Samsung GT-S8300 User guide

Download

Some of the contents in this manual may differ from your phone depending on the software of the phone or your

Draft

service provider.

World Wide Web http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-21468A

English (EU). 01/2009. Rev. 1.0

Samsung S8300V

user manual

using this

manual

designed to guide you through the functions and

features of your mobile phone. To get started quickly,

“assembling and preparing your mobile phone,”

This user manual has been specially

refer to “introducing your mobile phone,”

and “using basic functions.”

Instructional icons

Before you start, familiarise yourself with the icons you will see in this manual:

Warning

—situations that could cause

injury to yourself or others

Caution

—situations that could cause

damage to your phone or other equipment

Note

—notes, usage tips, or additional

information



Refer to

—pages with related information; for example: 12”)



p.12 (represents “see page

Followed by

→

menus you must select to perform a step; for example: In Menu mode, touch

Messages Messages, followed by Create message)

[ ]

Square brackets

example: [ ] (represents the Power/ Menu exit key)

—the order of options or

→ Create message (represents

—phone keys; for

Rights to all technologies and products that comprise this device are the property of their respective owners:

•Bluetooth

• Java™ is a trademark of Sun Microsystems, Inc.

• Windows Media Player

•DivX

Bluetooth SIG, Inc. worldwide—Bluetooth QD ID: B014869.

of Microsoft Corporation.

DivX, Inc., and is used under licence.

is a registered trademark of the

is a registered trademark

is a registered trademark of

using this manual

iii

ABOUT DIVX VIDEO

is a digital video format created by DivX, Inc.

DivX This is an official DivX Certified device that plays DivX video. Plays DivX

DivX

using this manual

video up to 720x480.

ABOUT DIVX VIDEO-ON-DEMAND

This DivX

video up to 320x240. May play

Certified device must be registered with DivX in order to play DivX Video-on-Demand (VOD) content. First generate the DivX VOD registration code for your device and submit it during the registration process. [Important: DivX VOD content is protected by a DivX DRM (Digital Rights Management) system that restricts playback to registered DivX Certified devices. If you try to play DivX VOD content not authorised for your device, the message "Authorization Error" will be displayed and your content will not play.] Learn more at www.divx.com/vod.

safety and usage information ..................2

Safety warnings .......................................... 2

Safety precautions ...................................... 4

Important usage information ....................... 7

introducing your mobile phone ............. 11

Unpack ..................................................... 11

Phone layout ............................................. 12

Keys ......................................................... 13

Display ...................................................... 14

Icons .........................................................14

assembling and preparing your

mobile phone ..........................................17

Install the SIM or USIM card and battery ... 17

Charge the battery .................................... 19

Insert a memory card (optional) ................. 20

using basic functions ............................ 21

Turn your phone on and off ....................... 21

Use the touch screen ................................ 22

Access menus .......................................... 23

Switch applications ................................... 23

contents

Use widgets .............................................. 24

Access help information ............................ 25

Customise your phone .............................. 25

Use basic call functions ............................ 26

Send and view messages ......................... 28

Add and find contacts ............................... 30

Use basic camera functions ...................... 31

Listen to music ......................................... 32

Browse the web ........................................ 34

Use the Google services ........................... 34

using advanced functions ..................... 36

Use advanced call functions ..................... 36

Use advanced phonebook functions ......... 38

Use advanced messaging functions .......... 40

Use advanced camera functions ............... 41

Use advanced music functions ................. 45

using tools and applications ................. 49

Use the Bluetooth wireless feature ............ 49

Activate and send an SOS message ......... 51

Activate the mobile tracker ........................ 52

Make fake calls ......................................... 52

Record and play voice memos .................. 53

Edit images ............................................... 54

Print images .............................................. 56

Edit videos ................................................ 57

Upload photos and videos to the web .......60

Use Java-powered games and

applications .............................................. 61

Synchronise data ...................................... 61

Use RSS reader ........................................ 62

View your current position ......................... 63

Create and view world clocks ................... 63

Set and use alarms ................................... 64

Use the calculator ..................................... 64

Convert currencies or measurements ........ 65

Set a countdown timer .............................. 65

Use the stopwatch .................................... 65

Create a new task ..................................... 65

Create a text memo .................................. 66

Manage your calendar .............................. 66

troubleshooting ........................................ a

index .........................................................d

contents

vii

safety and

usage

information

Comply with the following precautions to avoid dangerous or illegal situations and ensure peak

performance of your mobile phone.

Safety warnings

Keep your phone away from small children and pets

Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed.

Protect your hearing

Listening to a headset at high volumes can damage your hearing. Use only the minimum volume setting necessary to hear your conversation or music.

Install mobile phones and equipment with caution

Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly.

Handle and dispose of batteries and chargers with care

• Use only Samsung-approved batteries and

chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.

• Never dispose of batteries or phones in a fire.

Follow all local regulations when disposing used batteries or phones.

• Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.

• Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating.

Avoid interference with pacemakers

Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance.

safety and usage information

Turn off the phone in potentially explosive environments

Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or

safety and usage information

instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories.

Reduce the risk of repetitive motion injuries

When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks.

Safety precautions

Drive safely at all times

Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible.

Follow all safety warnings and regulations

Comply with any regulations that restrict the use of a mobile phone in a certain area.

Use only Samsung-approved accessories

Using incompatible accessories may damage your phone or cause injury.

Turn off the phone near medical equipment

Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel.

Turn off the phone or disable the wireless functions when in an aircraft

Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel.

Protect batteries and chargers from damage

• Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries.

• Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage.

• Never use a damaged charger or battery.

Handle your phone carefully and sensibly

• Do not allow your phone to get wet—liquids can cause serious damage. Do not handle your phone with wet hands. Water damage to your phone can void your manufacturer’s warranty.

safety and usage information

• Avoid using or storing your phone in dusty, dirty areas to prevent damage to moving parts.

• Your phone is a complex electronic device— protect it from impacts and rough handling to avoid serious damage.

safety and usage information

• Do not paint your phone, as paint can clog moving parts and prevent proper operation.

• Avoid using the phone’s camera flash or light close to the eyes of children or animals.

• Your phone and memory cards may be damaged by exposure to magnetic fields. Do not use carrying cases or accessories with magnetic closures or allow your phone to come in contact with magnetic fields for extended periods of time.

Avoid interference with other electronic devices

Your phone emits radio frequency (RF) signals that may interfere with unshielded or improperly shielded electronic equipment, such as pacemakers, hearing aids, medical devices, and other electronic devices in homes or vehicles. Consult the manufacturers of your electronic devices to solve any interference problems you experience.

Important usage information

Use your phone in the normal position

Avoid contact with your phone’s internal antenna.

Allow only qualified personnel to service your phone

Allowing unqualified personnel to service your phone may result in damage to your phone and will void your warranty.

Ensure maximum battery and charger life

• Avoid charging batteries for more than a week, as overcharging may shorten battery life.

• Over time, unused batteries will discharge and must be recharged before use.

• Disconnect chargers from power sources when not in use.

• Use batteries only for their intended purpose.

