SAMSUNG GT-I5800L User Guide
I5800L_UG_EN_07132010_D3
GT-I5800L Series
PORTABLE Quad-BAND
MOBILE PHONE
User Manual
Please read this manual before operating your
phone, and keep it for future reference.
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the
SAMSUNG Phone, including but not limited to, accessories, parts, or software relating thereto (the “Phone System”), is proprietary to
Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and
other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that
you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the
Intellectual Property shall remain with SAMSUNG and its suppliers.
© 2010 Samsung Electronics Canada Inc. Samsung is a registered trademark of Samsung Electronics Co. Ltd. and its related entities.
Licensed by Qualcomm Incorporated under one or more of the following patents: U.S. Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5,
101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390.
Printed in South Korea
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered Trademark RSA Security, Inc.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
This product has an Android platform based on Linux, which can be expanded by a variety of JavaScript-based software.
GoogleTM, Android MarketTM, Google TalkTM, Google MailTM, Google MapsTM, and YouTubeTM are trademarks of Google, Inc.
JavaTM is a trademark of Sun Microsystems, Inc.
Windows Media Player® is a registered trademark of Microsoft Corporation.
from SRS Labs, Inc.
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance.
DivX® isa registered trademark of DivX, Inc., and is used under licence.
Pat. 7,295,673
and are trademarks of SRS Labs, Inc. CS Headphone and WOW HD technologies are incorporated under licence
About DivX Video
DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for
more information and software tools to convert your files into DivX video.
About DivX Video-on-Demand
This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code,
locate the DivX VOD section in the device setup menu. Go to http://vod.divx.com with this code to complete the registration process and learn
more about DivX VOD.
DivX is Certified to play DivX® video up to 320 x 240.
The privacy and copyright laws of Canada govern the disclosure, reproduction and distribution of data, media and other content, including
music and video content. Certain activities, including downloads or transfer by any means (including, via cable, Bluetooth® or otherwise) of
such content may be an infringement of privacy or copyright law. Neither Samsung Electronics Canada Inc. nor any of its affiliates shall be
liable or responsible for any data or content disclosed, reproduced, downloaded or distributed by the user of this equipment.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT,
THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT
OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED
PROFITS OR BENEFITS.
Table of Contents
Section 1: Important Safety Precautions ........................ 4
Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Road Safety at All Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Switch Off When Refueling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Switch Off in an Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Switch Off in Hospitals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Keep your phone away from small children and pets . . . . . . . . . 4
Protect your hearing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Install mobile phones and equipment with caution . . . . . . . . . . . 4
Avoid interference with pacemakers . . . . . . . . . . . . . . . . . . . . . . 5
Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Special Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reduce the risk of repetitive motion injuries . . . . . . . . . . . . . . . . 5
Do not use the phone if the screen is cracked or broken . . . . . . 5
Sensible Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Liquid Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Accessories and Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Handle and dispose of batteries and chargers with care . . . . . . . 6
Qualified Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Section 2: Assembling ...................................................... 7
Unpack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Attach a hand strap (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . . . . . .12
Lock or unlock the touch screen and keys . . . . . . . . . . . . . . . . .12
Section 3: Getting Started ............................................... 13
Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Back View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Using the Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the idle screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Use the shortcuts panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Add or remove panels from the idle screen . . . . . . . . . . . . . . . .19
Access applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Customise your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Protecting your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Enter text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Using Android Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Download files from the web . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Synchronize data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Google Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Section 4: Communication ............................................. 28
Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Google Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
1
Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Section 5: Entertainment .................................................37
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Video Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Section 6: Personal Information .....................................49
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Section 7: Web ..................................................................54
Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Layar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Daily Briefing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Samsung Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Section 8: Connectivity ....................................................59
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
AllShare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
PC Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
2
Section 9: Tools ............................................................... 64
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Voice Dialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Write and Go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Section 10: Settings ........................................................ 67
Wireless and network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Sound and display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Location and security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Accounts and sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
SD card and phone storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Locale and text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Accessibility settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Text-to-speech . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
About phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Section 11: Safety ............................................................ 74
Getting the Most Out of Your Reception . . . . . . . . . . . . . . . . . . 74
UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Using Your Phone While Driving . . . . . . . . . . . . . . . . . . . . . . . . 75
Caring for the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Acknowledging Special Precautions and Industry Canada Notice 78
Information to User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Section 12: Warranty ....................................................... 81
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Index .................................................................................. 85
3
Section 1: Important Safety Precautions
Important Safety Precautions
Please read these guidelines before using your wireless phone.
