Samsung GT-N8000 User Guide
GT-N8000
user manual
Using this manual
2
Using this manual
Congratulations on your purchase of the Samsung mobile
device. This powerful, “go anywhere” device, puts the best
of the web and mobile computing at your fingertips in a
lightweight, highly versatile platform that fits your active
lifestyle. Built on the Google Android operating system, the
Samsung mobile device gives you access to thousands of
useful and entertaining applications to enrich your mobile
web experience.
With integrated wireless access and a responsive touch
screen, you can read books and newspapers on the go; stay
up-to-date on the latest news, sports, and weather; manage
your multimedia and business files; and browse the web for
maps, business locations, and more.
Read me first
●
Please read all safety precautions and this manual carefully
before using your device to ensure safe and proper use.
●
The descriptions in this manual are based on the default
settings of your device.
●
Images and screenshots used in this user manual may differ
in appearance from the actual product.
●
Content in this user manual may differ from the product, or
from software provided by service providers or carriers, and
is subject to change without prior notice. Refer to
www.samsung.com
manual.
for the latest version of the user
Using this manual
3
●
Available features and additional services may vary by
device, software, or service provider.
●
Formatting and delivery of this user manual is based
on Google Android operating systems and may vary
depending on the user’s operating system.
●
Applications and their functions may vary by country,
region, or hardware specifications. Samsung is not liable for
performance issues caused by third-party applications.
●
Samsung is not liable for performance issues or
incompatibilities caused by edited registry settings or
modified operating system software. Attempting to
customise the operating system may cause your device or
applications to work improperly.
●
You may upgrade your mobile device’s software by
accessing
●
Software, sound sources, wallpapers, images, and other
www.samsung.com
.
contents provided in this device are licenced for limited use
between Samsung and their respective owners. Extracting
and using these materials for commercial or other purposes
is an infringement of copyright laws. Samsung is not liable
for such copyright infringement by the user.
●
Please keep this manual for future reference.
Using this manual
4
Instructional icons
Before you start, familiarise yourself with the icons you will
see in this manual:
Warning—situations that could cause injury to
yourself or others
Caution—situations that could cause damage to
your device or other equipment
Note—notes, usage tips, or additional information
►
→
Refer to—pages with related information; for
example:
► p.12 (represents “see page 12”)
Followed by—the order of options or menus you
must select to perform a step; for example: Open the
→
application list and select Settings
About device
(represents Settings, followed by About device)
Copyright
Copyright © 2012 Samsung Electronics
This user manual is protected under international copyright
laws.
No part of this user manual may be reproduced, distributed,
translated, or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording,
or storing in any information storage and retrieval system,
without the prior written permission of Samsung Electronics.
Using this manual
5
Trademarks
●
SAMSUNG and the SAMSUNG logo are registered
trademarks of Samsung Electronics.
●
The Android logo, Google
Mail
are trademarks of Google, Inc.
●
Bluetooth
Inc. worldwide.
, YouTube™, Google Play™ Store, and Google Talk™
™
is a registered trademark of the Bluetooth SIG,
®
, Google Maps™, Google
™
●
Wi-Fi
Wi-Fi CERTIFIED
trademarks of the Wi-Fi Alliance.
●
DivX
associated logos are trademarks
of Rovi Corporation or its
subsidiaries and are used under
licence.
●
All other trademarks and copyrights are the property of
their respective owners.
, Wi-Fi Protected Setup™, Wi-Fi Direct™,
®
, and the Wi-Fi logo are registered
™
, DivX Certified® and
®
ABOUT DIVX VIDEO
DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX
Certified
for more information and software tools to convert your files
into DivX videos.
device that plays DivX video. Visit
®
www.divx.com
ABOUT DIVX VIDEO-ON-DEMAND
This DivX Certified® device must be registered in order to play
purchased DivX Video-on-Demand (VOD) movies. To obtain
your registration code, locate the DivX VOD section in your
device setup menu. Go to
on how to complete your registration.
DivX Certified
premium content.
May play DivX
to play DivX® video up to HD 720p, including
®
video up to HD 1080p.