Handle SIM cards and memory cards with care

• Do not remove a card while the phone is transferring or accessing information, as this could result in loss of data and/or damage to the card or phone.

• Protect cards from strong shocks, static electricity, and electrical noise from other devices.

• Frequent writing and erasing will shorten the life span of memory cards.

• Do not touch gold-coloured contacts or terminals with your fingers or metal objects. If dirty, wipe the card with a soft cloth.

safety and usage information

Ensure access to emergency services

Emergency calls from your phone may not be possible in some areas or circumstances. Before travelling in remote or undeveloped areas, plan an alternate method of contacting emergency services

safety and usage information

personnel.

Specific Absorption Rate (SAR) certification information

Your phone conforms to European Union (EU) standards that limit human exposure to radio frequency (RF) energy emitted by radio and telecommunications equipment. These standards prevent the sale of mobile phones that exceed a maximum exposure level (known as the Specific Absorption Rate, or SAR) of 2.0 watts per kilogram of body tissue.

During testing, the maximum SAR recorded for this model was 0. the actual SAR is likely to be much lower, as the phone has been designed to emit only the RF energy necessary to transmit a signal to the nearest base station. By automatically emitting lower levels when possible, your phone reduces your overall exposure to RF energy.

The Declaration of Conformity at the back of this manual demonstrates your phone’s compliance with the European Radio & Terminal Telecommunications Equipment (R&TTE) directive. For more information about the SAR and related EU standards, visit the Samsung mobile phone website.

548 watts per kilogram. In normal use,

Correct disposal of this product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking shown on the product or its

literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

safety and usage information

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate

safety and usage information

packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment.

battery return systems)

This marking on the battery, manual or

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

introducing your

mobile phone

In this section, learn about your mobile phone’s

layout, keys, display, and icons.

Unpack

Check your product box for the following items:

• Mobile phone

• Battery

• Travel adapter (charger)

• User manual

The items supplied with your phone may vary depending on the software and accessories available in your region or offered by your service provider.

You can obtain additional accessories from your local Samsung dealer.

Phone layout

Front camera lens for video

calls

Power/Menu exit key

Dial key

Touch screen

Earpiece

Alphanumeric

key

Mouthpiece

Back key

Volu me key

Proximity sensor

Special function key

Battery cover

Rear camera

lens

Camera key

Internal antenna

Hold key

Flashbulb

Mirror

Multifunction

jack

The front of your phone includes the following keys and features:

introducing your mobile phone

The rear of your phone includes the following keys and features:

You can lock the touch screen and keys to prevent any unwanted phone operations. To lock, press [ ].

Keys

Key Function

Make or answer a call; In Idle mode,

Dial

Back

Power/ Menu exit

Alphanumeric

retrieve recently dialled, missed, or received numbers

In Menu mode, return to the previous level

Turn the phone on and off (press and hold); End a call; In Menu mode, return to the main menu or return to Idle mode

Enter numbers, letters and special characters; In Idle mode, press and hold [1] to access voice mails and [0] to enter an international call prefix

Key Function

Special function

Volum e

Hold

Camera

Enter special characters or perform special functions; In Idle mode, press and hold [ ] for the silent profile; Press and hold [ ] to enter a pause between numbers

Adjust the phone’s volume

Lock or unlock the touch screen and keys

In Idle mode, turn on the camera (press and hold); In Camera mode, take a photo or record a video; If you change the key function, open the application switch window to access other applications without exiting the current application (press and hold)

introducing your mobile phone

Display

Icon line

Displays various icons

Text and graphic area

Displays messages, instructi ons, and information you enter

Softkey line

Displays the current actions assigned to each area

Keypad Phonebook Menu

Your phone’s display consists of the following areas:

introducing your mobile phone

Icons

Learn about the icons that appear on your display.

Icon Definition

Signal strength

GPRS network connected

Transferring data via GPRS network

EDGE network connected

Transferring data via EDGE network

UMTS network connected

Transferring data via UMTS network

HSDPA network connected

Transferring data via HSDPA network

Icon Definition

Voice call in progress

Video call in progress

SOS message feature activated

Browsing the web

Connected to secured web page

Roaming (outside of normal service area)

Call diverting activated

Synchronised with PC

Bluetooth hands-free car kit or headset connected

Bluetooth activated

Alarm activated

Icon Definition

Memory card inserted

New text message (SMS)

New multimedia message (MMS)

New email message

New voice mail message

New push message

New configuration message

Tex t m e s s a g e f u l l

Multimedia message full

Email message full

Push message full

introducing your mobile phone

Icon Definition

introducing your mobile phone

Configuration message full

Normal profile activated

Silent profile activated

Driving profile activated

Meeting profile activated

Outdoor profile activated

Offline profile activated

Battery power level

Current time

assembling and

preparing your

mobile phone

Get started by assembling and setting up

your mobile phone for its first use.

Install the SIM or USIM card and battery

When you subscribe to a cellular service, you will receive a Subscriber Identity Module, or SIM card, with subscription details, such as your personal identification number (PIN) and optional services.

To use UMTS or HSDPA services, you can purchase a Universal Subscriber Identity Module (USIM) card.

To install the SIM or USIM card and battery,

1. Remove the battery cover.

assembling and preparing your mobile phone

If the phone is on, press and hold [ ] to turn it off.

2. Insert the SIM or USIM card.

• Place the SIM or USIM card in the phone with the gold-coloured contacts facing down.

• Without inserting a SIM or USIM card, you can use your phone’s non-network services and some menus.

3. Insert the battery.

With th e triangle facing up

4. Replace the battery cover.

Charge the battery

Before using the phone for the first time, you must charge the battery.

1. Open the cover to the multifunction jack and plug the small end of the travel adapter into the multifunction jack.

Improperly connecting the travel adapter can cause serious damage to the phone. Any damages by misuse are not covered by the warranty.

assembling and preparing your mobile phone

2. Plug the large end of the travel adapter into a power outlet.

3. When the battery is fully charged (the icon is no longer moving), unplug the travel adapter from the power outlet.

assembling and preparing your mobile phone

4. Unplug the travel adapter from the phone.

5. Close the cover to the multifunction jack.

About the low battery indicator

When your battery is low, the phone will emit a warning tone and a low battery message. The battery icon will also be empty and blinking. If the battery level becomes too low, the phone will automatically power off. Recharge your battery to continue using your phone.

Insert a memory card (optional)

To store additional multimedia files, you must insert a memory card. Your phone accepts microSD™ memory cards up to 16 GB (depending on memory card manufacturer and type).

1. Remove the battery cover and battery.

2. Insert a memory card with the label side facing up.

using basic

functions

Learn how to perform basic operations and use the

main features of your mobile phone.

Turn your phone on and off

To turn your phone on,

1. Slide open the phone.

2. Press and hold [ ].

3. Enter your PIN and touch Confirm (if necessary).

To turn your phone off, repeat steps 1 and 2 above.

Switch to the offline profile

By switching to the offline profile, you can use your phone’s non-network services in areas where wireless devices are prohibited, such as aeroplanes and hospitals.

To switch to the offline profile, in Menu mode, touch Settings → Phone profiles → Offline.

Follow all posted warnings and directions from official personnel when in areas where wireless devices are prohibited.