Failure to comply with them may be dangerous or illegal.
Road Safety at All Times
Do not use your phone while driving, park the vehicle first. Obey
all regulations that restrict the use of mobile phones while driving.
Use handsfree accessories to increase your safety when possible.
Switch Off When Refueling
Do not use your phone at refuelling points (service stations) or
near fuels or chemicals. Turn off your phone when directed to do
so by warning signs or instructions. Your phone could cause
explosions or fire in and around fuel or chemical storage and
transfer areas or blasting areas. Do not store or carry flammable
liquids, gases, or explosive materials in the same compartment as
the phone, its parts, or accessories.
Switch Off in an Aircraft
Wireless phones can cause interference. Using them in an aircraft
is both illegal and dangerous.
4
Switch Off in Hospitals
Switch your phone off near medical equipment. Follow any
regulations or rules in force in any area.
Keep your phone away from small children and pets
Keep your phone and all accessories out of the reach of small
children or animals. Small parts can cause choking or serious
injury if swallowed.
Protect your hearing
Excessive exposure to sound at high volumes can cause hearing
damage. Always turn the volume down before plugging the
earphones into an audio source and only use the minimum volume
setting necessary to hear your conversation or music.
Install mobile phones and equipment with caution
Ensure that any mobile phones or related equipment installed in
your vehicle are securely mounted. Avoid placing your phone and
accessories near or in an air bag deployment area. Improperly
installed wireless equipment can cause serious injury when air
bags inflate rapidly.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between mobile phones
and pacemakers to avoid potential interference, as recommended
by manufacturers and the independent research group, Wireless
Technology Research.
If you have any reason to suspect that your phone is interfering
with a pacemaker or other medical device, turn off the phone
immediately and contact the manufacturer of the pacemaker or
medical device for guidance.
Interference
All wireless phones might be subject to interference, which could
affect their performance.
Special Regulations
Follow any special regulations in force in any area and always
switch your phone off whenever it is forbidden to use it, or when it
might cause interference or danger (for example, in a hospital).
Reduce the risk of repetitive motion injuries
While using your phone, hold it with a relaxed grip, press the keys
lightly, use special features that reduce the number of keys you
have to press (such as templates and predictive text), and take
frequent breaks.
Do not use the phone if the screen is cracked or broken
Broken glass or acrylic could cause injury to your hand and face.
Bring the phone to a Samsung Service Centre to replace the
screen. Damage caused by careless handling will void your
manufacturer’s warranty.
Sensible Use
Use the phone in the intended position (held to the ear). If your
phone has an external antenna, avoid unnecessary contact with
the antenna when the phone is on.
Emergency Call
Ensure that the phone is switched on and in-service. Enter the
emergency number for your present location and select to
make the call. Give all the necessary information as accurately as
possible. Do not end the call until given permission to do so.
Liquid Resistance
Your phone is not liquid resistant. Keep it dry.
Accessories and Batteries
Use only Samsung-approved accessories and batteries. Use of
any unauthorized accessories could damage your phone and
might be dangerous.
Important Safety Precautions 5
Important!:
Although the phone can be used while the battery is charging, the
battery must be fully charged before first use, otherwise you could
damage the battery.
Important!:
Using a non-supported battery might damage your phone.
Handle and dispose of batteries and chargers with care
Use only Samsung-approved batteries and chargers specifically
designed for your phone. Incompatible batteries and chargers can
cause serious injuries or damage to your phone.
Never dispose of batteries or phones in a fire. Follow all local
regulations when disposing of used batteries or phones.
Never place batteries or phones on or in heating devices, such as
microwave ovens, stoves, or radiators. Batteries may explode
when overheated.
Never crush or puncture the battery. Avoid exposing the battery to
high external pressure, which can lead to an internal short circuit
and overheating.
Qualified Service
Only qualified service personnel may repair your phone.
For more detailed safety information, see “Safety” on page 74.
