Samsung I8510

Quick Start

Guide

Using this

guide

This Quick Start Guide has
been specially designed to

guide you through the functions

and features of your device.

2

Instructional icons

Before you start, familiarise yourself with the icons you will
see in this guide:

Warning

: situations that could cause injury to yourself

or others

Caution

: situations that could cause damage to your

device or other equipment

Note

: notes, usage tips, or additional information

X

Refer to

: pages with related information; for example:

X

p. 12 (represents "see page 12")

→

Followed by

select to perform a step; for example: Press [Menu] →
Messaging → New message (represents [Menu],
followed by Messaging, followed by New message)

[]

Square brackets

(represents the End/Power key)

<>

Angled brackets

functions at each screen; for example: <OK>
(represents the OK softkey)

: the order of options or menus you must

: device keys; for example [ ]

: softkeys that control different

Safety and

usage

information

Comply with the following

precautions to avoid dangerous

or illegal situations and ensure

peak performance of your

device.

Safety warnings

Keep your device away from small children and
pets

Keep your device and all accessories out of the reach of
small children or animals. Small parts may cause choking
or serious injury if swallowed.

Protect your hearing

Listening to a headset at high volumes can
damage your hearing. Use only the minimum
volume setting necessary to hear your
conversation or music.

Install mobile devices and equipment with
caution

Ensure that any mobile devices or related equipment
installed in your vehicle are securely mounted. Avoid
placing your device and accessories near or in an air bag
deployment area. Improperly installed wireless equipment
can cause serious injury when air bags inflate rapidly.

3

Safety and usage i nformation

Handle and dispose of batteries and
chargers with care

• Use only Samsung-approved batteries
and chargers specifically designed for
your device. Incompatible batteries and
chargers can cause serious injuries or
damage to your device.

• Never dispose of batteries in a fire. Follow
all local regulations when disposing used
batteries.

• Never place batteries or phones on or in
heating devices, such as microwave
ovens, stoves, or radiators. Batteries may
explode when overheated.

4

Avoid interference with pacemakers

Maintain a minimum of 15 cm (6 inches)
between mobile devices and pacemakers to
avoid potential interference, as
recommended by manufacturers and the
independent research group, Wireless
Technology Research. If you have any
reason to suspect that your device is
interfering with a pacemaker or other medical
equipment, turn off the device immediately
and contact the manufacturer of the
pacemaker or medical equipment for
guidance.

Turn off the device in potentially
explosive environments

Do not use your device at refuelling points
(service stations) or near fuels or chemicals.
Turn off your device whenever directed by
warning signs or instructions. Your device
could cause explosions or fire in and around
fuel or chemical storage and transfer areas
or blasting areas. Do not store or carry
flammable liquids, gases, or explosive
materials in the same compartment as the
device, its parts, or accessories.

Reduce the risk of repetitive motion
injuries

When sending text messages or playing
games on your device, hold the device with
a relaxed grip, press the keys lightly, use
special features that reduce the number of
keys you have to press (such as templates
and predictive text), and take frequent
breaks.

Safety precautions

Drive safely at all times

Avoid using your device while driving and
obey all regulations that restrict the use of
mobile devices while driving. Use hands-free
accessories to increase your safety when
possible.

Follow all safety warnings and
regulations

Comply with any regulations that restrict the
use of a mobile device in a certain area.

Use only Samsung-approved
accessories

Using incompatible accessories may
damage your device or cause injury.

5

Safety and usage i nformation

Turn off the device near medical
equipment

Your device can interfere with medical
equipment in hospitals or health care
facilities. Follow all regulations, posted
warnings, and directions from medical
personnel.

Turn off the device or disable the
wireless functions when in an
aircraft

Your device can cause interference with
aircraft equipment. Follow all airline
regulations and turn off your device or switch
to a mode that disables the wireless
functions when directed by the airline
personnel.

6

Protect batteries and chargers from
damage

• Avoid exposing batteries to very cold or
very hot temperatures (below 0° C/32° F
or above 45° C/113° F). Extreme
temperatures can reduce the charging
capacity and life of your batteries.

• Prevent batteries from contacting metal
objects, as this can create a connection
between the + and - terminals of your
batteries and lead to temporary or
permanent battery damage.