Use the touch screen

Learn basic actions to use the touch screen.

Your phone’s touch screen lets you easily select items or perform functions.

• Touch an icon to open a menu or launch an application.

using basic functions

• Drag your finger left or right to scroll through horizontal lists.

• Drag your finger up or down to scroll through vertical lists.

Access menus

To access your phone’s menus,

1. In Idle mode, touch Menu to access Menu mode. You can also drag your finger to the left.

2. Select a menu or option.

3. Press [ ] to move up one level; Press [ ] to return to Idle mode.

Switch applications

Learn to switch to other applications from a menu, without closing the menu screen you are using.

To switch applications,

You must change the camera key function to

Switch

(in Menu mode, touch

Phone settings → Camera key function

Settings →

using basic functions

1. While using a menu, press and hold the Camera key. The following applications are available:

• Call: open the dialling screen

• Music player: launch the music player

• Messages: access the Messages menu

• Browser: launch the web browser

using basic functions

• Main menu: access the main menu screen

• Games and more: access the Games and

more menu

2. Select an application.

Use widgets

Learn to use widgets on the toolbar.

Open the toolbar

In Idle mode, touch the arrow at the bottom left of the screen to open the toolbar. You can rearrange widgets on the toolbar or move them to the idle screen.

Depending on your region or service provider, available widgets may vary.

Add the widgets to the idle screen

1. Open the toolbar.

2. Drag a widget from the toolbar to the idle screen. You can position the widget anywhere on the screen.

Change the widgets

1. In Menu mode, touch Settings → Display and light → Widget.

2. Select the widgets you want to include to the toolbar and touch Save.

Access help information

Learn to access helpful information about your phone.

1. Open the toolbar.

2. Touch from the toolbar.

3. Rotate the phone anti-clockwise to landscape view.

4. Select a help topic to learn about an application or feature.

Drag your finger to the right or left to get more information.

To return to the previous level, touch

Customise your phone

Get more from your phone by customising it to match your preferences.

Adjust the volume of the key tones

In Idle mode, press the Volume key up or down to adjust the key tone volume.

Adjust the vibration intensity on the touch screen

You can adjust the intensity of the vibration when you touch the phone screen.

1. In Idle mode, press the Volume key up or down.

2. Touch Vibration and press the Volume key up or down to adjust the intensity of the vibration.

using basic functions

Switch to or from the silent profile

In Idle mode, press and hold [ ] to silence or unsilence your phone.

Change your ringtone

1. In Menu mode, touch Settings → Phone

using basic functions

profiles.

2. Touch next to the profile you are using.

3. Touch Voice call ringtone or Video call ringtone.

4. Select a ringtone from the list and touch Save.

5. Touch Save.

Select a wallpaper (Idle mode)

1. In Menu mode, touch Settings → Display and light → Wallpaper.

2. Scroll left or right to an image.

3. Touch Set.

Lock your phone

1. In Menu mode, touch Settings → Security.

2. Touch On under Phone lock.

3. Enter a new 4- to 8-digit password and touch Confirm.

4. Enter the new password again and touch

Confirm.

Use basic call functions

Learn to make or answer calls and use basic call functions.

During a call, your phone automatically locks the touch screen to prevent accidental inputs. To unlock, press [ ].

Make a call

1. In Idle mode, enter an area code and a phone number.

2. Touch Voice call or press [ ] to dial the number. For a video call, touch More → Video call.

3. To end the call, press [ ].

Answer a call

1. When a call comes in, press [ ].

2. For a video call, press [ ] and touch Show me to allow the caller to see you via the front camera lens.

3. To end the call, press [ ].

Adjust the volume

To adjust the volume during a call, press the Volume key up or down.

Use the speakerphone feature

1. During a call, touch Speaker → Yes to activate the speaker.

2. To switch back to the earpiece, touch Speaker.

In Speakerphone mode, a noisy environment will make it difficult to hear the person whom you are speaking with. In a noisy environment, it is better to use the normal phone mode for better audio performance.

Use the headset

By plugging the supplied headset into the phone, you can make and answer calls:

• To redial the last call, press the headset button,

and then press again and hold.

• To answer a call, press the headset button.

• To end a call, press the headset button.

using basic functions

Send and view messages

Learn to send and view text (SMS), multimedia (MMS), and email messages.

Send a text or multimedia message

1. In Menu mode, touch Messages → Create

using basic functions

message → Message.

2. Touch Tap to add recipient → Enter manually.

3. Enter a destination number.

4. Touch Tap to add text.

5. Enter your message text. For sending as a text message, skip to step 7. For attaching multimedia, continue with step 6.

6. Touch Add media and add an item.

7. Touch Send to send the message.



p. 28

Send an email

1. In Menu mode, touch Messages → Create message → Email.

2. Touch Tap to add recipient → Enter manually.

3. Enter an email address.

4. Touch Tap to add subject and enter a subject.

5. Touch Tap to add text and enter your email text.

6. Touch Add files and attach a file (if necessary).

7. Touch Send to send the message.

Enter text

Enter text and create messages or notes.

Enter text using the virtual keypad

1. Open the text input field with the phone closed.

2. Touch the appropriate virtual keys to enter text.

• To switch between T9 and ABC modes, touch T9.

• To change case or switch to Number or Symbol mode, touch Abc.

• To switch to Symbol mode, touch .

You can use the following text input modes:

Mode Function

ABC

Number

Symbol

Touch the appropriate virtual key until the character you want appears on the display.

1. Touch the appropriate virtual keys to enter an entire word.

2. When the word displays correctly, touch

to insert a space. If the correct word does not display, touch to select an alternate word.

Touch the appropriate virtual key to enter a number.

Touch the appropriate virtual key to enter a symbol.

Enter text using the keypad

1. Open the text input field with the phone open.

2. Press the appropriate keys to enter text.

• To switch between T9 and ABC modes, press and hold [ ].

• To change case or switch to Number mode, press [ ].

• To switch to Symbol mode, touch .

You can use the following text input modes:

Mode Function

ABC

Press the appropriate alphanumeric key until the character you want appears on the display.

1. Press the appropriate alphanumeric keys to enter an entire word.

2. When the word displays correctly, press [ ] to insert a space. If the correct word does not display, press [ alternate word.

] to select an

using basic functions

Mode Function

Number

Press the appropriate alphanumeric key to enter a number.

View text or multimedia messages

1. In Menu mode, touch Messages → Inbox.

using basic functions

2. Select a text or multimedia message.

View an email

1. In Menu mode, touch Messages → Email inbox.

2. Select an account.

3. Touch Download.

4. Select an email or a header.

5. If you selected a header, touch Retrieve to view the body of the email.

Add and find contacts

Learn the basics of using the phonebook feature.

Add a new contact

1. In Idle mode, enter a phone number.

2. Touch More → Add to Phonebook → New.

3. Touch Phone or SIM.

4. Enter contact information.

5. Touch Save to add the contact to memory.

Find a contact

1. In Idle mode, touch Phonebook.

2. Touch the text input field (if necessary).

3. Enter the letter of the name you want to find. You can also drag to select the first letter of the name.

4. Select the contact’s name from the search list.

Once you have found a contact, you can:

• call the contact by touching

• edit the contact information by touching

Edit

Use basic camera functions

Learn the basics to capture and view photos and videos.