®
vod.divx.com
for more information
Using this manual
6
Contents
Assembling ....................................................... 12
Unpack ................................................................................................. 12
Install the SIM or USIM card ......................................................... 12
Charge the battery .......................................................................... 13
Insert a memory card (optional) ................................................ 15
Getting started ................................................. 18
Turn your device on and off ........................................................ 18
Get to know your device ............................................................... 19
Use the S Pen and the touch screen ........................................ 23
Get to know the Home screen ................................................... 25
Access applications ......................................................................... 31
Customise your device .................................................................. 32
Enter text ............................................................................................. 39
Using special features ..................................... 42
Learn basic S Pen actions................................................................42
Learn advanced S Pen actions ......................................................43
Replace the tip of S Pen ...................................................................44
Learn motions .....................................................................................45
Use Handwriting mode ...................................................................47
Use S Note .............................................................................................51
Use the quick note pad ...................................................................60
Use S Planner ....................................................................................... 61
Learn Quick Command feature....................................................64
S Pen Air View ...................................................................................... 65
Capture screen area ..........................................................................66
Contents
7
Contents
8
Web ................................................................... 67
Internet ................................................................................................. 67
Game Hub ........................................................................................... 72
Play Books ........................................................................................... 72
Play Movies ......................................................................................... 72
Play Store ............................................................................................. 73
YouTube ............................................................................................... 74
Video Hub ........................................................................................... 74
Maps ...................................................................................................... 75
Latitude ................................................................................................ 76
Local ....................................................................................................... 77
Navigation ........................................................................................... 77
Samsung Apps .................................................................................. 78
S Suggest ............................................................................................. 79
Google .................................................................................................. 79
Learning Hub ..................................................................................... 80
Communication ............................................... 81
Calling ................................................................................................... 81
Messaging ........................................................................................... 92
Google Mail ........................................................................................ 94
Email ...................................................................................................... 97
Talk ......................................................................................................... 99
ChatON ............................................................................................... 100
Messenger ......................................................................................... 101
Google+ ............................................................................................. 101
Entertainment ................................................ 102
Music Player ...................................................................................... 102
Music Hub ......................................................................................... 105
Contents
9
Camera ............................................................................................... 105
Video Player ...................................................................................... 115
Gallery ................................................................................................. 118
Paper Artist ....................................................................................... 122
Video Editor ...................................................................................... 122
Personal information ..................................... 126
Contacts ............................................................................................. 126
Connectivity ................................................... 130
PC connections ............................................................................... 130
Wi-Fi ..................................................................................................... 132
Wi-Fi Direct ........................................................................................ 135
AllShare Cast .................................................................................... 136
AllShare Play ..................................................................................... 137
Group Play ......................................................................................... 140
Bluetooth ........................................................................................... 141
Mobile network sharing .............................................................. 143
GPS ....................................................................................................... 145
TV connections ............................................................................... 146
VPN connections ............................................................................ 148
Tools ................................................................ 150
Alarm ................................................................................................... 150
Calculator .......................................................................................... 151
Downloads ........................................................................................ 151
Dropbox ............................................................................................. 152
My Files ............................................................................................... 153
Polaris Office .................................................................................... 155
PS Touch ............................................................................................. 156
Voice Search ..................................................................................... 157
S Voice ................................................................................................. 157
World Clock ...................................................................................... 158
Settings ........................................................... 159
Access the Settings menu .......................................................... 159
Wi-Fi ..................................................................................................... 159
Bluetooth ........................................................................................... 159
Data usage ........................................................................................ 159
More settings ................................................................................... 160
Blocking mode ................................................................................ 162
Sound .................................................................................................. 162
Display ................................................................................................ 163
Storage ............................................................................................... 164
Power saving mode ...................................................................... 164
Battery ................................................................................................ 164
Application manager ................................................................... 165
Location services ............................................................................ 165
Lock screen ....................................................................................... 165
Security ............................................................................................... 166
Language and input ..................................................................... 168
Cloud ................................................................................................... 170
Backup and reset ............................................................................ 170
Add account ..................................................................................... 171
Motion ................................................................................................ 171
S Pen .................................................................................................... 171
Accessory ........................................................................................... 172
Date and time .................................................................................. 172
Accessibility ...................................................................................... 173
Developer options ......................................................................... 174
About device .................................................................................... 176
Contents
10
Troubleshooting ............................................ 177
Index ............................................................... 182
Contents
11
Assembling
12
Assembling
Unpack
Check your product box for the following items:
●
Mobile device
●
Quick start guide
Use only Samsung-approved software. Pirated or illegal
software may cause damage or malfunctions that are
not covered by your manufacturer's warranty.
●
The items supplied with your device and available
accessories may vary depending on your region or
service provider.
●
You can purchase additional accessories from your
local Samsung dealer.
●
The supplied accessories perform best for your device.
●
Accessories other than the supplied ones may not be
compatible with your device.
Install the SIM or USIM card
When you subscribe to a cellular service, you will receive
a Subscriber Identity Module (SIM) card, with subscription
details, such as your personal identification number (PIN) and
optional services. To use UMTS or HSDPA services, you can
purchase a Universal Subscriber Identity Module (USIM) card.