• Never use a damaged charger or battery.

• Risk of explosion if a battery or device is
replaced by an incorrect type. Dispose of
used batteries or devices according to the
instructions.

Handle your device carefully and
sensibly

• Do not allow your device to get wet—
liquids can cause serious damage. Do not
handle your device with wet hands. Water
damage to your device can void your
manufacturer’s warranty.

• Avoid using or storing your device in
dusty, dirty areas to prevent damage to
moving parts.

• Your device is made of complex
electronics—protect it from impacts and
rough handling to avoid serious damage.

• Do not paint your device, as paint can
clog moving parts and prevent proper
operation.

• Avoid using the device’s camera flash or
light close to the eyes of children or
animals.

• Your device and memory cards may be
damaged by exposure to magnetic fields.
Do not use carrying cases or accessories
with magnetic closures or allow your
device to come in contact with magnetic
fields for extended periods of time.

Avoid interference with other
electronic equipment

Your device emits radio frequency (RF)
signals that may interfere with unshielded or
improperly shielded electronic equipment,
such as pacemakers, hearing aids, and
medical equipment in homes or vehicles.
Consult the manufacturers of your electronic
equipment to solve any interference
problems you experience.

7

Safety and usage i nformation

Important usage
information

Use your device in the normal
position

Avoid contact with your device’s internal
antenna.

Allow only qualified personnel to
service your device

Allowing unqualified personnel to service
your device may result in damage to your
device and will void your warranty.

Ensure maximum battery and
charger life

• Avoid charging batteries for more than a
week, as overcharging may shorten
battery life.

• Over time, unused batteries will discharge
and must be recharged before use.

8

• Disconnect chargers from power sources
when not in use.

• Use batteries only for their intended
purpose.

Handle SIM cards and memory
cards with care

• Do not remove a card while the device is
transferring or accessing information, as
this could result in loss of data and/or
damage to the card or device.

• Protect cards from strong shocks, static
electricity, and electrical noise from other
equipment.

• Frequent writing and erasing will shorten
the life span of memory cards.

• Do not touch gold-coloured contacts or
terminals with your fingers or metal
objects. If dirty, wipe the card with a soft
cloth.

Ensure access to emergency
services

Emergency calls from your device may not
be possible in some areas or circumstances.
Before travelling in remote or undeveloped
areas, plan an alternate method of
contacting emergency services personnel.

Specific Absorption Rate (SAR)
certification information

Your device conforms to European Union
(EU) standards that limit human exposure to
radio frequency (RF) energy emitted by radio
and telecommunications equipment. These
standards prevent the sale of mobile devices
that exceed a maximum exposure level
(known as the Specific Absorption Rate, or
SAR) of 2.0 watts per kilogram of body
tissue.

During testing, the maximum SAR recorded
for this model was 0.414 watts per kilogram.
In normal use, the actual SAR is likely to be
much lower, as the device has been
designed to emit only the RF energy
necessary to transmit a signal to the nearest
base station. By automatically emitting lower
levels when possible, your device reduces
your overall exposure to RF energy.

The Declaration of Conformity at the back of
this manual demonstrates your device’s
compliance with the European Radio &
Terminal Telecommunications Equipment
(R&TTE) directive. For more information
about the SAR and related EU standards,
visit the Samsung mobile phone website.

9

Safety and usage i nformation

Correct disposal of this product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union
and other European countries with
separate collection systems)

This marking shown on the product

or its literature, indicates that it
should not be disposed with other
household wastes at the end of its working
life.

To prevent possible harm to the environment
or human health from uncontrolled waste
disposal, please separate this from other
types of wastes and recycle it responsibly to
promote the sustainable reuse of material
resources.

10

Household users should contact either the
retailer where they purchased this product,
or their local government office, for details of
where and how they can take this item for
environmentally safe recycling.

Business users should contact their supplier
and check the terms and conditions of the
purchase contract. This product should not
be mixed with other commercial wastes for
disposal.

This EEE is compliant with RoHS.