6
Section 2: Assembling
Unpack
Check that your product box contains the following items:
•
Mobile phone
•
Battery
•
Travel adapter (charger)
•
User manual
Note:
Use only Samsung-approved software. Pirated or illegal software might
cause damage or malfunctions that are not covered by your
manufacturer's warranty.
•
The items supplied with your phone might vary depending on the
software and accessories available in your region or offered by your
service provider.
•
You can obtain additional accessories from your local Samsung dealer.
Warnin g!:
If your phone has a touch screen display, please note that a touch
screen responds best to a light touch from the pad of your finger or
a non-metallic stylus. Using excessive force or a metallic object
when pressing on the touch screen might damage the tempered
glass surface and void the warranty. For more information, refer to
“Standard Limited Warranty” on page 81.
Setting Up Your Phone
Install the SIM card and batter y
Before using your phone you need to correctly install the battery
and the SIM card. The microSD™ card slot is located in the same
internal area.
When you subscribe to a cellular network, you are provided with a
plug-in Subscriber Identity Module (SIM) card loaded with your
subscription details, such as your personal identification number
(PIN), available optional services, and many other features.
Important!:
The plug-in SIM card contacts and its information can easily be
damaged by scratching or bending, so be careful when handling,
inserting, or removing the card. Keep all SIM cards out of reach of
small children.
To install the SIM card and battery:
1. If the phone is on, press and hold [ ] and select
Power off
to turn it off.
Assembling 7
2.
Remove the back cover.
Tip:
Be careful not to damage your fingernails when you remove the back
cover.
3. Carefully slide the SIM card into the SIM card socket until
the card locks into place.
•
If you do not insert a SIM card, you can only use your phone’s
non-network services and some menus.
•
Do not insert a memory card into the SIM card slot.
4. Insert the battery.
5. Replace the back cover.
Note:
Make sure the card’s gold contacts face into the phone and that the
angled upper-left corner of the card is positioned as shown above.
Note:
If the card is not inserted correctly, the phone will not detect the SIM
card. Re-orient the card in the slot.
8
Installing the Memory Card
Your phone supports the use of a memory card (microSD™) for
data storage of such things as data, music, pictures, and video
files. This type of memory card is designed for use with this mobile
phone and other devices. To store additional multimedia files, you
must insert a memory card. Your phone accepts microSD™ or
microSDHC™ memory cards with maximum capacities of 32 GB
(depending on the memory card’s manufacturer and type).
Note:
Samsung uses approved industry standards for memory cards, but
some brands might not be fully compatible with your phone. Using an
incompatible memory card might damage your phone or the memory
card and can corrupt data stored on the card.
Your phone only supports the FAT file structure for memory cards.
If you insert a card formatted with a different file structure, your
phone will prompt you to reformat the memory card.
•
Frequent writing and erasing of data will shorten the life span of memory
cards.
•
When you insert a memory card into your phone, the file directory of the
memory card will appear in the /sdcard folder.
To install the memory card:
1. Remove the back cover.
2. Insert the microSD card into the slot with the label side
facing down.
3. Push the memory card into the memory card slot until it
locks into place.
Note:
Make sure the microSD’s gold contact pins face upward and that the
card is securely inserted.
4. Replace the back cover.
Removing the memor y card
Before removing a memory card, you must first unmount it for safe
removal.
To remove the memory card:
1. In Idle mode, select
phone storage → Unmount SD card
2. Remove the back cover.
3. Push the memory card gently until it disengages from the
Applications → Settings → SD card and
.
phone.
4. Pull the memory card out of the memory card slot.
5. Remove the memory card.
6. Replace the back cover.
Tip:
Do not remove a memory card while the phone is transferring or
accessing information, as this could result in the loss of data or damage
to the memory card or phone.
Assembling 9
Format the memory card
Formatting your memory card on a PC might cause
incompatibilities with your phone. Only format the memory card on
your phone.
To format the memory card:
Note:
You need to unmount the memory card before it is formatted. In Idle
mode, select
Unmount SD card
•
In Idle mode, select
storage → Format SD card → Format SD card
Tip:
Before formatting the memory card, remember to make backup copies of
all of the important data stored on your phone. The manufacturer’s
warranty does not cover loss of data resulting from user actions.
Applications → Settings → SD card and phone storage →
.
