Samsung GT-I9230 User Guide

User Manual

GT-I9230

www.samsung.com

About this manual

This device provides high quality mobile communication and entertainment using Samsung’s high standards and technological expertise. This user manual is specially designed to detail the device’s functions and features.

•

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Images and screenshots may differ in appearance from the actual product.

•

Content may differ from the final product, or from software provided by service providers or carriers, and is subject to change without prior notice. For the latest version of the manual, refer to the Samsung website,

•

Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Applications related to the content may not work properly depending on the device’s specifications and the environment that it is used in.

•

Available features and additional services may vary by device, software, or service provider.

•

Applications and their functions may vary by country, region, or hardware specifications. Samsung is not liable for performance issues caused by applications from any provider other than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or applications to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal

www.samsung.com

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services. To avoid additional charges, select an appropriate data tariff plan. For details, contact your service provider.

About this manual

•

Default applications that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an application provided with the device, contact a Samsung Service Centre. For user-installed applications, contact service providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Note: notes, usage tips, or additional information

This guide is protected under international copyright laws.

No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics.

About this manual

Trademarks

•

SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.

•

Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.

•

Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi CERTIFIED™, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance.

•

All other trademarks and copyrights are the property of their respective owners.

Table of Contents

Getting started

7 Device layout

9 Buttons

10 Package contents

11 Installing the SIM or USIM card

12 Installing the battery

14 Charging the battery

17 Inserting a memory card

19 Turning the device on and off

19 Holding the device

20 Locking and unlocking the device

20 Adjusting the volume

20 Switching to silent mode

40 Connecting to a Wi-Fi network

41 Setting up accounts

42 Transferring files

43 Securing the device

45 Upgrading the device

Communication

46 Phone

52 Contacts

56 Messaging

57 Email

58 Google Mail

60 Hangouts

60 Google+

Basics

21 Indicator icons

22 Using the touch screen

26 Control motions

30 Notifications

31 Home screen

34 Locked screen

35 Using applications

35 Applications screen

36 Help

37 Entering text

61 Messenger

61 ChatON

Web & network

62 Internet

63 Chrome

64 Bluetooth

65 Group Play

67 NFC

68 S Beam

Table of Contents

Media

69 Music

71 Camera

77 Gallery

80 Video

81 YouTube

83 FM Radio

Application & media stores

85 Play Store

86 Samsung Apps

86 Play Books

87 Play Movies

Travel & local

100 Maps

100 Local

101 Navigation

Settings

102 About Settings

102 Connections

105 My device

116 Accounts

117 More

120 Google Settings

Utilities

88 Memo

89 S Planner

91 Dropbox

91 Cloud

92 Clock

94 Calculator

94 Voice Recorder

95 S Voice

97 Google

98 Voice Search

98 My Files

99 Downloads

Troubleshooting

Getting started

Proximity/Light sensor

Device layout

Earpiece

Front camera

Internal touch screen

Confirm button

Menu button

Home button

Dial button

Delete button

Alphanumeric buttons

Memory card slot

Navigation button

Back button

Multipurpose jack

Lock button

Camera button

Power/End button

Microphone

Silent mode button

Getting started

Back button

Home button

External touch screen

Flash

Rear camera

Menu button

SIM card slot

Volume button

GPS antenna

Back cover

Speaker

Main antenna

•

Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery.

•

Do not use a screen protector. This causes sensor malfunctions.

•

Do not allow water to contact the touch screen. The touch screen may malfunction in humid conditions or when exposed to water.

Getting started

Buttons

Button Function

•

Press and hold to turn the device on or off.

•

Press to end a call.

Power/End

Home

Back

Navigation

Confirm

•

Press and hold for more than 7 seconds to reset the device if it has fatal errors or hang-ups, or freezes.

•

Press to return to the previous screen.

•

Tap to open a list of options available for the current screen.

•

Tap and hold on the Home screen to launch Google search.

•

Tap to return to the Home screen.

•

Tap and hold to open the list of recent applications.

•

Tap to return to the previous screen.

•

Press to scroll through options.

•

Press to select the highlighted option or confirm an input.

Camera

Dial

Delete

Alphanumeric

Silent mode

•

Press to launch

•

Press to take photos or videos in camera mode.

•

Press to make or answer a call.

•

Press to view the history of incoming and outgoing calls and messages.

•

Press in a text field to delete a preceding character.

•

Press to enter characters, numbers, and symbols.

•

Press and hold the 1 button on the Home screen to access voicemails.

