC......................................................................66
Adjusting the PC Screen................................................................70
Changing the Position of the Image................................................71
Changing the Size of the Image ....................................................72
Information..................................................................................73
Picture Quality Adjustment ............................................................74
67
Connecting to a PC
Connection to a Macintosh computer may require in adapter.
66
Connect a PC (15pin) cable between the PC Output jack (or DVI jack) on the PC and the
RGB IN(or DVI IN) Input jack (15p D-SUB) on the PDP.
Connect a Audio cable between the Audio (RGB or DVI) on the PC and the Audio L/R (RGB
or DVI) input jacks on the PDP.
To watch the PC screen:
1. Turn on your PDP, and press the TV/VIDEO button on the remote control.
2. Press the UP or DOWN button to select “PC”, then press the ENTER button.
3. Turn on PC and check for PC system requirements. (Refer to pages 66 and 67
for PC system requirements.)
4. Adjust the PC screen. (Refer to pages 70 and 76.)
Connecting a PC to the PDP
Audio CablePC CableDVI Cable
Power Plug
1
2
Pin Configuration
D-Sub Cable
DVI-D Cable (Digital-Only Connector)
• 15Pin Signal Cable (based on protruded pin)
Setting up Your PDP (Plug and Play)
Our adoption of the new VESAPlug and Play solution eliminates complicated and time consuming
setup. It allows you to install your monitor in a Plug and Play compatible system, without the usual
setup hassles and confusion. Your PC system can easily identify and configure itself for use with your
display. This monitor automatically tells the PC system its Extended Display Identification data (EDID)
using Display Data Channel (DDC) protocols.
DVI jack
(The actual configuration on your PC
may be different,
depending on the
model.)
PDP
PC
or
Use the DVI-D
connection cable.
(sold separately)
Ferrite Cores
6968
How to Set up Your PC Software (Windows only)
The Windows display-settings for a typical computer are shown below. However, the actual screens
on your PC will probably be different, depending upon your particular version of Windows and your
particular video card. But even if your actual screens look different, the same, basic set-up information
will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.)
On the windows screen, select in the following
sequence : Start ➝ Settings ➝ Control Panel.
When the control panel screen appears, click on
“Display” and a display dialog-box will appear.
Select the “Settings” tab in the display dialogbox.
The two key variables that apply to the PDP-PC
interface are “resolution” and “colors”.
The correct settings for these two variables are:
• Size (sometimes called “resolution”)
:640 x 480 pixels.
• Color: “24-bit” color (might also be expressed as “16 million colors”)Shown at left is
a typical screen for “Display” dialog box.
If a vertical-frequency option exists on your
display settings dialog box, the correct value is
“60” or “60 Hz.” Otherwise, just click “OK”
and exit the dialog box.
Continued...
Notes:
Both screen position and size will vary, depending on the type of PC monitor and its resolution.
The table below shows all of the display modes that are supported:
• The interlace mode is not supported.
• The PDP operates abnormally if a non-standard video format is selected.
Notes:
• When this PDP is used as a PC display, 32-bit color is supported.
• Depending on the manufacturer, your PC display screen might appear different.
(and depending on your particular version of Windows).
Check your PC instruction book for information about connecting your PC to a PDP.
• If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5kHZ
(horizontal).
• In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power
is turned off (or if the PC is disconnected). If so, press the Source button to enter the VIDEO mode.
Also, make sure that the PC is connected.
• Connect only a PC monitor to the monitor output port while viewing the PC screen. (Otherwise,
random signals might appear).
Video signal Dot X Line
640 X 350
640 X 400
720 X 400
640 X 480
IBM PC / AT
Compatible
800 X 600
1024 X 768
Vertical
Frequency (Hz)
70.086
85.080
85.080
70.087
85.039
59.940
72.809
75.000
85.008
56.250
60.317
72.188
75.000
85.061
60.004
70.069
75.029
84.997
Horizontal
Frequency (KHz)
31.469
37.861
37.861
31.469
37.927
31.469
37.861
37.500
43.269
35.156
37.879
48.077
46.875
53.674
48.363
56.476
60.023
68.677
Vertical
polarity
N
N
P
P
P
N
N
N
N
N/P
P
P
P
P
N
N
P
P
Horizontal
polarity
P
P
N
N
N
N
N
N
N
N/P
P
P
P
P
N
N
P
P
71
Adjusting the PC Screen
70
Adjusting the R.G.B
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button, then press the ENTER
button.