Assembling
13
To install the SIM or USIM card,
Open the cover of the SIM card slot.
1
Insert the SIM or USIM card with the gold-coloured
2
contacts facing down.
●
Do not insert a memory card into the SIM card slot.
If the memory card becomes lodged in the SIM card
slot, you must take your device to a Samsung Service
Centre to have the memory card removed.
●
The SIM card slot of your device is only suited for
standard SIM cards. Inserting a microSIM card or a
microSIM card with an unauthorised holder may
cause damage to the SIM card slot of your device.
Close the cover of the SIM card slot.
3
Charge the battery
Your device has a built-in battery. Before using the device
for the first time or when the battery has been unused for an
extended period, you must charge the battery.
Use only Samsung-approved chargers. Unauthorised
chargers can cause batteries to explode or damage your
device.
Assembling
14
●
Charge the battery only with a charger. You cannot
charge the battery with the USB cable.
●
When your battery is low, the device will emit a
warning tone and display a low battery message. The
battery icon
will also be empty. If the battery level
becomes too low, the device will automatically power
off. Recharge your battery to continue using your
device.
●
If the battery is completely discharged, you cannot
turn on the device, even with the USB power adapter
connected. Allow a depleted battery to charge for a
few minutes before you try to turn on the device.
Connect the USB cable to the USB power adapter, and
1
then plug the end of the USB cable into the multifunction
jack.
The shape of the USB power adapter may differ
depending on your region.
Connecting the USB cable improperly may cause
serious damage to the device or USB power adapter.
Any damage caused by misuse is not covered by the
warranty.
Assembling
15
Plug the USB power adapter into a power outlet.
2
●
You can use the device while it is charging, but it may
take longer to fully charge the battery.
●
While the device is charging, the touch screen may
not function due to an unstable power supply. If
this happens, unplug the USB power adapter from
the power outlet or unplug the USB cable from the
device.
●
While charging, the device may heat up. This is
normal and should not affect your device’s lifespan or
performance.
●
If your device is not charging properly, bring your
device and the charger to a Samsung Service Centre.
When the battery is fully charged, first unplug the USB
3
power adapter and USB cable from the device, and then
from the power outlet.
To save energy, unplug the USB power adapter when
not in use. The USB power adapter does not have a
power switch, so you must unplug the USB power
adapter from the electrical socket when not in use to
avoid wasting power. The device should remain close to
the electrical socket while charging.
Insert a memory card (optional)
Your device accepts memory cards with maximum capacities
of 64 GB. Depending on the memory card manufacturer and
type, some memory cards may not be compatible with your
device.
Assembling
16
Samsung uses approved industry standards for memory
cards, but some brands may not be fully compatible
with your device. Using an incompatible memory card
may damage your device or the memory card and can
corrupt data stored on the card.
●
Your device supports only the FAT file structure for
memory cards. If you insert a card formatted with
a different file structure, your device will ask you to
reformat the memory card.
●
Frequent writing and erasing of data will shorten the
lifespan of memory cards.
●
When you insert a memory card in your device, the
file directory of the memory card will appear in the
extSdCard folder under the internal memory.
Open the cover of the memory card slot.
1
Insert a memory card with the gold-coloured contacts
2
facing down.
Push the memory card in the memory card slot until it
3
locks in place.
Close the memory card cover.
4
Assembling
17
Remove the memory card
›
Before removing a memory card, first unmount it for safe
removal.
Open the application list and select
1
→
Unmount SD card → OK.
Open the memory card cover.
2
Push the memory card gently until it disengages from the
3
device.
Remove the memory card.
4
Close the memory card cover.
5
Do not remove a memory card while the device is
transferring or accessing information, as this could
result in loss of data or damage to the memory card or
device.
Format the memory card
›
Formatting your memory card on a PC may cause
incompatibilities with your device. Format the memory card
only on the device.
Open the application list and select Settings
→
Format SD card
Format SD card → Erase everything.
Settings → Storage
→
Storage →
Before formatting the memory card, remember to make
backup copies of all important data stored on your
device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
18
Getting started
Getting started
Turn your device on and off
To turn on your device, press and hold the Power key. If you
turn on your device for the first time, follow the on-screen
instructions to set up your device.
To turn off your device, press and hold the Power key and
→
select Power off
●
Follow all posted warnings and directions from
authorised personnel in areas where the use of
wireless devices is restricted, such as aeroplanes and
hospitals.
●
To use your device’s non-network services only, switch
to Flight mode.