Welcome

This Quick Start Guide will help

you assemble your Smartphone

and learn basic procedures. To

learn additional procedures,

Samsung I8510 user manual.

please refer to the

Topics in the Quick Start Guide include:

• Unpack

• Get to know your device

• Assemble and prepare your device

• Turn on your device for the first time

• Use basic call functions

• Enter text

• Work with applications

• Use basic camera functions

• Listen to music

• Customise your device

• View the electronic version of the user manual

Unpack

Your package contains the

following items:

• Smartphone

• Headset

•Battery

• Quick Start Guide

• Travel adapter (charger)

• PC data cable

• Samsung PC Studio CD

The items supplied with your phone may vary depending
on the software and accessories available in your region
or offered by your service provider.

11

Front view

Get to know

your device

12

Earpiece

4-way

navigation key

Tra ck pa d/

Confirm key

Volume key

Left softkey

Menu key

Tal k k ey

Multifunction jack

User defined key 1

Delete key

Mouthpiece

Front camera
lens

Display

Right softkey

Gallery key

End/Power key

User defined key 2

Alphanumeric
keys

Special function
keys

Rear view Keys

Key Function

Rear camera

Flashbulb

Camera mode

switch

Memory card

slot

Camera key

Internal antenna

lens

Speaker

Battery cover

Perform actions indicated at the
bottom of the display

Open the main menu; Show all
active applications (press and
hold)

Move through lists or menus;
Move the cursor up, down, left,
or right

Move the cursor (drag your
finger across the trackpad);
Confirm your selection or
execute the selected application

Open the gallery menu

13

Get to know your device

Key Function

Make or answer a call; In
Standby mode, access call logs

Turn the device on or off (press
and hold); Access the Quick
Menu;
End a call; Exit an application

Open the defined application

Delete

Open the defined application

Enter numbers and characters;
In Standby mode, press and
hold [1] to access voice mail

Enter an international call prefix
or pause; Display a list of
symbols

14

Key Function

Change the text input mode;
Change character case; In
Standby mode, activate or
deactivate Silent profile (press
and hold)

In Standby mode, adjust key
volume; During a call, adjust
earpiece volume; During an
incoming call, adjust ringtone
volume

In Camera mode, switch
between Camera mode,
Camcorder mode, and Quick
View mode

Turn on the camera (press and
hold); In Camera mode, take a
photo or record a video

Icons

Icon Definition

Signal strength (GSM/GPRS

network)

Signal strength (WCDMA network)

Signal strength (HSDPA network)

Alarm activated

New text message

New voice mail message

New email message

Sending a message

Call diverting active (if you have

multiple lines, a number will indicate

which line is diverted)

Active phone line 2

Missed call

Bluetooth activated

Icon Definition

Stereo headset connected

Mono headset connected

Connected to computer

In Home Zone service area

Keypad locked

Memory card inserted

Battery power level

15

Assemble

and prepare

your device

16

Insert the SIM card and battery

1. Remove the battery cover.

2. Insert the SIM card.

Insert the card with the gold-coloured contacts facing the
device.

3. Insert the battery.

4. Replace the battery cover.

Charge the battery

1. Open the cover to the multifunction jack
on the side of the device.

2. Plug the small end of the travel adapter
into the device.

3. Plug the large end of the travel adapter
into a power outlet.

4. When charging is finished, unplug the
travel adapter from the power outlet.

5. Remove the travel adapter from the
device.

17

Assemble and prepare your device

Insert a memory card (optional)

By inserting a memory card, you can store
multimedia files and messages or back up
your important information. Your phone
accepts microSD™ memory cards up to 8
GB (depending on memory card
manufacturer and type).

1. Open the cover to the memory card slot
on the side of the device.

2. Insert a memory card into the memory
card slot with the label facing down.

18

3. Push the memory card into the memory
card slot until it locks (clicks) in place.

4. Close the cover to the memory card slot.

Follow these steps when removing a
memory card

Carefully follow the steps below when
removing a memory card to avoid data
loss or damage to the memor y card.

1. Press and hold [ ] and select

Remove F: memory card

Yes

2. Press <

3. Open the cover to the memory card
slot and gently push the memory card
in until it disengages (clicks) from the
device.

4. Pull the memory card out of the
memory card slot.

5. Press <

If you must reboot the device to finish
installing an application, do not remove
the memory card until the reboot is
complete. Otherwise, your application
files may be corrupted or erased.