When you turn on the camera, the display may appear blank due to temporary electrostatic discharge. Try restarting the phone to solve the problem.

Capture photos

1. Slide open the phone.

2. In Idle mode, press and hold the Camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Aim the lens at the subject and make any adjustments.

5. Press the Camera key to take a photo. The photo is saved automatically.

View photos

In Menu mode, touch My files → Images → My photos → a photo file.

Rotate the phone anti-clockwise to landscape view. Tilt the phone to the left or right, photos will scroll left or right automatically.

To categorise and view photos in a wide view,

1. In Menu mode, touch Photo browser.

2. Rotate the phone anti-clockwise to landscape view.

using basic functions

3. Touch to categorise the photos.

4. Scroll left or right to view photos. Tilt the phone to the left or right, photos will scroll left or right automatically.

Capture videos

using basic functions

1. Slide open the phone.

2. In Idle mode, press and hold the Camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Touch → to switch to Recording mode.

5. Aim the lens at the subject and make any adjustments.

6. Press the Camera key to start recording.

7. Touch or press the Camera key to stop recording. The video is saved automatically.

View videos

In Menu mode, touch My files → Videos → My video clips → a video file.

Listen to music

Learn how to listen to music via the music player or FM radio.

Listen to the FM radio

1. Plug the supplied headset into the phone’s multifunction jack.

2. In Menu mode, touch Applications → FM radio.

3. Touch Yes to start automatic tuning. The radio scans and saves available stations automatically.

The first time you access the FM radio, you will be prompted to start automatic tuning.

4. Touch or to select a radio station. Touch and hold or to select a saved radio station. If you want to get information about the song you hear, touch More → Find music.



p. 48

5. To turn off the FM radio, touch .

Listen to music files

Start by transferring files to your phone or memory card:

• Download from the wireless web.

• Download from a PC with the optional Samsung

PC Studio.

• Receive via Bluetooth.



p. 45



p. 50

• Copy to your memory card.

• Synchronise with Windows Media Player 11.



p. 46



p. 45



p. 34

After transferring music files to your phone or memory card,

1. In Menu mode, touch Music → Music player.

2. Select a music category → a music file.

3. Control playback using the following icons:

Icon Function

Pause playback

Play or resume playback

Skip backward; Scan backward in a file (touch and hold)

Skip forward; Scan forward in a file (touch and hold)

using basic functions

Browse the web

Learn to access and bookmark your favourite web pages.

Browse web pages

1. In Menu mode, touch Browser → Home to

using basic functions

launch your service provider’s homepage.

2. Navigate web pages using the following icons:

Icon Function

Move backward or forward on a web page

Refresh the current web page

Zoom on a web page

Open a list of saved bookmarks

Add a bookmark

Change the view mode

Bookmark your favourite web pages

1. In Menu mode, touch Browser → Bookmarks.

2. Touch Add.

3. Enter a page title and a web address (URL).

4. Touch Save.

Use the Google services

If the Google service is available, Navigation service is unavailable information about Manual included on the supplied CD.

Navigation

Connect to Search

1. In Menu mode, select Google → Search.

2. Enter a keyword in the search box.

the

. For

, refer to the User

Connect to Mail

1. In Menu mode, select Google → Mail.

2. Set up your Google account and sign in.

3. Send or receive emails.

Connect to Maps

Depending on your region, the map service may not be available.

To search the map,

1. In Menu mode, select Google → Maps.

2. Scroll through the map.

3. Zoom in or out on the location you want.

To search for a specific location,

1. In Menu mode, select Google → Maps.

2. Touch Start and enter the address or the category of the business.

To get directions to a specific destination,

1. In Menu mode, select Google → Maps.

2. Touch More → Directions.

3. Enter the addresses of the starting location and the ending location.

4. Touch OK.

5. Select Show directions to view on the map.

using basic functions

using advanced

Use advanced call functions

Learn about your phone’s additional calling capabilities.

functions

Learn how to perform advanced operations and use

additional features of your mobile phone.

View and dial missed calls

Your phone will display calls you have missed on the display.

When you have one missed call, touch the call from the event alert widget and touch Voice call to dial.

When you have two missed calls or more, touch the call from the event alert widget and touch Logs → a missed call.

Call a recently dialled number

1. In Idle mode, press [ ] to display a list of recent numbers.

2. Select the number you want and touch or press [ ] to dial.

Hold a call or retrieve a held call

Touch Hold to place a call on hold or touch Retrieve to retrieve a held call.

1. Press [ ] to answer the second call. The first call is automatically placed on hold.

2. Touch Swap to switch between the calls.

Dial a second call

If your network supports this function, you can dial another number during a call:

1. Touch Hold to place the first call on hold.

2. Enter the second number to dial and touch Voice call or press [ ].

3. Touch Swap to switch between the two calls.

4. To end the call on hold, touch On hold → .

5. To end the current call, press [ ].

Answer a second call

If your network supports this function, you can answer a second incoming call:

Make a multiparty call (conference call)

1. Call the first party you want to add to the multiparty call.

2. While connected to the first party, call the second party. The first party is automatically placed on hold.

3. When connected to the second party, touch Join.

4. Repeat steps 2 and 3 to add more parties (if necessary).

5. To end the multiparty call, press [ ].

using advanced functions

Call an international number

1. In Idle mode, press and hold 0 to insert the [+] character.

2. Enter the complete number you want to dial (country code, area code, and phone number), and then touch Voice call or press [ ] to dial.

using advanced functions

Call a contact from the phonebook

You can call numbers directly from the phonebook using stored contacts.

1. In Idle mode, touch Phonebook.

2. Touch the contact you want.

3. Touch

next to



p. 30

the number you want to dial →

Use advanced phonebook functions

Learn to create namecards, set speed dial numbers, and create groups of contacts.

Create a namecard

1. In Idle mode, touch Phonebook → More → My namecard.

2. Enter your personal details.

3. Touch Save.

You can send your namecard by attaching it to a message or email or transferring it via the Bluetooth wireless feature.

Set speed dial numbers

1. In Idle mode, touch Phonebook.

2. Touch the Contacts drop-down menu and select Favourites.

3. Touch Add.

4. Select a contact. The contact is saved to the speed dial number.

The first three speed dial numbers will be assigned to the favourite contacts ( widget toolbar.

)

on the

Create a group of contacts

By creating groups of contacts, you can assign group names, ringtones, caller ID photos, and vibration type to each group or send messages and emails to an entire group. Start by creating a group:

1. In Idle mode, touch Phonebook.

2. Touch the Contacts drop-down menu and select Groups.

3. Touch Create group.

4. Set a group name, the caller ID photo, a group ringtone, and vibration type.

5. Touch Save.

Link your photos to contacts

Learn to tag faces in your photos to make calls or send messages from photos.