2
Press the UP or DOWN button to select “Color
Tone”, then Press the LEFT or RIGHT button to select
“Custom”. When “Custom” is selected, the word
“Color Adjust” will appear on the screen.
3
Press the UP or DOWN button to select “Color
Adjust”, then press the ENTER button.
4
Press the UP or DOWN button to select the item you
want to change, then press the RIGHT or LEFT
button to change the value of the item, using the
on-screen gauge as your guide.
5
Press the MENU button to exit.
Changing the Position of the Image
After connecting the PDP to your PC, adjust the position of the screen if it is not well-aligned.
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the MENU button, then adjust the screen position by using the UP/DOWN/LEFT/RIGHT button.
3
Press the MENU button to exit.
Mode
Adjust
Color Tone
Color Adjust
DNIe
Move Select Menu
Mode
Adjust
Color Tone
Color Adjust
DNIe
Move Select Menu
Mode
Adjust
Color Tone
Color Adjust
DNIe
Move Enter Menu
Custom
Custom
On
Custom
Custom
On
Custom
Custom
On
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Move Move Menu
PC
Wide
Position
Red
Green
Blue
Move Adjust Menu
Adjust
50
50
50
82Red
73
Changing the Size of the Image
72
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the UP or DOWN button to select “Scaling”.
3
Press the LEFT or RIGHT button to select “Wide”
or “Normal”.
4
Press the MENU button to exit.
Information
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the UP or DOWN button to select “Informa-
tion”, then press the ENTER button.
The vertical, horizontal frequencies and resolution
appear.
3
Press the MENU button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Select Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Select Menu
PC
Wide
PC
Wide
PC
Normal
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Resolution : 1024 * 768
H-Frequency : 48.52 KHz
V-Frequency : 60.21 Hz
PC
Wide
PC
Wide
Information
Menu
75
Coarse Adjustment
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the UP or DOWN button to select “Adjust”,
then press the ENTER button.
3
Press the UP or DOWN button to select “Coarse”.
Remove picture noise (vertical stripes) on the screen
by pressing the LEFT or RIGHT button. (If Coarse is
not set properly, vertical stripes will appear on the
screen.)
4
Press the MENU button to exit.
74
Picture Quality Adjustment
Picture Automatic Adjustment
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the UP or DOWN button to select “Auto
Adjust”, then press the ENTER button.
3
The message “Auto Adjust” appears on the screen
and the picture adjustments are automatically
activated.
4
Press the MENU button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
PC
Wide
PC
Wide
Auto Adjust
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Corase
Fine
Move Adjust Menu
PC
Wide
PC
Wide
Adjust
50
7
53Coarse
76
PLASMA DISPLAY PANEL
Time Setting
Setting the Clock.......................................................................78
Setting the Sleep Timer...............................................................79
Setting the Timers......................................................................80
Setting the Preferred Channel and Volume Level............................82
Fine T uning (Fine)
Preset:
• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.
Press the ENTER button to select PC mode.
1
Press the MENU button. Press the UP or DOWN
button to select “PC”, then press the ENTER button.
2
Press the UP or DOWN button to select “Adjust”,
then press the ENTER button.
3
Press the UP or DOWN button to select “Fine”.
Remove picture noise on the screen by pressing the
LEFT or RIGHT button. (If Fine is not set properly,
noise will appear on the screen.)
4
Press the MENU button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Corase
Fine
Move Adjust Menu
PC
Wide
PC
Wide
Adjust
50
7
53Fine
7978
Setting the Clock
You can set your PDP to automatically turn off after a preset interval.
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Time”, then
press the ENTER button.
3
Press the UP or DOWN button to select “Sleep”.
4
Press the LEFT or RIGHT button to select the time
interval for the PDP to stay on. The interval ranges
from 10 to 180 minutes.
5
Press the MENU button to exit.
Setting the Sleep Timer
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Time”, then
press the ENTER button.