Applications → Settings → SD card and phone
.
Charging the Battery
Before using your phone for the first time, you must charge the
battery. Your phone is powered by a rechargeable Li-ion battery.
The Travel Adapter used to charge the battery is included with
your phone. You can also charge the phone by connecting it to a
PC with a PC data cable.
Note:
Use only Samsung-approved batteries, cables, and chargers.
10
When your battery is low, the phone will emit a warning tone and
display a low battery message. The battery icon will also be empty
and turn red. If the battery level becomes too low, the phone will
automatically power off. Recharge your battery to continue using
your phone.
Note:
Long backlight settings, searching for service, vibrate mode, browser
use, and other variables can reduce the battery’s talk and standby
times.
Note:
You must fully charge the battery before using your phone for the first
time. A discharged battery recharges fully in approximately 4 hours.
Using the Travel Adapter
To charge the battery using the travel adapter:
1. With the battery installed, open the cover of the
multifunction jack at the top of the phone.
Plug the small end of the travel adapter into the
2.
multifunction jack.
Important!:
Verify that the phone’s battery is correctly installed before
connecting the charger. If the battery is not properly installed and
the charger is connected, the phone might power off and on
continuously, preventing proper operation.
Note:
Improperly connecting the travel adapter can cause serious damage to
the phone. Any damage caused by misuse is not covered by the
warranty.
3. Plug the large end of the travel adapter into a power outlet.
•
You can use the phone while it is charging, but it might take longer
to fully charge the battery.
•
While charging, the phone might heat up. This is normal and
should not affect your phone’s lifespan or performance.
•
If your phone is not charging properly, bring it and the
adapter
to a Samsung Service Centre.
travel
4. When the battery is fully charged, unplug the travel adapter
from the phone and then from the power outlet.
Tip:
Do not remove the battery before removing the travel adapter. Doing this
can damage the phone.
Note:
Failure to unplug the wall charger before you remove the battery, can
damage the phone.
Charge with the PC data cable
To charge the battery using the PC data cable:
Before charging, ensure that your PC is turned on.
1. Open the cover of the multifunction jack on the top of the
phone.
2. Plug one end (micro USB) of the PC data cable into the
multifunction jack.
3. Plug the other end of the PC data cable into a USB port on
your PC.
Tip:
Depending on the type of PC data cable you are using, it may take some
time before charging begins.
4. When the battery is fully charged (the battery icon is no
longer moving), unplug the PC data cable from the phone
and then from the PC.
Assembling 11
Attach a hand strap (optional)
To attach a hand strap:
1. Remove the back cover.
2. Slide the hand strap through the slot on the phone and hook
it over the small projection.
3. Replace the back cover.
Switching the Phone On or Off
To turn your phone on:
Press and hold to turn your phone on. An activation screen
launches and the phone automatically searches for a network.
When the network has been found, you can make and receive
calls. When you turn on your phone for the first time, tap the
Android image on the screen and follow the on-screen instructions
to set up your phone for the first time.
12
Note:
The display language is preset to English in the factory. To change the
language, use the Language menu. For more information, refer to
“Locale and text” on page 71.
To turn your phone off:
Press and hold and select
Note:
Follow all posted warnings and directions f rom official personnel when in
areas where the use of wireless devices is restricted, such as airplanes
and hospitals.
Tip:
To only use your phone’s non-network services, switch to Flight mode.
Press and hold and select
Power Off
Flight mode
.
.
Lock or unlock the touch screen and keys
You can lock the touch screen and keys to prevent any unwanted
phone operations.
To lock/unlock the touch screen:
To lock, press . To unlock, turn on the touch screen by
pressing any key and then flick the window with your finger.
Section 3: Getting Started
7
3
2
1
4
5
8
9
6
Features of Your Phone
Your phone is lightweight, easy-to-use and offers many significant
features. The following list outlines a few of the features included
with your phone.
•
The touch screen provides a quick response to a variety of menus and
options.
•
Multitasking
•
User-friendly, menu driven access to features and options.
•
Easy access to the Internet.
•
Built-in Bluetooth technology.
•
E-mail and Instant Messaging capability.
•
microSD™ card compatibility for data storage and access.