To link your photos to contacts,

1. In Idle mode, drag your finger to the right to access the photo contact screen.

2. Touch Add → a photo.

3. Touch Add to add a tag to a person’s face.

4. Touch Add tag, move or resize the rectangle on a face, and touch Done (if necessary).

5. Touch the face tag → Link to Phonebook → Search contact → a contact → Set. The selected contact is linked to the photo.

6. Press [ ] to add more photo contacts (step 2).

using advanced functions

Make calls or send messages from photos

1. In Idle mode, drag your finger to the right to access photo contact screen.

2. Scroll up or down to a photo. The face tag appears with the name.

using advanced functions

3. Touch the face tag Send message.

→ Voice call, Video call, or

Use advanced messaging functions

Learn to create templates and use templates to create new messages.

Create a text template

1. In Menu mode, touch Messages → Templates → Text templates.

2. Touch Create to open a new template window.

3. Touch

4. Touch More → Save as template.

the screen and e

nter your text.

Create a multimedia template

1. In Menu mode, touch Messages → Templates → Multimedia templates.

2. Touch Create to open a new template window.

3. Create a multimedia message, with a subject and desired attachments, to use as your template.

4. Touch More → Save as template.



p. 28

Insert text templates in new messages

1. To start a new message, in Menu mode, touch Messages → Create message → a message type.

2. Touch More → Insert → Text template → a template.

Create a message from a multimedia template

1. In Menu mode, touch Messages → Templates → Multimedia templates.

2. Select the template you want.

3. Touch Send. Your template opens as a new multimedia message.

Use advanced camera functions

Learn how to capture photos in various modes and customise camera settings.

Capture a series of photos

1. Slide open the phone.

2. Press and hold the Camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Touch → .

5. Make any necessary adjustments.

6. Press and hold the Camera key to take a series of photos.

Capture panoramic photos

1. Slide open the phone.

2. Press and hold the Camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Touch → .

5. Select the number of photos.

6. Make any necessary adjustments.

using advanced functions

7. Press the Camera key to take the first photo.

8. Slowly move the phone to the right. The phone captures the next photo automatically.

9. Repeat step 8 to complete the panoramic photo.

Capture divided photos

using advanced functions

1. Slide open the phone.

2. Press and hold the Camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Touch → .

5. Select an image layout.

6. Make any necessary adjustments.

7. Press the Camera key to take the divided photos.

Capture photos in Smile shot mode

1. Slide open the phone.

2. Press and hold the camera key to turn on the camera.

3. Rotate the phone anti-clockwise to landscape view.

4. Touch → .

5. Press the Camera key.

6. Aim the camera lens at your subject. Your phone recognises people in an image and detects their smiles. When the subject smiles, the phone automatically takes a photo.

Use camera options

While using the camera, touch → to access the following options:

Options Function

Focus mode

Timer

Resolution

White balance

Effects

ISO

Exposuremeter

Anti-Shake

Change the camera focus

Select the time delay

Change the resolution option

Adjust the colour balance of the image

Apply a special effect

Adjust the sensitivity of camera imaging sensor

Select a type of exposure metre

Reduce blur caused by vibration or movement

Options Function

WDR

Blink detection

Image quality

Adjust

Adjust the camera’s sensitivity to a wide range of available light

Set the camera to capture three photos in succession when people close eyes

Set the quality of your digital images

Adjust contrast, saturation, and sharpness of photos

While using the camcorder, touch → to access the following options:

Options Function

Timer

Resolution

White balance

Select the time delay

Change the resolution option

Adjust the colour balance of the video clip

using advanced functions

Options Function

Apply a special effect

Reduce blur caused by vibration or movement

Adjust the camera’s sensitivity to a wide range of available light

Adjust the quality of your video clips

Adjust contrast, saturation, and sharpness

using advanced functions

Effects

Anti-Shake

WDR

Video quality

Adjust

Customise camera settings

While using the camera, touch → to access the following:

Setting Function

Guidelines

Display the guidelines

Setting Function

Review

Auto rotation

GPS

Shutter sound

Audio recording

Storage

Shortcut info

Set the camera to switch to the preview screen after capturing photos or video clips

Set the preview screen to rotate as you rotate the phone

Set the camera to record GPS information to images or video clips

Select a sound to accompany the shutter action

Turn the audio on or off

Select a memory location to store new images or video clips

View shortcut keys to adjust camera options

Use advanced music functions

Learn to prepare music files, create playlists, and store radio stations.

Copy music files via Samsung PC Studio

1. In Menu mode, touch Settings → Phone settings → PC connections → Samsung PC studio → Save.

2. Press [ ] to return to Idle mode.

3. Using an optional PC data cable, connect the multifunction jack on your phone to a PC.

4. Run Samsung PC Studio and copy files from the PC to the phone. Refer to the Samsung PC Studio help for more information.

Copy music files to a memory card

1. Insert a memory card.

2. In Menu mode, touch Settings → Phone

settings → PC connections → Mass storage → Save.

3. Press [ ] to return to Idle mode.

4. Using an optional PC data cable, connect the multifunction jack on your phone to a PC. When connected, a pop-up window will appear on the PC.

5. Open the folder to view files.

6. Copy files from the PC to the memory card.

using advanced functions

Synchronise your phone with Windows Media Player

1. Insert a memory card.

2. In Menu mode, touch Settings → Phone

settings → PC connections → Media player → Save.

using advanced functions

3. Press [ ] to return to Idle mode.

4. Using an optional PC data cable, connect the multifunction jack on your phone to a PC with Windows Media Player installed.

When connected, a pop-up window will appear on the PC.

5. Open Windows Media Player to synchronise music files.

6. Edit or enter your phone’s name in the pop-up window (if necessary).

7. Select and drag the music files you want to the sync list.

8. Click Start Sync.

Create a playlist

1. In Menu mode, touch Music → Music player → Playlists.

2. Touch Create.

3. Enter a title for your new playlist.

4. To assign an image to the playlist, touch Tap to edit and select an image or capture a new photo.

5. Touch Save.

6. Select the new playlist.

7. Touch Add → Tracks.

8. Select the files you want to include and touch

Add.

Customise your music player settings

1. In Menu mode, touch Music → Music player.

2. Touch Settings.

3. Adjust the settings to customise your music player.

4. Touch Save.

Record songs from the FM radio

1. Plug the supplied headset into the phone’s multifunction jack.

2. In Menu mode, select Applications → FM radio.

3. Touch to start the FM radio.

4. Touch More → Record to start recording.

5. When you are finished recording, touch Stop. The music file will be saved in Radio clips (in Menu mode, select My files → Sounds).

The recording feature is developed for voice recording only. The quality of the recording will be much lower than digital media.

Store radio stations automatically

1. In Menu mode, touch Applications → FM radio.

2. Touch More → Self-tuning.

3. Touch Yes to confirm (if necessary). The radio scans and saves available stations automatically.

using advanced functions

Find information of music

Learn to access an online music service and get information about the songs you hear while on the move.

1. In Menu mode, touch Music → Find music.

2. Select Find music to connect to the server.

using advanced functions

3. When your phone is successfully registered, touch to record a part of music you want to find.

Some service providers may not support this service and the database may not have information for all songs.

using tools and

applications

Learn how to work with your mobile phone’s tools

and additional applications.