3
Press the LEFT or RIGHT button to select hour, then
press the UP or DOWN button to select the correct
hour.
4
Press the LEFT or RIGHT button to select minute, then
press the UP or DOWN button to select the correct
minute.
5
Press the MENU button to exit.
Note
• Time setting will be reset when you pull out the Power cord if the PDP is ON.
(If you want to keep the time setting, turn the PDP off using the POWER button on the remote control
or the Front Panel.)
Function
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
English
Off
Off
Off
Function
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
English
Off
Off
Off
➤
➤
Quick way to access the sleep timer: Just press the “SLEEP” button
on the remote control.
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Time
10 :
- -
- -
:
- -
- -
:
- -
Time
10 : 30 am
- -
:
- -
- -
:
- -
am
am
am
am
am
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Function
English
Function
English
Time
10 : 30 am
- -
:
- -
- -
:
- -
Time
10 : 30 am
- -
:
- -
- -
:
- -
Off
Off
Off
Off
Off
Off
am
Off
am
Off
Off
10
3
am
Off
am
Off
30
10
3
8180
Setting the Timers
This PDP can be set to turn on or off automatically at specific times that you choose. Before
using the timers, you must set the PDP’s clock, as described previously.
6
Press the LEFT or RIGHT button to select “Off” or
“On”, then press the UP or DOWN button to select
“Off” or “On”.
7
If you want to set Off Time, press the UP or DOWN
button to select the “Off Time”.
Set the “Off Time” just as you set “On Time”.
8
Press the MENU button to exit.
Note
• If you set to On Time or Off Time, the Power Indicator on the Front Panel is changed to Green.
Setting the On/Off Timer
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Time”, then
press the ENTER button.
3
Press the UP or DOWN button to select “On Time”.
4
Press the LEFT or RIGHT button to select hour, then
press the UP or DOWN button to select the correct
hour.
5
Press the LEFT or RIGHT button to select minute, then
press the UP or DOWN button to select the correct
minute.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Move Select Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Time
10 : 30 am
- -
:
- -
- -
:
- -
Time
10 : 30 am
- -
7 :
- -
:
- -
am
am
am
am
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Time
10 : 30 am
7 : 30
- -
:
- -
Time
12 : 00 am
7 : 30
- -
:
- -
am
On
am
Off
Off
10
3
am
On
am
Off
Off
10
3
Off
Off
Off
10
3
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Time
10 : 30 am
7 : 30
- -
:
- -
am
am
Off
Off
Off
10
3
Selecting a Menu Language .....................................................84
Viewing Closed Captions.........................................................85
Digital Noise Reduction ...........................................................86
Setting Auto Power Off ...........................................................87
Using the V-Chip.....................................................................88
Selecting the Film Mode...........................................................94
PLASMA DISPLAY PANEL
Function Description
82
Setting the Preferred Channel
and Volume Level
The preferred channel and volume can be set for when the timer automatically turns on the TV.
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Time”, then
press the ENTER button.
3
Press the UP or DOWN button to select “On Time
Volume”.
Press the LEFT or RIGHT button to adjust volume
level.
4
Press the UP or DOWN button to select “On Time
Channel”.
Press the LEFT or RIGHT button to select the channel.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Function
English
Function
English
Time
- -
:
- -
- -
:
- -
- -
:
- -
Time
- -
:
- -
- -
:
- -
- -
:
- -
Off
Off
Off
Off
Off
Off
am
am
am
am
am
am
Off
Off
Off
10
3
Off
Off
Off
10
3
Selecting a Menu Language
8584
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Caption”,
then press the ENTER button.
3
Press the LEFT or RIGHT button to turn closed captioning On/Off.
4
Press the UP or DOWN button to select “Mode”,
then press the LEFT or RIGHT button to select
“Caption” or “Text.”
5
Depending on the particular broadcast, it might be
necessary to make changes to “Channels” and
“Field”: Press the UP/DOWN/LEFT/RIGHT button
to make the changes. (Follow the same procedure
as in steps 3~4 above.)
Press the MENU button to exit.
Note
• Different channels and fields display different information: Field 2 carries additional information
that supplements the information in Field 1. (For example, Channel 1 may have subtitles in English,
while Channel 2 has subtitles in Spanish.