> to confirm.

OK

>.

.

Turn on your

device for

the first time

1. Press and hold [ ] to turn on your device.

2. Follow the onscreen instructions to set the region, city,
current time, and the date. Your device will
automatically connect to the cellular network.

Unlock the external keys

When you close your device, it automatically locks the
external keys. To unlock the keys, press <Unlock> and
then press the Confirm key.

19

Use basic

Make a voice call

1. In Standby mode, enter an area code and phone
number.

2. Press [ ] to dial the number.

3. To end the call, press [ ].

call functions

20

Make a video call

1. In Standby mode, enter an area code and phone
number.

2. Press <Options> → Call → Video call to dial the
number.

3. To end the call, press [ ].

Answer a call

1. When a call comes in, press [ ].

2. To end the call, press [ ].

Enter text

Change the text input mode

Press [ ] to switch between the following text input
modes:

• Predictive mode (initial capital)

• Predictive mode (lower case)

• Normal mode (initial capital)

• Normal mode (lower case)

• Number mode

To access symbols, press [ ].

21

Enter text

Enter text in Predictive mode

In Predictive mode, your device attempts to
predict the word you are entering to save
you time and keystrokes.

To enter a word in Predictive mode,

1. Press each alphanumeric key one time
only for each letter needed.

2. Type the complete word before
confirming that the device has predicted it
properly. The device will actively attempt
to predict words, so the correct word
may not appear until you have entered it
completely.

3. If the device shows the correct word,
press [0] to confirm the word.

4. If the device shows an incorrect word,
press [ ] to view other words that match
your entry, or add a word to the dictionary
(see the next section).

22

Add a word to the dictionary

When using Predictive mode, you can add
new words to the dictionary.

1. Press <Spell>.

2. Enter the word in normal mode and press
<OK> to confirm.

Work with

Open applications or folders

1. In Standby mode, press [Menu].

2. Scroll to an application and press the Confirm key.

Refer to the user manual to learn more about viewing and
managing documents with your device.

applications

Switch applications

Your device allows you to multi-task by running multiple
applications at the same time.

To switch from one active application to another,

1. Press and hold [Menu] to open a list of applications.

2. Scroll to an application and press <Select>.

23

Work with applications

Close applications

To close the current application, press
[ ].

To close an application that is running in the
background,

1. Press and hold [Menu] to open a list of
applications.

2. Scroll to an application and press [C].

3. Press <Yes> to close the application.

24

Use basic

Capture a photo

1. Press and hold the Camera key to turn on the camera.

2. Rotate the device 90° anti-clockwise (to the left).

3. Aim the lens at the subject and make any adjustments.

4. Press the Camera key to capture the image.

camera

functions

Do not manually open or
impact the lens cap to
prevent damage to the
lens cap or camera.

View a photo

1. In Standby mode, press [Menu] → Media → Gallery →
Images.

2. Scroll to an image and press the Confirm key.

25

Use basic camera functions

Record a video

1. Press and hold the Camera key to turn on
the camera.

2. Rotate the device 90o anti-clockwise (to
the left).

3. Slide the Camera mode switch to [ ].

4. Aim the lens at the subject and make any
adjustments.

5. Press the Camera key to begin recording.

6. Press < > or the Camera key to stop
recording.

26

Play a video

1. In Standby mode, press [Menu] → Media

→

Gallery → Video clips.

2. Scroll to a video and press the Confirm
key.

Listen to

music

Use your device to play MP3,

AAC, or WMA music files.

Add music files to your device

Use the following methods to add music files to your
device:

• Download files from a PC, using the supplied Samsung
PC Studio software

• Copy files to a memory card and insert the card into the
device

• Download files from the wireless web (see the user
manual)

• Receive via Bluetooth (see the user manual)

Play music files

1. In Standby mode, press [Menu] → Media → Music

player.

2. Press <Options> → Refresh library.

3. Select a playlist.

4. Scroll to a file and press the Confirm key.

27

Listen to music

5. Use the following during playback:

Key Function

Confirm

Navigation
(Down)

Navigation
(Left)

Pause or resume playback

Stop playback

Restart playback; Skip
backward (press within 3
seconds); Scan backward
(press and hold)

Navigation
(Right)

Volume

Skip forward; Scan forward
(press and hold)

Adjust the volume up or down

28

Customise

your device

Your device includes preset

profiles that control ringtones,

key tones, and alerts and

themes that control skins,

wallpaper, and menu layouts.