•

Press and hold on the Home screen to switch to silent mode.

Camera

Getting started

Button Function

Volume

Lock

•

Press to adjust the device volume.

•

Press to lock or unlock the device. The device goes into lock mode when the touch screen turns off.

Package contents

Check the product box for the following items:

•

Device

•

Battery

•

Quick start guide

•

The items supplied with the device and any available accessories may vary depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.

•

Other accessories may not be compatible with your device.

•

Use only Samsung-approved accessories. Malfunctions caused by using unapproved accessories are not covered by the warranty service.

•

Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Getting started

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

Only microSIM cards work with the device.

Open the cover of the SIM card slot.

Insert the SIM or USIM card with the gold-coloured contacts facing downwards.

Push the SIM or USIM card into the slot until it locks in place.

•

Do not insert a memory card into the SIM card slot. If a memory card happens to be lodged in the SIM card slot, take the device to a Samsung Service Centre to remove the memory card.

•

Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.

Close the cover of the SIM card slot.

Getting started

Removing the SIM or USIM card

Open the cover of the SIM card slot.

Push the SIM or USIM card until it disengages from the device, and then pull it out.

Close the cover of the SIM card slot.

Installing the battery

Remove the back cover.

Getting started

Be careful not to damage your fingernails when you remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

Insert the battery.

Do not remove the protective tape covering the antenna, as this can damage the antenna.

Replace the back cover.

Getting started

Removing the battery

Remove the back cover.

Pull out the battery.

Charging the battery

Use the charger to charge the battery before using it for the first time. A computer can be also used to charge the device by connecting them via the USB cable.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.

Getting started

Charging with the charger

Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into the multipurpose jack.

Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.

•

The device can be used while it is charging, but it may take longer to fully charge the battery.

•

If the device receives an unstable power supply while charging, the touch screen may not function. If this happens, unplug the charger from the device.

•

While charging, the device may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.

•

If the device is not charging properly, take the device and the charger to a Samsung Service Centre.

Getting started

After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket.

Do not remove the battery before removing the charger. This may damage the device.

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

Checking the battery charge status

When you charge the battery while the device is off, the following icons will show the current battery charge status:

Charging Fully charged

Reducing the battery consumption

Your device provides options that help you save battery power. By customising these options and deactivating features in the background, you can use the device longer between charges:

•

When you are not using the device, switch to sleep mode by pressing the Lock button.

•

Close unnecessary applications with the task manager.

•

Deactivate the Bluetooth feature.

•

Deactivate the Wi-Fi feature.

•

Deactivate auto-syncing of applications.

•

Decrease the backlight time.

•

Decrease the brightness of the display.

Getting started

Inserting a memory card

Your device accepts memory cards with maximum capacities of 64 GB. Depending on the memory card manufacturer and type, some memory cards may not be compatible with your device.

•

Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports only the FAT file system for memory cards. When inserting a card formatted in a different file system, the device asks to reformat the memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory appears in the

Open the cover of the memory card slot.

Insert a memory card with the gold-coloured contacts facing downwards.

Push the memory card into the slot until it locks in place.

SD memory card

folder.

Close the cover of the memory card slot.

Getting started

Removing the memory card

Before removing the memory card, first unmount it for safe removal. On the Home screen, tap

Apps

→

Settings

Open the cover of the memory card slot.

Push the memory card until it disengages from the device, and then pull it out.

Close the cover of the memory card slot.

Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.

→

Storage

→

Unmount SD card

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.

On the Home screen, tap

Format SD card

Before formatting the memory card, remember to make backup copies of all important data stored on the device. The manufacturer’s warranty does not cover loss of data resulting from user actions.

→

Erase everything

Apps

→

Settings

→

Storage

→

Format SD card

→

Getting started

Turning the device on and off

When turning on the device for the first time, follow the on-screen instructions to set up your device.

Press and hold the Power button for a few seconds to turn on the device.

•

Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.

•

Press and hold the Power button and tap features.

To turn off the device, press and hold the Power button, and then tap

Flight mode

to disable the wireless

Power off

Holding the device

Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery.

Getting started

Locking and unlocking the device

When not in use, lock the device to prevent unwanted operation. Pressing the Lock button turns off the screen and puts the device into lock mode. The device automatically gets locked if it is not used for a specified period.

To unlock the device, press the Lock button and flick your finger in any direction within the unlock screen area at the lower part of the screen.