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the LEFT or RIGHT button to select the appropriate language : English, Français or Español.
3
Press the MENU button to exit.
Viewing Closed Captions
Your TV decodes and displays the closed captions that are broadcast with certain
TV shows. These captions are usually subtitles for the hearing impaired or foreignlanguage translations. All VCRs record the closed caption signal from television
programs, so home-recorded video tapes also provide closed captions. Most prerecorded commercial video tapes provide closed captions as well. Check for the
closed caption symbol in your television schedule and on the tape’s packaging: .
Note: The Caption feature does not work with DVD or DTV signals.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Caption
Mode
Channel
Field
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Caption
On
Caption
2
1
Move Select Menu
Caption
Mode
Channel
Field
Move Select Menu
Caption
On
Text
2
1
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “Auto
Power Off”.
3
Press the LEFT or RIGHT button to select “On”.
4
Press the MENU button to exit.
Note
• If the Off timer is set, Auto Power Off will not function.
• The power will be turned off automatically after 15 minutes if the PDP is ON and there is no input
signal. (For instance, if you select a channel without a signal while in TV mode or when there is no
input signal after selecting an output signal)
8786
Digital Noise Reduction
If the broadcast signal received by your TV is weak, you can activate the Digital Noise
Reduction feature to help reduce any static and ghosting that may appear on the screen.
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “NR”.
3
Press the LEFT or RIGHT button to select “On”.
4
Press the MENU button to exit.
Setting Auto Power Off
The PDP can be set to turn off automatically if no buttons are pressed for 3 hours
after the PDP turns on via the On timer.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Function
English
On
Off
Off
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Function
English
Off
On
Off
8988
Using the V-Chip
The V-Chip feature automatically locks out programs that are deemed inappropriate
for children. The user must enter a PIN (personal ID number) before any of the V-Chip
restrictions are set up or changed.
Note : When the V-chip feature is activated, the PIP and auto channel program features
do not function.
Setting Up Your Personal ID Number (PIN)
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “V-Chip”,
then press the ENTER button.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
Note: The default PIN number of a new TV set is
“0-0-0-0.”
4
The “V-Chip” screen will appear. Press the UP or
DOWN button to select “Change Pin,” then press
the ENTER button.
5
The Change pin screen will appear. Choose any
4-digits for your PIN and enter them.
As soon as the 4 digits are entered, the “Confirm
New Pin” screen appears. Re-enter the same 4
digits. When the Confirm screen disappears, your
PIN has been memorized.
6
Press the MENU button to exit.
Note
• If you forget the PIN, press the remote-control buttons in the following sequence, which resets the pin
to 0-0-0-0 : Power Off ➔ Mute ➔ 8 ➔ 2 ➔ 4 ➔ Power On.
How to Enable/Disable the V-Chip
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “V-Chip”,
then press the ENTER button.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-Chip” screen will appear.
To enable the V-Chip feature, press the RIGHT button
so that the “V-Chip Lock” field is Yes.
(Pressing the left or right button will alternate
between “Yes” and “No”.)
5
Press the MENU button to exit.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
Change Pin
Confirm New Pin
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
Enter Pin :
----
V-Chip
No
V-Chip
Enter New Pin :
----
V-Chip
Confirm New Pin :
-
Enter Pin :
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
----
V-Chip
Yes
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Select Menu
9190
How to Set up Restrictions Using the “TV guidelines”
First, set up a personal identification number (PIN), and enable the V-Chip. (See previous section.)
Parental restrictions can be set up using either of two methods: The TV guidelines or the MPAA rating.
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “V-Chip”,
then press the ENTER button.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-Chip” screen will appear.
Press the UP or DOWN button to select “TV GuideLines”, press the ENTER button.
5
The “TV GuideLines” screen will appear. Press the
UP or DOWN button to select one of the six agebased categories:
TV-Y Young children
TV-Y7 Children 7 and over
TV-G General audience
TV-PG Parental guidance
TV-14 Viewers 14 and over
TV-MA Mature audience
6
At this point, one of the TV-Ratings is selected.
Press the RIGHT button : Depending on your existing setup, a letter “U” or “B” will start
blinking.