•
My Files feature providing access to Files, Games, Voice Recognition,
Alarms, Calendar, Tasks, Calculator, World Clock, Converter, Tip
Calculator, Timer, and Stopwatch.
Front View of Your Phone
1.
Proximity Sensor:
Turns off the phone’s touch screen display
when a call is in progress.
Getting Started 13
2.
7
3
2
1
4
5
6
Light Sensor:
Adjusts the touch screen brightness to suit the
amount of available light in the current location.
3.
Volume Key:
Adjusts the ringer volume while in standby mode
or adjusts the voice volume during a call.
•
When receiving an incoming call, briefly press down either end of
the volume key to mute the ring tone.
•
Press and hold either end of the volume key to reject the call and
send it directly to voicemail.
•
The volume key also adjusts the text size when you are reading a
message or using the web browser.
4.
Home Key:
Returns you to the idle screen or opens a list of
recent applications (press and hold).
5.
Menu Key:
Allows you to access a list of options that are
available on the current screen. It also allows you to open the
Google Search bar (press and hold the key).
6.
Mouthpiece:
7. Back Key: Returns to the previous menu or to the previous
Allows callers to hear you.
page within the Web browser.
8.
Touch Screen:
phone, such as the received signal strength, phone battery
Shows the information needed to operate your
level, time, etc.
9.
Earpiece:
14
Allows you to hear the caller.
Back View of Your Phone
1. Multifunction Jack: Allows you to connect a travel adapter or
other accessories, such as a USB/data cable.
2. Headset Jack: Allows you to connect a hands-free headset for
convenient, hands-free conversations.
3. Camera Lens: Allows you to take pictures and shoot videos
when you are in Camera mode.
Back Cover: Allows you to access to the battery, SIM card,
4.
and memory card.
5. Internal Antenna: Allows the phone to connect to a network.
6. Speaker: Allows you to hear the caller and to hear music or
audio played using your phone.
7. Power Key: Turns the phone on, ends a call, accesses the
quick menus, or locks the touch screen. Press and hold to
access
Silent mode, Flight mode
, and
Power off
.
Display Icons
This list identifies the indicator icons displayed on your phone’s
touch screen:
No signal:
Displays when a signal is not available.
Wi-Fi activated:
Bluetooth activated:
Bluetooth headset connected:
Displays when Wi-Fi is activated.
Displays when Bluetooth is activated.
Displays when a Bluetooth
headset has been paired with the phone.
GPS activated:
Voice call in progress:
Displays when the GPS is activated.
Displays when a voice call is in
progress.
Call on hold:
Indicates that a call is on hold.
Signal strength:
Displays your current signal strength. The
greater the number of bars, the stronger the signal.
GPRS network connected:
Displays when you are
connected to a GPRS network.
EDGE network connected:
Displays when you are
connected to an EDGE network.
UMTS network connected:
Displays when you are
connected to a UMTS network.
Speakerphone activated:
has been activated.
Missed call:
Displays when a call has been missed.
Synchronized with the web:
browsing the web.
Uploading data:
Displays when your phone is uploading
data.
Indicates that the speakerphone
Displays when you are
Getting Started 15
Downloading data:
Displays when your phone is
downloading data.
Call forwarding activated:
Displays when Call Forwarding
is activated.
Connected to PC:
Displays when your phone is connected
to a computer using a supported USB cable connection.
Memory card inserted:
Displays when an internal
microSD™ memory card is detected
No SIM card:
Indicates that a SIM card has not been
installed in the phone.
New text or multimedia message:
Displays when a new
text or multimedia message is received.
New email message:
Displays when a new email message
is received.
New voice mail message:
Displays when a new voicemail
message is received.
Alarm activated:
Displays when you set an alarm to ring
at a specified time.
Event notification:
Displays when an event notification
is received.
16
Roaming:
Displays when you are outside of your service
provider’s normal service area.
Silent mode activated:
is set to
Silent
Displays when the sound profile
or the volume has been manually lowered
below level 1.
Flight mode activated:
Displays when Flight mode is
activated. You cannot send or receive any calls or access
online information.
Vibration activated:
Displays when Vibrate mode is
activated
Music playback in progress:
Displays when music is being
played on your phone.
Error occurred or caution required:
Displays when an error
occurs on your phone.
Battery power level:
Displays the battery’s charge level.