Switch to Flight mode
›
In Flight mode, you can disable all wireless connections and
use non-network services in areas where wireless devices are
prohibited, such as aeroplanes and hospitals.
To activate or deactivate Flight mode, go to Settings
settings, and then check the check box next to Flight mode.
OK.
→
More
19
Getting started
Get to know your device
1
2
3
4
5
6
3
7
8
9
10
14
15
11
12
13
Device layout
›
20
Getting started
Number Function
1
2
3
4
5
6
7
8
9
10
1 1
12
13
14
15
Power/Reset/Lock key
Volume key
Speaker
Memory card slot
Multifunction jack
SIM card slot
Front camera lens
Ambient light sensor
Mouthpiece
Headset jack
1
Internal antenna
Rear camera lens
S Pen slot
IrLED
Flashbulb
1. Connecting a headset to your device improperly can damage
the headset jack or the headset.
21
Getting started
Keys
›
Key Function
Power/
Reset
Lock
Volume Adjust the device’s volume.
Indicator icons
›
Icons shown on the bottom of the screen may vary
depending on your region or service provider.
Icon Definition
No signal
Signal strength
GPRS network connected
EDGE network connected
Turn on the device (press and hold);
Access the device options (press and
2
/
hold); Lock the touch screen; Reset the
device (press and hold for 8-10 seconds.)
UMTS network connected
Open Wi-Fi APs available
Wi-Fi AP connected
Bluetooth activated
GPS activated
Call in progress
2. If your device has fatal errors or hang-ups, or freezes, you may
need to reset the device to regain functionality.
22
Getting started
Icon Definition
Call on hold
Missed call
Uploading data
Downloading data
Call diverting activated
Connected to PC
USB tethering activated
Wi-Fi tethering activated
New text or multimedia message
New email message
New Google Mail
New voice mail message
Alarm activated
Event notification
Roaming (outside of normal service area)
Smart stay activated
Flight mode activated
Music playback in progress
Error occurred or caution required
S Pen removed
Battery power level
10:00 AM
3. If you use a charger that is not approved by Samsung, this
indicator will not appear.
Current time
3
23
Getting started
Use the S Pen and the touch screen
Your device’s touch screen lets you easily select items or
perform functions. Learn basic actions for using the touch
screen.
●
Do not press the touch screen with your fingertips,
or use sharp tools on the touch screen. Doing so may
damage the touch screen or cause it to malfunction.
●
Do not allow the touch screen to come into contact
with other electrical devices. Electrostatic discharges
can cause the touch screen to malfunction.
●
Do not allow the touch screen to come into contact
with water. The touch screen may malfunction in
humid conditions or when exposed to water.
●
Leaving the touch screen idle for extended periods
may result in afterimages (screen burn-in) or ghosting.
Turn off the touch screen when you do not use the
device.
●
Do not bend the S Pen.
●
Do not use the S Pen near by a source of magnetic
interference. It may cause the S Pen to malfunction or
freeze.
●
For optimal use of the touch screen, remove the
screen protection film before using your device.
●
You can purchase a replacement S Pen from your
local Samsung dealer.
●
If your S Pen is not working properly, replace the tip of
the S pen or take it to a Samsung Service Centre.
●
For best results, keep the S Pen mostly perpendicular
to the touch screen and avoid using it at sharp angles.
24
Getting started
Control your touch screen with the following actions:
●
Tap: Touch once with your finger or the supplied S Pen to
select or launch a menu, option, or application.
●
Tap and hold: Tap an item and hold it for more than
2 seconds to open a list of options.
●
Drag: Tap and drag your finger up, down, left, or right to
move to items on lists.
●
Drag and drop: Tap and hold your finger on an item, and
then drag your finger to move the item.
●
Double-tap: Tap twice quickly with your finger to zoom in
or out while viewing photos or web pages.
Rotate the touch screen
›
Your device has a built-in motion sensor that detects its
orientation. If you rotate the device, the interface will
automatically rotate according to the orientation.
To set the interface to keep the orientation, select the right
side of the system bar, and then select Screen rotation on
the notifications panel.
Lock or unlock the touch screen
›
When you do not use the device for a specified period, your
device turns off the touch screen and automatically locks the
touch screen to prevent any unwanted device operations. To
manually lock the touch screen, press the Power key.
To unlock, turn on the screen by pressing the Power key, tap
anywhere on the screen, and then flick your finger in any
direction.
You can activate the screen lock feature to prevent
others from using or accessing your personal data and
information saved in your device.