(U= Unblocked, B= Blocked)
While the “U” or ”B” is blinking, press the UP or DOWN button to block or unblock the
category.
Press the RIGHT button to save the TV guidelines. A TV-Rating will be selected,
and no letters will blink.
To select a different TV-Rating, press the UP or DOWN button and then repeat the process.
Note 1: The TV-Y7, TV-PG, TV-14 and TV-MA have additional options. See the next step to
change any of the following sub-ratings:
FV: Fantasy violence
D: Sexually Sugessive Dialog
L: Adult Language
S: Sexual situation
V: Violence
Note 2: The V-Chip will automatically block certain categories that are “more restrictive”.
For example, if you block “TV-Y” category, then TV-Y7 will automatically be blocked.
Similarly, if you block the TV-G category, then all the categories in the “young adult” group
will be blocked (TV-G, TV-PG, TV-14 and TV-MA). The sub-ratings (D, L, S, V) work together
similarly. (See next section.)
7
How to set the FV, D, L, S and V sub-ratings.
First, select one of these TV-Ratings: TV-Y7, TV-PG, TV-14 or TV-MA (See Step 4, on
previous page).
Next, while the TV-Rating is selected, repeatedly press the RIGHT button.
This will cycle through the available sub-ratings (FV,L, S, D or V).
A blinking letter (“U” or “B”) will be displayed for each sub-rating. While the “U” or “B” is
blinking, press the UP or DOWN button to change the sub-rating.
Press the RIGHT button to save the TV guidelines. A TV-Rating will be selected and no
letters will select. To select a different TV-Rating, press the UP or DOWN button and then
repeat the process.
Note: The V-chip will automatically block certain categories that are “More restrictive”.
For example, if you block “L” sub-rating in TV-PG, then the “L” sub-ratings in TV-14 and
TV-MA will automatically be blocked.
8
Press the MENU button to clear all the screens. (Or proceed to the next section, and set up
additional restrictions based on the MPAA codes).
Note
• Note: These categories consist of two separate groups: TV-Y and TV-Y7 (young children
through age 7), and TV-G through TV-MA (everybody else). The TV-Y and TV-Y7 categories
are colored blue.
The restrictions for these two groups work independently: If a household includes very young
children as well as young adults, the TV guidelines must be set up separately for each age
group. (See next step.)
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Move Select Menu
Enter Pin :
TV GuideLines
All
FVUV
U
U
U
U
U
U
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
----
V-Chip
No
S
L
D
B : Blocked
U : Unblocked
U
U
U
U
U
U
U
U
U
U
U
9392
How to Set up Restrictions using the MPAA Ratings: G, PG, PG-13, R, NC-17, X
The MPAA rating system uses the Motion Picture Association of America (MPAA) system, and its main application is
for movies. When the V-Chip lock is on, the TV will automatically block any programs that are coded with objectionable ratings (either MPAA or TV-Ratings).
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the UP or DOWN button to select “V-Chip”,
then press the ENTER button.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-Chip” screen will appear.
Press the UP or
DOWN button
to select “MPAA Rating,”
press the
ENTER button
.
5
The “MPAA Rating” screen will appear. MPAA category.
Pressing the UP or DOWN button will cycle through the
MPAA categories:
While a particular category is selected, press the RIGHT button to activate it.
A selected letter (“U” or “B”) will be displayed. Press the UP or DOWN button to select “U” or ”B”.
Press the RIGHT button to save the settings.
Note: The V-Chip will automatically block any category that is “more restrictive. ”For example,
if you block the “PG-13” category, then “R”, “NC-17” and “X” will automatically be blocked also.
How to Reset the TV after the V-Chip Blocks a Channel (“Emergency Escape”)
If the TV is tuned to a restricted channel, the V-Chip will block it. The screen will go blank
and the following message will appear: “Excessive rating.”
To resume normal viewing, tune to a different channel using the number buttons.
Under certain conditions (depending on the rating of the local TV programs) the V-Chip might
lock out all the channels. In this case, use the V.Chip function for an “emergency escape”:
1
Press the MENU button.
2
Press the UP or DOWN button to select “V-Chip”, then press the ENTER button.