The more bars you see, the more power remains.
Current time:
Displays the current local time.
Using the Touch Screen
Your phone’s touch screen lets you easily select items or perform
functions.
•
To avoid scratching the touch screen, do not use sharp tools.
•
Do not allow the touch screen to come into contact with other electrical
devices. Electrostatic discharges can cause the touch screen to
malfunction.
•
Do not allow the touch screen to come into contact with water. The touch
screen might malfunction in humid conditions or when exposed to water.
•
For optimal use of the touch screen, remove the screen protection film
before using your phone.
•
Your touch screen has a layer that detects small electrical charges
emitted by the human body. For best performance, tap the touch screen
with your fingertip. The touch screen will not react to the touches of sharp
tools, such as a stylus or pen.
To control your touch screen:
•
Tap :
Tap once with your finger to select or launch a menu, option, or
application.
•
Tap and hold:
Tap an item and hold it for more than 2 seconds to open a
pop-up option list.
•
Scroll:
Tap and drag your finger up, down, left, or right to scroll to items
on lists.
•
Drag and drop:
Tap and hold your finger on an item and then drag your
finger to move the item.
•
Double Tap:
Tap twice quickly with your finger to zoom in or out while
viewing photos or web pages.
Your phone turns off the touch screen’s backlight when you do not
use the phone for a specified amount of time. To turn on the
screen, press any key.
To adjust the touch screen’s backlight time:
You can also adjust the backlight time.
•
In Idle mode, select
and display → Screen timeout
Applications
and then select
.
Settings → Sound
Using the idle screen
When the phone is in Idle mode, you will see the idle screen. From
the idle screen, you can view your phone’s status and access
applications and access Google Search.
The idle screen has multiple panels. Scroll left or right to switch
panels. You can also select a dot on the top of the screen to move
to the corresponding panel of the idle screen.
Add items to the idle screen
You can customise the idle screen by adding shortcuts to
applications or items in applications, widgets, or folders.
To add items to the idle screen:
1. Press
→ Add
or tap and hold the empty area of the idle
screen.
Getting Started 17
2.
Select an item category and then select an item:
• Samsung Widgets:
Add Samsung widgets to the idle screen.
(AccuWeather Clock, Buddies now, Calendar Clock, Daily Briefing,
Dual Clock, Feeds and Updates, and Y! Finance Clock.) You can
also select
Samsung Apps
to open the Samsung Apps page and
select from the list.
• Android Widgets:
Add Android widgets to the idle screen.
(Facebook, MySpace Friend Updates, MySpace Search, MySpace
Status Updater, and Picture frame, Power control, Search, Twidroid,
Twidroid Large, Twidroid Small, YouTube.)
• Shortcuts:
Add shortcuts to items. (Applications, Bookmark,
Contact, Direct dial, Direct message, Directions & Navigation,
Google Mail label, and Settings.)
•Folders:
Create a new folder or add folders for your contacts. (New
folder, All contacts, Contacts with phone numbers, Facebook
Phonebook, Received list from Bluetooth, and Starred contacts.)
• Wallpapers:
Set a background image. (Gallery or Wallpaper
gallery.)
Tip:
The options available might vary depending on the current idle screen
mode.
Move items on the idle screen
You can customise the idle screen by moving items to organize
them.
18
To move items on the idle screen:
1. Tap and hold the item that you want to move.
2. When the item turns gray, drag it to a new location.
Remove items from the idle screen
You can customise the idle screen by removing shortcuts to
applications or items in applications, widgets, or folders.
To remove items from the idle screen:
1. Tap and hold the item that you want to remove.
•
The item turns gray and the trash icon appears at the bottom of the
idle screen indicating that Trash mode has been activated.
2. Drag the item to the trash.
3. When the item and the trash turn red, release the item.
Use the shortcuts panel
In Idle mode or while using an application, tap the indicator icons
area at the top of the touch screen and drag your finger down to
open the shortcuts panel. You can activate or deactivate wireless
connection features and access a list of a notifications, such as
messages, calls, events, or processing status. To hide the
shortcuts panel, drag the bottom of the panel up.
In the shortcuts panel, you can use the following options:
•
Wi-Fi:
Activate or deactivate the Wi-Fi connection. For more information,
refer to
“Wi-Fi”
on page 60.