You can activate profiles for

different situations, personalise

profiles, apply themes, and

download new themes from the

web.

Activate a profile

1. In Standby mode, press [Menu] → Settings →

Profiles.

2. Scroll to a profile and press <Options> → Activate.

In Standby mode, the current profile is shown at the top
of the display (except for the General profile). To quickly
change profiles, press and hold [ ] and select a
different profile.

Personalise a profile

1. In Standby mode, press [Menu] → Settings →

Profiles.

2. Press <Options> → Personalise.

3. Change the settings as desired.

4. When you are finished personalising the profile, press

<Back>.

29

Customise your device

Apply a theme

1. In Standby mode, press [Menu] →
Settings → Themes.

2. Scroll to a category and press the
Confirm key:

• General - choose a skin for your
display.

• Menu view - choose a layout of the
display.

• Standby - choose shortcuts for
Standby mode.

• Wallpaper - choose a background
image for Standby mode.

• Call image - choose an image for
incoming calls.

3. Scroll to a theme or an image and press
the Confirm key.

30

Activate Etiquette pause

You can temporarily pause the music player
or mute calendar alarms by placing the
device face down when you activate
Etiquette pause. For calendar alarms,
Etiquette pause will activate the snooze
feature.

In Standby mode, press [Menu] → Settings

→

Settings → General → Personlisation

→

Tones → Etiquette mode → On.

View the
electronic
version of

the user

manual

For more information, view the Samsung I8510 user
manual. The manual is available on the Samsung website
(http://www.samsungmobile.com). The manual is available
as an Adobe Acrobat file (.pdf).

If you do not have Adobe Reader, you can download the
free programme at www.adobe.com.

31

ญ

Declaration of Conformity (R&TTE)

ଖ

ڈ
ڈ
ڈ
ڈ
ڈ

ڈ

ڈ

ڈ
ڈ
ڈ

We,

declare under our sole responsibility that the product

Samsung Electronics

GSM Mobile Phone : I8510

to which this declaration relates, is in conformity with the following standards and/or other normative
documents.

SAFETY EN 60950ڈ1 : 2001 +A11:2004

EN 301 489

01 V1.6.1 (09ڈ2005)
07 V1.3.1 (11ڈ2005)

EN 301 489

17 V1.2.1 (08ڈ2002)

EN 301 489

EMC

SAR

RADIO

We hereby declare that [all essential radio test suites have been carried out and that] the above named
product is in conformity to all the essential requirements of Directive 1999/5/EC.

The conformity assessment procedure referred to in Article 10 and detailed in Annex[

1999/5/EC has been followed with the involvement of the following Notified Body(ies):

BABT, Balfour House, Churchfield Road,

Walton-on-Thames, Surrey, KT12 2TD, UK

Identification mark: 0168

The technical documentation kept at :

Samsung Electronics QA Lab.

which will be made available upon request.

(Representative in the EU)

Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire,

2008.07.23

(place and date of issue) (name and signature of authorised person)

It is not the address of Samsung Service Centre. For the address or the phone number of Samsung

Service Centre, see the warranty card or contact the retailer where you purchased your product.

19 V1.2.1 (11ڈ2002)

EN 301 489

24 V1.3.1 (11ڈ2005)

EN 301 489

EN 50360 : 2001
EN 62209

1 : 2006

EN 301 511 V9.0.2 (03
EN 300 328 V1.7.1 (10

1 V3.2.1 (07ڈ2005)

EN 301 908
EN 301 908

2 V2.2.1 (10ڈ2003)

ଖ

GU46 6GG, UK

2003)

2006)

ଖ

Yong-Sang Park / S. Manager

ญ

]ofDirective

Some of the contents in this guide may differ from your device depending on the software of
the device or your service provider.

Printed in Korea

World Wide Web
http://www.samsungmobile.com

Code No.:GH68-19283A

English (EU). 04/2009. Rev. 2.2