3
Enter your PIN number, and press the RIGHT button to temporarily disable the V-Chip
Lock.
G General audience (no restrictions).
PG Parental guidance suggested.
PG-13 PG-13 (Parents strongly cautioned).
R
R (Restricted. Children under 17 should be accompanied by an adult).
NC-17 No children under age 17.
X X (Adults only).
NR Not rated.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Enter Menu
Function
English
Off
Off
Off
Function
English
Off
On
Off
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
G
PG
PG-13
R
NC-17
X
NR
Move Enter Menu
Enter Pin :
MPAA Rating
U
B : Blocked
U
U : Unblocked
U
U
U
U
U
V-Chip
----
V-Chip
No
94
PLASMA DISPLAY PANEL
Appendix
Troubleshooting............................................................................96
Care and Maintenance ................................................................97
Specifications ..............................................................................98
Selecting the Film Mode
1
Press the MENU button. Press the UP or DOWN
button to select “Function”, then press the ENTER
button.
2
Press the DOWN button to select Film Mode, then
press the RIGHT or LEFT button to select “On” or
“Off”.
•On: Automatically senses and processes film
signals from all sources and adjusts the
picture for optimum quality.
•Off: Switches off the Film mode.
3
Press the MENU button to exit.
Note
• Film mode is supported in Video, S-Video, Component 480i.
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chi p
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
On
9796
Troubleshooting
Problem
Poor picture.
Your Remote control does not
operate the PDP.
The PDP won’t turn on.
There is no screen image.
The image is too light or
too dark.
The image is too large or
too small.
Before you call a service technician, please scan this list of problems and possible solutions. It may save you
time and money.
Possible Solution
Check all wire connections.
Press the “Mode” button to put your remote control in the “TV”
mode.
Check if the power plug is connected.
Check to see that both the PDP and the source are plugged in
and turned on.
Adjust the Brightness or Contrast settings.
Adjust the Size settings.
With proper care, your PDP will give you many years of service. Please follow these guidelines to get
the maximum performance from your PDP.
Identifying Problems
• Do not put the PDP near extremely hot, cold, humid or dusty places.
• Do not put the PDP near appliances that create magnetic fields.
• Keep the ventilation openings clear.
• Do not place the PDP on a rough and slanted surface, such as cloth or paper.
Liquids
• Do not place liquids near or on the PDP.
Cabinet
• Never open the cabinet or touch the parts inside.
• Wipe your PDP with a clean, dry cloth. Never use water, cleaning fluids, wax, or chemicals.
• Do not put heavy objects on top of the cabinet.
Temperature
• If your PDP is suddenly moved from a cold to a warm place, unplug the power cord for at least two
hours so that moisture that may have formed inside the unit can dry completely.
Care and Maintenance
9998
MemoSpecifications
HPN4235
1027 (W) X 86.5 (D) X 630.5 (H) mm ; 40.43 (W) X 3.11 (D) X 24.82(H) inches
58 (W) X 21 (D) X 210 (H) mm ; 2.28 (W) X 0.83 (D) X 8.27 (H) inches
37 kg
134g ; 0.295 lbs (including batteries)
120V~, 60Hz
330 Watts
1024(H) x 768(V)
107 Cm/42 inches
VHF, UHF (75Ω unbalanced)
VIDEO
S-VIDEO
COMPONENT 1 - 480i / 480p / 720p / 1080i
COMPONENT 2 - 480i / 480p / 720p / 1080i
RGB : D-SUB 15P
DVI
VIDEO / S-VIDEO
COMPONENT 1
COMPONENT 2
PC (RGB)
DVI
10W + 10W (8 Ω)
Subwoofer (500mv RMS at 1KHz)
Model
Dimensions Display
Remote Control
Weight Display
Remote Control
Voltage
Power Consumption
Number of Pixels
Screen Size
ANTENNA input
VIDEO input
AUDIO input
AUDIO output
Exterior design and product specifications are subject to change without prior notice to improve
the performance of this product.
This PDP applies to Class B digital device.
(Note: Class B system is for home use.)
This PDP has been registered for residential use in terms of EMI. So it can be used in all areas as
well as residential areas.
Loading...