Bluetooth:
•
•
•
Activate or deactivate the Bluetooth connection. For more
information, refer to
GPS:
Activate or deactivate GPS. For more information, refer to
“Locale”
Vibration:
refer to
“Switch to Vibrate mode”
“Bluetooth”
on page 59.
on page 71.
Activate or deactivate Vibration mode. For more information,
on page 20.
Add or remove panels from the idle screen
You can add or remove panels from the idle screen to organise
widgets according to your preferences.
To add or remove panels from the idle screen:
1. In Idle mode, press
2. Select to add new panels or to remove a panel.
3. Press
→ Save
→ Edit
.
.
Access applications
To access your phone’s applications:
1. In Idle mode, select
2. Scroll left or right to display the application screens.
•
You can also select a dot on the top of the screen to move directly to
Applications
to access the application list.
the corresponding main menu screen.
3. Select an application.
•
When you use applications provided by Google, you must have a
Google account. If you do not have a Google account, you will need
to sign up for one.
•
You can add a shortcut to an application by tapping and holding the
application icon in the application list. You can then move the icon to
a new location in the idle screen.
4. Press to return to the previous screen or press to
return to the idle screen.
Your phone has a motion sensor that detects its orientation. If you
are in the portrait view and you rotate the phone while using some
features, the interface automatically switches to the landscape
view. To set the interface to keep its current orientation when you
rotate the phone, select
display → Orientation
Applications → Settings → Sound and
.
Organize applications
You can organize applications in the application list by changing
their order or grouping them into categories to suit your
preferences.
To organize your phone’s applications:
1. In the application list, press
2. Tap and hold an application.
3. Drag the application icon to a new location.
•
You can move an application icon to another main menu screen and
→ Edit
.
you can also move your most-used applications to the applications
bar at the bottom of the screen, next to
4. Press
→ Save
.
Home
.
Getting Started 19
Access recent applications
To access recent applications:
1. Press and hold to open the list of applications that you
have accessed recently.
2. Select the application that you want to access.
Customise your phone
You can customize your phone to suit your preferences.
Set current time and date
To set the current time and date:
1. In Idle mode, select
Date and time
2. Set the time and date and change the other options as
.
Applications
and then select
Settings →
needed.
Turn touch tone on or off
To turn the touch tone on or off:
•
In Idle mode, select
and display → Audible selection
Applications
and then select
.
Settings → Sound
Adjust ringer volume
To adjust the ringer volume:
•
Press the Volume key up or down to adjust the ringer volume.
20
•
In Idle mode, select
and display → Ringer Volume
Applications
and then select
Settings → Sound
. Drag the sliders to set the volume that
will be used for incoming calls and notifications.
Change ringtone
To change your ringtone:
1. In Idle mode, select
Sound and display → Phone ringtone
2. Select a ringtone from the list and select
Applications
and then select
.
OK
.
Settings →
Switch to Silent mode
To use Silent mode to mute or unmute your phone:
•
In Idle mode, select
and display → Silent mode
•
In Idle mode, select
Applications
and then select
.
Phone → Keypad
Settings → Sound
, and then tap and hold #.
Switch to Vibrate mode
Your phone will vibrate when a call, event, or notification is
received.
To use Vibrate mode:
•
In Idle mode, select
and display → Phone vibrate
•
Open the shortcuts panel at the top of the touch screen and select
Vibration
.
Applications
and then select
.
Settings → Sound
Use animations when switching windows
To activate animations when switching windows:
•
In Idle mode, select
and display → Animation → Some animations
•
To turn off the animations, select
and display → Animation → No animations
Applications
and then select
Settings → Sound
or
All animations
Applications → Settings → Sound
.
Set idle screen wallpaper
To change your idle screen wallpaper:
1. In Idle mode, press
Wallpaper gallery
2. Select an image.
3. Select
Set wallpaper
Note:
Samsung is not responsible for any use of default images or wallpapers
provided on your phone.
.
→ Wallpaper
or
Save
and select
.
Adjust the display brightness
To adjust the brightness of the screen:
1. In Idle mode, select
Sound and display → Brightness
2. Drag the slider to adjust the level of brightness.
3. Select
OK
Applications
and then select
.
.