Use the Bluetooth wireless feature

Learn about your phone’s ability to connect to other wireless devices for exchanging data and using hands-free features.

Turn on the Bluetooth wireless feature

1. In Menu mode, touch Applications → Bluetooth.

2. Touch the circle in the centre to turn on the Bluetooth wireless feature.

To allow other devices to locate your phone, touch

Settings → On under My phone’s

visibility → Save

If you select Custom, set duration that your phone is visible.

4. Touch Save.

Find and pair with other Bluetoothenabled devices

1. In Menu mode, touch Applications → Bluetooth → Search.

2. Select and drag a device icon into the centre.

3. Enter a PIN for the Bluetooth wireless feature or

using tools and applications

the other device’s Bluetooth PIN, if it has one, and touch Done. When the owner of the other device enters the same PIN or accepts the connection, pairing is complete.

You may not need to enter a PIN depending on the device.

Send data using the Bluetooth wireless feature

1. Select the file or item from one of your phone’s applications that you want to send.

2. Touch Send via or Send URL via → Bluetooth or touch More → Send namecard via →

Bluetooth.

Receive data using the Bluetooth wireless feature

1. Enter the PIN for the Bluetooth wireless feature and touch OK (if necessary).

2. Touch Yes to confirm that you are willing to receive data from the device (if necessary).

Use Remote SIM mode

In Remote SIM mode, you can make or answer calls only with a connected Bluetooth hands-free car kit via the SIM or USIM card on your phone.

To activate Remote SIM mode,

1. In Menu mode, touch Applications → Bluetooth → Settings.

2. Touch On under Remote SIM mode.

3. Touch Save. To use Remote SIM mode, start the Bluetooth

connection from a Bluetooth hands-free car kit.

Activate and send an SOS message

When you have an emergency, you can send an SOS message asking for help.

This feature may not be available depending on your region or service provider.

1. In Menu mode, touch Messages → SOS messages → Sending options.

2. Touch On to turn on the SOS messaging feature.

3. Touch the recipient field to open the recipient list.

4. Touch Contacts to open your contact list.

5. Select the contacts you want and touch Add.

6. Select a phone number (if necessary).

7. Touch OK to save the recipients.

8. Touch the Once drop-down menu and select the number of times to repeat the SOS message.

9. Touch Save → Yes.

To send an SOS message, the keys must be locked. Press the Volume key four times.

Once you send an SOS message, all phone functions will be suspended until you press [ ]. If you press [ ], phone functions will be available, but the keys will remain locked.

using tools and applications

Activate the mobile tracker

When someone inserts a new SIM or USIM card in your phone, the mobile tracker feature will automatically send the contact number to two recipients to help you locate and recover your phone. To activate the mobile tracker,

using tools and applications

1. In Menu mode, touch Settings → Security → Mobile tracker.

2. Enter your password and touch Confirm.

3. Touch On to turn on the mobile tracker.

4. Touch the recipient field to open the recipient list.

5. Enter a phone number.

6. Touch OK to save the recipients.

7. Touch the sender input field.

8. Enter the sender’s name.

9. Touch Save → Accept.

Make fake calls

You can simulate fake incoming calls when you want to get out of meetings or unwanted conversations. You can also make it appear as if you are talking on the phone by playing back a recorded voice.

To activate the fake call feature,

1. In Menu mode, touch Settings → Application settings → Fake call.

2. Touch On to activate the feature.

3. Touch Save.

To record a voice,

1. In Menu mode, touch Settings → Application settings → Fake call.

2. Touch Voice recorder.

3. Touch to start recording.

4. Speak into the microphone.

5. When you are finished speaking, touch .

6. Touch Set to set the recording as a response for the fake call.

7. Touch Save.

To make a fake call, press and hold the Volume key down in Idle mode.

Record and play voice memos

Learn to operate your phone’s voice recorder.

Record a voice memo

1. In Menu mode, touch Applications → Voice recorder.

2. Touch to start recording.

3. Speak your memo into the microphone.

4. When you are finished speaking, touch . Your memo is saved automatically.

Play a voice memo

1. In Menu mode, touch My files → Sounds → Voice clips.

2. Select a file.

3. Control the playback using the following icons:

Icon Function

Pause playback

Play or resume playback

Scan backward in a file

Scan forward in a file

Adjust the volume

using tools and applications

Edit images

Learn to edit images and apply fun effects.

Apply effects to images

1. In Menu mode, touch My files → Images → My photos → a photo file.

using tools and applications

2. Touch .

3. Touch Edit → Effects → an effect option.

4. Select a variation of the effect to apply and touch Done. To apply a blur effect to a specific area of an image, move or resize the rectangle and touch Blur → Done.

5. When you are finished with applying effects, touch Files → Save as.

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Adjust an image

1. In Menu mode, touch My files → Images → My photos → a photo file.

2. Touch .

3. Touch Edit → Adjust → an adjustment option (brightness, contrast, or colour). To adjust the image automatically, select Auto level.

4. Adjust the image as desired and touch Done.

5. When you are finished with adjustment, touch Files → Save as.

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Transform an image

1. In Menu mode, touch My files → Images → My photos → a photo file.

2. Touch .

3. Touch Edit → Transform → Resize, Rotate, or Flip.

4. Rotate or flip the image as desired and touch Done. To resize the image, select a size and touch Save → Done. Skip to step 6.

5. When you are finished with transforming options, touch Files → Save as.

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Crop an image

1. In Menu mode, touch My files → Images → My photos → a photo file.

2. Touch .

3. Touch Edit → Crop.

4. Move the rectangle over the area you want to crop and touch Crop → Done.

5. When you are finished cropping, touch Files → Save as.

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Insert a visual feature

1. In Menu mode, touch My files → Images → My photos → a photo file.

2. Touch .

using tools and applications

3. Touch Edit → Insert → a visual feature (frame, image, clip art, emoticon, or text).

4. Select a visual feature or enter text and touch Done.

5. When you are finished adding visual features, touch Files → Save as.

using tools and applications

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Add a memo

1. In Menu mode, touch My files → Images → My photos → a photo file.

2. Touch .

3. Touch Edit → Memo on screen.

4. Select a colour and enter a memo on the screen, and then touch Done.

5. When you are finished, touch Files → Save as.

6. Select a memory location (if necessary).

7. Enter a new file name for the image and touch

Save.

Print images

Learn to print your image with an optional PC data cable or the Bluetooth wireless feature.

To print an image using an optional PC data cable,

1. Connect the multifunction jack on your phone to a compatible printer.

2. Open an image.

3. Touch More → Print via → USB.

4. Set print options and print the image.

To print an image using the Bluetooth wireless feature,

1. Open an image.



p. 31



p. 31

2. Touch More → Print via → Bluetooth.

3. Select a Bluetooth-enabled printer and pair with the printer.

4. Set print options and print the image.



p. 50

Edit videos

Learn to edit video files and apply visual effects.

Trim any segment

1. In Menu mode, touch Applications → Video editor.

2. Touch Files → Import image or Import video.

3. Select an image or video category → an image or video and touch Add. For an image, select the duration that the image displays.