Adjusting the volume

Press the Volume button up or down to adjust the ringtone volume, or to adjust the sound volume when playing music or video.

Switching to silent mode

Use one of the following methods:

•

Press and hold the Volume button down until it switches to silent mode.

•

Press and hold the Power button, and then tap

•

Open the notifications panel at the top of the screen, and then tap

Mute

Vibrate

Sound

Vibrate

Basics

Indicator icons

The icons displayed at the top of the screen provide information about the status of the device. The icons listed in the table below are most common.

Icon Meaning

No signal

Signal strength

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

Wi-Fi connected

Bluetooth feature activated

GPS activated

Call in progress

Missed call

Synced with the web

Connected to computer

No SIM or USIM card

New text or multimedia message

Basics

Icon Meaning

Alarm activated

Mute mode activated

Vibration mode activated

Flight mode activated

Error occurred or caution required

Battery power level

Using the touch screen

Use only fingers to use the touch screen.

•

Do not allow the touch screen to come into contact with other electrical devices. Electrostatic discharges can cause the touch screen to malfunction.

•

To avoid damaging the touch screen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

•

Leaving the touch screen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touch screen when you do not use the device.

Basics

Finger gestures

Tapping

To open an application, to select a menu item, to press an on-screen button, or to enter a character using the on-screen keyboard, tap it with a finger.

Tapping and holding

Tap and hold an item for more than 2 seconds to access available options.

Basics

Dragging

To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the target position.

Double-tapping

Double-tap on a webpage or image to zoom in a part. Double-tap again to return.

Basics

Flicking

Flick left or right on the Home screen or the Applications screen to see another panel. Flick up or down to scroll through a webpage or a list, such as contacts.

Pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Basics

Control motions

Simple motions allow easy control of the device.

Before using motions, make sure the motion feature is activated. On the Home screen, tap

Apps

→

Settings

→

My device

→

Motions and gestures

, and then drag the

Motions and

gestures

switch to the right.

Excessive shaking or impact to the device may result in unintended inputs. Control motions properly.

Rotating the screen

Many applications allow display in either portrait or landscape orientation. Rotating the device causes the display to automatically adjust to fit the new screen orientation.

To prevent the display from rotating automatically, open the notifications panel and deselect

Screen rotation

•

Some applications do not allow screen rotation.

•

Some applications display a different screen depending on the orientation. The calculator turns into a scientific calculator when rotated to landscape.

Basics

Picking up

When you pick up the device after it has been idle for some time or when the screen has turned off, it vibrates if you have missed calls or new messages.

Holding to ear

While viewing call, message, or contact details, pick up and hold the device to your ear to make a call.

Basics

Panning to move

Tap and hold an item, and then move the device to the left or right to move the item to another panel on the Home screen or the Applications screen.

Panning to browse

When an image is zoomed in, tap and hold a point on the screen, and then move the device in any direction to browse the image.

Basics

Turning over

Turn over the device to mute ringtone, pause media playback, or mute the FM radio (when using the speaker).

Tilting

Tap and hold two points on the screen, and then tilt the device back and forth to zoom in or out.

Basics

Notifications

Notification icons appear on the status bar at the top of the screen to report missed calls, new messages, calendar events, device status, and more. Drag down from the status bar to open the notifications panel. Scroll the list to see additional alerts. To close the notifications panel, drag up the bar that is at the bottom of the screen.

From the notifications panel, you can view your device’s current settings. Drag down from the status bar, and then tap

•

Wi-Fi

: Activate or deactivate the Wi-Fi feature.

•

GPS

: Activate or deactivate the GPS feature.

•

Sound

mode.

•

Screen rotation

•

Bluetooth

•

Mobile data

•

Blocking mode

will block notifications. To select which notifications will be blocked, tap

device

•

Power saving

•

Wi-Fi hotspot

•

S Beam

: Activate or deactivate silent mode. You can vibrate or mute your device in silent

: Allow or prevent the interface from rotating when you rotate the device.

: Activate or deactivate the Bluetooth feature.

: Activate or deactivate the data connection.

: Activate or deactivate blocking mode. In blocking mode, the device

→

Blocking mode

: Activate or deactivate power-saving mode.

: Activate or deactivate the Wi-Fi tethering feature.

: Activate or deactivate the S Beam feature.

to use the following options:

Settings

→

The available options may vary depending on the region or service provider.

To rearrange the options on the notifications panel, open the notifications panel, tap and then tap and drag an item to another location.

→ ,

+ 97 hidden pages