Gallery
or
Settings →
Tip:
The brightness level of the display will affect how quickly the phone
consumes battery power.
Protecting your phone
.
Set an unlock pattern
You can set an unlock pattern to prevent unauthorized people from
using the phone without your permission.
To set an unlock pattern:
1. In Idle mode,
Location and security → Set unlock pattern
2. Follow the on-screen instructions and select
necessary).
3. Draw a pattern by dragging your finger to connect at least 4
dots.
4. Select
5. Draw the pattern again to confirm.
6. Select
Once you set an unlock pattern, you have to use the pattern each
time you turn the phone on or unlock the touch screen. If you do
not want the phone to require the pattern, clear the checkbox next
to
Require pattern
Continue
Confirm
select
.
.
in
Applications
and then select
Location and security
Settings →
.
Next
(if
.
Getting Started 21
Tip:
If you forget your unlock pattern, bring your phone to a Samsung Service
Centre to unlock it.
Note:
Samsung is not responsible for any loss of passwords or private
information or other damages caused by illegal software.
Lock your SIM card
You can lock your phone by activating the PIN supplied with your
SIM card.
To lock your SIM card:
1. In Idle mode,
select
Applications
and then select
Settings →
Location and security → Set up SIM card lock → Lock SIM Card
2. Enter your PIN and select
•
Once the PIN lock has been enabled, you must enter the PIN each
OK
.
time you turn on the phone.
Note:
If you enter an incorrect PIN too many times, your SIM card will be
blocked. You must enter a PIN unlock key (PUK) to unblock the SIM
card.
Tip:
If you block your SIM card by entering an incorrect PUK, bring t he card to
your service provider to unblock it.
22
Activate the mobile tracker
If you phone has been stolen and someone inserts a new SIM
card into your phone, the mobile tracker feature automatically
sends the contact number to specified recipients to help you to
locate and recover your phone.
To use the mobile tracker:
1. In Idle mode,
Location and security → Set Mobile tracker
2. Enter an 8-digit mobile tracker password, enter it again to
select
Applications
and then select
.
confirm it, and then select OK.
3. Select a recipient field and enter a phone number, including a
.
country code (starting with +).
4. Enter the sender's name.
5. Enter a text message that will be sent to the recipient.
6. Select
Save → Agree
.
You can also control the lost phone over the web. Visit
http://www.samsungdive.com
to see detailed information for this
feature.
Enter text
You can enter text by selecting characters on the virtual keypad or
by inputting handwriting on the screen. To enter text in a specific
Settings →
language, you need to change the writing language to one of the
supported languages.
Change the keyboard type
You can change the type of keyboard that you use to enter text.
To use the mobile tracker:
1. Tap and hold the text input field
2. Select
Input method
3. Select a keyboard type:
.
Swype
or
Samsung keypad
.
Enter text using the Swype keyboard
You can enter text by dragging your finger over the keyboard from
one letter to another until the word is complete. The word is
displayed in the text input field as you drag your finger over the
keyboard.
To use the Swype keyboard:
1. Select the first character of a word and drag your finger to the
second character without lifting your finger from the screen.
2. Continue to drag your finger from letter to letter until you have
finished spelling out the word.
Tip:
A blue line appears on the keyboard, joining the letters as they are
selected.
3. Lift your finger after touching the last character. The word is
inserted into the text input field.
4. Repeat steps 1-4 to continue entering text.
Tip:
Tap and hold each key to enter additional characters.
Getting Started 23
You can also use the following keys:
1
2
3
4
5
1
2
4
5
63
Function
Number
1
Change case.
2
Switch between ABC mode and Symbol/Number mode.
3
Clear your input.
4
Start a new line.
5
Insert a space.
Enter text using the Samsung keypad
You can enter text by selecting individual keys or by writing on the
screen.
To use the Samsung keypad:
1. Select and select a text input method:
Keypad, Handwriting box 1
2. Enter text by selecting the alphanumeric keys or by writing on
, or
Handwriting box 2
Qwerty Keypad, 3x4
.
the screen.
You can also use the following keys:
Tip:
To hide the Swype keyboard, press .
Tip:
To view help information about using the Swype keyboard, select .
24
Number Function
1
Change case.
2
Switch between ABC mode and Symbol/Number mode.