4. Touch More → Files to add more images or videos.

5. Touch Edit → Trim.

6. Touch to play the video and touch Start mark at the point where you want the new video to begin.

7. Touch End mark at the point where you want the new video to end.

8. Touch Trim.

9. When you are finished, touch More → Export → Video → Yes.

To save the project for future use, touch Files → Save project in

Other files

10. Enter a new file name and touch Save.

11. To check the file, touch Yes (if necessary).

. The project will be saved

Split videos

1. In Menu mode, touch Applications → Video editor.

using tools and applications

2. Touch Files → Import image or Import video.

3. Select an image or video category → an image or video and touch Add.

For an image, select the duration that the image displays.

4. Touch More → Files to add more images or

using tools and applications

videos.

5. Touch Edit → Split.

6. Touch to play the video and touch Split point → Split to divide the file into two clips.

7. Insert an image or video as desired between the clips.

8. When you are finished, touch More → Export → Video → Yes. To save the project for future use, touch Files → Save project in

Other files

9. Enter a new file name and touch Save.

. The project will be saved

10. To check the file, touch Yes (if necessary).

Insert text

Inserting text to a video may not be available depending on your service provider.

1. In Menu mode, touch Applications → Video editor.

2. Touch Files → Import image or Import video.

3. Select an image or video category → an image or video and touch Add. For an image, select the duration that the image displays.

4. Touch More → Files to add more images or videos.

5. Touch Edit → Insert → Text.

6. Touch to play the video and touch Start mark at the point where you want the text to be displayed.

7. Touch End mark at the point where you want the text to be disappeared.

8. Touch Insert.

9. Enter text and touch OK.

10. Move or resize the text and touch Done.

11. When you are finished, touch More → Export → Video → Yes. To save the project for future use, touch Files → Save project in

Other files

12. Enter a new file name and touch Save.

13. To check the file, touch Yes (if necessary).

. The project will be saved

Add sound track

1. In Menu mode, touch Applications → Video editor.

2. Touch Files → Import image or Import video.

3. Select an image or video category → an image or video and touch Add. For an image, select the duration that the image displays.

4. Touch More → Files to add more images or videos.

5. Touch Additional audio track → Import sound.

6. Touch Sounds → a sound category → a sound → Add.

7. When you are finished, touch More → Export → Video → Yes.

To save the project for future use, touch Files → Save project in

Other files

8. Enter a new file name and touch Save.

9. To check the file, touch Yes (if necessary).

. The project will be saved

using tools and applications

Upload photos and videos to the web

Learn to post your photos and videos to photo sharing websites and blogs.

• If the Navigation service is unavailable,

pix

using tools and applications

will display under

• Depending on your region or service provider, Share pix may not be available.

Set your favourite destination list

1. In Menu mode, touch Applications → Share pix → Settings → Preferred lists.

2. Touch Accept to confirm (if necessary).

3. Select the destinations you want to add and touch Save. If you select Update blog lists, new destination sites are added to the list automatically.

Applications

Upload a file

To upload photos and videos, you must have accounts of photo sharing websites and blogs.

1. In Menu mode, touch Applications → Share pix → a destination you want to post to.

2. Enter the user ID and password of the destination.

3. Touch Tap to add and select a media file.

4. Enter the post details and touch Upload to web.

You can also upload media files from or My files, by selecting

Upload to web.

Camera

or More →

Use Java-powered games and applications

Learn to use games and applications powered by award-winning Java technology.

Depending on the software of the phone, the download of java files may not be supported.

Play games

1. In Menu mode, touch Applications → Games and more.

2. Select a game from the list and follow the onscreen instructions.

Available games may vary, depending on your service provider or region. Game controls and options may vary.

Launch applications

1. In Menu mode, touch Applications → Games and more → an application.

2. Touch More to access a list of various options and settings for your application.

Synchronise data

Learn to synchronise Phonebook, Calendar, Task, and Memo with the web server you have specified.

Create a synchronisation profile

1. In Menu mode, touch Applications → Synchronise.

2. Touch Add and specify profile parameters.

3. When you are finished, touch Save.

using tools and applications

Start synchronisation

1. In Menu mode, touch Applications → Synchronise.

2. Select a synchronisation profile.

3. Touch the selected synchronisation profile or Start sync.

using tools and applications

4. Touch Continue to start synchronisation with the web server you have specified.

Use RSS reader

Learn to use RSS reader to get the latest news and information from your favourite websites.

Create feeds

1. In Menu mode, touch Applications → RSS reader.

2. Touch Add.

3. Enter the address of an RSS feed and touch Done.

4. Touch OK.

Read RSS feeds

1. In Menu mode, touch Applications → RSS reader.

2. Touch Update → a feed → Update → Yes.

3. Select a feed category → an updated feed.

Customise RSS reader settings

1. In Menu mode, touch Applications → RSS reader.

2. Touch More → Settings → Network settings.

3. Touch next to a profile you want.

4. Change the settings to customise your RSS reader.

5. Touch Save.

View your current position

In Menu mode, touch Settings → Phone settings → GPS settings → GPS position.

To select a connection type,

1. In Menu node, touch Settings → Phone settings → GPS settings → GPS connection.

2. Select Internal GPS or Bluetooth GPS and touch Save.

If you select with a Bluetooth-enabled device.

Bluetooth GPS

, you must pair



p. 50

Create and view world clocks

Learn to view the time in another city and set world clocks to appear on your display.

Create a world clock

1. In Menu mode, touch Organiser → World clock.

2. Touch → Add.

3. Select a time zone.

4. To set daylight saving time, touch .

5. Touch OK to create your world clock. The world clock is set as the second clock.

6. Touch Add to add more world clocks (step 3).

Add a world clock to your display

In Dual Clock Display mode, you can view clocks with two different time zones on your display.

After you have created a world clock,

1. In Menu mode, touch Organiser → World clock.

2. Touch → Set as 2nd clock.

3. Select the world clock you want to add.

4. Touch Set.

using tools and applications

Set and use alarms

Learn to set and control alarms for important events.

Set a new alarm

1. In Menu mode, touch Alarms.

2. Touch Create alarm.

using tools and applications

3. Set alarm details.

4. Touch Save.

The auto power-up feature sets the phone to automatically turn on and sound the alarm at the designated time if the phone is turned off.

Stop an alarm

When the alarm sounds,

• Drag the slider to Stop to stop an alarm without snooze.

• Drag the slider to Stop to stop an alarm with snooze or drag the slider to Snooze to silence the alarm for the snooze period.

Deactivate an alarm

1. In Menu mode, touch Alarms.

2. Touch Off next to the alarm you want to

deactivate.

Use the calculator

1. In Menu mode, touch Organiser → Calculator.

2. Use the keys that correspond to the calculator

display to perform basic mathematical operations.