► p. 35
25
Getting started
Get to know the Home screen
2
1
4
3
When the device is in Idle mode, you will see the Home
screen. From the Home screen, you can view indicator icons,
widgets, shortcuts to applications, and other items. Scroll left
or right to a panel of the Home screen.
The above screen may differ depending on your region
or service provider.
Number Function
1
2
3
4
Select a dot at the top of the screen to move
directly to the corresponding screen.
Search for applications and files in your device
and specific data on the web with the Google
Search widget.
Access the application list.
System bar (See the following section.)
26
Getting started
System bar
From the system bar, you can quickly navigate screens, access
applications, view system information, and more.
Number Function
Capture the current screen; Capture the
1
current screen and open the drawing pad (tap
and hold). This can be changed to another
feature.
► p. 163
2
3
4
5
6
Add an application shortcut on the Home
›
Return to the previous screen.
Return to the Home screen; Access the Google
search widget or Google Now (tap and hold).
Open the list of recent application.
Display indicator icons and your device’s
current status; Open the notifications panel.
Open Multi Window panel.
screen
Open the application list and tap and hold an application
1
icon.
Move the icon to the location you want or move it to
2
another panel of the Home screen.
27
Getting started
Add a widgets on the Home screen
›
Widgets are small applications that provide convenient
functions and information on your Home screen.
●
Some widgets connect to web services. Using a webbased widget may result in additional charges.
●
The widgets available may vary depending on your
region or service provider.
Open the application list and select
1
widget panel.
Scroll left or right on the widget panel.
2
Tap and hold a widget to add it to the Home Screen.
3
Move an item on the Home screen
›
Tap and hold an item to move until the Home screen grid
1
appears.
Drag the item to the location you want.
2
Remove an item on the Home screen
›
Tap and hold an item to remove.
1
The rubbish bin appears at the top of the Home screen.
Drag the item to the rubbish bin.
2
When the rubbish bin turns red, release the item.
3
Widgets to open the
28
Getting started
Add or remove a panel from the Home screen
›
You can add or remove Home screen panels to organise
widgets.
On the Home screen, place two fingers on the screen and
1
pinch them together to switch to Edit mode.
Add, remove, or reorganise panels:
2
To add a new panel, select ●.
●
To remove a panel, tap and hold the panel’s thumbnail
image, and then drag it to the rubbish bin.
●
To set a panel for the default Home screen, select
●
To change the order of panels, tap and hold the panel’s
thumbnail image, and then drag it to a new location.
.
Select
3
Launch Multi Window applications
›
Applications launched from the Multi Window panel appear
in smaller windows, which are movable and can be increased
and decreased.
Select
1
panel.
Select an application to launch it.
2
●
To move the application to another location, tap and
hold the application’s title and drag it to a new location.
●
To maximise the window to fit the screen, select
●
To make the application stay always on the top, select
.
●
To close the application, select
to return to the previous screen.
on the system bar to open the Multi Window
.
or .
29
Getting started
●
To display two different Multi Window applications side
by side in full screen, select Dual view. You can switch
the positions of the two applications by tapping and
holding an application’s title bar, and then dragging it
on the other application.
●
To arrange launched Multi Window applications in
overlaid windows, select Cascade view.
Configure Multi Window applications
Select 1 on the system bar to open the Multi Window
panel.
2
Select
Edit.
The upper panel displays the list of applications that can
launch as Multi Window applications, while the lower
panel displays the list of applications that are added to the
Multi Window panel.
●
To add an application to the Multi Window panel, select
an item from the upper panel.
●
To remove an application from the Multi Window panel,
select an item from the lower panel.
When you are finished, select
3
Done.
30
Getting started
Use the notifications panel
›
From the Home screen or while using an application, select
the right side of the system bar, and then select an option on
the notifications panel.
You can view the device’s current status and use the following
options:
●
●
●
: Activate or deactivate the Wi-Fi feature.
Wi-Fi
GPS
: Activate or deactivate the GPS feature.
Sound
: Activate or deactivate Silent mode. You can vibrate
or mute your device in Silent mode.
●
Screen rotation
●
Bluetooth
●
Mobile data
●
Blocking mode
: Activate or deactivate the auto rotation.
: Activate or deactivate the Bluetooth feature.
: Activate or deactivate the data connection.
: Activate or deactivate Blocking mode. In
Blocking mode, your device will block all notifications.
●
Power saving
●
AllShare Cast
●
Sync
: Activate or deactivate auto-syncing of applications.
: Activate or deactivate Power saving mode.
: Activate or deactivate AllShare Cast feature.
Available options may vary depending on your region
or service provider.
Loading...