Convert currencies or measurements

1. In Menu mode, touch Organiser → Convertor → a conversion type.

2. Enter the currencies or measurements and units in the appropriate fields.

Set a countdown timer

1. In Menu mode, touch Applications → Timer.

2. Set the length of time to count down.

3. Touch Start to begin the countdown.

4. Touch Stop to pause the countdown.

5. When the timer expires, drag the slider to Stop to stop the alerts.

Use the stopwatch

1. In Menu mode, touch Applications → Stopwatch.

2. Touch Start to begin the stopwatch.

3. Touch Lap to record lap times.

4. When you are finished, touch Stop.

5. Touch Reset to clear recorded times.

Create a new task

1. In Menu mode, touch Organiser → Task.

2. Touch Create task.

3. Enter the details of the task and touch Save.

using tools and applications

Create a text memo

1. In Menu mode, touch Organiser → Memo.

2. Touch Create memo.

3. Enter your memo text and touch Save.

using tools and applications

Manage your calendar

Learn to change the calendar view and create events.

Change the calendar view

1. In Menu mode, touch Organiser → Calendar.

2. Touch More → View by day or View by week.

Create an event

1. In Menu mode, touch Organiser → Calendar.

2. Touch Create schedule.

3. Enter the details of the event as required.

4. Touch Save.

troubleshooting

If you are having trouble with your mobile phone, try these troubleshooting procedures before contacting a service professional.

While using your phone, the following messages may appear:

Message Try this to solve the problem:

Insert SIM card to access network services

Phone lock

Ensure that the SIM or USIM card is installed correctly.

When the phone lock feature is enabled, you must enter the password you set for the phone.

Message Try this to solve the problem:

When using the phone for the first time or when the PIN requirement is

PIN code

PUK code

enabled, you must enter the PIN supplied with the SIM or USIM card. You can disable this feature by using

PIN lock

the

Your SIM or USIM card is blocked, usually as a result of entering your PIN incorrectly several times. You must enter the PUK supplied by your service provider.

menu.

Your phone displays “Service unavailable” or “Network error.”

• When you are in areas with weak signals or poor reception, you may lose reception. Move to another area and tr y again.

• You cannot access some options without a subscription. Contact your ser vice provider for more details.

troubleshooting

You enter a number, but the call is not dialled.

• Ensure that you have pressed the Dial key: [ ].

• Ensure that you have accessed the right cellular network.

• Ensure that you have not set call barring for the phone number.

Another caller cannot reach you.

• Ensure that your phone is turned on.

• Ensure that you have accessed the right cellular network.

• Ensure that you have not set call barring for the phone number.

Another caller cannot hear you speaking.

• Ensure that you are not covering the built-in microphone.

• Ensure that the microphone is close to your mouth.

• If using a headset, ensure that it is properly connected.

The phone beeps and the battery icon flashes.

Your battery is low. Recharge or replace the battery to continue using the phone.

The audio quality of the call is poor.

• Ensure that you are not blocking the phone’s internal antenna.

• When you are in areas with weak signals or poor reception, you may lose reception. Move to another area and tr y again.

You select a contact to call, but the call is not dialled.

• Ensure that the correct number is stored in the contact list.

• Re-enter and save the number, if necessary.

The battery does not charge properly or sometimes the phone turns itself off.

• The battery terminals may be dirty. Wipe both gold-coloured contacts with a clean, soft cloth and try charging the battery again.

• If the battery will no longer charge completely, dispose of the old battery properly and replace it with a new battery.

Your phone is hot to the touch.

When you use several applications at once, your phone requires more power and may heat up.

This is normal and should not affect your phone’s lifespan or performance.

troubleshooting

index

alarms

creating, 64 deactivating, stopping,

battery

charging, installing, low battery indicator,

Bluetooth

activating, receiving data, remote SIM mode, sending data,

browser

see web or photo browser

calculator

see tools, calculator

calendar

see tools, calendar

calls

advanced functions, answering additional calls, answering, basic functions, dialling additional calls, dialling missed calls, from the phonebook, international numbers, making fake calls, making,

multiparty, placing on hold, recently dialled, retrieving held calls, viewing missed,

clock

see world clock

conference calls

see calls, multiparty

contacts

adding, creating groups, finding, linking from photos,

converter

see tools, convertor

countdown timer

see tools, countdown timer

FM radio

listening to, recording songs, storing stations,

headset

images

adding memos, adjusting, applying effects, cropping, inserting visual features, printing, transforming,

internet

see web browser

Java

accessing applications, launching games,

key tones

lock

memo

memory card

messages

see phone lock

see text or voice memos

sending email, sending multimedia, sending text, viewing email,

viewing multimedia, viewing text,

mobile tracker

multimedia

see messages

music finding

music player

creating playlists, customising, listening to music, synchronising,

namecards

offline profile

phone lock

photo browser

index

photo contacts 39

photos

advanced capturing, basic capturing, editing, viewing,

radio

see FM radio

index

ringtone

RSS reader

see tools, RSS reader

share pix

see tool, mobile blog

silent profile

SIM card

SOS message

stopwatch

see tools, stopwatch

synchronisation

creating a profile, starting,

task

see tools, task

templates

inserting, multimedia, text,

text

creating memos, entering, messages,

timer

see tools, countdown timer

tools

alarm, calculator, calendar,

convertor, countdown timer, image editor, mobile blog, RSS reader, stopwatch, task,

video editor,

videos

capturing, editing,

viewing,

voice memos

playing,

recording,

54 60 62

volume

call volume, 27 key tone volume,

wallpaper

web browser

widgets

Windows Media Player

world clock

adding bookmarks, launching homepage,

creating, setting dual display,

index

Declaration of Conformity (R&TTE)

We, Samsung Electronics

declare under our sole responsibility that the product

GSM Mobile Phone : S8300V

to which this declaration relates, is in conformity with the following standards and/or other normative documents.

SAFETY

EMC

SAR

RADIO

We hereby declare that [all essential radio test suites have been carried out and that] the above named product is in conformity to all the essential requirements of Directive 1999/5/EC.

The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the following Notified Body(ies):

BABT, Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD, UK Identification mark: 0168

The technical documentation kept at :

Samsung Electronics QA Lab.

which will be made available upon request. (Representative in the EU)

Samsung Electronics Euro QA Lab. Blackbushe Business Park, Saxony Way, Yateley, Hampshire, GU46 6GG, UK*

200 . . Yong-Sang Park / S. Manager

(place and date of issue) (n ame and signature of authorised person)

* It is not the address of Samsung Service Centre. For the address or the

phone number of Samsung Service Centre, see the warranty card or contact the retailer where you purchased your phone.

Samsung GT-S8300 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

contents

Safety warnings

Safety precautions

Important usage information

Unpack

Phone layout

Keys

Display

Icons

Install the SIM or USIM card and battery

Charge the battery

Insert a memory card (optional)

Turn your phone on and off

Use the touch screen

Access menus

Switch applications

Use widgets

Access help information

Customise your phone

Use basic call functions

Send and view messages

Add and find contacts

Use basic camera functions

Listen to music

Browse the web

Use the Google services

Use advanced call functions

Use advanced phonebook functions

Use advanced messaging functions

Use advanced camera functions

Use advanced music functions

Use the Bluetooth wireless feature

Activate and send an SOS message

Make fake calls

Record and play voice memos

Print images

Synchronise data

Create and view world clocks

Use the calculator

Set a countdown timer

Use the stopwatch

Create a new task

Manage your calendar

troubleshooting

index
